SPECIFICATIONS
• Rugged Devine Design housing. F640 is cast aluminum with
optional cast bronze housing. F644 has a fabricated aluminum
housing with protective powder paint finish. Both concrete pour
or drywall versions available. Wiring hubs are 3/4".
• Cast aluminum or optional cast bronze louvered faces with tem-
pered clear glass lens. Provided with stainless steel allenhead
screw closure.
• Formed aluminum reflectors for maximum light output through
louvered faces.
• Low wattage incandescent, compact fluorescent, and 50 or 70
watt HPS on F644.
• Standard finishes are dark bronze, black, white and platinum.
• Units are designed for use in wet locations.
F640/F644
SERIES
STEPLIGHTS
ORDERING INFORMATION
ORDERING EXAMPLE: F644-50HPS-120-DB-DW
A
B
A
B
F640
F644
ABDepth
F640 53/4"10
3/8"3
1/8"
146 mm 264 mm 79 mm
F644 85/8"8
5/8"7
1/4"
219 mm 219 mm 184 mm
Note: Rough-in for drywall installation:
F640 = 4 5/8" x 9 3/8" x 3 5/8"
F644 = 8" dia. x 7 1/4"
Cat. #
Job Type
Approvals
- - - -
Series Wattage/Source Voltage Finish Options
SERIES
F640 F640 Series Vertical
F644 F644 Series Round
WATTAGE/SOURCE
F640
PL7 G23 Base Magnetic
PL9 G23 Base Magnetic
60INC 60W Incandescent Medium Base
F644
50HPS 50W HPS Medium Base
70HPS 70W HPS Medium Base
60INC 60W Incandescent Medium Base
PLC13 GX23-2 Base Mag.
VOLTAGE
120 120V
277 277V
347 347V
FINISH
DB Dark Bronze
BLK Black
WHT White
SAL Platinum
OPTIONS
DW1Drywall
CP1Concrete Pour
BZ Cast Bronze Face
BZ1 All Cast Bronze Fixture
JBTW Junction Box Through Wire
FFusing
LP Lamp Included
Copyright © 2010 HUBBELL LIGHTING All Rights Reserved F640/F644-SPEC7/10 Printed in USA
Devine Lighting • 701 Millennium Boulevard • Greenville, SC 29607 • PHONE: 864-678-1000
For more information visit our web site: www.hubbell-ltg.com
Due to our continued efforts to improve our products, product specifications are subject to change without notice.
1 Must select drywall or concrete pour.
