Delft3D
3D/2D modelling suite for integral water solutions
User Manual
NEFIS
DRAFT
DRAFT
DRAFT
NEFIS Library
Neutral File System for data storage and retrieval
User Manual
Version: 5.00
SVN Revision: 50387
April 18, 2018
DRAFT
NEFIS Library, User Manual
Published and printed by:
Deltares
Boussinesqweg 1
2629 HV Delft
P.O. 177
2600 MH Delft
The Netherlands
telephone: +31 88 335 82 73
fax: +31 88 335 85 82
e-mail: info@deltares.nl
www: https://www.deltares.nl
For sales contact:
telephone: +31 88 335 81 88
fax: +31 88 335 81 11
e-mail: software@deltares.nl
www: https://www.deltares.nl/software
For support contact:
telephone: +31 88 335 81 00
fax: +31 88 335 81 11
e-mail: software.support@deltares.nl
www: https://www.deltares.nl/software
Copyright © 2018 Deltares
All rights reserved. No part of this document may be reproduced in any form by print, photo
print, photo copy, microfilm or any other means, without written permission from the publisher:
Deltares.
DRAFT
Contents
Contents
List of Tables v
1 Introduction 1
1.1 General .................................... 1
1.2 Comments on the use of NEFIS ........................ 1
2 Definitions 3
2.1 Element definition ............................... 3
2.2 Cell definition ................................. 3
2.3 Group definition ................................ 3
3 Data handling 5
3.1 Accessing data ................................ 5
3.2 Data conversion ............................... 5
3.3 Error handling ................................. 5
4 API to NEFIS functions 7
4.1 Clsnef .................................... 8
4.2 Credat .................................... 8
4.3 Crenef .................................... 9
4.4 Defcel .................................... 10
4.5 Defelm .................................... 11
4.6 Defgrp .................................... 12
4.7 Flsdat ..................................... 13
4.8 Flsdef ..................................... 14
4.9 Getels/Getelt ................................. 15
4.10 Gethdf .................................... 16
4.11 Gethdt .................................... 17
4.12 Getiat ..................................... 18
4.13 Getnfv .................................... 19
4.14 Getrat ..................................... 19
4.15 Getsat .................................... 20
4.16 Inqcel ..................................... 21
4.17 Inqdat ..................................... 22
4.18 Inqelm .................................... 22
4.19 Inqfcl/Inqncl .................................. 24
4.20 Inqfel/Inqnel ................................. 25
4.21 Inqfgr/Inqngr ................................. 26
4.22 Inqfia/Inqnia ................................. 27
4.23 Inqfra/Inqnra ................................. 28
4.24 Inqfsa/Inqnsa ................................. 29
4.25 Inqfst/Inqnxt ................................. 30
4.26 Inqgrp .................................... 31
4.27 Inqmxi .................................... 32
4.28 Neferr ..................................... 32
4.29 Putelt/Putels ................................. 33
4.30 Putiat ..................................... 34
4.31 Putrat ..................................... 35
4.32 Putsat .................................... 36
A Example of a data structure 39
B Error/Warning numbers 41
Deltares iii
DRAFT
NEFIS Library, User Manual
C Demonstration programs 45
C.1 Demonstration program 1 ........................... 45
C.2 Demonstration program 2 ........................... 49
D Release notes 55
D.1 Differences between Version 5.00 and 4.00 . . . . . . . . . . . . . . . . . . 55
D.2 Differences between Version 4.00 and 3.10 . . . . . . . . . . . . . . . . . . 55
D.2.1 Improvements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
D.2.2 New functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
D.2.3 Outdated functions . . . . . . . . . . . . . . . . . . . . . . . . . . 56
D.2.4 Unavailable functions ......................... 56
D.3 Differences between Version 3.10 and 3.00 . . . . . . . . . . . . . . . . . . 56
D.3.1 Improvements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
D.3.2 New functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
D.4 Differences between Version 3.00 and 2.00 . . . . . . . . . . . . . . . . . . 56
D.4.1 Improvements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
D.4.2 New functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
D.4.3 Outdated functions . . . . . . . . . . . . . . . . . . . . . . . . . . 57
iv Deltares
DRAFT
List of Tables
List of Tables
2.1 Supported basic types ............................ 3
Deltares v
DRAFT
NEFIS Library, User Manual
vi Deltares
DRAFT
1 Introduction
1.1 General
NEFIS is a library of functions designed for scientific programs. These programs are charac-
terised by their large volume of input and output data. NEFIS is able to store and retrieve large
volumes of data on file or in shared memory. To achieve a good performance when storing
and retrieving data, the files are self-describing binary direct access files. Furthermore one of
the array dimensions may be variable and the sequence on the file can be prescribed. NEFIS
also allows users to store data in a machine-independent way on files, which means that the
data files can be interchanged between computer systems without having to be converted.
Data within NEFIS is divided into a hierarchical structure of groups, cells and elements. This
hierarchical structure is used to find the location in the file where the data should be stored or
retrieved. An element is the smallest unit which can be accessed at one time. One or more
elements make up a cell; and a group is defined as one or more dimensional arrays of cells.
This shows the logical cohesion of the data to be represented. Flags (in this context referred
as attributes) can be attached to groups as desired. These attributes can, for example, de-
fine a match between groups. They may also contain superscripts and subscripts for graphic
design. NEFIS can exist of one file for input and retrieval of data (i.e. a definition and a data
part). The previous NEFIS version needed two files for input and retrieval of data (i.e. a data
file and a definition file). A data file contains the data supplied by the user and the attributes
that have been added. The definition file contains the description of the structure. The rela-
tionship between a data file and a definition file is determined by the application. This means
that one definition file can be used by various data files. The opposite is also possible (i.e. a
data file can be used from different definition files). More over, a well-defined definition file is
able to scope all data files of a company.
1.2 Comments on the use of NEFIS
In almost all cases calling up a NEFIS function involves the use of a file descriptor. This file
descriptor is a integer value which is used by the NEFIS function to determined which files
need to be accessed. All NEFIS functions return an integer∗4 value representing an error
code. In the description of the functions, FORTRAN 77 notation is used to indicate the length
of arrays. An array Awith Nelements is therefore given as follows: A(1 : N). A ’dummy’
must be entered for a parameter in several functions. The value represents the size of the
memory that is available to store data. Not all data is written to the files after every operation;
parts are buffered. The functions Flsdef and Flsdat are available to compel these buffers to be
written to the file. It is then prudent to call these functions up after writing data. The function
Clsnef writes these buffers to the files depending on the access type, the functions Clsdat
and Clsdef also write these buffers to the files. The Cldtnf and Cldfnf functions do not write
these buffers to the files and therefor the timestamp will not be changed if nothing is written
to file. The functions Clsdat, Clsdef, Cldtnf and Cldfnf should be used if the functions Opndat
and Opndef are used. To overcome the problem of two types of functions to close the NEFIS
files the combination of Crenef and Clsnef function should be used, these functions take into
account the accesstype of the files.
Deltares 1 of 60
DRAFT
NEFIS Library, User Manual
2 of 60 Deltares
DRAFT
2 Definitions
2.1 Element definition
An element is the smallest unit, which can be accessed at one time. An element is a single
variable, or one or more dimensional array of single variables with fixed limits. The type,
dimensions, etc., of the element are fixed in a so-called element definition which is being
stored in the definition file.
The definition of an element consists of:
a unique name
the type of the element
the size of the single variable (in bytes) of which the element is made up
the number of dimensions (0 for a single variable)
the dimensions (for an array of single variables)
meta data which state the quantity, unit and the description of the element
The following "basic" types are permitted in NEFIS (given for C and Fortran 77):
Table 2.1: Supported basic types
Size [bytes] C Fortran
4 Float REAL∗4
8 Double REAL∗8
2 Short INTEGER∗2
4 Int INTEGER∗4
8 Long –
2 Short LOGICAL∗2
4 Int LOGICAL∗4
1 Char CHARACTER∗1
2∗4 2 ∗float COMPLEX∗8
2∗8 2 ∗double COMPLEX∗16
2.2 Cell definition
A cell consists of combination of one or more elements whose type may differ. This combi-
nation is fixed in a so-called cell definition that is stored in the definition file/part. In the cell
definition the elements which make up the cell are fixed as well as their storage sequence.
Once a cell has been defined it has a fixed size. Each cell definition has a unique name.
2.3 Group definition
A group consists of one or more dimensional arrays of cells. One of the dimensions may be
variable. The description of the group is fixed in a so-called group definition, which is stored
in the definition file/part. The storage sequence needs to be defined in the case of multi-
dimensional structures. This storage sequence defines which index must count first (most
rapidly), which index must count second, etc.
Deltares 3 of 60
DRAFT
NEFIS Library, User Manual
4 of 60 Deltares
DRAFT
3 Data handling
3.1 Accessing data
Data is written to and retrieved from file by means of a group name. Before data can be
accessed, the group name must be defined on the data file. At that moment space is reserved
for the data and for a number of attributes. NEFIS allows you to define several different group
names with the same group definition. When the group has been defined, the data can be
accessed using the group name and the element name as defined in the cell. The desired
dimensions of a group can be specified. Remember that an element is the smallest unit that
can be accessed. A buffer is used when data is stored or retrieved. The physical arrangement
of data in this buffer must correspond with the way in which the cells are defined. When for
example a cell is defined with REAL velocity components (u, v, w), then the values for the
elements of this cell must also appear in the same order in the buffer. The type of buffer is
of no importance for NEFIS functions and is determined by the user. For this reason, in the
description of functions the type of buffer is given as "void". Data can be written and read.
Data can also be altered (overwritten), but cannot be removed. Definitions can be written and
read, but cannot be altered (overwritten) or removed.
3.2 Data conversion
Where files have to be used on several different computer systems, they may be stored in a
standardised neutral (ANSI/IEEE 754) representation using xdr-routines if the variables oc-
cupy more than 4 bytes. Characters (CHARACTER∗1) are written directly to file. Integers
and logicals (INTEGER∗2 and LOGICAL∗2) are handled by a NEFIS routine. This is done by
giving the value "N" when the files are created with function "Crenef" via the CODING param-
eter. This enables the data to be correctly converted when written. If the data is subsequently
entered into another system, it is converted back into the relevant machine representation. If
the coding parameter is not a "N" while creating the NEFIS files the data will not be converted
and is written directly to file. Proposed coding value is than "B" (binary). When reading a
NEFIS the best choice is to assign a blank (" ") as coding value, this means that the coding
type is read from file.
3.3 Error handling
All NEFIS functions are INTEGER∗4 functions. The functions give a return value equal to 0
when the function has been completed without an error. If the value is not equal to 0, the
function has ended abnormally and the corresponding error message can be obtained with
the function Neferr.
Deltares 5 of 60
DRAFT
NEFIS Library, User Manual
6 of 60 Deltares
DRAFT
4 API to NEFIS functions
The functions currently available in NEFIS to manipulate descriptions and data are given
below in alphabetical order:
Name Definition
4.1 Close a NEFIS data and definition file
4.2 Declare a data group in the data file
4.3 Create a NEFIS data and definition file
4.4 Define a cell
4.5 Define an element
4.6 Define a group
4.7 Flush buffers to the data file
4.8 Flush buffers to the definition file
4.9 Read one or all string elements from the data file
4.9 Read one or all alpha numeric elements from the data file
4.10 Give information from the header of a NEFIS definition file
4.11 Give information from the header of a NEFIS data file
4.12 Read an integer attribute from the data group
4.14 Read a real attribute from the data group
4.15 Read a character attribute from the data group
4.16 Read a cell definition
4.17 Read a group definition name from a data group
4.18 Read an element definition
4.19 Read the first cell name on a definition file
4.20 Read the first element from the definition file
4.21 Read the first group from the definition file
4.22 Read the first name and corresponding value of the integer attributes of a
given data group
4.23 Read the first name and corresponding value of the real attributes of a
given data group
4.24 Read the first name and corresponding value of the character attributes of
a given data group
4.25 Read the first data group name and definition name from the data file
4.26 Read the group definition
4.27 Determine the maximum used index of a data group with free dimension
4.19 Read the next cell name on the definition file
4.20 Read the first element from the definition file
4.21 Read the next group from the definition file
4.22 Read the next name and corresponding value of the integer attributes of a
given data group
4.23 Read the next name and corresponding value of the real attributes of a
given data group
4.24 Read the next name and corresponding value of the character attributes of
a given data group
4.25 Read the next data group name
4.28 Retrieve an error message
4.29 Write one or more character elements to the data file
4.29 Write one or more elements to the data file
4.30 Write an integer attribute to the data group
4.31 Write a real attribute to the data file
4.32 Write a character attribute to the data file
Deltares 7 of 60
DRAFT
NEFIS Library, User Manual
The following sections contain a detailed description of NEFIS functions.
4.1 Clsnef
Description
Close the data and definition file. Depending on the access type the output buffers will be
written to the files before closing the files.
Syntax
error = Clsnef (fd_nefis)
Parameters
fd_nefis input/output
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
output Set to -1, if function is successful
error return value
type c int
Fortran integer∗4
= 0 No error occurred
6= 0 Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.2 Credat
Description
Declare a data group in the data file.
Syntax
error = Credat (fd_nefis, grpnam, grpdef)
Parameters
fd_nefis input
type c int
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
Fortran character∗16
input Name of the data group to be created. This name must be unique
to the data file.
grpdef input
type c char ∗
Fortran character∗16
8 of 60 Deltares
DRAFT
API to NEFIS functions
input Name of the group definition to be used for this data group. This
group definition must already be defined on the definition file (see
function Defgrp 4.6).
error return value
type c int
Fortran integer∗4
= 0 No error occurred
6= 0 Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remarks:
Space is reserved on the data file, but this space is not initialised.
For data groups with a variable dimension the space is only then reserved when the data
is being written.
4.3 Crenef
Description
Create or open a NEFIS data and definition file
Syntax
error = Crenef (fd_nefis, dat_name, def_name, coding, access)
Parameters
fd_nefis input/output
type c int ∗
Fortran integer∗4
input NEFIS file descriptor
output Set to -1, if function is unsuccessful
dat_name input
type c char ∗
Fortran character(len=∗)
input Name of the data file, maximum file name length is 256 characters.
def_name input
type c char ∗
Fortran character(len=∗)
input Name of the definition file, maximum file name length is 256 char-
acters.
coding input
type c char[1]
Fortran character(len=1)
=’B’ big-endian representation of the data, we called it neutral repre-
sentation
=’L’ little-endian representation of the data
6=’B’ or
’L’
Endianess-representation is taken from the machine
Deltares 9 of 60
DRAFT
NEFIS Library, User Manual
If the data file does not exist, this is an input parameter stating whether the data
in the file have to be converted into the big-endian (IEEE-754) representation.
Where the data file does already exist, this is an output parameter stating
whether or not the data in the file are already in neutral representation.
access input
type c char
Fortran character(len=1)
=’c’ create a NEFIS file set, existing NEFIS file will be deleted
=’r’ read only access of the NEFIS file set
=’u’ update of the NEFIS file set, write and read access of the NEFIS
file set.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
6= 0 Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.4 Defcel
Description
Define a cell
Syntax
error = Defcel (fd_nefis, celnam, nelems, elmnms)
Parameters
fd_nefis input
type c int
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
celnam input
type c char ∗
Fortran character(len=16)
input Name of the cell to be defined.
nelems input
type c int ∗
Fortran integer∗4
input Number of elements in this cell.
elmnms input
type c int ∗
Fortran integer∗4
10 of 60 Deltares
DRAFT
API to NEFIS functions
input Array(1:NELEMS) with the names of the elements which make
up this cell. The element names must already be defined. (see
function Defelm 4.5). The sequence of the names in this array is
also the physical order in which the data in the buffer are expected
when reading and writing entire cells.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.5 Defelm
Description
Define an element.
Syntax
error = Defelm (fd_nefis, elmnam, elmtyp, nbytsg, elmqty, elmunt, elmdes, elmndm, elmdms)
Parameters
fd_nefis input
type c int
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
elmnam input
type c char ∗
Fortran character(len=16)
input Name for the element to be defined.
elmtyp input
type c char ∗
Fortran character(len=8)
input Type of element. The following types can be used: REAL, INTE-
GER, LOGICAL, CHARACTE(R) and COMPLEX.
nbytsg input
type c int
Fortran integer∗4
input The size in bytes of a single variable of this type. For example, this
is usually 4 for an element that will contain real values.
elmqty input
type c char ∗
Fortran character(len=16)
input The quantity of this element.
elmunt input
Deltares 11 of 60
DRAFT
NEFIS Library, User Manual
type c char ∗
Fortran character(len=16)
input The unit of this element.
elmdes input
type c char ∗
Fortran character(len=64)
input The description of this element.
elmndm input
type c int
Fortran integer∗4
input The number of dimensions of this element. This is 0 for a single
element. For elements other than single elements, the number of
dimensions may be from 1 to 5.
elmdms input
type c int ∗
Fortran integer∗4
input This is an array(1:ELMNDM) with the dimension for an element
other than a single element. The sequence and the size of the
values in this array determine the structure of the element. For
a single element, this value may be 0. The dimensions must be
larger than 0 for an array. The correctness of the dimensions is
not being checked.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.6 Defgrp
Description
Define a group on the definition file.
Syntax
error = Defgrp (fd_nefis, grpnam, celnam, grpndm, grpdms, grpord)
Parameters
fd_nefis input
type c int
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
Fortran character(len=16)
12 of 60 Deltares
DRAFT
API to NEFIS functions
input Name for the group to be defined.
celnam input
type c char ∗
Fortran character(len=16)
input Name of the cell with which this group is made up. This cell must
already be defined (see function Defcel 4.4).
grpndm input
type c int ∗
Fortran integer∗4
input The number of dimensions of this group. The number of dimen-
sions may be 0 for a group with only 1 cell. The maximum number
of dimensions is 5.
grpdms input
type c int ∗
Fortran integer∗4
input This is an array(1:GRPNDM) with the dimensions. One of the di-
mensions may be 0 which number indicates the part that is vari-
able. The correctness of the dimensions is not being checked.
grpord input
type c int ∗
Fortran integer∗4
input This is an array(1:GRPNDM) which gives the order in which the
cells must be written to the data file (which index runs most rapidly,
which runs next most rapidly etc.). The sequence which operates
in FORTRAN for a multi-dimensional array is 1, 2, 3, etc.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
The group order array (grpord) allows you to write data to a file in a several different
order. The best possible performance is achieved by selecting a sequence which is
the same as that in which the data will usually be retrieved later. For example, where
it is necessary to store precipitation observations which are made on a daily basis in
various locations and where the pattern of access to these observations is normally
that all locations call them up at a specific time, it is advisable to arrange for the counter
giving the locations to open more rapidly than the others. This parameter is dummy
where the number of dimensions is 0 or 1.
4.7 Flsdat
Description
Flush the buffers to the data file.
Deltares 13 of 60
DRAFT
NEFIS Library, User Manual
Syntax
error = Flsdat (fd_nefis)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
It is prudent to use this function after writing data to the file, because otherwise if the ap-
plication ends abnormally the data is present on the file but can no longer be accessed.
The Clsnef function also writes the buffers to the file.
4.8 Flsdef
Description
Flush the buffers to the definition file.
Syntax
error = Flsdef (fd_nefis)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
It is prudent to use this function after writing the definition file, because otherwise if the
application ends abnormally the definitions is present on the file but can no longer be
accessed. The Clsnef function also writes the buffers to the file.
14 of 60 Deltares
DRAFT
API to NEFIS functions
4.9 Getels/Getelt
Description
Read one or all (same kind) elements from a group on a data file. Getels is used for string
values and Getelt is used for alpha-numeric values.
Syntax
error = Getels (fd_nefis, grpnam, elmnam, uindex, usrord, buflen, buffer)
error = Getelt (fd_nefis, grpnam, elmnam, uindex, usrord, buflen, buffer)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group of which one or more elements must e
read.
elmnam input
type c char ∗
fortran character∗16
input Name of the element which is to be read. When Elmnam = ’∗’, this
means that all elements must be read.
uindex input
type c int ∗Uindex[<grpndm>][3]
fortran integer Uindex(3,<GRPNDM>)
input This array contains information on the indices of the cells that must
be run. For each dimension of the data group three numbers must
be given, namely the start index, the end index and the step size.
usrord input
type c int ∗Usrord[<grpndm>]
fortran integer Usrord(<GRPNDM>)
input This is an array (1:GRPDNM) which determines the sequence in
which the cells must be run. This is achieved by stating which
index runs most rapidly, which runs next most rapidly etc.) With
this the "view" of a group can be changed provided that also the
buffer is filled in this sequence.
buflen input
type c int ∗
fortran integer
input Size in bytes of the available buffer.
buffer output
type c void
fortran void
Deltares 15 of 60
DRAFT
NEFIS Library, User Manual
output Buffer in which the values of the cells concerned are written
(strings and numbers). When the buffer is used to receive strings,
it also possible to use the function Getels.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remarks:
If a character string/array is retrieved by a c/c++ program no ’\0’ is added to the string
or array item. This is because the NEFIS library does not recognize the single item, it
is just reading the bites.
How parameter UINDEX works can best be presented by an example: Suppose you
have defined with Defgrp a group with dimensions (20,13) and reversed the array with
parameter USRORD towards (13, 20). With the following values in UINDEX:
UINDEX(1-3,1) = 1, 13, 3
UINDEX(1-3,2) = 5, 20, 5
then the cells will be run in the following sequence:
[ 5,1] [ 5,4] [ 5,7] [ 5,10] [ 5,13]
[10,1] [10,4] [10,7] [10,10] [10,13]
[15,1] [15,4] [15,7] [15,10] [15,13]
[20,1] [20,4] [20,7] [20,10] [20,13].
The given indices must be within the defined limits. Obviously, for indices of the variable
dimension (see Defgrp 4.6) this restriction does not hold. The step size must be positive.
4.10 Gethdf
Description
Give information from the header of a definition file.
Syntax
c: error = Gethdf (fd_nefis, header)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
header input
type c char ∗[128+1]
fortran character∗128
16 of 60 Deltares
DRAFT
API to NEFIS functions
input In this string the information from the file header is being put.
Among other things this information contains the name of the sys-
tem upon which the file is being created and whether or not the
data representation is neutral (ANSI/IEEE 754). When using two
separated NEFIS files for data and definition the size of the header
can be 60 instead of 128.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
If the header is retrieved by a c/c++ program no ’\0’ is added to the string
4.11 Gethdt
Description
Give information from the header of a data file.
Syntax
error = Gethdt (fd_nefis, header)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
header input
type c char ∗
fortran character∗128
input In this string information from the file header is being put. Among
other things this information contains the name of the system upon
which the file is being created and whether or not the data repre-
sentation is neutral (ANSI/IEEE 754). When using two separated
NEFIS files for data and definition the size of the header can be
60 instead of 128.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Deltares 17 of 60
DRAFT
NEFIS Library, User Manual
Remark:
If the header is retrieved by a c/c++ program no ’\0’ is added to the string
4.12 Getiat
Description
Read an integer attribute from a data group.
Syntax
error = Getiat (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group from which an integer attribute is to be
read.
attnam input
type c char ∗
fortran character∗16
input Name of the attribute (see function Putiat 4.30).
attval output
type c int ∗
Fortran integer∗4
input Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
See also the functions Inqfia and Inqnia 4.22.
18 of 60 Deltares
DRAFT
API to NEFIS functions
4.13 Getnfv
Description
Returns the full version number of the NEFIS library.
Syntax
error = Getnfv (nef_version)
Parameters
nef_version output
type c char ∗∗
fortran character∗
input In this string the full version number of the NEFIS library is re-
turned.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
The corresponding error message can not be retrieved with the function Neferr.
Example:
@(#)Deltares, NEFIS Version 5.07.02.3965M, Aug 4 2014, 20:09:15
4.14 Getrat
Description
Read a real attribute from a data group.
Syntax
error = Getrat (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group from which an integer attribute is to be
read.
attnam input
type c char ∗
fortran character∗16
input Name of the attribute (see function Putrat 4.31).
Deltares 19 of 60
DRAFT
NEFIS Library, User Manual
attval output
type c float ∗
fortran real∗4
output Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
See also the functions INQFRA and INQNRA.
4.15 Getsat
Description
Read a string attribute from a data group.
Syntax
error = Getsat (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group from which an integer attribute is to be
read.
attnam input
type c char ∗
fortran character∗16
input Name of the attribute (see function Putrat 4.31).
attval output
type c char ∗
fortran character∗16
output Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
20 of 60 Deltares
DRAFT
API to NEFIS functions
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remarks:
If string attribute is retrieved by a c/c++ program no ’\0’ is added to the string
See also the functions Inqfsa and Inqnsa 4.24.
4.16 Inqcel
Description
Read a cell definition from the definition file
Syntax
error = Inqcel (fd_nefis, celnam, nelems, elmnms)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
celnam input
type c char ∗
fortran character∗16
input Name of the cell to be defined.
nelems input/output
type c int ∗
Fortran integer∗4
input current length of array ELMNMS, value will be
checked against number of elements in this cell def-
inition
output the number of elements used in this cell definition
elmnms output
type c char ∗elmnms[nelems][16+1]
fortran character∗16 elmnms(nelems)
An array (1:NELEMS) with the names of the ele-
ments used in this cell definition.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Deltares 21 of 60
DRAFT
NEFIS Library, User Manual
4.17 Inqdat
Description
Read corresponding group definition from the data group.
Syntax
error = Inqdat (fd_nefis, grpnam, grpdef)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group of which the definition name is to be read.
grpdef output
type c char ∗
fortran character∗16
output Name of the definition used for this data group.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.18 Inqelm
Description
Read an element definition from the definition file.
Syntax
error= Inqelm (fd_nefis, elmnam, elmtyp, nbytsg, elmqty, elmunt, elmdes, elmndm, elmdms)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
elmnam input
type c char ∗
fortran character∗16
input Name of the element whose definition is to be read.
22 of 60 Deltares
DRAFT
API to NEFIS functions
elmtyp output
type c char ∗
fortran character∗8
output Type of element.
nbytsg output
type c int
Fortran integer∗4
output The size in bytes of a single variable of the element.
elmqty output
type c char ∗
fortran character∗16
output The quantity of this element.
elmunt output
type c char ∗
fortran character∗16
output The unit of this element.
elmdes output
type c char ∗
fortran character∗64
output The description of this element.
elmndm input/output
type c int ∗
Fortran integer∗4
input Current length of array ELMDMS, value will be checked against
number of dimensions of this element. Because ELMNDM is not
known in advance, it is recommended that the current length of
this array be set at the maximum value (=5).
output The number of dimensions of this element (maximum 5).
elmdms output
type c int
Fortran integer∗4
output This is an array(1:ELMNDM) with the dimension for an element
other than a single element.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Deltares 23 of 60
DRAFT
NEFIS Library, User Manual
4.19 Inqfcl/Inqncl
Description
Read the first and next cell name, dimension, size in bytes and containing element names
from the definition file.
Syntax
error = Inqfcl (fd_nefis, celnam, nelems, bytes, elmnms)
error = Inqncl (fd_nefis, celnam, nelems, bytes, elmnms)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
celnam output
type c char ∗
fortran character∗16
output Name of the cell for which data is retrieved.
nelems output
type c int ∗
Fortran integer∗4
input Current length of array ELMNMS, value will be checked against
number of elements in this cell definition.
output The number of elements used in this cell definition.
bytes output
type c int ∗
Fortran integer∗4
output Length of the cell in bytes.
elmnms output
type c char ∗elmnms[nelems][16+1]
fortran character∗16 elmnms(nelems)
output Array(1:NELEMS) with the names of the elements which make
up this cell. The element names must already be defined. (see
function Defelm 4.5) The sequence of the names in this array is
also the physical order in which the data in the buffer are expected
when reading and writing entire cells.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
The elmnms array is a character array, the ’\0’ is not added to the array items when
retrieving the array.
24 of 60 Deltares
DRAFT
API to NEFIS functions
4.20 Inqfel/Inqnel
Description
Read the first and next element from the definition file.
Syntax
error = Inqfel (fd_nefis, elmnam, elmtyp, elmqty, elmunt, elmdes, bytes, numbyt, elmndm,
elmdms)
error = Inqnel (fd_nefis, elmnam, elmtyp, elmqty, elmunt, elmdes, bytes, numbyt, elmndm,
elmdms)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
elmnam output
type c char ∗
fortran character∗16
output Name of the element.
elmtyp output
type c char ∗
fortran character∗8
output Type of element. An element can be one of the following types:
REAL, INTEGER, LOGICAL, CHARACTE(R) or COMPLEX.
elmqty output
type c char ∗
fortran character∗16
output The quantity of the element.
elmunt output
type c char ∗
fortran character∗16
output The unit of the element.
elmdes output
type c char ∗
fortran character∗64
output The description of the element.
bytes output
type c int ∗
Fortran integer∗4
output The size in bytes of a single variable of this type. For example, this
is usually 4 for an element that will contain real values.
numbyt output
type c int ∗
Fortran integer∗4
Deltares 25 of 60
DRAFT
NEFIS Library, User Manual
output The size in bytes of the complete element. That is usually
bytes∗elmdms(1)∗...∗elmdms(elmndm) for an element which will
contain real values.
elmndm output
type c int ∗
Fortran integer∗4
input current length of array ELMDMS, value will be checked against
number of dimensions of this element. Because ELMNDM is not
known in advance, it is recommended that the current length of
this array be set at the maximum value (=5).
output the number of dimensions of the element. The number of dimen-
sions may be from 1 to 5.
elmdms output
type c int ∗
Fortran integer∗4
output This is an array(1:ELMNDM) with the dimension for an element.
The sequence and the size of the values in this array determine
the structure of the element.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.21 Inqfgr/Inqngr
Description
Read the first or next group from definition file.
Syntax
error = Inqfgr (fd_nefis, grpnam, celnam, grpndm, grpdms, grpord)
error = Inqngr (fd_nefis, grpnam, celnam, grpndm, grpdms, grpord)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam output
type c char ∗
fortran character∗16
output Name of the group.
celnam output
type c char ∗
26 of 60 Deltares
DRAFT
API to NEFIS functions
fortran character∗16
output Name of the cell with which this group is made up. (see function
Defcel, 4.4).
grpndm input/output
type c int ∗
Fortran integer∗4
input current length of array GRPDMS and GRPORD, this value will be
checked against number of dimensions of this group. Because
GRPNDM is not known in advance, it is recommended that the
current length of this array be set at the maximum value (=5).
output The number of dimensions of this group. The maximum number
of dimensions is 5.
grpdms output
type c int ∗
Fortran integer∗4
output This is an array(1:GRPNDM) with the dimensions. One of the di-
mensions may be 0 which number indicates the part that is vari-
able. The correctness of the dimensions is not being checked.
grpord output
type c int ∗
Fortran integer∗4
output This is an array(1:GRPNDM) which gives the order in which the
cells must be written to the data file (which index runs most rapidly,
which runs next most rapidly etc.). The sequence which operates
in FORTRAN for a multi-dimensional array is 1, 2, 3, etc..
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.22 Inqfia/Inqnia
Description
Read the names and values of the first and next integer attributes, INQFIA and INQNIA re-
spectively, of a data group.
Syntax
error = Inqfia (fd_nefis, grpnam, attnam, attval)
error = Inqnia (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
Deltares 27 of 60
DRAFT
NEFIS Library, User Manual
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group of which the names and values of the
attributes must be read.
attnam output
type c char ∗
fortran character∗16
output Name of the attribute (see function Putiat 4.30).
attval output
type c int ∗
Fortran integer∗4
output Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
The function INQFIA gives the first name and the corresponding value. With function
INQNIA possibly following names and values may be retrieved.
4.23 Inqfra/Inqnra
Description
Read the names and values of the first and next real attributes, INQFRA and INQNRA re-
spectively, of a data group.
Syntax
error = Inqfra (fd_nefis, grpnam, attnam, attval)
error = Inqnra (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group of which the names and values of the
attributes must be read.
28 of 60 Deltares
DRAFT
API to NEFIS functions
attnam output
type c char ∗
fortran character∗16
output Name of the attribute (see function Putrat 4.31).
attval output
type c int ∗
Fortran integer∗4
output Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
The INQFRA function gives the first name and corresponding value. With the INQNRA
function the possibly following names and values may be retrieved.
4.24 Inqfsa/Inqnsa
Description
Read the names and values of the first and next character attributes, INQFSA and INQNSA
respectively, of a data group.
Syntax
error = Inqfsa (fd_nefis, grpnam, attnam, attval)
error = Inqnsa (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group of which the names and values of the
attributes must be read.
attnam output
type c char ∗
fortran character∗16
output Name of the attribute (see function Putsat, 4.32).
attval output
Deltares 29 of 60
DRAFT
NEFIS Library, User Manual
type c char ∗
fortran character∗16
output Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
The INQFSA function gives the first name and corresponding value. With the INQNSA
function the possibly following names and values may be retrieved.
4.25 Inqfst/Inqnxt
Description
Read the name of the first (INQFST) and the next (INQNXT) data group from a data file and
the corresponding group definition name.
Syntax
error = Inqfst (fd_nefis, grpnam, grpdef)
error = Inqnxt (fd_nefis, grpnam, grpdef)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam output
type c char ∗
fortran character∗16
output Name of the first and the next data group, INQFST and INQNXT
respectively, on the data file (see function Credat, 4.2).
grpdef output
type c char ∗
fortran character∗16
output Name of the definition used for this data group (see function Cre-
dat, 4.2).
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
30 of 60 Deltares
DRAFT
API to NEFIS functions
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
INQFST gives the first name, INQNXT the next one until there are no names left.
4.26 Inqgrp
Description
Read a group definition from the definition file.
Syntax
error = Inqgrp (fd_nefis, grpdef, celnam, grpndm, grpdms, grpord)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpdef input
type c char ∗
fortran character∗16
input Name for the group whose definition is to be retrieved.
celnam output
type c char ∗
fortran character∗16
output Name of the cell with which this group is made up.
grpndm input/output
type c int ∗
Fortran integer∗4
input The number of dimensions which can be stored in the arrays GR-
PDMS and GRPORD. Because GRPNDM is not known in ad-
vance, it is recommended to fix the current length of this array
at the maximum value (=5).
output The number of dimensions of this group.
grpdms output
type c int
Fortran integer∗4
output This is an array(1:GRPNDM) with the dimensions of the group.
grpord output
type c int
Fortran integer∗4
output This is an array (1:GRPNDM) which gives the order in which the
data was written to the data file (which index runs most rapidly,
which runs next most rapidly, etc.).
error return value
type c int
Deltares 31 of 60
DRAFT
NEFIS Library, User Manual
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.27 Inqmxi
Description
Give the maximum used index of the free dimension of a data groupp.
Syntax
error = Inqmxi (fd_nefis, grpnam, max_index)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name for the group whose maximum variable index is to be re-
trieved.
max_index output
type c int ∗
Fortran integer∗4
output Maximum index of group ’grpnam’. If the maximum index is zero
then there is no data written to that group.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
4.28 Neferr
Description
Error message can be retrieved from the NEFIS library and/or printed to standard output.
Syntax
error = Neferr (print_flag, error_string)
Parameters
32 of 60 Deltares
DRAFT
API to NEFIS functions
print_flag input
type c int
Fortran integer∗4
input Print flag to indicate whether the error message is send to stan-
dard output.
== 0 Do not print error string
== 1 Do print the error string on standard output
== 2 Do print the error string on standard error
error_string output
type c char ∗
fortran character∗1024
output The string error_string contains the error message generated by
the last NEFIS function which detected the error. Or if the last
function did not detected an error the number of errors occurred
when using the NEFIS library.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
4.29 Putelt/Putels
Description
Write one or all (same kind) elements to a group on the data file. Putelt is used for alpha-
numeric values and Putels is used for string values.
Syntax
error = Putels (fd_nefis, grpnam, elmnam, uindex, usrord, buffer)
error = Putelt (fd_nefis, grpnam, elmnam, uindex, usrord, buffer)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗grpname[16+1]
fortran character∗16 grpnam
input Name of the data group of which one or all elements must be
written.
elmnam input
type c char ∗elmnam[16+1]
fortran character∗16 elmnam
input Name of the element which must be written. When Elmnam = ’∗’,
this means that all (same kind) elements must be written.
uindex input
type c int ∗Uindex[<grpndm>][3]
fortran integer Uindex(3,<GRPNDM>)
Deltares 33 of 60
DRAFT
NEFIS Library, User Manual
input This array contains information on the indices of the cells that must
be walked through. For each dimension of the data group three
numbers must be given viz. the start index, the end index and the
step size.
usrord input
type c int ∗Usrord[<grpndm>]
fortran integer Usrord (<GRPNDM>)
input This is an array (1:GRPNDM) which determines the sequence in
which the cells must be stepped through. This is achieved by stat-
ing which index runs most rapidly, which runs next most rapidly
etc.. This allows you to make up a desired group representation,
provided that the buffer has the same sequence.
buffer output
type c void ∗
fortran void
input Buffer with values which must be written in the given element of
the cells indicated by UINDEX. Obviously, the data in the buffer
must have the same sequence.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
How parameter UINDEX works can best be presented by an example: Suppose you
have defined with DEFGRP a group with dimensions (20,13) and reversed the array
with parameter USRORD towards (13,20). With the following values in UINDEX:
UINDEX(1-3,1) = 1, 13, 3
UINDEX(1-3,2) = 5, 20, 5
then the cells will be run in the following sequence:
[ 5,1] [ 5,4] [ 5,7] [ 5,10] [ 5,13]
[10,1] [10,4] [10,7] [10,10] [10,13]
[15,1] [15,4] [15,7] [15,10] [15,13]
[20,1] [20,4] [20,7] [20,10] [20,13].
The given indices must be within the defined limits. Obviously, for indices of the variable
dimension (see Defgrp 4.6) this restriction does not hold. The step size must be positive.
4.30 Putiat
Description
Write an integer attribute to a data group.
Syntax
error = Putiat (fd_nefis, grpnam, attnam, attval)
34 of 60 Deltares
DRAFT
API to NEFIS functions
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group at which an integer attribute is to be writ-
ten.
attnam input
type c char ∗
fortran character∗16
input Name of the attribute.
attval input
type c int ∗
Fortran integer∗4
input Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
If this attribute name already exists then the previous value will be replaced by a new
one.
4.31 Putrat
Description
Write a real attribute to a data group.
Syntax
error = Putrat (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
Deltares 35 of 60
DRAFT
NEFIS Library, User Manual
input Name of the data group at which an integer attribute is to be writ-
ten.
attnam input
type c char ∗
fortran character∗16
input Name of the attribute.
attval input
type c int ∗
Fortran integer∗4
input Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
If this attribute name already exists then the previous value will be replaced by a new
one.
4.32 Putsat
Description
Write a string attribute to a data group.
Syntax
error = Putsat (fd_nefis, grpnam, attnam, attval)
Parameters
fd_nefis input
type c int ∗
Fortran integer∗4
input NEFIS file descriptor (see function Crenef, 4.3)
grpnam input
type c char ∗
fortran character∗16
input Name of the data group at which an string attribute is to be written.
attnam input
type c char ∗
fortran character∗16
input Name of the attribute.
attval input
type c char ∗
36 of 60 Deltares
DRAFT
API to NEFIS functions
fortran character∗16
input Attribute value.
error return value
type c int
Fortran integer∗4
= 0 No error occurred
>0Fatal error occurred
Corresponding error message can be printed to standard error or retrieved with the function
Neferr, 4.28.
Remark:
If this attribute name already exists then the previous value will be replaced by a new
one.
Deltares 37 of 60
DRAFT
NEFIS Library, User Manual
Deltares, 2016. “BIBTEX key with no entry, needed if no citations are made in the document.”
38 of 60 Deltares
DRAFT
A Example of a data structure
Before data from an application can be written to NEFIS files, the structure in terms of ele-
ments, cells and groups must be determined. This can be done in various ways. For instance
a field of 5 000 points (a 2-dimensional raster of 100×50) with at each point:
a discharge Q
a velocity V(2), consisting of two components
waveheight spectrum Hs(10,4), 10 angles, 4 periods
output data at 12 points in time
This data can be portrayed in various ways. Some options are described below.
Option A
Elements: "DISCH" Q
"VELO" V(2)
"SPEC" Hs(10,4)
Cell: "POINT" [DISCH, VELO, SPEC]
Group: "MODEL" (100, 50, 12) of type POINT
Option B
Elements: "DISCH" Q(100)
"VELO" V(100,2)
"SPEC" Hs(100,10,4)
Cell: "CROSS-SECTION" [DISCH, VELO, SPEC]
Group: "MODEL" (50, 12) of type CROSS-SECTION
Option C
Elements: "DISCH" Q(100,50)
"VELO" V(100,50,2)
"SPEC" Hs(100,50,10,4)
Cell: "AREA" [DISCH, VELO, SPEC]
Group: "MODEL" (12) of type AREA
The most important criterion when selecting one of the three possibilities is:
in which units data will need to be accessed subsequently (the larger the units, the better
the performance) and in which units the data is available. The smallest unit which can be
accessed is an element.
Deltares 39 of 60
DRAFT
NEFIS Library, User Manual
40 of 60 Deltares
DRAFT
B Error/Warning numbers
Nr Error/Warning description
1001 —
1002 Crenef: Data filename too long ( length <%d )
1003 Crenef: Definition filename too long ( length <%d )
1004 Gethdt: Supplied character string too small for header
1005 Gethdt: Unable to read data file header (file write only?)
1006 Gethdt: During reading of data file header
1007 Gethdf: Supplied character string too small for header
1008 Gethdf: Unable to read definition file header (file write only?)
1009 Gethdf: During reading of definition file header
1010 —
1011 Inqcel: User supplied array too small to contain Cell properties: ’%s’ %ld>%ld
1012 Inqelm: User supplied array too small to contain Element properties: ’%s’
%ld>%ld
1013 Inqfcl: User supplied array too small to contain Cell properties: ’%s’ %ld>%ld
1014 Inqncl: User supplied array too small to contain Cell properties: ’%s’ %ld>%ld
1015 Inqfgr: User supplied array too small to contain group properties: ’%s’ %ld>%ld
1016 Inqngr: User supplied array too small to contain group properties: ’%s’ %ld>%ld
1019 Putiat: Groupname ’%s’ or integer attribute name ’%s’ too long
1020 Putrat: Groupname ’%s’ or real attribute name ’%s’ too long
1021 Putsat: Groupname ’%s’ or real attribute name ’%s’ or attribute value ’%s’ too
long
2001 —
2002 Crenef: Data filename too long ( length < %d )
2003 Crenef: Definition filename too long ( length < %d )
2004 Gethdt: Supplied character string too small for header
2005 Gethdt: Unable to read data file header (file write only?).
2006 Gethdt: During reading of data file header.
2007 Gethdf: Supplied character string too small for header
2008 Gethdf: Unable to read definition file header (file write only?).
2009 Gethdf: During reading of definition file header.
2010 —
2011 Getsat: User supplied attribute string too small
2012 Inqcel: Supplied array too small to contain all element names: ’%s’ %ld>%d
2013 Inqcel: User supplied array too small to contain Cell properties: ’%s’ %ld>%ld
2014 Inqdat: User supplied array to store group definition too small
2015 Inqelm: User supplied array’s to store element definition too small: %s, %ld, %ld,
%ld, %ld,%ld
2016 Inqelm: Element name ’%s’ too long
2017 Inqelm: User supplied array to contain element names too small
2018 Inqfst: User supplied array to contain names too small
2019 Inqelm: User supplied array’s to store element definition too small
2020 Inqfel: User supplied array to contain element names too small
2021 Inqelm: User supplied array’s to store element definition too small
2022 Inqfel: User supplied array to contain element names too small
2023 Inqfcl: Supplied array too small to contain all element names: ’%s’ %ld>%d
2024 Inqfcl: User supplied array too small to contain Cell properties: ’%s’ %ld>%ld
2025 Inqfcl: Supplied array too small to contain all element names: ’%s’ %ld>%d
2026 Inqncl: User supplied array too small to contain Cell properties: ’%s’ %ld>%ld
2027 Inqfgr: User supplied array to contain names too small
2028 Inqfgr: User supplied array too small to contain group properties: ’%s’ %ld>%ld
Deltares 41 of 60
DRAFT
NEFIS Library, User Manual
Nr Error/Warning description
2029 Inqfgr: User supplied array to contain names too small
2030 Inqngr: User supplied array too small to contain group properties: ’%s’ %ld>%ld
2031 Inqfia: User supplied array to contain integer attribute names too small
2032 Inqfra: User supplied array to contain real attribute names too small
2033 Inqfsa: User supplied array to contain string attribute names too small
2034 Inqgrp: Group name too long ’%s’
2035 Inqgrp: User supplied array to contain group dimensions too small
2037 Inqnxt: User supplied array to contain names too small
2038 Inqnia: User supplied array to contain integer attribute names too small
2039 Inqnra: User supplied array to contain real attribute names too small
2040 Inqnra: User supplied array to contain string attributes (name/value) too small
2042 Putiat: Groupname ’%s’ or integer attribute name ’%s’ too long
2043 Putrat: Groupname ’%s’ or real attribute name ’%s’ too long
2044 Putsat: Groupname ’%s’ or string attribute name ’%s’ or attribute value ’%s’ too
long
3001 Start value user index [%ld,2]=%ld should be smaller than [%ld,2]=%ld
3002 Increment value user index [%ld,2]=%ld should be greater than 0
3003 Start value user index [%ld,0]=%ld should be greater than zero
3004 Stop value %ld should be smaller than %ld
3005 Buffer length too small, should be %ld instead of %ld Group "%s", element "%s"
3006 Variable dimension %ld not found for: group "%s", element "%s"
4001 Start value user index [%ld,2]=%ld should be smaller than [%ld,2]=%ld
4002 Increment value user index [%ld,2]=%ld should be greater than 0
4003 Start value user index [%ld,0]=%ld should be greater than zero
4004 Stop value %ld should be smaller than %ld
5001 Number of dimensions not within the range [1,%d] Element ’%s’ has dimension
%ld
5002 This size of real (%ld) is not supported
5003 This size of integer (%ld) is not supported
5004 This size of complex (%ld) is not supported
5005 This size of logical (%ld) is not supported
5006 This element type is not supported ’%s’
5007 Element ’%s’ already exists
5008 Error writing element ’%s’ to definition file
5009 Element ’%s’ does not exist
5010 Cel ’%s’ already exists
5011 Error writing cel ’%s’ to definition file
5012 —
5013 Cel ’%s’ does not exist
5014 Group ’%s’ already exists.
5015 Error on writing group ’%s’ to definition file.
5016 Number of dimensions not within the range [1,MAX_DIM] Group ’%s’
5017 Group definition ’%s’ does not exist.
5018 Cel ’%s’ does not exist.
5019 Data group ’%s’ already exists in data file
5020 Error on writing group ’%s’ with variable dimension.
5021 Error on writing group ’%s’ with fixed dimension
5022 Error on writing group ’%s’ with variable dimension.
5023 Error on writing group ’%s’ with fixed dimension
5024 Maximum size reached in DataDefinition file "%s"
42 of 60 Deltares
DRAFT
Error/Warning numbers
Nr Error/Warning description
5025 Maximum size reached in definition file "%s"
5026 Maximum size reached in definition file "%s"
5027 Maximum size reached in definition file "%s"
5028 Maximum size reached in definition file "%s"
5029 Maximum size reached in definition file "%s"
5030 Maximum size reached in DataDefinition file "%s"
5031 Maximum size reached in definition file "%s"
6001 Hashtable not written to data file ’%s’
6002 Hashtable not written to definition file ’%s’
6002 Hashtable not written to DefinitionData file ’%s’
6003 Cell ’%s’ does not exist in definition file
6004 Group ’%s’ does not exist in data file
6005 Element ’%s’ does not exist in definition file
6006 —
6007 Group ’%s’ does not exist in definition file
6008 —
6009 On reading attribute of group ’%s’
6010 No space left in data file for integer attribute of group ’%s’
6011 No space left in data file for real attribute of group ’%s’
6012 No space left in data file for string attribute of group ’%s’
6013 Group ’%s’ does not exist in data file
6014 On reading attribute of group ’%s’
6015 Integer attribute ’%s’ of group ’%s’not found
6016 No valid attribute name found
6017 Real attribute ’%s’ of group ’%s’not found
6018 No valid attribute name found
6019 String attribute ’%s’ of group ’%s’not found
6020 No valid attribute name found
-6021 No more data groups available in DefinitonData file ’%s’
No data groups available in DefinitonData file ’%s’
-6022 No more data groups available in data file ’%s’
No data groups available in data file ’%s’
-6023 No more elements available in DefinitionData file ’%s’
No elements available in DefinitionData file ’%s’
-6024 No more elements available in definition file ’%s’
No elements available in definition file ’%s’
-6025 No more cells available in DefinitionData file ’%s’
No cells available in DefinitionData file ’%s’
-6026 No more cells available in definition file ’%s’
No cells available in definition file ’%s’
-6027 No more defined groups available in DefinitionData file ’%s’
No defined groups available in DefinitionData file ’%s’
-6028 No more defined groups available in definition file ’%s’
No defined groups available in definition file ’%s’
6029 On reading first variable pointer table
6030 On reading variable pointer table, table %ld
6031 On reading variable pointer table, table %ld
6032 On reading variable pointer table, table %ld
6033 Maximum size reached in DataDefinition file
6034 Maximum size reached in data file
7001 No entry found in hash table for key ’%s’
Deltares 43 of 60
DRAFT
NEFIS Library, User Manual
Nr Error/Warning description
7002 Unable to read next pointer (file write only?)
7003 During reading of next pointer
7004 During reading of cell structure
7005 During reading of element structure
7006 During reading of group structure
7007 During reading of data structure
8001 Data file ’%s’ has already been opened
8002 Definition file ’%s’ has already been opened
8003 Maximum number (=%d) of open files has been achieved
8004 Header was not written to data file ’%s’
8005 Hashtable was not written to data file ’%s’
8006 Hashtable was not written to data file ’%s’
8007 Unable to access data file ’%s’
8008 During reading header of data file ’%s’
8009 File ’%s’ is not a NEFIS data file
8010 During reading hashtable of data file ’%s’
8011 Unable to write header of definition file ’%s’
8012 Unable to write hashtable of definition file ’%s’
8013 Unable to write hashtable of definition file ’%s’
8014 Unable to access definition file ’%s’
8015 during reading header of definition file ’%s’
8016 File ’%s’ is not a NEFIS definition file
8017 On reading hashtable of definition file ’%s’
8018 Unable to write header of DefinitionData file ’%s’
8019 Unable to write hashtable of DefinitionData file ’%s’
8020 Unable to write hashtable of DefinitionData file ’%s’
8021 Unable to access DefinitionData file ’%s’
8022 during reading header of DefinitionData file ’%s’
8023 File ’%s’ is not a NEFIS DefinitionData file
8024 On reading hashtable of DefinitionData file ’%s’
8025 Unable to close data file ’%s’
8026 Unable to close definition file ’%s’
8027 Unable to close DefinitionData file ’%s’
8028 —
8029 File ’%s’ can not be opened with unsupported NEFIS access type ’%c’
8030 Cannot open file ’%s’ for access type ’%c’
8031 File ’%s’ can not be opened as read only
9001 The variable MAX_VAR_GROUPS needs to be increased. Contact Deltares |
Delft Hydraulics
9002 Element "%s" of group "%s" not found on file "%s"
10001 This size of integer (%d) is not supported
10002 This size of real (%d) is not supported
10003 This size of character (!=1) is not supported
10004 This size of complex (%d) is not supported
10005 This size of logical (%d) is not supported
10006 This element type is not supported ’%s’
44 of 60 Deltares
DRAFT
C Demonstration programs
Two demonstration programs are appended, DEMO_01 and DEMO_02. DEMO_01 partic-
ularly demonstrates how the stored and retrieved sequences can be handled. The program
uses the file DEMO_01.INP and generates the definition file (DEMO_01.DEF) and the data file
(DEMO_01.DAT). The program DEMO_01 is the example mentioned earlier (see Examples
option A). The measurement data is defined as:
velocity
depth 1: 1000×location number+10×time+1
depth 2: 1000×location number+10×time+2
depth 3: 1000×location number+10×time+3
depth
1000×location number + 10×time + 4
Program DEMO_02 shows an example of how variable dimensions are handled and also
demonstrates how easy it is to use only the relevant part of available data. This program does
not need an input file.
C.1 Demonstration program 1
program demo01
implicit none
!
! Company name : Deltares | Delft Hydraulics
! P.O.Box 177
! 2600 MH Delft
! The Netherlands
! DESCRIPTION :
!
! This program demonstrates how the NEFIS functions can be used
! to write data to a NEFIS file, and how this data can be
! retrieved again from the same file.
!
!=======================================================================
! ..
! .. Local Scalars ..
!
character*1024 errstr ! character string to catch the nefis error message
character coding*1 ! indicates y/n neutral representation of data
integer :: dummy ! dummy parameter in function calls
integer :: error ! contains return-value of nefis functions
integer :: i ! loop control variabel, array index
integer :: j ! loop control variabel, array index
integer :: k ! loop control variabel, array index
integer :: obsfil ! unitnumber of user’s observation file
!
! .. local arrays ..
!
character elmnms(2)*14 ! cell element names
integer :: fds ! nefis file descriptor
integer :: grpdms(5) ! dimensions of data group to define
integer :: grpord(5) ! order information of data group to define
integer :: usrord(5) ! ordering information of user data
integer :: usrind(3,5) ! ordering information of user data
real :: veloctiy(3,4) ! array to contain velocity-element info of 4 points
integer :: depth(12) ! array to contain depths
integer :: obsdat(4,100,10) ! .. array to contain observed data
! ..
! .. external functions ..
Deltares 45 of 60
DRAFT
NEFIS Library, User Manual
!
integer :: crenef ! nefis-function: open a data and definition file
integer :: defelm ! nefis-function: define an element
integer :: defcel ! nefis-function: define a cell
integer :: defgrp ! nefis-function: define a group
integer :: credat ! nefis-function: create space for data on data file
integer :: putelt ! nefis-function: write data of 1 or more elements
!
! .. to data file
!
integer :: getelt ! nefis-function: retrieve data of 1 or more
!
! .. elements from data file
!
integer :: clsnef ! nefis-function: close a data and definition file
!
!=======================================================================
!
obsfil = 11
coding = ’b’ ! let us write the data to a big endian format
rdwr = ’c’ ! create a nefis file set
! ..
write(*,’(’’Demo_01: Open NEFIS data and definition file’’)’)
error = crenef(fds, ’data_d01.def’, ’data_d01.def’, coding, rdwr)
if (error /= 0) goto 9999
!=======================================================================
!
! FIRST, LET’S DEFINE SOME ELEMENTS
!
! DEFINE A 1 DIMENSIONAL ELEMENT OF 3 REALS,
! NAMED: MEAN VELOCITY
!
write(*,’(’’demo_01: Define ELEMENT: MEAN VELOCITY (3)’’)’)
error = defelm (fds, ’MEAN VELOCITY’, ’REAL’, 4, &
’VELOCITY’, ’[M/S]’, &
’Mean velocity in centre of river at ’ // &
’3 different levels’, 1, 3)
IF (ERROR /= 0) GOTO 9999
!
! DEFINE A (0 DIMENSIONAL) ELEMENT OF 1 REAL,
! NAMED: WATERDEPTH
!
write(*,’(’’demo_01: Define ELEMENT: WATERDEPTH’’)’)
dummy = 1
error = defelm (fds, ’WATERDEPTH’, ’REAL’, 4, ’DEPTH’, &
’[M]’, ’DEPTH AT CENTRE OF RIVER’, 1, dummy)
if (error /= 0) goto 9999
!
! LET’S DEFINE A CELL TO CONTAIN OBSERVATIONS AT A
! CERTAIN POINT AND A CERTAIN PLACE,
! NAMED: OBSERVATION
!
elmnms(1) = ’MEAN VELOCITY’
elmnms(2) = ’WATERDEPTH’
write(*,’(’’demo_01: Define CELL: ’’, &
’’OBSERVATION = MEAN VELOCITY + WATERDEPTH’’)’)
error = defcel(fds, ’OBSERVATION’, 2, elmnms)
if (error /= 0) goto 9999
!
! DEFINE A GROUP FOR 10 DIFFERENT LOCATIONS,
! ABLE TO CONTAIN 100 OBSERVATIONS (TIME SERIES)
! FOR EACH LOCATION, NAMED: RIVER DATA
!
grpdms(1) = 100 ! MAX. 100 OBSERVATIONS FOR EACH LOCATION
grpdms(2) = 10 ! MAX. 10 LOCATIONS
grpord(1) = 2
46 of 60 Deltares
DRAFT
Demonstration programs
grpord(2) = 1
!
! CELLS WILL BE STORED IN THE FILE IN THE ORDER:
! (1,1), (1,2) ..... (1,10), (2,1), (2,2).... ETC.
!
write(*,’(’’demo_01: Define GROUP:’’, ’’ RIVERDATA = OBSERVATION (100,10)’’)’)
error = defgrp (fds, ’RIVERDATA’, ’OBSERVATION’, 2, grpdms, grpord)
!
if (error /= 0) goto 9999 ! END OF DEFINITION PART
!
!=======================================================================
!
! NOW, LET’S CREATE SPACE ON THE DATA FILE FOR
! RED RIVER DATA
!
write(*,’(’’demo_01: Create space for data labelled: RED RIVER,’’, &
’’ using THE RIVERDATA GROUP DEFINITION’’)’)
error = credat (fds, ’RED RIVER’, ’RIVERDATA’)
if (error /= 0) goto 9999
!
! NOW, READ ALL FIELD OBSERVATIONS FROM A FILE
!
write(*,’(’’demo_01: Read observation data from input file’’, &
’’ (not a NEFIS action)’’)’)
!
open (obsfil,file=’observ.inp’)
do i = 1, 10
read (obsfil,*)
do j = 1, 100
read (obsfil,*) (obsdat(k,j,i), k=1,4) ! VELOCITIES AND WATERDEPTH AT LOCATION I, TIME J
enddo
enddo
close (obsfil)
!=======================================================================
!
! OBSERVATIONS CAN BE WRITTEN TO THE NEFIS DATA FILE
! FOR EXAMPLE CELL AFTER CELL
!
usrord(1) = 1
usrord(2) = 2
!
! THIS IS THE FORTRAN ORDER, IE.:
! (1,1), (2,1) .. (100,1), (1,2), (2,2) .. ETC.
!
! write(*,’(’’demo_01: Write DATA to NEFIS file, ONE cell at a time’’)’)
! do 40 i = 1, 100
! do 30 j = 1, 10
! usrind(1,1) = i
! usrind(2,1) = i
! usrind(3,1) = 1
! usrind(1,2) = j
! usrind(2,2) = j
! usrind(3,2) = 1
! usrind(1,3) = 3
! usrind(2,3) = 3
! usrind(3,3) = 3
! usrind(1,4) = 4
! usrind(2,4) = 4
! usrind(3,4) = 4
! usrind(1,5) = 5
! usrind(2,5) = 5
! usrind(3,5) = 5
! write(*,’(’’demo_01: Data: ’’,i8)’) OBSDAT(4,I,J)
! error = putelt (fds, ’RED RIVER’, ’WATERDEPTH’, usrind, usrord, obsdat(4,i,j))
! if (error /= 0) goto 9999
! enddo
Deltares 47 of 60
DRAFT
NEFIS Library, User Manual
! enddo
! write(*,’(’’demo_01: RED RIVER written in [sec]’’,1PE13.5)’) cpu2-cpu1
!
! OR ALL CELLS TOGETHER (10*100 CELLS)
!
usrind(1,1) = 1
usrind(2,1) = 100
usrind(3,1) = 1
usrind(1,2) = 1
usrind(2,2) = 10
usrind(3,2) = 1
!
! INDEX OF FIRST CELL TO STORE INFORMATION TO
!
usrord(1) = 1
usrord(2) = 2
!
! .. THIS IS THE FORTRAN ORDER, IE.:
! (1,1), (2,1) .. (100,1), (1,2), (2,2) .. ETC.
!
write(*,’(’’demo_01: Write the DATA, all cells at ONE go’’)’)
error = putelt (fds, ’RED RIVER’, ’*’, usrind, usrord, obsdat)
IF (ERROR /= 0) GOTO 9999
!
! ALL DATA IS NOW STORED ON THE NEFIS DATA FILE
!
!=======================================================================
!
! LET’S DO SOME RETRIEVAL
!
! LET’S RETRIEVE THE VELOCITIES FROM LOCATIONS
! 6-9 AT TIME 54, IE. FROM
! CELLS (54,6), (54,7), (54,8) AND (54,9).
! THE PERFORMANCE WILL BE RATHER GOOD, BECAUSE THE
! DATA ON THE NEFIS DATA FILE IS WRITTEN IN THIS
! ORDER (SEE DEFGRP).
!
usrind(1,1) = 6
usrind(2,1) = 9
usrind(3,1) = 1
usrind(1,2) = 54
usrind(2,2) = 54
usrind(3,2) = 1
!
usrord(1) = 2
usrord(2) = 1
!
! MEANS: FROM CELL (54,6), (54,7), (54,8) AND (54,9)
!
write(*,’(’’demo_01: Start retrieval’’)’)
Error = getelt (fds, ’RED RIVER’,’MEAN VELOCITY’, &
usrind, usrord, 48, velocity)
if (error /= 0) goto 9999
! ..
write(*,’(’’demo_01: Velocities at time 54’’)’)
doi=1,4
write (*,’(a,i2,’’:’’,3f8.1)’) ’ Location ’, i+5, (velocity(j,i), j=1,3)
enddo
!
! NOW, RETRIEVE AT LOCATION 7 THE WATERDEPTHS FROM
! TIME 35-46
!
usrind(1,1) = 7
usrind(2,1) = 7
usrind(3,1) = 1
usrind(1,2) = 35
48 of 60 Deltares
DRAFT
Demonstration programs
usrind(2,2) = 46
usrind(3,2) = 1
!
usrord(1) = 2
usrord(2) = 1
!
! MEANS: FROM CELL (35,7), (36,7), (37,7) .... (46,7)
!
error = getelt (fds, ’RED RIVER’, ’WATERDEPTH’, &
usrind, usrord, 48, depth)
if (error /= 0) goto 9999
! ..
write (*,’(’’demo_01: Waterdepths at location 7’’)’)
do i = 1, 12
write (*,’(a,i2,’’:’’,f8.1)’) ’ Time ’, i+34, depth(i)
enddo
!=======================================================================
!
! close the NEFIS files
!
write(*,’(’’demo_01: Close the NEFIS files’’)’)
error = clsnef (fds)
!
9999 continue
!
error = neferr( 0, errstr)
write(*,’(a)’) trim(errstr)
write(*,*)
write(*,’(’’demo_01: End of demonstration’’)’)
end program
C.2 Demonstration program 2
program demo_02
implicit none
!
! Company name : Deltares | Delft Hydraulics
! P.O.Box 177
! 2600 MH Delft
! The Netherlands
!------------------------------------------------------------------------------
! System: NEFIS
!
! $Header: /delft3d/libraries/nefis/demo/demo_02/demo_02.f 2 10/03/06 9:56 Mooiman $
!------------------------------------------------------------------------------
! Programmer : A. Hoekstra
! Project : NEutral FIle Structure
!------------------------------------------------------------------------------
!*************DESCRIPTION *************
!
! - This demo-program demonstrates the use of NEFIS store-
! and retrieval functions. Special is the use of a
! datagroup with a variable dimension.
!
! This program performs the following tasks:
! - create an element, cel and a 3-d group defintion
! - create a data group
! - store data in this group
! - retrieve data from this group, using a
! different view
! - retrieve data using a filter
!
! Note: the error-return code from the NEFIS-functions is
! not checked
!------------------------------------------------------------------------------
Deltares 49 of 60
DRAFT
NEFIS Library, User Manual
!
! Scalars
!
character*1024 errstr ! character string to catch the NEFIS error message
character coding*1 ! indicates Y/N neutral representation of data
character rdwr*1 ! indicates read write acces of the file
integer error ! contains return-value of NEFIS-functions
!
! Arrays
!
integer fds ! nefis file descriptor
!
! Declarations of NEFIS-functions
!
integer :: clsnef
integer :: credat
integer :: flsdat
integer :: crenef
integer :: neferr
!
! Executable statements
!
!
! Open a definition file
!
coding = ’L’
rdwr = ’c’
error = crenef (fds, ’data_d02.daf’, ’data_d02.daf’, coding, rdwr)
if (error /= 0) goto 9999
!
! Define element, cel, and group-definition
!
call define (fds)
!
! Create space for data
!
error = credat (fds, ’GrpNaam’, ’Groep’)
if (error /= 0) goto 9999
!
error = flsdat (fds)
if (error /= 0) goto 9999
!
! Write data to file
!
call putdat (fds)
!
! Retrieve data, using a different view
!
call dtview (fds)
!
! Retrieve a part of the data
!
call filter (fds)
!
! Close the files
!
9999 continue
!
if (error.eq.0) error = clsnef (fds)
!
error = neferr( 1, errstr)
!
end program
!================================================================================
subroutine define (fds)
implicit none
50 of 60 Deltares
DRAFT
Demonstration programs
!
integer fds
!
integer error
character*134 errstr
!
integer :: grpdms(5)
integer :: grpord(5)
!
integer :: defcel
integer :: defelm
integer :: defgrp
integer :: flsdef
integer :: neferr
!
! Executable statements
!
! Define a simple element, type Real*4
!
error = defelm (fds, ’ElmName’, ’Integer’, 4, &
’ElmQuantity’, ’ElmUnity’, ’ElmDescription’, &
1, 1)
if (error /= 0) goto 9999
!
! Define a cel with only one real value
!
error = defcel (fds, ’Cell’, 1, ’ElmName’)
if (error /= 0) goto 9999
!
! Define a 3-d group of dimension (3,5,0),
! so a group with a variable dimension
!
grpdms(1) = 3
grpdms(2) = 5
grpdms(3) = 0
grpord(1) = 1
grpord(2) = 3
grpord(3) = 2
error = defgrp (fds, ’Groep’, ’Cell’, 3, grpdms, grpord)
if (error /= 0) goto 9999
!
! Flush buffers to file
!
error = flsdef (fds)
if (error /= 0) goto 9999
!
9999 continue
error = neferr( 1, errstr)
end subroutine
!================================================================================
subroutine putdat (fds)
implicit none
!
character*1024 errstr
!
integer fds
!
integer start, stop, incr
parameter (start=1, stop=2, incr=3)
equivalence(aarray,array)
!
character :: space*7
integer :: col
integer :: error
integer :: plane
integer :: row
Deltares 51 of 60
DRAFT
NEFIS Library, User Manual
integer :: uindex(3,5)
integer :: usrord(5)
integer :: array (3,5,7)
integer :: aarray (105)
!
integer :: flsdat
integer :: putelt
integer :: neferr
!
! Executable statements
!
space = ’ ’
!
! Set view to (3,5,*)
!
usrord (1) = 1
usrord (2) = 2
usrord (3) = 3
!
! Define indices for each dimension
!
uindex (start,1) = 1
uindex (stop ,1) = 3
uindex (incr ,1) = 1
uindex (start,2) = 1
uindex (stop ,2) = 5
uindex (incr ,2) = 1
uindex (start,3) = 1
uindex (stop ,3) = 7
uindex (incr ,3) = 1
!
! Fill array with values
!
do plane = 1,7
do col = 1,5
do row = 1,3
array (row, col, plane) = row*1000+col*100+plane
enddo
enddo
enddo
!
! Write data to file
!
error = putelt (fds, ’GrpNaam’, ’*’ ,uindex, usrord, array)
if (error /= 0) goto 9999
!
! Flush the buffers
!
error = flsdat (fds)
if (error /= 0) goto 9999
!
! Output data to screen
!
write(*,’(’’ ARRAY(3,5,7) written to file:’’)’)
do plane = 1,7
do col = 1,5
write (*,’( 3i10)’) (array(row,col,plane),row=1,3)
enddo
write (*,*)
enddo
!
9999 continue
error = neferr( 1, errstr)
end subroutine
!================================================================================
subroutine dtview (fds)
52 of 60 Deltares
DRAFT
Demonstration programs
implicit none
!
character*1024 errstr
!
integer :: fds
!
integer :: start, stop, incr
parameter (start=1, stop=2, incr=3)
!
character :: space*7
integer :: col
integer :: error
integer :: plane
integer :: row
integer :: uindex(3,5)
integer :: usrord(3)
integer :: array (7,3,5)
!
integer :: getelt
integer :: neferr
!
! Executable statements
!
space = ’ ’
!
! Change view to (*,3,5)
!
usrord (1) = 3
usrord (2) = 1
usrord (3) = 2
!
! define indices for each dimension
!
uindex (start,1) = 1
uindex (stop ,1) = 7
uindex (incr ,1) = 1
uindex (start,2) = 1
uindex (stop ,2) = 3
uindex (incr ,2) = 1
uindex (start,3) = 1
uindex (stop ,3) = 5
uindex (incr ,3) = 1
!
! Retrieve data
!
error = getelt (fds, ’GrpNaam’, ’*’ ,uindex, usrord, 7*3*5*4, array)
if (error /= 0) goto 9999
!
! Output data to screen
!
write(*,’(’’ Same values now retrieved in ARRAY(7,3,5)’’)’)
do plane = 1,5
do col = 1,3
write (*,’( 7i10 )’) (array(row,col,plane),row=1,7)
enddo
write (*,*)
enddo
!
9999 continue
error = neferr( 1, errstr)
end subroutine
!================================================================================
subroutine filter (fds)
implicit none
!
character*1024 errstr
Deltares 53 of 60
DRAFT
NEFIS Library, User Manual
!
integer :: fds
!
integer :: start, stop, incr
parameter (start=1, stop=2, incr=3)
!
character :: space*7
integer :: col
integer :: error
integer :: plane
integer :: row
integer :: uindex(3,5)
integer :: usrord(3)
integer :: array (4,2,3)
!
integer :: getelt
integer :: neferr
!
! Executable statements
!
space = ’ ’
!
! Change view to (*,3,5)
!
usrord (1) = 3
usrord (2) = 1
usrord (3) = 2
!
! Define indices and step for each dimension
! The stepsize of 2 creates a filter
!
uindex (start,1) = 1
uindex (stop ,1) = 7
uindex (incr ,1) = 2
uindex (start,2) = 1
uindex (stop ,2) = 3
uindex (incr ,2) = 2
uindex (start,3) = 1
uindex (stop ,3) = 5
uindex (incr ,3) = 2
!
! Retrieve data
!
error = getelt (fds, ’GrpNaam’, ’*’, uindex, usrord, 4*2*3*4, array)
if (error /= 0) goto 9999
!
! Output data to screen
!
write(*,’(’’ Every other value retrieved in ARRAY(4,2,3)’’)’)
do plane = 1,3
do col = 1,2
write (*,’( 4i10 )’) (array(row,col,plane),row=1,4)
enddo
write (*,*)
enddo
!
9999 continue
error = neferr( 0, errstr)
write(*,’(a)’) trim(errstr)
end subroutine
54 of 60 Deltares
DRAFT
D Release notes
D.1 Differences between Version 5.00 and 4.00
NEFIS5 support file sizes up to 264 −1byte. The internal pointers to the data on the file is
64-bits, these pointers are also written to the NEFIS-file. As a consequence the files made
by NEFIS5 and NEFIS4 are not compatible. The Application Programming Interface (API) is
compatible with NEFIS4. NEFIS5 will read NEFIS4 data, and if necessary NEFIS5 will write
32-bit data to an existing NEFIS4 file. New files will always be a NEFIS5 file.
D.2 Differences between Version 4.00 and 3.10
D.2.1 Improvements
The following improvements are obtained:
Access For reading a NEFIS files no write access is needed.
One file If the same name for the data and the definition file is used, one
NEFIS file is created. That NEFIS files has the same perfor-
mance and usability as when using two files.
Variable dimension The performance to retrieve data from a group with variable di-
mension is highly improved.
Elements The performance for cells containing more than 40 elements is
highly improved.
Qdblok3 The object qdblok3 is not needed anymore. This object con-
tained a separated data block (Fortran: Data Block), which was
separately compiled. The data is now integrated into the NEFIS
library.
D.2.2 New functions
The following function are added to NEFIS version 4.00:
Name Definition
Crenef Open or create a NEFIS file set at once, you have to supply the ac-
cess type of the files. So, for post-processing the "read" permission is
enough to make graphs.
Clsnef Close the NEFIS file set. Depending on the access type the buffer will
be written to file or not.
Getels For all architectures the function Getels is added. This function reads
one or all string elements from the data file.
Neferr NEFIS error function to retrieve more sensible error messages.
Putels For all architectures the function Putels is added. This function writes
one or more character elements to the data file
Inqfcl/Inqncl Reading first and next cell definition from the definition file
Inqfel/Inqnel Reading first and next element definition from the definition file
Inqfgr/Inqngr Reading first and next group definition from the definition file
Deltares 55 of 60
DRAFT
NEFIS Library, User Manual
D.2.3 Outdated functions
The next functions are still available in NEFIS but are not supported anymore:
Name Definition
Cldfnf Close the definition file without flushing the buffer (timestamp does not change
due to this function).
Cldtnf Close the data file without flushing the buffer (timestamp does not change due
to this function).
Clsdat Flush buffers to the data file and close that file.
Clsdef Flush buffers to the definition file and close that file.
Opndat Create or open a NEFIS data file.
Opndef Create or open a NEFIS definition file.
D.2.4 Unavailable functions
The following functions are not available anymore within this version NEFIS.
Name Definition
Getelm Replaced by function Getelt.
Putelm Replaced by function Putelt.
D.3 Differences between Version 3.10 and 3.00
D.3.1 Improvements
Two functions are added to the library, which avoid changing the time stamp of the NEFIS
files. These functions can only be used when reading data from file, if also data is written to
file then the function Clsdat and Clsdef have to be used.
D.3.2 New functions
The following functions are added to NEFIS version 3.10:
Name Definition
Cldfnf Does NOT write buffers to the definition file and close the file (consequence:
timestamp does not change).
Cldtnf Does NOT write buffers to the definition file and close the file (consequence:
timestamp does not change).
D.4 Differences between Version 3.00 and 2.00
D.4.1 Improvements
Performance improvement for reading and writing data to the files when using the functions
PUTELT and GETELT. The improvement depends on the chosen structure. Depending on
the structure the performance reach from several percents to factors (upto factor 13 in some
tests).
56 of 60 Deltares
DRAFT
Release notes
D.4.2 New functions
The following functions are added to NEFIS version 3.00:
Name Definition
Getelt Replaces the GETELM function. GETELT outperforms GETELM which is now
outdated. The GETELM and GETELT functions can be used interchangeable
for data groups without variable dimension.
Gethdf This function gives information from the header of a NEFIS definition file.
Gethdt Give information from the header of a NEFIS data file.
Inqfia Give the first name and value of an integer attribute of a data group.
Inqfra Like INQFIA, but here for the real attributes.
Inqfsa Like INQFIA, but here for the real attributes.
Inqmxi Give the maximum used index of the free dimension of a data group.
Inqnia This function gives the next name and value of an integer attribute of a data
group (see INQFIA function).
Inqnra Like INQNIA, but here for the real attributes.
Inqnsa Like INQNIA, but here for the real attributes.
Putelt Outperforms PUTELM and replaces it. As a result, PUTELM is considered to
be outdated. However, PUTELM and PUTELT can be used interchangeable
for data groups without variable dimension.
D.4.3 Outdated functions
The next functions are still available in NEFIS but are not supported anymore:
Name Definition
Getelm Replaced by function Getelt.
Putelm Replaced by function Putelt.
Deltares 57 of 60
DRAFT
NEFIS Library, User Manual
58 of 60 Deltares
DRAFT
PO Box 177
2600 MH Del
Rotterdamseweg 185
2629 HD Del
The Netherlands
+31 (0)88 335 81 88
sales@deltaressystems.nl
www.deltaressystems.nl
DRAFT

Navigation menu
