322 SAGINAW CONTROL & ENGINEERING • STOCK PRICE LIST
Catalog Height Width Depth Number Viewing Area Industry Product List
No. (A) (B) (C) Windows Height x Width Standard Code Price
Stainless Steel
SCE-HWK2228(SS)
SCE-HWK2822(SS)
Protective Access
Enclosures
Designed to mount on the exterior of an
enclosure to provide protection for controls
with easy access. Concealed hinges. Black
mini quarter turn latches. Polycarbonate
viewing window. Gasket and hardware
included. For installation information,
consult our Installation Manual at www.
saginawcontrol.com. Made of heavy gauge
carbon steel and powder coated ANSI-61
gray. “SS” parts made of heavy gauge
stainless steel Type 304 with #4 brushed
nish.
IS1 - Industry Standards -
NEMA Type 12 & Type 13
UL Listed Type 12
CSA Type 12
IEC 60529 IP 55
IS2 - Industry Standards -
NEMA Type 4, 12 & Type 13
UL Listed Type 4 & 12
CSA Type 4 & 12
IEC 60529 IP66
IS5 - Industry Standards -
NEMA Type 4, 4X, 12 & Type 13
UL Listed Type 4, 4X & 12
CSA Type 4, 4X & 12
IEC 60529 IP66
Hinged Window Enclosure
Hinged Access Enclosure
Phone (989) 799-6871
Fax (989) 799-4524
Catalog Height Width Depth Industry Product List
No. (A) (B) (C) Standard Code Price
Stainless Steel
Designed to house electrical controls,
instruments and components used in an
indoor or outdoor environment to provide
a degree of protection for the equipment
inside the enclosure against ingress of solid
foreign objects (falling dirt); and provide a
degree of protection with respect to the
harmful effects on the equipment due to the
ingress of water (rain, sleet, snow).
IS2 - Industry Standards -
NEMA Type 4, 12 & Type 13
UL Listed Type 4 & 12
CSA Type 4 & 12
IEC 60529 IP66
IS5 - Industry Standards -
NEMA Type 4, 4X, 12 & Type 13
UL Listed Type 4, 4X & 12
CSA Type 4, 4X & 12
IEC 60529 IP66
Protective Access Enclosures
9
SCE-HWK1212(SS)
SCE-HWK1814(SS)
SCE-HWK2218(SS)
SCE-HWK1212 12.00 12.00 1.50 IS2 P6 310.45
SCE-HWK1814 18.00 14.00 1.50 IS2 P6 360.12
SCE-HWK2218 22.00 18.00 1.50 IS1 P6 434.63
SCE-HWK2228 22.00 28.00 1.50 IS1 P6 496.72
SCE-HWK2822 28.00 22.00 1.50 IS1 P6 496.72
SCE-HWK1212SS 12.00 12.00 1.50 IS5 P6 640.77
SCE-HWK1814SS 18.00 14.00 1.50 IS5 P6 869.25
SCE-HWK2218SS 22.00 18.00 1.50 IS1 P6 1,048.07
SCE-HWK2228SS 22.00 28.00 1.50 IS1 P6 1,296.42
SCE-HWK2822SS 28.00 22.00 1.50 IS1 P6 1,296.42
1 8.00 x 7.38
1 14.00 x 9.38
1 18.00 x 13.38
2 18.00 x 10.56
2 10.88 x 17.38
1 8.00 x 7.38
1 14.00 x 9.38
1 18.00 x 13.38
2 18.00 x 10.56
2 10.88 x 17.38
SCE-HA1010 10.00 10.00 1.50 IS2 P6 247.95
SCE-HA1212 12.00 12.00 1.50 IS2 P6 268.92
SCE-HA1814 18.00 14.00 1.50 IS2 P6 318.22
SCE-HA1010SS 10.00 10.00 1.50 IS5 P6 566.45
SCE-HA1212SS 12.00 12.00 1.50 IS5 P6 592.52
SCE-HA1814SS 18.00 14.00 1.50 IS5 P6 811.61
