DATE: TYPE:

PROJECT:

L342 Wide 75°

L344 Medium 45°

L346 Narrow 27°

4½" Square Aperture, 5” Square Surface Form with Lens

1100, 1500, and 2100 Lumen

Xicato® XTM Remote Phosphor

OPTICS and APPLICATIONS

L Series optical systems are engineered to provide optimal performance with

maximum brightness control. A clear Solite spread lens is provided for an even

beam distribution.

DESIGN FEATURES - MultiSource® Capable

Fixture housings are designed with MultiSource® plug and play connectors

allowing field conversion to other sources. Components are Zhaga compatible

to accomodate furture source options. Proprietary heat sinks ensure proper

temperatures are maintained.

MODULES and DRIVERS

Xicato® XTM modules provide excellent even, stable color and increased

fixture efficiencies. The XTM holds color consistency within 1x2 MacAdam

Ellipses. Dimming is standard 0-10V/10%. Rated life is 50,000 hours at 70%

lumen output.

FINISH

Standard trim finish is anodized Softglow® clear. SoftSheen™ finish and other

colors are available. Standard cylinder exterior is satin white baked enamel.

Cylinders are satin brushed and emulsion cleaned before paint spraying, then

baked for superior adhesion and durability.

GENERAL

Fixture is pre-wired, certified by a Nationally Recognized Testing Lab(NRTL),

either UL or CSA, suitable for damp locations. All products are union made.

Designed and manufactured in the USA.

WARRANTY

5 Year Warranty. See www.kurtversen.com for details or select hyperlink.

ENERGY INFORMATION

DIMENSIONS and SOURCES

Rev1 Date 4/11/2017

©2017 Kurt Versen, a division of Hubbell Lighting, Inc. Because of continuing product improvement programs, Kurt Versen reserves the right

to change specifications without notice. 701 Millennium Boulevard • Greenville, SC 29607 / Tel 864.678.1000 / Website www.kurtversen.com

ORDERING GUIDE

Base Specification (required) Options

Example: L342-1135D-SSG-BL

Model

L342 Wide

L344 Medium

L346 Narrow

Kelvin

27 2700K

30 3000K

35 3500K

40 4000K

Source

Lumens

11 1100

15 1500

21 2100

Volts

Standard

120/277V

Cone

Color

Standard clear

B Black

G Gold

W Wheat

Y Pewter

Cone

Paint

Standard clear

WHT White

cone,

complete.

Fuse

(optional)

F Fuse.

Cone

Finish

Standard

Softglow®

SS SoftSheenTM

Mounting

Standard

ceiling mount

M Wall mount.

P5 Pendant mount, 21"

length.

CB3 Cable mount.

YK Yoke mount.

Exterior

Color/Finish

Standard Satin

white

BL

Satin black.

BA

Brushed

aluminum.

PCB Powder Coat

black.

PCW Powder Coat

white.

PCC Powder Coat,

custom RAL

color

(ex. PCC1234).

Dimming

D Standard 0-10V, to

10%.

D11 Hi-lume 1% 3-wire

LED driver

DE1 Hi-lume 1%

EcoSystem LED driver

DALI1 to 1%

DM11 0-10V to 1%

DM011 0-10V to 0.1%

OPTION NOTES

1. See dimension chart for default heights. Add -R or -T to applicable models shown only when alternate

height is desired.

2. Artist Series® 98 +/-3 CRI. Vibrant Series™, 83 CRI, 3000K only. Vibrant Series™, 95 CRI, 3000K only.

Contact factory for energy information.

3. Cable Mount: 24” Standard length. White cord on white exterior. Black cord on all other exterior colors.

Cyliner

Height

Default cylinder

height per chart

R1 Remote

Driver, short

cylinder height

T2 Integral

Driver, tall

cylinder height

Lens

Options

Standard

Solite Lens

CRI

Standard 80 CRI

AS2 98 CRI

VS82 Vibrant

83 CRI

VS92 Vibrant

95 CRI

Fixture Beam

Module

Lumens

Dimming

Option

Driver

Location

A

Aperture

B

Dia

C

Height

L342

L344

L346

Wide

Medium

Narrow

1100

or

1500

D Integral

4½” 5”

7½”

D1-R, DE-

R, DM1-R,

DM01-R,

DALI-R

Remote

D1, DE, DM1,

DM01, DALI Integral

9½”

D-T Integral

2100 All Integral

Fixture

Module

Lumens

Delivered

Lumens

System

Watts lm/W

L342

1100 769 12 64.0

1500 1084 17 64.0

2100 1553 24 65.0

L344

1100 863 12 72.0

1500 1216 17 72.0

2100 1703 24 71.0

L346

1100 865 12 72.0

1500 1249 17 73.0

2100 1748 24 73.0

L342 Wide 75°

Performance Datachart

10° 20° 30°

8'

10'

12'

14'

16'

40

22

13

9

7

36

19

12

8

6

2'

3'

3'

4'

5'

31

17

10

7

5

4'

5'

7'

8'

10'

19

10

6

4

3

6'

9'

11'

13'

16'

6'

8'

11'

13'

15'

45

24

15

10

7

38

20

13

9

6

26

14

9

6

4

Ceiling to FloorSingle Unit Initial Footcandles, 30" Work Plane Multiple Units Initial Footcandles, 30" Work Plane

Ceiling 80% Walls 50% Floor 20%

FC FC Diam Spacing RCR 1 RCR 3 RCR 8

Nadir

FC Diam FC Diam

Spacing is Maximum Over Work Plane

L342 Xicato® XTM 2100 lm 3000K

Candlepower Distribution

Candelas

L342

Xicato® XTM

2100 lm 3000K

S/M 1.12

Luminous efficacy 65.0

°Vertical Angles

*Luminaire Lumens

120

240

360

480

600

720

840

960

1080

1200

55°

35°

45°

75°

65°

25°15°5°

24W

0

5

10

15

20

25

30

35

40

45

50

55

60

65

70

75

80

85

90

1553*

°1216

1186

1147

1131

1133

1102

882

597

389

229

117

46

21

12

9

0

0

0

0

Notes

1

Photometric Reports: L342 2100 lm Report No. 17.01114.

2

Softglow® colored cone multipliers, contact factory.

3

SoftSheenTM cone multipliers, contact factory.

4

Single unit Datachart pattern diameters are determined by the number of degrees

from each side of nadir. Therefore a 15° diameter represents a total 30° pattern width

at the work plane. Footcandle values are at the edge of that diameter.

5

The luminous efficacy (lm/W) refers to the total measured luminous flux (lumens) of the

fixture divided by the total measured electrical input power (watts) of the complete fixture.

85°

701 Millennium Boulevard • Greenville, SC 29607 / Tel 864.678.1000 / Website www.kurtversen.com

©2017 Kurt Versen, a division of Hubbell Lighting, Inc. / L342 L344 L346 / Rev1 Date 4/11/17

Because of continuing product improvement programs, Kurt Versen reserves the right to change specifications without notice.

L344 Medium 45°

Performance Datachart

10° 20° 30°

9'

12'

14'

16'

18'

68

32

22

16

12

59

27

19

14

10

2'

3'

4'

5'

5'

33

16

11

8

6

5'

7'

8'

10'

11'

10

5

3

2

2

8'

11'

13'

16'

18'

5'

7'

8'

10'

11'

86

40

28

20

15

76

36

24

18

13

58

27

19

14

10

Ceiling to FloorSingle Unit Initial Footcandles, 30" Work Plane Multiple Units Initial Footcandles, 30" Work Plane

Ceiling 80% Walls 50% Floor 20%

FC FC Diam Spacing RCR 1 RCR 3 RCR 8

Nadir

FC Diam FC Diam

Spacing is Maximum Over Work Plane

L344 Xicato® XTM 2100 lm 3000K

Candlepower Distribution

Candelas

L344

Xicato® XTM

2100 lm 3000K

S/M .72

Luminous efficacy 71.0

°Vertical Angles

*Luminaire Lumens

300

600

900

1200

1500

1800

2100

2400

2700

3000

55°

35°

45°

75°

65°

25°15°5°

24W

0

5

10

15

20

25

30

35

40

45

50

55

60

65

70

75

80

85

90

1703*

°2892

2808

2592

2223

1699

1163

670

317

141

58

34

22

14

0

0

0

0

0

0

Notes

1

Photometric Reports: L344 2100 lm Report No. 17.01116.

2

Specular colored cone multipliers, contact factory.

3

SoftSheenTM cone multiplier and Softglow® cone multiplier, contact factory.

4

Single unit Datachart pattern diameters are determined by the number of degrees

from each side of nadir. Therefore a 15° diameter represents a total 30° pattern width

at the work plane. Footcandle values are at the edge of that diameter.

5

The luminous efficacy (lm/W) refers to the total measured luminous flux (lumens) of the

fixture divided by the total measured electrical input power (watts) of the complete fixture.

85°

701 Millennium Boulevard • Greenville, SC 29607 / Tel 864.678.1000 / Website www.kurtversen.com

©2017 Kurt Versen, a division of Hubbell Lighting, Inc. / L342 L344 L346 / Rev1 Date 4/11/17

Because of continuing product improvement programs, Kurt Versen reserves the right to change specifications without notice.

L346 Narrow 27°

701 Millennium Boulevard • Greenville, SC 29607 / Tel 864.678.1000 / Website www.kurtversen.com

©2017 Kurt Versen, a division of Hubbell Lighting, Inc. / L342 L344 L346 / Rev1 Date 4/11/17

Because of continuing product improvement programs, Kurt Versen reserves the right to change specifications without notice.

Performance Datachart

5° 15° 25°

12'

14'

16'

18'

20'

57

39

28

21

17

52

35

26

19

15

2'

2'

2'

3'

3'

21

14

10

8

6

5'

6'

7'

8'

9'

8

5

4

3

2

9'

11'

13'

14'

16'

4'

5'

6'

7'

8'

103

70

51

39

30

92

62

45

34

27

71

49

35

27

21

Ceiling to FloorSingle Unit Initial Footcandles, 30" Work Plane Multiple Units Initial Footcandles, 30" Work Plane

Ceiling 80% Walls 50% Floor 20%

FC FC Diam Spacing RCR 1 RCR 3 RCR 8

Nadir

FC Diam FC Diam

Spacing is Maximum Over Work Plane

L346 Xicato® XTM 2100 lm 3000K

Candlepower Distribution

Candelas

L346

Xicato® XTM

2100 lm 3000K

S/M .46

Luminous efficacy 73.0

°Vertical Angles

*Luminaire Lumens

500

1000

1500

2000

2500

3000

3500

4000

4500

5000

55°

35°

45°

75°

65°

85°

25°15°5°

24W

0

5

10

15

20

25

30

35

40

45

50

55

60

65

70

75

80

85

90

1748*

°5165

4737

3470

2113

1343

951

600

289

129

51

32

23

16

15

0

0

0

0

0

Notes

1

Photometric Reports: L346 2100 lm Report No. 17.01118.

2

Softglow® colored cone multipliers, contact factory.

3

SoftSheenTM cone multipliers, contact factory.

4

Single unit Datachart pattern diameters are determined by the number of degrees

from each side of nadir. Therefore a 15° diameter represents a total 30° pattern width

at the work plane. Footcandle values are at the edge of that diameter.

5

The luminous efficacy (lm/W) refers to the total measured luminous flux (lumens) of the

fixture divided by the total measured electrical input power (watts) of the complete fixture.
