Osteoporosis: The Disease, Its Controversies, Treatments and Its
Complications
Definitions: Osteoporosis literally means porous bone. However, there is a
biologic definition and a clinical working definition.
Biologic Definition: The weakening of bone due to thinning of the bone cortex and
the trabecular struts between the cortices. This is an age related phenomenon more
than an actual disease and is similar to loss of muscle mass and the thinning of scalp
hair that is experienced with age.
Clinical Definition: The World Health Organization (WHO) defines osteoporosis
via a Bone Mineral Density (BMD) measurement using a dual energy x-ray
absorption (DEXA) scan which gives a value in mg/dl or g/dl. This value is similar
to the Hounsfield units more familiar to dental practitioners. A diagnosis of
osteoporosis is made when the BMD value is 2.5 standard deviations below the
arbitrary normal set as the mean BMD of a 22 year old white Caucasian woman. If
the BMD value is only from 1 to 2.4 standard deviations below this arbitrary norm,
a diagnosis of osteopenia is made. Osteopenia is not considered a disease by the
WHO. These standard deviations of the BMD are referred to a T-score. Since T-
scores related to osteopenia and osteoporosis are always below the arbitrary norm
they are usually minus T scores (i.e. -2.0, -2.5, -3.4 etc). The WHO defines normal as
T-scores better than -1 (i.e. -0.5, +1, +1.5, etc.) and osteopenia as a T score between
-1 and -2.5. A T-score below -2.5 is considered osteoporosis and an individual with
a history of a “fragility fracture” (non-traumatic fracture) and a T score below -2.5 is
considered to have severe osteoporosis (Fig. 1).
The Mechanism of Osteoporosis: Bone remodeling is actually bone renewal.
Once an osteoblast becomes entrapped in its own mineral matrix to become an
osteocyte, it lives for about 180 days1. During that life span it prevents resorption
1
![](asset-2.png)
of its mineral matrix by secreting osteoprotegerin (OP) which inhibits the signaling
mechanism for osteoclasts to resorb bone.2 The osteoclast signaling mechanism is
a protein called Reactor Activator of Nuclear kappa-b Ligand referred to as RANK-
L.3 It is secreted by the osteoclast itself and sometimes even by osteoblasts. Young
osteocytes secrete sufficient amounts of OP to inhibit the resorptive signaling affects
of RANKL. However, as osteocytes age toward the end of their 180 day life span
known as a Sigma their ability to secret OP declines and RANK-L stimulation tips the
scale toward bone resorption (Fig. 2, Fig. 3).4 In a similar mechanism necrotic bone
which secretes no OP is either resorbed or sequestered depending on the amount of
necrotic bone present.
New bone formation results directly from this resorption. As the osteoclast resorbs
the mineral matrix of bone it releases the bone morphogenetic protein (BMP) and
the insulin like growth factors 1 and 2 (ILG-1 and ILG-2) originally embedded into it
by the osteoblast which formed the bone (fig. 4).5 These growth and differentiating
factors act upon local resident and some circulating stem cells as well as adjacent
osteoblasts to lay down replacement bone. Osteoporosis comes into play because
after age 22, this replacement is not 1 to 1 with resorption.
Why is osteoporosis more common in post menopausal women?
This less than 1 to 1 new bone formation after resorption is small but equal between
men and women prior to menopause. During and mostly after menopause the
rate of BMD decline is much greater in women than in men. This is due to their fall
off of estrogen because estrogen is required for osteoblast differentiation.6 In the
absence of estrogen, mesenchymal stem cells and osteoprogenitor cells undergo
more lipoblast differentiation. This has been graphically observed in various jaw
surgeries and ilium bone harvests for jaw reconstruction as fatty marrow.
What are the epidemiologic Factors Related to Osteoporosis?
2
![](asset-3.png)
In addition to menopause as the most significant factor leading to osteoporosis,
genetics, age, activity, (functional bone loading) and nutrition also play a role. Most
dental practitioners and orthopedic surgeons who perform surgeries on bone
know that some individuals possess a more dense bone then others. The WHO
also recognized this related to racial characteristics and sex. That is, individuals of
African black heritage are noted to have higher BMD and T-scores than their age
matched white Caucasian counterparts and men of any race or culture have higher
bone mineral density values than women of the same age and race or culture (Fig.
5).
Bone mineral density declines with age in both men and women of any race.
However, the rate of decline is about equal between races and sex until menopause
after which the rate of BMD decline is much greater in women of all races (see Fig.
5). Clinical experience suggests that osteoporosis is clinically more common and
more significant in white Caucasian women and Asian women although this latter
group has not been as thoroughly studied.
Since bone is primarily type I collagen into which calcium hydroxylappetite crystals
are placed along with trace amounts of the afore mentioned growth factors, the
nutrition supporting bone renewal and therefore resisting osteoporosis centers
about protein, calcium, and 25 hydroxy Vitamin D. Therefore, adequate dietary
protein must be within the diet itself and supplements of calcium and hydroxy
Vitamin D is often recommended. However, one must remember that osteoporosis
is a problem more of bone turnover than of mineral content which underscores the
limited value of the BMD value itself and of dietary calcium and vitamin D.
There is little doubt that activity also plays a key role as functionally stimulated
bone will tend to respond by thickening the cortex and the marrow trabecular
network. This is graphically illustrated by our astronauts who lose up to 30% of
their bone mass after a prolonged stay in a zero gravity environment but regain
3
![](asset-4.png)
almost all of it with their return to earth’s gravity. Dental practitioners also witness
this correlation after functionally loading dental implants. In such cases, the
trabecular bone density is seen to increase once the implants are restored and is
especially evident when the implants are placed into a bone graft (Fig. 6 and Fig. 7).
Treatment Strategies and Drugs for Osteoporosis.
The fundamental goal in treating osteoporosis is prevention of fractures. The two
skeletal locations of interest related to osteoporosis factures are the ‘spine” which
is actually the vertebral bodies and the “hip” which is actually the neck of the femur
about the greater and lesser trochanters (Fig. 8, Fig. 9).
Bisphosphonates
The treatment strategy of the bisphosphonates is anti-resorption which sounds
very positive upon superficial inspection. That is, preventing resorption should in
theory prevent the bone from becoming porous. However, this strategy ignores the
known resorption – renewal cycle of bone. It therefore actually reduces new bone
formation and leaves old bone in place. A compilation of the Merck Co. sponsored
studies and independent studies confirmed a bone strengthening effect for 3 years
after which the therapeutic effect of oral bisphosphonates ceases. Recognizing this,
the FDA, as of September 2011, recommended stronger warnings in the product
label as well as a limitation on the duration of therapy to the manufacturers of
oral bisphosphonates.7 Specifically, they recommended that physicians treating
osteoporosis patients re-evaluate them at three years and should consider
withdrawing the drug on or before five years. This old bone over time and with
long term bisphosphonate use becomes brittle and actually more prone to fracture.
This has become apparent to the dental community as bisphosphonate induced
osteonecrosis (BIONJ)8, 9, 10, 11 (Fig. 10, Fig. 11)and to orthopedic surgeons as non-
traumatic subtrochantaric fractures of the femur (Fig. 12).12, 13, 14, 15, 16
4
![](asset-5.png)
The jaws are the target for exposed bone osteonecrosis because of the fundamental
action of bisphosphonates which is to achieve anti-resorption by impairing and
mostly killing osteoclasts and their precursors in bone marrow.17 Because the
alveolar bone in the jaws is the most and fastest remodeling bone in the adult
skeleton due to dental occlusion and the wearing of dentures, BIONJ always begins
in the alveolar bone or the surface of a torus which is another rapidly remodeling
bony structure.18 The mid shaft of the femur is the second area of significant bone
remodeling in the adult skeleton because it is the bending moment point during
walking. Therefore, the bisphosphonates caused fractures are always located in this
unique area which does not experience fractures from trauma which occur mostly at
the trochanteric level.13, 14
The oral bisphosphonate drugs used to treat osteoporosis are residronate (Actonel
or Atelvia) 35 mg/week, Ibandronate (Boniva) 150 mg/month (this averages out to
be 35 mg/week) and Alendronate (Fosamax) 70 mg/week (note alendronate is now
available as a generic). Each of these is a nitrogen containing bisphosphonate which
adds sufficient potency to be used to treat osteoporosis and to cause BIONJ. Each
pill is irritating to the esophagus and has a high incidence of esophagitis.19 This is
why individuals are instructed to take the pill with two full glasses of water and
to remain upright for an hour. It is also why the initial daily doses of Actonel and
Fosamax created such a significant noncompliance that each manufacturer switched
to a weekly dose and the introduction of Boniva was a monthly dose. This was
later followed by the introduction of Zoledronic acid as Reclast for a once each year
intravenous dose, and the even more recent introduction of denosumab as Prolia by
a subcutaneous injection.
The intravenous from of Zoledronic acid known as Reclast is the same as the
commercial drug known as Zometa administered to limit bony resorption from
metastatic cancer deposits in bone and reduce the hypercalcemia of malignancy
as an intravenous 4 mg dose monthly.20 As Reclast, Zoledronic acid is also
5
![](asset-6.png)
administered intravenously to avoid the esophagitis and therefore noncompliance
as a 5 mg dose once yearly.21 Reclast was introduced to the market place in 2008
and has already caused cases of bisphosphonate induced osteonecrosis of the
jaws. Its optimal dose overtime and length of therapy has not been stated by the
manufacturer.
Denosumab: The strategy for denosumab is the same as that for bisphosphonates.
That is, prevention of fractures by an antiresorptive mechanism. Like
bisphosphonates denosumab targets the osteoclast and prevents its ability to resorb
bone and therefore also prevents new bone formation. Therefore, denosumab has
the same down side as the bisphosphonates in retaining old bone which is initially
stronger but with time becomes brittle and prone to become exposed jaw bone in
the mouth and possibly to cause femur fractures as alendronate is known to cause
with long term use. 13, 14
The commercial preparation of denosumab is known as Prolia. It is a subcutaneous
injection of 60 mg once every six months. It was introduced in June of 2010. Like
Reclast the optimal length of therapy is not known or stated by the manufacturer.
Cases of osteonecrosis of the jaws caused by Prolia have also already been
reported.22
Prolia’s mechanism of anti-resorption and therefore anti-bone renewal is somewhat
different than the bisphosphonates. Whereas bisphosphonates are an internal
metabolic poison, Prolia is a monoclonal antibody that inhibits RANK Ligand. By
doing so it impairs the osteoclast from resorbing bone.
Raloxifene (Evista): Raloxifene commercially marketed as Evista is a selective
estrogen receptor modulator or SERM medication.23 It is not a bisphosphonate
and therefore has no esophagitis or other complication associated with swallowing
the pill. Evista comes as a 60 mg oral capsule to be taken once daily without
6
![](asset-7.png)
the precautions required of a bisphosphonate. It has not been known to cause
osteonecrosis of the jaws or femur fractures. Because it acts on estrogen receptors
in bone in a stimulatory manner like estrogen itself it promotes osteoblast
differentiation and therefore maintains bone in postmenopausal women in a
manner similar to the natural estrogen of premenopausal women.24 Additionally,
Raloxifene acts on the estrogen receptors in breast tissue in an inhibitory manner
thus providing somewhat of a preventative measure against invasive breast cancer.
This breast cancer preventative aspect has been related as equivalent to the
chemotherapy drug Taxotere and has gained FDA clearance of Raloxifene for this
benefit as well.25
Recombinant Human Parathyroid Hormone 1-34 rhPTH 1-34 (Forteo)
This recombinant protein represents the active amino acid sequence of human
parathyroid hormone. Although naturally secreted human parathyroid hormone
is known to stimulate osteoclast mediated bone resorption, daily micro doses
of 20 micrograms paradoxically stimulates osteoblasts to secrete new osteoid
instead. Therefore, rhPTH1-34 is vastly different in its osteoporosis strategy
than bisphosphonates and denosumab. While bisphosphonates and denosumab
essentially retain old bone, rhPTH1-34 produces new bone. Therefore, it actually
increases bone mass not just bone mineral density.26 As Forteo rhPTH1-34 is
subcutaneous injection of 20 micrograms daily. It is FDA approved for three
cycles of 28 days each for maximum effect. Its specific FDA approved indications
is for “severe osteoporosis: so that it is usually not prescribed for osteopenia or
prevention of osteoporosis. It has not been associated with osteonecrosis of the
jaws. However, in some animal models high doses and long term use has been
associated with cancer development.27 Although such cancer development has not
occurred above background rates in humans, its treatment sequences are limited to
three 28 day cycles.
Salmon Calcitonin
7
![](asset-8.png)
Salmon Calcitonin known commercially as Miacalcin or Fortical comes as a nasal
spray and a subcutaneous injection each delivering 200 IU of synthetic Calcitonin
for a once daily use. As a synthetic of the salmon Calcitonin molecule, it is more
potent and has a much longer duration of action than mammalian Calcitonin.28
As does native human Calcitonin, the bisphosphonates and the denosumab drugs,
salmon Calcitonin has an antiresorptive effect on bone by depressing osteoclast
function and reducing their numbers. Therefore, its overall effect is the retention
of existing bone at the expense of bone renewal. Salmon Calcitonin differs from
the bisphosphonates in one critical area. That is, it does not have the long 11 year
half life in bone as do all bisphosphonates.29 Instead, it is readily metabolized and
therefore does not accumulate in bone.
Most importantly is a relatively new warning concerning salmon Calcitonin by
the United States Food and Drug Administration (FDA). As recently as April
15, 2013 the FDA published their review of all the safety data related to salmon
Calcitonin and identified a small but significant overall increased cancer risk from
a background rate of 0.7% to 2.4% (a 3.4 fold increase) with long term use.30 The
FDA recommended limiting salmon Calcitonin to no more than three months and
stated that the benefits of salmon Calcitonin did not outweighed the risk of its use in
osteoporosis.
Vitamin-D and Calcium: 25-OH vitamin D is the activated form of vitamin D
and together with calcium supplements are the mainstay of supplements to treat
osteopenia and in some cases of osteoporosis. They are recommended to be taken
with all the other osteoporosis medications as well. They are the inorganic building
blocks of bone but do not by themselves promote the synthesis of type I collagen
which is the organic building block of bone. Therefore, dietary protein intake is as
important as vitamin D and calcium. Dietary calcium is usually adequate or close to
adequate. The daily requirement of calcium is 1000 mg. The daily requirement of
8
![](asset-9.png)
Vitamin D is 800 IU. The daily recommended intake of protein is 4grams in women
and 5 grams in men.
From a bone science perspective one must accept that an age related reduction in
bone mass does occur in most everyone. However, in most people, children, young
adults, men, women including post menopausal women it does not reach a critical
level that causes a fracture without an episode of significant trauma. No doubt
many people especially post menopausal women may benefit from osteoporosis
treatment. However, the DXA scan generated BMD is only a surrogate test that
does not even correlate to fracture risk and measures the wrong thing. Therefore,
who will actually benefit from osteoporosis treatment and what treatment is best
is largely left up to individual prescribers and the many influences placed upon
them. Additionally, bisphosphonates and denosumab represent poor long term
strategies to prevent osteoporosis related fractures and alendronate (Fosamax)
in particular has actually caused femur fractures and jaw fractures. Raloxifene
and rhPTH1-34 represent an improved strategy to treat osteoporosis via drug
therapy. However, Raloxifene is less popular than the bisphosphonates and has not
been studied or approved to prevent hip fractures. Forteo is limited at this time
to severe osteoporosis, leaving bisphosphonates as the mainstay for osteoporosis
prevention and treatment with exercise, vitamin D, calcium, and an adequate
protein diet as the main alternative. Suffice it to say that fewer individuals actually
require drug treatment than are currently receiving it. At this time, the current
FDA recommendation of limiting drug therapy to three years after which retesting
and a continued treatment is indicated only if the osteoporosis has worsened is
a reasonable approach until more definitive data or better long term treatments
become available.
Osteoporosis - The Clinical Disease
As a disease entity, osteoporosis today is mired in confusion, controversy, and
competition. There seems to be two camps significantly divided as to whether
9
![](asset-a.png)
osteoporosis represents a true disease or an aging process and whether drug
treatment or exercise and nutrition are the best at preventing fractures. Those in
the camp of drug therapy produce a large number of statistical extrapolations as
facts that, if taken as accurate, recommend that osteoporosis begins and occurs
in children and develops in men as well as in premenopausal women.31, 32 Those
groups are not traditionally known to suffer from osteoporosis signs or symptoms
yet this camp suggests drug treatments for this population as well and therefore for
nearly everyone.
Those in the nutrition camp counter by relating that low bone density is an aging
process not a disease and use the analogy of skin laxity and a reduction in muscle
mass seen in everyone as they age. Their point is also that low bone density does
not equate to an increase fracture risk but that low bone quality does instead which
undermines many of the drug therapies currently in place.33
Both camps are fueled by large revenues tied to each industry. Osteoporosis
drugs represent a 17 billion dollar per year market and the exercise nutritional
supplement/diet control market an equal amount.
In the middle of this is the public and many of the physicians not committed to
either camp and of course, the dental profession which must deal with preventing
and treating the continually growing number of cases of what is now referred to
by the American Medical Association as Drug Induced Osteonecrosis of the Jaws
(DIONJ)34 that are occurring.
The Case For Osteoporosis Treatment With Primary Drug Therapy
The following statistics have been published by bone and mineral organizations,
osteoporosis organizations, and others as well as physician members of such
organizations.35, 36 They are:
10
![](asset-b.png)
1. 50% of women over 50 will suffer an osteoporosis-related fracture in her
lifetime
2. Osteoporosis causes 1.5 million fractures every year in the United States.
3. In women age 50 to 59, 58% have low bone mass and this percentage increases
each year.
4. In women over 45 years of age, osteoporosis accounts for more days spent in the
hospital than many other diseases including diabetes, myocardial infarction, and
breast cancer.
5. The national direct expenditures for osteoporosis related fractures are 14 billion
dollars each year.
6. Osteoporosis has been called a pediatric disease with geriatric consequences.
7. Over 80% of all fractures in people over 50 are caused by osteoporosis.
8. Twenty eight percent of women and 37% of men who suffer a hip fracture will
die within the following year.
9. In the United States today 10 million individuals have osteoporosis and 34
million more have low bone mass, placing them at risk for this disease.
10. More than two million American men suffer from osteoporosis, and millions
more are at risk. Each year, 80,000 men have a hip fracture, and one third of
these die within a year.
The Case Against Osteoporosis As A Disease And For Nutritional/Diet Therapy
Instead
This camp points out the flaws in these statistics and makes the case that treating an
arbitrary bone mineral density is the wrong strategy.37, 38 They report:
1. The United States Surgeon General reports only 17% of women over 50 years
of age will develop a hip fracture that the 50% claim comes from incidental
radiographic findings of reduced vertebral size unassociated with symptoms
but recorded as a fracture.
11
![](asset-c.png)
2. “Low Bone Mass” is not low bone mass at all but low Bone Mineral Density
(BMD) measured by the dual energy x-ray absorbitometry (DXA) scan that
was actually developed by Merck Co the originators and manufacturer
of alendronate (Fosamax) and set the mark of a -2.5 T-score as the firm
diagnosis of osteoporosis.39 They further claim that these so called
osteoporosis caused fractures are actually caused by falls and other injuries
and that a causal effect from the osteoporosis has not been proven. This
claim is supported by a multi-centered European study in the British Medical
Journal entitled “Shifting the Focus in Fracture Prevention from Osteoporosis
to Falls.”40
3. The low bone mass as measured by the DXA scan of BMD units in g/dl has
been studied by the World Health Organization which found that women’s
maximum bone mass occurs around the age of 22 years and set this value as
normal. However, nearly everyone over the age of 30 will naturally have a
lower bone mass than at age 22 and certainly most all women over 50 years
will have as well. They further claim that the BMD does not measure bone
quality and does not take into consideration vitamin D levels, steroid history,
vitamin K levels, muscle strength, activity level, urine PH, and acidifying
drinks and diet.
4. Osteoporosis by itself does not require hospitalization, only the fractures do.
If falls and other injuries actually cause these fractures, the actual hospital
stays cannot be attributed to osteoporosis. Even the length of hospital stays
are found to be related to the many comorbid diseases in this age group not
the osteoporosis.
5. If the expenditures are 17 billion dollars each year on osteoporosis drugs and
the cost of treating fractures is 14 billion dollars it would seem to be nearly
equal and once again predicated on the fact that the osteoporosis causes the
fractures not falls or other injuries that would fracture a bone regardless
of drug therapy. This author (REM) would be in agreement with this as we
have followed 104 patients with DIONJ due to oral bisphosphonates and 34
12
![](asset-d.png)
(32.7%) fractured a bone or the jaw due to a fall even though they had been
taking an oral bisphosphonate.
6. All diseases can be said to begin in children and adolescents. Heart disease
and hypertension in particular have been shown to follow this epidemiology.
This should not be the indication to start drug therapy.
7. 80% of fractures in people over 50 years is an estimate and assumes once
again that the osteoporosis is the cause of rather than a coincidence in the
fracture. This statistic is refuted by another multi-centered randomized
prospective unsponsored study out of Europe that appeared in the British
Medical Journal.41
8. The high rate of death each year after a hip fracture in both men and women
is not related to their osteoporosis but due to the comorbidities for the
diseases of aging such as heart disease, diabetes, arthritis etc. that caused
them to fall in the first place.
9. The large numbers of individuals carrying a diagnosis of osteoporosis and/
or low bone mass is due to the low threshold values of the BMD set by a drug
company and later adopted by the WHO. It does not consider bone quality
which is protein related, something that the BMD does not measure.
10. If 80,000 men develop hip fractures caused by osteoporosis and one third
die each year that would identify that over 26,000 men die each year from
osteoporosis. That is, three times more than the deaths from oral pharyngeal
cancer, and more than three times those from leukemia, kidney, thyroid, and
esophageal cancers among others. This is highly unlikely.
The nutrition/exercise camp instead recommends daily exercise together with
calcium, vitamin D and vitamin K supplements along with a normal to high
protein diet. They discourage alcohol and highly acidic drinks particularly
phosphoric acid containing soft drinks. They embrace the European studies
which recommend reducing the probability of falls in those over 50 years of age
by:
13
![](asset-e.png)
1. Exercise training
2. Building muscle strength
3. Improve home lighting
4. Reducing sleep medications, antidepressants, and other medications that
produce drowsiness
5. Firmly securing carpets and throw rugs
6. Since many fractures occur in the bathroom, add grab bars to shower and
bath tub areas, and increase the surface texture of floors to prevent slipping.
Osteopenia/Osteoporosis and the Dental Profession:
The dental profession is indirectly and directly affected by the osteoporosis
controversy. While treatment is mostly a matter between these groups with
divergent opinions and even data, the dental profession needs to understand
the process of bone aging/osteoporosis and the varying treatments in which
our patients take. It also needs to be able to understand the medical language
concerning osteoporosis and know how to communicate with physicians treating
osteoporosis.
More directly it involves the type of bone in which we place dental implants today
and of course DIONJ. Related to bone type, most all dental implant placing dentist
know that the maxilla in general and the posterior mandible have less trabecular
bone density. That it, it is mostly type III or Type IV bone and indeed worsens with
age. Therefore, these site locations together with advanced age are associated
with a slightly reduced primary stability and a slightly greater implant failure rate.
Overcoming this reduced trabecular bone density and even combating periodontal
bone loss with the use of bisphosphonates was once of great research interest
among periodontal researchers.42 However, with the identification of DIONJ
due to the same bisphosphonates being researched as well as reduction in the
manufacturer’s sponsorship of such research little or no applications have emerged.
14
![](asset-f.png)
Instead, post menopausal women must accept a slightly higher failure rate if dental
implants are placed or undergo a site improvement or site preparation procedure.
Today, this may take the form of socket grafting, ridge splitting procedures with
grafting, segmental distraction, sinus augmentation or horizontal or vertical ridge
augmentation using the providers preferred grafting material.
Drug Induced Osteonecrosis of the Jaws (DIONJ)
Today, most every dental professional is aware of jaw osteonecrosis caused by
IV and oral bisphosphonates and more are becoming aware of cases caused by
denosumab. Drug induced osteonecrosis of the jaw was first introduced to the
dental and medical profession in the textbook: Oral and Maxillofacial Pathology:
A Rationale for Diagnosis and Treatment by Marx and Stern 2002.43 The first
scientific literature publications occurred in September of 200344 with two more
following by the end of that year.45, 46 Now a decade later, two textbooks, and
over 1400 publications have appeared relating over 15,000 DIONJ cases attesting
to the epidemic proportions predicted in the first publication.44 Today, dental
professionals must be keenly aware of the mechanism of DIONJ, the risks of
precipitating it as well as prevention and treatment measures in the patients treated
for osteopenia and/or osteoporosis.
The current drugs that place osteopenia and osteoporosis patients at risk for DIONJ
are the oral bisphosphonates, alendronate (Fosamax and generic equivalents),
Residronate (Actonel and Atelvia) and Ibandronate (Boniva); the subcutaneously
injected denosumab (Prolia); and the intravenous bisphosphonate Zolendronate
(Reclast). All of them impair osteoclastic bone resorption and therefore bone
renewal thereby retaining old bone and reducing its ability to turnover. Because the
alveolar bone in the jaws turnover faster and more than any other bone in the adult
skeleton47 it is the focal point for DIONJ from these drugs.
15
![](asset-10.png)
Of the oral bisphosphonates, alendronate is the drug linked to 96% of cases of DIONJ
from an oral bisphosphonate as compared to residronate 3% and Ibandronate
1%.48 This is mostly due to the fact that the alendronate is marketed at twice the
dose of all other bisphosphonates (70mg/week) while it has the same absorption,
distribution, and the same potency of the others. Although Zolendronate as Reclast
is new and is given 5 mg IV only once yearly for osteoporosis it has already caused
several cases of DIONJ in this authors experience. This is because the half life
in bone of 11 years is the same for all the bisphosphonates29 and the IV infusion
loads the bone 140 times more than any oral bisphosphonates.48 Therefore, dental
professionals must realize that although some DIONJ cases may occur sooner,
the significant DIONJ risk for an oral bisphosphonate begins at about 3 years of
weekly dosing and with IV Reclast at about the fourth yearly dose. Needless to say,
those osteopenia/osteoporosis patients converted to Reclast after taking an oral
bisphosphonate are at risk for DIONJ before the fourth dose.
Denosumab (Prolia) as a RANK Ligand inhibitor does not seem to bind to bone
or to accumulate in bone as do bisphosphonates. Therefore, discontinuation as a
“drug holiday” becomes a useful tool for the clinician in this drug as it does in oral
bisphosphonates. Drug holidays are useful in patients taking oral bisphosphonates
because only 0.64% of any oral bisphosphonate is absorbed through the intestines
into the circulation.19, 20, 49 This amounts to a slower accumulation in bone and a
gradual toxic death to osteoclasts. Therefore, the bone marrow is able to replace
lost osteoclasts to some degree and remains able to repopulate the osteoclast
population during a drug holiday.
Prevention – What to Do and What Not to Do:
Dental professionals are well to note that these anti-osteoclastic drugs when given
to adults do not become bound into tooth structure. Therefore, caries removal,
restorations, crown and bridge, nonsurgical root canal therapy as well as dental
16
![](asset-11.png)
prophylaxis, removable partial and full dentures are safe to perform at any time.
In fact, it is advisable to accomplish these more preventative dental procedures in
these patients so as to prevent the need for alveolar bone surgeries in the future.
What is to be avoided is deferring needed dental care or neglecting it because of the
intimidation of DIONJ.
For the patient requiring a surgery within the alveolar bone (tooth removals,
alveoloplasty, dental implants, osseous periodontal surgery, apical resective
root canal therapy) and who has taken an oral bisphosphonate or Prolia for less
than three years it is reasonable to assess the bone turnover suppression by
requesting a morning fasting serum c-terminal telopeptide (CTX) test. Several
studies have shown that a value of 150 pg/ml or greater is consistent with alveolar
bone healing.50, 51, 52 In such cases where the CTX test is above 150 pg/ml, the
planned alveolar bone surgery can be accomplished and a three month drug
holiday requested from the prescribing physician to cover the healing period. If
the CTX value is below 150 pg/ml it is advisable to request a drug holiday from the
prescribing physician prior to accomplishing the planned alveolar bone surgery.
The length of the drug holiday will depend on the drug dose and the length of time
the patient took the drug. Most patients taking these drugs for less than three years
will either return a CTX value above 150 pg/ml initially or require a short drug
holiday of three months or less to gain a value above 150 pg/ml.
For patients who have taken an oral bisphosphonate or Prolia for more than three
years the initial CTX is usually below the 150 pg/ml level. For such patients a longer
drug holiday is usually necessary and many are required to be as long as nine
months. If the practitioner has no access to obtain a CTX serum test or the patient
declines it, this author has found that an arbitrary nine months to one year drug
holiday will gain alveolar bone healing after a surgical procedure in most all cases.
17
![](asset-12.png)
For urgent surgeries in the alveolar bone such as painful abscesses, bone fractures
vertical root fractures etc it is better to accomplish the needed surgery and request
a drug holiday for the following three months than to allow the problem to further
damage bone that may very well initiate osteonecrosis is such patients. Of course,
an informed consent outlining a greater risk for developing DIONJ due to the urgent
need for alveolar bone surgery in the face of bone healing compromised by these
drugs is advisable.
A special note about the CTX Test:
Despite three peer reviewed studies documenting the clinical utility of a properly
performed CTX test50, 51, 52 as well as the use of the CTX or NTX test in most all of the
oral bisphosphonate drug company sponsored research studies,53, 54 the value of
this test for oral surgical procedures remains controversial. It is curiously missing
from the position papers of the American Association of Oral and Maxillofacial
Surgeons,55 the American Dental Association,56 and the American Society of Bone
and Mineral Research.57 This likely due to several misapplications of the CTX
and misunderstandings of what is actually tested and what can interfere with its
accuracy.
The CTX test measures an eight amino acid sequence derived from collagen when
the osteoclast resorbs bone. Its name CTX comes from the fact that this amino acid
sequence is derived from the carboxy terminal end of collagen hence its designation
CTX. A less consistent serum test from the amino terminal end of collagen is termed
the NTX and is a lesser used alternate test.
Some of the misapplications arise from the fact that cancers split off collagen
fragments that cross react with this test resulting in abnormally high values.
Therefore, using the CTX in cases of IV bisphosphonate ONJ cases where the
bisphosphonates was prescribed for treating metastatic cancer deposits in bone or
18
![](asset-13.png)
for hypercalcemia of malignancy is inappropriate and detracts from its valid use
in noncancerous patients. Additionally, patients who have received methotrexate
which inhibits bone marrow stem cells and/or steroids which inhibit collagen
synthesis will cause CTX values to be falsely low. This is due to the reduction of
collagen in bone. Therefore, the CTX is not to be relied upon in such patients. One
other phenomenon may also be noted. That is, patients beginning a drug holiday
after seven or more years of an oral bisphosphonate will begin with very low CTX
values followed by a rise as the drug holiday progresses. However, a paradoxical
decrease in the CTX value may be seen as the drug holiday progresses further. This
is due to a recovery of the bone marrow osteoclast precursors which produces
osteoclasts that begin resorbing bone. As they do, they die off and rupture releasing
the unmetabolized bisphosphonate with its high affinity for bone. The released
bisphosphonate then is taken up by the bone again, suppressing the CTX value.
However, a nine month to one year drug holiday will return alveolar bone healing in
these individuals.
Diagnosis and Treatment:
An updated definition for Drug Induced Osteonecrosis of the Jaws can be derived
from the definitions used by most dental associations for Bisphosphonate Related,
Bisphosphonate Induced, or Bisphosphonate Associated Osteonecrosis of the
Jaws as: Exposed bone in the maxilla or mandible in a patient receiving a systemic
antiresorptive drug that fails to heal over eight weeks and who has not received
radiotherapy directly to the jaws. About 50% occur spontaneously with the
remainder resulting after a trauma to the jaws, usually a tooth removal or other
alveolar bone surgery. About 50% will also occur in the lingual cortex in the molar
region of the mandible. This has been attributed to the axial loading forces being
directed on this cortex and to the increase forces on molar teeth during occlusion
(Fig. 13).
Staging of DIONJ:
19
![](asset-14.png)
Previous staging systems for ONJ have incorrectly included pain as a major
contributor to staging. Since pain in DIONJ is due to secondary infection, it changes
with antibiotic therapy, the patient’s pain tolerance and the day to day activity of
the secondary infection. Since any staging system should indicate the severity and
extent of the disease regardless of subjective pain the following staging system is
the most appropriate:
Stage I: Exposed bone limited to one quadrant
Stage II: Exposed bone involving two quadrants
Stage III: Exposed bone in three or four quadrants or osteolysis to the inferior
border or a pathologic fracture or extension into the maxillary sinus
Treating DIONJ in the osteopenia/osteoporosis patient
The exposed bone represents necrotic bone. If the offending drug is continued the
area of exposed bone is likely to increase and secondary areas of exposed bone may
develop. It is advised to request a drug holiday from the prescribing physician. It
is cautioned that the dental practitioner should refrain from instituting the drug
holiday directly as osteoporosis therapy is not within the scope of any dental
specialty. Studies have shown that a drug holiday of nine months will result in a
spontaneous sequestration and exfoliation of the exposed bone followed by mucosal
healing in 50% of cases (Fig. 14 and Fig. 15).48 These cases are usually the smaller
areas of exposed bone. During this drug holiday clinicians find it useful to use
0.12% chlorhexidine oral rinses three times daily to prevent secondary infection. If
a secondary infection does develop penicillin VK 500 mg four times daily or if the
patient is penicillin allergic, doxycycline 100 mg once daily are the best antibiotics
to use.
In the 50% of cases where the exposed bone does not exfoliate with a drug holiday
a surgical debridement after a drug holiday of nine months or a CTX value greater
than 150 pg/ml has been associated with resolution of the DIONJ (Fig.’s 16, 17,
20
![](asset-15.png)
18, 19).48 It should be noted that such drug holidays and debridement surgeries
are not predictable and often not successful in the cancer patients treated with IV
bisphosphonates or sub cutaneous Xgeva due to the 11 year bone half life of the
bisphosphonates coupled with the 140 times greater bone loading via the IV route
and the high dose of denosumab in Xgeva.
Longer term use of oral bisphosphonates, especially alendronate, with or without
comorbidities may result in extensive osteonecrosis (Stage III). In the mandible this
may require a mandibular resection (Fig.’s 20, 21, 22, 23, 24, 25) and in the maxilla
an alveolar resection anteriorly Fig.’s 26, 27, 28, 29, 30) and an alveolar resection
together with a sinus debridement posteriorly (Fig.’s 31, 32, 33, 34, 35). In each
procedure a nine moth drug holiday followed by another three month drug holiday
during the healing course has been shown to predictably resolve the DIONJ. In cases
where the CTX rises above 150 pg/ml prior to nine months the indicated surgery
may be accomplished at that time with predictable healing.
It is extremely rare that a prescribing physician will disagree with a drug holiday.
In such a situation the dental team may suggest the alternatives of vitamin-D
together with calcium, and protein or Raloxifene or rhPTH1-34 as an alternative.
Additionally, the author (REM) will refer the physician to the sentinel article by
Black DN, Schwartz, Ensrud et al 58 that appeared in the Journal of the American
Medical Association December 26, 2006. In this multicentered randomized
prospective study discontinuation of the bisphosphonate for 5 years did not result
in an extension or worsening of osteoporosis. In the dental utility of drug holidays
for one year or less to treat or prevent DIONJ, it is well within the proven safety
toward the patient’s osteoporosis.
Once a DIONJ in the osteopenia/osteoporosis patient is resolved bony
reconstruction of the lost bone is feasible by the usual and individually preferred
methods of the practitioner. Where there remains sufficient bone to accommodate
21
![](asset-16.png)
dental implants, dental implant placements can be safely accomplished in these
patients as in any other patient provided the patient is not restarted on one of the
drugs discussed in this chapter known to cause DIONJ (See Fig.’s 16, 17, 18, 19).
22
![](asset-17.png)
References
1. Jameson JL, Kasper DL, Faui AS, Braunwald E, Lingo DL et al. HARRISON
ENDOCRINOLOGY. McGraw Hill Medical 2006, pp411-414
2. Hofbauer K, Khosla S, Dunstan et al. The roles of osteoprotegerin and
osteoprotegerin ligand in the paracrine regulation of bone resorption. J Bone
Miner Res 2000, 15:2-12
3. Hofbauer L, Heufeldes A: Role of receptor activator of nuclear factor-Kb
Ligand and osteoprotegerin in bone cell biology. J Mol Med 2001, 79:243-253
4. Hofbauer L, Kuhne C, Viereck: The OPG/RANKL/RANK system in metabolic
bone disease. J Musculoskel neuron Interact 2004, 4:268-275
5. Wergedal JE, Mohan S, Lundy M, Baylink DJ. Skeletal growth factors and
other factors known to be present in bone matrix stimulate proliferation and
protein synthesis in human bone cells. J Bone Miner Res 1990, 5:179-186
6. Riggs L. The mechanisms of estrogen regulation of bone resorption. J Clin
Invest 2000, 106:1203-1204
7. Food and Drug Administration. Background document for meeting of
advisory committee for reproductive health drugs and drug safety and risk
management advisory committee. FDA, Sept.9, 2011 (http:11wwwfda.gov/
downloads/advisory committees/committees meeting
8. Ruggiero SL, Mehrotra B, Rosenberg TJ, Engnoff SS. Osteonecrosis of the jaws
associated with the use of bisphosphonates: a review of 63 cases. J Oral
Maxillofac Surg 2004, 62:527-534
9. Marx RE, Sawatari Y, Fortin M, Broumand V. Bisphosphonate induced
exposed bone osteonecrosis/osteopetrosis) of the jaws. Risk factors,
recognition, prevention, and treatment. J Oral Maxillofac Surg 2005, 63:1567-
1575
10. Migliorati CA, Schubert MM, Peterson DE, Seneda LM. Bisphosphonate-
associated osteonecrosis of mandibular and maxillary bone: an emerging
oral complication of supportive cancer therapy.
11. Durie BGM, Katz M, Crowley J. Osteonecrosis of the jaws and
bisphosphonates. N Engl J Med 2005, 353:99-100
12. Edwards MH, McCrae FC, YoungMia SA. Alendronate related femoral
diaphysis fracture. What should be done to predict and prevent subsequent
fracture of the contralateral side. Osteoporos Int 2010, 21:701-703
23
![](asset-18.png)
13. Neviaser AS, Lane JM, Lenart BA, Edobor-Osula F, Lorich DG. Low-energy
femoral shaft fractures associated with alendronate use. J Orthop Trauma.
2008 May-Jun;22(5):346-50
14. Shane E. Evolving data about subtrochanteric fractures and bisphosphonates.
N Engl J. Med 2010, 362:1761-1771
15. Park-Wyllie LY, Mamdani MM, Juirlink DN, Hawher GA, Gunray N, et al.
Bisphosphonate use and atypical fractures of the femoral shaft. N Engl J Med.
2011 36, 1728-1737
16. Schilecher J, Michaelsion K, Aspenberg P. Bisphosphonate use. And atypical
fractures of the femoral shaft. Ne Engl J Med. 2011 36, 1728-1737
17. Eslami B, Zhou S, Van Ekeren I, Le Boff MS, Glowacki J. Reduced
osteoclastogenesis and RANKL expression in marrow from women taking
alendronate. Calcif Tissue Imt t2010,
18. Marx RE: Oral & Intravenous Bisphosphonate Induced Osteonecrosis of the
Jaws, History, Etiology, Prevention, and Treatment, Quintessence Publishing
Co., 2006
19. Merck & Co. Inc. Fosamax (alendronate sodium) tablets and oral solution.
Product information sheet. 2012. http://www.merck.com/product/usa/
pi_circulars/f/fosamax/fosamax_pi.pdf. Accessed 18 November 2012
20. Novartis AG. Zometa: Zoledronic acid injection. Product Information Sheet,
Novartis AG, 2004:1
21. Black DM, Delmas PD, Eastell R, Reid IR, Boonen S, Cauley JA, Cosman F,
Lakatos P, Leung PC, Man Z, Mautalen C, Mesenbrink P, Hu H, Caminis J, Tong
K, Rosario-Jansen T, Krasnow J, Hue TF, Sellmeyer D, Eriksen EF, Cummings
SR; HORIZON Pivotal Fracture Trial. Once-yearly Zoledronic acid for
treatment of postmenopausal osteoporosis. N Engl J Med. 2007 May
3;356(18):1809-22
22. Aghaloo TL, Feinsenfeld AL, Pretetradis S. Osteonecrosis of the jaws in a
patient on Denosumab. J Oral Maxillofac Surg. 2010, 68:959-963
23. Ozmen B, Kirmaz C, Aydin K, Kafesciler SO, Guclu F, Hekimsoy ZInfluence of
the selective oestrogen receptor modulator (raloxifene hydrochloride) on IL-
6, TNF-alpha, TGF-beta1 and bone turnover markers in the treatment of
postmenopausal osteoporosis. Eur Cytokine Netw. 2007 Sep;18(3):148-53.
Epub 2007 Sep 7.
24
![](asset-19.png)
24. Vogel VG, Costantino JP, Wickerham DL, Cronin WM, Cecchini RS, Atkins JN,
Bevers TB, Fehrenbacher L, Pajon ER Jr, Wade JL 3rd, Robidoux A, Margolese
RG, James J, Lippman SM, Runowicz CD, Ganz PA, Reis SE, McCaskill-Stevens
W, Ford LG, Jordan VC, Wolmark N; National Surgical Adjuvant Breast and
Bowel Project (NSABP). Effects of tamoxifen vs raloxifene on the risk of
developing invasive breast cancer and other disease outcomes: the NSABP
Study of Tamoxifen and Raloxifene (STAR) P-2 trial. JAMA. 2006 Jun
21;295(23):2727-41. Epub 2006 Jun 5. Erratum in: JAMA. 2007 Sep
5;298(9):973. JAMA. 2006 Dec 27;296(24):2926.
25. Siris ES, Harris ST, Eastell R, Zanchetta JR, Goemaere S, Diez-Perez A, Stock
JL, Song J, Qu Y, Kulkarni PM, Siddhanti SR, Wong M, Cummings SR;
Continuing Outcomes Relevant to Evista (CORE) Investigators, Skeletal
effects of raloxifene after 8 years: results from the continuing outcomes
relevant to Evista (CORE) study. J Bone Miner Res. 2005 Sep;20(9):1514-24.
Epub 2005 May 16.
26. Neer RM, Arnaud CD, Zanchetta JR, Prince R, Gaich GA, Reginster JY,
Hodsman AB, Eriksen EF, Ish-Shalom S, Genant HK, Wang O, Mitlak BH.
Effect of parathyroid hormone (1-34) on fractures and bone mineral density
in postmenopausal women with osteoporosis. N Engl J Med. 2001 May
10;344(19):1434-41
27. Vahle JL, Sato M, Long GG, Young JK, Francis PC, Engelhardt JA, Westmore MS,
Linda Y, Nold JB. Skeletal changes in rats given daily subcutaneous injections
of recombinant human parathyroid hormone (1-34) for 2 years and
relevance to human safety.Toxicol Pathol. 2002 May-Jun;30(3):312-21.
28. Arnala IO. Salmon calcitonin (miacalcic ns 200 iu) in prevention of bone loss
after hip replacement. Scand J Surg. 2012;101(4):249-54
29. Llasseter KC, Porras AG, Denker A, et al. Pharmacokinetic considerations in
determining the terminal half lives of bisphosphonates. Clin Drug Invest
2005; 25:107-114
30. [No authors listed] In brief: FDA warning of cancer risk with salmon
calcitonin. Med Lett Drugs Ther. 2013 Apr 15;55(1414):29. PMID: 23588101
[PubMed - in process]
31. Gafni RI, Baron J. Overdiagnosis of osteoporosis in children due to
misinterpretation of dual-energy x-ray absorptiometry (DEXA). J Pediatr.
2004 Feb;144(2):253-7.
32. Melton LJ 3rd, Atkinson EJ, O'Connor MK, O'Fallon WM, Riggs BL. Bone
density and fracture risk in men. J Bone Miner Res. 1998 Dec;13(12):1915-23
33. Faulkner KG. Bone matters: are density increases necessary to reduce
fracture risk? J Bone Miner Res. 2000 Feb;15(2):183-7.
25
![](asset-1a.png)
34. Buck CJ. American Medical Association ICD-9-CM for Physician. Elsevier/
Saunders 2011:pg962
35. International Osteoporosis foundation:www.iofbonehealth.org/facts-
statistics. Accessed May 28, 2013.
36. Clinero Inc: Osteoporosis.emedtv.com/osteoporosis/osteoporosis-
statistics.html/.
37. Understanding Osteoporosis Statistics and What They Mean for Women’s
Bone Health: www.womentowomen.com/bonehealth/osteoporosis-
statistics. aspx.
38. Roche JJ, Wenn RT, Sahota O, Moran CG. Effect of comorbidities and
postoperative complications on mortality after hip fracture in elderly people:
prospective observational cohort study. BMJ. 2005 Dec 10;331(7529):1374.
Epub 2005 Nov 18.
39. Spiegel A. How a bone disease grew to fit the prescription: NPR:http://
www.npr.org/templates/story/story.php?storyId=121609815. Accessed Dec
22, 2009.
40. Jarwen TLN, Sievanen H, Khan KM, Heinonen A, Kannus P. Shifting The Focus
In Fracture Prevention From Osteoporosis To Falls. British Medical Journal,
2008 336:124-126
41. Alonso-Cuello P, Garcia-Franco AL, Guyatt C, and Moynihan R. Drugs For Pre-
Osteoporosis: Prevention Or Disease Mongering: British Medical Journal,
2008 336:126-129
42. Lane N, Armitage GC, Loomer P, Hsieh S, Majumdar S, Wang HY, Jeffcoat M,
Munoz T. Bisphosphonate therapy improves the outcome of conventional
periodontal treatment: results of a 12-month, randomized, placebo-
controlled study. J Periodontol. 2005 Jul;76(7):1113-22
43. Marx RE, Stern D: Oral and Maxillofacial Pathology; A Rational for Diagnosis
and Treatment, Quintessence Publishing Co., 2002
44. Marx, RE, Pamidronate (Aredia) and Zoledronate (Zometa) Induced
Avascular Necrosis of the Jaws: A Growing Epidemic, Jour Oral Surg, Sep. Vol.
61, No. 9, 2003
45. Migliorati CA. Bisphosphonates and oral cavity avascular bone necrosis. J Clin
Oncol 2003, 21:4253-4254
46. Wang J, Goodger NM, Pogrel MA. Osteonecrosis of the jaws associated with
cancer chemotherapy. J Oral Maxillofac Surg 2003, 61, 1104-1107
47. Dixon RB, Trickler ND, Garetto LP: bone turnover in elderly canine mandible
and tibia. J Dent Res 1997, 76:2579
26
![](asset-1b.png)
48. Marx RE. Oral and Intravenous Bisphosphonate Induced Osteonecrosis of the
Jaws. 2nd Ed. Quintessence Publishing Co, Hanover Park, IL 2011
49. Novartis AG. Aredia. Pamidronate disodium for injection, for intravenous
infusion. Product Information sheet. Novartis AG, 2004:1
50. Marx RE, Cillo JE Jr, Ulloa JJ. Oral bisphosphonate-induced osteonecrosis: risk
factors, prediction of risk using serum CTX testing, prevention, and
treatment. J Oral Maxillofac Surg. 2007 Dec;65(12):2397-2410
51. Kwon YD, Ohe JY, Lim DY, Chung DJ, Park JD. Retrospective study of two
biochemical markers for the risk assessment of oral bisphosphonate related
osteonecrosis of the jaws. Can they be utilized as risk markers? Clin Oral Impl
Res 2011, 22:100-105
52. Kunchur R, Need A, Hughes T, Goss A. Clinical investigation of C-terminal
cross linking telopeptide test in prevention and management and
management of bisphosphonate-associated osteonecrosis of the jaws. J Oral
Maxillofac Surg 2009 67:1167-1173
53. Bone HG, Hosking D, Devogalaer JP. Et al. Ten years experience with
alendronate for osteoporosis in postmenopausal women. N Engl J. Med 2004;
350:1189-1199
54. Black DM, Thompson DE, Vauer DC et al. Fracture risk reduction with
alendronate in women with osteoporosis: The fracture intervention trial. J
Clin Endocrinol Metale 2000:85;4118-4124
55. Ruggiero SL, Dodson TB, Assael LA, Landesberg R, Marx RE, Mehrotra B;
American Association of Oral and Maxillofacial Surgeons position paper on
bisphosphonate-related osteonecrosis of the jaws--2009 update J Oral
Maxillofac Surg. 2009 May;67(5 Suppl):2-12.
56. Migliorati CA, Casiglia J, Epstein J, Jacobsen PL, Siegel Ma et al. Managing the
care of patients with bisphosphonate associated osteonecrosis. An American
Academy of Oral Medicine Position Paper. J Am Dent Assoc 2005:136,1658-
1668
57. Khosla S, Burr D, Cauley J, Dempster DW, Ebeling PR, Felsenberg D, Gagel RF,
Gilsanz V, Guise T, Koka S, McCauley LK, McGowan J, McKee MD, Mohla S,
Pendrys DG, Raisz LG, Ruggiero SL, Shafer DM, Shum L, Silverman SL, Van
Poznak CH, Watts N, Woo SB, Shane E; American Society for Bone and
Mineral Research. Bisphosphonate-associated osteonecrosis of the jaw:
report of a task force of the American Society for Bone and Mineral Research.
J Bone Miner Res. 2007 Oct;22(10):1479-91.
27
![](asset-1c.png)
58. Black DM, Schwartz AV, Ensrud KE, Cauley JA, Lewis S, Quandt SA, et al.
Effects of continuing or stopping alendronate after five years of treatment.
The fracture intervention trial long term extension (flex); A randomized trial.
JAMA 2006, 296:2927-2938
28
![](asset-1d.png)
Figure Legends
Fig. 1 The World Health Organization’s bell curve defining normal, osteopenia,
osteoporosis, and T-scores.
Fig. 2 RANK Ligand concentrations above that of osteoprotegerin stimulates
osteoclasts to resorb bone.
Fig. 3 Bone resorption by several osteoclasts recognizing decreased
osteoprotegerin secretion from old bone at bottom but unable to resorb
younger adjacent bone due to its higher level of osteoprotegerin secretion.
Fig. 4 Resorption of the bone mineral matrix releases the growth and
differentiation factors to regenerate new bone.
Fig. 5 The World Health Organization’s graph of declining bone mineral densities
related to age, sex, and race.
Fig. 6 Less future graft prior to the functional loading from dental implants.
Fig. 7 Increased graft density seen after loading implants with an overdenture.
Fig. 8 Compression fractures of the vertebral bodies called spine fractures are
attributed to osteoporosis.
Fig. 9 Hip fracture from trauma occur at the trochanteric level. Many are thought
to be predisposed to such fractures form osteoporosis.
Fig. 10 Bisphosphonate induced osteonecrosis of the mandible.
Fig. 11 Bisphosphonate induced osteonecrosis of the maxilla.
Fig. 12 Mid shaft of femur (subtrochantaric) fracture caused by Alendronate
(Fosamax).
Fig. 13 The axial loading from molar occlusion on the mandible is directed toward
the lingual cortex resulting in a site of predilection for drug induced
osteonecrosis in the osteoporotic patient.
Fig 14 Exposed bone due to 5.5 years of alendronate (Fosamax) therapy for
osteopenia.
Fig. 15 Resolution of exposed bone seen in figure 14 correlated to a nine month drug
holiday and rising CTX values.
29
![](asset-1e.png)
Fig. 16 Exposed bone representing bisphosphonate induced osteonecrosis due to
alendronate (Fosamax).
Fig. 17 A minor office based debridement removed the exposed bone after a nine
month drug holiday at a CTX value over 150 pg/ml.
Fig 18 Implant placement into are of previous bisphosphonate exposed bone.
Fig. 19 Successful implant placement and long term outcome (5 years follow-up)
due to implant placements after a nine month drug holiday or a CTX value
above 150 pg/ml.
Fig. 20 Exposed necrotic bone in the mandible representing bisphosphonate
induced osteonecrosis.
Fig. 21 Necrotic bone form bisphosphonate induced osteonecrosis often become
secondarily infected. In this case two cutaneous fistulas developed.
Fig. 22 A hemimandibulectomy was required to resolve this case of bisphosphonate
induced osteonecrosis.
Fig. 23 Resolution of exposed necrotic bone and healing of mucosa after surgery.
Fig. 24 Resolution of cutaneous fistulas after surgery.
Fig. 25 A long span titanium plate was used initially to reconstruct the resultant
continuity defect and has been stable for 4 years.
Fig. 26 Bisphosphonate induced osteonecrosis of the maxilla limited to the alveolar
bone.
Fig. 27 Necrotic bone removed after a drug holiday of nine months and a CTX value
over 150 pg/ml.
Fig. 28 The resultant alveolar defect was grafted with in-situ tissue engineering
principles using Platelet Rich Plasma (PRP), recombinant human Bone
Morphogenetic Protein (rhBMP-2/ACS) and Crushed Cancellous Freeze
Dried Allogeneic Bone (CCFDAB).
Fig. 29 Healed site of resolved osteonecrosis with provisional appliance made to
avoid pressure on graft site.
Fig. 30 Fully regenerated alveolar ridge from insitu tissue engineered graft.
Fig. 31 Stage III bisphosphonate induced osteonecrosis of the maxilla.
30
![](asset-1f.png)
Fig. 31 After a nine moth drug holiday and a CTX level above 150 pg/ml a bony
debridement and aggressive removal of secondarily infected sinus
membrane was accomplished.
Fig. 33 Teeth, necrotic bone, and infected sinus membrane from debridement
surgery.
Fig. 34 To assist the healing advancement of the buccal fat pad with its robust blood
supply before a primary mucosal closure is advised.
Fig. 35 Healed surgical site and resolution of the osteonecrosis and sinusitis.
31
