1 Introduction
- 1.1 Overview
- 1.2 Target Audience
2 Message Load Service Description
3 Message Submit Service Description
4 Errors
Appendix A
Appendix B: Glossary

Global PAYplus Version 4.6.2

Actions on Pay

ments

Service

-Oriented Architecture

Partnership.

PROPRIETARY AND CONFIDENTIAL - This document contains information, which contains Confidential and

Know How property of D+H. Disclosure to or use by persons who are not expressly authorized in writing by D+H

is strictly prohibited.

D+H reserves the right to alter the specifications and descriptions in this publication without prior notice. No part

of this publication shall be deemed to be part of any contract or warranty unless specifically incorporated by

reference into such contract or warranty.

All brand or product names are the trademarks or registered trademarks of their respective holders.

The information contained herein is merely descriptive in nature, and does not constitute a binding offer for the

license of the product described herein.

Catalog ID: GPP4.6-00-S03-03-201603

Actions on Payments Version Control

Global PAYplus Service-Oriented Architecture Page 3

Version Control

Version Date Summary of Changes

1.0 Document Created

2.0 Aug 2015 Document restructured on new template.

3.0 Nov 2015 Rebranded on new template.

Actions on Payments Table of Contents

Global PAYplus Service-Oriented Architecture Page 4

Table of Contents

1 INTRODUCTION .......................................................................................................................... 5

1.1 Overview ............................................................................................................................... 5

1.2 Target Audience .................................................................................................................... 5

2 MESSAGE LOAD SERVICE DESCRIPTION ............................................................................. 6

2.1 Overview ............................................................................................................................... 6

2.2 Service Function ................................................................................................................... 6

2.3 Input ...................................................................................................................................... 6

2.3.1 Output Request ................................................................................................................. 7

2.3.2 Processing ......................................................................................................................... 9

2.4 Output ................................................................................................................................... 9

2.5 Errors .................................................................................................................................... 9

2.6 Examples .............................................................................................................................. 9

2.6.1 Example 1: Ad-hock Structure - Load Specific Payment Fields ........................................ 9

2.6.2 Example 2: Presets with Output Mode FULL + Convert to SWIFT 103 .......................... 11

2.6.3 Example 3: Non-existing MID .......................................................................................... 18

2.6.4 Example 4: Presets with Output Mode ORIG_PERSISTENT_DATA ............................. 19

3 MESSAGESUBMITSERVICE DESCRIPTION .......................................................................... 22

3.1 Overview ............................................................................................................................. 22

3.2 Service Functions................................................................................................................ 22

3.3 Input .................................................................................................................................... 23

3.3.1 Service Input Table Legend ............................................................................................ 23

3.4 Processing .......................................................................................................................... 23

3.5 Output ................................................................................................................................. 25

3.6 Errors .................................................................................................................................. 25

3.7 Examples ............................................................................................................................ 26

3.7.1 Example 1: Manual Creation of a Payment ..................................................................... 26

3.7.2 Example 2: Final Approve of an Existing Payment ......................................................... 29

3.7.3 Example 3: Cancel a Payment ........................................................................................ 31

3.7.4 Example 4: When an Action is not Allowed for the Queue ............................................. 33

4 ERRORS .................................................................................................................................... 37

4.1 Generic Errors ..................................................................................................................... 37

4.2 Static Data Related Error Codes ......................................................................................... 38

4.3 Message Processing Related Error Codes ......................................................................... 38

APPENDIX A ........................................................................................................................................ 39

List of System Users .......................................................................................................................... 39

List of System Entitlements ............................................................................................................... 39

Document Preservation ..................................................................................................................... 39

Message Load Service .................................................................................................................. 39

Message Submit Service ............................................................................................................... 39

APPENDIX B: GLOSSARY .................................................................................................................. 40

Actions on Payments Introduction

Global PAYplus Service-Oriented Architecture Page 5

1 Introduction

Note: This SOA Guide has not yet been certified for GPP V4.6; therefore, there may be inaccuracies

in this document that may require amendments in the future. For more information, please contact

your D+H Project Manager.

1.1 Overview

GPP is a robust payment engine whose workflow emulates the business flow of the bank or other

financial institution. Configurable reference data profiles control the sequence of workflow steps and

the actions performed in each step.

GPP processes and manages payments. As part of the message processing flow, the payment is

always associated with a message status (msg sts). When a payment reaches the end of processing,

the status is Complete. Where a payment is being held for manual intervention, it would be set to

Repair or any other available/relevant status.

To be able to handle payments outside of GPP, the following standalone services are used:

• QueueListService: Provides a list of payments which meet a given selection criteria and are

filtered by user restrictions, for example, it will include a list of all payments that meet the

combined criteria of the input, such as payments with same message status that the user has

permissions to view. For more information, see GPP SOA Guide Queue List Service.

• MessageLoadService: Loads a specific payment, i.e. the third party application gets all payment

details

• MessageSubmitService: Takes a manual action on a specific payment, such as Submit or Cancel

This document describes the last two services and focuses on the ability to simulate the UI ability to

load and take action on payments. For more information about the QueueListService, see GPP SOA

Queue List Service document.

1.2 Target Audience

This book describes GPP web services that are based on a Service-Oriented Architecture (SOA)

concept which enables 3rd party applications to interact with GPP.

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 6

2 Message Load Service Description

2.1 Overview

This service enables a user to retrieve full or partial data for a single payment transaction, based on

the unique payment ID (MID).

The service also enables a user to retrieve the output in a different message format. For example, the

original payment message type is pain.001, and the user can request to receive the output as

message type pacs.008.

2.2 Service Function

This service supports the single MessageLoadService method only.

2.3 Input

The table below describes the required input parameters.

The L column lists the level for each parameter, which is the element level in the file. The + indicators

in Tag Name column are accordance to the level number.

Parameter Tag Name L

Format Comment

Header Header 0

Request header

D+H

Header +FndtHeader 1

Service Header

Credentials ++Credentials 2

{1..1} Credentials

User ID +++UserID 3

String

{1..1} A valid GPP user (see List of System

Users). User name is case sensitive.

Use the exact user name.

The user must have the following

credentials: User exists, and active

(status = AC) and not logged in

(LOGGED_IN <> 2)

User

Entitlement

code

+++Role 3

String

{1..1} A valid GPP entitlement profile (see List

of System Entitlements).

Credentials check: The entitlement

exists and assigned to the login user.

Also where applicable the relevant

access permission is granted.

Body Body 0

{1..1} Service Body

Request

details +PerformMessage

LoadRequest

{1..1} Request details

Audit user ++UserID 2

String

{0..1} Audit user only. This input is not being

validated. Where applicable, this would

be used as the audit user

Unique

Inputs

MID ++P_MID 2

String

(length

16) {1..1}

Message ID

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 7

Parameter Tag Name L

Format Comment

Output

request Payments are stored in D+H message

structure in the database. Where not

specified, the output would be D+H

message (as-is). The following options

(one of 2) are allowed. And one of them

must be present.in the input.

Ad-hock

structured ++fndtMsgSubset 2

{0..1} or An ad-hoc defined structure that is

defined by this element. Allows

retrieving specific information about a

payment.

Presets ++ParseOutputMode 2

{0..1} A preset of allowed outputs. FULL,

ORIG_PERSISTENT_DATA,

PERSISTENT_DATA. (See section

Presets for Further Details)

origPmntConversionType Defines the original XML message

structure.

Possible values: AS IS (the output

would be exactly what is stored in GPP

database), or xml type from Xml Type.

pmntConversionType Defines the outgoing XML message

structure.

If empty, the output will be the same as

set in the database (i.e. AS-IS). If not

empty, can get a value from Xml Type.

Requesting a specific output format (the

service converts the input format).

2.3.1 Output Request

The service output may provide one of the following structures:

2.3.1.1 Ad-hock Structure

This structure enables retrieving partial data available for a single payment, based on the payment

unique ID (MID). The input shall include the specific logical fields requested by the user.

(See Example 1: Ad-hock Structure - Load Specific Payment Fields.)

2.3.1.2 Presets

This structure enables retrieving data available for a single payment, based on the payment unique ID

(MID). The returned output fields will be determined by the input’s output mode.

This table shows the allowed Output Modes for Presets:

Output Mode Support Type Output Provided

FULL Fully supported ALL MINF Relational columns

All Monitor Fields

All User Defined Fields

Updated Xml pmnt Section

Original Message

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 8

Output Mode Support Type Output Provided

Msg Extension

ORIG_PERSISTENT_DATA Fully supported Original Message

Msg Extension (if provided)

PERSISTENT_DATA Fully supported ALL MINF Relational columns

All Monitor Fields

All User Defined Fields

Updated Xml pmnt Section

This table is an extract from system tables: XML_DOCUMENT_TYPES for the different

DOCUMENT_ID. It shows the Applicable XML Types that can be used as a preset for each.

Xml Type Support Type Content

ACMT_023 As-is

ACMT_024 As-is

CAMT_052 As-is

CAMT_054 As-is

EXTN As-is

FNDT_MSG As-is

MOP_OUT As-is

N90 As-is

N91 As-is

N92 As-is

N95 As-is

N96 As-is

N98 As-is

N99 As-is

Pacs_002 As-is

Pacs_004 As-is

Pacs_008 As-is Also PACS_00801 is version 001 support is required.

Pacs_009 As-is

Pain_001 As-is

Pain_002 As-is

SWIFT_103 As-is

SWIFT_190 As-is

SWIFT_191 As-is

SWIFT_192 As-is

SWIFT_195 As-is

SWIFT_196 As-is

SWIFT_199 As-is

SWIFT_202 As-is

SWIFT_202COV As-is

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 9

Xml Type Support Type Content

SWIFT_210 As-is

SWIFT_290 As-is

SWIFT_291 As-is

SWIFT_292 As-is

SWIFT_295 As-is

SWIFT_296 As-is

SWIFT_299 As-is

SWIFT_400 As-is

SWIFT_401 As-is

SWIFT_402 As-is

SWIFT_900 As-is

SWIFT_910 As-is

2.3.2 Processing

1. A query is constructed and a single payment is fetched.

2. The payment may be converted as requested in the output request.

3. When no message is found, the relevant error is returned.

Note: This service can be used for both payments and templates.

2.4 Output

The output depends on the input parameters. That is, either a response that is taking an extract of the

message (see Example 1: Ad-hock Structure - Load Specific Payment Fields) or a full message with

the ability to convert the original/outgoing XML to any message type.

2.5 Errors

This table shows the relevant Error Messages:

Code Description

77782 Message was not found for MID [MID not found in MINF]

See also Errors.

2.6 Examples

2.6.1 Example 1: Ad-hock Structure - Load Specific Payment Fields

Invoke the service with an existing MID (10801N3428AO0448) request for specific attributes (logical

fields) from MINF (Message information table in the DB).

2.6.1.1 Request

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:q0="http://fundtech.com/SCL/MessageLoadService"

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 10

xmlns:q1="http://fundtech.com/SCL/CommonTypes" xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soapenv:Header>

<q1:credentials>

<q1:UserID>SERVICES</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</soapenv:Header>

<soapenv:Body>

<q0:PerformMessageLoadRequest>

<q1:credentials>

<q1:UserID>audit3</q1:UserID>

</q1:credentials>

<q1:P_MID>10801N3428AO0448</q1:P_MID>

<q0:fndtMsgSubset>

<q1:document id="X_FNDT_MSG_EXT">

<q1:field id="X_EXTN_PRS_PERIST_INF">

<q1:field id="P_MSG_STS"/>

<q1:field id="P_BASE_AMT"/>

<q1:field id="P_BASE_CCY"/>

<q1:field id="P_DEPARTMENT"/>

<q1:field id="P_MSG_CLASS"/>

<q1:field id="P_MSG_TYPE"/>

<q1:field id="P_OFFICE"/>

<q1:field id="P_PROC_DT"/>

<q1:field id="P_TIME_STAMP"/>

</q1:field>

<q1:field id="X_EXTN_CREDIT_SIDE">

<q1:field id="P_CDT_ACCT_CCY"/>

<q1:field id="P_CDT_ACCT_NB"/>

<q1:field id="P_CDT_AMT"/>

<q1:field id="P_CDT_CUST_CD"/>

<q1:field id="P_CDT_MOP"/>

</q1:field>

<q1:field id="X_EXTN_DEBIT_SIDE">

<q1:field id="P_DBT_ACCT_NB"/>

<q1:field id="P_DBT_AMT"/>

<q1:field id="P_DBT_CUST_CD"/>

<q1:field id="P_DBT_MOP"/>

<q1:field id="P_DBT_RATE_USAGE_NM"/>

</q1:field>

</q1:document>

</q0:fndtMsgSubset>

</q0:PerformMessageLoadRequest>

</soapenv:Body>

</soapenv:Envelope>

2.6.1.2 Response

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<Msg>

<Pmnt/>

<Extn>

<P_MSG_STS>WAIT_CONFIRMATION</P_MSG_STS>

<P_BASE_AMT>636.36</P_BASE_AMT>

<P_BASE_CCY>USD</P_BASE_CCY>

<P_DEPARTMENT>PSV</P_DEPARTMENT>

<P_MSG_CLASS>PAY</P_MSG_CLASS>

<P_MSG_TYPE>Pain_001</P_MSG_TYPE>

<P_OFFICE>US1</P_OFFICE>

<P_PROC_DT>2010-04-20</P_PROC_DT>

<P_TIME_STAMP>2010-08-02 00:03:16.956</P_TIME_STAMP>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 11

<P_CDT_ACCT_CCY>AUD</P_CDT_ACCT_CCY>

<P_CDT_ACCT_NB>50006789</P_CDT_ACCT_NB>

<P_CDT_AMT>700</P_CDT_AMT>

<P_CDT_CUST_CD>USD1SACITIUS33XXX</P_CDT_CUST_CD>

<P_CDT_MOP>CRSCCY</P_CDT_MOP>

</CreditSide>

<P_DBT_ACCT_NB>8552502</P_DBT_ACCT_NB>

<P_DBT_AMT>700</P_DBT_AMT>

<P_DBT_CUST_CD>US1SACOMPUS33XXX</P_DBT_CUST_CD>

<P_DBT_MOP>BOOK</P_DBT_MOP>

<P_DBT_RATE_USAGE_NM>US1^STANDARD</P_DBT_RATE_USAGE_NM>

</DebitSide>

</ProcessingPersistentInfo>

<D_ELAPSED_TIME_MS>[MessageLoad]:5.684</D_ELAPSED_TIME_MS>

</QaInfo>

</Extn>

</Msg>

</ResponseDetails>

</FndtMsg>

</soap:Body>

</soap:Envelope>

2.6.2 Example 2: Presets with Output Mode FULL + Convert to SWIFT 103

Invoke the service with an existing MID (1042984940CK0208) request for FULL (one of the use

presets) and convert the original payment format (Message type pain.001) into message type SWIFT

103 xml format.

2.6.2.1 Request

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:mes="http://fundtech.com/SCL/MessageLoadService"

xmlns:com="http://fundtech.com/SCL/CommonTypes">

<soap:Header>

<com:FndtHeader>

<com:credentials>

<com:UserID>MASTERUSER</com:UserID>

<com:Role>ADMIN</com:Role>

</com:credentials>

</com:FndtHeader>

</soap:Header>

<soap:Body>

<mes:PerformMessageLoadRequest>

<com:P_MID>1042984940CK0208</com:P_MID>

<com:credentials>

<com:UserID>audit3</com:UserID>

</com:credentials>

<mes:outputMode

origPmntConversionType="Pain_001"pmntConversionType="SWIFT_103">FULL</mes:outputMode>

</mes:PerformMessageLoadRequest>

</soap:Body>

</soap:Envelope>

2.6.2.2 Response

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<ns1:FndtMsg xmlns="http://fundtech.com/SCL/CommonTypes">

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 12

<P_MID>1042984940CK0208</P_MID>

</Header>

<Msg>

<Pmnt>

<swif:SWIFT MT="103" xmlns:swif="urn:fundtech/scl/SWIFT">

<swif:Header>

<swif:Create_Date_Time xmlns="urn:fundtech/scl/SWIFT">2008-06-

25T06:19:06</swif:Create_Date_Time>

<swif:Msg_ID xmlns="urn:fundtech/scl/SWIFT">CTv422-001</swif:Msg_ID>

</swif:Header>

<swif:Data xmlns="urn:fundtech/scl/SWIFT">

<F32A>

</F32A>

<F20>

<Sender_s_Reference>CTv41-52</Sender_s_Reference>

</F20>

<F33B>

</F33B>

<F21>

<Related_Reference>CTv422-8/2008-06-25</Related_Reference>

</F21>

<F71A>

</F71A>

<F52a>

<Identifier_Code>BOFAUS31XXX</Identifier_Code>

</F52a>

<F50a>

<F50F>

<Id>

<PartyName>THE US COMPANY</PartyName>

</Id>

</F50F>

</F50a>

<F57a>

<Identifier_Code>CITIUS33XXX</Identifier_Code>

</F57a>

<Cdrt_F58a_F59a>

</Cdrt_F58a_F59a>

</swif:Data>

</swif:SWIFT>

</Pmnt>

<Extn>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.367</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.366</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 13

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.365</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.364</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.363</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.362</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40035</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.361</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_ERROR_PARAMS>@@2010-03-

03@@STRING@@@@,@@PROCESSING@@STRING@@@@,@@SLA-PROCS@@STRING@@</F_AUDIT_ERROR_PARAMS>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>1001</F_AUDIT_ERROR_CODE>

<F_AUDIT_TIME_STAMP>2010-04-29 18:59:54.360</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_ERROR_PARAMS>@@PEND_APPROV@@STRING@@@@,@@SCHEDULE@@STRING@@</F_AUDIT_ERROR_PARAMS>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40090</F_AUDIT_ERROR_CODE>

<F_AUDIT_USER_NAME>ADMIN2</F_AUDIT_USER_NAME>

<F_AUDIT_TIME_STAMP>2010-04-29 08:49:40.472</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_ERROR_PARAMS>@@Submit@@STRING@@</F_AUDIT_ERROR_PARAMS>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_USER_NAME>ADMIN2</F_AUDIT_USER_NAME>

<F_AUDIT_TIME_STAMP>2010-04-29 08:49:40.471</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 14

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_USER_NAME>ADMIN2</F_AUDIT_USER_NAME>

<F_AUDIT_TIME_STAMP>2010-04-29 08:49:40.470</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>40171</F_AUDIT_ERROR_CODE>

<F_AUDIT_USER_NAME>ADMIN2</F_AUDIT_USER_NAME>

<F_AUDIT_TIME_STAMP>2010-04-29 08:49:40.469</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

<M_AUDIT_TRAIL>

<F_AUDIT_ERROR_CODE>1001</F_AUDIT_ERROR_CODE>

<F_AUDIT_USER_NAME>ADMIN2</F_AUDIT_USER_NAME>

<F_AUDIT_TIME_STAMP>2010-04-29 08:49:40.468</F_AUDIT_TIME_STAMP>

<F_AUDIT_END_DATE>2010-04-29T00:00:00</F_AUDIT_END_DATE>

<F_AUDIT_UPDATE_DATE>2010-04-29T00:00:00</F_AUDIT_UPDATE_DATE>

<F_AUDIT_ZONE_CODE>EST</F_AUDIT_ZONE_CODE>

<F_AUDIT_ERROR_PARAMS>@@(RECEIVED)@@STRING@@@@,@@PEND_APPROV@@STRING@@</F_AUDIT_ERROR_PARAMS>

<F_AUDIT_IS_NEW>false</F_AUDIT_IS_NEW>

</M_AUDIT_TRAIL>

</AuditTrail>

<M_MSG_NOTES_GRID>

<F_MSG_NOTES_USER_ID>USER1</F_MSG_NOTES_USER_ID>

<F_MSG_NOTES_TEXT>LINE 1 TEXT</F_MSG_NOTES_TEXT>

<F_MSG_NOTES_TIMESTAMP>2010-04-29 08:49:42.025</F_MSG_NOTES_TIMESTAMP>

<F_MSG_NOTES_CREATE_DATE>2010-04-29 08:49:42

(EST)</F_MSG_NOTES_CREATE_DATE>

<F_MSG_NOTES_EXTERNAL_NOTE_IND>true</F_MSG_NOTES_EXTERNAL_NOTE_IND>

<F_MSG_NOTES_ATTACHED_FILE_LINK>//NoteFile1.txt</F_MSG_NOTES_ATTACHED_FILE_LINK>

<F_MSG_NOTES_REC_STATUS>AC</F_MSG_NOTES_REC_STATUS>

</M_MSG_NOTES_GRID>

</MsgNotes>

<P_CDT_ACCT_CCY>USD</P_CDT_ACCT_CCY>

<P_CDT_ACCT_NB>33334567812</P_CDT_ACCT_NB>

<P_CDT_ACCT_OFFICE>US1</P_CDT_ACCT_OFFICE>

<P_CDT_AMT>755</P_CDT_AMT>

<P_CDT_CROSS_CONV>false</P_CDT_CROSS_CONV>

<P_CDT_CUST_CD>USD1SACITIUS33XXX</P_CDT_CUST_CD>

<P_CDT_MOP>BOOK</P_CDT_MOP>

<P_CDT_RATE_USAGE_NM>US1^STANDARD</P_CDT_RATE_USAGE_NM>

<P_CDT_TX_CD>CRBOFA</P_CDT_TX_CD>

<P_CDT_VD>2010-05-02</P_CDT_VD>

</CreditSide>

<P_DBT_ACCT_CCY>USD</P_DBT_ACCT_CCY>

<P_DBT_ACCT_NB>22222222</P_DBT_ACCT_NB>

<P_DBT_ACCT_OFFICE>US1</P_DBT_ACCT_OFFICE>

<P_DBT_AMT>755</P_DBT_AMT>

<P_DBT_CROSS_CONV>false</P_DBT_CROSS_CONV>

<P_DBT_CUST_CD>US1SACOMPUS33XXX</P_DBT_CUST_CD>

<P_DBT_MOP>BOOK</P_DBT_MOP>

<P_DBT_RATE_USAGE_NM>US1^STANDARD</P_DBT_RATE_USAGE_NM>

<P_DBT_TX_CD>DRBOFA</P_DBT_TX_CD>

<P_DBT_VD>2010-05-02</P_DBT_VD>

</DebitSide>

<P_BASE_AMT>755</P_BASE_AMT>

<P_BASE_CCY>USD</P_BASE_CCY>

<P_BASE_RATE_USAGE_NM>US1^BASE</P_BASE_RATE_USAGE_NM>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 15

<P_BA_CD>US1</P_BA_CD>

<P_CHARGES_PAID>false</P_CHARGES_PAID>

<P_DEPARTMENT>PSV</P_DEPARTMENT>

<P_DISPLAY_MSG_TYPE>PAIN001</P_DISPLAY_MSG_TYPE>

<P_FC_INFO_IND>0</P_FC_INFO_IND>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_CLASS>PAY</P_MSG_CLASS>

<P_MSG_STS>COMPLETE</P_MSG_STS>

<P_MSG_TYPE>Pain_001</P_MSG_TYPE>

<P_NON_ACC>false</P_NON_ACC>

<P_OFFICE>US1</P_OFFICE>

<P_ORG_INITG_PTY_CUST_CD>US1SACOMPUS33XXX</P_ORG_INITG_PTY_CUST_CD>

<P_ORIG_MSG_TYPE>Pain_001</P_ORIG_MSG_TYPE>

<P_PAYMENT_TP>FEDWIRE</P_PAYMENT_TP>

<P_PRIORITY>900</P_PRIORITY>

<P_PROC_DT>2010-05-02</P_PROC_DT>

<P_PRODUCT_CD>HVP</P_PRODUCT_CD>

<P_RVS_SELL>false</P_RVS_SELL>

<P_TIME_STAMP>2010-05-02 14:54:01.528</P_TIME_STAMP>

<P_USER_MSG_TYPE>false</P_USER_MSG_TYPE>

</ProcessingPersistentInfo>

<P_CLEARING_CUTOFF_NM>SLA-CLEAR</P_CLEARING_CUTOFF_NM>

<P_CLEARING_CUTOFF_STS>B</P_CLEARING_CUTOFF_STS>

<P_CLEARING_CUTOFF_TM>2010-05-02T15:30:00</P_CLEARING_CUTOFF_TM>

<P_PROC_CUTOFF_NM>SLA-PROCS</P_PROC_CUTOFF_NM>

<P_PROC_CUTOFF_STS>B</P_PROC_CUTOFF_STS>

<P_PROC_CUTOFF_TM>2010-05-02T18:00:00</P_PROC_CUTOFF_TM>

<P_TREASURY_CUTOFF_NM>SLA-TRSURY</P_TREASURY_CUTOFF_NM>

<P_TREASURY_CUTOFF_STS>B</P_TREASURY_CUTOFF_STS>

<P_TREASURY_CUTOFF_TM>2010-05-02T18:00:00</P_TREASURY_CUTOFF_TM>

</CutoffInfo>

<UserDefinedFields xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"

xmlns:q1="http://fundtech.com/SCL/CommonTypes"

xmlns:q0="http://fundtech.com/SCL/MessageSubmitService">

<q1:System>

<q1:PMT_CTGORY>1234</q1:PMT_CTGORY>

</q1:System>

</UserDefinedFields>

<D_DIRECT_RECEIVER_INDEX>X</D_DIRECT_RECEIVER_INDEX>

</ProcessingTransientInfo>

<MU_COMPLIANCE_FORCE_STS>X</MU_COMPLIANCE_FORCE_STS>

<MU_FORCE_STANDARD_VD>X</MU_FORCE_STANDARD_VD>

<MU_HANDLE_71G_GAP>X</MU_HANDLE_71G_GAP>

<MU_MISSED_CUTOFF>X</MU_MISSED_CUTOFF>

<MU_NSF_FORCE_STS>X</MU_NSF_FORCE_STS>

<MU_PI_FORCE_STS>X</MU_PI_FORCE_STS>

<MU_REQ_FOR_CHARGES_FORCE_STS>X</MU_REQ_FOR_CHARGES_FORCE_STS>

<MU_SPECIAL_INST_STS>X</MU_SPECIAL_INST_STS>

<MU_STOP_FLAGS_OVERRIDE_STS>X</MU_STOP_FLAGS_OVERRIDE_STS>

</UserMonitors>

<MF_CANCEL_MATCH_STS>X</MF_CANCEL_MATCH_STS>

<MF_CANCEL_REQUEST_VALID_STS>X</MF_CANCEL_REQUEST_VALID_STS>

<MF_CDT_STOP_FLAGS_STS>N</MF_CDT_STOP_FLAGS_STS>

<MF_COMPLIANCE_VALIDATION_STS>B</MF_COMPLIANCE_VALIDATION_STS>

<MF_DBT_STOP_FLAGS_STS>N</MF_DBT_STOP_FLAGS_STS>

<MF_DIRECT_COVER_GENERATED>X</MF_DIRECT_COVER_GENERATED>

<MF_FEE_PROC_STS>P</MF_FEE_PROC_STS>

<MF_GENERATED_ANSWER_MESSAGE>X</MF_GENERATED_ANSWER_MESSAGE>

<MF_GENERATED_CANCEL_REQUEST>X</MF_GENERATED_CANCEL_REQUEST>

<MF_GENERATE_REQ_CHARGES>X</MF_GENERATE_REQ_CHARGES>

<MF_INITIAL_CREATE>X</MF_INITIAL_CREATE>

<MF_MOP_SELECTION_STS>S</MF_MOP_SELECTION_STS>

<MF_N_MESSAGES_MATCH_STS>X</MF_N_MESSAGES_MATCH_STS>

<MF_OUT_REQ_FOR_CHRG_MATCH_STS>X</MF_OUT_REQ_FOR_CHRG_MATCH_STS>

<MF_PISN_MATCH_STS>X</MF_PISN_MATCH_STS>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 16

<MF_PISN_PROCESS_STS>X</MF_PISN_PROCESS_STS>

<MF_POSTING_STS>P</MF_POSTING_STS>

<MF_REQ_FOR_CHARGES_MATCH_STS>X</MF_REQ_FOR_CHARGES_MATCH_STS>

<MF_REQ_FOR_CHARGES_VALID_STS>X</MF_REQ_FOR_CHARGES_VALID_STS>

<MF_SPECIAL_INST_STS>X</MF_SPECIAL_INST_STS>

<MF_TIME_HOLD>H</MF_TIME_HOLD>

</ServiceMonitors>

</Monitors>

<M_DBT_CUST_PROFILE>

<F_DBT_CUST_BASE_NO>102030</F_DBT_CUST_BASE_NO>

<F_DBT_CUST_COUNTRYCODE>US</F_DBT_CUST_COUNTRYCODE>

<F_DBT_CUST_CUST_CODE>US1SACOMPUS33XXX</F_DBT_CUST_CUST_CODE>

<F_DBT_CUST_CUST_NAME>THE US COMPANY</F_DBT_CUST_CUST_NAME>

<F_DBT_CUST_CUST_TYPE>CU</F_DBT_CUST_CUST_TYPE>

<F_DBT_CUST_DEPARTMENT>PSV</F_DBT_CUST_DEPARTMENT>

</M_DBT_CUST_PROFILE>

<M_CDT_CUST_PROFILE>

<F_CDT_CUST_ABA>7878712</F_CDT_CUST_ABA>

<F_CDT_CUST_ADDRESS1>111, WALL STREET</F_CDT_CUST_ADDRESS1>

<F_CDT_CUST_ADDRESS2>TEST2 ADDRESSS</F_CDT_CUST_ADDRESS2>

<F_CDT_CUST_ALIAS>8585</F_CDT_CUST_ALIAS>

<F_CDT_CUST_CITY>NEW YORK</F_CDT_CUST_CITY>

<F_CDT_CUST_COUNTRYCODE>IE</F_CDT_CUST_COUNTRYCODE>

<F_CDT_CUST_CUST_NAME>CITIBANK N.A.</F_CDT_CUST_CUST_NAME>

<F_CDT_CUST_SWIFT_ID>CITIUS33XXX</F_CDT_CUST_SWIFT_ID>

<F_CDT_CUST_ZIP>10043</F_CDT_CUST_ZIP>

</M_CDT_CUST_PROFILE>

<M_STTLM_CCY_PROFILE>

<F_INSTR_CCY_DRAFT>false</F_INSTR_CCY_DRAFT>

<F_INSTR_CCY_EURO>IN</F_INSTR_CCY_EURO>

</M_STTLM_CCY_PROFILE>

<M_DBT_MOP_PROFILE>

<F_MOP_ALLOW_NAC_MSG>false</F_MOP_ALLOW_NAC_MSG>

<F_MOP_CHK_DRAFT_CURRENCY>false</F_MOP_CHK_DRAFT_CURRENCY>

<F_MOP_CURRENCY></F_MOP_CURRENCY>

<F_MOP_MOPDOWN>false</F_MOP_MOPDOWN>

<F_MOP_NCC_TYPE></F_MOP_NCC_TYPE>

<F_MOP_NM>BOOK</F_MOP_NM>

<F_MOP_SENDOUTMSG>false</F_MOP_SENDOUTMSG>

<F_MOP_SEND_REC_IDCODE>SA</F_MOP_SEND_REC_IDCODE>

<F_MOP_SETTLEMENT_ACC>1</F_MOP_SETTLEMENT_ACC>

<F_MOP_SETT_ACC_EXISTS>false</F_MOP_SETT_ACC_EXISTS>

<F_MOP_SPLIT_OVER_MAX>false</F_MOP_SPLIT_OVER_MAX>

</M_DBT_MOP_PROFILE>

<M_CDT_MOP_PROFILE>

<F_CDT_MOP_ALLOW_NAC_MSG>false</F_CDT_MOP_ALLOW_NAC_MSG>

<F_CDT_MOP_CCY></F_CDT_MOP_CCY>

<F_CDT_MOP_CHK_DRAFT_CCY>false</F_CDT_MOP_CHK_DRAFT_CCY>

<F_CDT_MOP_DOWN>false</F_CDT_MOP_DOWN>

<F_CDT_MOP_NCC_TP></F_CDT_MOP_NCC_TP>

<F_CDT_MOP_NM>BOOK</F_CDT_MOP_NM>

<F_CDT_MOP_SENDOUTMSG>false</F_CDT_MOP_SENDOUTMSG>

<F_CDT_MOP_SEND_REC_IDCODE>SA</F_CDT_MOP_SEND_REC_IDCODE>

<F_CDT_MOP_SETTLEMENT_ACC>1</F_CDT_MOP_SETTLEMENT_ACC>

<F_CDT_MOP_SETT_ACC_EXISTS>false</F_CDT_MOP_SETT_ACC_EXISTS>

<F_CDT_MOP_SPLIT_OVER_MAX>false</F_CDT_MOP_SPLIT_OVER_MAX>

</M_CDT_MOP_PROFILE>

</ReferenceData>

<D_FIRST_IN_CDT_CHAIN_BIC>CITIUS33XXX</D_FIRST_IN_CDT_CHAIN_BIC>

</XMLPersistentInfo>

<D_ELAPSED_TIME_MS>[MessageLoad]:558.9982</D_ELAPSED_TIME_MS>

</QaInfo>

</Extn>

</Msg>

<Pmnt>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 17

<Nm>THE US COMPANY</Nm>

<Id>

<OrgId>

<Othr>

<Id>US1SACOMPUS33XXX</Id>

</Othr>

</OrgId>

</Id>

</InitgPty>

</GrpHdr>

<Dbtr>

<Nm>THE US COMPANY</Nm>

<Id>

<OrgId>

<Othr>

<Id>US1SACOMPUS33XXX</Id>

</Othr>

</OrgId>

</Id>

</Dbtr>

<Id>

<Othr>

</Othr>

</Id>

</DbtrAcct>

<BIC>BOFAUS31XXX</BIC>

</FinInstnId>

</DbtrAgt>

<PmtId>

</PmtId>

<Amt>

</Amt>

<BIC>CITIUS33XXX</BIC>

</FinInstnId>

</CdtrAgt>

<Id>

<Othr>

</Othr>

</Id>

</CdtrAcct>

</CdtTrfTxInf>

</PmtInf>

</CstmrCdtTrfInitn>

</Document>

</Pmnt>

<q1:ProcessingPersistentInfo>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 18

<q1:P_OFFICE>US1</q1:P_OFFICE>

<q1:P_DEPARTMENT>PSV</q1:P_DEPARTMENT>

<q1:DebitSide>

<q1:P_DBT_ACCT_NB>22222222</q1:P_DBT_ACCT_NB>

<q1:P_DBT_ACCT_CCY>USD</q1:P_DBT_ACCT_CCY>

<q1:P_DBT_ACCT_OFFICE>US1</q1:P_DBT_ACCT_OFFICE>

</q1:DebitSide>

</q1:ProcessingPersistentInfo>

<q1:OperationalSection>

<q1:D_BUTTON_ID>Submit</q1:D_BUTTON_ID>

</q1:OperationalSection>

<q1:UserDefinedFields>

<q1:System>

<q1:PMT_CTGORY>1234</q1:PMT_CTGORY>

</q1:System>

<q1:Office/>

<q1:Customer/>

</q1:UserDefinedFields>

<q1:MsgNotes>

<q1:M_MSG_NOTES_GRID>

<q1:F_MSG_NOTES_EXTERNAL_NOTE_IND>1</q1:F_MSG_NOTES_EXTERNAL_NOTE_IND>

<q1:F_MSG_NOTES_ATTACHED_FILE_LINK>//NoteFile1.txt</q1:F_MSG_NOTES_ATTACHED_FILE_LINK>

<q1:F_MSG_NOTES_TEXT>LINE 1 TEXT</q1:F_MSG_NOTES_TEXT>

<q1:F_MSG_NOTES_USER_ID>USER1</q1:F_MSG_NOTES_USER_ID>

<q1:F_MSG_NOTES_CREATE_DATE>2010-01-

26T18:42:42.914+02:00</q1:F_MSG_NOTES_CREATE_DATE>

<q1:F_MSG_NOTES_REC_STATUS>AC</q1:F_MSG_NOTES_REC_STATUS>

</q1:M_MSG_NOTES_GRID>

</q1:MsgNotes>

</Extn>

</OrigMsg>

</ResponseDetails>

</ns1:FndtMsg>

</soap:Body>

</soap:Envelope>

2.6.3 Example 3: Non-existing MID

Invoke service with a non-existing MID (10729B4917DE3425) - service returns a fail response.

2.6.3.1 Request

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:mes="http://fundtech.com/SCL/MessageLoadService"

xmlns:com="http://fundtech.com/SCL/CommonTypes">

<soap:Header>

<com:FndtHeader>

<com:credentials>

<com:UserID>MASTERUSER</com:UserID>

<com:Role>ADMIN</com:Role>

</com:credentials>

</com:FndtHeader>

</soap:Header>

<soap:Body>

<mes:PerformMessageLoadRequest>

<com:P_MID>10729B4917DE3425</com:P_MID>

<com:credentials>

<com:UserID>audit3</com:UserID>

</com:credentials>

<mes:outputMode origPmntConversionType="Pain_001"

pmntConversionType="Pain_001">FULL</mes:outputMode>

</mes:PerformMessageLoadRequest>

</soap:Body>

</soap:Envelope>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 19

2.6.3.2 Response

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<ns1:FndtMsg xmlns="http://fundtech.com/SCL/CommonTypes">

<Msg>

<Extn>

</Extn>

</Msg>

<description>Message was not found for MID |1</description>

<error>

<description>Message was not found for MID 10729B4917DE3425</description>

</error>

</errorsList>

</ResponseDetails>

</ns1:FndtMsg>

</soap:Body>

</soap:Envelope>

2.6.4 Example 4: Presets with Output Mode ORIG_PERSISTENT_DATA

Invoke the service with an existing MID (1042984940CK0208) request for

ORIG_PERSISTENT_DATA (one of the use presets). No format conversion is required.

2.6.4.1 Request

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:q0="http://fundtech.com/SCL/MessageLoadService"

xmlns:q1="http://fundtech.com/SCL/CommonTypes" xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soapenv:Header>

<q1:credentials>

<q1:UserID>YUVBOFA</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</soapenv:Header>

<soapenv:Body>

<q0:PerformMessageLoadRequest>

<q1:credentials>

<q1:UserID>audit3</q1:UserID>

</q1:credentials>

<q1:P_MID>1042984940CK0208</q1:P_MID>

<q0:outputMode origPmntConversionType="Pain_001"

pmntConversionType="">ORIG_PERSISTENT_DATA</q0:outputMode>

</q0:PerformMessageLoadRequest>

</soapenv:Body>

</soapenv:Envelope>

2.6.4.2 Response

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<P_MID>1042984940CK0208</P_MID>

</Header>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 20

<Msg>

<Pmnt/>

<Extn>

<P_TIME_STAMP>2010-05-02 14:54:01.528</P_TIME_STAMP>

</ProcessingPersistentInfo>

<D_ELAPSED_TIME_MS>[MessageLoad]:13.054</D_ELAPSED_TIME_MS>

</QaInfo>

</Extn>

</Msg>

<Pmnt>

<Nm>THE US COMPANY</Nm>

<Id>

<OrgId>

<Othr>

<Id>US1SACOMPUS33XXX</Id>

</Othr>

</OrgId>

</Id>

</InitgPty>

</GrpHdr>

<Dbtr>

<Nm>THE US COMPANY</Nm>

<Id>

<OrgId>

<Othr>

<Id>US1SACOMPUS33XXX</Id>

</Othr>

</OrgId>

</Id>

</Dbtr>

<Id>

<Othr>

</Othr>

</Id>

</DbtrAcct>

<BIC>BOFAUS31XXX</BIC>

</FinInstnId>

</DbtrAgt>

<PmtId>

</PmtId>

<Amt>

</Amt>

<BIC>CITIUS33XXX</BIC>

</FinInstnId>

Actions on Payments Message Load Service Description

Global PAYplus Service-Oriented Architecture Page 21

</CdtrAgt>

<Id>

<Othr>

</Othr>

</Id>

</CdtrAcct>

</CdtTrfTxInf>

</PmtInf>

</CstmrCdtTrfInitn>

</Document>

</Pmnt>

<q1:ProcessingPersistentInfo>

<q1:P_OFFICE>US1</q1:P_OFFICE>

<q1:P_DEPARTMENT>PSV</q1:P_DEPARTMENT>

<q1:DebitSide>

<q1:P_DBT_ACCT_NB>22222222</q1:P_DBT_ACCT_NB>

<q1:P_DBT_ACCT_CCY>USD</q1:P_DBT_ACCT_CCY>

<q1:P_DBT_ACCT_OFFICE>US1</q1:P_DBT_ACCT_OFFICE>

</q1:DebitSide>

</q1:ProcessingPersistentInfo>

<q1:OperationalSection>

<q1:D_BUTTON_ID>Submit</q1:D_BUTTON_ID>

</q1:OperationalSection>

<q1:UserDefinedFields>

<q1:System>

<q1:PMT_CTGORY>1234</q1:PMT_CTGORY>

</q1:System>

<q1:Office/>

<q1:Customer/>

</q1:UserDefinedFields>

<q1:MsgNotes>

<q1:M_MSG_NOTES_GRID>

<q1:F_MSG_NOTES_EXTERNAL_NOTE_IND>1</q1:F_MSG_NOTES_EXTERNAL_NOTE_IND>

<q1:F_MSG_NOTES_ATTACHED_FILE_LINK>//NoteFile1.txt</q1:F_MSG_NOTES_ATTACHED_FILE_LINK>

<q1:F_MSG_NOTES_TEXT>LINE 1 TEXT</q1:F_MSG_NOTES_TEXT>

<q1:F_MSG_NOTES_USER_ID>USER1</q1:F_MSG_NOTES_USER_ID>

<q1:F_MSG_NOTES_CREATE_DATE>2010-01-

26T18:42:42.914+02:00</q1:F_MSG_NOTES_CREATE_DATE>

<q1:F_MSG_NOTES_REC_STATUS>AC</q1:F_MSG_NOTES_REC_STATUS>

</q1:M_MSG_NOTES_GRID>

</q1:MsgNotes>

</Extn>

</OrigMsg>

</ResponseDetails>

</FndtMsg>

</soap:Body>

</soap:Envelope>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 22

3 Message Submit Service Description

3.1 Overview

This service creates a new message in GPP or amends an existing one. The service includes some

action button validations (i.e., the action button is allowed for the message status) and some payment

attributes validations (for example, mandatory attributes are set correctly), as well as user

authorization to perform the action.

The service can accept a batch (i.e. multiple payments) or a single payment action.

3.2 Service Functions

This service only supports a single method: MessageSubmitService.

This table lists the possible action buttons available for use in the service:

Button ID Description

Submit Performs validations and processes the payment when a new

message is manually created.

Reject Prompts a rejection (PACS 002) for a payment

CancelTemplate Cancels/deletes a templates

Approve Releases the payment/template into the processing flow from the

Pending Approval status queue

CreatePaymentFromTemplate Receives the template ID Receives the template ID and changed

fields, and generates individual/multiple payments (in this case,

the payment information is derived from the template and from

the quick fill fields).

Step 1 – Get the list of templates that belong to the selected

template set (by user). For this step use the GetQueueListService

with the operator In Template Set.

Step 2 – Generate individual/multiple payments by sending the

template ID and the fields that the user entered (such as value

date and amount).

Send to Repair Sends the payment to Repair status

Save Saves payment without performing validation (set payment status

to Timed Hold)

AcceptDupex Confirms the payment is not a duplicate for payments that are

waiting in possible duplicate queue

Cancel Request Initiates the cancellation process. That is, changing message

status to Pending cancellation request from which a user can

either RefuseCancel or Cancel the payment.

RefuseCancel Refuse to cancel a payment (for a cancellation request). Payment

returns to its previous status

Cancel Sends payment to Cancel status queue

Validate Returns all errors without saving the payment

FinalApprove Perform final approval step for pending approval messages

Note: An additional capability is to store user notes for every action that will be associated with the

message. These notes are defined as internal or external notes. Each note may contain a link to a

reference file. Some notes can be accessed and edited.

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 23

3.3 Input

• A subset of D+H standard message

• These Input Parameters must be part of the input request:

Mandatory extension fields for MessageSubmitService input.

Parameter Tag Name L Format Comment

Extension Extn 0 {1..1} D+H Extension

Persistent

Information

+ProcessingPersiste

ntInfo

1 {1..1}

Office ++P_OFFICE 2 String

{0..1} A 3 letter code from BANKS table in the

Department ++P_DEPARTMENT 2 String {0..1} The relevant Office Department code

Operational

instructions +OperationalSection 1 {1..1}

Action

name ++D_BUTTON_ID 2 String {1..1} The action name is a valid button ID

taken from MESSAGEBUTTONS table

(See Action Buttons)

3.3.1 Service Input Table Legend

The table explains the symbols used in the Service Input tables.

Symbol Description

L Element level in the file

++++ Shows the element indentation

3.4 Processing

Input validations that include:

1. Action button exists (MESSAGEBUTTONS.BUTTONID) AND.

2. Message button is allowed for the message status (P_MSG_STS).

a. Assess Message fields sets selection system rule to identify the relevant button screen set

(see list of Screen SetScreen Set).

These are the Screen Sets for the Different Message Statuses:

Condition Screen set

[P_MSG_STS] = APPROVE_CANCEL WSI_STTN_APPR_CNCL

[P_MSG_STS] = COMPLETE AND [P_IS_HISTORY] = 2

WSI_STTN_CMPLT_TMP

[P_MSG_STS] = DUPEX WSI_STTN_DUPX

[P_MSG_STS] = NAK WSI_STTN_NAK

[P_MSG_STS] = PEND_APPROV WSI_STTN_PND_APPR

[P_MSG_STS] = (RECEIVED) WSI_STTN_RCVD

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 24

Condition Screen set

[P_MSG_STS] = REPAIR WSI_STTN_RPR

[P_IS_HISTORY] = 2 AND [P_MSG_STS] = REPAIR WSI_STTN_RPR_TMPLT

[P_MSG_STS] = SCHEDULE WSI_STTN_SCHED

[P_MSG_STS] = VERIFY WSI_STTN_VRFY

With screen set defined, assess the available action buttons for the screen and make sure the

provided button ID is allowed for this screen set:

Screen Set Message Status Button ID

WSI_STTN_CMPLT_TMP Complete templates Submit

WSI_STTN_CMPLT_TMP Complete templates CreatePaymentFromTemplate

WSI_STTN_APPR_CNCL Approve cancel Approve

WSI_STTN_APPR_CNCL Approve cancel RefuseCancel

WSI_STTN_APPR_CNCL Approve cancel Reject

WSI_STTN_PND_APPR Pending approval Approve

WSI_STTN_PND_APPR Pending approval Cancel

WSI_STTN_PND_APPR Pending approval CancelTemplate

WSI_STTN_PND_APPR Pending approval FinalApprove

WSI_STTN_PND_APPR Pending approval Reject

WSI_STTN_PND_APPR Pending approval Submit

WSI_STTN_RPR_TMPLT Repair template CancelTemplate

WSI_STTN_DUPX Possible duplicate AcceptDupex

WSI_STTN_CMPLT_TMP Complete templates CancelTemplate

WSI_STTN_CMPLT_TMP Complete templates Reject

WSI_STTN_CMPLT_TMP Complete templates Send to Repair

WSI_STTN_DUPX Possible duplicate Cancel

WSI_STTN_DUPX Possible duplicate Reject

WSI_STTN_DUPX Possible duplicate Submit

WSI_STTN_DUPX Possible duplicate Validate

WSI_STTN_RCVD Received Save

WSI_STTN_RCVD Received Submit

WSI_STTN_RCVD Received Validate

WSI_STTN_RPR Repair Cancel

WSI_STTN_RPR Repair Save

WSI_STTN_RPR Repair Validate

WSI_STTN_RPR Repair Submit

WSI_STTN_SCHED Schedule Cancel

WSI_STTN_NAK NAK Send to Repair

WSI_STTN_NAK NAK Cancel

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 25

3.5 Output

• Successful creation of a new message in GPP repository (MINF table)

• A D+H message format is returned, along with a message ID that was associated with the

message

This table is an extract from D+H message showing the important additional derived information that

is returned together with the response.

Parameter Tag Name Format Comment

Message ID P_MID String {1..1} Message unique ID in GPP

Message status P_MSG_STS String {1..1} The queue where the payment is. This

would be MSG_STATUS from

STATUSES system table

Time stamp P_TIME_STAMP Date time {1..1} Server time representing the last time

the message was modified

Payment/Template

indicator P_IS_HISTORY [0,2]{1..1} Valid Values:

0 - Active Partition

1 - Historical Partition

2 - Templates Partition

3.6 Errors

Code Description Notes

40037 Party cannot be found. Invalid account

number: [invalid account number].

40039 Unable to identify 1st in credit chain

40040 Unable to identify 1st in debit chain

40041 Failed to derive account number

40078 Sender ([Original Sender BIC]) has no debit

authorization on account number ([Debit

account number]) (BIC = [Debit party BIC])

Debit authorization check has been failed

40083 Party cannot be found. Invalid ABA: [Invalid

ABA].

40079 Initiating party [Name of the party] has no

debit authorization on account number

[Debit account number]

Debit authorization check has been failed

40102 Payment status does not allow cancellation Error message which will be issued when

cancellation request cannot be processed

because the original payment status does

not allow cancellation

40161 Payment future value date (|1) is greater

than the MOP max extension (|2)

60019 Dbtr is empty

60020 Dbtr BIC is invalid

60021 Dbtr Agent ID is invalid

60022 Dbtr Agent BIC is invalid

60023 Instg Rmbrsmnt Agent is empty

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 26

Code Description Notes

60024 Instg Rmbrsmnt Agent BIC is invalid

60025 Instd Rmbrsmnt Agent is empty

60026 Instd Rmbrsmnt Agent BIC is invalid

60027 Thrd Rmbrsmnt Agent is empty

60028 Thrd Rmbrsmnt Agent BIC is invalid

60029 Intrmy Agent1 should be empty

60030 Intrmy Agent1 is empty

60031 Intrmy Agent1 BIC is invalid

60032 Cdtr Agent is empty

60033 Cdtr Agent BIC is invalid

60034 Cdtr is empty

60084 The action ButtonID used in the submit

action is not allowed for a message with

status Current message status

60035 Cdtr BIC is invalid

40199 Cancel action is not permitted on a

Template pending Future changes

40200 No action is permitted on a Template

pending Future changes

See also Generic Errors.

3.7 Examples

3.7.1 Example 1: Manual Creation of a Payment

3.7.1.1 Request

Provide payment details and action button (D_BUTTON_ID) as submit.

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope

xmlns:q0="http://fundtech.com/SCL/MessageSubmitService"

xmlns:q1="http://fundtech.com/SCL/CommonTypes"

xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soapenv:Header>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>SERVICES</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</q1:FndtHeader>

</soapenv:Header>

<soapenv:Body>

<q0:MessageSubmitRequest>

<q0:MsgBatch>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>audit3</q1:UserID>

</q1:credentials>

</q1:FndtHeader>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 27

<q1:FndtPmntTxInf>

<q1:FndtMsg>

<q1:Msg>

<q1:Pmnt>

<Document

xmlns="urn:iso:std:iso:20022:tech:xsd:pain.001.001.03"

xmlns:n1="http://www.w3.org/2001/XMLSchema-instance">

<BtchBookg>false</BtchBookg>

<Nm>THE US COMPANY</Nm>

<Id>

<OrgId>

<Othr>

<Id>US1SACOMPUS33XXX</Id>

</Othr>

</OrgId>

</Id>

</InitgPty>

</GrpHdr>

<Dbtr>

<Nm>THE US COMPANY</Nm>

<Id>

<OrgId>

<Othr>

<Id>US1SACOMPUS33XXX</Id>

</Othr>

</OrgId>

</Id>

</Dbtr>

<Id>

<Othr>

</Othr>

</Id>

</DbtrAcct>

<BIC>BOFAUS31XXX</BIC>

</FinInstnId>

</DbtrAgt>

<PmtId>

</PmtId>

<Amt>

</Amt>

<BIC>CITIUS33XXX</BIC>

</FinInstnId>

</CdtrAgt>

<Id>

<Othr>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 28

</Othr>

</Id>

</CdtrAcct>

</CtgyPurp>

<Strd>

<Tp>

</CdOrPrtry>

</Tp>

</RfrdDocInf>

</Strd>

</RmtInf>

</CdtTrfTxInf>

</PmtInf>

</CstmrCdtTrfInitn>

</Document>

</q1:Pmnt>

<q1:Extn>

<q1:ProcessingPersistentInfo>

<q1:P_OFFICE>US1</q1:P_OFFICE>

<q1:P_DEPARTMENT>PSV</q1:P_DEPARTMENT>

</q1:ProcessingPersistentInfo>

<q1:OperationalSection>

<q1:D_BUTTON_ID>Submit</q1:D_BUTTON_ID>

</q1:OperationalSection>

</q1:Extn>

</q1:Msg>

</q1:FndtMsg>

</q1:FndtPmntTxInf>

</q0:MsgBatch>

</q0:MessageSubmitRequest>

</soapenv:Body>

</soapenv:Envelope

3.7.1.2 Response

Use Case 1: Payment was successfully created. The MID is returned along with the time stamp of

creation and a payment/template indicator and the message status.

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<P_MID>10C02A4104J00231</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>PEND_APPROV</P_MSG_STS>

<P_TIME_STAMP>2010-12-02 10:41:06.134</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 29

</soap:Body>

</soap:Envelope>

Use Case 2: Message already exists (payment is created but moving to possible duplicate queue)

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<P_MID>10C02A3752KR0425</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<M_MSGERR_LINE>

<F_MSGERR_CODE>6042</F_MSGERR_CODE>

<F_MSGERR_TIME_STAMP>2010-12-02 10:37:53.726</F_MSGERR_TIME_STAMP>

<F_MSGERR_CREATE_DATE>2010-11-30T20:17:53</F_MSGERR_CREATE_DATE>

<F_MSGERR_TIME_ZONE>EST</F_MSGERR_TIME_ZONE>

<F_MSGERR_FAULT></F_MSGERR_FAULT>

<F_MSGERR_PARAMS/>

<F_MSGERR_DISPLAY>0</F_MSGERR_DISPLAY>

<F_MSGERR_FIELD_LOGICAL_ID/>

</M_MSGERR_LINE>

</MsgErrors>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>DUPEX</P_MSG_STS>

<P_TEMPLATE_CD>05</P_TEMPLATE_CD>

<P_TIME_STAMP>2010-12-02 10:37:53.775</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

</soap:Body>

</soap:Envelope>

3.7.2 Example 2: Final Approve of an Existing Payment

Provide payment reference (P_MID), payment time stamp (P_TIME_STAMP) and action button

(D_BUTTON_ID) as FinalApprove.

3.7.2.1 Request

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:q0="http://fundtech.com/SCL/MessageSubmitService"

xmlns:q1="http://fundtech.com/SCL/CommonTypes" xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soapenv:Header>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>SERVICES</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</q1:FndtHeader>

</soapenv:Header>

<soapenv:Body>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 30

<q0:MessageSubmitRequest>

<q0:MsgBatch>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>audit3</q1:UserID>

</q1:credentials>

</q1:FndtHeader>

<q1:FndtPmntTxInf>

<q1:FndtMsg>

<q1:Header>

<q1:P_MID>11313E2230DI0630</q1:P_MID>

</q1:Header>

<q1:Msg>

<q1:Pmnt/>

<q1:Extn>

<q1:ProcessingPersistentInfo>

<q1:P_OFFICE>US1</q1:P_OFFICE>

<q1:P_DEPARTMENT>PSV</q1:P_DEPARTMENT>

<q1:P_TIME_STAMP>2011-03-13 14:22:31.887</q1:P_TIME_STAMP>

</q1:ProcessingPersistentInfo>

<q1:OperationalSection>

<q1:D_BUTTON_ID>FinalApprove</q1:D_BUTTON_ID>

</q1:OperationalSection>

</q1:Extn>

</q1:Msg>

</q1:FndtMsg>

</q1:FndtPmntTxInf>

</q0:MsgBatch>

</q0:MessageSubmitRequest>

</soapenv:Body>

</soapenv:Envelope>

3.7.2.2 Response

Use case 1: The Final Approval step was performed for a payment in pending approval status. (Final

approve button is available for this status)

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<P_MID>11313E2230DI0630</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>COMPLETE</P_MSG_STS>

<P_TIME_STAMP>2011-03-13 14:23:26.432</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

</soap:Body>

</soap:Envelope>

Use case 2: The final approval step was performed for a payment in Repair status. (Final approve

button is not available for this status), the user gets error code 60084 meaning: The action

FinalApprove is not allowed for a message with status REPAIR.

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 31

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<D_SKIP_PERSIST_ON_ERROR>true</D_SKIP_PERSIST_ON_ERROR>

<P_MID>11313E1430EZ0219</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<M_MSGERR_LINE>

<F_MSGERR_CODE>60084</F_MSGERR_CODE>

<F_MSGERR_TIME_STAMP>2011-03-13 14:15:34.242</F_MSGERR_TIME_STAMP>

<F_MSGERR_SEVERITY>0</F_MSGERR_SEVERITY>

<F_MSGERR_CREATE_DATE>2011-03-13T03:45:34.242-

05:00</F_MSGERR_CREATE_DATE>

<F_MSGERR_TIME_ZONE>EST</F_MSGERR_TIME_ZONE>

<F_MSGERR_FAULT></F_MSGERR_FAULT>

<F_MSGERR_PARAMS>@@ @@STRING@@@@,@@ @@STRING@@</F_MSGERR_PARAMS>

<F_MSGERR_DISPLAY>0</F_MSGERR_DISPLAY>

<F_MSGERR_FIELD_LOGICAL_ID/>

</M_MSGERR_LINE>

</MsgErrors>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>REPAIR</P_MSG_STS>

<P_TIME_STAMP>2011-03-13 14:14:31.342</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

</soap:Body>

</soap:Envelope>

3.7.3 Example 3: Cancel a Payment

Cancel processing flow to an existing payment by providing the MID and the action button cancel.

3.7.3.1 Request

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope

xmlns:q0="http://fundtech.com/SCL/MessageSubmitService"

xmlns:q1="http://fundtech.com/SCL/CommonTypes"

xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soapenv:Header>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>SERVICES</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</q1:FndtHeader>

</soapenv:Header>

<soapenv:Body>

<ns20:MessageSubmitRequest

xmlns:ns10="http://notesservice.pubsub.ws.services.cp.bofa.com"

xmlns:ns11="http://ws.entitlements.services.cp.bofa.com/"

xmlns:ns12="http://www.bankofamerica.com/cpo/payments/services/approval/v002"

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 32

xmlns:ns13="http://fundtech.com/SCL/CommonTypes"

xmlns:ns14="http://fundtech.com/SCL/MopSelectionService"

xmlns:ns15="http://fundtech.com/SCL/MessageLoadService"

xmlns:ns16="http://fundtech.com/SCL/ProfileListService"

xmlns:ns17="http://fundtech.com/SCL/StaticDataCommonTypes"

xmlns:ns18="http://fundtech.com/SCL/QueueListService"

xmlns:ns19="http://Fundtech.com/prule-metadata-dto.xsd"

xmlns:ns2="http://payments.cpo.gcib.bofa.com/xsd/paymentorchestrator/sla/V001"

xmlns:ns20="http://fundtech.com/SCL/MessageSubmitService"

xmlns:ns21="http://www.bankofamerica.com/xmlschema/resource/metadata/osa/infrastructure/v001"

xmlns:ns22="http://payments.cpo.gcib.bofa.com/xsd/paymentextn/V001"

xmlns:ns23="http://payments.cpo.gcib.bofa.com/xsd/paymentlisttype/V001"

xmlns:ns24="http://payments.cpo.gcib.bofa.com/xsd/paymentservice/V001"

xmlns:ns25="urn:iso:std:iso:20022:tech:xsd:pain.001.001.03"

xmlns:ns26="http://payments.cpo.gcib.bofa.com/xsd/paymentutilityservice/V001"

xmlns:ns4="http://payments.cpo.gcib.bofa.com/xsd/cpsMessageTypes/V001"

xmlns:ns5="http://payments.cpo.gcib.bofa.com/xsd/commontypes/V001"

xmlns:ns6="http://payments.cpo.gcib.bofa.com/xsd/fxservice/V001"

xmlns:ns7="http://pubsubservice.message.ws.services.cp.bofa.com"

xmlns:ns8="http://pubsubservice.ws.services.cp.bofa.com/xsd/headertypes/V001"

xmlns:ns9="http://payments.baml.com/PaymentsNotificationV001">

<ns20:MsgBatch>

<ns13:FndtHeader>

<ns13:credentials>

<ns13:UserID>muli2</ns13:UserID>

</ns13:credentials>

</ns13:FndtHeader>

<ns13:FndtPmntTxInf>

<ns13:FndtMsg>

<ns13:Header>

<ns13:credentials>

<ns13:UserID>Muli 2</ns13:UserID>

</ns13:credentials>

<ns13:P_MID>10B29H2451640188</ns13:P_MID>

</ns13:Header>

<ns13:Msg>

<ns13:Pmnt>

<ns25:Document>

<ns25:CstmrCdtTrfInitn>

<ns25:GrpHdr>

<ns25:InitgPty>

<ns25:Id>

<ns25:OrgId>

<ns25:Othr>

<ns25:Id>US1SACOMPUS33XXX</ns25:Id>

</ns25:Othr>

</ns25:OrgId>

</ns25:Id>

</ns25:InitgPty>

</ns25:GrpHdr>

<ns25:PmtInf>

<ns25:ReqdExctnDt>2011-09-26</ns25:ReqdExctnDt>

</ns25:PmtInf>

</ns25:CstmrCdtTrfInitn>

</ns25:Document>

</ns13:Pmnt>

<ns13:Extn>

<ns13:ProcessingPersistentInfo>

<ns13:P_OFFICE>US1</ns13:P_OFFICE>

<ns13:P_DEPARTMENT>PSV</ns13:P_DEPARTMENT>

<ns13:P_TIME_STAMP>2010-11-29 17:24:51.905</ns13:P_TIME_STAMP>

<ns13:P_IS_HISTORY>0</ns13:P_IS_HISTORY>

</ns13:ProcessingPersistentInfo>

<ns13:OperationalSection>

<ns13:D_BUTTON_ID>Cancel</ns13:D_BUTTON_ID>

</ns13:OperationalSection>

</ns13:Extn>

</ns13:Msg>

</ns13:FndtMsg>

</ns13:FndtPmntTxInf>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 33

</ns20:MsgBatch>

</ns20:MessageSubmitRequest>

</soapenv:Body>

</soapenv:Envelope>

3.7.3.2 Response

Message ID is cancelled.

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soap:Body xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<D_SKIP_PERSIST_ON_ERROR>true</D_SKIP_PERSIST_ON_ERROR>

<P_MID>10B29H2451640188</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<M_MSGERR_LINE>

<F_MSGERR_CODE>40227</F_MSGERR_CODE>

<F_MSGERR_TIME_STAMP>2010-12-02 10:51:41.613</F_MSGERR_TIME_STAMP>

<F_MSGERR_SEVERITY>0</F_MSGERR_SEVERITY>

<F_MSGERR_CREATE_DATE>2010-11-30T20:31:41</F_MSGERR_CREATE_DATE>

<F_MSGERR_TIME_ZONE>EST</F_MSGERR_TIME_ZONE>

<F_MSGERR_FAULT></F_MSGERR_FAULT>

<F_MSGERR_PARAMS>@@ @@STRING@@</F_MSGERR_PARAMS>

<F_MSGERR_DISPLAY>0</F_MSGERR_DISPLAY>

<F_MSGERR_FIELD_LOGICAL_ID/>

</M_MSGERR_LINE>

</MsgErrors>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>CANCELED</P_MSG_STS>

<P_TIME_STAMP>2010-12-01 15:52:26.772</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

</soap:Body>

</soap:Envelope>

3.7.4 Example 4: When an Action is not Allowed for the Queue

• Message is in PEND_APPROVE and user tries to perform retract

• First step – create the message (also demonstrates the quick fill button):

3.7.4.1 Request

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope

xmlns:q0="http://fundtech.com/SCL/MessageSubmitService"

xmlns:q1="http://fundtech.com/SCL/CommonTypes"

xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soapenv:Header>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 34

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>SERVICES</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</q1:FndtHeader>

</soapenv:Header>

<soapenv:Body>

<q0:MessageSubmitRequest>

<q0:MsgBatch>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>audit3</q1:UserID>

</q1:credentials>

</q1:FndtHeader>

<q1:FndtPmntTxInf>

<q1:FndtMsg>

<q1:Msg>

<q1:Pmnt>

<Document

xmlns="urn:iso:std:iso:20022:tech:xsd:pain.001.001.03"

xmlns:n1="http://www.w3.org/2001/XMLSchema-instance">

<PmtId>

</PmtId>

<Amt>

</Amt>

</CdtTrfTxInf>

</PmtInf>

</CstmrCdtTrfInitn>

</Document>

</q1:Pmnt>

<q1:Extn>

<q1:ProcessingPersistentInfo>

<q1:P_OFFICE>US1</q1:P_OFFICE>

<q1:P_DEPARTMENT>PSV</q1:P_DEPARTMENT>

<q1:P_TEMPLATE_CD>TEMPLATE_UPDATEaf</q1:P_TEMPLATE_CD>

<q1:P_TEMPLATE_MID>10A04K1340292853</q1:P_TEMPLATE_MID>

</q1:ProcessingPersistentInfo>

<q1:OperationalSection>

<q1:D_BUTTON_ID>CreatePaymentFromTemplate</q1:D_BUTTON_ID>

</q1:OperationalSection>

</q1:Extn>

</q1:Msg>

</q1:FndtMsg>

</q1:FndtPmntTxInf>

</q0:MsgBatch>

</q0:MessageSubmitRequest>

</soapenv:Body>

</soapenv:Envelope>

3.7.4.2 Response

<?xml version="1.0" encoding="UTF-8"?>

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soap:Body

xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<FndtMsgBatch

xmlns="http://fundtech.com/SCL/CommonTypes">

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 35

<P_MID>10C23F4124960431</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>PEND_APPROV</P_MSG_STS>

<P_TEMPLATE_CD>TEMPLATE_UPDATEaf</P_TEMPLATE_CD>

<P_TEMPLATE_NM>TEMPLA</P_TEMPLATE_NM>

<P_TIME_STAMP>2010-12-23 15:41:25.738</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

</soap:Body>

</soap:Envelope>

Second step – button ID is Retract.

3.7.4.3 Request

<?xml version="1.0" encoding="UTF-8"?>

<soapenv:Envelope

xmlns:q0="http://fundtech.com/SCL/MessageSubmitService"

xmlns:q1="http://fundtech.com/SCL/CommonTypes"

xmlns:soapenv="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance">

<soapenv:Header>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>SERVICES</q1:UserID>

<q1:Role>ADMIN</q1:Role>

</q1:credentials>

</q1:FndtHeader>

</soapenv:Header>

<soapenv:Body>

<q0:MessageSubmitRequest>

<q0:MsgBatch>

<q1:FndtHeader>

<q1:credentials>

<q1:UserID>audit3</q1:UserID>

</q1:credentials>

</q1:FndtHeader>

<q1:FndtPmntTxInf>

<q1:FndtMsg>

<q1:Header>

<q1:P_MID>10C23F4124960431</q1:P_MID>

</q1:Header>

<q1:Msg>

<q1:Pmnt/>

<q1:Extn>

<q1:ProcessingPersistentInfo>

<q1:P_OFFICE>US1</q1:P_OFFICE>

<q1:P_DEPARTMENT>PSV</q1:P_DEPARTMENT>

<q1:P_TIME_STAMP>2010-12-23 15:41:25.738</q1:P_TIME_STAMP>

</q1:ProcessingPersistentInfo>

<q1:OperationalSection>

<q1:D_BUTTON_ID>Retract</q1:D_BUTTON_ID>

</q1:OperationalSection>

</q1:Extn>

</q1:Msg>

</q1:FndtMsg>

Actions on Payments Message Submit Service Description

Global PAYplus Service-Oriented Architecture Page 36

</q1:FndtPmntTxInf>

</q0:MsgBatch>

</q0:MessageSubmitRequest>

</soapenv:Body>

</soapenv:Envelope>

3.7.4.4 Response

<?xml version="1.0" encoding="UTF-8"?>

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope"

xmlns:xsd="http://www.w3.org/2001/XMLSchema"

xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

<soap:Body

xmlns:ns1="http://fundtech.com/SCL/CommonTypes">

<FndtMsgBatch

xmlns="http://fundtech.com/SCL/CommonTypes">

<D_SKIP_PERSIST_ON_ERROR>true</D_SKIP_PERSIST_ON_ERROR>

<P_MID>10C23F4124960431</P_MID>

</Header>

<Msg>

<Pmnt/>

<Extn>

<M_MSGERR_LINE>

<F_MSGERR_CODE>60084</F_MSGERR_CODE>

<F_MSGERR_TIME_STAMP>2010-12-23 15:42:41.331</F_MSGERR_TIME_STAMP>

<F_MSGERR_SEVERITY>0</F_MSGERR_SEVERITY>

<F_MSGERR_CREATE_DATE>2010-12-22T01:22:41</F_MSGERR_CREATE_DATE>

<F_MSGERR_TIME_ZONE>EST</F_MSGERR_TIME_ZONE>

<F_MSGERR_FAULT/>

<F_MSGERR_PARAMS>@@ @@STRING@@@@,@@ @@STRING@@</F_MSGERR_PARAMS>

<F_MSGERR_DISPLAY>0</F_MSGERR_DISPLAY>

<F_MSGERR_FIELD_LOGICAL_ID/>

</M_MSGERR_LINE>

</MsgErrors>

<P_IS_HISTORY>0</P_IS_HISTORY>

<P_MSG_STS>PEND_APPROV</P_MSG_STS>

<P_TEMPLATE_CD>TEMPLATE_UPDATEaf</P_TEMPLATE_CD>

<P_TEMPLATE_NM>TEMPLA</P_TEMPLATE_NM>

<P_TIME_STAMP>2010-12-23 15:41:25.738</P_TIME_STAMP>

</ProcessingPersistentInfo>

</Extn>

</Msg>

</FndtMsg>

</FndtPmntTxInf>

</FndtMsgBatch>

</soap:Body>

</soap:Envelope>

Actions on Payments Errors

Global PAYplus Service-Oriented Architecture Page 37

4 Errors

4.1 Generic Errors

Code Description Notes

28560 An error has occurred while trying to perform this

action

40087 Service [service name] failure

40071 [Office name] is not a valid Office Office was not found in cache

40127 Service [service name] failure, (last step: [Last step

name])

3104 Payment currency should equal to debit account or

credit account currency Error message reported when

neither the Debit nor Credit

account's currency is in the

payment's currency. Message is

routed to the Repair queue.

10002 Interface severe error during processing. Reason:

[Reason for the crash] The Alerts are generated as part of

the transaction and thus are either

persisted into MQ or the entire

transaction is rolled back and the

alert will be generated when the

transaction is completed after the

system is available again

40104 Rule type ID [Rule type ID] – [Rule type description]

- was not found Error message which will be

issued when message processing,

mandatory rule type was not

found, (e.g. department, business

area, payment classification etc)

60000 The data content of this field may not contain a / as

its first character, nor as its last character; nor may it

contain // (two consecutive slashes) anywhere

within its contents.

60001 Instr Id is empty

60002 Instr Id length should not exceed 16 characters

60003 Instr Id format is invalid

60004 Instr Id is invalid, should not start or end with a slash

/ and should not contain two consecutive slashes //.

60005 Sttlm date is empty

60006 Sttlm ccy is empty

60007 Sttlm amount is empty

60008 Sttlm date is invalid

60009 Year in the Sttlm date is invalid

60010 Sttlm ccy is invalid

60011 Sttlm amount is invalid. Number of decimal digits in

amount exceeds maximum allowed for the currency

60012 Sttlm amount is invalid, the integer part of amount

should contain at least one digit

60013 Decimal separator in Sttlm amount is incorrect,

should be a single comma

Actions on Payments Errors

Global PAYplus Service-Oriented Architecture Page 38

Code Description Notes

60014 Instd ccy/Instd amount is empty

60015 Instd ccy is invalid

60016 Instd amount is invalid

60017 Instd amount is invalid, the integer part of amount

should contain at least one digit

60018 Decimal separator in Instd amount is incorrect,

should be a single comma

4.2 Static Data Related Error Codes

Code Description Notes

77787 Input parameter(s) [missing parameter names] missing. An input parameter is missing.

4.3 Message Processing Related Error Codes

Code Description Notes

77782 Message was not found for MID

[missing MID] MID not found in MINF

3104 Payment currency should equal

debit account or credit account

currency

Error message reported when neither the Debit nor

Credit account currency is in the payment's

currency. Message is routed to the Repair queue.

Actions on Payments Appendix A

Global PAYplus Service-Oriented Architecture Page 39

Appendix A

List of System Users

GPP users are specified in the System User menu, or in DB in USERS table. For more information,

see GPP Online Help.

List of System Entitlements

GPP users are associated with an appropriate entitlement. Entitlement is a profile in GPP specified in

the Entitlement menu. For more information, see GPP Online Help.

Document Preservation

Message Load Service

Maintenance Query

Any change in message attributes Select t.* from LOGICAL_FIELDS

List of supported documents Select DOCUMENT_ID from

XML_DOCUMENT_TYPES

List of supported message output values Select distinct XML_TYPE

from LOGICAL_FIELDS_XPATH

union

select distinct FORMAT_TYPE from

XML_FORMAT_TYPE_RELATIONS

Message Submit Service

Maintenance Query

List of messages that are

allowed for creation MESSAGEBUTTONS.AVAILABLE_FOR_PAYMENT_CREATION

<> 0

List of message buttons Select BUTTONID, BUTTONDESCRIPTION from

MESSAGEBUTTONS

Service screen sets Select PRULES.CONDITIONS_AS_TEXT,

PRULES.RULE_ACTION

from OBJECT_PRULES

inner join PRULES

on PRULES.UID_PRULES = OBJECT_PRULES.RULE_UID

where OBJECT_PRULES.RULE_TYPE_ID = 108 and RULE_UID

such as %WSI%;

List of applicable action

buttons per message status Select *

from MESSAGE_FIELDS_SETTING

where FIELDS_GROUP_ID = SERVICES_INTERFACE

Actions on Payments Appendix B: Glossary

Global PAYplus Service-Oriented Architecture Page 40

Appendix B: Glossary

This table lists the terms used in this document:

Term Description

GPP Global PAYplus

Logical field ID Messages attribute description. With GPP use of logical fields that

are associated to different XML paths, it is possible to define a

message attribute, its type, its display name and other attributes. For

example, the Sttlm amt describes the settlement amount of the

outgoing payment. The logical field ID is used behind the scenes

and is unique (X_STTLM_AMT)

LOGICAL_FIELDS_XPATH Describes a different XML path location & element name for the

logical field ID for different message types (like PACS008, PAIN

001).

For example: X_STTLM_AMT has different XML path in PACS 008

(/IntrBkSttlmAmt tag name: IntrBkSttlmAmt).

Note that the path may be a relative path. For full path, refer to the

parent path ID that is specified under the logical field.

MID Message ID –a unique identifier generated by GPP for each

Created/Incoming payment

MINF Message information table in the database. Stores all messages in

the system. Primary key: P_MID

PACS Payments Clearing and Settlement.

PAIN Payment Initiation.

PDO Payment Data Object (PDO)

SOA Service-Oriented Architecture

Service Oriented Architecture GPP SOA Guide Actions On Payments

Navigation menu

Versions of this User Manual:

Views

Navigation
