TEY1DNC-42
Lloyd Urinal Flush Valve
Exposed 1.0 GPF, Battery Powered
Parts ManualPD-00514, V.01
1
2
3
4
5
6
TEY1DNC-42
Lloyd Urinal Flush Valve
Exposed 1.0 GPF, Battery Powered
Parts ManualPD-00514, V.01
Item Part Description
1 THU3002 Solenoid Assembly Unit
2 THU3004 Sensor Controller
3 THU3005 Battery Case
4 THU3003 5/8" Duckbill
5 THU3035 Screener
6 THU3036 Screener Cap Screw
