WIDEBAND CABLE MODEM
Intel® Puma™ 5 8x4
DOCSIS/EuroDOCSIS 3.0 8x4
Dual Wideband Tuners
Supports IPv4 AND IPv6
ALWAYSON, HIGHPERFORMANCE INTERNET CONNECTION
The CDA-RES is the perfect choice for cable operators who want to oer high-speed broadband access to their customer
base economically. It delivers speeds of up to 320Mbps (8x4) with eight bonded downstream channels over its DOCSIS
interface - eight times faster than a conventional single-channel DOCSIS 2.0 cable modem! The integrated Gigabit Ethernet
port enables easy home networking.
RAPID, SIMPLE DEPLOYMENT, MONITORING AND MANAGEMENT
Installation of the CDA-RES is quick, straight-forward, and can even be carried out by the end-user. Once connected, the
built-in TFTP client automatically gets the IP address and conguration data from the network server without human
intervention. A browser-based utility allows convenient viewing of key network statistics, and SNMP support provides total
remote control over the device.
KEY FEATURES
• DOCSIS/EuroDOCSIS 3.0 compliant
• 8x4 channel bonding
• Full-featured, high bandwidth,
compact economical cable modem
• Extensive operator control via
conguration le and SNMP
• Well-dened LEDs clearly display device
and network status
CDA-RES
Headquarters - www.hitrontech.com
No. 1-8, Lihsin 1st Rd., Hsinchu Science Park,
Hsinchu, Taiwan
Tel: +886 3 5786658 Fax: +886 3 5778856
USA - www.hitron-americas.com
304 Inverness Way South, Suite 480
Englewood, Colorado 80112
Tel: +1 303 792 3380 Fax: +1 303 799 6185
Europe - www.hitron-europe.com
Kingsfordweg 151 1043 GR
Amsterdam, The Netherlands
Tel: +31 20 491 9995 Fax: +31 20 491 9995
CDA-RES
INTERNET
CABLE PLANT
MEDIA CENTER
NAS
PC GAMING
CONSOLE
TV
ETHERNET COAX
HIGH-PERFORMANCE INTERNET ACCESS
Protocol Support
• DOCSIS/EuroDOCSIS 1.1/2.0/3.0
• SNMP v1, v2C, v3
• DHCP, TFTP and ToD clients (IPv4/IPv6)
Connectivity
• RF F-type female 75Ω connector
• RJ-45 Ethernet port 10/100/1000 Mbps
(Auto-MDI/MDIX)
Management
• Web-based GUI control conguration and management
• Dual-color LEDs clearly display network status and activity
• Power on self diagnostic
• MIB II/MCNS MIB
• Hitron proprietary MIBs for extended support
Reception-Demodulation
• Demodulation: 64QAM, 256QAM
• Data Rate: Up to 320 Mbps with 8 bonded downstream
channels (DOCSIS)
• Frequency (edge-to-edge): 88 ~ 1002 MHz (DOCSIS)
• Channel Bandwidth: 6 MHz (DOCSIS,)
• Signal Level: -15 dBmV to 15 dBmV
• Input return loss: >6dB
Transmitter-Modulation
• Modulation: QPSK, 8QAM, 16QAM, 32QAM, 64QAM, and
128QAM (SCDMA only)
• Data rate up to 120 Mbps with 4 upstream channel
bonding
• Frequency: 5 ~ 42 MHz (DOCSIS)
• Output return loss: >6dB
Mechanical
• 5 status LEDs (Power, DS, US, Status, LAN)
• Factory default reset button
• Dimensions: 110mm(W) x 70mm(D) x 25mm(H)
• Weight: 100g ± 10g
Environmental
• Power Input DC: DC 12V/1A
• Power Consumption: 6W (typical), 9W (max.)
• Operating Temperature: 32°F (0°C) to 104°F (40°C)
• Operating Humidity: 10% ~ 90% (Non- condensing)
• Storage Temperature: -40°F (-40°C) to 176°F (80°C)
• Surge Protection:
RF input sustains at least 6KV
Ethernet RJ-45 sustains at least 1.5KV
Compliance Certicates
• RoHS Compliant
• FCC, UL
CDA-RES
P/N: CDA-RES_2013_1A - Issued Apr. 2013- Specications subject to change without further notice
