DigitalPersona, Inc.
One Touch® for Windows® SDK
C/C++ Edition
Version 1.6
Developer Guide
DigitalPersona, Inc.
© 1996–2010 DigitalPersona, Inc. All Rights Reserved.
All intellectual property rights in the DigitalPersona software, firmware, hardware, and documentation included with or
described in this guide are owned by DigitalPersona or its suppliers and are protected by United States copyright laws,
other applicable copyright laws, and international treaty provisions. DigitalPersona and its suppliers retain all rights not
expressly granted.
DigitalPersona, U.are.U, and One Touch are trademarks of DigitalPersona, Inc., registered in the United States and other
countries. Adobe and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries. Microsoft, Visual C++, Visual Studio, Windows, Windows Server, and Windows Vista
are registered trademarks of Microsoft Corporation in the United States and other countries.
This guide and the software it describes are furnished under license as set forth in the “License Agreement” that is shown
during the installation process.
Except as permitted by such license or by the terms of this guide, no part of this document may be reproduced, stored,
transmitted, and translated, in any form and by any means, without the prior written consent of DigitalPersona. The
contents of this guide are furnished for informational use only and are subject to change without notice. Any mention of
third-party companies and products is for demonstration purposes only and constitutes neither an endorsement nor a
recommendation. DigitalPersona assumes no responsibility with regard to the performance or use of these third-party
products. DigitalPersona makes every effort to ensure the accuracy of its documentation and assumes no responsibility or
liability for any errors or inaccuracies that may appear in it.
Technical Support
Upon your purchase of a Developer Support package (available from http://buy.digitalpersona.com), you are entitled to a
specified number of hours of telephone and email support.
Feedback
Although the information in this guide has been thoroughly reviewed and tested, we welcome your feedback on any
errors, omissions, or suggestions for future improvements. Please contact us at
TechPubs@digitalpersona.com
or
DigitalPersona, Inc.
720 Bay Road, Suite 100
Redwood City, California 94063
USA
(650) 474-4000
(650) 298-8313 Fax
Document Publication Date: June 22, 2010 (1.6.0)8
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide iii
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Target Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Notational Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Typographical Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Online Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Supported DigitalPersona hardware Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fingerprint Template Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Quick Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connect the Fingerprint Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the Sample Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installing the SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installing the Runtime Environment (RTE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing and Uninstalling the RTE Silently . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Biometric System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fingerprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fingerprint Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fingerprint Enrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fingerprint Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
False Positives and False Negatives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Components of the SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Device Component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Clean-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Fingerprint Recognition Component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Fingerprint Enrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
DigitalPersonaOne Touch for Windows SDK: C/C++ Edition | Developer Guide iv
Table of Contents
Typical Fingerprint Enrollment Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Fingerprint Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Typical Fingerprint Verification Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5 Core API Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Device Functions List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Extraction Functions List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Matching Functions List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Device Functions Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DPFPBufferFree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DPFPCreateAcquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DPFPDestroyAcquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
DPFPEnumerateDevices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
DPFPGetDeviceInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
DPFPSetDeviceParameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
DPFPGetDeviceParameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DPFPGetVersion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
DPFPInit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
DPFPStartAcquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
DPFPStopAcquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
DPFPTerm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Extraction Functions Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
FX_init . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
FX_getVersionInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
FX_createContext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
FX_closeContext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
FX_terminate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
FX_getFeaturesLen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
FX_extractFeatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
FX_getDisplayImage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Matching Functions Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
MC_init . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
MC_getVersionInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
MC_getSettings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
MC_createContext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
MC_closeContext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
MC_getSecurityLevel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
MC_setSecurityLevel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
MC_terminate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
DigitalPersonaOne Touch for Windows SDK: C/C++ Edition | Developer Guide v
Table of Contents
MC_getFeaturesLen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
MC_generateRegFeatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
MC_verifyFeaturesEx . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Data Structures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
DP_DEVICE_INFO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
DP_DEVICE_VERSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
DP_HW_INFO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
DP_PRODUCT_VERSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
FT_VERSION_INFO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
MC_SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Enumerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
DP_ACQUISITION_PRIORITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
DP_DEVICE_MODALITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
DP_DEVICE_TECHNOLOGY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
DP_DEVICE_UID_TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
DP_SAMPLE_QUALITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
FT_IMG_QUALITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
FT_FTR_QUALITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
FT_FTR_TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Type Definitions and Constants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
DFLT_FA_RATE MED_SEC_FA_RATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
DP_SAMPLE_TYPE_IMAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
FT_FA_RATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
HDPOPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
HIGH_SEC_FA_RATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
LOW_SEC_FA_RATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
MED_SEC_FA_RATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6 User Interface API Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
DPEnrollUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
DPVerifyUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Callbacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
DPENROLLMENTPROC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
DPVERIFYPROC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Enumerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
DP_ENROLLMENT_ACTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
7 Events Notifications and Return Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Events Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Return Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
DigitalPersonaOne Touch for Windows SDK: C/C++ Edition | Developer Guide vi
Table of Contents
8 Developing Citrix-aware applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
9 Redistribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
RTE\Install Folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Redist Folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Fingerprint Reader Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Hardware Warnings and Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Fingerprint Reader Use and Maintenance Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
A Setting the False Accept Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
False Accept Rate (FAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Representation of Probability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Requested FAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Achieved FAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
B Platinum SDK Enrollment Template Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Platinum SDK Enrollment Template Conversion for Microsoft Visual C++ . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Platinum SDK Enrollment Template Conversion for Visual Basic 6.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
C Get/Set Device Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 1
Introduction 1
The One Touch® for Windows SDK is a software development tool that enables developers to integrate
fingerprint biometrics into a wide set of Microsoft® Windows®-based applications, services, and products. The
tool enables developers to perform basic fingerprint biometric operations: capturing a fingerprint from a
DigitalPersona fingerprint reader, extracting the distinctive features from the captured fingerprint sample, and
storing the resulting data in a template for later comparison of a submitted fingerprint with an existing
fingerprint template.
In addition, the One Touch for Windows SDK enables developers to use a variety of programming languages in
a number of development environments to create their applications. The product includes detailed
documentation and sample code that can be used to guide developers to quickly and efficiently produce
fingerprint biometric additions to their products.
The One Touch for Windows SDK builds on a decade-long legacy of fingerprint biometric technology, being the
most popular set of development tools with the largest set of enrolled users of any biometric product in the
world. Because of its popularity, the DigitalPersona® Fingerprint Recognition Engine software—with its high
level of accuracy—and award-winning U.are.U® Fingerprint Reader hardware have been used with the widest-
age, hardest-to-fingerprint demographic of users in the world.
The One Touch for Windows SDK has been designed to authenticate users on the Microsoft® Windows Vista®
and Microsoft® Windows® XP operating systems running on any of the x86-based platforms. The product is
used with DigitalPersona fingerprint readers in a variety of useful configurations: standalone USB peripherals,
modules that are built into customer platforms, and keyboards.
Also note that the DigitalPersona One Touch I.D. SDK includes the One Touch for Windows RTE, .NET
documentation and .NET samples as well; and can be used to implement a full-fledged biometrics product
encompassing fingerprint collection, enrollment, and verification. We strongly suggest that OTID developers
use this embedded version of OTW.
Fingerprint Authentication on a Remote Computer
This SDK includes transparent support for fingerprint authentication through Windows Terminal Services
(including Remote Desktop Connection) and through a Citrix connection to Metaframe Presentation Server
using a client from the Citrix Presentation Server Client package.
Through Remote Desktop or a Citrix session, you can use a local fingerprint reader to log on to, and use other
installed features of, a remote machine running your fingerprint-enabled application.
The following types of Citrix clients are supported:
Program Neighborhood
Program Neighborhood Agent
Web Client
To take advantage of this feature, your fingerprint-enabled application must run on the Terminal Services or
Citrix server, not on the client. If you are developing a Citrix-aware application, see additional information in the
Developing Citrix-aware applications chapter on page 85.
Chapter 1: Introduction Target Audience
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 2
Target Audience
This guide is for developers who have a working knowledge of the C or C++ programming language.
Chapter Overview
Chapter 1, Introduction, this chapter, describes the audience for which this guide is written; defines the
typographical and notational conventions used throughout this guide; identifies a number of resources that
may assist you in using the One Touch for Windows SDK: C/C++ Edition; identifies the minimum system
requirements needed to run the One Touch for Windows SDK: C/C++ Edition; and lists the DigitalPersona
products and fingerprint templates supported by the One Touch for Windows SDK: C/C++ Edition.
Chapter 2, Quick Start, provides a quick introduction to the One Touch for Windows SDK: C/C++ Edition using
one of the sample applications provided as part of the SDK.
Chapter 3, Installation, contains instructions for installing the SDK and the RTE and identifies the files and
folders that are installed on your hard disk.
Chapter 4, Overview, introduces One Touch for Windows SDK: C/C++ Edition terminology and concepts, shows
how data flows among the various One Touch for Windows SDK: C/C++ Edition components, and includes
workflow diagrams and explanations of the One Touch for Windows: C/C++ Edition API functions used to
perform the operations in the workflows.
Chapter 5, Core API Reference, defines the functions, data structures, and type definitions that are part of the
One Touch for Windows: C/C++ Edition Core API.
Chapter 6, User Interface API Reference, defines the functions and enumerations of the User Interface API, a high-
level wrapper providing a premade user interface and access to the full functionality of the Core API through a
small number of simple functions.
Chapter 7, Events Notifications and Return Codes, defines the codes returned by the One Touch for Windows: C/
C++ Edition API functions.
Chapter 9, Redistribution, identifies the files that you may distribute according to the End User License
Agreement (EULA) and lists the functionalities that you need to provide to your end users when you develop
products based on the One Touch for Windows: C/C++ Edition API.
Appendix A, Setting the False Accept Rate, provides information about determining and using specific values for
the FAR and evaluating and testing achieved values.
Appendix B, Platinum SDK Enrollment Template Conversion, contains sample code for converting Platinum SDK
registration templates for use with the One Touch for Windows SDK: C/C++ Edition.
A glossary and an index are also included for your reference.
Chapter 1: Introduction Document Conventions
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 3
Document Conventions
This section defines the notational and typographical conventions used in this guide.
Notational Conventions
The following notational conventions are used throughout this guide:
NOTE: Notes provide supplemental reminders, tips, or suggestions.
IMPORTANT: Important notations contain significant information about system behavior, including problems
or side effects that can occur in specific situations.
Typographical Conventions
The following typographical conventions are used in this guide:
Additional Resources
You can refer to the resources in this section to assist you in using the One Touch for Windows SDK: C/C++
Edition.
Typeface Purpose Example
Courier
bold
Used to indicate computer programming code The only valid value for this field is TRUE.
Initialize the licensing library by calling the
DPFPInit function.
Italics Used for emphasis or to introduce new terms
For developers who are viewing this document
online, text in italics may also indicate
hypertext links to other areas in this guide.
Duration is the period of time for which a template
certificate, once issued, is valid.
Call DPIDCreateIdentificationSet before
calling this function (page 20).
Bold Used for keystrokes and window and dialog
box elements
Press Enter.
Click the Info tab.
Chapter 1: Introduction Related Documentation
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 4
Related Documentation
Online Resources
System Requirements
This section lists the minimum software and hardware requirements needed to run the One Touch for Windows
SDK: C/C++ Edition.
x86-based processor or better
Microsoft® Windows® XP, 32-bit and 64-bit versions; Microsoft® Windows® XP Embedded, 32-bit version1;
or Microsoft® Windows Vista®, 32-bit and 64-bit versions
USB connector on the computer where the fingerprint reader is to be connected
DigitalPersona U.are.U 4000B or U.are.U 4500 fingerprint reader
Supported DigitalPersona hardware Products
The One Touch for Windows SDK: C/C++ Edition supports the following DigitalPersona hardware products:
DigitalPersona U.are.U 4000B/4500 or later fingerprint readers and modules
DigitalPersona U.are.U Fingerprint Keyboard
Subject Document
Fingerprint recognition, including the history and basics
of fingerprint identification and the advantages of
DigitalPersona’s Fingerprint Recognition Engine
The DigitalPersona White Paper: Guide to Fingerprint
Recognition. The file, Fingerprint Guide.pdf, is located in
the Docs folder in the software package, and is not
automatically installed on your computer as part of the
setup process.
Late-breaking news about the product The Readme.txt files provided in the root directory in the
SDK software package as well as in some subdirectories
Web site name URL
DigitalPersona Developer Connection Forum for peer-to
peer interaction between DigitalPersona Developers
http://www.digitalpersona.com/webforums/
Latest updates for DigitalPersona software products http://www.digitalpersona.com/support/downloads/
software.php
1. A list of DLL dependencies for installation of your application on Microsoft Windows XP Embedded, One Touch for Windows XPE Dependencies.xls, is
located in the Docs folder in the SDK software package.
Chapter 1: Introduction Fingerprint Template Compatibility
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 5
Fingerprint Template Compatibility
Fingerprint templates produced by all editions of the One Touch for Windows SDK are also compatible with the
following DigitalPersona SDKs:
Gold SDK
Gold CE SDK
One Touch for Linux SDK, all distributions
NOTE: Platinum SDK enrollment templates must be converted to a compatible format to work with these SDKs.
See Appendix B on page 93 for sample code that converts Platinum SDK templates to this format.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 6
Quick Start 2
This chapter provides a quick introduction to the One Touch for Windows SDK: C/C++ Edition using one of the
sample applications provided as part of the One Touch for Windows SDK.
The application is a sample Microsoft® Visual C++® project that demonstrates the functionality of the user
interfaces supported by the One Touch for Windows SDK: C/C++ Edition User Interface API.
Quick Concepts
The following definitions will assist you in understanding the purpose and functionality of the sample
application that is described in this section.
Enrollment—The process of capturing a person’s fingerprint four times, extracting the features from the
fingerprints, creating a fingerprint template, and storing the template for later comparison.
Verification—The process of comparing a captured fingerprint to a fingerprint template to determine whether
the two match.
Unenrollment—The process of deleting a fingerprint template associated with a previously enrolled
fingerprint.
For further descriptions of these processes, see Chapter 4 on page 17.
Install the Software
To install the One Touch for Windows SDK: C/C++ Edition
1. In the SDK folder in the SDK software package, open the Setup.exe file, and then click Next.
2. Follow the installation instructions as they appear.
3. Restart your computer.
Connect the Fingerprint Reader
Conenct the fingerprint reader to the USB connector on the system where you installed the SDK.
Chapter 2: Quick Start Using the Sample Application
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 7
Using the Sample Application
By performing the exercises in this section, you will
Start the sample application
Enroll a fingerprint
Verify a fingerprint
Unenroll (delete) a fingerprint
Exit the sample application
To start the sample application
1. Open the UIVBDemo.exe file.
It is located in the <destination folder>One Touch SDK\C++ Samples\
DPFP UI Demo\Release folder.
2. The DPFPUI Demo dialog box appears.
Enrolling a fingerprint consists of scanning your fingerprint four times
using the fingerprint reader.
To enroll a fingerprint
1.In the DPFPUI Demo dialog box, click Enroll Fingerprints.
The Fingerprint Enrollment dialog box appears.
2. On the right “hand,” click the index finger.
A second Fingerprint Enrollment dialog box appears.
Chapter 2: Quick Start Using the Sample Application
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 8
3. Using the fingerprint reader, scan your right index fingerprint.
Chapter 2: Quick Start Using the Sample Application
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 9
4. Repeat step 3 until the Success message appears.
5. In the message box, click OK.
The Enrollment was successful message appears.
6. Click OK.
Chapter 2: Quick Start Using the Sample Application
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 10
To verify a fingerprint
1. In the DPFPUI Demo dialog box, click Verify Fingerprint.
The Verify Your Identify dialog box appears.
2. Using the fingerprint reader, scan your right index fingerprint.
The Success message appears, which indicates that your fingerprint was verified.
3. In the message box, click OK.
4. Using the fingerprint reader, scan your right middle fingerprint.
The Retry message appears, which indicates that your fingerprint was not verified.
5. In the message box, click OK.
6. Click Cancel.
Chapter 2: Quick Start Using the Sample Application
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 11
To unenroll (delete) a fingerprint
1. In the DPFPUI Demo dialog box, click Enroll Fingerprints.
The Fingerprint Enrollment dialog box appears, indicating that you have enrolled your right index
fingerprint.
2. In the right “hand,” click the green index finger.
A message box appears, asking you to verify the deletion.
Chapter 2: Quick Start Using the Sample Application
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 12
3. In the message box, click Ye s.
The Success message appears.
4. In the message box, click OK.
The Fingerprint Deleted message appears.
The right index finger is no longer green, indicating that the fingerprint associated with that finger is not
enrolled (has been deleted).
To exit the application
In the DPFPUI Demo dialog box, click Quit.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 13
Installation 3
This chapter contains instructions for installing the various components of the One Touch for Windows SDK: C/
C++ Edition and identifies the files and folders that are installed on your hard disk.
The following two installations are located in the SDK software package:
SDK, which you use in developing your application. This installation is located in the SDK folder.
RTE (runtime environment), which you must provide to your end users to implement the One Touch for
Windows SDK: C/C++ Edition interfaces, objects, methods, and properties. This installation is located in
the RTE folder. (The RTE installation is also included in the SDK installation.)
Installing the SDK
To install the One Touch for Windows SDK: C/C++ Edition
1. In the SDK folder in the SDK software package, open the Setup.exe file, and then click Next.
2. Follow the installation instructions as they appear.
3. Restart your computer.
Table 1 describes the files and folders that are installed in the <destination folder> folder on your hard disk. The
RTE files and folders, which are listed in Table 2 on page 15, are also installed on your hard disk.
NOTE: All installations share the DLLs and the DPHostW.exe file that are installed with the C/C++ edition.
Additional product-specific files are provided for other editions.
Table 1. One Touch for Windows SDK: C/C++ Edition installed files and folders
Folder File Description
One Touch SDK\C-C++\Docs One Touch for Windows SDK
C-C++ Developer Guide.pdf
DigitalPersona One Touch for Windows SDK:
C/C++ Edition Developer Guide
One Touch SDK\C-C++\
Include
dpDefs.h
DPDevClt.h
dpFtrEx.h
dpMatch.h
dpRCodes.h
dpUIApi.h
Header files used by all of the One Touch for
Windows SDK APIs
Chapter 3: Installation Installing the Runtime Environment (RTE)
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 14
Installing the Runtime Environment (RTE)
When you develop a product based on the One Touch for Windows SDK: C/C++ Edition, you need to provide
the redistributables to your end users. These files are designed and licensed for use with your application. You
may include the installation files located in the RTE\Install folder in your application or you may incorporate the
redistributables directly into your installer. You may also use the merge modules located in the Redist folder in
the SDK software package to create your own MSI installer. (See Redistribution on page 86 for licensing terms.)
If you created an application based on the One Touch for Windows: C/C++ Edition APIs that does not include an
installer, your end users must install the One Touch for Windows: C/C++ Edition Runtime Environment to run
your application.
To install the One Touch for Windows: C/C++ Edition RTE for 32-bit operating systems
1. In the RTE folder in the SDK software package, open the Setup.exe file.
2. Follow the installation instructions as they appear.
Table 2 identifies the files that are installed on your hard disk.
One Touch SDK\C-C++\Lib DPFPApi.lib
DPFpUI.lib
dpHFtrEx.lib
dpHMatch.lib
Import libraries used by the One Touch for
Windows SDK: C/C++ Edition API
One Touch SDK\C-C++\C++
Samples\DPFP UI Demo
This folder contains a sample Microsoft® Visual C++® project that demonstrates the
functionality of the user interfaces supported by the One Touch for Windows SDK:
C/C++ Edition User Interface API.
One Touch SDK\C-C++\C++
Samples\Enrollment Sample
Code
This folder contains a sample Microsoft Visual C++ project that shows how to use the
One Touch for Windows: C/C++ Edition Core API for performing fingerprint enrollment
and fingerprint verification.
Table 1. One Touch for Windows SDK: C/C++ Edition installed files and folders (continued)
Folder File Description
Chapter 3: Installation Installing the Runtime Environment (RTE)
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 15
To install the One Touch for Windows: C/C++ Edition RTE for 64-bit operating systems
1. In the RTE\x64 folder in the SDK software package, open the Setup.exe file.
2. Follow the installation instructions as they appear.
Table 3 identifies the files that are installed on your hard disk for 64-bit versions of the supported operating
systems.
Table 2. One Touch for Windows: C/C++ Edition RTE installed files and folders, 32-bit installation
Folder File Description
<destination folder>\Bin DPCOper2.dll
DPDevice2.dll
DPDevTS.dll
DpHostW.exe
DPmsg.dll
DPMux.dll
DpSvInfo2.dll
DPTSClnt.dll
DPCrStor.dll
DLLs and executable file used by the all of the
One Touch for Windows APIs
<system folder> DPFPApi.dll
DpClback.dll
dpHFtrEx.dll
dpHMatch.dll
DPFpUI.dll
DLLs used by all of the One Touch for Windows
SDK APIs
Chapter 3: Installation Installing and Uninstalling the RTE Silently
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 16
Installing and Uninstalling the RTE Silently
The One Touch for Windows SDK software package contains a batch file, InstallOnly.bat, that you can use to
silently install the RTE. In addition, you can modify the file to selectively install the various features of the RTE.
Refer to the file for instructions.
The SDK software package also contains a file, UninstallOnly.bat, that you can use to silently uninstall the RTE.
Table 3. One Touch for Windows: C/C++ Edition RTE installed files and folders, 64-bit installation
Folder File Description
<destination folder>\Bin DPCOper2.dll
DPDevice2.dll
DPDevTS.dll
DpHostW.exe
DPMux.dll
DpSvInfo2.dll
DPTSClnt.dll
DPCrStor.dll
DLLs and executable file used by the all of the
One Touch for Windows APIs
<destination folder>\Bin\x64 DPmsg.dll DLL used by the all of the One Touch for
Windows APIs
<system folder> DPFPApi.dll
DpClback.dll
dpHFtrEx.dll
dpHMatch.dll
DPFpUI.dll
32-bit DLLs used by all of the One Touch for
Windows APIs
<system64 folder> DPFPApi.dll
DpClback.dll
dpHFtrEx.dll
dpHMatch.dll
DPFpUI.dll
64-bit DLLs used by all of the One Touch for
Windows APIs
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 17
Overview 4
This chapter introduces One Touch for Windows SDK: C/C++ Edition concepts and terminology. This chapter
also includes typical workflow diagrams and explanations of the One Touch for Windows: C/C++ Edition API
functions used to perform the tasks in the workflows. For additional information on fingerprint biometrics, refer
to the “DigitalPersona White Paper: Guide to Fingerprint Recognition” included in the One Touch for Windows
SDK software package “doc” folder as “Fingerprint Guide.pdf.”
Biometric System
A biometric system is an automatic method of identifying a person based on the person’s unique physical and/
or behavioral traits, such as a fingerprint or an iris pattern, or a handwritten signature or voice. Biometric
identifiers are
Universal
Distinctive
Persistent (sufficiently unchangeable over time)
Collectable
Biometric systems have become an essential component of effective person recognition solutions because
biometric identifiers cannot be shared or misplaced and they naturally represent an individual’s bodily identity.
Substitute forms of identity, such as passwords (commonly used in logical access control) and identity cards
(frequently used for physical access control), do not provide this level of authentication that strongly validates
the link to the actual authorized user.
Fingerprint recognition is the most popular and mature biometric system used today. In addition to meeting
the four criteria above, fingerprint recognition systems perform well (that is, they are accurate, fast, and robust),
they are publicly acceptable, and they are hard to circumvent.
Fingerprint
A fingerprint is an impression of the ridges on the skin of a finger. A fingerprint recognition system uses the
distinctive and persistent characteristics from the ridges, also referred to as fingerprint features, to distinguish
one finger (or person) from another. The One Touch for Windows SDK: C/C++ Edition incorporates the
DigitalPersona Fingerprint Recognition Engine (Engine), which uses traditional as well as modern fingerprint
recognition methodologies to convert these fingerprint features into a format that is compact, distinguishing,
and persistent. The Engine then uses the converted, or extracted, fingerprint features in comparison and
decision-making to provide reliable personal recognition.
Chapter 4: Overview Fingerprint Recognition
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 18
Fingerprint Recognition
The DigitalPersona fingerprint recognition system uses the processes of fingerprint enrollment and fingerprint
verification, which are illustrated in the block diagram in Figure 1 on page 19. Some of the tasks in these
processes are done by the fingerprint reader and its driver; some are accomplished using One Touch for
Windows: C/C++ Edition API functions, which use the Engine; and some are provided by your software
application and/or hardware.
Fingerprint Enrollment
Fingerprint enrollment is the initial process of collecting fingerprint data from a person (enrollee) and storing the
resulting data as a fingerprint template for later comparison. The following procedure describes typical
fingerprint enrollment. (Steps preceded by an asterisk are not performed by the One Touch for Windows SDK:
C/C++ Edition.)
1. *Obtain the enrollee’s identifier (Subject Identifier).
2. Capture the enrollee’s fingerprint using the fingerprint reader.
3. Extract the fingerprint feature set for the purpose of enrollment from the fingerprint sample.
4. Repeat steps 2 and 3 until you have enough fingerprint feature sets to create a fingerprint template.
5. Create a fingerprint template.
6. *Associate the fingerprint template with the enrollee through a Subject Identifier, such as a user name,
email address, or employee number.
7. *Store the fingerprint template, along with the Subject Identifier, for later comparison.
Fingerprint templates can be stored in any type of repository that you choose, such as a fingerprint
capture device, a smart card, or a local or central database.
Fingerprint Verification
Fingerprint verification is the process of comparing the fingerprint data to the fingerprint template produced at
enrollment and deciding if the two match. The following procedure describes typical fingerprint verification.
(Steps preceded by an asterisk are not performed by the One Touch for Windows SDK: C/C++ Edition.)
1. *Obtain the Subject Identifier of the person to be verified.
2. Capture a fingerprint sample using the fingerprint reader.
3. Extract a fingerprint feature set for the purpose of verification from the fingerprint sample.
4. *Retrieve the fingerprint template associated with the Subject Identifier from your repository.
Chapter 4: Overview False Positives and False Negatives
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 19
5. Perform a one-to-one comparison between the fingerprint feature set and the fingerprint template, and
make a decision of match or non-match.
6. *Act on the decision accordingly, for example, unlock the door to a building for a match, or deny access to
the building for a non-match.
Figure 1. DigitalPersona fingerprint recognition system
False Positives and False Negatives
Fingerprint recognition systems provide many security and convenience advantages over traditional methods
of recognition. However, they are essentially pattern recognition systems that inherently occasionally make
certain errors because no two impressions of the same finger are identical. During verification, sometimes a
person who is legitimately enrolled is rejected by the system (a false negative decision), and sometimes a
person who is not enrolled is accepted by the system (a false positive decision).
The proportion of false positive decisions is known as the false accept rate (FAR), and the proportion of false
negative decisions is known as the false reject rate (FRR). In fingerprint recognition systems, the FAR and the FRR
are traded off against each other, that is, the lower the FAR, the higher the FRR, and the higher the FAR, the
lower the FRR.
A One Touch for Windows: C/C++ Edition API function enables you to set the value of the FAR, also referred to
as the security level, to accommodate the needs of your application. In some applications, such as an access
&UHDWHILQJHUSULQW
IHDWXUHVHWV
6WRUHWHPSODWHDQG
6XEMHFW,GHQWLILHU
&DSWXUHILQJHUSULQWV &UHDWHWHPSODWH
&UHDWHILQJHUSULQW
IHDWXUHVHW
&RPSDUHDQG
PDNHGHFLVLRQ
8VHGHFLVLRQLQ
DSSOLFDWLRQ
*HW6XEMHFW,GHQWLILHU
)LQJHUSULQW(QUROOPHQW
)LQJHUSULQW9HULILFDWLRQ
*HW6XEMHFW,GHQWLILHU
3HUIRUPHGE\2QH7RXFKIRU:LQGRZV6'.&&
1RWSHUIRUPHGE\2QH7RXFKIRU:LQGRZV6'.&&
/HJHQG
5HWULHYHWHPSODWHDQG
6XEMHFW,GHQWLILHU
&DSWXUHILQJHUSULQW
Chapter 4: Overview False Positives and False Negatives
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 20
control system to a highly confidential site or database, a lower FAR is required. In other applications, such as an
entry system to an entertainment theme park, security (which reduces ticket fraud committed by a small
fraction of patrons by sharing their entry tickets) may not be as significant as accessibility for all of the patrons,
and it may be preferable to decrease the FRR at the expense of an increased FAR.
It is important to remember that the accuracy of the fingerprint recognition system is largely related to the
quality of the fingerprint. Testing with sizable groups of people over an extended period has shown that a
majority of people have feature-rich, high-quality fingerprints. These fingerprints will almost surely be
recognized accurately by the DigitalPersona Fingerprint Recognition Engine and practically never be falsely
accepted or falsely rejected. The DigitalPersona fingerprint recognition system is optimized to recognize
fingerprints of poor quality. However, a very small number of people may have to try a second or even a third
time to obtain an accurate reading. Their fingerprints may be difficult to verify because they are either worn
from manual labor or have unreadable ridges. Instruction in the proper use of the fingerprint reader will help
these people achieve the desired results.
Chapter 4: Overview Operations
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 21
Operations
Each time the user puts a finger on the fingerprint reader, fingerprint-related data is sent to the Engine. When
the client application needs to perform some action requiring scanning a fingerprint, it should create an
operation.
There is only one type of operation supported: Fingerprint sample acquisition. Right now the Engine supports
only one type of fingerprint sample, which is a fingerprint image. During the creation of a fingerprint sample
acquisition operation, the client application may specify its priority level, which can be low, normal, or high.
Note that the high priority level is reserved for internal DigitalPersona use only.
Note that no more than one client application may obtain the results of a single fingerprint scan.
It is possible to create and register any number of operations with normal priority, but no more than one
operation for each of low and high priority at a time.
When the Engine is ready to dispatch the result of fingerprint scan, it processes operations using the following
rules in the sequence shown.
1. If there is a high-priority operation registered, the result is dispatched to the process that owns the
operation.
2. If there is no high-priority operation registered, the engine determines which process owns the
topmost window. If there is a normal-priority operation owned by this process, it will receive the
result.
3. If the above-mentioned steps do not allow the engine to dispatch the result, the process owning the low-
priority operation (if registered) will receive the result.
If the result is still not dispatched, it is discarded.
Components of the SDK
The One Touch for Windows SDK: C/C++ Edition consists of the following two components:
Device component
The device component directs fingerprint reader (device) data and events to your application.
Fingerprint recognition component
The fingerprint recognition component performs fingerprint enrollment and verification and includes
two modules: the fingerprint feature extraction module and the fingerprint comparison module.
Chapter 4: Overview Device Component
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 22
Device Component
The device component workflow is shown below and is followed by explanations of the One Touch for
Windows: C/C++ Edition Core API functions that are used to perform the tasks in the workflow.
Figure 2. Device component workflow
&UHDWHDILQJHUSULQWVDPSOH
DFTXLVLWLRQRSHUDWLRQ
'3)3&UHDWH$FTXLVLWLRQ
,QLWLDOL]HWKH
GHYLFHFRPSRQHQW
'3)3,QLW
(QXPHUDWHDYDLODEOH
ILQJHUSULQWUHDGHUVGHYLFHV
'3)3(QXPHUDWH'HYLFHV
6XEVFULEHFOLHQWIRUUHFHLYLQJ
RSHUDWLRQHYHQWVQRWLILFDWLRQV
'3)36WDUW$FTXLVLWLRQ
8QVXEVFULEHFOLHQW
IURPUHFHLYLQJRSHUDWLRQ
HYHQWVQRWLILFDWLRQV
'3)36WRS$FTXLVLWLRQ
3URFHVVWKHHYHQW
7HUPLQDWHWKH
GHYLFHFRPSRQHQW
'3)37HUP
,QLWLDOL]DWLRQ
2SHUDWLRQ
&OHDQXS
/HJHQG
2SWLRQDOVWHS
Chapter 4: Overview Initialization
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 23
Initialization
Initialize the device component by calling the DPFPInit function (page 44).
Operation
1. (Optional) If necessary, enumerate the available fingerprint readers (devices) connected to a computer by
calling the DPFPEnumerateDevices function (page 41).
2. Create a fingerprint sample acquisition operation by calling the DPFPCreateAcquisition (page 38)
and specifying the device’s UID. You can also subscribe to all available fingerprint readers by passing the
value GUID_NULL.
3. Subscribe the client application for receiving operation events notifications by calling
DPFPStartAcquisition (page 45)and passing the operation handle.
4. Process the event.
5. Unsubscribe by calling the DPFPStopAcquisition function (page 46)
6. Release a subscribed fingerprint reader by calling the DPFPDestroyAcquisition function
(page 40).
Clean-up
Terminate the device component when your application no longer requires access to any fingerprint
readers by calling the DPFPTerm function (page 46).
Chapter 4: Overview Fingerprint Recognition Component
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 24
Fingerprint Recognition Component
This section includes illustrations of typical fingerprint enrollment and verification workflows for the fingerprint
recognition component and explanations of the One Touch for Windows: C/C++ Edition Core API functions
used to perform the tasks in the workflows. Your application workflows may be different than those illustrated
here. For example, you could choose to create fingerprint feature sets locally and then send them to a server for
enrollment.
Fingerprint Enrollment
A typical fingerprint enrollment application workflow is represented below. Each figure is followed by
explanations of the One Touch for Windows: C/C++ Edition Core API functions that are used to perform the
tasks in that part of the workflow. Both the fingerprint feature extraction and the fingerprint comparison
modules are used for performing enrollment.
Chapter 4: Overview Typical Fingerprint Enrollment Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 25
Typical Fingerprint Enrollment Workflow
Figure 3. Typical fingerprint enrollment workflow: Initialization
Initialization Tasks
Steps 3 and 4 can be done before steps 1 and 2.
1. Initialize the fingerprint feature extraction module by calling the FX_init function (page 47).
2. Create a feature extraction context by calling the FX_createContext function (page 48)
3. Initialize the fingerprint comparison module by calling the MC_init function (page 55).
4. Create a comparison context by calling the MC_createContext function (page 56).
Steps 5 through 7 can be done in any order.
&UHDWHDIHDWXUHH[WUDFWLRQFRQWH[W
);BFUHDWH&RQWH[W
5HWULHYHWKHVL]HRIWKHILQJHUSULQW
IHDWXUHVHW)6(SDVVLQJIHDWXUH
VHWSXUSRVH)7B35(B5(*B)75
);BJHW)HDWXUHV/HQ
,QLWLDOL]DWLRQ
&UHDWHDFRPSDULVRQFRQWH[W
0&BFUHDWH&RQWH[W
,QLWLDOL]HWKHILQJHUSULQW
FRPSDULVRQPRGXOH
0&BLQLW
5HWULHYHWKHUHTXLUHGQXPEHURI
ILQJHUSULQWIHDWXUHVHWV1
0&BJHW6HWWLQJV
5HWULHYHWKHVL]HRIWKH
ILQJHUSULQWWHPSODWH67SDVVLQJ
IHDWXUHVHWSXUSRVH)7B5(*B)75
0&BJHW)HDWXUHV/HQ
$
,QLWLDOL]HWKHILQJHUSULQW
IHDWXUHH[WUDFWLRQPRGXOH
);BLQLW
6WDUW
Chapter 4: Overview Typical Fingerprint Enrollment Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 26
5. Retrieve the size of the fingerprint feature set (FSE) by calling the FX_getFeaturesLen function and
passing feature set purpose FT_PRE_REG_FTR (page 50).
6. Retrieve the size of the fingerprint template (ST) by calling the MC_getFeaturesLen function and
passing feature set purpose FT_REG_FTR (page 59).
7. Retrieve the number (N) of fingerprint feature sets required to create the fingerprint template by calling
the MC_getSettings function (page 56).
Figure 4. Typical fingerprint enrollment workflow: Fingerprint feature set creation
&DSWXUHDILQJHUSULQW
VDPSOHIURPWKH
ILQJHUSULQWUHDGHU
3UHSDUHWKHILQJHUSULQW
VDPSOHIRUGLVSOD\
);BJHW'LVSOD\,PDJH
'LVSOD\WKHLPDJH
6WRUHWKHILQJHUSULQWIHDWXUH
VHWLQYRODWLOHPHPRU\
)LQJHUSULQWIHDWXUHVHWFUHDWLRQ
&UHDWHDILQJHUSULQWIHDWXUH
VHWSDVVLQJ)6(DQGIHDWXUH
VHWSXUSRVH)7B35(B5(*B)75
);BH[WUDFW)HDWXUHV
5HTXLUHGQXPEHU
RIILQJHUSULQW
IHDWXUHVHWV"
1R
<HV
$
%
2QH7RXFKIRU:LQGRZV6'.&&
$SSOLFDWLRQQRWSDUWRI6'.
)LQJHUSULQWUHDGHU
/HJHQG
2SWLRQDOVWHS
Chapter 4: Overview Typical Fingerprint Enrollment Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 27
Fingerprint Feature Set Creation Tasks
Repeat the following required steps until you have created the number of fingerprint feature sets required to
generate a fingerprint template. This number (N) was obtained when you called the MC_getSettings
function during initialization (page 56). (Steps preceded by an asterisk are not accomplished using One Touch
for Windows: C/C++ Edition Core API functions.)
1. *Capture a fingerprint image from the fingerprint reader.
2. Create a fingerprint feature set by calling the FX_extractFeatures function and passing FSE and
feature set purpose FT_PRE_REG_FTR (page 51).
Steps 3 and 4 are optional.
3. Prepare the fingerprint image captured by the fingerprint reader for display by calling the
FX_getDisplayImage function (page 53).
4. *Display the image.
5. *If the FX_extractFeatures function succeeds, store the resulting fingerprint feature set in volatile
memory.
Chapter 4: Overview Typical Fingerprint Enrollment Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 28
Figure 5. Typical fingerprint enrollment workflow: Fingerprint template creation and clean-up
%
)LQJHUSULQWWHPSODWHFUHDWLRQ
6WRUHWKHILQJHUSULQWWHPSODWH
DQGDVVRFLDWHLWZLWKDXVHU,'
&UHDWHDILQJHUSULQWWHPSODWH
SDVVLQJ67DQG1QXPEHURI
ILQJHUSULQWIHDWXUHVHWV
0&BJHQHUDWH5HJ)HDWXUHV
2QH7RXFKIRU:LQGRZV6'.&&
$SSOLFDWLRQQRWSDUWRI6'.
/HJHQG
'HVWUR\WKH
FRPSDULVRQFRQWH[W
0&BFORVH&RQWH[W
&OHDQXS
7HUPLQDWHWKHILQJHUSULQW
FRPSDULVRQPRGXOH
0&BWHUPLQDWH
'HVWUR\WKHIHDWXUH
H[WUDFWLRQFRQWH[W
);BFORVH&RQWH[W
(QG
7HUPLQDWHWKHILQJHUSULQW
IHDWXUHH[WUDFWLRQPRGXOH
);BWHUPLQDWH
Chapter 4: Overview Fingerprint Verification
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 29
Fingerprint Template Creation Tasks
1. Create a fingerprint template by calling the MC_generateRegFeatures function and passing ST
and the N number of fingerprint features sets created previously and stored in volatile memory (page 60).
Step 2 is not accomplished using One Touch for Windows: C/C++ Edition Core API functions.
2. Store the fingerprint template in your repository and associate it with a user ID.
Clean-up Tasks
Steps 3 and 4 can be done before steps 1 and 2; however, during clean-up, you should always terminate
modules in the reverse order of their initialization. In other words, if you initialize the fingerprint feature
extraction module first, you should terminate that module last, and if you initialize the comparison module
first, you should terminate that module last.
1. Destroy the comparison context by calling the MC_closeContext function (page 57)
2. Terminate the fingerprint comparison module by calling the MC_terminate function (page 59).
3. Destroy the feature extraction context by calling the FX_closeContext function (page 49)
4. Terminate the fingerprint feature extraction module by calling the FX_terminate function (page 49).
Fingerprint Verification
A typical fingerprint verification application workflow is represented in the following three illustrations. Each
figure is followed by explanations of the One Touch for Windows: C/C++ Edition Core API functions that are
used to perform the tasks in that part of the workflow. Both the fingerprint feature extraction and the
fingerprint comparison modules are used for performing verification.
Chapter 4: Overview Typical Fingerprint Verification Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 30
Typical Fingerprint Verification Workflow
Figure 6. Typical fingerprint enrollment workflow: Initialization
Initialization Tasks
Steps 3 and 4 can be done before steps 1 and 2.
1. Initialize the fingerprint feature extraction module by calling the FX_init function (page 47).
2. Create a feature extraction context by calling the FX_createContext function (page 48)
3. Initialize the fingerprint comparison module by calling the MC_init function (page 55).
4. Create a comparison context by calling the MC_createContext function (page 56).
5. Optionally, set the security level of the comparison context by calling the MC_setSecurityLevel
function (page 57). If you do not call this function, the default security level will be used.
6. Retrieve the size of the fingerprint feature set (FSV) by calling the FX_getFeaturesLen function and
passing feature set purpose FT_VER_FTR (page 50).
&UHDWHDIHDWXUHH[WUDFWLRQFRQWH[W
);BFUHDWH&RQWH[W
,QLWLDOL]DWLRQ
&UHDWHDFRPSDULVRQFRQWH[W
0&BFUHDWH&RQWH[W
,QLWLDOL]HWKHILQJHUSULQW
FRPSDULVRQPRGXOH
0&BLQLW
$
,QLWLDOL]HWKHILQJHUSULQW
IHDWXUHH[WUDFWLRQPRGXOH
);BLQLW
6WDUW
5HWULHYHVL]HRIWKHILQJHUSULQW
IHDWXUHVHW)69SDVVLQJIHDWXUH
VHWSXUSRVH)7B9(5B)75
);BJHW)HDWXUHV/HQ
6HWWKHVHFXULW\OHYHORIWKH
FRPSDULVRQFRQWH[W
0&BVHW6HFXULW\/HYHO
/HJHQG
2SWLRQDOVWHS
Chapter 4: Overview Typical Fingerprint Verification Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 31
Figure 7. Typical fingerprint verification workflow: Fingerprint feature set creation
&DSWXUHDILQJHUSULQW
VDPSOHIURPWKH
ILQJHUSULQWUHDGHU
3UHSDUHWKHILQJHUSULQW
VDPSOHIRUGLVSOD\
);BJHW'LVSOD\,PDJH
'LVSOD\WKHLPDJH
6WRUHWKHILQJHUSULQWIHDWXUH
VHWLQYRODWLOHPHPRU\
)LQJHUSULQWIHDWXUHVHWFUHDWLRQ
&UHDWHDILQJHUSULQWIHDWXUHVHW
SDVVLQJ)69DQGIHDWXUHVHW
SXUSRVH)7B9(5B)75
);BH[WUDFW)HDWXUHV
2QH7RXFKIRU:LQGRZV6'.&&
$SSOLFDWLRQQRWSDUWRI6'.
)LQJHUSULQWUHDGHU
/HJHQG
2SWLRQDOVWHS
$
%
$FTXLUHDXVHU,'
Chapter 4: Overview Typical Fingerprint Verification Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 32
Fingerprint Feature Set Creation Tasks
Steps preceded by an asterisk are not accomplished using One Touch for Windows: C/C++ Edition Core API
functions.
1. *Acquire the user ID that was used to associate the fingerprint template with the person to be verified.
2. *Capture a fingerprint image from the person via the fingerprint reader.
3. Create a fingerprint feature set by calling the FX_extractFeatures function and passing FSV and
feature set purpose FT_VER_FTR (page 51).
Steps 4 and 5 are optional.
4. Prepare the fingerprint image captured by the fingerprint reader for display by calling the
FX_getDisplayImage function (page 53).
5. *Display the image.
6. *If the FX_extractFeatures function succeeds, store the resulting fingerprint feature set in volatile
memory.
Chapter 4: Overview Typical Fingerprint Verification Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 33
Figure 8. Typical fingerprint verification workflow: Comparison and decision and clean-up
'HVWUR\WKH
FRPSDULVRQFRQWH[W
0&BFORVH&RQWH[W
&OHDQXS
7HUPLQDWHWKHILQJHUSULQW
FRPSDULVRQPRGXOH
0&BWHUPLQDWH
'HVWUR\WKHIHDWXUH
H[WUDFWLRQFRQWH[W
);BFORVH&RQWH[W
&RPSDULVRQDQG'HFLVLRQ
%
(QG
7HUPLQDWHWKHILQJHUSULQW
IHDWXUHH[WUDFWLRQPRGXOH
);BWHUPLQDWH
5HWULHYHWKHSUHYLRXVO\VWRUHG
ILQJHUSULQWWHPSODWHDVVRFLDWHGZLWK
WKHXVHU,'DQGLWVVL]H67
3HUIRUPILQJHUSULQWYHULILFDWLRQ
SDVVLQJWKHWHPSODWHDQG67DQG
WKHVWRUHGIHDWXUHVHWDQG)69
0&BYHULI\)HDWXUHV([
$SSOLFDWLRQQRWSDUWRI6'.
/HJHQG
Chapter 4: Overview Typical Fingerprint Verification Workflow
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 34
Comparison-and-Decision Tasks
Step 1 is not accomplished using One Touch for Windows: C/C++ Edition Core API functions.
1. *Retrieve the fingerprint template associated with the user ID and size ST from your repository.
2. Perform fingerprint verification by calling the MC_verifyFeaturesEx function and passing the
stored fingerprint feature set together with FSV, and the fingerprint template together with ST (page 62).
Clean-up Tasks
Steps 3 and 4 can be done before steps 1 and 2; however, during clean-up, you should always terminate
modules in the reverse order of their initialization. In other words, if you initialize the fingerprint feature
extraction module first, you should terminate that module last, and if you initialize the comparison module
first, you should terminate that module last.
1. Destroy the comparison context by calling the MC_closeContext function (page 57)
2. Terminate the fingerprint comparison module by calling the MC_terminate function (page 59).
3. Destroy the feature extraction context by calling the FX_closeContext function (page 49)
4. Terminate the fingerprint feature extraction module by calling the FX_terminate function (page 49).
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 35
Core API Reference 5
This chapter provides a reference to the One Touch for Windows: C/C++ Edition Core API, including information
about its
Functions on page 35
Data Structures on page 64
Enumerations on page 68
Type Definitions and Constants on page 74
The next chapter, User Interface API Reference, describes the DPUIAPI wrapper that simplifies access to the entire
functionality available in the Core API described in this chapter. The wrapper provides a premade user interface
that handles device component, fingerprint enrollment, and fingerprint verification tasks through only two
functions and two callbacks.
This chapter defines the One Touch for Windows: C/C++ Edition Core API functions. Use the three categorized
lists in this section to quickly find the functions contained in the following pages by function name or by
description.
Functions
The functions are arranged for convenience into these three categories.
Device functions - are used to communicate with the U.are.U fingerprint reader.
Extraction functions - are used for performing feature extraction, which is the system function that is
applied to a fingerprint sample to compute repeatable and distinctive information to be used for
fingerprint verification or fingerprint enrollment.
Matching - compares a fingerprint template and a feature set and calculates a score that indicates how
likely it is that they come from the same finger.
Device Functions List
Function Page Description
DPFPBufferFree 38 Frees memory previously allocated by a DPFP function call.
DPFPCreateAcquisition 38 Creates a fingerprint sample acquisition operation.
DPFPDestroyAcquisition 40 Destroys the operation previously created by DPFPCreateAcquisition
and deallocates all resources associated with that operation.
DPFPEnumerateDevices 41 Enumerates fingerprint readers (devices) connected to the computer.
DPFPGetDeviceInfo 41 Retrieves information about a specified fingerprint reader.
Chapter 5: Core API Reference Extraction Functions List
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 36
Extraction Functions List
Matching Functions List
DPFPSetDeviceParameter 42 Sets a specified value to a dedicated storage location on a U.are.U fingerprint
reader.
DPFPGetDevice Parameter 43 Gets the value contained in a dedicated storage location on a U.are.U
fingerprint reader.
DPFPGetVersion 44 Gets the API version information.
DPFPInit 44 Initializes the device component and allocates necessary resources.
DPFPStartAcquisition 45 Subscribes the client application for receiving operation events notifications.
DPFPStopAcquisition 46 Unsubscribes the client application from receiving operation events
DPFPTerm 46 Terminates the device component and deallocates resources.
Function Page Description
- Module Initialization, Settings and Termination -
FX_init 47 Initializes the dpFtrEx module.
FX_getVersionInfo 48 Returns the software version of the module.
FX_createContext 48 Creates a feature extraction context.
FX_closeContext 49 Closes a feature extraction context.
FX_terminate 49 Closes the dpFtrEx module.
- Feature Manipulation -
FX_getFeaturesLen 50 Returns the length of the features of the specified type.
FX_extractFeatures 51 Extracts the features from a given scan.
FX_getDisplayImage 53 Returns an image prepared for display.
Function Page Description
- Module Initialization, Settings, and Termination -
MC_init 55 Initializes the dpMatch module.
MC_getVersionInfo 55 Returns the software version of the module.
Function Page Description
Chapter 5: Core API Reference Matching Functions List
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 37
MC_getSettings 56 Returns the number of fingerprint feature sets required.
MC_createContext 56 Creates a matching context.
MC_closeContext 57 Closes a matching context.
MC_getSecurityLevel 57 Returns the current security level.
MC_setSecurityLevel 58 Sets the security level for a matching context.
MC_terminate 59 Closes the dpMatch module.
- Fingerprint Enrollment and Verification -
MC_getFeaturesLen 59 Returns the minimum and recommended length of the features.
MC_generateRegFeatures 60 Creates a fingerprint template.
MC_verifyFeaturesEx 62 Compares a fingerprint template with a fingerprint feature set.
Function Page Description
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 38
Device Functions Reference
Device functions are used to communicate with the U.are.U fingerprint reader, and are listed in the pages that
follow.
DPFPBufferFree
Frees memory previously allocated by a DPFP function call.
Syntax
void DPFPBufferFree (PVOID p);
Parameter Names
Library
DPFPApi.lib
DPFPCreateAcquisition
Creates a fingerprint sample acquisition operation.
Syntax
HRESULT DPFPCreateAcquisition(
DP_ACQUISITION_PRIORITY eAcquisitionPriority,
REFGUID DevUID,
ULONG uSampleType,
HWND hWnd,
ULONG uMsg,
HDPOPERATION * phOperation
);
p[in] The memory area to be freed.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 39
Parameters
eAcquisitionPriority [in] Acquisition priority needed. Must be one of the following values:
DP_PRIORITY_HIGH (RESERVED. For internal use only.)
The process subscribing with this priority
acquires device events exclusively.
The process subscribing with this priority
must have administrative privileges or run
under Local SYSTEM account.
Only one subscriber with this priority is
allowed.
DP_PRIORITY_NORMAL The process subscribing with this priority
acquires device events only if it runs as a
foreground process.
Multiple subscribers with this priority are
allowed.
DP_PRIORITY_LOW The process subscribing with this priority
acquires device events only if there are no
subscribers with higher priority.
Only one subscriber with this priority is
allowed.
DevUID [in] Fingerprint Reader serial number. Can be GUID_NULL if any
reader can be used.
uSampleType [in] Type of fingerprint sample needed. This parameter must be
DP_SAMPLE_TYPE_IMAGE.
hWnd [in] Handle of the window to be notified of operation events.
uMsg [in] Window message to be sent as an event notification.
phOperation [out] Pointer to operation handle to be filled if operation was created
successfully.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 40
Return Values
Remarks
In order to free memory allocated for the operation created, the client application must call
DPFPDestroyAcquisition for the handle returned in phOperation.
Library
DPFPApi.lib
DPFPDestroyAcquisition
Destroys the operation previously created by DPFPCreateAcquisition and deallocates all resources
associated with that operation.
Syntax
HRESULT DPFPDestroyAcquisition (HDPOPERATION hOperation);
Parameter Names
Return Values
Library
DPFPApi.lib
S_OK Operation was successfully created.
E_ACCESSDENIED Application attempted to subscribe to device events using
DP_PRIORITY_HIGH but the priority does not have adequate rights to do so.
Only members of built-in Administrators group and Local SYSTEM account have
the right to subscribe with DP_PRIORITY_HIGH priority. If DigitalPersona Pro
is also installed on the same computer, an administrator needs to allow use of this
function by enabling “Allow Fingerprint Data Redirection” in the governing GPO.
The E_ACCESSDENIED error will be returned otherwise.
E_INVALIDARG For subscribers with DP_PRIORITY_HIGH and DP_PRIORITY_LOW
priorities, this error indicates that there is another application which has already
subscribed to device events with the same priority.
hOperation [in] Handle to operation that is to be destroyed.
S_OK Operation was successfully destroyed.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 41
DPFPEnumerateDevices
Enumerates the device UIDs of available fingerprint readers (devices) connected to this computer.
Syntax
HRESULT DPFPEnumerateDevices (
ULONG * puDevCount,
GUID ** ppDevUID
);
Parameters
Return Values
Remarks
Caller must release returned memory by calling DPFPBufferFree.
Library
DPFPApi.lib
DPFPGetDeviceInfo
Retrieves information about a particular reader.
Syntax
HRESULT DPFPGetDeviceInfo (
REFGUID DevUID,
DP_DEVICE_INFO * pDevInfo
);
Parameters
puDevCount [out] Number of readers available. If no readers are found, this number is 0.
puDevUID [out] Pointer to be filled with the pointer to the array of device UIDs for available
fingerprint readers. If NULL, only the number of available readers will be
returned.
S_OK Function was successful.
DevUID [in] Pointer to the UID of the fingerprint reader to retrieve information about.
pDevInfo [in, out] Pointer to DP_DEVICE_INFO structure receiving information about the
specified reader.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 42
Return Values
Library
DPFPApi.lib
DPFPSetDeviceParameter
Writes a value (pData) to a dedicated storage location on a U.R.U fingerprint reader with the specified serial
number.
Syntax
HRESULT DPFPSetDeviceParameter(
REFGUID DevUID,
unsigned long ulParamID,
const DATA_BLOB* pData
);
Parameters
Return Values
Library
DPFPApi.lib
S_OK Information was retrieved.
DevUID [in] Fingerprint reader serial number. Can be GUID_NULL if any reader can be used.
ulParamID Target Parameter ID, as follows:
FT_SET_CLIENT_PRIVATE_KEY
Writes a hashed private key into a fingerprint reader’s persistant storage. This
feature is supported on DigitalPersona’s 4000B and later readers. The source data
to hash is supplied through pData.
The reader needs to be recycled (disconnected and reconnected) before the key
can be retrieved through DPFPGetDeviceParameter.
pData Parameter value to set.
S_OK Parameter was set.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 43
DPFPGetDeviceParameter
Retrieves a parameter value from a specified reader.
Syntax
HRESULT DPFPGetDeviceParameter,
REFGUID DevUID,
unsigned long ulParamID,
const DATA_BLOB* pData
);
Parameters
Return Values
Library
DPFPApi.lib
DevUID [in] Fingerprint reader serial number. Can be GUID_NULL if any reader can be used.
ulParamID Target Parameter ID, as follows:
FT_GET_CLIENT_PRIVATE_KEY
Reads a private key hash stored within a fingerprint reader’s persistant storage.
This feature is supported on DigitalPersona’s 4000B and later readers.
The reader needs to be recycled (disconnected and reconnected) after invoking
DPFPSetDeviceParameter, before the key can be retrieved.
pData is required in order to allocate 16 bytes of storage when the function is used
to retrieve this parameter.
pData [out] Parameter value to retrieve. The caller has to allocate, load, and destroy
DATA_BLOB members.
S_OK Parameter retrieved.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 44
DPFPGetVersion
Gets the API version information.
Syntax
HRESULT DPFPGetVersion (
DP_PRODUCT_VERSION * pVersion
);
Parameters
Return Values
Library
DPFPApi.lib
DPFPInit
Allocates and initializes necessary resources. It MUST be called before any other DPFPApi calls except for
DPFPBufferFree.
Syntax
HRESULT DPFPInit ();
Return Values
Remarks
Every successful (that is, FAILED() == FALSE) call of DPFPInit must have a corresponding call of
the DPFPTerm function.
Library
DPFPApi.lib
pVersion [out] Pointer to the structure to be filled.
S_OK Function was successful.
S_OK Initialization successful.
S_FALSE Library is already initialized.
0x800706B3 The RPC server is not listening, which means that the Biometric Authentication
Service has not been started.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 45
DPFPStartAcquisition
Subscribes the client application for receiving operation events notifications.
Syntax
HRESULT DPFPStartAcquisition (
HDPOPERATION hOperation
);
Parameters
Return Values
Remarks
Each process can have no more than one active subscription for each operation priority level.
Library
DPFPApi.lib
hOperation [in] Operation handle.
S_OK If subscription is successful.
Chapter 5: Core API Reference Device Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 46
DPFPStopAcquisition
Unsubscribes the client application from receiving operation events notifications.
Syntax
HRESULT DPFPStopAcquisition (
HDPOPERATION hOperation
);
Parameters
Return Values
Library
DPFPApi.lib
DPFPTerm
Deallocates resources allocated by DPFPInit.
Syntax
Void DPFPTerm ();
Library
DPFPApi.lib
hOperation [in] Operation handle.
S_OK If unsubscription is successful.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 47
Extraction Functions Reference
The dpFtrEx module contains code for performing feature extraction, which is the system function that is
applied to a fingerprint sample to compute repeatable and distinctive information to be used for fingerprint
verification or fingerprint enrollment.
The feature extraction modules maintain one or more contexts for each caller. A context can be created by
calling FX_createContext, and is released with FX_closeContext.
Extraction functions are used to create feature extraction contexts, extract features, and prepare an image for
display.
FX_extractFeatures is the function that extracts the features from the image, which is passed as one of
the arguments. A handle to the context has to be passed to FX_extractFeatures and
FX_getDisplayImage.
FX_init
Initializes the fingerprint extraction module. It reads various internal settings from the registry, initializes the
MC_SETTINGS structure and initializes the lookup tables used for matching.
This function must be called before any other function in the module is called.
Syntax
FX_DLL_INTERFACE FT_RETCODE fx_init(void);
Return Values
Library
dpHFtrEx.lib
FT_OK Initialization successful.
FT_ERR_NO_MEMORY There was not enough memory to initialize the feature extraction
module.
FT_ERR_BAD_INI_SETTING Initialization settings are corrupted.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 48
FX_getVersionInfo
Retrieves the software version of the feature extraction module in the structure of type FT_VERSION_INFO.
Syntax
FX_DLL_INTERFACE void FX_getVersionInfo(
OUT FT_VERSION_INFO_PT fxModuleVersionPt
);
Parameters
Return Values
Library
dpHFtrEx.lib
FX_createContext
Creates a feature extraction context. If this function succeeds, it returns the handle to the context that is
created. All of the operations in this context require this handle.
Syntax
FX_DLL_INTERFACE FT_RETCODE FX_createContext(
OUT FT_HANDLE *fxContext
);
Parameters
Return Values
fxModuleVersionPt [out] Pointer to the buffer containing the software version of the fingerprint
feature extraction module.
FT_OK Function successful.
fxContext [out] Pointer to the memory location where the context handle will be placed.
FT_OK The function succeeded.
FT_ERR_NO_INIT FX_init has not yet been successfully called. The feature
extraction module has not been initialized.
FT_ERR_INVALID_CONTEXT There is not enough memory to create a context.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 49
Library
dpHFtrEx.lib
FX_closeContext
Destroys a feature extraction context created by FX_createContext and releases the allocated resources.
Syntax
FX_DLL_INTERFACE FT_RETCODE FX_closeContext(
IN FT_HANDLE fxContext
);
Parameters
Return Values
Library
dpHFtrEx.lib
FX_terminate
Terminates the fingerprint extraction module and releases all resources associated with it.
Syntax
FX_DLL_INTERFACE FT_RETCODE FX_terminate (void);
Return Values
Library
dplibrary.dll
fxContext [in] Pointer to the context handle of the context to be closed.
FT_OK The function succeeded.
FT_ERR_NO_INIT FX_init not yet been successfully called. The feature extraction
module has not been initialized.
FT_ERR_INVALID_CONTEXT The given feature extraction context is not valid.
FT_OK The function succeeded.
FT_WRN_NO_INIT The feature extraction module has not been initialized.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 50
FX_getFeaturesLen
Retrieves the size of the buffer for the fingerprint feature set. This function returns either the minimum or the
recommended size that provides the best recognition accuracy, or both.
Syntax
FX_DLL_INTERFACE FT_RETCODE FX_getFeaturesLen(
IN FT_FTR_TYPE featureSetPurpose,
OUT int* recommendedFeatureSetSize,
OUT int* minimumFeatureSetSize
);
Parameters
Return Values
Library
dpHFtrEx.lib
featureSetPurpose [in] Feature set purpose. Specifies the purpose for which the
fingerprint feature set is to be created. For a fingerprint feature
set to be used for enrollment, use the value
FT_PRE_REG_FTR; for verification, use FT_VER_FTR.
FT_REG_FTR is not a valid value for this function.
recommendedFeatureSetSize Pointer to the memory receiving the size of the buffer for the
fingerprint feature set recommended for best recognition
accuracy, or NULL.
If NULL is passed, minimumFeatureSetSize must not be
NULL.
minimumFeatureSetSize Pointer to the memory receiving the minimum size of the buffer
for the fingerprint feature set, or NULL.
If NULL is passed, recommendedFeatureSet must not be
NULL.
FT_OK The function succeeded.
FT_ERR_NO_INIT The feature extraction module has not been initialized.
FT_ERR_INVALID_PARAM The featureSetPurpose parameter is not valid.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 51
FX_extractFeatures
Creates a fingerprint feature set by applying fingerprint feature extraction to the fingerprint image obtained
from the fingerprint reader to compute repeatable and distinctive information. Depending on the specified
feature set purpose, this information can be used for either fingerprint enrollment or verification.
Syntax
FX_DLL_INTERFACE FT_RETCODE FX_extractFeatures(
IN FT_HANDLE fxContext,
IN int imageSize,
IN const FT_IMAGE_PTC imagePt,
IN FT_FTR_TYPE featureSetPurpose,
IN int featureSetSize,
OUT FT_BYTE* featureSet,
OUT FT_IMG_QUALITY_PT imageQualityPt,
OUT FT_FTR_QUALITY_PT featuresQualityPt,
OUT FT_BOOL* featureSetCreated
);
Parameter Names
fxContext [in] Handle to the feature extraction context
imageSize [in] Size in bytes of the image obtained from the fingerprint reader.
imagePt [in] Pointer to the buffer that contains the fingerprint image obtained from
the fingerprint reader
featureSetPurpose [in] Feature set purpose. Specifies the purpose for which the fingerprint
feature set is to be created. For a fingerprint feature set to be used for
enrollment, use the value FT_PRE_REG_FTR; for verification, use
FT_VER_FTR. FT_REG_FTR is not a valid value for this function.
featureSetSize [in] Fingerprint feature set size. This parameter is the size, in bytes, of the
fingerprint feature set. Use the FX_getFeaturesLen function (page 50)
to obtain information about which fingerprint feature set size to use.
featureSet [out] Pointer to the buffer location receiving the fingerprint feature set
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 52
Return Values
imageQualityPt [out] Pointer to the buffer containing information about the quality of the
fingerprint image. Image quality is represented by one of the following
values:
FT_GOOD_IMG. The fingerprint image quality is good.
FT_IMG_TOO_LIGHT. The fingerprint image is too light.
FT_IMG_TOO_DARK. The fingerprint image is too dark.
FT_IMG_TOO_NOISY. The fingerprint image is too blurred.
FT_LOW_CONTRAST. The fingerprint image contrast is too low.
FT_UNKNOWN_IMG_QUALITY. The fingerprint image quality is
undetermined.
featuresQualityPt [out] Pointer to the buffer containing information about the quality of the
fingerprint features. If the fingerprint image quality (imageQualityPt)
is not equal to the value FT_GOOD_IMG, extraction is not attempted, and
the parameter is set to FT_UNKNOWN_FTR_QUALITY.
Fingerprint features quality is represented by one of the following values:
FT_GOOD_FTR. The fingerprint features quality is good.
FT_NOT_ENOUGH_FTR. There are not enough fingerprint features.
FT_NO_CENTRAL_REGION. The fingerprint image does not contain the
central portion of the finger.
FT_AREA_TOO_SMALL. The fingerprint image area is too small.
FT_UNKNOWN_FTR_QUALITY. Quality cannot be determined.
featureSetCreated [out] Pointer to the memory receiving the value of whether the fingerprint
feature set is created. If the value of this parameter is FT_TRUE, the
fingerprint feature set was written to featureSet. If the value is
FT_FALSE, a fingerprint feature set was not created.
FT_OK The function succeeded.
FT_ERR_NO_INIT The fingerprint feature extraction module is not initialized.
FT_ERR_INVALID_CONTEXT The given feature extraction context is not valid.
FT_ERR_INVALID_PARAM One or more parameters are not valid.
FT_ERR_NO_MEMORY Not enough memory to perform fingerprint feature extraction.
FT_ERR_UNKNOWN_DEVICE The fingerprint reader is not supported.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 53
Library
dpHFtrEx.lib
FX_getDisplayImage
Prepares the fingerprint image obtained from the fingerprint reader for display. This may involve resizing,
changing the number of grayscale intensity levels, rotating, and otherwise processing the fingerprint image to
ensure that it displays well. The fingerprint image passed to the FX_getDisplayImage function is the
same fingerprint image used by the FX_extractFeatures function (page 51).
Syntax
FX_DLL_INTERFACE FT_RETCODE FX_getDisplayImage(
IN FT_HANDLE fxContext,
IN const FT_IMAGE_PTC imagePt,
IN const FT_IMAGE_SIZE_PT pImageSize,
IN const FT_BOOL imageRotation,
IN const int numIntensityLevels,
OUT FT_IMAGE_PT pImageBuffer
);
Parameter Names
fxContext [in] Handle to the feature extraction context
imagePt [in] Pointer to the buffer containing the fingerprint image obtained from
the fingerprint reader
pImageSize [in] Pointer to the buffer containing the requested dimensions (width and
height) of the fingerprint image
imageRotation [in] Indicates whether the fingerprint image is to be rotated. If the value of
this parameter is equal to FT_TRUE, the fingerprint image is rotated. If
the value is FT_FALSE, the fingerprint image is not rotated.
numIntensityLevels [in] Requested number of grayscale intensity levels. Valid values are
integers between 1 and 256.
pImageBuffer [out] Pointer to the buffer which will be filled with display image bytes.
Buffer must be large enough to hold the image information that will be
returned, i.e. width times height of the image.
Chapter 5: Core API Reference Extraction Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 54
Return Values
Library
dpHFtrEx.lib
FT_OK The function succeeded.
FT_ERR_NO_INIT The fingerprint feature extraction module is not initialized.
FT_ERR_INVALID_CONTEXT The given feature extraction context is not valid.
FT_ERR_INVALID_PARAM One or more parameters are not valid.
FT_ERR_NO_MEMORY There is not enough memory to perform the function.
FT_ERR_UNKNOWN_DEVICE The fingerprint reader is not supported.
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 55
Matching Functions Reference
The dpMatch module contains code that compares a fingerprint template and a fingerprint feature set and
calculates a score that indicates how likely it is that they come from the same finger.
The dpMatch module has a structure of type MC_SETTINGS, which is initialized by MC_init.
Most of the functions must be called in a particular context, which is specified by passing a context handle as
the first argument.
MC_init
Initializes the fingerprint comparison module. This function must be called before any other functions in the
module are called.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_init(void);
Return Values
Library
dpHMatch.lib
MC_getVersionInfo
Retrieves the software version information of the fingerprint comparison module.
Syntax
MC_DLL_INTERFACE void MC_getVersionInfo(
OUT FT_VERSION_INFO_PT mcModuleVersionPt
);
Parameters
FT_OK The function succeeded.
FT_ERR_BAD_INI_SETTING Initialization settings are corrupted.
FT_ERR_NO_MEMORY There is not enough memory to initialize the fingerprint comparison
module.
mcModuleVersionPt [out] Pointer to software version of the fingerprint comparison module
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 56
Return Values
Library
dpHMatch.lib
MC_getSettings
Retrieves the current fingerprint comparison module settings in the structure of type MC_SETTINGS. This
function provides the number of fingerprint feature sets required for the purpose of fingerprint enrollment.
This setting is read-only.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_getSettings(
OUT MC_SETTINGS_PT mcSettingsPt
);
Parameters
Return Values
Library
dpHMatch.lib
MC_createContext
Creates a context for the fingerprint comparison module. If this function succeeds, it returns the handle to the
context that is created. All of the operations in this context require this handle.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_createContext(
OUT FT_HANDLE* mcContext
);
Parameters
FT_OK Function was completed successfully.
mcSettingsPt [out] Pointer to the structure of the fingerprint comparison module settings
FT_OK Function was completed successfully.
mcContext [out] Pointer to the memory receiving the handle to the comparison context
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 57
Return Values
Library
dpHMatch.lib
MC_closeContext
Destroys a comparison context and releases the resources associated with it.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_closeContext(
IN FT_HANDLE mcContext
);
Parameters
Return Values
Library
dpHMatch.lib
MC_getSecurityLevel
Retrieves the current security level of the specified comparison context in terms of the false accept rate (FAR).
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_getSecurityLevel(
IN FT_HANDLE mcContext,
OUT FT_FA_RATE* targetFar
);
Parameters
FT_OK Function was completed successfully.
mcContext [in] Handle to the comparison module context
FT_OK Function was completed successfully.
mcContext [in] Handle to the comparison context
targetFar [out] Pointer to the memory receiving the target FAR for the comparison context
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 58
Return Values
Library
dpHMatch.lib
MC_setSecurityLevel
Sets the security level of a comparison context by specifying a target false accept rate (FAR). The lower the value
of the FAR, the higher the security level and the higher the target false reject rate (FRR). (See False Positives and
False Negatives on page 19 for more information about FAR and FRR.)
IMPORTANT: This function is to be used for comparison contexts only. Do not specify a security level for a
feature extraction context.
IMPORTANT: Although the default value of MED_SEC_FA_RATE is adequate for most applications, you
might require a lower or higher value to meet your needs. If you decide to use a value other than
the default, be sure that you understand the consequences of doing so. Refer to Appendix A on
page 91 for more information about setting the value of the FAR.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_setSecurityLevel(
IN FT_HANDLE mcContext,
IN FT_FA_RATE targetFar
);
Parameters
Return Values
FT_OK Function was completed successfully.
mcContext [in] Handle to the comparison context
targetFar [in] Target FAR. For high security, use the low value of FAR defined in
HIGH_SEC_FA_RATE; for mid-range security, use the mid-range value of FAR
defined in MED_SEC_FA_RATE (the default); and for low security, use the high
value of FAR defined in LOW_SEC_FA_RATE.
FR_OK The function is successful
FR_ERR_NO_INIT The fingerprint comparison module is not initialized.
FR_ERR_INVALID_PARAM The value of the parameter targetFar <= 0.0 or >= 100.0, or
the specified comparison context is not valid.
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 59
Library
dpHMatch.lib
MC_terminate
Terminates the fingerprint comparison module and releases the resources associated with it.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_terminate(void);
Return Values
Library
dpHMatch.lib
MC_getFeaturesLen
Retrieves the size of the buffer for the fingerprint template. This function returns either the minimum or the
recommended size that provides the best recognition accuracy, or both.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_getFeaturesLen(
IN FT_FTR_TYPE featureSetPurpose,
IN int reserved,
OUT int* recommendedTemplateSize,
OUT int* minimumTemplateSize
);
FR_ERR_INVALID_CONTEXT The specified comparison context is not valid.
FR_WRN_INTERNAL The value of the parameter targetFar is unacceptably high and
was reduced to an internally defined value.
FT_OK Termination was successful.
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 60
Parameters
Return Values
Library
dpHMatch.lib
MC_generateRegFeatures
Creates a fingerprint template to be used for later comparison with a fingerprint feature set. This function,
known as fingerprint enrollment, computes the fingerprint template using the specified number of fingerprint
feature sets (numFeatureSets) successfully returned by the FX_extractFeatures function
(page 51).
featureSetPurpose [in] Feature set purpose. Specifies the purpose for which the
fingerprint feature set is to be created. For a feature set to be used for
enrollment, use the value FT_PRE_REG_FTR; for verification, use
FT_VER_FTR; and for a fingerprint template, use FT_REG_FTR.
reserved [in] This parameter is deprecated and should always be set to 0.
recommendedTemplateSize [out] Pointer to the memory receiving the size of the buffer for the
fingerprint template recommended for best recognition accuracy, or
NULL. If NULL is passed, minimumTemplateSize must not
be NULL.
minimumTemplateSize [out] Pointer to the memory receiving the minimum size of the
buffer for the fingerprint template, or NULL. If NULL is passed,
recommendedTemplateSize must not be NULL.
FT_OK Termination was successful.
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 61
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_generateRegFeatures(
IN FT_HANDLE mcContext,
IN int reserved0,
IN int numFeatureSets,
IN int featureSetSize,
IN FT_BYTE* featureSet[],
IN int templateSize,
OUT FT_BYTE* template,
OUT FT_BYTE reserved1[],
OUT FT_BOOL* templateCreated
);
Parameters
mcContext [in] Handle to the comparison context
reserved0 [in] This parameter is deprecated and should always be set to 0.
numFeatureSets [in] Number of input fingerprint feature sets, which is the number specified in
the numFeatureSets field of the structure of type MC_SETTINGS.
featureSetSize [in] Size of the buffer for the fingerprint feature set (assuming that the size of
each fingerprint feature set is the same)
featureSet[] [in] Array of pointers to the locations of the buffers for each fingerprint feature
set
templateSize [in] Size of the fingerprint template
template [out] Pointer to the location of the buffer receiving the fingerprint template
reserved1[] [out] This parameter is deprecated and should be set to NULL.
templateCreated [out] Pointer to the memory that will receive the value of whether the
template is created. If the value of this parameter is FT_TRUE, the
fingerprint template was written to template. If the value is FT_FALSE,
a template was not created.
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 62
Return Values
Library
dpHMatch.lib
MC_verifyFeaturesEx
Performs a one-to-one comparison of a fingerprint feature set with a fingerprint template produced at
enrollment and makes a decision of match or non-match. This function is known as fingerprint verification. The
function succeeds if the comparison score is high enough given the security level of the specified comparison
context.
Syntax
MC_DLL_INTERFACE FT_RETCODE MC_verifyFeaturesEx(
IN FT_HANDLE mcContext,
IN int templateSize,
IN OUT FT_BYTE* template,
IN int featureSetSize,
IN FT_BYTE* featureSet,
IN int reserved0,
OUT void* reserved1,
OUT int reserved2[],
OUT FT_VER_SCORE_PT reserved3,
OUT double* achievedFar,
OUT FT_BOOL* comparisonDecision
);
FR_OK The function succeeded.
FR_ERR_NO_INIT The fingerprint comparison module is not initialized.
FR_ERR_NO_MEMORY There is not enough memory to perform the function.
FR_ERR_BAD_INI_SETTING Initialization settings are corrupted.
FR_ERR_INVALID_BUFFER A buffer is not valid.
FR_ERR_INVALID_PARAM One or more parameters are not valid.
FR_ERR_INTERNAL An internal error occurred.
Chapter 5: Core API Reference Matching Functions Reference
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 63
Parameters
Return Values
Library
dpHMatch.lib
mcContext [in] Handle to the comparison context
templateSize [in] Size of the fingerprint template
template [in, out] Pointer to the location of the buffer containing the fingerprint
template
featureSetSize [in] Size of the fingerprint feature set
featureSet [in] Pointer to the location of the buffer containing the fingerprint feature
set
reserved0 [in] This parameter is deprecated and should always be 0.
reserved1 [in] This parameter is deprecated and should always be NULL.
reserved2[] [out] This parameter is deprecated and should always be NULL.
reserved3 [out] This parameter is deprecated and should always be NULL.
achievedFar [out] Pointer to the value of the achieved FAR for this comparison. If the
achieved FAR is not required, a NULL pointer can be passed.
comparisonDecision [out] Pointer to the memory that will receive the comparison decision. This
parameter indicates whether the comparison of the fingerprint feature set
and the fingerprint template resulted in a decision of match (FT_TRUE)
or non-match (FT_FALSE) at the security level of the specified
comparison context.
FR_OK The function succeeded.
FR_ERR_NO_INIT The fingerprint comparison module is not initialized.
FR_ERR_NO_MEMORY There is not enough memory to perform the function.
FR_ERR_BAD_INI_SETTING Initialization settings are corrupted.
FR_ERR_INVALID_BUFFER An internal error occurred.
FR_ERR_INVALID_PARAM One or more parameters are not valid.
Chapter 5: Core API Reference Data Structures
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 64
Data Structures
This section defines the One Touch for Windows: C/C++ Edition Core API data structures.
DP_DEVICE_INFO
Device information structure.
Syntax
typedef struct DP_DEVICE_INFO
{
GUID DeviceUid;
DP_DEVICE_UID_TYPE eUidType;
DP_DEVICE_MODALITY eDeviceModality;
DP_DEVICE_TECHNOLOGY eDeviceTech;
DP_HW_INFO HwInfo;
} DP_DEVICE_INFO, * PDP_DEVICE_INFO;
Data Fields
DP_DEVICE_VERSION
Device hardware/firmware version number structure.
Syntax
typedef struct DP_DEVICE_VERSION
{
ULONG uMajor;
ULONG uMinor;
ULONG uBuild;
} DP_DEVICE_VERSION;
DeviceUid Device unique identifier
eUidType Defines whether the UID is persistent or volatile
eDeviceModality Defines which modality the device is being used in
eDeviceTech Defines the type of technology used in the device
HwInfo Describes the device hardware
Chapter 5: Core API Reference DP_HW_INFO
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 65
Data Fields
DP_HW_INFO
Device hardware information structure.
Syntax
typedef struct DP_HW_INF
{
unsigned int uLanguageId;
wchar_t szVendor[DP_MAX_USB_STRING_SIZE];
wchar_t szProduct[DP_MAX_USB_STRING_SIZE];
wchar_t szSerialNb[DP_MAX_USB_STRING_SIZE];
DP_DEVICE_VERSION HardwareRevision
DP_DEVICE_VERSION FirmwareRevision;
} DP_HW_INFO, * PDP_HW_INFO;
Data Fields
wMajor Major version of the product
wMinor Minor version of the product
wRevision Revision number of the product
uBuild Build number of the product
uLanguageId Device language
szVendor Manufacturer name, for example, “DigitalPersona, Inc.”
szProduct Build number of device hardware/firmware
Chapter 5: Core API Reference DP_PRODUCT_VERSION
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 66
DP_PRODUCT_VERSION
DigitalPersona product version structure.
Syntax
typedef struct DP_PRODUCT_VERSION
{
WORD wMajor;
WORD wMinor;
WORD wRevision;
WORD wBuild;
} DP_PRODUCT_VERSION, * PDP_PRODUCT_VERSION;
Data Fields
FT_VERSION_INFO
Fingerprint feature extraction or fingerprint comparison module version information structure.
Syntax
typedef struct
{
unsigned major;
unsigned minor;
unsigned revision;
unsigned build;
} FT_VERSION_INFO, * FT_VERSION_INFO_PT;
wMajor Major version of the product
wMinor Minor version of the product
wRevision Revision number of the product
uBuild Build number of the product
Chapter 5: Core API Reference MC_SETTINGS
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 67
Data Fields
MC_SETTINGS
Fingerprint comparison module settings structure.
Syntax
typedef struct{
int numPreRegFeatures;
} MC_SETTINGS, * MC_SETTINGS_PT;
Data Fields
Major Major version number
Minor Minor version number
Revision Revision number number
Build Build number
numPreRegFeatures Number of fingerprint feature sets required to generate a fingerprint
template
Chapter 5: Core API Reference Enumerations
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 68
Enumerations
This section defines the One Touch for Windows: C/C++ Edition Core API enumerations.
DP_ACQUISITION_PRIORITY
Defines the priority of a fingerprint sample capture operation performed by a fingerprint reader.
Syntax
typedef enum DP_ACQUISITION_PRIORITY
{
DP_PRIORITY_HIGH= 1,
DP_PRIORITY_NORMAL= 2,
DP_PRIORITY_LOW = 3
} DP_ACQUISITION_PRIORITY;
Values
DP_DEVICE_MODALITY
Defines the modality that a fingerprint reader uses to capture fingerprint samples.
Syntax
typedef enum DP_DEVICE_MODALITY
{
DP_UNKNOWN_DEVICE_MODALITY = 0,
DP_SWIPE_DEVICE,
DP_AREA_DEVICE,
DP_DEVICE_MODALITY_NUM,
} DP_DEVICE_MODALITY;
DP_PRIORITY_HIGH Highest priority (RESERVED. For internal use only.)
DP_PRIORITY_NORMAL Standard priority
DP_PRIORITY_LOW Lowest priority
Chapter 5: Core API Reference DP_DEVICE_TECHNOLOGY
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 69
Values
DP_DEVICE_TECHNOLOGY
Defines the fingerprint reader technology.
Syntax
typedef enum DP_DEVICE_TECHNOLOGY
{
DP_UNKNOWN_DEVICE_TECHNOLOGY = 0,
DP_OPTICAL_DEVICE,
DP_CAPACITIVE_DEVICE,
DP_THERMAL_DEVICE,
DP_PRESSURE_DEVICE,
DP_DEVICE_TECHNOLOGY_NUM,
} DP_DEVICE_TECHNOLOGY;
Values
DP_UNKNOWN_DEVICE_MODALITY Device modality is unknown
DP_SWIPE_DEVICE Swipe mode device
DP_AREA_DEVICE Area mode device
DP_DEVICE_MODALITY_NUM Count of different modalities defined
DP_UNKNOWN_DEVICE_TECHNOLOGY The technology used in the device is not known.
DP_OPTICAL_DEVICE The technology used in the device is optical.
DP_CAPACITIVE_DEVICE The technology used in the device is capacitive.
DP_THERMAL_DEVICE The technology used in the device is thermal.
DP_PRESSURE_DEVICE The technology used in the device is pressure.
DP_DEVICE_TECHNOLOGY_NUM Count of the different technologies defined.
Chapter 5: Core API Reference DP_DEVICE_UID_TYPE
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 70
DP_DEVICE_UID_TYPE
Defines the type of UUID identifying the device.
Syntax
typedef enum DP_DEVICE_UID_TYPE
{
DP_PERSISTENT_DEVICE_UID = 0,
DP_VOLATILE_DEVICE_UID,
} DP_DEVICE_UID_TYPE;
Values
DP_SAMPLE_QUALITY
Defines the quality of the fingerprint sample.
Syntax
typedef enum DP_SAMPLE_QUALITY {
DP_QUALITY_GOOD = 0,
DP_QUALITY_NONE = 1,
DP_QUALITY_TOOLIGHT = 2,
DP_QUALITY_TOODARK = 3,
DP_QUALITY_TOONOISY = 4,
DP_QUALITY_LOWCONTR = 5,
DP_QUALITY_FTRNOTENOUGH = 6,
DP_QUALITY_NOCENTRAL = 7,
DP_QUALITY_NOFINGER = 8,
DP_QUALITY_TOOHIGH = 9,
DP_QUALITY_TOOLOW = 10,
DP_QUALITY_TOOLEFT = 11,
DP_QUALITY_TOORIGHT = 12,
DP_QUALITY_TOOSTRANGE = 13,
DP_QUALITY_TOOFAST = 14,
DP_QUALITY_TOOSKEWED = 15,
DP_QUALITY_TOOSHORT = 16,
DP_QUALITY_TOOSLOW = 17,
} DP_SAMPLE_QUALITY;
DP_PERSISTENT_DEVICE_UID Unique hardware identifier. Hardware dependent.
DP_VOLATILE_DEVICE_UID Software generated identifier.
Chapter 5: Core API Reference DP_SAMPLE_QUALITY
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 71
Values
DP_QUALITY_GOOD The image is of good quality.
DP_QUALITY_NONE There is no image.
DP_QUALITY_TOOLIGHT The image is too light.
DP_QUALITY_TOODARK The image is too dark.
DP_QUALITY_TOONOISY The image is too noisy.
DP_QUALITY_LOWCONTR The image contrast is too low.
DP_QUALITY_FTRNOTENOUGH The image does not contain enough information.
DP_QUALITY_NOCENTRAL The image is not centered.
DP_QUALITY_NOFINGER The scanned object is not a finger.
DP_QUALITY_TOOHIGH The finger was too high on the swipe sensor.
DP_QUALITY_TOOLOW The finger was too low on the swipe sensor.
DP_QUALITY_TOOLEFT The finger was too close to left border of the swipe sensor.
DP_QUALITY_TOORIGHT The finger was too close to right border of the swipe sensor.
DP_QUALITY_TOOSTRANGE The scan looks strange.
DP_QUALITY_TOOFAST The finger was swiped too quickly.
DP_QUALITY_TOOSKEWED The image is too skewed.
DP_QUALITY_TOOSHORT The image is too short.
DP_QUALITY_TOOSLOW The finger was swiped too slowly.
Chapter 5: Core API Reference FT_IMG_QUALITY
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 72
FT_IMG_QUALITY
Defines the image quality.
typedef enum
{
FT_GOOD_IMG,
FT_IMG_TOO_LIGHT,
FT_IMG_TOO_DARK,
FT_IMG_TOO_NOISY,
FT_LOW_CONTRAST,
FT_UNKNOWN_IMG_QUALITY
} FT_IMG_QUALITY, *FT_IMG_QUALITY_PT;
Values
FT_FTR_QUALITY
Defines the fingerprint features quality.
typedef enum
{
FT_GOOD_FTR,
FT_NOT_ENOUGH_FTR,
FT_NO_CENTRAL_REGION,
FT_UNKNOWN_FTR_QUALITY,
FT_AREA_TOO_SMALL
} FT_FTR_QUALITY, * FT_FTR_QUALITY_PT;
FT_GOOD_IMG The fingerprint image quality is good.
FT_IMG_TOO_LIGHT The fingerprint image is too light.
FT_IMG_TOO_DARK The fingerprint image is too dark.
FT_IMG_TOO_NOISY The fingerprint image is too blurred.
FT_LOW_CONTRAST The fingerprint image contrast is too low.
FT_UNKNOWN_IMG_QUALITY The fingerprint image quality is undetermined.
Chapter 5: Core API Reference FT_FTR_TYPE
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 73
Values
FT_FTR_TYPE
Defines the feature set purpose.
Syntax
typedef enum
{
FT_PRE_REG_FTR,
FT_REG_FTR,
} FT_FTR_TYPE;
Values
FT_GOOD_FTR The fingerprint features quality is good.
FT_NOT_ENOUGH_FTR There are not enough fingerprint features.
FT_NO_CENTRAL_REGION The fingerprint image does not contain the central portion of the
finger.
FT_UNKNOWN_FTR_QUALITY The fingerprint features quality is undetermined.
FT_AREA_TOO_SMALL The fingerprint image area is too small.
FT_PRE_REG_FTR Value for a fingerprint feature set to be used for enrollment
FT_REG_FTR Value for a fingerprint template
FT_VER_FTR Value for a fingerprint feature set to be used for verification
Chapter 5: Core API Reference Type Definitions and Constants
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 74
Type Definitions and Constants
This section defines the One Touch for Windows: C/C++ Edition Core API type definitions and constants.
DFLT_FA_RATE MED_SEC_FA_RATE
Default value for target FAR.
Syntax
#define DFLT_FA_RATE MED_SEC_FA_RATE
DP_SAMPLE_TYPE_IMAGE
Type of fingerprint sample needed. This value is used in the uSampleType parameter of the
DPFPCreateAcquisition function (page 38).
Syntax
#define DP_SAMPLE_TYPE_IMAGE 4
FT_FA_RATE
Target false accept rate (FAR). These are percentages, that is, a value of 0.1 means 0.1% = 1/1000. */
Syntax
typedef double FT_FA_RATE;
HDPOPERATION
Operation handle.
Syntax
typedef unsigned long HDPOPERATION
HIGH_SEC_FA_RATE
High security/low value for target FAR.
Syntax
#define HIGH_SEC_FA_RATE 0.0001f
Chapter 5: Core API Reference LOW_SEC_FA_RATE
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 75
LOW_SEC_FA_RATE
Low security/high value for target FAR.
Syntax
#define LOW_SEC_FA_RATE 0.0100f
MED_SEC_FA_RATE
Mid-range security/mid-range value for target FAR.
Syntax
#define MED_SEC_FA_RATE 0.0010f
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 76
User Interface API Reference 6
This chapter provides a reference to the User Interface API (DPUIAPI) wrapper that simplifies access to the entire
functionality available in the Core API described in the previous chapter. The wrapper provides a premade user
interface that handles device component, fingerprint enrollment, and fingerprint verification tasks through a
few simple functions and two callbacks.
Functions
DPEnrollUI
This function displays the user interface for enrolling the fingerprints and returns after closing of the user
interface. It does not store the fingerprint template; instead, it calls the application-defined function
DPENROLLMENTPROC for each enrollment or deletion of a fingerprint.
Syntax
DPFPUI_STDAPI DPEnrollUI(HWND hParentWnd,
USHORT usMaxEnrollFingerCount,
PULONGpulEnrolledFingersMask,
DPENROLLMENTPROC dpEnrollmentProc,
LPVOID pUserData
);
Parameters
hParentWnd [in] Handle to the parent window.
usMaxEnrollFingerCount [in] Maximum number of fingers allowed to be enrolled. The value
should be between 1 and 10 (both inclusive).
pulEnrolledFingersMask [in, out] Bitwise mask that specifies the fingers enrolled. For possible
values, see Table 4.
dpEnrollmentProc [in] Pointer to the function to be notified when a fingerprint
template is available for enrollment.
pUserData [in] The pointer to the user data.
Chapter 6: User Interface API Reference DPEnrollUI
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 77
The pulEnrolledFingersMask parameter contains a combination of the values representing a user’s
enrolled fingerprints. For example, if a user’s right index fingerprint and right middle fingerprint are
enrolled, the value of this property is 00000000 011000000, or 192.
Return Values
Library
DPFPUI.dll
Table 4. Values for the pulEnrolledFingersMask parameter
Finger Binary Representation Integer Representation
Left little finger 000000000 000000001 1
Left ring finger 000000000 000000010 2
Left middle finger 000000000 000000100 4
Left index finger 000000000 000001000 8
Left thumb 000000000 000010000 16
Right thumb 000000000 000100000 32
Right index finger 000000000 001000000 64
Right middle finger 000000000 010000000 128
Right ring finger 000000000 100000000 256
Right little finger 000000001 000000000 512
S_OK Function successfully completed.
Chapter 6: User Interface API Reference DPVerifyUI
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 78
DPVerifyUI
Displays the fingerprint verification user interface. The title, text, and banner image of the fingerprint
verification user interface can be customized.
Syntax
DPFPUI_STDAPI DPVerifyUI(
HWND hParentWnd,
DPVERIFYPROC dpVerifyProc,
LPCWSTR lpszCaption,
LPCWSTR lpszText,
HBITMAP hBanner,
LPVOID pUserData
);
Parameters
Return Values
Library
DPFPUI.dll
hParentWnd [in] Handle to the parent window.
dpVerifyProc [in] Pointer to the callback function.
lpszCaption [in] The caption of the dialog box.
lpszText [in] The text of the dialog box.
hBanner [in] The custom banner bitmap.
pUserData [in] The pointer to the user data.
S_OK Fingerprint verification user interface successfully displayed.
0x800704c7 Fingerprint verification canceled by user.
E_ABORT Fingerprint verification was aborted by callback function.
Chapter 6: User Interface API Reference Callbacks
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 79
Callbacks
A callback is executable code that is passed as an argument to other code. It allows a lower-level software layer
to call a subroutine (or function) defined in a higher-level layer.
DPENROLLMENTPROC
This is the application-provided callback function. This function is called while enrolling a new fingerprint or
deleting an enrolled fingerprint. The application should handle the storing of new fingerprint templates for
comparison or deleting of an enrolled fingerprint template in this callback. The application can display its own
success or error messages.
typedef HRESULT (CALLBACK *DPENROLLMENTPROC)(
HWND hParentWnd,
DP_ENROLLMENT_ACTION enrollmentAction,
UINT uiFingerIndex,
PDATA_BLOB pFingerprintTemplate,
LPVOID pUserData
);
Parameters
The uiFingerIndex parameter contains the index value of the finger associated with a fingerprint
template to be enrolled or with a fingerprint template to be deleted, as defined in ANSI/NIST-ITL 1. The index
values are assigned to the graphical representation of the fingers on the hands in the user interface. All
possible values are listed in Table 5.
hParentWnd [in] Handle to the parent window.
enrollmentAction [in] Specifies whether to enroll the fingerprint or delete it. Values are
DP_ENROLLMENT_ADD or DP_ENROLLMENT_DELETE.
uiFingerIndex [in] The index of the fingerprint to be enrolled, as defined in ANSI/NIST-
ITL 1. For possible values, see Table 5.
pFingerprintTemplate [in] If the enrollmentAction parameter is
DP_ENROLLMENT_ADD, then this contains a pointer to the
fingerprint template. Otherwise it is NULL.
pUserData [in] Pointer to the user data.
Chapter 6: User Interface API Reference DPVERIFYPROC
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 80
Return Values
Library
DPFPUI.dll
DPVERIFYPROC
This is an application-provided callback function. It is called when a fingerprint feature set is ready for
comparison. The application should handle the comparison of this fingerprint feature set against the
fingerprint templates.
Syntax
typedef HRESULT (CALLBACK *DPVERIFYPROC)(
HWND hParentWnd,
PDATA_BLOB pVerificationFeatureSet,
LPVOID pUserData
);
Parameters
Table 5. Values for the uiFingerIndex parameter
Finger Index Value Finger Index Value
Right thumb 1 Left thumb 6
Right index finger 2 Left index finger 7
Right middle finger 3 Left middle finger 8
Right ring finger 4 Left ring finger 9
Right little finger 5 Left little finger 10
S_OK The fingerprint template was successfully saved.
0x800704c7 The operation could not be completed. A retry should be performed.
hParentWnd [in] Handle to the parent window.
pVerificationFeatureSet [in] Pointer to the fingerprint feature set to be verified.
pUserData [in] Pointer to the user data.
Chapter 6: User Interface API Reference DPVERIFYPROC
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 81
Return Values
Library
DPFPUI.dll
S_OK The fingerprint feature set to be verified matches one of the fingerprint templates.
0x800704c7 The fingerprint feature set to be verified did not match any of the fingerprint
templates. A retry should be performed.
Chapter 6: User Interface API Reference Enumerations
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 82
Enumerations
DP_ENROLLMENT_ACTION
Defines the requested fingerprint enrollment action.
Syntax
typedef enum
{
DP_ENROLLMENT_ADD,
DP_ENROLLMENT_DELETE
} DP_ENROLLMENT_ACTION;
Values
DP_ENROLLMET_ADD Enroll a fingerprint template.
DP_ENROLLMET_DELETE Delete a fingerprint template.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 83
Events Notifications and Return Codes 7
This chapter defines the notification events and return codes used within the One Touch for Windows: C/C++
Edition SDK.
Events Notifications
During the creation of an operation, the client application specifies the handle of the window to be notified on
operation-related events as well as the window message to be sent as a notification. The wParam of the
message specifies the event type. The value of lParam is event-specific.
Value Defines Description
0WN_COMPLETED Operation completed successfully. The fingerprint image is returned in
lParam as pointer to DATA_BLOB structure.
1WN_ERROR An error occurred. The error code is returned in lParam.
2WN_DISCONNECT The device has been disconnected. The pointer to device UID is returned
in lParam.
3WN_RECONNECT The device has been reconnected. The pointer to device UID is returned
in lParam.
4WN_SAMPLEQUALITY Provides information about the quality of the fingerprint image. lParam
contains the fingerprint image quality listed in the enum of type
DP_SAMPLE_QUALITY.
5WN_FINGER_TOUCHED The device has been touched.
6WN_FINGER_GONE The finger has been removed from the device.
7WN_IMAGE_READY An image is ready from the device. The pointer to device UID is returned
in lParam.
10 WN_OPERATION_STOPPED Sent when an operation was stopped by calling
DPFPStopAcquisition.
Chapter 7: Events Notifications and Return Codes Return Codes
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 84
Return Codes
Value Return Code Description
0FT_OK The function succeeded.
1FT_WRN_NO_INIT The fingerprint feature extraction module or the fingerprint
comparison module are not initialized.
8FT_WRN_INTERNAL An internal error occurred.
9FT_WRN_KEY_NOT_FOUND The fingerprint feature extraction module or the fingerprint
comparison module could not find an initialization setting.
11 FT_WRN_UNKNOWN_DEVICE The fingerprint reader is not known.
12 FT_WRN_TIMEOUT The function has timed out.
-1 FT_ERR_NO_INIT The fingerprint feature extraction module or the fingerprint
comparison module is not initialized.
-2 FT_ERR_INVALID_PARAM One or more parameters are not valid.
-3 FT_ERR_NOT_IMPLEMENTED The called function was not implemented
-4 FT_ERR_IO A generic I/O file error occurred.
-7 FT_ERR_NO_MEMORY There is not enough memory to perform the action.
-8 FT_ERR_INTERNAL An unknown internal error occurred.
-9 FT_ERR_BAD_INI_SETTING Initialization settings are corrupted.
-10 FT_ERR_UNKNOWN_DEVICE The fingerprint reader is not known.
-11 FT_ERR_INVALID_BUFFER A buffer is not valid.
-16 FT_ERR_FEAT_LEN_TOO_SHORT The specified fingerprint feature set or fingerprint template buffer
size is too small.
-17 FT_ERR_INVALID_CONTEXT The given context is not valid.
-29 FT_ERR_INVALID_FTRS_TYPE The feature set purpose is not valid.
-32 FT_ERR_FTRS_INVALID Decrypted fingerprint features are not valid. Decryption may have
failed.
-33 FT_ERR_UNKNOWN_EXCEPTION An unknown exception occurred.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 85
Developing Citrix-aware applications 8
This SDK includes support for fingerprint authentication through Windows Terminal Services (including
Remote Desktop Connection) and through a Citrix connection to Metaframe Presentation Server using a client
from the Citrix Presentation Server Client package.
The following types of Citrix clients are supported for fingerprint authentication:
Program Neighborhood
Program Neighborhood Agent
Web Client
In order to utilize this support, your application (or the end-user) will need to copy a file to the client computer
and register it. The name of the file is DPICACnt.dll, and it is located in the "Misc\Citrix Support" folder in the
product package.
To deploy the DigitalPersona library for Citrix support:
1. Locate the DPICACnt.dll file in the "Misc\Citrix Support" folder of your software package..
2. Copy the file to the folder on the client computer where the Citrix client components are located (i.e. for
the Program Neighborhood client it might be the "Program Files\Citrix\ICA Client" folder).
3. Using the regsvr32.exe program, register the DPICACnt.dll library.
If you have several Citrix clients installed on a computer, deploy the DPICACnt.dll library to the Citrix client
folder for each client.
If your application will also be working with Pro Workstation 4.2.0 and later or Pro Kiosk 4.2.0 and later, you will
need to inform the end-user’s administrator that they will need to enable two Group Policy Objects (GPOs),
"Use DigitalPersona Pro Server for authentication" and "Allow Fingerprint Data Redirection". For information on
how to enable these policies, see the "DigitalPersona Pro for AD Guide.pdf" located in the DigitalPersona Pro
Server software package.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 86
Redistribution 9
You may redistribute the files in the RTE\Install and the Redist folders in any of the One Touch for Windows SDK
software packages to your end users pursuant to the terms of the end user license agreement (EULA),
attendant to the software and located in the Docs folder in the SDK software package.
When you develop a product based on the One Touch for Windows SDK, you need to provide the
redistributables to your end users. These files are designed and licensed for use with your application. You may
include the installation files located in the RTE\Install folder in your application, or you may incorporate the
redistributables directly into your installer. You may also use the merge modules located in the Redist folder in
the SDK software package to create your own MSI installer.
Per the terms of the EULA, DigitalPersona grants you a non-transferable, non-exclusive, worldwide license to
redistribute, either directly or via the respective merge modules, the following files contained in the RTE\Install
and Redist folders in the One Touch for Windows SDK software package to your end users and to incorporate
these files into derivative works for sale and distribution:
RTE\Install Folder
InstallOnly.bat
Setup.exe
Setup.msi
UninstallOnly.bat
Redist Folder
The following table indicates which merge modules are required to support each development language and
OS.
Merge module C/C++ COM/ActiveX .NET Java
32-bit 64-bit 32-bit 64-bit 32-bit 64-bit 32-bit 64-bit
DpDrivers.msm XXXXXXXX
DpPolicies_OTW.msm XXXXXXXX
DpCore.msm XXXXXXXX
DpCore_x64.msm XXXX
DpProCore.msm X X X X
DpProCore_x64.msm X X X X
Chapter 9: Redistribution Redist Folder
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 87
The merge modules, and the files that they contain, are listed below alphabetically.
DpCore.msm
This merge module contains the following files:
Dpcoper2.dll
Dpdevice2.dll
Dpfpapi.dll
Dphostw.exe
Dpmux.dll
Dpmsg.dll
Dpclback.dll
DPCrStor.dll
DpCore_x64.msm
This merge module contains the following files:
Dpcoper2.dll
Dpdevice2.dll
Dpfpapi.dll
Dphostw.exe
DpFpRec.msm X X X X
DpFpRec_x64.msm X X X X
DpFpUI.msm XXXXXXXX
DpFpUI_x64.msm XXXX
DpOTCOMActX.msm X X X X
DpOTCOMActX_x64.msm X X
DpOTDotNet.msm X X
DpOTShrDotNet.msm X X
DpOTJni.msm XX
DpOTJni_x64.msm X
DpOTJava.msm XX
Merge module C/C++ COM/ActiveX .NET Java
Chapter 9: Redistribution Redist Folder
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 88
Dpmux.dll
Dpclback.dll
DPCrStor.dll
x64\Dpmsg.dll
DpDrivers.msm
This merge module contains the following files:
Dpd00701x64.dll
Dpdevctlx64.dll
Dpdevdatx64.dll
Dpersona_x64.cat
Dpersona_x64.inf
Dpi00701x64.dll
Dpinst32.exe
Dpinst64.exe
Usbdpfp.sys
Dpersona.cat
Dpersona.inf
Dpdevctl.dll
Dpdevdat.dll
Dpk00701.sys
Dpk00303.sys
Dpd00303.dll
Dpd00701.dll
Dpi00701.dll
DpFpRec.msm
This merge module contains the following files:
Dphftrex.dll
Dphmatch.dll
DpFpRec_x64.msm
This merge module contains the following files:
<system folder>\Dphftrex.dll
Chapter 9: Redistribution Redist Folder
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 89
<system folder>\Dphmatch.dll
<system64 folder>\Dphftrex.dll
<system64 folder>\Dphmatch.dll
DPFpUI.msm
This merge module contains the following file:
Dpfpui.dll
DPFpUI_x64.msm
This merge module contains the following file:
<system folder>\Dpfpui.dll
<system64 folder>\Dpfpui.dll
DpProCore.msm
This merge module contains the following files:
Dpdevts.dll
Dpsvinfo2.dll
Dptsclnt.dll
•DpOTCOMActX.msm
This merge module contains the following files:
DPFPShrX.dll
DPFPDevX.dll
DPFPEngX.dll
DPFPCtlX.dll
•DpOTCOMActX_x64.msm
This merge module contains the following files:
DPFPShrX.dll
DPFPDevX.dll
DPFPEngX.dll
DPFPCtlX.dll
x64\DpFpCtlX.dll
x64\DpFpDevX.dll
x64\DpFpEngX.dll
x64\DpFpShrX.dll
Chapter 9: Redistribution Fingerprint Reader Documentation
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 90
•DpOTDotNET.msm
This merge module contains the following files:
DPFPDevNET.dll
DPFPEngNET.dll
DPFPVerNET.dll
DPFPGuiNET.dll
DPFPCtlXTypeLibNET.dll
DPFPCtlXWrapperNET.dll
DPFPShrXTypeLibNET.dll
DpOTShrDotNET.msm
This merge module contains the following files:
DPFPShrNET.dll
Fingerprint Reader Documentation
You may redistribute the documentation included in the Redist folder of any One Touch for Windows SDK
software package to your end users pursuant to the terms of this section and of the EULA, attendant to the
software and located in the Docs folder in the SDK software package.
Hardware Warnings and Regulatory Information
If you distribute DigitalPersona U.are.U fingerprint readers to your end users, you are responsible for advising
them of the warnings and regulatory information included in the Warnings and Regulatory Information.pdf file
in the Redist folder of any One Touch for Windows SDK software package. You may copy and redistribute the
language, including the copyright and trademark notices, set forth in the Warnings and Regulatory
Information.pdf file.
Fingerprint Reader Use and Maintenance Guide
The DigitalPersona U.are.U fingerprint reader use and maintenance guides, DigitalPersona Reader Maintenance
Touch.pdf and DigitalPersona Reader Maintenance Swipe.pdf, are located in the Redist folder in the One Touch
for Windows SDK software package. You may copy and redistribute the DigitalPersona Reader Maintenance
Touch.pdf and the DigitalPersona Reader Maintenance Swipe.pdf files, including the copyright and trademark
notices, to those who purchase a U.are.U module or fingerprint reader from you.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 91
Setting the False Accept Rate A
This appendix is for developers who want to specify a false accept rate (FAR) other than the default used by the
DigitalPersona Fingerprint Recognition Engine.
False Accept Rate (FAR)
The false accept rate (FAR), also known as the security level, is the proportion of fingerprint verification
operations by authorized users that incorrectly returns a comparison decision of match. The FAR is typically
stated as the ratio of the expected number of false accept errors divided by the total number of verification
attempts, or the probability that a biometric system will falsely accept an unauthorized user. For example, a
probability of 0.001 (or 0.1%) means that out of 1,000 verification operations by authorized users, a system is
expected to return 1 incorrect match decision. Increasing the probability to, say, 0.0001 (or 0.01%) changes this
ratio from 1 in 1,000 to 1 in 10,000.
Increasing or decreasing the FAR has the opposite effect on the false reject rate (FRR), that is, decreasing the
rate of false accepts increases the rate of false rejects and vice versa. Therefore, a high security level may be
appropriate for an access system to a secured area, but may not be acceptable for a system where convenience
or easy access is more significant than security.
Representation of Probability
Probability should always be in the range from 0 to 1. Some common representations of probability are listed in
column one of Table 2. The value in the third row represents the current default value used by the
DigitalPersona Fingerprint Recognition Engine, which offers a mid-range security level. The value in the second
row represents a typical high FAR/low security level, and the value in the fourth row represents a typical low
FAR/high security level.
Table 2. Common values of probability
Decimal (0 to 1) Percent (0 to 100%) Fraction (1/n1 to 1)
1. Where n is equal to infinity.
0.001 0.1% 1/1000
0.0001 0.01% 1/10000
0.00001 0.001% 1/100000
0.000001 0.0001% 1/1000000
Appendix A: Setting the False Accept Rate
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 92
Requested FAR
You specify the value of the FAR using the targetFar parameter of the MC_setSecurityLevel
function. While you can request any value from 0 to 100%, it is not guaranteed that the Engine will fulfill the
request exactly. The Engine implementation makes the best effort to accommodate the request by internally
setting the value closest to that requested within the restrictions it imposes for security.
The following sample code sets the FAR to a value of 0.005%.
Achieved FAR
The actual value of the FAR achieved for a particular verification operation is returned in the achievedFar
parameter of MC_verifyFeaturesEx function as a probability value between 0 and 1. This value is
typically much smaller than the requested FAR due to the accuracy of the DigitalPersona Fingerprint
Recognition Engine. The requested FAR specifies the maximum value of the FAR to be used by the Engine in
making the verification decision. The actual FAR achieved by the Engine when conducting a legitimate
comparison is usually a much lower value. The Engine implementation may choose the range and granularity
for the achieved FAR. If you make use of this value in your application, for example, by combining it with other
achieved FARs, you should use it with caution, as the granularity and range may change between versions of
DigitalPersona SDKs without notice.
Testing
Although you may achieve the desired values of the FAR in your development environment, it is not
guaranteed that your application will achieve the required security level in real-world situations. Even though
the Engine is designed to make its best effort to accurately implement the probability estimates, it is
recommended that you conduct system-level testing to determine the actual operating point and accuracy in a
given scenario. This is even more important in systems where multiple biometric factors are used for
identification.
...
//Sets the FAR to 0.005%
rc = MC_setSecurityLevel(mcContext, 0.005);
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 93
Platinum SDK Enrollment Template Conversion B
This appendix is for Platinum SDK users who need to convert their Platinum SDK registration templates to a
format that is compatible with the SDKs that are listed in Fingerprint Template Compatibility on page 5.
Sample code is included below for C++ and Visual Basic.
Platinum SDK Enrollment Template Conversion for Microsoft Visual C++
Use Code Sample 1 in applications developed in Microsoft Visual C++ to convert DigitalPersona Platinum SDK
registration templates.
Code Sample 1. Platinum SDK Template Conversion for Microsoft Visual C++
#import "DpSdkEng.tlb" no_namespace, named_guids, raw_interfaces_only
#include <atlbase.h>
bool PlatinumTOGold(unsigned char* platinumBlob, int platinumBlobSize,
unsigned char* goldBlob, int goldBufferSize,
int* goldTemplateSize)
{
// Load the byte array into FPTemplate Object
// to create Platinum template object
SAFEARRAYBOUND rgsabound;
rgsabound.lLbound = 0;
rgsabound.cElements = platinumBlobSize;
CComVariant varVal;
varVal.vt = VT_ARRAY | VT_UI1;
varVal.parray = SafeArrayCreate(VT_UI1, 1, &rgsabound);
unsigned char* data;
if (FAILED(SafeArrayAccessData(varVal.parray, (void**)&data)))
return false;
memcpy(data, platinumBlob, platinumBlobSize);
SafeArrayUnaccessData(varVal.parray);
IFPTemplatePtr pIFPTemplate(__uuidof(FPTemplate));
if (pIFPTemplate == NULL)
return false;
Appendix B: Platinum SDK Enrollment Template Conversion
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 94
AIErrors error;
if (FAILED(pIFPTemplate->Import(varVal, &error)))
return false;
if (error != Er_OK)
return false;
// Now pIFPTemplate contains the Platinum template.
// Use TemplData property to get the Gold Template out.
CComVariant varValGold;
if (FAILED(pIFPTemplate->get_TemplData(&varValGold)))
return false;
unsigned char* dataGold;
if (FAILED(SafeArrayAccessData(varValGold.parray, (void**)&dataGold)))
return false;
int blobSizeRequired = varValGold.parray->rgsabound->cElements *
varValGold.parray->cbElements;
*goldTemplateSize = blobSizeRequired;
if (goldBufferSize < blobSizeRequired) {
SafeArrayUnaccessData(varValGold.parray);
return false;
}
memcpy(goldBlob, dataGold, blobSizeRequired);
SafeArrayUnaccessData(varValGold.parray);
return true;
}
Code Sample 1. Platinum SDK Template Conversion for Microsoft Visual C++ (continued)
Appendix B: Platinum SDK Enrollment Template Conversion
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 95
Platinum SDK Enrollment Template Conversion for Visual Basic 6.0
Use Code Sample 2 in applications developed in Microsoft Visual Basic 6.0 to convert DigitalPersona Platinum
SDK enrollment templates.
Code Sample 2. Platinum SDK Template Conversion for Visual Basic 6.0
Public Function PlatinumToGold(platinumTemplate As Variant) As Byte()
Dim pTemplate As New FPTemplate
Dim vGold As Variant
Dim bGold() As Byte
Dim er As DpSdkEngLib.AIErrors
er = pTemplate.Import(platinumTemplate)
If er <> Er_OK Then PlatinumToGold = "": Exit Function
vGold = pTemplate.TemplData
bGold = vGold
PlatinumToGold = bGold
End Function
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 96
Get/Set Device Parameters C
This appendix is for developers who want to specify and retrieve a device-specific private key on any of
DigitalPersona’s family of fingerprint readers (4000B and later).
Overview
All of DigitalPersona’s current family of fingerprint readers, beginning with the U.are.U 4000B series, have a
dedicated memory location that can be used to set a private key on the device and then retrieve the key
programatically. This feature can be used to “lock in” the use of a specific device with your applications. This is
most often used to ensure that a specific feature set and/or tested hardware device is the one that your
application expects.
Parameters
There are two Device Parameter functions accessible through the DPFPAPI library (DPFPAPI.dll);
DPFPSetDeviceParameter() and DPFPGetDeviceParameter(). The prototypes for these functions are available in
dpfpapi.h, and are shown below for your convenience.
DPFP_STDAPI DPFPSetDeviceParameter(
REFGUID DevUID,
unsigned long ulParamID,
const DATA_BLOB* pData
);
DPFP_STDAPI DPFPGetDeviceParameter(
REFGUID DevUID,
unsigned long ulParamID,
DATA_BLOB* pData
);
These two functions set and get (read) the value stored on the fingerprint reader. They both require the use of a
device GUID, which can be retrieved through DPFPEnumerateDevices (see page 41).
A parameter ID is also needed (ulParamID). The currently supported parameter IDs are:
FT_SET_CLIENT_PRIVATE_KEY - Writes a private key to a device. The device then needs to be recycled prior
to reading the value.
FT_GET_CLIENT_PRIVATE_KEY - Reads the private key from a device.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 97
Glossary
biometric system
An automatic method of identifying a person
based on the person’s unique physical and/or
behavioral traits, such as a fingerprint or an iris
pattern, or a handwritten signature or a voice.
comparison
The estimation, calculation, or measurement of
similarity or dissimilarity between fingerprint
feature set(s) and fingerprint template(s).
comparison score
The numerical value resulting from a comparison of
fingerprint feature set(s) with fingerprint
template(s). Comparison scores can be of two
types: similarity scores or dissimilarity scores.
context
A temporary object used for passing data between
the steps of multi-step programming operations.
DigitalPersona Fingerprint Recognition Engine
A set of mathematical algorithms formalized to
determine whether a fingerprint feature set
matches a fingerprint template according to a
specified security level in terms of the false accept
rate (FAR).
enrollee
See fingerprint data subject.
enrollment
See fingerprint enrollment.
false accept rate (FAR)
The proportion of fingerprint verification
transactions by fingerprint data subjects not
enrolled in the system where an incorrect decision
of match is returned.
false reject rate (FRR)
The proportion of fingerprint verification
transactions by fingerprint enrollment subjects
against their own fingerprint template(s) where an
incorrect decision of non-match is returned.
features
See fingerprint features.
fingerprint
An impression of the ridges on the skin of a finger.
fingerprint capture device
A device that collects a signal of a fingerprint data
subject’s fingerprint characteristics and converts it to a
fingerprint sample. A device can be any piece of
hardware (and supporting software and firmware). In
some systems, converting a signal from fingerprint
characteristics to a fingerprint sample may include
multiple components such as a camera, photographic
paper, printer, digital scanner, or ink and paper.
fingerprint characteristic
Biological finger surface details that can be detected
and from which distinguishing and repeatable
fingerprint feature set(s) can be extracted for the
purpose of fingerprint verification or fingerprint
enrollment.
fingerprint data
Either the fingerprint feature set, the fingerprint
template, or the fingerprint sample.
fingerprint data storage subsystem
A storage medium where fingerprint templates are
stored for reference. Each fingerprint template is
associated with a fingerprint enrollment subject.
Fingerprint templates can be stored within a
fingerprint capture device; on a portable medium such
as a smart card; locally, such as on a personal computer
or a local server; or in a central database.
fingerprint data subject
A person whose fingerprint sample(s), fingerprint
feature set(s), or fingerprint template(s) are present
within the fingerprint recognition system at any time.
Glossary
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 98
Fingerprint data can be either from a person being
recognized or from a fingerprint enrollment
subject.
fingerprint enrollment
a. In a fingerprint recognition system, the initial
process of collecting fingerprint data from a person
by extracting the fingerprint features from the
person’s fingerprint image for the purpose of
enrollment and then storing the resulting data in a
template for later comparison.
b. The system function that computes a fingerprint
template from a fingerprint feature set(s).
fingerprint enrollment subject
The fingerprint data subject whose fingerprint
template(s) are held in the fingerprint data storage
subsystem.
fingerprint feature extraction
The system function that is applied to a fingerprint
sample to compute repeatable and distinctive
information to be used for fingerprint verification
or fingerprint enrollment. The output of the
fingerprint feature extraction function is a
fingerprint feature set.
fingerprint features
The distinctive and persistent characteristics from
the ridges on the skin of a finger. See also
fingerprint characteristics.
fingerprint feature set
The output of a completed fingerprint feature
extraction process applied to a fingerprint sample.
A fingerprint feature set(s) can be produced for the
purpose of fingerprint verification or for the
purpose of fingerprint enrollment.
fingerprint image
A digital representation of fingerprint features prior
to extraction that are obtained from a fingerprint
reader. See also fingerprint sample.
fingerprint reader
A device that collects data from a person’s fingerprint
features and converts it to a fingerprint image.
fingerprint recognition system
A biometric system that uses the distinctive and
persistent characteristics from the ridges of a finger,
also referred to as fingerprint features, to distinguish
one finger (or person) from another.
fingerprint sample
The analog or digital representation of fingerprint
characteristics prior to fingerprint feature extraction
that are obtained from a fingerprint capture device. A
fingerprint sample may be raw (as captured), or
intermediate (after some processing).
fingerprint template
The output of a completed fingerprint enrollment
process that is stored in a fingerprint data storage
subsystem. Fingerprint templates are stored for later
comparison with a fingerprint feature set(s).
fingerprint verification
a. In a fingerprint recognition system, the process of
extracting the fingerprint features from a person’s
fingerprint image provided for the purpose of
verification, comparing the resulting data to the
template generated during enrollment, and deciding
if the two match.
b. The system function that performs a one-to-one
comparison and makes a decision of match or non-
match.
match
The decision that the fingerprint feature set(s) and
the fingerprint template(s) being compared are from
the same fingerprint data subject.
non-match
The decision that the fingerprint feature set(s) and
the fingerprint template(s) being compared are not
from the same fingerprint data subject.
Glossary
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 99
one-to-one comparison
The process in which recognition fingerprint
feature set(s) from one or more fingers of one
fingerprint data subject are compared with
fingerprint template(s) from one or more fingers of
one fingerprint data subject.
repository
See fingerprint data storage subsystem.
security level
The target false accept rate for a comparison
context. See also FAR.
verification
See fingerprint verification.
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 100
Index
A
additional resources 3
online resources 4
related documentation 4
Allow Fingerprint Data Redirection 85
audience for this guide 2
B
biometric system
defined 97
explained 17
bold typeface, uses of 3
C
chapters, overview of 2
Citrix 1
Citrix Web Client 1
Citrix, developing for 85
comparison context
creating
function for 56
in typical enrollment workflow 25
in typical verification workflow 30
destroying
function for 57
in typical enrollment workflow 29
in typical verification workflow 34
comparison module, purpose of 21
comparison, defined 97
compatible fingerprint templates
See fingerprint template compatibility
context 25
creating
comparison context
function for 56
in typical enrollment workflow 25
in typical verification workflow 30
feature extraction context
in typical enrollment workflow 25
in typical verification workflow 30
defined 97
destroying
comparison context
function for 57
in typical enrollment workflow 29
in typical verification workflow 34
feature extraction context
in typical enrollment workflow 29
in typical verification workflow 34
conventions, document
See document conventions
converting Platinum SDK enrollment templates
for Microsoft Visual Basic 6.0 95
for Microsoft Visual C++ 93
Core API Reference 35
Courier bold typeface, use of 3
creating
comparison context
function for 56
in typical enrollment workflow 25
in typical verification workflow 30
feature extraction context
in typical enrollment workflow 25
in typical verification workflow 30
fingerprint feature set
function for 51
in typical enrollment workflow 27
in typical verification workflow 32
fingerprint template
function for 60
in typical enrollment workflow 29
D
destroying
comparison context
function for 57
in typical enrollment workflow 29
in typical verification workflow 34
feature extraction context
in typical enrollment workflow 29
in typical verification workflow 34
device component
purpose of 21
workflow 22–23
DFLT_FA_RATE constant, defined 74
DigitalPersona Developer Connection Forum, URL to 4
DigitalPersona Fingerprint Recognition Engine 17
DigitalPersona fingerprint recognition system 18
illustrated 19
DigitalPersona products, supported 4
document conventions 3
notational 3
typographical 3
documentation, related 4
DP_ACQUISITION_PRIORITY enumeration, defined 68
Index E
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 101
DP_DEVICE_INFO data structure, defined 64
DP_DEVICE_MODALITY enumeration, defined 68
DP_DEVICE_TECHNOLOGY enumeration, defined 69
DP_DEVICE_UID_TYPE enumeration, defined 70
DP_DEVICE_VERSION data structure, defined 64
DP_ENROLLMENT_ACTION enumeration, defined 82
DP_HW_INFO data structure, defined 65
DP_PRODUCT_VERSION data structure, defined 66
DP_SAMPLE_QUALITY enumeration, defined 70
DP_SAMPLE_TYPE_IMAGE constant, defined 74
DPENROLLMENTPROC callback, defined 79
DPEnrollUI function, defined 76
DPFPBufferFree function, defined 38
DPFPCreateAcquisition function
defined 38
using in device component workflow 23
DPFPDestroyAcquisition function
defined 40
using in device component workflow 23
DPFPEnumerateDevices function
defined 41
using in device component workflow 23
DPFPGetDevice Parameter 36
DPFPGetDeviceInfo function, defined 41
DPFPGetVersion function, defined 44
DPFPInit function
defined 44
using in device component workflow 23
DPFPSetDeviceParameter 36
DPFPStartAcquisition function
defined 45
using in device component workflow 23
DPFPStopAcquisition function
defined 46
using in device component workflow 23
DPFPTerm function
defined 46
using in device component workflow 23
DPVERIFYPROC callback, defined 80
DPVerifyUI function, defined 78
driver 18
E
Engine
See DigitalPersona Fingerprint Recognition Engine
enrollee 18
enrollment
See fingerprint enrollment
enrollment mask, possible values for 77
F
false accept rate 19
defined 97
setting target for comparison context
function for 58
in typical verification workflow 30
setting to value other than the default 91
false negative decision 19
false negative decision, proportion of 19
See also false accept rate
false positive decision 19
false positive decision, proportion of 19
See also false accept rate
false positives and false negatives 19
false reject rate 19
defined 97
FAR
See false accept rate
feature extraction context
creating
in typical enrollment workflow 25
in typical verification workflow 30
destroying
in typical enrollment workflow 29
in typical verification workflow 34
important notice not to set security level for 58
feature extraction module, purpose of 21
features
See fingerprint features
files and folders
installed for RTE
32-bit installation 15
64-bit installation 16
installed for SDK 13
fingerprint 17
defined 97
fingerprint capture device 18
defined 97
See fingerprint reader
fingerprint characteristics, defined 97
fingerprint comparison module
See comparison module
fingerprint data 18
defined 97
fingerprint data storage subsystem, defined 97
fingerprint enrollment 18
defined 98
typical workflow 24–29
clean-up 29
fingerprint feature set creation 27
Index F
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 102
fingerprint template creation 29
initialization 25
fingerprint feature extraction
defined 98
performing
function for 51
in typical enrollment workflow 27,32
fingerprint feature extraction module
See feature extraction module
fingerprint feature set 18
creating
function for 51
in typical enrollment workflow 27
in typical verification workflow 32
defined 98
retrieving number required for fingerprint template
creation
function for 56
in typical enrollment workflow 26
retrieving size of
in typical enrollment workflow 26
in typical verification workflow 30
fingerprint features, defined 98
fingerprint image
preparing for display
function for 53
in typical enrollment workflow 27
in typical verification workflow 32
fingerprint image, defined 98
fingerprint reader 18
defined 98
redistributing documentation for 90
use and maintenance guides, redistributing 90
fingerprint recognition 18
fingerprint recognition component 24
purpose of 21
fingerprint recognition system 17
defined 98
See also DigitalPersona fingerprint recognition system
fingerprint recognition, guide to 4
fingerprint sample, defined 98
See fingerprint image
fingerprint template 18
creating
function for 60
in typical enrollment workflow 29
defined 98
retrieving size of
function for 59
in typical enrollment workflow 26
fingerprint template compatibility 5
fingerprint verification 18
defined 98
performing
function for 62
in typical verification workflow 34
typical workflow 29–34
clean-up 34
comparison and decision 34
fingerprint feature set creation 32
initialization 30
folders and files
installed for RTE
32-bit installation 15
64-bit installation 16
installed for SDK 13
FRR
See false reject rate
FT_FA_RATE data type, defined 74
FT_FTR_QUALITY enumeration, defined 72
FT_FTR_TYPE enumeration, defined 73
FT_IMG_QUALITY enumeration, defined 72
FT_PRE_REG_FTR value
defined 51
using in typical enrollment workflow 26,27
FT_REG_FTR value
defined 60
using in typical enrollment workflow 26
FT_VER_FTR value
defined 51
using in typical verification workflow 30,32
FT_VERSION_INFO data structure, defined 66
FX_closeContext function
defined 49
using
in typical enrollment workflow 29
in typical verification workflow 34
FX_createContext function
defined 48
using
in typical enrollment workflow 25
in typical verification workflow 30
FX_extractFeatures function
defined 51
using
in typical enrollment workflow 27
in typical verification workflow 32
FX_getDisplayImage function
defined 53
using
Index G
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 103
in typical enrollment workflow 27
in typical verification workflow 32
FX_getFeaturesLen function
defined 50
using
in typical enrollment workflow 26
in typical verification workflow 30
FX_getVersionInfo function
defined 48
FX_init function
defined 47
using
in typical enrollment workflow 25
in typical verification workflow 30
FX_terminate function
defined 49
using
in typical enrollment workflow 29
in typical verification workflow 34
G
Group Policy Objects 85
GUID_NULL value
defined 39
using in device component workflow 23
H
hardware warnings and regulatory information,
redistributing 90
HDPOPERATION data type, defined 74
HIGH_SEC_FA_RATE constant, defined 74
I
See fingerprint image
important notation, defined 3
important notice
do not specify security level for feature extraction
context 58
read Appendix A before setting targetFar
parameter 58
initializing
comparison module
function for 55
in typical enrollment workflow 25
in typical verification workflow 30
feature extraction module
in typical enrollment workflow 25
in typical verification workflow 30
installation files for redistributables
redistributing 86
installing
RTE 14
RTE silently 16
italics typeface, uses of 3
L
LOW_SEC_FA_RATE constant, defined 75
M
match 19
defined 98
MC_closeContext function
defined 57
using
in typical enrollment workflow 29
in typical verification workflow 34
MC_createContext function
defined 56
using
in typical enrollment workflow 25
in typical verification workflow 30
MC_generateRegFeatures function
defined 60
using in typical enrollment workflow 29
MC_getFeaturesLen function
defined 59
using in typical enrollment workflow 26
MC_getSecurityLevel function, defined 57
MC_getSettings function
defined 56
using in typical enrollment workflow 26
MC_getVersionInfo function, defined 55
MC_init function
defined 55
using
in typical enrollment workflow 25
in typical verification workflow 30
MC_setSecurityLevel function
defined 58
using in typical verification workflow 30
MC_SETTINGS data structure, defined 67
MC_terminate function
defined 59
using
in typical enrollment workflow 29
in typical verification workflow 34
MC_verifyFeaturesEx function
defined 62
using in typical verification workflow 34
MED_SEC_FA_RATE constant, defined 74,75
merge modules
Index N
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 104
contents of 86
redistributing 86
Metaframe Presentation Server 1
N
non-match 19
defined 98
notational conventions 3
note notation, defined 3
number of required fingerprint feature sets for
fingerprint template creation, retrieving
function for 56
in typical enrollment workflow 26
O
one-to-one comparison 19
defined 99
online resources 4
overview
of chapters 2
of concepts and terminology 17
P
Platinum SDK enrollment template conversion 93
product compatibility
See fingerprint template compatibility
Program Neighborhood 1
Program Neighborhood Agent 1
R
Redist folder, redistributing contents of 86
redistributables, redistributing 86
redistribution of files 86
regulatory information, requirement to advise end users
of 90
releasing
resources associated with comparison module
function for 59
in typical enrollment workflow 29
in typical verification workflow 34
resources associated with feature extraction module
in typical enrollment workflow 29
in typical verification workflow 34
remote authentication 1
Remote Desktop Connection 1
repository 18
requirements, system
See system requirements
resources, additional
See additional resources
resources, online
See online resources
retrieving
number of required fingerprint feature sets for
fingerprint template creation
function for 56
in typical enrollment workflow 26
security level of comparison context, function for 57
size of fingerprint feature set
in typical enrollment workflow 26
in typical verification workflow 30
size of fingerprint template
function for 59
in typical enrollment workflow 26
software version information
comparison module, function for 55
RTE
installing 14
installing/uninstalling silently 16
redistributing 86
RTE\Install folder, redistributing contents of 86
runtime environment
See RTE
S
sample code for converting Platinum SDK enrollment
templates
for Microsoft Visual Basic 6.0 95
for Microsoft Visual C++ 93
SDK
components of 21
files and folders installed 13
security level 19
retrieving for comparison context, function for 57
setting for comparison context
function for 58
in typical verification workflow 30
silently installing RTE 16
size of fingerprint feature set, retrieving
in typical enrollment workflow 26
in typical verification workflow 30
size of fingerprint template, retrieving
function for 59
in typical enrollment workflow 26
software version information
retrieving for comparison module, function for 55
supported DigitalPersona products 4
system requirements 4
T
target audience for this guide 2
target false accept rate for comparison context
retrieving, function for 57
Index U
DigitalPersona One Touch for Windows SDK: C/C++ Edition | Developer Guide 105
setting
function for 58
in typical verification workflow 30
targetFar parameter
defined 57
important notice to read Appendix A before setting 58
template compatibility
See fingerprint template compatibility
terminating
comparison module
function for 59
in typical enrollment workflow 29
in typical verification workflow 34
feature extraction module
in typical enrollment workflow 29
in typical verification workflow 34
typefaces, uses of
bold 3
Courier bold 3
italics 3
typographical conventions 3
U
uninstalling RTE silently 16
updates for DigitalPersona software products, URL for
downloading 4
URLs
DigitalPersona Developer Connection Forum 4
Updates for DigitalPersona Software Products 4
use and maintenance guides for fingerprint readers,
redistributing 90
Use DigitalPersona Pro Server for authentication 85
using
device component API functions 23
fingerprint recognition component API functions 24–
34
V
verification
See fingerprint verification
W
Windows Terminal Services 1

Navigation menu
