Single Badge Solutions for Identication and Access
Overview
The RF IDeas pcProx Plus is a cutting-edge card reader that combines proximity and contactless technologies into
one reader. It is a desktop reader that is capable of reading both 125 kHz proximity cards and 13.56 MHz contactless
cards. This reader eliminates the need for manual entry and provides error-free identication and security throughout the
workplace. The pcProx Plus allows users to use their building access card or any 125 kHz or 13.56 MHz tags/labels for
other forms of identication.
The plug-n-play reader comes with ash memory, allowing users to quickly congure the output to meet their needs. With
its dual-frequency multi-technology, the pcProx Plus is highly congurable and capable of simultaneously handling any
two of the available technologies.
As a card and badge enroller or reader, it emulates a keyboard to keystroke the card’s data to the cursor’s location in an
application. The reader can be congured to add keystrokes and commands before or after the card’s data.
The pcProx Plus reader can be used as a stand-alone unit, or can be seamlessly integrated with other software
applications using the optional Software Developer’s Kit (SDK). As an integrated reader, it has the ability to work with a
multitude of applications.
Applications
WaveID® is the standard that enables badge-based reader solutions throughout the workplace. It gives a name to the many badge-based authentication and identication
solutions powered by RF IDeas readers. In today’s business environment, most employees carry badges for building access. WaveID in action is both the physical place for
employees to wave their badge for identication, as well as a visual cue that an RF IDeas reader powers a specic device or solution.
pcProx® Plus Enroll
Dual-frequency proximity and contactless
card reader for identication and enrollment
125 kHz Proximity &
13.56 MHz Contactless
PC/LAN Access Control
Application Log-On
Employee Identication
PLC & Embedded Controllers
Manufacturing
OEM
oem
computer
logon
manufacturing
Time & Attendance
Meeting Attendance, Visitor Management
Hoteling
Secure Printing
Point of Sale
point of
sale
multi-function
printers
Dispensing
Mobile
Physical Access
Toll Free: 866-439-4884 Sales@RFIDeas.com
Phone: 847-870-1723
pcProx Plus
Single Badge Solutions for Identication and Access
1/15 A
Features
Easy Interface and Protocol: USB models connect
directly to a USB port and can be congured to send
data as keystroking, non-keystroking or serial ASCII.
RS-232 models connect to a serial port and send data
as ASCII. Ethernet models connect through an RJ45
connection and are sent data as either ASCII or E/IP.
Note: To utilize PoE and E/IP features with some models, a C-6200
adapter may be required
Compatibility: Compatible with Windows CE®/2000®/XP®/
Vista®/7®, Macintosh®, Solaris™, ThinManager® thin
clients, and Linux. (Free conguration software required
on Windows® operating system.)
Improves Accuracy and Productivity: Eliminates errors
associated with individual identication.
Versatile Mounting Options: Featuring an articulated
cable, the standard housing reader can easily be
mounted on kiosks, monitors, time clocks, and more.
*Also available in a wall mount design.
Optional Mounting
Brackets
Additional Products and Accessories
Mounted Desktop
Reader
pcProx Plus
82 Series
Surface Mount
www.RFIDeas.com
©2015 RF IDeas. All rights reserved. Specications subject to change without notice. pcProx® and
WaveID® are registered trademarks of RF IDeas. Windows®, Macintosh®, Solaris™, Sun Ray™
and Linux are trademarks of their respective companies. All other trademarks, service marks and
product or service names are property of their respective owners.
Please feel free to call, email or visit our website for a full list of applications,
products, conguration options, supported cards and form factor
specications. Our website includes application videos, support materials,
case studies and detailed information about our product line.
Specications—Desktop
Operating Frequency: Both 125 kHz & 13.56 MHz (Dual)
Typical maximum read range:
125 kHz:
1.0” – 3.0” (2.5 – 7.6 cm) dependent upon proximity card type and
environmental conditions
13.56 MHz:
2.0” – 4.0” (5.0 – 10.0 cm) with PVC ID cards ;
1.0” – 1.5” (2.5 – 3.8 cm) with labels or tags ;
1.0” – 2.0” (2.5 – 5.0 cm) with MIFARE card
Current Consumption: USB Units - Typical 70 mA, max 100 mA;
Serial Units - Typical 75 mA, max 110 mA
Dimensions: 3 3/8” x 2” x 0.6” (8.57cm x 5.08cm x 1.52cm)
Weight: 4.0oz (113.39g)
Housing Color: Black or Pearl
Cable Length: 6 in, 16 in & 6 ft (Custom Lengths Available)
Indicators: Tri-state LED, dual tone beeper
Power Supply: USB Self-powered; PoE; Serial RS-232:
several power options exist
Interface: USB, Serial RS-232, Ethernet
Operating Temperature Range: -22° to 150°F (-30° to 65°C)
Operating Humidity Range: 5% to 95% relative humidity,
non-condensing
Storage Temperature Range: -40° to 185°F (-40° to 85°C)
Certications: FCC, United States; CE Mark, Europe;
C-TICK, RoHS, Industry Canada, UL
Warranty: One year for material/workmanship defects; see
complete policy for details.
Supported Cards
pcProx 125 kHz
AWID Cardax*
CASI-RUSCO® Deister*
DIGITAG EM 410x
Farpointe Data GProx™ II*
HID® Prox HiTag 1, S & 2
Indala® (Motorola) ioProx™ (Kantech)
Keri NXT Keri*
Nexwatch (Honeywell) Pyramid
Radio Key® ReadyKey Pro*
Secura Key Rosslare
Russwin* GE Security
*Unique ID
pcProx 13.56 MHz
iCLASS® SE™ iCLASS ID
iCLASS CSN NFC CSN Type 2/4
I-Code CSN I-tag CSN
ISO 14443A CSN1 ISO 15693 CSN
MIFARE CSN MIFARE Ultralight CSN
my-d CSN DESFire CSN
Tag-It CSN Advant CSN (Legic)
1Select NFC credentials
For a full list of supported cards, visit our website www.RFIDeas.com
