VA Online Memorial - Data scraper improvements
©TopCoder, Inc. 2018 Page 1 of 6
VA Online Memorial - Data scraper improvements
Revision History
Author
Revision Number
Date
TCCODER
1.0
Feb 09, 2018
VA Online Memorial - Data scraper improvements
©TopCoder, Inc. 2018 Page 2 of 6
Deployment Instructions!
1. Deployment Dependencies!
2. Organization of Submission!
3. Deployment Instructions!
4. Verification!
5. Resource Contact List!
VA Online Memorial - Data scraper improvements
©TopCoder, Inc. 2018 Page 3 of 6
Deployment Instructions
1. Deployment Dependencies
Before performing a deployment, it is assumed that the following have been set up:
● NodeJs 8+
● Postgresql Database
● Libpq (pg_config)
2. Organization of Submission
● va-backend/ – source of the submission
● docs/ - the deployment guide
3. Deployment Instructions
Go to the va-backend/ folder and follow the instructions of the README.md file to install all packages.
To install libpq do one of the following:
On OS X: brew install postgres
On Ubuntu/Debian: apt-get install libpq-dev g++ make
On RHEL/CentOS: yum install postgresql-devel
Change the database configuration in the packages/va-data-scraper and packages/va-models packages to match
your Postgresql database configuration.
Go to the va-backend/packages/va-data-scraper and follow the instructions of the README.md file
information on how to run the package.
Don’t run “npm install” inside the va-backend/packages/va-data-scraper folder.
4. Verification
Go to the folder va-backend/packages/va-data-scraper.
Run the command:
$ npm run download-data
Wait until it downloads 20 files and hit Ctrl+C (if you want to download all files go ahead but it’s not
necessary).
As described in https://apps.topcoder.com/forums/?module=Thread&threadID=912402, an option to ignore
CSV error can be made.
VA Online Memorial - Data scraper improvements
©TopCoder, Inc. 2018 Page 4 of 6
For that set the environment variable OPTION_IGNORE_BAD_CSV_LINE to “true” and run the script
(check va-backend/packages/va-data-scraper/services/data.js file for OPTION_IGNORE_BAD_CSV_LINE
usage).
To start the data scraper script run:
$ export OPTION_IGNORE_BAD_CSV_LINE=true
$ npm run import-data
You will see something like this:
> node --expose-gc --max_old_space_size=4096 scripts/import-data.js
[2018-02-08T11:15:21.140Z][INFO] Will ignore bad csv lines
[2018-02-08T11:15:21.143Z][INFO] connecting to database: postgres://postgres:topcoder@localhost:5432/test
[2018-02-08T11:15:21.330Z][INFO] Processing file downloads/ngl_alabama.csv
[▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇] 100% 387.8s
0.0s
[2018-02-08T11:21:54.236Z][INFO] Parsed file downloads/ngl_alabama.csv with 21872 lines. Inserted 20070 veterans
[2018-02-08T11:21:54.255Z][INFO] Processing file downloads/ngl_alaska.csv
[▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇] 100% 155.9s
0.0s
[2018-02-08T11:24:31.838Z][INFO] Parsed file downloads/ngl_alaska.csv with 8880 lines. Inserted 8411 veterans
[2018-02-08T11:24:31.936Z][INFO] Processing file downloads/ngl_arizona.csv
[▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇] 100% 2740.8s
0.0s
[2018-02-08T12:10:29.041Z][INFO] Parsed file downloads/ngl_arizona.csv with 96485 lines. Inserted 95108 veterans
While running the files you can check that the memory consumption stays below 150Mb (4Gb+ before).
To verify that transaction is working properly, move all files from the downloads/ folder to a temporary folder,
but keep file ngl_california.csv.
Drop the Postgresql database and create it again:
psql> DROP DATABASE test;
psql> CREATE DATABASE test;
Run the import the command again with OPTION_IGNORE_BAD_CSV_LINE set to “false”.
$ export OPTION_IGNORE_BAD_CSV_LINE=false
$ npm run import-data
It will crash while reading a CSV file.
> node --expose-gc --max_old_space_size=4096 scripts/import-data.js
[2018-02-08T12:19:18.491Z][INFO] connecting to database: postgres://postgres:topcoder@localhost:5432/test
[2018-02-08T12:19:19.446Z][INFO] Processing file downloads/ngl_california.csv
[▇———————————————————————————————————————————————————————————] 1% 0.0s 0.0s
[2018-02-08T12:22:42.783Z][ERROR] Failed to recover CSV line
[2018-02-08T12:22:42.785Z][ERROR] Failed to read file. Stack: Error: Invalid closing quote at line 1; found "M"
instead of delimiter ","
[2018-02-08T12:22:42.787Z][INFO] Operation completed!
Check the database tables. No data must be present.
VA Online Memorial - Data scraper improvements
©TopCoder, Inc. 2018 Page 5 of 6
Run the import the command again. This time the command will not crash and some warnings or errors will be
printed in the screen.
While running this file, ngl_california.csv, (the biggest one available) you can check that the memory
consumption stays below 600Mb (4Gb+ before). This is due to the Sequelize library and not with the line by
line read.
Last requirement verification:
Third, the scraper will ignore importing any row that has no information in these columns: first/last name,
birth/burial date and cemetery name/city/address. That does make our data complete, but also skips a lot of
records. We want you to analyze those skipped rows and propose a different strategy for importing records that
would yield better results (you can propose more than one).
For that set the environment OPTION_IMPORT_EXTRA_DATA to true and run the script again (check va-
backend/packages/va-data-scraper/services/data.js file for OPTION_IMPORT_EXTRA_DATA usage).
Drop the Postgresql database and create it again. Run the commands below:
$ export OPTION_IGNORE_BAD_CSV_LINE=true
$ export OPTION_IMPORT_EXTRA_DATA=true
$ npm run import-data
You should see something like this:
[2018-02-08T00:15:14.259Z][INFO] Will ignore bad csv lines
[2018-02-08T00:15:14.261Z][INFO] Will try to import extra data
[2018-02-08T00:15:14.262Z][INFO] connecting to database: postgres://postgres:topcoder@localhost:5432/test
[2018-02-08T00:15:14.425Z][INFO] Processing file downloads/ngl_alabama.csv
[▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇] 100% 375.6s
0.0s
[2018-02-08T00:21:34.670Z][INFO] Parsed file downloads/ngl_alabama.csv with 21872 lines. Inserted 21848 veterans
[2018-02-08T00:21:34.684Z][INFO] Processing file downloads/ngl_alaska.csv
[▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇] 100% 153.2s
0.0s
[2018-02-08T00:24:09.535Z][INFO] Parsed file downloads/ngl_alaska.csv with 8880 lines. Inserted 8869 veterans
[2018-02-08T00:24:09.629Z][INFO] Processing file downloads/ngl_arizona.csv
[▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇▇] 100% 3953.9s
0.0s
[2018-02-08T01:30:19.496Z][INFO] Parsed file downloads/ngl_arizona.csv with 96485 lines. Inserted 96474 veterans
Comparing the execution with the previous one we have:
File
Without Extra Flag
With extra Flag
Increase
ngl_alabama.csv
20070 inserted
21848 inserted
8.8%
ngl_alaska.csv
8411 inserted
8869 inserted
5.4%
ngl_arizona.csv
95108 inserted
96474 inserted
1.4%
Checking the results, it can be verified an increase in the amount of imported data in all cases.
VA Online Memorial - Data scraper improvements
©TopCoder, Inc. 2018 Page 6 of 6
The following rules have been applied:
1- If column relationship is empty and names are equal to v_names we set relationship to Veteran (Self).
2- If column relationship is empty and last name is equal to v_last_name we set relationship to Other
Relative.
3- If the v_name or v_last_name columns are empty and relationship is equal to Veteran (Self), we copy
names to v_names.
4- If birth date or death date are null, we calculate the veteran id using a MD5 hash of the entire CSV line.
This could produce a duplicate result, but it’s very unlikely.
5. Resource Contact List
Name
Resource Email
TCCODER
Through TopCoder Member Contact
