Neutron Engineering Inc.
Report No.: NEI-ETSP-2-0909C206 Page 1 of
6
EN 62311 TEST REPORT
Issued Date : Jan. 19, 2010
Report No. : 0909C206
Equipment : 3G Portable Router with Battery
Model Name : 3G-6210N; 3G-210N
Applicant : EDIMAX TECHNOLOGY CO., LTD.
Address : No. 3, Wu Chuan 3rd Road, Wu-Ku
Industrial Park. Taipei Hsien, Taiwan
Tested by:
Neutron Engineering Inc. EMC Laboratory
Date of Test:
Nov. 13, 2009 ~ Nov. 24, 2009
Testing Engineer :
(Rush Kao)
Technical Manager :
(Jeff Yang)
Authorized Signatory :
(Andy Chiu)
Neutron Engineering Inc.
B1, No. 37, Lane 365, YangGuang St.,
NeiHu District 114, Taipei, Taiwan.
TEL: +886-2-2657-3299
FAX: +886-2-2657-3331
Neutron Engineering Inc.
Report No.: NEI-ETSP-2-0909C206 Page 2 of
6
1. CERTIFICATION
Equipment : 3G Portable Router with Battery
Brand Name : EDIMAX
Model Name : 3G-6210N; 3G-210N
A p p l i c a n t : EDIMAX TECHNOLOGY CO., LTD.
Date of Test : Nov. 13, 2009 ~ Nov. 24, 2009
Standards : EN 62311:2008
The above equipment has been tested and found compliance with the requirement of the relative
standards by Neutron Engineering Inc. EMC Laboratory.
The test data, data evaluation, and equipment configuration contained in our test report (Ref No.
NEI-ETSP-2-0909C206) were obtained utilizing the test procedures, test instruments, test sites
that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality
assessment standard and technical standard(s).
Neutron Engineering Inc.
Report No.: NEI-ETSP-2-0909C206 Page 3 of
6
2. GENERAL INFORMATION
2.1 GENERAL DESCRIPTION OF EUT
Equipment 3G Portable Router with Battery
Trade Name EDIMAX
Model Name 3G-6210N; 3G-210N
OEM Brand/Model Name Airlive/Traveler 3G
Intellinet/524803
PCI/ CQW-MRB
Model Difference
Models’ differences between each other only the changes of
model name which do not affect the EMI performance.
Model 3G-6210N was used for final testing and collecting
test data included in this report.
Product Description
The EUT is 3G Portable Router with Battery.
Operation Frequency: 2412~2472 MHz
Modulation Type: 802.11b:CCK, DQPSK, DBPSK
802.11g:OFDM
802.11n:OFDM( 1 TX & 1 RX )
Bit Rate of Transmitter: 802.11b:
11/5.5/2/1 Mbps
802.11g:
54/48/36/24/18/12/9/6 Mbps
802.11n up to +150 Mbps
Number Of Channel Please see Note 2.
Antenna Designation: Please see Note 3.
Antenna Gain(Peak) Please see Note 3.
EIRP Power: 802.11b: 19.48 dBm (Max.)
802.11g: 19.59 dBm (Max.)
802.11n(20MHz): 19.63 dBm (Max.)
802.11n(40MHz): 19.71 dBm (Max.)
Based on the application, features, or specification exhibited
in User's Manual, the EUT is considered as an
ITE/Computing Device. More details of EUT technical
specification, please refer to the User's Manual.
Power Source Battery supplied & DC Voltage supplied from AC/DC adapter.
Power Rating
Battery: DC 3.7V, 1800mAh, 6.7Wh
AC/DC adapter:
I/P: AC 100-240V~300mA, 50-60Hz, 21-28VA / O/P: DC 5V,
2A MAX.
Connecting I/O Port(s) Please refer to the User's Manual
Products Covered Battery: TPZLIB-100
AC/DC adapter: PSAA10R-050(ED)-R
Note :
1. For a more detailed features description, please refer to the manufacturer’s specifications or
the User's Manual.
Neutron Engineering Inc.
Report No.: NEI-ETSP-2-0909C206 Page 4 of
6
2. CH 01 – CH 13 for 802.11b, 802.11g, 802.11n(20MHz)
CH 03 – CH 11 for 802.11n(40MHz)
Channel List
Channel Frequency
(MHz) Channel Frequency
(MHz) Channel Frequency
(MHz)
01 2412 06 2437 11 2462
02 2417 07 2442 12 2467
03 2422 08 2447 13 2472
04 2427 09 2452
05 2432 10 2457
3. Table for Filed Antenna
Ant. Brand Model Name Antenna Type Connector Gain (dBi)
1 N/A N/A Printed N/A 3.00
Neutron Engineering Inc.
Report No.: NEI-ETSP-2-0909C206 Page 5 of
6
3. MAXIMUM PERMISSIBLE EXPOSURE
3.1 Applicable Standard
According to its specifications, the EUT must comply with the requirements of the following
standards:
EN 62311 –Assessment of electronic and electrical equipment related to human exposure
restrictions for electromagnetic fields (0 Hz - 300 GHz)
LIMIT
For frequency range 10 MHz to 10 GHz
The basic restriction at frequencies between 10 MHz and 100 GHz is on localized SAR in the
head. Any device with output power below 20 mW cannot produce an exposure exceeding this
restriction under the most pessimistic exposure conditions. The basic restriction is 2 W/kg so any
unit which supplies less than 20 mW (=2/100W) from its antenna port, averaged over 6 minutes,
will meet the basic restriction.
For frequency range 10 GHz to 300 GHz
The most conservative assumption is that all the transmitted power is absorbed within the
specified area, therefore any device which supplies less than 20 mW will meet the basic
restriction. The average time is equal to 68/f-1.05 munutes (where f is in GHz) In the frequency
range 10 GHz to 300 GHz, the basic restriction is 10 Wm-2 averaged over any 20 cm2 of exposed
area with a spatial maximum of 200 Wm-2 averaged over 1 cm2
2 MPE Calculation Method
E (V/m) = (30*P*G) 0.5/d
E = Electric Field (V/m)
P = Peak RF output Power (W)
G = EUT Antenna numeric gain (numeric)
d = Separation distance between radiator and human body (m)
From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well
as the gain of the used antenna, the RF power density can be obtained.
Neutron Engineering Inc.
Report No.: NEI-ETSP-2-0909C206 Page 6 of
6
4. CALCULATED RESULT AND LIMIT
802.11 b mode (Max.)
Antenna
Gain
(dBi)
Peak output
Power
(dBm)
Peak output
Power (W)
Electric
Field
(V/m)
Limit of Electric
Field
(V/m)
Result
1.85 19.44 0.0879 8.12 61 Pass
802.11 g mode (Max.)
Antenna
Gain
(dBi)
Peak output
Power
(dBm)
Peak output
Power (W)
Electric
Field
(V/m)
Limit of Electric
Field
(V/m)
Result
1.85 18.62 0.0728 7.39 61 Pass
802.11 n(20MHz) mode (Max.)
Antenna
Gain
(dBi)
Peak output
Power
(dBm)
Peak output
Power (W)
Electric
Field
(V/m)
Limit of Electric
Field
(V/m)
Result
1.85 1 8.78 0.0755 7.53 61 Pass
802.11 n(40MHz) mode (Max.)
Antenna
Gain
(dBi)
Peak output
Power
(dBm)
Peak output
Power (W)
Electric
Field
(V/m)
Limit of Electric
Field
(V/m)
Result
1.85 18.15 0.0653 7.00 61 Pass
RF exposure assessment has been performed below to prove that this unit will not generate the
harmful EM emission above the reference level as specified in EC Council Recommendation
(1999/519/EC)
