Quectel GSM AT Commands Manual V1.3

GSM

Quectel Cellular Engine

HTTP Service

AT Commands

GSM_HTTP_ATC_V1.3

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 1 -

Document Title

HTTP Service AT Commands

Version

1.3

Date

2015-12-29

Status

Release

Document Control ID

GSM_HTTP_ATC_V1.3

General Notes

Quectel offers this information as a service to its customers, to support application and

engineering efforts that use the products designed by Quectel. The information provided is

based upon requirements specifically provided to Quectel by the customers. Quectel has not

undertaken any independent search for additional relevant information, including any

information that may be in the customer’s possession. Furthermore, system validation of this

product designed by Quectel within a larger electronic system remains the responsibility of

the customer or the customer’s system integrator. All specifications supplied herein are

subject to change.

Copyright

This document contains proprietary technical information which is the property of Quectel

Limited., copying of this document and giving it to others and the using or communication of

the contents thereof, are forbidden without express authority. Offenders are liable to the

a utility model or design. All specification supplied herein are subject to change without

notice at any time.

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 2 -

Contents

Contents ............................................................................................................................................ 2

0. Revision History ........................................................................................................................... 3

1. Introduction ................................................................................................................................... 4

1.1. Reference ........................................................................................................................... 4

2. AT Commands for HTTP Service ................................................................................................. 5

2.1. Overview of AT Commands for HTTP Service ................................................................. 5

2.2. Detailed Description of AT Commands for HTTP Service ............................................... 5

2.2.1. AT+QHTTPURL Set HTTP Server URL ....................................................... 5

2.2.2. AT+QHTTPGET Send HTTP GET Request .................................................. 6

2.2.3. AT+QHTTPREAD Read HTTP Server Response ......................................... 6

2.2.4. AT+QHTTPPOST Send HTTP POST Request .............................................. 7

2.2.5. AT+QHTTPDL Download file from HTTP server......................................... 8

3. Supported Unsolicited Result Codes ............................................................................................. 9

3.1. Summary of CME ERROR Codes ..................................................................................... 9

4. Examples ..................................................................................................................................... 11

4.1. Send HTTP GET Request ................................................................................................ 11

4.2. Send HTTP POST Request .............................................................................................. 12

4.3. Download File from HTTP Server ................................................................................... 13

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 3 -

0. Revision History

Revision

Date

Author

Description of change

1.0

2009-07-06

Jay XIN

Initial

1.1

2012-06-04

Will SHAO

Added Command AT+QHTTPDL

1.2

2015-04-13

Will SHAO

Added applicable modules

1.3

2015-12-29

Jelly WANG

Modified the problem that some AT commands

are displayed incompletely.

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 4 -

1. Introduction

Quectel Module has an internal TCP/IP stack that is driven by AT commands and enables the host

application to easily access the Internet service. It includes TCP service, UDP service, FTP service

and HTTP service, etc. This document is a reference guide to all the AT commands and responses

defined for HTTP Service. The advantage of this solution is that it eliminates the need for the

application manufacturer to implement own HTTP protocol, thus minimizing cost and time to

integrate Internet connectivity into a new or existing host application.

This document is applicable to all Quectel GSM modules.

1.1. Reference

Table 1: Reference

SN

Document name

Remark

[1]

GSM_TCPIP_AN.pdf

TCPIP Application Notes

[2]

RFC 2616

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 5 -

2. AT Commands for HTTP Service

2.1. Overview of AT Commands for HTTP Service

Command

Description

AT+QHTTPURL

Set HTTP Server URL

AT+QHTTPGET

Send HTTP GET Request

AT+QHTTPREAD

Read HTTP Server Response

AT+QHTTPPOST

Send HTTP POST Request

AT+QHTTPDL

Download file from http server

Execution of above HTTP related AT commands will switch to data mode. To switch back to AT

mode, you can input “+++” and this will terminate the current HTTP AT command. The interval

time between the first “+” and the character before the first “+” MUST NOT be less than 500 ms

and the interval time between the last “+” and the character next to the last “+” MUST NOT be

less than 500 ms and the interval time between each “+” MUST be less than 1000 ms.

2.2. Detailed Description of AT Commands for HTTP Service

2.2.1. AT+QHTTPURL Set HTTP Server URL

AT+QHTTPURL Set HTTP Server URL

Test Command

AT+QHTTPURL=?

Response

+QHTTPURL: (1-450),(1-65535)

OK

Parameter

See Write Command

Write Command

AT+QHTTPURL=<url_le

n>,<input_time>

Response

CONNECT

If error is related to ME functionality:

ERROR

+CME ERROR: <err>

Parameter

<url_len> The length in bytes of the URL.

<input_time> Maximum time in seconds to input URL.

Reference

If sending HTTP GET Request, for example, input URL path:

http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo?

Message=helloquectel

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 6 -

If sending HTTP POST Request, for example, input URL path:

http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo

Server address must be provided as IP address in standard

dot-format (e.g. “192.168.1.1”) or as server address names

resolvable by a DNS server (e.g. “api.efxnow.xom”).

2.2.2. AT+QHTTPGET Send HTTP GET Request

AT+QHTTPGET Send HTTP GET Request

Test Command

AT+QHTTPGET=?

Response

+QHTTPGET: (1-65535)

OK

Parameter

See Write Command

Write Command

AT+QHTTPGET=<to_rea

d_time>

Response

OK

If error is related to ME functionality:

ERROR

+CME ERROR: <err>

Parameter

<to_read_time> Time in seconds. AT+QHTTPREAD will be

invalid if the idle time after AT+QHTTPGET is

longer than the time of <to_read_time>.

Reference

2.2.3. AT+QHTTPREAD Read HTTP Server Response

AT+QHTTPREAD Read HTTP Server Response

Test Command

AT+QHTTPREAD=?

Response

+QHTTPREAD: (1-65535)

OK

Parameter

See Write Command

Write Command

AT+QHTTPREAD=<wait

_time>

Response

CONNECT

<data>

OK

If error is related to ME functionality:

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 7 -

ERROR

+CME ERROR: <err>

Parameter

<wait_time> Time in seconds. It will close http session when

timeout.

<data> The data of HTTP server responds.

Reference

2.2.4. AT+QHTTPPOST Send HTTP POST Request

AT+QHTTPPOST Send HTTP POST Request

Test Command

AT+QHTTPPOST=?

Response

+QHTTPPOST: (1-29696),(1-65535),(1-65535)

OK

Parameter

See Write Command

Write Command

AT+QHTTPPOST=<body_s

ize>,<input_time>,<to_read

_time>

Response

CONNECT

<body_data>

OK

If error is related to ME functionality:

ERROR

+CME ERROR: <err>

Parameter

<body_size> Size in bytes of the body data to POST.

<input_time> Maximum time in seconds to input the body

data.

<to_read_time> Time in seconds. AT+QHTTPREAD will be

invalid if the idle time after

AT+QHTTPGET is longer than the time of

<to_read_time>

<body_data> Input the body data to POST from UART.

Reference

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 8 -

2.2.5. AT+QHTTPDL Download file from HTTP server

AT+QHTTPDL Download file from HTTP server

Test Command

AT+QHTTPDL=?

Response

+QHTTPDL:"filename"[,<length>[,(1-65535)]]

OK

Parameter

See Write Command

Write Command

AT+QHTTPDL=

“<filename>”[,<length>

[,< wait_time>]]

Response

OK

Finally, if download the file successfully, response

+ QHTTPDL:<dl size>,<content-length>,<errcode>

If error is related to ME functionality:

ERROR

+CME ERROR: <err>

Parameter

<filename> The path of the file to be stored, such as

“RAM:1.txt”

<length> The maximum size of the file to be

download. Default is 10240. Unit: byte. It is

only used for RAM file.

<wait_time> Time in seconds. It will close HTTP

session when timeout.

<dl size> The length of data has been download

<content-length> The content length. If the content-length is

unknown, then set it to -1.

<errcode> If all data has been downloaded, the

<errcode> is 0, else it is a numeric to

indicate the type of error, please refer to the

chapter 3.

<err> A numeric to indicate the type of error,

please refer to the chapter 3.

Reference

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 9 -

3. Supported Unsolicited Result Codes

3.1. Summary of CME ERROR Codes

Final result code +CME ERROR: <err> indicates an error related to mobile equipment or network.

The operation is similar to ERROR result code. None of the following commands in the same

Command line is executed. Neither ERROR nor OK result code shall be returned. The following

<err> is just the new <err> code for HTTP. About other <err> codes, please refer to [1].

<err> values used by common messaging commands:

Code of <err>

Meaning

3801

HTTP time out

3802

HTTP busy

3803

HTTP UART busy

3804

HTTP get no request

3805

HTTP network busy

3806

HTTP network open failed

3807

HTTP network no config

3808

HTTP network deactive

3809

HTTP network error

3810

HTTP url error

3811

HTTP empty url

3812

HTTP ip addr error

3813

HTTP DNS error

3814

HTTP socket create error

3815

HTTP socket connect error

3816

HTTP socket read error

3817

HTTP socket write error

3818

HTTP socket close

3819

HTTP data encode error

3820

HTTP data decode error

3821

HTTP to read timeout

3822

HTTP response failed

3823

incoming call busy

3824

voice call busy

3825

input timeout

3826

wait data timeout

3827

wait http response timeout

3828

alloc memory fail

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 10 -

3829

HTTP need relocation

4000

Exceed max length

4001

Open file fail

4002

Write file fail

4003

Get size fail

4004

Read fail

4005

List file fail

4006

Delete file fail

4007

Get Disk info fail

4008

No space

4009

Time out

4010

File not found

4011

File too large

4012

File already exist

4013

Invalid parameter

4014

Driver error

4015

Create fail

4016

Access denied

4017

File too large

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 11 -

4. Examples

4.1. Send HTTP GET Request

AT+QIFGCNT=0

OK

AT+QICSGP=1,"CMNET" //Set APN

OK

AT+QIREGAPP //Optional

OK

AT+QIACT //Optional

OK

AT+QHTTPURL=79,30 //Set the URL

CONNECT

….

//for example, input 79 bytes:

http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo?Message=helloquectel

OK

AT+QHTTPGET=60 //Send HTTP GET Request

OK

AT+QHTTPREAD=30 //Read the response of HTTP server.

CONNECT

…. //Output the response data of HTTP server to UART.

//for example, UART outputs:

<?xml version="1.0" encoding="utf-8"?>

<string xmlns="https://api.efxnow.com/webservices2.3">Message='helloquectel' ASCII:104 101

108 108 111 113 117 101 99 116 101 108 </string>

OK

AT+QIDEACT //Deactivate GPRS PDP connect.

DEACT OK

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 12 -

4.2. Send HTTP POST Request

AT+QIFGCNT=0

OK

AT+QICSGP=1,"CMNET" //Set APN

OK

AT+QIREGAPP //Optional

OK

AT+QIACT //Optional

OK

AT+QHTTPURL=58,30 //Set the URL

CONNECT

….

//for example, input 58 bytes:

http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo

OK

AT+QHTTPPOST=18,50,10

//POST the data whose size is 18 Bytes and the maximum

latency time for inputting is 50 s. It is recommended to set

the latency time as long as enough to download all the data

in the latency time.

CONNECT

//This means it is ready to receive data from UART. And DCD

has been set to low. Receive data from UART and not echo.

//for example, input 18 bytes: Message=helloworld

OK

//This means all data has been received over, and DCD is set to high.

AT+QHTTPREAD=30 //Read the response of HTTP server.

CONNECT

…. //Output the response data of HTTP server to UART

//for example, UART outputs:

<?xml version="1.0" encoding="utf-8"?>

<string xmlns="https://api.efxnow.com/webservices2.3">Message='helloworld' ASCII:104 101

108 108 111 119 111 114 108 100 </string>

Quectel

Confidential

HTTP Service AT Commands

GSM_HTTP_ATC_V1.3 - 13 -

OK

AT+QIDEACT //Deactivate GPRS PDP connect.

DEACT OK

4.3. Download File from HTTP Server

AT+QIFGCNT=0

OK

AT+QICSGP=1,"CMNET" //Set APN

OK

AT+QIREGAPP //Optional

OK

AT+QIACT //Optional

OK

AT+QHTTPURL=29,30 //Set the URL

CONNECT

….

//for example, input 29 bytes:

http://api.efxnow.com/1.TXT

OK

AT+QHTTPGET=60 //Send HTTP GET Request

OK

AT+QHTTPDL=“RAM:1.TXT”,1024 //Download the file to“RAM:1.TXT”， max size is

1024 bytes

+ QHTTPDL：100,100 ,0

OK

Quectel

Confidential

Shanghai Quectel Wireless Solutions Co., Ltd.

Office 501, Building 13, No.99, Tianzhou Road, Shanghai, China 201103

Tel: +86 21 5108 6236

Mail: info@quectel.com

Quectel GSM AT Commands Manual V1.3

Quectel_GSM__AT_Commands_Manual_V1.3

Navigation menu

Versions of this User Manual:

Views

Navigation
