2
Series
Series
EV-2646-NKGQ
2.8~12mm
42 IR LEDs.
1/3” Sony Super HAD II CCD.
600 TV Lines.
Digital Noise Reduction (DNR)
for clear image in low light.
Advanced 32x DSS
(Digital Slow Shutter).
Wall-mount bracket available.
EV-2221-N3BQ
3.6mm, 420TVL
EV-2801-N3BQ
3.6mm, 540TVL
EV-2221-NKBQ
2.8~11mm, 420TVL
1/3” Sony Super HAD II CCD.
18 IR LEDs, up to 50ft (15m) range.
Tamper-resistant design.
Cables concealed in bracket.
Day/Night operation.
EV-2806-NMMQ
2.8~12mm
33 IR LEDs.
1/3” Sony Super HAD II CCD.
600 TV Lines.
Dual voltage: 12VDC/24VAC.
Digital Noise Reduction (DNR).
OSD (On-Screen Display).
360 3-Axis gimbal.
Digital Wide Dynamic Range
(DWDR) for specific light conditions.
Wall-mount bracket available.
Gray base with interchangeable
black and white covers included:
EV-2240-N3B
3.6mm
Excellent daytime
dynamic range.
480 TV Lines provide a crisp,
clear image.
1/4” CMOS sensor.
Small 37/16” (88mm) diameter.
AGC (Automatic gain control).
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
EV-2125-N2WQ
2.9mm
1/3” Sony Super HAD II CCD.
480 TV Lines.
Small size:
3” (76mm) diameter.
Low current draw: 60mA@12VDC.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
1/3” Sony Super HAD II CCD.
360 3-Axis rotation.
Heavy-duty, vandal-resistant.
Cables concealed in bracket
to prevent tampering.
Ceiling, wall-mount, and conduit
box brackets available.
EV-122C-DVB3Q
3.6mm, 24 IR, Gray
EV-122C-DVH3Q
3.6mm, 24 IR, White
EV-122C-DVAVQ
4~9mm, 36 IR, Gray
EV-122C-DVHVQ
4~9mm, 36 IR, White
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP67
1/3” Sony Super HAD II CCD.
Heavy-duty, vandal-resistant.
Dual voltage: 12VDC/24VAC.
Low current draw: 280mA.
Size: 51/2”x41/2” (140x115 mm).
18 IR LEDs.
Wall-mount brackets available.
EV-2186-NKEQ
2.8~11mm, 18 IR, 480TVL
EV-2786-NKEQ
2.8~11mm, 18 IR, 600TVL
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
EV-2166-N3WQ
3.6mm, 18 IR, 420TVL
EV-2766-N3WQ
3.6mm, 18 IR, 540TVL
EV-2166-NVWQ
4~9mm, 21 IR, 420TVL
EV-2766-NVWQ
4~9mm, 21 IR, 600TVL
1/3” Sony Super HAD II CCD.
Heavy-duty, vandal-
resistant design.
Low current draw:
200mA@12VDC.
Size: 41/4”x31/2” (108x85 mm).
Wall-mount brackets available.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
1/3” Sony Super HAD II CCD.
360 3-Axis rotation.
Heavy-duty, vandal-resistant.
Cables concealed in bracket
to prevent tampering.
Ceiling, wall-mount, and conduit
box brackets available.
EV-2706-N3GQ
3.6mm, 24 IR, Gray
EV-2706-N3WQ
3.6mm, 24 IR, White
EV-2706-NFGQ
4~9mm, 36 IR, Gray
EV-2706-NFWQ
4~9mm, 36 IR, White
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP67
33 IR LEDs.
Digital Noise Reduction (DNR).
600 TV Lines.
1/3” Sony Super HAD II CCD.
IR Cut filter.
OSD (On-Screen Display)
with remote.
Service monitor port for
convenient installation.
Advanced 256x DSS
(Digital Slow Shutter).
360 3-Axis rotation.
Dual voltage: 12VDC/24VAC.
2-in-1 Housing, flush or surface mount.
33 IR LEDs.
Wide Dynamic Range (WDR).
690 TV Lines.
OSD with remote.
360 3-Axis rotation.
Dual voltage: 12VDC/24VAC.
2-in-1 Housing, flush or surface
mount:
EV-2876-UKGQ
2.8~12mm
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP68
EV-122C-DVB3Q
EV-2706-N3GQ
EV-2726-N3GQ
EV-122C-DVH3Q
EV-2706-N3WQ
EV-2726-N3WQ
EV-122C-DVAVQ
EV-2706-NFGQ
EV-2726-NFGQ
EV-122C-DVHVQ
EV-2706-NFWQ
EV-2726-NFWQ
EV-2806-NMMQ
EV-2646-NKGQ
EV-2186-NKEQ
EV-2786-NKEQ
EV-2166-N3WQ
EV-2766-N3WQ
EV-2166-NVWQ
EV-2766-NVWQ
EV-DCSGQ
EV-DCSWQ
EV-DCLGQ
EV-DCLWQ
N/A
N/A
N/A
EV-DSSGQ
EV-DSSWQ
EV-DSLGQ
EV-DSLWQ
N/A
N/A
N/A
Model Wall Ceiling
EV-2866-NKGQ
2.8~12mm
Conduit
Box
EV-DWSGQ
EV-DWSWQ
EV-DWLGQ
EV-DWLWQ
EV-2806WM
EV-2086WM
EV-2066WM
Elite 3x
Elite
WDR
WDR (Wide Dynamic Range) for clear images in
strong backlight.
3D-NR (3D Digital Noise Reduction)
for clear images in low light.
700 TV Lines.
Sony 1/3” EXview HAD II CCD,
Sony Effio-P DSP.
IR LEDs for nighttime use.
OSD (On-Screen Display) for
programming special features.
360 3-Axis rotation.
Heavy-duty, vandal-resistant.
Cables concealed in bracket to prevent tampering.
Ceiling, wall-mount, and conduit box brackets
available.
Elite 3x
EV-2726-N3GQ
3.6mm, 24 IR, Gray
EV-2726-N3WQ
3.6mm, 24 IR, White
EV-2726-NFGQ
4~9mm, 36 IR, Gray
EV-2726-NFWQ
4~9mm, 36 IR, White
EV-DDSGQ
EV-DDSWQ
EV-DDLGQ
EV-DDLWQ
N/A
N/A
N/A
Conduit
Drop
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
Armored Ball Turret Camera
Indoor IR Dome Cameras
Mini Vandal Dome Camera
Vandal Dome Camera
Large Vandal IR Dome Cameras
Mid-Size Vandal IR Dome Cameras
Indoor Dome Camera
Vandal Rollerball Cameras (480TVL)
Mounting Brackets
3X Dome Cameras
CCTV
Vandal Rollerball Cameras (600TVL)
3X Vandal Rollerball Cameras
(700TVL)
Flush or Surface Mount
3
Withstands temperatures of -40 ~122 F (-40 ~50 C )
1/3” Sony Super HAD II CCD.
12VDC Operation.
84 IR LEDs for nighttime use.
Weatherproof (IP66).
EV-1826-NKGAQ
2.8~12mm, 600TVL
1/3” Sony Super
HAD II CCD.
Split-glass design
eliminates IR reflection.
Low current draw
(250mA@12VDC
with IRs on).
Up to 50ft (15m)
range.(EV-1026-N2SQ
and EV-1606-N2SQ have
Up to 40ft (12m) range.
EV-1026-N2SQ
2.9mm, 480TVL,12 IR
EV-1606-N2SQ
2.9mm, 600TVL,12 IR
EV-1026-N3SQ
3.6mm, 480TVL,24 IR
EV-1606-N3SQ
3.6mm, 600TVL,24 IR
EV-1026-N6SQ
6mm, 480TVL,24 IR
EV-1606-N6SQ
6mm, 600TVL,24 IR
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
1/3” Sony Super HAD II CCD.
12VDC Operation.
Weatherproof (6mm: IP67, 2.8~12mm: IP66).
Cables concealed in bracket to prevent tampering.
EV-1816-N6GQ and EV-1816-NKGQ only:
OSD functions programmable with controller
(EV-18C -- sold separately).
Able to mount to industry
standard lampholder
cover plate.
EV-1196-N6GQ
6mm, 480TVL
EV-1816-N6GQ
6mm, 600TVL
EV-1196-NKGQ
2.8~12mm, 480TVL
EV-1816-NKGQ
2.8~12mm, 600TVL
EV-1125-N3BQ
3.6mm lens
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
1/3” Sony Super HAD II
CCD.
480 TV lines.
3.6mm Lens.
Weatherproof IP66.
12VDC Operation.
Low current draw: 150mA.
EV-1665-N2BQ
2.2mm
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
600 TV Lines.
12VDC Operation.
1/3” Sony Super
HAD II CCD.
2.2mm Lens
(170 viewing angle).
EV-1186-N3GQ
3.6mm, 480TVL
EV-1806-N3GQ
3.6mm, 600TVL
1/3” Sony Super HAD II CCD.
12VDC Operation.
Heavy-duty, vandal-resistant.
Cables concealed in bracket to prevent tampering.
EV-1806-N3GQ only:
OSD functions programmable with controller
(EV-18C -- sold separately).
Able to mount to industry
standard lampholder
cover plate.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP67
EV-1726-NKGQ
2.8~12mm, 56 IR
EV-1726-NWGQ
6~50mm, 56 IR
1/3” Sony Super HAD II CCD.
Third-generation DSP chip.
600 TV Lines.
Dual voltage: 12VDC/24VAC.
Advanced 256x DSS (Digital Slow Shutter).
OSD (On-Screen Display) for easy programming.
DWDR (Digital Wide Dynamic Range) for clear
images under strong backlighting.
DNR (Digital Noise Reduction)
for clear images in low light.
Programmable 8-zone privacy settings.
Cable concealed in the bracket for extra security.
56 IR LEDs for clear images in total darkness.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
Elite 3x
EV-1626-NKGQ
2.8~12mm, 14 IR
EV-1626-NWGQ
6~50mm, 14 IR
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
1/3” Sony Super HAD II CCD.
600 TV Lines.
Dual voltage: 12VDC/24VAC.
Advanced 256x Digital Slow Shutter.
OSD (On-Screen Display) for easy programming.
DWDR (Digital Wide Dynamic Range) for
clear images under strong backlighting.
DNR (Digital Noise Reduction) for clear images
in low light.
Cable concealed in the bracket for extra security.
Low current draw (310mA with IR LEDs on).
14 IR LEDs for clear
images in total darkness.
Able to mount to industry
standard lampholder cover plate.
Elite 3x
EV-1826-NKGQ
2.8~12mm, 600TVL
1/3” Sony Super HAD II CCD.
12VDC Operation.
Heavy-duty, vandal-resistant.
Cables concealed in bracket to prevent tampering.
OSD Functions programmable with controller
(EV-18C --- sold separately).
Optional Mounting Brackets:
EV-11LR
Large Round Junction Box
EV-11LS
Single-Gang Mounting Plate
EV-18C
Program special features such as DWDR, backlight
compensation, and privacy for the following models:
– EV-1806-N3GQ
– EV-1816-N6GQ
– EV-1816-NKGQ
– EV-1826-NKGQ
Flexible installation allows the
user to program special
features from the installation
site or the control room.
One controller will work for
several cameras.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
Z
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
Weatherproof
for outdoor use
12 and 24-IR LED Bullet Cameras
Wide-Angle Bullet Camera
3X Bullet Cameras
42-IR LED Day/Night Cameras
30-IR LED Bullet Cameras
84-IR LED Day/Night Cameras
Mini Bullet Camera
CCTV
Zeta Series OSD Controller
Low-Temperature
84-IR LED Bullet Camera
Mini 3X Bullet Cameras
2013 SECO-LARM Condensed Catalog
4
EV-5120-N3WQ
3.7mm, 480TVL
Contained in a discreet,
non-functioning PIR
sensor housing.
3.7mm Pinhole lens
(78 viewing angle).
1/3” Sony Super HAD II CCD.
480 TV Lines.
12VDC Operation.
Low current draw: 200mA.
EV-5620-N3WQ
3.7mm, 600TVL
Same as EV-5120-N3WQ, but 600 TV Lines.
EV-5105-N1SQ
1.5mm
Low-profile design —
install on doors, walls, car
bumpers, entryways, and more.
Weatherproof (IP67).
Wide-angle 1.5mm lens.
Includes two stainless-steel mounting
plates (single-gang and slimline),
or use without plates.
¼” Sony Color CCD.
600 TV Lines.
12VDC Operation.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP67 1/4” Sony CCD.
3.5~94.5mm
Varifocal lens.
Up to 432x zoom
(up to 27x optical
zoom and 16x
digital zoom).
Multiple focus
modes.
Up to 360 /second.
high-speed pan/tilt motion.
Manual tilt speed: 120 /second.
Manual pan speed: 300 /second.
On-Screen Display (OSD) programming:
The OSD shows camera status and settings
together with preset target views.
Standard PTZ control: Works with Pelco-D or
Pelco-P compatible controllers via an RS-485 port.
Advanced 128x DSS (Digital Slow Shutter).
Eight Privacy zones.
Flexible programming capabilities:
Up to 128 preset target views, each with its own
characteristics such as white balance and auto
exposure.
Four alarm inputs, two alarm outputs.
Password protected.
Built-in heater and fan.
48W@24VAC (with heater and fan on).
EV-7606-NZWQ
3.5~94.5mm, 560TVL
Seamlessly integrates with
E-941SA-1200, E-941SA-1K2PQ,
and E-941SA-1K2PD.
Wide-angle 1.5mm lens.
¼” Sony Color CCD.
600 TV Lines.
12VDC Operation.
Vandal-resistant design.
EV-6600-N2BQ
2.8mm
1/3” Sony Super HAD II CCD.
Camera is covertly mounted behind
a 12” one-way observational mirror.
2.8mm Lens.
600 TV Lines.
OSD (On-Screen Display)
control to program special
features such as DWDR, backlight
compensation, privacy, and more.
EV-6120-N3WQ
3.7mm, 480TVL
Contained in a discreet,
ceiling-mount housing.
1/3” Sony Super HAD II CCD.
480 TV Lines.
12VDC Operation.
Low current draw: 86mA.
EV-6620-N3WQ
3.7mm, 600TVL
Same as EV-6120-N3WQ,
but wth 600 TV Lines.
3.7mm Pinhole lens.
1/3” Sony Super HAD II CCD.
12VDC Operation.
No exposed screws.
Small size: 3”x115/16” (77x49 mm).
Low-profile design,
extends outward only 1”.
EV-122C-FVB3Q
480 TV Lines
EV-6640-N3WQ
600 TV Lines
EV-4605-N3SQ
3mm
EV-4606-N3SBQ
3mm, 30 IR LEDs
1/3” Sony Super HAD II CCD.
600 TV Lines.
12VDC Operation.
EV-4606-N3SBQ is
similar to EV-4605-N3SQ,
but includes
30 IR LEDs.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
EV-7105-NPEQ
EV7100POLEM
Type
EV-7606CM
Ceiling
Mount
Pole
Mount
Flush
Mount
Corner
Mount
EV-7100FLUSM
EV-7100CORNM
EV-7606-NZWQ
EV-7100CEILM
EV-7606KM
EV-7606PM
N/A
EV-7105-NPEQ
3.8~38mm, 500TVL Color
1/4” Sony CCD.
3.8~38mm
Varifocal lens.
Up to 100x zoom
(max. 10x optical zoom
and 10x digital zoom).
Multiple focus modes.
Max. 360 /second high-speed pan/tilt motion.
On-Screen Display (OSD) programming: The OSD
shows camera status and settings together with the
preset target views.
Standard PTZ control: Works with Pelco-D or
Pelco-P compatible controllers via an RS-485 port.
Advanced 128x DSS (Digital Slow Shutter).
Flexible programming capabilities:
Up to 127 preset target views, each with its
own characteristics such as white balance and
auto exposure.
Built-in heater and fan.
20W@24VAC (with heater and fan on).
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
EV-6610-N2BQ
2.9mm
1/3” Sony Super HAD II CCD.
Camera is covertly
mounted behind a 17”
one-way observational
mirror.
2.9mm Lens.
600 TV Lines.
12VDC Operation.
E-941EC2-N1Q
1.5mm
EV-6640SWQ - Optional
surface-mount bracket.
Model
Patent
pending
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
CCTV
PIR Cameras
Corner-Mount Cameras
Discreet Wall-Plate Camera
17-Inch Mirror Camera
Flush-Mount Ball UFO Cameras
Large PTZ Camera (27x)
Maglock Camera
Covert Ceiling-Mount Cameras
12-Inch Mirror Camera
PTZ Mounting Brackets
Mini PTZ Camera (10x)
5
DR-
104Q
---
4 Channels, 120PPS
DR-108Q
--- 8 Channels, 240PPS
DR-116Q
---
16 Channels, 480PPS
High-resolution recording: D1 (Up to 720x480).
VGA Output (up to 1280x1024) and HDMI® output
(up to 1920x1080).
Free CMS software included.
Free DDNS server.
Dual-stream support.
Twin SATA controller for expandable HDD up to 4TB.
EZ Copy: Simple one-button video export.
Allows simultaneous live view or playback while
recording, transferring, or backing up data.
Supports internal SATA or external USB DVD/RW for
easy backup and video export.
Recording priority programmable per channel for
schedule, alarm, motion, or continuous.
Dedicated audio channel for each video channel.
Two USB 2.0 ports for backup of recorded files
or quick export of recorded video.
RS-485 Control protocols for PTZ cameras.
Network hardware supports 10/100Mbps.
IR Remote control included.
3-Year warranty.
Available without HDD, or with 500GB, 1TB, or 2TB.
EV-8605-H4WQ
5MP Sensor
EV-8626-HVWQ
5MP Sensor, Bullet Camera
EV-8601-HVWQ
5MP Sensor, Dome Camera
1920x1080 Resolution for crystal clear high-definition
video surveillance.
4mm Lens.
42 IR LEDs.
30fps (Frames per second).
1/2” Sony 2.0MP CMOS.
Weatherproof (IP66).
Rugged, vandal-resistant design with no exposed
screws.
12VDC Operation.
EV-H200-N4GQ
4mm, 1920x1080
EV-8605-HZWQ
360° Image
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
1920x1080 Resolution for crystal clear high-definition
video surveillance.
4mm Lens.
42 IR LEDs.
30fps (Frames per second).
1/2” Sony 2.0MP CMOS.
Weatherproof (IP66).
Cables concealed in bracket.
12VDC Operation.
EV-H100-N4GQ
4mm, 1920x1080
1920x1080 Resolution for crystal clear high-definition
video surveillance.
2.8~12mm Lens.
84 IR LEDs.
30fps (Frames per second).
1/2” Sony 2.0MP CMOS.
Weatherproof (IP66).
Cables concealed in bracket.
12VDC Operation.
EV-H101-NMWQ
2.8~12mm, 1920x1080
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
4 Channels
8 Channels
16 Channels
No HDD
DR-104Q
DR-108Q
DR-116Q
500GB
DR-104-500Q
DR-108-500Q
DR-116-500Q
1TB
DR-104-1.0TQ
DR-108-1.0TQ
DR-116-1.0TQ
2TB
DR-104-2.0TQ
DR-108-2.0TQ
DR-116-2.0TQ
Supports H.264 and MJPEG.
High resolution: 1080p, SXGA, 720p, XGA, SVGA, D1,
VGA, CIF.
Supports Power over Ethernet.
IP66 Weatherproof.
10/100Mbps Ethernet interface (RJ45).
Supports Internet Explorer, Firefox, Safari, and Chrome.
Dual voltage: 12VDC/24VAC.
Supports H.264 and MJPEG.
High resolution: 1080p, SXGA, 720p, XGA, SVGA, D1,
VGA, CIF.
Supports Power over Ethernet.
10/100Mbps Ethernet interface (RJ45).
Supports Internet Explorer, Firefox, Safari, and Chrome.
Dual voltage: 12VDC/24VAC.
Captures a 360 image which can be controlled and
panned using an NVR.
High resolution: 1080p, SXGA, 720p, XGA, SVGA,
D1, VGA, CIF.
Supports Power over Ethernet.
10/100Mbps Ethernet interface (RJ45).
Supports Internet Explorer, Firefox, Safari, and
Chrome.
Dual voltage: 12VDC/24VAC.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP66
CCTV
DR-1 Series H.264 Network DVRs
HD-SDI 42-IR LED Dome Camera
Weatherproof IP Cameras Low-Prole IP Dome Camera 360° Panoramic IP Camera
HD-SDI 42-IR LED Bullet Camera HD-SDI 84-IR LED Bullet Camera
Ordering Information:
2013 SECO-LARM Condensed Catalog
6
EVP-124M6P16Q
16 Outputs, 6A Continuous, PTC Fuses
Individual status LEDs.
Individually protected outputs.
Eight outputs are 12VDC.
Eight outputs are 24VAC.
Extra-large enclosure.
EVP-1SA4P4UL
4 Outputs, 4A Continuous, PTC Fuses
EVP-1SA4P9UL
9 Outputs, 4A Continuous, PTC Fuses
EVP-1SA8P16UL
16 Outputs, 8A Continuous, PTC Fuses
Individual red status indicator LEDs for each output.
Main power switch with surge protection.
Includes enclosure and transformer.
Output voltage adjustable to compensate for
voltage drop.
Output fuses rated 1.1 Amp.
Main power switch to turn on/off power to outputs.
Additional power distribution boards also available.
EVP-1SD2P4UL
4 Outputs, 2A Continuous, PTC Fuses
EVP-1SD4P9UL
9 Outputs, 4A Continuous, PTC Fuses
EVP-1SD6P16UL
16 Outputs, 6A Continuous, PTC Fuses
Individual red status indicator LEDs for each output.
Includes enclosure, power cord, and transformer.
Output voltage adjustable to compensate for
voltage drop.
Output fuses rated 1.1 Amp.
Main power switch to turn on/off power to outputs.
Built-in backup battery charger.
Additional power distribution boards also available.
12 Amp supply current.
Universal 100~240 VAC input.
12.6~13.5 VDC output.
High-efficiency switching type.
Ultra-low ripple voltage for improved image quality.
PS-U0406-PULQ
4 Outputs, 6A Continuous, PTC Fuses
PS-U0906-PULQ
9 Outputs, 6A Continuous, PTC Fuses
PS-U1806-PULQ
18 Outputs, 6A Continuous, PTC Fuses
Universal 100~240 VAC input.
12.6.~13.5 VDC Output.
New lightweight, cost-effective design.
High-efficiency switching type.
Ultra-low ripple voltage for improved image quality.
Adjustable output to compensate for voltage drop.
Outputs protected with 2.5 Amp PTC fuses.
Built-in protection against short circuit
and overheating.
Individual channel status LEDs.
Heavy-duty steel case with removable cover.
Dimensions: 10”x73/4”x31/2” (254x196x89 mm).
Main input power fuse.
Includes circuit board only.
PD-4PSQ
4 Outputs, 1.1A each, PTC Fuses, 5A
PD-9PSQ
9 Outputs, 1.1A each, PTC Fuses, 5A
Available from 0.5~5 Amps.
See pg. 18 for details.
PH-A1612-PUQ
16 Outputs, 12A Continuous, PTC Fuses
Field-selectable 24 or 28 VAC outputs, or OFF.
110VAC Input.
12A@24VAC.
Output fuses rated at 3 Amps per channel.
Dual-color LED status indicator for each output
(Blue
---
normal, Red
---
fault, OFF
---
not in use).
Removable terminal blocks for easy wiring.
Rack, wall or desk (stackable) mountable.
Built-in surge protection.
Dimensions (excluding bracket):
13/4”x171/2”x113/8” (44x445x289 mm).
Universal 100~240 VAC input.
12.6~13.5 VDC Output.
High-efficiency switching type.
Adjustable output to compensate for voltage drop.
Outputs protected with 3 Amps PTC Fuses.
Built-in protection against short circuit and
overheating.
Dual-color LED status indicator for each output
(Blue – normal, Red – fault, OFF – not in use).
Dimensions (excluding bracket):
13/4”x171/2”x113/8” (44x445x289 mm).
6 Amp models available.
PH-U1612-PULQ
16 Outputs, 12A Continuous, PTC Fuses
PH-U3212-PULQ
32 Outputs, 12A Continuous, PTC Fuses
PS-U1812-PULQ
18 Outputs, 12A Continuous, PTC Fuses
PS-U3612-PULQ
36 Outputs, 12A Continuous, PTC Fuses
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
12VDC CCTV Power Supplies
Switching CCTV Power Supplies 24VAC CCTV Power Supplies
12VDC/24VAC CCTV Power Supply
High-Amp DC Power Supplies
Power Distribution Boards
CCTV
Rack-Mount DC CCTV Power
Supplies
12VDC Plug-in AC Adapters
Rack-Mount AC CCTV Power Supply
7
Patent
pending
EVT-TB1-42T
Active Video Balun Receiver
Active Video Balun Set
EVT-AB1
EVT-RB1-4T2
Up to 1.5mi (2.4km) with active
receiver. Video, data, and surge
protection. Interlockable.
Includes 12VDC 0.5 Amp power adapter.
Active Video Balun Transmitter
EVT-AH16-VT2Q
16-Port Active Balun Hub
Rack mount or stackable.
Compact enclosure, only 1U (13/4”, 44mm) high.
Video in: 16 (terminal blocks).
Video out: 32 (BNC connectors).
Power input: 12~24 VDC/VAC.
Includes 12VDC 1.5 Amp power adapter.
Current draw: 500mA.
Built-in video and data surge protection.
Transmits up to: 3,000ft (914m) w/ Passive Balun,
1.5mi (2.4km) w/ Active TX.
EB-P501-01Q
Standard Balun
EB-P501-01SQ
Balun with Surge Protection
EB-P501-20Q
Balun with 6” Pigtail
Gold-plated BNC connector.
Transmits up to 1,950ft
(600m) B/W or
1,300ft (400m) color.
Passive operation –
no external power required.
Sleek, new design
with ergonomic grip.
Screw terminals for
easy installation.
Sold in quantities of 10.
EB-P101-24GQ
Built-in ground loop isolator.
Passive operation –
no external power required.
5” Pigtail for flexible
installation.
Transmits up to 1,950ft (600m)
B/W or 1,300ft (400m) color.
Screwless terminals for quick installation.
Built-in surge protection.
Transmits video,
power, and data
over Cat5e/6.
Passive operation –
no external power required.
Transmits up to 1,950ft (600m)
B/W or 1,300ft (400m) color.
Pigtails for flexible installation.
EVT-PB1-L05Q Only: Power converter
with 12~24 VAC/VDC input and 12.6VDC output.
EB-P501-02Q
Patented design includes built-in terminals
for power or data pass-through.
Ergonomic grip.
Gold-plated BNC connector.
Passive operation –
no external power required.
Transmits up to 1,950ft (600m) B/W
or 1,300ft (400m) color.
EB-P101-25WQ
Weatherproof for outdoor use.
Passive operation – no
external power required.
Pigtails for flexible installation.
Transmits up to 1,950ft (600m) B/W
or 1,300ft (400m) color.
Built-in surge protection.
EB-P101-20VQ
DC Plug and DC Jack, Screwless Terminals
EVT-PB1-L05Q
DC Plug, Terminal Blocks, Built-In Power Converter
Transmits up to
1,950ft (600m) B/W
or 1,300ft (400m) color.
Passive operation –
no external power required.
Screwless terminals for
easy installation.
Sold in quantities of 50.
EB-P101-01Q
Basic Balun
EB-P101-20Q
Balun with 6” Pigtail
EB-P104-01Q
Connects up to four CCTV cameras to
a central location using low-cost Cat5e/6 cable.
Transmits up to 1,950ft (600m) B/W
or 1,300ft (400m) color.
Passive operation –
no external power required.
Terminal blocks for easy
installation.
Built-in surge protection.
EB-P116-01Q
Connects up to 16 CCTV cameras to a
central location using low-cost Cat5e/6 cable.
Transmits up to 1,950ft (600m) B/W or
1,300ft (400m) color.
Passive operation – no external power required.
Compact 1U enclosure mounts in a standard 19” rack.
Terminal blocks for easy installation.
Built-in surge protection.
EB-P304-40VQ
4 Channels
EB-P316-60VQ
16 Channels, Rack Mountable
Installs at a
point between
baluns on the
camera end of
an installation and a video transceiver on the DVR
end of an installation.
Video and data signals pass through the unit to a
video transceiver while power enters the unit to
power the CCTV cameras.
EB-P304-41VQ
4 Channels
EB-P316-61VQ
16 Channels, Rack Mountable
Installs near the
DVR and
transmits video
signals while
transmitting power and data to
baluns on the camera end of an installation.
Separate inputs for each channel transmit video
signals to the DVR while transmitting data and power
back to the camera via Cat5e/6 with RJ45 connections.
EB-P304-42VQ
4 Built-in, 12VDC Power Supply
EB-P304-43VQ
4 Built-in, 24VAC Power Supply
4 channels.
Installs near the
DVR and transmits
video signals while
transmitting power
and data to baluns
on the camera end of an installation.
All-in-one solution: Built-in power supply (1A/channel)
to power CCTV cameras.
EB-P101-20VQ
Patented
Passive Video Baluns
Active Video Baluns
Rack-Mount Active Balun Hub
CCTV
4-Channel Passive Video Transceiver
Video, Power, and Data Baluns
Basic Passive Video Baluns
End-Point VPD Combiners with Power
Balun with Data or Power
Pass-Through
Passive Video Balun
with Ground Loop Isolator
Passive Weatherproof Balun
Passive Mid-Point VPD Combiners
Passive End-Point VPD Combiners
16-Channel Passive Video Transceiver
2013 SECO-LARM Condensed Catalog
8
VGA Input resolution:
Up to 1024x768 (DB15).
Output: Composite video
(BNC connector), plus
VGA pass-through (DB15).
VC-2VAQ
Black/Red
Wires
EVA-F5521-3Q
Male DC Plug, pigtail connector, 3ft.
EVA-M5521-3Q
Female DC Jack, pigtail connector, 3ft.
EVA-CB0R1Q
BNC-to-RCA connector.
Gold-plated connectors.
EVA-WB0B1-08Q
6” (15cm) Male-to-female
BNC connector.
Gold-plated BNC connector.
CA-171T
RJ45 to terminal block.
CA-1616Q
DC Plug-to-plug adapter.
CA-1515Q
DC Jack-to-jack adapter.
CA-1526-1FQ
DC Jack-to-double
DC plug, 1ft wires.
CA-161T
DC Plug-to-terminal block.
X-714-046-18B
Hook-and-loop cable tie.
Organize loose cables.
CA-151R
DC Jack-to-terminal block.
CA-1610-3FLQ*
DC Male plug, 3ft (0.9m) wire.
LED Indicates power and polarity.
*Patent
pending
CA-1510-3FLQ*
DC Female jack, 3ft (0.9m) wire.
LED Indicates power and polarity.
CA-1615-06LQ*
DC Jack-to-plug, 6” (152mm) wire.
LED Indicates power and polarity.
DE-S101Q
Extend USB devices over
Cat5e/6 up to 150ft (50m).
USB 1.1 compliant.
Output: Four RS-485 connectors.
Range: Up to 3,937ft (1,200m).
Connect up to 64 cameras
or devices via RS-485.
Power adapter included.
RD-304-D1Q
EVA-RS1
Connects up to 32 devices.
Range: Up to 3,937ft (1,200m).
DB9 Female connector for
RS-232 and 2-wire removable
terminal block for RS-485.
VA-1102B-WQ
1 Input, 2 Outputs
VA-1104B-WQ
1 Input, 4 Outputs
Distributes single video input to multiple video outputs
.
Compatible with color or black/white signals.
Transmits up to 984ft (300m).
NTSC or PAL compatible.
Voltage: 12VDC or 24VAC.
12VDC Power adapter included.
Power loop-out
(VA-1102B-WQ only).
Gold-plated BNC connectors.
VA-2101B-WQ
1 Input, 1 Output
VA-2404B-WQ
4 Inputs, 4 Outputs
Video amplifier compensates
for video loss.
Brightness and sharpness
adjustments for each channel.
NTSC or PAL compatible.
Transmits up to 3,280ft (1,000m).
12VDC Power adapter included.
Power loop-through to
power nearby devices.
Now with VESA
Mount
Converts almost any LCD
monitor into a security monitor.
Video input auto-configure.
On-screen display (OSD).
Desktop, VESA, or wall
mountable.
Compact size, for
plug-and-play installation.
5VDC Power adapter included.
Output: NTSC: 640x480,
PAL: 768x576.
High resolution, up to 1280x1024 NTSC.
BNC Pass-through output.
Stores settings in case of power loss.
Smaller size.
VC-3BAQ
Similar to VC-1BAQ, but with:
VC-1BAQ
MVM-T1601-1Q
3 Inputs, 6 Outputs
BNC connectors.
Each output can easily switch
to any of the video sources.
Frequency: 672Hz~27MHz.
100mA@12VDC.
VS-1V12BQ
Protects the camera
from surges of electricity.
BNC Male input,
BNC Female output.
VG-1C12BQ
Gold-plated BNC connector.
Passive operation ---
No external power required.
High immunity to interference
--- Built-in impedance-coupled
device and noise filter.
BNC terminals for easy installation.
DE-A101Q
1-In, 1-Out
DE-A104Q
1-In, 4-Out
Extend USB devices over
Cat5e/6 up to 300ft (100m).
USB 2.0 compliant.
Surge protection for
PoE (Power over
Ethernet) devices.
RJ45 Connections.
IPV-P188Q
Surge protection for
HD-SDI devices.
BNC Male input,
BNC Female output.
VS-1V22AQ
BNC to VGA Converters
VGA to BNC Converter
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
DC Pigtail Connectors
CCTV Accessories
Illuminated Power Connectors
Passive USB over Cat5e/6
Data Distributor
Ground Loop Isolator
RS-232 to RS-485 Converter
Video Distributors
Video Amplifiers
CCTV
Video Matrix
Video Surge Protector
Active USB 2.0 over Cat5e/6
PoE Surge Protector
HD-SDI Surge Protector
9
*
SK-910RC4Q
5 Relay Outputs
Four relays, one per
channel, each 10A@24VDC.
Outputs are programmable for
timed (1, 2, 3, 4, 5, 10, 30, or 60 secs),
toggle, latching, or validity modes.
Auxiliary 12VDC relay output (wet contact):
1sec~10min adjustable via built-in potentiometer.
Compatible with all SECO-LARM 315MHz transmitters.
Power adapter included.
Optional central receiver accessories include:
Weatherproof transmitter (SK-919TPWFEUQ).
Wireless LED siren (SK-910RSQ).
Wireless magnetic contacts (SM-93T19Q).
Wireless PIR sensor (E-9908-1T19Q).
315
MHz Up to
500ft
*
For remote
activation of locks,
cameras, etc.
from a desk or
other location.
Use in offices,
factories, etc.
Portable, attractive,
heavy-duty aluminum
case.
Includes rechargeable battery and power adapter.
Compatible with all SECO-LARM 315MHz receivers.
SK-919TP2D-P
2-Button Desktop Transmitter
SK-919TP2D-F
2-Button Footswitch Transmitter
315
MHz
Up to
500ft
20ft Sensing range.
Pet immunity.
VD-40BN
Dummy PTZ
Speed Dome
with Flashing LED
VD-40BNA
Dummy Mini PTZ
Speed Dome
with Flashing LED
VD-30BNA
Dummy Bullet
Camera with Flashing
LED
VD-20BNB
Dummy Mini Dome
with Flashing LED
VD-20BN
Dummy Ball-Mount
Dome with
Flashing LED
VD-10BNA
Dummy Box
Camera with
Flashing LED
VD-10BN
Dummy Security
Camera with
Flashing LED
VD-30BS
Dummy IR Bullet
Camera with
Flashing LED
VD-10PL
Dummy IR Bullet
Camera with
Working IR LEDs
VD-20BNA
Dummy Dome
Camera with
Flashing LED
*
315
MHz
SK-919TPWFEUQ
Weatherproof Transmitter
Similar to the SK-919TDWS-BU.
(See pg. 10)
With terminal blocks.
Weatherproof (IP65).
Indoor/outdoor use.
E-9908-1T19Q
Wireless PIR Sensor
Up to
500ft
SM-93T19Q
Wireless Magnetic
Contacts
Weatherproof (IP65).
Indoor/outdoor use.
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP65
SK-910RSQ
Wireless LED Siren
Audible alarm sounds
when triggered.
Flashes LED to alert
user when triggered.
Weatherproof.
27
MHz
Monitors up to three zones
per premises or vehicle,
plus manual paging.
Connect to burglar
or communications
panels.
Range:
Up to 1/2 mile* (0.8km).
Includes belt-clip
vibrating receiver (E-37RV).
E-37ANT
Use as an alternative to AM or CB antenna.
E-37EV
E-37RV
Extra belt-clip vibrating receiver.
Transmits an IP
signal or any other
TCP/IP signals over
existing coax cable.
Supports PoE (Power over Ethernet).
Distance: Up to 5,900ft (1,800m).
5VDC Adapter included.
IPB-A1200Q
Ethernet over Coax
with Power
Identical to
IPB-A1200Q, but
uses Cat5e/6 cable
instead of coax.
Distance: Up to 3,900ft (1,200m).
5VDC Adapter included.
IPB-A1100Q
Ethernet Extender
Extend the range of
power and data
up to 984ft (300m).
No external power required.
IPR-P188Q
PoE Repeater
*Actual range may vary greatly depending on the installation and operating environment.
Central Receiver
Alarm Pager System
RF Wireless Controls
Series Dummy Cameras
Ethernet Extenders
Wireless
CCTV
2013 SECO-LARM Condensed Catalog
10
*
*
*
~
~
~
~
~
~
~
~
~
SK-910RBQ
SK-910RAQ, SK-910RAV
External or internal battery power.
External or internal triggering.
Use to make almost any security output wireless.
Other specifications similar to SK-919TD1S-UP.
SK-919TDWS-BU
SK-910RBQ
11~24 VAC/VDC, 10A@24VDC relay output
SK-910RAQ
Mini size, 11~24 VAC/VDC, 3A relay output
SK-910RAVQ
Mini size, 3~13.8 VDC, 5A transistor ground output
SK-919TD1S-UP
Factory pre-coded
SK-919TT1S-BU
DIP Switch coding
Sample Application:
Make push-to-exit plate
or keypad wireless.
Leather pouch for SK-919TD1S-UP
& SK-919TT1S-BU.
Control garage doors, house lights, etc.
Output is programmable for 4sec momentary
(default), 1sec momentary, toggle, or validity.
(SK-910RBQ also features a latching mode.)
LED Indicates RF reception, learn mode entered,
transmitter learned, memory cleared.
Over 68 billion possible codes.
LED Transmission indicator.
SK-915LP
Similar to SK-910RBQ, but 433.92MHz. Special
order item.
SK-910R-4Q
SK-939TS1S-B
Same as SK-919TT1S-BU,
but 433.92MHz. Special
order item.
315
MHz Up to
500ft *
SK-910RAV2Q
SK-910RB2Q
SK-910RB2Q
11~24 VAC/VDC, 2 x 10A@24VDC relay outputs.
SK-910RAV2Q
Mini size, 3~13.8 VDC,
2 x 3A transistor ground outputs.
Each output independently configurable
(SK-910RB2Q only).
Outputs are programmable for 4sec momentary
(default), 1sec momentary, toggle, or validity.
(SK-910RB2Q also features a latching mode.)
Two LEDs indicate RF reception, learn mode entered,
transmitter learned, memory cleared.
SK-910R2-4Q
Similar to SK-910RB2Q, but 433.92MHz.
Special order item.
315
MHz Up to
500ft *
Control garage doors, house lights, etc.
Outputs are programmable for timed (1, 2, 3, 4, 5, 10,
30, or 60 seconds), toggle, latching, or validity modes.
Individual channel status LEDs indicate RF reception,
learn mode entered, transmitter learned, and memory
cleared.
315
MHz Up to
500ft
315
MHz Up to
500ft
*
SK-919TD2A-UP
Factory pre-coded,
over
68 billion
possible codes
SK-919TD2A-U
Uncoded, over 68 billion
possible codes
SK-917T2A-UQ
CODEBUMP™ codehopping
technology, 18 quintillion codes
SK-915BA
12VDC Battery for all
transmitters except handheld.
SK-939TS2A-PQ
Same as SK-919TD2A-UP, but 433.92MHz.
Special order item.
315
MHz Up to
500ft
*
SK-919TP4J-NUQ
Factory pre-coded.
Over 68 billion possible codes
SK-917TP4J-NU
CODEBUMP™ codehopping
technology, 18 quintillion codes
LED Transmission indicator.
SK-939TS4J-NU
Same as SK-919TP4J-NUQ, but 433.92MHz.
Special order item.
315
MHz Up to
500ft
*
Extreme durability ¯ Rubber buttons eliminate
damage caused by electrostatic discharge.
Gold-plated battery clips and contact points extend
the life of the transmitter.
Includes two 3VDC lithium batteries and visor clip.
Slimline design: 31/2”x23/16”x1/2” (89x56x12 mm).
SK-919TP1H-BUQ
--- 1 Button, 1 Channel
SK-919TP2H-NUQ
--- 2 Buttons, 3 Channels
SK-919TP4H-NUQ
--- 4 Buttons, 15 Channels
SK-9HBC
Belt-clip holster for slimline handheld transmitters
X-930-089
3VDC Lithium battery for
handheld transmitters
Belt-Clip Holster
315
MHz Up to
500ft
315
MHz
Up to
500ft
*Actual range may vary greatly depending on the installation and operating environment.
SK-91ERSD
Up to 1,000ft* (300m) range max.
Extends the range of SECO-LARM RF receivers.
Plugs into the receiver.
315
MHz
Same as SK-919TDWS-BU, but 433.92MHz.
Special order item.
SK-939TDW-BUQ
SK-910R3Q
3 Channels
SK-910R4Q
4 Channels
LED Transmission indicator.
SK-919TP3JRUQ
Factory pre-coded.
Over 68 billion possible codes
SK-917TP3J-RU
CODEBUMP™ codehopping
technology, 18 quintillion codes
SK-910R4-4Q
Similar to SK-910R4Q, but 433.92MHz.
Special order item.
315
MHz *
Up to
500ft
SK-910R4Q
1-Channel Receivers 2-Channel Receivers 3 and 4-Channel Receivers
1-Button Transmitters
2-Button Transmitters
Slimline Handheld Transmitters
Wired 1-Button Transmitter
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
4-Button Transmitters
Extended Range Antenna
Wireless
3-Button Transmitters
11
Magnet can be reversed in the housing for right-hand
or left-hand swinging doors.
For indoor use, similar to the 600-lb and 1,200-lb
single-door maglocks.
Anodized aluminum (US28).
Optional mounting brackets:
E-941S300R/LQ: “L” bracket
E-941S300R/ZQ: “Z” and “L” bracket
E-941S300R/UQ: “U”, “Z”, “L” bracket
E-941SA-300RQ
For indoor and outdoor applications.
Weatherproof.
3ft (0.9m) Hookup wire included.
Input voltage
—
12VDC.
Anodized aluminum (US28).
No residual magnetism.
E-941SA-300
Outdoor
Indoor
E-941DA-600Q
600-lb Holding force for each door.
12 or 24 VDC (selectable).
Anodized aluminum (US28).
No residual magnetism.
MOV surge protection.
Adjustable mounting bracket.
Complete mounting hardware for typical installations.
Detachable faceplate.
Built-in dual-colored status LED and bond sensor to
show locking status (E-941DA-600PQ only).
UL Listed.
“L” , “Z” and “U” Brackets available for easy mounting
(see pg. 12).
Double-Door, 600-lb, UL
Listed
E-941DA-600PQ
Double-Door, 600-lb,
Bond Sensor, LED, UL
Listed
Indoor
1,200-lb Holding force for each door.
12 or 24 VDC (selectable).
Anodized aluminum (US28).
No residual magnetism.
MOV surge protection.
Adjustable mounting bracket.
Complete mounting hardware for typical installations.
Detachable faceplate.
Built-in dual-colored status LED and bond sensor to
show locking status (E-941DA-1K2P only).
UL Listed.
“L” , “Z” and “U” Brackets available for easy mounting
(see pg. 12).
E-941DA-1K2Q
Double-Door, 1,200-lb, UL Listed
E-941DA-1K2P
Double-Door, 1,200-lb,
Bond Sensor, LED, UL Listed
Indoor
Anodized aluminum housing (US28).
12 or 24VDC (selectable).
No residual magnetism.
MOV surge protection.
Adjustable mounting bracket.
Complete mounting hardware for typical installations.
Detachable faceplate.
Built-in dual-colored status LED and bond sensor to
show locking status (E-941SA-600PQ only).
UL Listed.
“L” , “Z” and “U” Brackets available for easy
mounting (see pg. 12).
E-941SA-600
600-lb Holding Force, UL Listed
E-941SA-600PQ
600-lb Holding Force,
Bond Sensor, LED, UL Listed
10 SECO-LARM
maglocks now
UL listed.
Indoor
Anodized aluminum housing (US28).
12 or 24 VDC (selectable).
No residual magnetism.
MOV surge protection.
Adjustable mounting bracket.
Complete mounting hardware for typical installations.
Detachable faceplate.
Built-in dual-colored status LED and bond sensor to
show locking status (E-941SA-1K2PQ and
E-941SA-1K2PD only).
UL Listed (E-941SA-1200 and E-941SA-1K2PQ only).
“L” Bracket and “Z” brackets available for easy
mounting (see pg. 12).
E-941SA-1200
1,200-lb Holding Force, UL Listed
E-941SA-1K2PQ
1,200-lb Holding Force,
Bond Sensor, LED, UL Listed
E-941SA-1K2PD
1,200-lb Holding Force, Bond Sensor, LED,
Timer 1~78 sec (not UL Listed)
Indoor
1,200-lb Single-Door Maglocks
1,200-lb Double-Door Maglocks
300-lb Electromagnetic Locks
All SECO-LARM Electromagnetic
Locks come with a Lifetime
Warranty. For details, please
contact SECO-LARM.
For small, low-security drawers or cabinets.
Holding force:
80-lb (36kg)@12VDC
110-lb (51kg)@24VDC.
12 or 24 VDC.
Anodized aluminum (US28).
No residual magnetism.
E-941SA-80Q
Indoor
LIFETIME WARRANTY
80-lb Electromagnetic Lock
600-lb Single-Door Maglocks
600-lb Double-Door Maglocks
Access
2013 SECO-LARM Condensed Catalog
12
E-942F1300/ZQ
(for E-942FC-1300)
E-942F-600/Z
(for E-942FC-600)
“Z” Brackets
E-942F-1300/L
(for E-942FC-1300)
E-942F-600/L
(for E-942FC-600)
“L” Brackets
E-941S-600/ZQ
(for 600-lb series locks)
E-941S-1K2/ZQ
(for 1,200-lb series locks)
E-941S300R/ZQ
(for E-941SA-300RQ)
“L” Brackets
E-941S-600/LQ
(for 600-lb series locks)
E-941S-1K2/LQ
(for 1,200-lb series locks)
E-941S300R/LQ
(for E-941SA-300RQ)
“U” (Glass Door) Brackets
E-941S-600/UQ
(for 600-lb series locks)
E-941S-1K2/UQ
(for 1,200-lb series locks)
E-941S300R/UQ
(for E-941SA-300RQ, includes
“Z”, “L”, and “U” brackets)
“Z” Brackets
Plate Spacers
Armature Plate Holder
E-941S-600/HQ
(for 600-lb series)
E-941S-1K2/HQ
(for 1,200-lb series)
Both the E-941S-600/UQ and E-941S-1K2/UQ are
adjustable for 9~13 mm glass.
E-941S-300/PQ
(for E-941SA-300)
E-941S300R/PQ
(for E-941SA-300RQ)
E-941S-600/PQ
(3/16” for 600-lb series)
E-941S-1K2/PQ
(1/4” for 1,200-lb series)
E-941D-600/PQ
(for 600-lb double-door)
E-941D-1K2/P
(for 1,200-lb double-door)
“L” Brackets are also available for special-use mounting
applications where space is insufcient for the mounting
of the magnet.
All of the above include one “Z” bracket and one “L”
bracket for mounting on in-swing doors.
The “Z” bracket consists of two parts and is adjustable
for exible positioning of the armature plate. Also
includes cover plate to hide mounting screws
(excludes E-941S300R/ZQ).
The E-941S-600/HQ and E-941S-1K2/HQ can be used
to mount the armature plates to a metal-core door or
provide extra security for the armature plate.
For sliding or swinging gates.
Holding force: 1,300-lb (591kg).
Water- and vandal-resistant.
Dual-threaded conduit fitting.
E-942FC-1300
1,300-lb Holding Force
61/2 ft Hookup cord.
12 or 24 VDC.
"Z" and "L" brackets available.
E-942FC-600
600-lb Holding Force
For sliding or swinging gates.
Holding force: 600-lb (272kg).
Water- and vandal-resistant.
Dual-threaded conduit fitting.
61/2 ft Hookup cord.
12 or 24 VDC.
"Z" and "L" brackets available.
Outdoor
Outdoor
E-942FC-1K3SQ
1,300-lb Holding Force
E-942FC-600SQ
600-lb Holding Force
Includes E-942FC-1300 gate lock with brackets for
lock and armature.
For outdoor sliding or swinging electric gates.
Weld or bolt brackets directly to gate.
Corrosion-resistant, zinc-plated brackets.
Black finish matches most gates.
Lock is water-resistant and vandal-resistant.
Adapter and mounting hardware included.
Same as E-942FC-1K3SQ, but 600-lb holding force
and smaller profile.
(Magnetic lock portion only)
(Magnetic lock portion only)
Outdoor
Outdoor
SA-025EQ
12~24 VDC Operation.
Lock control relay (SPDT):
10A@24VDC.
Remote alarm relay (SPDT):
10A@24VDC.
Local alarm, transistor
ground output.
Three relocking modes via jumper:
—Standard (preset) —BOCA —Timed
SA-027WQ
7-Day Timer
7-Day timer.
12~24 VAC/VDC.
One NO or NC Form C
relay: 10A@120VAC / 28VDC.
Can be programmed for 60 events.
One egress input.
Output can be toggle or momentary, and
can be programmed for 1~99 seconds.
Manual mode button.
SA-027Q
Annual Timer
365-Day annual timer.
12~24 VAC/VDC Operation.
Two NO or NC Form C relays:
10A@120VAC / 28VDC.
Each relay can be programmed for 50 events,
total of 100 individual programmable events.
100 Programmable events can be set weekly,
daily or hourly 365 days a year.
One egress input per relay (two total).
Output can be toggle or momentary, and
can be programmed for 1~99 seconds.
Easy
Programming
Electromagnetic Gate Locks Gate Lock Mounting Brackets
Gate Locks with Weldable Brackets
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
Maglock Mounting Brackets
Access
Programmable Annual Timer
Delayed Egress Timer
Programmable 7-Day Timer
13
One output: Form C
relay output (5A@28VDC).
100 Unique 4~8 digit codes.
Stainless-steel faceplate.
Easily delete individual codes.
Programmable wrong-code lockout.
Programmable output relay
activation buzzer.
Relay output inhibit control.
SK-1011-SQ
SK-1131-SQ
Similar to SK-1011-SQ, but with:
120 User codes, three outputs, backlit
keys, mantrap, alarm output,
door- forced-open warning,
door- propped-open warning duress
output, door auto relock, and other
advanced features.
Auto or manual-code entry checking.
Egress input.
Built-in tamper (N.C.) circuit.
EEPROM Memory: Prevents data loss.
Power: 12~24 VAC/VDC.
Backbox included.
Limited lifetime warranty.
Three outputs:
--
Main relay: Form C, 5A@28VDC.
--
Aux. relay: Form C, 1A@28VDC.
--
Transistor ground output (100mA@24VDC).
120 Unique 4~8 digit codes.
Backlit keyboard is easy to use at night.
Three LEDs can be wired as needed.
Alarm output, mantrap, and door auto-relock features,
plus much more.
Backbox included.
Limited lifetime warranty.
(Keys are backlit)
Similar to SK-1323-SDQ, but with proximity reader.
Rugged construction: Heavy-duty stainless-steel
faceplate with a coated steel backing.
Up to 210 user codes.
Code flexibility: Codes can be four or five digits long.
Dual voltage: 12~24 VAC/VDC operation.
Two Form C relays rated 12A@14VDC.
Door sensing input allows for anti-tailgating operation.
Overhead LEDs and programmable backlit keys for
easy use in the dark.
Each relay output can be set from 1~99 seconds or
toggle.
Wrong code lockout: After three wrong codes are
entered, the keypad will go into lockdown for 55 secs.
All features are programmed directly from the keypad
— no need for an external programmer.
EEPROM Memory protects programmed information
in case of power loss.
Tamper switch: N.C. dry contact,
3A@125/250 VAC.
Egress / push button input.
SK-3523-SDQ
PR-K1S1-A
Additional cards sold
in packs of 10.
EM-125 Format.
PR-K1K1-AQ
Proximity keyfobs. Sold in packs of 10.
EM-125 Format.
PR-K1S1-A and PR-K1K1-AQ are compatible
with all SECO-LARM proximity reader products.
10 Cards included.
Sealed and weatherproof (IP67).
Mounts easily to interior or
exterior walls.
Up to 100 users.
Output relay for timed (1~180 sec) or latch mode.
Egress input for simple exiting of protected area.
Tri-color wave-shaped LED status bar indicates
proximity reader’s mode and status.
Blue : On/Valid Card indicator.
Green: Programming Mode.
Red: Invalid Card.
PR-112S-A
W
e
a
t
h
e
r
p
r
o
o
f
f
o
r
o
u
t
d
o
o
r
u
s
e
IP67
SK-1123-SQ
Surface Mount
, 2 Outputs:
5A@28VDC (relay),
1A@28VDC (relay)
110 User codes.
During the day, keypad illumination can be
dimmed or turned off during standby.
Tamper switch, security screws, and heavy-duty
construction.
Each output can be programmed for momentary
(1~999 sec) or toggle.
Each code can be programmed for 4~8 digits.
Egress input for exiting the protected premises.
12~24 VAC/VDC.
Fits standard single-gang electrical box
(SK-1123-FQ).
Limited lifetime warranty.
SK-1123-FQ
Flush Mount
, 2 Outputs:
5A@28VDC (relay),
100mA@24VDC (transistor)
SK-2323-SDQ
Mullion-Style Keypad
1,010 Users.
12~24 VAC/DC operation.
Two Form C relay outputs.
Each relay has programmable output
time from 1~99 seconds or toggle.
Rugged, weatherproof design.
Backlit keys for easy nighttime use.
Two egress inputs.
Door sensor input.
Built-in tamper sensor.
All features are programmed from the keypad.
Circuitry is potted with epoxy for outdoor use.
SK-2323-SPQ
Mullion-Style Keypad with
Built-In Proximity Reader
Similar to SK-2323-SDQ, but with proximity reader.
Three programmable access modes --- proximity
card only, proximity card or user code access, or
combined proximity card with user code access.
Compatible with all SECO-LARM proximity cards.
SK-1323-SPQ
Sealed-Housing Stand-Alone
Keypad with Built-In Proximity Reader
SK-1323-SDQ
Sealed-Housing
Stand-Alone Keypad
Features similar
to SK-2323-SDQ.
SK-2323-SDAQ
Mullion-Style
Piezoelectric Keypad
Same as SK-2323-SDQ, but with
the following additional features:
--
Piezoelectric touch keys
(can be pressed with gloves on).
--
Lower profile.
SK-2323-SPAQ
Mullion-Style Piezoelectric
Keypad with Built-In Proximity Reader
Similar to SK-2323-SDAQ, but with proximity
reader.
KD-100Q
Dummy Keypad
Keypad LEDs flash.
Keypad “beeps” when
keys are pressed.
Weather-resistant for
outdoor use.
Uses two or four (AAA) batteries.
Indoor Access Control KeypadsOutdoor Access Control Keypads
Stand-Alone Proximity Reader
Proximity Cards and Keyfobs
Heavy-Duty Outdoor Keypad
Outdoor Access Control Keypads
CBA Series Dummy Keypad
Access
2013 SECO-LARM Condensed Catalog
14
Surface-type door closer.
Non-handed operation.
Separate adjustment of
both closing and latch
speeds.
SD-C141S
For use in wood doors.
Baked painted finish.
SD-995C
SD-994C
SK-990AQ
Fail Secure
Similar to SD-995C, but for use in wood doors.
SD-994C24
Same as SD-994C, but 24VDC.
ANSI-sized:
SD-995C/SD-995C24 —
47/8"x11/4"x11/4" (124x32x32 mm).
SD-994C/SD-994C24 —
715/16"x17/16"x13/8" (202x36x32 mm).
Reversible for right-hand or left-hand doors.
Jaw strength: 2,000-lb.
Stainless-steel lip (keeper) for strength and
long life.
Non-polarized connection.
SD-995C24
Same as SD-995C, but 24VDC.
Current draw: 150mA@24VDC.
For use in metal doors.
Field-programmable in seconds
for fail-secure or fail-safe operation.
Power-off locking. Power unlocking.
For entrance doors.
SK-990BQ
Fail Safe
Power locking.
Power-off unlocking.
Current draw: 250mA@12VDC.
UL 1034 Burglary.
Field-selectable for fail-safe or fail-secure operation.
Field-selectable dual-voltage: 12/24 VDC.
Powered by a solenoid.
Reversible, non-handed design fits either right-hand
or left-hand doors.
Low profile: Strike is only 11/4” (32mm) deep.
Includes three faceplates for nearly any type of door.
SD-996C-NUQ
Includes 3
faceplates
Fail Safe/
Fail Secure
12/24 VDC
SD-993B-SS
1,500-lb
Shear Lock
SD-993S-UB
“U” Bracket
Bracket for mounting
on most glass doors.
SD-993S-SB
Surface-Mount Bracket
Holding force:
1,500-lb (680kg).
Small size for use with most metal door jambs.
Works with sliding, single-action, and
double-action (swing-through) doors and gates.
Fail-safe operation.
12 or 24 VDC.
For surface mounting of
shear lock (when recessed
mounting is not possible).
Fail-secure
operation
Fail-safe
operation
For concealed mounting.
5/8” (17mm) Bolt extension.
Fail-safe operation (unlocks when power is lost).
12VDC Input.
Narrow design:
77/8"x15/16" (200x32 mm).
Door-position monitoring output (NO/NC/COM).
Similar to SD-997BQ,
but fail-secure
(locks when power
disconnected).
Incorporates manual
lock/unlock cylinder
to operate the
SD-997A-DQ if power is lost.
SD-997BQ
SD-997A-DQ
Manual
lock/unlock
cylinder
Lock
knob
SD-997SMB-AQ*
Surface-mount
bracket set for
SD-997BQ.
SD-997UB-AQ*
“U” Bracket for SD-997BQ for glass doors.
*Use with SD-997BQ only.
SS-090KN Series
Extra keys. Specify
number when ordering.
SS-090 Series
Two terminals, shunt SPST.
Maintained ON/OFF, key removable
from both ON and OFF positions.
Specify key number when ordering.
SS-095 Series
Two terminals, momentary SPST.
Maintained OFF, springs back from
ON, key removable from OFF only.
Specify key number when ordering.
SS-090-1H0
Similar to SS-090, but key removable
in OFF position only (key #1300 only).
SS-092-2A0
Two internal SPST switches,
one always ON, one always
OFF (key #1300 only).
(N.O., Turn to Close)
SS-090-2H0 SS-095-1H0 SS-090KN-0 1300
SS-090-2H1 SS-095-1H1 SS-090KN-1 1301
SS-090-2H2 SS-095-1H2 SS-090KN-2 1302
SS-090-2H3 SS-095-1H3 SS-090KN-3 1303
SS-090-2H4 SS-095-1H4 SS-090KN-4 1304
SS-090-2H5 SS-095-1H5 SS-090KN-5 1305
SS-090-2H6 SS-095-1H6 SS-090KN-6 1306
SS-090-2H7 SS-095-1H7 SS-090KN-7 1307
SS-090-2H8 SS-095-1H8 SS-090KN-8 1308
SS-090-2H9 SS-095-1H9 SS-090KN-9 1309
SS-090-2HX SS-095-1HX SS-090KN-X 1310
SS-090 SS-095 SS-090KN Key #
Electric Deadbolts
Door Closer
Electric Door Strikes
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
R-T-E Key Switch Plates
SD-72051-V0
Shunt switch, shunt ON/momentary
OFF, single-gang plate.
SD-71051-V0
Same as SD-72051-V0, but slimline.
SD-72002-V0
Shunt switch, maintained ON/OFF,
single-gang plate.
SD-71002-V0
Same as SD-72002-V0, but slimline.
SS-199Q
Stainless-steel slimline plate
with 3/4” D-hole.
SS-299Q
Stainless-steel plate
with 3/4” D-hole.
(N.C., Turn-to-Open, Pre-Wired Switches)
Remote Plates
Key Locks
Electric Shear Lock
Access
Universal Door Strike
15
SD-927PKC-NEQ
No Touch --- Just wave a
hand in front of the sensor.
Sensing range up to 4" (10cm).
Attractive "ring" illuminator turns
from
red to green or green to red (selectable)
on sensor activation.
Reduces risk of cross contamination.
Reliable IR technology senses motion.
SD-927PKC-NSQ
Same as SD-927PKC-NEQ,
but in Spanish.
SD-927PWCQ
Same as SD-927PKC-NEQ,
but with white plate and white body.
Includes decals in English,
Spanish, and French.
SD-927PKC-NFQ
Same as SD-927PKC-NEQ,
but in French.
Indoor No-Touch Sensors
DP-222Q
Color Camera
and Monitor Set
DP-222-MQ
Additional Monitor
Color Video Door Phone
Rugged, heavy-duty construction.
For 36” (0.9m) doors. Actual length is 34.5” (0.88m).
Includes two built-in, dual-contact switches (5A@125VAC).
Includes SECO-LARM SD-969-A18 Armored Door Cord.
SD-961A-36
Redesigned _
Easier to install.
Push-to-Exit Bar
For exit doors
--
Allows exit from
inside while locked from outside.
Reversible non-handed design.
For metal or wood doors.
Stainless-steel 3/4" (19mm) throw-latch bolt.
Deadlocking latch.
Can be unlocked for extended periods of time.
Fits doors from 30"~48" (0.7~1.2m) wide.
Heavy-duty steel construction.
SD-962AR-36A
SD-962AR-36M
Conforms to and meets ADA regulations.
For use in institutions, schools, and commercial
buildings where heavy-duty, reliable operation is
required.
Aluminum construction.
Rim-Type Exit Devices
Entry-Type Levers
Use with SD-962AR-36A.
USD26D Finish.
Non-handed.
SD-962HL-4A
(2 Keys included)
Use with SD-962AR-36G.
Grade 1, through-bolted design.
Rigid, non-clutch mechanism.
Non-handed design,
easily eld-reversible.
SD-962H-6LB
(2 Keys included)
Designed to conduct power to
electric
locks or access
control devices mounted in doors.
18” (46cm) Stainless-steel cable.
Mounting screws included.
Sold in packs of ten.
SD-969-S18
Die-cast aluminum end caps
SD-969-A18
Plastic end caps
SD-969-S18
SD-969-A18
Armored Door Cords
SD-9163-KSVQ
Same as SD-9263-KSVQ,
but slimline.
SD-9163-KSQ
Same as SD-9263-KSQ,
but slimline.
SD-9263-KSQ
Same as SD-9263-KSVQ,
but no mechanical override
button.
SD-9263-KSVQ
Form C contact closure.
Single-gang No-Touch sensor.
Adjustable sensing range
and delay time.
Mechanical override button.
SD-9163-KS2Q
*
Same as SD-9263-KS2Q,
but slimline.
SD-9163-KS1Q
Same as SD-9263-KS1Q,
but slimline.
SD-9263-KS1Q
Same as SD-9263-KSQ,
but in Spanish.
SD-9263-KS2Q
*
Same as SD-9263-KSQ,
but in French.
*Special order item. Please contact SECO-LARM.
Outdoor No-Touch Sensors
Access
Grade 1 Rim-Type Exit Devices
SD-962AR-36G
ANSI A156.3, Grade 1 heavy-duty exit device.
Conforms to and meets ADA regulations.
UL Listed.
For use in institutions, schools, and
commercial buildings where heavy-duty, reliable
operation is required.
Aluminum construction.
SD-962SR-36I
ANSI A156.3, Grade 1 heavy-duty exit device.
Conforms to and meets ADA regulations.
For use in institutions, schools, and commercial
buildings where heavy-duty, reliable operation is
required.
Stainless-steel construction.
Hands-Free Video Door Phone
Built-in microphone on both the camera and monitor
— no handset needed.
Simple 2-wire connection.
Crisp, 700 TV-line resolution.
Camera and monitor turn on and off via push button.
Camera and monitor turn off automatically if not in use.
Includes power adapter.
Simple 2-wire connection.
Remotely and securely talk to
visitors and unlock doors or gates.
Camera and monitor turn on
and off via push button.
Camera and monitor turn off automatically if not in use.
Includes power adapter.
DP-234Q
Color Camera
and Monitor Set
DP-234-MQ
Additional Monitor
2013 SECO-LARM Condensed Catalog
16
SD-7275SGEX1Q
Single-gang, vandal-resistant.
1” Diameter, illuminated
red/green push button.
SD-7175SGEX1Q
Slimline, vandal-resistant.
1” Diameter, illuminated
red/green push button.
SD-7103GC-PTQ
Similar to SD-7103GC-PEQ,
but with timer.
Built-in timer, 1~180 seconds.
Buzzer output for audible status.
SD-7202GC-PTQ
Similar to SD-7202GC-PEQ,
but with timer.
Built-in timer, 1~180 seconds.
Buzzer output for audio status.
SD-7201GAPT1Q
Similar to SD-7201GCPE1Q,
but with timer.
Built-in timer, 1~180 seconds.
Buzzer output for audio status.
SD-7101KBPE1Q
Slimline, black N.C. push button.
SD-7201KBQ
SD-7101RAEX1Q
Slimline, red N.O. push button.
Single-gang plate.
Black push button.
N.C. Switch.
Timer only
Timer only
Timer only
Timer only
Timer only
Same as SD-7213-GSP,
but slimline.
SD-7113-GSP
Same as SD-7213-GSP,
but with stainless-steel
push button and guard ring.
SD-7273-SSP
SD-7173-SSP
Same as SD-7113-GSP,
but with stainless-steel push
button and guard ring.
Same as SD-7213-GSP,
but with red push button.
SD-7213-RSP
Green mushroom-cap
push button.
NO/NC contacts rated
5A@125VAC.
Built-in pneumatic timer,
1~60 seconds.
No power required.
SD-7213-GSP
SD-7204SGEX1Q
Single-gang, vandal-resistant.
1” Diameter push button.
NO/NC contacts.
SD-7104SGEX1Q
Slimline, vandal-resistant.
1” Diameter push button.
NO/NC contacts.
*Actual range may vary greatly depending on the installation and operating environment.
*
SD-8202GT-PEQ
Green, illuminated 2" square
push button.
For hard-to-wire installations.
Built-in RF transmitter (Similar to SK-919TD1S-UP).
Please see pg. 10 for RF receivers.
SD-8103GT-PEQ
Slimline, small square
illuminated push button.
SD-8201GTPE1Q
Green, 1½" diameter,
mushroom-cap push button.
315
MHz Up to
500ft
2" Square illuminated green
push button.
NO/NC contacts rated
10A@125VAC.
Includes switchable English,
French, and Spanish messages.
SD-7202GC-PEQ
Similar to SD-7202GC-PEQ,
but with white plate.
SD-7223GW-LQ
SD-7103GC-PEQ
Stainless-steel slimline plate.
Small, green, illuminated
push button.
Includes switchable English,
French, and Spanish messages.
SD-6176-SS1Q
Same as SD-6276-SSQ, but slimline.
SD-6276-SS1Q
Single-gang, vandal-resistant.
Field-programmable color,
red or green.
Weather resistant.
SD-6276-SSVQ
Same as SD-6276-SS1Q,
but English only, with override.
SD-6176-SSVQ
Same as SD-6176-SS1Q,
but English only, with override.
Similar to SD-7201GC-PEQ,
but with “EXIT” and “SALIDA”
messages on faceplate.
SD-7201GCPE1Q
Similar to SD-7201GCPE1Q,
but with DPDT switch.
Two NO and two NC contacts,
each rated 5A@125VAC.
SD-7201GF-PE1
Green, 11/2” dia., illuminated,
mushroom-cap push button.
NO/NC, DPST contact rated
5A@125VAC.
SD-7251GCEX1Q
Similar to SD-7201GCPE1Q,
but with blank white plate.
SD-7217GWQ
Stainless-steel faceplate.
Green mushroom-cap push button.
NO/NC contacts rated 5A@125VAC.
SD-7201GC-PEQ
SD-7201RC-PE1Q
Similar to SD-7201GCPE1Q,
but with red mushroom-cap
push button.
Mushroom R-T-E Plates Illuminated R-T-E Plates
Vandal Resistant, Illuminated
R-T-E Plates with Timer
Push Button R-T-E Plates
R-T-E Plates with Pneumatic
Timer
RF Wireless R-T-E Plates
Vandal-Resistant RTE Plates
Piezoelectric R-T-E Plates
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
Access
17
90ft (30m) Sensing distance.
IP66 for indoor/outdoor use.
Mounts flat or at 90o
to the wall with no need
for extra brackets.
Adjustable lens angle.
E-961-S90WQ
10~30 VAC/VDC (non-polarized).
For indoor or outdoor use.
NO or NC alarm output.
N.C. Tamper circuit included.
Interruption time adjustable.
Built-in laser beam alignment system makes
for quick, easy installations.
Outdoor range: 90ft (30m)
Outdoor range: 290ft (90m)
Outdoor range: 190ft (60m)
E-960-D90Q
E-960-D290Q
E-960-D190Q
With laser beam alignment
E-932-D33TBQ
Photoelectric
Through-Beam Sensor
Range: 33ft (10m)
Flush-mount design.
Fits single-gang box.
For entrances, hallways, offices, etc.
E-932-S16RRQ
Photoelectric
Reflective-Beam Sensor
Range: 16ft (5m)
The E-964-D390Q has all the same features as
the E-960-D90Q, D190Q, and D290Q, including laser
beam alignment.
Incorporates a 4-frequency function (programmable)
to eliminate the possibility of interference when
multiple photobeams are located within close
proximity.
Outdoor range: 390ft (120m)
E-964-D390Q
4 Frequencies to
eliminate interference. With laser beam alignment
12~24 VAC/VDC (non-polarized).
Multi-frequency (four channels selectable).
Reduces interference between multiple
units installed in close proximity.
Weatherproof, sunlight-filtering case for indoor
& outdoor conditions.
Anti-frost system with built-in heater.
NO/NC alarm output. N.C. tamper circuit.
Quick, easy installation with built-in laser beam
& audible alignment system.
Built-in alignment-strength indicator.
Outdoor range: 165ft (50m)
Outdoor range: 660ft (200m)
Outdoor range: 330ft (100m)
E-964-Q165Q
E-964-Q330Q
E-964-Q660Q
Outdoor range: 495ft (150m)
E-964-Q495Q
With laser beam alignment
E-931-S33PRQ
Range: 33ft (10m)
For assembly-line automation, outdoor gates, garage
doors, or overhead doors.
Excellent immunity to shiny objects that could
cause false triggering.
Operates on 12~250 VAC/VDC.
The E-931-S33PRQ
Polarized Reflective-
Beam Sensor provides
reliable detection of
shiny objects that could be missed by a non-polarized
sensor.
For entrance monitoring
or entrance indicator.
“Ding-dong” or siren
sound on beam
interruption.
E-931CS22RRCQ
Range: 22ft (6.7m)
Plug-in components.
No hard wiring needed.
Includes reflector,
brackets, 9VDC adapter,
mounting hardware, chime.
Optional counter also available.
E-931ACC-CQ
Counter for the E-931CS22RRCQ.
Uses 12~240 VDC /
24~240 VAC
Pre-wired 6ft
(1.8m) cord
Weatherproof (IP66) construction
for indoor/outdoor use
Brackets and mounting hardware included
E-931ACC-RC1Q
3” Round Reflector
E-931ACC-HR1Q
Hood for the E-931ACC-RC1Q or
E-931ACC-R2Q (2” square reflector)
Range: 35ft (10m)
E-931ACC-R2Q
2” Square Reflector
E-931-S35RRQ
E-931-S45RRQ
Range: 25ft (7.5m) outdoor,
50ft (15m) indoor.
LED Alignment indicator.
No synchronizing wires required.
Slimline design:
15/16”x7/8” (34x23 mm).
Programmable trigger:
One beam or two adjacent beams.
E-9611-2B25
Black Enclosure
2 Beams, 11
1
/
4
” (29cm) long
E-9622-4B25
Black Enclosure
E-9622-4W25
White Enclosure
4 Beams, 22
1
/
2
” (57cm) long
E-9644-6B25
Black Enclosure
E-9644-6W25
White Enclosure
6 Beams, 44
1
/
2
” (113cm) long
E-9660-8B25
Black Enclosure
8 Beams, 60” (152cm) long
E-9680-10B25
Black Enclosure
10 Beams, 80” (203cm) long
Range: Up to 45ft (14m);
Adjustable Sensing Distance and
Response Time;
Includes Reector Hood
E-931-S50RRQ
Up to 50ft (15m)
sensing range.
Uses 12~250 VAC/VDC.
Weatherproof (IP66)
construction for
indoor/outdoor use.
Anti-condensation housing.
E-931ACC-SQ
Additional speaker/chime for the
E-931CS22RRCQ.
Reflective Photobeam Sensors
Flush-Mount Beam Sensors
Twin Photobeam Detectors Curtain Sensors
Multi-Frequency Photobeam
Quad Photobeam Detectors
Single Photobeam Detector
Polarized Reflective Beam Sensor
Entry Alert System
Sensors
Long-Range Barrier Sensors
Outdoor range: 196ft (60m).
Indoor range: 393ft (120m).
1A Relay output.
NO or NC alarm output.
Adjustable interruption time.
Built-in heater.
E-9626-2B190Q
---
2 Pairs, 26” (66cm)
4
Frequencies
50ft Reflective Photobeam Sensor
E-9643-4B190Q
---
4 Pairs, 43” (109cm)
E-9661-6B190Q
---
6 Pairs, 61” (155cm)
E-9679-8B190Q
---
8 Pairs, 79” (201cm)
2013 SECO-LARM Condensed Catalog
18
ST-UV12-S0.5Q
0.5 Amp
ST-UV12-S1.0Q
1 Amp
ST-UV12-S2.0Q
2 Amp
Sideways plug for ease of
use on power strips.
Universal 100~240 VAC input.
Regulated 12VDC output.
 Low current draw.
6ft (1.8m) Cord, 2.1mm
plug (positive center).
ST-UV12-S1.0Q
Shown
Fits easily on
power strip
ST-UV12-S5.0Q
5 Amp
LED Power indicator.
Universal 100~240 VAC input.
Regulated 12VDC output.
6ft (1.8m) Cord, 2.1mm plug
(positive center).
Includes AC power cord (IEC320-C13).
Low current draw.
LED power
indicator
ST-2406-7AQ
ST-2406-5AQ
Model #
ST-1206-1.5AQ
ST-2406-2AQ
ST-2406-3AQ
Voltage
(DC) Current Current
(peak)
ST-2406-10AQ
6/12/24
6/12/24
6/12
6/12/24
6/12/24
6/12/24
7A
4A
1.5A
1.5A
2.5A
9A
7.5A
5A
2A
2A
3A
10A
ST-1206-1.5AQ
ST-2406-2AQ
ST-2406-3AQ
ST-2406-5AQ
ST-2406-7AQ
ST-2406-10AQ
Regulated and filtered output
voltage.
Short-circuit protection.
Built-in backup battery charger.
Switches to backup battery
automatically in case of power loss.
Convert low-voltage AC input power
to low-
voltage DC output power.
ST-2406-2AQ
ST-2406-10AQ
ST-HB105-TTQ
Compensates for DC voltage
drops over long cable runs:
7~12 VDC input for 12VDC outputs.
12~24 VDC input for 24VDC output.
Output current: 500mA@12/24 VDC.
Dual-input voltage: 120/240 VAC, 50/60Hz.
Works with the SECO-LARM series of power supply/
chargers.
Shielded windings to reduce electromagnetic
interference.
ST-UV16-W50Q
ST-UV16-W100Q
ST-UV24-W50Q
ST-UV24-W100Q
ST-UVDA-W100Q
ST-UVDA-W180Q
ST-UV28-T350Q
16VAC/50W
16VAC/100W
24VAC/50W
24VAC/100W
24/28 VAC/100W*
24/28 VAC/180W*
28VAC/350W
*
Dual-voltage output: 24 or 28 VAC
Triggered by positive voltage
(+DC), closure of dry contact,
or opening of dry contact.
Adjust from 1sec to 60min.
Form C relay.
SA-026Q
SA-025Q
Miniature: 13/16"x29/32"x5/8"
(30x58x16mm).
Adjustable from 1~180 sec.
Buzzer output.
Form C relay.
Use in CCTV, access
control alarms, etc.
6ft (1.8m) Line cord, 2.1mm
positive center plug.
ST-1212-R0.5A
500mA, Regulated
ST-LA108-TPQ
0.5 Amp
ST-LA115-TPQ
1.5 Amp
ST-LA110-TTQ*
1 Amp
ST-LA130-TPQ
3 Amp
ST-LA130-TPQ
Model #
ST-LA110-TTQ
Voltage
Input
(AC/DC)
12~24 12.6
5, 12, 24
ST-LA108-TPQ
ST-LA115-TPQ
Voltage
Output
(DC)
12~24
12~24
12~24
12.6
5, 12, 24
ST-LA108-TPQ
ST-LA115-TPQ
ST-LA110-TTQ
Input: Terminal Block.
Output: DC Plug (pigtail).
*Terminal Block.
ST-LA130-TPQ
12/24 VDC Operation.
Low current draw: 15mA.
2A Relay, DPDT, Form C.
3~24 VDC Trigger.
Large terminal blocks for
easy installation.
SR-1212-C2ALQ
SR-2206-C5AQ
SR-2212-C5AQ
12/24 VDC operation.
High-sensitivity,
low-trigger voltage.
Two 7A relays, SPDT,
Form C.
3~24 VDC Trigger.
SR-1212-C7ALQ
Easily fit inside alarm panel enclosures
12/24 VDC Operation.
5A relay, DPDT, Form C.
12/24 VDC Trigger.
Large terminal blocks for
easy installation.
6/12 VDC Operation.
5A Relay, DPDT, Form C.
6/12 VDC Trigger.
Large terminal blocks for
easy installation.
SR-2112-C7AQ/10
12/24 VDC Operation.
7A Relay, SPDT, Form C.
12/24 VDC Trigger.
Breakaway 10-pack.
Open-Frame Transformers
Power Supply Chargers
Tabletop Switching Power Supply
12VDC Plug-in Switching AC
Adapters
Voltage Booster
Voltage Converters
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
Programmable Timers
SH-532L
128dB Multi-tone siren.
Miniature size: 4” long, 3½” diameter.
6~12 VDC, 1.4A current draw.
Siren
12VDC Linear AC Adapter
Security
Relay Boards
19
ST-BD01Q
Prevents deep discharge of backup batteries.
Selectable input: 12/24 VDC.
Adjustable voltage cutoff and restore point.
Green LED AC indicator & 2-color LED DC indicator.
Two NO/NC triggers.
Two independent channels. Stores up to four numbers.
Delivers message of up to 16sec to each number.
Repeats message for one minute to ensure full delivery.
Optional 9VDC internal battery.
Use worldwide with Universal Dial Tone.
E-920B
With
2 NO/NC
triggers
ST-BL01Q
Real-time, latch, and
auto-reset modes for
testing NO and
NC circuits.
Features LED and
buzzer indicator for remotely
testing a connection.
Convenient headlight LED to
guide your way.
SM-204Q
N.C. Mini self-stick surface mount
with flange and center leads. 1” Gap.
M -- Magnet for SM-204Q/205Q.
Available in brown or white.
SM-205Q
N.C. Self-stick surface mount with
flange and side leads. 1” Gap.
M -- Magnet for SM-204Q
and SM-205Q.
Available in brown or white.
SM-266
N.C. Super-thin screen mount
with leads. 11/4” Gap.
SM-200Q
N.C. Surface mount with
screw terminals. 3/4” Gap.
Includes cover.
SM-300Q
N.O. Surface mount with screw
terminals. 3/4” Gap. Includes cover.
SM-823
-- Additional terminal cover.
Available in brown or white.
SM-852L
Aluminum “L” bracket
for SM-226LQ.
SM-831
Alnico 5 magnet, 11/4”x1/4” dia.
SM-841
Alnico 5 magnet, 15/8”x3/8” dia.
SM-851
Aluminum “Z” bracket
for SM-216Q.
SM-226LQ
N.C. Overhead door with “L” bracket.
24” Stainless-steel cable. 23/4” Gap.
SM-226L-3Q
NO/NC Overhead door with
“L” bracket. 23/4” Gap.
SM-226RQ
N.C. Overhead door with round
bracket. 24” Cable. 23/4” Gap.
SM-431-T
Quick Connect
Surface Mount
For N.C. circuits.
External screw terminals.
1" Gap.
Available in brown or white.
SM-433-T
Concealed Screws
Surface Mount
For N.C. circuits.
Concealed screw terminals.
11/4" Gap.
Available in brown or white.
SM-407-5T
Quick Connect
Recessed Mount
For N.C. circuits.
External screw terminals.
3/4" Gap.
SM-207Q
N.C. 3/8” Press-fit mount
with leads. 1” Gap.
Available in brown or white.
SM-207-5LQ
N.C. Mini 3/8” press-fit mount
with leads. 1” Gap.
Available in brown or white.
SM-206
N.C. 1/4” Recessed
mount with leads. 1” Gap.
Available in brown or white.
SM-207-5Q
N.C. Mini 3/8” press-fit mount
with leads. 3/8” Gap.
Available in brown or white.
SM-207-31
N.C. Mini 1/4” press-fit mount.
1” Gap.
SM-207-41
N.C. Mini 3/8” press-fit mount.
13/4” Gap.
ST-BT03Q
Same as ST-BT02Q, but 12 or 24 VDC.
Includes headlight, LED and buzzer.
ST-BT02Q
6-in-1 12VDC Battery tester
with continuity LED
ST-BT02Q Shown
Indicates the condition of rechargeable gel-type
12VDC batteries.
Equipped with a momentary simulated load.
Portable and easy to use.
Test for:
1. Voltage
2. Battery load
3. Voltage drop
4. PTC fuse
5. Polarity
6. Continuity
Low Battery Cutoff
Voice Dialer
Multi-Purpose Battery Testers
High-Speed Latching Tester
Overhead Door Contacts
Quick-Connect Magnetic Contacts
Recessed Contacts
Self-Stick Contacts Magnetic Contact Accessories
Screen Contact
Wide Gap Contacts
Surface-Mount Contacts
SM-216Q
N.C. Wide-gap surface mount with
screw terminals. 23/4” Gap.
SM-216M
-- Magnet for SM-216Q.
Available in brown or gray.
SM-217Q
N.C. Wide-gap mini surface
mount with concealed screw
terminals. 2” Gap.
Security
2013 SECO-LARM Condensed Catalog
20
Access
SS-078Q
N.O. Latching panic button.
SS-076Q
Toggle switch.
Available in gray or white.
SS-074Q/BG
N.O. Double-button
momentary hold-up switch.
SS-075Q
N.O. “EMERGENCY” button.
SS-072Q
N.O. Tamper switch.
SS-040Q
N.C. Vibration/shock sensor.
Adjustable sensitivity.
Available in white or brown.
SS-075C-PEQ
Emergency & Push-To-Exit
NO or NC (selectable)
momentary contact.
Three labels included.
SS-077Q
N.C. Latching panic button.
SS-073Q
N.C. Tamper switch.
SS-032Q/RD
Red N.O. Button
SS-033Q/BK
Black N.C. Button
SS-202
Foil Connection Block
ENFORCER 190
Audio discriminator.
Patented design detects
high-frequency sound of
glass breaking while
filtering out ambient
environmental noise.
When ceiling mounted, protects to a 25ft radius.
Protects 45ft to the front and 25ft to either side.
2Amp dry contact relay.
Choice of: amber, blue, clear, green, or red.
Built-in siren for both audible and visual notification.
Ultra-bright: Twice as many LEDs as the SL-1301-BAQ.
Operating life of 50,000 hours (5.7 years) of
continuous use.
9-Volt backup battery option for continuous operation.
SL-1301-SAQ
SH-504Q
Miniature 85dB electronic buzzer.
5~15 VDC, surface mount or mount
in 3/4" (19mm) hole of alarm panel
or remote plate.
Low current draw of 35mA@12VDC.
(SL-126Q)
Easy 2-wire connection for 6~12 VDC or 6~24 VDC.
SL-126Q
For 6~12 VDC use.
SL-126-A24Q
For 6~24 VDC use.
Choice of: amber, blue, clear, green, or red.
For "informative" household burglar alarm use.
Incorrect polarity cannot damage circuit or draw current.
Low current consumption with long-operating lifespan
of over 300 continuous hours (2,000,000 flashes).
Lens is made of high-impact resistant acrylic, case
of high-impact resistant ABS plastic.
SL-126LQ
--
Replacement lens for SL-126Q,
SL-126-A24Q, SL-1301 series, and SL-1501-BAQ.
Choose amber, blue, clear, green, or red.
Indoor
Choice of: amber, blue, clear, green, or red.
Operating life of 50,000 hours (5.7 years) of
continuous use.
Less heat generated than a xenon-tube strobe.
9-Volt backup battery option for continuous operation.
SL-1301-EAQ
Basic LED strobe light
SL-1301-BAQ
Programmable Flash and Speed
P66
Outdoor
4 High-intensity 1W LEDs
SL-1311-MA
Available in four colors:
Amber, clear, blue or red.
10~30 VDC Operation.
19 Programmable flash patterns.
Synchronize up to 15 units.
Outdoor
SS-090KN Series
Extra keys. Specify number
when ordering.
See pg. 14 for key number chart.
SS-090 Series
 Two terminals, shunt SPST.
Maintained ON-OFF, key removable
from both ON and OFF positions.
Specify key number when ordering.
SS-095 Series
Two terminals, momentary SPST.
Maintained OFF, springs back from
ON, key removable from OFF only.
Specify key number when ordering.
SS-090-1H0
Similar to SS-090, but key removable
in OFF position only (key #1300 only).
SS-092-2A0
Two internal SPST switches,
one always ON, one always
OFF (key #1300 only).
(N.O., Turn to Close)
Available in four colors: White, red, blue
or yellow (/WAQ, /RAQ, /BAQ, /YAQ).
12-LED strips for informative or decorative applications.
12VDC Operation.
Each strip can be cut to varying
lengths depending on the application.
Connect up to 30 strips in series.
Requires one power connector
(SL-SAS-PC1Q), sold separately.
Optional accessories:
● SL-SAS-PC1Q Power Connector
● SL-SAS-EC1Q End Cap
● SL-SAS-SH1Q LED Strip Fastener
SL-S212
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
Key Locks
Glass-Break Detector, Audio
Strobe Lights
LED Strobe Lights
LED Strobe Lights with Siren
High-Intensity LEDs
Buzzer
Security
Detectors and Switches
12-Inch LED Strips
21
Transmits VGA
signals over shielded
Cat5e/6 cable.
Use with personal
computer, DVR, etc.
with VGA output to
CRT or LED monitors
or VGA projectors.
Up to 443ft (135m) range.
Passive device. No power required.
Sold in pairs.
MVE-SV010Q
/
MVD-V1501-1Q
Transmits VGA signals from a single
source to multiple CRT or LCD
monitors or VGA projectors.
Extends VGA range up to 984ft (300m)
over one Cat5e/6 cable.
Supports up to
1920x1200 resolution.
Each set includes one
transmitter and one receiver.
Additional receiver
(MVD-V1101-1RQ) available.
Powered (5VDC
adapter included).
MVD-V1201-1Q
MVD-V1101-1RQ
Additional receiver for the
MVD-V1501-1Q and MVD-V1201-1Q.
Powered (5VDC adapter included).
VGA Extender 1-In-5-Out
VGA Extender 1-In-2-Out
MVE-PCW15Q
MVE-PC015Q
Transmits YPbPr or RGB video signals.
Four RCA connectors to RJ45 jack.
Supports HDTV
(480i/480p/720i/720p/1080i/1080p).
Maximum distance:
164ft (50m)@1080p,
900ft (300m)@480i.
Passive operation,
requires no power.
Stackable or wall mountable.
Programmable digital
audio or IR pass-through.
Similar to MVE-PC015Q,
but wall-plate version.
/
V
MVE-AD010
DVI Extender
Transmits DVI over one Cat5e/6 cable.
Up to 1080p.
Extends range up to 160ft (50m).
Powered on both ends (two 5VDC adapters included).
-
MVE-AHW1Q
Active.
IR Pass-through.
Transmits HDMI
®
signal
over dual Cat5e/6 cables.
Range: Up to 164ft (50m).
Resolution: Up to 1080p.
/
MVE-WH010Q
Wirelessly transmits HDMI
®
from a DVR, Blu-Ray
player, or other high-definition source to a monitor.
Range: Up to 98ft (30m).
Supports resolutions up to 1080p.
Signal can pass through walls.
IR Pass-through carries remote control signals from
the monitor’s location back to the source.
Two 5VDC adapters included.
A
MVE-AH010Q
Connect HDMI
®
equipment using low-cost
Cat5e/6 UTP cables.
Works with full-motion video
and audio signal up to 195ft (60m).
HDMI
®
over Cat5e/6 without any signal loss.
Supports 480i/480p/576i/576p/720p/1080i/1080p.
Built-in equalization and signal-boost function.
Auto-adjusts the equalization and amplification to
eliminate feedback.
Compact size.
5VDC Power supply included.
Supports DDC, EDID, and hot-plug detection.
A
MVE-AH020Q
Connect HDMI
®
equipment using low-cost
Cat5e/6 UTP cable.
Works with full-motion video
and audio signal up to 164ft (50m).
HDMI
®
over Cat5e/6 without any signal loss.
Supports 480i/480p/576i/576p/720p/1080i/1080p.
Built-in equalization and signal-boost function.
Auto-adjusts the equalization and amplification to
eliminate feedback.
Compact size.
5VDC Power supplies included.
Supports DDC, EDID and hot-plug detection.
Connect HDMI
®
equipment using low-cost Cat5e/6
UTP cable.
Works with full-motion video and audio signals up
to 230ft (70m).
Supports 3D.
IR Pass-through carries remote control signals
from the monitor’s location back to the source.
HDMI
®
over Cat5e/6 without any signal loss.
Supports 480i/480p/576i/576p/720p/1080i/1080p.
Compact size.
5VDC Power supply included.
MVE-AH110Q
Up to 230ft (70m)
MVE-AHW10Q
Up to 230ft (70m), Wallplate
Passive VGA Balun
Active VGA Extenders
Component Video Baluns
Audio/Video
Active DVI Extender
Wall-Plate HDMI® over Cat5e/6
Wireless HDMI® Extender
HDMI® over Dual Cat5e/6
HDMI® over Single Cat5e/6
HDBase-T Extenders
2013 SECO-LARM Condensed Catalog
22
V
Black
chrome
cable
MC-1102-18NQ
1.5ft (0.5m), 28AWG
MC-1102-03FQ
3ft (1m), 28AWG
MC-1102-06FQ
6ft (1.83m), 28AWG
MC-1102-10FQ
10ft (3m), 28AWG
MC-1102-16FQ
16ft (5m), 28AWG
MC-1102-20FQ
20ft (6m), 26AWG
MC-1102-25FQ
25ft (7.6m), 26AWG
MC-1102-30FQ
30ft (9m), 26AWG
MC-1102-50FQ
50ft (15m), 26AWG
3D Support.
4K Support.
Up to 1080p.
Lifetime warranty.
MVR-HH01Q
Extends high-definition video
and digital audio up to 115ft (35m).
Supports high-definition video
up to 1080p.
-
MC-2201Q
MC-2101Q
For joining two HDMI® cables together.
Gold-plated contacts.
Compatible with all 19-pin
HDMI® cables, supports HDCP.
Similar to MC-2201Q,
but rotates 180 .
Use for running HDMI® cables
in tight locations.
V
MVU-SH01
Input:
– S-Video (1.0Vp~p 75Ω).
– Composite (NTSC/PAL, 1.0Vp~p 75Ω, RCA).
– Audio (Stereo L/R, RCA).
Output:
– HDMI® (720p or 1080p selectable).
– Audio (3.5mm Stereo output).
5VDC Adapter included.
/
MVM-H4201-1Q
4-In, 2-Out
MVM-H4401-1Q
4-In, 4-Out
Supports resolutions up to 1080p.
Supports 3D.
IR Pass-through for remote control support.
Desk or wall-mountable.
Small size: 11”x63/16”x11/8” (280x157x28 mm).
-
MVM-R4201-1Q
4-In, 2-Out
MVM-R4401-1Q
4-In, 4-Out
Transmit IR remote signals
over HDMI® cables.
Use with HDMI® extenders,
switches, and matrixes.
Convenient for applications where
the HDMI® source is not near the monitor.
/
V
MVS-H4101-0Q
Easily switch between
any of four HDMI® sources
by remote control
or push button.
Supports resolutions
up to 1080p.
24K Gold-plated connectors.
Supports 3D.
IR Remote control included.
V
-
MVA-DV01
DVI to VGA Converter
Converts DVI (digital) signal to VGA (analog) signal.
Powered (5VDC adapter included).
/
V
MVE-PB010Q
RCA Plug, Terminal Block
MVE-PB020Q
RCA Jack, RJ45, Snap-In
Transmits composite video over low-cost Cat5e/6.
Up to 2,230ft. (680m) color, 2,550ft (780m) B/W.
-
MVA-VH01Q
VGA Input (plus stereo audio)
to HDMI
®
signal. Allows display
from computer on HDMI
®
monitor.
Input: VGA connector and dual
RCA jacks (red/right, white/left).
Output: HDMI® jack.
HDCP Pass-through.
5VDC Power adapter included.
V
MVA-VD01
VGA to DVI Converter
Converts VGA (analog) signal to DVI (digital) signal.
Powered (5VDC adapter included).
MVA-EH01Q
Component Video + Digital Audio
to HDMI
®
Converter
Input: Four RCA connectors
(three for component video,
and one for digital audio).
Output: HDMI® jack.
Supports HDTV resolution
up to 1080p.
5VDC Power adapter included.
V
sales@seco-larm.com CA & Int’l 949-261-2999 Toll Free 800-662-0800 www.seco-larm.com
HDMI® Cables
HDMI® Couplers
HDMI® Repeater
Video/Audio to HDMI® Converter
Audio/Video
HDMI® Matrix
IR Over HDMI®
HDMI® Switcher
DVI/VGA Converter
Composite Video Baluns
VGA & Stereo to HDMI® Converter
VGA/DVI Converter
Component Video & Digital
Audio to HDMI®
23
Two 2-button RF remotes:
– Arm/disarm up to 200ft (60m).
– Panic protection. Silent arm/disarm.
– Defective zone & shock sensor bypass via remote.
Built-in dual-stage shock sensor (patented).
5-Function LED shows armed, disarmed, valet,
learn mode, and RF reception.
Emergency disarm/valet.
Instant triggering.
Current-sensing protection.
Backup battery capability.
CBA® 33
Self-Contained Vehicle Alarm
E-100LB
Entry-Level Alarm
Entry-level alarm system packed with the most
wanted features including two slimline 4-button RF
remote controls, relay for ashing parking lights,
and outputs for door locks and starter disable.
Two 4-button RF remotes.
Door lock outputs (+/–).
Starter-disable output.
Flashing parking lights (built-in relay).
Dual-stage shock sensor (patented).
128dB Multi-tone siren.
5-Function LED.
Multi-function push button.
Multiple programming functions.
E-300L
Full-Featured 3-Channel Alarm
Two 3-button RF remotes.
Dual-stage glass-break sensor (patented)
with remote microphone.
Dual-stage shock sensor
(patented)
.

Starter-disable relay built-in.
SLI® 762PP-ISS
Passive Proximity Immobilizer
The Passive Proximity Immobilizer eliminates the
hassle of remembering how and when to operate
a vehicle security system. Just put the included
keyfob on the keychain, and the system arms and
disarms automatically.
Two on-board relays for
disabling the starter,
ignition, or fuel pump.
Installer test mode helps
determine best position
for the sensing coil.
Plug-in status LED included.
No valet switch needed.
SLI® 762FP-ISS
Touchkey Immobilizer
The Touchkey Immobilizer combines high security
with the convenience of completely passive arming.
To arm, turn off the ignition. 30 Seconds later, up to
two of the car’s electrical circuits are disabled.
To disarm the system, insert the Touchkey
momentarily into the Touchkey receptacle.
Start the vehicle within 30 seconds or the
Immobilizer will rearm.
Two Touchkeys supplied with each unit.
Handsomely crafted backlit
receptacle.
Flashing status LED
indicates immobilizer
armed, disarmed,
code-learning mode,
and valet override.
SLI® 259A
Dual-Stage Microwave Sensor
SS-052B
Dual-Stage
Electromagnetic Shock Sensor
SS-051ME
Dual-Stage Glass-break Sensor
SR-5201R
Power Door Lock Interface
Use on vehicles with cloth or open tops,
or open sunroofs.
Dual-stage protection:
Chirps siren if exterior
zone violated (someone
gets too close to car),
triggers alarm if interior
zone is violated (break-in
or vandalism attempt).
Dual-stage protection: Chirps
siren if car lightly tapped, triggers
alarm on break-in or vandalism
attempts.
Includes remote microphone with
3ft cable for easy mounting
and concealing inside the car.
Dual-stage protection:
Chirps siren on light tap
of window, triggers alarm
on break-in.
Allows nearly any alarm to control nearly
any type power-door lock/unlocks.
Includes two pre-wired, built-in,
heavy-duty 30 Amp relays with
protecting diodes and
spike/noise suppressors.
X-187-037-1SC
Relay
SPDT, 12V, 30A/40A
Heavy-duty automotive relay.
SS-066TL
Pin Switch
European-style pin switch.
SS-061LSN
Pin Switch
Patented heavy-duty, long, steel body
with nylon fiberglass shaft and
stainless-steel contact terminal.
SLI® 840
High-End Keyless Entry/Alarm
For use in almost any vehicle security application.
Use as a keyless entry system, or as a complete
multi-featured alarm. Special order item.
Two 4-button “Icon” RF remotes.
Door lock outputs (+/–).
Starter-disable output.
Flashing parking lights (built-in relay).
Domelight supervision output.
Dual-stage shock sensor (patented).
128dB Multi-tone siren and separate horn-honk output.
7-Function LED.
Multi-function push button.
13 Programming functions.
SLI® 820R
Keyless Entry Upgrade Alarm
Upgrades factory
keyless entry system by
adding a complete security system.
Disarm defeat input prevents thieves from using the
car’s unlock switch to disarm alarm.
Includes dual-stage electronic shock sensor.
Built-in parking light relay.
Starter disable output.
SLI®
820RA
Similar to SLI 820R, but without the siren or
shock sensor.
Vehicle Security Systems Keyless Entry/Alarm Vehicle Accessories
Vehicle
Immobilizers
2013 SECO-LARM Condensed Catalog
Dome Cameras · DNR Cameras · Bullet Cameras · H.264 Network DVRs · PTZ Cameras · Specialty Cameras · Flush-Mount Cameras ·
CCTV Power Supplies · Rack-Mount Power Supplies · Video Baluns · Balun Hubs · VGA Accessories · Video Distributors · Video Amplifiers ·
RF Transmitters and Receivers · Electromagnetic Locks · Access Control Power Supplies · Digital Access Keypads · Shear Locks · Electric Door Strikes ·
Electric Deadbolts · Keylocks · No-Touch Request-to-Exit Sensors · Push-to-Exit Bars · Video Door Phone · Request-to-Exit Plates · Pneumatic Timers ·
Photobeam Sensors · Entry Alert Systems · Open-Frame Transformers · Timer Modules · Voice Dialers · Panic Buttons · Switches · Strobe Lights · LED Modules ·
LED Strip Lights · Glass Break Detector · Emergency Buttons · Magnetic Contacts · Component Accessories · HDMI® Accessories · Vehicle Security ·
Much, much more...

Navigation menu
