JADE-PKI 1.0 Manual

Amadeusz Piotr ˙

Zo lnowski

September 9, 2012

Contents

1 Introduction 1

1.1 Agent messaging . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.2 Agent mobility . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2 Installation 1

3 Conﬁguration 2

3.1 Setting up PKI . . . . . . . . . . . . . . . . . . . . . . . . . . 2

3.2 Conﬁguring JADE-PKI . . . . . . . . . . . . . . . . . . . . . 3

4 Basic usage 5

4.1 Usage with PKIAgentMessagingService . . . . . . . . . . . . 5

4.2 Usage with PKIAgentMobilityService . . . . . . . . . . . . . . 6

4.3 Combining PKIAgentMessagingService and PKIAgentMobi-

lityService............................. 7

1 Introduction

The purpose of the JADE-PKI add-on is to introduce a public key infras-

tructure into JADE. The add-on provides security for two areas: agent mes-

saging and agent mobility.

1.1 Agent messaging

Agent messaging is secured by the PKIAgentMessagingService. It provides

methods of encryption, signing, decryption and veriﬁcation of the ACL mes-

sages. An agent does not perform these operation itself, but gives it to the

service. The agent only marks a message whether it should be signed and/or

encrypted.

1.2 Agent mobility

When the agent moves between containers its code and data are exposed to

malicious modiﬁcation. The PKIAgentMobilityService provides integrity

of code and data of the agent and certiﬁcation of identity of the agent. It

achieves that by signing the code and the data with the private key of the

container and attaching the certiﬁcate into the ﬁeld of the agent. For the

agent to be secured that way it needs to implement the Signable interface

or, which is recommended, extend one of the implementation: SMobileAgent

or SAgent.

2 Installation

1. Assume that $JADEHOME points to the root directory of your JADE

installation.

2. Unpack pkiAddOn-1.0.zip into $JADEHOME/add-ons/pki. JAR ﬁles

are built already in lib subdirectory.

3. Your $CLASSPATH should look as follows:

CLASSPATH=$JADEHOME/add-ons/pki/lib/pki.jar:\

$JADEHOME/add-ons/pki/lib/pki-examples.jar:\

$JADEHOME/lib/jade.jar:\

$JADEHOME/lib/commons-codec/commons-codec-1.3.jar

3 Conﬁguration

Before JADE-PKI services can be used, they need to be set up.

3.1 Setting up PKI

1. The ﬁrst step is to set up a public key infrastructure. Please follow

http://www.ibm.com/developerworks/java/library/j-certgen/ to

set up certiﬁcates chain to your needs. The minimal setup is one

root CA and a certiﬁcate for every container signed by the root CA.

CommonName should be set conforming to the following scheme:

my-host.my-domain/my-platform/my-container

2. The certiﬁcates cannot be used directly. They need to be loaded into

Java key stores. There’s the pkiimport tool in tools subdirectory of

$JADEHOME/add-ons/pki. To pack all trusted CAs (necessarily includ-

ing the root CA created at point 1) into the store, invoke pkiimport

according to the following scheme:

./pkiimport truststore <keystore> <certfile1>:<alias1> \

<certfile2>:<alias2> ...

where <keystore> is an output ﬁle, <certfileN> is a trusted CA and

<aliasN> is an alias for that certiﬁcate by which the certiﬁcate can

be referenced in a Java key store. You will be asked for password to

set up for the key store.

3. The container key and corresponding certiﬁcate need to be put into

another Java key store alone. For this pkiimport can be used, too.

Invoke it according to the following scheme:

./pkiimport keystore <keystore> <keyfile> <certfile> \

<alias>

where <keystore> is an output ﬁle, <keyfile> is the private key of

the container and <certfile> is its corresponding certiﬁcate. This

step needs to be repeated for every container certiﬁcate created at the

point 1.

The result of the steps above are the following ﬁles:

•truststore.jks – one Java key store containing trusted CAs,

•<container-name>-keystore.jks – a Java key store containing a pri-

vate key and a certiﬁcate for a container named <container-name> –

for each container.

3.2 Conﬁguring JADE-PKI

Here goes the example ﬁle for the Main-Container:

# ---- JADE configuration ----

gui=true

# ------ Platform ------

name=myplatform

platform-id=myplatform

host=mymainhost

local-host=mymainhost

nomtp=true

# ------ Services ------

services=\

jade.core.management.AgentManagementService;\

jade.core.messaging.MessagingService;\

jade.core.resource.ResourceManagementService;\

jade.core.mobility.AgentMobilityService;\

jade.core.event.NotificationService;\

jade.security.pki.core.PKICoreService;\

jade.security.pki.messaging.PKIAgentMessagingService;\

jade.security.pki.mobility.PKIAgentMobilityService

# ------ PKI configuration ------

jade_pki_keyStore=/path/to/maincontainer-keystore.jks

jade_pki_keyStorePassword=123456

jade_pki_trustStore=/path/to/truststore.jks

jade_pki_trustStorePassword=123456

# ---- end JADE configuration ----

Table 1: Parametrs for the PKIAgentCoreService.

Name Description

jade pki keyStore A path to a key store where a private key and

a certiﬁcate of the container is in.

jade pki keyStorePassword A password to the store pointed with the

jade pki keyStore parameter.

jade pki trustStore A path to a store where certiﬁcates of trusted

CAs are in.

jade pki trustStorePassword A password to the store pointed with the

jade pki trustStore parameter.

The following classes are the JADE-PKI services:

•jade.security.pki.core.PKICoreService,

•jade.security.pki.messaging.PKIAgentMessagingService,

•jade.security.pki.mobility.PKIAgentMobilityService.

The ﬁrst is a requirement for the remaining two. The second secures agent

messaging and the last secures the agent when it moves between containers.

Options in the PKI configuration section are used by the PKICoreService

on initialization. They are described in the table 1.

And here goes an example of the conﬁguration for an another container:

# ---- JADE configuration ----

container=true

container-name=Container-2

main=false

# ------ Platform ------

name=myplatform

platform-id=myplatform

host=mymainhost

local-host=anotherhost

# ------ Services ------

services=\

jade.core.management.AgentManagementService;\

jade.core.messaging.MessagingService;\

jade.core.resource.ResourceManagementService;\

jade.core.mobility.AgentMobilityService;\

jade.core.event.NotificationService;\

jade.security.pki.core.PKICoreService;\

jade.security.pki.messaging.PKIAgentMessagingService;\

jade.security.pki.mobility.PKIAgentMobilityService

# ------ PKI configuration ------

jade_pki_keyStore=/path/to/anothercontainer-keystore.jks

jade_pki_keyStorePassword=987654

jade_pki_trustStore=/path/to/truststore.jks

jade_pki_trustStorePassword=123456

# ---- end JADE configuration ----

Another container has diﬀerent key store with its private key and cer-

tiﬁcate, but uses a copy of the same ﬁle with the trusted CAs. Please take

notice of the Platform section. The name, id and a host are the same as

those of the main container, but local-host is the host name of this another

container.

4 Basic usage

4.1 Usage with PKIAgentMessagingService

To make use of the message signing and encryption the agent needs to start

SendCertificateBehaviour behaviour which is in jade.security.pki.-

messaging.behaviours package. This can be done in setup() method of

the agent as follows:

@Override

protected void setup() {

addBehaviour(new SendCertificateBehaviour(this));

}

The message is encrypted, signed, decrypted and veriﬁed by the service.

The agent only marks the message for the operation which can be done as

follows:

/* Retrieve the service helper. The ServiceException is

* thrown if the service isn’t initialized on the

* current container, but for clarity it’s not caught

* here. */

PKIAgentMessagingHelper pki = (PKIAgentMessagingHelper)

getHelper(

"jade.security.pki.messaging.PKIAgentMessaging");

/* Create a message. A performative can be anything,

* of course. */

ACLMessage msg = new ACLMessage(ACLMessage.REQUEST);

/* Set msg content, sender and so on... */

/* The message is marked for signing. */

pki.markForSignature(msg);

/* Before message is marked for encryption, an agent needs to

* retrieve the receiver agent’s container. */

if (pki.requestReceiversCertificate(myAgent, replyTo,

1000)) {

/* A certificate is retrieved, marking for encryption. An

* algorithm for a symmetric encryption is the AES in the

* CBC mode and with the PKCS5 padding. */

pki.markForEncryption(msg, "AES/CBC/PKCS5Padding",

new KeySizeAlgorithmParameterSpec(128));

}

/* The message is send. The JADE-PKI serivce handles it,

* encrypts and signs (in that order). */

send(msg);

4.2 Usage with PKIAgentMobilityService

The agent to be secured with the service needs to implement the Signable

interface. It is easier, however, to extend the SMobileAgent class which

implements most of Signable methods.

public class SMobAgentExmpl extends SMobileAgent {

private int constantValue;

private int counter;

/* This method needs to return data which needs to be

* protected when agent moves between containers. In

* the example the counter field will be signed.

* The data needs to be returned in the form of byte

* array. */

@Override

public byte[] getMutableData() {

return ByteBuffer.allocate(4).putInt(counter).array();

}

/* This method needs to return data which is not going to

* be changed after its initialization. In the example the

* constantValue field will be signed. */

@Override

public byte[] getImmutableData() {

return ByteBuffer.allocate(4).putInt(constantValue

).array();

}

@Override

protected void setup() {

counter = 0;

constantValue = 3;

/* This method request the service to sign the agent

* class, identifier (AID) and data returned with

* getImmutableData(). */

ownMe();

}

@Override

protected void afterMove() {

/* We check if the move was successful. If the agent

* has been modified during transfer, then the

* verification has failed and getSafeMoveStatus() will

* return value different than SAFE_MOVE_OK. */

if (getSafeMoveStatus() != SAFE_MOVE_OK) {

return;

}

/* On each container this value can be modified. It

* is signed when the agent leaves container.

counter++;

}

4.3 Combining PKIAgentMessagingService and PKIAgent-

MobilityService

To combine the use of both services it is best to extend the SAgent class

which starts the SendCertificateBehaviour and extends SMobileAgent.
