49VL5B provides overwhelming screen immersion thanks to its super-narrow bezel and
delivers a clear image from any angle with an innovative IPS panel. With its extremely
attractive and highly functional design, it can be used to deliver information in a variety of
business environments.
Enhance a Seamless Viewing Experience
Super-Narrow Bezel Video Wall 49VL5B
Conventional IPS
Super-Narrow Bezel
The super-narrow bezel video wall
creates a visually stunning digital wall
that is efciently installed, maintained
and managed.
Key Features
Narrow
Bezel
178° 178°
Wide Viewing Angle
IPS panel technology means a more advanced control of the
liquid crystal display. As a result, it allows users to view the
screen from virtually any angle.
Stable Panel
On account of the structure of the liquid crystal in an IPS
display, when you touch the screen, there are no ashes or
ripple effects due to the rapid recovery.
Advanced IPS
Technology
SuperSign W for Content Management
Flexible content editing in various layouts, including
both regular and irregular video-wall layouts,
is made possible in a timely and cost-effective
manner without the need for an expensive
video-wall console.
Content
Management
Arbitrary Location
Redesign
Split / Encoding
Media Editor
Bezel to Bezel
3.5mm
2.3mm (Left/Top),
1.2mm (Right/Bottom)
49VL5B
• Brightness : 450cd/m2
• Bezel to Bezel : 3.5mm
• Depth : 89.7mm
• Interface : HDMI / DVI / RGB / RJ45 / USB / RS232C
Screen Size
49”
Specifications 49VL5B
PANEL
Screen Size 49" (48.50" measured diagonally)
Panel Technology IPS
Aspect Ratio 16 : 9
Native Resolution 1,920 x 1,080 (FHD)
Brightness 450cd/m2
Contrast Ratio 1,300 : 1
Viewing Angle (H x V) 178 x 178
Response Time 8ms (G to G)
Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer (Haze 10%)
Life time
50,000 Hrs
Orientation Portrait & Landscape
CONNECTIVITY
Input HDMI, DVI-D, RGB
Output DVI-D
External Control RS232C (In/Out), RJ45, IR Receiver, USB
PHYSICAL
SPECIFICATION
Bezel Color Black
Bezel Width
2.3mm (Left / Top), 1.2mm (Right / Bottom)
Monitor Dimension (W x H x D)
1,077.7 x 607.8 x 89.7mm
Weight (Head)
17.8kg
Carton Dimensions (W x H x D) 1,214 x 778 x 263mm
Packed Weight 22.8kg
VESATM Standard Mount Interface 600 x 400mm
SPECIAL FEATURES
Temperature Sensor, Tile Mode (Up to 15x15), Natural Mode@Tile Mode, Energy Saving, Smart Energy Saving, File Play with USB
ENVIRONMENTAL
CONDITIONS
Operation Temperature Range 0°C to 40°C
Operation Humidity Range 10% to 80%
POWER
Power Supply 100-240V~, 50/60Hz
Power Type Built-in Power
Power
Consumption
Typ. 90W
Smart Energy Saving 40W
STANDARD
(CERTIFICATION)
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KCC
ErP / Energy Star
NA / Yes (Energy Star 6.0)
MEDIA PLAYER
COMPATIBILITY
Slot PC compatible (optional)
No
External Media player Attachable
Yes
SOFTWARE
COMPATIBILITY
SuperSign-W/Lite
Yes
SuperSign-C
Yes
ACCESSORY Accessory
Remote Control, Power Cable, DVI Cable, Manual, IR Receiver, RS-232C Cable, Guide Bracket, Screw
Optional Accessory
Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V)
LG may make changes to specifications and product descriptions without notice.
Copyright © 2016 LG Electronics Inc. All rights reserved. “LG Life’s Good” is a registered of LG Corp.
The names of products and brands mentioned here may be the trademarks of their respective owners.
More info www.lgecommercial.com
youtube.com/c/LGECommercialDisplay
Download LG Commercial Display Mobile App
Apple App Store Google Play Store
➊ RS-232C IN
➋ RS-232C OUT
➌ USB
➍ HDMI IN
➎ DVI IN
➏ DVI OUT
Connectivity
➐ RGB/AV/COMPONENT IN
➑ IR IN
➒ LAN
➋ ➌ ➍ ➎ ➏ ➑ ➒➐➊
Dimension (unit : mm)
49"
1,077.7 x 607.8 x 89.7mm / 17.8kg
1,077.7
1.3(RIGHT) 89.7 (D) 600 (VESA) 4-M6 TAP
(VESA)
88.1
2.3 (UP)
1.3 (BOTTOM)
111.4
400 (VESA)
607.8 (H)
2.3(LEFT)
