PRIMEFLEX for Microsoft Storage Spaces Direct
Hyper Converged Infrastructure
FUJITSU
Integrated
System
Fujitsu’s Hyper Converged Infrastructure simplies your ICT
FUJITSU Integrated System PRIMEFLEX for Microsoft Storage Spaces Direct
Fujitsu proposes a new style of infrastructure
ICT infrastructure plays important role to support business strategy. The system is expanding its complications everyday and increases costs to maintain infrastructure and
operations.
FUJITSU Integrated System PRIMEFLEX for Microsoft Storage Spaces Direct integrates storage into server with Software Defined Storage technology. Fujitsu original software
‘ServerView Infrastructure Manager for PRIMEFLEX’ (ISM for PRIMEFLEX) simplifies implementation, operation and expansion process.
The simple and easy next generation platform will provide easy and flexible infrastructure operation to optimize your investment.
■ Largely reduced setup works
Verified virtualization infrastructure based on Fujitsu knowledge, it largely reduces workload of design
process. Fujitsu customizes system to suit device specification for fast implementation.
■Immediate use with factory setup service
The PRIMEFLEX for Microsoft Storage Spaces Direct is setup in the factory with integration service before
delivery. The PRIMEFLEX for Microsoft Storage Spaces Direct can be used immediately after turning on a
system. It allows to start system operation immediately.
■High quality support (Operation, maintenance service SupportDesk)
Engineers at support center specialized in Hardware/Software technology support customer’s various
issues and reduces user workload.
Reliable and speedy implementation
Implement designed and pre-set system. High quality one-stop support system
after implementation
Fujitsu’s Hyper Converged Infrastructure simplies your ICT
FUJITSU Integrated System PRIMEFLEX for Microsoft Storage Spaces Direct
■ Small start from minimum 2 nodes
PRIMEFLEX for Microsoft Storage Spaces Direct can start small with as small as 2 nodes of simple
configurations with server alone. It can start small and expand as it grows up to 16 nodes. System
expansion with CPU / memory / built-in storage units can be done in addition to node unit when
the resource is lacking due to the increased workload of systems and users.
■ Simple and rapid expansion
Device expansion is simple and fast with integrated infrastructure operation management
software’s automated deployment tool. It reduces 50% of the workload* compare to previous.
Flexible and scalable
Optimizing infrastructure investment
Fujitsu’s Hyper Converged Infrastructure simplies your ICT
FUJITSU Integrated System PRIMEFLEX for Microsoft Storage Spaces Direct
‘ISM for PRIMEFLEX’, the dedicated software of PRIMEFLEX for Microsoft Storage Spaces Direct,
provides intuitive visual, operation and varieties of automated features. It conserves energy of
infrastructure deployment, operation and management.
Simple operation
New infrastructure operation with dedicated software
■ Easy management screen
Unify device management with GUI for intuitive operation. Status monitoring such as inlet temperature
and power consumption, device details can be unified managed.
Device location can check with 3D color screen. It has improved visibility with color warning when failure
occurs. It helps to identify the failure locations.
■Multiple features to reduce administrator’s burden
Firmware optimization can be automated (rolling update) to reduce workload of administrator.
Unified collection of hardware and OS logs. It reduces management workload by collecting logs regularly.
Fujitsu’s Hyper Converged Infrastructure simplies your ICT
FUJITSU Integrated System PRIMEFLEX for Microsoft Storage Spaces Direct
Usage scene
Contact
FUJITSU AMERICA, INC.
Address: 1250 East Arques Avenue Sunnyvale, CA 94085-3470, U.S.A.
Telephone: 800 831 3183 or 408 746 6000
Website: www.fujitsu.com/us
Contact Form: us.fujitsu.com/ContactFujitsu
Have a question? Email us at: AskFujitsu@us.fujitsu.com
Fujitsu, the Fujitsu logo and “shaping tomorrow with you“ are trademarks or registered trademarks of Fujitsu Limited in the United States and other
countries. All other trademarks referenced herein are the property of their respective owners.
The statements provided herein are for informational purposes only and may be amended or altered by Fujitsu America, Inc. without notice or liability.
Product description data represents Fujitsu design objectives and is provided for comparative purposes; actual results may vary based on a variety of
factors. Specications are subject to change without notice.
Copyright ©2018 Fujitsu America, Inc.
All rights reserved.
■Functions implemented in products differ according to operation
management software and model selected.
■Contents of this catalog are as of January 2018.
■Specifications and design may change without prior notice. Specifications,
designs etc. may change without prior notice due to editing.
■Company names and product names mentioned here are trademarks or
the registered trademarks of each company.
■Microsoft is a registered trademark or trademark of Microsoft Corporation
in the United States of America and other countries.
■Intel and Xeon are trademarks of Intel Corporation in the United States of
America and/or other countries.
■Company names and product names mentioned here are trademarks or
the registered trademarks of each company. Moreover, trademarks are not
necessarily indicated (®, TM) in the system name, product name, etc.
mentioned in this catalog.
Summary of specifications
Model PRIMEFLEX for Microsoft Storage Spaces Direct
Type Base type High performance/large capacity type
Server model PRIMERGY RX2530 M4 PRIMERGY RX2540 M4
Number of nodes 2 - 16
Node addition unit 1
Height per node 1U 2U
Hypervisor Microsoft Windows Server 2016 (Datacenter)
SDS Microsoft Storage Spaces Direct
Operation Management Software ServerView Infrastructure Manager for PRIMEFLEX
Number of
VM
Server virtualization *1
(per node) Up to approx. 33VM Up to approx.125VM
VDI *2
(per node) Up to approx. 66VM Up to approx. 198VM
Server
specication
(per 1 node)
Number of processors 2
Processor Intel Xeon Processor Scalable Family
Memory capacity 64 GB to 3,072 GB
Network interface 1000BASE-T× 3
10GBASE-T × 4
Storage
capacity *4
SSD cache *3 800GB - 3.84TB 800GB - 12.8TB
HDD data domain 2.4TB - 12TB 2.4TB - 40TB
Power 100V - 200V
Power unit (800W/1,200 × 2
*1 Estimated amount per 1 VM with CPU: 1GHz, Memory: 4GB, HDD: 100GB allocation
*2 Estimated amount per 1 VM with CPU: 630MHz, Memory: 4GB, HDD: 50GB(Linked clone) allocation
*3 It is recommended to set the capacity of SSD cache to 10% or more of the HDD data domain
*4 Physical capacity with SDD/HDD installation
