Round Tapered Steel
Catalog
Number
Pole
Height Shaft Size Wall
Thickness
Bolt
Circle
(B.C. )
B.C. Range Base
Plate
Base Plate
Shape Anchor Bolts Anchor Bolt
Projection
Pole
Weight
Wind Load Rating1
85
MPH
90
MPH
100
MPH
110
MPH
Group 1
RTS-H-20-65-A 20' 6.5" x 3.7” .119" 10" 9.5 - 13.0" 12.5" Square (4) 1 x 36 x 4" 4.25" 187 23.1 21.5 17.4 14.4
RTS-H-25-70-A 25' 7.0" x 3.5” .119" 10" 10.0 - 13.0" 12.5" Square (4) 1 x 36 x 4" 4.25" 226 21.2 17.9 14.5 11.8
RTS-H-30-80-A 30' 8.0" x 3.8” .119" 11" 11.0 - 13.5" 12.5" Square (4) 1 x 36 x 4" 4.25" 290 19.5 15.2 12.1 9.8
RTS-H-35-85-A 35' 8.5" x 3.6” .119" 13" 11.5 - 13.5" 12.5" Square (4) 1 x 36 x 4" 4.25" 340 14.9 12.7 10.0 8.7
RTS-H-39-90-A 39' 9.0" x 3.5” .119" 13" 12.5 - 13.5" 12.5" Square (4) 1 x 36 x 4" 4.25" 382 13.4 10.6 8.3 6.5
Group 2
RTS-H-10-50-A 10' 4.4" x 3.0” .119" 8" 8" 8.5" Triangular (3) 3/4 x 17 x 3" 3.5" 60 22.0 21.5 17.4 14.4
RTS-H-12-50-A 12' 4.7" x 3.0” .119" 8" 8" 8.5" Triangular (3) 3/4 x 17 x 3" 3.5" 70 18.8 17.9 14.5 11.8
RTS-H-14-50-A 14' 5.0" x 3.0” .119" 8" 8" 8.5" Triangular (3) 3/4 x 17 x 3" 3.5" 80 17.7 15.2 12.1 9.8
RTS-H-16-50-A 16' 5.2" x 3.0” .119" 8" 8" 8.5" Triangular (3) 3/4 x 17 x 3" 3.5" 95 16.5 12.7 10 8
RTS-H-18-50-A 18' 5.5" x 3.0” .119" 8" 8" 8.5" Triangular (3) 3/4 x 17 x 3" 3.5" 110 14.0 10.6 8.3 6.5
RTS-H-20-60-A 20' 5.8" x 3.0” .119" 8" 8" 8.5" Triangular (3) 3/4 x 17 x 3" 3.5" 125 12.1 8.9 6.8 5.3
Group 3
RTS-H-25-70-B 25' 7.0" x 3.5” .179" 10.0" 9.5 - 10.5" 10.88" Square (4) 1.0 x 36 x 4" 4.25" 280 25.0 22.6 18.1 14.7
RTS-H-30-80-B 30' 8.0" x 3.8” .179" 11.0" 10.5 - 11.5" 11.5" Square (4) 1.25 x 42 x 6" 5.0" 380 25.0 25.0 25.0 21.6
RTS-H-35-95-A 35' 9.5" x 4.6” .119" 13.0" 12.5 - 13.5" 13.0" Square (4) 1.0 x 36 x 4" 4.25" 370 20.0 17.7 14.1 11.5
RTS-H-40-90-A 40' 9.0" x 3.6” .119" 12.5" 12.0 - 13.0" 12.38" Square (4) 1.0 x 36 x 4" 4.25" 355 15.5 13.6 10.6 8.3
RTS-H-40-90-B 40' 9.0" x 3.6” .179" 12.5" 12.0 - 13.0" 12.38" Square (4) 1.25 x 42 x 6" 5.0" 515 25.0 25.0 20.2 16.5
RTS-H-45-10-A 45' 10.0" x 3.7” .119" 13.5" 13.0 - 14.0" 14.0" Square (4) 1.0 x 36 x 4" 4.25" 450 12.4 10.8 8.1 6.1
RTS-H-50-10-A 50' 10.0" x 3.0” .119" 13.5" 13.0 - 14.0" 14.0" Square (4) 1.0 x 36 x 4" 4.25" 475 9.5 8.2 5.8 4.2
RTS-H-50-10-B 50' 10.0" x 3.0” .179" 13.5" 13.0 - 14.0" 14.0" Square (4) 1.25 x 42 x 6" 5.0" 680 19.2 17.4 13.6 10.7
1 Allowable EPA, to determine max pole loading weight, multiply allowable EPA by 30 lbs. Example: RTS-25-70-A pole in 100 MPH zone = 435 lbs (14.5x30)
Allowable EPA values based on AASHTO LTS4 methodology, using 3-second gusts wind speeds; ASCE 7-05
Note: Factory supplied template must be used when setting anchor bolts; Hubbell Lighting will deny any claim for incorrect anchorage placement resulting from failure to use
factory supplied template and anchor bolts
ORDERING INFORMATION
2 DRILL PATTERN S2; 2-Bolt 3 1/2" C-C
3 Due to the slenderness of the pole shaft near the top, only single luminaires and 2 luminaires 180 degrees apart are provided as standard.
Other configurations are possible by using the tenon top and available bracket arms and adapters
4 The noted options must include an elevation and orientation when being specified. The elevation is the height in feet above the base plate and the orientation is the position around
the pole shaft in relation to the standard handhole opening. Options must be located above the standard handhole opening and must be at least 1 foot apart from each other.
5 For group 2 and group3 poles, the GFI option is provision for GFI only. The GFI receptacle and GFI in-use cover can be purchased separately.
6 Group 1 only
7Group 1 and 3 only
• Round tapered steel shafts
• One-piece construction
• Side and tenon mounting available
• Provision for grounding - standard
• Template and galvanized anchor bolts
included
• Group 1 & 3 poles - 4 bolt base design
• Group 2 poles - 3 bolt base design
• Individual nut covers provided for group 1
poles. Full base cover optional
• Group 2 poles decorative acorn 'top' nut
• Full base cover standard for group 3
• Powder coat paint finish - standard
• Handhole with cover - standard
• 4" x 6.5" handhole - Group 1 and 3 poles
• 3" x 5" hand hole - Group 2 poles
• Standard handhole location - 18" above
base plate
Complete part number includes pole style with brand idendifier, height, shaft size designation, wall thickness, either a side or tenon designation and a color
ORDERING INFORMATION
OPTIONS
GFI4,5 GFI Receptacle and
Cover
EHH4Extra Hand-hole
with cover
CO54Coupling, 1/2"
CO74Coupling, 3/4"
OPTIONS (con't)
C204Coupling 2"
MPB4,6 Mid-Pole Bracket
(12" long w/ 2"
pipe tenon, 4" tall)
VM2 2nd mode vibration
damper
SBC7Square Base cover,
2-piece
LAB Less anchor bolts
FINISH
DB Dark Bronze Textured
BL Black Textured
WH White Textured
GT Graphite Textured
PS Platinum Silver Smooth
GYS Gray Smooth
CC Custom Color
ORDERING EXAMPLE: RTS-H-30-80-B -TA-DB-VM2
SIDE MOUNTINGS2,3
1Single Arm Mount
2Two fixtures at 180
2L Two fixtures at 90
3T Three fixtures at 90
3Y Three fixtures at 120
4Four fixtures at 90
TA Tenon (2.365" OD)
TB Tenon (2.875" OD)
TC Tenon (3.5" OD)
OT Open Top (includes pole cap)
TOP MOUNTINGS
S2 3-1/2" CC
POLES
RTS-H
Wall thickness
See details below
Shaft bottom O.D.
Pole height
Series and Brand
