ZENIT® Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
3CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2Colour Temperature 000 - 255 7200K - 3200K Colour Temperature
3 Zoom 000 - 255 narrow to wide Zoom
4CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Strobe functions
000 - 005 Strobe open
Multifunctional Strobe
006 - 010 Strobe closed
011 - 033 Pulse Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127 Strobe Break Effect, 5s…..1s (Short burst with
break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
3
Colour Macro
& Colour Jumping
& Colour Fading
000 - 005 Colour off
Colour Macro
006 - 013 Red
014 - 021 Amber
022 - 029 Yellow warm
030 - 037 Yellow
038 - 045 Green
046 - 053 Turquoise
054 - 061 Cyan
062 - 069 Blue
070 - 077 Lavender
078 - 085 Mauve
086 - 093 Magenta
094 - 101 Pink
102 - 109 Warm White
110 - 117 White
118 - 125 Cold White
126 - 127 Colour Jumping Stop
128 - 191 Colour Jumping Speed slow -> fast / Colour 1
-> 12
192 - 255 Colour Fading Speed slow -> fast / Colour 1
-> 12
4 Zoom 000 - 255 narrow to wide Zoom
Cameo® is a brand of the Adam Hall Group · Adam Hall GmbH · Adam-Hall-Str. 1 · D-61267 Neu-Anspach · Germany
Telefon +49 (0) 6081 / 94 19-0 · Fax +49 (0) 6081 / 94 19-1000 · www.adamhall.com
5CH Mode
Ch. Function Values Sub-Group
1 Red 000 - 255 0% to 100% Red
2 Green 000 - 255 0% to 100% Green
3 Blue 000 - 255 0% to 100% Blue
4 White 000 - 255 0% to 100% White
5 Zoom 000 - 255 narrow to wide Zoom
9CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Strobe Functions
000 - 005 Strobe open
Multifunctional Strobe
006 - 010 Strobe closed
011 - 033 Pulse Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127 Strobe Break Effect, 5s…..1s (Short burst with
break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
3 Red 000 - 255 0% to 100% Red
4 Green 000 - 255 0% to 100% Green
5 Blue 000 - 255 0% to 100% Blue
6 White 000 - 255 0% to 100% White
7
Colour Macro
& Colour Jumping
& Colour Fading
(overrides RGBW)
000 - 005 Colour off
Colour Macro
006 - 013 Red
014 - 021 Amber
022 - 029 Yellow warm
030 - 037 Yellow
038 - 045 Green
046 - 053 Turquoise
054 - 061 Cyan
062 - 069 Blue
070 - 077 Lavender
078 - 085 Mauve
086 - 093 Magenta
094 - 101 Pink
102 - 109 Warm White
110 - 117 White
118 - 125 Cold White
126 - 127 Colour Jumping Stop
128 - 191 Colour Jumping Speed slow -> fast / Colour 1
-> 12
192 - 255 Colour Fading Speed slow -> fast / Colour 1
-> 12
8 Zoom 000 - 255 narrow to wide Zoom
ZENIT® Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
Cameo® is a brand of the Adam Hall Group · Adam Hall GmbH · Adam-Hall-Str. 1 · D-61267 Neu-Anspach · Germany
Telefon +49 (0) 6081 / 94 19-0 · Fax +49 (0) 6081 / 94 19-1000 · www.adamhall.com
9Device Settings
(please read remark 1*)
000 - 005 No function
Device Settings
006 - 027 Dimmer Response LED (Hold 3s)
028 - 049 Dimmer Response Halogen (Hold 3s)
050 - 093 No function
094 - 115 PWM Frequency 800 Hz (Hold 5s)
116 - 137 PWM Frequency 1200 Hz (Hold 5s)
138 - 159 PWM Frequency 2000 Hz (Hold 5s)
160 - 181 PWM Frequency 3600 Hz (Hold 5s)
182 - 203 PWM Frequency 12 kHz (Hold 5s)
204 - 225 PWM Frequency 25 kHz (Hold 5s)
226 - 247 Zoom Reset (Hold 5s)
248 - 255 No function
10CH Mode
Ch. Function Values Sub-Group
1 Red 000 - 255 0% to 100% Red
2 Red fine 000 - 255 0% to 100%
3 Green 000 - 255 0% to 100% Green
4 Green fine 000 - 255 0% to 100%
5 Blue 000 - 255 0% to 100% Blue
6 Blue fine 000 - 255 0% to 100%
7 White 000 - 255 0% to 100% White
8 White fine 000 - 255 0% to 100%
9 Zoom 000 - 255 narrow to wide Zoom
10 Zoom fine 000 - 255 narrow to wide
11CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Strobe functions
000 - 005 Strobe open
Multifunctional Strobe
006 - 010 Strobe closed
011 - 033 Pulse Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127 Strobe Break Effect, 5s…..1s (Short burst with
break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
3 Red 000 - 255 0% to 100% Red
4 Green 000 - 255 0% to 100% Green
5 Blue 000 - 255 0% to 100% Blue
6 White 000 - 255 0% to 100% White
ZENIT® Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
Cameo® is a brand of the Adam Hall Group · Adam Hall GmbH · Adam-Hall-Str. 1 · D-61267 Neu-Anspach · Germany
Telefon +49 (0) 6081 / 94 19-0 · Fax +49 (0) 6081 / 94 19-1000 · www.adamhall.com
7
Colour Macro
& Colour Jumping
& Colour Fading
(overrides RGBW)
000 - 005 Colour off
Colour Macro
006 - 013 Red
014 - 021 Amber
022 - 029 Yellow warm
030 - 037 Yellow
038 - 045 Green
046 - 053 Turquoise
054 - 061 Cyan
062 - 069 Blue
070 - 077 Lavender
078 - 085 Mauve
086 - 093 Magenta
094 - 101 Pink
102 - 109 Warm White
110 - 117 White
118 - 125 Cold White
126 - 127 Colour Jumping Stop
128 - 191 Colour Jumping Speed slow -> fast / Colour 1
-> 12
192 - 255 Colour Fading Speed slow -> fast / Colour 1
-> 12
8
Colour Temperature
Correction
(affects RGBW and
Colour Macros)
000 - 005 off
Colour Temperature
Correction
006 - 255 cold -> warm
9 Zoom 000 - 255 narrow to wide Zoom
10 Set Dimmer Curve
000 - 005 no function
Set Dimmer Curve
006 - 063 Linear Dimmer Curve
064 - 127 Exponential Dimmer Curve
128 - 191 Logarithmic Dimmer Curve
192 - 255 S-Curve Dimmer Curve
11 Device Settings
(please read remark 1*)
000 - 005 No function
Device Settings
006 - 027 Dimmer Response LED (Hold 3s)
028 - 049 Dimmer Response Halogen (Hold 3s)
050 - 093 No function
094 - 115 PWM Frequency 800 Hz (Hold 5s)
116 - 137 PWM Frequency 1200 Hz (Hold 5s)
138 - 159 PWM Frequency 2000 Hz (Hold 5s)
160 - 181 PWM Frequency 3600 Hz (Hold 5s)
182 - 203 PWM Frequency 12 kHz (Hold 5s)
204 - 225 PWM Frequency 25 kHz (Hold 5s)
226 - 247 Zoom Reset (Hold 5s)
248 - 255 No function
ZENIT® Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
Cameo® is a brand of the Adam Hall Group · Adam Hall GmbH · Adam-Hall-Str. 1 · D-61267 Neu-Anspach · Germany
Telefon +49 (0) 6081 / 94 19-0 · Fax +49 (0) 6081 / 94 19-1000 · www.adamhall.com
17CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Dimmer fine 000 - 255 0% to 100%
3 Strobe Functions
000 - 005 Strobe open
Multifunctional Strobe
006 - 010 Strobe closed
011 - 033 Pulse Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127 Strobe Break Effect, 5s…..1s (Short burst with
break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
4 Red 000 - 255 0% to 100% Red
5 Red fine 000 - 255 0% to 100%
6 Green 000 - 255 0% to 100% Green
7 Green fine 000 - 255 0% to 100%
8 Blue 000 - 255 0% to 100% Blue
9 Blue fine 000 - 255 0% to 100%
10 White 000 - 255 0% to 100% White
11 White fine 000 - 255 0% to 100%
12
Colour Macro
& Colour Jumping
& Colour Fading
(overrides RGBW)
000 - 005 Colour off
Colour Macro
006 - 013 Red
014 - 021 Amber
022 - 029 Yellow warm
030 - 037 Yellow
038 - 045 Green
046 - 053 Turquoise
054 - 061 Cyan
062 - 069 Blue
070 - 077 Lavender
078 - 085 Mauve
086 - 093 Magenta
094 - 101 Pink
102 - 109 Warm White
110 - 117 White
118 - 125 Cold White
126 - 127 Colour Jumping Stop
128 - 191 Colour Jumping Speed slow -> fast / Colour 1
-> 12
192 - 255 Colour Fading Speed slow -> fast / Colour 1
-> 12
13
Colour Temperature
Correction
(affects RGBW and
Colour Macros)
000 - 005 off
Colour Temperature
Correction
006 - 255 cold -> warm
ZENIT® Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
Cameo® is a brand of the Adam Hall Group · Adam Hall GmbH · Adam-Hall-Str. 1 · D-61267 Neu-Anspach · Germany
Telefon +49 (0) 6081 / 94 19-0 · Fax +49 (0) 6081 / 94 19-1000 · www.adamhall.com
14 Zoom 000 - 255 narrow to wide Zoom
15 Zoom fine 000 - 255 narrow to wide
16 Set Dimmer Curve
000 005 No function
Set Dimmer Curve
006 - 063 Linear Dimmer Curve
064 - 127 Exponential Dimmer Curve
128 - 191 Logarithmic Dimmer Curve
192 - 255 S-Curve Dimmer Curve
17 Device Settings
(please read remark 1*)
000 - 005 No function
Device Settings
006 - 027 Dimmer Response LED (Hold 3s)
028 - 049 Dimmer Response Halogen (Hold 3s)
050 - 093 No function
094 - 115 PWM Frequency 800 Hz (Hold 5s)
116 - 137 PWM Frequency 1200 Hz (Hold 5s)
138 - 159 PWM Frequency 2000 Hz (Hold 5s)
160 - 181 PWM Frequency 3600 Hz (Hold 5s)
182 - 203 PWM Frequency 12 kHz (Hold 5s)
204 - 225 PWM Frequency 25 kHz (Hold 5s)
226 - 247 Zoom Reset (Hold 5s)
248 - 255 No function
EN: (1*) After the adjustments have been made, set the value to 000 to avoid disturbance by endless function call.
DE: (1*) Nachdem die Einstellungen vorgenommen wurden, stellen Sie den Wert auf 000 ein, um Störungen durch endlosen
Funktionsaufruf zu vermeiden.
FR: (1*) Une fois les ajustements effectués, réglez la valeur sur 000 pour éviter les perturbations par appel de fonction sans fin.
ES: (1*) Después de realizar los ajustes, establezca el valor en 000 para evitar perturbaciones mediante una llamada de función sin fin.
PL: (1*) Po dokonaniu ustawień ustaw wartość na 000, aby uniknąć zakłóceń przez niekończące się wywołanie funkcji.
IT: (1*) Dopo aver effettuato le regolazioni, impostare il valore su 000 per evitare disturbi causati da una chiamata a funzione infinita.
ZENIT® Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
