Great quality large
format printing to
match your passion
A desktop size printer to serve
professional photographers and
aspiring amateurs. Print in stunning
quality with a 12-ink system up to A2.
•Bring your images to life with stunning prints that
reproduce the detail and colour you work so hard to
capture.
•Print up to A2 with colour calibration on a variety of
paper, including glossy, matte, fine art or canvas.
•Using LUCIA PRO pigment inks, colours are richer and
blacks are deeper, producing prints that are faithful
to your images.
•With compatibility for a full range of devices and
platforms, print your images with ease from PCs,
smartphones, or the cloud.
•The Print Studio Pro plugin lets you print effortlessly
from professional editing software such as Adobe
Lightroom®, Photoshop® .
Product Range
imagePROGRAF
PRO-1000
PIXMA PRO-1
PIXMA PRO-10S
imagePROGRAF PRO-1000
PIXMA PRO-1
PIXMA PRO-10S
PIXMA PRO-100S
Technical Specifications
Canon Inc.
canon.com
Canon Europe
canon-europe.com
English edition
Canon Europa NV 2015
PRODUCT SPECIFICATION
Class 17"
Ink Type 12 Inks : MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO
Maximum Print Resolution [1] 2,400 x 1,200 dpi
Printing Speed [2] A2 (LU-101 colour): Approx. 3 min 35s
A2 (PT-101 colour or mono): Approx. 6 mins
Dimensions, Weight Approx. 723 x 433 x 285 mm
Weight approx. 32 kg (including print head and inks)
Power Supply AC 100-240V (50-
60Hz)
Power consumption (approx 37W) [3]
Standby consumption (approx 2.5W)
Power off (approx 0.4W)
Operational Environment Temperature: 5-35℃, Humidity: 10-90%RH (no dew
condensation) [4]
Acoustic Noise approx. 41.0 dB(A) -Photo (4 x 6“) [5]
approx. 40.8 Db(A) -Document (A4. B/W), Quiet Mode OFF [6]
approx. 40.4 Db(A) -Document (A4. B/W), Quiet Mode ON
Operation Panel Display 3.0" (320 x 240 TFT LCD), Key x 13, LED x 2
21 Languages Selectable: English / German / French / Turkish
/ Italian / Spanish / Portuguese / Dutch / Polish / Hungarian /
Danish / Norwegian / Swedish / Finnish / Czech / Russian /
Simplified Chinese / Traditional Chinese / Thai / Indonesian /
Japanese
Memory 1GB
INTERFACE TYPE & SOFTWARE
Supported Operating
Systems [7] Windows 32bit:
Windows Vista, Windows 7, Windows 8, Windows 8.1,
Windows 10
Windows Server 2008
Windows 64bit:
Windows Vista , Windows 7, Windows 8, Windows 8.1,
Windows 10
Windows Server 2008/2008R2, Windows Server 2012/2012R2
*Windows RT(Windows 8 ARM version) is not supported
Macintosh
OS10.7.5 -OS10.10.x
Supported Mobile Systems iOS
Android
Interface Hi Speed USB Type: Built-in
USB 2.0 High-Speed Full Speed (12 Mbit/sec),
High Speed (480 Mbit/sec), Bulk transfer
Wireless LAN Wi-Fi
IEEE802.11n
IEEE802.11g
IEEE802.11b
Ethernet Type Built-in:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX
Auto-Negotiation
Smart device & Cloud apps Canon PRINT app (iOS or Android)
Pro Gallery Print app (iPad only)
PIXMA Cloud Link
Apple AirPrint
Google Cloud Print
Camera direct Wi-Fi PictBridge
Software Print Studio Pro, Quick Utility Toolbox
PRINT HEAD
Type Canon Bubble-jet on Demand
Head Configuration 12 colors integrated type (4 colors chips x 3)
Nozzle Pitch 600dpi x 2
Nozzle per Chip 1,536 nozzles x 12 colors, includes Non-firing nozzle detection
and compensation system
Droplet Size 4 Picoliter per colour
INK TANK
Model LUCIA PRO Ink Tanks:
PFI-1000
MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO
Page yield (4 x 6" PT-101) [8] Number of 10x15cm photos
Matte Black (MBK): 5490 photos*
Photo Black (PBK): 2205 photos*
Grey (GY): 1465 photos*
Photo Grey (PGY): 3165 photos*
Photo Cyan (PC): 5140 photos*
Cyan (C): 5025 photos*
Photo Magenta (PM): 3755 photos
Magenta (M): 5885 photos*
Yellow (Y): 3365 photos
Red (R): 5355 photos*
Blue (B): 4875 photos*
Chroma Optimizer (CO): 680 photos
* Estimated Supplemental Yield
Page yield (A2 PT-101) [8] Number of A2 colour photos
Matte Black (MBK): 1600 photos*
Photo Black (PBK): 256 photos*
Grey (GY): 106 photos*
Photo Grey (PGY): 270 photos*
Photo Cyan (PC): 600 photos*
Cyan (C): 675 photos*
Photo Magenta (PM): 374 photos*
Magenta (M): 965 photos*
Yellow (Y): 329 photos
Red (R): 935 photos*
Blue (B): 545 photos*
Chroma Optimizer (CO): 97 photos*
* Estimated Supplemental Yield
MEDIA HANDLING
Media Feeding Rear tray / Manual feed slot
Media Type Plain Paper,
Photo Paper Plus Glossy II,
Photo Paper Pro Platinum,
Photo Paper Pro Luster,
Photo Paper Plus Semi-gloss,
Photo Paper Pro Premium Matte,
Matte Photo Paper,
Other Fine Art, Canvas and Glossy Photo Papers
Media size A5, A4, A3, A3+, A2, B5, B4, B3,
4x6", 5x7", 8x10", 10x12", 14x17", 17x22", LTR, LGL, LDR
Media Thickness Rear tray: Plain paper 64-105 g/m2, Canon specialty paper
Max. 300 g/m2,
Rear tray thickness: 0.1-0.3 mm
Manual feed slot: Canon specialty paper Max. 400 g/m2,
Manual feed thickness: 0.1-0.7 mm
Media Width Rear tray: 89-432 mm,
Manual feed slot: 203.2-432 mm
Minimal Printable Paper
Length Rear tray: 127 mm
Manual feed slot: 254 mm
Maximum Printable Paper
Length 594 mm
Margins (Top, Bottoms,
Sides) Recommended -Top margin: 57 mm,
Bottom margin: 55 mm, Left / Right: 3.4 mm
(LTR/LGL: Left margin 6.4 mm, Right margin 6.3mm）
Printable area -Top margin 3 mm, Bottom margin 5 mm,
Left/Right margin 3.4 mm
(LTR/LGL: Left margin 6.4 mm, Right margin 6.3 mm）
Media Width for Borderless
Printing[9] A4, A3, A3+, A2, 4x6", 5x7", 8x10", 10x12", 14x17", 17x22", LTR
CONSUMABLES
Ink Tank PFI-1000 MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO (80ml)
Maintenance Cartridge MC-20
Disclaimer
[1]
Ink droplets can be placed with a pitch of 1/2400 inch at minimum.
[2]
Print speed is based on the default setting using ISO/JIS
-SCID N5 and does not take
into account data processing time on host computer. Print speed may vary
depending on system configuration, interface, software, document complexity, print
mode, page coverage, type of paper used etc.
[3]
When printing ISO/JIS
-SCID N2 pattern on A4 size Photo Paper Pro Platinum (PT-101)
using default settings.
[4]
The performance of the printer may be reduced under certain temperature and
humidity conditions.
[5]
When printing ISO/JIS
-SCID N2 pattern on Photo Paper Pro Platinum using default
settings.
[6]
Acoustic Noise is measured based on ISO7779 standard.
[7]
Minimum system requirements is according to that of OS and application software
used.
[8]
Declared yield value in accordance with ISO/IEC 29103. Values obtained by
continuous printing.
[9]
Paper types NOT supported for borderless printing are as follows: Photo Stickers
Specifications are subject to change without notice.
Great quality large format
printing to match your passion
A desktop size printer to serve professional photographers and
aspiring amateurs. Print in stunning quality with a 12-ink system
up to A2.
Sales Start Date: February, 2016
Product Details:
Product Name Mercury Code EAN Code Recommended Retail Price
PRO-1000 GB 0608C008AA 4549292039696 TBC
Optional Accessories:
Product Name Mercury Code EAN Code Recommended Retail Price
PFI-1000MBK 0545C001AA 4549292046304 TBC
PFI-1000PBK 0546C001AA 4549292046342 TBC
PFI-1000C 0547C001AA 4549292046373 TBC
PFI-1000M 0548C001AA 4549292046403 TBC
PFI-1000Y 0549C001AA 4549292046434 TBC
PFI-1000PC 0550C001AA 4549292046465 TBC
PFI-1000PM 0551C001AA 4549292046496 TBC
PFI-1000R 0554C001AA 4549292045000 TBC
PFI-1000B 0555C001AA 4549292046595 TBC
PFI-1000GY 0552C001AA 4549292046526 TBC
PFI-1000PGY 0553C001AA 4549292044997 TBC
PFI-1000CO 0556C001AA 4549292046625 TBC
MC-20 OS 0628C002AA 4549292040210 TBC
Great quality large format
printing to match your passion
A desktop size printer to serve professional photographers and
aspiring amateurs. Print in stunning quality with a 12-ink system
up to A2.
What’s in the box?
•imagePROGRAF PRO-1000
•Power Cord
•Print Head
•12 individual ink tanks
•Sample Media, LU-101 A3 x 5
•Head alignment media MP-101 A4 x 2
•Setup CD-ROM (CD only for Windows –
Mac drivers available online*)
•Starter guide
*All drivers and mobile apps are available online at
http://www.canon.com/ijsetup
Measurement / Logistic Information:
Product Name Mercury Code Pack description Quantity per
pack Length
(mm) Width
(mm) Height
(mm) Gross / Net
Weight (kg)
PRO-1000 GB 0608C008AA Individual 11006 556 433 38.3 / 30.7
Pallet (Upper) 41118 1012 870 154.7 / 153.2
Pallet (Bottom) 41118 1012 870 154.7 / 153.2
