2016/3/15 ZPMV2.E343861 - Wiring, Printed - Component
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/showpage.html?name=ZPMV2.E343861&ccnshorttitle=Wiring,+Printed+-+Component&objid=1081572715&cfgid=1073741824&version=versionless&parent_id=10738…
1/2
ZPMV2.E343861
Wiring, Printed - Component
For enhanced search functionality, please visit UL's iQ™ Family of Databases.
Click on a product designation for complete information.
Page Bottom
Wiring, Printed - Component
See General Information for Wiring, Printed - Component
JIANGMEN DEYUN ELECTRONICS CO LTD E343861
73 LONGXI RD
DONGNAN INDUSTRIAL ZONE
#2 JIANGHAI DISTRICT
JIANGMEN, GUANGDONG 529080 CHINA
Cond Width Max Max
Min Cond SS/ Area Solder Oper Meets C
Min Edge Thk DS/ Diam Limits Temp Flame UL796 T
Type mm(in) mm(in) mic(mil) DSO mm(in) C sec C Class DSR I
Multilayer printed wiring boards.
DY4 0.10 (0.004) 0.15 (0.006) 17 (0.67) Int:68 DS 50.8 (2.0) 288 10 130 V-0 All 4
Single layer printed wiring boards.
DY2 0.10 (0.004) 0.15 (0.006) 17 (0.67) DS 50.8 (2.0) 288 10 130 V-0 All 4
Marking: Company name or trademark or file number and type designation. May be followed by a suffix to denote factory identification or burning
test classification.
Last Updated on 2013-12-02
