QuickSpecs
HPE OfficeConnect 1950 Switch Series
Overview
Page
1
HPE OfficeConnect 1950 Switch Series
Models
HPE OfficeConnect 1950 12XGT 4SFP+ Switch
JH295A
HPE OfficeConnect 1950 24G 2SFP+ 2XGT Switch
JG960A
HPE OfficeConnect 1950 48G 2SFP+ 2XGT Switch
JG961A
HPE OfficeConnect 1950 24G 2SFP+ 2XGT PoE+ Switch
JG962A
HPE OfficeConnect 1950 48G 2SFP+ 2XGT PoE+ Switch
JG963A
Key features
•
10G Connectivity for fast network to servers and storage
• Combination of SFP+ and 10GBASE-T ports—supports both fiber and cost-effective copper connectivity
• True stacking allows for redundancy while simplifying administration
• Customized operation using intuitive Web interface
• Limited Lifetime warranty
Product overview
The HPE OfficeConnect 1950 Series is a smart Web-managed 10-Gigabit and Gigabit platform for advanced small business
networks needing highest performance now or in the future.
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Overview
Page
2
The HPE OfficeConnect 1950 Switch Series includes five switches: New to the series is a 16-port 10-Gigabit aggregation switch
that has 12 10GBASE
-T and 4 SFP+ ports, which is ideal as the core of a high performance workgroup or small business network.
Additional series models have Gigabit access ports with 10
-Gigabit uplinks, including two standard and two PoE+ models in 24-
and 48
-port configurations. The access switches each have two 10GBASE-T ports supporting copper- based Category 6A-based
cabling, and two 10G SFP+ ports for fiber connectivity. The PoE+ models both have a PoE power budget
of 370 W to power up
PoE/PoE+ compliant client devices.
The HPE OfficeConnect 1950 Switch Series has an intuitive Web
-based interface for simple customization of network operation. It
supports true
-stacking, the aggregation switch supporting up to two devi
ces, while the access switches allowing up to four devices,
to be logically administered as a single entity, simplifying administration while supporting greater network redundancy. Mode
ls
support both rack mounting and desktop operation. These switches hav
e IPv4 and IPv6 operation, with Layer 2 switching as well
as Layer 3 static routing. Other features include: link aggregation to boost link performance; VLANs, Access Control Lists, a
nd
802.1X network login for enhanced security; and three versions of Span
ning Tree Protocol (STP) for added network resiliency.
HPE OfficeConnect 1950 Switch Series is covered by a Limited Lifetime Warranty.
Features and benefits
Management
• Four-high true stacking
simplifies administration of multiple devices. Create a single logical managed unit with up to four HPE OfficeConnect 1950
switches. Balance connections across multiple units with standard Link Aggregation (LACP) for enhanced network
resiliency. Stack using affordable Cat 6a, or long distance fiber, or localized DAC cables. Stacked units can be co-located or
separated physically.
• Intuitive Web browser-based management
allows for easy customization of the switch even by non-technical users.
• Secure Web-management sessions with HTTPS / SSL
encrypts and otherwise protects management sessions through HTTP Secure (HTTPS). Prevents snooping of sensitive
management information such as passwords.
• SNMPv1, v2c, and v3
facilitates remote management of the switch, as the
device can be discovered and monitored from an SNMP management
station
• Complete session logging
provides detailed information for problem identification and resolution
• Dual flash images
provides independent primary and secondary operating system files for backup while upgrading
• Port mirroring
enables traffic on a port to be simultaneously sent to a network analyzer for monitoring
• Network Time Protocol (NTP)
synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clock-
dependent devices within the network so that the devices can provide diverse applications based on the consistent time
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
advertises and receives management information from adjacent devices on a network, facilitating easy mapping by
network management applications
• Limited Command Line Interface (CLI)
facilitates in the deployment and initial configuration of the unit. Supports troubleshooting actions as well.
• RMON
provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events
• Default DHCP client modes
simplifies device deployment. Connect a new out-of-the box switch to a network with a DHCP server and the device will
obtain its IP address automatically with plug-and-play operation. In the absence of a DHCP server, the switch will fall-back
to a unique static address determined by the switch's MAC address.
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Overview
Page
3
•
Cable diagnostic tool
use to remotely detect cable issues with cables attached to the switch.
Quality of
Service (QoS)
• Broadcast control
allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic
• Rate limiting
sets per-port ingress enforced maximums and per-port, per-queue minimums
• Traffic prioritization
makes it possible to prioritize important and/or time-
sensitive traffic ahead of less important traffic. Use with VoIP or video
to optimize its performance on the network. Recognizes both IEEE 802.1p and DSCP prioritization tagging. Packets are
mapped to four hardware queues for more effective throughput.
• Powerful QoS feature
supports the following congestion actions: strict priority queuing (SP), weighted round robin (WRR) queuing, and
SP+WRR
Connectivity
• Auto-MDI/MDIX
adjusts automatically to straight-through or crossover cables on all 10/100/1000 and 10GBASE-T ports.
• IEEE 802.3X flow control
provides a configurable flow throttling mechanism propagated through the network to prevent packet loss at a congested
node.
• Packet storm protection
protects against broadcast, multicast, or unicast storms with user-defined thresholds
• Jumbo frame support up to 10-kilobyte frames
improves efficiency of data transfers by allowing more data into a given packet. This especially useful for transfers of large
amounts of data. HPE 1950 Switches support up to 10 kilobyte frame sizes.
• IEEE 802.3at Power over Ethernet (PoE+)
delivers power to compliant devices over Ethernet cabling, greatly simplifying installation of those devices. The HPE
OfficeConnect 1950 Series has two PoE+ enabled models. The PoE+ 802.3at standard supports delivery of up to 30
Watts of power to the attached devices, enough to support the latest models of IP phones, Wireless Access Points, video
surveillance cameras, or other PoE/PoE+ enabled devices. HPE 1950 PoE+ models support 370W of total PoE power.
• IEEE 802.3af Power over Ethernet (PoE) ready
delivers power to compliant devices over Ethernet cabling, greatly simplifying installation of those devices. HPE 1950
PoE+ models are
fully backward compliant with the older PoE standard which provides up to 15.4 Watts of PoE power per
port to attached devices.
• Available redundant power for PoE+ models
optional Redundant Power System is available to add power redundancy and to supplement the PoE power of the PoE+
switches. With the optional RPS, the PoE+ power budget can be increased to 740 Watts; additionally, the switch will
continue operating and powering downstream PoE devices even if the unit internal power supply should fail. Order the
HPE RPS1600 Redundant Power System (JG136A).
• Fully IPv6 capable
- IPv6 host
enables switches to be managed and deployed at the IPv6 network's edge
- IPv6 routing
supports IPv6 static routes
- MLD snooping
forwards IPv6 multicast traffic to the appropriate interface, preventing traffic flooding
- IPv6 ACL/QoS
supports ACL and QoS for IPv6 network traffic
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Overview
Page
4
Security
• Access Control Lists (ACLs)
gives granular control over what traffic goes where in the network. Allows for traffic filtering. ACLs rules can be based on
MAC-address or IP-address. ACL rules can be time-based to implement access control during certain hours or days.
• IEEE 802.1X and RADIUS network logins
controls port-based access for authentication and accountability
Automatic VLAN assignment
assigns users automatically to the appropriate VLAN based on their identity, location and time of day
• Port isolation
the port isolation feature isolates Layer 2 traffic for data privacy and security without using VLANs. This feature can also
be used to isolate the hosts in a VLAN from one another
• ARP attack protection
the ARP detection feature enables access devices to block ARP packets from unauthorized clients to prevent user
spoofing and gateway spoofing attacks
• STP BPDU port protection
blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks
• STP root guard
protects the root bridge from malicious attacks or configuration mistakes
• Automatic denial-of-service protection
protects the network by blocking malicious DoS attacks aimed at the switch itself.
• Management password
provides security so that only authorized access to the Web browser interface is allowed
Performance
• Half-/full-duplex auto-negotiating capability on every port
doubles the throughput of every port
• Selectable queue configurations
allows for increased performance by selecting the number of queues and associated memory buffering that best meet the
requirements of the network applications
• IGMP / MLD Snooping
improves network performance by filtering multicast traffic when there is no multicast receiver on a connection. Without
this, multicast traffic is flooded to all ports. IGMP snooping is used in IPv4 networks. The IPv6 equivalent MLD Snooping is
also supported.
• 10-Gigabit SFP+ based Fiber Uplinks
supports high-bandwidth connections over fiber. HPE 1950 Switches each have two SFP+ transceiver slots supporting
10-Gigabit fiber-
based connections using optional 10G transceivers. Fiber is particularly suited for connecting at distances
beyond the 100 Meter limitation of copper-
based Cat 5e cabling. Alternatively use the SFP+ ports for redundant stacking
of up to four units using Direct Attached Cables (DAC).
• 10-Gigabit 10GBASE-T RJ45 Uplinks
supports high-bandwidth connections over Cat 6a cabling. HPE 1950 Switches each have two 10GBASE-T RJ45 ports
supporting 10-Gigabit copper-based connections. Cat 6a is economical and practical for distances up to 100 meters.
Alternatively use the 10GBASE-T ports for redundant stacking of up to four units.
Layer 2 swit
ching
• VLAN support and tagging
supports IEEE 802.1Q with 4,094 simultaneous VLAN IDs
• Spanning Tree Protocol (STP)
supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Overview
Page
5
•
BPDU filtering
improves network efficiency by filtering unnecessary BPDU packets on a port. When Spanning Tree Protocol (STP) is
enabled globally but disabled on specific ports, BPDU packets are not sent out the ports where STP is disabled.
Layer 3 services
• Address Resolution Protocol (ARP)
determines the MAC address of another IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection
of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a
Layer 2 network
• DHCP relay
simplifies management of DHCP addresses in networks with multiple subnets
Layer 3 routing
• Static IPv4/IPv6 routing
provides basic routing (supporting up to 32 static routes and 8 virtual VLAN interfaces); allows manual routing
configuration
Resiliency and high availability
• Link aggregation
groups together up to 8 ports per trunk automatically using Link Aggregation Control Protocol (LACP), or manually, to
form an ultra-high-bandwidth connection
to the network backbone; helps prevent traffic bottlenecks. The switch supports
up to 128 trunks.
Convergence
• LLDP-MED (Media Endpoint Discovery)
defines a standard extension of LLDP that stores values for parameters such as QoS and VLAN to configure auto
matically
network devices such as IP phones
• Auto voice VLAN
recognizes IP phones and automatically assigns voice traffic to dedicated VLAN for IP phones
• PoE Models For Converged Voice / Data Networks
simplifies and lowers the cost of installing a converged infrastructure. Power IP phones, Access Points, Video Surveillance
cameras, or other PoE-enabled devices. HPE 1950 Switches support multiple methods of allocating PoE power -- IEEE
802.3af class, LLDP-MED, or user-specified -- for more efficient energy useage.
Additional information
• Green initiative support
provides support for RoHS and WEEE regulations
• Green IT and power
improves energy efficiency through the use of the latest advances in silicon development; shuts off unused ports and
utilizes variable-speed fans, reducing energy costs
• Energy Efficient Ethernet
compliant with IEEE 802.3az standard requirements to save energy during periods of low data activity
Warranty and support
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Overview
Page
6
•
Limited Lifetime Warranty
See http://www.hpe.com/officeconnect/support for warranty and support information included with your product
purchase.
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Configuration
Page
7
Build To Order
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
Shippable solution.
JG960A
24 RJ-45 auto-negotiating 10/100/1000 ports
• 2 SFP+ fixed 1000/10000 SFP+ ports
• min=0 \ max=2 SFP+ Transceivers
• 2 RJ-45 1/10GBASE-T port
1U - Height
See Configuration
NOTE:1, 2
JG960A#B2B
JG960A#B2C
JG960A#AC3
JG961A
48 RJ-45 auto-negotiating 10/100/1000 ports
• 2 SFP+ fixed 1000/10000 SFP+ ports
• min=0 \ max=2 SFP+ Transceivers
• 2 RJ-45 1/10GBASE-T ports
See Configuration
NOTE:1, 2
JG961A#B2B
JG961A#B2C
JG961A#AC3
No Localized Power Cord Selected
JG962A
24 RJ-45 auto-negotiating 10/100/1000 PoE+ ports
• 2 SFP+ fixed 1000/10000 SFP+ ports
• min=0 \ max=2 SFP+ Transceivers
• 2 RJ-45 1/10GBASE-T ports
See Configuration
NOTE:1, 2
JG962A#B2B
JG962A#B2C
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Configuration
Page
8
JG962A#AC3
JG963A
48 RJ-45 auto-negotiating 10/100/1000 PoE+ ports
• 2 SFP+ fixed 1000/10000 SFP+ ports
• min=0 \ max=2 SFP+ Transceivers
• 2 RJ-45 1/10GBASE-T ports
See Configuration
NOTE:1, 2
JG963A#B2B
JG963A#B2C
JG963A#AC3
JH295A
12 RJ-45 1/10GBASE-T ports
• 4 SFP+ fixed 1000/10000 SFP+ ports
• min=0 \ max=4 SFP+ Transceivers
See Configuration
NOTE:1, 2
JH295A#B2B
JH295A#B2C
JH295A#AC3
No Localized Power Cord Selected
Configuration Rules:
Note 1
The following Transceivers install into this switch:
HPE X120 1G SFP LC SX Transceiver
JD118B
HPE X120 1G SFP LC LX Transceiver
JD119B
HPE X120 1G SFP RJ45 T Transceiver
JD089B
HPE X130 10G SFP+ LC SR Transceiver
JD092B
HPE X130 10G SFP+ LC LR Transceiver
JD094B
HPE X240 10G SFP+ SFP+ 0.65m DAC C-Cable
JH693A
HPE X240 10G SFP+ SFP+ 1.2m DAC C-Cable
JH694A
HPE X240 10G SFP+ SFP+ 3m DAC C-Cable
JH695A
Note 2
Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See
Localization Menu)
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Configuration
Page
9
Remarks:
Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord
- #B2B in North America, Mexico, Taiwan, and Japan or
#B2C ROW. (Watson Defaul
t B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord
- Localized Option (Watson Default for BTO and Box
Level CTO)
JD118B
JD119B
JD089B
JD092B
JD094B
JG136A
Height = 1U
See Configuration
NOTE:2, 3, 4
JG137A
Installs into JG136A only
See Configuration
NOTE:1, 3
JD183A
Installs into JH295A only
See Configuration
NOTE:
2, 5
Configuration Rules:
Note 1
If this power supply is selected, The JG136A - HPE A-RPS1600 Redundant Power System must be on
order or onsite.
Note 2
Localization required.
Note 3
Each switch will only support 1 JG136A and 1 JG137A Power supply systems.
Note 4
This power supply only supported on switches JG962A and JG963A.
Note 5
This power supply is only supported on switch JH295A
JD187A
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Configuration
Page
10
See Configuration
NOTE:
1
JD190A
See Configuration
NOTE:2
Remarks:
These cables are used to connect the External Power System to Switch.
Configuration Rules:
Note 1
This Cable is only supported on switches JG962A and JG963A when used with the RPS 1600 (JG136A)
Note 2
This Cable is only supported on switch JH295A when used with the RPS 800 (JD183A)
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
11
HPE OfficeConnect 1950 12XGT 4SFP+ Switch (JH295A)
I/O ports and slots
12 RJ-45 1/10GBASE-T ports
4 SFP+ fixed 1000/10000 SFP+ ports
Additional ports and
slots
1 dual-personality (RJ-45 or Mini USB) console port to access limited CLI port
1 RJ-45 out-of-band management port
Physical characteristics
Dimensions
17.32(w) x 6.3(d) x 1.73(h) in (44 x 16 x 4.4 cm) (1U height)
Weight
8.07 lb (3.66 kg)
Memory and processor
Cortex-A9 @ 1.25 MHz, 512 MB flash; Packet buffer size: 2 MB, 1 GB SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
100 Mb Latency
< 5
µ
s
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 1.5
µ
s
Throughput
up to 238 Mpps (64-byte packets)
Routing/Switching
capacity
320 Gbps
Routing table size
512 entries (IPv4), 256 entries (IPv6)
MAC address table size
16384 entries
Reliability
MTBF (years)
81.8
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
10% to 90%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 16,404 ft (5 km)
Acoustic
Low-speed fan: 48.1 dB, High-speed fan: 59.8 dB; ISO 7779 Dual speed fan
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 240 VAC, rated
Maximum power rating
75 W
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all
modules populated.
Safety
UL 60950; IEC 60950-1; EN 60950-1; GB 4943.1
Emissions
FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2
2000, 61000-3-3; ICES-003 Class A
Management
IMC - Intelligent Management Center; Limited command-line interface; Web browser; SNMP manager;
HTTPS; RMON1; FTP; Supported by HP IMC and generic SNMP management platforms. Refer to
documentation for MIB support details.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office.
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
12
HPE OfficeConnect 1950 24G 2SFP+ 2XGT Switch (JG960A)
I/O ports and slots
24 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
2 SFP+ fixed 1000/10000 SFP+ ports
2 RJ-45 1/10GBASE-T ports
Additional ports and
slots
1 RJ-45 console port to access limited CLI port
Physical characteristics
Dimensions
17.17(w) x 6.3(d) x 1.73(h) in (43.6 x 16 x 4.4 cm) (1U height)
Weight
6.61 lb (3 kg)
Memory and processor
128 MB flash; Packet buffer size: 1.5 MB, 1 GB SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
100 Mb Latency
< 5
µ
s
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 1.5 µs
Throughput
up to 95.2 Mpps (64-byte packets)
Routing/Switching
capacity
128 Gbps
Routing table size
32 entries (IPv4), 32 entries (IPv6)
MAC address table size
16384 entries
Reliability
MTBF (years)
87.2
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
10% to 90%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 16,404 ft (5 km)
Acoustic
Low-speed fan: 19.0 dB, High-speed fan: 44.5 dB; ISO 7779 Dual speed fan
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 240 VAC, rated
Maximum power rating
34 W
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety
UL 60950; IEC 60950-1; EN 60950-1; GB 4943.1
Emissions
FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2
2000, 61000-3-3; ICES-003 Class A
Management
IMC - Intelligent Management Center; Limited command-line interface; Web browser; SNMP Manager;
HTTPS; RMON1; FTP; Supported by HPE IMC and generic SNMP management platforms. Refer to
documentation for MIB support details.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office.
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
13
HPE OfficeConnect 1950 48G 2SFP+ 2XGT Switch (JG961A)
I/O ports and slots
48 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
2 SFP+ fixed 1000/10000 SFP+ ports
2 RJ-45 1/10GBASE-T ports
Additional ports and
slots
1 RJ-45 console port to access limited CLI port
Physical characteristics
Dimensions
17.32(w) x 10.63(d) x 1.73(h) in (44 x 27 x 4.4 cm) (1U height)
Weight
11.02 lb (5 kg)
Memory and processor
128 MB flash; Packet buffer size: 3 MB, 1 GB SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
100 Mb Latency
< 5 µs
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 1.5
µ
s
Throughput
up to 130.9 Mpps (64-byte packets)
Routing/Switching
capacity
176 Gbps
Routing table size
32 entries (IPv4), 32 entries (IPv6)
MAC address table size
16384 entries
Reliability
MTBF (years)
51
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
10% to 90%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 16,404 ft (5 km)
Acoustic
Low-speed fan: 38.4 dB, High-speed fan: 47.0 dB; ISO 7779 Dual speed fan
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 240 VAC, rated
Maximum power rating
54 W
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety
UL 60950; IEC 60950-1; EN 60950-1; GB 4943.1
Emissions
FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2
2000, 61000-3-3; ICES-003 Class A
Management
IMC - Intelligent Management Center; Limited command-line interface; Web browser; SNMP Manager;
HTTPS; RMON1; FTP; Supported by HPE IMC and generic SNMP management platforms. Refer to
documentation for MIB support details.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office.
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
14
HPE OfficeConnect 1950 24G 2SFP+ 2XGT PoE+ Switch (JG962A)
I/O ports and slots
24 RJ-45 auto-negotiating 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE, IEEE 802.3at)
2 SFP+ fixed 1000/10000 SFP+ ports
2 RJ-45 1/10GBASE-T ports
Additional ports and
slots
1 RJ-45 console port to access limited CLI port
Physical characteristics
Dimensions
17.32(w) x 14.17(d) x 1.73(h) in (44 x 36 x 4.4 cm) (1U height)
Weight
13.23 lb (6 kg)
Memory and processor
128 MB flash; Packet buffer size: 1.5 MB, 1 GB SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
100 Mb Latency
< 5 µs
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 1.5
µ
s
Throughput
up to 95.2 Mpps (64-byte packets)
Routing/Switching
capacity
128 Gbps
Routing table size
32 entries (IPv4), 32 entries (IPv6)
MAC address table size
16384 entries
Reliability
MTBF (years)
44.4
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
10% to 90%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 16,404 ft (5 km)
Acoustic
Low-speed fan: 37.3 dB, High-speed fan: 47.1 dB; ISO 7779 Dual speed fan
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 240 VAC, rated
Maximum power rating
425 W
PoE power
370 W PoE+
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
PoE power is the power supplied by the internal power supply. It is
dependent on the type and quantity of power supplies and may be
supplemented with the use of an external power supply (EPS).
When supplemented with the use of an HPE RPS1600 Redundant Power
System, up to 720W of PoE+ can be supplied. Unit max. power
consumption with RPS is 750W.
Safety
UL 60950; IEC 60950-1; EN 60950-1; GB 4943.1
Emissions
FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2
2000, 61000-3-3; ICES-003 Class A
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
15
Management
IMC - Intelligent Management Center; Limited command-line interface; Web browser; SNMP Manager;
HTTPS; RMON1; FTP; Supported by HPE IMC and generic SNMP management platforms. Refer to
documentation for MIB support details.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE OfficeConnect 1950 48G 2SFP+ 2XGT PoE+ Switch (JG963A)
I/O ports and slots
48 RJ-45 auto-negotiating 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE, IEEE 802.3at)
2 SFP+ fixed 1000/10000 SFP+ ports
2 RJ-45 1/10GBASE-T ports
Additional ports and
slots
1 RJ-45 console port to access limited CLI port
Physical characteristics
Dimensions
17.32(w) x 16.54(d) x 1.73(h) in (44 x 42 x 4.4 cm) (1U height)
Weight
15.43 lb (7 kg)
Memory and processor
128 MB flash; Packet buffer size: 3 MB, 1 GB SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
100 Mb Latency
< 5 µs
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 1.5
µ
s
Throughput
up to 130.9 Mpps (64-byte packets)
Routing/Switching
capacity
176 Gbps
Routing table size
32 entries (IPv4), 32 entries (IPv6)
MAC address table size
16384 entries
Reliability
MTBF (years)
26.8
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
10% to 90%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 16,404 ft (5 km)
Acoustic
Low-speed fan: 47.3 dB, High-speed fan: 50.0 dB; ISO 7779 Dual speed fan
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 240 VAC, rated
Maximum power rating
470 W
PoE power
370 W PoE+
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
PoE power is the power supplied by the internal power supply. It is
dependent on the type and quantity of power supplies and may be
supplemented with the use of an external power supply (EPS).
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
16
When supplemented with the use of an HPE RPS1600 Redundant Power
System, up to 800W of PoE+ can be supplied. Unit max. power
consumption with RPS is 910W.
Safety
UL 60950; IEC 60950-1; EN 60950-1; GB 4943.1
Emissions
FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2
2000, 61000-3-3; ICES-003 Class A
Management
IMC - Intelligent Management Center; Limited command-line interface; Web browser; SNMP Manager;
HTTPS; RMON1; FTP;; Supported by HPE IMC and generic SNMP management platforms. Refer to
documentation for MIB support details.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office.
Standards and protocols
(applies to all products in
series)
Device management
RFC 2819 RMON
General protocols
IEEE 802.1D MAC Bridges
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1W Rapid Spanning Tree Protocol
IEEE 802.1X
IEEE 802.3 Type 10BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.3af Power over Ethernet
IEEE 802.3at PoE+
IEEE 802.3i 10BASE-T
IEEE 802.3x Flow Control
IEEE 802.3z 1000BASE-X
MIBs
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 2021 RMONv2 MIB
RFC 2233 Interface MIB
RFC 2233 Interfaces MIB
RFC 2571 SNMP Framework MIB
RFC 2572 SNMP-MPD MIB
RFC 2573 SNMP-Notification MIB
RFC 2573 SNMP-Target MIB
RFC 2613 SMON MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet-Like-MIB
RFC 2667 IP Tunnel MIB
RFC 2668 802.3 MAU MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2737 Entity MIB (Version 2)
RFC 3414 SNMP-User based-SM MIB
RFC 3415 SNMP-View based-ACM MIB
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Technical Specifications
Page
17
RFC 3418 MIB for SNMPv3
Network management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
IEEE 802.1D (STP)
RFC 1215 SNMP Generic traps
QoS/Cos
IEEE 802.1p (CoS)
Security
IEEE 802.1X Port Based Network Access Control
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Accessories
Page
18
HPE OfficeConnect 1950 Switch Series accessories
Transceivers
HPE X130 10G SFP+ LC SR Transceiver
JD092B
HPE X130 10G SFP+ LC LR Transceiver
JD094B
HPE X120 1G SFP LC SX Transceiver
JD118B
HPE X120 1G SFP LC LX Transceiver
JD119B
HPE X120 1G SFP RJ45 T Transceiver
JD089B
Cables
HPE X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Campus-Cable
JH693A
HPE X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Campus-Cable
JH694A
HPE X240 10G SFP+ to SFP+ 3m Direct Attach Copper Campus-Cable
JH695A
HPE OfficeConnect 1950 12XGT 4SFP+ Switch (JH295A)
HPE RPS 800 Redundant Power Supply
JD183A
HPE X290 500/800 1m RPS Cable
JD190A
HPE OfficeConnect 1950 24G 2SFP+ 2XGT PoE+(370W) Switch (JG962A)
HPE RPS1600 Redundant Power System
JG136A
HPE RPS1600 1600W AC Power Supply
JG137A
HPE X290 1000 A JD5 2m RPS Cable
JD187A
HPE OfficeConnect 1950 48G 2SFP+ 2XGT PoE+(370W) Switch (JG963A)
HPE RPS1600 Redundant Power System
JG136A
HPE RPS1600 1600W AC Power Supply
JG137A
HPE X290 1000 A JD5 2m RPS Cable
JD187A
QuickSpecs
HPE OfficeConnect 1950 Switch Series
Summary of Changes
Page
19
Date
Version History
Action
Description of Change:
05-Feb-2018
Version 10
Changed
Technical Specifications, Configuration and Accessories
updated
04-Sep-2017
Version 9
Changed
Updates made on Features and benefits
30-May-2017
Version 8
Changed
Minor updates made on Technical Specifications
05-Sep-2016
Version 7
Added
Model added: JH295A
01-Aug-2016
Version 6
Changed
Adding #AC3 Option on Configuration section
Technical Specifications updated
06-May-2016
Version 5
Changed
Document name changed to HPE OfficeConnect 1950
Switch Series. SKU descriptions, Features and Benefits and
Overview updated.
01-Dec-2015
Version 4
Changed
Overview and Technical Specifications updated
28-Sep-2015
Version 3
Added
Bundles section added on Accessories. SKUs
added: JH376A, JH377A
Changed
Minor changes on the Overview section
29-Jun-2015
Version 2
Changed
Changes made on the Product overview and Features and
benefits sections
06-Mar-2015
Version 1
Created
Document creation
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such pro
ducts and services.
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit:
http://www.hpe.com/networking
c04545486
- 15191 - Worldwide - V10 - 05-February-2018

Navigation menu
