L011000 CPC MR15 Spec Sheet (NEW)

User Manual: Pdf L011000 - CPC-MR15 Spec Sheet (NEW)

Open the PDF directly: View PDF PDF.
Page Count: 2

Part Number
Fabrication
Dimensions
(mm)
Block Dimensions
(mm) Rail Dimensions
(mm)
Load
Capacities
(KN)
Static Moment
(Nm) Block
Weight
(lbs)
Rail
Weight
(lbs)
H W22W L L1 h2 P P1 P2 D x d x g1 M x g2 S T
W1 H1 R1 R2 R3
C C0Mr0Mp0My0
CPC-MR15MLSSV0N-050-5-5 16 8.50 32 60.00 44.00 12.00
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 50 5 5
5.35 9.08 70 63.3 63.3 0.2 0.1
CPC-MR15MLSSV0N-100-10-10 16 8.50 32 60.00 44.00 12.00
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 100 10 10
5.35 9.08 70 63.3 63.3 0.2
0.2
CPC-MR15MLSSV0N-300-10-10 16 8.50 32 60.00 44.00 12.00
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 300 10 10
5.35 9.08 70 63.3 63.3 0.2
0.6
CPC-MR15MLSSV0N-500-10-10 16 8.50 32 60.00 44.00 12.00
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 500 10 10
5.35 9.08 70 63.3 63.3 0.2
1.0
CPC-MR15MLSSV0N-780-10-10 16 8.50 32 60.00 44.00 12.00
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 780 10 10
5.35 9.08 70 63.3 63.3 0.2
1.6
CPC-MR15MLSSV0N-1000L 16 8.50 32 60.00 44.00 12.00
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 1000 20 20
5.35 9.08 70 63.3 63.3 0.2
2.1
CPC-MR15MNSSV0N-050-5-5 16 8.50 32 43.00 27.00 12.00
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 50 5 5
3.81 5.59 43.6 27 27 0.1 0.1
CPC-MR15MNSSV0N-100-10-10 16 8.50 32 43.00 27.00 12.00
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 100 10 10
3.81 5.59 43.6 27 27 0.1
0.2
CPC-MR15MNSSV0N-300-10-10 16 8.50 32 43.00 27.00 12.00
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 300 10 10
3.81 5.59 43.6 27 27 0.1
0.6
CPC-MR15MNSSV0N-500-10-10 16 8.50 32 43.00 27.00 12.00
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 500 10 10
3.81 5.59 43.6 27 27 0.1
1.0
CPC-MR15MNSSV0N-780-10-10 16 8.50 32 43.00 27.00 12.00
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 780 10 10
3.81 5.59 43.6 27 27 0.1
1.6
CPC-MR15MNSSV0N-1000L 16 8.50 32 43.00 27.00 12.00
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 1000 20 20
3.81 5.59 43.6 27 27 0.1
2.1
CPC-MR15WLSSV0N-050-5-5 16 9.00 60 74.40 57.60 12.00
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 50 5 5
6.725 12.58 257.6 93.1 93.1 0.4 0.3
CPC-MR15WLSSV0N-100-10-10 16 9.00 60 74.40 57.60 12.00
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 100 10 10
6.725 12.58 257.6 93.1 93.1 0.4
0.6
CPC-MR15WLSSV0N-300-10-10 16 9.00 60 74.40 57.60 12.00
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 300 10 10
6.725 12.58 257.6 93.1 93.1 0.4
1.9
CPC-MR15WLSSV0N-500-10-10 16 9.00 60 74.40 57.60 12.00
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 500 10 10
6.725 12.58 257.6 93.1 93.1 0.4
3.1
CPC-MR15WLSSV0N-780-10-10 16 9.00 60 74.40 57.60 12.00
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 780 10 10
6.725 12.58 257.6 93.1 93.1 0.4
4.9
CPC-MR15WLSSV0N-1000L 16 9.00 60 74.40 57.60 12.00
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 1000 20 20
6.725 12.58 257.6 93.1 93.1 0.4
6.2
CPC-MR15WNSSV0N-050-5-5 16 9.00 60 55.30 38.50 12.00
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 50 5 5
5.065 8.385 171.7 45.7 45.7
0.3
0.3
CPC-MR15WNSSV0N-100-10-10 16 9.00 60 55.30 38.50 12.00
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 100 10 10
5.065 8.385 171.7 45.7 45.7
0.3
0.6
CPC-MR15WNSSV0N-300-10-10 16 9.00 60 55.30 38.50 12.00
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 300 10 10
5.065 8.385 171.7 45.7 45.7
0.3
1.9
CPC-MR15WNSSV0N-500-10-10 16 9.00 60 55.30 38.50 12.00
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 500 10 10
5.065 8.385 171.7 45.7 45.7
0.3
3.1
CPC-MR15WNSSV0N-780-10-10 16 9.00 60 55.30 38.50 12.00
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 780 10 10
5.065 8.385 171.7 45.7 45.7
0.3
4.9
CPC-MR15WNSSV0N-1000L 16 9.00 60 55.30 38.50 12.00
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5
1000 20 20 5.065 8.385 171.7 45.7 45.7 0.3
6.2
L011000
CPC-MR15 - Miniature Linear Guides
The rated load capacities and static moment values are calculated according to
the IS014728 standard. The rated life for basic dynamic load is dened as the total
100km travel distance that 90% of a group of identical linear guides can be operated
individually under the same conditions, free from any material damage caused by
rolling fatigue-When the standard of 50km travel distance is applied. The basic
dynamic load rating C of IS014728 should be multiplied by 1.26 for conversion.
Distributed by Anaheim Automation, Inc.
USA Stock in Anaheim, CA
1-800-345-9401
www.anaheimautomation.com
CPC-MR15 - Miniature Linear Guides
DIMENSIONS
SPECIFICATIONS
Part Number
Fabrication
Dimensions
(mm)
Block Dimensions
(mm) Rail Dimensions
(mm)
Load
Capacities
(KN)
Static Moment
(Nm) Block
Weight
(lbs)
Rail
Weight
(lbs)
H W22W L L1 h2 P P1 P2 D x d x g1 M x g2 S T
W1 H1 R1 R2 R3
C C0Mr0Mp0My0
CPC-MR15MLSUV0N-050-5-5 16 8.50 32 60.00 44.00 12.3
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 50 5 5
5.35 9.08 70 63.3 63.3 0.2 0.1
CPC-MR15MLSUV0N-100-10-10 16 8.50 32 60.00 44.00 12.3
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 100 10 10
5.35 9.08 70 63.3 63.3 0.2
0.2
CPC-MR15MLSUV0N-300-10-10 16 8.50 32 60.00 44.00 12.3
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 300 10 10
5.35 9.08 70 63.3 63.3 0.2
0.6
CPC-MR15MLSUV0N-500-10-10 16 8.50 32 60.00 44.00 12.3
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 500 10 10
5.35 9.08 70 63.3 63.3 0.2
1.0
CPC-MR15MLSUV0N-780-10-10 16 8.50 32 60.00 44.00 12.3
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 780 10 10
5.35 9.08 70 63.3 63.3 0.2
1.6
CPC-MR15MLSUV0N-1000L 16 8.50 32 60.00 44.00 12.3
40
25 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 1000 20 20
5.35 9.08 70 63.3 63.3 0.2
2.1
CPC-MR15MNSUV0N-050-5-5 16 8.50 32 43.00 27.00 12.3
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 50 5 5
3.81 5.59 43.6 27 27 0.1 0.1
CPC-MR15MNSUV0N-100-10-10 16 8.50 32 43.00 27.00 12.3
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 100 10 10
3.81 5.59 43.6 27 27 0.1
0.2
CPC-MR15MNSUV0N-300-10-10 16 8.50 32 43.00 27.00 12.3
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 300 10 10
3.81 5.59 43.6 27 27 0.1
0.6
CPC-MR15MNSUV0N-500-10-10 16 8.50 32 43.00 27.00 12.3
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 500 10 10
3.81 5.59 43.6 27 27 0.1
1.0
CPC-MR15MNSUV0N-780-10-10 16 8.50 32 43.00 27.00 12.3
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 780 10 10
3.81 5.59 43.6 27 27 0.1
1.6
CPC-MR15MNSUV0N-1000L 16 8.50 32 43.00 27.00 12.3
40
20 25 6 x 3.5 x 4.5 M3 x 5.5 3.3 4.3
15 9.5 1000 20 20
3.81 5.59 43.6 27 27 0.1
2.1
CPC-MR15WLSUV0N-050-5-5 16 9.00 60 74.40 57.60 12.3
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 50 5 5
6.725 12.58 257.6 93.1 93.1 0.4 0.3
CPC-MR15WLSUV0N-100-10-10 16 9.00 60 74.40 57.60 12.3
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 100 10 10
6.725 12.58 257.6 93.1 93.1 0.4
0.6
CPC-MR15WLSUV0N-300-10-10 16 9.00 60 74.40 57.60 12.3
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 300 10 10
6.725 12.58 257.6 93.1 93.1 0.4
1.9
CPC-MR15WLSUV0N-500-10-10 16 9.00 60 74.40 57.60 12.3
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 500 10 10
6.725 12.58 257.6 93.1 93.1 0.4
3.1
CPC-MR15WLSUV0N-780-10-10 16 9.00 60 74.40 57.60 12.3
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 780 10 10
6.725 12.58 257.6 93.1 93.1 0.4
4.9
CPC-MR15WLSUV0N-1000L 16 9.00 60 74.40 57.60 12.3
40
35 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 1000 20 20
6.725 12.58 257.6 93.1 93.1 0.4
6.2
CPC-MR15WNSUV0N-050-5-5 16 9.00 60 55.30 38.50 12.3
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 50 5 5
5.065 8.385 171.7 45.7 45.7
0.3
0.3
CPC-MR15WNSUV0N-100-10-10 16 9.00 60 55.30 38.50 12.3
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 100 10 10
5.065 8.385 171.7 45.7 45.7
0.3
0.6
CPC-MR15WNSUV0N-300-10-10 16 9.00 60 55.30 38.50 12.3
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 300 10 10
5.065 8.385 171.7 45.7 45.7
0.3
1.9
CPC-MR15WNSUV0N-500-10-10 16 9.00 60 55.30 38.50 12.3
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 500 10 10
5.065 8.385 171.7 45.7 45.7
0.3
3.1
CPC-MR15WNSSV0N-780-10-10 16 9.00 60 55.30 38.50 12.3
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5 780 10 10
5.065 8.385 171.7 45.7 45.7
0.3
4.9
CPC-MR15WNSUV0N-1000L 16 9.00 60 55.30 38.50
12.3
40
20 45 8 x 4.5 x 4.5 M4 x 4.5 3.3 4.5
42 9.5
1000 20 20 5.065 8.385 171.7 45.7 45.7 0.3
6.2
L011000
CPC-MR15 - Miniature Linear Guides
The rated load capacities and static moment values are calculated according to
the IS014728 standard. The rated life for basic dynamic load is dened as the total
100km travel distance that 90% of a group of identical linear guides can be operated
individually under the same conditions, free from any material damage caused by
rolling fatigue-When the standard of 50km travel distance is applied. The basic
dynamic load rating C of IS014728 should be multiplied by 1.26 for conversion.
Distributed by Anaheim Automation, Inc.
USA Stock in Anaheim, CA
1-800-345-9401
www.anaheimautomation.com
CPC-MR15 - Miniature Linear Guides
DIMENSIONS
SPECIFICATIONS
