EC2x&EG9x&EM05 HTTP(S)
AT Commands Manual
LTE Module Series
Rev. EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual_V1.0
Date: 2017-11-20
Status: Released
www.quectel.com
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 1 / 36
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China
Tel: +86 21 5108 6236
Email: info@quectel.com
Or our local office. For more information, please visit:
http://quectel.com/support/sales.htm
For technical support, or to report documentation errors, please visit:
http://quectel.com/support/technical.htm
Or email to: support@quectel.com
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION
AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE
FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF
DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR
REGISTRATION OF A UTILITY MODEL OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2017. All rights reserved.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 2 / 36
About the Document
History
Revision
Date
Author
Description
1.0
2017-11-20
Duke XIN/
Haley HUANG
Initial
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 3 / 36
Contents
About the Document ................................................................................................................................... 2
Contents ....................................................................................................................................................... 3
Table Index ................................................................................................................................................... 5
1 Introduction .......................................................................................................................................... 6
1.1. The Process of Using HTTP(S) AT Commands ...................................................................... 6
1.2. Description of HTTP(S) Header .............................................................................................. 7
1.2.1. Customize HTTP(S) Request Header ............................................................................. 7
1.2.2. Output HTTP(S) Response Header ................................................................................. 7
1.3. Description of Data Mode ........................................................................................................ 8
2 Description of HTTP(S) AT Commands ............................................................................................. 9
2.1. AT+QHTTPCFG Configure Parameters for HTTP(S) Server ............................................... 9
2.2. AT+QHTTPURL Set URL of HTTP(S) Server .................................................................... 12
2.3. AT+QHTTPGET Send GET Request to HTTP(S) Server .................................................. 13
2.4. AT+QHTTPGETEX Send Range GET Request to HTTP(S) Server.................................. 14
2.5. AT+QHTTPPOST Send POST Request to HTTP(S) Server via UART/USB .................... 15
2.6. AT+QHTTPPOSTFILE Send POST Request to HTTP(S) Server via File ......................... 17
2.7. AT+QHTTPREAD Read Response from HTTP(S) Server via UART/USB ........................ 18
2.8. AT+QHTTPREADFILE Read Response from HTTP(S) Server via File ............................ 19
2.9. AT+QHTTPSTOP Cancel HTTP(S) Request ..................................................................... 20
3 Examples ............................................................................................................................................ 21
3.1. Access to HTTP Server ......................................................................................................... 21
3.1.1. Send HTTP GET Request and Read the Response ..................................................... 21
3.1.2. Send HTTP POST Request and Read the Response ................................................... 22
3.1.2.1. Post Body Obtained from UART/USB ................................................................... 22
3.1.2.2. Post Body Obtained from File System .................................................................. 23
3.2. Access to HTTPS Server ...................................................................................................... 24
3.2.1. Send HTTPS GET Request and Read the Response ................................................... 24
3.2.2. Send HTTPS POST Request and Read the Response ................................................ 26
3.2.2.1. Post Body Obtained from UART/USB ................................................................... 26
3.2.2.2. Post Body Obtained from File System .................................................................. 28
4 Error Handling .................................................................................................................................... 30
4.1. Executing HTTP(S) AT Commands Fails .............................................................................. 30
4.2. PDP Activation Fails .............................................................................................................. 30
4.3. DNS Parse Fails .................................................................................................................... 30
4.4. Entering Data Mode Fails ...................................................................................................... 31
4.5. Sending GET/POST Requests Fails .................................................................................. 31
4.6. Reading Response Fails ....................................................................................................... 31
5 Summary of ERROR Codes .............................................................................................................. 33
6 Summary of HTTP(S) Response Codes .......................................................................................... 35
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 5 / 36
Table Index
TABLE 1: SUMMARY OF ERROR CODES ...................................................................................................... 33
TABLE 2: SUMMARY OF HTTP(S) RESPONSE CODES ................................................................................ 35
TABLE 3: RELATED DOCUMENTS .................................................................................................................. 36
TABLE 4: TERMS AND ABBREVIATIONS ........................................................................................................ 36
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 6 / 36
1 Introduction
EC2x&EG9x&EM05 modules provide HTTP(S) application to HTTP(S) server. This document is a
reference guide to all the AT commands defined for HTTP(S).
This document is applicable to following Quectel modules.
EC2x (including EC25, EC21, EC20 R2.0 and EC20 R2.1)
EG9x (including EG91 and EG95)
EM05
1.1. The Process of Using HTTP(S) AT Commands
Through EC2x&EG9x&EM05 TCP/IP AT commands, customers can configure a PDP context,
activate/deactivate the PDP context and query the PDP context status. And through EC2x&EG9x&EM05
HTTP(S) AT commands, customers can send HTTP(S) GET/POST requests to HTTP(S) server, and read
HTTP(S) response from HTTP(S) server. The general process is as follows:
Step 1: Configure <APN>, <username>, <password> and other parameters of a PDP context by
AT+QICSGP. Please refer to Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual
for details. If QoS settings need to be updated, configure them by AT+CGQMIN, AT+CGEQMIN,
AT+CGQREQ and AT+CGEQREQ commands. For more details, please refer to
Quectel_EC25&EC21_AT_Commands_Manual, Quectel_EG9x_AT_Commands_Manual and
Quectel_EM05_AT_Commands_Manual.
Step 2: Activate the PDP context by AT+QIACT, then the assigned IP address can be queried by
AT+QIACT?. Please refer to Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual for
details.
Step 3: Configure the PDP context ID and SSL context ID by AT+QHTTPCFG command.
Step 4: Configure SSL context parameters by AT+QSSLCFG command. For more details, please refer
to Quectel_EC2x&EG9x&EM05_SSL_AT_Commands_Manual.
Step 5: Set HTTP(S) URL by AT+QHTTPURL command.
Step 6: Send HTTP(S) request. AT+QHTTPGET command can be used for sending HTTP(S) GET
request, and AT+QHTTPPOST or QHTTPOSTFILE command can be used for sending HTTP(S)
POST request.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 7 / 36
Step 7: Read HTTP(S) response information by AT+QHTTPREAD or QHTTPREADFILE command.
Step 8: Deactivate the PDP context by AT+QIDEACT command. For more details, please refer to
Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual.
1.2. Description of HTTP(S) Header
1.2.1. Customize HTTP(S) Request Header
HTTP(S) request header is filled by the module automatically. HTTP(S) request header can be
customized by configuring <request_header> as 1 via AT+QHTTPCFG command, and then inputting
HTTP(S) request header according to the following requirements:
1. Follow HTTP(S) header syntax.
2. The value of URI in HTTP(S) request line and the “Host:” header must be in line with the URL
configured by AT+QHTTPURL command.
3. The HTTP(S) request header must end with <CR><LF>.
The following example shows a valid HTTP(S) POST request header:
POST /processorder.php HTTP/1.1<CR><LF>
Host: 220.180.239.212:8011<CR><LF>
Accept: */*<CR><LF>
User-Agent: QUECTEL_MODULE<CR><LF>
Connection: Keep-Alive<CR><LF>
Content-Type: application/x-www-form-urlencoded<CR><LF>
Content-Length: 48<CR><LF>
<CR><LF>
Message=1111&Appleqty=2222&Orangeqty=3333&find=1
1.2.2. Output HTTP(S) Response Header
HTTP(S) response header will not be outputted automatically. HTTP(S) response header information can
be obtained by configuring <response header> to 1 via AT+QHTTPCFG command, and then HTTP(S)
response header will be outputted with HTTP(S) response body after executing AT+QHTTPREAD or
AT+QHTTPREADFILE command.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 8 / 36
1.3. Description of Data Mode
The COM port of EC2x&EG9x&EM05 module has two working modes: AT command mode and data
mode. In AT command mode, the inputted data via COM port will be treated as AT command. While in
data mode, it will be treated as data.
Inputting “+++” or pulling up DTR (AT&D1 should be set first) can make the COM port exit from data mode.
To prevent the “+++” from being misinterpreted as data, the following sequence should be followed:
1) Do not input any character within 1s or longer before inputting “+++”.
2) Input “+++” within 1s, and no other characters can be inputted during the time.
3) Do not input any character within 1s after “+++” has been inputted.
When AT+QHTTPURL, AT+QHTTPOST and AT+QHTTPREAD are executed, the COM port will enter
data mode. If customers are using “+++” or DTR to make the port exit from data mode, the executing
procedure of these commands will be interrupted before the response is returned. In such case, the COM
port cannot reenter data mode by executing ATO command.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 9 / 36
2 Description of HTTP(S) AT Commands
2.1. AT+QHTTPCFG Configure Parameters for HTTP(S) Server
The command is used to configure the parameters for HTTP(S) server, including configuring a PDP
context ID, customizing HTTP(S) request header, outputting HTTP(S) response header and querying SSL
settings. If the Write Command only executes one parameter, it will query the current settings.
AT+QHTTPCFG Configure Parameters for HTTP(S) Server
Test Command
AT+QHTTPCFG=?
Response
+QHTTPCFG: "contextid",(1-16)
+QHTTPCFG: "requestheader",(0,1)
+QHTTPCFG: "responseheader",(0,1)
+QHTTPCFG: "sslctxid",(0-5)
+QHTTPCFG: "contenttype",(0-3)
+QHTTPCFG: "rspout/auto",(0,1)
+QHTTPCFG: "closed/ind",(0,1)
OK
Write Command
AT+QHTTPCFG="contextid"[,<contextI
D>]
Response
If <contextID> is not omitted:
OK
Or
+CME ERROR: <err>
If <contextID> is omitted, query the current settings:
+QHTTPCFG: "contextid",<contextID>
OK
Write Command
AT+QHTTPCFG="requestheader"[,<re
quest_header>]
Response
If <request_header> is not omitted:
OK
Or
+CME ERROR: <err>
If <request_header> is omitted , query the current settings:
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 10 / 36
+QHTTPCFG: "requestheader",<request_header>
OK
Write Command
AT+QHTTPCFG="responseheader"[,<r
esponse_header>]
Response
If <response_header> is not omitted:
OK
Or
+CME ERROR: <err>
If <response_header> is omitted , query the current settings:
+QHTTPCFG: "responseheader",<response_header>
OK
Write Command
AT+QHTTPCFG="sslctxid"[,<sslctxID>
]
Response
If <sslctxID> is not omitted:
OK
Or
+CME ERROR: <err>
If <sslctxID> is omitted, query the current settings:
+QHTTPCFG: "sslctxid",<sslctxID>
OK
Write Command
AT+QHTTPCFG="rspout/auto"[,<auto_
outrsp>]
Response
If <auto_outrsp> is not omitted:
OK
Or
+CME ERROR: <err>
If <auto_outrsp> is omitted, query the current settings:
+QHTTPCFG: "rspout/auto",<auto_outrsp>
OK
Write Command
AT+QHTTPCFG="closed/ind"[,<closed
ind>]
Response
If <closedind> is not omitted:
OK
Or
+CME ERROR: <err>
If <closedind> is omitted, query the current settings:
+QHTTPCFG: "closed/ind",<closedind>
OK
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 11 / 36
Parameter
AT+QHTTPCFG="rspout/auto"[,<auto_outrsp>] and AT+QHTTPCFG="closed/ind"[,<closedind>] are
not supported on EM05 module currently.
Read Command
AT+QHTTPCFG?
Response
+QHTTPCFG: "contextid",<contextID>
+QHTTPCFG: "requestheader",<request_header>
+QHTTPCFG: "responseheader",<response_header>
+QHTTPCFG: "sslctxid",<sslctxID>
+QHTTPCFG: "contenttype",<content_type>
+QHTTPCFG: "rspout/auto",<auto_outrsp>
+QHTTPCFG: "closed/ind",<closedind>
OK
<contextID> Numeric type. PDP context ID. The range is 1-16, and the default value is 1.
<request_header> Numeric type. Disable or enable to customize HTTP(S) request header.
0 Disable
1 Enable
<response_header> Numeric type. Disable or enable to output HTTP(S) response header.
0 Disable
1 Enable
<sslctxID> Numeric type. SSL context ID used for HTTP(S). The range is 0-5, and the
default value is 1. Customers should configure the SSL parameters by
AT+QSSLCFG. For details, please refer to Quectel_EC2x&EG9x&EM05_
SSL_AT_ Commands_Manual.
<content_type> Numeric type. Data type of HTTP(S) body.
0 application/x-www-form-urlencoded
1 text/plain
2 application/octet-stream
3 multipart/form-data
<auto_outrsp> Numeric type. Disable or enable auto output of HTTP(S) response data. If
auto output of HTTP(S) response data is enabled, then the execution of
AT+QHTTPREAD and AT+QHTTPREADFILE commands will be failed.
0 Disable
1 Enable
<closedind> Numeric type. Disable or enable report indication of closed HTTP(S) session.
0 Disable
1 Enable
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
NOTE
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 12 / 36
2.2. AT+QHTTPURL Set URL of HTTP(S) Server
URL must begin with “http://” or “https://”, which indicates the access to an HTTP or HTTPS server.
Parameter
<URL_length> Numeric type. The length of URL. The range is 1-2048. Unit: byte.
<timeout> Numeric type. The maximum time for inputting URL. The range is 1-65535, and
the default value is 60. Unit: second.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
AT+QHTTPURL Set URL of HTTP(S) Server
Test Command
AT+QHTTPURL=?
Response
+QHTTPURL: (1-2048),(1-65535)
OK
Write Command
AT+QHTTPURL=<URL_length>[,<tim
eout>]
Response
a) If the parameter format is correct, and it is not sending
HTTP(S) GET/POST requests:
CONNECT
TA switches to transparent access mode, and the URL can be
inputted. When the total size of the inputted data reaches
<URL_length>, TA will return to command mode and report
the following code:
OK
If the <timeout> has reached, but the received length of URL
is less than <URL_length>, TA will return to command mode
and report the following code:
+CME ERROR: <err>
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
Read Command
AT+QHTTPURL?
Response
[+QHTTPURL: <URL><CR><LF>]
OK
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 13 / 36
2.3. AT+QHTTPGET Send GET Request to HTTP(S) Server
According to the configured <request_header> parameter in AT+QHTTPCFG="requestheader"[,
<request_header>] command, AT+HTTPGET Write Command has two different formats. If
<request_header> is set to 1, after AT+QHTTPGET command has been sent, "CONNECT" may be
outputted in 125s to indicate that the connection is successful. If it is not outputted during the time, then
"+CME ERROR: <err>" will be outputted.
After AT+HTTPGET Write Command has been sent, it is recommended to wait for a specific period of
time (refer to the maximum response time below) for "+QHTTPGET:
<err>[,<httprspcode>[,<content_length>]]" to be outputted after "OK" is reported.
In "+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]", the <httprspcode> parameter can only be
reported when <err> equals 0. If HTTP(S) response header contains "CONTENT-LENGTH" information,
then <content_length> information will be reported.
AT+QHTTPGET Send GET Request to HTTP(S) Server
Test Command
AT+QHTTPGET=?
Response
+QHTTPGET: (1-65535),(1-2048),(1-65535)
OK
If <request_header> equals 0 (disable
to customize HTTP(S) request header)
Write Command
AT+QHTTPGET[=<rsptime>]
Response
a) If the parameter format is correct and no other errors occur:
OK
When the module has received response from HTTP(S)
server, it will report the following URC:
+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
If <request_header> equals 1 (enable to
customize HTTP(S) request header)
Write Command
AT+QHTTPGET=<rsptime>,<data_len
gth>[,<input_time>]
Response
a) If HTTP(S) server is connected successfully:
CONNECT
TA switches to transparent access mode, and the HTTP(S)
GET request header can be inputted. When the total size of
the inputted data reaches <data_length>, TA will return to
command mode and report the following code:
OK
When the module has received response from HTTP(S)
server, it will report the following URC:
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 14 / 36
Parameter
<rsptime> Numeric type. The range is 1-65535, and the default value is 60. Unit: second. It is
used to configure the timeout for the HTTP(S) GET response "+QHTTPGET:
<err>[,<httprspcode>,<content_length>]" to be outputted after "OK" is returned.
<data_length> Numeric type. The length of HTTP(S) request information, including HTTP(S)
request header and HTTP(S) request body. The range is 1-2048. Unit: byte.
<input_time> Numeric type. The maximum time for inputting HTTP(S) request
information. The range is 1-65535, and the default value is 60. Unit: second.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
<httprspcode> Please refer to Chapter 6.
<request_header> Please refer to Chapter 2.1.
<content_length> Numeric type. The length of HTTP(S) response body. Unit: byte.
2.4. AT+QHTTPGETEX Send Range GET Request to HTTP(S) Server
Like read files, MCU can get data from HTTP(S) server with specified position and specified length by
AT+HTTPGETEX command, and this command is only executable in the condition of
AT+QHTTPCFG="requestheader",0. After that, HTTP(S) server will always respond to Range GET
Request with "206" code.
+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]
If the <input_time> has reached, but the length of received
data is less than <data_length>, TA will return to command
mode and report the following code:
+CME ERROR: <err>
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by <rsptime>
AT+QHTTPGETEX Send Range GET Request to HTTP(S) Server
Test Command
AT+QHTTPGETEX=?
Response
+QHTTPGETEX: (1-65535),<start_postion>,<read_len>
OK
Write Command
AT+QHTTPGET=<rsptime>,<start_po
sition>,<read_len>
Response
a) If the parameter format is correct and no other errors occur:
OK
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 15 / 36
Parameter
<rsptime> Numeric type. The range is 1-65535, and the default value is 60. Unit: second. It is
used to configure the timeout for the HTTP(S) GET response "+QHTTPGET:
<err>[,<httprspcode>,<content_length>]" to be outputted after "OK" is returned.
<start_postion > Numeric type. The start position of the data that the HTTP(S) client wants to GET.
<read_len> Numeric type. The length of the data that the HTTP(S) client wants to GET.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
<httprspcode> Please refer to Chapter 6.
<content_length> Numeric type. The length of HTTP(S) response body. Unit: byte.
AT+QHTTPGETE command is not supported on EM05 module currently.
2.5. AT+QHTTPPOST Send POST Request to HTTP(S) Server via
UART/USB
The command is used to send HTTP(S) POST request. According to the configured <request_header>
parameter in AT+QHTTPCFG="requestheader"[,<request_header>] command, the AT+QHTTPPOST
Write Command has two different formats. If <request_header> is set to 0, post body should be inputted
via UART/USB port. If <request_header> is set to 1, then both post header and body should be inputted
via UART/USB port.
After AT+QHTTPPOST command has been sent, "CONNECT" may be outputted in 125s to indicate the
connection is successful. If it is not received during the time, "+CME ERROR: <err>" will be outputted.
It is recommended to wait for a specific period of time (refer to the maximum response time below) for
"+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]" to be outputted after "OK" is reported.
When the module has received response from HTTP(S)
server, it will report the following URC:
+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by <rsptime>
NOTE
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 16 / 36
AT+QHTTPPOST Send POST Request to HTTP(S) Server via UART/USB
Test Command
AT+QHTTPPOST=?
Response
+QHTTPPOST: (1-1024000),(1-65535),(1-65535)
OK
If <request_header> equals 0 (disable
to customize HTTP(S) request header)
Write Command
AT+QHTTPPOST=<data_length>[,<in
put_time>,<rsptime>]
Response
a) If the parameter format is correct and HTTP(S) server is
connected successfully and HTTP(S) request header is sent
completely, it will prompt to input body:
CONNECT
TA switches to transparent access mode, and the HTTP(S)
POST body can be inputted. When the total size of the
inputted data reaches <data_length>, TA will return to
command mode and report the following code:
OK
When the module has received response from HTTP(S)
server, it will report the following URC:
+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]
If the <input_time> has reached, but the received length of
data is less than <data_length>, TA will return to command
mode and report the following code:
+CME ERROR: <err>
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
If <request_header> equals 1 (enable to
customize HTTP(S) request header)
Write Command
AT+QHTTPPOST=<data_length>[,<in
put_time>,<rsptime>]
Response
a) If the parameter format is correct and HTTP(S) server is
connected successfully:
CONNECT
TA switches to the transparent access mode, and the
HTTP(S) POST header and body can be inputted. When the
total size of the inputted data reaches <data_length>, TA will
return to command mode and report the following code:
OK
When the module has received response from HTTP(S)
server, it will report the following URC:
+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 17 / 36
Parameter
<data_length> Numeric type. If <request_header> is 0, it indicates the length of post body,
and if <request_header> is 1, it indicates the length of HTTP(S) request
information, including HTTP(S) request header and HTTP(S) request body.
The range is 1-1024000. Unit: byte.
<input_time> Numeric type. The maximum time for inputting post body or HTTP(S) request
information. The range is 1-65535, and the default value is 60. Unit: second.
<rsptime> Numeric type. The range is 1-65535, and the default value is 60. Unit:
second. It is used to configure the timeout for the HTTP(S) POST response
"+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]" to be outputted
after "OK" is returned.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
<httprspcode> Please refer to Chapter 6.
<request_header> Please refer to Chapter 2.1.
<content_length> Numeric type. The length of HTTP(S) response body. Unit: byte.
2.6. AT+QHTTPPOSTFILE Send POST Request to HTTP(S) Server via
File
The command can be used to send HTTP(S) POST request via file. According to the <request_header>
in AT+QHTTPCFG="requestheader"[,<request_header>] command, the file operated by
AT+HTTPPOSTFILE command has two different formats. If <request_header> is set to 0, the file in file
system will be post body. If <request_header> is set to 1, the file in file system will be post header and
body.
The module will report "+QHTTPPOSTFILE: <err>[,<httprspcode>[,<content_length>]]" information to
indicate the executing result of AT+QHTTPPOSFILE command. The <httprspcode> parameter can only
be reported when <err> equals 0.
If the <input_time> has reached, but the length of received
data is less than <data_length>, TA will return to command
mode and report the following code:
+CME ERROR: <err>
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by network and <rsptime>
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 18 / 36
It is recommended to wait for a specific period of time (refer to the maximum response time below) for
"+QHTTPPOSTFILE: <err>[,<httprspcode>[,<content_length>]]" to be outputted after "OK" is reported.
Parameter
<file_name> String type. File name. The max length of file name is 80 bytes.
<rsptime> Numeric type. The range is 1-65535, and the default value is 60. Unit:
second. It is used to configure the timeout for the HTTP(S) POST response
"+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]" to be
outputted after "OK" is returned.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
<httprspcode> Please refer to Chapter 6.
<request_header> Please refer to Chapter 2.1.
<content_length> Numeric type. The length of HTTP(S) response body. Unit: byte.
2.7. AT+QHTTPREAD Read Response from HTTP(S) Server via
UART/USB
After sending HTTP(S) GET/POST requests, customers can retrieve HTTP(S) response information from
HTTP(S) server via UART/USB port by AT+QHTTPREAD command. And "+QHTTPGET:
<err>[,<httprspcode>[,<content_length>]]", "+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]" or
AT+QHTTPPOSTFILE Send POST Request to HTTP(S) Server by File
Test Command
AT+QHTTPPOSTFILE=?
Response
+QHTTPPOSTFILE: <file_name>,(1-65535)
OK
Write Command
AT+QHTTPPOSTFILE=<file_name>[,<
rsptime>]
If <request_header> equals 1, the
specified file must contain HTTP(S)
request header information.
Response
a) If parameter format is correct and HTTP(S) server is
connected successfully:
OK
When the module has received response from HTTP(S)
server, it will report the following URC:
+QHTTPPOSTFILE:
<err>[,<httprspcode>,<content_length>]
b) If parameter format is incorrect or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by <rsptime>
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 19 / 36
"+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]" information must be received before
executing AT+QHTTPREAD command.
Parameter
<wait_time> Numeric type. The maximum interval time between receiving two packets of data.
The range is 1-65535, and the default value is 60. Unit: second.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
2.8. AT+QHTTPREADFILE Read Response from HTTP(S) Server via File
After sending HTTP(S) GET/POST requests, customers can retrieve HTTP(S) response information from
HTTP(S) server via file by AT+QHTTPREADFILE. And "+QHTTPGET:
<err>[,<httprspcode>[,<content_length>]]", "+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]" or
"+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]" information must be received before
executing AT+QHTTPREADFILE command.
AT+QHTTPREAD Read Response from HTTP(S) Server via UART/USB
Test Command
AT+QHTTPREAD=?
Response
+QHTTPREAD: (1-65535)
OK
Write Command
AT+QHTTPREAD[=<wait_time>]
Response
a) If the parameter format is correct and read successfully:
CONNECT
<Output HTTP(S) response information>
OK
+QHTTPREAD: <err>
If <wait_time> reaches or other errors occur, but body has not
been outputted completely, it will report the following code:
+CME ERROR: <err>
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
AT+QHTTPREADFILE Read Response from HTTP(S) Server via File
Test Command
AT+QHTTPREADFILE=?
Response
+QHTTPREADFILE: <file_name>,(1-65535)
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 20 / 36
Parameter
<wait_time> Numeric type. The maximum interval time between receiving two packets of
data. The range is 1-65535, and the default value is 60. Unit: second.
<file_name> String type. File name. The maximum length of the file name is 80 bytes.
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
2.9. AT+QHTTPSTOP Cancel HTTP(S) Request
MCU can cancel HTTP(S) GET/POST request, and disconnect session with HTTP(S) server via this
command.
AT+QHTTPSTOP command is not supported on EG9x and EM05 modules currently.
OK
Write Command
AT+QHTTPREADFILE=<file_name>[,
<wait_time>]
Response
a) If the parameter format is correct:
OK
When body is read over or <wait_time> reaches, it will report:
+QHTTPREADFILE: <err>
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
AT+QHTTPSTOP Cancel HTTP(S) Request
Test Command
AT+QHTTPSTOP=?
Response
OK
Execution Command
AT+QHTTPSTOP
Response
a) If the parameter format is correct and no other errors occur:
OK
b) If the parameter format is incorrect or other errors occur:
+CME ERROR: <err>
Maximum Response Time
10s
NOTE
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 21 / 36
3 Examples
3.1. Access to HTTP Server
3.1.1. Send HTTP GET Request and Read the Response
The following examples show how to send HTTP GET request and enable output of HTTP response
header, as well as how to read HTTP GET response.
//Example of how to send HTTP GET response.
AT+QHTTPCFG="contextid",1 //Configure the PDP context ID as 1.
OK
AT+QHTTPCFG="responseheader",1 //Allow to output HTTP response header.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,"UNINET","","" ,1 //Configure PDP context 1. APN is "UNINET" for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"10.7.157.1"
OK
AT+QHTTPURL=23,80 //Set the URL which will be accessed.
CONNECT
HTTP://www.sina.com.cn/ //Input URL whose length is 23 bytes. (This URL is only an
example. Please input the correct URL in practical test.)
OK
AT+QHTTPGET=80 //Send HTTP GET request and the maximum response time is
80s.
OK
+QHTTPGET: 0,200,601710 //If HTTP response header contains "CONTENT-LENGTH"
information, then the <content_length> information will be
reported.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 22 / 36
//Example of how to read HTTP response.
//Solution 1: Read HTTP response information and output it via UART port.
AT+QHTTPREAD=80 //Read HTTP response information and output it via UART.
The maximum time to wait for HTTP session to be closed is
80s.
CONNECT
HTTP/1.1 200 OK <CR><LF> //HTTP response header and body
Server: nginx<CR><LF>
Date: Tue, 12 Sep 2017 05:57:29 GMT<CR><LF>
Content-Type: text/html<CR><LF>
Content-Length: 601710<CR><LF>
Connection: close<CR><LF>
Last-Modified: Tue, 12 Sep 2017 05:54:48 GMT<CR><LF>
Vary: Accept-Encoding<CR><LF>
Expires: Tue, 12 Sep 2017 05:58:28 GMT<CR><LF>
Cache-Control: max-age=60<CR><LF>
X-Powered-By: shci_v1.03<CR><LF>
Age: 1<CR><LF>
……<CR><LF> //Lines are omitted here
<CR><LF>
<body>
OK
+QHTTPREAD: 0 //Read HTTP response header and body successfully.
//Solution 2: Read HTTP response information and store it to RAM file.
AT+QHTTPREADFILE="RAM:1.txt",80 //Read HTTP response header and body and store them to
“RAM:1.txt”. The maximum time to wait for HTTP session to
be closed is 80s.
OK
+QHTTPREADFILE: 0 //HTTP response header and body are stored successfully.
3.1.2. Send HTTP POST Request and Read the Response
3.1.2.1. Post Body Obtained from UART/USB
The following examples show how to send HTTP POST request and retrieve post body via UART port, as
well as how to read HTTP POST response.
AT+QHTTPCFG="contextid",1 //Configure the PDP context ID as 1.
OK
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 23 / 36
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,"UNINET","" ,"" ,1 //Configure PDP context 1. APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPURL=59,80 //Set the URL which will be accessed.
CONNECT
http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo? //Input URL whose length is 59
bytes. (This URL is only an
example. Please input the
correct URL in practical test.)
OK
AT+QHTTPPOST=20,80,80 //Send HTTP POST request. POST body is obtained via UART.
The maximum input body time is 80s and the maximum
response time is 80s.
CONNECT
Message=HelloQuectel //Input post body whose length is 20 bytes. (The post body is
only an example. Please input the correct post body in
practical test.)
OK
+QHTTPPOST: 0,200,177 //If the HTTP response header contains
"CONTENT-LENGTH" information, then the <content_length>
information will be reported.
AT+QHTTPREAD=80 //Read HTTP response body and output it via UART. The
maximum time to wait for HTTP session to be closed is 80s.
CONNECT
<?xml version="1.0" encoding="utf-8"?>
<string xmlns="httpHTTPs://api.efxnow.com/webservices2.3">Message='HelloQuectel' ASCII:72
101 108 108 111 81 117 101 99 116 101 108 </string> //Output HTTP response body.
OK
+QHTTPREAD: 0 //HTTP response body is outputted successfully.
3.1.2.2. Post Body Obtained from File System
The following examples show how to send HTTP POST request and retrieve post body via file system, as
well as how to store HTTP POST response to file system.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 24 / 36
AT+QHTTPCFG="contextid",1 //Configure the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,"UNINET","" ,"" ,1 //Configure PDP context 1. APN is "UNINET" for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPURL=59,80 //Set the URL which will be accessed.
CONNECT
http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo? //Input URL whose length is 59
bytes. (This URL is only an
example. Please input the
correct URL in practical test.)
OK
//POST request information from RAM file, and read HTTP response information and store it to RAM file.
AT+QHTTPPOSTFILE="RAM:2.txt",80 //Send HTTP POST request. POST body is obtained from
"RAM:2.txt", and the maximum response time is 80s.
OK
+QHTTPPOSTFILE: 0,200,177 //After HTTP POST request is sent successfully,
AT+QHTTPREAD command can be executed.
AT+QHTTPREADFILE="RAM:3.txt",80 //Read HTTP response body and store it to "RAM:3.txt". The
maximum time to wait for HTTP session to be closed is 80s.
OK
+QHTTPREADFILE: 0 //HTTP response body is stored successfully.
3.2. Access to HTTPS Server
3.2.1. Send HTTPS GET Request and Read the Response
The following examples show how to send HTTPS GET request and enable output of HTTPS response
header, as well as how to read HTTPS GET response.
//Example of how to send HTTPS GET request.
AT+QHTTPCFG="contextid",1 //Configure the PDP context ID as 1.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 25 / 36
OK
AT+QHTTPCFG="responseheader",1 //Allow to output HTTPS response header.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,"UNINET","" ,"" ,1 //Configure PDP context 1. APN is "UNINET" for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"10.7.157.1"
OK
AT+QHTTPCFG="sslctxid",1 //Set SSL context ID.
OK
AT+QSSLCFG="sslversion",1,1 //Set SSL version as 1 which means TLSV1.0.
OK
AT+QSSLCFG="ciphersuite",1,0x0005 //Set SSL cipher suite as 0x0005 which means RC4-SHA.
OK
AT+QSSLCFG="seclevel",1,0 //Set SSL verify level as 0 which means CA certificate is not
needed.
OK
AT+QHTTPURL=22,80 //Set the URL which will be accessed.
CONNECT
https://www.alipay.com //Input URL whose length is 19 bytes. (This URL is only an
example. Please input the correct URL in practical test.)
OK
AT+QHTTPGET=80 //Send HTTPS GET request and the maximum response time
is 80s.
OK
+QHTTPGET: 0,200,21472 //If the HTTPS response header contains "CONTENT-LENGTH"
information, then the <content_length> information will be
reported.
//Example of how to read HTTPS response.
//Solution 1: Read HTTPS response information and output it via UART.
AT+QHTTPREAD=80 //Read HTTPS response information and output it via UART.
The maximum time to wait for HTTPS session to be closed is
80s.
CONNECT //HTTPS response header and body.
HTTP/1.1 200 OK<CR><LF>
Server: Tengine/2.1.0<CR><LF>
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 26 / 36
Date: Tue, 12 Sep 2017 05:54:34 GMT <CR><LF>
Content-Type: text/html; charset=utf-8<CR><LF>
Content-Length: 21451<CR><LF>
Connection: keep-alive <CR><LF>
…… <CR><LF> //Lines are omitted here
<CR><LF>
<body>
OK
+QHTTPREAD: 0 //Read HTTPS response header and body successfully.
//Solution 2: Read HTTPS response information and store it to RAM file.
AT+QHTTPREADFILE="RAM:4.txt",80 //Read HTTPS response header and body and store them to
"RAM:4.txt". The maximum time to wait for HTTPS session
to be closed is 80s.
OK
+QHTTPREADFILE: 0 //HTTPS response header and body are stored successfully.
3.2.2. Send HTTPS POST Request and Read the Response
3.2.2.1. Post Body Obtained from UART/USB
The following examples show how to send HTTPS POST request and retrieve post body via UART port,
as well as how to read HTTPS POST response.
AT+QHTTPCFG="contextid",1 //Configure the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,"UNINET","" ,"" ,1 //Configure PDP context 1. APN is "UNINET" for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPCFG="sslctxid",1 //Set SSL context ID.
OK
AT+QSSLCFG="sslversion",1,1 //Set SSL version as 1 which means TLsV1.0.
OK
AT+QSSLCFG="ciphersuite",1,0x0005 //Set SSL cipher suite as 0x0005 which means RC4-SHA.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 27 / 36
OK
AT+QSSLCFG="seclevel",1,2 //Set SSL verify level as 2 which means CA certificate, client
certificate and client private key should be uploaded by
AT+QFUPL command.
OK
AT+QSSLCFG="cacert",1,"RAM:cacert.pem"
OK
AT+QSSLCFG="clientcert",1,"RAM:clientcert.pem"
OK
AT+QSSLCFG="clientkey",1,"RAM:clientkey.pem"
OK
AT+QHTTPURL=45,80 //Set the URL which will be accessed.
CONNECT
HTTPs://220.180.239.212:8011/processorder.php //Input URL whose length is 45 bytes. (This URL is
only an example. Please input the correct URL in
practical test.)
OK
AT+QHTTPPOST=48,80,80 //Send HTTPS POST request. POST body is obtained from UART.
The maximum input body time is 80s and the maximum
response time is 80s.
CONNECT
Message=1111&Appleqty=2222&Orangeqty=3333&find=1 //Input post body whose length is 48 bytes.
(This post body is only an example.
Please input the correct one in practical
test.)
OK
+QHTTPPOST: 0,200,285 //If the HTTPS response header contains "CONTENT-LENGTH"
information, then the <content_length> information will be
reported.
AT+QHTTPREAD=80 //Read HTTPS response body and output it via UART. The
maximum time to wait for HTTPS session to be closed is 80s.
CONNECT //Read HTTPS response body successfully.
<html>
<head>
<title>Quectel's Auto Parts - Order Results</title>
</head>
<body>
<h1>Quectel's Auto Parts</h1>
<h2>Order Results</h2>
<p>Order processed at 02:49, 27th December</p><p>Your order is as follows: </p>1111
message<br />2222 apple<br />3333 orange<br /></body>
</html>
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 28 / 36
OK
+QHTTPREAD: 0 //HTTPS response body is outputted successfully.
3.2.2.2. Post Body Obtained from File System
The following examples show how to send HTTPS POST request and retrieve post body from file system,
as well as how to store HTTPS POST response to file system.
AT+QHTTPCFG="contextid",1 //Configure the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,"UNINET","" ,"" ,1 //Configure PDP context 1. APN is "UNINET" for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPCFG="sslctxid",1 //Set SSL context ID.
OK
AT+QSSLCFG="sslversion",1,1 //Set SSL version as 1 which means TLsV1.0.
OK
AT+QSSLCFG="ciphersuite",1,0x0005 //Set SSL cipher suite as 0x0005 which means RC4-SHA.
OK
AT+QSSLCFG="seclevel",1,2 //Set SSL verify level as 2 which means CA certificate, client
certificate and client private key should be uploaded by
AT+QFUPL command.
OK
AT+QSSLCFG="cacert",1,"RAM:cacert.pem"
OK
AT+QSSLCFG="clientcert",1,"RAM:clientcert.pem"
OK
AT+QSSLCFG="clientkey",1,"RAM:clientkey.pem"
OK
AT+QHTTPURL=45,80 //Set the URL which will be accessed.
CONNECT
https:// 220.180.239.212:8011/processorder.php //Input URL whose length is 45 bytes. (This URL is
only an example. Please input the correct URL in
practical test.)
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 29 / 36
OK
//POST request information from RAM file, and read HTTPS response information and store it to RAM file.
AT+QHTTPPOSTFILE="RAM:5.txt",80 //Send HTTPS POST request. POST body is obtained from
"RAM:5.txt", and the maximum response time is 80s.
OK
+QHTTPPOSTFILE: 0,200,177 //After HTTPS POST request is sent successfully,
AT+QHTTPREAD command can be executed.
AT+QHTTPREADFILE="RAM:6.txt",80 //Read HTTPS response body and store it to "RAM:6.txt".
The maximum time to wait for HTTPS session to be closed is
80s.
OK
+QHTTPREADFILE: 0 //HTTPS response body is stored successfully.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 30 / 36
4 Error Handling
4.1. Executing HTTP(S) AT Commands Fails
When executing HTTP(S) AT commands, if "ERROR" response is received from the module, please
check whether the (U)SIM card is inserted and whether it is "+CPIN: READY" returned when executing
AT+CPIN?.
4.2. PDP Activation Fails
If it is failed to active a PDP context by AT+QIACT command, please check the following configurations:
1. Query whether the PS domain is attached or not by AT+CGATT? command. If not, please execute
AT+CGATT=1 command to attach the PS domain.
2. Query the PS domain status by AT+CGREG? command and make sure the PS domain has been
registered.
3. Query the PDP context parameters by AT+QICSGP command and make sure the APN of specified
PDP context has been set.
4. Make sure the specified PDP context ID is neither used by PPP nor activated by AT+CGACT
command.
5 According to 3GPP specifications, the module only supports three PDP contexts activated
simultaneously, so customers must make sure the number of activated PDP contexts is less than 3.
If all above configurations are correct, but activating the PDP context by AT+QIACT command still fails,
please reboot the module to resolve this issue. After rebooting the module, please check the
configurations mentioned above for at least three times and each time at an interval of 10 minutes to
avoid frequently rebooting the module.
4.3. DNS Parse Fails
When executing AT+QHTTPGET, AT+QHTTPPOST and AT+QHTTPPOSTFILE commands, if "+CME
ERROR: 714" (714: HTTP(S) DNS error) is returned, please check the following aspects:
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 31 / 36
1. Make sure the domain name of HTTP(S) server is valid.
2. Query the status of the PDP context by AT+QIACT? command to make sure the specified PDP
context has been activated successfully.
3. Query the address of DNS server by AT+QIDNSCFG command to make sure the address of DNS
server is not "0.0.0.0".
If the DNS server address is "0.0.0.0", there are two solutions:
1. Reassign a valid DNS server address by AT+QIDNSCFG command.
2. Deactivate the PDP context by AT+QIDEACT command, and re-activate the PDP context via
AT+QIACT command.
4.4. Entering Data Mode Fails
When executing AT+QHTTPURL, AT+QHTTPGET, AT+QHTTPPOST and AT+QHTTPREAD commands,
if "+CME ERROR: 704" (704: HTTP(S) UART busy) is returned, please check whether there are other
ports in data mode, since the module only supports one port in data mode at a time. If any, please
re-execute these commands after other ports have exited from data mode.
4.5. Sending GET/POST Requests Fails
When executing AT+QHTTPGET, AT+QHTTPPOST and AT+QHTTPPOSTFILE commands, if a failed
result is received, please check the following configurations:
1. Make sure the URL inputted via AT+HTTPURL command is valid and can be accessed.
2. Make sure the specified server supports GET/POST commands.
3. Make sure the PDP context has been activated successfully.
If all above configurations are correct, but sending GET/POST requests by AT+QHTTPGET,
AT+QHTTPPOST and AT+QHTTPPOSTFILE commands still fails, please deactivate the PDP context by
AT+QIDEACT and re-activate the PDP context by AT+QIACT to resolve this issue. If activating the PDP
context fails, please refer to Chapter 4.2 to resolve it.
4.6. Reading Response Fails
Before reading response by AT+QHTTPREAD and AT+QHTTPREADFILE commands, customers should
execute AT+QHTTPGET, AT+QHTTPPOST and AT+QHTTPPOSTFILE commands and the following
URC information will be reported:
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 32 / 36
"+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]"/
"+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]"/
"+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]"
During executing AT+QHTTTPREAD and AT+QHTTPREADFILE commands, if customers encounter
some errors, such as: "+CME ERROR: 717" (717: HTTP(S) socket read error), please resend HTTP(S)
GET/POST requests to HTTP(S) server by AT+QHTTPGET, AT+QHTTPPOST and
AT+QHTTPPOSTFILE commands. If sending GET/POST requests to HTTP(S) server fails, please refer
to Chapter 4.5 to resolve it.
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 33 / 36
5 Summary of ERROR Codes
The error code <err> indicates an error related to mobile equipment or network. The details about <err>
are described in the following table.
Table 1: Summary of Error Codes
<err>
Meaning
0
Operation successful
701
HTTP(S) unknown error
702
HTTP(S) timeout
703
HTTP(S) busy
704
HTTP(S) UART busy
705
HTTP(S) no GET/POST requests
706
HTTP(S) network busy
707
HTTP(S) network open failed
708
HTTP(S) network no configuration
709
HTTP(S) network deactivated
710
HTTP(S) network error
711
HTTP(S) URL error
712
HTTP(S) empty URL
713
HTTP(S) IP address error
714
HTTP(S) DNS error
715
HTTP(S) socket create error
716
HTTP(S) socket connect error
717
HTTP(S) socket read error
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 34 / 36
718
HTTP(S) socket write error
719
HTTP(S) socket closed
720
HTTP(S) data encode error
721
HTTP(S) data decode error
722
HTTP(S) read timeout
723
HTTP(S) response failed
724
Incoming call busy
725
Voice call busy
726
Input timeout
727
Wait data timeout
728
Wait HTTP(S) response timeout
729
Memory allocation failed
730
Invalid parameter
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 35 / 36
6 Summary of HTTP(S) Response Codes
<httprspcode> indicates the response codes from HTTP(S) server. The details about <httprspcode> are
described in the following table.
Table 2: Summary of HTTP(S) Response Codes
<httprspcode>
Meaning
200
OK
403
Forbidden
404
Not found
409
Conflict
411
Length required
500
Internal server error
LTE Module Series
EC2x&EG9x&EM05 HTTP(S) AT Commands Manual
EC2x&EG9x&EM05_HTTP(S)_AT_Commands_Manual 36 / 36
7 Appendix A References
Table 3: Related Documents
Table 4: Terms and Abbreviations
SN
Document Name
Remark
[1]
RFC2616
Hyper Text Transport Protocol
[2]
Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_
Manual
Introduction about EC2x&EG9x&EM05
TCP/IP AT commands
[3]
Quectel_EC2x&EG9x&EM05_FILE_Application_Note
EC2x&EG9x&EM05 FILE application
note
[4]
Quectel_EC25&EC21_AT_Commands_Manual
EC25&EC21 AT commands manual
[5]
Quectel_EG9x_AT_Commands_Manual
EG9x AT commands manual
[6]
Quectel_EM05_AT_Commands_Manual
EM05 AT commands manual
[7]
Quectel_EC2x&EG9x&EM05_SSL_AT_Commands_
Manual
Introduction about EC2x&EG9x&EM05
SSL AT commands
Abbreviation
Description
DNS
Domain Name Server
DTR
Data Terminal Ready
HTTP(S)
Hyper Text Transport Protocol (Secure)
PPP
Point-to-Point Protocol
SSL
Security Socket Layer
URI
Uniform Resource Identifier
URL
Uniform Resource Locator
