421 51 6240 04 1/13/16
Specifications subject to change without notice.
EFFICIENT 14 SEER AIR CONDITIONER
ENVIRONMENTALLY SOUND R−410A REFRIGERANT
1−1/2 THRU 5 TONS SPLIT SYSTEM
208/230 Volt, 1−phase, 60 Hz
REFRIGERATION CIRCUIT
SScroll compressors on all models
SFilter−Drier supplied with every unit for field installation
SCopper tube / aluminum fin coil
EASY TO INSTALL AND SERVICE
SEasy Access service valves on all models
SExternal high and low refrigerant service ports
SOnly two screws to access control panel
SFactory charged with R−410A refrigerant
BUILT TO LAST
SBaked−on powder coat finish over galvanized steel
SPost−painted (black) coil fins
SCoated, weather−resistant cabinet screws
SCoated inlet grille with 3/8” (10mm) grille spacing for extra
protection (hail guard)
LIMITED WARRANTY*
S10 year parts limited warranty (including compressor and
coil) with timely registration
S5 year parts limited warranty if not registered within 90
days of original installation
*For owner occupied, residential applications only. See
warranty certificate for complete details and
restrictions, including warranty coverage for other
applications.
Use of the AHRI Certified TM Mark indicates a
manufacturer’s participation in the program. For
verification of certification for individual products,
go to www.ahridirectory.org .
Model
Number
Size
(tons)
Nominal
BTU/hr
Min. Circuit
Ampacity
Max. Fuse
or Breaker
Operating Dimensions
width x depth x height in. (mm)
Ship / Operating
Weight lbs. (kg)
NXA418GKC 1−1/2 18,000 11.7 20 23−1/8 x 23−1/8 x 24−13/16
(587 x 587 x 630) 134/123 (61/56)
NXA424GKC 2 24,000 14.1 20 25−3/4 x 25−3/4 x 25
(654 x 654 x 635) 140/119 (84/54)
NXA430GKC 2−1/2 30,000 16.8 25 31−3/16 x 31−3/16 x 31−13/16
(792 x 792 x 808) 186/151 (84/68)
NXA436GKC 3 36,000 18.1 30 31−3/16 x 31−3/16 x 24−13/16
(792 x 792 x 630) 151/134 (68/87)
NXA442GKC 3−1/2 42,000 22.3 35 31−3/16 x 31−3/16 x 39−1/8
(792 x 792 x 994) 232/192 (105/87)
NXA448GKC 4 48,000 20.9 35 31−3/16 x 31−3/16 x 28−7/16
(792 x 792 x 722) 200/182 (91/82)
NXA460GKC 5 60,000 27.5 40 31−3/16 x 31−3/16 x 31−13/16
(792 x 792 x 808) 218/197 (99/89)
®
NXA4
Performance Series
Product Specifications
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
2421 51 6240 04
Specifications subject to change without notice.
OUTDOOR UNIT MODEL NUMBER IDENTIFICATION GUIDE
Digit Position: 1 2 3 4 5, 6 7 8 9 10 11
Example Part Number: N X A 4 18 G K C 1 0
N = Entry BRANDING
X = R−410A REFRIGERANT
A = Air Conditioner
H = Heat Pump TYPE
3 = 13 SEER
4 = 14 SEER NOMINAL EFFICIENCY
18 = 18,000 BTUH = 1−1/2 tons
24 = 24,000 BTUH = 2 tons
30 = 30,000 BTUH = 2−1/2 tons
36 = 36,000 BTUH = 3 tons
42 = 42,000 BTUH = 3−1/2 tons
48 = 48,000 BTUH = 4 tons
60 = 60,000 BTUH = 5 tons NOMINAL CAPACITY
G = Coil Guard Grille FEATURES
K = 208/230−1−60 VOLTAGE
Sales Code
Engineering Revision
Extra Digit
ACCESSORIES PART NUMBER IDENTIFICATION GUIDE
Digit Position: 123456, 7 8, 9 10, 11
Example Part Number: N A S A 0 0 1 01 C H
N = Non−Branded BRANDING
A = Accessory PRODUCT GROUP
S = Split System (AC & HP) KIT USAGE
A = Original
B = 2nd Generation MAJOR SERIES
0 = Generic or Not Applicable
2 = R−22
4 = R−410A REFRIGERANT
Product Identifier Number
Package Quantity
Type of Kit (Example: CH = Crankcase Heater)
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
421 51 6240 04 3
Specifications subject to change without notice.
SD5272−4 REV B
1. Allow 24” clearance to service side of unit, 48” above unit, 6“ on one side, 12” on remaining sides.
2. Maintain a distance of 24” between units or 18” if no overhang within 12’.
3. Minimum outdoor operating ambient in cooling mode is 55ºF, max 125ºF.
4. Center of Gravity
Model
Dimensions Inches (English)
A B C D E F G K L M N P
Minimum
Ground
Mounting Pad
Size
X
Minimum
Rooftop
Mounting Pad
Size
Y
Shipping
Dimensions
L x W x H
NXA418GKC 23−1/8 24−13/16 3−3/4 3/4 4−7/16 18−1/16 7−13/16 2−13/16 1/2 13 11−1/8 10−1/4 23−1/8 x 23−1/8 17−3/4 x 17−3/4 25−1/4 x 25−1/4 x 27−3/16
NXA424GKC 25−3/4 25 3−3/4 3/4 4−7/16 21−1/4 9−1/8 2−13/16 1/2 13−5/8 12−1/8 9−7/8 25−3/4 x 25−3/4 20−7/16 x 20−7/16 27−7/8 x 27−7/8 x 32−9/16
NXA430GKC 31−3/16 31−13/16 3−3/4 3/4 6−9/16 24−11/16 9−1/8 2−13/16 1/2 16−1/8 15−1/16 12−5/8 31−3/16 x 31−3/16 23 x 23 33−3/8 x 33−3/8 x 34
NXA436GKC 31−3/16 24−13/16 3−7/8 7/8 6−9/16 24−11/16 9−1/8 2−15/16 5/8 15−9/16 16−1/2 10−1/4 31−3/16 x 31−3/16 23 x 23 33−3/8 x 33−3/8 x 27−3/16
NXA442GKC 31−3/16 39−1/8 3−7/8 7/8 6−9/16 24−11/16 9−1/8 2−15/16 5/8 16−1/8 16−11/16 14 31−3/16 x 31−3/16 23 x 23 33−3/8 x 33−3/8 x 40−5/8
NXA448GKC 31−3/16 28−7/16 3−7/8 7/8 6−9/16 24−11/16 9−1/8 2−15/16 5/8 16−3/16 16−1/4 10−1/4 31−3/16 x 31−3/16 23 x 23 33−3/8 x 33−3/8 x 30−5/8
NXA460GKC 31−3/16 31−13/16 3−7/8 7/8 6−9/16 24−11/16 9−1/8 2−15/16 5/8 15−1/2 16 10−7/8 35 x 35 26−3/4 x 26−3/7 33−3/8 x 33−3/8 x 34
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
4421 51 6240 04
Specifications subject to change without notice.
SD5272−4 REV B
1. Allow 610 mm clearance to service side of unit, 1219 mm above unit, 152 mm on one side, 305 mm on remaining sides
2. Maintain a distance of 610mm between units or 457mm if no overhang within 3.7m.
3. Minimum outdoor operating ambient in cooling mode is 13ºC, max 52ºC.
4. Center of Gravity
Model
Dimensions mm (SI Metric)
A B C D E F G K L M N P
Minimum
Ground
Mounting
Pad Size
X
Minimum
Rooftop
Mounting
Pad Size
Y
Shipping
Dimensions
L x W x H
NXA418GKC 587 630 95 19 113 459 198 71 13 330 283 260 587 x 587 451 x 451 642 x 642 x 691
NXA424GKC 654 635 95 19 113 540 232 71 13 346 308 251 654 x 654 518 x 518 708 x 708 x 827
NXA430GKC 792 808 95 19 113 627 232 71 13 410 383 321 792 x 792 583 x 583 847 x 847 x 864
NXA436GKC 792 630 98 22 167 627 232 75 16 395 419 260 792 x 792 583 x 583 847 x 847 x 691
NXA442GKC 792 994 98 22 167 627 232 75 16 410 424 356 792 x 792 583 x 583 847 x 847 x 1031
NXA448GKC 792 722 98 22 167 627 232 75 16 411 413 260 792 x 792 583 x 583 847 x 847 x 778
NXA460GKC 792 808 98 22 167 627 232 75 16 394 406 276 792 x 792 583 x 583 847 x 847 x 864
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
421 51 6240 04 5
Specifications subject to change without notice.
PHYSICAL DATA (1−phase)
Model Size 18 24 30 36 42 48 60
Nominal Cooling Capacity (BTU/hr) 18,000 24,000 30,000 36,000 42,000 48,000 60,000
Nominal SEER 14.0
Compressor Type Scroll
REFRIGERANT R−410A
Charge −lb(kg) 3.2(1.45) 3.87(1.76) 5.67(2.57) 4.95(2.25) 7.90(3.58) 8.31(3.77) 9.39(4.26)
Required Subcooling °F (°C) 16 (8.8) 10 (5.5) 12(6.6) 11 (6) 9 (5) 11 (6) 13 (7.2)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1600 1881 2614 3167 3700 3454 3700
Motor HP 1/12 1/12 1/10 1/5 1/4 1/4 1/4
Motor RPM 1100 1100 1100 1100 1110 1110 1100
COND COIL
Face Area (Sq ft) 8.4 9.9 17.24 12.9 21.6 15.1 17.25
Fins per In. 25 25 25 25 25 20 25
Rows 1 1 1 1 1 2 2
Circuits 3 4 4 5 7 6 8
VALVE CONNECT. (In. ID)
Vapor − in. (mm) 3/4 (19) 3/4 (19) 3/4 (19) 7/8 (22) 7/8 (22) 7/8 (22) 7/8 (22)
Liquid − in. (mm) 3/8 (10)
REFRIGERANT TUBES* (In. OD)
Rated Vapor 3/4 (19) 3/4 (19) 3/4 (19) 7/8 (22) 7/8 (22) 7/8 (22) 1 1/8 (29)
Max Liquid Line 3/8 (10)
* Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of
lineset. Note: See unit Installation Instruction for proper installation.
ELECTRICAL DATA (208/230−1−60, voltage range 197V − 253V)
Model Size 18 24 30 36 42 48 60
Minimum Circuit Ampacity −
MCA (amps) 11.7 14.1 16.8 18.1 22.3 20.9 27.5
Maximum OverCurrent
Protective device − MOCP (amps) 20 20 25 30 35 35 40
Compressor RLA (Rated Load Amps)
LRA (Locked Rotor Amps)
9
47.5
10.9
62.9
12.8
67.8
13.6
79.0
16.7
109.0
15.6
105.7
20.8
127.1
Fan Motor FLA (Full Load Amps) .40 .50 .75 1.10 1.40 1.40 1.52
A-Weighted Sound Power Level - Without Sound Jacket
Model
Standard
Rating
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
NXA418GKC 75 45 53 57 62 60 53 48
NXA424GKC 72 46 57 60 64 61 56 50
NXA430GKC 73 50 56 63 64 61 58 54
NXA436GKC 75 51 61 65 67 63 60 53
NXA442GKC 73 49 58 63 64 59 56 50
NXA448GKC 76 53 61 64 66 62 60 51
NXA460GKC 75 54 57 63 64 62 58 51
Note: Tested in accordance with AHRI Standard 270-2008 (not listed in AHRI).
A-Weighted Sound Power Level - With Sound Jacket
Model
Standard
Rating
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
NXA418GKC 75 45 53 58 62 61 55 49
NXA424GKC 73 47 59 61 64 61 55 48
NXA430GKC 72 49 57 62 63 60 57 52
NXA436GKC 75 51 62 65 66 62 60 52
NXA442GKC 72 50 58 62 63 58 55 47
NXA448GKC 73 55 61 64 63 60 57 48
NXA460GKC 73 54 59 63 63 60 56 48
Note: Tested in accordance with AHRI Standard 270-2008 (not listed in AHRI).
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
6421 51 6240 04
Specifications subject to change without notice.
REFRIGERANT CHARGE ADJUSTMENTS
Liquid Line Size R-410A Charge oz/ft
3/8 0.60
(Factory charge for lineset = 9 oz)
5/16 0.40
1/4 0.27
Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz. When using other length or
diameter liquid lines, charge adjustments are required per the chart above.
Charging Formula:
[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment
Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?
Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.
Net result is to remove 4.95 oz of refrigerant from the system
Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?
Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.
Net result is to add 9 oz of refrigerant to the system
LONG LINE APPLICATIONS
An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain
acceptable refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a
system as long line depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and
outdoor units.
For Air Conditioner systems, the charts below shows when an application requires a TXV and long line accessories due to lineset
length.
AC with R−410A Refrigerant Long Line Description ft (m) Beyond these lengths, a TXV is required
Total Length Outdoor Unit Above or Below Indoor Unit
TXV required beyond 50 ft. (15.2 m) TXV required beyond 20 ft. (6.1 m)
AC with R−410A Refrigerant Long Line Description ft (m) (Beyond these lengths, long line accessories are required)
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
1/4 + TXV No accessories needed within al
lowed lengths
No accessories needed within
allowed lengths 175 (53.3)
5/16 + TXV 120 (36.6) 50 (15.2) vertical or 120 (36.6) total 120 (36.6)
3/8 + TXV 80 (24.4) 35 (10.7) vertical or 80 (24.4) total 80 (24.4)
Note: See Long Line Guideline for details
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
421 51 6240 04 7
Specifications subject to change without notice.
R−410A COOLING CAPACITY LOSS FOR VARIOUS LINE LENGTHS & TUBE DIAMETERS
Model
Size
Liquid
Line
in.(mm)
Acceptable
Vapor Line
Sizes
in. (mm)
Cooling Capacity Loss (%) at Total Equivalent Line Length, feet (m)
Refer to Long Line Application Guideline to calculate equivalent length
Standard Application Long Line Application (Requires Accessories)
25’
(7.6)
50’
(15.2)
80’
(24.4)
81’
(24.7)
100’
(30.5)
125’
(38.1)
150’
(45.7)
175’
(53.3)
200’
(61)
225’
(68.6)
250’
(76.2)
18
3/8 (10)
1/2 (13) 1 2 3 3 4 6 7 8 9 10 12
5/8 (16) 001 11122333
3/4 (19) 000 00111111
24
5/8 (16) 011 12334456
3/4 (19) 000 00111112
7/8 (22) 000 00000001
30
5/8 (16) 123 33456789
3/4 (19) 001 11122233
7/8 (22) 000 00111111
36
5/8 (16) 1 2 4 4 5 6 7 9 10 11 13
3/4 (19) 001 11223344
7/8 (22) 000 00111122
42
3/4 (19) 012 22344566
7/8 (22) 001 11122233
1−1/8 (29) 00000000001
48
3/4 (19) 012 23455678
7/8 (22) 001 11222334
1−1/8 (29) 00000000111
60
3/4 (19) 1 2 4 4 5 6 7 9 10 11 12
7/8 (22) 012 22344556
1−1/8(29) 00001111112
Consult the Long Line Application Guideline document before purchasing/installing line sets.
Applications in shaded area may have height restrictions that limit allowable total equivalent length when outdoor unit is
below indoor unit.
COOLING PERFORMANCE FOR COMBINATION RATINGS Indoor Models
For complete ratings information, use the AHRI website directory search: www.AHRIdirectory.org.
New ratings may be listed online before Specification Sheets are updated.
Unit Size
INDOOR
MODEL
AHRI STANDARD RATINGS
FURNACE
MODEL
COOLING
CAPACITY
FACTORY
ENHANCE
SEER
EER
STANDARD TDR TXV
NXA418GKC EA*4X19L17A* 17,500 TXV 14.00 11.70
NXA424GKC EA*4X25L17A* 23,400 TXV 14.00 11.70
NXA430GKC EA*4X37L21A* 29,600 TXV 14.50 12.00
NXA436GKC EA*4X37L21A* 34,200 TXV 14.00 12.00
NXA442GKC EA*4X43L21A* 38,500 TXV 14.00 12.00
NXA448GKC EA*4X61L24A* 45,000 TXV 14.50 11.70
NXA460GKC EA*4X60L24A* 56,500 TXV 14.00 11.70
TESTED AHRI COMBINATION RATINGS* Or scan this QR code:
NOTE: Ratings contained in this document are subject to change at any time.
For AHRI ratings certificates, please refer to the AHRI directory. www.ahridirectory.org
Additional ratings and system combinations can be accessed via the Airquest database:
http://www.icpeqp.com/AHRIratings/ratings.aspx?Brand=Airquest
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
8421 51 6240 04
Specifications subject to change without notice.
EXPANDED COOLING PERFORMANCE RATINGS For Outdoor / Indoor Models #
For complete ratings information, use the AHRI website directory search: www.AHRIdirectory.org.
New ratings may be listed online before Specification Sheets are updated.
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total
Sens
‡
NXA418GKC Outdoor Section With EA*4X30L17** Indoor Section
525
72 20.84 11.15 1.18 20.08 10.86 1.33 19.26 10.56 1.49 18.34 10.22 1.67 17.28 9.84 1.89 16.07 9.40 2.13
67 19.05 13.80 1.19 18.30 13.49 1.34 17.50 13.16 1.50 16.60 12.80 1.68 15.58 12.39 1.89 14.40 11.93 2.13
63{{ 17.78 13.32 1.20 17.04 12.99 1.34 16.24 12.64 1.50 15.35 12.25 1.68 14.35 11.82 1.89 13.21 11.33 2.14
62 17.42 16.39 1.20 16.70 16.06 1.34 15.92 15.68 1.50 15.12 15.12 1.68 14.34 14.34 1.89 13.45 13.45 2.13
57 17.00 17.00 1.20 16.41 16.41 1.34 15.79 15.79 1.50 15.10 15.10 1.68 14.32 14.32 1.89 13.43 13.43 2.13
600
72 21.18 11.76 1.21 20.40 11.48 1.35 19.56 11.17 1.52 18.61 10.83 1.70 17.52 10.45 1.92 16.27 10.01 2.16
67 19.36 14.78 1.22 18.61 14.48 1.36 17.78 14.15 1.52 16.86 13.79 1.71 15.81 13.37 1.92 14.62 12.90 2.16
63{{ 18.10 14.24 1.23 17.35 13.91 1.37 16.53 13.56 1.53 15.62 13.17 1.71 14.59 12.73 1.92 13.42 12.24 2.16
62 17.79 17.69 1.23 17.14 17.14 1.37 16.49 16.49 1.53 15.76 15.76 1.71 14.94 14.94 1.92 14.00 14.00 2.16
57 17.72 17.72 1.23 17.11 17.11 1.37 16.46 16.46 1.53 15.74 15.74 1.71 14.92 14.92 1.92 13.98 13.98 2.16
675
72 21.42 12.36 1.23 20.63 12.08 1.38 19.76 11.77 1.55 18.80 11.43 1.73 17.69 11.05 1.94 16.41 10.61 2.19
67 19.60 15.75 1.25 18.83 15.44 1.39 17.99 15.11 1.55 17.05 14.75 1.73 15.99 14.33 1.95 14.77 13.85 2.19
63{{ 18.34 15.14 1.26 17.57 14.81 1.40 16.74 14.45 1.56 15.82 14.06 1.74 14.77 13.61 1.95 13.59 13.10 2.19
62 18.33 18.33 1.25 17.71 17.71 1.40 17.04 17.04 1.55 16.28 16.28 1.74 15.43 15.43 1.95 14.46 14.46 2.19
57 18.31 18.31 1.25 17.68 17.68 1.40 17.01 17.01 1.55 16.26 16.26 1.74 15.41 15.41 1.95 14.44 14.44 2.19
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total
Sens
‡
NXA424GKC Outdoor Section With EA*4X25L17* Indoor Section
700
72 27.81 14.89 1.62 26.74 14.49 1.80 25.61 14.07 2.00 24.39 13.62 2.23 23.06 13.14 2.51 21.56 12.60 2.83
67 25.46 18.45 1.62 24.46 18.04 1.80 23.40 17.61 2.00 22.25 17.13 2.23 21.01 16.63 2.51 19.58 16.06 2.83
63{{ 23.79 17.82 1.62 22.84 17.40 1.80 21.83 16.94 2.00 20.74 16.47 2.24 19.53 15.94 2.52 18.16 15.36 2.85
62 23.31 21.92 1.62 22.38 21.48 1.80 21.40 21.01 2.00 20.37 20.37 2.24 19.43 19.43 2.51 18.33 18.33 2.84
57 22.74 22.74 1.62 22.00 22.00 1.80 21.20 21.20 2.00 20.34 20.34 2.24 19.39 19.39 2.51 18.30 18.30 2.84
800
72 28.26 15.70 1.66 27.15 15.30 1.84 25.97 14.87 2.04 24.70 14.42 2.27 23.33 13.94 2.54 21.80 13.40 2.87
67 25.87 19.75 1.66 24.84 19.33 1.84 23.75 18.90 2.04 22.56 18.42 2.27 21.27 17.91 2.55 19.81 17.34 2.87
63{{ 24.22 19.04 1.66 23.25 18.61 1.84 22.19 18.15 2.04 21.05 17.67 2.28 19.82 17.14 2.55 18.40 16.54 2.88
62 23.79 23.64 1.66 22.94 22.94 1.84 22.09 22.09 2.04 21.17 21.17 2.27 20.16 20.16 2.55 19.00 19.00 2.87
57 23.69 23.69 1.66 22.90 22.90 1.84 22.06 22.06 2.04 21.14 21.14 2.27 20.13 20.13 2.55 18.98 18.98 2.87
900
72 28.57 16.50 1.70 27.42 16.10 1.87 26.21 15.67 2.08 24.91 15.21 2.31 23.51 14.73 2.58 21.94 14.19 2.90
67 26.18 21.03 1.70 25.11 20.60 1.88 23.99 20.16 2.08 22.77 19.68 2.31 21.46 19.16 2.58 19.98 18.58 2.91
63{{ 24.53 20.22 1.70 23.52 19.79 1.88 22.44 19.33 2.08 21.28 18.83 2.32 20.02 18.30 2.59 18.58 17.68 2.92
62 24.50 24.50 1.70 23.67 23.67 1.88 22.78 22.78 2.08 21.82 21.82 2.31 20.76 20.76 2.59 19.55 19.55 2.91
57 24.47 24.47 1.70 23.64 23.64 1.88 22.75 22.75 2.08 21.79 21.79 2.31 20.73 20.73 2.59 19.52 19.52 2.91
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
421 51 6240 04 9
Specifications subject to change without notice.
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total
Sens
‡
NXA430GKC Outdoor Section With EA*4X37L21A* Indoor Section
875
72 34.17 17.94 1.96 32.63 17.38 2.16 31.02 16.79 2.40 29.33 16.18 2.66 27.51 15.54 2.98 25.57 14.86 3.35
67 31.02 22.10 1.97 29.61 21.53 2.17 28.14 20.94 2.40 26.58 20.31 2.66 24.91 19.66 2.98 23.13 18.96 3.35
63{{ 28.77 21.25 1.97 27.46 20.67 2.17 26.08 20.08 2.40 24.62 19.45 2.67 23.07 18.79 2.98 21.39 18.09 3.35
62 28.19 26.15 1.97 26.92 25.56 2.17 25.60 25.36 2.40 24.34 24.34 2.66 23.11 23.11 2.98 21.76 21.76 3.35
57 27.51 27.51 1.97 26.51 26.51 2.17 25.45 25.45 2.40 24.30 24.30 2.66 23.07 23.07 2.98 21.73 21.73 3.35
1000
72 34.79 18.95 2.01 33.19 18.37 2.21 31.51 17.78 2.44 29.73 17.16 2.71 27.85 16.51 3.03 25.85 15.82 3.40
67 31.61 23.69 2.01 30.13 23.11 2.21 28.60 22.50 2.44 26.98 21.87 2.71 25.25 21.19 3.03 23.42 20.49 3.40
63{{ 29.34 22.73 2.02 27.97 22.14 2.22 26.53 21.53 2.45 25.01 20.89 2.71 23.40 20.21 3.03 21.68 19.49 3.40
62 28.87 28.71 2.01 27.71 27.71 2.22 26.56 26.56 2.45 25.33 25.33 2.71 24.00 24.00 3.03 22.57 22.57 3.40
57 28.75 28.75 2.01 27.66 27.66 2.22 26.52 26.52 2.45 25.29 25.29 2.71 23.97 23.97 3.03 22.54 22.54 3.40
1125
72 35.24 19.93 2.06 33.57 19.35 2.26 31.84 18.74 2.49 30.02 18.11 2.76 28.08 17.45 3.08 26.02 16.75 3.45
67 32.05 25.24 2.06 30.53 24.64 2.26 28.94 24.02 2.49 27.27 23.37 2.76 25.51 22.69 3.08 23.63 21.95 3.45
63{{ 29.77 24.16 2.06 28.34 23.56 2.26 26.86 22.94 2.49 25.30 22.28 2.76 23.65 21.59 3.08 21.90 20.83 3.45
62 29.83 29.83 2.06 28.67 28.67 2.26 27.45 27.45 2.49 26.15 26.15 2.76 24.74 24.74 3.07 23.23 23.23 3.45
57 29.79 29.79 2.06 28.63 28.63 2.26 27.41 27.41 2.49 26.11 26.11 2.76 24.71 24.71 3.07 23.20 23.20 3.45
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total
Sens
‡
NXA436GKC Outdoor Section With EA*4X37L21A* Indoor Section
1050
72 41.01 22.33 2.30 39.34 21.71 2.58 37.16 20.92 2.85 34.76 20.05 3.16 32.31 19.19 3.53 29.95 18.38 4.00
67 38.18 28.11 2.30 36.67 27.49 2.57 34.60 26.64 2.84 32.34 25.73 3.14 30.03 24.81 3.50 27.81 23.93 3.98
63{{ 35.95 27.24 2.31 34.52 26.60 2.58 32.59 25.75 2.84 30.42 24.81 3.13 28.19 23.85 3.50 26.15 22.98 3.98
62 35.34 33.63 2.31 33.97 32.97 2.57 32.13 32.02 2.83 30.31 30.31 3.13 28.47 28.47 3.50 26.72 26.72 3.98
57 34.72 34.72 2.32 33.59 33.59 2.58 32.04 32.04 2.84 30.27 30.27 3.13 28.43 28.43 3.50 26.69 26.69 3.98
1200
72 41.38 23.50 2.36 39.65 22.88 2.64 37.35 22.06 2.91 34.95 21.21 3.22 32.45 20.34 3.59 30.04 19.50 4.06
67 38.62 30.04 2.36 37.06 29.41 2.63 34.94 28.56 2.90 32.63 27.64 3.20 30.27 26.71 3.56 27.99 25.80 4.04
63{{ 36.46 29.05 2.37 34.99 28.41 2.63 32.98 27.54 2.89 30.76 26.59 3.19 28.46 25.61 3.55 26.38 24.71 4.04
62 36.09 35.91 2.37 34.84 34.84 2.63 33.16 33.16 2.89 31.29 31.29 3.19 29.34 29.34 3.56 27.44 27.44 4.04
57 36.00 36.00 2.37 34.79 34.79 2.63 33.12 33.12 2.89 31.24 31.24 3.19 29.30 29.30 3.56 27.42 27.42 4.04
1350
72 41.60 24.63 2.42 39.82 24.00 2.70 37.54 23.20 2.97 35.04 22.33 3.28 32.50 21.46 3.65 30.06 20.63 4.12
67 38.92 31.92 2.41 37.32 31.28 2.68 35.15 30.42 2.95 32.81 29.49 3.26 30.41 28.52 3.62 28.13 27.55 4.10
63{{ 36.82 30.81 2.42 35.31 30.16 2.69 33.26 29.28 2.95 31.00 28.31 3.25 28.69 27.30 3.62 26.56 26.31 4.10
62 37.07 37.07 2.42 35.77 35.77 2.68 33.98 33.98 2.95 32.01 32.01 3.25 29.98 29.98 3.62 27.99 27.99 4.10
57 37.02 37.02 2.42 35.73 35.73 2.68 33.95 33.95 2.95 31.98 31.98 3.25 29.95 29.95 3.62 27.97 27.97 4.10
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total
Sens
‡
NXA442GKC Outdoor Section With EB*4X43L21 Indoor Section
1225
72 46.79 25.57 2.60 44.65 24.77 2.86 42.40 23.95 3.15 40.04 23.09 3.47 37.52 22.19 3.84 34.83 21.24 4.26
67 42.38 31.68 2.61 40.45 30.89 2.86 38.42 30.07 3.15 36.27 29.20 3.47 33.99 28.29 3.84 31.54 27.32 4.25
63{{ 39.24 30.38 2.61 37.46 29.59 2.86 35.58 28.77 3.15 33.58 27.91 3.47 31.47 26.99 3.83 29.19 26.02 4.24
62 38.60 37.63 2.61 36.93 36.70 2.86 35.35 35.35 3.14 33.75 33.75 3.47 32.02 32.02 3.83 30.14 30.14 4.24
57 38.17 38.17 2.61 36.78 36.78 2.86 35.29 35.29 3.14 33.70 33.70 3.47 31.98 31.98 3.83 30.10 30.10 4.24
1400
72 47.55 27.01 2.67 45.33 26.20 2.93 42.99 25.37 3.21 40.52 24.49 3.54 37.91 23.57 3.91 35.15 22.61 4.32
67 43.11 33.98 2.67 41.10 33.17 2.93 38.99 32.32 3.21 36.77 31.44 3.54 34.41 30.50 3.90 31.91 29.50 4.32
63{{ 39.94 32.51 2.67 38.08 31.70 2.93 36.14 30.86 3.21 34.06 29.97 3.54 31.88 29.03 3.90 29.56 28.02 4.31
62 39.87 39.87 2.67 38.37 38.37 2.93 36.76 36.76 3.21 35.04 35.04 3.54 33.19 33.19 3.90 31.17 31.17 4.32
57 39.81 39.81 2.67 38.31 38.31 2.93 36.71 36.71 3.21 34.99 34.99 3.54 33.14 33.14 3.90 31.13 31.13 4.31
1575
72 48.11 28.39 2.74 45.80 27.57 2.99 43.39 26.72 3.28 40.85 25.83 3.61 38.17 24.91 3.98 35.33 23.93 4.39
67 43.66 36.19 2.74 41.58 35.36 2.99 39.41 34.49 3.28 37.13 33.57 3.60 34.73 32.60 3.97 32.20 31.50 4.38
63{{ 40.46 34.55 2.74 38.54 33.72 2.99 36.53 32.85 3.28 34.42 31.93 3.60 32.20 30.94 3.97 29.88 29.72 4.38
62 41.18 41.18 2.74 39.58 39.58 2.99 37.88 37.88 3.28 36.06 36.06 3.60 34.10 34.10 3.97 31.98 31.98 4.38
57 41.12 41.12 2.74 39.53 39.53 2.99 37.83 37.83 3.28 36.01 36.01 3.60 34.05 34.05 3.97 31.94 31.94 4.38
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
10 421 51 6240 04
Specifications subject to change without notice.
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total
Sens
‡
NXA448GKC Outdoor Section With EA*4X61L24* Indoor Section
1400
72 53.91 26.70 3.12 51.70 25.95 3.46 49.29 25.14 3.81 46.61 24.25 4.20 43.50 23.23 4.66 39.94 22.07 5.22
67 49.07 33.08 3.15 47.03 32.30 3.47 44.83 31.48 3.81 42.36 30.56 4.19 39.52 29.52 4.65 36.26 28.33 5.22
63{{ 45.60 31.80 3.16 43.67 31.02 3.48 41.61 30.19 3.81 39.31 29.27 4.18 36.66 28.22 4.64 33.61 27.02 5.22
62 44.81 39.26 3.16 42.96 38.43 3.48 41.03 40.90 3.80 39.14 39.14 4.18 36.99 36.99 4.64 34.49 34.49 5.22
57 44.02 44.02 3.16 42.51 42.51 3.48 40.91 40.91 3.80 39.08 39.08 4.18 36.94 36.94 4.64 34.44 34.44 5.22
1600
72 54.74 28.18 3.20 52.46 27.42 3.54 49.97 26.60 3.89 47.17 25.68 4.28 43.95 24.64 4.74 40.30 23.48 5.30
67 49.91 35.43 3.22 47.78 34.64 3.55 45.50 33.80 3.89 42.95 32.87 4.27 40.01 31.79 4.73 36.67 30.58 5.30
63{{ 46.41 33.99 3.23 44.41 33.19 3.55 42.28 32.35 3.89 39.89 31.40 4.26 37.15 30.32 4.72 34.04 29.09 5.30
62 45.97 45.97 3.23 44.36 44.36 3.55 42.62 42.62 3.89 40.65 40.65 4.27 38.35 38.35 4.73 35.68 35.68 5.30
57 45.90 45.90 3.23 44.29 44.29 3.55 42.56 42.56 3.89 40.59 40.59 4.27 38.30 38.30 4.73 35.63 35.63 5.30
1800
72 55.35 29.59 3.27 53.00 28.82 3.62 50.43 27.99 3.97 47.55 27.07 4.35 44.26 26.02 4.82 40.51 24.83 5.38
67 50.51 37.70 3.29 48.34 36.90 3.63 45.99 36.05 3.97 43.37 35.09 4.35 40.38 33.98 4.81 37.00 32.68 5.38
63{{ 47.02 36.10 3.31 44.97 35.29 3.63 42.77 34.42 3.97 40.33 33.45 4.34 37.54 32.33 4.81 34.39 30.98 5.38
62 47.51 47.51 3.31 45.80 45.80 3.63 43.96 43.96 3.97 41.87 41.87 4.35 39.44 39.44 4.81 36.63 36.63 5.38
57 47.45 47.45 3.31 45.74 45.74 3.63 43.91 43.91 3.97 41.82 41.82 4.35 39.40 39.40 4.81 36.58 36.58 5.38
EVAPORA-
TOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F (°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F
Capacity
MBtuh
Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Capacity
MBtuh
Total
Sys
tem
KW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡
NXA460GKC Outdoor Section With EA*4X60L24A* Indoor Section
1750
72 68.41 35.82 4.01 65.35 34.67 4.39 62.15 33.49 4.86 58.70 32.23 5.39 55.01 30.89 5.96 50.87 29.41 6.55
67 62.24 44.04 4.01 59.41 42.88 4.38 56.50 41.69 4.83 53.38 40.43 5.35 50.00 39.08 5.91 46.23 37.59 6.49
63{{ 57.78 42.37 4.02 55.13 41.19 4.37 52.41 39.99 4.81 49.54 38.75 5.32 46.39 37.40 5.87 42.89 35.91 6.45
62 56.92 52.17 4.02 54.40 50.96 4.37 51.84 49.69 4.81 49.16 49.16 5.32 46.64 46.64 5.88 43.73 43.73 6.46
57 55.64 55.64 4.02 53.56 53.56 4.37 51.43 51.43 4.81 49.13 49.13 5.32 46.56 46.56 5.88 43.68 43.68 6.46
2000
72 69.54 37.55 4.10 66.36 36.39 4.49 63.04 35.18 4.96 59.50 33.91 5.49 55.63 32.53 6.06 51.36 31.03 6.66
67 63.30 46.83 4.11 60.35 45.64 4.47 57.34 44.44 4.93 54.11 43.16 5.45 50.61 41.77 6.01 46.74 40.24 6.60
63{{ 58.79 44.95 4.11 56.04 43.76 4.47 53.23 42.55 4.91 50.24 41.27 5.42 47.00 39.89 5.98 43.39 38.33 6.56
62 58.25 55.83 4.11 55.72 55.33 4.47 53.37 53.37 4.91 50.91 50.91 5.43 48.16 48.16 5.99 45.09 45.09 6.58
57 57.80 57.80 4.11 55.59 55.59 4.47 53.30 53.30 4.91 50.84 50.84 5.43 48.11 48.11 5.99 45.03 45.03 6.58
2250
72 70.37 39.17 4.20 67.10 37.99 4.59 63.67 36.77 5.06 60.02 35.48 5.59 56.04 34.08 6.17 51.66 32.55 6.76
67 64.08 49.47 4.20 61.08 48.28 4.57 57.95 47.04 5.03 54.64 45.73 5.55 51.07 44.31 6.12 47.12 42.69 6.70
63{{ 59.56 47.41 4.20 56.73 46.20 4.56 53.82 44.95 5.01 50.77 43.65 5.52 47.44 42.21 6.08 43.78 40.57 6.66
62 59.69 59.69 4.20 57.32 57.32 4.56 54.90 54.90 5.02 52.28 52.28 5.53 49.41 49.41 6.10 46.17 46.17 6.69
57 59.58 59.58 4.20 57.25 57.25 4.56 54.83 54.83 5.02 52.23 52.23 5.53 49.35 49.35 6.10 46.12 46.12 6.69
} Sensible capacities shown are based on 80_F (27_C) entering air at the indoor coil. For sensible capacities at other than 80_F (27_C), deduct 835 Btuh (245 kW) per 1000 CFM (480 L/S) of
indoor coil air for each degree below 80_F (27_C), or add 835 Btuh
(245 kW) per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F (27_C).
# Expanded cooling capacities are based on indoor and outdoor unit at the same elevation per AHRI standard 210/240-2008. If additional tubing length and/or indoor unit is located above
outdoor unit, a slight variation in capacity may occur.
** System kw is total of indoor and outdoor unit kilowatts.
{{ At TVA rating indoor condition (75_F edb/63_F ewb). All other indoor air temperatures are at 80_F edb.
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
EWB — Entering Wet Bulb
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
421 51 6240 04 11
Specifications subject to change without notice.
CONDENSER ONLY RATINGS
SST
°F (°C) CONDENSER ENTERING AIR TEMPERATURES °F (°C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
NXA418GKC
30
(1.11)
TCG 16.00 14.90 13.90 12.90 12.00 10.90 9.80 8.60
SDT 73.60 83.20 92.80 102.60 112.40 122.40 132.30 142.40
KW 0.77 0.88 0.99 1.12 1.27 1.44 1.65 1.88
35
(1.67)
TCG 17.60 16.50 15.40 14.40 13.40 12.20 11.00 9.80
SDT 75.00 84.60 94.30 104.00 113.80 123.50 133.50 143.50
KW 0.77 0.88 1.00 1.13 1.28 1.46 1.66 1.90
40
(4.44)
TCG 19.40 18.20 17.10 16.00 14.90 13.70 12.40 11.00
SDT 76.50 86.10 95.80 105.40 115.00 124.80 134.60 144.60
KW 0.77 0.88 1.00 1.14 1.29 1.47 1.67 1.91
45
(7.22)
TCG 21.20 20.00 18.90 17.70 16.50 15.20 13.80 12.30
SDT 78.00 87.50 97.10 106.70 116.40 126.10 135.90 145.70
KW 0.77 0.88 1.01 1.14 1.30 1.48 1.69 1.93
50
(10.0)
TCG 23.20 22.00 20.80 19.50 18.30 16.90 15.40 13.80
SDT 79.30 88.90 98.50 108.10 117.70 127.40 137.10 146.90
KW 0.76 0.88 1.01 1.15 1.30 1.49 1.70 1.94
55
(12.78)
TCG 25.30 24.00 22.80 21.50 20.10 18.70 17.10 15.40
SDT 80.80 90.40 100.00 109.50 119.10 128.80 138.40 148.00
KW 0.75 0.87 1.00 1.15 1.31 1.50 1.71 1.95
NXA424GKC
30
(1.11)
TCG 21.30 20.10 18.90 17.70 16.60 15.40 14.20 13.00
SDT 69.90 79.40 88.80 98.30 107.80 117.30 126.70 136.10
KW 1.05 1.21 1.37 1.54 1.74 1.96 2.22 2.52
35
(1.67)
TCG 23.40 22.10 20.80 19.60 18.30 17.10 15.80 14.40
SDT 71.10 80.60 90.00 99.50 108.90 118.20 127.50 136.90
KW 1.06 1.21 1.37 1.54 1.74 1.96 2.22 2.52
40
(4.44)
TCG 25.60 24.20 22.90 21.50 20.20 18.80 17.40 15.90
SDT 72.40 81.80 91.20 100.60 109.80 119.10 128.40 137.70
KW 1.06 1.21 1.37 1.55 1.74 1.97 2.22 2.53
45
(7.22)
TCG 28.00 26.50 25.10 23.60 22.10 20.60 19.00 17.40
SDT 73.80 83.20 92.40 101.70 110.90 120.20 129.40 138.60
KW 1.07 1.22 1.37 1.55 1.74 1.97 2.23 2.53
50
(10.0)
TCG 30.50 28.90 27.30 25.80 24.10 22.50 20.80 19.00
SDT 75.20 84.40 93.70 102.90 112.10 121.20 130.40 139.60
KW 1.07 1.22 1.37 1.55 1.74 1.97 2.23 2.53
55
(12.78)
TCG 33.20 31.50 29.80 28.00 26.20 24.40 22.60 20.70
SDT 76.70 85.80 95.00 104.20 113.30 122.40 131.50 140.60
KW 1.07 1.22 1.38 1.55 1.75 1.97 2.23 2.53
NXA430GKC
30
(1.11)
TCG 24.90 23.60 22.30 21.00 19.60 18.30 16.80 15.20
SDT 68.80 78.20 87.70 97.20 106.60 116.00 125.40 134.80
KW 1.22 1.39 1.56 1.74 1.95 2.19 2.47 2.80
35
(1.67)
TCG 27.40 26.00 24.60 23.20 21.70 20.20 18.60 16.90
SDT 70.00 79.40 88.80 98.10 107.50 116.90 126.20 135.50
KW 1.23 1.39 1.56 1.75 1.96 2.20 2.48 2.81
40
(4.44)
TCG 30.10 28.60 27.00 25.50 23.90 22.20 20.50 18.70
SDT 71.30 80.60 89.90 99.20 108.50 117.80 127.10 136.40
KW 1.24 1.40 1.57 1.76 1.97 2.21 2.49 2.82
45
(7.22)
TCG 33.10 31.40 29.70 28.00 26.30 24.50 22.60 20.60
SDT 72.70 81.90 91.10 100.40 109.60 118.90 128.10 137.30
KW 1.24 1.40 1.57 1.76 1.97 2.22 2.50 2.83
50
(10.0)
TCG 36.20 34.40 32.50 30.70 28.80 26.80 24.80 22.60
SDT 74.20 83.20 92.40 101.60 110.80 120.00 129.10 138.20
KW 1.25 1.41 1.58 1.77 1.98 2.22 2.51 2.84
55
(12.78)
TCG 39.60 37.60 35.60 33.50 31.50 29.30 27.10 24.80
SDT 75.70 84.70 93.80 102.90 112.00 121.10 130.20 139.20
KW 1.25 1.41 1.58 1.77 1.98 2.23 2.52 2.85
NXA436GKC
30
(1.11)
TCG 26.10 27.90 27.70 26.40 24.50 22.40 20.20 18.30
SDT 67.10 78.20 88.40 98.00 107.30 116.50 125.70 135.10
KW 1.34 1.73 2.00 2.24 2.48 2.75 3.08 3.51
35
(1.67)
TCG 29.80 31.20 30.80 29.30 27.20 24.90 22.60 20.50
SDT 68.60 79.50 89.50 98.90 108.10 117.30 126.50 135.80
KW 1.33 1.71 1.99 2.23 2.47 2.74 3.07 3.51
40
(4.44)
TCG 33.60 34.60 33.90 32.20 30.00 27.50 25.10 22.80
SDT 70.00 80.80 90.50 99.80 109.10 118.20 127.30 136.60
KW 1.31 1.69 1.97 2.21 2.46 2.73 3.07 3.50
45
(7.22)
TCG 37.30 38.00 37.10 35.20 32.70 30.10 27.50 25.10
SDT 71.40 81.80 91.50 100.80 110.00 119.00 128.10 137.30
KW 1.30 1.67 1.95 2.20 2.45 2.73 3.07 3.50
50
(10.0)
TCG 41.00 41.30 40.10 38.00 35.40 32.60 29.80 27.30
SDT 72.60 82.80 92.40 101.70 110.80 119.80 128.90 138.00
KW 1.28 1.65 1.94 2.19 2.45 2.74 3.08 3.51
55
(12.78)
TCG 44.50 44.50 43.00 40.70 37.90 34.90 32.00 29.20
SDT 73.70 83.80 93.40 102.60 111.70 120.60 129.60 138.70
KW 1.26 1.64 1.94 2.20 2.46 2.75 3.09 3.53
See notes on page 12
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
12 421 51 6240 04
Specifications subject to change without notice.
CONDENSER ONLY RATINGS CONTINUED
SST
°F (°C) CONDENSER ENTERING AIR TEMPERATURES °F (°C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
NXA442GKC
30
(1.11)
TCG 33.60 32.00 30.40 28.70 26.90 25.00 23.10 21.00
SDT 67.80 77.30 86.90 96.50 106.00 115.50 125.00 134.40
KW 1.73 1.92 2.14 2.39 2.66 2.97 3.31 3.70
35
(1.67)
TCG 37.10 35.30 33.50 31.60 29.70 27.60 25.50 23.30
SDT 69.00 78.50 88.00 97.50 107.00 116.40 125.70 135.10
KW 1.73 1.93 2.15 2.40 2.67 2.98 3.33 3.71
40
(4.44)
TCG 40.80 38.90 36.90 34.80 32.70 30.50 28.10 25.70
SDT 70.20 79.70 89.10 98.60 108.00 117.30 126.50 135.80
KW 1.74 1.94 2.16 2.41 2.68 2.99 3.34 3.73
45
(7.22)
TCG 44.90 42.70 40.50 38.20 35.90 33.50 31.00 28.30
SDT 71.60 80.90 90.30 99.60 108.90 118.20 127.40 136.60
KW 1.74 1.94 2.17 2.41 2.69 3.00 3.35 3.74
50
(10.0)
TCG 49.30 46.90 44.40 42.00 39.40 36.70 34.00 31.10
SDT 73.00 82.30 91.50 100.70 110.00 119.20 128.30 137.50
KW 1.75 1.95 2.17 2.42 2.70 3.01 3.36 3.76
55
(12.78)
TCG 54.00 51.40 48.70 45.90 43.10 40.20 37.20 34.10
SDT 74.50 83.60 92.80 101.90 111.10 120.20 129.30 138.40
KW 1.75 1.95 2.17 2.42 2.71 3.02 3.38 3.77
NXA448GKC
30
(1.11)
TCG 40.80 38.00 35.60 33.50 31.40 29.10 26.60 23.70
SDT 69.00 78.10 87.30 96.60 106.00 115.30 124.50 133.70
KW 2.01 2.38 2.69 2.97 3.28 3.65 4.13 4.75
35
(1.67)
TCG 44.70 41.80 39.30 37.10 34.80 32.30 29.50 26.40
SDT 70.30 79.30 88.50 97.70 107.00 116.30 125.40 134.60
KW 1.99 2.37 2.69 2.99 3.30 3.67 4.14 4.75
40
(4.44)
TCG 48.90 45.90 43.30 40.90 38.40 35.70 32.60 29.20
SDT 71.70 80.60 89.80 99.00 108.20 117.30 126.50 135.50
KW 1.97 2.36 2.69 3.00 3.32 3.69 4.16 4.76
45
(7.22)
TCG 53.30 50.30 47.60 45.00 42.20 39.30 35.90 32.20
SDT 73.10 82.10 91.10 100.30 109.40 118.50 127.50 136.40
KW 1.94 2.35 2.69 3.01 3.34 3.71 4.18 4.76
50
(10.0)
TCG 58.10 55.00 52.10 49.30 46.30 43.10 39.40 35.30
SDT 74.70 83.60 92.60 101.70 110.70 119.70 128.60 137.40
KW 1.90 2.32 2.68 3.01 3.35 3.73 4.19 4.77
55
(12.78)
TCG 63.30 60.00 57.00 53.90 50.60 47.00 43.00 38.60
SDT 76.40 85.20 94.20 103.20 112.20 121.00 129.80 138.40
KW 1.86 2.30 2.67 3.01 3.36 3.74 4.20 4.77
NXA460GKC
30
(-1.11)
TCG 53.80 50.20 47.00 44.00 41.20 38.30 35.20 31.80
SDT 71.80 80.60 89.70 98.90 108.10 117.40 126.50 135.60
KW 3.08 3.18 3.40 3.73 4.14 4.62 5.14 5.69
35
(1.67)
TCG 59.10 55.20 51.70 48.60 45.50 42.30 38.80 35.10
SDT 73.20 82.00 91.00 100.10 109.30 118.50 127.60 136.60
KW 3.06 3.17 3.40 3.73 4.15 4.63 5.16 5.71
40
(4.44)
TCG 64.70 60.60 56.90 53.50 50.00 46.50 42.80 38.70
SDT 74.70 83.40 92.40 101.40 110.60 119.70 128.70 137.60
KW 3.03 3.16 3.39 3.73 4.16 4.65 5.18 5.74
45
(7.22)
TCG 70.70 66.40 62.40 58.70 54.90 51.10 46.90 42.50
SDT 76.30 85.00 93.90 102.90 112.00 121.00 129.90 138.70
KW 3.01 3.14 3.39 3.74 4.17 4.67 5.21 5.77
50
(10.0)
TCG 77.20 72.60 68.40 64.30 60.20 55.90 51.40 46.60
SDT 78.20 86.80 95.60 104.50 113.50 122.40 131.20 139.80
KW 2.97 3.12 3.38 3.75 4.20 4.70 5.25 5.81
55
(12.78)
TCG 84.20 79.30 74.70 70.30 65.80 61.10 56.10 50.80
SDT 80.20 88.80 97.50 106.30 115.10 123.90 132.50 141.00
KW 2.93 3.10 3.39 3.76 4.22 4.74 5.29 5.86
* AHRI listing applies only to systems shown in Combination Ratings table.
KW - Outdoor Unit Kilowatts Only.
SDT - Saturated Temperature Leaving Compressor (°F)
SST - Saturated Temperature Entering Compressor (°F/°C)
TCG - Gross Cooling Capacity (1000 Btuh)
PRODUCT SPECIFICATIONS Split System Air Conditioner: NXA4
421 51 6240 04 13
Specifications subject to change without notice.
ACCESSORY USAGE GUIDELINES
Accessory
REQUIRED FOR
LOW−AMBIENT
APPLICATIONS
{Below 55°F (13°C)}
REQUIRED FOR
LONG−LINE
APPLICATIONS*
Crankcase Heater Yes Yes
Evaporator Freeze Thermostat Yes No
Winter Start Control Yes** No
TXV Yes Yesǂ
Hard Start Kit (Capacitor & Relay) Yes Yes
Low Ambient Kit (Pressure Switch) Yes No
Support Feet, 4” (102mm) tall Recommended No
* Refer to the Long Line Application Guideline document.
** Can only be installed in conjunction with the Low Pressure Switch
ǂ TXV required beyond 20 ft (6.1m) vertical separation or 50 ft (15.2) total length.
ACCESSORIES
Accessory Kit Number Description 18 24 30 36 42 48 60
NASA001CH Crankcase Heater for Scroll Compressor X X X
NASA003CH Crankcase Heater for Scroll Compressor X X X X
NASA001SC Start Component − PTC Device XXXXXXX
NASA00201FS Evaporator Freeze Thermostat XXXXXXX
NASA404PS High Pressure Switch XXXXXXX
NASA403PS Low Pressure Switch, AC, R−410A XXXXXXX
NASA401LS Liquid Line Solenoid Valve, R−410A XXXXXXX
NASA001TD Time Delay Relay, Indoor Blower XXXXXXX
NASA00201WS Winter Start Control XXXXXXX
NASA001AC Anti−Cycle Timer (5 minute delay) XXXXXXX
NASA404PS High Pressure Switch, AC or HP, R−410A XXXXXXX
NASA401LA Low Ambient Kit (Pressure Switch), R−410A XXXXXXX
NASA001SJ Sound Jacket, Compressor X X
NASA002SJ Sound Jacket, Compressor X X X
NASA003SJ Sound Jacket, Compressor X
NAEA40501TX TXV Kit for use with copper or tin fan coils X X X
NAEA40601TX TXV Kit for use with copper or tin fan coils X X
NAEA40701TX TXV Kit for use with copper or tin fan coils X
NAEB40501TX TXV Kit for use with aluminum fan coils X X X
NAEB40601TX TXV Kit for use with aluminum fan coils X X
NAEB40701TX TXV Kit for use with aluminum fan coils X
NASA00201SF Support Feet, 4” (102mm) tall (5 blocks) XXXXXXX
Copyright 2016 International Comfort Products
Lewisburg, Tennessee 37091 USA
www.GoAirquest.com
