Global PAYplus Version 4.6.3
Fndt Usage for Balance Inquiry
Interface Message
Technical Guide
Copyright
© 2009-2016 D+H Global Transaction Banking Solutions. All rights reserved. D+H is a trademark of D+H Limited
Partnership.
PROPRIETARY AND CONFIDENTIAL - This document contains information, which contains Confidential and
Know How property of D+H. Disclosure to or use by persons who are not expressly authorized in writing by D+H
is strictly prohibited.
D+H reserves the right to alter the specifications and descriptions in this publication without prior notice. No part
of this publication shall be deemed to be part of any contract or warranty unless specifically incorporated by
reference into such contract or warranty.
All brand or product names are the trademarks or registered trademarks of their respective holders.
The information contained herein is merely descriptive in nature, and does not constitute a binding offer for the
license of the product described herein.
Catalog ID: GPP4.6-00-T23-02-201606
Fndt Usage for Balance Inquiry Interface Message Version Control
Global PAYplus Technical Guide Page 3
Version Control
Version
Date
Summary of Changes
1.0
Document created
2.0
December 2015
Updated for rebranding
3.0
June 2016
Updated with marking of subtrees that the order of their child
elements is not mandatory
Fndt Usage for Balance Inquiry Interface Message Table of Contents
Global PAYplus Technical Guide Page 4
Table of Contents
1 INTRODUCTION .......................................................................................................................... 5
1.1 Overview ............................................................................................................................... 5
1.2 About This Document ........................................................................................................... 5
1.3 Background ........................................................................................................................... 5
1.4 Scope .................................................................................................................................... 5
1.5 References ............................................................................................................................ 5
2 INTERFACE STRUCTURES ....................................................................................................... 6
2.1 Balance Inquiry Request ....................................................................................................... 6
2.1.1 Detailed Structure when using Minimal Scope .................................................................. 8
2.2 Earmark Release Request .................................................................................................. 16
2.2.1 Detailed Structure when using Minimal Scope ................................................................ 17
2.3 Balance Inquiry Response .................................................................................................. 22
2.3.1 Detailed Structure when using Minimal Scope ................................................................ 23
3 USAGE ....................................................................................................................................... 29
APPENDIX A: GLOSSARY OF TERMS .............................................................................................. 30
APPENDIX B: CONVENTIONS (INCLUDING FORMAT AND PRESENCE) ...................................... 32
APPENDIX C: EXAMPLES OF REQUESTS AND RESPONSES ....................................................... 34
C.1 Balance Inquiry Request without Earmark ................................................................................. 34
C.2 Balance Inquiry Request without Earmark After User Action of Force NSF............................... 35
C.3 Balance Inquiry Request without Earmark After User Action of Override Posting Restriction ... 37
C.4 Balance Inquiry Request with Earmark....................................................................................... 38
C.5 Earmark Release Request .......................................................................................................... 40
C.6 Successful Balance Inquiry Response without Earmark ............................................................ 41
C.7 Successful Balance Inquiry Response with Earmark ................................................................. 42
C.8 Failed Balance Inquiry Response ............................................................................................... 43
Fndt Usage for Balance Inquiry Interface Message Introduction
Global PAYplus Technical Guide Page 5
1 Introduction
Note: This document has not yet been certified for GPP V4.6; therefore, there may be inaccuracies in
this document that may require amendments in the future. For more information, please contact your
D+H Project Manager.
1.1 Overview
This guide describes Global PAYplus (GPP)’s standard Balance Inquiry interface, between GPP and
the Financial Institution’s HOST responsible for providing balance check information.
GPP Standard Balance Inquiry is an XML interface based on GPP’s Fndt (FuNDs Transfer) message
format.
Detailed in this document is the interface structure of the Balance Inquiry interface Request and
Response:
Balance Inquiry Request (outward from GPP’s perspective, to the financial institution HOST)
Balance Inquiry Response (inward to GPP’s perspective, from the financial institution HOST)
The processing, manual handling and configuration required around Balance Inquiry are not detailed
in this document. For more details refer to the sections related to the Balance Inquiry Interface in the
GPP Business Guide System Integration – Single Payments document.
1.2 About This Document
Information is provided for clients implementing a Balance Inquiry interface with Global PAYplus
(GPP), using the GPP Fndt (FuNDs Transfer) Message Format as the base for providing transaction
information, and response for providing balance check information.
1.3 Background
A standard interface was defined to streamline the process of integrating GPP with various existing
systems in a bank or financial institution. In addition to providing additional fields for GPP processing,
this structure supports the use of ISO 20022 or SWIFT messages embedded in the structure.
When a message is received as a SWIFT message it is included within the Fndt Message within a
GPP specific wrapping XML structure, with the original text in one tag and a structured list of attributes
as additional and separate tags.
1.4 Scope
The guide covers the communication protocols, field mapping, audit, contingency and recovery
requirements.
1.5 References
For information about the GPP Fndt Message structure, see GPP Technical Guide Fndt Message
Format.
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplus Technical Guide Page 6
2 Interface Structures
For the formatting and conventions in the interface detailed structure tables, the following should be
taken into consideration:
The shading in the detailed tables in this chapter marks tags, which represent subtree parents, for
example, tags in level 1, 2, where leaf tags in level 3 exist under the level 1 and 2. Each level has
a different shade, with the first (1) being the darkest shade and gradually getting lighter through
the levels.
For conventions, including the explanation of the values in the Presence and Format within the
detailed structure tables, see Appendix B: Conventions (Including Format and Presence).
For examples of the different requests and responses for different scenarios, see Appendix C:
Examples of Requests and Responses.
2.1 Balance Inquiry Request
The following sections from the full Fndt (FuNDs Transfer) Message structure are the minimal scope
to be included when it is used as a Balance Inquiry Request (additional sections can be configured to
be included, if required):
Notes:
The Pmnt section appears in this table, since it is recommended for readability to include it.
However, it can be excluded.
When a sub-tree tag is marked with * - the elements underneath it can appear in any order. That
is the XSD definition of the list of elements is ‘all’ and not ’sequence.’
Level 1
Level 2
Level 4
Level 5
Description
FndtMs
g
Header
General identifying attributes
Msg
Transaction message and extension
Pmnt quotes the transaction. When
used for Balance Inquiry, it is an ISO
based pain/pacs, or a SWIFT
message embedded within the GPP
proprietary XML structure.
For more information, see GPP
Technical Guide Fndt Message.
Processin
gPersiste
ntInfo*
DebitSide1
*
Debit Side Persistent Information
BalanceC
heckInf
Balance Check Information
1
Not in the minimal scope, but included mainly for FX information that may be used in HOST
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplus Technical Guide Page 7
Level 1
Level 2
Level 4
Level 5
Description
Monitors*
Monitors. User/Services/Interface
tracking monitors.
Note: Not mandatory in initial Balance
Inquiry requests.
MU_NSF_FORCE_STS will be
provided with 1 in case of a repeated
Balance Inquiry request due to user
forcing the transaction from the
Insufficient Funds (NSF) queue, and
MU_STOP_FLAGS_OVERRIDE_ST
S will be provided with O in case of a
repeated Balance Inquiry request due
to user forcing the transaction from
the Posting Restriction (POSTREST)
queue.
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 8
2.1.1 Detailed Structure when using Minimal Scope
Notes:
The Pmnt section appears in this table, since it is recommended for readability to include it. However, it can be excluded.
When a sub-tree tag is marked with * - the elements underneath it can appear in any order. That is the XSD definition of the list of elements is ‘all’ and not
’sequence.’
For the conventions of the Presence and Format columns in this table, see Appendix B: Conventions (Including Format and Presence).
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
FndtMsg
1
+
[1..1]
Fndt (FuNDs
Transfer)
Message
Header
2
+
[1..1]
Header
contextName
3
+
[0..1]
Context
Name
Generic field to add information
regarding the specific usage.
Note: Specifically for the usage
for Balance Inquiry request. The
value can be BalanceInquiry, or
BalanceInquiry_with_Earmark.
Text {1,n}
Populate with either of:
BalanceInquiry – for a model when
no earmarking is done
BalanceInquiry_with_Earmark – for
a model when earmarking is done
Note: value configured in the relevant
Interface_Type entry within the
CUSTOM_PROPERTIES column.
contextLocalName
3
+
[0..1]
Context
Local Name
Generic optional field to add
regarding the specific usage, but
using the financial institution
system terminology naming, in
case such a local name exists
and is required for the
identification on the financial
institution side.
Text {1,n}
If required – populate with specific
local context string
credentials
3
+
[0..1]
Credentials
Credentials when required.
UserID
4
+
[0..1]
User ID
User ID
Text {1,8}
Populate with User Id
Role
4
+
[0..1]
Role
Role
Text {1,50}
Populate with User Role
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 9
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
D_SKIP_PERSIS
T_ON_ERROR
3
+
[0..1]
Skip Persist
On Error
Indicator
An indication whether to store
the transaction details when an
error or errors were found
[1,0] {1, 1}
Populate with 02
Workflow
3
+
[0..1]
Workflow
Defined for mass processing.
The valid values are Template,
File or Swift.
Text {1,50}
Populate with - TBD
P_MID
3
+
[0..1]
GPP
Message
Identifier
The Internal GPP message
Identifier.
Text {1,16}
Map from P_MID (logical field P_MID)
deliveryTimestam
p
3
+
[0..1]
Deliver
Timestamp
The Timestamp when the
request was created.
ISO Date
Time
Populate with Office Date Time
P_INIT_SRC_ID
3
+
[0..1]
Initiating
Source
System Id
The ID of the source system
initiating the request/response.
Text {1,50}
Populate with GPP
EventID
3
+
[0..1]
Event ID
Unique 16 characters event ID
generated for each interface
request.
This ID is used to identify a
resent request (EventID is as in
the original request), from a new
request issued due to force or
retry (EventID quotes a new
value).
Text {1,16}
Map from D_MEI_EVENT_ID if the
INTERFACE_TYPES.EVENT_ID_GE
NERATION is configured with 1 for the
INTERFACE_TYPE entry for this
request
Msg
2
+
[1..1]
Message
Pmnt
3
+
[0..1]
Transaction
ISO or SWIFT message text that
is stored in an XML structure in
the XML_MSG.
The entire transaction is mapped from
MINF.XML_MSG
Extn*
3
+
[1..1]
Extension
ProcessingPersist
entInfo*
4
+
[1..1]
ProcessingP
ersistentInfo
Transaction derived attributes
relevant to the transaction
information.
2
Not skip the saving of the message in case of error invoking the Balance Inquiry request
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 10
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
DebitSide*
5
+
[0..1]
Debit Side
Persistent
Info
Information on the Debit side.
Note: This section includes
optional additional information
that is not part of the minimal
scope, but may be required in
some case, for instance for
rechecking the FX calculations.
Note: Although the quote of the
different accounts to be balance
checked (principal debit account
and fee account) is included in
this section in the full Fndt
Message structure, in the
minimal scope for this usage,
these accounts are quoted
within <BalanceCheckInf> sub-
tree. The sub-tree includes all
the BI information, information
sent to HOST and information
received back from HOST.
P_DBT_MID_RAT
E
6
+
[0..1]
Debit Mid
Rate
The debit side mid-rate used to
compute the base amount of the
debit side FX calculation, if FX
was involved in this transaction.
fractionDig
its 10
totalDigits
18
Mapped from
MINF.P_DBT_MID_RATE (logical field
P_DBT_MID_RATE)
P_DBT_ RATE
6
+
[0..1]
Debit Rate
The debit side rate used for the
debit side FX calculation, if FX
was involved in this transaction.
fractionDig
its 10
totalDigits
18
Mapped from MINF.P_DBT_ RATE
(logical field P_DBT_ RATE)
P_DBT_RATE_U
SAGE_NM
6
+
[0..1]
Debit Rate
Usage Name
The name of the Rate Usage
profile selected to be used for
debit side FX calculation, if FX
was involved in this transaction.
Text {1,40}
Mapped from
MINF.P_DBT_RATE_USAGE_NM
(logical field
P_DBT_RATE_USAGE_NM)
P_DBT_SPREAD
6
+
[0..1]
Debit Spread
Debit spread - the max
difference in rate between the
standard (or quoted) rate and
the rate given to the customer
on the debit side.
fractionDig
its 3
totalDigits
18
Mapped from MINF.P_DBT_SPREAD
(logical field P_DBT_SPREAD)
P_DBT_CROSS_
CONV
6
+
[0..1]
Debit Cross
Conversion
Indicator
An indicator whether cross
conversion was required for the
debit side FX calculation, if FX
was involved in this transaction.
[1,0] {1, 1}
Mapped from
MINF.P_DBT_CROSS_CONV (logical
field P_DBT_CROSS_CONV)
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 11
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
P_DBT_TRIANGU
LATION_CCY
6
+
[0..1]
Debit
Triangulation
Currency
The triangulation currency used
for cross conversion debit side
FX calculation, if cross
conversion FX was involved in
this transaction.
[A-Z] {3, 3}
Mapped from
MINF.P_DBT_TRIANGULATION_CCY
(logical field
P_DBT_TRIANGULATION_CCY)
P_DBT_AMT_ST
EP1
6
+
[0..1]
Debit
Amount
Step1
The amount calculated on the
first step of the cross conversion
debit side FX calculation, if
cross conversion FX was
involved in this transaction.
fractionDig
its 3
totalDigits
18
Mapped from
MINF.P_DBT_AMT_STEP1 (logical
field P_DBT_AMT_STEP1)
P_DBT_RATE_ST
EP1
6
+
[0..1]
Debit Rate
Step1
The rate used on the first step of
the cross conversion debit side
FX calculation, if cross
conversion FX was involved in
this transaction.
fractionDig
its 10
totalDigits
18
Mapped from
MINF.P_DBT_RATE_STEP1 (logical
field P_DBT_RATE_STEP1)
P_DBT_RATE_ST
EP2
6
+
[0..1]
Debit Rate
Step2
The rate used on the second
step of the cross conversion
debit side FX calculation, if
cross conversion FX was
involved in this transaction.
fractionDig
its 10
totalDigits
18
Mapped from
MINF.P_DBT_RATE_STEP2 (logical
field P_DBT_RATE_STEP2)
BalanceCheckInf
4
+
[0..1]
Balance
Check
Information
Information previously received
from a Balance Inquiry
response.
M_BI_INFO_LINE
5
+
[0..n]
BI
information
Line
F_BI_INFO_DEBI
T_TYPE
6
+
[0..1]
Debit Type
The type of the amount on which
balance check is requested -
either MAIN or FEE.
Text {1,
10}
If amount is the principal debit amount
– Populate with MAIN
If amount is fee - Populate with FEE
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 12
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
F_BI_INFO_ACC
NO
6
+
[0..1]
Account
Number
The account number to be
validated.
Text {1,34}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_ACCT_NB (logical
field P_DBT_ACCT_NB)
If <F_BI_INFO_DEBIT_TYPE> =
FEE – Mapped from
MINF.P_DBT_FEE_ACCT_NB
(logical field
P_DBT_FEE_ACCT_NB) - fee
side debit account - if is specified,
otherwise - use
MINF.P_DBT_ACCT_NB (logical
field P_DBT_ACCT_NB) - principal
debit account
F_BI_INFO_ACC_
CURRENCY
6
+
[0..1]
Account
Currency
The currency of the account.
[A-Z] {3, 3}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_FEE_ACCT_CCY
(logical field P_DBT_ACCT_CCY)
If <F_BI_INFO_DEBIT_TYPE> =
FEE – Mapped from
Msg_Fees.Fee_Currency3 in all
entries of appropriate subset of
Msg_Fees entries
3
All of these should be in same currency since they relate to one customer’s fee account’s currency, or the customer’s principal account’s currency.
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 13
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
F_BI_INFO_ACC_
OFFICE
6
+
[0..1]
Account
Office
The office of the account.
[A-Z,0-1]
{3, 3}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_ACCT_OFFICE
(logical field
P_DBT_ACCT_OFFICE)
If <F_BI_INFO_DEBIT_TYPE> =
FEE – Mapped from
MINF.P_DBT_FEE_ACCT_OFFIC
E (logical field
P_DBT_FEE_ACCT_OFFICE) -
fee side debit account - if is
specified, otherwise - use
MINF.P_DBT_ACCT_OFFICE
(logical field
P_DBT_ACCT_OFFICE) -
principal debit account
F_BI_INFO_ACC_
TRNS_CD
6
+
[0..1]
Account
Transaction
Code
The transaction code associated
with the account that the
balance check is on.
The source for this attribute is as
follows:
For Principal account it is
populated with the debit
transaction code selected
using the Debit transaction
code rules.
For fee account it is
populated with the
transaction code of the
relevant Fee Formula.
[A-Z,0-1]
{3, 3}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_TX_CD (logical field
P_DBT_TX_CD)
If <F_BI_INFO_DEBIT_TYPE> =
FEE - Mapped from
FEE_FORMULA.FEE_TX_CD
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 14
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
F_BI_INFO_BOO
KING_ENT
6
+
[0..1]
Booking
Entity
The Booking Entity (accounting
system) that the account is
managed in.
The source for this attribute is:
For Principal account, if it is
from the Account object
containing the information
for the debit account – either
from its GPP DB Account
entry or received from
Account lookup.
For fee account: if it is same
as principal account, then
same source. If it is a
different account it is only
populated from its GPP DB
Account entry.
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from the Account
object BOOKNG_ENT field
If <F_BI_INFO_DEBIT_TYPE> =
FEE - Mapped from:
If same as principal account – then
same source
If different - from
ACCOUNTS.BOOKNG_ENT of
entry for the fee account
F_BI_INFO_AMO
UNT
6
+
[0..1]
Amount
The amount on which balance
check is requested.
fractionDig
its 3
totalDigits
18
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_AMT (logical field
P_DBT_AMT)
If <F_BI_INFO_DEBIT_TYPE> =
FEE - Sum of
Msg_Fees.Fee_Acc_Amount in all
entries of appropriate subset of
Msg_Fees entries
F_BI_INFO_VALU
E_DATE
6
+
[0..1]
Value Date
Value date for which the balance
was checked.
ISO Date
Mapped from MINF.P_DBT_VD
(logical field P_DBT_VD)
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 15
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
F_BI_INFO_EAR
MARK_REF
6
+
[0..1]
Earmark
Reference
Earmark reference returned
from the Balance Inquiry
response (if already returned).
Text {1,50}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from logical field
P_BI_MAIN_ERAMARK_REF, if
not empty4
If <F_BI_INFO_DEBIT_TYPE> =
FEE - Mapped from logical field
P_BI_FEE_ERAMARK_REF, if not
empty
4
It will not be empty, when the current Balance Inquiry invocation is not the first one performed during the processing of this transaction. Earmark Reference needs to be reported to the HOST system to allow updating the
earmarking per up-to-date details.
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 16
2.2 Earmark Release Request
The following sections from the full Fndt (FuNDs Transfer) Message structure are the minimal scope
to be included when it is used as an Earmark Release Request (additional sections can be configured
to be included, if required):
Notes:
The Pmnt section appears in this table, since it is recommended for readability to include it.
However, it can be excluded.
When a sub-tree tag is marked with * - the elements underneath it can appear in any order. That
is the XSD definition of the list of elements is ‘all’ and not ’sequence.’
Level 1
Level 2
Level 4
Level 5
Description
FndtMs
g
Header
General identifying attributes
Msg
Transaction message and extension
Pmnt quotes the transaction. When
used for Balance Inquiry, it is an ISO
based pain/pacs, or a SWIFT
message embedded within the GPP
proprietary XML structure.
For more information, see GPP
Technical Guide Fndt Message.
Balance
Check
Information
Section holding the information
received from the HOST on the
Balance Inquiry response (including
the earmark reference, if returned)
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 17
2.2.1 Detailed Structure when using Minimal Scope
Notes:
The Pmnt section appears in this table, since it is recommended for readability to include it. However, it can be excluded.
When a sub-tree tag is marked with * - the elements underneath it can appear in any order. That is the XSD definition of the list of elements is ‘all’ and not
’sequence.’
For the conventions of the Presence and Format columns in this table, see Appendix B: Conventions (Including Format and Presence).
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
FndtMsg
1
+
[1..1]
Fndt (FuNDs
Transfer)
Message
Header
2
+
[1..1]
Header
contextName
3
+
[0..1]
Context
Name
Generic field to add information
regarding the specific usage.
Specifically for the usage for
Earmark Release request, the
value will be EarmarkRelease.
Text {1,n}
Populate with EarmarkRelease – for a
case earmarking was done, but needs
to be released – e.g. if message was
canceled during processing after
earmarking was registered for it
Note: value configured in the relevant
Interface_Type entry within the
CUSTOM_PROPERTIES column.
contextLocalNam
e
3
+
[0..1]
Context
Local Name
Generic optional field to add
regarding the specific usage,
but using the financial institution
system terminology naming, in
case such a local name exists
and is required for the
identification on the financial
institution side.
Text {1,n}
If required – populate with specific
local context string
credentials
3
+
[0..1]
Credentials
Credentials when required.
UserID
4
+
[0..1]
User ID
User ID
Text {1,8}
Populate with User Id
Role
4
+
[0..1]
Role
Role
Text {1,50}
Populate with User Role
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 18
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
D_SKIP_PERSIS
T_ON_ERROR
3
+
[0..1]
Skip Persist
On Error
Indicator
An indication whether to store
the transaction details when an
error or errors were found.
[1,0] {1, 1}
Populate with 05
Workflow
3
+
[0..1]
Workflow
Defined for mass processing.
The valid values are Template,
File or Swift.
Text {1,50}
Populate with - TBD
P_MID
3
+
[0..1]
GPP
Message
Identifier
The Internal GPP message
Identifier.
Text {1,16}
Map from P_MID (logical field P_MID)
deliveryTimestam
p
3
+
[0..1]
Deliver
Timestamp
The Timestamp when either the
request or the response was
created.
Note: As per specific
integration, if matching between
response and its request is not
done using MQ Correlation ID,
this tag can be used as part of
the matching key when quoting
the timestamp of the request.
If MQ Correlation ID is used for
matching, this tag can quote the
timestamp when the response
was created.
ISO Date
Time
Populate either with
<deliveryTimestamp> from request or
with current Timestamp
P_INIT_SRC_ID
3
+
[0..1]
Initiating
Source
System Id
The ID of the source system
initiating the request/response.
Text {1,50}
Populate with GPP
5
Not skip the saving of the message in case of error invoking the Balance Inquiry request
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 19
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
EventID
3
+
[0..1]
Event ID
Unique 16 characters event ID
generated for each interface
request.
This ID is used to identify a
resent request (EventID is as in
the original request), from a new
request issued due to force or
retry (EventID quotes a new
value).
Note: the Event ID of the
earmark release will not quote
the Event ID of the original
Balance Inquiry request, but
rather a new unique ID.
Text {1,16}
Map from D_MEI_EVENT_ID if the
INTERFACE_TYPES.EVENT_ID_GE
NERATION is configured with 1 for the
INTERFACE_TYPE entry for this
request
Msg
2
+
[1..1]
Message
Pmnt
3
+
[0..1]
Transaction
ISO or SWIFT message text
that is stored in an XML
structure in the XML_MSG.
The entire transaction is mapped from
MINF.XML_MSG
Extn*
3
+
[1..1]
Extension
BalanceCheckInf
4
+
[0..1]
Balance
Check
Information
Information previously received
from a Balance Inquiry
response.
M_BI_INFO_LINE
5
+
[0..n]
BI
information
Line
F_BI_INFO_DEBI
T_TYPE
6
+
[0..1]
Debit Type
The type of the amount on
which balance check is
requested - either MAIN or FEE.
Text {1,
10}
If amount is the principal debit
amount – Populate with MAIN
If amount is fee – Populate with
FEE
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 20
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
F_BI_INFO_ACC
NO
6
+
[0..1]
Account
Number
The account number to be
validated.
Text {1,34}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_ACCT_NB (logical
field P_DBT_ACCT_NB)
If <F_BI_INFO_DEBIT_TYPE> =
FEE – Mapped from
MINF.P_DBT_FEE_ACCT_NB
(logical field
P_DBT_FEE_ACCT_NB) - fee
side debit account - if is specified,
otherwise - use
MINF.P_DBT_ACCT_NB (logical
field P_DBT_ACCT_NB) - principal
debit account
F_BI_INFO_ACC
_CURRENCY
6
+
[0..1]
Account
Currency
The currency of the account.
[A-Z] {3, 3}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_FEE_ACCT_CCY
(logical field P_DBT_ACCT_CCY)
If <F_BI_INFO_DEBIT_TYPE> =
FEE – Mapped from
Msg_Fees.Fee_Currency6 in all
entries of appropriate subset of
Msg_Fees entries.
6
All of these should be in same currency since they relate to one customer’s fee account’s currency, or the customer’s principal account’s currency
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 21
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into GPP
Table and Field
F_BI_INFO_ACC
_OFFICE
6
+
[0..1]
Account
Office
The office of the account.
[A-Z,0-1]
{3, 3}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_ACCT_OFFICE
(logical field
P_DBT_ACCT_OFFICE)
If <F_BI_INFO_DEBIT_TYPE> =
FEE – Mapped from
MINF.P_DBT_FEE_ACCT_OFFIC
E (logical field
P_DBT_FEE_ACCT_OFFICE) -
fee side debit account - if is
specified, otherwise - use
MINF.P_DBT_ACCT_OFFICE
(logical field
P_DBT_ACCT_OFFICE) -
principal debit account
F_BI_INFO_AMO
UNT
6
+
[0..1]
Amount
The amount on which balance
check is requested.
fractionDig
its 3
totalDigits
18
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from
MINF.P_DBT_AMT (logical field
P_DBT_AMT)
If <F_BI_INFO_DEBIT_TYPE> =
FEE - Sum of
Msg_Fees.Fee_Acc_Amount in all
entries of appropriate subset of
Msg_Fees entries
F_BI_INFO_VAL
UE_DATE
6
+
[0..1]
Value Date
Value date for which the
balance was checked.
ISO Date
Mapped from MINF.P_DBT_VD
(logical field P_DBT_VD)
F_BI_INFO_EAR
MARK_REF
6
+
[0..1]
Earmark
Reference
Earmark reference returned
from the Balance Inquiry
response.
Text {1,50}
If <F_BI_INFO_DEBIT_TYPE> =
MAIN - Mapped from logical field
P_BI_MAIN_ERAMARK_REF
If <F_BI_INFO_DEBIT_TYPE> =
FEE - Mapped from logical field
P_BI_FEE_ERAMARK_REF
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 22
2.3 Balance Inquiry Response
The following sections from the full Fndt (FuNDs Transfer) Message structure are the minimal scope
to be included in a Balance Inquiry Response (additional sections can be configured to be included, if
required):
Notes:
The Pmnt section appears in this table, since it is recommended for readability to include it.
However, it can be excluded.
When a sub-tree tag is marked with * - the elements underneath it can appear in any order. That
is the XSD definition of the list of elements is ‘all’ and not ’sequence.’
Level 1
Level 2
Level 3
Level 4
Level 5
Description
FndtMsg
Header
General identifying attributes
Msg
Transaction message and extension
Pmnt
Pmnt quotes the transaction. When
used for Balance Inquiry, it is an ISO
based pain/pacs, or a SWIFT message
embedded within the GPP proprietary
XML structure.
For more information, see GPP
Technical Guide Fndt Message.
Extn*
Referenc
eData
Transaction related profile reference
data.
M_DBT_
ACCOUN
T
Debit Account Information, mainly Stop
Flags /Posting Restrictions on the
debit account.
Populated in the Balance Inquiry
response.
M_DBT_
CUST_P
ROFILE
Debit Party Profile Information, mainly
Stop Flags / Posting Restrictions on
the debit customer. Populated in the
Balance Inquiry response.
Balance
CheckInf
Balance Check Information
Respon
seDetail
s
Applicable for Interface Responses
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 23
2.3.1 Detailed Structure when using Minimal Scope
Notes:
The Pmnt section appears in this table, since it is recommended for readability to include it. However, it can be excluded.
When a sub-tree tag is marked with * - the elements underneath it can appear in any order. That is the XSD definition of the list of elements is ‘all’ and not
’sequence.’
For the conventions of the Presence and Format columns in this table, see Appendix B: Conventions (Including Format and Presence).
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into
GPP Table and Field
FndtMsg
1
+
[1..1]
Fndt (FuNDs
Transfer)
Message
Header
2
+
[1..1]
Header
contextName
3
+
[0..1]
Context Name
Generic field to add
information regarding the
specific usage.
Note: Specifically for the
usage for Balance
Inquiry/Earmark Release
response. The value can
be one of the following:
BalanceInquiry
BalanceInquiry_with_
Earmark
EarmarkRelease
Text {1,n}
Populate with value in
<ContexName> in the
request - either of:
BalanceInquiry – for a
model when no
earmarking is done
BalanceInquiry_with_Ear
mark – for a model when
earmarking is done
EarmarkRelease – for a
case when earmarking
was done but needs to be
released, for example, if
message was canceled
during processing after
earmarking was
registered for it
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 24
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into
GPP Table and Field
contextLocalName
3
+
[0..1]
Context Local
Name
Generic optional field to
add regarding the specific
usage, but using the
financial institution
system terminology
naming, in case such a
local name exists and is
required for the
identification on the
financial institution side.
Text {1,n}
If required, populate with
specific local context string
credentials
3
+
[0..1]
Credentials
Credentials when
required.
Not required in the response.
Can be omitted
UserID
4
+
[0..1]
User ID
User ID
Text {1,8}
N/A
Role
4
+
[0..1]
Role
Role
Text {1,50}
N/A
D_SKIP_PERSIST_ON_E
RROR
3
+
[0..1]
Skip Persist On
Error Indicator
An indication whether to
store the transaction
details when an error or
errors were found.
[1,0] {1,1}
Not required in the response.
Can be omitted
Workflow
3
+
[0..1]
Workflow
Defined for mass
processing. The valid
values are Template, File,
or Swift.
Text {1,50}
Populate with - TBD
P_MID
3
+
[0..1]
GPP Message
Identifier
The Internal GPP
message Identifier.
Text {1,16}
Populated with value in
<P_MID> in the request.
Can be used for matching in
GPP
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 25
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into
GPP Table and Field
deliveryTimestamp
3
+
[0..1]
Deliver
Timestamp
The Timestamp when
either the request or the
response was created.
Note: As per specific
integration - If matching
between response and its
request is not done using
MQ Correlation ID – this
tag can be used as part of
the matching key – when
quoting the timestamp of
the request.
If MQ Correlation ID is
used for matching – this
tag can quote the
timestamp when the
response was created.
ISO Date
Time
Populate either with
<deliveryTimestamp> from
request or with current
Timestamp
P_INIT_SRC_ID
3
+
[0..1]
Initiating
Source System
Id
The ID of the source
system initiating the
request/response.
Text {1,50}
Populate with a code of the
HOST system
Will not be used in GPP
EventID
3
+
[0..1]
Event ID
Unique 16-chars event ID
generated for each
interface request.
Text {1,16}
Can be copied from request.
Currently not used in GPP for
matching with request, so not
mandatory
Msg
2
+
[1..1]
Message
Pmnt
3
+
[0..1]
Payment
ISO or SWIFT message
text that is stored in an
XML structure in the
XML_MSG.
Optionally can b populated
with value in <Pmnt> in the
request, or omitted
Will not be used in GPP
Extn*
3
+
[1..1]
Extension
ReferenceData
4
+
[0..1]
Reference Data
Note: For the Balance
Inquiry response usage
the only information
returned within this
section will be the debit
Stop Flags/Posting
Restrictions information.
M_DBT_ACCOUNT
5
+
[0..1]
Debit Account
Debit Account Details
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 26
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into
GPP Table and Field
F_DBT_ACCT_STOPFLA
GDR
6
+
[0..1]
Debit Stop Flag
/ Posting
Restriction on
Debit Account
on indication
Indicates that there is a
debit Stop Flag/Posting
Restriction set on the
debit account.
Note: Specific reason
indicated in the next tag.
[1,0] {1,1}
F_DBT_ACCT_REASON
DR
6
+
[0..1]
Debit Stop Flag
/ Posting
Restriction on
Debit Account
Reason
The code/reason for the
debit Stop Flag/Posting
Restriction set on the
debit account.
Note: Codes provided
should quote values
already configured in
GPP as Stop Flags.
Text {1,35}
M_DBT_CUST_PROFILE
5
+
[0..1]
Debit Customer
Debit Customer Details
F_DBT_CUST_STOPFLA
GFROM
6
+
[0..1]
Debit Stop Flag
/ Posting
Restriction on
Debit Customer
indication
Indicates that there is a
debit Stop Flag / Posting
Restriction set on the
debit customer.
Note: Specific reason
indicated in the next tag.
[1,0] {1,1}
F_DBT_CUST_FROMRE
ASON
6
+
[0..1]
Debit Stop Flag
/ Posting
Restriction on
Debit Customer
Reason
The code / reason for the
debit Stop Flag / Posting
Restriction set on the
debit customer.
Note: Codes provided
should quote values
already configured in
GPP as Stop Flags.
Text {1,35}
BalanceCheckInf
4
+
[0..1]
Balance Check
Information
Note: May be omitted in
case of failed response.
M_BI_INFO_LINE
5
+
[0..n]
BI information
Line
The first tags of this section,
all but the
<F_BI_INFO_EARMARK_RE
F> and
<F_BI_INFO_BALANCE> -
should be received back
populated with values in the
request
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 27
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into
GPP Table and Field
F_BI_INFO_DEBIT_TYP
E
6
+
[0..1]
Debit Type
The type of the amount
on which balance check
is requested - either
MAIN or FEE.
Text {1, 10}
GPP will map the earmark
reference and balance to
appropriate logical fields
(FEE or MAIN) based on the
value in this tag
F_BI_INFO_ACCNO
6
+
[0..1]
Account
Number
The account number to
be validated.
Text {1,34}
F_BI_INFO_ACC_CURR
ENCY
6
+
[0..1]
Account
Currency
The currency of the
account.
[A-Z] {3, 3}
F_BI_INFO_ACC_OFFIC
E
6
+
[0..1]
Account Office
The office of the account.
[A-Z,0-1] {3,
3}
F_BI_INFO_AMOUNT
6
+
[0..1]
Amount
The amount on which
balance check is
requested.
fractionDigits
3
totalDigits 18
F_BI_INFO_VALUE_DAT
E
6
+
[0..1]
Value Date
Value date for which the
balance was checked.
ISO Date
F_BI_INFO_BALANCE
6
+
[0..1]
Balance
Balance per the account
quoted in
<F_BI_INFO_ACCNO>,
returned from the Balance
Inquiry interface (if
returned).
Text {1,50}
If
<F_BI_INFO_DEBIT_TY
PE> = MAIN - Map to
logical field
P_BI_DBT_ACC_BALAN
CE
If
<F_BI_INFO_DEBIT_TY
PE> = FEE - Map to
logical field
P_BI_FEE_ACC_BALAN
CE
F_BI_INFO_EARMARK_
REF
6
+
[0..1]
Earmark
Reference
Earmark reference
returned from the Balance
Inquiry interface (if
returned).
Text {1,50}
If
<F_BI_INFO_DEBIT_TY
PE> = MAIN - Map to
logical field
P_BI_MAIN_ERAMARK_
REF
If
<F_BI_INFO_DEBIT_TY
PE> = FEE - Map to
logical field
P_BI_FEE_ERAMARK_R
EF
Fndt Usage for Balance Inquiry Interface Message Interface Structures
Global PAYplusTechnical Guide Page 28
Tag
L
0
1
2
3
4
5
6
7
8
9
10
Presence
Element
Description
Format
Mapped From/Into
GPP Table and Field
ResponseDetails
2
+
[1..1]
Response
Details
returnCode
3
+
[1..1]
Return Code
The return code to
indicate success (1), wait
for final response (200),
or failure (any other code)
of Balance Inquiry.
Note: any failure can be
marked with 0, but it is
preferable to use more
specific codes to
distinguish between NSF
failure and any other
failure. Mapping between
financial institution codes
and GPP internal codes
should be configured to
allow usage of the
financial institution codes.
[0-9] {1, 5}
description
3
+
[0..1]
Description
The description of the
return code. Relevant
only for a failure (not 1)
<returnCode>.
Text {1,250}
errorsList
3
+
[0..n]
Error List
List of errors for this
response.
error
4
+
[1..1]
Error
code
5
+
[1..1]
Code
The return code to
indicate one of multiple
failure codes of Balance
Inquiry.
[0-9] {1, 5}
description
5
+
[0..1]
Description
The description of the
failure code.
Text {1,250}
dataArray
3
+
[0..n]
Data Array
List of additional
information entries, if
required.
data
4
+
[0..1]
Data
Additional information
entry.
Text {1,250}
Fndt Usage for Balance Inquiry Interface Message Usage
Global PAYplusTechnical Guide Page 29
Note: Although the interface supports receiving proprietary return codes for the various failure
responses, as long as the appropriate mapping between financial institution’s codes and GPP internal
codes is pre-configured, When using the Standard Fndt Message FI can also directly use the GPP
internal numeric return codes listed as follows:
1 – to indicate a Success
990 – to indicate a Processing/technical error
995 – to indicate Insufficient funds
996 – to indicate a Posting restriction
0 – to indicate any error when no specific error handling is required but routing transaction to
Repair
3 Usage
For more information on logic related to STP processing and invocation points of the Balance Inquiry
request, usage of the information provided in the Balance Inquiry response interface, related manual
handling and related configuration see Balance Inquiry Interface section in the GPP Business Guide
System Integration – Single Payment document.
Fndt Usage for Balance Inquiry Interface Message Appendix A: Glossary of Terms
Global PAYplusTechnical Guide Page 30
Appendix A: Glossary of Terms
This table lists the terms used in this guide.
Term
Description
Fndt
Message
The FuNDs Transfer message structure is a GPP specific XML structure that is
comprising of the full set of information as received, enriched, computed or manually
updated per message. This structure is used as part of the standard interfaces for
interacting with financial institution systems.
ISO
International organization for standards.
The prefix convention for naming transaction attribute fields is described in this table:
Prefix
Meaning
Explanation
T_
Tree
Place holder in the tree view that hold the relevant associated
information. For example: T_PARTIES holds all of the
transaction parties.
X_
XML
ISO (<pmnt>) information that is stored in an XML structure in
the XML_MSG.
OX_
Original XML
Copy of the originally received XML transaction (<pmnt>)
information that is stored in an XML structure in
ORIG_XML_MSG.
OC_
Original Copy of XML
field
Prefix used if there is more than one way to receive specific
data. Example: OX_CDTR_AGT_BIC_1OR or
OX_CDTR_AGT_BIC_2AND. GPP copies the data into
OC_CDTR_AGT_BIC to facilitate determining whether creditor
agent BIC was provided or not. Relevant only for originally
received attributes.
P_
Process
GPP extension field for transaction data that cannot be placed
in the ISO standard format. Commonly used attributes: P_MID,
P_OFFICE, etc.
F_
GPP derived payment
attribute
Derived attribute that are taken from the static data profile that
is associated with transaction details. For example, after
P_CDT_MOP is determined, the related credit MOP profile
attributes are set in these fields. Examples: F_CDT_MOP_NM
is the credit MOP name derived from the credit MOP value.
F_MOP_NM is associated with the debit MOP.
D_
Derived
Derived attributes that are calculated ‘on the fly’ while the GPP
service is calculating the information. Derived fields are not
stored in the transaction after processing is completed, or
stopped for manual handling or wait. Therefore, they usually
cannot be used as a condition in business rules.
Fndt Usage for Balance Inquiry Interface Message Appendix A: Glossary of Terms
Global PAYplusTechnical Guide Page 31
Prefix
Meaning
Explanation
MU
MF
MI
User Monitor
Flow (service) monitor
Interface monitor
Monitors are divided into three categories:
User monitors that track the user action over the UI such as
forcing a transaction out of the insufficient funds queue
Workflow monitors, which are internal monitors in the code
that track the payment processing flow
Interface monitors that monitor interface interactions
These P_ field attributes hold the monitor statuses strings for
every transaction.
P_USER_STATE_MONITOR - for User Monitors – MU_ prefix
P_SERVICE_STATE_MONITOR - for Flow Monitors – MF_
prefix
P_INTERFACE_STATE_MONITOR - for Interface Monitors –
MI_ prefix
The location of each monitor in the field is defined by
LOGICAL_FIELDS.LOCATION. The first location is 0 (zero).
Example of a monitor string P_ field value:
XXXXXXXXXXXXXXXXXXXT.
The following SQL can be used to check the full list of
monitors as per their monitor P_field and their location:
select lf.obj_ref_data_id, lf.location, lf.* from logical_fields lf
where lf.obj_ref_data_id like %MONITOR
order by 1,2
Fndt Usage for Balance Inquiry Interface Message Appendix B: Conventions (Including Format and
Presence)
Global PAYplusTechnical Guide Page 32
Appendix B: Conventions (Including Format and Presence)
This table details naming conventions used within the document.
Term
Meaning
Tag name in Bold
Indicate Aggregates
ISO Date Time
Date Time formats defined as ISO Date Time will conform to ISO8601.
Representation:
ISO Date Time with milliseconds:
YYYY-MM-DD [T] {0,1} HH:MM:SS.mmm [Z,-,+] {1,1} HH:MM {0,1}
ISO Date Time without milliseconds:
YYYY-MM-DD [T] {0,1} HH:MM:SS [Z,-,+] {1,1} HH:MM {0,1}
Where:
YYYY is the year
MM is the month (01 - 12)
DD is the day (01 - 31)
T is a literal separator between the date and time portions (optional)
HH is the hour in 24 hour time
MM is the minutes
SS is the seconds
mmm is the milliseconds
Z is the time zone designator:
Z for when time is in UTC time, OR
+HH:MM; OR
or - HH:MM
ISO Date
Date formats defined as ISO Date Time will conform to ISO8601.
Representation:
YYYY-MM-DD
Where:
YYYY is the year
MM is the month (01 - 12)
DD is the day (01 - 31)
ISO Decimal Values
Decimal values defined as ISO Decimal Values will use the ISO format
definition using fractionDigits and totalDigits
Where:
totalDigits defines the total number of digits in the number (on both sides
of the decimal point)
fractionDigits defines the number of digits to the right of the decimal point
(the fraction)
SWIFT Date
Date formats defined as SWIFT Date will conform to SWIFT
representation:
YYMMDD
Where:
YY is the year
MM is the month (01 - 12)
DD is the day (01 - 31)
Fndt Usage for Balance Inquiry Interface Message Appendix B: Conventions (Including Format and
Presence)
Global PAYplusTechnical Guide Page 33
Term
Meaning
SWIFT Decimal
Values
Decimal values defined as SWIFT Decimal Values will use the SWIFT
representation of digits and a comma acting as the decimal separator
between the fraction and the full number
Presence
(Cardinality)
0..1 means Optional
1..1 means Required
0..n means Optional and may have multiple occurrences (limited to
specified n)
1..n means required and may have multiple occurrences (limited to
specified n)
String format
[character set] {min length, max length]
[A-Z] means only upper letter characters
[a-z] means only lower letter characters
[0-9] means only digits
[A-Za-z] means upper and lower letter characters
Text means all characters
{1,6} means a string at least one character long and no longer than 6
characters
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 34
Appendix C: Examples of Requests and Responses
C.1 Balance Inquiry Request without Earmark
This is an example of a Balance Inquiry request that does not ask for an Earmark in the response.
<FndtMsg>
<Header>
<contextName>BalanceInquiry</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
<EventID>1112223334445556</EventID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
<Extn>
<ProcessingPersistentInfo>
<DebitSide>
<P_DBT_MID_RATE>1.67</P_DBT_MID_RATE>
<P_DBT_RATE>1.67</P_DBT_RATE>
<P_DBT_RATE_USAGE_NM>Regular</P_DBT_RATE_USAGE_NM>
<P_DBT_SPREAD>0.5</P_DBT_SPREAD>
<P_DBT_CROSS_CONV>0</P_DBT_CROSS_CONV>
</DebitSide>
</ProcessingPersistentInfo>
<BalanceCheckInf>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_DR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 35
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_FDR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
</Extn>
</Msg>
</FndtMsg>
C.2 Balance Inquiry Request without Earmark After User Action of Force NSF
This is an example of a Balance Inquiry request that does not ask for an Earmark in the response, and that is recreated and sent after a user clicked the
Force Ins. Funds button in the Insufficient Funds (NSF) queue.
<FndtMsg>
<Header>
<contextName>BalanceInquiry</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
<EventID>1112223334445557</EventID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
<Extn>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 36
<ProcessingPersistentInfo>
<DebitSide>
<P_DBT_MID_RATE>1.67</P_DBT_MID_RATE>
<P_DBT_RATE>1.67</P_DBT_RATE>
<P_DBT_RATE_USAGE_NM>Regular</P_DBT_RATE_USAGE_NM>
<P_DBT_SPREAD>0.5</P_DBT_SPREAD>
<P_DBT_CROSS_CONV>0</P_DBT_CROSS_CONV>
</DebitSide>
</ProcessingPersistentInfo>
<BalanceCheckInf>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_DR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_FDR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
<Monitors>
<UserMonitor>
<MU_NSF_FORCE_STS>1</MU_NSF_FORCE_STS>
</UserMonitor >
</Monitors>
</Extn>
</Msg>
</FndtMsg>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 37
C.3 Balance Inquiry Request without Earmark After User Action of Override Posting Restriction
This is an example of a Balance Inquiry request that does not ask for an Earmark in the response, and that is recreated and sent after a user clicked the
Override button in the Posting Restriction (POSTREST) queue.
<FndtMsg>
<Header>
<contextName>BalanceInquiry</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
<EventID>1112223334445557</EventID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
<Extn>
<ProcessingPersistentInfo>
<DebitSide>
<P_DBT_MID_RATE>1.67</P_DBT_MID_RATE>
<P_DBT_RATE>1.67</P_DBT_RATE>
<P_DBT_RATE_USAGE_NM>Regular</P_DBT_RATE_USAGE_NM>
<P_DBT_SPREAD>0.5</P_DBT_SPREAD>
<P_DBT_CROSS_CONV>0</P_DBT_CROSS_CONV>
</DebitSide>
</ProcessingPersistentInfo>
<BalanceCheckInf>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_DR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 38
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_FDR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
<Monitors>
<UserMonitor>
<MU_STOP_FLAGS_OVERRIDE_STS>O</MU_STOP_FLAGS_OVERRIDE_STS>
</UserMonitor >
</Monitors>
</Extn>
</Msg>
</FndtMsg>
C.4 Balance Inquiry Request with Earmark
This is an example of a Balance Inquiry request that does ask for an Earmark in the response.
<FndtMsg>
<Header>
<contextName>BalanceInquiry_with_Earmark</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
<EventID>1112223334445556</EventID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 39
<Extn>
<ProcessingPersistentInfo>
<DebitSide>
<P_DBT_MID_RATE>1.67</P_DBT_MID_RATE>
<P_DBT_RATE>1.67</P_DBT_RATE>
<P_DBT_RATE_USAGE_NM>Regular</P_DBT_RATE_USAGE_NM>
<P_DBT_SPREAD>0.5</P_DBT_SPREAD>
<P_DBT_CROSS_CONV>0</P_DBT_CROSS_CONV>
</DebitSide>
</ProcessingPersistentInfo>
<BalanceCheckInf>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_DR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_FDR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
</Extn>
</Msg>
</FndtMsg>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 40
C.5 Earmark Release Request
This is an example of an Earmark Release request when a message was canceled after the Balance Inquiry invocation and the funds were earmarked on the
financial institution’s system and need to be released. In this scenario, only the principal amount was earmarked (no Earmark reference was returned for the
Fee occurrence of the Balance Inquiry response) and therefore, the Fee occurrence is sent back to the financial institution’s system as part of this release, but
with no Earmark reference tag.
<FndtMsg>
<Header>
<contextName>EarmarkRelease</contextName>
<contextLocalName>FREE_EARMARK</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
<EventID>8882223334445556</EventID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
<Extn>
<BalanceCheckInf>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_ACC_TRANS_CD>TRN_DR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
<F_BI_INFO_EARMARK_REF>3394777746</F_BI_INFO_EARMARK_REF>
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 41
<F_BI_INFO_ACC_TRANS_CD>TRN_FDR</F_BI_INFO_ACC_TRANS_CD>
<F_BI_INFO_BOOKING_ENT>MINDOL-SYS</F_BI_INFO_BOOKING_ENT>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
</Extn>
</Msg>
</FndtMsg>
C.6 Successful Balance Inquiry Response without Earmark
This is an example of a Balance Inquiry response that does not include an Earmark, but does include the current balance of the account.
<FndtMsg>
<Header>
<contextName>BalanceInquiry</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
<Extn>
<BalanceCheckInf>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
<F_BI_INFO_BALANCE>160999.34</F_BI_INFO_BALANCE>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 42
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
<F_BI_INFO_BALANCE>160.55</F_BI_INFO_BALANCE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
</Extn>
</Msg>
<ResponseDetails>
<returnCode>1</returnCode>
<description>Balance Inquiry success</description>
</ResponseDetails>
</FndtMsg>
C.7 Successful Balance Inquiry Response with Earmark
This is an example of a Balance Inquiry response that does include an Earmark, only on the principal amount (also includes current balance of the account).
<FndtMsg>
<Header>
<contextName>BalanceInquiry_with_Earmark</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:47-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>GPP</P_INIT_SRC_ID>
</Header>
<Msg>
<Pmnt>
…
</Pmnt>
<Extn>
<BalanceCheckInf>
<M_BI_INFO_LINE>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 43
<F_BI_INFO_DEBIT_TYPE>MAIN</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>123456789</F_BI_INFO_ACCNO>
<F_BI_INFO_ACC_CURRENCY>GBP</F_BI_INFO_ACC_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_AMOUNT>100.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-28+02:00</F_BI_INFO_VALUE_DATE>
<F_BI_INFO_BALANCE>160999.34</F_BI_INFO_BALANCE>
<F_BI_INFO_EARMARK_REF>3394777746</F_BI_INFO_EARMARK_REF>
</M_BI_INFO_LINE>
<M_BI_INFO_LINE>
<F_BI_INFO_DEBIT_TYPE>FEE</F_BI_INFO_DEBIT_TYPE>
<F_BI_INFO_ACCNO>26026</F_BI_INFO_ACCNO>
<F_BI_INFO_CURRENCY>GBP</F_BI_INFO_CURRENCY>
<F_BI_INFO_ACC_OFFICE>XXX</F_BI_INFO_ACC_OFFICE>
<F_BI_INFO_AMOUNT>1.0</F_BI_INFO_AMOUNT>
<F_BI_INFO_VALUE_DATE>2010-12-31+02:00</F_BI_INFO_VALUE_DATE>
<F_BI_INFO_BALANCE>160.55</F_BI_INFO_BALANCE>
</M_BI_INFO_LINE>
</BalanceCheckInf>
</Extn>
</Msg>
<ResponseDetails>
<returnCode>1</returnCode>
<description>Balance Inquiry success</description>
</ResponseDetails>
</FndtMsg>
C.8 Failed Balance Inquiry Response
This is an example of a failed Balance Inquiry response. Response returned with code 995 that is mapped internally as NSF.
<FndtMsg>
<Header>
<contextName>BalanceInquiry_with_Earmark</contextName>
<contextLocalName>BALINQ</contextLocalName>
<credentials>
<UserID>String</UserID>
<Role>String</Role>
</credentials>
<D_SKIP_PERSIST_ON_ERROR>0</D_SKIP_PERSIST_ON_ERROR>
<Workflow>String</Workflow>
<P_MID forCreation="false">11209G4837O30871</P_MID>
<deliveryTimestamp>2001-12-17T09:30:57-05:00</deliveryTimestamp>
<P_INIT_SRC_ID>HOST_XXX</P_INIT_SRC_ID>
</Header>
Fndt Usage for Balance Inquiry Interface Message Appendix C: Examples of Requests and Responses
Global PAYplus Technical Guide Page 44
<ResponseDetails>
<returnCode>995</returnCode>
<description>Insufficient Funds on Principal account</description>
</ResponseDetails>
</FndtMsg>

Navigation menu
