Product Description
HUAWEI E5186s
-22a LTE CPE
V200R001
Issue
Date
HUAWEI TECHNOLOGIES CO., LTD.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 2
Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.
Please feel free to contact our local office or company headquarters.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://consumer.huawei.com/en/
Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 3
About This Document
Purpose
This document describes the main functions, supported services, and system
architecture of the HUAWEI E5186s-22a Long Term Evolution (LTE)
Customer-Premises Equipment (CPE) V200R001 (E5186s-22a for short).
This document is organized as follows.
Chapter Description
1 Overview Supported network modes, basic services and
functions, and appearance of the E5186s-22a.
2 Product Features Features and technical specifications of the
E5186s-22a.
3 Services and Applications Services provided by the E5186s-22a.
4 System Architecture System architecture of the E5186s-22a.
5 Packing List Items included with the E5186s-22a.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 4
Change History
Version Change Description Date
01 First release 2013-12-17
02 Change the frequency bands of LTE
Change the maximum transmission rate
of
LTE TDD downlink packet data service
from 110 Mbit/s to 220 Mbit/s
Modify the memory
Modify the maximum transmit power of
WLAN
Modify the gain of the WLAN antenna
Modify the system architecture diagram
Delete “External Antenna” in table 5-1
2014-04-02
03 Modify the weight
Delete “USB Cable” in table 5-1
2014-04-29
04 Modify the memory 2014-05-15
05 Modify the frequency of 2.4 GHz WLAN
into 2.400 GHz - 2.474 GHz
Modify the frequency of 5 GHz WLAN
into 5.150GHz - 5.825GHz
2015-07-09
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 5
Contents
1 Overview......................................................................................................................................... 6
2 Product Features ......................................................................................................................... 8
2.1 Main Features................................................................................................................................................ 8
2.2 Technical Spec ifications ............................................................................................................................... 9
2.2.1 Hardware Specifications ..................................................................................................................... 9
2.2.2 Antenna Specifications ..................................................................................................................... 11
2.2.3 Software Specifications .................................................................................................................... 12
3 Services and Applications ....................................................................................................... 15
3.1 Data Services .............................................................................................................................................. 15
3.1.1 Accessing the Internet Using an LTE, UMTS, or GSM Network ................................................ 15
3.1.2 Accessing the Internet Using Ethernet ........................................................................................... 16
3.2 Voice Services ............................................................................................................................................. 16
3.3 USB Sharing Services ................................................................................................................................ 18
3.4 Security Services ........................................................................................................................................ 18
3.4.1 Firewall ................................................................................................................................................ 18
3.4.2 User Authentication ........................................................................................................................... 19
3.4.3 PIN Protection .................................................................................................................................... 19
3.5 Maintenance and Management ................................................................................................................ 19
4 System Architecture.................................................................................................................. 20
4.1 System Architecture Diagram.................................................................................................................... 20
4.2 Functional Modules .................................................................................................................................... 20
5 Packing List ................................................................................................................................. 21
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 6
1 Overview
As a high-performance LTE CPE device, the E5186s-22a enables users to get access
to wireless and wired networks. The E5186s-22a supports the following frequency
bands:
LTE
Frequency division duplex (FDD): 2600/2100/1800/900/800 MHz
FDD Down Link (DL) Carrier Aggregation (CA): 1800 MHz + 2600 MHz, 1800
MHz + 800 MHz, 2600 MHz + 800 MHz, 1800 MHz intra-band contiguous,
2600 MHz intra-band contiguous
Time division duplex (TDD): 2600 MHz
TDD DL CA: 2600 MHz intra-band contiguous
DC-HSPA+/HSPA+/HSPA/UMTS: 2100/900 MHz
EDGE/GPRS/GSM: 1900/1800/900/850 MHz
The E5186s-22a can work in any of the following network standards:
LTE
Dual Carrier High Speed Packet Access Plus (DC-HSPA+)
High Speed Packet Access Plus (HSPA+)
High Speed Uplink Packet Access (HSUPA)
High Speed Downlink Packet Access (HSDPA)
Universal Mobile Telecommunications System (UMTS)
Enhanced Data Rates for Global Evolution (EDGE)
General Packet Radio Service (GPRS)
Global System for Mobile Communications (GSM)
The E5186s-22a provides the following services and functions:
Data services
Voice services
Short message service (SMS)
USB Sharing services
Security functions
Maintenance and management
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 7
Figure 1-1 shows the appearance of the E5186s-22a.
Figure 1-1 E5186s-22a appearance
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 8
2 Product Features
2.1 Main Features
The following lists the main features of the E5186s-22a:
Access to LTE/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM wireless
networks
Access to wired Ethernet networks
LTE FDD downlink packet data service at a maximum transmission rate of 300
Mbit/s (theoretical value)
LTE FDD uplink packet data service at a maximum transmission rate of 50 Mbit/s
(theoretical value)
LTE TDD downlink packet data service at a maximum transmission rate of 220
Mbit/s (theoretical value)
LTE TDD uplink packet data service at a maximum transmission rate of 10 Mbit/s
(theoretical value)
DC-HSPA+ downlink packet data service at a maximum transmission rate of 43.2
Mbit/s (theoretical value)
HSPA+ downlink packet data service at a maximum transmission rate of 21.6
Mbit/s (theoretical value)
HSPA downlink packet data service at a maximum transmission rate of 14.4
Mbit/s (theoretical value)
HSPA uplink packet data service at a maximum transmission rate of 5.76 Mbit/s
(theoretical value)
UMTS packet data service at a maximum transmission rate of 384 kbit/s
(theoretical value)
UMTS circuit-switched data service at a maximum transmission rate of 64 kbit/s
(theoretical value)
EDGE packet data service at a maximum transmission rate of 236.8 kbit/s
(theoretical value)
GPRS packet data service at a maximum transmission rate of 85.6 kbit/s
(theoretical value)
IEEE802.11a/b/g/n/ac
Wi-Fi 2.4 GHz and 5 GHz bands
LAN/WAN autonegotiation Ethernet port
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 9
Gigabit Ethernet port
Support for HUAWEI Mobile WiFi App
Functioning as a Dynamic Host Configuration Protocol (DHCP) server and
supporting Network Address Translation (NAT)
Internet Protocol version 6 (IPv6)/Internet Protocol version 4 (IPv4)dual stack
Wi-Fi and Wi-Fi protected setup (WPS)
Windows XP SP3, Windows Vista SP1/SP2, Windows 7, Windows 8, Windows
8.1, Mac OS X 10.7, 10.8, and 10.9 with latest upgrades
LTE/UMTS/GSM external antenna ports
USB 2.0 host port
Personalized light emitting diode (LED) indicators
2.2 Technical Specifications
2.2.1 Hardware Specifications
Table 2-1 lists the hardware specifications of the E5186s-22a.
Table 2-1 Hardware specifications
Item Description
Technical
standards
WAN:
LTE/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM
LAN: IEEE 802.3/802.3u
WLAN: IEEE 802.11 a/b/g/n/ac
Working bands LTE:
FDD 2600/2100/1800/900/800 MHz
FDD DL CA 1800 MHz + 2600 MHz, 1800 MHz + 800
MHz, 2600 MHz + 800 MHz, 1800 MHz intra-band
contiguous, 2600 MHz intra-band contiguous
TDD 2600 MHz
TDD DL CA 2600 MHz intra-band contiguous
DC-HSPA+/HSPA+/HSPA/UMTS: 2100/900 MHz
EDGE/GPRS/GSM: 1900/1800/900/850 MHz
WLAN(indoor use only):
2.4GHz 2.400 GHz - 2.474 GHz
5GHz 5.150GHz - 5.825GHz
Memory 512 MB NAND Flash
256 MB Double Data Rate (DDR) Synchronous Dynamic
Random Access Memory (SDRAM)
External ports One power port
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 10
Item Description
Two RJ11 ports for telephone connections
Three gigabit Ethernet RJ45 ports for LAN connections
One gigabit Ethernet RJ45 port for both LAN and WAN
connections
One USB 2.0 host port
One micro subscriber identity module (SIM) card port
Two external antenna ports
Buttons One power switch
One Wi-Fi button
One WPS button
One RESET button
LED indicators One POWER indicator
One Wi-Fi indicator
One VOICE indicator
One MODE indicator
One signal strength indicator
Three LAN indicators
One LAN/WAN indicator
Maximum
transmit power
LTE: Conform to Power Class 3 Definition
UMTS: Conform to Power Class 3 Definition
WLAN 802.11a: 20 dBm
802.11b: 17 dBm
802.11g: 16 dBm
802.11n: 16 dBm
802.11ac: 20 dBm
Receiving
sensitivity
LTE: Confirm to 3GPP Requirements
UMTS: Confirm to 3GPP Requirements
WLAN 802.11a: –65 dBm at 54 Mbit/s
802.11b: -76 dBm at 11 Mbit/s
802.11g: –65 dBm at 54 Mbit/s
802.11n: –64 dBm at 65 Mbit/s
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 11
Item Description
802.11ac: –59 dBm at 78 Mbit/s
Power
consumption
< 20 W
Power supply AC: 100–240 V
DC: 12 V/2 A
Dimensions (H x
W x D)
190 mm × 200 mm × 32 mm
Weight About 518 g
Temperature Working temperature: 0°C to +40°C
Storage temperature: –20°C to +70°C
Humidity 5%–95% RH
2.2.2 Antenna Specifications
Table 2-2 Specifications of the LTE main antenna
Item Description
Frequency range 790–2690 MHz
Input impedance 50
Standing wave
ratio (SWR)
< 3
Efficiency > 50%
Gain 0–3 dBi
Polarization type Linear polarization
Table 2-3 Specifications of the WLAN antenna at 2.4 GHz
Item Description
Frequency range 2.400 GHz - 2.474 GHz
Input impedance 50
SWR < 3
Efficiency > 50%
Gain 1 dBi
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 12
Item Description
Polarization type Linear polarization
Table 2-4 Specifications of the WLAN antenna at 5 GHz
Item Description
Frequency range 5.150GHz - 5.825GHz
Input impedance 50
SWR < 3
Efficiency > 50%
Gain 2 dBi
Polarization type Linear polarization
2.2.3 Software Specifications
Table 2-5 lists the software specifications of the E5186s-22a.
Table 2-5 Software specifications
Item Description
Gateway Supports the default route: 0.0.0.0
Supports the default gateway address: 192.168.8.1
Supports the Address Resolution Protocol (ARP).
Supports the Internet Control Message Protocol (ICMP).
Supports the domain name service (DNS).
Supports the Digital Living Network Alliance (DLNA)
Supports Samba sharing
Supports external USB storage devices and USB printer
NAT Supports NAT and Network Address and Port
Translation (NAPT), which complies with
RFC2663, RFC3022, and RFC3027.
Supports CONE NAT
Supports fragmented message identification
during common NAT.
DHCP server Enables and disables the DHCP server.
Configures DHCP server address pools.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 13
Item Description
Sets the lease time.
Displays the status of the DHCP server
address pools, including host names, Media
Access Control (MAC) addresses, IP
addresses, and remaining lease time.
SMS Writing/Sending/Receiving
Writing/Sending/Receiving extra-long messages
Voice and fax VoIP Supports the Session Initiation Protocol (SIP)
Supports G.711a, G.711u, G.729a, G.729b,
G.726 (-24/-32), G.722, and G.723.1 for
encoding and decoding
CS voice Supports CS voice communication over UMTS
and GSM networks
Supports the circuit switched fallback (CSFB)
Fax T.38 fax
Fax pass through
Firewall Enables and disables the firewall.
Filters LAN MAC addresses.
Filters LAN IP addresses.
Filters URLs.
Supports demilitarized zone (DMZ).
Supports Universal Plug and Play (UPnP).
Supports Application Level Gateway (ALG).
WLAN Broadcasts and hides service set identifiers (SSIDs).
Complies with IEEE 802.11a/b/g/n/ac.
Supports WPS.
Authentication Supports OpenSystem authentication.
Supports encryption using wired equivalent
privacy (WEP), Wi-Fi protected access
preshared key (WPA-PSK), and WPA2-PSK
keys.
Supports the Advanced Encryption Standard
(AES) encryption algorithm.
Supports the TKIP and AES hybrid encryption
algorithm.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 14
Item Description
MAC address
authentication
Supports the MAC address authentication
whitelist.
Supports the MAC address authentication
blacklist.
Supports a maximum of 10 MAC address
entries.
Supports automatic transmission rate adjustment.
Station
management
Supports station status queries.
Supports a maximum of 32 connected
stations at 2.4 GHz.
Supports a maximum of 32 connected
stations at 5 GHz.
IPv6/IPv4 dual
stack
DHCPv6/v4 server and client
DNSv6/v4 server and client
Display IPv6/v4 WAN address
HUAWEI Mobile
WiFi App
View service provider's name, the roaming status and signal
strength
View the data traffic usage and SMS
Manage the connected devices
Change CPE's SSID and password
System
requirements
Operating system: supports Windows XP SP3, Windows Vista
SP1/SP2, Windows 7, Windows 8, Windows 8.1, Mac OS X
10.7, 10.8, and 10.9 with latest upgrades.
Hardware configuration: meets the configuration requirements
of the operating system.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 15
3 Services and Applications
3.1 Data Services
By connecting to the E5186s-22a over a wireless or wired network, users can get
access to high-speed Internet services.
The E5186s-22a can simultaneously set up wireless connections with 64 Wi-Fi
devices and establish a local area network (LAN) by connecting to concentrators and
switches.
3.1.1 Accessing the Internet Using an LTE, UMTS, or GSM
Network
The E5186s-22a uses an LTE, UMTS, or GSM network to access the Internet.
Figure 3-1 Accessing the Internet using an LTE, UMTS, or GSM Network
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 16
3.1.2 Accessing the Internet Using Ethernet
The LAN/WAN multiplexed port supports automatic identification of the LAN/WAN port
in access mode, and automatic selection of accessing manners of ADSL domestic
wideband, DHCP hotel wideband or static IP wideband. You can easily access the
Internet using the Ethernet by connecting the LAN/WAN multiplexed port to the
Ethernet with a network cable.
Figure 3-2 Accessing the Internet using Ethernet
3.2 Voice Services
The E5186s-22a provides two telephone ports to which users can connect telephones
to implement basic voice functions or connect fax machines to use fax services.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 17
Figure 3-3 E5186s-22a connected to telephones
Figure 3-4 E5186s-22a connected to a fax machine
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 18
3.3 USB Sharing Services
With one USB port, users can connect a USB storage device to the USB port on the
E5186s-22a to save and share files. Only USB storage devices in FAT and FAT32
formats are supported. Users can also connect a USB printer to the USB port on the
E5186s-22a for printing services.
Figure 3-5 E5186s-22a connected to a USB storage device or USB printer
3.4 Security Services
The E5186s-22a offers security features, such as network firewalls, user
authentication, and personal identification number (PIN) protection, to protect users
from network security threats.
3.4.1 Firewall
The E5186s-22a has the following firewall functions:
Firewall switch: Enable and disable the firewall.
LAN MAC address filtering: Prevent specified MAC addresses on a LAN from
accessing the network.
LAN IP address filtering: Prevent specified IP addresses on a LAN from
accessing the network.
URL filtering: Prevent computers on a LAN from visiting specified URLs.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 19
3.4.2 User Authentication
The E5186s-22a complies with the following user authentication protocols:
WEP
WPA-PSK
WPA2-PSK
3.4.3 PIN Protection
If PIN protection is enabled, after the E5186s-22a restarts, users must enter the
correct PIN each time they log in to the web management page.
3.5 Maintenance and Management
The E5186s-22a allows users to locally manage connected devices, complete
network settings, and check the device status to ensure consistent performance.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 20
4 System Architecture
4.1 System Architecture Diagram
Figure 4-1 shows the E5186s-22a system architecture.
Figure 4-1 E5186s-22a system architecture
4.2 Functional Modules
LTE/UMTS/GSM modem
Processes the access, management, and data transmission of
LTE/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM.
CPU
Transmits data and voices from the wireless metropolitan area network (WMAN)
to the LAN.
Subscriber Line Interface Circuit (SLIC)
Connects telephones or a fax to the E5186s-22a.
LAN/WAN switch
Transmits data over Ethernet ports. When the Ethernet port works as a WAN port,
it supports data transmitting.
Wi-Fi access point (AP)
Enables wireless devices to connect to a LTE/UMTS/GSM network using Wi-Fi or
related standards.
USB 2.0 host port
Connects a USB storage device to the E5186s-22a.
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 21
5 Packing List
Table 5-1 lists the items included with the E5186s-22a.
Table 5-1 Items in the E5186s-22a package
Item Quantity Remarks
LTE CPE 1 Mandatory
Power adapter 1 Mandatory
Ethernet cable 1 Mandatory
Quick Start 1 Mandatory
Safety Information 1 Mandatory
Warranty Card 1 Optional
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 22
A Acronyms and Abbreviations
Numerics
3G The Third Generation
A
AC Alternating Current
AES Advanced Encryption Standard
ALG Application Level Gateway
ARP Address Resolution Protocol
AP Access Point
APN Access Point Name
C
CPE Customer-Premises Equipment
CSFB circuit switched fallback
D
DC Direct Current
DC-HSPA+ Dual Carrier High Speed Packet Access Plus
DDR Double Data Rate
DHCP Dynamic Host Configuration Protocol
DL Down Link
DMZ demilitarized zone
DNS domain name service
E
EDGE Enhanced Data Rates for GSM Evolution
F
FDD frequency division duplex
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 23
G
GPRS General Packet Radio Service
GSM Global System for Mobile Communications
H
HSPA+ High Speed Packet Access Plus
HSPA High Speed Packet Access
HSDPA High Speed Downlink Packet Access
HSUPA High Speed Uplink Packet Access
I
ICMP Internet Control Message Protocol
IP Internet Protocol
L
LAN Local Area Network
LED Light Emitting Diode
LTE Long Term Evolution
M
MAC Media Access Control
MDI Medium Dependent Interface
MDIX Medium Dependent Interface Crossover
N
NAPT Network Address and Port Translation
NAT Network Address Translation
P
PIN Personal Identification Number
S
SDRAM Synchronous Dynamic Random Access
Memory
SIM subscriber identity module
SIP Session Initiation Protocol
SMS Short Message Service
SOHO Small Office Home Office
SSID service set identifier
T
HUAWEI E5186s-22a LTE CPE V200R001
Product Description
Issue 05 (2015-07-09) Commercial in Confidence 24
TDD time division duplex
TKIP Temporal Key Integrity Protocol
U
UL Up Link
UMTS Universal Mobile Telecommunications
System
UPnP Universal Plug and Play
URL Uniform Resource Locator
USB Universal Serial Bus
W
WAN Wide Area Network
Wi-Fi Wireless Fidelity
WLAN Wireless Local Area Network
WPA-PSK Wi-Fi Protected Access Pre-shared Key
WPS Wi-Fi Protected Setup

Navigation menu
