Philips Signage Solutions

U-Line Display

75"

Edge LED Backlight

Ultra HD

75BDL3000U

Captivate your audience

With an ultra large screen experience

Experience your content like never before thanks to four times the resolution of a

conventional display. This ultra large 75” display offers 3840 x 2160 pixels so refined, so

lifelike, it's a window to a new world

Optimized for public viewing

• 4K Ultra HD: resolution like you've never seen it before

Innovative solutions for any signage application

• Play content from 4 separate inputs with QuadViewer

• CMND: Take control of your displays

• Optional OPS Insert to create an all-in-one solution

• Schedule what you want, when you want with SmartPlayer

Care about you, your business and your audience

• SmartPower for energy saving

• Keep your content up and running with FailOver

• Simplify meetings with FailOver for conferencing

75BDL3000U/00

Highlights

U-Line Display

75" Edge LED Backlight, Ultra HD

4K Ultra HD Resolution

See your Signage Solutions like never before

thanks to four times the resolution of a

conventional Full HD display. 3840 x 2160

pixels provide and image so refined, so lifelike,

it's a window to a new world.

QuadViewer

Be more flexible with your screen real estate.

With the ability to play content from up to four

separate inputs, all on one screen.

QuadViewer is ideal for control rooms,

corporate environments, and meeting rooms.

CMND

A robust display management platform,

CMND puts the power back into your hands.

Update and manage content with CMND &

Create or control your settings with CMND &

Control. It's all possible with CMND.

OPS Insert

Turn your display into an all-in-one digital

signage solution and create a display network

which is connected, intelligent and secure.

Open Pluggable Specification (OPS) is an

industry standard slot into which you can add

an OPS-standardized media player. This cable

free solution gives you the ability to install, use

or maintain your hardware whenever you

need.

FailOver

Keeping your content up and running is critical

for demanding commercial applications. While

it is unlikely you will face a content disaster,

FailOver provides content protection with a

revolutionary technology that plays back-up

content on screen in the event of a media

player failure. FailOver automatically kicks in

when the primary input fails. Simply select a

primary input connection and a FailOver

connection and your ready for instant

protection.

FailOver for Meeting Rooms

Using FailOver, simplify your presentations and

videoconferencing. When a meeting or

conference room is not in use, background

content can run from whatever input source

you choose. When the meeting starts and you

need to share a presentation or your screen,

simply connect your computer and the display

automatically switches inputs and shows what's

on your screen, with no need to manually

switch inputs.

SmartPower

The backlight intensity can be controlled and

pre-set by the system to reduce the power

consumption by up to 50%, which saves

substantially on energy costs.

SmartPlayer

Turn your USB into a true cost effective digital

signage device. Simply save your content

(video, audio, pictures) on your USB and plug

into your display.Create your playlist and

schedule your content via the on screen menu,

and enjoy your own created playlists anytime,

anywhere.

OPSInsert

Issue date 2016-07-02

Version: 1.0.1

12 NC: 8670 001 37272

EAN: 87 12581 73952 2

© 2016 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

75BDL3000U/00

Specifications

U-Line Display

75" Edge LED Backlight, Ultra HD

Picture/Display

• Diagonal screen size: 74.5 inch / 189.3 cm

• Panel technology: IPS

• Optimum resolution: 3840 x 2160 @ 60Hz

• Brightness: 410 cd/m²

• Contrast ratio (typical): 1200:1

• Dynamic contrast ratio: 500,000:1

• Aspect ratio: 16:9

• Response time (typical): 8 ms

• Pixel pitch: 0.429 x 0.429 mm

• Display colors: 1073 M

• Viewing angle (H / V): 178 / 178 degree

• Picture enhancement: 3/2 - 2/2 motion pull down,

3D Combfilter, 3D MA deinterlacing, Dynamic

contrast enhancement, Motion compens.

deinterlacing, Progressive scan

• Panel resolution: 3840 x 2160

Connectivity

• Video input: VGA (Analog D-Sub), DisplayPort

(1.2), DVI-D, HDMI (x3), Component (RCA),

Composite (RCA)

• Video output: DisplayPort

• Audio input: 3.5 mm jack, Audio Left/Right (RCA)

• Audio output: 3.5mm jack, External speaker

connector, SPDIF

• External control: RS232C (in/out) 2.5 mm jack,

RJ45, IR (in/out) 3.5 mm jack

• Other connections: AC-out, OPS, USB

Dimensions

• Bezel width: 12.50 mm

• Set dimensions (W x H x D):

1676.60 x 955.00 x 73.80 mm

• Set dimensions in inch (W x H x D):

66.01 x 37.60 x 2.91 inch

• VESA Mount: 600 x 400 mm, M8

• Product weight: 53.3 kg

• Product weight (lb): 117.51 lb

• Smart insert height: 300 mm

• Smart insert width: 250 mm

Convenience

• Placement: Landscape (16/7)

• Network controllable: RS232, HDMI (One Wire),

LAN (RJ45)

• Signal Loop Through: RS232, DisplayPort, IR

Loopthrough

• Energy saving functions: Smart Power

• Remote control signal: Lockable

• Keyboard control: Hidden, Lockable

• Ease of installation: Smart Insert

• Other convenience: Carrying handles

• Screen saving functions: Pixel Shift, Low Brightness

• Picture in picture: PIP

• Picture performance: Advanced color control

Power

• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz

• Consumption (Typical): 197 W

• Standby power consumption: <0.5W

Sound

• Built-in speakers: 2 x 10W RMS

Operating conditions

• Temperature range (operation): 5 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• Relative humidity: 20 ~ 80 %

• MTBF: 50,000 hour(s)

• Altitude: 0 ~ 3000 m

Accessories

• Included accessories: AC Power Cord, Batteries

for remote control, Quick start guide, Remote

Control, User manual on CD-ROM, RS232 cable,

HDMI cable

• Optional accessories: HDBaseT OPS Receiver

(CRD25), IR Light Motion Sensor (CRD41)

Miscellaneous

• On-Screen Display Languages: English, French,

German, Italian, Polish, Russian, Spanish, Turkish,

Simplified Chinese, Traditional Chinese, Arabic,

Japanese, Portuguese

• Regulatory approvals: CE, UL/cUL, CCC, C-Tick,

RoHS, GOST, FCC, Class A

• Warranty: 3 year warranty

Multimedia Applications

• USB Playback Audio: AAC, AIF, AIFF, ASF, LPCM,

M3U, M4A, MP3, MP4, WAV, WMA

• USB Playback Picture: BMP, GIF, JPEG, JPG

• USB Playback Video: M2TS, M4V, MK3D, MKV,

MP4, MPEG, MPG, MTS, TS, TTS, VOB, WMV

•
