MatrixSSL 3.2 OS Porting Guide

Overview

Who Is This Document For?!4

Documentation Style Conventions!4

Commercial Version Differences!4

Conﬁguring a Development Environment!5

Project Type!5

Compiler Options and Preprocessor Deﬁnes!5

Platform Deﬁne!5

Performance Deﬁnes !6

Platform-Speciﬁc Requirements!8

Design Framework!8

Data Types and Structures!9

Time Functions!10

osdepTimeOpen!10

osdepTimeClose!10

psGetTime!11

psDiffMsecs!13

psCompareTime!14

Random Number Generation Functions!15

osdepEntropyOpen!16

PeerSec Networks, Inc. 410 Broadway Ave E. #205 Seattle, WA 98102 T 425.646.7850 F 206.501.4366

support@peersec.com www.peersec.com

osdepEntropyClose!16

psGetEntropy!17

File Access Functions!18

psGetFileBuf!18

Trace and Debug Functions!19

osdepTraceOpen!19

osdepTraceClose!19

_psTrace!20

_psTraceStr!20

_psTraceInt!20

_psTracePtr!21

osdepBreak!21

Standard Library Dependencies!22

Memory Allocation!23

malloc!23

realloc!23

free!23

Memory Operations!24

memcmp!24

memcpy!24

memset!24

memmove!24

strstr!25

strlen!25

Additional Topics!26

Client and Server Socket-based Applications!26

64-Bit Integer Support!27

Multithreading and fork( )!27

Threading!27

fork()!27

osdepMutexOpen!28

osdepMutexClose!28

psCreateMutex!29

psLockMutex!29

psUnlockMutex!30

psDestroyMutex!30

Overview

This document is the technical reference for porting the MatrixSSL C code library to a software

platform that isn’t supported by default in the product package.

Who Is This Document For?

•Software developers that are porting the MatrixSSL library to a new platform

•Software developers who want to understand the platform-speciﬁc functionality of MatrixSSL

Documentation Style Conventions

•File names and directory paths are italicized.

•C code literals are distinguished with the Monaco font.

Commercial Version Differences

Some of the compile options and discussions in this document are specific to the commercially

licensed version of MatrixSSL. Sections of this document that refer to the commercial version

will be shaded.

Configuring a Development

Environment

This section is a general overview on how to organize and compile the MatrixSSL source code

package when configuring a development environment for a new platform.

Project Type

When beginning a port of MatrixSSL the first thing to decide is what type of binary is being

built. The typical options on many platforms are to create a static library, a shared library, an

executable or a binary image. It is most common on full featured operating systems to create a

MatrixSSL library and use that to later link with the custom executable being created. If multiple

applications use MatrixSSL functionality, then a dynamic library is more efficient for disk space,

otherwise a static library can actually be smaller directly linked with an application. On many

embedded and real time operating systems, a single binary is compiled with MatrixSSL and all

other objects (operating system and application code) into a binary image.

Once the project type is chosen, the next step is to include the MatrixSSL source files. The best

place to look for the list of files is in the Makefile that is included in the top level directory of the

package. The Makefile separates the source files into core, crypto, and matrixssl lists for

functional clarity but all the files should be included in a project that uses the SSL or TLS

protocols. An application that only uses MatrixSSL cryptography directly can link with just core

and crypto source.

Compiler Options and Preprocessor Deﬁnes

Platform Deﬁne

The MatrixSSL source is written in ANSI C and the compiler options for your platform should

be set to reflect that if necessary.

The majority of preprocessor defines for MatrixSSL are contained within the configuration

headers and are used to enable and disable functionality within the library. These functionality-

based defines are discussed in the API and Developer’s Guide documentation. By comparison,

the defines that are used to specify the hardware platform and operating system should be set

using the -D compiler flag inside the development environment.

If you choose to follow the platform framework that is implemented in the default package the

most important preprocessor define to set is the <OS> define that will determine which osdep.c

file is compiled into the library. As of version 3.1 the two default <OS> options are POSIX and

WIN32. However, if you are reading this document it is likely that your platform is not

supported by either of these defaults. For more information on the <OS> define and

implementing MatrixSSL on an unsupported platform, see the Implementing core/<OS> section

below.

Performance Deﬁnes

For commercial versions of MatrixSSL, there are preprocessor defines for common CPU

architectures that will optimize some of the cryptographic algorithms. As of version 3.1,

optimized assembly code for x86, ARM and MIPS platforms is included, providing significantly

faster performance for public and private key operations. The preprocessor defines are:

PSTM_X86, PSTM_ARM or PSTM_MIPS.

Notes on PSTM_X86 assembly option: Some of the defines below also must be specified in

order to compile the code under GCC. Also, the assembly code is written in AT&T UNIX syntax,

not Intel syntax. This means it will not compile under Microsoft Visual Studio or the Intel

Compiler. Currently, to use the optimizations on Windows, the files containing assembly code

must be compiled with GCC under windows and then linked with the remaining code as

compiled by the non-GCC tools.

Notes on Mac OS X assembly: Due to the registers required and the build options available

under OS X, it is not currently possible to build a dynamic library with assembly optimizations.

If a dynamic library for MatrixSSL is required, it should be built dynamically without the

assembly language objects, and just those objects should be statically linked in to each of the

applications using MatrixSSL for minimal code footprint. Also, note that some of the options

below must be defined on OS X.

There are several compiler options that also affect size and speed on various platforms. The

options below are given for the GCC compiler. Other compilers should support similar types of

optimizations.

GCC Flag

Notes

-Os

By default, MatrixSSL uses this optimization which is a good balance

between performance and speed. Because embedded devices are often

constrained by RAM, FLASH and CPU cache sizes, often optimizing

for size produces faster code than optimizing for speed with -O3

-g

Because MatrixSSL is provided as source code, it can be compiled with

debug flags (-g) rather than optimization flags.

-fomit-frame-pointer

This option allows one additional register to be used by application

code, allowing the compiler to generate faster code. It is required on

X86 platforms when using MatrixSSL assembly optimizations because

the assembly code is written to take advantage of this register.

-mdynamic-no-pic

This option can also allow an additional register to be useable by

application code. On the Mac OS X platform, it is required to compile

with assembly language optimizations.

-ffunction-sections

This option effectively allows the linker to treat each function as its

own object when statically linking. This means that only functions that

are actually called are linked in. MatrixSSL is already divided into

objects optimally, but this option may help overall when producing a

binary of many different objects.

Platform-Specific Requirements

The primary effort of a MatrixSSL port is to implement a small set of specific functionality

required by the inner workings of the library. This section defines all the platform-specific

requirements the developer must implement.

Design Framework

PeerSec Networks has attempted to make the porting process as straightforward as possible.

There is any number of ways the developer can organize the source files to include these specific

requirements but it is strongly encouraged that the default framework be used for purposes of

support and modularization.

The default design framework will only require the user to work with two source code files:

File

Description

core/osdep.h

Existing header file the developer should include the platform

specific headers and typedefs to

core/<OS>/osdep.c

New C source code file the developer will use to implement the

specific platform functions.

The <OS> designation will be defined by the developer and should be a brief capitalized

description of the operating system being ported to. This value should then be set as a

preprocessor define so that the correct data types are pulled from core/osdep.h and that the core/

<OS>/osdep.c file is compiled into the library. As of version 3.2 the currently supported defines

are POSIX and WIN32 and can be used as references during the porting process.

Data Types and Structures

The following table describes the set of data types the user must define for the new platform.

These should be added to the existing core/osdep.h file and wrapped in #ifdef <OS> blocks.

Data Type

Deﬁnition

Comments

int32

A 32-bit integer type

Always required

uint32

A 32-bit unsigned integer type

Always required

int16

A 16-bit integer type

Always required

uint16

A 16-bit unsigned integer type

Always required

int64

A 64-bit integer type

Only required if USE_INT64 is defined

uint64

A 64-bit unsigned integer type

Only required if USE_INT64 is defined

psTime_t

A data type to store a time counter

for the platform

Always required. See the Time

Functions section below for details.

Allows for a higher resolution and

length than a single 32 bit value, if

desired.

psMutex_t

A data type to support a lockable

mutex.

Only required if USE_MULTITHREADING

is defined. See the Multithreading

section below for details.

Time Functions

These functions should be implemented in core/<OS>/osdep.c

The implementation allows for an arbitrary internal time structure to be used (for example a 64

bit counter), while providing the ability to get a delta between times and a time-based

monotonically increasing value, both as 32 bit signed integers.

osdepTimeOpen

Prototype

int osdepTimeOpen(void);

Return Values

PS_SUCCESS

Successful initialization.

PS_FAILURE

Failed time module initialization. Shouldn’t continue.

Servers and Clients

This is the one-time initialization function for the platform specific time support. For

example, it may initialize a high resolution timer, calibrate the system time, etc. This

function must always exist even if there is no operation to perform. This function is

internally invoked from matrixSslOpen().

Memory Proﬁle

This function may internally allocate memory that can be freed during osdepTimeClose

osdepTimeClose

Prototype

void osdepTimeClose(void);

Return Values

None.

Servers and Clients

This function performs the one-time final cleanup for the platform specific time support.

This function must always exist even if there is no operation to perform. This function is

internally invoked from matrixSslClose().

Memory Proﬁle

This function should free any memory that was allocated during osdepTimeOpen

psGetTime

Prototype

int32 psGetTime(psTime_t *currentTime);

Parameters

currentTime

output

Platform-specific time format representing the

current time or ticks

Return Values

> 0

A platform-specific time measurement (each subsequent call

to psGetTime must return an ever-increasing value.)

<= 0

Error retrieving time

Implementation Requirements

This routine must be able to perform two tasks:

1. This function MUST return a platform-specific time measurement in the return

parameter. This value SHOULD be the GMT Unix Time which is the number of

elapsed seconds since January 1st, 1970 GMT. If it is not possible to return the GMT

Unix Time the function MAY return a platform-specific counter value such as CPU

ticks or seconds since platform boot. Ideally, if using cpu time, the current count will

be stored in non-volatile memory each power down, so that it may be loaded again at

startup, and the value returned by this function will continue to increase between any

number of power cycles. The SSL and TLS protocols use this 32 bit signed value as

part of the prevention of replay message attacks.

2. This function must populate a platform specific static time structure if it is provided in

the currentTime parameter. The contents of the psTime_t structure must contain the

information necessary to compute the difference in milliseconds between two

psTime_t values. If the platform cannot provide a millisecond resolution time, it is

fine to scale up from the most accurate source available. For example, if the clock can

only return values in 1 second granularity, that value can simply be multiplied by 1000

and returned, when requested. The currently supported psTime_t structures for POSIX

and WIN32 are defined in ./core/osdep.h and it is recommended additional <OS>

versions are included there as well.

Servers and Clients Usage

Clients and Servers both use this function as described in Implementation Requirement 1

above. This routine is called when the CLIENT_HELLO and SERVER_HELLO handshake

messages are being created. The SSL/TLS specifications require that the first 4 bytes of

the Random value for these messages be the GMT Unix Time which is the number of

elapsed seconds since January 1st, 1970 GMT. Many embedded platforms do not

maintain the true calendar date and time so it is acceptable for these platforms to simply

return a counter value such as ‘ticks’ since power on, or ‘CPU lifetime ticks’. Also it is

acceptable that Unix Time will overflow 32 bits in 2038. Ideally, this value is designed to

provide a “forever increasing” value for each SSL message, across multiple SSL sessions

and cpu power cycles.

Server Usage

Servers also use this function as described in Implementation Requirement 2 above.

Servers must manage an internal session table in which entries can expire or be compared

for staleness against other entries. The psGetTime function is used to store the current

time for these table entries for later comparison using psDiffMsecs and psCompareTime.

Memory Proﬁle

This implementation requires that the psTime_t structure only contain static members.

Implementations of psGetTime must not allocate memory that is not freed before the

function returns.

psDiffMsecs

Prototype

int32 psDiffMsecs(psTime_t then, psTime_t now);

Parameters

then

input

Time structure from a previous call to psGetTime

now

input

Time structure from a previous call to psGetTime

Return Values

> 0

Success. The difference in milliseconds between then and now

<= 0

Error computing the difference in time

Implementation Requirements

This routine must be able to return the difference, in milliseconds, between two given

time structures as a signed 32 bit integer. The value will overflow if ‘then’ differs from

‘now’ by more than 24 days.

Server Usage

Servers are the only users of this function. Servers manage an internal session cache

table for protocol optimization in which entries can expire or be compared for staleness

against other entries. The psGetTime function is used to store the current time for these

table entries for later comparison using psDiffMsecs and psCompareTime.

Memory Proﬁle

This implementation requires that the psTime_t structure can only contain only static

members. Implementations of psGetTime must not allocate memory that isn’t freed

before the function returns.

psCompareTime

Prototype

int32 psCompare(psTime_t a, psTime_t b);

Parameters

input

Time structure from a previous call to psGetTime

input

Time structure from a previous call to psGetTime

Return Values

a is earlier in time than b OR a and b are the same time

b is earlier in time than a

Implementation Requirements

This routine must be able to determine which time is earlier given two time structures.

Server Usage

Servers are the only users of this function. Servers manage an internal session cache

table for protocol optimization in which entries can expire or be compared for staleness

against other entries. The psGetTime function is used to store the current time for these

table entries for later comparison using psDiffMsecs and psCompareTime.

Memory Proﬁle

This implementation requires that the psTime_t structure can only contain only static

members. Implementations of psGetTime must not allocate memory that isn’t freed

before the function returns.

Random Number Generation Functions

A source of pseudo-random bytes is an important component in the SSL security protocol. These

functions must be implemented in core/<OS>/osdep.c

The generation of truly random bytes of data is critical to the security of SSL, TLS and any of

the underlying algorithms. There are two components to providing truly random data for

cryptography.

1. Collecting Entropy (random data from external events):

• User interaction such as the low bit of the time between key presses and clicks, mouse

movement direction, etc.

•Operating system state, such as network packet timing, USB timing, memory layout, etc.

•Hardware state, such as the variation of pixels on a webcam, the static on a radio tuner

card, etc.

2. Pseudo Random Number Generation (PRNG) is a step that combines (scrambles) the raw

random input into bytes of data suitable for use in crypto applications. For example, the

Yarrow PRNG is an algorithm that takes random data as input and processes it using a

symmetric cipher (AES) and a one way hash (SHA-1). An application developer can request

these processed bytes using a second API.

Desktop and Server operating systems typically implement both the collection of data and

PRNG, and provide a method for reading random bytes from the OS. For example, LINUX and

BSD based operating system provide /dev/random and/or /dev/urandom, and Windows has

CryptGenRandom() and related APIs.

On embedded platforms, MatrixSSL can provide a PRNG algorithm (Yarrow) suitable for a

small footprint application, however the first requirement of collecting random data is more

difficult and very platform specific. Looking at the points above, embedded hardware often has

very limited user interaction, very limited time variation on operating system events (close to

zero on an RTOS) and very limited hardware peripherals from which to draw. Entropy can be

gathered from some timing measurements, and high quality entropy can be gathered if the

processor can sample from ADC or a free-running oscillator on the hardware platform. Please

contact PeerSec Networks for guidance on gathering entropy for a specific hardware platform.

osdepEntropyOpen

Prototype

int osdepEntropyOpen(void);

Return Values

PS_SUCCESS

Successful initialization.

PS_FAILURE

Failed entropy module initialization. Shouldn’t continue.

Servers and Clients

This is the one-time initialization function for the platform specific PRNG support. This

function must always exist even if there is no operation to perform. This function is

internally invoked from matrixSslOpen().

Memory Proﬁle

This function may internally allocate memory that can be freed during

osdepEntropyClose

Prototype

void osdepEntropyClose(void);

Return Values

None.

Servers and Clients

This function performs the one-time final cleanup for the platform specific entropy and

PRNG support. This function is internally invoked from matrixSslClose().

Memory Proﬁle

This function should free any memory that was allocated during osdepEntropyOpen

psGetEntropy

Prototype

int32 psGetEntropy(unsigned char *bytes, uint32 size);

Parameters

bytes

output

Random bytes must be copied to this buffer

size

input

The number of random bytes the caller is requesting

Return Values

> 0

Success. The number of random bytes copied to bytes. Should

be the same value as size

PS_FAILURE

Failure. Error generating random bytes

Implementation Requirements

This routine must be able to provide an indefinite quantity of random data. This function

is internally invoked by several areas of the MatrixSSL code base. Please contact PeerSec

Networks for guidance in implementing entropy gathering.

Server and Client Usage

There are various places in which random data is needed within the SSL protocol for both

clients and servers.

Memory Proﬁle

This API may adjust its internal state or storage size of collected entropy data.

File Access Functions

These functions can optionally be implemented in core/<OS>/osdep.c. They are only required if

PS_USE_FILE_SYSTEM is defined in the platform build environment.

psGetFileBuf

Prototype

int32 psGetFileBuf(psPool_t *pool, const char *filename,

!!unsigned char **buf, int32 *bufLen);

Parameters

pool

input

The memory pool if using PeerSec Deterministic Memory

(USE_PEERSEC_MEMORY_MANAGEMENT is enabled)

filename

input

The filename (with directory path) of the file to open

buf

output

The contents of the filename in a memory buffer

bufLen

output

Length, in bytes, of buf

Return Values

PS_SUCESS

Success. The file contents are in the memory buffer at buf

< 0

Failure.

Implementation Requirements

This routine must be able to open a given file and copy the contents into a memory

location that is returned to the caller. The memory location must be allocated from

within the function and if a pool parameter is passed in, the function must use psMalloc

for the memory allocation.

Server and Client Usage

Reading files from disk will only be necessary if matrixSslLoadRsaKeys or

matrixSslLoadDhParams is used during initialization.

Memory Proﬁle

The allocated buf will be freed internally using psFree by the callers of psGetFileBuf.

Deﬁne Dependencies

USE_FILE_SYSTEM

optionally enable in coreConfig.h

Trace and Debug Functions

The _psTrace set of APIs are the low level platform-specific trace routines that are used by

psTraceCore (USE_CORE_TRACE), psTraceCrypto (USE_CRYPTO_TRACE), psTraceInfo

(USE_SSL_INFORMATIONAL_TRACE), and psTraceHs (USE_SSL_HANDSHAKE_MSG_TRACE). These

functions should be implemented in core/<OS>/osdep.c, and can be stubbed out if trace is not

required.

osdepTraceOpen

Prototype

int osdepTraceOpen(void);

Return Values

PS_SUCCESS

Successful initialization.

PS_FAILURE

Failed trace module initialization. Shouldn’t continue.

Servers and Clients

This is the one-time initialization function for the platform specific trace support. This

function must always exist even if there is no operation to perform. This function is

internally invoked by matrixSslOpen().

Memory Proﬁle

This function may internally allocate memory that can be freed during osdepTraceClose

osdepTraceClose

Prototype

void osdepTraceClose(void);

Return Values

None.

Servers and Clients

This function performs the one-time final cleanup for the platform specific trace support.

This function must always exist even if there is no operation to perform. This function is

internally invoked by matrixSslClose().

Memory Proﬁle

This function must free any memory that was allocated during osdepTraceOpen

_psTrace

Prototype

void _psTrace(char *message);

Parameters

message

input

A fully formed string message to output as debug trace

Implementation Requirements

This routine should output the message to the standard debug output location.

_psTraceStr

Prototype

void _psTraceStr(char *message, char *value);

Parameters

message

input

A string message containing a single %s format character that

will be output as debug trace

value

input

A string value that should be substituted for the %s in the

message parameter.

Implementation Requirements

This routine should substitute the value string for %s in the message parameter and

output the result to the standard debug output location.

_psTraceInt

Prototype

void _psTraceInt(char *message, int32 value);

Parameters

message

input

A string message containing a single %d format character

that will be output as debug trace

value

input

An integer that should be substituted for the %d in the

message parameter.

Implementation Requirements

This routine should substitute the value string for %s in the message parameter and

output the result to the standard debug output location.

_psTracePtr

Prototype

void _psTracePtr(char *message, void *value);

Parameters

message

input

A string message containing a single %p format character

that will be output as debug trace

value

input

A void pointer that should be substituted for the %p in the

message parameter.

Implementation Requirements

This routine should substitute the value pointer for %p in the message parameter and

output the result to the standard debug output location.

osdepBreak

Prototype

void osdepBreak(void);

Implementation Requirements

This routine should be a platform-specific call to halt program execution in a debug

environment. This function is invoked as part of the _psError set of APIs if

HALT_ON_PS_ERROR is enabled to aid in source code debugging. There is a small set of

_psError calls inside the library but the intention is that the user add them to the source

code to help narrow down run-time problems.

Deﬁne Dependencies

HALT_ON_PS_ERROR

optionally enable in core/coreConfig.h

Standard Library Dependencies

MatrixSSL also relies on a small set of standard library calls that the platform must provide. The

functions in this list should typically be provided in the standard C libraries, such as libc, newlib

and uClibc, but if not, you will need to implement them.

The Implementation Requirements descriptions for these routines are taken directly from the

BSD Library Functions Manual.

Memory Allocation

malloc

Prototype

void *malloc(size_t size);

Implementation Requirements

The malloc function allocates size bytes of memory and returns a pointer to the

allocated memory.

realloc

Prototype

void *realloc(void *ptr, size_t size);

Implementation Requirements

The realloc function tries to change the size of the allocation pointed to by ptr to size,

and returns ptr. If there is not enough room to enlarge the memory allocation pointed to

by ptr, realloc creates a new allocation, copies as much of the old data pointed to by

ptr as will fit to the new allocation, frees the old allocation, and returns a pointer to the

allocated memory. If ptr is NULL, realloc is identical to a call to malloc for size bytes.

If size is zero and ptr is not NULL, a new, minimum sized object is allocated and the

original object is freed.

free

Prototype

void free(void *ptr);

Implementation Requirements

The free function deallocates the memory allocation pointed to by ptr.

Memory Operations

memcmp

Prototype

int memcmp(const void *s1, const void *s2, size_t n);

Implementation Requirements

The memcmp function compares byte string s1 against byte string s2. Both strings are

assumed to be n bytes long. The memcmp function returns 0 if the two strings are

identical, otherwise returns the difference between the first two differing bytes (treated as

unsigned char values, so that `\200' is greater than `\0', for example). Zero-length strings

are always identical.

memcpy

Prototype

void *memcpy(void *s1, void *s2, size_t n);

Implementation Requirements

The memcpy function copies n bytes from memory area s2 to memory area s1. If s1 and

s2 overlap, behavior is undefined. Applications in which s1 and s2 might overlap should

use memmove instead. The memcpy function returns the original value of s1.

memset

Prototype

void *memset(void *s, int c, size_t n);

Implementation Requirements

The memset function writes n bytes of value c (converted to an unsigned char) to the

string s. The memset function returns its first argument.

memmove

Prototype

void *memmove(void *s1, void *s2, size_t n);

Implementation Requirements

The memmove function copies n bytes from string s2 to string s1. The two strings may

overlap; the copy is always done in a non-destructive manner. The memmove function

returns the original value of s1.

strstr

Prototype

char *strstr(const char *s1, const char *s2);

Implementation Requirements

The strstr function locates the first occurrence of the null-terminated string s2 in the

null-terminated string s1. If s2 is an empty string, s1 is returned; if s2 occurs nowhere in

s1, NULL is returned; otherwise a pointer to the first character of the first occurrence of s2

is returned.

strlen

Prototype

size_t strlen(const char *s);

Implementation Requirements

The strlen function computes the length of the string s. The strlen function returns the

number of characters that precede the terminating NUL character.

Additional Topics

Client and Server Socket-based Applications

If directly porting the BSD sockets-based client and server applications that are provided in the

apps directory, there is an additional set of functions that must be available on the platform.

Below is an alphabetical list of the functions with an ✓ indicating that is it needed by that

application. If porting to non-BSD sockets applications, it is easier to rewrite the examples with

the native transport API than to try to implement the apis 1:1 below.

Function

Client

Server

✓

bind

✓

connect

✓

exit

✓

fcntl

✓

inet_addr

✓

listen

✓

puts

✓

recv

✓

select

✓

send

✓

setsockopt

✓

signal

✓

socket

✓

strncpy

✓

64-Bit Integer Support

If your platform supports 64-bit integer types (long long) you should make sure USE_INT64 is

enabled in core/coreConfig.h so that native 64-bit math operations can be used. If used, your

platform may also require the udivdi3 function. If this symbol (or other 64-bit related

functions) is not available, you can optionally disable USE_INT64 to produce a slower

performance library.

64 bit integer math support is not the same as running in ’64 bit addressing mode’ for the

operating system. Many 32 bit processors do support multiplying two 32 bit numbers for a 64 bit

result, and can enable this define.

Multithreading and fork( )

In most cases, a single threaded, non blocking event loop is more efficient for handling multiple

socket connections. This is evidenced by the architecture of high performance web servers such

as nginx and lightHttpd. As such, MatrixSSL does not contain any locking for individual SSL

connections.

Threading

If threading is present in an application using MatrixSSL, a few guidelines should be followed:

•It is highly recommended that any given SSL session be associated only with a single thread.

This means multiple threads should never share access to a single ssl_t structure, or its

associated socket connection. Theoretically, the connection may be handled by a thread and

then passed on to another without simultaneous access, but this complexity isn’t recommended.

It is also possible to add a mutex lock around each access of the ssl_t structure, associated

socket, etc., however ensuring that parsing and writing of records is properly interleaved

between threads is difficult.

•The only SSL protocol resource shared between sessions in MatrixSSL is the session cache on

server side SSL connections. This is a performance optimization which allows clients that

reconnect to bypass CPU intensive public key operations for a period of time. MatrixSSL does

internally define and lock a mutex to keep this cache consistent if multiple threads access it at

the same time. This code is enabled with the USE_MULTITHREADING define.

•User implementations of entropy gathering, filesystem and time access may internally require

mutex locks for consistency, which is beyond the scope of this document.

fork()

Applications using fork() to handle new connections are common on Unix based platforms.

Because the MatrixSSL session cache is located in the process data space, a forked process will

not be able to update the master session cache, thereby preventing future sessions from being

able to take advantage of this speed improvement. In order to support session resumption in

forked servers, a shared memory or file based session cache must be implemented.

The mutex implementation is wrapped within the USE_MULTITHREADING define in core/

coreConfig.h and the platform-specific implementation should be included in the core/<OS>/

osdep.c file.

osdepMutexOpen

Prototype

int osdepMutexOpen(void);

Return Values

PS_SUCCESS

Successful initialization.

PS_FAILURE

Failed mutex module initialization. Shouldn’t continue.

Servers

This is the one-time initialization function for the platform specific mutex support. This

function must always exist even if there is no operation to perform. This function is

internally invoked by matrixSslOpen().

Memory Proﬁle

This function may internally allocate memory that can be freed during osdepMutexClose

osdepMutexClose

Prototype

void osdepMutexClose(void);

Return Values

None.

Servers

This function performs the one-time final cleanup for the platform specific mutex

support. This function must always exist even if there is no operation to perform. This

function is internally invoked by matrixSslClose().

psCreateMutex

Prototype

int32 psCreateMutex(psMutex_t *mutex);

Parameters

mutex

input/output

An allocated psMutex_t structure to initialize

for future calls to psLockMutex,

psUnlockMutex, and psDestroyMutex

Return Values

PS_SUCCESS

Success. The mutex has been created.

PS_FAILURE

Failure

Server Usage

The server uses this function to create the sessionTableLock during application

initialization.

psLockMutex

Prototype

int32 psLockMutex(psMutex_t *mutex);

Parameters

mutex

input

Mutex to lock

Return Values

PS_SUCCESS

Success. The mutex has been locked.

PS_FAILURE

Failure

Server Usage

The server uses this function to lock the sessionTableLock each time the session cache

table is being modified.

psUnlockMutex

Prototype

int32 psUnlockMutex(psMutex_t *mutex);

Parameters

mutex

input

Mutex to unlock

Return Values

PS_SUCCESS

Success. The mutex has been locked.

PS_FAILURE

Failure

Server Usage

The server uses this function to unlock the sessionTableLock each time the session

cache table is done being modified.

psDestroyMutex

Prototype

void psUnlockMutex(psMutex_t *mutex);

Parameters

mutex

input

Mutex to destory

Server Usage

The server uses this function to destroy the sessionTableLock mutex during application

shutdown.

MatrixSSL_OSPortingGuide Matrix SSL OSPorting Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
