Video | VIDEOJET multi 4000

VIDEOJET multi 4000

www.boschsecurity.com

u16 video input channels with Dual Streaming

uDeinterlacing at video input and progressive

encoding with H.264 High Profile

uNetwork-attached iSCSI recording

uMotion detection and privacy masking

uONVIF conformant

VIDEOJET multi 4000 from Bosch is a 16‑channel CCTV

video encoder that offers top-of-the-line Video-over-IP

performance for CCTV today.

The VIDEOJET multi 4000 H.264 High Profile encoder

delivers real-time H.264 compressed video over IPv4

and IPv6 networks. It provides Dual Streaming per

camera with full frame rate at best quality.

The unit supports PAL and NTSC sources and offers

bidirectional audio communication in parallel to video.

View the video on a PC using Bosch’s comprehensive

video management system, with or without Bosch’s

IntuiKey keyboard. Alternatively, use a Web browser.

Bosch VideoSDK provides the means to integrate the

encoder with other video management systems.

With 16 channels in a rack-mountable 1HU form factor

VIDEOJET multi 4000 offers the highest port density at

this quality of video. Its 1 Gbps Ethernet interface

allows to deliver IP video fast and with low delay.

System overview

1 VIDEOJET multi 4000 with 16 analog cameras, network-attached

iSCSI storage, or streaming only

2 Network-attached iSCSI RAID unit

3 Management station with CCTV keyboard

4 Decoder

5 Monitors

Functions

Flexibility

The encoder supports external iSCSI storage across an

IP network.

It also supports VRM (Video Recording Manager),

Bosch’s flexible and scalable recording management

software. This allows a flexible assignment of

recording space on camera level including load

balancing and decent redundancy features. VRM is

available as stand-alone system or embedded into

Bosch Video Management System.

Dual Streaming

The encoder uses the feature Dual Streaming to

generate two independent IP video streams per

channel at variable resolutions.

Recording

You can record each video input independently on

different media. Thus video can be recorded centrally

on iSCSI drives managed by VRM.

The encoder features a highly flexible recording

scheduler, providing up to ten programmable

recording profiles and allowing individually assigned

camera profiles. With these profiles, you can

accelerate the frame rate as well as increase the

quality on alarm, saving recording space during non-

alarm periods.

Access security

The encoder offers various security levels for

accessing the network, the unit, and the data

channels. As well as password protection with up to

three levels, they support 802.1x authentication using

a RADIUS server for identification. You can secure Web

browser access by HTTPS using an SSL certificate that

is stored in the unit. For total data protection, each

communication channel—video, audio, or serial I/O—

can be independently AES encrypted.

Intelligence

The encoder comes with built-in MOTION+ video

motion detection. This motion detection algorithm is

based on pixel change and includes object size

filtering capabilities.

On alarm, the device can send an e‑mail with JPEG

images attached.

Viewing

View the encoder video on a PC using a Web browser,

in Bosch Video Management System, or integrate it

into another video management system. By routing the

IP video to a high-performance VIDEOJET decoder or

to Monitor Wall, you can present the video with

ultimate clarity.

Easy upgrade

Remotely upgrade the device whenever new firmware

becomes available. This ensures up-to-date products,

thus protecting investment with little effort.

ONVIF conformance

Conformance to ONVIF 1.02 and ONVIF Profile S

provides interoperability between network video

products regardless of manufacturer. In addition, the

firmware of the device supports all applicable features

of the ONVIF 2.2 specification.

ONVIF conformant devices are able to exchange live

video, audio, metadata, and control information and

ensure that they are automatically discovered and

connected to network applications such as video

management systems.

Certifications and approvals

Safety

Region Number

IEC 60950

System

Region Number

IEC 62676-2

EN 50132-5-2

Electromagnetic Compatibility

Region Number

EU EN55022 ITE

EN55024 ITE

EN50130-4 Alarm systems

EN50121-4

EN61000-3-2

EN61000-3-3

US FCC 47 CFR, Part 15 Subpart B Class B

AU AS/NZS 3548 Class B

Approvals

Region Certification

Europe CE VIDEOJET multi 4000

USA UL Bosch UL online certifications directory

(link)

Installation/configuration notes

Stream 1 Stream 2

4CIF 25/30 fps 25/30 fps

2CIF 25/30 fps 25/30 fps

CIF 25/30 fps 25/30 fps

2 | VIDEOJET multi 4000

Dimensions

Dimensions in mm (in)

Front view

VIDEOJET multi 4000 front

1Factory reset button 4 LED STATUS

2LED ACTIVITY 5LED CONNECT

3LED LINK

Rear view

VIDEOJET multi 4000 rear

1VIDEO IN 1 to 16 4Alarm in, relay out, COM

(RS-232/422/485)

2 1 x 10/100/1000 Base‑T

Gigabit Ethernet

5AUDIO OUT

3AUDIO IN 6Power supply input

Parts included

VIDEOJET multi 4000

Quantity Component

1 VIDEOJET multi 4000

1 Accessory bag

1 Installation manual

1 Optional power cord

(only for specific countries, e.g. UK, Japan)

VIDEOJET multi 4000 EU/US

Quantity Component

1 VIDEOJET multi 4000 EU or

VIDEOJET multi 4000 US

1 Accessory bag

1 Installation manual

1 Power cord with IEC lock system

Technical specifications

Input/output

Video 16 x input

• connector BNC

• impedance 75 ohm, terminated

• signal Analog composite, 0.7 to 1.2 Vpp , NTSC or

PAL

Audio 2 x mono in, microphone/line

1 x mono line out

• connector 2 x 3.5 mm (1/8 in) stereo jack

• signal line in 9 kohm typical, 5.5 Vpp max, microphone

amplifier 60 dB max

• signal line out 3.0 Vpp at 10 kohm

Alarm 4 x input

• connector Clamp (non-isolated closing contact)

• activation

resistance

10 ohm max

Relay 1 x output

• connector Clamp

• signal 30 Vpp (SELV), 0.2 A

COM port Clamp, RS‑232/422/485

Video

Standards H.264 High Profile (ISO/IEC 14496‑10)

M‑JPEG

Data rates 9.6 kbps to 2 Mbps per channel

Resolution

(Horizontal x vertical

PAL/NTSC)

4CIF

704 x 576/480

GOP structure I, IP

Total delay 260 ms typical

Dual Streaming Full performance and full frame rate on both

streams for every video input channel

Frame rate 1 to 25/30 fps

3 | VIDEOJET multi 4000

Audio

AAC

• Profile AAC-LC

• Frequency

rate

300 Hz to 6.4 kHz

• Data rate 48/80 kbps at 16 kHz sampling rate

G.711

• Frequency

rate

300 Hz to 3.4 kHz

• Data rate 80 kbps at 8 kHz sampling rate

L16

• Frequency

rate

300 Hz to 6.4 kHz

• Data rate 640 kbps at 16 kHz sampling rate

Signal-to-noise ratio > 50 dB

Network

Ethernet 10/100/1000 Base‑T, auto sensing, half/full

duplex, RJ45

Protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP/

RTCP, IGMP V2/V3, ICMP, ICMPv6, RTSP,

FTP, Telnet, ARP, DHCP, NTP (SNTP),

SNMP (V1, MIB-II), 802.1x, DNS, DNSv6,

DDNS (DynDNS.org, selfHOST.de, no-

ip.com), SMTP, iSCSI, UPnP (SSDP),

DiffServ (QoS), LLDP, SOAP, Dropbox, CHAP,

digest authentication

Connections 32 simultaneous unicast/multicast min

Encryption TLS 1.0, SSL, DES, 3DES, AES

Control

Software update Flash ROM, remote programmable

Configuration Configuration Manager or web browser

Camera control Via serial interface;

supported* protocols and devices:

• Bosch AUTODOME, HSPT, MIC1‑300 IP, TC8x00

• Canon VCC1, VC-C4R

• CBC SMD 12P/12PII/20P

• JVC TK-C676

• Panasonic WV-CS850

• Pelco Spectra D/P

• Sensomatic SpeedDome Ultra

• Sony EVI D30/31/D100

• Ultrak KD6

Control

• VT VPT4x

* Basic functions only, no claim for full

functionality valid. Bosch may not be made

responsible if functions are not implemented

or not working under all circumstances.

Mechanical

Dimensions

(H x W x D)

44 x 483 x 157 mm (1.7 x 19 x 6.2 in)

Color RAL 9017 (Traffic Black)

Weight Approx. 1.7 kg (3.7 lb)

Electrical

Input voltage 100 to 240 VAC, 47 to 63 Hz

Input current 0.32 to 0.15 A

Power consumption 23 W

Connectors IEC 320 C14

Environmental

Operating

temperature

0 °C to +50 °C (+32 °F to +122 °F)

Storage temperature 0 °C to +50 °C (+32 °F to +122 °F)

Relative humidity 0 to 95%, non-condensing

Thermal value 79 BTU/h max

Ordering information

VIDEOJET multi 4000

High-performance multi-channel encoder. H.264 High

Profile; Dual Streaming; audio; MOTION+; iSCSI

recording; 16 channels; power cord added for specific

countries only

Order number VJM-4016

VIDEOJET multi 4000 EU

High-performance multi-channel encoder. H.264 High

Profile; Dual Streaming; audio; MOTION+; iSCSI

recording; 16 channels; EU power cord with IEC lock

Order number VJM-4016-EU

VIDEOJET multi 4000 US

High-performance multi-channel encoder. H.264 High

Profile; Dual Streaming; audio; MOTION+; iSCSI

recording; 16 channels; US power cord with IEC lock

Order number VJM-4016-US

Accessories

DIVAR IP 2000, 2 x 2 TB HDD

All-in-one recording and management solution for

network surveillance systems of up to 16 channels,

2 x 2 TB storage capacity

Order number DIP-2042-2HD

4 | VIDEOJET multi 4000

DIVAR IP 2000, 4 x 2 TB HDD

All-in-one recording and management solution for

network surveillance systems of up to 16 channels,

4 x 2 TB storage capacity

Order number DIP-2042-4HD

DIVAR IP 3000, 2 x 2 TB HDD

All-in-one recording, viewing, and management

solution for network surveillance systems of up to 32

channels, 2 x 2 TB storage capacity

Order number DIP-3042-2HD

DIVAR IP 3000, 4 x 2 TB HDD

All-in-one recording, viewing, and management

solution for network surveillance systems of up to 32

channels, 4 x 2 TB storage capacity

Order number DIP-3042-4HD

5 | VIDEOJET multi 4000
