Communications Systems | DCN‑IDESK Interpreter Desk

DCN‑IDESK Interpreter Desk

www.boschsecurity.com

uLow susceptibility to mobile phone interference

uErgonomic design with features for visually impaired

uUp to 31 interpretation channels and the original

floor language with an audio bandwidth of 20 kHz

uA graphic LCD with backlighting for bright

information display in dark conditions

u5 pre-select keys for relay languages with activation

indication at the display

The DCN-IDESK is a single-user interpreter desk with a

stylish and modern design. It fully conforms to

internationally agreed standards. Clear positioning per

functional area of the desk controls allows intuitive

operation without mistakes.

A socket is provided to connect the pluggable

microphones (DCN-MICS and DCN-MICL, to be

ordered separately).

Functions

• A maximum of six desks can be installed per booth

• Tabletop and flush mountable

• Pluggable microphone (DCN-MICS)

• Ergonomic design

Controls and Indicators

• A and B output channel with status and selection

indication at the display

• All channels have channel number, language names

and quality level indicated at the display

• Features for visually impaired such as a small bump

on the middle button, and beeps to indicate

microphone on/off and double relay selected

• Built-in loudspeaker with language channel selector

• Speech timer to indicate elapsed time of

interpretation

• Speak slowly facility to alert the current speaker to

slow down

• Help request to an operator or usher

• Booth telephone and intercom indicator

• Automatic headset selection when headset connected

• Easy programming via menus on the display after

entering the programming mode

• Microphone key with surrounding red “on-air”

indicator and green for “booth not in use”

• Mute key

• Help key

• Slow (speak slowly) key

• Operator and chairman intercom call keys

• Message key with yellow LED indicator

• Telephone and Intercom call yellow LED indicators

• A and B channel engaged yellow LED indicators

• Rotary step control for channel settings (and other

functions).

Pressing this button sets the selection to the first

available channel

• LCD with backlighting showing selected and activated

output channel with channel numbers and

abbreviated language names

• Loudspeaker rotary volume control

• Headphone rotary volume control

• Headphone rotary bass and treble tone controls

• Beep on/off key

• Five Relay language pre-select keys

• Floor/auto-relay key with green LED indicators

• Rotary step control (same as for speaking section) to

select the relay languages for the relay pre-select keys

and the loudspeaker channel. Pressing this button

sets the selection to the first available channel

• LCD with backlighting, showing selected relay

language with channel numbers, abbreviated names

and quality indicators. Also the selected loudspeaker

channel with abbreviated name is shown

Interconnections

• Socket for pluggable microphone

• Headphone or headset connector (five-pole 180° Din

type socket wired according to IEC 574-3)

• 6.3 mm (0.25 in) and 3.5 mm (0.14 in) stereo jack

headphone connectors

• 2 m (78.7 in) DCN cable with molded six-pole circular

connector

• Six-pole circular socket for loop-through connection

to the DCN network

• Eight-pole modular jack connector for connection to

booth telephone, intercom and booth on-air sign

Technical Specifications

Electrical

Headphone connection

Frequency response 30 Hz - 20 kHz

Load impedance > 32 ohm

Output power 2 x 30 mW/32 ohm

Headset connection

Frequency response 30 Hz - 20 kHz

Load impedance > 32 ohm

Output power 60 mW/32 ohm

Nominal microphone input

level

7 mVrms

Overload microphone input

level

> 124 mVrms

Mechanical

Mounting Free-standing or mounted on a table

Dimensions (H x W x D)

(with microphone)

82 x 330 x 170 mm (3.2 x 13 x 6.7 in)

Slope 25 degrees

Weight 1.3 kg (2.87 lb)

Color top Silver (RAL 9022)

Color base

DCN-IDESK-L Light grey (RAL 000 7500)

DCN-IDESK-D Charcoal (PH 10736)

Ordering Information

DCN‑IDESK‑L Interpreter Desk Light

with light base, microphone to be ordered separately

Order number DCN-IDESK-L

DCN‑MICS Pluggable Short Microphone

length 310 mm (12.2 inch), silver

Order number DCN-MICS

DCN‑MICL Pluggable Long Microphone

length 480 mm (18.9 inch), silver

Order number DCN-MICL

DCN‑IDESK‑D Interpreter Desk Dark

with dark base, microphone to be ordered separately

Order number DCN-IDESK-D

DCN‑MICS Pluggable Short Microphone

length 310 mm (12.2 inch), silver

Order number DCN-MICS

DCN‑MICL Pluggable Long Microphone

length 480 mm (18.9 inch), silver

Order number DCN-MICL

2 | DCN‑IDESK Interpreter Desk

3 | DCN‑IDESK Interpreter Desk
