Realtek PON Diagshell User Guide RTK Diag Shell V0.0.1
User Manual: Pdf
Open the PDF directly: View PDF
.
Page Count: 529 [warning: Documents this large are best viewed by clicking the View PDF Link!]
- Chapter 1 Introduction
- Chapter 2 Commands
- VLAN commands
- SVLAN commands
- QoS commands
- l2-table commands
- trap commands
- rma commands
- igmp commands
- Storm Control commands
- stp commands
- Mirror commands
- meter commands
- bandwidth commands
- mib commands
- ACL commands
- PON Mac commands
- Classfication commands
- GPON commands
- Switch commands
- Dot1x commands
- Trunk commands
- Auto Fallback commands
- OAM commands
- Loop commands
Realtek
CONFIDENTIAL
for Loso Technology, Inc
SDK Diag Shell
RTL8690x
User Guide
(CONFIDENTIAL: Development Partners Only)
Rev. 0.0.1
30 Nov 2012
Realtek Semiconductor Corp.
No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan
Tel.: +886-3-578-0211 Fax: +886-3-577-6047
www.realtek.com
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
COPYRIGHT
©2009-2010 Realtek Semiconductor Corp. All rights reserved. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in
any form or by any means without the written permission of Realtek Semiconductor Corp.
TRADEMARKS
Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this
document are trademarks/registered trademarks of their respective owners.
DISCLAIMER
Realtek provides this document “as is”, without warranty of any kind, neither expressed nor implied,
including, but not limited to, the particular purpose. Realtek may make improvements and/or changes
in this document or in the product described in this document at any time. This document could
include technical inaccuracies or typographical errors.
USING THIS DOCUMENT
This document is intended for use by the system engineer when integrating with Realtek Switch
Software SDK. Though every effort has been made to assure that this document is current and
accurate, more information may have become available subsequent to the production of this guide. In
that event, please contact your Realtek representative for additional information that may help in the
development process.
REVISION HISTORY
Revision Release Date Summary
0.0.1 201211-30 Initial version for 8690x chip
SFU Product Page 2 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Table of Contents
Chapter 1 Introduction 16
Chapter 2
te
table
-frame-type
de
vid
t
e
ent
vid
vlan
1.1 Conventions 16
1.2 Argument Types 16
1.3 Command Help 17
Commands 18
2.1. VLAN commands 18
vlan init 18
vlan crea 19
vlan destroy 20
vlan set vlan- 21
vlan get vlan-table 23
vlan set entry 24
vlan get entry 26
vlan set accept 27
vlan get accept-frame-type 28
vlan set egress 29
vlan get egress 30
vlan set tag-mo 33
vlan get tag-mode 34
vlan set vlan-treat 35
vlan get vlan- reat vid 36
vlan set cfi-ke p 37
vlan get cfi-keep 38
vlan set transpar 39
vlan get transparent 40
vlan set ingress-filter 41
vlan get ingress-filter 42
vlan set state 43
vlan get state 44
vlan set pvid 45
vlan get pvid 46
vlan set ext-p 47
vlan get ext-pvid 48
vlan set protocol- 49
SFU Product Page 3 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get protocol-vlan 50
format
2.2. 5
te
table
rt
ity-source
iority
te
n
vlan set port-based-fid 51
vlan get port-based-fid 52
vlan set port-based-pri 53
vlan get port-based-pri 54
vlan set leaky 55
vlan get leaky 56
vlan set keep- 57
vlan get kee-format 58
SVLAN commands 9
svlan init 59
svlan crea 60
svlan destroy 61
svlan set entry 62
svlan get entry 64
svlan set svlan- 65
svlan get svlan-table 67
svlan set port svid 68
svlan get port svid 69
svlan set service-po 70
svlan get service-port 71
svlan set lookup-type 72
svlan get lookup-type 73
svlan set tpid 74
svlan get tpid 75
svlan set prior 76
svlan get priority-source 77
svlan set unmatch 78
svlan get unmatch 79
svlan set untag 80
svlan get untag 81
svlan set trap-pr 82
svlan get trap-priority 83
svlan set dei-keep sta 84
svlan get dei-keep state 85
svlan set vlan-aggregatio 86
svlan get vlan-aggregation 87
svlan add vlan-conversion 88
svlan del vlan-conversion 90
SFU Product Page 4 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get vlan-conversion 91
svlan set vlan-conversion 93
sp2c unmatch-action
2.3. 9
priority-to-queue
1
ctor
ithm
ight
2.4. 1
aging-time
t
g
ed
ilter
t
t ip
dip
svlan get vlan-conversion sp2c unmatch-action 94
QoS commands 5
qos init 95
qos set 96
qos get priority-to-queue 98
qos set remapping 99
qos get remapping 02
qos set priority-sele 104
qos get priority-selector 105
qos get remarking dot1p 108
qos set remarking dscp 109
qos get remarking dscp 111
qos set scheduling algor 112
qos get scheduling algorithm 113
qos set scheduling queue-we 114
qos get scheduling queue-weight 115
qos set avb remapping 116
qos get avb remapping 118
l2-table commands 19
l2-table init 119
l2-table set 120
l2- able get aging-time 121
l2-table set limit-learnin 122
l2-table get limit-learning 124
l2-table get learning-exce 125
l2-table set src-port-egress-f 126
l2-table get src-port-egress-filter 127
l2-table clear learning-exceed 128
l2-table set aging-out 129
l2- able get aging-out 130
l2- able add ip-mcast d 131
l2-table get ip-mcast dip 133
l2-table del ip-mcast dip 134
l2-table add ip-mcast sip 135
l2-table get ip-mcast sip dip 137
l2-table del ip-mcast sip dip 138
l2-table add ip-mcast vid dip 139
SFU Product Page 5 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get ip-mcast vid dip 141
l2-table del ip-mcast vid dip 142
l2-table add mac-mcast filter 143
-id
-
-
c
t
-
c er-id
-
- ed-filter-id
t y
xt-entry
flush
t
tion
t
t
t
t
t orts
ap-priority
ding
2.5. 1
l2-table get mac-mcast filter-id 144
l2-table del mac mcast filter-id 145
l2-table get mac-mcast vid 147
l2-table del mac mcast vid 148
l2-table add ma -ucast vid 149
l2- able get mac-ucast vid 151
l2-table del mac ucast vid 152
l2-table add ma -ucast filt 153
l2-table get mac-ucast filter-id 155
l2-table del mac ucast filter-id 156
l2-table set mac ucast enhanc 157
l2- able get entr 158
l2-table del all 159
l2-table get ne 160
l2-table set link-down- 161
l2-table get link-down-flush 162
l2-table set flush mac-ucast 163
l2- able get learning-count 164
l2-table set ip-mcast-mode 165
l2-table get ip-mcast-mode 166
l2-table set lookup-miss ac 167
l2-table get lookup-miss action 169
l2- able set ip-mcast-data action 170
l2- able get ip-mcast-data action 171
l2- able set port-move action 172
l2-table get port-move action 173
l2-table set unknown-sa action 174
l2- able get unknown-sa action 175
l2- able set lookup-miss flood-p 176
l2-table get lookup-miss flood-ports 177
l2-table set lookup-miss multicast tr 178
l2-table get lookup-miss multicast trap-priority 179
l2-table set lookup-miss multicast reserved-floo 180
l2-table get lookup-miss reserved-flooding 181
trap commands 82
trap init 182
SFU Product Page 6 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trap set 183
cdp
2.6. 1
2.7. 1
ld checksum-error
2.8. 2
-multicast
orm
trap get cdp 184
trap set csstp 185
trap get csstp 186
rma commands 87
rma set action 187
rma get action 188
rma set priority 189
rma get priority 190
rma dump 191
igmp commands 92
igmp set action 192
igmp get action 193
igmp set igmp-m 194
igmp get igmp-mld checksum-error 195
igmp set igmp-mld isolation-leaky 196
igmp get igmp-mld isolation-leaky 197
igmp set igmp-mld vlan-leaky 198
igmp get igmp-mld vlan-leaky 199
igmp set ip-mcast-lookup-mode 200
igmp get ip-mcast-lookup-mode 201
igmp set ip-mcast-table 202
igmp get ip-mcast-table 203
Storm Control commands 04
storm-control set broadcast state 204
storm-control set boradcast 205
storm-control get boradcast 206
storm-control set multicast 207
storm-control get multicast 208
storm-control set unknown 209
storm-control get unknown-multicast 210
storm-control set unknown-unicast 211
storm-control get unknown-unicast 212
storm-control set arp-storm 213
storm-control get arp-storm 214
storm-control set dhcp-storm 215
storm-control get dhcp-storm 216
storm-control set igmp-mld-st 217
storm-control get igmp-mld-storm 218
SFU Product Page 7 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set bypass-packet 219
storm-control get bypass-packet 220
2.9. 2
state
2.10. 2
mirroring
ess-mode
2.11. 2
entry
-exceed
d
2.12. 2
egress ifg
t
ass-packet
2.13. 2
mp counter
stp commands 21
stp init 221
stp set 222
stp get state 223
Mirror commands 24
mirror init 224
mirror set 225
mirror dump 226
mirror set egr 227
mirror get egress-mode 228
meter commands 29
meter init 229
meter set 230
meter get entry 231
meter get meter 232
meter reset meter-excee 233
meter set tick-token 234
meter get tick-token 235
meter set pon-tick-token 236
meter get pon-tick-token 237
bandwidth commands 38
bandwidth init 238
bandwidth set 239
bandwidth get egress ifg 240
bandwidth set egress por 241
bandwidth get egress port 243
bandwidth set ingress port 244
bandwidth get ingress port 245
bandwidth set ingress ifg 246
bandwidth get ingress ifg 247
bandwidth set ingress byp 248
bandwidth get ingress bypass-packet 249
bandwidth set ingress flow-control 250
bandwidth get ingress flow-control 251
mib commands 52
mib init 252
mib du 253
SFU Product Page 8 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib reset counter 256
mib dump statistic 257
ode
-reason
l
2.14. 2
entry
le
le
n
n
ate
ort
mib reset statistic 258
mib set statistic m 259
mib get statistic mode 260
mib set statistic type 261
mib get statistic type 262
mib get packet-debug 263
mib set sync-mode 264
mib get sync-mode 265
mib set reset-value 266
mib get reset-value 267
mib set ctag- ength 268
mib get ctag-length 269
mib set count-mode 270
mib get count-mode 271
ACL commands 72
acl init 272
acl add 273
acl del entry 274
acl get entry 276
acl show 278
acl clear 280
acl set ru 281
acl show ru 284
acl clear actio 285
acl set action 287
acl show actio 290
acl show templ 291
acl clear template 292
acl set template 293
acl add template 295
acl get template 297
acl del template 298
acl set range-vid 299
acl get range-vid 300
acl set range-ip 301
acl get range-ip 303
acl set range-l4p 304
SFU Product Page 9 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get range-l4port 305
acl set range-length 306
acl get range-length 307
t
et
f
2.15. PON Mac commands 3
t-cont
l
2.16. 3
r
le
stream-action
unmatch-act
acl get reason 308
acl set mode 309
acl get mode 310
acl set state 311
acl get state 312
acl set permi 313
acl get permit 314
field-selector s 315
ield-selector get 316
17
pon init 317
pon set 318
pon get t-cont 320
pon add t-cont 322
pon del t-cont 323
pon set l id 324
pon get llid 326
pon add llid 328
pon del llid 329
pon clear 330
pon reset 331
Classfication commands 32
classf init 332
classf clea 333
classf show 334
classf set ru 335
classf set down 338
classf set upstream-action 341
classf add entry 344
classf get entry 346
classf del entry 347
classf set operation 348
classf get operation 349
classf set cf-sel-port 350
classf get cf-sel-port 351
classf set upstream- 352
SFU Product Page 10 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get upstream-unmatch-act 353
classf set permit-sel-range 354
classf get permit-sel-range 355
classf set remarking dscp 356
classf get remarking dscp 357
ort
-prior
2.17. 3
itial
l-number
te
te
us
m
i
meters
classf set range-ip 358
classf get range-ip 359
classf set range-l4p 360
classf get range-l4port 361
classf set us-1p-remark 362
classf get us-1p-remark-prior 363
GPON commands 64
gpon init 364
gpon dein 365
gpon set seria 366
gpon get serial-number 367
gpon set password 368
gpon get password 369
gpon activate 370
gpon deactiva 371
gpon get onu-sta 372
gpon get alarm-stat 373
gpon set active-timer 374
gpon get active-timer 375
gpon set ds-laser 376
gpon set ds-phy 377
gpon set ds-ploa 378
gpon set ds-bwmap 379
gpon set ds-gem 380
gpon set ds-eth 381
gpon set ds-omc 382
gpon get ds parameters 383
gpon set us-laser 385
gpon set us-phy 386
gpon set us-ploam 387
gpon set us-dbr 388
gpon get us para 389
gpon add tcont alloc-id 390
gpon del tcont alloc-id 391
SFU Product Page 11 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get tcont alloc-id 392
flow-id
ow-id
filter-entry
fi -
f
s t ry
lt
f
unter global
tcont
2.18. 4
48-pass-1
sation
gpon show tcont 393
gpon add ds-flow 394
gpon del ds-flow flow-id 395
gpon get ds-flow flow-id 396
gpon show ds-flow 397
gpon add us-flow fl 398
gpon del us-flow flow-id 399
gpon get us-flow flow-id 400
gpon show us-flow 401
gpon add multicast- 402
gpon del multicast- lter entry 403
gpon get multicast- ilter-entry 404
gpon show multica t-fil er-ent 405
gpon set multicast-fi er 406
gpon get multicast- ilter 408
gpon set tx 409
gpon get tx 410
gpon show co 411
gpon show counter tcont 413
gpon show counter flow 414
gpon omci_tx 415
gpon set auto- 416
gpon get auto-tcont 417
gpon set auto-boh 418
gpon get auto-boh 419
gpon set eqd-offset 420
gpon get eqd-offset 421
gpon set debug 422
Switch commands 23
switch init 423
switch set 424
switch get 48-pass-1 425
switch set ipg-compen 426
switch get ipg-compensation 427
switch set bypass-tx-crc 428
switch get bypass-tx-crc 429
switch set rx-check-crc 430
switch get rx-check-crc 431
SFU Product Page 12 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set mac-address 432
-
g
op
re
2.19. 4
port-based
et
2.20. 4
distribute-algorithm
ng
switch get mac-address 433
switch set max pkt-len 434
switch get max-pkt-len 435
switch set limit-pause 436
switch get limit-pause 437
switch set small-ipg-ta 438
switch get small-ipg-tag 439
switch set small-pkt 440
switch get small-pkt 441
switch set output-dr 442
switch get output-drop 443
switch set back-pressu 444
switch get back-pressure 445
switch reset 446
Dot1x commands 47
dot1x init 447
dot1x set 448
dot1x get port-based 449
dot1x set mac-based 450
dot1x get mac-based 451
dot1x set trap-priority 452
dot1x get trap-priority 453
dot1x set unauth-pack 454
dot1x get unauth-packet 455
dot1x set guest-vlan 456
dot1x get guest-vlan 457
Trunk commands 58
trunk init 458
trunk set 459
trunk get distribute-algorithm 460
trunk set flood-mode 461
trunk get flood-mode 462
trunk set flow-control 463
trunk get flow-control 464
trunk set hash-mappi 465
trunk get hash-mapping 466
trunk set member-port 467
trunk get member-port 468
SFU Product Page 13 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set mode 469
trunk get mode 470
-empty
2.21. 4
f
f -count
f r
f nt
f
f
f
f el
f
f
f
2.22. 4
state
lexer
y
2.23. 4
state
s
ier
yp
r
trunk get queue 471
Auto Fallback commands 72
auto-fallback set port 472
auto- allback get port 473
auto- allback set error 475
auto- allback get erro -count 476
auto- allback set monitor-cou 477
auto- allback get monitor-count 478
auto- allback set ignore-timeout 479
auto- allback get ignore-timeout 480
auto- allback set reduce-power-lev 481
auto- allback get reduce-power-level 482
auto- allback set timer 483
auto- allback get timer 484
OAM commands 85
oam init 485
oam set 486
oam get state 487
oam set multip 488
oam get multiplexer 489
oam set parser 490
oam get parser 491
oam set trap-priorit 492
oam get trap-priority 493
Loop commands 94
rldp init 494
rldp get 496
rldp get status 497
rldp clear statu 498
rldp set magic 499
rldp get magic 500
rldp get identif 501
rldp set compare-t 502
rldp get compare-typ 503
rldp set period 504
rldp get period 505
rldp set numbe 506
SFU Product Page 14 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get number 507
rldp set control-state 508
rldp get control-state 509
rldp get looped-port-id 510
- entifier
-flow-control
mands
mask
s
s
etail
il
rldp set re-generate id 511
rldp set handle 512
rldp get handle 513
rldp set mode 514
rldp get mode 515
rldp set bypass 516
rldp get bypass-flow-control 517
rlpp set trap 518
rlpp get trap 519
Interrupt com 520
interrupt init 520
interrupt set 521
interrupt get mask 522
interrupt get statu 523
interrupt clear statu 524
interrupt get status d 525
interrupt clear status deta 526
interrupt set polarity 527
interrupt get polarity 528
SFU Product Page 15 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Chapter 1 Introduction
This document provides a summary of the commands supported on the
REALTEK SDK diag shell Command Line Interface(CLI). The document
is divided into two sections. Section 1 describes the convention,
argument types, privileges and command modes, command help, and
command line editing. Section 2 gives a brief usage and description
of all commands included in the diag shell.
1.1 Conventions
The following conventions are used in the command syntax throughout
this document:
¾ Vertical bars ( | ) separate alternative, mutually exclusive
arguments.
¾ Square brackets ( [ ] ) indicate optional elements.
¾ Braces ( < > ) indicate a required choice.
¾ Braces within square brackets ( [< >] ) indicate required choices
within optional elements.
¾ Bold indicates commands and keywords.
¾ Italics indicate user variables.
1.2 Argument Types
The following argument types are recognized by the CLI and are used
in the command syntax throughout this document:
¾ MACADDR – MAC address.
Example: 00:3B:51:A9:CC:07.
¾ PORT_LIST – Port list, separated by “,” or “-”.
Example: 1-3,6,8.
¾ MASK_LIST – mask list, separated by “,” or “-”.
Example: 1-3,6,8.
¾ IPV4ADDR – IPv4 address.
Example: 192.168.1.100.
¾ IPV6ADDR – IPv6 address.
Example:101:234:689:ACD:151:03B:1A9:C07.
SFU Product Page 16 / 529 Rev. 0.01
¾ UINT – unsigned integer.
Example: 123.
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
1.3 Command Help
You may enter ? at any command mode, and the CLI will return possible
commands at that point, along with some description of the keywords:
RTK.0> vlan ?
create - create VLAN
destroy - destroy VLAN
set - Set configuration
get - get configuration
You may use the <Tab> key to do keyword auto completion:
RTK.0> vlan set p<Tab>
pvid - config port based vid
protocol-vlan – protocol
You do not need to type in the entire commands; you only need to
type in enough characters for the CLI to recognize the command as
unique.
SFU Product Page 17 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Chapter 2 Commands
2.1. VLAN commands
vlan init
Description:
This command is used to initialize & reset VLAN module. By using
this command, the following configuration will be appilied.
All VLAN will be deleted.
VLAN 1 will be created and all ports are untagged member.
The PVID of all ports are 1.
Syntax:
vlan init
Parameter:
None
Examples:
This example shows how to initialize VLAN.
RTK.0> vlan init
SFU Product Page 18 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan create
Description:
Create a new VLAN
Syntax:
vlan create vlan-table vid vid
Parameter:
vid – specify the numeric VLAN identifier
Examples:
This example shows how to create a new VLAN which ID is 100:
RTK.0> vlan create vlan-table vid 100
SFU Product Page 19 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan destroy
Description:
Destroy a VLAN
Syntax:
vlan destroy vlan-table vid vid
vlan destroy vlan-table all [restore-default-vlan]
vlan destroy vlan-table all untag
vlan destroy entry all
vlan destroy entry index
Parameter:
vid – specify the numeric VLAN identifier
vlan-table – vlan table
all - all vlan
restore-default-v
lan
– destroy all VLAN identifier except for
default VLAN
Untag - all port to untag member
index - vlan member configuration index
entry - vlan member configuration
Examples:
This example shows how to destroy VLAN 100:
RTK.0> vlan destroy vlan-table vid 100
SFU Product Page 20 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set vlan-table
Description:
This command can configure the 4k vlan entry.
Syntax:
vlan set vlan-table vid vid member <PORT_LIST: ports | all |
none>
vlan set vlan-table vid vid tag-member <PORT_LIST: ports | all
| none>
vlan set vlan-table vid vid untag-member <PORT_LIST: ports | all
| none>
vlan set vlan-table vid vid ext-member <PORT_LIST: ext | all |
none>
vlan set vlan-table vid vid fid-msti fid_msti
vlan set vlan-table vid vid hash-mode <ivl | svl>
vlan set vlan-table vid vid vlan-based-policing state <disable
| enable>
vlan set vlan-table vid vid meter meter
vlan set vlan-table vid vid vlan-based-priority state <disable
| enable>
vlan set vlan-table vid vid vlan-based-priority priority
priority
Parameter:
vid – specify the numeric VLAN identifier
ports - specified port list
all - specify all ports
none - specify no port
member - member configuration
tag-member - tagging member configuration
untag-member - untag set configuration
ext - extention member ports
fid_msti - the filter-id or msti for this vlan
ivl - specify the hash key for this vlan lookup
is using VID
svl - specify the hash key for this vlan lookup
is using MSTI/FID
disable - disable
enable - enable
SFU Product Page 21 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter - specify the meter index
priority – specify the priority value for this vlan
Examples:
This example shows how to congigurate the VLAN which ID is 100:
Add port 0,1,2 to vlan 100
Assign port 0,1 to tag member
Enable vlan based priority and set priority to 6
Enable vlan based policing and set meter index to 10
RTK.0> vlan create vlan-table vid 100
RTK.0> vlan set vlan-table vid 100
RTK.0> vlan set vlan-table vid 100 member 0-2
RTK.0> vlan set vlan-table vid 100 tag-member 0-1
RTK.0> vlan set vlan-table vid 100 vlan-based-priority state
enable
RTK.0> vlan set vlan-table vid 100 vlan-based-priority priority
6
RTK.0> vlan set vlan-table vid 100 vlan-based-policing state
enable
RTK.0> vlan set vlan-table vid 100 meter 10
SFU Product Page 22 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get vlan-table
Description:
Show VLAN table configuration of a specific vid
Syntax:
vlan get vlan-table vid vid
Parameter:
vid – specify the numeric VLAN identifier
Examples:
This example shows how to get the VLAN table configuration of
vid 100:
RTK.0> vlan get vlan-table vid 100
Vid:100
Hash Policing Meter VlanPriEn Priority FID
SVL En 10 En 6 0
member port : 0-2
tag member port : 0-1
extention member port: none
SFU Product Page 23 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set entry
Description:
This command can configure the 32 vlan member configuration.
Syntax:
vlan set entry index enhanced-vid vid
vlan set entry index member <PORT_LIST: ports | all | none>
vlan set entry index ext-member <PORT_LIST: ext | all | none>
vlan set entry index fid-msti fid_msti
vlan set entry index hash-mode <ivl | svl>
vlan set entry index vlan-based-policing state <disable |
enable>
vlan set entry index meter meter
vlan set ventry index vlan-based-priority state <disable |
enable>
vlan set entry index vlan-based-priority priority priority
Parameter:
vid – specify the numeric VLAN identifier
enhanced-vid - enhanced VLAN id
index - vlan member configuration index
ports - the vlan member or tag member ports
all - specify all ports
none - specify no port
ext - extention member ports
fid_msti - the filter-id or msti for this vlan
ivl - specify the hash key for this vlan lookup
is using VID
svl - specify the hash key for this vlan lookup
is using MSTI/FID
disable - disable
enable - enable
meter - specify the meter index for this vlan based
policing
priority – specify the priority value for this vlan
Examples:
This example shows how to congigurate VLAN member configuration
index 0 which ID is 100:
SFU Product Page 24 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Add port 0,1,2 to vlan 100
Enable vlan based priority and set priority to 6
Enable vlan based policing and set meter index to 10
RTK.0> vlan set entry 0 enhanced-vid 100
RTK.0> vlan set entry 0 member 0-2
RTK.0> vlan set entry 0 vlan-based-priority state enable
RTK.0> vlan set entry 0 vlan-based-priority priority 6
RTK.0> vlan set entry 0 vlan-based-policing state enable
RTK.0> vlan set entry 0 meter 10
SFU Product Page 25 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get entry
Description:
Show VLAN member configuration of a specific index
Syntax:
vlan get entry index
Parameter:
index - vlan member configuration index
Examples:
Show VLAN member configuration index 0:
RTK.0> vlan get entry 0
vlan id:0
Evid PlyEn MtrIdx PriEn pri Fid
100 En 10 En 6 0
member port : 0-2
extention member port: 0-5
SFU Product Page 26 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set accept-frame-type
Description:
Configure accepted frame type for ingress frame per port
Syntax:
vlan set accept-frame-type port <PORT_LIST:ports | all> <all |
tag-only | untag-only | priority-tag-and-tag>
Parameter:
ports – specify the port list for apply this
setting
all - specify all ports
all - accept all type frame
tag-only - accept tag only frame
untag-only - accept untag only frame
priority-tag-and-
tag
- accept priority tag and 1q-tag frame
Examples:
This example shows how to accept all untag frame only for port
1 to 3:
RTK.0> vlan set accept-frame-type port 1-3 untag-only
SFU Product Page 27 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get accept-frame-type
Description:
Show accepted frame type for each port
Syntax:
vlan get accept-frame-type port <PORT_LIST:ports | all>
Parameter:
ports – specify the port list for apply this
setting
all - specify all ports
Examples:
This example shows how to get accept frame types for all ports
RTK.0> vlan get accept-frame-type port 0-6
Port Accept Frame Type
0 all
1 untagged-only
2 untagged-only
3 untagged-only
4 all
5 all
6 all
SFU Product Page 28 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set egress
Description:
Show per egress port setting for VLAN mode real keep reference
by ingress port
Syntax:
vlan set egress port <PORT_LIST:egr_ports | all> keep-tag
ingress-port <PORT_LIST:igr_ports | all> state <enable | disable>
Parameter:
egr_ports – specify egress port list for apply this
setting
all – specify all ports
igr_ports – The ingress port list to apply egress-keep
setting
keep-tag - keeping tag
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to enable the egress keep for port 1 the
ingress packet is from port 2-5:
RTK.0> vlan set egress port 1 keep-tag ingress-port 2-5 state
enable
SFU Product Page 29 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get egress
Description:
Show per egress port setting for VLAN mode real keep reference
by ingress port
Syntax:
vlan get egress port <PORT_LIST:egr_ports | all> keep-tag
ingress-port <PORT_LIST:igr_ports | all> state
Parameter:
egr_ports – specify egress port list for apply this
setting
all – specify all ports
igr_ports – The ingress port list to apply egress-keep
setting
keep-tag - keeping tag
state - state configuration
Examples:
This example shows how to get the egress keep setting for port
1
RTK.0> vlan get egress port 1 keep-tag ingress-port 0-6 state
Port P0 P1 P2 P3 P4 P5 P6
1 Disable Disable Enable Enable Enable Enable Disable
SFU Product Page 30 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set ingress-filter
Description:
Configure per-port VLAN ingress check.
Syntax:
vlan set ingress-filter port <PORT_LIST:igr_ports | all> state
<enable | disable>
Parameter:
ports - specified port list
all – specify all ports
enable - enable the vlan ingress filter function
disable - disable the vlan ingress filter function
Examples:
This example shows how to enable the ingress filter for port 1
RTK.0> vlan set ingress-filter port 1 state enable
SFU Product Page 31 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get ingress-filter
Description:
Show per port ingress filter setting
Syntax:
vlan get ingress-filter port <PORT_LIST:ports | all> state
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get the ingress filter setting for port
0-6:
RTK.0> vlan get ingress-filter port 0-6 state
Port Ingress-filter
0 Enable
1 Enable
2 Enable
3 Enable
4 Enable
5 Enable
6 Enable
SFU Product Page 32 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set tag-mode
Description:
Configure egress port vlan tag mode.
Syntax:
vlan set tag-mode port <PORT_LIST: ports | all> <original |
keep-format | priority-tag>
Parameter:
ports - specified port list
all – specify all ports
original -
O
riginal mode. Output frame will follow
VLAN untag setting
keep-format - Keep format mode. Output frame will keep
VLAN original format.(If packet not
modified asic will not re-caculate CRC)
priority-tag - Priority tag mode. Output frame will be
priority tag.
Examples:
This example shows how to set egress tag mode for port 1 set to
priority tag mode. Set port 3 to keep-format mode.
RTK.0> vlan set tag-mode port 1 priority-tag
RTK.0> vlan set tag-mode port 3 keep-format
SFU Product Page 33 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get tag-mode
Description:
Get per port egress tag mode.
Syntax:
vlan get tag-mode port <PORT_LIST: ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get the egress tag mode for port 1-5
RTK.0> vlan get tag-mode port 1-5
Port Mode
1 priority-tag
2 original
3 keep-format
4 original
5 original
SFU Product Page 34 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set vlan-treat vid
Description:
Configure ingress packet with special vlan VID(0 and 4095) that
will be treat as tagging pacet or un-tagging packet.
Syntax:
vlan set vlan-treat vid <0 | 4095> type <tagging | un-tagging>
Parameter:
0 – specify the ingress packet with vid 0
4095 – specify the ingress packet with vid 4095
type - vlan treat type
tagging - packet will be treat as tagging frame
un-tagging - packet will be treat as un-tagging frame
Examples:
This example shows how to set ingress packet with vid 0 will be
treat as tagging packet and packet with vid 4095 will be treat
as un-tagging packet.
RTK.0> vlan set vlan-treat vid 0 type tagging
RTK.0> vlan set vlan-treat vid 4095 type un-tagging
SFU Product Page 35 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get vlan-treat vid
Description:
Get the setting of ingress packet with special vlan VID(0 and
4095) that will be treat as tagging pacet or un-tagging packet.
Syntax:
vlan get vlan-treat vid <0 | 4095> type
Parameter:
0 – specify the ingress packet with vid 0
4095 – specify the ingress packet with vid 4095
type - vlan treat type
Examples:
This example shows how to get ingress packet with vid 0 and 4095
will be treat as tagging packet or un-tagging packet.
RTK.0> vlan get vlan-treat vid 0
vlan 0 treat Tagging
RTK.0> vlan get vlan-treat vid 4095
vlan 4095 treat Untagging
SFU Product Page 36 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set cfi-keep
Description:
Configure egress CFI value will keep ingress packet CFI value
or set CFI to 0.
Syntax:
vlan set cfi-keep <cfi-to-0 | keep-cfi>
Parameter:
cfi-to-0 – egress packet cfi always set to 0
keep-cfi – keep ingress tag cfi value to egress tag
Examples:
This example shows how to set egress packet CFI always be 0.
RTK.0> vlan set cfi-keep cfi-to-0
SFU Product Page 37 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get cfi-keep
Description:
Get egress CFI keep mode.
Syntax:
vlan get cfi-keep
Parameter:
None
Examples:
This example shows how to get egress CFI mode.
RTK.0> vlan get cfi-keep
cfi-keep :Disable
SFU Product Page 38 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set transparent
Description:
Set vlan transparent mode. When transparent enable it will
discard the “vlan set egress-keep port” setting.
Syntax:
vlan set transparent state <enable | disable>
Parameter:
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to enable vlan transparent.
RTK.0> vlan set transparent state enable
SFU Product Page 39 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get transparent
Description:
Get vlan transparent mode.
Syntax:
vlan get transparent state
Parameter:
state - state configuration
Examples:
This example shows how to get vlan transparent state.
RTK.0> vlan get transparent state
vlan transparent state: Enable
SFU Product Page 40 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set ingress-filter
Description:
Set per port vlan ingress filter state.
Syntax:
vlan set ingress-filter port <PORT_LIST:ports | all> state
<enable | disable>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to enable vlan ingress-filter for port
1-3.
RTK.0> vlan set ingress-filter port 1-3 state enable
SFU Product Page 41 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get ingress-filter
Description:
Get per port vlan ingress filter state.
Syntax:
vlan get ingress-filter port <PORT_LIST:ports | all> state
Parameter:
ports – The port list
all – specify all ports
state - state configuration
Examples:
This example shows how to get vlan ingress-filter state for port
0-6.
RTK.0> vlan get ingress-filter port 0-6 state
Port Ingress-filter
0 Enable
1 Enable
2 Enable
3 Enable
4 Enable
5 Enable
6 Enable
SFU Product Page 42 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set state
Description:
Set system vlan filter state.
Syntax:
vlan set state <enable | disable>
Parameter:
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to get system vlan filter state.
RTK.0> vlan set state enable
SFU Product Page 43 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get state
Description:
Get system vlan filter state.
Syntax:
vlan get state
Parameter:
None
Examples:
This example shows how to get system vlan filter state.
RTK.0> vlan get state
vlan state: Enable
SFU Product Page 44 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set pvid
Description:
Set port based VID. The index is index to vlan member
configuration table.
Syntax:
vlan set pvid port <PORT_LIST:ports | all> vid
vlan set pvid port <PORT_LIST:ports | all> vlan-index index
Parameter:
ports - specified port list
all – specify all ports
index - vlan member configuration index
vlan-idex - vlan member configuration
vid – specify the numeric VLAN identifier
Examples:
This example shows how to set port 5 port-base vlan to vlan 100.
RTK.0> vlan set pvid port 5 100
SFU Product Page 45 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get pvid
Description:
Get port based VID. The index is index to vlan member
configuration table.
Syntax:
vlan get pvid port <PORT_LIST:ports | all>
vlan get pvid port <PORT_LIST:ports | all> vlan-index
Parameter:
ports - specified port list
all – specify all ports
vlan-idex - vlan member configuration
Examples:
This example shows how to get port 5 port-base vlan setting.
RTK.0> vlan get pvid port 5
Port 5 PVID: 100
SFU Product Page 46 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set ext-pvid
Description:
Set port based VID for extention ports. The index is index to
vlan member configuration table.
Syntax:
vlan set ext-pvid port <PORT_LIST:ports | all> vid
vlan set ext-pvid port <PORT_LIST:ports | all> vlan-index index
Parameter:
ports - specified port list
all – specify all ports
index - vlan member configuration index
vlan-idex - vlan member configuration
vid – specify the numeric VLAN identifier
Examples:
This example shows how to set extention port 3 port-base vlan
to vlan 100.
RTK.0> vlan set ext-pvid port 3 100
SFU Product Page 47 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get ext-pvid
Description:
Get port based VID for extention ports. The index is index to
vlan member configuration table.
Syntax:
vlan get ext-pvid port <PORT_LIST:ports | all>
vlan get ext-pvid port <PORT_LIST:ports | all> vlan-index
Parameter:
ports - specified port list
all – specify all ports
vlan-idex - vlan member configuration
Examples:
This example shows how to get extension port 3 port-base vlan
setting.
RTK.0> vlan get ext-pvid port 3
EXT Port 3 PVID: 100
SFU Product Page 48 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set protocol-vlan
Description:
Set protocol base vlan, for protocol group.
Syntax:
vlan set protocol-vlan group index frame-type <ethernet | snap
| llc-other> frame_type
vlan set protocol-vlan port <PORT_LIST:ports | all> group index
vid vid priority priority
vlan set protocol-vlan port <PORT_LIST:ports | all> group index
state <enable | disable>
Parameter:
index – index to protocol vlan group
ports - specified port list
all – specify all ports
ethernet – specify protocol of this entry is ethernet
snap – specify protocol of this entry is snap
llc-other – specify protocol of this entry is
llc-other
frame_type - frame type value (example 0x8899)
vid – specify the numeric VLAN identifier
priority - priority configuration
Examples:
This example shows how to set protocol vlan group 0 the protocol
is ehternet and the ether type of 8899.
RTK.0> vlan set protocol-vlan group 0 frame-type ethernet 0x8899
SFU Product Page 49 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get protocol-vlan
Description:
Get protocol base vlan setting.
Syntax:
vlan get protocol-vlan group index
vlan get protocol-vlan port <PORT_LIST:ports | all>
Parameter:
index – index to protocol vlan group
ports - specified port list
all – specify all ports
Examples:
This example shows how to get protocol vlan for group 0.
RTK.0> vlan get protocol-vlan group 0
Group FRAME-TYPE ETHER-TYPE
0 Ethernet 0x8899
SFU Product Page 50 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set port-based-fid
Description:
This command set per port based filter-id.
Syntax:
vlan set port-based-fid port <PORT_LIST:ports | all> filter-id
fid
vlan set port-based-fid port <PORT_LIST:ports | all> state
<enable | disable>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
fid - filter-id
Examples:
This example shows how to set port 1 filter-id to 6.
RTK.0> vlan set port-based-fid port 1 filter-id 6
RTK.0> vlan set port-based-fid port 1 state enable
SFU Product Page 51 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get port-based-fid
Description:
This command get per port based filter-id.
Syntax:
vlan get port-based-fid port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get port 1 filter-id setting.
RTK.0> vlan get port-based-fid port 1
Port FID State
1 6 Enable
SFU Product Page 52 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set port-based-pri
Description:
This command set port based priority.
Syntax:
vlan set port-based-pri port <PORT_LIST:ports | all> priority
priority
Parameter:
ports - specified port list
all – specify all ports
priority - priority configuration
Examples:
This example shows how to set port 1 priority to 6.
RTK.0> vlan set port-based-pri port 1 priority 6
SFU Product Page 53 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get port-based-pri
Description:
This command canget port based priority.
Syntax:
vlan get port-based-pri port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get port 1 priority setting.
RTK.0> vlan get port-based-pri port 1
Port 1 VLAN based priority: 6
SFU Product Page 54 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set leaky
Description:
This command set VLAN leaky function
Syntax:
vlan set leaky ip-mcast port <PORT_LIST:ports | all> state
<enable | disable>
vlan set leaky <cdp | csstp> state <enable | disable>
vlan set leaky rma rma_tail state <enable | disable>
Parameter:
ip-mcast – ip mulitcast
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
cdp – cisco Discovery Protocol
csstp – cisco Shared Spanning Tree Protocol
rma - reserved multicast address
rma_tail - tail of RMA MAC address
Examples:
This example shows how to enable CSSTP VLAN leaky function.
RTK.0> vlan set leaky csstp state enable
RTK.0>
SFU Product Page 55 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get leaky
Description:
This command get VLAN leaky function.
Syntax:
vlan get leaky ip-mcast port <PORT_LIST:ports | all> state
vlan get leaky <cdp | csstp> state
vlan get leaky rma rma_tail state
Parameter:
ip-mcast – ip mulitcast
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
cdp – Cisco Discovery Protocol
csstp – Cisco Shared Spanning Tree Protocol
rma - reserved multicast address
rma_tail - tail of RMA MAC address
Examples:
This example shows how to get CSSTP VLAN leaky function state.
RTK.0> vlan get leaky csstp state
Leaky state of Shared Spanning Tree Protocol: Enable
RTK.0>
SFU Product Page 56 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan set keep-format
Description:
This command set VLAN keep format function. If this feature is
enabled on specified type of frame, these frame will keep it VLAN
tag format regardless of VLAN untag setting.
Syntax:
vlan set keep-format <cdp | sstp> state <enable | disable>
vlan set keep-format rma rma_tail state <enable | disable>
Parameter:
state - state configuration
disable - disable configuration
enable - enable configuration
cdp – cisco Discovery Protocol
sstp – cisco Shared Spanning Tree Protocol
rma - reserved multicast address
rma_tail - tail of RMA MAC address
Examples:
This example shows how to set CDP & SSTP keep-format function
to enabled.
RTK.0> vlan set keep-format cdp state enable
RTK.0> vlan set keep-format sstp state enable
SFU Product Page 57 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
vlan get kee-format
Description:
This command get VLAN keep format function.
Syntax:
vlan get keep-format <cdp | sstp> state
vlan get keep-format rma rma_tail state
Parameter:
state - state configuration
cdp – Cisco Discovery Protocol
sstp – Cisco Shared Spanning Tree Protocol
rma - reserved multicast address
rma_tail - tail of RMA MAC address
Examples:
This example shows how to get CDP & SSTP keep-format function.
RTK.0> vlan get keep-format cdp
VLAN Keep format state of Cisco Discovery Protocol: Enable
RTK.0> vlan get keep-format sstp
VLAN Keep format state of Shared Spanning Tree Protocol: Enable
SFU Product Page 58 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.2. SVLAN commands
svlan init
Description:
This command can initial svlan module, set svlan related
configurations to default, and clear all svlan tables. Only
after executing this command, other svlan commands can be
executed and will not return FAILED.
Syntax:
svlan init
Parameter:
None
Examples:
This example shows how to initial svlan funtions and enable to
execute other related svlan commands.
RTK.0> svlan init
RTK.0> svlan get service-port
Server Ports: none
RTK.0>
SFU Product Page 59 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan create
Description:
This command can create a new svlan. After svlan is created,
svlan member and other properties can be set.
Syntax:
svlan create svlan-table svid svid
Parameter:
svid – specify the numeric SVLAN identifier
Examples:
This example shows how to create a new svlan which svid is 100.
RTK.0> svlan init
RTK.0> svlan create svlan-table svid 100
RTK.0>
SFU Product Page 60 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan destroy
Description:
This command can destroy a svlan or all created svlan.
Syntax:
svlan destroy svlan-table svid svid
svlan destroy svlan-table all
Parameter:
svid – specify the numeric SVLAN identifier
svlan-table – svlan table
all - All vlan
Examples:
This example shows how to destroy svid 100.
RTK.0> svlan create svlan-table svid 100
RTK.0> svlan destroy svlan-table svid 100
RTK.0>
SFU Product Page 61 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set entry
Description:
This command can configure the svlan properties of member
configuration entry. It is used for debug mode and will be
executed whether svlan module had been initialed or not. But only
svid of entry is created then the entry properties can be set.
Syntax:
svlan set entry index svid svid
svlan set entry index member <PORT_LIST:ports | all | none>
svlan set entry index tag-member <PORT_LIST:ports | all | none>
svlan set entry index untag-member <PORT_LIST:ports | all |
none>
svlan set entry index priority priority
svlan set entry index fid-msti state <disable | enable>
svlan set entry index fid-msti fid_msti
svlan set entry index enhanced-fid state <disable | enable>
svlan set entry index enhanced-fid efid
Parameter:
index – index of svlan member configuration
svid - specify the numeric sVLAN identifier
member - member configuration
tag-member - tagging member configuration
untag-member - untag set configuration
ports - the vlan member or tag member ports
all - specify all ports
none - specify no port
priority - specify the priority value
fid_msti - the filter-id or msti for this vlan
efid - specify the enhanced filter-id
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to congigurate the svlan which svid is
1000:
Add port 0,1,2,3,4,5,6 to vlan 1000
SFU Product Page 62 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Assign port 3 to tag member
Set svlan priority to 7
Enable svlan based fid and efid to fid 0 and efid 7
RTK.0> svlan destroy svlan-table all
RTK.0> svlan create svlan-table svid 1000
RTK.0> svlan set entry 0 member 0-6
RTK.0> svlan set entry 0 tag-member 3
RTK.0> svlan set entry 0 priority 7
RTK.0> svlan set entry 0 fid-msti state enable
RTK.0> svlan set entry 0 fid-msti 0
RTK.0> svlan set entry 0 enhanced-fid state enable
RTK.0> svlan set entry 0 enhanced-fid 7
RTK.0> svlan get entry 0
Index SVID Member TagSet Spri FidEn FID EfidEn Efid
0 1000 0-6 3 7 Enable 0 Enable 7
SFU Product Page 63 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get entry
Description:
Show svlan configuration of a specific entry.
Syntax:
svlan get entry index
svlan get entry all
Parameter:
index – index of svlan member configuration
all - All entries of SVLAN confingrations
Examples:
This example shows how to get the svlan table configuration of
entry 0 and all entries retriving
RTK.0> svlan get entry 0
Index SVID Member TagSet Spri FidEn FID EfidEn Efid
0 1000 0-6 3 7 Enable 0 Enable 7
RTK.0>
RTK.0> svlan get entry all
Index SVID Member TagSet Spri FidEn FID EfidEn Efid
0 1000 0-6 3 7 Enable 0 Enable 7
1 1001 0-6 0 Disable 0 Disable 0
RTK.0>
SFU Product Page 64 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set svlan-table
Description:
This command can configure svlan with specify svid and only if
this svlan is created
Syntax:
svlan set svlan-table svid svid member <PORT_LIST:ports | all
| none>
svlan set svlan-table svid svid tag-member <PORT_LIST: ports |
all | none>
svlan set svlan-table svid svid untag-member <PORT_LIST:ports
| all | none>
svlan set svlan-table svid svid priority priority
svlan set svlan-table svid svid fid-msti state <disable |
enable>
svlan set svlan-table svid svid fid-msti fid_msti
svlan set svlan-table svid svid enhanced-fid state <disable |
enable>
svlan set svlan-table svid svid enhanced-fid efid
Parameter:
svid - specify the numeric sVLAN identifier
member - member configuration
tag-member - tagging member configuration
untag-member - untag set configuration
ports - the vlan member or tag member ports
all - specify all ports
none - specify no port
priority - specify the priority value
fid_msti - the filter-id or msti for this vlan
efid - specify the enhanced filter-id
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to congigurate the svlan which svid is
2000:
Add port 0-4 to vlan 2000
SFU Product Page 65 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Assign port 3 to tag member
RTK.0> svlan create svlan-table svid 2000
RTK.0> svlan set svlan-table svid 2000 member 0-4
RTK.0> svlan set svlan-table svid 2000 tag-member 3
RTK.0> svlan get svlan-table svid 2000
SVID Member UntagSet Spri FidEn FID EfidEn Efid
2000 0-4 0-2,4-6 0 Disable 0 Disable 0
RTK.0>
SFU Product Page 66 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get svlan-table
Description:
Show svlan configuration of a specify svid.
Syntax:
svlan get svlan-table svid svid
Parameter:
svid - specify the numeric SVLAN identifier
Examples:
This example shows how to get the svlan table configuration of
specify svid 2000
RTK.0> svlan get svlan-table svid 2000
SVID Member UntagSet Spri FidEn FID EfidEn Efid
2000 0-4 0-2,4-6 0 Disable 0 Disable 0
RTK.0>
SFU Product Page 67 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set port svid
Description:
This command can configure port based svlan with specify svid.
Syntax:
svlan set port <PORT_LIST:ports | all> svid svid
Parameter:
svid - specify the numeric VLAN identifier
ports - specified port list
all – specify all ports
Examples:
This example shows how to congigurate the port 0 port-based svlan
with svid 100 and port 1 port-based svlan with svid 200
RTK.0> svlan create svlan-table svid 100
RTK.0> svlan create svlan-table svid 200
RTK.0> svlan set port 0 svid 100
RTK.0> svlan set port 1 svid 200
RTK.0>
SFU Product Page 68 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get port svid
Description:
Show port based svlan with specify svid.
Syntax:
svlan get port <PORT_LIST:ports | all> svid
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get the port 0/1 port-based svlan.
RTK.0> svlan get port 0-1 svid
Port SVID
0 100
1 200
RTK.0>
SFU Product Page 69 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set service-port
Description:
This command can configure svlan tag aware ports or svlan service
ports.
Syntax:
svlan set service-port <PORT_LIST:ports | all | none>
Parameter:
ports - specified port list
all – specify all ports
none - specify no port
Examples:
This example shows how to configurate svlan servive ports 0,3
RTK.0> svlan set service-port 0,3
RTK.0>
SFU Product Page 70 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get service-port
Description:
Show svlan tag aware ports or svlan service ports
Syntax:
svlan get service-port
Parameter:
None
Examples:
This example shows how to get svlan servive ports or stag aware
ports
RTK.0> svlan set service-port 0,3
RTK.0> svlan get service-port
Server Ports: 0,3
RTK.0>
SFU Product Page 71 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set lookup-type
Description:
This command can configure svlan lookup from svlan member
configuration entry or vlan 4k table. This command is supported
depond on chip design or not.
Syntax:
svlan set lookup-type <svlan-table | vlan-4k-table>
Parameter:
svlan-table - 64 svlan member configurations
vlan-4k-table - 4K vlan table
Examples:
This example shows how to configurate svlan lookup mode to lokkup
svlan member configuration entries.
RTK.0> svlan set lookup-type svlan-table
RTK.0>
SFU Product Page 72 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get lookup-type
Description:
Show svlan lookup mode
Syntax:
svlan get lookup-type
Parameter:
None
Examples:
This example shows how to get svlan lookup mode
RTK.0> svlan set lookup-type svlan-table
RTK.0> svlan get lookup-type
Lookup type: SVLAN 64 entries
RTK.0>
SFU Product Page 73 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set tpid
Description:
This command can configure svlan tagging ethertype
Syntax:
svlan set tpid tpid
Parameter:
tpid - ethertype for stag
Examples:
This example shows how to configurate ethertype of svlan tag to
0x9100.
RTK.0> svlan set tpid 0x9100
RTK.0>
SFU Product Page 74 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get tpid
Description:
Show svlan tagging ethertype
Syntax:
svlan get tpid
Parameter:
None
Examples:
This example shows how to get ethertype of svlan tag
RTK.0> svlan set tpid 0x9100
RTK.0> svlan get tpid
TPID: 0x9100
RTK.0>
SFU Product Page 75 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set priority-source
Description:
This command can configure egress stag priority field inserting
source. This configuration will effect asic egress staging
priority assignment only.
Syntax:
svlan set priority-source <internal-priority | dot1q-priority
| svlan-member-cofig | port-based-priority>
Parameter:
internal-priority - switch core internal priority
dot1q-priority - ingress cvlan tagged priority field
svlan-member-cofi
g
- priority of svlan member configuration
port-based-priori
ty
- port based priority
Examples:
This example shows how to configurate svlan tagging priority
source from cvlan ingress tagged priority field. That means
egress stag priority is as the same as ctag priority.
RTK.0> svlan set priority-source dot1q-priority
RTK.0>
SFU Product Page 76 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get priority-source
Description:
Show egress stag priority field inserting source
Syntax:
svlan get priority-source
Parameter:
None
Examples:
This example shows how to get source decision of svlan tagging
priority field
RTK.0> svlan set priority-source dot1q-priority
RTK.0> svlan get priority-source
Priority source: 1q tag priority
RTK.0>
SFU Product Page 77 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set unmatch
Description:
This command can configure asic ation for ingress stag which svid
is unmatched any of svlan member configuration entry if svlan
lookup is used.
Syntax:
svlan set unmatch <drop | trap-to-cpu>
svlan set unmatch assign-svlan svid svid
Parameter:
drop - drop packet
trap-to-cpu - trap packet to cpu port
assign-svlan - assign svlan property
svid – specify the numeric SVLAN identifier
Examples:
This example shows how to assign action for packets ingress svid
unmatched all svlan member configuration to svlan with svid
1001.
RTK.0> svlan create svlan-table svid 1001
RTK.0> svlan set unmatch assign-svlan svid 1001
RTK.0>
SFU Product Page 78 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get unmatch
Description:
Show action for ingress stag packets from service port which svid
is unmatched all svlan member configuration entries
Syntax:
svlan get unmatch
Parameter:
None
Examples:
This example shows how to get action for packets from service
ports that ingress svid unmatched all svlan member configuration
RTK.0> svlan set unmatch assign-svlan svid 1001
RTK.0> svlan get unmatch
Action: Assign to SVLAN SVID: 1001
RTK.0>
SFU Product Page 79 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set untag
Description:
This command can configure action for packets without stag from
svlan service port
Syntax:
svlan set untag < drop | trap-to-cpu >
svlan set untag assign-svlan svid svid
Parameter:
drop - drop packet
trap-to-cpu - trap packet to cpu port
assign-svlan - assign svlan property
svid – specify the numeric SVLAN identifier
Examples:
This example shows how to assign trap action for packets without
ingress stag from svlan service port.
RTK.0> svlan set untag trap-to-cpu
RTK.0>
SFU Product Page 80 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get untag
Description:
Show action for ingress un-stag packets from svlan service port
Syntax:
svlan get untag
Parameter:
None
Examples:
This example shows how to get action for ingress un-stag packets
from svlan service port
RTK.0> svlan set untag assign-svlan svid 1001
RTK.0> svlan get untag
Action: Assign to SVLAN SVID: 1001
RTK.0>
SFU Product Page 81 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set trap-priority
Description:
This command can configure priority for packets trapped to cpu
for related svlan functions
Syntax:
svlan set trap-priority priority
Parameter:
priority - priority for trapping packets
Examples:
This example shows how to assin priority 7 packets which meet
svlan related trapped behavior
RTK.0> svlan set trap-priority 7
RTK.0>
SFU Product Page 82 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get trap-priority
Description:
Show svlan related assigned trapping priority
Syntax:
svlan get trap-priority
Parameter:
None
Examples:
This example shows how to get svlan trapping priority
RTK.0> svlan set trap-priority 6
RTK.0> svlan get trap-priority
Trap priority: 6
RTK.0>
SFU Product Page 83 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set dei-keep state
Description:
This command can configure egress keepping dei field of ingress
stag. The DEI of stag will be keep only if this state is set,
otherwise it will always be 0 in egress svlan tag.
Syntax:
svlan set dei-keep state <disable | enable>
Parameter:
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to configurate enable keeping ingress dei
field of stag packets for egress stag.
RTK.0> svlan set dei-keep state enable
RTK.0>
SFU Product Page 84 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get dei-keep state
Description:
Show egress keep dei field state of ingress stag packets
Syntax:
svlan get dei-keep state
Parameter:
state - state configuration
Examples:
This example shows how to get keep ingress dei field state of
stagged packets for egress stag
RTK.0> svlan set dei-keep state enable
RTK.0> svlan get dei-keep
Keep DEI state: Enable
RTK.0>
SFU Product Page 85 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set vlan-aggregation
Description:
This command can configure svlan vlan-aggregation state for
downstream egress port. Asic can tagging vid by ingress learning
in downstream egress port while vlan aggregation state is set.
Not only downstream stag only packet, but also ctag packets will
be treated as egress ctag packets by vid which auto vid leaning
with mac-address if forced-state is set.
Syntax:
svlan set vlan-aggregation port <PORT_LIST:ports | all > state
<disable | enable>
svlan set vlan-aggregation forced-state <disable | enable>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
forced-state - forced state configuration
Examples:
This example shows how to configurate the egress port 1
downstream packet vlan aggregation state enable.
RTK.0> svlan set vlan-aggregation port 1 state enable
RTK.0> svlan get vlan-aggregation port 1 state
Port Status
1 Enable
RTK.0>
SFU Product Page 86 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get vlan-aggregation
Description:
Show svlan vlan-aggregation state for downstream egress port.
Syntax:
svlan get vlan-aggregation port <PORT_LIST:ports | all > state
svlan get vlan-aggregation forced-state
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
forced-state - forced state configuration
Examples:
This example shows how to get port 0-3 downstream packet vlan
aggregation state
RTK.0> svlan get vlan-aggregation port 0-3 state
Port Status
0 Disable
1 Enable
2 Disable
3 Disable
RTK.0>
SFU Product Page 87 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan add vlan-conversion
Description:
This command can add ingress vlan conversion configuration from
ingress vlan vid or multicast address to svlan svid. Also, this
command can add egress vlan conversion configuration for
different svlan and egress port to different egress vlan vid.
Syntax:
svlan add vlan-conversion c2s vid vid port <PORT_LIST:ports |
all> svid svid
svlan add vlan-conversion mc2s ip ip ip-mask ip_mask svid svid
svlan add vlan-conversion mc2s mac-address mac mac-mask
mac_mask svid svid
svlan add vlan-conversion sp2c svid svid port port vid vid
Parameter:
c2s – cvlan to svlan conversion
mc2s - multicast to svlan conversion
sp2c - svlan with egress port to cvlan conversion
vid – specify the numeric VLAN identifier
svid – specify the numeric SVLAN identifier
ports - specified port list
all – specify all ports
ip - IPv4 address
ip_mask - IPv4 address mask
mac - MAC address
mac_mask - MAC address mask
port - specified port
Examples:
This example shows how to add vlan conversion configuration:
Ingress vid 100 from port 0 convert to svlan svid 2000
Ingress vid 100 from port 1 convert to svlan svid 2001
Ingress vid 200 from port 1 convert to svlan svid 2000
IPv4 dip 239.0.0.0~239.0.0.255 to svlan 2002
Layer 2 multicast address 01:xx:11:22:00:00~01:xx:11:22:FF:FF
to svlan 2003
SVLAN svid 2000 and egress port 0 to vlan vid 100
SVLAN svid 2001 and egress port 1 to vlan vid 100
SFU Product Page 88 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
SVLAN svid 2000 and egress port 1 to vlan vid 200
RTK.0> svlan create svlan-table svid 2000
RTK.0> svlan create svlan-table svid 2001
RTK.0> svlan create svlan-table svid 2002
RTK.0> svlan create svlan-table svid 2003
RTK.0> svlan add vlan-conversion c2s vid 100 port 0 svid 2000
RTK.0> svlan add vlan-conversion c2s vid 200 port 1 svid 2000
RTK.0> svlan add vlan-conversion c2s vid 100 port 1 svid 2001
RTK.0> svlan add vlan-conversion mc2s ip 239.0.0.0 ip-mask
255.255.255.0 svid 2002
RTK.0> svlan add vlan-conversion mc2s mac-address
01:00:11:22:00:00 mac-mask 00:00:FF:FF:00:00 svid 2003
RTK.0> svlan add vlan-conversion sp2c svid 2000 port 0 vid 100
RTK.0> svlan add vlan-conversion sp2c svid 2000 port 1 vid 200
RTK.0> svlan add vlan-conversion sp2c svid 2001 port 1 vid 100
RTK.0>
SFU Product Page 89 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan del vlan-conversion
Description:
This command can delete vlan conversion configuration with
ingress vid to svid or svid to egress vid.
Syntax:
svlan del vlan-conversion c2s vid vid port <PORT_LIST:ports |
all> svid svid
svlan del vlan-conversion mc2s ip ip ip-mask ip_mask
svlan del vlan-conversion mc2s mac-address mac mac-mask
mac_mask
svlan del vlan-conversion sp2c svid svid port port
Parameter:
c2s – cvlan to svlan conversion
mc2s - multicast to svlan conversion
sp2c - svlan with egress port to cvlan conversion
vid – specify the numeric VLAN identifier
svid – specify the numeric SVLAN identifier
ports - specified port list
all – specify all ports
ip - IPv4 address
ip_mask - IPv4 address mask
mac - MAC address
mac_mask - MAC address mask
port - specified port
Examples:
This example shows how to delete ipv4 dip 239.0.0.0~239.0.0.255
to svid 2002 and svid 2001 with egress port 1
RTK.0> svlan del vlan-conversion mc2s ip 239.0.0.0 ip-mask
255.255.255.0
RTK.0> svlan del vlan-conversion sp2c svid 2001 port 1
RTK.0>
SFU Product Page 90 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get vlan-conversion
Description:
Show vlan conversion configuration with ingress cvlan,
multicast or egress svlan and egress port.
Syntax:
svlan get vlan-conversion c2s vid vid port <PORT_LIST:ports |
all>
svlan get vlan-conversion mc2s ip ip ip-mask ip_mask
svlan get vlan-conversion mc2s mac-address mac mac-mask
mac_mask
svlan get vlan-conversion sp2c svid svid port port
Parameter:
c2s – cvlan to svlan conversion
mc2s - multicast to svlan conversion
sp2c - svlan with egress port to cvlan conversion
vid – specify the numeric VLAN identifier
svid – specify the numeric SVLAN identifier
ports - specified port list
all – specify all ports
ip - IPv4 address
ip_mask - IPv4 address mask
mac - MAC address
mac_mask - MAC address mask
port - specified port
Examples:
This example shows how to get the svlan vlan conversion
configuration with ingress vid 100/200 and egress svid 2000 with
egress port 0/1.
RTK.0> svlan get vlan-conversion c2s vid 100 port all
Vid Port Svid
100 0 2000
100 1 2001
RTK.0> svlan get vlan-conversion c2s vid 200 port all
Vid Port Svid
200 1 2000
SFU Product Page 91 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> svlan get vlan-conversion sp2c svid 2000 port 0
Svid Port Cvid
2000 0 100
RTK.0> svlan get vlan-conversion sp2c svid 2000 port 1
Svid Port Cvid
2000 1 200
RTK.0>
SFU Product Page 92 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan set vlan-conversion sp2c unmatch-action
Description:
This command can configuration packet egress mode while svlan
downstream packets which unmatch any entry of svid with egress
port to egress vid conversion setting.
Syntax:
svlan set vlan-conversion sp2c unmatch-action <untag | ctag>
Parameter:
untag – egress cvlan untagging format
ctag - egress cvlan tagging format
Examples:
This example shows how to configurate always untag egress
packets witch unmatch any entry of svid with egress port vlan
conversion.
RTK.0> svlan set vlan-conversion sp2c unmatch-action untag
RTK.0>
SFU Product Page 93 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
svlan get vlan-conversion sp2c unmatch-action
Description:
Show configuration setting for svlan downstream packets which
unmatch any entry of svid with destination port to egress vid
conversion setting.
Syntax:
svlan get vlan-conversion sp2c unmatch-action
Parameter:
None
Examples:
This example shows how to get unmatched svid with egress port
to egress vid conversion configuration
RTK.0> svlan get vlan-conversion sp2c unmatch-action
SP2C unmatching C-tag format: Untagging
RTK.0>
SFU Product Page 94 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.3. QoS commands
qos init
Description:
This command will initializae qos module to default setting.
Syntax:
qos init
Parameter:
None
Examples:
This example shows how to initialized QoS module.
RTK.0> qos init
RTK.0>
SFU Product Page 95 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set priority-to-queue
Description:
This command can configure the priority to queue table, this
table have 4 entries. Each entry can map 8 priority to specifiy
queue-id.
This table be referenced by “qos set priority-to-queue-mapping”
Syntax:
qos set priority-to-queue table index priority
MASK_LIST:priority queue-id qid
qos set priority-to-queue port <PORT_LIST:ports | all> table
index
Parameter:
index – index of priority to queue table
table - priority to queue mapping table
priority - priority configuration
qid - specify the numeric queue identifier
ports - specified port list
all – specify all ports
Examples:
This example shows how to congigurate the prority to queue table
entry 0 which mappimg is:
priority 0 to 7
priority 1 to 6
priority 2 to 5
priority 3 to 4
priority 4 to 3
priority 5 to 2
priority 6 to 1
priority 7 to 0
Mapping port 0 ~ 6 to prority to queue table entry 0
RTK.0> qos set priority-to-queue table 0 priority 0 queue-id 7
RTK.0> qos set priority-to-queue table 0 priority 1 queue-id 6
RTK.0> qos set priority-to-queue table 0 priority 2 queue-id 5
RTK.0> qos set priority-to-queue table 0 priority 3 queue-id 4
RTK.0> qos set priority-to-queue table 0 priority 4 queue-id 3
SFU Product Page 96 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> qos set priority-to-queue table 0 priority 5 queue-id 2
RTK.0> qos set priority-to-queue table 0 priority 6 queue-id 1
RTK.0> qos set priority-to-queue table 0 priority 7 queue-id 0
RTK.0> qos set priority-to-queue port 0-6 table 0
SFU Product Page 97 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get priority-to-queue
Description:
Show priority to queue mapping table
Syntax:
qos get priority-to-queue table index
qos get priority-to-queue port <PORT_LIST:ports | all>
Parameter:
index – index of priority to queue table
table - priority to queue mapping table
ports - specified port list
all – specify all ports
Examples:
This example shows how to get prority to queue table.
Get prority to queue table entry 0
RTK.0> qos get priority-to-queue table 0
Index pri_0 pri_1 pri_2 pri_3 pri_4 pri_5 pri_6 pri_7
0 7 6 5 4 3 2 1 0
Get prority to queue table entry 0 seting for port 1
RTK.0> qos get priority-to-queue port 1
Port Index
1 0
SFU Product Page 98 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set remapping
Description:
Per system set priority remapping for dot1p, DSCP, port-ased
priority and forward to CPU priority.
Syntax:
qos set remapping dot1p dot1p-priority dot1p_priority
internal-priority internal_priority
qos set remapping dscp dscp MASK_LIST:dscp internal-priority
priority
qos set remapping forward-to-cpu internal-priority
internal_priority remapping-priority remapping_priority
qos set remapping port <PORT_LIST:ports | all>
internal-priority priority
Parameter:
dot1p - dot1p remapping configuration
dscp - dscp remapping configuration
forward-to-cpu - to cpu port remapping configuration
port - port-based priority
dot1p-priority - dot1p priority
internal-priority - switch internal priority
remapping-priorit
y
- priority for remapped configuration
ports - specified port list
all – specify all ports
Examples:
This example shows how to remappimg internal priority from
packet dot1p priorty , the remapping setting as:
dot1p-priority 0 remapping to priority 7
dot1p-priority 1 remapping to priority 6
dot1p-priority 2 remapping to priority 5
dot1p-priority 3 remapping to priority 4
RTK.0> qos set remapping dot1p dot1p-priority 0
internal-priority 7
RTK.0> qos set remapping dot1p dot1p-priority 1
internal-priority 6
RTK.0> qos set remapping dot1p dot1p-priority 2
SFU Product Page 99 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
internal-priority 5
RTK.0> qos set remapping dot1p dot1p-priority 3
internal-priority 4
This example shows how to remappimg internal priority from DSCP
priority, the remapping setting as:
DSCP priority 0~15 remapping to 0
DSCP priority 16~31 remapping to 1
DSCP priority 32~47 remapping to 2
DSCP priority 48~63 remapping to 3
RTK.0> qos set remapping dscp dscp 0-15 internal-priority 0
RTK.0> qos set remapping dscp dscp 16-31 internal-priority 1
RTK.0> qos set remapping dscp dscp 32-47 internal-priority 2
RTK.0> qos set remapping dscp dscp 48-63 internal-priority 3
This example shows how to remappimg forward to CPU packet
priority as:
Internal priority 0 remapping to 0
Internal priority 1 remapping to 0
Internal priority 2 remapping to 3
Internal priority 3 remapping to 3
Internal priority 4 remapping to 5
RTK.0> qos set remapping forward-to-cpu internal-priority 0
remapping-priority 0
RTK.0> qos set remapping forward-to-cpu internal-priority 1
remapping-priority 0
RTK.0> qos set remapping forward-to-cpu internal-priority 2
remapping-priority 3
RTK.0> qos set remapping forward-to-cpu internal-priority 3
remapping-priority 3
RTK.0> qos set remapping forward-to-cpu internal-priority 4
remapping-priority 5
This example shows how to set port based priority as:
Port 0 remapping to priority 0
Port 1 remapping to priority 1
Port 2 remapping to priority 2
SFU Product Page 100 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Port 3 remapping to priority 3
RTK.0> qos set remapping port 0 internal-priority 0
RTK.0> qos set remapping port 1 internal-priority 1
RTK.0> qos set remapping port 2 internal-priority 2
RTK.0> qos set remapping port 3 internal-priority 3
SFU Product Page 101 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get remapping
Description:
Get remapping setting.
Syntax:
qos get remapping dot1p
qos get remapping dscp
qos get remapping forward-to-cpu
qos get remapping port <PORT_LIST:ports | all>
Parameter:
dot1p - dot1p remapping configuration
dscp - dscp remapping configuration
forward-to-cpu - to cpu port remapping configuration
port - port-based priority
ports - specified port list
all – specify all ports
Examples:
This example shows how get remapping setting:
RTK.0> qos get remapping dot1p
1p Priority internal priority
0 7
1 1
2 2
3 3
4 4
5 5
6 6
7 7
RTK.0> qos get remapping dscp
DSCP Priority
0 0
1 0
2 0
3 0
4 0
SFU Product Page 102 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
5 0
6 0
7 0
8 0
9 0
10 0
11 0
12 0
13 0
14 0
15 0
16 0
17 0
18 0
19 0
--More—
RTK.0> qos get remapping forward-to-cpu
Priority: 0 Remapping prority: 0
Priority: 1 Remapping prority: 0
Priority: 2 Remapping prority: 0
Priority: 3 Remapping prority: 0
Priority: 4 Remapping prority: 0
Priority: 5 Remapping prority: 0
Priority: 6 Remapping prority: 0
Priority: 7 Remapping prority: 0
RTK.0> qos get remapping port 0-6
Port prioirty
0 0
1 0
2 0
3 0
4 0
5 0
6 0
SFU Product Page 103 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set priority-selector
Description:
There are 9 priority source in system. This command can assign
weight to wach priority source. The source with highest weight
will be select to internal priority.
There are 2 prioirty selector group. Per port can select which
selector group this port will be used.
Syntax:
qos set priority-selector group-id index <port| dot1q | dscp |
acl | smac | svlan | vlan | l4 | lookup-table> weight
qos set priority-selector port <PORT_LIST:ports | all> group-id
index
Parameter:
index - priority selector group index
port - port based priority source
dot1q - dot1q priority source
dscp - dscp priority source
acl - acl priority source
lut - lookup table priority source
smac - source mac priority source
svlan - svlan priority source
vlan - vlan priority source
l4 - L4 priority source
weight - the weight for this priority source
ports - specified port list
all – specify all ports
Examples:
This example shows how to set acl priority weight to 15 and
port-based priorty weight to 10 for selector group 0.
Set port 0-5 apply selector group 0.
RTK.0> qos set priority-selector group-id 0 acl 15
RTK.0> qos set priority-selector group-id 0 port 10
RTK.0> qos set priority-selector port 0-5 group-id 0
SFU Product Page 104 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get priority-selector
Description:
Show system priority selector weight for each priority source.
Syntax:
qos get priority-selector group-id index
qos get priority-selector port <PORT_LIST:ports | all> group-id
Parameter:
index - priority selector group index
ports - specified port list
all – specify all ports
Examples:
This example shows how to get priority selector weight for each
priority source.
RTK.0> qos get priority-selector group-id 0
TYPE Weight
port 10
dot1q 0
dscp 0
acl 15
vlan 0
lookup-table 0
smac 0
svlan 0
l4 0
RTK.0> qos get priority-selector port 0-5 group-id
Port Group
0 0
1 0
2 0
3 0
4 0
5 0
SFU Product Page 105 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set remarking dot1p
Description:
Per egress port enable/disable dot1p priority remarking and set
per system internal priority to remarking dot1p mapping.
Syntax:
qos set remarking dot1p port <PORT_LIST:ports | all> state
<disable | enable>
qos set remarking dot1p user-priority priority dot1p-priority
dot1p_priority
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
dot1p-priority - dot1p priority
user-priority - switch user priority
priority - priority configuration
Examples:
This example shows how to congigurate internal priority
remarking to packet dot1p priority as:
The example shows how to enable dot1p priority remarking for port
1,2,3
internal priority 0 remarking dot1p priority 7
internal priority 1 remarking dot1p priority 6
internal priority 2 remarking dot1p priority 5
internal priority 3 remarking dot1p priority 4
internal priority 4 remarking dot1p priority 3
internal priority 5 remarking dot1p priority 2
internal priority 6 remarking dot1p priority 1
internal priority 7 remarking dot1p priority 0
RTK.0> qos set remarking dot1p user-priority 0 dot1p-priority
7
SFU Product Page 106 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> qos set remarking dot1p user-priority 1 dot1p-priority
6
RTK.0> qos set remarking dot1p user-priority 2 dot1p-priority
5
RTK.0> qos set remarking dot1p user-priority 3 dot1p-priority
4
RTK.0> qos set remarking dot1p user-priority 4 dot1p-priority
3
RTK.0> qos set remarking dot1p user-priority 5 dot1p-priority
2
RTK.0> qos set remarking dot1p user-priority 6 dot1p-priority
1
RTK.0> qos set remarking dot1p user-priority 7 dot1p-priority
0
RTK.0> qos set remarking dot1p port 1,2,3 state enable
SFU Product Page 107 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get remarking dot1p
Description:
Per system set forward to CPU priority remapping.
Syntax:
qos get remarking dot1p port <PORT_LIST:ports | all> state
qos get remarking dot1p
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
source - remarking source
SFU Product Page 108 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set remarking dscp
Description:
Set dscp remarking function. Per port would enable/disable DSCP
remarking. The remarking source can be selected for each port.
The remarking source would be internal-prioirty, user-prioirty
and packet original dscp value.
Syntax:
qos set remarking dscp port <PORT_LIST:ports | all> state
<disable | enable>
qos set remarking port <PORT_LIST:ports | all> dscp source
<internal-priority | user-priority | dscp>
qos set remarking dscp inter-priority priority remarking-dscp
dscp
qos set remarking dscp user-priority priority remarking-dscp
dscp
qos set remarking dscp original-dscp MASK_LIST:dscp
remarking-dscp remarking_dscp
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
source - remarking source
inter-priority - switch internal/user priority
internal-priority - switch internal priority
user-priority - switch user priority
original-dscp - ingress original dscp
remarking-dscp - egress remarked dscp
dscp - dscp configuration
priority - priority configuration
Examples:
This example shows how to enable dscp remarking on port 4.
The remarking source is based on packet original dscp value.
The dscp remarking value will be set as
SFU Product Page 109 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Packet original DSCP valu 0-31 remapping to 0
Packet original DSCP valu 32-63 remapping to 32
RTK.0> qos set remarking dscp port 4 state enable
RTK.0> qos set remarking port 4 dscp source dscp
RTK.0> qos set remarking dscp original-dscp 0-31 remarking-dscp
0
RTK.0> qos set remarking dscp original-dscp 31-63
remarking-dscp 31
RTK.0>
SFU Product Page 110 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get remarking dscp
Description:
Get dscp remarking setting.
Syntax:
qos get remarking dscp port <PORT_LIST:ports | all> state
qos get remarking port <PORT_LIST:ports | all> dscp source
qos get remarking dscp <inter-priority | original-dscp>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
source - remarking source
inter-priority - switch internal/user priority
original-dscp - ingress original dscp
SFU Product Page 111 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set scheduling algorithm
Description:
This command can set per port per queue scheduling algorithm.
Syntax:
qos set scheduling algorithm port <PORT_LIST:ports | all>
queue-id qid <strict | wfq>
Parameter:
ports - specified port list
all – specify all ports
qid - specify the numeric queue identifier
strict - scheduling using strict queue type
wfq - scheduling using WFQ type
Examples:
This example shows how to congigurate port 1 queue 0-3 using
strict, queue 4-7 using WFQ:
RTK.0> qos set scheduling algorithm port 1 queue-id 0 strict
RTK.0> qos set scheduling algorithm port 1 queue-id 1 strict
RTK.0> qos set scheduling algorithm port 1 queue-id 2 strict
RTK.0> qos set scheduling algorithm port 1 queue-id 3 strict
RTK.0> qos set scheduling algorithm port 1 queue-id 4 wfq
RTK.0> qos set scheduling algorithm port 1 queue-id 5 wfq
RTK.0> qos set scheduling algorithm port 1 queue-id 6 wfq
RTK.0> qos set scheduling algorithm port 1 queue-id 7 wfq
SFU Product Page 112 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get scheduling algorithm
Description:
Show per port per queue scheduling algorithm.
Syntax:
qos get scheduling algorithm port <PORT_LIST:ports | all>
queue-id qid
Parameter:
ports - specified port list
all – specify all ports
qid - specify the numeric queue identifier
Examples:
This example shows how to get queue scheduling algorithm for port
1 queue 0 and queue 1.
RTK.0> qos get scheduling algorithm port 1 queue-id 0
port: 1 queue: 0 type:strict
RTK.0> qos get scheduling algorithm port 1 queue-id 1
port: 1 queue: 1 type:strict
RTK.0>
SFU Product Page 113 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set scheduling queue-weight
Description:
This command can set per port per queue WFQ scheduling weight .
Syntax:
qos set scheduling queue-weight port <PORT_LIST:ports | all >
queue-id qid weight weight
Parameter:
ports - specified port list
all – specify all ports
qid - specify the numeric queue identifier
weight - the queue scheduling weight
Examples:
This example shows how to congigurate port 1 queue 0 weight 65535,
queue 4 weight 15:
RTK.0> qos set scheduling queue-weight port 1 queue-id 0 weight
65535
RTK.0> qos set scheduling queue-weight port 1 queue-id 4 weight
15
RTK.0>
SFU Product Page 114 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get scheduling queue-weight
Description:
Show per port per queue scheduling weight.
Syntax:
qos get scheduling queue-weight port <PORT_LIST:ports | all>
queue-id qid
Parameter:
ports - specified port list
all – specify all ports
qid - specify the numeric queue identifier
Examples:
This example shows how to get queue scheduling weight for port
1 queue 0-1.
RTK.0> qos get scheduling queue-weight port 1 queue-id 0
port: 1 queue: 0 weight:65535
RTK.0> qos get scheduling queue-weight port 1 queue-id 1
port: 1 queue: 1 weight:0
RTK.0>
SFU Product Page 115 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos set avb remapping
Description:
Per system set av bridge priority remapping.
Syntax:
qos set avb remapping internal-priority priority user-priority
user_priority
qos set avb remapping port <PORT_LIST:ports | all> state
<disable | enable>
Parameter:
internal-priority - switch internal priority
user-priority - switch user priority
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to enable av bridge priority remaping
on port 1 and the remapping table will as follow:
Internal priority 0 remapping to 0
Internal priority 1 remapping to 0
Internal priority 2 remapping to 3
Internal priority 3 remapping to 3
Internal priority 4 remapping to 3
Internal priority 5 remapping to 7
Internal priority 6 remapping to 7
Internal priority 7 remapping to 7
RTK.0> qos set avb remapping port 1 state enable
RTK.0> qos set avb remapping internal-priority 0 user-priority
0
RTK.0> qos set avb remapping internal-priority 1 user-priority
0
RTK.0> qos set avb remapping internal-priority 2 user-priority
3
RTK.0> qos set avb remapping internal-priority 3 user-priority
SFU Product Page 116 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
3
RTK.0> qos set avb remapping internal-priority 4 user-priority
3
RTK.0> qos set avb remapping internal-priority 5 user-priority
7
RTK.0> qos set avb remapping internal-priority 6 user-priority
7
RTK.0> qos set avb remapping internal-priority 7 user-priority
7
SFU Product Page 117 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
qos get avb remapping
Description:
Get AV bridage priority remapping setting.
Syntax:
qos get avb remapping internal-priority priority
qos get avb remapping port <PORT_LIST:ports | all> state
Parameter:
internal-priority - switch internal priority
ports - specified port list
all – specify all ports
state - state configuration
Examples:
RTK.0> qos get avb remapping port all
Port State
0 Disable
1 Enable
2 Disable
3 Disable
4 Disable
5 Disable
RTK.0> qos get avb remapping internal-priority 0
Priority Remap-Pri
0 0
RTK.0> qos get avb remapping internal-priority 1
Priority Remap-Pri
1 0
SFU Product Page 118 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.4. l2-table commands
l2-table init
Description:
This command can initialize & reset L2 module.
Syntax:
l2-table init
Parameter:
None
Examples:
This example shows how to initialize L2 module.
RTK.0> l2-table init
SFU Product Page 119 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set aging-time
Description:
Thie command set aging time. The unit is 0.1 second.
Syntax:
l2-table set aging-time time
Parameter:
time - aging time, unit 0.1 second
Examples:
This example shows how to set aging time to 300 seconds.
RTK.0> l2-table set aging-time 3000
SFU Product Page 120 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get aging-time
Description:
This command can get aging time.
Syntax:
l2-table get aging-time
Parameter:
None
Examples:
This example shows how to get aging time.
RTK.0> l2-table get aging-time
Age Time: 3000
SFU Product Page 121 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set limit-learning
Description:
This command can set per port or system limit learning number.
The number specified in this command is only count dynamic L2
entries. For those packets which is not learned due to the
current entry number is equal to limit learning number, an action
can also be set for these packet.
Syntax:
l2-table set limit-learning port <PORT_LIST:ports | all> count
count
l2-table set limit-learning port <PORT_LIST:ports | all> count
unlimited
l2-table set limit-learning port <PORT_LIST:ports | all> action
<drop | forward | copy-to-cpu | trap-to-cpu>
l2-table set limit-learning action <drop | forward | copy-to-cpu
| trap-to-cpu>
l2-table set limit-learning count count
l2-table set limit-learning count unlimited
Parameter:
ports – specify a port list
all - specify all ports
drop - drop packet
trap-to-cpu - trap packet to cpu port
forward - forward packet
copy-to-cpu - copy packet to cpu port
count - limited learning count
unlimited - unlimited configuration
action - over learning behavior
Examples:
This example shows how to set the following configuration.
Set system limit learning to 1000.
Set port 0-1 limit learning to 20.
Set system limit learning action as “Drop”
Set port 0-1 limit learning action as “Forward”
RTK.0> l2-table set limit-learning count 1000
SFU Product Page 122 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> l2-table set limit-learning action drop
RTK.0> l2-table set limit-learning port 0-1 count 20
RTK.0> l2-table set limit-learning port 0-1 action forward
RTK.0>
SFU Product Page 123 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get limit-learning
Description:
This command can get the configuration of limit learning
Syntax:
l2-table get limit-learning port <PORT_LIST:ports | all> count
l2-table get limit-learning port <PORT_LIST:ports | all> action
l2-table get limit-learning action
l2-table get limit-learning count
Parameter:
ports – specify a port list
all - specify all ports
count - limited learning count
action - over learning behavior
Examples:
This example shows how to get system and port limit learning
configuration.
RTK.0> l2-table get limit-learning count
System Learning Limit: 1000
RTK.0> l2-table get limit-learning action
System learning Over Action: Drop
RTK.0> l2-table get limit-learning port 0-6 count
Port 0 learning limit: 20
Port 1 learning limit: 20
Port 5 learning limit: 2112
RTK.0> l2-table get limit-learning port 0-1 action
Port 0 learning limit over action: Forward
Port 1 learning limit over action: Forward
RTK.0>
SFU Product Page 124 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get learning-exceed
Description:
This command get the status of limit learning exceed. If the
current learning number is equal to limit learning, the status
will becomes YES.
Syntax:
l2-table get learning-exceed
l2-table get learning-exceed port <PORT_LIST:ports | all>
Parameter:
ports – specify a port list
all - specify all ports
Examples:
This example shows how to get system and port learning-exceed.
RTK.0> l2-table get learning-exceed
Learning-exceed = No
RTK.0> l2-table get learning-exceed port 0-1
Port Id 0, learning-exceed = No
Port Id 1, learning-exceed = No
RTK.0>
SFU Product Page 125 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set src-port-egress-filter
Description:
This command set source port egress filtering function.
Syntax:
l2-table set src-port-egress-filter port <PORT_LIST:ports |
all> state <disable | enable>
l2-table set src-port-egress-filter ext <PORT_LIST:ports>
state <disable | enable>
Parameter:
ports – specify a port list
all - specify all ports
ext – specify a extention port list
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to disable source port filtering at port
0-2 and extension port 0-1
RTK.0> l2-table set src-port-egress-filter port 0-2 state
disable
RTK.0> l2-table set src-port-egress-filter ext 0-1 state disable
RTK.0>
SFU Product Page 126 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get src-port-egress-filter
Description:
This command can get source port filtering configuration.
Syntax:
l2-table get src-port-egress-filter port <PORT_LIST:ports |
all> state
l2-table get src-port-egress-filter ext <PORT_LIST:ports>
state
Parameter:
ports – specify a port list
all - specify all ports
ext – specify a extention port list
state - state configuration
Examples:
This example shows how to get source port filtering for all ports
and all extension ports.
RTK.0> l2-table get src-port-egress-filter port 0-6
SRC Port 0 egress filter state: Disable
SRC Port 1 egress filter state: Disable
SRC Port 2 egress filter state: Disable
SRC Port 3 egress filter state: Enable
SRC Port 4 egress filter state: Enable
SRC Port 5 egress filter state: Enable
SRC Port 6 egress filter state: Enable
RTK.0> l2-table get src-port-egress-filter ext 0-5
EXT Port 0 egress filter state: Disable
EXT Port 1 egress filter state: Disable
EXT Port 2 egress filter state: Enable
EXT Port 3 egress filter state: Enable
EXT Port 4 egress filter state: Enable
EXT Port 5 egress filter state: Enable
RTK.0>
SFU Product Page 127 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table clear learning-exceed
Description:
This command can clear the learning-exceed status.
Syntax:
l2-table clear learning-exceed
l2-table clear learning-exceed port <PORT_LIST:ports | all>
Parameter:
ports – specify a port list
all - specify all ports
Examples:
This example shows how to clear the learning-exceed status.
RTK.0> l2-table clear learning-exceed
Learning-exceed clear
RTK.0> l2-table clear learning-exceed port 0-6
Port Id 0, learning-exceed clear
Port Id 1, learning-exceed clear
Port Id 2, learning-exceed clear
Port Id 3, learning-exceed clear
Port Id 4, learning-exceed clear
Port Id 5, learning-exceed clear
Port Id 6, learning-exceed clear
RTK.0>
SFU Product Page 128 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set aging-out
Description:
This command set the state of aging-out.
Syntax:
l2-table set aging-out port < PORT_LIST:ports | all > state
<disable | enable>
Parameter:
ports – specify a port list
all - specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to disable aging-out at port 0-2.
RTK.0> l2-table set aging-out port 0-2 state disable
RTK.0>
SFU Product Page 129 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get aging-out
Description:
This command get the state of aging-out.
Syntax:
l2-table get aging-out port <PORT_LIST:ports | all > state
Parameter:
ports – specify a port list
all - specify all ports
state - state configuration
Examples:
This example shows how to get the state of aging-out.
RTK.0> l2-table get aging-out port 0-6
Port 0 Age state: Disable
Port 1 Age state: Disable
Port 2 Age state: Disable
Port 3 Age state: Enable
Port 4 Age state: Enable
Port 5 Age state: Enable
Port 6 Age state: Enable
RTK.0>
SFU Product Page 130 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add ip-mcast dip
Description:
This command used to add an IP multicast DIP only entry
Syntax:
l2-table add ip-mcast dip dip port <PORT_LIST:ports | all | none>
l2-table add ip-mcast dip dip ext <PORT_LIST:ext | all | none>
l2-table add ip-mcast dip dip priority priority
l2-table add ip-mcast dip dip port <PORT_LIST:ports | all>
l3-interface index
l2-table add ip-mcast dip dip <priority | l3routing |
forcedl3routing> state <disable | enable>
Parameter:
dip - destination ip address
ports - specified port list
all – specify all ports
none - specify no port
state - state configuration
disable - disable configuration
enable - enable configuration
priority - priority configuration
ext – specify a extention port list
l3-interface - specify layer 3 routing interface
l3routing - layer 3 routing configuration
forcedl3routing - forced layer 3 routing configuration
Examples:
This example shows how to add an IP multicast DIP only entry.
DIP = 224.1.1.1
Portmask = Port 0-2
Enable Priority assignment and the priority is 6.
RTK.0> l2-table add ip-mcast dip 224.1.1.1 port 0-2
LUT address: 0x0000 (2K LUT)
RTK.0> l2-table add ip-mcast dip 224.1.1.1 priority state enable
LUT address: 0x0000 (2K LUT)
SFU Product Page 131 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> l2-table add ip-mcast dip 224.1.1.1 priority 6
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 132 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get ip-mcast dip
Description:
This command can get an IP multicast DIP only entry
Syntax:
l2-table get ip-mcast dip dip
Parameter:
dip - destination ip address
Examples:
This example shows how to get an IP multicast DIP only entry which
DIP = 224.1.1.1.
RTK.0> l2-table get ip-mcast dip 224.1.1.1
LUT address: 0x0000 (2K LUT)
DestinationIP Member Fwd Pri State Ext DipOnly ForceExt
L3Route L3Idx
--------------- ------ --- --- ------ ------ ------- --------
------- -----
224.1.1.1 0-2 En 6 Auto En Dis Dis
0
RTK.0>
SFU Product Page 133 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del ip-mcast dip
Description:
This command can delete a IP multicast DIP only entry.
Syntax:
l2-table del ip-mcast dip dip
Parameter:
dip - destination ip address
Examples:
This example shows how to delete an IP multicast DIP only entry
which DIP = 224.1.1.1.
RTK.0> l2-table del ip-mcast dip 224.1.1.1
RTK.0>
SFU Product Page 134 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add ip-mcast sip dip
Description:
This command add an IP multicast entry with both DIP and SIP.
Syntax:
l2-table add ip-mcast sip sip dip dip port <PORT_LIST:ports |
all | none>
l2-table add ip-mcast sip sip dip dip ext <PORT_LIST:ext | all
| none>
l2-table add ip-mcast sip sip dip dip priority priority
l2-table add ip-mcast sip sip dip dip priority state <disable
| enable>
Parameter:
sip - source ip address
dip - destination ip address
ports - specified port list
all – specify all ports
none - specify no port
state - state configuration
disable - disable configuration
enable - enable configuration
priority - priority configuration
ext – specify a extention port list
Examples:
This example shows how to add an IP multicast entry.
DIP = 224.1.1.1
SIP = 10.1.1.1
Portmask = Port 0-2
Enable Priority assignment and the priority is 6.
RTK.0> l2-table add ip-mcast sip 10.1.1.1 dip 224.1.1.1 port
0-2
LUT address: 0x0000 (2K LUT)
RTK.0> l2-table add ip-mcast sip 10.1.1.1 dip 224.1.1.1
priority state enable
SFU Product Page 135 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
LUT address: 0x0000 (2K LUT)
RTK.0> l2-table add ip-mcast sip 10.1.1.1 dip 224.1.1.1
priority 6
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 136 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get ip-mcast sip dip
Description:
This command get an IP multicast entry with both DIP and SIP.
Syntax:
l2-table get ip-mcast sip sip dip dip
Parameter:
sip - source ip address
dip - destination ip address
Examples:
This example shows how to get an IP multicast entry.
DIP = 224.1.1.1
SIP = 10.1.1.1
RTK.0> l2-table get ip-mcast sip 10.1.1.1 dip 224.1.1.1
LUT address: 0x0000 (2K LUT)
DestinationIP SourceIP Member Fwd Pri State Ext DipOnly
--------------- --------------- ------ --- --- ------ ------
-------
224.1.1.1 10.1.1.1 Dis 0 Auto Dis
RTK.0>
SFU Product Page 137 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del ip-mcast sip dip
Description:
The command can delete an IP multicast entry with DIP and SIP
Syntax:
l2-table del ip-mcast sip sip dip dip
Parameter:
sip - source ip address
dip - destination ip address
Examples:
This example shows how to delete an IP multicast entry.
DIP = 224.1.1.1
SIP = 10.1.1.1
RTK.0> l2-table del ip-mcast sip 10.1.1.1 dip 224.1.1.1
RTK.0>
SFU Product Page 138 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add ip-mcast vid dip
Description:
This command can add an IP multicast entry with VID & DIP
Syntax:
l2-table add ip-mcast vid vid dip dip port <PORT_LIST:ports |
all | none>
l2-table add ip-mcast vid vid dip dip ext <PORT_LIST:ext | all
| none>
l2-table add ip-mcast vid vid dip dip priority priority
l2-table add ip-mcast vid vid dip dip priority state <disable
| enable>
Parameter:
vid – specify the numeric VLAN identifier
dip - destination ip address
ports - specified port list
all – specify all ports
none - specify no port
state - state configuration
disable - disable configuration
enable - enable configuration
priority - priority configuration
ext – specify a extention port list
Examples:
This example shows how to add an IP multicast entry.
DIP = 224.1.1.1
VID = 10
Portmask = Port 0-2
Enable Priority assignment and the priority is 6.
RTK.0> l2-table add ip-mcast vid 10 dip 224.1.1.1 port 0-2
LUT address: 0x0000 (2K LUT)
RTK.0> l2-table add ip-mcast vid 10 dip 224.1.1.1 priority
state enable
LUT address: 0x0000 (2K LUT)
SFU Product Page 139 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> l2-table add ip-mcast vid 10 dip 224.1.1.1 priority 6
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 140 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get ip-mcast vid dip
Description:
This command can get an IP multicast entry with VID & DIP
Syntax:
l2-table get ip-mcast vid vid dip dip
Parameter:
vid – specify the numeric VLAN identifier
dip - destination ip address
Examples:
This example shows how to get an IP multicast entry.
DIP = 224.1.1.1
VID = 10
LUT address: 0x0000 (2K LUT)
DestinationIP SourceIP Member Fwd Pri State Ext DipOnly
--------------- --------------- ------ --- --- ------ ------
-------
224.1.1.1 10.1.1.1 0-2 En 6 Auto Dis
RTK.0>
SFU Product Page 141 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del ip-mcast vid dip
Description:
This command can delete an IP multicast entry with VID & DIP.
Syntax:
l2-table del ip-mcast vid vid dip dip
Parameter:
vid – specify the numeric VLAN identifier
dip - destination ip address
Examples:
This example shows how to delete an IP multicast entry.
DIP = 224.1.1.1
VID = 10
RTK.0> l2-table del ip-mcast vid 10 dip 224.1.1.1
RTK.0>
SFU Product Page 142 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add mac-mcast filter-id
Description:
This command can add a L2 SVL mulitcast entry
Syntax:
l2-table add mac-mcast filter-id fid mac-address mac port
<PORT_LIST:ports | all | none>
l2-table add mac-mcast filter-id fid mac-address mac ext
<PORT_LIST:ext | all | none>
l2-table add mac-mcast filter-id fid mac-address mac priority
priority
l2-table add mac-mcast filter-id fid mac-address mac priority
state <disable | enable>
Parameter:
fid - filter-id
mac - mac address
ports - specified port list
all – specify all ports
none - specify no port
state - state configuration
disable - disable configuration
enable - enable configuration
priority - priority configuration
ext – specify a extention port list
Examples:
This example shows how to add a L2 SVL multicast entry.
MAC = 01:00:5E:01:02:03
FID = 2
Portmask = Port 0-2
RTK.0> l2-table add mac-mcast filter-id 2 mac-address
01:00:5E:01:02:03 port 0-2
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 143 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get mac-mcast filter-id
Description:
This command can get a L2 SVL multicast entry.
Syntax:
l2-table get mac-mcast filter-id fid mac-address mac
Parameter:
fid - filter-id
mac - mac address
Examples:
This example shows how to get a L2 SVL multicast entry.
MAC = 01:00:5E:01:02:03
FID = 2
RTK.0> l2-table get mac-mcast filter-id 2 mac-address
01:00:5E:01:02:03
LUT address: 0x0000 (2K LUT)
MACAddress Member FID FwdPriEn Pri Ext
------------------ ------ ---- -------- --- ------
01:00:5E:01:02:03 2 Dis 0
RTK.0>
SFU Product Page 144 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del mac-mcast filter-id
Description:
This command can delete a L2 SVL multicast entry.
Syntax:
l2-table del mac-mcast filter-id fid mac-address mac
Parameter:
fid - filter-id
mac - mac address
Examples:
This example shows how to delete a L2 SVL multicast entry.
MAC = 01:00:5E:01:02:03
FID = 2
RTK.0> l2-table del mac-mcast filter-id 2 mac-address
01:00:5E:01:02:03
RTK.0>
SFU Product Page 145 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add mac-mcast vid
Description:
This command can add a L2 IVL mulitcast entry
Syntax:
l2-table add mac-mcast vid vid mac-address mac port
<PORT_LIST:ports | all | none>
l2-table add mac-mcast vid vid mac-address mac ext
<PORT_LIST:ext | all | none>
l2-table add mac-mcast vid vid mac-address mac priority priority
l2-table add mac-mcast vid vid mac-address mac priority state
<disable | enable>
Parameter:
vid – specify the numeric VLAN identifier
mac - mac address
ports - specified port list
all – specify all ports
none - specify no port
state - state configuration
disable - disable configuration
enable - enable configuration
priority - priority configuration
ext – specify a extention port list
Examples:
This example shows how to add a L2 IVL multicast entry.
MAC = 01:00:5E:01:02:03
VID = 10
Portmask = Port 0-2
RTK.0> l2-table add mac-mcast vid 10 mac-address
01:00:5E:01:02:03 port 0-2
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 146 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get mac-mcast vid
Description:
This command can get a L2 IVL mulitcast entry
Syntax:
l2-table get mac-mcast vid vid mac-address mac
Parameter:
vid – specify the numeric VLAN identifier
mac - mac address
Examples:
This example shows how to get a L2 IVL multicast entry.
MAC = 01:00:5E:01:02:03
VID = 10
RTK.0> l2-table get mac-mcast vid 10 mac-address
01:00:5E:01:02:03
LUT address: 0x0524 (2K LUT)
MACAddress Member VID FwdPriEn Pri Ext
------------------ ------ ---- -------- --- ------
01:00:5E:01:02:03 0-2 10 Dis 0
RTK.0>
SFU Product Page 147 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del mac-mcast vid
Description:
This command can delete a L2 IVL mulitcast entry
Syntax:
l2-table del mac-mcast vid vid mac-address mac
Parameter:
vid – specify the numeric VLAN identifier
mac - mac address
Examples:
This example shows how to delete a L2 IVL multicast entry.
MAC = 01:00:5E:01:02:03
VID = 10
RTK.0> l2-table del mac-mcast vid 10 mac-address
01:00:5E:01:02:03
RTK.0>
SFU Product Page 148 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add mac-ucast vid
Description:
This command can add a L2 IVL unicast entry
Syntax:
l2-table add mac-ucast vid vid mac-address mac spn port
l2-table add mac-mcast vid vid mac-address mac ext-spn port
l2-table add mac-ucast vid vid mac-address mac filter-id fid
l2-table add mac-ucast vid vid mac-address mac age age
l2-table add mac-ucast vid vid mac-address mac priority priority
l2-table add mac-ucast vid vid mac-address mac <priority |
sa-priority | arp-usage | auth | da-block | sa-block | static> state
<disable | enable>
Parameter:
vid – specify the numeric VLAN identifier
mac - mac address
spn - specify learning source port
ext-spn – specify learing extention port
fid - filter-id
age - aging time
priority - priority configuration
state - state configuration
disable - disable configuration
enable - enable configuration
priority – lookup priority
sa-priority - source address lookup priority
arp-usage - entry for arp record
auth - 1x authed
da-block - destination address block
sa-block - source address block
static - static entry
Examples:
This example shows how to add a L2 IVL unicast entry.
MAC = 00:01:02:03:04:05
VID = 10
Source port = Port 2
Static = ENABLED
SFU Product Page 149 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> l2-table add mac-ucast vid 10 mac-address
00:01:02:03:04:05 static state enable
LUT address: 0x0000 (2K LUT)
RTK.0> l2-table add mac-ucast vid 10 mac-address
00:01:02:03:04:05 spn 2
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 150 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get mac-ucast vid
Description:
This command can get a L2 IVL unicast entry
Syntax:
l2-table get mac-ucast vid vid mac-address mac
Parameter:
vid – specify the numeric VLAN identifier
mac - mac address
Examples:
This example shows how to get a L2 IVL unicast entry.
MAC = 00:01:02:03:04:05
VID = 10
RTK.0> l2-table get mac-ucast vid 10 mac-address
00:01:02:03:04:05
LUT address: 0x0000 (2K LUT)
Spa/ Priority
Block
MACAddress Ext Fid Efid Age Vid State LRN Sa Fwd Pri
Auth Da Sa Arp
----------------- --- --- ---- --- ---- ------ --- --- --- ---
---- --- --- ---
00:01:02:03:04:05 0/0 0 0 0 10 Auto IVL Dis Dis 0 Dis
Dis Dis Dis
RTK.0>
SFU Product Page 151 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del mac-ucast vid
Description:
This command can delete a L2 IVL unicast entry
Syntax:
l2-table del mac-ucast vid vid mac-address mac
Parameter:
vid – specify the numeric VLAN identifier
mac - mac address
Examples:
This example shows how to delete a L2 IVL unicast entry.
MAC = 00:01:02:03:04:05
VID = 10
RTK.0> l2-table del mac-ucast vid 10 mac-address
00:01:02:03:04:05
RTK.0>
SFU Product Page 152 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table add mac-ucast filter-id
Description:
This command can add a L2 SVL unicast entry
Syntax:
l2-table add mac-ucast filter-id fid mac-address mac spn port
l2-table add mac-mcast filter-id fid mac-address mac ext-spn
port
l2-table add mac-ucast filter-id fid mac-address mac filter-id
fid
l2-table add mac-ucast filter-id fid mac-address mac age age
l2-table add mac-ucast filter-id fid mac-address mac priority
priority
l2-table add mac-ucast filter-id fid mac-address mac < priority
| sa-priority | arp-usage | auth | da-block | sa-block | static>
state <disable | enable>
Parameter:
fid - filter-id
mac - mac address
spn - specify learning source port
ext-spn – specify learing extention port
fid - filter-id
age - aging time
priority - priority configuration
state - state configuration
disable - disable configuration
enable - enable configuration
priority – lookup priority
sa-priority - source address lookup priority
arp-usage - entry for arp record
auth - 1x authed
da-block - destination address block
sa-block - source address block
static - static entry
Examples:
This example shows how to add a L2 SVL unicast entry.
MAC = 00:01:02:03:04:05
SFU Product Page 153 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Filter-ID = 5
Source port = Port 2
Static = ENABLED
RTK.0> l2-table add mac-ucast filter-id 5 mac-address
00:01:02:03:04:05 static state enable
LUT address: 0x0000 (2K LUT)
RTK.0> l2-table add mac-ucast filter-id 5 mac-address
00:01:02:03:04:05 spn 2
LUT address: 0x0000 (2K LUT)
RTK.0>
SFU Product Page 154 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get mac-ucast filter-id
Description:
This command can get a L2 SVL unicast entry
Syntax:
l2-table get mac-ucast filter-id fid mac-address mac
Parameter:
fid - filter-id
mac - mac address
Examples:
This example shows how to get a L2 SVL unicast entry.
MAC = 00:01:02:03:04:05
Filter-ID = 5
RTK.0> l2-table get mac-ucast filter-id 5 mac-address
00:01:02:03:04:05
LUT address: 0x0000 (2K LUT)
Spa/ Priority Block
MACAddress Ext Fid Efid Age Vid State LRN Sa Fwd Pri
Auth Da Sa Arp
----------------- --- --- ---- --- ---- ------ --- --- --- ---
---- --- --- ---
00:01:02:03:04:05 0/0 5 0 0 0 Auto SVL Dis Dis 0 Dis
Dis Dis Dis
RTK.0>
SFU Product Page 155 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del mac-ucast filter-id
Description:
This command can delete a L2 SVL unicast entry
Syntax:
l2-table del mac-ucast filter-id fid mac-address mac
Parameter:
fid - filter-id
mac - mac address
Examples:
This example shows how to delete a L2 SVL unicast entry.
MAC = 00:01:02:03:04:05
Filter-ID = 5
RTK.0> l2-table del mac-ucast filter-id 5 mac-address
00:01:02:03:04:05
RTK.0>
SFU Product Page 156 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set mac-ucast enhanced-filter-id
Description:
This command can set enhanced filter ID. Enhanced filter ID is
on hash key for unicast entry. When users add an unicast entry,
enhance filter ID set by this command will be used.
Syntax:
l2-table set mac-ucast enhanced-filter-id efid
Parameter:
efid - enhanced filter-id
Examples:
This example shows how to set enhanced fileter ID to 3.
RTK.0> l2-table set mac-ucast enhanced-filter-id 3
RTK.0>
SFU Product Page 157 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get entry
Description:
This command can get an entry by specifying a fixed index at
Lookup table.
Syntax:
l2-table get entry address address
Parameter:
address – specify entry address
RTK.0> l2-table get entry address 1000
L2 Unicast table:
SaPriEn FwdPriEn Pri Auth DaBlock SaBlock Arp ExtDsl
RTK.0> l2-table set mac-ucast enhanced-filter-id 3
Examples:
This example shows how to get entry index 1000.
LUT address: 0x0000 (2K LUT)
MACAddress Spa Fid Efid Age Vid State Hash
00:00:00:00:00:00 0 0 0 0 0 Auto SVL
Dis Dis 0 Dis Dis Dis Dis 0
SFU Product Page 158 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table del all
Description:
l2-table del all [include-static]
This example shows how to clear entire Lookup table including
static entry
RTK.0>
This command can clear entire Lookup table.
Syntax:
Parameter:
include-static - include static entry
Examples:
RTK.0> l2-table del all include-static
SFU Product Page 159 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get next-entry
Description:
l2-table get next-entry mac-ucast address address
l2-table get next-entry l2-ip-mcast address address
– specify entry address
l2-ip-mcast
RTK.0> l2-table get next-entry address 1000
00:00:00:00:00:00 0 0 0 0 0 Auto SVL
This command can get next entry after specified index. If
specified index is a valid entry, this entry will be returned.
If specified index is a non-valid entry, the next valid entry
will be returned.
Syntax:
l2-table get next-entry address address
l2-table get next-entry mac-ucast address address spn port
l2-table get next-entry l2-mcast address address
l2-table get next-entry ip-mcast address address
Parameter:
address
mac-ucast - unicast entry
spn - specify learning source port
l2-mcast - l2 multicast entry
ip-mcast - ip multicast entry
- either l2 or ip multicast entry
Examples:
This example shows how to get next valid entry after index 1000.
LUT address: 0x0000 (2K LUT)
L2 Unicast table:
MACAddress Spa Fid Efid Age Vid State Hash
SaPriEn FwdPriEn Pri Auth DaBlock SaBlock Arp ExtDsl
Dis Dis 0 Dis Dis Dis Dis 0
RTK.0>
SFU Product Page 160 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set link-down-flush
Description:
Syntax:
- state configuration
RTK.0> l2-table set link-down-flush state enable
This command can configure link-down-flush feature. By enabling
this feature, all dynamic entry will be flushed when a port is
like down.
l2-table set link-down-flush state <disable | enable>
Parameter:
state
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to configure link-down-flush feature to
disabled.
RTK.0>
SFU Product Page 161 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get link-down-flush
Description:
This command can get current state of link-down-flush feature.
Syntax:
state
l2-table get link-down-flush state
Parameter:
- state configuration
Examples:
This example shows how to get link-down flush state.
RTK.0> l2-table get link-down-flush state
Link down flush state: Enable
RTK.0>
SFU Product Page 162 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set flush mac-ucast
Description:
This command can flush unicast entries in Lookup table.
all
- include static entry
Syntax:
l2-table set flush mac-ucat [include-static]
l2-table set flush mac-ucat static-only
l2-table set flush mac-ucat port <PORT_LIST:ports | all>
[include-static]
l2-table set flush mac-ucat port <PORT_LIST:ports | all>
static-only
l2-table set flush mac-ucat port <PORT_LIST:ports | all>
filter-id fid [include-static]
l2-table set flush mac-ucat port <PORT_LIST:ports | all>
filter-id fid static-only
l2-table set flush mac-ucat port <PORT_LIST:ports | all> vid vid
[include-static]
l2-table set flush mac-ucat port <PORT_LIST:ports | all> vid vid
static-only
Parameter:
ports - specified port list
– specify all ports
include-static
Static-only - static entry only
fid - filter-id
vid – specify the numeric VLAN identifier
Examples:
This example shows how to flush all dynamic entry at Port 2 only.
RTK.0> l2-table set flush mac-ucast port 2
RTK.0>
SFU Product Page 163 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get learning-count
Description:
This command can get current dynamic entry learning counter for
a specified port or system.
Syntax:
l2-table get learning-count
l2-table get learning-count port <PORT_LIST:ports | all >
Parameter:
ports – specify a port list
all - specify all ports
Examples:
This example shows how to get current learnig counter at port
2.
RTK.0> l2-table get learning-count port 2
Port 2 learning counter: 0
RTK.0>
SFU Product Page 164 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set ip-mcast-mode
Description:
This command can set hash mode for IPv4 multicast packet.
Syntax:
l2-table set ip-mcast-mode <dip-and-sip | dip-and-vid |
vid-and-mac>
Parameter:
dip-and-sip - lookup hashing with dip and sip
dip-and-vid - lookup hashing with dip and vid
vid-and-mac - lookup hashing with vid and mac address
Examples:
This example shows how to configure IPv4 multicast hash methed
to DIP and SIP.
RTK.0> l2-table set ip-mcast-mode dip-and-sip
RTK.0>
SFU Product Page 165 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get ip-mcast-mode
Description:
This command can get hash mode for IPv4 multicast packet.
Syntax:
l2-table get ip-mcast-mode
Parameter:
None
Examples:
This example shows how to get IPv4 multicast hash method
RTK.0> l2-table get ip-mcast-mode
IPMC mode : DIP + SIP
RTK.0>
SFU Product Page 166 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set lookup-miss action
Description:
This command can configure the per port lookup miss (IPv4
multicast/IPv6 multicast/L2 multicast/Unicat) packets action.
Syntax:
l2-table set lookup-miss port <PORT_LIST:ports | all > <
ip-mcast | ip6-mcast> action <drop | flood-in-vlan | trap-to-cpu>
l2-table set lookup-miss port <PORT_LIST:ports | all > multicast
action <drop | drop-exclude-rma | flood-in-vlan | trap-to-cpu>
l2-table set lookup-miss port <PORT_LIST:ports | all > unicast
action <drop | flood-in-vlan | trap-to-cpu>
Parameter:
ports – specify a port list
all - specify all ports
ip-mcast - ipv4 unknown multicast
ip6-mcast - ipv6 unknown multicast
multicast - l2 unknown multicast
unicast - unknown unicast
drop - drop packet
drop-exclude-rma - drop packets but exclude rma
flood-in-vlan - flood in vlan
trap-to-cpu - trap packet to cpu port
Examples:
This example shows how to configure lookup miss packet action:
Port 0 unknown L2 multicast: Drop but exclude RMA
Port 1 unknown IPv4 multicast: Trap to CPU
Port 2 unknown IPv6 multicast: Flood in VLAN
Port 3 unknown unicast: Drop
RTK.0> l2-table set lookup-miss port 0 multicast action
drop-exclude-rma
RTK.0> l2-table set lookup-miss port 1 ip-mcast action
trap-to-cpu
RTK.0> l2-table set lookup-miss port 2 ip6-mcast action
flood-in-vlan
RTK.0> l2-table set lookup-miss port 3 unicast action drop
SFU Product Page 167 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0>
SFU Product Page 168 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get lookup-miss action
Description:
This command can get the per port lookup miss (IPv4
multicast/IPv6 multicast/L2 multicast/Unicat) packets action.
Syntax:
l2-table get lookup-miss port <PORT_LIST:ports | all> <ip-mcast
| ip6-mcast | multicast | unicast >
Parameter:
ports - specified port list
all – specify all ports
ip-mcast - ipv4 unknown multicast
ip6-mcast - ipv6 unknown multicast
multicast - l2 unknown multicast
unicast - unknown unicast
Examples:
This example shows how to get L2 muliticast lookup miss packet
action at port 0-3
RTK.0> l2-table get lookup-miss port 0-3 multicast
Port 0 lookup-miss multicast Action: Drop exclude RMA
Port 1 lookup-miss multicast Action: Forward
Port 2 lookup-miss multicast Action: Forward
Port 3 lookup-miss multicast Action: Forward
RTK.0>
SFU Product Page 169 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set ip-mcast-data action
Description:
This command can set per port IP multicast packets receiving
state. If user set this feature to drop, all ip multicast
received will be dropped.
Syntax:
l2-table set ip-mcast-data port <PORT_LIST:ports | all > action
<drop | forward>
Parameter:
ports – specify a port list
all - specify all ports
drop - drop packet
forward - forward packet
Examples:
This example shows how to configure the action of IP multicast
packets at port 0 to “drop”
RTK.0> l2-table set ip-mcast-data port 0 action drop
RTK.0>
SFU Product Page 170 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get ip-mcast-data action
Description:
This command can get per port IP multicast packets receiving
state.
Syntax:
l2-table get ip-mcast-data port <PORT_LIST:ports | all > action
Parameter:
ports – specify a port list
all - specify all ports
Examples:
This example shows how to get the action of IP multicast packets
at port 0-6
RTK.0> l2-table get ip-mcast-data port 0 action
Port 0 IPMC action: Drop
RTK.0>
SFU Product Page 171 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set port-move action
Description:
This command can configure source MAC address movement action.
Only when the action is configured to “forward”, the MAC address
will be moved to new source port.
Syntax:
l2-table set port-move action <copy-to-cpu | drop | forward |
trap-to-cpu>
Parameter:
drop - drop packet
trap-to-cpu - trap packet to cpu port
forward - forward packet
copy-to-cpu - copy packet to cpu port
Examples:
This example shows how to configure port-move action to “drop”.
RTK.0> l2-table set port-move port 0-6 action drop
RTK.0>
SFU Product Page 172 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get port-move action
Description:
This command can get source MAC address movement action.
Syntax:
l2-table get port-move action
Parameter:
None
Examples:
This example shows how to get port-move action
RTK.0> l2-table get port-move port 0-6
Port 0 Port move Action: Drop
Port 1 Port move Action: Drop
Port 2 Port move Action: Drop
Port 3 Port move Action: Drop
Port 4 Port move Action: Drop
Port 5 Port move Action: Drop
Port 6 Port move Action: Drop
RTK.0>
SFU Product Page 173 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set unknown-sa action
Description:
This command can set the action of unknown source MAC address.
Syntax:
l2-table set unknown-sa action <copy-to-cpu | drop | forward |
trap-to-cpu>
Parameter:
drop - drop packet
trap-to-cpu - trap packet to cpu port
forward - forward packet
copy-to-cpu - copy packet to cpu port
Examples:
This example shows how to configure the action of unknown source
MAC address to “trap to CPU”.
RTK.0> l2-table set unknown-sa port 0-6 action trap-to-cpu
RTK.0>
SFU Product Page 174 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get unknown-sa action
Description:
This command can get the action of unknown source MAC address.
Syntax:
l2-table get unknown-sa action
Parameter:
None
Examples:
This example shows how to get the action of unknown source MAC
address
RTK.0> l2-table get unknown-sa port 0-6 action
Port 0 unknown SA Action: Trap to CPU
Port 1 unknown SA Action: Trap to CPU
Port 2 unknown SA Action: Trap to CPU
Port 3 unknown SA Action: Trap to CPU
Port 4 unknown SA Action: Trap to CPU
Port 5 unknown SA Action: Trap to CPU
Port 6 unknown SA Action: Trap to CPU
RTK.0>
SFU Product Page 175 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set lookup-miss flood-ports
Description:
This command can configure the flooding portmask of lookup miss
packets.
Syntax:
l2-table set lookup-miss <broadcast | unicast | multicast>
flood-ports <PORT_LIST:ports | all | none>
Parameter:
broadcast - broadcast
unicast - unicast
multicast - multicast
ports - specified port list
all – specify all ports
none - specify no port
Examples:
This example shows how to configure the flooding portmask of
broadcast / unknown unicast / unknown multicast packets:
Broadcast: flood to all ports
Unknown unicast: flood to port 1
Unknown multicast: flood to port 0-2
RTK.0> l2-table set lookup-miss broadcast flood-ports 0-6
RTK.0> l2-table set lookup-miss unicast flood-ports 1
RTK.0> l2-table set lookup-miss multicast flood-ports 0-2
RTK.0>
SFU Product Page 176 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get lookup-miss flood-ports
Description:
This command can get the flooding portmask of lookup miss
packets.
Syntax:
l2-table get lookup-miss <broadcast | unicast | multicast>
Parameter:
broadcast - broadcast
unicast - unicast
multicast - multicast
Examples:
This example shows how to get the flooding portmask of broadcast
/ unknown unicast / unknown multicast packets:
RTK.0> l2-table get lookup-miss broadcast flood-ports
Lookup-miss Broadcast Lookup miss flood portmask: 0-6
RTK.0> l2-table get lookup-miss unicast flood-ports
Lookup-miss Unicast Lookup miss flood portmask: 1
RTK.0> l2-table get lookup-miss multicast flood-ports
Lookup-miss Multicast Lookup miss flood portmask: 0-2
RTK.0>
SFU Product Page 177 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set lookup-miss multicast trap-priority
Description:
This command can configure the priority for trapped unknown
multicast packets.
Syntax:
l2-table set lookup-miss multicast trap-priority priority
Parameter:
priority - priority configuration
Examples:
This example shows how to configure the priority for trapped
unknown multicast packets as 2:
RTK.0> l2-table set lookup-miss multicast trap-priority 2
RTK.0>
SFU Product Page 178 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get lookup-miss multicast trap-priority
Description:
This command can get the priority for trapped unknown multicast
packets.
Syntax:
l2-table get lookup-miss multicast trap-priority
Parameter:
None
Examples:
This example shows how to get the priority for trapped unknown
multicast packets.
RTK.0> l2-table get lookup-miss multicast trap-priority
Lookup-miss multicast trap-priority: 2
RTK.0>
SFU Product Page 179 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table set lookup-miss multicast reserved-flooding
Description:
This command can configure the action of reserved unknown IP
multicast address packet. The reserved IP multicast is 224.0.0.0
~ 224.0.0.255 for IPv4 and FFXX::00XX for IPv6.
Syntax:
l2-table set lookup-miss multicast reserved-flooding <disable
| enable>
Parameter:
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to configure the action of unknown
reserved IP multicast packets to “flood”.
RTK.0> l2-table set lookup-miss multicast reserved-flooding
enable
RTK.0>
SFU Product Page 180 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
l2-table get lookup-miss reserved-flooding
Description:
This command can get the action of reserved unknown IP multicast
address packet.
Syntax:
l2-table get lookup-miss reserved-flooding
Parameter:
None
Examples:
This example shows how to get the action of unknown reserved IP
multicast packets
RTK.0> l2-table get lookup-miss multicast reserved-flooding
Unknown reserved IP multicast Flooding: Enable
RTK.0>
SFU Product Page 181 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.5. trap commands
trap init
Description:
This command can initialize trap related functions.
Syntax:
trap init
Parameter:
None
Examples:
This example shows how to initial trap reltated functions.
RTK.0> trap init
RTK.0>
SFU Product Page 182 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trap set cdp
Description:
This command can configure the action of CDP packets
Syntax:
trap set cdp action <drop | forward | forward-exclude-cpu |
trap-to-cpu>
Parameter:
drop - drop packet
trap-to-cpu - trap packet to cpu port
forward - forward packet
forward-exclude-c
pu
- forward packet exclude to cpu port
Examples:
This example shows how to configure the action of CDP packet to
“Drop”
RTK.0> trap set cdp action drop
RTK.0>
SFU Product Page 183 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trap get cdp
Description:
This command can get the action of CDP packets
Syntax:
trap get cdp action
Parameter:
None
Examples:
This example shows how to get the action of CDP packets
RTK.0> trap get cdp action
CDP Drop
RTK.0>
SFU Product Page 184 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trap set csstp
Description:
This command can configure the action CSSTP packets
Syntax:
trap set csstp action <drop | forward | forward-exclude-cpu |
trap-to-cpu>
Parameter:
drop - drop packet
trap-to-cpu - trap packet to cpu port
forward - forward packet
forward-exclude-c
pu
- forward packet exclude to cpu port
Examples:
This example shows how to configure the action of CSSTP packet
to Drop.
RTK.0> trap set csstp action drop
RTK.0>
SFU Product Page 185 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trap get csstp
Description:
Thie command can get the action of CSSTP packets
Syntax:
trap get csstp action
Parameter:
None
Examples:
This example shows how to get the action of CSSTP packet
RTK.0> trap get csstp action
CSSTP Drop
RTK.0>
SFU Product Page 186 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.6. rma commands
rma set action
Description:
This command can configure the action of RMA (Reserved Multicast
Address) packets. Make sure that ‘trap init’ command is executed
before.
Syntax:
rma set address rma_tail action <drop | forward |
forward-exclude-cpu | trap-to-cpu>
Parameter:
rma_tail - last byte of 01:80:C2:00:00:xx address
drop - drop packet
trap-to-cpu - trap packet to cpu port
forward - forward packet
forward-exclude-c
pu
- forward packet exclude to cpu port
Examples:
This example shows how to configure the action of MAC_DA =
01:80:C2:00:00:01 to “trap to CPU”.
RTK.0> rma set address 01 action trap-to-cpu
RTK.0>
SFU Product Page 187 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rma get action
Description:
This command can get the action of RMA (Reserved Multicast
Address) packets. Make sure that ‘trap init’ command is executed
before.
Syntax:
rma get address rma_tail action
Parameter:
rma_tail - last byte of 01:80:C2:00:00:xx address
Examples:
This example shows how to get the action of MAC_DA =
01:80:C2:00:00:01 packets.
RTK.0> rma get address 01 action
RMA 01-80-C2-00-00-01 action: Trap to CPU
RTK.0>
SFU Product Page 188 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rma set priority
Description:
This command can configure the trapping priority when for RMA
(Reserved Multicast Address) packets. Make sure that ‘trap init’
command is executed before.
Syntax:
rma set priority priority
Parameter:
priority - priority configuration
Examples:
This example shows how to configure the trapping priority of RMA
packet to 4.
RTK.0> rma set priority 4
RTK.0>
SFU Product Page 189 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rma get priority
Description:
This command can get the trapping priority when for RMA (Reserved
Multicast Address) packets. Make sure that ‘trap init’ command
is executed before.
Syntax:
rma get priority
Parameter:
None
Examples:
This example shows how to get the trapping priority of RMA
packet.
RTK.0> rma get priority
The RMA trap priority = 4
RTK.0>
SFU Product Page 190 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rma dump
Description:
This command can get all supported RMA configurations. Make sure
that ‘trap init’ command is executed before.
Syntax:
rma dump
Parameter:
None
Examples:
This example shows how to get all RMA related configurations.
RTK.0> rma dump
RMA 01-80-C2-00-00-xx
trail action
00 Forward 01 Drop 02 Drop
03 Forward 04 Forward 05 Forward
06 Forward 07 Forward 08 Forward
09 Forward 0a Forward 0b Forward
0c Forward 0d Forward 0e Forward
0f Forward 10 Forward 11 Forward
12 Forward 13 Forward 14 Forward
15 Forward 16 Forward 17 Forward
18 Forward 19 Forward 1a Forward
1b Forward 1c Forward 1d Forward
1e Forward 1f Forward 20 Forward
21 Forward 22 Forward 23 Forward
24 Forward 25 Forward 26 Forward
27 Forward 28 Forward 29 Forward
2a Forward 2b Forward 2c Forward
2d Forward 2e Forward 2f Forward
RTK.0>
SFU Product Page 191 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.7. igmp commands
igmp set action
Description:
This command can configure action of IGMP/MLD packets. Make sure
that ‘trap init’ command is executed before.
Syntax:
igmp set <igmpv1 | igmpv2 | igmpv3 | mldv1 | mldv2> port
<PORT_LIST:ports | all> action <drop | forward | trap-to-cpu>
Parameter:
ports – specify a port list
all - specify all ports
igmpv1 - igmp version 1
igmpv2 - igmp version 2
igmpv3 - igmp version 3
mldv1 - mld version 1
mldv2 - mld version 2
drop - drop packet
forward - forward packet
trap-to-cpu - trap packet to cpu port
Examples:
This example shows how to set IGMP/MLD packet action at Port 0
to “Trap to CPU”.
RTK.0> igmp set igmpv1 port 0 action trap-to-cpu
RTK.0> igmp set igmpv2 port 0 action trap-to-cpu
RTK.0> igmp set igmpv3 port 0 action trap-to-cpu
RTK.0> igmp set mldv1 port 0 action trap-to-cpu
RTK.0> igmp set mldv2 port 0 action trap-to-cpu
RTK.0>
SFU Product Page 192 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp get action
Description:
This command can configure action of IGMP/MLD packets. Make sure
that ‘trap init’ command is executed before.
all
Port: 0, IGMPv2 : Trap to CPU
Syntax:
trap get <igmpv1 | igmpv2 | igmpv3 | mldv1 | mldv2> port
<PORT_LIST:ports | all> action
Parameter:
ports – specify a port list
- specify all ports
Examples:
This example shows how to get IGMPv2 packet action at Port 0.
RTK.0> igmp get igmpv2 port 0 action
RTK.0>
SFU Product Page 193 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp set igmp-mld checksum-error
Description:
This command can configure action of IGMP/MLD checksum error
packets. Make sure that ‘trap init’ command is executed before.
Syntax:
igmp set igmp-mld checksum-error action <drop | forward |
trap-to-cpu>
Parameter:
drop - drop packet
forward - forward packet
trap-to-cpu - trap packet to cpu port
Examples:
This example shows how to configure the action of IGMP/MLD
checksum error packet as drop.
RTK.0> igmp set igmp-mld checksum-error action drop
RTK.0>
SFU Product Page 194 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp get igmp-mld checksum-error
Description:
This command can get action of IGMP/MLD checksum error packets.
Make sure that ‘trap init’ command is executed before.
Syntax:
igmp get igmp-mld checksum-error action
Parameter:
None
Examples:
This example shows how to get the action of IGMP/MLD checksum
error packet
RTK.0> igmp get igmp-mld checksum-error action
IGMP/MLD Checksum error Action: Drop
RTK.0>
SFU Product Page 195 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp set igmp-mld isolation-leaky
Description:
This command can configure the state of IGMP/MLD isolation leaky
function. Make sure that ‘trap init’ command is executed before.
Syntax:
igmp set igmp-mld isolation-leaky state <disable | enable>
disable
enable
Examples:
RTK.0> igmp set igmp-mld isolation-leaky state enable
Parameter:
state - state configuration
- disable configuration
- enable configuration
This example shows how to configure the state of IGMP/MLD
isolation leaky function as enabled.
RTK.0>
SFU Product Page 196 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp get igmp-mld isolation-leaky
Description:
Syntax:
RTK.0>
This command can get the state of IGMP/MLD isolation leaky
function. Make sure that ‘trap init’ command is executed before.
igmp get igmp-mld isolation-leaky state
Parameter:
None
Examples:
This example shows how to get the state of IGMP/MLD isolation
leaky function.
RTK.0> igmp get igmp-mld isolation-leaky state
IGMP/MLD Isolation Leaky: Enable
SFU Product Page 197 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp set igmp-mld vlan-leaky
Description:
This command can configure the state of IGMP/MLD VLAN leaky
function. Make sure that ‘trap init’ command is executed before.
Syntax:
igmp set igmp-mld vlan-leaky state <disable | enable>
Parameter:
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to configure the state of IGMP/MLD VLAN
leaky function as enabled.
RTK.0> igmp set igmp-mld vlan-leaky state enable
RTK.0>
SFU Product Page 198 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp get igmp-mld vlan-leaky
Description:
This command can get the state of IGMP/MLD VLAN leaky function.
Make sure that ‘trap init’ command is executed before.
Syntax:
igmp get igmp-mld vlan-leaky state
Parameter:
None
Examples:
This example shows how to get the state of IGMP/MLD VLAN leaky
function.
RTK.0> igmp get igmp-mld vlan-leaky state
IGMP/MLD VLAN Leaky: Enable
RTK.0>
SFU Product Page 199 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp set ip-mcast-lookup-mode
Parameter:
- lookup hashing with dip and sip
Description:
This command can configure IP multicast lookup mode. Make sure
that ‘l2 init’ command is executed before.
Syntax:
igmp set ip-mcast-lookup-mode <dip-and-sip | dip-only>
dip-and-sip
dip-only - lookup hashing with dip only
Examples:
This example shows how to configure IP multicast lookup mode to
“DIP only”.
RTK.0> igmp set ip-mcast-lookup-mode dip-only
RTK.0>
SFU Product Page 200 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp get ip-mcast-lookup-mode
Description:
This command can get IP multicast lookup mode. Make sure that
‘l2 init’ command is executed before.
Syntax:
igmp get ip-mcast-lookup-mode
Parameter:
None
Examples:
This example shows how to get IP multicast lookup mode.
RTK.0> igmp get ip-mcast-lookup-mode
IPMC lookup mode: DIP only
RTK.0>
SFU Product Page 201 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp set ip-mcast-table
Parameter:
Description:
This command can set an entry into IP multicast table.
Syntax:
igmp set ip-mcast-table index index group-ip dip port
<PORT_LIST:ports | all | none>
index - entry index
dip - destination ip address
ports - specified port list
all – specify all ports
none - specify no port
Examples:
This example shows how to set an entry into index 0 of IP
multicast table.
Group IP: 224.1.2.3
Port: 0-6
RTK.0> igmp set ip-mcast-table index 0 group-ip 224.1.2.3 port
0-6
RTK.0>
SFU Product Page 202 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
igmp get ip-mcast-table
Description:
This command shows how to get an entry from IP multicast table.
Syntax:
igmp get ip-mcast-table index index
Parameter:
index - entry index
RTK.0> igmp get ip-mcast-table index 0
Examples:
This example shows how to get index 0 from IP multicast table.
Index : 0
DIP : 224.1.2.3
Portmask : 0-6
RTK.0>
SFU Product Page 203 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.8. Storm Control commands
storm-control set broadcast state
Description:
Syntax:
storm-control set unknown-multicast state <disable | enable>
storm-control set unknown-unicast state <disable | enable>
This example shows how to enable broadcast-storm,
multicast-storm, dscp-storm and arp-storm.
RTK.0> storm-control set dhcp-storm state enable
This command can enable the storm finction. System only supports
4 storm type enable at same time. Before configuration storm
control, user must enable the storm type first. Make sure that
‘rate init’ command is executed before.
storm-control set broadcast state <disable | enable>
storm-control set multicast state <disable | enable>
storm-control set arp-storm <disable | enable>
storm-control set dscp-storm state <disable | enable>
storm-control set igmp-mld-storm state <disable | enable>
Parameter:
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
System only supports 4 storm type enable at same time.
RTK.0> storm-control set broadcast state enable
RTK.0> storm-control set multicast state enable
RTK.0> storm-control set unknown-multicast state disable
RTK.0> storm-control set unknown-unicast state disable
RTK.0> storm-control set arp-storm state enable
RTK.0> storm-control set igmp-mld-storm state disable
RTK.0>
SFU Product Page 204 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set boradcast
Description:
This command can configure broadcast storm relative setting.
Make sure that ‘rate init’ command is executed before.
Syntax:
storm-control set broadcast state <disable | enable>
– specify a port list
RTK.0> storm-control set broadcast state enable
storm-control set broadcast port <PORT_LIST:ports | all> state
<disable | enable>
storm-control set broadcast port <PORT_LIST:ports | all> meter
index
Parameter:
ports
all - specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
meter - policing meter configuration
Examples:
This example shows how to configure broadcast storm enable at
port 0 and set the meter index as 0. The strom rate limit set
to 8kbps.
RTK.0> meter set entry 0 rate 8
RTK.0> storm-control set broadcast port 0 state enable
RTK.0> storm-control set broadcast port 0 meter 0
SFU Product Page 205 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get boradcast
storm-control get broadcast
all
3 Disable 0
RTK.0>
Description:
This command can get the broadcast storm relative setting. Make
sure that ‘rate init’ command is executed before.
Syntax:
storm-control get broadcast port <PORT_LIST:ports | all>
Parameter:
ports – specify a port list
- specify all ports
Examples:
This example shows how to get broadcast storm control function
setting.
RTK.0> storm-control get broadcast
State: Enable
RTK.0> storm-control get broadcast port 0-6
Port State Meter
0 Enable 0
1 Disable 0
2 Disable 0
4 Disable 0
5 Disable 0
6 Disable 0
SFU Product Page 206 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set multicast
Description:
This command can configure multicast storm relative setting.
Make sure that ‘rate init’ command is executed before.
Syntax:
- specify all ports
- state configuration
- enable configuration
storm-control set multicast state <disable | enable>
storm-control set multicast port <PORT_LIST:ports | all> state
<disable | enable>
storm-control set multicast port <PORT_LIST:ports | all> meter
index
Parameter:
ports – specify a port list
all
state
disable - disable configuration
enable
meter - policing meter configuration
Examples:
This example shows how to configure multicast storm enable at
port 0 and set the meter index as 0. The strom rate limit set
to 8 kbps.
RTK.0> meter set entry 0 rate 8
RTK.0> storm-control set multicast state enable
RTK.0> storm-control set multicast port 0 state enable
RTK.0> storm-control set multicast port 0 meter 0
SFU Product Page 207 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get multicast
storm-control get multicast
RTK.0> storm-control get multicast
3 Disable 0
6 Disable 0
Description:
This command can get the multicast storm relative setting. Make
sure that ‘rate init’ command is executed before.
Syntax:
storm-control get multicast port <PORT_LIST:ports | all>
Parameter:
ports – specify a port list
all - specify all ports
Examples:
This example shows how to get multicast storm control function
setting.
State: Enable
RTK.0> storm-control get multicast port 0-6
Port State Meter
0 Enable 0
1 Disable 0
2 Disable 0
4 Disable 0
5 Disable 0
RTK.0>
SFU Product Page 208 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set unknown-multicast
Description:
This command can configure unknown-multicast storm relative
setting. Make sure that ‘rate init’ command is executed before.
Syntax:
storm-control set unknown-multicast state <disable | enable>
storm-control set unknown-multicast port <PORT_LIST:ports |
all> state <disable | enable>
storm-control set unknown-multicast port <PORT_LIST:ports |
all> meter index
Parameter:
ports – specify a port list
all - specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
meter - policing meter configuration
Examples:
This example shows how to configure unknown-multicast storm
enable at port 0 and set the meter index as 0. The
unknown-multicast strom rate limit set to 8 kbps.
RTK.0> meter set entry 0 rate 8
RTK.0> storm-control set unknown-multicast state enable
RTK.0> storm-control set unknown-multicast port 0 state enable
RTK.0> storm-control set unknown-multicast port 0 meter 0
SFU Product Page 209 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get unknown-multicast
Description:
This command can get the unknown-multicast storm relative
setting. Make sure that ‘rate init’ command is executed before.
Syntax:
storm-control get unknown-multicast
storm-control get unknown-multicast port <PORT_LIST:ports |
all>
Parameter:
all
0 Enable 0
3 Disable 0
RTK.0>
ports – specify a port list
- specify all ports
alternated - alternated function
Examples:
This example shows how to get unknown-multicast storm control
function setting.
RTK.0> storm-control get unknown-multicast
State: Enable
RTK.0> storm-control get unknown-multicast port 0-6
Port State Meter
1 Disable 0
2 Disable 0
4 Disable 0
5 Disable 0
6 Disable 0
SFU Product Page 210 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set unknown-unicast
Description:
This command can configure unknown-unicast storm relative
setting. Make sure that ‘rate init’ command is executed before.
Syntax:
all
- state configuration
RTK.0> meter set entry 0 rate 8
storm-control set unknown-unicast state <disable | enable>
storm-control set unknown-unicast port <PORT_LIST:ports | all>
state <disable | enable>
storm-control set unknown-unicast port <PORT_LIST:ports | all>
meter index
Parameter:
ports – specify a port list
- specify all ports
state
disable - disable configuration
enable - enable configuration
meter - policing meter configuration
Examples:
This example shows how to configure unknown-unicast storm enable
at port 0 and set the meter index as 0. The unknown-unicast strom
rate limit set to 8 kbps.
RTK.0> storm-control set unknown-unicast state enable
RTK.0> storm-control set unknown-unicast port 0 state enable
RTK.0> storm-control set unknown-unicast port 0 meter 0
SFU Product Page 211 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get unknown-unicast
Description:
This command can get the unknown-unicast storm relative setting.
Make sure that ‘rate init’ command is executed before.
Syntax:
storm-control get unknown-unicast
storm-control get unknown-unicast port <PORT_LIST:ports | all>
Parameter:
ports – specify a port list
all - specify all ports
alternated - alternated function
Examples:
This example shows how to get unknown-unicast storm control
function setting.
RTK.0> storm-control get unknown-unicast
State: Enable
RTK.0> storm-control get unknown-unicast port 0-6
1 Disable 0
2 Disable 0
5 Disable 0
Port State Meter
0 Enable 0
3 Disable 0
4 Disable 0
6 Disable 0
RTK.0>
SFU Product Page 212 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set arp-storm
Description:
This command can configure arp storm relative setting. Make sure
that ‘rate init’ command is executed before.
Syntax:
storm-control set arp-storm state <disable | enable>
storm-control set arp-storm port <PORT_LIST:ports | all > state
<disable | enable>
storm-control set arp-storm port <PORT_LIST:ports | all > meter
index
Parameter:
ports – specify a port list
all - specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
meter - policing meter configuration
Examples:
This example shows how to configure arp-storm enable at port 0
and set the meter index as 0. The arp-storm rate limit set to
8 kbps.
RTK.0> storm-control set arp-storm port 0 state enable
RTK.0> meter set entry 0 rate 8
RTK.0> storm-control set arp-storm state enable
RTK.0> storm-control set arp-storm port 0 meter 0
SFU Product Page 213 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get arp-storm
Description:
This command can get the arp storm relative setting. Make sure
that ‘rate init’ command is executed before.
Syntax:
storm-control get arp-storm
storm-control get arp-storm port <PORT_LIST:ports | all>
– specify a port list
This example shows how to get arp-storm control function
setting.
RTK.0> storm-control get arp-storm port 0-6
2 Disable 0
Parameter:
ports
all - specify all ports
Examples:
RTK.0> storm-control get arp-storm
State: Enable
Port State Meter
0 Enable 0
1 Disable 0
3 Disable 0
4 Disable 0
5 Disable 0
6 Disable 0
RTK.0>
SFU Product Page 214 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set dhcp-storm
Description:
This command can configure dhcp storm relative setting. Make
sure that ‘rate init’ command is executed before.
Syntax:
storm-control set dhcp-storm state <disable | enable>
storm-control set dhcp-storm port <PORT_LIST:ports | all> state
<disable | enable>
storm-control set dhcp-storm port <PORT_LIST:ports | all> meter
index
Parameter:
state
- disable configuration
- enable configuration
Examples:
ports – specify a port list
all - specify all ports
- state configuration
disable
enable
meter - policing meter configuration
This example shows how to configure dhcp-storm enable at port
0 and set the meter index as 0. The dhcp-storm rate limit set
to 8 kbps.
RTK.0> meter set entry 0 rate 8
RTK.0> storm-control set dhcp-storm state enable
RTK.0> storm-control set dhcp-storm port 0 state enable
RTK.0> storm-control set dhcp-storm port 0 meter 0
SFU Product Page 215 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get dhcp-storm
storm-control get dhcp-storm port <PORT_LIST:ports | all
ports
all
Description:
This command can get the dhcp storm relative setting. Make sure
that ‘rate init’ command is executed before.
Syntax:
storm-control get dhcp-storm
Parameter:
– specify a port list
- specify all ports
Examples:
This example shows how to get dhcp-storm control function
setting.
RTK.0> storm-control get dhcp-storm
State: Enable
RTK.0> storm-control get dhcp-storm port 0-6
Port State Meter
0 Enable 0
1 Disable 0
2 Disable 0
3 Disable 0
4 Disable 0
5 Disable 0
6 Disable 0
RTK.0>
SFU Product Page 216 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set igmp-mld-storm
Description:
RTK.0> storm-control set igmp-mld-storm state enable
This command can configure igmp-mld storm relative setting. Make
sure that ‘rate init’ command is executed before.
Syntax:
storm-control set igmp-mld-storm state <disable | enable>
storm-control set igmp-mld-storm port <PORT_LIST:ports | all >
state <disable | enable>
storm-control set igmp-mld-storm port <PORT_LIST:ports | all >
meter index
Parameter:
ports – specify a port list
all - specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
meter - policing meter configuration
Examples:
This example shows how to configure igmp-mld-storm enable at
port 0 and set the meter index as 0. The igmp-mld-storm rate limit
set to 8 kbps.
RTK.0> meter set entry 0 rate 8
RTK.0> storm-control set igmp-mld-storm port 0 state enable
RTK.0> storm-control set igmp-mld-storm port 0 meter 0
SFU Product Page 217 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get igmp-mld-storm
Description:
This command can get the igmp-mld storm relative setting. Make
sure that ‘rate init’ command is executed before.
storm-control get igmp-mld-storm port <PORT_LIST:ports |
all
ports
3 Disable 0
6 Disable 0
Syntax:
storm-control get igmp-mld-storm
Parameter:
– specify a port list
all - specify all ports
Examples:
This example shows how to get igmp-mld-storm control function
setting.
RTK.0> storm-control get igmp-mld-storm
State: Enable
RTK.0> storm-control get igmp-mld-storm port 0-6
Port State Meter
0 Enable 0
1 Disable 0
2 Disable 0
4 Disable 0
5 Disable 0
RTK.0>
SFU Product Page 218 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control set bypass-packet
Description:
This command can set the bypass strom packet type. Make sure that
‘rate init’ command is executed before.
Syntax:
storm-control set bypass-packet <igmp | cdp | csstp> state
<disable | enable>
storm-control set bypass-packet rma rma_tail state <disable |
enable>
- state configuration
- igmp protocol
rma_tail
Parameter:
state
disable - disable configuration
enable - enable configuration
igmp
cdp - cisco discovery protocol
csstp - cisco shared spanning tree protocol
- last byte of 01:80:C2:00:00:xx address
Examples:
This example shows how to bypass cisco discovery protocol packet,
cisco shared spanning tree protocol and BPDU packet.
RTK.0> storm-control set bypass-packet cdp state enable
RTK.0> storm-control set bypass-packet csstp state enable
RTK.0> storm-control set bypass-packet rma 0x00 state enable
SFU Product Page 219 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
storm-control get bypass-packet
Description:
storm-control get bypass-packet <igmp | cdp | csstp> state
Parameter:
CDP bypass state: Enable
RTK.0> storm-control get bypass-packet csstp state
RTK.0> storm-control get bypass-packet rma 0x0 state
Get storm bypass-packet setting. Make sure that ‘rate init’
command is executed before.
Syntax:
storm-control get bypass-packet rma rma_tail state
state - state configuration
igmp - igmp protocol
cdp - cisco discovery protocol
csstp - cisco shared spanning tree protocol
rma_tail - last byte of 01:80:C2:00:00:xx address
Examples:
This example show how to get storm-control bypass packet
setting.
RTK.0> storm-control get bypass-packet cdp state
CSSTP bypass state: Enable
RTK.0> storm-control get bypass-packet igmp state
IGMP bypass state: Disable
RMA 01-80-C2-00-00-00 bypass Storm-Control state: Enable
RTK.0>
SFU Product Page 220 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.9. stp commands
stp init
Description:
This command can initialize spanning tree protocol (STP) related
functions.
Syntax:
stp init
Parameter:
None
Examples:
This example shows how to initial STP reltated functions.
RTK.0> stp init
RTK.0>
SFU Product Page 221 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
stp set state
Description:
Per port and per STP instance set STP port state.
ports
- disable state
- blocking state
- forwarding state
- learning state
Syntax:
stp set stp-table instance instance port <PORT_LIST:ports | all>
state <disable | blocking | forwarding | learning>
Parameter:
– specify a port list
all - specify all ports
state - state configuration
disable
blocking
forwarding
learning
Examples:
This command shows how to set STP port state to “blocking” for
port 2 STP instance 0.
RTK.0> stp set stp-table instance 0 port 2 state blocking
SFU Product Page 222 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
stp get state
Description:
Get STP port state
Syntax:
stp get stp-table instance instance port <PORT_LIST:ports | all>
state
- state configuration
Examples:
RTK.0> stp get stp-table instance 0 port 2 state
Parameter:
Ports – specify a port list
All - specify all ports
State
This command shows how to get STP port state for port 2 STP
instance 0.
MSTI 0 Status:
Port 2: BLOCKING
SFU Product Page 223 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
This example shows how to reset and initialize mirror module.
2.10. Mirror commands
mirror init
Description:
This command can reset & initialize Mirror module.
Syntax:
mirror init
Parameter:
None
Examples:
RTK.0> mirror init
RTK.0>
SFU Product Page 224 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mirror set mirroring
Description:
This command can configure the mirror function.
Syntax:
mirror set mirroring-port port mirrored-port port
<PORT_LIST:ports | none> [rx-mirror] [tx-mirror]
Parameter:
mirroring-port - specify the mirroring port
mirrored-port - specify the mirrored port
ports - specified port list
none - specify no port
rx-mirror
tx-mirror
- mirror rx packets
- mirror rX packets
Examples:
This example shows how to mirror both TX & RX packets from port
0 to Port 1.
RTK.0> mirror set mirroring-port 1 mirrored-port 0
RTK.0>
SFU Product Page 225 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mirror dump
Description:
This command can get the mirror function
Syntax:
mirror dump
Parameter:
None
Examples:
This example shows get current mirror configuration.
RTK.0> mirror dump
Monitor port: 1
Mirroring TX portmask: none
Mirroring RX portmask: none
Mirror Egress Mode: All packets
RTK.0>
SFU Product Page 226 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mirror set egress-mode
Description:
This command can configure egress-mode of mirror function
mirror set egress-mode <all-pkt | mirrored-only>
Syntax:
Parameter:
all-pkt - all packets
mirrored-only - mirrored packets
Examples:
This example shows how to set the egress-mode to
“mirrored-only”.
RTK.0> mirror set egress-mode mirrored-only
RTK.0>
SFU Product Page 227 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mirror get egress-mode
Description:
This command can get egress-mode of mirror function
Syntax:
mirror get egress-mode
Parameter:
None
Examples:
This example shows how to get the egress-mode.
RTK.0> mirror get egress-mode
Mirror Egress Mode: Mirrored packets only
RTK.0>
SFU Product Page 228 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.11. meter commands
meter init
Description:
This command can reset & initialize Meter module.
Syntax:
meter init
Parameter:
None
Examples:
This example shows how to initialize Meter module.
RTK.0> meter init
RTK.0>
SFU Product Page 229 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter set entry
Description:
These command sets can set meter relative parameter for each
meter entry.
The meter parameter would be:
- Burst size
- Packet rate
- Rate counting include IFG or not
Syntax:
meter set entry index burst-size size
meter set entry index rate rate
meter set entry index ifg <include | exclude>
rate
Parameter:
index - index of meter entry
burst-size - burst size configuration
- packet rate, unit kpbs
ifg - inter-frame gap configuration
include - include configuration
exclude - exclude configuration
Examples:
This example shows how to set the packet rate to 1024 kbps and
rate counting is including IFG for meter entry 0.
RTK.0> meter set entry 0 rate 1024
RTK.0> meter set entry 0 ifg include
RTK.0>
SFU Product Page 230 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter get entry
Description:
Get setting for each meter entry.
meter get entry index burst-size
- index of meter entry
- burst size configuration
- packet rate, unit kpbs
- inter-frame gap configuration
Examples:
Syntax:
meter get entry index
meter get entry index rate
meter get entry index ifg
Parameter:
index
burst-size
rate
ifg
This example shows how get meter setting for meter entry 0-4.
RTK.0> meter get entry 0-4
Meter idx = 0 , meter rate = 1024 , Kbps include IFG = Enable ,
burst size = 0
Meter idx = 1 , meter rate = 0 , Kbps include IFG = Disable ,
burst size = 0
Meter idx = 2 , meter rate = 0 , Kbps include IFG = Disable ,
burst size = 0
Meter idx = 3 , meter rate = 0 , Kbps include IFG = Disable ,
burst size = 0
Meter idx = 4 , meter rate = 0 , Kbps include IFG = Disable ,
burst size = 0
SFU Product Page 231 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter get meter-exceed
Description:
Chen the meter staus is exceed or not.
Syntax:
meter get entry index meter-exceed
Parameter:
index - index of meter entry
Examples:
This example shows how to get meter exceed status for meter
mentry 0-4.
RTK.0> meter get entry 0-4 meter-exceed
Meter idx = 0, meter exceed = No
Meter idx = 1, meter exceed = No
Meter idx = 2, meter exceed = No
Meter idx = 3, meter exceed = No
Meter idx = 4, meter exceed = No
SFU Product Page 232 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter reset meter-exceed
Description:
Reset meter exceed status.
Syntax:
meter reset entry index meter-exceed
Parameter:
index - index of meter entry
Examples:
This example shows how to clear meter exceed status for meter
entry 0.
RTK.0> meter reset entry 0 meter-exceed
RTK.0>
SFU Product Page 233 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter set tick-token
Description:
This command can set the tick-token for meter global
configuration.
Syntax:
meter set tick-token tick-period period token token
Parameter:
tick-period - timing tick, unit 1/system clock frequency
Token - toke size, unit byte
Examples:
This example shows how to set tick-period to 48 and token size
set to 66 byte.
RTK.0> meter set tick-token tick-period 48 token 66
RTK.0>
SFU Product Page 234 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter get tick-token
Description:
Get meter tick token setting.
Syntax:
meter get tick-token
Parameter:
None
Examples:
This example shows how get meter tick-token setting.
RTK.0>
RTK.0> meter get tick-token
tick period:48, token:66
SFU Product Page 235 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter set pon-tick-token
Description:
This command can set the tick-token setting for pon port.
meter set pon-tick-token tick-period period token token
tick-period
Token
Syntax:
Parameter:
- timing tick, unit 1/system clock frequency
- toke size, unit byte
Examples:
This example shows how to set tick-period to 48 and token size
set to 66 byte for pon port.
RTK.0> meter set pon-tick-token tick-period 48 token 66
RTK.0>
SFU Product Page 236 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
meter get pon-tick-token
Description:
This command can get the tick-token setting for pon port.
meter get pon-tick-token
None
Syntax:
Parameter:
Examples:
This example shows how to get meter tick-token setting for pon
port.
RTK.0> meter get pon-tick-token
tick period:48, token:66
RTK.0>
SFU Product Page 237 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.12. bandwidth commands
bandwidth init
Description:
This command can reset & initialize bandwidth control module.
Syntax:
bandwidth init
Parameter:
None
Examples:
This example shows how to initial bandwidth control related
functions.
RTK.0> bandwidth init
RTK.0>
SFU Product Page 238 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth set egress ifg
Description:
This command can configure egress bandwidth control, which is
included ifg calcuation or not.
RTK.0> bandwidth set egress ifg port 2-3 include
Syntax:
bandwidth set egress ifg <include | exclude>
bandwidth set egress ifg port <PORT_LIST:ports | all> <include
| exclude>
Parameter:
Include - include configuration
Exclude - exclude configuration
Ports - specified port list
All – specify all ports
Examples:
This example shows how to configure port 2 and port 3 egress
bandwidth control which is included ifg calculation.
RTK.0>
SFU Product Page 239 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth get egress ifg
Description:
This command can get configuration of egress bandwidth control,
which is included ifg calcuation or not.
Syntax:
bandwidth get egress ifg
bandwidth get egress ifg port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get port 1 egress bandwidth control
included ifg or not.
RTK.0> bandwidth get egress ifg port 1
port:1 Egress Rate counting ifg: exclude
RTK.0>
SFU Product Page 240 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth set egress port
Description:
This command can configure per port or per queue egress rate.
After configuring the egree queue APR rate, the configed rate
meter needs to configure by meter commands and different port
using different meter index range mapping to APR index. For 86900
chip, meter index and arp index mapping is as below.
Port Meter-Range
0,4 0~7
1,5 8~15
2 16~23
3 24~31
Syntax:
bandwidth set egress port <PORT_LIST:ports | all> rate rate
bandwidth set egress port <PORT_LIST:ports | all> qid qid
apr-index index
bandwidth set egress port <PORT_LIST:ports | all> qid qid
shared-bandwidth state <disable | enable>
ports
all
- state configuration
- enable configuration
arp-index
- average shared bandwidth configuration
Examples:
RTK.0> bandwidth set egress port 2 rate 100000
Parameter:
- specified port list
– specify all ports
state
disable - disable configuration
enable
rate - packet rate, unit kpbs
qid - specify the numeric queue identifier
- meter index for arp
shared-bandwidth
This example shows how to configure port 2 egress rate to 100Mbps
and egress queue 0/1 apr rate to related meter index 0/1.
RTK.0> bandwidth set egress port 2 queue-id 0 apr-index 0
RTK.0> bandwidth set egress port 2 queue-id 0 share-bandwidth
state enable
SFU Product Page 241 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> bandwidth set egress port 2 queue-id 1 apr-index 1
RTK.0> bandwidth set egress port 2 queue-id 1share-bandwidth
state enable
RTK.0> meter set entry 16 rate 10240
RTK.0> meter set entry 17 rate 10240
RTK.0>
SFU Product Page 242 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth get egress port
Description:
This command can get egress port rate and queue ARP index usage.
It needs to use meter commands for retrieving related ARP rate
of queue-id belong to desired egress port.
Syntax:
bandwidth get egress port <PORT_LIST:ports | all>
bandwidth get egress port <PORT_LIST:ports | all> qid
MASK_LIST:qid
- specified port list
queue: 1 apr-index: 0
Parameter:
ports
all – specify all ports
qid - specify the numeric queue identifier
Examples:
This example shows how to egress bandwidth control of egress port
1.
RTK.0> bandwidth get egress port 1
port: 1 rate:1048568
queue: 0 apr-index: 0
queue: 2 apr-index: 0
queue: 3 apr-index: 0
queue: 4 apr-index: 0
queue: 5 apr-index: 0
queue: 6 apr-index: 0
queue: 7 apr-index: 0
RTK.0> meter get entry 8
Meter idx = 8 , meter rate = 0 , Kbps include IFG = Disable ,
burst size = 0
RTK.0>
SFU Product Page 243 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth set ingress port
- packet rate, unit kpbs
Description:
This command can configure per port ingress rate.
Syntax:
bandwidth set ingress port <PORT_LIST:ports | all> rate rate
Parameter:
ports - specified port list
all – specify all ports
rate
Examples:
This example shows how to enable port 1 ingress rate with 10Mpbs
configuration.
RTK.0> bandwidth set ingress port 1 rate 10240
RTK.0>
SFU Product Page 244 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth get ingress port
port: 2 rate:1048568
Description:
This command can get per port ingress rate configuration.
Syntax:
bandwidth get ingress port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get port 0-3 ingress bandwidth rate.
RTK.0> bandwidth get ingress port 0-3 rate
port: 0 rate:1024
port: 1 rate:10240
port: 3 rate:1048568
RTK.0>
SFU Product Page 245 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth set ingress ifg
Description:
This command can configure ingress bandwidth control, which is
included ifg calcuation or not.
Syntax:
bandwidth set ingress ifg port <PORT_LIST:ports | all> <include
| exclude>
Parameter:
include - include configuration
exclude - exclude configuration
ports - specified port list
all – specify all ports
Examples:
This example shows how to configure port 2 and port 3 ingress
bandwidth control which is included ifg calculation.
RTK.0> bandwidth set ingress ifg port 2-3 include
RTK.0>
SFU Product Page 246 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth get ingress ifg
Syntax:
all
Examples:
port: 0 ifg: exclude
Description:
This command can get configuration of ingress bandwidth control,
which is included ifg calcuation or not.
bandwidth get ingress ifg port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
– specify all ports
This example shows how to get port 1 egress bandwidth control
included ifg or not.
RTK.0> bandwidth get ingress ifg port 0-3
port: 1 ifg: exclude
port: 2 ifg: include
port: 3 ifg: include
RTK.0>
SFU Product Page 247 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth set ingress bypass-packet
State
- disable configuration
- enable configuration
Examples:
RTK.0> bandwidth set ingress bypass-packet state enable
RTK.0>
Description:
This command can configure ingress rate control, which is
bypassed some kinds of packet or not. Differet chip supports
different kinds of packet to bypass ingress rate control.
Syntax:
bandwidth set ingress bypass-packet state <disable | enable>
Parameter:
- state configuration
Disable
Enable
This example shows how to enable bypassing RMA, IGMP/MLD control
packet and Realtek proprietary control frames for ingress
bandwidth contol.
SFU Product Page 248 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth get ingress bypass-packet
Description:
This command can get configuration of ingress rate control,
which is bypassed some kinds of packet or not.
Parameter:
byapss packet format:
-DMAC=01-80-C2-00-00-xx
-IGMP/MLD control packet
Syntax:
bandwidth get ingress bypass-packet state
State - state configuration
Examples:
This example shows how get packets bypass state for ingress
bandwidth control.
RTK.0> bandwidth get ingress bypass-packet state
Ingress Rate byapss:Enable
-8899 frames
RTK.0>
SFU Product Page 249 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth set ingress flow-control
Description:
This command can configure ingress bandwidth without UTP
flow-control ability.
Syntax:
Ports
– specify all ports
This example shows how to set port 1-2 to keep flow-control
ability while those ports are under rate control of ingress
bandwidth.
bandwidth set ingress flow-control port <PORT_LIST:ports | all>
state <disable | enable>
Parameter:
- specified port list
All
State - state configuration
Disable - disable configuration
Enable - enable configuration
Examples:
RTK.0> bandwidth set ingress flow-control port 1-2 state enable
RTK.0>
SFU Product Page 250 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
bandwidth get ingress flow-control
Syntax:
ports
all
state - state configuration
This example shows how to get flow-control ability of port 0-3
ingress rate control.
1 Enable
Description:
This command used to get ingress bandwidth with UTP flow-control
ability or not.
bandwidth get ingress flow-control port <PORT_LIST:ports | all>
state
Parameter:
- specified port list
– specify all ports
Examples:
RTK.0> bandwidth get ingress flow-control port 0-3 state
Port Flow-Control
0 Disable
2 Enable
3 Disable
RTK.0>
SFU Product Page 251 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib init
Examples:
This example shows how to initialize mib module.
2.13. mib commands
mib init
Description:
This command can initialize & reset mib module.
Syntax:
Parameter:
None
RTK.0> mib init
SFU Product Page 252 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib dump counter
Description:
This command can display current MIB counter information.
Syntax:
mib dump counter dot1dTpLearnedEntryDiscards
mib dump counter port <PORT_LIST:ports | all>
mib dump counter port <PORT_LIST:ports | all> <
dot1dTpPortInDiscards | dot3ControlInUnknownOpcodes |
dot3InPauseFrames | dot3OutPauseFrames |
dot3StatsDeferredTransmissions | dot3StatsExcessiveCollisions |
dot3StatsLateCollisions | dot3StatsMultipleCollisionFrames |
dot3StatsSingleCollisionFrames | dot3StatsSymbolErrors |
etherStatsCRCAlignErrors | etherStatsCollisions |
etherStatsDropEvents | etherStatsFragments | etherStatsJabbers |
etherStatsUndersizeDropPkts | etherStatsPkts64Octets |
etherStatsPkts65to127Octets | etherStatsPkts128to255Octets |
etherStatsPkts256to511Octets | etherStatsPkts512to1023Octets |
etherStatsPkts1024to1518Octets | etherStatsPkts1519toMaxOctets |
etherStatsOversizePkts | etherStatsUndersizePkts |
etherStatsTxBroadcastPkts | etherStatsTxMulticastPkts |
inOamPduPkts | outOamPduPkts | ifInOctets | ifInUcastPkts |
ifInMulticastPkts | ifInBroadcastPkts | ifOutOctets |
ifOutUcastPkts | ifOutMulticastPkts | ifOutBroadcastPkts |
ifOutDiscards>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to display dot1dTpLearnedEntryDiscards
counter information.
RTK.0> mib dump counter dot1dTpLearnedEntryDiscards
dot1dTpLearnedEntryDiscards: 0
This example shows how to display port 0 MIB counter information:
SFU Product Page 253 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> mib dump counter port 0
Port: 0
ifInOctets : 0
ifInUcastPkts : 0
ifInMulticastPkts : 0
ifInBroadcastPkts : 0
ifOutOctets : 0
ifOutBroadcastPkts : 0
ifOutDiscards : 0
ifOutUcastPkts : 0
ifOutMulticastPkts : 0
dot1dTpPortInDiscards : 0
dot3InPauseFrames : 0
dot3OutPauseFrames : 0
dot3StatsSingleCollisionFrames : 0
dot3StatsMultipleCollisionFrames : 0
dot3StatsDeferredTransmissions : 0
dot3StatsLateCollisions : 0
dot3StatsExcessiveCollisions : 0
dot3StatsSymbolErrors : 0
dot3ControlInUnknownOpcodes : 0
etherStatsDropEvents : 0
etherStatsFragments : 0
etherStatsJabbers : 0
etherStatsCollisions : 0
etherStatsCRCAlignErrors : 0
etherStatsTxUndersizePkts : 0
etherStatsTxOversizePkts : 0
etherStatsTxPkts64Octets : 0
etherStatsTxPkts65to127Octets : 0
etherStatsTxPkts128to255Octets : 0
etherStatsTxPkts256to511Octets : 0
etherStatsTxPkts512to1023Octets : 0
etherStatsTxPkts1024to1518Octets : 0
etherStatsTxPkts1519toMaxOctets : 0
etherStatsTxBroadcastPkts : 0
etherStatsTxMulticastPkts : 0
etherStatsRxUndersizePkts : 0
etherStatsRxUndersizeDropPkts : 0
SFU Product Page 254 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
etherStatsRxOversizePkts : 0
etherStatsRxPkts64Octets : 0
etherStatsRxPkts65to127Octets : 0
etherStatsRxPkts128to255Octets : 0
etherStatsRxPkts256to511Octets : 0
etherStatsRxPkts512to1023Octets : 0
etherStatsRxPkts1024to1518Octets : 0
etherStatsRxPkts1519toMaxOctets : 0
inOamPduPkts : 0
outOamPkdPkts : 0
SFU Product Page 255 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib reset counter
Description:
This command reset MIB counter on a chip.
Syntax:
mib reset counter global
mib reset counter port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to reset port 1 MIB counter.
RTK.0> mib reset counter port 1
RTK.0>
This example shows how to reset global MIB counter.
mib reset counter global
RTK.0>
SFU Product Page 256 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib dump statistic
Description:
This command get ACL statistic counter on a chip.
Syntax:
mib dump statistic index index
Parameter:
index - specified statistic counter index
Examples:
This example shows how to get ACL statistic counter on index 0.
RTK.0> mib dump statistic index 0
Index 0: 0
SFU Product Page 257 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib reset statistic
Description:
This command reset ACL statistic counter on a chip.
Syntax:
mib reset statistic index index
Parameter:
index - specified statistic counter index
Examples:
This example shows how to reset ACL statistic counter on index
0.
RTK.0> mib reset statistic index 0
RTK.0>
SFU Product Page 258 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib set statistic mode
Description:
This command set ACL statistic counter m(0,2,4,…30) mode on a
chip.
Syntax:
mib set statistic mode index index <bits-32 | bits-64>
Parameter:
index - specified statistic counter index
bits-32 - 32 bits counter mode
bits-64 - 64 bits counter mode
Examples:
This example shows how to set ACL statistic counter mode of index
0 to bit 32.
RTK.0> mib set statistic mode index 0 bits-32
RTK.0>
SFU Product Page 259 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get statistic mode
Description:
This command get ACL statistic counter m(0,2,4,…30) mode on a
chip.
Syntax:
mib get statistic mode index index
Parameter:
index - specified statistic counter index
Examples:
This example shows how to get ACL statistic counter mode on index
0.
RTK.0> mib get statistic mode index 0
0: 32-bits
SFU Product Page 260 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib set statistic type
Description:
This command set ACL statistic counter type(packet/byte) count
on a chip.
Syntax:
mib set statistic type index index <byte-count | packet-count>
Parameter:
index - specified statistic counter index
byte-count - byte counting type
packet-count - packet counting type
Examples:
This example shows how to set ACL statistic counter type to byte
count.
RTK.0> mib set statistic type index 0 byte-count
RTK.0>
SFU Product Page 261 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get statistic type
Description:
This command get ACL statistic counter type(packet/byte) count
on a chip.
Syntax:
mib get statistic type index index
Parameter:
index - specified statistic counter index
byte-count - byte counting type
packet-count - packet counting type
Examples:
This example shows how to get ACL statistic counter type on index
0.
RTK.0> mib get statistic type index 0
0: Byte count
SFU Product Page 262 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get packet-debug-reason
Description:
This command get per-port newest packet trap/drop reason and
code number on a chip.
Syntax:
mib get packet-debug-reason port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get port 0 newest packet trap/drop
reason.
RTK.0> mib get packet-debug-reason port 0
Port code Drop Trap Reason
0 0 normal
SFU Product Page 263 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib set sync-mode
Description:
This command set MIB data update mode (freerun/stop sync).
Syntax:
mib set syn-mode <freerun | stop>
Parameter:
freerun - free running configuration
stop - stopping configuration
Examples:
This example set MIB data update mode to freerun.
RTK.0> mib set sync-mode freerun
RTK.0>
SFU Product Page 264 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get sync-mode
Description:
This command get MIB data update mode(freerun/stop sync).
Syntax:
mib get syn-mode
Parameter:
None
Examples:
This example shows how to get MIB update mode.
RTK.0> mib get sync-mode
MIB sync mode: normal free run sync
SFU Product Page 265 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib set reset-value
Description:
This command set mib reset value.
Syntax:
mib set reset-value <0 | 1>
Parameter:
0 - reset to 0
1 - reset to 1
Examples:
This example shows how to set MIB reset value to 0.
RTK.0> mib set reset-value 0
RTK.0>
SFU Product Page 266 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get reset-value
Description:
This command get MIB reset value.
Syntax:
mib get reset-value
Parameter:
None
Examples:
This example shows how to get MIB reset value.
RTK.0> mib get reset-value
Reset MIB counter to: all 0
SFU Product Page 267 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib set ctag-length
Description:
This command can set RX/TX counters including or excluding C-tag
when calculating packet length.
Syntax:
mib set ctag-length <rx-counter | tx-counter> <include |
exclude>
Parameter:
rx-counter - receiving counter
tx-counter - transmitting counter
include - include configuration
exclude - exclude configuration
Examples:
This example shows how to set TX MIB counter to exclude C-tag
length.
RTK.0> mib set ctag-length tx-counter exclude
RTK.0>
SFU Product Page 268 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get ctag-length
Description:
This command can get RX/TX counters including or excluding C-tag
when calculating packet length.
Syntax:
mib get ctag-length <rx-counter | tx-counter>
Parameter:
rx-counter - receiving counter
tx-counter - transmitting counter
Examples:
This example shows how to get if packet length in TX MIB counter
include or exclude C-tag length.
RTK.0> mib get ctag-length tx-counter
tx-counter tag length: exclude
SFU Product Page 269 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib set count-mode
Description:
This command set MIB update mode.
Syntax:
mib set conut-mode freerun
mib set conut-mode by-timer latch-time timer
Parameter:
freerun - free running configuration
by-timer - running depond on timer setting
timer - time setting, unit second
Examples:
This example shows how to set MIB data update mode to latch time
to 10 seconds.
RTK.0> mib set count-mode by-timer latch-time 10
RTK.0>
SFU Product Page 270 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
mib get count-mode
Description:
This command get configuration of MIB update mode.
Syntax:
mib get conut-mode
Parameter:
None
Examples:
This example shows how to get MIB data update mode.
RTK.0> mib get count-mode
MIB count mode: control by MIB timer
Timer : 10
SFU Product Page 271 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.14. ACL commands
acl init
Description:
This command can initial acl module, set acl related config to
default, and clear acl entries. Only after executing this
command, other acl commands can be executed and will not return
FAILED.
Syntax:
acl init
Parameter:
None
Examples:
This example shows how to initial acl functions.
RTK.0> acl init
RTK.0> acl get port 0-6 state
Port State
0 Disable
1 Disable
2 Disable
3 Disable
4 Disable
5 Disable
6 Disable
RTK.0>
SFU Product Page 272 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl add entry
Description:
This command can add acl rule after rule contents are configured.
In SVLAN and VLAN action setting, some configurations need to
be making sure that related setting is done before adding rule.
Otherwise, the adding rule can not be set to hardware or there
will be unexpected behaviors.
Syntax:
acl add entry index
Parameter:
index - acl rule index
Examples:
This example shows how to add a acl rule to entry index 0 that
all ingress packets from port 1 will be assigned priority to 7.
RTK.0> acl clear
RTK.0> acl set rule template entry 0
RTK.0> acl set rule state valid
RTK.0> acl set rule port 1
RTK.0> acl set action priority assign-priority 7
RTK.0> acl add entry 0
RTK.0>
SFU Product Page 273 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl del entry
Description:
This command can delete acl rule entry by desired index or delete
all of rules. After rule entry being deleted, the content of
entry will be cleared to default.
Syntax:
acl del entry index
acl del entry all
Parameter:
index - acl rule index
all - all entries
Examples:
This example shows how to delete acl rule index 1.
RTK.0> acl del entry 1
RTK.0> acl get entry 1
Valid: Invalid
Not: Disable
Cvlan action: Ingress Vlan vid: 0
Svlan action: Ingress Vlan svid: 0
Forward: Copy Ports:
Policing: Policing meter: 0
Pri-Remark: ACL priority acl-pri: 0
Interrupt: Disable
Classification: None
ACL index latch: Disable
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[5] SMAC1
[6] SMAC2
[7] ETHERTYPE
Active Port: none
Tags: Mask:
SFU Product Page 274 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
field[0] data: 0x0000 mask: 0x0000
field[1] data: 0x0000 mask: 0x0000
field[2] data: 0x0000 mask: 0x0000
field[3] data: 0x0000 mask: 0x0000
field[4] data: 0x0000 mask: 0x0000
field[5] data: 0x0000 mask: 0x0000
field[6] data: 0x0000 mask: 0x0000
field[7] data: 0x0000 mask: 0x0000
RTK.0>
SFU Product Page 275 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get entry
Description:
Show acl rule contents and action
Syntax:
acl get entry index [action]
Parameter:
index - acl rule index
action - rule action data configuration
Examples:
This example shows how to get content and action of acl rule entry
0 and action contents only of entry 1.
RTK.0> acl get entry 0
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Redirect Ports: 2
Policing: Disable
Pri-Remark: Disable
Interrupt or Classification: Disable
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[5] SMAC1
[6] SMAC2
[7] ETHERTYPE
Active Port: 0-6
Tags: Mask:
field[0] data: 0x0000 mask: 0xF0F0
field[1] data: 0x0000 mask: 0xF0F0
field[2] data: 0x0000 mask: 0xF0F0
field[3] data: 0x0000 mask: 0x0000
field[4] data: 0x0000 mask: 0x0000
SFU Product Page 276 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
field[5] data: 0x0000 mask: 0x0000
field[6] data: 0x0000 mask: 0x0000
field[7] data: 0x0000 mask: 0x0000
RTK.0> acl get entry 1 action
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Disable
Policing: Policing meter: 1
Pri-Remark: ACL priority acl-pri: 7
Interrupt or Classification: Disable
RTK.0>
SFU Product Page 277 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl show
Description:
Show user configured acl contents and actions of rule be added
to entry.
acl show
None
RTK.0> acl clear
Syntax:
Parameter:
Examples:
This example shows how to show contents and actions of rule be
configed before adding to entry.
RTK.0> acl set rule template entry 0
RTK.0> acl set rule state valid
RTK.0> acl set rule port 0
RTK.0> acl set rule dmac data 0F:0F:0F:0F:0F:0F mask
F0:F0:F0:F0:F0:F0
RTK.0> acl set action priority assign-priority 7
RTK.0> acl show
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Disable
Policing: Disable
Pri-Remark: ACL priority acl-pri: 7
Interrupt or Classification: Disable
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[5] SMAC1
[6] SMAC2
[7] ETHERTYPE
SFU Product Page 278 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Active Port: 0
Tags: Mask:
dmac data: 0F:0F:0F:0F:0F:0F
mask: F0:F0:F0:F0:F0:F0
RTK.0>
SFU Product Page 279 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl clear
Description:
This command can clear contents of configured acl rule. It is
necessary to use this command before editing and adding new rule
to make sure action and rule contents are wanted.
Syntax:
acl clear
Parameter:
None
Examples:
This example shows how to clear pre-configured contents of acl
rule which need to add.
RTK.0> acl show action
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Redirect Ports: 1
Policing: Acl MIB counter: 1
Pri-Remark: ACL priority acl-pri: 7
Interrupt or Classification: Disable
RTK.0> acl clear
RTK.0> acl show action
Valid: Invalid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Disable
Policing: Disable
Pri-Remark: Disable
Interrupt or Classification: Disable
RTK.0>
SFU Product Page 280 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set rule
Description:
This command can edit wanted rule contents before being added
to device. Different chip version will support different
contents to be configured. The rule content is depended on which
template is used. So, configuring used template is more
important before setting rule.
Syntax:
acl set rule <dmac | smac> data mac [mask mac_mask]
acl set rule <sip | dip> data ip [mask ip_mask]
acl set rule <sip6 | dip6> data ip6 [mask ip6_mask]
acl set rule <ethertype | gemport-llid | next-header | ext> data
data [mask mask]
acl set rule <range-l4port | range-vid | range-ip |
range-length> care-range MASK_LIST:list
acl set rule ctag vid vid priority priority cfi cfi [mask
vid_mask vid_mask priority_mask priority_mask cfi_mask cfi_mask]
acl set rule stag vid vid priority priority dei dei [mask
vid_mask vid_mask priority_mask priority_mask dei_mask dei_mask]
acl set rule user-field index data data [mask mask]
acl set rule pattern field-index index data data [mask mask]
acl set rule field-valid care-field MASK_LIST:list [mask_field
MASK_LIST:mask]
acl set rule care-tags [ctag] [ip] [ipv6] [pppoe] [stag] [tcp]
[ucp]
acl set rule port <PORT_LIST: ports | all | none>
acl set rule template entry index
acl set rule operation reverse-state <disable | enable>
acl set rule state <valid | invalid>
Parameter:
data - rule matching data
mask - rule matching mask
dmac - destination mac address
smac - source mac address
dip - destination ipv4 address
sip - source ipv4 address
dip6 - destination ipv6 address
SFU Product Page 281 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
sip6 - source ipv6 address
ethertype - ethernet type or payload lengthlength
gemport-llid - gemport id or llid
next-header - ipv6 next header
range-l4port - layer4 port number range checking list
range-vid - vid range checking list
range-ip - ip range checking list
range-length - packet length range checking list
stag - stag rule matching
pattern
priority - priority configuration
vid – specify the numeric VLAN identifier
dei - dei field of stag
ctag - ctag rule matching
cfi - cfi field of ctag
user-field - user defined field
field-valid - user defined field valid list
ext - extention source ports
- rule raw data matching
field-index - rule field index
care-tags - packet types checking
port - rule actived port configuration
ports - specified port list
all – specify all ports
none - specify no port
template - rule matching template usage
state - rule valid state configuration
reverse-state - reverse configuration
Examples:
This example shows how to configure acl rule with specified
destination mac, source mac and source ip address for ingress
policing action.
RTK.0> acl clear
RTK.0> acl set rule template entry 0
RTK.0> acl set rule state valid
RTK.0> acl set rule port 0-6
RTK.0> acl set rule dmac data 01:80:C2:00:00:40
RTK.0> acl set rule smac data 00:01:02:03:04:05
SFU Product Page 282 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> acl set rule sip data 172.1.2.3
RTK.0> acl set action meter 3
RTK.0> acl show
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Disable
Policing: Policing meter: 3
Pri-Remark: Disable
Interrupt or Classification: Disable
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] SMAC0
[4] SMAC1
[5] SMAC2
[6] IP4SIP0
[7] IP4SIP1
Active Port: 0-6
Tags: Mask:
dmac data: 01:80:C2:00:00:40
mask: FF:FF:FF:FF:FF:FF
smac data: 00:01:02:03:04:05
mask: FF:FF:FF:FF:FF:FF
sip data: 172.1.2.3
mask: 255.255.255.255
RTK.0>
SFU Product Page 283 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl show rule
Description:
Show user configured acl contents of rule which will be added
to entry.
Syntax:
acl show rule
Parameter:
None
Examples:
[5] SMAC1
Active Port: 0
This example shows how to show contents of rule have been
configed before adding to entry.
RTK.0> acl clear
RTK.0> acl set rule template entry 0
RTK.0> acl set rule state valid
RTK.0> acl set rule port 0
RTK.0> acl set rule dmac data 0F:0F:0F:0F:0F:0F mask
F0:F0:F0:F0:F0:F0
RTK.0> acl show rule
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[6] SMAC2
[7] ETHERTYPE
Tags: Mask:
dmac data: 0F:0F:0F:0F:0F:0F
mask: F0:F0:F0:F0:F0:F0
RTK.0>
SFU Product Page 284 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl clear action
Description:
This command can clear configured actions of editing rule. It
should be execute before adding new configed rule. Otherwise,
unexpected behavior may happen.
Examples:
ACL index latch: Disable
Syntax:
acl clear action
Parameter:
None
This example shows how to clear configured actions of acl rule
before adding.
RTK.0> acl show
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Redirect Ports: 3
Policing: Policing meter: 31
Pri-Remark: ACL priority acl-pri: 7
Interrupt: Enable
Classification: None
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[5] SMAC1
[6] SMAC2
[7] ETHERTYPE
Active Port: none
Tags: Mask:
stag data: priority: 3 dei: 0 vid: 2000
mask: priority: 7 dei: 1 vid: 4095
SFU Product Page 285 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0>
RTK.0> acl clear action
RTK.0> acl show action
Valid: Valid
Not: Disable
Cvlan action: Disable
Svlan action: Disable
Forward: Disable
Policing: Disable
Pri-Remark: Disable
Interrupt or Classification: Disable
RTK.0>
SFU Product Page 286 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set action
Description:
This command can edit wanted actions of rule will be added to
device. Different chip version will support different actions
to be configed.
Syntax:
acl set action cvlan inress vid vid
acl set action cvlan egress vid vid
acl set action cvlan using-svid
acl set action cvlan meter index
acl set action cvlan statistic index
acl set action cvlan remarking dscp dscp
acl set action cvlan remarking dot1p priority
acl set action svlan inress svid svid
acl set action svlan egress svid svid
acl set action svlan using-cvid
acl set action svlan meter index
acl set action svlan statistic index
acl set action svlan remarking dscp dscp
acl set action svlan remarking dot1p priority
acl set action meter index
acl set action drop
acl set action interrrupt
acl set action classf sid sid
acl set action none
acl set action priority remarking dscp dscp
acl set action priority remarking dot1p priority
acl set action priority meter index
acl set action priority statistic index
acl set action statistic index
acl set action trap-to-cpu
acl set action copy port <PORT_LIST:ext | all | none>
acl set action redirect port <PORT_LIST:ext | all | none>
acl set action mirror port <PORT_LIST:ext | all>
acl set action latch-index
acl set action classf none
acl set action classf llid llid
acl set action classf ext-member <PORT_LIST:ext | all>
SFU Product Page 287 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Parameter:
cvlan
svlan
- assign vid depend on VLAN identifier
- interrupt action configuration
ext
RTK.0> acl clear
RTK.0> acl set rule state valid
- cvlan related action configuration
- svlan related action configuration
priority - priority related action configuration
ingress - ingress vlan assign
egress - egress vlan assign
using-cvid
using-svid - assign vid depend on SVLAN identifier
remarking - enable remarking
dot1p - dot1p configuration
dscp - dscp configuration
meter - policing meter configuration
statistic - statistic counter configuration
trap-to-cpu - trap packet to cpu port
copy - copy packet to assigned ports
redirect - redirect packet to assigned ports
mirror - mirror packet to assigned ports
interrupt
latch-index - latch hit rule index
classf - classification related action
none - nop
sid - stream id configuration
llid - llid configuration
- specify a extention port list
Examples:
This example shows how configure acl rule to redirect ingress
port 0 packets to port 1 with assigned priority 7.
RTK.0> acl set rule template entry 0
RTK.0> acl set rule port 0
RTK.0> acl set action redirect port 1
RTK.0> acl set action priority assign-priority 7
RTK.0> acl show
Valid: Valid
Not: Disable
SFU Product Page 288 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Cvlan action: Disable
Svlan action: Disable
Forward: Redirect Ports: 1
Policing: Disable
Pri-Remark: ACL priority acl-pri: 7
Interrupt or Classification: Disable
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[5] SMAC1
[6] SMAC2
[7] ETHERTYPE
Active Port: 0
Tags: Mask:
RTK.0>
SFU Product Page 289 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl show action
Description:
This command can show configured actions of editing rule.
Syntax:
acl show action
Parameter:
None
Valid: Valid
Svlan action: Disable
Pri-Remark: ACL priority acl-pri: 7
ACL index latch: Disable
Examples:
This example shows how to show configured actions of acl rule
before adding.
RTK.0> acl show action
Not: Disable
Cvlan action: Disable
Forward: Redirect Ports: 3
Policing: Policing meter: 31
Interrupt: Enable
Classification: None
RTK.0>
SFU Product Page 290 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl show template
Description:
This command can show configured content of editing template.
[4] SMAC1
RTK.0>
Syntax:
acl show template
Parameter:
None
Examples:
This example shows how the editing template is.
RTK.0> acl clear template
RTK.0> acl set template dmac
RTK.0> acl set template smac
RTK.0> acl set template sip
RTK.0> acl show template
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] SMAC0
[5] SMAC2
[6] IP4SIP0
[7] IP4SIP1
SFU Product Page 291 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl clear template
Description:
This command can clear configured content of editing template.
Syntax:
acl clear template
Parameter:
None
Examples:
RTK.0> acl show template
Template: 0 [0] DMAC0
[7] unknown
This example shows how to clear editing template
[1] DMAC1
[2] DMAC2
[3] IP4DIP0
[4] IP4DIP1
[5] STAG
[6] CTAG
[7] unknown
RTK.0> acl clear template
RTK.0> acl show template
Template: 0 [0] unknown
[1] unknown
[2] unknown
[3] unknown
[4] unknown
[5] unknown
[6] unknown
RTK.0>
SFU Product Page 292 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set template
Description:
This command can use to configure content of editing template.
Each template contains limited packet pattern bits for acl rule
matching. The ordering of editing template pattern bits is
depended on editing order.
Syntax:
acl set template user-field <stag | ctag | ethertype | gem-llid
| ipv6-next-header | dip | sip | smac | dmac | sip6 | dip6 | range-vid
| range-ip | range-length | range-l4port | field-valid | ext-pmask
| unknown>
acl set template user-field index
smac - source mac address
ethertype
- layer4 port number range checking list
range-ip
range-length
field-valid
Parameter:
dmac - destination mac address
dip - destination ipv4 address
sip - source ipv4 address
dip6 - destination ipv6 address
sip6 - source ipv6 address
- ethernet type or payload lengthlength
gemport-llid - gemport id or llid
next-header - ipv6 next header
range-l4port
range-vid - vid range checking list
- ip range checking list
- packet length range checking list
stag - stag rule matching
ctag - ctag rule matching
user-field - user defined field
- user defined field valid list
ext-pmask - extention port mask
unknown - unknown configuration
Examples:
This example shows how to configure acl template with dmac and
smac and IPv4 dip.
SFU Product Page 293 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> acl clear template
RTK.0> acl show template
[5] DMAC0
RTK.0> acl set template dip
RTK.0> acl set template smac
RTK.0> acl set template dmac
Template: 0 [0] IP4DIP0
[1] IP4DIP1
[2] SMAC0
[3] SMAC1
[4] SMAC2
[6] DMAC1
[7] DMAC2
RTK.0>
SFU Product Page 294 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl add template
Description:
This command can use to add configured template to device. The
template number is supportted by different devices.
Syntax:
Parameter:
This example shows how to add template with stag, ctag, dip, sip,
user-defined field 0 and 1 to template entry 2.
[4] IP4SIP0
RTK.0> acl get template entry 2
[5] IP4SIP1
acl add template entry index
index - specified entry index
Examples:
RTK.0> acl clear template
RTK.0> acl set template stag
RTK.0> acl set template ctag
RTK.0> acl set template dip
RTK.0> acl set template sip
RTK.0> acl set template user-field 0
RTK.0> acl set template user-field 1
RTK.0> acl show template
Template: 0 [0] STAG
[1] CTAG
[2] IP4DIP0
[3] IP4DIP1
[5] IP4SIP1
[6] Field_Sel0
[7] Field_Sel1
RTK.0> acl add template entry 2
Template: 2 [0] STAG
[1] CTAG
[2] IP4DIP0
[3] IP4DIP1
[4] IP4SIP0
SFU Product Page 295 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
[6] Field_Sel0
[7] Field_Sel1
RTK.0>
SFU Product Page 296 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get template
Description:
This command can be used to get templates which be configured
to device.
This example shows how to get template index 0 and 1.
[6] IP4DIP0
Syntax:
acl get template entry index
Parameter:
Index - specified entry index
Examples:
RTK.0> acl get template entry 0
Template: 0 [0] DMAC0
[1] DMAC1
[2] DMAC2
[3] STAG
[4] SMAC0
[5] SMAC1
[6] SMAC2
[7] ETHERTYPE
RTK.0> acl get template entry 1
Template: 1 [0] CTAG
[1] IP4SIP0
[2] IP4SIP1
[3] VIDRANGE
[4] IPRANGE
[5] PORTRANGE
[7] IP4DIP1
RTK.0>
SFU Product Page 297 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl del template
Description:
This command can be used to delete templates which be configured
to device. After deleting template, any packet will not hit acl
rules with deleted template entry index.
Syntax:
acl del template entry index
Parameter:
index - specified entry index
Examples:
This example shows how to delete template entry 2.
[2] unknown
[6] unknown
RTK.0> acl get template entry 2
Template: 2 [0] STAG
[1] CTAG
[2] IP4DIP0
[3] IP4DIP1
[4] IP4SIP0
[5] IP4SIP1
[6] Field_Sel0
[7] Field_Sel1
RTK.0> acl del template entry 2
RTK.0> acl get template entry 2
Template: 2 [0] unknown
[1] unknown
[3] unknown
[4] unknown
[5] unknown
[7] unknown
RTK.0>
SFU Product Page 298 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set range-vid
Description:
This command can configure vid, either svlan or cvlan, range
check entry. While acl rule was configed to match desired vid
range, valid entries will be compare with acl rule. If packets
are without vlan tagging, then vid and svid will be assign as
0 to compared all vid range checking entries. The entry setting
is be disabled while either state is configured to invalid or
low-bound/up-bound is set as 0/4095.
Syntax:
acl set range-vid entry index state <valid | invlaid>
acl set range-vid entry index type <svid | cvid>
acl set range-vid entry index <low-bound | up-bound> vid
Parameter:
type
- high bound range
RTK.0> acl set range-vid entry 0 state valid
RTK.0> acl set range-vid entry 1 state valid
index - specified entry index
state - valid state configuration
- vid range type
low-bound - low bound range
up-bound
vid – specify the numeric VLAN identifier
Examples:
This example shows how to configured cvlan vid range for vid 100
to 200 and svlan vid range for svid 1000 to 2000.
RTK.0> acl set range-vid entry 0 type cvid
RTK.0> acl set range-vid entry 0 low-bound 100
RTK.0> acl set range-vid entry 0 up-bound 200
RTK.0> acl set range-vid entry 1 type svid
RTK.0> acl set range-vid entry 1 low-bound 1000
RTK.0> acl set range-vid entry 1 up-bound 2000
SFU Product Page 299 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get range-vid
Description:
Show vid range checking entry contents.
Syntax:
acl get range-vid entry index
Parameter:
index - specified entry index
Examples:
This example shows configuration of vid range checking entry
index 1.
RTK.0> acl get range-vid entry 1
Range check of VID
Index: 1 Upper: 2000 Lower: 1000 Type: SVID
RTK.0>
SFU Product Page 300 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set range-ip
Description:
This command can configure IP address, either destination or
source, range check entry. While acl rule be configed to match
desired IP range, only valid entries will be compare with acl
rule. The entry setting is be disabled, while either state is
configed to invalid or low-bound/up-bound is set as 0.0.0.0/
255.255.255.255. Different device supports different address
bits checking for IPv6 IP range checking. At least IPv6 IP range
checking is supporting with LSB 32-bits.
Syntax:
acl set range-ip entry index state <valid | invlaid>
acl set range-ip entry index type <sip | dip | sip6 | dip6>
acl set range-ip entry index low-bound low_bound_ip up-bound
up_bound_ip
Parameter:
index - specified entry index
state - valid state configuration
type - ip range type
dip - destination ipv4 address
- source ipv4 address
sip
dip6 - destination ipv6 address
sip6 - source ipv6 address
low-bound - low bound range
up-bound - high bound range
Examples:
This example shows how to configure IP range checking entry 0
for IPv4 dip range within 172.1.1.1/16.
RTK.0> acl set range-ip entry 0 state valid
RTK.0> acl set range-ip entry 0 type dip
RTK.0> acl set range-ip entry 0 low-bound 172.1.1.1 up-bound
172.1.1.16
RTK.0> acl get range-ip entry 0
Range check of IP address
Index: 0 Upper: 172.1.1.16 Lower: 172.1.1.1 Type: IPv4 Dip
SFU Product Page 301 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0>
SFU Product Page 302 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get range-ip
Description:
Show IP range checking entry contents.
Syntax:
acl get range-ip entry index
Parameter:
index - specified entry index
RTK.0>
Examples:
This example shows configuration of IP range checking entry
index 1.
RTK.0> acl get range-ip entry 1
Range check of IP address
Index: 1 Upper: 192.168.1.255 Lower: 192.168.1.1 Type: Ipv4 Sip
SFU Product Page 303 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set range-l4port
Description:
This command can configure layer-4 tcp or udp port, either
destination or source, range check entry. While acl rule was
configed to match desired tcp or udp port range, only valid
entries will be compare with acl rule. The entry setting is be
disabled while either state is configured to invalid or
low-bound/up-bound is set as 0/65535.
Syntax:
acl set range-l4port entry index state <valid | invlaid>
acl set range-l4port entry index type <src-port | dst-port>
acl set range-l4port entry index <low-bound | up-bound> l4port
Parameter:
index
state
- source port number
- destination port number
Range check of L4 port
- specified entry index
- valid state configuration
type - ip range type
src-port
dst-port
low-bound - low bound range
up-bound - high bound range
l4port – specify the tcp/udp layer4 port number
Examples:
This example shows how to configure layer-4 port range checking
entry index 0 to tcp source port range checking from 1024~2000.
RTK.0> acl set range-l4port entry 0 type src-port
RTK.0> acl set range-l4port entry 0 low-bound 1024
RTK.0> acl set range-l4port entry 0 up-bound 2000
RTK.0> acl set range-l4port entry 0 state valid
RTK.0> acl get range-l4port entry 0
Index: 0 Upper: 2000 Lower: 1024 Type: Source Port
RTK.0>
SFU Product Page 304 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get range-l4port
Description:
Show layer-4 tcp/udp port range checking entry contents.
Parameter:
Range check of L4 port
Syntax:
acl get range-l4port entry index
index - specified entry index
Examples:
This example shows configuration of layer-4 tcp/udp port range
checking entry index 0-1.
RTK.0> acl get range-l4port entry 0
Index: 0 Upper: 2000 Lower: 1024 Type: Source Port
RTK.0> acl get range-l4port entry 1
Range check of L4 port
Index: 1 Upper: 1023 Lower: 0 Type: Destination Port
RTK.0>
SFU Product Page 305 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set range-length
Description:
This command can configure length-range checking entry of
ingress packet. While acl rule be configed to match packet length
range, only valid entries will be compare with acl rule. The
entry setting is be disabled while either state is configured
to invalid or low-bound/up-bound is set as 0/16383. If
reverse-state is set, it means packets which length is not within
low-bound and up-bound setting are matched configuration.
acl set range-length entry index <low-bound | up-bound> length
index
reverse-state
disable
enable
RTK.0> acl set range-length entry 0 reverse-state disable
Syntax:
acl set range-length entry index reverse-state <disable |
enable>
Parameter:
- specified entry index
- reverse configuration
- disable configuration
- enable configuration
low-bound - low bound range
up-bound - high bound range
length – specify length
Examples:
This example shows how to configure packet length range checking
entry index 0 to lenth 64~1518.
RTK.0> acl set range-length entry 0 low-bound 64
RTK.0> acl set range-length entry 0 up-bound 1518
RTK.0>
SFU Product Page 306 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get range-length
Description:
Show packet length range checking entry contents.
Syntax:
acl get range-length entry index
Parameter:
index - specified entry index
Examples:
This example shows configuration of packet length range checking
entry index 0 and index 1.
RTK.0> acl get range-length entry 0
Range check of packet length
Index: 0 Upper: 2000 Lower: 64 Type: Not Revise
RTK.0> acl get range-length entry 1
Range check of packet length
Index: 1 Upper: 1522 Lower: 68 Type: Not Revise
RTK.0>
SFU Product Page 307 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get reason
Description:
Shows acl hit rule entry for each action. Each action will be
executed by the first matched rule entry.
Syntax:
acl get reason <all | cvlan | svlan | priority | policing |
forward | extend>
Parameter:
- svlan related action hit rule index
- priority related action hit rule index
- priority related action hit rule index
Examples:
extend no 0
all - all actions hit rule index
cvlan - cvlan related action hit rule index
svlan
priority
policing
extend - extend related action hit rule index
This example shows how to get acl action hit rule entry number.
RTK.0> acl get reason all
Action Hit Index
cvlan yes 0
svlan no 0
priority no 0
policing no 0
forward no 0
RTK.0>
SFU Product Page 308 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set mode
Description:
This example shows how to configure acl mode to 128 rules.
This command can configure acl mode for different number of rules
usage.
Syntax:
acl set mode <64-entries | 128-entries>
Parameter:
64-entries - 64 rule entries usage
128-entries - 128 rule entries usage
Examples:
RTK.0> acl init
RTK.0> acl set mode 128-entries
RTK.0>
SFU Product Page 309 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get mode
Description:
Show acl number of rules usage.
Syntax:
acl get mode
Parameter:
None
Examples:
This example shows how to get valid number of acl rules.
RTK.0> acl init
RTK.0> acl get mode
ACL mode: 64 Entries
RTK.0>
SFU Product Page 310 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set state
Description:
This command can configure per-port acl enable state. If acl
ingress state is enabled, all packets from the acl enable port
will be matching acl rules and switch will follow the 1st matched
acl action to packets which hit configured acl rules.
Syntax:
ports
All
1 Disable
3 Enable
4 Enable
acl set port <PORT_LIST:ports | all> state <disable | enable>
Parameter:
- specified port list
– specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to configure acl state of ports from port
2 to port 4.
RTK.0> acl set port 2-4 state enable
RTK.0> acl get port 0-6 state
Port State
0 Disable
2 Enable
5 Disable
6 Disable
RTK.0>
SFU Product Page 311 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get state
Description:
Show per-port acl enable state.
Syntax:
acl get port <PORT_LIST:ports | all> state
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
Examples:
3 Enable
This example shows how to get acl state of port 1,3 and 5.
RTK.0> acl get port 1,3,5 state
Port State
1 Disable
5 Disable
RTK.0>
SFU Product Page 312 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl set permit
Description:
This command can configure switch action for packets which
unmatched ingress acl rules. If permit is not set, switch will
drop packets, which are unmatched any acl rule.
– specify all ports
- permit configuration
- disable configuration
- enable configuration
4 Disable
Syntax:
acl set port <PORT_LIST:ports | all> permit <disable | enable>
Parameter:
ports - specified port list
all
permit
disable
enable
Examples:
This example shows how to configure port 0-3 acl permit enable
setting.
RTK.0> acl set port 0-3 permit enable
RTK.0> acl get port 0-6 permit
Port State
0 Enable
1 Enable
2 Enable
3 Enable
5 Disable
6 Disable
RTK.0>
SFU Product Page 313 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
acl get permit
Description:
Show per port acl permit state.
Syntax:
Parameter:
acl get port <PORT_LIST:ports | all> permit
ports - specified port list
all – specify all ports
permit - permit configuration
Examples:
This example shows how to get the ports 1,3,5 acl permit state.
RTK.0> acl get port 1,3,5 permit
Port State
1 Enable
3 Enable
5 Disable
RTK.0>
SFU Product Page 314 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
field-selector set
ipv4-header
ipv6-header
offset
Examples:
RTK.0> field-selector set index 10 format ip-payload offset 10
Description:
This command can configure acl user defined field. Each field
can set 16-bits content of packet which user wants to filter for
acl uage. From pure raw packet to layer-4 content as tcp or udp,
the field can be set for parsing content of packet inside the
first 256 bytes.
Syntax:
field-selector set index index format <default | raw | llc | arp
| ipv4-header | ipv6-header | ip-payload | l4-payload> offset offset
Parameter:
index - specify index
format - parsing format
default - un-assigned format
raw - parsing as l2 raw packet
llc - parsing as llc packet
arp - parsing as arp packet
- parsing from ipv4 header
- parsing from ipv6 header
ip-payload - parsing from ipv4 payload
- specify parsing byte offset
This example show how to configure using acl to trap total length
field of ipv4 header which greate than 128 by setting field
selector 8 and udp ssdp “M-SEARCH” packets by setting field
selector 9/10/11/12.
RTK.0> field-selector set index 8 format ipv4-header offset 2
RTK.0> field-selector set index 9 format ip-payload offset 8
RTK.0> field-selector set index 11 format ip-payload offset 12
RTK.0> field-selector set index 12 format ip-payload offset 14
SFU Product Page 315 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
field-selector get
Description:
Show user defined field selector configuration.
Syntax:
field-selector get index index
Parameter:
index - specify index
Examples:
This example shows how to get field selectors 8-10.
RTK.0> field-selector get index 8
Index Offset Mode
8 2 IPv4 header
RTK.0> field-selector get index 9
Index Offset Mode
9 29 IP payload
RTK.0> field-selector get index 10
RTK.0>
Index Offset Mode
10 31 IP payload
SFU Product Page 316 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.15. PON Mac commands
pon init
Description:
Initial PON mac module. For PON port the queue management and
schedule must using PON command to configurate it.
Syntax:
pon init
Parameter:
None
Examples:
This example shows how to initialize pon module.
RTK.0> pon init
RTK.0>
SFU Product Page 317 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon set t-cont
Description:
The PON port queue management is based on T-CONT per tcont have
32 queues. If the PON port is used as UTP port, please use tcont
0 queue 0~7 to confgirate this port. This command set is buffer
mode, user muset call “pon add t-cont” to apply these seeting
to chip. For GPON mode please use “pon set t-cont” command
Syntax:
pon set t-cont t-cont queue-id queue-id <cir | pir> rate rate
pon set t-cont t-cont queue-id queue-id scheduling type
RTK.0> pon clear
< strict | wfq >
pon set t-cont t-cont queue-id queue-id egress-drop state
<disable | enable>
Parameter:
t-cont - GPON T-CONT id
queue-id - Queue id
cir - Committed Information Rate,
Pir - Peak Information rate
Rate - The PIR and CIR rate unit 64Kbps
Strict - The traffic schedule is based on strick
priority
Wfq - The traffic schedule is based on wfq
Enable - Enable per queue egress drop
Disable - Disable per queue egress drop
Examples:
This example shows how to set t-cont 0 queue 0~1 as follow
configurations.
Queue-id schedule-type PIR/CIR egress-drop-state
0 Strict 100/10 disable
1 WFQ 100/10 disable
RTK.0> pon set t-cont 0 queue-id 0 scheduling type strict
RTK.0> pon set t-cont 0 queue-id 0 pir rate 100
RTK.0> pon set t-cont 0 queue-id 0 cir rate 10
RTK.0> pon set t-cont 0 queue-id 0 egress-drop state disable
SFU Product Page 318 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> pon add t-cont 0 queue-id 0
RTK.0> pon clear
RTK.0> pon set t-cont 0 queue-id 1 scheduling type wfq
RTK.0> pon set t-cont 0 queue-id 1 pir rate 100
RTK.0> pon set t-cont 0 queue-id 1 cir rate 10
RTK.0> pon set t-cont 0 queue-id 1 egress-drop state disable
RTK.0> pon add t-cont 0 queue-id 1
SFU Product Page 319 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon get t-cont
Description:
This command can get queue setting. The “pon get t-cont
queue-list” can get which queue is scheduled by this t-cont.
Syntax:
pon get t-cont t-cont queue-id queue-id
pon get t-cont t-cont queue-list
Parameter:
t-cont - GPON T-CONT id
queue-id
queue-list
PIR:100
Egress Drop:Disable
RTK.0> pon get t-cont 0 queue-list
queue 2 :O
queue 5 :O
- Queue id
- Queue list for this t-cont
Examples:
This example shows how to get queue setting for t-cont 0 queue
0.
RTK.0> pon get t-cont 0 queue-id 0
CIR:10
queue Type:strict
WFQ weight:1
This example shows how to get which queue is scheduled by t-cont
0.
queue 0 :O
queue 1 :O
queue 3 :O
queue 4 :O
queue 6 :O
queue 7 :O
queue 8 :X
queue 9 :X
SFU Product Page 320 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
queue 10 :X
queue 11 :X
queue 12 :X
queue 13 :X
queue 14 :X
queue 15 :X
queue 16 :X
queue 17 :X
queue 21 :X
queue 18 :X
queue 19 :X
queue 20 :X
queue 22 :X
queue 23 :X
queue 24 :X
queue 25 :X
queue 26 :X
queue 27 :X
queue 28 :X
queue 29 :X
queue 30 :X
queue 31 :X
SFU Product Page 321 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon add t-cont
Description:
Use this command to apply pon queue setting to asic.
Syntax:
pon add t-cont t-cont queue-id queue-id
Parameter:
t-cont - GPON T-CONT id
queue-id - Queue id
Examples:
This example shows how to set t-cont 0 queue 0~1 as follow
configurations.
Queue-id schedule-type PIR/CIR egress-drop-state
0 Strict 100/10 disable
1 WFQ 100/10 disable
RTK.0> pon clear
RTK.0> pon set t-cont 0 queue-id 0 scheduling type strict
RTK.0> pon set t-cont 0 queue-id 0 pir rate 100
RTK.0> pon set t-cont 0 queue-id 0 cir rate 10
RTK.0> pon set t-cont 0 queue-id 0 egress-drop state disable
RTK.0> pon add t-cont 0 queue-id 0
RTK.0> pon clear
RTK.0> pon set t-cont 0 queue-id 1 scheduling type wfq
RTK.0> pon set t-cont 0 queue-id 1 pir rate 100
RTK.0> pon set t-cont 0 queue-id 1 cir rate 10
RTK.0> pon set t-cont 0 queue-id 1 egress-drop state disable
RTK.0> pon add t-cont 0 queue-id 1
SFU Product Page 322 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon del t-cont
Description:
Use this command to remove queue from given t-cont scheduler.
Syntax:
pon del t-cont t-cont queue-id queue-id
Parameter:
t-cont - GPON T-CONT id
queue-id - Queue id
Examples:
This example shows how to delete queue 0 from t-cont 0.
RTK.0> pon del t-cont 0 queue-id 0
SFU Product Page 323 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon set llid
Description:
The PON port queue management is based on LLID, per llid have
8 queues. If the PON port is used as UTP port, please use llid
0 queue 0~7 to confgirate this port. This command set is buffer
mode, user muset call “pon add llid” to apply these seeting to
chip. For EPON mode please use “pon set llid” command
pon set llid llid queue-id queue-id scheduling type
- EPON llid
- Queue id
- Committed Information Rate,
- Peak Information rate
- The PIR and CIR rate unit 64Kbps
- The traffic schedule is based on strick
priority
- The traffic schedule is based on wfq
- Enable per queue egress drop
- Disable per queue egress drop
Examples:
Syntax:
pon set llid llid queue-id queue-id <cir | pir> rate rate
< strict | wfq >
pon set llid llid queue-id queue-id egress-drop state <disable
| enable>
Parameter:
t-cont
queue-id
cir
Pir
Rate
Strict
Wfq
Enable
Disable
This example shows how to set llid 0 queue 0~1 as follow
configurations.
Queue-id schedule-type PIR/CIR egress-drop-state
0 Strict 100/10 disable
1 WFQ 100/10 disable
RTK.0> pon clear
RTK.0> pon set llid 0 queue-id 0 scheduling type strict
RTK.0> pon set llid 0 queue-id 0 pir rate 100
RTK.0> pon set llid 0 queue-id 0 cir rate 10
RTK.0> pon set llid 0 queue-id 0 egress-drop state disable
RTK.0> pon add llid 0 queue-id 0
SFU Product Page 324 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> pon set llid 0 queue-id 0 scheduling type strict
RTK.0> pon set llid 0 queue-id 0 pir rate 100
RTK.0> pon set llid 0 queue-id 0 cir rate 10
RTK.0> pon set llid 0 queue-id 0 egress-drop state disable
RTK.0> pon add llid 0 queue-id 0
RTK.0> pon clear
RTK.0> pon set llid 0 queue-id 1 scheduling type wfq
RTK.0> pon set llid 0 queue-id 1 pir rate 100
RTK.0> pon set llid 0 queue-id 1 cir rate 10
RTK.0> pon set llid 0 queue-id 1 egress-drop state disable
RTK.0> pon add llid 0 queue-id 1
SFU Product Page 325 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon get llid
Description:
This command can get queue setting. The “pon get llid queue-list”
can get which queue is scheduled by this llid.
WFQ weight:1
Syntax:
pon get llid llid queue-id queue-id
pon get llid llid queue-list
Parameter:
llid - EPON llid
queue-id - Queue id
queue-list - Queue list for this t-cont
Examples:
This example shows how to get queue setting for llid queue 0.
RTK.0> pon get llid 0 queue-id 0
CIR:10
PIR:100
queue Type:strict
Egress Drop:Disable
This example shows how to get which queue is scheduled by llid
0.
RTK.0> pon get llid 0 queue-list
queue 0 :O
queue 1 :O
queue 2 :O
queue 3 :O
queue 4 :O
queue 5 :O
queue 6 :O
queue 7 :O
queue 8 :X
queue 9 :X
queue 10 :X
SFU Product Page 326 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
queue 11 :X
queue 12 :X
queue 13 :X
queue 14 :X
queue 15 :X
queue 16 :X
queue 17 :X
queue 18 :X
queue 19 :X
queue 20 :X
queue 21 :X
queue 22 :X
queue 23 :X
queue 24 :X
queue 25 :X
queue 26 :X
queue 27 :X
queue 28 :X
queue 29 :X
queue 30 :X
queue 31 :X
SFU Product Page 327 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon add llid
Description:
Use this command to apply pon queue setting to asic.
Syntax:
Parameter:
queue-id
Queue-id schedule-type PIR/CIR egress-drop-state
RTK.0> pon set llid 0 queue-id 0 egress-drop state disable
RTK.0> pon set llid 0 queue-id 1 pir rate 100
RTK.0> pon add llid 0 queue-id 1
pon add llid llid queue-id queue-id
llid - EPON llid
- Queue id
Examples:
This example shows how to set llid 0 queue 0~1 as follow
configurations.
0 Strict 100/10 disable
1 WFQ 100/10 disable
RTK.0> pon clear
RTK.0> pon set llid 0 queue-id 0 scheduling type strict
RTK.0> pon set llid 0 queue-id 0 pir rate 100
RTK.0> pon set llid 0 queue-id 0 cir rate 10
RTK.0> pon add llid 0 queue-id 0
RTK.0> pon clear
RTK.0> pon set llid 0 queue-id 1 scheduling type wfq
RTK.0> pon set llid 0 queue-id 1 cir rate 10
RTK.0> pon set llid 0 queue-id 1 egress-drop state disable
SFU Product Page 328 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon del llid
Description:
Use this command to remove queue from given llid scheduler.
RTK.0> pon del llid 0 queue-id 0
Syntax:
pon del llid llid queue-id queue-id
Parameter:
llid -EPON llid
queue-id -Queue id
Examples:
This example shows how to delete queue 0 from LLID 0.
SFU Product Page 329 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon clear
0 Strict 100/10 disable
RTK.0> pon set llid 0 queue-id 1 pir rate 100
Description:
This command can clear contents of configured pon queue setting.
It is necessary to use this command before editing and adding
new queue to make sure the setting are wanted.
Syntax:
pon clear
Parameter:
none
Examples:
This example shows how to set llid 0 queue 0~1 as follow
configurations.
Queue-id schedule-type PIR/CIR egress-drop-state
1 WFQ 100/10 disable
RTK.0> pon clear
RTK.0> pon set llid 0 queue-id 0 scheduling type strict
RTK.0> pon set llid 0 queue-id 0 pir rate 100
RTK.0> pon set llid 0 queue-id 0 cir rate 10
RTK.0> pon set llid 0 queue-id 0 egress-drop state disable
RTK.0> pon add llid 0 queue-id 0
RTK.0> pon clear
RTK.0> pon set llid 0 queue-id 1 scheduling type wfq
RTK.0> pon set llid 0 queue-id 1 cir rate 10
RTK.0> pon set llid 0 queue-id 1 egress-drop state disable
RTK.0> pon add llid 0 queue-id 1
SFU Product Page 330 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
pon reset
Description:
This command can reset all pon mac setting to default as “pon
init” was called. All queue will be remove from all t-cont or
llid.
Syntax:
pon reset
Parameter:
None
Examples:
This example shows how to reset pon mac setting.
RTK.0> pon reset
SFU Product Page 331 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.16. Classfication commands
classf init
Description:
Classificatoin module initialization. It will delete all
classification entries.
Syntax:
classf init
Parameter:
None
Examples:
This example shows how to initialize classification module.
RTK.0> classf init
RTK.0>
SFU Product Page 332 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf clear
Description:
Clear classification edit buffer. The edit buffer is used to
store settings of classification rule and action, and will be
applied by “classf add entry” command.
Syntax:
classf clear
Parameter:
None
Examples:
This example shows how to clear classification edit buffer. It
must be used before a new classification entry is added.
RTK.0> classf clear
RTK.0>
SFU Product Page 333 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf show
Description:
Show the edit buffer of classification rule
Syntax:
classf show
Parameter:
None
Examples:
This example shows how to display edit buffer of classification
rule:
Rule:
Assign ID: 10
RTK.0> classf show
Not: Disable
direction: Upstream
tag vid data: 1000
mask: 0xfff
Upstream action:
Stag action: No operation
Ctag action: No operation
SID action: ASSIGN to SID
RTK.0>
SFU Product Page 334 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set rule
Syntax:
– specify the rule is applied to upstream or
downstream direction
tos-sid
- specify to outer tag vid field
- specify to outer tag priority field
- specify to internal priority field
- specify to stag exist field
ether-type - specify to Ethernet type field
wan-if - wan interface
- care field of ipv4 multicast packet
igmp-bit
- care field of mld packet
mask
Description:
Configure the edit buffer of classification rule
classf set rule direction <upstream | downstream>
classf set rule <tos-sid | tag-vid | tag-priority |
internal-priority | svlan-bit | cvlan-bit | uni | ether-type |
range-l4port | range-ip | hit-acl | wan-if | ipmc-bit | ip6mc-bit
| igmp-bit | mld-bit | dei-cfi> data data mask mask
Parameter:
direction
upstream – upstream configuration
downstream – downstream configuration
- for upstream rule, this field specify to
tos, for downstream rule this field specify
to steam id
tag-vid
tag-priority
internal-priority
svlan-bit
cvlan -bit - specify to ctag exist field
uni - specify to ingress uni for downstream and
specify to egress uni for upstream
range-l4port - layer4 port number range checking list
range-ip - ip range checking list
hit-acl - acl matched index
ipmc-bit
ip6mc-bit - care field of ipv6 multicast packe
- care field of igmp packet
mld-bit
dei-cfi - dei or cfi field of tag
data - the data value of each field
- the data mask of each field
SFU Product Page 335 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Examples:
This example shows how to edit a classification downstream rule
for variant fields.
RTK.0> classf set rule ether-type data 0x0800 mask 0xffff
RTK.0> classf set rule cvlan-bit data 1 mask 1
RTK.0> classf set rule tag-priority data 5 mask 7
Not: Disable
direction: Downstream
Rule:
Rule:
Rule:
tag vid data: 1000
mask: 0xfff
mask: 0x7
Stag action: No operation
UNI ports: none
RTK.0> classf clear
RTK.0> classf set rule direction downstream
RTK.0> classf set rule svlan-bit data 1 mask 1
RTK.0> classf set rule tag-vid data 1000 mask 0xfff
RTK.0> classf set rule uni data 1 mask 7
RTK.0> classf show
Rule:
ether type data: 0x0800
mask: 0xffff
s-bit data: 1
mask: 0x1
c-bit data: 1
mask: 0x1
Rule:
tag priority data: 5
Rule:
UNI data: 1
mask: 0x7
Downstream action:
Ctag action: No operation
Classf PRI action: Follow switch core
UNI action: No operation
SFU Product Page 336 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0>
SFU Product Page 337 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set downstream-action
Description:
Configure the edit buffer of classification downstream action
Syntax:
classf set downstream-action svlan-act <nop | vs-tpid | c-tpid
| del | transparent | sp2c>
classf set downstream-action cvlan-id-act assign vid
classf set downstream-action cvlan-id-act <follow-swcore |
copy-outer | copy-inner | lookup-table> [vid]
classf set downstream-action cvlan-priority-act assign
priority
classf set downstream-action remark-dscp <disable | enable>
svlan-act
- de-tagging vlan
– specify assigned value
classf set downstream-action svlan-id-act assign vid
classf set downstream-action svlan-id-act <copy-outer |
copy-inner> [vid]
classf set downstream-action svlan-priority-act assign
priority
classf set downstream-action svlan-priority-act <copy-outer |
copy-inner | internal-priority> [priority]
classf set downstream-action cvlan-act <nop | c-tag | sp2c | del
| transparent>
classf set downstream-action cvlan-priority-act <copy-outer |
copy-inner | internal-priority> [priority]
classf set downstream-action priority-act assign priority
classf set downstream-action priority-act follow-swcore
Parameter:
– specify the stag action
nop - no operation
vs-tpid - s-tagging with tpid in svlan configuration
c-tpid - s-tagging with 802.1Q tpid 0x8100
del
transparent - vlan transparent configuration
sp2c - specify from the sp2c table
svlan-id-act – specify the stag vid action
svlan-priority-ac
t
– specify the stag priority action
assign
SFU Product Page 338 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
copy-outer - specify from outer tag
copy-inner - specify from inner tag
vid – specify the numeric VLAN identifier
priority - priority configuration
internal-priority - spefify from switch internal priority
cvlan-id-act – specify the ctag vid action
cvlan-priority-ac
t
– specify the ctag priority action
ctag - c-tagging
priority-act - classification priority assign
follow-swcore - follow switch normal decision
lookup-table - specify from lookup table
remark-dscp - dscp remarking
uni-forward-act - egress forward configuration
flood - flooding within assigned ports
forced - forced forward to assigned ports
ports - specified port list
all - specify all ports
none - specify no port
Examples:
This example shows how to edit a classification downstream
action. Remove Stag. Assign Ctag with VID=100, priority=2.
Assign internal priority=5. And force forward to UNI 0.
RTK.0> classf clear
RTK.0> classf set rule direction downstream
RTK.0> classf set rule ether-type data 0x0800 mask 0xffff
RTK.0> classf set rule cvlan-bit data 1 mask 1
RTK.0> classf set rule svlan-bit data 1 mask 1
RTK.0> classf set rule tag-vid data 1000 mask 0xfff
RTK.0> classf set rule tag-priority data 5 mask 7
RTK.0> classf set rule uni data 1 mask 7
RTK.0> classf set downstream-action svlan-act del
RTK.0> classf set downstream-action cvlan-act c-tag
RTK.0> classf set downstream-action cvlan-id-act assign 100
RTK.0> classf set downstream-action cvlan-priority-act assign
2
RTK.0> classf set downstream-action priority-act assign 5
SFU Product Page 339 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> classf set downstream-action uni-forward-act forced port
0
RTK.0> classf show
Not: Disable
direction: Downstream
Rule:
ether type data: 0x0800
mask: 0xffff
Rule:
s-bit data: 1
mask: 0x1
Rule:
c-bit data: 1
mask: 0x1
Rule:
tag vid data: 1000
mask: 0xfff
Rule:
tag priority data: 5
mask: 0x7
Rule:
UNI data: 1
mask: 0x7
Downstream action:
Stag action: Delete
Ctag action: Tagging
Ctag VID action: Assign
Ctag VID: 100
Ctag PRI action: Assign
Ctag PRI: 2
Classf PRI action: Assign
CF PRI: 5
UNI action: Force forward
UNI ports: 0
RTK.0>
SFU Product Page 340 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set upstream-action
Description:
Configure the edit buffer of classification upstream action
Syntax:
classf set upstream-action svlan-act <nop | vs-tpid | c-tpid |
del | transparent>
classf set upstream-action svlan-id-act assign vid
classf set upstream-action svlan-id-act <copy-outer |
copy-inner> [vid]
classf set upstream-action svlan-priority-act assign priority
classf set upstream-action svlan-priority-act <copy-outer |
copy-inner | internal-priority> [priority]
classf set upstream-action cvlan-act <nop | c-tag | c2s | del
| transparent>
classf set upstream-action cvlan-id-act assign vid
classf set upstream-action cvlan-id-act <copy-outer |
copy-inner> [vid]
classf set upstream-action cvlan-priority -act assign priority
classf set upstream-action cvlan-priority-act <copy-outer |
copy-inner | internal-priority> [priority]
classf set upstream-action priority-act assign priority
classf set upstream-action priority-act follow-swcore
classf set upstream-action sid-act <sid | qid> id
classf set upstream-action sid-act nop
classf set upstream-action statistic index
classf set upstream-action remark-dscp <disable | enable>
classf set upstream-action drop <disable | enable>
Parameter:
svlan-act – specify the stag action
nop - no operation
vs-tpid - s-tagging with tpid in svlan configuration
c-tpid - s-tagging with 802.1Q tpid 0x8100
del - de-tagging vlan
transparent - vlan transparent configuration
svlan-id-act – specify the stag vid action
svlan-priority-ac
t
– specify the stag priority action
SFU Product Page 341 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
assign – specify assigned value
copy-outer - specify from outer tag
copy-inner - specify from inner tag
vid – specify the numeric VLAN identifier
priority - priority configuration
internal-priority - spefify from switch internal priority
cvlan-id-act – specify the ctag vid action
cvlan-priority-ac
t
– specify the ctag priority action
ctag - c-tagging
c2s - specify from the c2s table
priority-act - classification priority assign
follow-swcore - follow switch normal decision
sid-act – specify the stream id action
sid - stream id configuration
qid – specify the numeric queue identifier
statistic - statistic counter configuration
remark-dscp - dscp remarking
drop - drop packet
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to edit a classification upstream action.
Add Stag by VID 1000, priority copy from outer tag. Ctag
transparent. And assign stream-ID to 1.
RTK.0> classf clear
RTK.0> classf set rule direction upstream
RTK.0> classf set rule svlan-bit data 0 mask 1
RTK.0> classf set rule cvlan-bit data 1 mask 1
RTK.0> classf set rule tag-vid data 100 mask 0xfff
RTK.0> classf set upstream-action svlan-act vs-tpid
RTK.0> classf set upstream-action svlan-id-act assign 1000
RTK.0> classf set upstream-action svlan-priority-act
copy-outer
RTK.0> classf set upstream-action cvlan-act transparent
RTK.0> classf set upstream-action sid-act sid 1
RTK.0> classf show
SFU Product Page 342 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Not: Disable
direction: Upstream
Rule:
c-bit data: 0
mask: 0x1
Rule:
s-bit data: 1
mask: 0x1
Rule:
tag vid data: 100
mask: 0xfff
Upstream action:
Stag action: VS_TPID
Stag VID action: Assign
Stag VID: 1000
Stag PRI action: Copy from 1st tag
Stag PRI: 0
Ctag action: Transparent
SID action: ASSIGN to SID
Assign ID: 1
RTK.0>
SFU Product Page 343 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf add entry
Description:
Add the classification entry according to the edit buffer of rule
and upsteam/downstream action
Syntax:
classf add entry index
Parameter:
index – specify the entry index
Examples:
This example shows how to add a classification entry in detail.
Including edit buffer of rule and downstream action.
RTK.0> classf clear
RTK.0> classf set rule direction downstream
RTK.0> classf set rule ether-type data 0x0800 mask 0xffff
RTK.0> classf set rule cvlan-bit data 1 mask 1
RTK.0> classf set rule svlan-bit data 1 mask 1
RTK.0> classf set rule tag-vid data 1000 mask 0xfff
RTK.0> classf set rule tag-priority data 5 mask 7
RTK.0> classf set rule uni data 1 mask 7
RTK.0> classf set downstream-action svlan-act del
RTK.0> classf set downstream-action cvlan-act c-tag
RTK.0> classf set downstream-action cvlan-id-act assign 100
RTK.0> classf set downstream-action cvlan-priority-act assign
2
RTK.0> classf set downstream-action priority-act assign 5
RTK.0> classf set downstream-action uni-forward-act forced port
0
RTK.0> classf add entry 0
RTK.0>
RTK.0> classf get entry 0
Valid: Valid
Not: Disable
direction: Downstream
databit: 0x4519-801f-0800
carebit: 0xff1f-807f-ffff
SFU Product Page 344 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Downstream action:
Stag action: Delete
Ctag action: Tagging
Ctag VID action: Assign
Ctag VID: 100
Ctag PRI action: Assign
Ctag PRI: 2
Classf PRI action: Assign
CF PRI: 5
UNI action: Force forward
UNI ports: 0
RTK.0>
SFU Product Page 345 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get entry
Description:
Show the raw data of classification entry
Syntax:
classf get entry index
Parameter:
index – specify the entry index
Examples:
This example shows how to display classification entry:
RTK.0> classf get entry 0
Valid: Valid
Not: Disable
direction: Downstream
databit: 0x4519-801f-0800
carebit: 0xff1f-807f-ffff
Downstream action:
Stag action: Delete
Ctag action: Tagging
Ctag VID action: Assign
Ctag VID: 100
Ctag PRI action: Assign
Ctag PRI: 2
Classf PRI action: Assign
CF PRI: 5
UNI action: Force forward
UNI ports: 0
RTK.0>
SFU Product Page 346 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf del entry
Description:
Delete the classification entry
Syntax:
classf del entry index
classf del entry all
Parameter:
index – specify the entry index
all - all entries
Examples:
This example shows how to del a classification entry
RTK.0> classf del entry 0
SFU Product Page 347 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set operation
Description:
Configuration the operation mode as hit or not hit for upstream
or downstream rule
Syntax:
classf set operation entry index <upstream | downstream> < hit
| not >
Parameter:
index – specify the entry index
upstream – upstream configuration
downstream – downstream configuration
hit – hit operation
not – reverse operation
Examples:
This example shows how to configure a downstream classification
entry as hit operation
RTK.0> classf set operation entry 0 downstream hit
SFU Product Page 348 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get operation
Description:
Get the operation mode for upstream or downstream rule
Syntax:
classf get entry index
Parameter:
index – specify the entry index
Examples:
This example shows how to display a classification entry
operation
RTK.0> classf get entry 0
Valid: Valid
Not: Disable
direction: Downstream
databit: 0x4519-801f-0800
carebit: 0xff1f-807f-ffff
Downstream action:
Stag action: Delete
Ctag action: Tagging
Ctag VID action: Assign
Ctag VID: 100
Ctag PRI action: Assign
Ctag PRI: 2
Classf PRI action: Assign
CF PRI: 5
UNI action: Force forward
UNI ports: 0
SFU Product Page 349 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set cf-sel-port
Description:
Configuration PON port or RGMII port as the classification
uplink port
Syntax:
classf set cf-sel-port <pon | rg> <disable | enable>
Parameter:
pon – pon port configuration
rg - rg port configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to enable PON port as classification
uplink port
RTK.0> classf set cf-sel-port pon enable
SFU Product Page 350 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get cf-sel-port
Description:
Get the state of classification uplink port selection.
Syntax:
classf get cf-sel-port
Parameter:
None
Examples:
This example shows how to display a classification uplink port
selection
RTK.0> classf get cf-sel-port
Cf select port: PON enabled
Cf select port: RGMII disabled
SFU Product Page 351 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set upstream-unmatch-act
Description:
Configuration classification upstream unmatch action
Syntax:
classf set upstream-unmatch-act <drop | permit-without-pon |
permit>
Parameter:
drop – drop packet
permit – forward packet
permit-without-pon - forward packet exclude pon port
Examples:
This example shows how to configure upstream unmatch action as
drop
RTK.0> classf set upstream-unmatch-act drop
SFU Product Page 352 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get upstream-unmatch-act
Description:
Get the classification upstream unmatch action
Syntax:
classf get upstream-unmatch-act
Parameter:
None
Examples:
This example shows how to display a classification upstream
unmatch action
RTK.0> classf get upstream-unmatch-act
Upstream un-match action: Drop
SFU Product Page 353 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set permit-sel-range
Description:
Set classification entry range selection for upstream unmatch
action. There are two options, one is for entry range 0-511, and
the other is for entry range 64-511.
Syntax:
classf set permit-sel-range < 0to511 | 64to511>
Parameter:
0to511 – checking from rule 0 to rule 511
64to511 – checking from rule 64 to rule 511
Examples:
This example shows how to configure entry rang selection to
64-511.
RTK.0> classf set permit-sel-range 64to511
SFU Product Page 354 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get permit-sel-range
Description:
This command can use to get classification entry range selection
for upstream unmatch action. There are two options, one is for
entry range 0-511, and the other is for entry range 64-511.
Syntax:
classf get us-unmatch-act
Parameter:
None
Examples:
RTK.0> classf get permit-sel-range
This example shows how to display the classification entry rang
selection
Permit range from 64 to 511
SFU Product Page 355 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set remarking dscp
Description:
priority
Set DSCP remarking for classification DSCP_remarking action
used.
Syntax:
classf set remarking dscp priority priority dscp dscp
Parameter:
- priority configuration
dscp - dscp configuration
Examples:
This example shows how to configure classification DSCP
remarking as priority 0 mapping to dscp 7, priority 1 mapping
to dscp 15, priority 2 mapping to dscp 23, priority 3 mapping
to dscp 31, priority 4 mapping to dscp 39, priority 5 mapping
to dscp 47, priority 6 mapping to dscp 55, priority 7 mapping
to dscp 63
RTK.0> classf set remarking dscp priority 0 dscp 7
RTK.0> classf set remarking dscp priority 1 dscp 15
RTK.0> classf set remarking dscp priority 2 dscp 23
RTK.0> classf set remarking dscp priority 3 dscp 31
RTK.0> classf set remarking dscp priority 4 dscp 39
RTK.0> classf set remarking dscp priority 5 dscp 47
RTK.0> classf set remarking dscp priority 6 dscp 55
RTK.0> classf set remarking dscp priority 7 dscp 63
SFU Product Page 356 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get remarking dscp
Description:
Get classification DSCP remarking.
Syntax:
classf get remarking dscp
Parameter:
None
Examples:
This example shows how to display a classification DSCP
remarking table
RTK.0> classf get remarking dscp
CF_priority DSCP
0 7
1 15
2 23
3 31
4 39
5 47
6 55
7 63
SFU Product Page 357 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set range-ip
Description:
Set classification IP range for classification range-ip rule
Syntax:
classf set range-ip entry index type <sip | dip >
classf set range-ip entry index low-bound low_bound_ip up-bound
up_bound_ip
Parameter:
index - specified entry index
type - ip range type
dip - destination ipv4 address
sip - source ipv4 address
low-bound - low bound range
up-bound - high bound range
Examples:
This example shows how to configure a upstream rule for source
IP range 10.1.1.1 to 10.1.2.2
RTK.0> classf clear
RTK.0> classf set rule direction upstream
RTK.0> classf set rule range-ip data 0 mask 0x7
RTK.0> classf set upstream-action sid-act sid 0
RTK.0> classf add entry 0
RTK.0> classf set range-ip entry 0 type sip
RTK.0> classf set range-ip entry 0 low-bound 10.1.1.1 up-bound
10.1.2.2
SFU Product Page 358 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get range-ip
Description:
Get classification IP range setting by specific entry index
Syntax:
classf get range-ip entry index
Parameter:
index - specified entry index
Examples:
This example shows how to display classification IP range
setting
RTK.0> classf get range-ip entry 0
Range check of IP address
Index: 0 Upper: 10.1.2.2 Lower: 10.1.1.1 Type: Ipv4 Sip
SFU Product Page 359 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set range-l4port
Description:
Set classification L4 port range for classification
range-l4port rule
Parameter:
Examples:
Syntax:
classf set range-l4port entry index type <src-port | dst-port>
classf set range-l4port entry index low-bound l4lport up-bound
l4uport
index - specified entry index
type - ip range type
src-port - source port number
dst-port - destination port number
low-bound - low bound range
up-bound - high bound range
This example shows how to configure a upstream rule for L4 source
port range from 2000 to 3000
RTK.0> classf clear
RTK.0> classf set rule direction upstream
RTK.0> classf set rule range-l4port data 0 mask 0x7
RTK.0> classf set upstream-action sid-act sid 0
RTK.0> classf add entry 0
RTK.0> classf set range-l4port entry 0 type src-port
RTK.0> classf set range-l4port entry 0 low-bound 2000 up-bound
3000
SFU Product Page 360 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get range-l4port
Description:
Get classification L4 port range setting by specific entry index
Syntax:
classf get range-l4port entry index
Parameter:
index - specified entry index
Examples:
This example shows how to display classification L4 port range
setting
RTK.0> classf get range-l4port entry 0
Range check of L4 port
Index: 0 Upper: 3000 Lower: 2000 Type: Source Port
SFU Product Page 361 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf set us-1p-remark-prior
Description:
For upstream 802.1P remarking, it decide whether ACL action or
classification action is high priority.
Syntax:
classf set us-1p-remark-prior < cf | acl >
Parameter:
cf - classification is high priority
acl - ACL is high priority
Examples:
This example shows how to configure a upstream 1P remark as ACL
take high priority than classification
RTK.0> classf set us-1p-remark-prior acl
SFU Product Page 362 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
classf get us-1p-remark-prior
Description:
For upstream 802.1P remarking, it decide whether ACL action or
classification action is high priority.
Syntax:
classf get range-l4port entry index
Parameter:
None
Examples:
This example shows how to display 802.1P remark decision for ACL
and classification.
RTK.0> classf get us-1p-remark-prior
ACL prior than CF
SFU Product Page 363 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.17. GPON commands
gpon init
Description:
Initialize GPON module. It must be called before any GPON
function.
Syntax:
gpon init
Parameter:
None
Examples:
This example shows how to initialize GPON module.
RTK.0> gpon init
RTK.0>
SFU Product Page 364 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon deinitial
Description:
Deitialize GPON module.
Syntax:
gpon deinitial
Parameter:
None
Examples:
This example shows how to deinitialize GPON module.
RTK.0> gpon deinitial
RTK.0>
SFU Product Page 365 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set serial-number
Description:
Configure the serial number. It contain 4 bytes verdor ID, and
4 bytes serial number. It must be called before GPON activate
command.
Syntax:
Parameter:
This example shows how to configure serial number.
gpon set serial-number vendor_id serial_number
vendor_id – specify the verdor ID, it is string
format.
serial_number - specify serial number, it is hex format.
Examples:
RTK.0> gpon set serial-number real 0x98765432
RTK.0>
SFU Product Page 366 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get serial-number
Syntax:
RTK.0>
Description:
Get the serial number.
gpon get serial-number
Parameter:
None
Examples:
This example shows how to get serial number.
RTK.0> gpon get serial-number
serial number: real 0x98765432
SFU Product Page 367 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set password
Description:
Configure the serial number. It contain 10 bytes password. It
must be called before GPON activate command.
Syntax:
gpon set password password
Parameter:
password – specify the password, it is string format.
Examples:
This example shows how to configure password.
RTK.0> gpon set password aaaaaaaaaa
RTK.0>
SFU Product Page 368 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get password
Description:
Get the password.
Syntax:
gpon get password
Parameter:
None
Examples:
This example shows how to get password.
RTK.0> gpon get password
password: aaaaaaaaaa
RTK.0>
SFU Product Page 369 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon activate
Description:
Activate GPON module. After gpon activate, the GPON module will
do ranging process.
Syntax:
– specify the intial state to o1 state for
ranging process.
– specify the intial state to o7 state for
ranging process.
This example shows how to activate GPON.
RTK.0>
gpon activate init-state < o1 | o7 >
Parameter:
o1
o7
Examples:
RTK.0> gpon activate init-state o1
SFU Product Page 370 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon deactivate
Description:
Syntax:
Parameter:
Deactivate GPON module. After gpon deactivate, it will issue
dying gasp messages.
gpon deactivate
None
Examples:
This example shows how to deactivate GPON.
RTK.0> gpon deactivate
RTK.0>
SFU Product Page 371 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get onu-state
Description:
Get the ONU status of ranging process.
Syntax:
gpon get onu-state
Parameter:
None
Examples:
This example shows how to get ONU status.
RTK.0> gpon get onu-state
ONU state: Initial State(O1)
RTK.0>
SFU Product Page 372 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get alarm-status
Description:
Get the ONU alarm status. It includes LOS alarm, LOF alarm and
LOM alarm.
Syntax:
gpon get alarm-status
Parameter:
None
Examples:
This example shows how to get ONU alarm status. Clear means no
alarm, and occur means alarm issued.
RTK.0> gpon get alarm-status
Alarm LOS, status: clear
Alarm LOF, status: occur
Alarm LOM, status: occur
RTK.0>
SFU Product Page 373 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set active-timer
Description:
Configure the timers used in raning process. It includes to1
imter and to2 timer. It must be called before GPON activate
command.
This example shows how to configure to1 timer and to2 timer.
Syntax:
gpon set active-timer to1 to1_timer to2_timer
Parameter:
to1_timer - specify the value of to1 timer
to2_timer - specify the value of to2 timer
Examples:
RTK.0> gpon set active-timer to1 10000 to2 200
RTK.0>
SFU Product Page 374 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get active-timer
Description:
Disaply the active timer including to1 and to2.
Syntax:
gpon get active-timer
Parameter:
None
Examples:
This example shows how to display to1 and to2 timer:
RTK.0> gpon get active-timer
to1 timer: 10000 ms
to2 timer: 200 ms
RTK.0>
SFU Product Page 375 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-laser
Description:
Configure downstream optical parameters. It must be called
before GPON activate command.
Syntax:
gpon set ds-laser < opt_los | cdr_los > state < enable | disable
> polarity < high | low >
gpon set ds-laser los_holdover < enable | disable >
Parameter:
opt_los – specify the optical LOS input.
cdr_los
- specify to disable LOS input
– specify the polarity of LOS input is high
active
– specify the polarity of LOS input is low
active
– LOS will only be raised after being stable
for more than 1ms.
– specify to enable los_holdover function
– specify the CDR LOS input.
enable - specify to enable LOS input
disable
high
low
los_holdover
enable
disable – specify to disable los_holdover function
Examples:
This example shows how to configure the downstream optical
parameters including OPT LOS state, polarity, and LOS holdover
function.
RTK.0> gpon set ds-laser opt_los state enable polarity low
RTK.0> gpon set ds-laser los_holdover disable
RTK.0>
SFU Product Page 376 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-phy
Description:
Configure downstream physical parameters. It must be called
before GPON activate command.
Syntax:
gpon set ds-phy descramble < enable | disable >
gpon set ds-phy fec-state < enable | disable > fec-threshold
threshold
Parameter:
descramble – specify the descramble function.
enable – enable descramble function.
disable
– disable descramble function.
fec-state - specify FEC function
enable – enable downstream FEC correction
function.
disable – disable downstream FEC correction even
when DS FEC encoding is enabled. The
encoded parity bytes are ignored and the
data will be passed to following
processing modules.
fec-threshold – D/S FEC status detection threshold,
number of GPON frames. By default, it
should be set to 1.
threshold – specify the value of FEC threshold
Examples:
This example shows how to configure the downstream physical
parameters including descramble, and downstream FEC functions.
RTK.0> gpon set ds-phy descramble enable
RTK.0> gpon set ds-phy fec-state enable fec-threshold 1
RTK.0>
SFU Product Page 377 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-ploam
Description:
Configure downstream PLOAM parameters. It must be called before
GPON activate command.
Syntax:
gpon set ds-ploam < drop-crc-error | filter-onuid |
accept-broadcast > < enable | disable >
Parameter:
drop-crc-error
Examples:
RTK.0>
- specify to dropping or accept received
PLOAMd messages with CRC error.
(counters will be increased)
filter-onuid – ONU_ID filtering for downstream PLOAM
accept-broadcast – Accept broadcast PLOAMd messages
enable – enable downstream PLOAM function
disable – disable downstream PLOAM function
This example shows how to configure the downstream PLOAM
parameters including drop CRC error packet, filter ONU-ID, and
accept broadcast functions.
RTK.0> gpon set ds-ploam drop-crc-error enable
RTK.0> gpon set ds-ploam filter-onuid enable
RTK.0> gpon set ds-ploam accept-broadcast enable
SFU Product Page 378 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-bwmap
Description:
Configure downstream BWMAP parameters. It must be called before
GPON activate command.
Syntax:
strict-plen
RTK.0> gpon set ds-bwmap drop-crc-error enable
gpon set ds-bwmap < drop-crc-error | filter-onuid | strict-plen
> < enable | disable >
Parameter:
drop-crc-error - specify to dropping or accept received
BWMAP with CRC error
filter-onuid – accept BWMap items matching
provisioned T-CONTs
– process received PLENd in strict mode
or standard mode. If set to enable, only
2 usable matching PLENd structures are
accepted. If set to disable, processing
in standard mode.
enable – enable related downstream BWMAP
function
disable – disable related downstream BWMAP
function
Examples:
This example shows how to configure the downstream PLOAM
parameters including drop CRC error packet, filter ONU-ID, and
strict PLEN functions.
RTK.0> gpon set ds-bwmap filter-onuid enable
RTK.0> gpon set ds-bwmap strict-plen disable
RTK.0>
SFU Product Page 379 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-gem
Description:
RTK.0> gpon set ds-gem assembly-threshold 16
Configure downstream GEM parameters. It must be called before
GPON activate command.
Syntax:
gpon set ds-gem assembly-threshold threshold
Parameter:
assembly-threshold - specify number of GPON frames for
assembly timeout threshold. The unit is
125us.
threshold – specify the threshold value
Examples:
This example shows how to configure the downstream GEM assembly
threshold parameters.
RTK.0>
SFU Product Page 380 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-eth
drop-crc-error
enable
pettern
Description:
Configure downstream Ethernet parameters. It must be called
before GPON activate command.
Syntax:
gpon set ds-eth drop-crc-error < enable | disable >
gpon set ds-eth pti-pettern pettern pti-mask mask
Parameter:
- specify dropping received Ethernet
packet with CRC error
– enable drop received Ethernet packet
with CRC error
disable – disable drop received Ethernet packet
with CRC error
- PTI pattern for Ethernet fragments.
mask - PTI mask for Ethernet fragments.
Examples:
This example shows how to configure the downstream Ethernet
parameter, including drop CRC error frame, and PTI setting.
RTK.0> gpon set ds-eth drop-crc-error enable
RTK.0> gpon set ds-eth pti-pettern 0x1 pti-mask 0x1
RTK.0>
SFU Product Page 381 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set ds-omci
Description:
Configure downstream OMCI parameters. It must be called before
GPON activate command.
Syntax:
gpon set ds-omci pti-pettern pettern pti-mask mask
Parameter:
pettern - PTI pattern for OMCI fragments.
mask - PTI mask for OMCI fragments.
Examples:
This example shows how to configure the downstream OMCI PTI
parameter.
RTK.0> gpon set ds-omci pti-pettern 0x5 pti-mask 0x5
RTK.0>
SFU Product Page 382 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get ds parameters
Description:
Get downstream parameters.
gpon get < ds-laser | ds-phy | ds-ploam | ds-bwmap | ds-gem |
ds-eth | ds-omci >
ds-eth
OPT LOS polarity: high
LOS holdover: disable
RTK.0>
Syntax:
Parameter:
ds-laser - get downstream optical parameter.
ds-phy - get downstream physical parameter.
ds-ploam - get downstream PLOAM parameter.
ds-bwmap - get downstream BWMAP parameter.
ds-gem - get downstream GEM parameter.
- get downstream ethernet parameter.
ds-omci - get downstream OMCI parameter.
Examples:
This example shows how to display the parameters of downstream
optical, physical, PLOAM, BWMAP, GEM, Ethernet, and OMCI.
RTK.0> gpon get ds-laser
OPT LOS state: enable
CDR LOS state: disable
CDR LOS polarity: low
RTK.0> gpon get ds-phy
Descramble: enable
FEC state: enable
FEC threshold: 0
RTK.0>
RTK.0> gpon get ds-ploam
Accept broadcast: enable
Drop CRC error: enable
Filter ONU-ID: enable
RTK.0>
SFU Product Page 383 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> gpon get ds-bwmap
Drop CRC error: enable
Filter ONU-ID: enable
Assembly threshold: 16
Strict PLENd: disable
RTK.0>
RTK.0> gpon get ds-gem
RTK.0>
RTK.0> gpon get ds-eth
Drop CRC error: enable
PTI pattern: 0x1
PTI mask: 0x1
RTK.0>
RTK.0> gpon get ds-omci
PTI pattern: 0x1
PTI mask: 0x1
RTK.0>
SFU Product Page 384 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set us-laser
Description:
Configure upstream optical parameters. It must be called before
GPON activate command.
– specify the laser on offset
RTK.0> gpon set us-laser on-offset 40 off-offset 30
Syntax:
gpon set us-laser on-offset on_offset off-offset off_offset
Parameter:
on_offset
off_offset – specify the laser off offset
Examples:
This example shows how to configure the upstream optical
parameters including laser-on and laser-off offset.
RTK.0>
SFU Product Page 385 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set us-phy
Parameter:
– enable scramble function.
disable
Examples:
RTK.0> gpon set us-phy scramble enable
Description:
Configure upstream physical parameters. It must be called before
GPON activate command.
Syntax:
gpon set us-phy scramble < enable | disable >
gpon set us-phy burst-polarity < high | low >
gpon set us-phy auto-sstart < enable | disable >
gpon set us-phy suppress-laser < enable | disable >
scramble – specify the upstream scramble function.
enable
disable – disable scramble function.
burst-polarity - specify burst enable polarity
high – set burst enable polarity to high.
low – set burst enable polarity to low.
auto-sstart – Process Small SSTART (< BOH LEN)
automatically
enable – enable auto-sstart function.
disable – disable auto-sstart function.
suppress-laser – suppressing laser when ONT is outside of
state 3, 4 and 5
enable – enable suppress-laser function.
– disable suppress-laser function.
This example shows how to configure the upstream physical
parameters including scramble, burst-enable polarity, auto and
downstream FEC functions.
RTK.0> gpon set us-phy burst_polarity low
RTK.0> gpon set us-phy suppress_laser enable
RTK.0> gpon set us-phy auto_sstart enable
RTK.0>
SFU Product Page 386 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set us-ploam
Description:
Configure upstream PLOAM parameters. It must be called before
GPON activate command.
Syntax:
gpon set us-ploam state < enable | disable >
Parameter:
enable - sending normal upstream PLOAM
disable – always sending no_msg PLOAM
Examples:
This example shows how to configure the upstream PLOAM function
to send normal PLOAM.
RTK.0> gpon set us-ploam state enable
RTK.0>
SFU Product Page 387 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set us-dbr
Description:
Configure upstream DBA report function. It must be called before
GPON activate command.
RTK.0>
Syntax:
gpon set us-dbr state < enable | disable >
Parameter:
enable – enable upstream DBA report function
disable – disable upstream DBA report function
If DBRu is requested by BWMAP, all ‘0’
will be sent.
Examples:
This example shows how to enable the upstream DBA report
function.
RTK.0> gpon set us-dbr state enable
SFU Product Page 388 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get us parameters
Parameter:
us-ploam
burst-enable polarity: low
RTK.0> gpon get us-dbr
Description:
Get upstream parameters.
Syntax:
gpon get < us-laser | us-phy | us-ploam | us-dbr >
us-laser - get upstream optical parameter.
us-phy - get upstream physical parameter.
- get upstream PLOAM parameter.
ds-dbr - get upstream DBR parameter.
Examples:
This example shows how to display the parameters of upstream
optical, physical, PLOAM, and DBR.
RTK.0> gpon get us-laser
Laser-on offset: 40
Laser-off offset: 30
RTK.0>
RTK.0> gpon get us-phy
Scramble: enable
Auto-sstart: enable
Suppressing laser: enable
RTK.0>
RTK.0> gpon get us-ploam
PLOAMu state: enable
RTK.0>
DBRu state: enable
RTK.0>
SFU Product Page 389 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon add tcont alloc-id
Description:
Parameter:
Add alloc_id 1000, return TCONT_id=0
Add a tcont entry by alloc-ID.
Syntax:
gpon add tcont alloc-id id
id – the alloc-ID value, from 0 to 4095
Examples:
This example shows how to add a tcont entry for alloc-ID 1000.
RTK.0> gpon add tcont alloc-id 1000
RTK.0>
SFU Product Page 390 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon del tcont alloc-id
Description:
Delete a tcont entry by alloc-ID.
gpon del tcont alloc-id id
id
Syntax:
Parameter:
– the alloc-ID value, from 0 to 4095
Examples:
This example shows how to delete a tcont entry by alloc-ID 1000.
RTK.0> gpon del tcont alloc-id 1000
RTK.0>
SFU Product Page 391 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get tcont alloc-id
Description:
Get a tcont entry by alloc-ID.
Syntax:
gpon get tcont alloc-id id
Parameter:
id – the alloc-ID value, from 0 to 4095
Examples:
This example shows how to get a tcont entry by alloc-ID 1000.
RTK.0> gpon get tcont alloc-id 1000
alloc_id: 1000, TCONT_id 0:
RTK.0>
SFU Product Page 392 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show tcont
Description:
Display the added tcont entries.
Syntax:
gpon show tcont
Parameter:
None
Examples:
This example shows how to display whole tcont entries.
RTK.0> gpon show tcont
============================================================
GPON ONU MAC TCONT Status
TCont ID | Alloc ID | Physical | Logical | Type
0 | 1000 | * | * | 3
1 | 2000 | * | * | 3
2 | 3000 | * | * | 3
============================================================
RTK.0>
SFU Product Page 393 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon add ds-flow flow-id
Description:
Add a downstream flow entry by flow-ID.
– the flow-ID value, from 0 to 127
– specify the flow is used for Ethernet
packet
This example shows how to add a downstream flow for flow-ID 0,
GEM port 1000, Ethernet type, and no encryption.
Syntax:
gpon add ds-flow flow-id id gem-port gem < ether | OMCI >
[ multicast ] [ aes ]
Parameter:
id
gem – the GEM port value, from 0 to 4095
ether
OMCI – specify the flow is used for OMCI
packet
multicast – specify the flow is used for multicast
packet
aes – specify the flow is AES encryption
Examples:
RTK.0> gpon add ds-flow flow-id 0 gem-port 1000 ether
RTK.0>
SFU Product Page 394 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon del ds-flow flow-id
Description:
Delete a downstream flow entry by alloc-ID.
Syntax:
gpon del ds-flow flow-id id
– the flow-ID value, from 0 to 127
Parameter:
id
Examples:
This example shows how to delete a downstream flow by flow-ID
0.
RTK.0> gpon del ds-flow flow-id 0
RTK.0>
SFU Product Page 395 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get ds-flow flow-id
Description:
Display the downstream flow entry by flow-ID.
Syntax:
gpon get ds-flow flow-id id
RTK.0>
Parameter:
id – the flow-ID value, from 0 to 127
Examples:
This example shows how to display the downstream flow entry by
flow-ID 0.
RTK.0> gpon get ds-flow flow-id 0
flow_id gem_port type multicast AES
======= ======== ==== ========= ===
0 1000 ETH no no
SFU Product Page 396 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show ds-flow
Description:
Syntax:
0 | 1000 | ETH | |
Display the added downstream flow entries.
gpon show ds-flow
Parameter:
None
Examples:
This example shows how to display whole downstream flow entries.
RTK.0> gpon show ds-flow
============================================================
GPON ONU MAC D/S Flow Status
Flow ID | GEM Port | Type | Multicast | AES
1 | 1001 | ETH | |
2 | 1002 | ETH | |
============================================================
RTK.0>
SFU Product Page 397 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon add us-flow flow-id
Description:
gpon add us-flow flow-id id gem-port gem < ether | OMCI >
Examples:
RTK.0> gpon add us-flow flow-id 0 gem-port 1000 ether
Add a upstream flow entry by flow-ID.
Syntax:
Parameter:
id – the flow-ID value, from 0 to 127
gem – the GEM port value, from 0 to 4095
ether – specify the flow is used for Ethernet
packet
OMCI – specify the flow is used for OMCI
packet
This example shows how to add a upstream flow for flow-ID 0, GEM
port 1000, Ethernet type.
RTK.0>
SFU Product Page 398 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon del us-flow flow-id
Description:
Delete a upstream flow entry by alloc-ID.
id
Syntax:
gpon del us-flow flow-id id
Parameter:
– the flow-ID value, from 0 to 127
Examples:
This example shows how to delete a upstream flow by flow-ID 1.
RTK.0> gpon del us-flow flow-id 0
RTK.0>
SFU Product Page 399 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get us-flow flow-id
Description:
Syntax:
Parameter:
Display the upstream flow entry by flow-ID.
gpon get us-flow flow-id id
id – the flow-ID value, from 0 to 127
Examples:
This example shows how to display the upstream flow entry by
flow-ID 1.
RTK.0> gpon get us-flow flow-id 0
flow_id gem_port type
======= ======== ====
0 1000 ETH
RTK.0>
SFU Product Page 400 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show us-flow
Description:
Display the added upstream flow entries.
Syntax:
gpon show us-flow
Parameter:
This example shows how to display whole upstream flow entries.
============================================================
None
Examples:
RTK.0> gpon show us-flow
GPON ONU MAC U/S Flow Status
Flow ID | GEM Port | Type | TCont | Channel | OMCI
0 | 1000 | ETH | 0 | 16 |
1 | 1001 | ETH | 0 | 16 |
============================================================
RTK.0>
SFU Product Page 401 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon add multicast-filter-entry
Description:
Add a multicast filter entry.
Syntax:
gpon add multicast-filter-entry mac-address mac
Parameter:
mac – the multicast MAC address, the format
is xx:xx:aa:bb:cc:dd. Only the LSB 32
bits aa:bb:cc:dd are used for filtering
MAC DA.
Examples:
This example shows how to add a multicast filter entry for MAC
address 01:00:5e:01:02:03.
RTK.0> gpon add multicast-filter-entry mac-address
01:00:5e:01:02:03
RTK.0>
SFU Product Page 402 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon del multicast-filter-entry
Description:
Delete a multicast filter entry.
Syntax:
gpon del multicast-filter-entry mac-address mac
Parameter:
mac – the multicast MAC address, the format
is xx:xx:aa:bb:cc:dd.
Examples:
This example shows how to delete a multicast filter entry by MAC
address 01:00:5e:01:02:03.
RTK.0> gpon del multicast-filter-entry mac-address
01:00:5e:01:02:03
RTK.0>
SFU Product Page 403 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get multicast-filter-entry
Syntax:
– the multicast filter table index, from
0 to 255
Description:
Display the multicast filter entry by index.
gpon get multicast-filter-entry index index
Parameter:
index
Examples:
This example shows how to display the multicast filter entry by
index.
RTK.0> gpon get multicast-filter-entry index 0
Index | MAC Address
0 | 01-00-5e-01-02-03
RTK.0>
SFU Product Page 404 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show multicast-filter-entry
Description:
Display the whole multicast filter table entries.
Syntax:
gpon show multicast-filter-entry
Parameter:
None
Examples:
This example shows how to display whole multicast filter table
entries.
============================================================
RTK.0> gpon show multicast-filter-entry
GPON ONU MAC Multicast MAC Filter Table
Index | MAC Address
0 | 01-00-5e-01-02-03
============================================================
RTK.0>
SFU Product Page 405 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set multicast-filter
Description:
Configure multicast filter parameters.
Syntax:
gpon set multicast-filter < broadcast-pass | non-multicast-pass
> < enable | disable >
gpon set multicast-filter < prefix-ipv4 | prefix-ipv6 > prefix
gpon set multicast-filter < force-ipv4 | force-ipv6 > < pass |
drop | normal >
gpon set multicast-filter filter-mode < include | exclude >
Parameter:
broadcast-pass – specify bypass broadcast packet
non-multicast-pass – specify bypass non-multicast flow
packet
enable – specify to enable function
disable – specify to disable function
prefix-ipv4 – specify multicast IPv4 prefix field
prefix-ipv6 – specify multicast IPv6 prefix field
prefix – specify the prefix value. For IPv4, it
is 3 bytes; for IPv6, it is 2 bytes.
force-ipv4 – specify multicast IPv4 force mode
force-ipv6 – specify multicast IPv6 force mode
pass – specify to force bypass
drop – specify to force drop
normal – specify to non force mode
filter-mode – specify multicast filter mode for
multicast filter table entry
include – specify to include mode, it means the
DA MAC match to any entry in multicast
filter table.
exclude – specify to exclude mode, it means the
DA MAC not match to any entry in
multicast filter table.
Examples:
This example shows how to configure the parameters of multicast
filter function. Set broadcast packet and non-multicast flow to
SFU Product Page 406 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
by pass check. Set multicast IPv4 prefix to 0x01005E, and IPv6
to 0x3333. Set non force mode for IPv4/6 multicast. And set
filter mode to include mode.
RTK.0> gpon set multicast-filter broadcast-pass enable
RTK.0> gpon set multicast-filter non-multicast-pass enable
RTK.0> gpon set multicast-filter prefix-ipv4 0x01005e
RTK.0> gpon set multicast-filter prefix-ipv6 0x3333
RTK.0> gpon set multicast-filter force-ipv4 normal
RTK.0> gpon set multicast-filter force-ipv6 normal
RTK.0> gpon set multicast-filter filter-mode include
RTK.0>
SFU Product Page 407 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get multicast-filter
Description:
Display the multicast filter parameters.
Syntax:
gpon get multicast-filter
Parameter:
None
Examples:
This example shows how to get multicast filter parameters.
RTK.0> gpon get multicast-filter
Broadcast bypass enable
Non-multicast bypass enable
Ipv4 force mode Normal
RTK.0>
Ipv4 prefix 0x01005e
Ipv6 prefix 0x3333
Ipv6 force mode Normal
Filter mode Including
SFU Product Page 408 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set tx
gpon set tx-force-idle < enable | disable >
tx-laser
force-on
force-off
disable
Examples:
Description:
Configure transmit laser force mode.
Syntax:
gpon set tx-laser < force-on | force-off | normal >
Parameter:
– specify transmit laser force mode
– specify to force on
– specify to force on
normal – specify to non force mode
tx-force-idle – specify force transmit Idle pattern
enable – enable force transmit Idle pattern
– disable force transmit Idle pattern
This example shows how to configure transmit laser to force send
Idle pattern.
RTK.0> gpon set tx-laser force-on
RTK.0> gpon set tx-force-idle enable
RTK.0>
SFU Product Page 409 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get tx
Description:
Get transmit laser force mode.
Syntax:
gpon get tx
Parameter:
None
Examples:
This example shows how to display transmit laser mode.
RTK.0> gpon get tx
TX laser mode: Force on
TX force Idle: enable
RTK.0>
SFU Product Page 410 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show counter global
Description:
Show global counters.
Syntax:
gpon show counter global ( active | ds-phy | ds-plm | ds-bw |
ds-gem | ds-eth | ds-omci | us-phy | us-dbr | us-plm | us-gem | us-eth
| us-omci )
Parameter:
active – specify the activation counters,
including SN_Req and Ranging_Req
ds-phy – specify the downstream physical
counters, including BIP, FEC,
superframe los, and PLEN fail.
ds-plm – specify the downstream PLOAM
counters.
ds-bw – specify the downstream BWMAP
counters.
ds-gem
us-gem
– specify the downstream GEM counters,
including LOS, Idle, non_Idle, HEC,
over_interleaving, length mismatch,
and multiple flow match.
ds-eth – specify the downstream ethernet
counters, including unicast,
multicast, forward multicast, leak
multicast, and FCS error.
ds-omci – specify the downstream OMCI counters,
including total, CRC error, drop, and
processed.
us-phy – specify the upstream physical
counters, including tx BOH.
us-dbr – specify the upstream DBR counters,
including tx DBRu.
us-plm – specify the upstream PLOAM counters,
including total, processed, urgent,
processed urgent, normal, process
normal, SN, and Nomsg.
– specify the upstream GEM counters,
SFU Product Page 411 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
including block, and byte.
us-eth
us-omci
GPON ONU MAC Device Counter: Activation
RTK.0>
GPON ONU MAC Device Counter: DS PHY
FEC Correct bits: 0
FEC codewords Uncor: 65536
RTK.0>
GPON ONU MAC Device Counter: DS PLOAM
Corrected RX PLOAMd: 1
– specify the upstream ethernet
counters, including aborted packet.
– specify the upstream OMCI counters,
including processed OMCI.
Examples:
This example shows how to display global counters.
RTK.0> gpon show counter global active
============================================================
SN Req : 0
Ranging Req : 0
RTK.0> gpon show counter global ds-phy
============================================================
BIP Error bits : 0
BIP Error blocks: 0
FEC Correct bytes: 0
FEC Correct codewords: 0
Superframe LOS : 0
PLEN fail : 0
RTK.0> gpon show counter global ds-plm
============================================================
Total RX PLOAMd : 1
CRC Err RX PLOAM : 0
Proc RX PLOAMd : 0
Overflow Rx PLOAM : 0
============================================================
RTK.0>
SFU Product Page 412 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show counter tcont
Description:
Show Tcont counters, including send Idle bytes.
Syntax:
gpon show counter tcont tcont_id
Parameter:
tcont_id – specify the tcont-ID
Examples:
This example shows how to display Tcont counters.
GPON ONU MAC Device Counter: TCont 0 Eth
RTK.0> gpon show counter tcont 0
============================================================
GPON ONU MAC Device Counter: TCont 0 Gem
U/S sent GEM : 0
============================================================
============================================================
U/S sent Eth Pkt: 0
============================================================
============================================================
GPON ONU MAC Device Counter: TCont 0 Idle
U/S sent Idle Byte: 0
============================================================
RTK.0>
SFU Product Page 413 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon show counter flow
Description:
Show flow counters, including downstream GEM packets,
downstream GEM bytes, downstream RX Ethernet packets,
downstream forward Ethernet packets, and upstream GEM bytes.
Syntax:
gpon show counter flow flow_id
Parameter:
flow_id – specify the flow-ID
Examples:
This example shows how to display flow counters.
RTK.0> gpon show counter flow 0
============================================================
GPON ONU MAC Device Counter: D/S Flow 0 Gem
D/S GEM blocks : 0
D/S GEM bytes : 0
============================================================
============================================================
GPON ONU MAC Device Counter: D/S Flow 0 Eth
RX Eth Pkt : 0
Fwd Eth Pkt : 0
============================================================
============================================================
GPON ONU MAC Device Counter: U/S Flow 0 Gem
U/S GEM blocks : 0
U/S GEM bytes : 0
============================================================
RTK.0>
SFU Product Page 414 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon omci_tx
Description:
Configure debug flag of GPON module. For debug used.
Syntax:
gpon omci_tx data1 data2 data3 data4 data5 data6 data7 data8
data9 data10 data11
Parameter:
data1 - daga11 – data block of OMCI packet. 4 bytes for
each data block. total 44 byte.
Examples:
This example shows how to transmit a OMCI packet.
RTK.0> gpon omci_tx 0x11223344 0x55667788 0x99aabbcc 0x11223344
0x55667788 0x99aabbcc 0x11223344 0x55667788 0x99aabbcc
0x11223344 0x55667788
RTK.0>
SFU Product Page 415 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set auto-tcont
Parameter:
Description:
Configure to add tcont automatically when received assign ONU-ID
PLOAM. Default is enable.
Syntax:
gpon set auto-tcont < enable | disable >
enable – enable to add tcont automatically when
received assign ONU-ID PLOAM.
disable – disable to add tcont automatically
when received assign ONU-ID PLOAM.
Examples:
This example shows how to disable adding tcont automatically
when received assign ONU-ID PLOAM.
RTK.0> gpon set auto-tcont enable
RTK.0>
SFU Product Page 416 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get auto-tcont
Description:
Get to the state of add tcont automatically when received assign
ONU-ID PLOAM.
gpon get auto-tcont
None
Syntax:
Parameter:
Examples:
This example shows how to get the state of add tcont
automatically when received assign ONU-ID PLOAM.
RTK.0> gpon get auto-tcont
GPON auto TCONT state: Enable
RTK.0>
SFU Product Page 417 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set auto-boh
Description:
Configure to update BOH automatically when received burst
overhead, extended overhead, and ranging time PLOAM. Default is
enable.
Syntax:
Parameter:
gpon set auto- boh < enable | disable >
enable – enable auto-boh.
disable – disable auto-boh.
Examples:
This example shows how to enable auto-boh.
RTK.0> gpon set auto-boh enable
RTK.0>
SFU Product Page 418 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get auto-boh
Description:
Get to the state of auto-boh.
Syntax:
gpon get auto-boh
Parameter:
None
Examples:
This example shows how to get the state of auto-boh.
RTK.0> gpon get auto-boh
GPON auto BOH state: Enable
RTK.0>
SFU Product Page 419 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set eqd-offset
Description:
Configure to adjust eqd offset.
Syntax:
gpon set eqd-offset < plus | minus > offset
This example shows how to adjust eqd by offset.
Parameter:
plus – the eqd is plus offset.
minus – the eqd is minus offset.
offset – specify the offset value.
Examples:
RTK.0> gpon set eqd-offset plus 100
RTK.0>
SFU Product Page 420 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon get eqd-offset
Description:
Get to the eqd offset setting.
Syntax:
gpon get eqd-offset
Parameter:
None
Examples:
This example shows how to get the eqd offset.
RTK.0> gpon get eqd-offset
GPON EQD offset: 100
RTK.0>
SFU Product Page 421 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
gpon set debug
Description:
Configure debug flag of GPON module. For debug used.
Syntax:
gpon set debug < enable | disable >
Parameter:
disable
Examples:
enable – specify to enable debug mode
– specify to disable debug mode
This example shows how to enable and disable GPON debug mode.
RTK.0> gpon set debug enable
RTK.0> gpon set debug disable
SFU Product Page 422 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.18. Switch commands
Syntax:
None
RTK.0> switch init
switch init
Description:
This command can reset & initialize switch control module.
switch init
Parameter:
Examples:
This example shows how to initialized switch module.
SFU Product Page 423 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set 48-pass-1
Description:
This command can set switch 48-pass-1 state.
Syntax:
switch set 48-pass-1 state <disable | enable>
Parameter:
state
- disable configuration
- enable configuration
Examples:
- state configuration
disable
enable
This example shows how to enable switch 48-pass-1.
RTK.0> switch set 48-pass-1 state enable
SFU Product Page 424 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get 48-pass-1
Description:
switch get 48-pass-1 state
RTK.0> switch get 48-pass-1 stat
This command can get switch 48-pass-1 setting.
Syntax:
Parameter:
None
Examples:
This example shows how to get switch 48-pass-1 setting.
48 Pass 1 function: Enable
RTK.0>
SFU Product Page 425 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set ipg-compensation
Syntax:
switch set ipg-compensation state <disable | enable>
switch set ipg-compensation <65ppm | 90ppm>
state
65ppm
- 90ppm configuration
This example shows how to enable ipg compensation function and
set rate to 90ppm.
RTK.0> switch set ipg-compensation state enable
Description:
This command can get switch igp compensation rate. The switch
igp compensation can be enableot disable by this command.
Parameter:
- state configuration
disable - disable configuration
enable - enable configuration
- 65ppm configuration
90ppm
Examples:
RTK.0> switch get ipg-compensation
IPG compensation: 90PPM
SFU Product Page 426 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get ipg-compensation
Description:
switch get ipg-compensation state
switch get ipg-compensation
state
Examples:
RTK.0> switch get ipg-compensation
This command can get ipg compensation settiog.
Syntax:
Parameter:
- state configuration
This example shows how to get ipg compensation setting.
RTK.0> switch get ipg-compensation state
Short IPG function: Enable
IPG compensation: 90PPM
SFU Product Page 427 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set bypass-tx-crc
Description:
switch set bypass-tx-crc state <disable | enable>
Parameter:
- enable configuration
This example shows how set bypass TX CRC state to enable.
This command can set switch tx CRC mode. Set state to disable
will bypass tx CRC check, the CRC error packet will be send out.
Syntax:
state - state configuration
disable - disable configuration
enable
Examples:
RTK.0> switch set bypass-tx-crc state enable
RTK.0>
SFU Product Page 428 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get bypass-tx-crc
Description:
This command used to get bypass tx crc state.
Syntax:
switch get bypass-tx-crc state
Examples:
This example shows how to get bypass tx CRC state.
RTK.0> switch get bypass-tx-crc state
Parameter:
None
Bypass Tx CRC: Enable
RTK.0>
SFU Product Page 429 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set rx-check-crc
Description:
switch set rx-check-crc port <PORT_LIST:ports | all> state
<disable | enable>
- disable configuration
This command can per port set rx CRC check state.
Syntax:
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable
enable - enable configuration
Examples:
This example shows how to set port 0 rx-check-crc status to
disable. Port 2 can accept CRC error frames.
RTK.0> switch set rx-check-crc port 0 state disable
SFU Product Page 430 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get rx-check-crc
Description:
This command can per port get rx-check-crc status.
Syntax:
switch get rx-check-crc port <PORT_LIST:ports | all> state
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
Examples:
This example shows how to get rx-check-crc status for port 0.
RTK.0> switch get rx-check-crc port 0 state
Port Status
-----------------------------
0 Disable
SFU Product Page 431 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set mac-address
Description:
This command can set switch MAC address.
Syntax:
switch set mac-address mac
Parameter:
Mac - mac address
Examples:
This example shows how to set switch MAC address to
00:00:11:52:33:22.
RTK.0> switch set mac-address 00:00:11:52:33:22.
SFU Product Page 432 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get mac-address
Description:
This command can get switch MAC address.
Syntax:
switch get mac-address
Parameter:
None
Examples:
This example shows how to get switch MAC address.
RTK.0> switch get mac-address
Switch MAC Address: 00:00:11:52:33:22
SFU Product Page 433 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set max-pkt-len
Description:
This command can set maximum accept packet length for each port.
Please set max-pkt-len first, and then assign each port to
max-pkt-len index.
Syntax:
switch set max-pkt-len <fe | ge> port <PORT_LIST:ports | all>
index index
switch set max-pkt-len index index length lenth
Parameter:
fe - fast ethernet
ge - giga ethernet
ports - specified port list
all – specify all ports
index - index of length configuration
length - packet length, unit byte
Examples:
This example shows how to set port 0 link in giga mode the maximum
accept packet length to 1518 bytes.
RTK.0> switch set max-pkt-len index 0 length 1518
RTK.0> switch set max-pkt-len ge port 0 index 0
SFU Product Page 434 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get max-pkt-len
Description:
This command can get the maximum accept packet length setting.
Syntax:
switch get max-pkt-len <fe | ge> port <PORT_LIST:ports | all>
switch get max-pkt-len index index
Parameter:
fe - fast Ethernet
ge - giga Ethernet
ports - specified port list
all – specify all ports
index - index of length configuration
Examples:
This example shows how to get maximum accept packet length
setting.
RTK.0> switch get max-pkt-len index 0
Max-Length Index 0 is Length 0 bytes.
RTK.0> switch get max-pkt-len ge port 0
Port Speed Config
-----------------------------
0 1000M 0
SFU Product Page 435 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set limit-pause
Description:
This command can set switch limit pause frame state.
Syntax:
switch set limit-pause state <disable | enable>
Parameter:
State - state configuration
Disable - disable configuration
Enable - enable configuration
Examples:
This example shows how to set switch limit pause frame state to
enable.
RTK.0> switch set limit-pause state enable
SFU Product Page 436 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get limit-pause
Description:
This command can set switch limit pause frame state.
Syntax:
switch get limit-pause state
Parameter:
None
Examples:
This example shows how to get switch limit pause frame state.
RTK.0> switch get limit-pause state
Limit Pause Frame: Enable
SFU Product Page 437 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set small-ipg-tag
Description:
This cmmand can set each port can accept small IPG tag or not.
Syntax:
switch set small-ipg-tag port <PORT_LIST:ports | all> state
<disable | enable>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to accept small ipg for port 0.
RTK.0> switch set small-ipg-tag port 0 state enable
SFU Product Page 438 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get small-ipg-tag
Description:
This command used to get accept small ipg tag setting for each
port.
Syntax:
switch get small-ipg-tag port <PORT_LIST:ports | all> state
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
Examples:
This example shows how to get small ipg setting for port 0.
RTK.0> switch get small-ipg-tag port 0
Port Status
-----------------------------
0 Enable
RTK.0>
SFU Product Page 439 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set small-pkt
Description:
Thos command can set each port can accept small packet or not.
Syntax:
switch set small-pkt port <PORT_LIST:ports | all> state <disable
| enable>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to accept small packet for port 0.
RTK.0> switch set small-pkt port 0 state enable
SFU Product Page 440 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get small-pkt
Description:
Syntax:
switch get small-pkt port <PORT_LIST:ports | all> state
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
Examples:
This example shows how to get small packet setting for port 0.
RTK.0> switch get small-ipg-tag port 0
Port Status
-----------------------------
0 Disable
SFU Product Page 441 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set output-drop
Description:
When this function enabled packet will be droped in ingress port
when traffic conjuest occurs. The packet type would be broadcast,
unknown-unicast and multicast.
Syntax:
switch set output-drop port <PORT_LIST:ports | all> state
<disable | enable>
switch set output-drop <broadcast | unknown-unicast |
multicast> state <disable | enable>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
broadcast - broadcast
unknown-unicast - unknown unicast
multicast - multicast
Examples:
This example shows how to enable output-drop function on port
0 and set check packet type to broadcast, unknown-unicast and
multicast.
RTK.0> switch set output-drop port 0 state enable
RTK.0> switch set output-drop broadcast state enable
RTK.0> switch set output-drop unknown-unicast state enable
RTK.0> switch set output-drop multicast state enable
SFU Product Page 442 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get output-drop
Description:
This command can get output-drop configuration.
Syntax:
switch get output-drop port <PORT_LIST:ports | all> state
switch get output-drop <broadcast | unknown-unicast |
multicast> state
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
broadcast - broadcast
unknown-unicast - unknown unicast
multicast - multicast
Examples:
This example shows how to get output-drop setting for port 0.
RTK.0> switch get output-drop port 0 state
Port Status
0 Disable
SFU Product Page 443 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch set back-pressure
Description:
This cmmand can set switch back-pressure mode.
Syntax:
switch set back-pressure <jam | defer>
Parameter:
jam - jam configuration
defer - defer configuration
Examples:
This example shows how to set switch back-pressure to jam mode.
RTK.0> switch set back-pressure jam
SFU Product Page 444 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch get back-pressure
Description:
This command get get switch back-pressure mode.
Syntax:
switch get back-pressure
Parameter:
None
Examples:
This example shows how to get switch back-pressure mode.
RTK.0> switch get back-pressure
Back-pressure: jam mode
SFU Product Page 445 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
switch reset
Description:
This command used to reset switch.
Syntax:
switch reset <global | chip>
Parameter:
global - global reset
chip - whole chip reset
Examples:
This example shows how to reset the switch chip.
RTK.0> switch reset chip
SFU Product Page 446 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.19. Dot1x commands
dot1x init
Description:
This command can reset & initialize Dot1x module.
Syntax:
dot1x init
Parameter:
None
Examples:
This example shows how to initial Dot1x module.
RTK.0> dot1x init
RTK.0>
SFU Product Page 447 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x set port-based
Description:
This command can set Dot1x port-based state, authentication
state and direction.
Syntax:
dot1x set port-based port <PORT_LIST:ports | all> state <disable
| enable>
dot1x set port-based port <PORT_LIST:ports | all> <auth |
unauth>
dot1x set port-based port <PORT_LIST:ports | all> direction <in
| both>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
auth - authed configuration
unauth - un-authed configuration
direction - auth packet checking direction
in - in direction
both - both in and out direction
Examples:
This example shows how to enable port 0 port-based 1X. Set port
0 to Authed state. The auth packet checking direction set to both
in and out direction.
RTK.0> dot1x set port-based port 0 state enable
RTK.0> dot1x set port-based port 0 auth
RTK.0> dot1x set port-based port 0 direction both
SFU Product Page 448 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x get port-based
Description:
This command can get port-based Dot1x setting.
Syntax:
dot1x get port-based port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get port-based Dot1x status for port
0.
Port Direction State AuthedStatus
0 BOTH Enable Authorized
SFU Product Page 449 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x set mac-based
Description:
This command can set Dot1x mac based state, authentication state
and direction.
Syntax:
dot1x set mac-based port <PORT_LIST:ports | all> state <disable
| enable>
dot1x set mac-based direction <in | both>
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
disable - disable configuration
enable - enable configuration
direction - auth packet checking direction
in - in direction
both - both in and out direction
Examples:
This example shows how to enable port 1 dot1x mac-based state
to enable. The auth packet checking direction set to rx
direction.
RTK.0> dot1x set mac-based port 1 state enable
RTK.0>
RTK.0> dot1x set mac-based direction in
RTK.0>
SFU Product Page 450 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x get mac-based
Description:
This command can get mac-based Dot1x setting.
Syntax:
dot1x get mac-based port <PORT_LIST:ports | all> state
dot1x get mac-based direction
Parameter:
ports - specified port list
all – specify all ports
state - state configuration
direction - authorized checking direction
Examples:
This example shows how to get mac-based Dot1x status for port
0.
RTK.0> dot1x get mac-based direction
Mac-based direction: BOTH
RTK.0> dot1x get mac-based port 1
Port State
1 Disable
RTK.0>
SFU Product Page 451 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x set trap-priority
Description:
Configure priority for packets trapped to CPU for related dot1x
functions
Syntax:
dot1x set trap-priority priority
Parameter:
priority - priority for trapping packets
Examples:
This example shows how to configurate dot1x trap priority to 7.
RTK.0> dot1x set trap-priority 7
RTK.0>
SFU Product Page 452 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x get trap-priority
Description:
Retriving priority for packets trapped to cpu for related dot1x
functions
Syntax:
dot1x get trap-priority
Examples:
Parameter:
None
This example shows how to get dot 1x trap priority.
RTK.0> dot1x get trap-priority
Trap priority:7
SFU Product Page 453 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x set unauth-packet
Description:
This command can set forwad action for unauth-packet.
Syntax:
dot1x set unauth-pakcet port <PORT_LIST:ports | all> action
<drop | guest-vlan | trap-to-cpu>
Parameter:
ports - specified port list
all – specify all ports
drop - drop packet
trap-to-cpu - trap packet to cpu port
guest-vlan - assign to guest vlan
Examples:
This example shows how to set the unauth-packet all trap-to-cpu
for port 0.
RTK.0> dot1x set unauth-packet port 0 action trap-to-cpu
SFU Product Page 454 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x get unauth-packet
Description:
This command can get unauth-packet action.
Syntax:
dot1x get unauth-pakcet port <PORT_LIST:ports | all> action
Parameter:
ports - specified port list
all – specify all ports
action - packet be treated configuration
Examples:
This example shows how to get unauth-packet action for port 0.
RTK.0> dot1x get unauth-packet port 0 action
Port Unauth Action
0 Drop
RTK.0>
SFU Product Page 455 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x set guest-vlan
Description:
This command use to assign vid for guest vlan and it can set the
packet belong to guset vlan can forward to authed destination
mac or not.
Syntax:
dot1x set guest-vlan vid vid
dot1x set guest-vlan to-auth-da <allow | disallow>
Parameter:
vid – specify the numeric VLAN identifier
to-auth-da – forward to authed destination mac
Allow - allow configuration
Disallow - disallow configuration
Examples:
This example can assign VID 200 to guest vlan and it set guest
vlan packet can not forward to authed destination mac.
RTK.0> vlan create vlan-table vid 200
RTK.0> dot1x set guest-vlan vid 200
RTK.0> dot1x set guest-vlan to-auth-da disallow
SFU Product Page 456 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
dot1x get guest-vlan
Description:
This command can get dot1x guest vlan setting.
Syntax:
dot1x get guest-vland
Parameter:
None
Examples:
This example shows how to get dot1x guest vlan setting.
RTK.0> dot1x get guest-vlan
Guest vlan: 200
Allow guest vlan talk to auth. DA: Disable
RTK.0>
SFU Product Page 457 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.20. Trunk commands
trunk init
Description:
This command can reset & initialize port trunking module.
Syntax:
trunk init
Parameter:
None
Examples:
This example shows how to reset initial port trunking function.
RTK.0>
RTK.0> trunk init
RTK.0> trunk get member-port
Trunk portmask: none
SFU Product Page 458 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set distribute-algorithm
Description:
This command can configure the distribution algorithm for trunk
group.
Syntax:
trunk set distribute-algorithm [ dst-ip ] [ dst-l4-port ]
[ dst-mac ] [ src-ip ] [ src-l4-port ] [ src-mac ] [ src-port ]
Parameter:
dst-ip - Destination IP
dst-l4-port - Destination Layer 4 port number
dst-mac - Destination MAC address
src-ip - Source IP
src-l4-port - Source Layer 4 port number
src-mac - Source MAC address
src-port - Source port
Examples:
This example shows how to configure the distribution algorithm
as “Destination IP” + “Source IP”.
RTK.0> trunk set distribute-algorithm dst-ip src-ip
RTK.0>
SFU Product Page 459 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get distribute-algorithm
Description:
This command can get the distribution algorithm for trunk group.
Syntax:
trunk get distribute-algorithm
Parameter:
RTK.0> trunk get distribute-algorithm
None
Examples:
This example shows how to get the distribution algorithm.
Distribute Algorithm:
Source IP
Destination IP
RTK.0>
SFU Product Page 460 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set flood-mode
Description:
This command can configure the flood mode for trunk group.
Syntax:
trunk set flood-mode < normal | to-1st-logic-port >
Parameter:
normal - Flooding packets will be forwarded
according to distribution algorithm
to-1st-logic-port - Flooding packets will be forwarded
according to 1st logical port
Examples:
This example shows how to configure the flood mode to
“to-1st-logical port”.
RTK.0> trunk set flood-mode to-1st-logic-port
RTK.0>
SFU Product Page 461 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get flood-mode
Description:
This command can get the flood mode for trunk group.
Syntax:
trunk get flood-mode
Parameter:
None
Examples:
This example shows how to get the flood mode.
RTK.0> trunk get flood-mode
Flood Mode: Forward to first port
RTK.0>
SFU Product Page 462 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set flow-control
Description:
This command can configure the flow control ability for trunk
group. When enabling this ability, Apollo will send pause frame
to the ports which receive packet and forward the packets to
trunk group. This ability is used when users want to change
distribution algorithm of member ports
Syntax:
trunk set flow-control state < disable | enable >
Parameter:
disable - Disable flow Control
enabled - Enable flow control
Examples:
This example shows how to configure the flow control to enabled.
RTK.0> trunk set flow-control state enable
RTK.0>
SFU Product Page 463 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get flow-control
Description:
This command can get the flow control ability for trunk group.
Syntax:
trunk get flow-control
Parameter:
None
Examples:
This example shows how to get the flow control ability.
RTK.0> trunk get flow-control
Trunk Flow Control: Enable
RTK.0>
SFU Product Page 464 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set hash-mapping
Description:
This command can configure the mapping table of hash value and
port ID in trunk group.
Syntax:
Parameter:
trunk set hash-mapping hash-value < value | all > port port
value - Specify the hash value (0 ~ 15)
all - Specify all hash value
port - The port ID in trunk group
Examples:
This example shows how to configure the 16 hash values to 4 trunk
ports.
RTK.0> trunk set hash-mapping hash-value 0 port 0
RTK.0> trunk set hash-mapping hash-value 1 port 0
RTK.0> trunk set hash-mapping hash-value 2 port 0
RTK.0> trunk set hash-mapping hash-value 3 port 0
RTK.0> trunk set hash-mapping hash-value 4 port 1
RTK.0> trunk set hash-mapping hash-value 5 port 1
RTK.0> trunk set hash-mapping hash-value 6 port 1
RTK.0> trunk set hash-mapping hash-value 7 port 1
RTK.0> trunk set hash-mapping hash-value 8 port 2
RTK.0> trunk set hash-mapping hash-value 9 port 2
RTK.0> trunk set hash-mapping hash-value 10 port 2
RTK.0> trunk set hash-mapping hash-value 11 port 2
RTK.0> trunk set hash-mapping hash-value 12 port 3
RTK.0> trunk set hash-mapping hash-value 13 port 3
RTK.0> trunk set hash-mapping hash-value 14 port 3
RTK.0> trunk set hash-mapping hash-value 15 port 3
RTK.0>
SFU Product Page 465 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get hash-mapping
Description:
This command can get the mapping table of hash value and port
ID in trunk group.
Syntax:
trunk get hash-mapping hash-value all
trunk get hash-mapping hash-value value
Parameter:
all - Specify all hash value
value - specify the hash value (0 ~ 15)
Examples:
This example shows how to get all hash value in mapping table.
RTK.0> trunk get hash-mapping hash-value all
Hash Value 0 to Port 0 in trunk group
Hash Value 1 to Port 0 in trunk group
Hash Value 2 to Port 0 in trunk group
Hash Value 7 to Port 1 in trunk group
Hash Value 10 to Port 2 in trunk group
Hash Value 14 to Port 3 in trunk group
RTK.0>
Hash Value 3 to Port 0 in trunk group
Hash Value 4 to Port 1 in trunk group
Hash Value 5 to Port 1 in trunk group
Hash Value 6 to Port 1 in trunk group
Hash Value 8 to Port 2 in trunk group
Hash Value 9 to Port 2 in trunk group
Hash Value 11 to Port 2 in trunk group
Hash Value 12 to Port 3 in trunk group
Hash Value 13 to Port 3 in trunk group
Hash Value 15 to Port 3 in trunk group
SFU Product Page 466 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set member-port
RTK.0>
Description:
This command can configure the member ports of trunk group.
Syntax:
trunk set member-port < PORT_LIST:ports | none >
Parameter:
ports - Trunk port mask (0-1, 4-5)
none - Specify no ports in trunk
Examples:
This example shows how to configure a trunk group with member
ports 0-1.
RTK.0> trunk set member-port 0-1
SFU Product Page 467 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get member-port
Description:
This command can get the member ports of trunk group.
Syntax:
trunk get member-port
Parameter:
None
Examples:
This example shows how to get a trunk group member ports
RTK.0> trunk get member-port
Trunk portmask: 0-1
RTK.0>
SFU Product Page 468 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk set mode
Description:
This command can configure the mode of trunk group.
Dumb mode: The destination port choosen is based on system hash
value mapping table.
Normal mode: The destination port choosen is based on customer
hash value mapping table.
Syntax:
trunk set mode < dumb | normal >
- Normal mode
Parameter:
dumb - Dumb mode
normal
Examples:
This example shows how to configure a trunk mode as “normal
mode”.
RTK.0> trunk set mode normal
RTK.0>
SFU Product Page 469 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get mode
Parameter:
Description:
This command can get the mode of trunk group.
Syntax:
trunk get mode
None
Examples:
This example shows how to get trunk mode.
RTK.0> trunk get mode
Trunk Mode: Normal mode
RTK.0>
SFU Product Page 470 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
trunk get queue-empty
Description:
This command can get the port mask wich all queues are empty.
Syntax:
trunk get queue-empty
Parameter:
None
Examples:
This example shows how to get queue empty mask.
RTK.0> trunk get queue-empty
Queue Empty Port Mask: none
RTK.0>
SFU Product Page 471 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.21. Auto Fallback commands
auto-fallback set port
Description:
This command can configure the state of auto fallback per port
basis.
Syntax:
Parameter:
auto-fallback set port PORT_LIST:ports state < disable | enable
>
ports - Specify a port list
disable - Disable Auto fallback
enable - Enable Auto fallback
Examples:
This example shows how to enable auto fallback at port 0 & 1.
RTK.0> auto-fallback set port 0-1 state enable
RTK.0>
SFU Product Page 472 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback get port
Description:
This command can get the state / status / counter of auto fallback
per port basis .
Syntax:
auto-fallback get port PORT_LIST:ports state
auto-fallback get port PORT_LIST:ports error-counter
auto-fallback get port PORT_LIST:ports monitor-counter
auto-fallback get port PORT_LIST:ports restore
auto-fallback get port PORT_LIST:ports valid-flow
- the state of restore power level
- the state of valid flow
Examples:
This example shows how to get auto fallback information at port
0 & 1.
Parameter:
ports - Specify a port list
state - state of auto fallback
error-counter - Error packet counter
monitor-counter - Monitor packet counter
restore
valid-flow
RTK.0> auto-fallback get port 0-1 state
Port 0 Auto Fallback State: Enable
Port 1 Auto Fallback State: Enable
RTK.0> auto-fallback get port 0-1 error-counter
Port 0 Error counter: 0
Port 1 Error counter: 0
SFU Product Page 473 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
RTK.0> auto-fallback get port 0-1 monitor-counter
Port 0 Monitort counter: 0
Port 1 Monitort counter: 0
RTK.0> auto-fallback get port 0-1 restore
Port 1 Valid Flow state: None Valid Flow
Port 0 Restore Power Level: Not Restore Power Level
Port 1 Restore Power Level: Not Restore Power Level
RTK.0> auto-fallback get port 0-1 valid-flow
Port 0 Valid Flow state: None Valid Flow
RTK.0>
SFU Product Page 474 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback set error-count
Description:
This command can configure the error count threshold of auto
fallback..
1
- Specify the error count threshold to 4
- Specify the error count threshold to 128
Examples:
Syntax:
auto-fallback set error-count < 1 | 2 | 4 | 8 | 16 | 32 | 64 |
128 >
Parameter:
- Specify the error count threshold to 1
2 - Specify the error count threshold to 2
4
8 - Specify the error count threshold to 8
16 - Specify the error count threshold to 16
32 - Specify the error count threshold to 32
64 - Specify the error count threshold to 64
128
This example shows how to configure the error count threshold
as 8
RTK.0> auto-fallback set error-count 8
RTK.0>
SFU Product Page 475 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback get error-count
Description:
This command can get the error count threshold of auto fallback..
Syntax:
auto-fallback set error-count
Parameter:
None.
Examples:
This example shows how to get the error count threshold.
RTK.0> auto-fallback get error-count
Max Error Count: 8 packets
RTK.0>
SFU Product Page 476 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback set monitor-count
Description:
This command can configure the monitor count threshold of auto
fallback.
Syntax:
RTK.0> auto-fallback set monitor-count 8K
auto-fallback set monitor-count < 8K | 16K | 32K | 64K | 128K
| 256K | 512K | 1M >
Parameter:
8K - Specify the monitor count threshold to 8K
16K - Specify the monitor count threshold to 16K
32K - Specify the monitor count threshold to 32K
64K - Specify the monitor count threshold to 64K
128K - Specify the monitor count threshold to
128K
256K - Specify the monitor count threshold to
256K
512K - Specify the monitor count threshold to
512K
1M - Specify the monitor count threshold to 1M
Examples:
This example shows how to configure the monitor count threshold
as 8K
RTK.0>
SFU Product Page 477 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback get monitor-count
auto-fallback set monitor-count < 8K | 16K | 32K | 64K | 128K
| 256K | 512K | 1M >
Description:
This command can get the monitor count threshold of auto
fallback.
Syntax:
Parameter:
None.
Examples:
This example shows how to get the monitor count threshold.
RTK.0> auto-fallback get monitor-count
Max Monitor Count: 8K packets
RTK.0>
SFU Product Page 478 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback set ignore-timeout
Description:
RTK.0>
This command can configure the ignore timeout ability of auto
fallback. When enabling this ability, TCP timeout event will not
be treated as an error.
Syntax:
auto-fallback set ignore-timeout < disable | enable >
Parameter:
disable - enable ignore timeout ability
enable - disable ignore timeout ability
Examples:
This example shows how to configure the ignore timeout ability
as enabled
RTK.0> auto-fallback set ignore-timeout enable
SFU Product Page 479 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback get ignore-timeout
Description:
This command can get the ignore timeout ability of auto fallback.
Syntax:
auto-fallback get ignore-timeout
Parameter:
Examples:
This example shows how to get the ignore timeout ability as
enabled
None.
RTK.0> auto-fallback get ignore-timeout
Ignore Timeout State: Enable
RTK.0>
SFU Product Page 480 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback set reduce-power-level
Description:
This command can configure the ability of reducing power level
when the error event is great than error count threshold.
Syntax:
auto-fallback set reduce-power-level < disable | enable >
- enable reduce power level ability
Parameter:
disable
enable - disable reduce power level ability
Examples:
This example shows how to configure the reduce power level
ability as enabled
RTK.0> auto-fallback set reduce-power-level enable
RTK.0>
SFU Product Page 481 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback get reduce-power-level
Description:
auto-fallback get reduce-power-level
Examples:
This command can get the ability of reducing power level.
Syntax:
Parameter:
None
This example shows how to get the reduce power level ability as
enabled
RTK.0> auto-fallback get reduce-power-level
Reduce Power Level State: Enable
RTK.0>
SFU Product Page 482 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback set timer
Description:
- disable timer
timer
This command can configure the state of timer and its value.
Syntax:
auto-fallback set timer state < disable | enable >
auto-fallback set timer timer
Parameter:
disable
enable - enable timer
- the value of timer
Examples:
This example shows how to configure the timer as enabled and its
value as 1000
RTK.0> auto-fallback set timer 1000
RTK.0> auto-fallback set timer state en
RTK.0>
SFU Product Page 483 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
auto-fallback get timer
Description:
This command can get the state of timer and its value.
Syntax:
auto-fallback get timer state
auto-fallback get timer
Parameter:
None
Examples:
This example shows how to get the state of timer its value.
Timer State: Enable
Timeout threshold: 4ms
RTK.0> auto-fallback get timer state
RTK.0> auto-fallback get timer
RTK.0>
SFU Product Page 484 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
2.22. OAM commands
oam init
Description:
This command can reset & initialize OAM module. The oam module
used to control received oam packet behavior.
Syntax:
oam init
Parameter:
None
Examples:
This example shows how to initialize OAM module.
RTK.0> oam init
RTK.0>
SFU Product Page 485 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam set state
Description:
This command can enable or disable oam function. Enable oam
function will trap oam packet to CPU.
Syntax:
oam set state <disable | enable>
Parameter:
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to enable oam function.
RTK.0> oam set state enable
RTK.0>
SFU Product Page 486 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam get state
Description:
This command can get the oam status.
Syntax:
oam get state
Parameter:
None
Examples:
This example shows how to get oam state.
RTK.0> oam get state
OAM State is Enable
SFU Product Page 487 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam set multiplexer
Description:
oam set multiplexer port <PORT_LIST:ports | all> action <forwad
| discard | from-cpu-only>
- specified port list
This example shows how to set port 0 oam multiplexer action to
forward.
This command used to set oam transmitting multiplexing function.
Syntax:
Parameter:
ports
all – specify all ports
forward - forward non-oam packet
discard - discard non-oam packet
from-cpu-only - accept packet from cpu port only
Examples:
RTK.0> oam set multiplexer port 0 action forward
0 Forward
RTK.0>
SFU Product Page 488 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam get multiplexer
Description:
This command can get per port oam multiplexer action.
Syntax:
ports
all
oam get multiplexer port <PORT_LIST:ports | all>
Parameter:
- specified port list
– specify all ports
Examples:
This example shows how to get port 0 oam multiplexer action.
RTK.0> oam get multiplexer port 0
Port Multiplexer Action
0 Forward
RTK.0>
SFU Product Page 489 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam set parser
Description:
This command can set oam parser action.
Syntax:
oam set parser port <PORT_LIST:ports | all> action <forwad |
loopback | discard>
ports
all
forward
lookback
- trap OAMPDUs to CPU
Parameter:
- specified port list
– specify all ports
- forward non-OAMPDUs
- loopback non-OAMPDUs
- drop CRC and receiving FAILED packets
discard - discard non-OAMPDUs
Examples:
This example shows how to set port 0 oam parser acxion to
lookback.
RTK.0> oam set parser port 0 action loopback
Set OAM Parser
Port Parser Action
-----------------------------
0 Loop Back
RTK.0>
SFU Product Page 490 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam get parser
Syntax:
Description:
This command can per port get oam parser action.
oam get parser port <PORT_LIST:ports | all>
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get oam parser action for port 0.
RTK.0> oam get parser port 0
Get OAM Parser
Port Parser Action
-----------------------------
0 Forward
RTK.0>
SFU Product Page 491 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam set trap-priority
Description:
Configure priority for packets trapped to cpu for related oam
functions
Syntax:
oam set trap-priority priority
Parameter:
priority - priority for trapping packets
Examples:
This example shows how to configurate oam trap priority to 7.
RTK.0> oam set trap-priority 7
SFU Product Page 492 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
oam get trap-priority
Description:
Retriving priority for packets trapped to cpu for related oam
function
Syntax:
oam get trap-priority
None
Parameter:
Examples:
This example shows how to get oam trap priority.
RTK.0> oam get trap-priority
OAM Trap Priority is 7
RTK.0>
SFU Product Page 493 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Examples:
2.23. Loop commands
rldp init
Description:
This command can reset & initialize RLDP module.
Syntax:
rldp init
Parameter:
None
This example shows how to initialize RLDP module.
RTK.0> rldp init
RTK.0>
SFU Product Page 494 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set state
Description:
These commands configure the enable/disable RLDP function of the
entire chip and each port. Chip level state configuration has
higher precedence then per port state control.
Syntax:
rldp set state <disable | enable>
rldp set port <PORT_LIST:ports | all> state <disable | enable>
Parameter:
Set RLDP port state
disable - disable configuration
enable - enable configuration
ports - specified port list
all – specify all ports
Examples:
This example shows how to enable the chip and port 1-3’s RLDP
function.
RTK.0> rldp set state enable
RLDP: Disable -> Enable
RTK.0> rldp set port 1-3 state enable
Port state
---- ------------------
1 Disable -> Enable
2 Disable -> Enable
3 Disable -> Enable
RTK.0>
SFU Product Page 495 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get state
Description:
These commands get the chip and port RLDP enable/disable
configuration.
Syntax:
rldp get state
rldp get port <PORT_LIST:ports | all> state
Parameter:
ports - specified port list
all – specify all ports
Examples:
This example shows how to get chip level and port 0-3’s RLDP
configuraitons.
RTK.0> rldp get state
RLDP Enable
RTK.0> rldp get port 0-3 state
Get RLDP port state
Port state
---- --------
0 Disable
1 Enable
2 Enable
3 Enable
SFU Product Page 496 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get status
Description:
Parameter:
- specified port list
This command gets the currently loop status of each port. It
display if the port is currently in looping status and if each
port ever entering/leaving looping status.
Syntax:
rldp get port <PORT_LIST:ports | all> status
ports
all – specify all ports
Examples:
This example shows how to display port 1 and port 3s’ RLDP status.
RTK.0> rldp get port 1,3 status
Get RLDP port looped state
Port looping enter leave
---- ------- ----- -----
1
3
RTK.0>
SFU Product Page 497 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp clear status
Description:
This command clears the entering/leaving status of specified
port.
Syntax:
rldp clear port <PORT_LIST:ports | all> status <entering |
leaving>
Parameter:
This example shows how to clear port 0, 3s’ entering status and
port 1, 2s’ leaving status.
Clear RLDP port looped state
1 V
ports - specified port list
all – specify all ports
entering - enter looping status
leaving - leave looping status
Examples:
RTK.0> rldp clear port 0,3 status entering
Clear RLDP port looped state
Port enter leave
---- ----- -----
0 V
3 V
RTK.0>
RTK.0> rldp clear port 1,2 status leaving
Port enter leave
---- ----- -----
2 V
RTK.0>
SFU Product Page 498 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set magic
Syntax:
Description:
This command sets the magic of outgoing RLDP frames.
rldp set magic mac
Parameter:
mac - mac address
Examples:
This example shows how to configure the magic of RLDP.
RTK.0> rldp set magic 01:02:03:04:05:06
RLDP Magic: 00:00:00:00:00:00 -> 01:02:03:04:05:06
RTK.0>
SFU Product Page 499 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get magic
This example shows how to get magic of RLDP.
RTK.0>
Description:
This command gets the magic used by RLDP.
Syntax:
rldp get magic
Parameter:
None
Examples:
RTK.0> rldp get magic
RLDP Magic: 01:02:03:04:05:06
SFU Product Page 500 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get identifier
Description:
This command gets the current identifier used by RLDP which is
generated by random number generator.
Syntax:
rldp get identifier
Parameter:
None
Examples:
This example shows how to get identifier of RLDP.
RTK.0> rldp get identifier
RLDP Identifier: 5A:E7:BD:3C:81:96
RTK.0>
SFU Product Page 501 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set compare-typ
Description:
This command configures the RLDP compare type to either compare
both identifier and magic or magic only.
Syntax:
rldp set compare-typ <magic-and-identifier | magic-only>
Parameter:
magic-and-identif
ier
- checking both magic and identifier
magic-only - checking magic only
Examples:
This example shows how to configure RLDP to compare magic only.
RTK.0> rldp set compare-type magic-only
RLDP Compare Type: Magic Number + Identifier -> Magic Number
RTK.0>
SFU Product Page 502 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get compare-typ
Description:
This command gets the current compare type used by RLDP.
Syntax:
rldp get compare-typ
Parameter:
None
Examples:
This example shows how to get compare type of RLDP.
TK.0> rldp get compare-type
RLDP Compare Type: Magic Number
RTK.0>
SFU Product Page 503 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set period
Description:
loop
This command set the check/loop state period of RLDP.
Syntax:
rldp set <check | loop> period time
Parameter:
check - checking state
- looping state
time - time to send packets, unit 1 ms
Examples:
This example shows how to configure RLDP’s check and loop state
period.
RTK.0> rldp set check period 5000
RLDP check period: 2000 ms -> 5000 ms
RTK.0>
RTK.0> rldp set loop period 5000
RLDP loop period: 2000 ms -> 5000 ms
RTK.0>
SFU Product Page 504 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get period
Description:
This command gets the check/loop state period of RLDP.
Syntax:
rldp get <check | loop> period
Parameter:
check - checking state
loop
- looping state
Examples:
This example shows how to get RLDP’s check/loop state period.
RTK.0> rldp get check period
RLDP check period: 5000 ms
RTK.0> rldp get loop period
RLDP loop period: 5000 ms
RTK.0>
SFU Product Page 505 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set number
Description:
This command sets the check/loop state of RLDP frame send count.
Syntax:
rldp set <check | loop> number count
Parameter:
check - checking state
loop - looping state
count
RTK.0> rldp set loop number 3
- number of sending packets
Examples:
This example shows how to configure RLDP’s check and loop state
frame send count.
RTK.0> rldp set check number 5
RLDP check number count: 4 -> 5
RLDP loop number count: 4 -> 3
RTK.0>
SFU Product Page 506 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get number
Description:
This command gets the check/loop state of RLDP send count.
Syntax:
rldp get <check | loop> number
Parameter:
check - checking state
loop - looping state
Examples:
This example shows how to get send count of RLDP check and loop
state.
RTK.0> rldp get check number
RLDP check number count: 5
RTK.0> rldp get loop number
RLDP loop number count: 3
RTK.0>
SFU Product Page 507 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set control-state
Description:
This command set the force looping state of each port to indicate
that the ports has entering loop state.
Syntax:
rldp set port <PORT_LIST:ports | all> control-state <looping |
non-looping>
Parameter:
ports - specified port list
all – specify all ports
looping - looping state
non-looping - non-looping state
Examples:
This example shows how to configure port 0-2 enter loop state
and leave.
RTK.0> rldp set port 0-2 control-state looping
RTK.0>
RTK.0>
RTK.0> rldp get port 0-3 status
Get RLDP port looped state
Port looping enter leave
---- ------- ----- -----
0 V V
1 V V
2 V V
3
RTK.0> rldp set port 1,2 control-state none-looping
RTK.0>
RTK.0> rldp get port 0-3 status
Get RLDP port looped state
Port looping enter leave
---- ------- ----- -----
0 V V
1 V
2 V
3
SFU Product Page 508 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get control-state
Description:
This command gets the force looping state of RLDP.
- specified port list
– specify all ports
Examples:
RLDP port control-state
0: Looping
3: None-looping
Syntax:
rldp get port <PORT_LIST:ports | all> control-state
Parameter:
ports
all
This example shows how get port 0-4s’ the force looping state
of RLDP.
RTK.0> rldp get port 0-4 control-state
Port state
---- ------------
1: None-looping
2: None-looping
4: None-looping
SFU Product Page 509 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get looped-port-id
Description:
This command get the port ID detected by RLDP which is looped
with specified port.
Syntax:
rldp get port <PORT_LIST:ports | all> looped-port-id
Parameter:
ports - specified port list
all
Examples:
– specify all ports
This example shows how to get the looped port id of the specified
port.
RTK.0> rldp get port 0-4 looped-port-id
Get RLDP port looped port id
Port looped port
---- -----------
0 0
1 0
2 0
3 0
4 0
SFU Product Page 510 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set re-generate-identifier
Description:
This command regenerates the identifier used by RLDP.
Syntax:
rldp set re-generate-identifier
Parameter:
None
Examples:
This example shows how to regenerate the identifier of RLDP.
RTK.0> rldp get identifier
RLDP Identifier: AD:86:E0:14:AE:5B
RTK.0> rldp set re-generate-identifier
RTK.0> rldp get identifier
RLDP Identifier: 72:74:33:30:4B:0D
RTK.0>
SFU Product Page 511 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set handle
Description:
This command configures that RLDP frame should processed by chip
or software.
Syntax:
rldp set handle <hardware | software>
Parameter:
hardware - detect by hardware
software - detect by software
Examples:
This example shows how to configure the RLDP should processed
by chip hardware.
RTK.0> rldp set handle hardware
RTK.0>
SFU Product Page 512 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get handle
Description:
This command gets the current RDLP handler.
Syntax:
rldp get handle
Parameter:
None
Examples:
This example shows how get the current RLDP handler.
RTK.0> rldp set handle hardware
RTK.0>
SFU Product Page 513 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set mode
rldp set mode <sa-moving | periodic>
sa-movin
periodic
RTK.0> rldp set mode periodic
Description:
This command configures the RLDP detection mode to either
sa-moving or periodic mode.
Syntax:
Parameter:
- detect by host port moving
- detect periodicly
Examples:
This example shows how to configure the RLDP to periodic mode.
RTK.0>
SFU Product Page 514 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get mode
Description:
rldp get mode
None
RTK.0> rldp get mode
This command gets the current RLDP detection mode.
Syntax:
Parameter:
Examples:
This example shows how to get the current RLDP detection mode.
RLDP Mode: Peroidical
SFU Product Page 515 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp set bypass-flow-control
Description:
rldp set bypass-flow-control state <disable | enable>
state
This command configures if RLDP affects by flow control
mechanism.
Syntax:
Parameter:
- state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how to configure RLDP to bypass flow control
mechanism.
RTK.0> rldp set bypass-flow-control state enable
RLDP Bypass: Disable ->Enable
RTK.0>
SFU Product Page 516 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rldp get bypass-flow-control
Description:
This command gets the current state of RLDP bypass flowcontrol.
Syntax:
rldp get bypass-flow-control state
RTK.0> rldp get bypass-flow-control
Parameter:
state - state configuration
Examples:
This example shows how to get the current bypass flowcontrol
state of RLDP.
RLDP Bypass: Enable
RTK.0>
SFU Product Page 517 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rlpp set trap
Description:
This command configure if the RLPP packet is trapped to CPU or
not.
Syntax:
rldp set trap state <disable | enable>
Parameter:
state - state configuration
disable - disable configuration
enable - enable configuration
Examples:
This example shows how set RLPP packet to no trapped to CPU.
RTK.0> rlpp set trap state disable
RTK.0>
SFU Product Page 518 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
rlpp get trap
Description:
This command gets current RLPP trap state.
Syntax:
rlpp get trap state
Parameter:
state - state configuration
Examples:
This example shows how to get the trap state of RLPP.
RTK.0> rlpp get trap
RLPP Trap to CPU: Disable
RTK.0>
SFU Product Page 519 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
Interrupt commands
interrupt init
Description:
This command can reset interrupt mask and clear interrupt status.
Syntax:
interrupt init
Parameter:
None
Examples:
This example shows how intitalize interrupt.
RTK.0> interrupt init
SFU Product Page 520 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt set mask
Description:
This command can turn on/off the interrupt mask.
Syntax:
interrupt set mask < all | link-change | meter-exceed |
learn-over | speed-change | special-congestion | loop-detection
| cable-diag | acl | gphy | serdes | gpon | epon | ptp | dying-gasp
| thermal | adc > state < disable | enable >
Parameter:
- select all interrupt mask bit
- mask for link change interrupt
- mask for cable diagnostic interrupt
all
link-change
meter-exceed - mask for meter exceed interrupt
learn-over - mask for L2 table learn over interrupt
speed-change - mask for port speed change interrupt
special-congestion - mask for special congestion interrupt
loop-detection - mask for loop dection interrupt
cable-diag
acl - mask for acl interrupt
gphy - mask for GPHY interrupt
serdes - mask for Serdes interrupt
gpon - mask for GPON interrupt
epon - mask for EPON interrupt
ptp - mask for PTP interrupt
dying-gasp - mask for DyingGasp interrupt
thermal - mask for Thermal exceed interrupt
adc - mask for ADC interrupt
disable - disable the interrupt mask
enable - enable the interrupt mask
Examples:
This example show how to turn on GPON interrupt mask.
RTK.0> interrupt set mask gpon state enable
SFU Product Page 521 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt get mask
Description:
This command can turn on/off the interrupt mask.
- mask for GPHY interrupt
- mask for ADC interrupt
Syntax:
interrupt get mask < all | link-change | meter-exceed |
learn-over | speed-change | special-congestion | loop-detection
| cable-diag | acl | gphy | serdes | gpon | epon | ptp | dying-gasp
| thermal | adc > state
Parameter:
all - select all interrupt mask bit
link-change - mask for link change interrupt
meter-exceed - mask for meter exceed interrupt
learn-over - mask for L2 table learn over interrupt
speed-change - mask for port speed change interrupt
special-congestion - mask for special congestion interrupt
loop-detection - mask for loop dection interrupt
cable-diag - mask for cable diagnostic interrupt
acl - mask for acl interrupt
gphy
serdes - mask for Serdes interrupt
gpon - mask for GPON interrupt
epon - mask for EPON interrupt
ptp - mask for PTP interrupt
dying-gasp - mask for DyingGasp interrupt
thermal - mask for Thermal exceed interrupt
adc
Examples:
This example show how to display GPON interrupt mask.
RTK.0> interrupt get mask gpon state
IMR: Enable
SFU Product Page 522 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt get status
Description:
This command get the interrupt status.
Syntax:
interrupt get status < all | link-change | meter-exceed |
learn-over | speed-change | special-congestion | loop-detection
| cable-diag | acl | gphy | serdes | gpon | epon | ptp | dying-gasp
| thermal | adc >
Parameter:
all - select all interrupt mask bit
link-change - status for link change interrupt
meter-exceed - status for meter exceed interrupt
learn-over - status for L2 table learn over interrupt
loop-detection
- status for acl interrupt
gpon
ptp
speed-change - status for port speed change interrupt
special-congestion - status for special congestion interrupt
- status for loop dection interrupt
cable-diag - status for cable diagnostic interrupt
acl
gphy - status for GPHY interrupt
serdes - status for Serdes interrupt
- status for GPON interrupt
epon - status for EPON interrupt
- status for PTP interrupt
dying-gasp - status for DyingGasp interrupt
thermal - status for Thermal exceed interrupt
adc - status for ADC interrupt
Examples:
This example show how to display GPON interrupt status.
RTK.0> interrupt get status gpon
IMS: Disable
SFU Product Page 523 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt clear status
Description:
This command clear the interrupt status.
Parameter:
link-change - status for link change interrupt
special-congestion - status for special congestion interrupt
- status for loop dection interrupt
acl
- status for GPHY interrupt
epon
ptp
dying-gasp
thermal - status for Thermal exceed interrupt
- status for ADC interrupt
Examples:
This example show how to clear GPON interrupt status.
Syntax:
interrupt clear status < all | link-change | meter-exceed |
learn-over | speed-change | special-congestion | loop-detection
| cable-diag | acl | gphy | serdes | gpon | epon | ptp | dying-gasp
| thermal | adc >
all - select all interrupt mask bit
meter-exceed - status for meter exceed interrupt
learn-over - status for L2 table learn over interrupt
speed-change - status for port speed change interrupt
loop-detection
cable-diag - status for cable diagnostic interrupt
- status for acl interrupt
gphy
serdes - status for Serdes interrupt
gpon - status for GPON interrupt
- status for EPON interrupt
- status for PTP interrupt
- status for DyingGasp interrupt
adc
RTK.0> inter clear status gpon
SFU Product Page 524 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt get status detail
Description:
Syntax:
speed-change - status for port speed change interrupt
- status for GPHY interrupt
This example shows how to display link up interrupt detail
status.
This command get the specific interrupt status for ports or PHYs.
interrupt get status < speed-change | link-up | link-down | gphy
> detail
Parameter:
link-up - status for link up interrupt
link-down - status for link down interrupt
gphy
Examples:
RTK.0> interrupt get status link-up detail
Status: 0x00000000
SFU Product Page 525 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt clear status detail
Description:
This command clear the specific interrupt status for ports or
PHYs.
link-up - status for link up interrupt
RTK.0> interrupt clear status link-up detail
Syntax:
interrupt clear status < speed-change | link-up | link-down |
gphy > detail
Parameter:
speed-change - status for port speed change interrupt
link-down - status for link down interrupt
gphy - status for GPHY interrupt
Examples:
This example show how to clear all ports link up interrupt
status.
SFU Product Page 526 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt set polarity
Description:
This command configure the interrupt polarity is high active or
low active while trigged.
Syntax:
interrupt set polarity < high | low >
Parameter:
high - high active
low - low active
Examples:
This example show how to set the interrupt polarity as high
active.
RTK.0> interrupt set polarity high
SFU Product Page 527 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
interrupt get polarity
Description:
This command get the interrupt polarity is high active or low
active while trigged.
Parameter:
Syntax:
interrupt set polarity
None
Examples:
This example show how to display the interrupt polarity.
RTK.0> interrupt get polarity
Polarity: High
SFU Product Page 528 / 529 Rev. 0.01
Realtek
CONFIDENTIAL
for Loso Technology, Inc
PON Diag Shell
User Guide
