Safe

• No viruses or spyware, no conflicts with other

applications, no operating system failures – that is

Linux based reliability

All in one

• Firmware is already installed, no other

installation or software is necessary

• Free upgrade

www.ipcorder.com

Ecological and economical

• Has low environmental footprint and lowers

your operating costs with its very low power

consumption, especially compared to a traditional

PC based software solution

Unique

• In addition to IP cameras, variety of network

input/output, sensor and other devices

can be also connected

• You can specify how to react to events using

custom Actions

• Java powered GUI

Clever

• IPCorder searches your network for available

IP cameras and other supported devices and

performs automatic setup

• Automatic router control for easy remote access

• Intuitive usage

Independent

• A access live video, recordings and device

settings directly from your internet browser

• PCs with all the most common operating systems

can be used for viewing

• PC independent operation

KNR series

STANDALONE NETWORK VIDEO RECORDERS

Small size •For up to 40 IP cameras •ONVIF capable •Access through

the most common web browsers •Smartphone application (iOS, Android)

NVR doesn´t have to be boring!!!

IPCorder LIGHT STRIP

IPCorder brings colours

to the world of IP camera systems!

Choose one of the 7 colours.

KOUKAAM PRESENTS IPCORDER - KNR SERIES

www.ipcorder.com

Storage

Maximum storage capacity

HDD type

Supported video channels

Power

Dimensions (W × H × D)

Maximum recommended incoming trafic

(MPEG-4/H.264)

1 bay 1 bay 2 bay 5 bay

3 TB 3 TB 6 TB 15 TB

3.5“ SATA I or II or III 3.5“ SATA I or II or III 3.5“ SATA I or II or III 3.5“ SATA I or II or III

up to 4 up to 4/8 up to 8/12/16 up to 16/24/32/40

12 V DC 12 V DC 12 V DC 48 V DC

external power supply external power supply external power supply external power supply

145×40×205 mm 120×35×210 mm 120×85×254 mm 257×92×245 mm

16 Mbps 16/32 Mbps 32/48/64 Mbps 64/96/128/160 Mbps

KNR-090 KNR-1000 series KNR-200 series KNR-5000 series

INDEPENDENT SOLUTION FOR IP CAMERAS AND AUTOMATION

Standalone | Linux based reliability | Java based GUI | Windows, Linux and Mac clients

welcome | Automatic installation | Custom actions | Support for megapixel IP cameras | Audio

IPCorder KNR-090

economical version, for home and small systems,

up to 4 IP cameras, 1× HDD

IPCorder KNR-1000 series

for offices, store chains,

up to 8 IP cameras, 1× HDD

IPCorder KNR-200 series

for offices, store chains,

up to 16 IP cameras, 2× HDD

IPCorder KNR-5000 series

box version, for industry and large scale systems,

up to 40 IP cameras, 5× HDD, 2× LAN,

redundant network adapter with load balancing

"Drag and drop" action

Simultaneous viewing of live streams

and synchronized recordings playback

Status monitors to display device

and system status values

Pan, tilt

and zoom

control (PTZ)

Input/Output

devices Live/Recordings

View page

customization

with one click

Date-time

event/value

charts

User buttons

for automation

Various

camera brands

supported

+

Fullscreen Language

settings

Audio

FIRMWARE 2.1 FOR IPCORDER

NEW AUDIO - RECORDING AND PLAYBACK FROM IP CAMERAS

Live View and Playback

• Simultaneous Live View and Playback display

• Fully drag and drop customizable viewing grid

(live views, recordings, values)

• Fullscreen mode and multiple screen support

• Automatic or manual video stream selection

• Digital zoom feature with digital pan/tilt

• Display of numerical values from IPCorder, cameras,

sensors and other devices

• User buttons to trigger custom Actions

• PTZ control panel

• Synchronized playback

• Search for recordings by motion detection or other events

with date-time interval

• Event/Value charts display during search

• Export of selected time period of recorded video to a single file

• Export of stored numerical values from selected time period

• Audio - recording and playback of audio from IP cameras

synchronized with the image

• IPCorder Mobile application for smartphones and tablets

Recording Modes

• Permanent

• Event based (Motion Detection, digital input trigger etc.)

• Multiple independent recording schedules

Supported cameras, videoservers

and other devices

• ONVIF protocol support

• Supported brands:

ACTi, Arecont Vision, AXIS, Brickcom, D-Link, Hikvision,

IQinVision, Linksys, Panasonic, Sony, StarDot, UDP, VIVOTEK,

Y-Cam, 3S Vision

• KOUKAAM NETIO series

• External I/O and sensor (temperature, humidity etc.)

devices from the HW Group company – Poseidon and Damocles

products

• For a complete list please see:

http://www.ipcorder.com/en/support/supported-devices/

www.ipcorder.com

Special Features

• Easy creation of custom Actions triggered by events

or user buttons

• Schedules for recording and Actions limitation

• Hard disc and system health check with reports

• Automatic recovery after power outage

• Setup wizard

• Customizable logo

• E-mail support – SMTP/TLS

• Support of input/output devices

• I/O devices data display/export/import

Remote Access

• Router control - Automatic (UPnP Port Forwarding)

or Static forwarding setup

Networking

• 10/100/1000 Mbps Ethernet, RJ-45

• Supported protocols: IPv4, TCP/IP, UDP, HTTP, UPnP,

RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, ONVIF,

HTTP multipart

Client System Requirements

• Operating systems: Microsoft Windows 2000, 2003, XP,

Vista, 7 (32-bit and 64-bit version) / Linux 2.6+ / Apple

MacOS X 10.4, 10.5 and 10.6

• Browsers: Microsoft Internet Explorer 7.0 and 8.0, Mozilla

Firefox 3.5 and 3.6, Safari 4 and 5, Google Chrome

• Java SE 5.0 and higher

• Requirements for hardware configuration depend on type

and number of connected cameras
