Simple Gnuradio User Manual V1.0

User Manual: Pdf

Open the PDF directly: View PDF .
Page Count: 208 [warning: Documents this large are best viewed by clicking the View PDF Link!]

Simple User Manual for Gnuradio 3.1.1

This document is part of GNU Radio

GNU Radio is free software, you can redistribute it and/or modify It under the terms of the GNU

General Public License as published by the Free Software Foundation, either version 3, or (at your

option) any later version.

GNU Radio is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without

even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See

the GNU General Public License for more details.

You should have received a copy of the GNU General Public License along with GNU Radio; see the

file COPYING. If not, write to the Free Software Foundation, Inc., 51 Franklin Street, Boston, MA

02110-1301, USA.

This Document Was Last Updated on:

25-November-2007

By:

Firas Abbas

Simple Gnuradio User Manual Page 2 of 208

Table of Contents

1) GNURADIO PACKAGE........................................................................................................................................ 19

1.1) GNURADIO/BLKS SUB PACKAGE...................................................................................................................... 19

1.1.1) gnuradio/blksimpl/am_demod.py ................................................................................................. 19

1.1.1.1) am_demod_cf ( ) ...................................................................................................................................................19

1.1.1.2) demod_10k0a3e_cf ()...........................................................................................................................................19

1.1.2) gnuradio/blksimpl/channel_model.py ......................................................................................... 19

1.1.2.1) channel_model ( ) .................................................................................................................................................20

1.1.3) gnuradio/blksimpl/cpm.py .............................................................................................................. 20

1.1.3.1) cpm_mod ( ) ...........................................................................................................................................................20

1.1.4) gnuradio/blksimpl/d8psk.py........................................................................................................... 21

1.1.4.1) d8psk_mod ( )........................................................................................................................................................21

1.1.4.2) d8psk_demod ( ) ...................................................................................................................................................21

1.1.5) gnuradio/blksimpl/dbpsk.py........................................................................................................... 22

1.1.5.1) dbpsk_mod ( )........................................................................................................................................................22

1.1.5.2) dbpsk_demod ( ) ...................................................................................................................................................23

1.1.6) gnuradio/blksimpl/dqpsk.py........................................................................................................... 23

1.1.6.1) dqpsk_mod ( )........................................................................................................................................................23

1.1.6.2) dqpsk_demod ( ) ...................................................................................................................................................24

1.1.7) gnuradio/blksimpl/filterbank.py .................................................................................................... 24

1.1.7.1) synthesis_filterbank ( )........................................................................................................................................25

1.1.7.2) analysis_filterbank ( ) ..........................................................................................................................................25

1.1.8) gnuradio/blksimpl/fm_demod.py .................................................................................................. 26

1.1.8.1) fm_demod_cf ( ) ....................................................................................................................................................26

1.1.8.2) demod_20k0f3e_cf ()............................................................................................................................................26

1.1.8.3) demod_200kf3e_cf ()............................................................................................................................................26

1.1.9) gnuradio/blksimpl/fm_emph.py..................................................................................................... 27

1.1.9.1) fm_deemph ( )........................................................................................................................................................27

1.1.9.2) fm_preemph () .......................................................................................................................................................27

1.1.10) gnuradio/blksimpl/gmsk.py............................................................................................................ 28

1.1.10.1) gmsk_mod ( ).......................................................................................................................................................28

1.1.10.2) gmsk_demod ( ) ..................................................................................................................................................29

1.1.11) gnuradio/blksimpl/nbfm_rx.py....................................................................................................... 29

1.1.11.1) nbfm_rx ( ) ............................................................................................................................................................29

1.1.12) gnuradio/blksimpl/nbfm_tx.py....................................................................................................... 30

1.1.12.1) nbfm_tx ( ) ............................................................................................................................................................30

1.1.13) gnuradio/blksimpl/ofdm.py............................................................................................................. 30

1.1.13.1) ofdm_mod ( ) .......................................................................................................................................................30

1.1.13.2) ofdm_demod ( )...................................................................................................................................................31

1.1.14) gnuradio/blksimpl/ofdm_sync_fixed.py ...................................................................................... 31

Simple Gnuradio User Manual Page 3 of 208

1.1.14.1) ofdm_sync_fixed ( ) ...........................................................................................................................................31

1.1.15) gnuradio/blksimpl/ofdm_sync_ml.py........................................................................................... 31

1.1.15.1) ofdm_sync_ml ( ) ................................................................................................................................................31

1.1.16) gnuradio/blksimpl/ofdm_sync_pn.py .......................................................................................... 32

1.1.16.1) ofdm_sync_pn ( )................................................................................................................................................32

1.1.17) gnuradio/blksimpl/ofdm_sync_pnac.py ...................................................................................... 32

1.1.17.1) ofdm_sync_pnac ( ) ...........................................................................................................................................32

1.1.18) gnuradio/blksimpl/ofdm_receiver.py ........................................................................................... 32

1.1.18.1) ofdm_receiver ( ).................................................................................................................................................32

1.1.19) gnuradio/blksimpl/pkt.py ................................................................................................................ 33

1.1.19.1) mod_pkts ( ) .........................................................................................................................................................33

1.1.19.1) demod_pkts ( ) ....................................................................................................................................................33

1.1.20) gnuradio/blksimpl/psk.py................................................................................................................ 34

1.1.21) gnuradio/blksimpl/qam.py .............................................................................................................. 34

1.1.22) gnuradio/blksimpl/qam8.py............................................................................................................ 34

1.1.22.1) qam8_mod ( ).......................................................................................................................................................34

1.1.22.2) qam8_demod ( ) ..................................................................................................................................................34

1.1.23) gnuradio/blksimpl/qam16.py.......................................................................................................... 35

1.1.23.1) qam16_mod ( ).....................................................................................................................................................35

1.1.23.2) qam16_demod ( ) ................................................................................................................................................36

1.1.24) gnuradio/blksimpl/qam64.py.......................................................................................................... 36

1.1.24.1) qam64_mod ( ).....................................................................................................................................................36

1.1.24.2) qam64_demod ( ) ................................................................................................................................................37

1.1.25) gnuradio/blksimpl/qam256.py........................................................................................................ 37

1.1.25.1) qam256_mod ( ) ..................................................................................................................................................37

1.1.25.2) qam256_demod ( )..............................................................................................................................................38

1.1.26) gnuradio/blksimpl/rational_resampler.py................................................................................... 38

1.1.26.1) rational_resampler ( ) ........................................................................................................................................38

1.1.26.2) design_filter ( ) ....................................................................................................................................................39

1.1.27) gnuradio/blksimpl/standard_squelch.py .................................................................................... 39

1.1.27.1) standard_squelch ( )..........................................................................................................................................39

1.1.28) gnuradio/blksimpl/wfm_rcv.py ...................................................................................................... 39

1.1.28.1) wfm_rcv ( )............................................................................................................................................................40

1.1.29) gnuradio/blksimpl/wfm_rcv_pll.py ............................................................................................... 40

1.1.29.1) wfm_rcv_pll ( ).....................................................................................................................................................40

1.1.30) gnuradio/blksimpl/wfm_tx.py......................................................................................................... 40

1.1.30.1) wfm_tx ( ) ..............................................................................................................................................................40

1.1.31) gnuradio/blksimpl/cvsd.py ............................................................................................................. 41

1.1.31.1) cvsd_encode ( )...................................................................................................................................................41

1.1.31.2) cvsd_decode ( )...................................................................................................................................................41

1.2) GNURADIO/BLKS2 SUB PACKAGE ................................................................................................................... 41

1.2.1) gnuradio/blks2impl/am_demod.py ............................................................................................... 42

1.2.1.1) am_demod_cf ( ) ...................................................................................................................................................42

Simple Gnuradio User Manual Page 4 of 208

1.2.1.2) demod_10k0a3e_cf()............................................................................................................................................42

1.2.2) gnuradio/blks2impl/channel_model.py ....................................................................................... 42

1.2.2.1) channel_model ( ) .................................................................................................................................................42

1.2.3) gnuradio/blks2impl/cpm.py ............................................................................................................ 43

1.2.3.1) cpm_mod ( ) ...........................................................................................................................................................43

1.2.4) gnuradio/blks2impl/d8psk.py......................................................................................................... 44

1.2.4.1) d8psk_mod ( )........................................................................................................................................................44

1.2.4.2) d8psk_demod ( ) ...................................................................................................................................................44

1.2.5) gnuradio/blks2impl/dbpsk.py ........................................................................................................ 45

1.2.5.1) dbpsk_mod ( )........................................................................................................................................................45

1.2.5.2) dbpsk_demod ( ) ...................................................................................................................................................45

1.2.6) gnuradio/blks2impl/dqpsk.py ........................................................................................................ 46

1.2.6.1) dqpsk_mod ( )........................................................................................................................................................46

1.2.6.2) dqpsk_demod ( ) ...................................................................................................................................................46

1.2.7) gnuradio/blks2impl/filterbank.py .................................................................................................. 47

1.2.7.1) synthesis_filterbank ( )........................................................................................................................................47

1.2.7.2) analysis_filterbank ( ) ..........................................................................................................................................48

1.2.8) gnuradio/blks2impl/fm_demod.py ................................................................................................ 48

1.2.8.1) fm_demod_cf ( ) ....................................................................................................................................................48

1.2.8.2) demod_20k0f3e_cf ()............................................................................................................................................49

1.2.8.3) demod_200kf3e_cf ()............................................................................................................................................49

1.2.9) gnuradio/blks2impl/fm_emph.py................................................................................................... 49

1.2.9.1) fm_deemph ( )........................................................................................................................................................49

1.2.9.2) fm_preemph () .......................................................................................................................................................50

1.2.10) gnuradio/blks2impl/gmsk.py.......................................................................................................... 51

1.2.10.1) gmsk_mod ( ).......................................................................................................................................................51

1.2.10.2) gmsk_demod ( ) ..................................................................................................................................................51

1.2.11) gnuradio/blks2impl/nbfm_rx.py .................................................................................................... 52

1.2.11.1) nbfm_rx ( ) ............................................................................................................................................................52

1.2.12) gnuradio/blks2impl/nbfm_tx.py..................................................................................................... 52

1.2.12.1) nbfm_tx ( ) ............................................................................................................................................................52

1.2.13) gnuradio/blks2impl/ofdm.py .......................................................................................................... 53

1.2.13.1) ofdm_mod ( ) .......................................................................................................................................................53

1.2.13.2) ofdm_demod ( )...................................................................................................................................................53

1.2.14) gnuradio/blks2impl/pkt.py .............................................................................................................. 54

1.2.14.1) mod_pkts ( ) .........................................................................................................................................................54

1.2.14.2) demod_pkts ( ) ....................................................................................................................................................54

1.2.15) gnuradio/blks2impl/psk.py ............................................................................................................. 54

1.2.16) gnuradio/blks2impl/qam.py............................................................................................................ 55

1.2.17) gnuradio/blks2impl/qam8.py.......................................................................................................... 55

1.2.17.1) qam8_mod ( )......................................................................................................................................................55

1.2.17.2) qam8_demod ( ) ..................................................................................................................................................55

1.2.18) gnuradio/blks2impl/qam16.py........................................................................................................ 56

1.2.18.1) qam16_mod ( ).....................................................................................................................................................56

Simple Gnuradio User Manual Page 5 of 208

1.2.18.2) qam16_demod ( ) ................................................................................................................................................56

1.2.19) gnuradio/blks2impl/qam64.py........................................................................................................ 57

1.2.19.1) qam64_mod ( ).....................................................................................................................................................57

1.2.19.2) qam64_demod ( ) ................................................................................................................................................57

1.2.20) gnuradio/blks2impl/qam256.py ..................................................................................................... 58

1.2.20.1) qam256_mod ( ) ..................................................................................................................................................58

1.2.20.2) qam256_demod ( )..............................................................................................................................................58

1.2.21) gnuradio/blks2impl/rational_resampler.py................................................................................. 59

1.2.21.1) rational_resampler ( ) ........................................................................................................................................59

1.2.21.2) design_filter ( ) ....................................................................................................................................................59

1.2.22) gnuradio/blks2impl/standard_squelch.py .................................................................................. 60

1.2.22.1) standard_squelch ( )..........................................................................................................................................60

1.2.23) gnuradio/blks2impl/wfm_rcv.py .................................................................................................... 60

1.2.23.1) wfm_rcv ( )............................................................................................................................................................60

1.2.24) gnuradio/blks2impl/wfm_rcv_pll.py ............................................................................................. 60

1.2.24.1) wfm_rcv_pll ( )....................................................................................................................................................61

1.2.25) gnuradio/blks2impl/wfm_tx.py ...................................................................................................... 61

1.2.25.1) wfm_tx ( ) ..............................................................................................................................................................61

1.3) GNURADIO/WXGUI SUB PACKAGE ................................................................................................................... 61

1.3.1) gnuradio/wxgui/fftsink.py ............................................................................................................... 61

1.3.1.1) fft_sink_x ( ) ..........................................................................................................................................................61

1.3.2) gnuradio/wxgui/fftsink2.py ............................................................................................................. 62

1.3.2.1) fft_sink_x ( ) ..........................................................................................................................................................62

1.3.3) gnuradio/wxgui/scopesink.py........................................................................................................ 62

1.3.3.1) scope_sink_x ( )...................................................................................................................................................62

1.3.4) gnuradio/wxgui/scopesink2.py...................................................................................................... 62

1.3.4.1) scope_sink_x ( )...................................................................................................................................................63

1.3.4.2) constellation_sink ( ) ..........................................................................................................................................63

1.3.5) gnuradio/wxgui/form.py .................................................................................................................. 63

1.3.6) gnuradio/wxgui/numbersink.py..................................................................................................... 63

1.3.6.1) number_sink_x ( )................................................................................................................................................63

1.3.7) gnuradio/wxgui/numbersink2.py................................................................................................... 63

1.3.7.1) number_sink_x ( )................................................................................................................................................64

1.3.8) gnuradio/wxgui/waterfallsink.py ................................................................................................... 64

1.3.8.1) waterfall_sink_x ( ) ..............................................................................................................................................64

1.3.9) gnuradio/wxgui/waterfallsink2.py ................................................................................................. 64

1.3.9.1) waterfall_sink_x ( ) ..............................................................................................................................................64

1.3.10) gnuradio/wxgui/plot.py .................................................................................................................... 65

1.3.11) gnuradio/wxgui/powermate.py ...................................................................................................... 65

1.3.12) gnuradio/wxgui/silder.py................................................................................................................. 65

1.3.13) gnuradio/wxgui/stdgui.py ............................................................................................................... 65

1.3.14) gnuradio/wxgui/stdgui2.py ............................................................................................................. 65

1.3.15) gnuradio/wxgui/ra_fftsink.py ......................................................................................................... 65

Simple Gnuradio User Manual Page 6 of 208

1.3.15.1) ra_fft_sink_x ( ) ..................................................................................................................................................65

1.3.16) gnuradio/wxgui/ra_fftsink.py ......................................................................................................... 66

1.3.16.1) ra_fft_sink_x ( ) ..................................................................................................................................................66

1.3.17) gnuradio/wxgui/ra_waterfallsink.py ............................................................................................. 66

1.3.17.1) waterfall_sink_x ( ) ............................................................................................................................................66

1.3.18) gnuradio/wxgui/ra_stripcharsink.py ............................................................................................ 66

1.3.18.1) stripchar_sink_x ( ) ...........................................................................................................................................67

1.4) GNURADIO/VOCODER SUB PACKAGE ............................................................................................................. 67

1.4.1) gnuradio/vocoder/gsm_full_rate.py ............................................................................................. 67

1.4.1.1) encode_sp ( ) ........................................................................................................................................................67

1.4.1.2) decode_ps ( ) ........................................................................................................................................................67

1.4.2) gnuradio/vocoder/cvsd_vocoder.py ............................................................................................ 67

1.4.2.1) encode_sb ( ) ........................................................................................................................................................68

1.4.2.2) decode_bs ( ) ........................................................................................................................................................68

1.5) GNURADIO/PAGER SUB PACKAGE .................................................................................................................. 68

1.5.1) gnuradio/pager/flex_demod.py...................................................................................................... 68

1.5.1.1) flex_demod ( ).......................................................................................................................................................68

1.5.2) gnuradio/pager/pager_swig.py...................................................................................................... 68

1.5.3) gnuradio/pager/aypabtu.py ............................................................................................................ 69

1.5.4) gnuradio/pager/usrp_flex.py .......................................................................................................... 69

1.5.5) gnuradio/pager/usrp_flex_all.py ................................................................................................... 69

1.5.6) gnuradio/pager/usrp_flex_band.py .............................................................................................. 69

1.6) GNURADIO/GRUIMPL SUB PACKAGE............................................................................................................... 70

1.6.1) gnuradio/ gruimpl /crc.py................................................................................................................ 70

1.6.1.1) gen_and_append_crc32 ( )................................................................................................................................70

1.6.1.2) check_crc32 ( ) .....................................................................................................................................................70

1.6.2) gnuradio/ gruimpl /freqz.py ............................................................................................................ 70

1.6.2.1) freqz ( ) ...................................................................................................................................................................70

1.6.3) gnuradio/ gruimpl /gnuplot_freqz.py ........................................................................................... 71

1.6.3.1) gnuplot_freqz ( )...................................................................................................................................................71

1.6.4) gnuradio/ gruimpl /gnuplot_freqz.py ........................................................................................... 71

1.6.4.1) gnuplot_freqz ( )...................................................................................................................................................71

1.6.5) gnuradio/ gruimpl /hexint.py .......................................................................................................... 72

1.6.5.1) hexint ( ) .................................................................................................................................................................72

1.6.6) gnuradio/ gruimpl /listmsc.py ........................................................................................................ 72

1.6.6.1) list_revers ( ) .........................................................................................................................................................72

1.6.7) gnuradio/ gruimpl /lmx2306.py ...................................................................................................... 72

1.6.7.1) lmx2306 ( ) .............................................................................................................................................................72

1.6.8) gnuradio/ gruimpl /mathmisc.py ................................................................................................... 73

1.6.9) gnuradio/ gruimpl /os_read_exactly.py....................................................................................... 73

1.6.9.1) os_read_exactly ( ) ..............................................................................................................................................73

Simple Gnuradio User Manual Page 7 of 208

1.6.10) gnuradio/ gruimpl /sdr_1000.py..................................................................................................... 73

1.6.10.1) sdr_1000 ( ) .........................................................................................................................................................73

1.6.11) gnuradio/ gruimpl /seq_with_cursor.py ...................................................................................... 74

1.6.12) gnuradio/ gruimpl /socket_stuff.py .............................................................................................. 74

1.6.12.1) tcp_connect_or_die ( ) ....................................................................................................................................74

1.6.12.2) udp_connect_or_die ( )...................................................................................................................................74

1.7) GNURADIO/GRU SUB PACKAGE ....................................................................................................................... 74

1.8) GNURADIO/GR SUB PACKAGE......................................................................................................................... 74

1.8.1) gnuradio/ gr / basic_flow_graph.py.............................................................................................. 75

1.8.2) gnuradio/ gr / flow_graph.py .......................................................................................................... 75

1.8.3) gnuradio/ gr / exceptions.py .......................................................................................................... 75

1.8.4) gnuradio/ gr / gnuradio_swig_py_filter.py.................................................................................. 75

1.8.4.1) iir_filter_ffd ( )......................................................................................................................................................75

1.8.4.2) single_pole_iir_filter_xx ( )...............................................................................................................................76

1.8.4.3) hilbert_fc ( )..........................................................................................................................................................76

1.8.4.4) filter_delay_fc ( ) .................................................................................................................................................76

1.8.4.5) fft _filter_xx ( ) .....................................................................................................................................................76

1.8.4.6) fractional_interpolator_xx ( ) ...........................................................................................................................76

1.8.4.7) goertzel_fc ( ).......................................................................................................................................................77

1.8.4.8) cma_equalizer_cc ( )..........................................................................................................................................77

1.8.4.9) adaptive_fir_ccf ( )..............................................................................................................................................77

1.8.4.10) fir_filter_xxx ( )..................................................................................................................................................77

1.8.4.11) freq_xlating_fir_filter_xxx ( ) .........................................................................................................................78

1.8.4.12) interp_fir_filter_xxx ( ) .......................................................................................................................................78

1.8.4.13) rational_resampler_base_xxx ( ) ....................................................................................................................79

1.8.5) gnuradio/ gr / gnuradio_swig_py_gengen.py ............................................................................ 79

1.8.5.1) add_xx ( ) ................................................................................................................................................................79

1.8.5.2) add_vxx ( ) ..............................................................................................................................................................79

1.8.5.3) add_const_xx ( )....................................................................................................................................................80

1.8.5.4) add_const_vxx ( ) .................................................................................................................................................80

1.8.5.5) argmax_xx ( ) .........................................................................................................................................................80

1.8.5.6) chunks_to_symbols _xx( ) .................................................................................................................................80

1.8.5.7) packed_to_unpacked _xx( ) ...............................................................................................................................81

1.8.5.8) unpacked_to_packed _xx( ) ...............................................................................................................................81

1.8.5.9) divide_xx( ).............................................................................................................................................................81

1.8.5.10) max_xx ( ) .............................................................................................................................................................82

1.8.5.11) multiply_xx ( )......................................................................................................................................................82

1.8.5.12) multiply_vxx ( )....................................................................................................................................................82

1.8.5.13) multiply_const_xx ( ) .........................................................................................................................................82

1.8.5.14) multiply_const_vxx ( ) .......................................................................................................................................83

1.8.5.15) mute_xx ( )............................................................................................................................................................83

1.8.5.16) noise_source_x ( )..............................................................................................................................................83

1.8.5.17) peak_detector_xb ( ) ..........................................................................................................................................83

Simple Gnuradio User Manual Page 8 of 208

1.8.5.18) sample_and_hold_xx ( )....................................................................................................................................84

1.8.5.19) sig_source_x ( ) ..................................................................................................................................................84

1.8.5.20) sub_xx ( ) ..............................................................................................................................................................85

1.8.5.21) vector_sink_x ( ) .................................................................................................................................................85

1.8.5.22) vector_source_x ( ) ............................................................................................................................................85

1.8.6) gnuradio/ gr / gnuradio_swig_py_runtime.py............................................................................ 86

1.8.6.1) io_signature ( ) ......................................................................................................................................................86

1.8.6.2) buffer ()....................................................................................................................................................................86

1.8.6.3) buffer_reader ( ) ....................................................................................................................................................86

1.8.6.4) basic_block ( ) .......................................................................................................................................................87

1.8.6.5) block ( )....................................................................................................................................................................87

1.8.6.6) block_detail ( ) .......................................................................................................................................................87

1.8.6.7) hier_block2 ( )........................................................................................................................................................88

1.8.6.8) single_threaded_scheduler ( )...........................................................................................................................88

1.8.6.9) message ( ).............................................................................................................................................................88

1.8.6.9) message_from_string ( ).....................................................................................................................................88

1.8.6.10) message_handler ( ) ..........................................................................................................................................89

1.8.6.11) msg_queue ( )......................................................................................................................................................89

1.8.6.12) dispatcher ( )........................................................................................................................................................89

1.8.6.13) error_handler ( )..................................................................................................................................................89

1.8.6.14) file_error_handler ( ) ..........................................................................................................................................90

1.8.6.15) sync_block ( ) ......................................................................................................................................................90

1.8.6.16) sync_decimator ( )..............................................................................................................................................90

1.8.6.16) sync_interpolator ( )...........................................................................................................................................90

1.8.6.17) top_block ( ) .........................................................................................................................................................90

1.8.6.18) enable_realtime_scheduling ( ).......................................................................................................................91

1.8.7) gnuradio/ gr / threading.py ............................................................................................................. 91

1.8.8) gnuradio/ gr / threading_23.py ...................................................................................................... 91

1.8.9) gnuradio/ gr / threading_24.py ...................................................................................................... 91

1.8.10) gnuradio/ gr / hier_block2.py ......................................................................................................... 91

1.8.11) gnuradio/ gr / hier_block.py ........................................................................................................... 91

1.8.12) gnuradio/ gr / prefs.py ..................................................................................................................... 92

1.8.13) gnuradio/ gr / scheduler.py ............................................................................................................ 92

1.8.14) gnuradio/ gr / top_block.py ............................................................................................................ 92

1.8.15) gnuradio/ gr / gnuradio_swig_python.py.................................................................................... 92

1.8.16) gnuradio/ gr / gnuradio_swig_io.py ............................................................................................. 93

1.8.16.1) file_sink_base ( ).................................................................................................................................................93

1.8.16.2) file_sink ( )............................................................................................................................................................93

1.8.16.3) file_source ( ).......................................................................................................................................................93

1.8.16.4) file_descriptor_sink ( ) ......................................................................................................................................94

1.8.16.5) file_descriptor_source ( ) .................................................................................................................................94

1.8.16.6) microtune_xxxx_eval_board ( ).......................................................................................................................94

1.8.16.7) microtune_4702_eval_board ( ).......................................................................................................................94

1.8.16.8) microtune_4937_eval_board ( ).......................................................................................................................94

Simple Gnuradio User Manual Page 9 of 208

1.8.16.8) sdr_1000_base ( ) ...............................................................................................................................................95

1.8.16.9) oscope_sink_f ( ) ................................................................................................................................................95

1.8.16.10) ppio ( ) .................................................................................................................................................................95

1.8.16.11) message_source ( ) .........................................................................................................................................95

1.8.16.12) message_sink ( ) ..............................................................................................................................................95

1.8.16.13) udp_sink ( ) ........................................................................................................................................................96

1.8.16.14) udp_source ( ) ...................................................................................................................................................96

1.8.17) gnuradio/ gr / gnuradio_swig_general.py................................................................................... 96

1.8.17.1) nop ( ) ....................................................................................................................................................................96

1.8.27.2) null_sink ( )...........................................................................................................................................................97

1.8.27.3) null_source ( ) .....................................................................................................................................................97

1.8.27.4) head ( ) ..................................................................................................................................................................97

1.8.27.5) skiphead ( )...........................................................................................................................................................97

1.8.27.6) quadrature_demod_cf ( ) ..................................................................................................................................97

1.8.27.7) float_to_complex ( ) ...........................................................................................................................................98

1.8.27.8) check_counting_s ( ) .........................................................................................................................................98

1.8.27.9) lfsr_32k_source_s ( ) .........................................................................................................................................98

1.8.27.10) check_lfsr_32k_s ( ).........................................................................................................................................98

1.8.27.11) stream_to_vector ( ).........................................................................................................................................99

1.8.27.12) vector_to_stream ( ).........................................................................................................................................99

1.8.27.13) keep_one_in_n ( ).............................................................................................................................................99

1.8.27.14) fft_vcc ( ).............................................................................................................................................................99

1.8.27.15) fft_vfc ( )..............................................................................................................................................................99

1.8.27.16) float_to_short ( ) .............................................................................................................................................100

1.8.27.17) float_to_uchar ( ) ............................................................................................................................................100

1.8.27.18) short_ to_float ( ) ............................................................................................................................................100

1.8.27.19) char_to_float ( )...............................................................................................................................................100

1.8.27.20) uchar_to_float ( ) ............................................................................................................................................100

1.8.27.21) frequency_modulator_fc ( ) .........................................................................................................................101

1.8.27.22) phase_modulator_fc ( ).................................................................................................................................101

1.8.27.23) bytes_to_syms ( )...........................................................................................................................................101

1.8.27.24) simple_framer ( ) ............................................................................................................................................101

1.8.27.25) simple_correlator ( ) ......................................................................................................................................101

1.8.27.26) align_on_samplenumbers_ss ( ) ................................................................................................................102

1.8.27.27) complex_to_float ( ).......................................................................................................................................102

1.8.27.28) complex_to_real ( ) ........................................................................................................................................102

1.8.27.29) complex_to_imag ( ) ......................................................................................................................................102

1.8.27.30) complex_to_mag ( ) .......................................................................................................................................102

1.8.27.31) complex_to_mag_squared ( )......................................................................................................................103

1.8.27.32) complex_to_arg ( ) .........................................................................................................................................103

1.8.27.33) complex_to_interleaved_short ( ) ..............................................................................................................103

1.8.27.34) interleaved_short_to_complex ( ) ..............................................................................................................103

1.8.27.35) firdes ( ).............................................................................................................................................................103

1.8.27.35.1) firdes.low_pass ( ) .................................................................................................................................103

1.8.27.35.2) firdes.high_pass ( )................................................................................................................................104

Simple Gnuradio User Manual Page 10 of 208

1.8.27.35.3) firdes.band_pass ( ) ..............................................................................................................................104

1.8.27.35.4) firdes.complex_band_pass ( ) ............................................................................................................104

1.8.27.35.5) firdes.band_reject ( ).............................................................................................................................105

1.8.27.35.6) firdes.hilbert ( ).......................................................................................................................................105

1.8.27.35.7) firdes.root_raised_cosine ( )...............................................................................................................105

1.8.27.35.8) firdes.gaussian ( )..................................................................................................................................106

1.8.27.35.9) firdes.window ( ).....................................................................................................................................106

1.8.27.36) interleave () ......................................................................................................................................................106

1.8.27.37) deinterleave ()..................................................................................................................................................106

1.8.27.38) delay () ..............................................................................................................................................................107

1.8.27.39) simple_sequelch_cc () ..................................................................................................................................107

1.8.27.40) agc_xx () ...........................................................................................................................................................107

1.8.27.41) gri_agc_xx ()....................................................................................................................................................107

1.8.27.42) gri_agc2_xx ()..................................................................................................................................................108

1.8.27.43) rms_xx ()...........................................................................................................................................................108

1.8.27.44) nlog10_ff () .......................................................................................................................................................109

1.8.27.45) fake_channel_encoder_pp ().......................................................................................................................109

1.8.27.46) fake_channel_decoder_pp ().......................................................................................................................109

1.8.27.47) throttle ()...........................................................................................................................................................109

1.8.27.48) mpsk_receiver_cc () ......................................................................................................................................109

1.8.27.49) stream_mux () .................................................................................................................................................111

1.8.27.50) stream_to_streams () ....................................................................................................................................111

1.8.27.51) streams_to_stream () ....................................................................................................................................111

1.8.27.52) streams_to_vector () .....................................................................................................................................111

1.8.27.53) stream_to_vector ()........................................................................................................................................111

1.8.27.54) vector_to_ streams () ....................................................................................................................................112

1.8.27.55) vector_to_stream ()........................................................................................................................................112

1.8.27.56) conjugate_cc () ...............................................................................................................................................112

1.8.27.57) vco_f () ..............................................................................................................................................................112

1.8.27.58) threshold_ff ()..................................................................................................................................................112

1.8.27.59) clock_recovery_mm_xx () ............................................................................................................................113

1.8.27.60) dd_mpsk_sync_cc () .....................................................................................................................................113

1.8.27.61) packet_sink ()..................................................................................................................................................114

1.8.27.62) lms_dfe_xx () ...................................................................................................................................................114

1.8.27.63) dpll_bb ()...........................................................................................................................................................114

1.8.27.64) pll_freqdet_cf ()...............................................................................................................................................115

1.8.27.65) pll_refout_cc ()................................................................................................................................................115

1.8.27.66) pll_carriertracking_cc().................................................................................................................................115

1.8.27.67) pn_correlator_cc ().........................................................................................................................................116

1.8.27.68) probe_signal_f () ............................................................................................................................................116

1.8.27.69) probe_avg_mag_sqrd_xx ().........................................................................................................................116

1.8.27.70) ofdm_correlator () ..........................................................................................................................................117

1.8.27.71) ofdm_cyclic_prefixer () .................................................................................................................................117

1.8.27.72) ofdm_bpsk_mapper () ...................................................................................................................................117

1.8.27.73) ofdm_bpsk_demapper () ..............................................................................................................................118

Simple Gnuradio User Manual Page 11 of 208

1.8.27.74) ofdm_ mapper_bcv () ....................................................................................................................................118

1.8.27.75) ofdm_qpsk_mapper () ...................................................................................................................................118

1.8.27.76) ofdm_qam_mapper () ....................................................................................................................................118

1.8.27.77) ofdm_frame_sink ()........................................................................................................................................119

1.8.27.78) ofdm_insert_preamble () ..............................................................................................................................119

1.8.27.79) ofdm_sampler ()..............................................................................................................................................119

1.8.27.80) regenerate_bb () .............................................................................................................................................120

1.8.27.81) costas_loop_cc ()...........................................................................................................................................120

1.8.27.82) pa_2x2_phase_combiner ()..........................................................................................................................120

1.8.27.83) kludge_copy () ................................................................................................................................................121

1.8.27.84) prefs ()...............................................................................................................................................................121

1.8.27.85) test ()..................................................................................................................................................................121

1.8.27.86) unpack_k_bits_bb () ......................................................................................................................................121

1.8.27.87) correlate_access_code_bb () ......................................................................................................................122

1.8.27.88) diff_phasor_cc () ............................................................................................................................................122

1.8.27.89) constellation_decoder_cb ()........................................................................................................................122

1.8.27.90) binary_slicer_fb () ..........................................................................................................................................122

1.8.27.91) diff_encoder_bb ()..........................................................................................................................................123

1.8.27.92) diff_decoder_bb ()..........................................................................................................................................123

1.8.27.93) framer_sink_1 ()..............................................................................................................................................123

1.8.27.94) map_bb () .........................................................................................................................................................123

1.8.27.95) feval ()................................................................................................................................................................123

1.8.27.96) feval_xx ().........................................................................................................................................................124

1.8.27.97) pwr_squelch_xx ()..........................................................................................................................................124

1.8.27.98) squelch_base_xx ()........................................................................................................................................124

1.8.27.99) ctcss_squelch_ff ().........................................................................................................................................125

1.8.27.100) feedforward_agc_cc () ................................................................................................................................125

1.8.27.101) bin_statistics_f ()..........................................................................................................................................126

1.8.27.102) glfsr_source_x () ..........................................................................................................................................126

1.9) GNURADIO/ WINDOW.PY ................................................................................................................................ 126

1.9.1) hamming() ......................................................................................................................................... 126

1.9.2) hanning() ........................................................................................................................................... 127

1.9.3) welch()................................................................................................................................................ 127

1.9.4) parzen() .............................................................................................................................................. 127

1.9.5) bartlett() ............................................................................................................................................. 127

1.9.6) blackman2() ...................................................................................................................................... 127

1.9.7) blackman3() ...................................................................................................................................... 128

1.9.8) blackman4() ...................................................................................................................................... 128

1.9.9) exponential()..................................................................................................................................... 128

1.9.10) riemann() ........................................................................................................................................... 128

1.9.11) blackmanharris ().................................................................................................................................. 128

1.9.12) nuttall()............................................................................................................................................... 128

1.9.13) kaiser() ............................................................................................................................................... 129

Simple Gnuradio User Manual Page 12 of 208

1.10) GNURADIO/ VIDEO_SDL.PY............................................................................................................................ 129

1.10.1) video_sdl_sink_uc() ....................................................................................................................... 129

1.10.2) video_sdl_sink_s().......................................................................................................................... 129

1.10.3) sink_uc() ............................................................................................................................................ 130

1.10.4) sink_s() .............................................................................................................................................. 130

1.11) GNURADIO/ TRELLIS.PY ................................................................................................................................. 130

1.11.1) fsm().................................................................................................................................................... 130

1.11.2) interleaver()....................................................................................................................................... 131

1.11.3) trellis_permutation () ........................................................................................................................... 131

1.11.4) trellis_siso_f () ....................................................................................................................................... 131

1.11.5) trellis_encoder_xx () ............................................................................................................................ 131

1.11.6) trellis_metrics_x ()................................................................................................................................ 132

1.11.7) trellis_viterbi_x () .................................................................................................................................. 132

1.11.8) trellis_viterbi_combined_xx ()........................................................................................................... 132

1.12) GNURADIO/ SOUNDER.PY .............................................................................................................................. 132

1.12.1) sounder_tx ().......................................................................................................................................... 134

1.12.2) sounder_rx ().......................................................................................................................................... 134

1.12.3) sounder ()................................................................................................................................................ 134

1.13) GNURADIO/ RADAR_MONO.PY....................................................................................................................... 134

1.13.1) radar_tx ()................................................................................................................................................ 135

1.13.2) radar_rx () ............................................................................................................................................... 135

1.13.3) radar () ..................................................................................................................................................... 135

1.14) GNURADIO/ RA.PY.......................................................................................................................................... 135

1.15) GNURADIO/ PACKET_UTIL.PY ........................................................................................................................ 135

1.15.1) conv_packed_binary_string_to_1_0_string ().............................................................................. 135

1.15.2) conv_1_0_string_to_packed_binary_string ().............................................................................. 136

1.15.3) make_packet () ..................................................................................................................................... 136

1.15.4) unmake_packet () ................................................................................................................................ 136

1.15.5) _npadding_bytes () ............................................................................................................................. 137

1.16) GNURADIO/ OPTFIR.PY................................................................................................................................... 137

1.16.1) low_pass () ............................................................................................................................................. 137

1.16.2) high_pass ()............................................................................................................................................ 137

1.17) GNURADIO/ OFDM_PACKET_UTIL.PY ............................................................................................................ 138

1.17.1) conv_packed_binary_string_to_1_0_string ().............................................................................. 138

1.17.2) conv_1_0_string_to_packed_binary_string ().............................................................................. 138

1.17.3) make_packet () ..................................................................................................................................... 138

1.17.4) unmake_packet () ................................................................................................................................ 138

Simple Gnuradio User Manual Page 13 of 208

1.17.5) _npadding_bytes () ............................................................................................................................. 139

1.18) GNURADIO/ MODULATION_UTILS.PY ............................................................................................................. 139

1.18.1) type_1_mods ()..................................................................................................................................... 139

1.18.2) type_1_demods () ................................................................................................................................ 139

1.19) GNURADIO/ LOCAL_CALIBRATOR.PY ............................................................................................................ 140

1.20) GNURADIO/GR_UNITTEST.PY......................................................................................................................... 140

1.21) GNURADIO/ENG_OPTION.PY .......................................................................................................................... 140

1.22) GNURADIO/ENG_NOTATION.PY...................................................................................................................... 140

1.22.1) num_to_str ()......................................................................................................................................... 140

1.22.2) str_to_num ()......................................................................................................................................... 141

1.23) GNURADIO/AUDIO_OSS.PY ............................................................................................................................ 141

1.24) GNURADIO/AUDIO_ALSA.PY .......................................................................................................................... 141

1.25) gnuradio/audio.py................................................................................................................................ 141

1.25.1) source () ................................................................................................................................................. 141

1.25.2) sink () ...................................................................................................................................................... 142

1.26) GNURADIO/ATSC.PY....................................................................................................................................... 142

1.27) GNURADIO/USRP.PY ...................................................................................................................................... 142

1.27.1) source_x() ......................................................................................................................................... 142

1.27.1.1) tune() ...............................................................................................................................................................142

1.27.1.2) has_rx_halfband() ........................................................................................................................................143

1.27.1.3) nddcs()............................................................................................................................................................143

1.27.2) sink_x() .............................................................................................................................................. 143

1.27.2.1) tune() ...............................................................................................................................................................143

1.27.2.2) has_tx_halfband() ........................................................................................................................................144

1.27.2.3) nducs()............................................................................................................................................................144

1.27.3) determine_rx_mux_value ().......................................................................................................... 144

1.27.4) tune_result () .................................................................................................................................... 145

1.27.5) determine_tx_mux_value () .......................................................................................................... 145

1.27.6) selected_subdev ().......................................................................................................................... 145

1.27.7) calc_dxc_freq () ............................................................................................................................... 145

1.27.8) pick_rx_subdevice() ....................................................................................................................... 146

1.27.9) pick_tx_subdevice() ....................................................................................................................... 146

1.27.10) pick_ subdev()............................................................................................................................. 146

1.28) GNURADIO/USRP1.PY .................................................................................................................................... 147

1.28.1) source_x() ......................................................................................................................................... 147

1.28.1.1) set_decim_rate()...........................................................................................................................................147

1.28.1.2) set_nchannels() ............................................................................................................................................148

Simple Gnuradio User Manual Page 14 of 208

1.28.1.3) set_mux() .......................................................................................................................................................148

1.28.1.4) set_rx_freq() ..................................................................................................................................................148

1.28.1.5) set_ddc_phase()...........................................................................................................................................148

1.28.1.6) set_fpga_mode()...........................................................................................................................................149

1.28.1.7) set_verbose() ................................................................................................................................................149

1.28.1.8) set_pga().........................................................................................................................................................149

1.28.1.9) pga() ................................................................................................................................................................149

1.28.1.10) pga_min()..................................................................................................................................................149

1.28.1.11) pga_max() .................................................................................................................................................150

1.28.1.12) pga_db_per_step()..................................................................................................................................150

1.28.1.13) fpga_master_clock_freq().....................................................................................................................150

1.28.1.14) converter_rate().......................................................................................................................................150

1.28.1.15) decim_rate() .............................................................................................................................................150

1.28.1.16) nchannels()...............................................................................................................................................151

1.28.1.17) mux() ..........................................................................................................................................................151

1.28.1.18) rx_freq().....................................................................................................................................................151

1.28.1.19) daughterboard_id().................................................................................................................................151

1.28.1.20) write_aux_dac() .......................................................................................................................................151

1.28.1.21) read_aux_dac()........................................................................................................................................152

1.28.1.22) write_eeprom().........................................................................................................................................152

1.28.1.23) read_eeprom() .........................................................................................................................................152

1.28.1.24) write_i2c() .................................................................................................................................................152

1.28.1.25) read_i2c() ..................................................................................................................................................153

1.28.1.26) set_adc_offset().......................................................................................................................................153

1.28.1.27) set_dac_offset().......................................................................................................................................153

1.28.1.28) set_adc_buffer_bypass() ......................................................................................................................153

1.28.1.29) serial_number() .......................................................................................................................................154

1.28.1.30) _write_oe() ................................................................................................................................................154

1.28.1.31) write_io() ...................................................................................................................................................154

1.28.1.32) read_io() ....................................................................................................................................................154

1.28.1.33) set_dc_offset_cl_enable().....................................................................................................................155

1.28.1.34) set_format() ..............................................................................................................................................155

1.28.1.35) make_format()..........................................................................................................................................155

1.28.1.36) format()......................................................................................................................................................155

1.28.1.37) format_width() .........................................................................................................................................156

1.28.1.38) format_shift() ...........................................................................................................................................156

1.28.1.39) format_want_q() ......................................................................................................................................156

1.28.1.40) format_bypass_halfband() ...................................................................................................................156

1.28.1.41) _write_fpga_reg()....................................................................................................................................156

1.28.1.42) _write_fpga_reg_masked() ...................................................................................................................157

1.28.1.43) _read_fpga_reg().....................................................................................................................................157

1.28.1.44) _write_9862()............................................................................................................................................157

1.28.1.45) _read_9862().............................................................................................................................................157

1.28.1.46) _write_spi()...............................................................................................................................................158

1.28.1.47) _read_spi()................................................................................................................................................158

Simple Gnuradio User Manual Page 15 of 208

1.28.2) sink_x() .............................................................................................................................................. 158

1.28.2.1) set_interp_rate() ...........................................................................................................................................159

1.28.2.2) set_nchannels() ............................................................................................................................................159

1.28.2.3) set_mux() .......................................................................................................................................................159

1.28.2.4) set_tx_freq() ..................................................................................................................................................160

1.28.2.5) set_verbose() ................................................................................................................................................160

1.28.2.6) set_pga().........................................................................................................................................................160

1.28.2.7) pga() ................................................................................................................................................................160

1.28.2.8) pga_min() .......................................................................................................................................................161

1.28.2.9) pga_max() ......................................................................................................................................................161

1.28.2.10) pga_db_per_step()..................................................................................................................................161

1.28.2.11) fpga_master_clock_freq().....................................................................................................................161

1.28.2.12) converter_rate().......................................................................................................................................161

1.28.2.13) interp_rate()..............................................................................................................................................162

1.28.2.14) nchannels()...............................................................................................................................................162

1.28.2.16) tx_freq() .....................................................................................................................................................162

1.28.2.17) daughterboard_id().................................................................................................................................163

1.28.2.18) write_aux_dac() .......................................................................................................................................163

1.28.2.19) read_aux_dac()........................................................................................................................................163

1.28.2.20) write_eeprom().........................................................................................................................................163

1.28.2.21) read_eeprom() .........................................................................................................................................164

1.28.2.22) write_i2c() .................................................................................................................................................164

1.28.2.23) read_i2c() ..................................................................................................................................................164

1.28.2.24) set_adc_offset().......................................................................................................................................164

1.28.2.25) set_dac_offset().......................................................................................................................................164

1.28.2.26) set_adc_buffer_bypass() ......................................................................................................................165

1.28.2.27) serial_number() .......................................................................................................................................165

1.28.2.28) _write_oe() ................................................................................................................................................165

1.28.2.29) write_io() ...................................................................................................................................................165

1.28.2.30) read_io() ....................................................................................................................................................166

1.28.2.31) _write_fpga_reg()....................................................................................................................................166

1.28.2.32) _write_fpga_reg_masked() ...................................................................................................................166

1.28.2.33) _read_fpga_reg().....................................................................................................................................166

1.28.2.34) _write_9862()............................................................................................................................................167

1.28.2.35) _read_9862().............................................................................................................................................167

1.28.2.36) _write_spi()...............................................................................................................................................167

1.28.2.37) _read_spi()................................................................................................................................................168

1.29) GNURADIO/USRP_MULTI.PY .......................................................................................................................... 168

1.29.1) multi_source_align () ..................................................................................................................... 169

1.29.1.1) get_master_usrp ().......................................................................................................................................169

1.29.1.2) get_slave_usrp ()..........................................................................................................................................169

1.29.1.3) get_master_source_c ()..............................................................................................................................169

1.29.1.4) get_slave_source_c ().................................................................................................................................170

1.29.1.5) sync () .............................................................................................................................................................170

Simple Gnuradio User Manual Page 16 of 208

1.29.1.6) print_db_info () .............................................................................................................................................170

1.29.1.7) tune_all_rx ()..................................................................................................................................................170

1.29.1.8) set_gain_all_rx ()..........................................................................................................................................171

1.30) GNURADIO/TX_DEBUG_GUI.PY...................................................................................................................... 171

1.31) GNURADIO/FLEXRF_DEBUG_GUI.PY ............................................................................................................. 171

1.32) GNURADIO/DB_BASE.PY................................................................................................................................ 171

1.33) GNURADIO/DB_BASIC.PY............................................................................................................................... 171

1.33.1) db_basic_tx ()................................................................................................................................... 172

1.33.1.1) dbid () ..............................................................................................................................................................172

1.33.1.2) name () ............................................................................................................................................................172

1.33.1.3) side_and_name ().........................................................................................................................................172

1.33.1.4) freq_range ()..................................................................................................................................................173

1.33.1.5) set_freq () .......................................................................................................................................................173

1.33.1.6) gain_range () .................................................................................................................................................173

1.33.1.7) set_gain () ......................................................................................................................................................173

1.33.1.8) is_quadrature () ............................................................................................................................................173

1.33.2) db_basic_rx () .................................................................................................................................. 174

1.33.2.1) dbid () ..............................................................................................................................................................174

1.33.2.2) name () ............................................................................................................................................................174

1.33.2.3) side_and_name ().........................................................................................................................................174

1.33.2.4) freq_range ()..................................................................................................................................................175

1.33.2.5) set_freq () .......................................................................................................................................................175

1.33.2.6) gain_range () .................................................................................................................................................175

1.33.2.7) set_gain () ......................................................................................................................................................175

1.33.2.8) is_quadrature () ............................................................................................................................................176

1.33.3) db_lf_rx () .......................................................................................................................................... 176

1.33.3.1) dbid () ..............................................................................................................................................................176

1.33.3.2) name () ............................................................................................................................................................176

1.33.3.3) side_and_name ().........................................................................................................................................176

1.33.3.4) freq_range ()..................................................................................................................................................177

1.33.3.5) set_freq () .......................................................................................................................................................177

1.33.3.6) gain_range () .................................................................................................................................................177

1.33.3.7) set_gain () ......................................................................................................................................................177

1.33.3.8) is_quadrature () ............................................................................................................................................178

1.33.4) db_lf_tx () .......................................................................................................................................... 178

1.33.4.1) dbid () ..............................................................................................................................................................178

1.33.4.2) name () ............................................................................................................................................................178

1.33.4.3) side_and_name ().........................................................................................................................................179

1.33.4.4) freq_range ()..................................................................................................................................................179

1.33.4.5) set_freq () .......................................................................................................................................................179

1.33.4.6) gain_range () .................................................................................................................................................179

1.33.4.7) set_gain () ......................................................................................................................................................179

1.33.4.8) is_quadrature () ............................................................................................................................................180

Simple Gnuradio User Manual Page 17 of 208

1.34) GNURADIO/DB_DBS_RX.PY ........................................................................................................................... 180

1.34.1) db_dbs_rx ()...................................................................................................................................... 180

1.34.1.1) dbid () ..............................................................................................................................................................180

1.34.1.2) name () ............................................................................................................................................................180

1.34.1.3) side_and_name ().........................................................................................................................................181

1.34.1.4) freq_range ()..................................................................................................................................................181

1.34.1.5) set_freq () .......................................................................................................................................................181

1.34.1.6) gain_range () .................................................................................................................................................181

1.34.1.7) set_gain () ......................................................................................................................................................182

1.34.1.8) is_quadrature () ............................................................................................................................................182

1.34.1.9) set_bw ().........................................................................................................................................................182

1.35) GNURADIO/DB_FLEXRF.PY ............................................................................................................................ 182

GNURADIO/DB_FLEXRF_MIMO.PY ............................................................................................................................... 182

1.35.1) db_flexrf_xxxx_tx () ........................................................................................................................ 182

db_flexrf_xxxx_tx_mimo_x() ........................................................................................................................... 182

1.35.1.1) dbid () ..............................................................................................................................................................183

1.35.1.2) name () ............................................................................................................................................................183

1.35.1.3) side_and_name ().........................................................................................................................................184

1.35.1.4) freq_range ()..................................................................................................................................................184

1.35.1.5) set_freq () .......................................................................................................................................................184

1.35.1.6) is_quadrature () ............................................................................................................................................185

1.35.1.7) set_auto_tr () .................................................................................................................................................185

1.35.1.8) set_enable ()..................................................................................................................................................185

1.35.2) db_flexrf_xxxx_rx ()........................................................................................................................ 185

db_flexrf_xxxx_rx_mimo_x()........................................................................................................................... 185

1.35.2.1) dbid () ..............................................................................................................................................................186

1.35.2.2) name () ............................................................................................................................................................186

1.35.2.3) side_and_name ().........................................................................................................................................187

1.35.2.4) freq_range ()..................................................................................................................................................187

1.35.2.5) set_freq () .......................................................................................................................................................187

1.35.2.6) gain_range () .................................................................................................................................................188

1.35.2.7) set_gain () ......................................................................................................................................................188

1.35.2.8) is_quadrature () ............................................................................................................................................188

1.35.2.9) set_auto_tr () .................................................................................................................................................188

1.35.2.10) select_rx_antenna ()...............................................................................................................................189

1.35.2.11) i_and_q_swapped () ...............................................................................................................................189

1.36) GNURADIO/DB_INSTANTIATOR.PY................................................................................................................. 189

1.37) GNURADIO/DB_TV_RX.PY.............................................................................................................................. 189

1.37.1) db_tv_rx () ......................................................................................................................................... 190

1.37.1.1) dbid () ..............................................................................................................................................................190

1.37.1.2) name () ............................................................................................................................................................190

1.37.1.3) side_and_name ().........................................................................................................................................190

Simple Gnuradio User Manual Page 18 of 208

1.37.1.4) freq_range ()..................................................................................................................................................191

1.37.1.5) set_freq () .......................................................................................................................................................191

1.37.1.6) gain_range () .................................................................................................................................................191

1.37.1.7) set_gain () ......................................................................................................................................................191

1.37.1.8) is_quadrature () ............................................................................................................................................191

1.38) GNURADIO/DB_WBX.PY ................................................................................................................................. 192

1.38.1) DB_WBX_LO_RX () ................................................................................................................................... 192

1.38.1.1) dbid () ..............................................................................................................................................................192

1.38.1.2) name () ............................................................................................................................................................193

1.38.1.3) side_and_name ().........................................................................................................................................193

1.38.1.4) freq_range ()..................................................................................................................................................193

1.38.1.5) set_freq () .......................................................................................................................................................193

1.38.1.6) gain_range () .................................................................................................................................................194

1.38.1.7) set_gain () ......................................................................................................................................................194

1.38.1.8) is_quadrature () ............................................................................................................................................194

1.38.1.9) set_auto_tr () .................................................................................................................................................195

1.38.1.10) select_rx_antenna ()...............................................................................................................................195

1.38.1.11) i_and_q_swapped () ...............................................................................................................................195

1.38.2) db_wbx_lo_tx () ............................................................................................................................... 195

1.38.2.1) dbid () ..............................................................................................................................................................196

1.38.2.2) name () ............................................................................................................................................................196

1.38.2.3) side_and_name ().........................................................................................................................................196

1.38.2.4) freq_range ()..................................................................................................................................................197

1.38.2.5) set_freq () .......................................................................................................................................................197

1.38.2.6) is_quadrature () ............................................................................................................................................197

1.38.2.7) set_auto_tr () .................................................................................................................................................198

1.38.2.8) set_enable ()..................................................................................................................................................198

2) USRPM PACKAGE ............................................................................................................................................. 198

2.1) USRPM/USRP_DBID.PY .................................................................................................................................. 198

2.2) USRPM/USRP_PRIMS.PY................................................................................................................................ 199

2.3) USRPM/USRP_FPGA_REGS.PY............................................................................................................................ 199

INDEX.............................................................................................................................................................................. 202

Simple Gnuradio User Manual Page 19 of 208

1) gnuradio package

Description The main package. All gnuradio stuff are here

1.1) gnuradio/blks sub package

Type Folder

Description Semi-hideous kludge to import everything in the blksimpl directory into the gnuradio.blks

namespace. This keeps us from having to remember to manually update this file.

1.1.1) gnuradio/blksimpl/am_demod.py

Type Python file

Description AM demodulation block

Examples

Note

1.1.1.1) am_demod_cf ( )

Type Function

Description Generalized AM demodulation block with audio filtering.This block demodulates a band-

limited, complex down-converted AM channel into the original baseband signal, applying

low pass filtering to the audio output. It produces a float stream in the range [-1.0, +1.0].

Usage blks.am_demod_cf (fg, channel_rate, audio_decim, audio_pass, audio_stop)

Parameters fg: flowgraph

channel_rate: incoming sample rate of the AM baseband

type channel_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

audio_pass: audio low pass filter passband frequency

type audio_pass: float

audio_stop: audio low pass filter stop frequency

type audio_stop: float

1.1.1.2) demod_10k0a3e_cf ()

Type Function

Description AM demodulation block, 10 KHz channel. This block demodulates an AM channel

conformant to 10K0A3E emission standards, such as broadcast band AM transmissions.

Usage blks.demod_10k0a3e_cf(fg, channel_rate, audio_decim)

Parameters fg: flowgraph

channel_rate: incoming sample rate of the AM baseband

type channel_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

1.1.2) gnuradio/blksimpl/channel_model.py

Type Python file

Description Creates a channel model

Examples

Note

Simple Gnuradio User Manual Page 20 of 208

1.1.2.1) channel_model ( )

Type Function

Description Creates a channel model that includes:

- AWGN noise power in terms of noise voltage

- A frequency offset in the channel in ratio

- A timing offset ratio to model clock difference (clock rate ratio) (epsilon). It is sample

rate difference between tx and rx

- Multipath taps

Usage blks.channel_model(fg, noise_voltage=0.0, frequency_offset=0.0, epsilon=1.0,

taps=[1.0,0.0])

Parameters

Sub Function 1 blks.channel_model.set_noise_voltage(noise_voltage)

Sub Function 2 blks.channel_model.set_frequency_offset(frequency_offset)

Sub Function 3 blks.channel_model.set_taps(taps)

1.1.3) gnuradio/blksimpl/cpm.py

Type Python file

Description Continuous Phase modulation.

Examples See gnuradio-examples/python/digital for examples

Note

1.1.3.1) cpm_mod ( )

Type Function

Description Hierarchical block for Continuous Phase Modulation.

The input is a byte stream (unsigned char) representing packed bits and the output is

the complex modulated signal at baseband.

See Proakis for definition of generic CPM signals:

s(t)=exp(j phi(t))

phi(t)= 2 pi h int_0^t f(t') dt'

f(t)=sum_k a_k g(t-kT)

(normalizing assumption: int_0^infty g(t) dt = 1/2)

Usage blks.cpm_mod(fg,samples_per_symbol=2,bits_per_symbol=1,

h_numerator=1, h_denominator=2,

cpm_type=0,bt=_def_bt, symbols_per_pulse=1, generic_taps

numpy.empty(1), verbose=False, log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud >= 2

type samples_per_symbol: integer

bits_per_symbol: bits per symbol

type bits_per_symbol: integer

h_numerator: numerator of modulation index

type h_numerator: integer

h_denominator: denominator of modulation index (numerator and denominator must

be relative primes)

type h_denominator: integer

cpm_type: supported types are: 0=CPFSK, 1=GMSK, 2=RC, 3=GENERAL

type cpm_type: integer

bt: bandwidth symbol time product for GMSK

type bt: float

symbols_per_pulse: shaping pulse duration in symbols

type symbols_per_pulse: integer

generic_taps: define a generic CPM pulse shape (sum = samples_per_symbol/2)

Simple Gnuradio User Manual Page 21 of 208

type generic_taps: array of floats

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.4) gnuradio/blksimpl/d8psk.py

Type Python file

Description differential 8PSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.1.4.1) d8psk_mod ( )

Type Function , D8PSK modulator

Description Hierarchical block for RRC-filtered QPSK modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks.d8psk_mod(fg,

samples_per_symbol=3,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.4.2) d8psk_demod ( )

Type Function , D8PSK demodulator

Description Differentially coherent detection of differentially encoded 8psk. Hierarchical block for RRC-

filtered DQPSK demodulation. The input is the complex modulated signal at baseband. The

output is a stream of bits packed 1 bit per byte (LSB)

Usage blks.d8psk_demod(fg,

samples_per_symbol=3,

excess_bw=.35,

costas_alpha=.175,

gain_mu=.175,

mu=0.5,

omega_relative_limit=.005,

gray_code=True,

verbose=False,

log=False)

Simple Gnuradio User Manual Page 22 of 208

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: float

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

costas_alpha: loop filter gain

type costas_alpha: float

gain_mu: for M&M block

type gain_mu: float

mu: for M&M block

type mu: float

omega_relative_limit: for M&M block

type omega_relative_limit: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print demodulation data to files?

type debug: bool

1.1.5) gnuradio/blksimpl/dbpsk.py

Type Python file

Description differential BPSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.1.5.1) dbpsk_mod ( )

Type Function , DBPSK modulator

Description Hierarchical block for RRC-filtered BPSK modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks.dbpsk_mod(fg,

samples_per_symbol=2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

log: Log modulation data to files?

type log: bool

Simple Gnuradio User Manual Page 23 of 208

1.1.5.2) dbpsk_demod ( )

Type Function , DBPSK demodulator

Description Differentially coherent detection of differentially encoded BPSK. Hierarchical block for RRC-

filtered DBPSK demodulation. The input is the complex modulated signal at baseband. The

output is a stream of bits packed 1 bit per byte (LSB).

Usage blks.d8psk_demod(fg,

samples_per_symbol=2,

excess_bw=.35,

costas_alpha=.1,

gain_mu=None,

mu=0.5,

omega_relative_limit=.005,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: float

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

costas_alpha: loop filter gain

type costas_alpha: float

gain_mu: for M&M block

type gain_mu: float

mu: for M&M block

type mu: float

omega_relative_limit: for M&M block

type omega_relative_limit: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print demodulation data to files?

type debug: bool

1.1.6) gnuradio/blksimpl/dqpsk.py

Type Python file

Description differential QPSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.1.6.1) dqpsk_mod ( )

Type Function , DQPSK modulator

Description Hierarchical block for RRC-filtered QPSK modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks.dqpsk_mod(fg,

samples_per_symbol=2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

Simple Gnuradio User Manual Page 24 of 208

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.6.2) dqpsk_demod ( )

Type Function , DQPSK demodulator

Description Differentially coherent detection of differentially encoded QPSK. Hierarchical block for RRC-

filtered DQPSK demodulation. The input is the complex modulated signal at baseband. The

output is a stream of bits packed 1 bit per byte (LSB)

Usage blks.d8psk_demod(fg,

samples_per_symbol=2,

excess_bw=.35,

costas_alpha=.15,

gain_mu=None,

mu=0.5,

omega_relative_limit=.005,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: float

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

costas_alpha: loop filter gain

type costas_alpha: float

gain_mu: for M&M block

type gain_mu: float

mu: for M&M block

type mu: float

omega_relative_limit: for M&M block

type omega_relative_limit: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.7) gnuradio/blksimpl/filterbank.py

Type Python file

Description Include Both Filter Synthesis and Analysis

Examples See gnuradio-examples/python/usrp folder

Note

Simple Gnuradio User Manual Page 25 of 208

1.1.7.1) synthesis_filterbank ( )

Type Function

Description Uniformly modulated polyphase DFT filter bank: synthesis

See http://cnx.rice.edu/content/m10424/latest

Takes M complex streams in, produces single complex stream out that runs at M times the

input sample rate

The channel spacing is equal to the input sample rate.

The total bandwidth and output sample rate are equal the

input sample rate * nchannels.

Output stream to frequency mapping:

channel zero is at zero frequency.

if mpoints is odd:

Channels with increasing positive frequencies come from

channels 1 through (N-1)/2.

Channel (N+1)/2 is the maximum negative frequency, and

frequency increases through N-1 which is one channel lower

than the zero frequency.

if mpoints is even:

Channels with increasing positive frequencies come from

channels 1 through (N/2)-1.

Channel (N/2) is evenly split between the max positive

and negative bins.

Channel (N/2)+1 is the maximum negative frequency, and

frequency increases through N-1 which is one channel lower

than the zero frequency.

Channels near the frequency extremes end up getting cut

off by subsequent filters and therefore have diminished

utility.

Usage blks.synthesis_filterbank (fg, mpoints, taps=None)

Parameters fg: flow_graph

mpoints: number of freq bins/interpolation factor/subbands

taps: filter taps for subband filter

Example See ayfabtu.py

1.1.7.2) analysis_filterbank ( )

Type Function

Description Uniformly modulated polyphase DFT filter bank: analysis

See http://cnx.rice.edu/content/m10424/latest

Takes 1 complex stream in, produces M complex streams out that runs at 1/M times the

input sample rate. Same channel to frequency mapping as described in filter synthesis.

Usage blks.analysis_filterbank (fg, mpoints,taps)

Parameters fg: flow_graph

mpoints: number of freq bins/interpolation factor/subbands

taps: filter taps for subband filter

Examples See test_dft_analysis

Simple Gnuradio User Manual Page 26 of 208

1.1.8) gnuradio/blksimpl/fm_demod.py

Type Python file

Description FM demodulation block

Examples

Note

1.1.8.1) fm_demod_cf ( )

Type Function

Description Generalized FM demodulation block with deemphasis and audio filtering.This block

demodulates a band-limited, complex down-converted FM channel into the original baseband

signal, optionally applying deemphasis. Low pass filtering is done on the resultant signal. It

produces an output float stream in the range of [-1.0, +1.0].

Usage blks.fm_demod_cf (fg, channel_rate, audio_decim, deviation,

audio_pass, audio_stop, gain=1.0, tau=75e-6)

Parameters fg: flowgraph

channel_rate: incoming sample rate of the FM baseband

type sample_rate: integer

deviation: maximum FM deviation (default = 5000)

type deviation: float

audio_decim: input to output decimation rate

type audio_decim: integer

audio_pass: audio low pass filter passband frequency

type audio_pass: float

audio_stop: audio low pass filter stop frequency

type audio_stop: float

gain: gain applied to audio output (default = 1.0)

type gain: float

tau: deemphasis time constant (default = 75e-6), specify 'None' to prevent deemphasis

1.1.8.2) demod_20k0f3e_cf ()

Type Function

Description NBFM demodulation block, 20 KHz channels

Usage blks.demod_20k0f3e_cf(fg, channel_rate, audio_decim)

Parameters fg: flowgraph

sample_rate: incoming sample rate of the FM baseband

type sample_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

1.1.8.3) demod_200kf3e_cf ()

Type Function

Description WFM demodulation block, mono. This block demodulates a complex, down converted,

wideband FM channel conforming to 200KF3E emission standards, outputting floats in the

range [-1.0, +1.0].

Usage blks.demod_200kf3e_cf(fg, channel_rate, audio_decim)

Parameters fg: flowgraph

sample_rate: incoming sample rate of the FM baseband

type sample_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

Simple Gnuradio User Manual Page 27 of 208

1.1.9) gnuradio/blksimpl/fm_emph.py

Type Python file

Description FM deemphasis and preemphasis IIR filter

Examples

Note

1.1.9.1) fm_deemph ( )

Type Function

Description FM Deemphasis IIR filter.

H(s) = -------

1 + s

tau is the RC time constant.

critical frequency: w_p = 1/tau

We prewarp and use the bilinear z-transform to get our IIR coefficients.

See "Digital Signal Processing: A Practical Approach" by Ifeachor and Jervis

Usage blks.fm_deemph(fg, fs, tau=75e-6)

Parameters fg: flow graph

type fg: gr.flow_graph

fs: sampling frequency in Hz

type fs: float

tau: Time constant in seconds (75us in US, 50us in EUR)

type tau: float

1.1.9.2) fm_preemph ()

Type Function

Description FM Preemphasis IIR filter.

1 + s*t1

H(s) = ----------

1 + s*t2

I think this is the right transfer function.

This fine ASCII rendition is based on Figure 5-15

in "Digital and Analog Communication Systems", Leon W. Couch II

+-----||------+

| |

o------+ +-----+--------o

| C1 | |

+----/\/\/\/--+ \

\ R2

o--------------------------+--------o

f1 = 1/(2*pi*t1) = 1/(2*pi*R1*C)

Simple Gnuradio User Manual Page 28 of 208

1 R1 + R2

f2 = ------- = ------------

2*pi*t2 2*pi*R1*R2*C

t1 is 75us in US, 50us in EUR

f2 should be higher than our audio bandwidth.

The Bode plot looks like this:

/----------------

/ <-- slope = 20dB/decade

-------------/

f1 f2

We prewarp and use the bilinear z-transform to get our IIR coefficients.

See "Digital Signal Processing: A Practical Approach" by Ifeachor and Jervis

Usage blks.fm_deemph(fg, fs, tau=75e-6)

Parameters fg: flow graph

type fg: gr.flow_graph

fs: sampling frequency in Hz

type fs: float

tau: Time constant in seconds (75us in US, 50us in EUR)

type tau: float

1.1.10) gnuradio/blksimpl/gmsk.py

Type Python file

Description differential QPSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.1.10.1) gmsk_mod ( )

Type Function , GMSK modulator

Description Hierarchical block for Gaussian Minimum Shift Key (GMSK) modulation. The input is a byte

stream (unsigned char) and the output is the complex modulated signal at baseband.

Usage blks.gmsk_mod(fg, samples_per_symbol =2,

bt=.35,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud >= 2

type samples_per_symbol: integer

bt: Gaussian filter bandwidth * symbol time

type bt: float

verbose: Print information about modulator?

type verbose: bool

Simple Gnuradio User Manual Page 29 of 208

debug: Print modulation data to files?

type debug: bool

1.1.10.2) gmsk_demod ( )

Type Function , GMSK demodulator

Description Hierarchical block for Gaussian Minimum Shift Key (GMSK) demodulation. The input is the

complex modulated signal at baseband. The output is a stream of bits packed 1 bit per byte

(the LSB)

Usage blks.gmsk_demod(fg,

samples_per_symbol=2,

gain_mu=None,

mu=0.5,

omega_relative_limit=0.005,

freq_error=0.0,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

Clock recovery parameters. These all have reasonable defaults.

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

freq_error: bit rate error as a fraction

type freq_error :float

1.1.11) gnuradio/blksimpl/nbfm_rx.py

Type Python file

Description Narrow Band FM Receiver

Examples

Note

1.1.11.1) nbfm_rx ( )

Type Function

Description Narrow Band FM Receiver. Takes a single complex baseband input stream and produces a

single float output stream of audio sample in the range [-1, +1].

Usage blks.nbfm_rx(fg, audio_rate, quad_rate, tau=75e-6, max_dev=5e3)

Parameters fg: flow graph

audio_rate: sample rate of audio stream, >= 16k

type audio_rate: integer

quad_rate: sample rate of output stream, quad_rate must be an integer multiple of

audio_rate.

type quad_rate: integer

tau: preemphasis time constant (default 75e-6)

type tau: float

max_dev: maximum deviation in Hz (default 5e3)

type max_dev: float

Simple Gnuradio User Manual Page 30 of 208

1.1.12) gnuradio/blksimpl/nbfm_tx.py

Type Python file

Description Narrow Band FM Transmitter

Examples

Note

1.1.12.1) nbfm_tx ( )

Type Function

Description Narrow Band FM Transmitter. Takes a single float input stream of audio samples in the

range [-1,+1] and produces a single FM modulated complex baseband output.

Usage blks.nbfm_tx (fg, audio_rate, quad_rate, tau=75e-6, max_dev=5e3)

Parameters fg: flow graph

audio_rate: sample rate of audio stream, >= 16k

type audio_rate: integer

quad_rate: sample rate of output stream, quad_rate must be an integer multiple of

audio_rate

type quad_rate: integer

tau: preemphasis time constant (default 75e-6)

type tau: float

max_dev: maximum deviation in Hz (default 5e3)

type max_dev: float

1.1.13) gnuradio/blksimpl/ofdm.py

Type Python file

Description OFDM mod/demod with packets as i/o

Examples

Note

1.1.13.1) ofdm_mod ( )

Type Function

Description Modulates an OFDM stream. Based on the options fft_length, occupied_tones, and

cp_length, this block creates OFDM symbols using a specified modulation option. Send

packets by calling send_pkt Hierarchical block for sending packets. Packets to be sent are

enqueued by calling send_pkt. The output is the complex modulated signal at baseband.

Usage blks.ofdm_mod (fg, options, msgq_limit=2, pad_for_usrp=True)

Parameters fg: flow graph

type fg: flow graph

options: pass modulation options from higher layers (fft length, occupied tones, etc.)

msgq_limit: maximum number of messages in message queue

type msgq_limit: int

pad_for_usrp: If true, packets are padded such that they end up a multiple of 128 samples

Sub Function

Blks.ofdm_mod.send_pkt(payload, eof=False)

Description Send the payload

Parameters payload: data to send

type payload: string

eof : To signal end of transmission

Type eof : Bool True or False

Simple Gnuradio User Manual Page 31 of 208

1.1.13.2) ofdm_demod ( )

Type Function

Description Demodulates a received OFDM stream. Based on the options fft_length, occupied_tones,

and cp_length, this block performs synchronization, FFT, and demodulation of incoming

OFDM symbols and passes packets up the a higher layer. The input is complex baseband.

When packets are demodulated, they are passed to the app via the callback. Hierarchical

block for demodulating and deframing packets.The input is the complex modulated signal at

baseband. Demodulated packets are sent to the handler.

Usage blks.ofdm_demod (fg, options, callback=None)

Parameters fg: flow graph

type fg: flow graph

options: pass modulation options from higher layers (fft length, occupied tones, etc.)

callback: function of two args: ok, payload

type callback: ok: bool; payload: string

1.1.14) gnuradio/blksimpl/ofdm_sync_fixed.py

Type Python file

Description OFDM synchronizer

Examples

1.1.14.1) ofdm_sync_fixed ( )

Type Function

Description Use a fixed trigger point instead of sync block

Usage blks.ofdm_sync_fixed(fg, fft_length, cp_length, snr)

Parameters

Note Needs more documentaion

1.1.15) gnuradio/blksimpl/ofdm_sync_ml.py

Type Python file

Description Maximum Likelihood OFDM synchronizer

Examples

1.1.15.1) ofdm_sync_ml ( )

Type Function

Description Maximum Likelihood OFDM synchronizer:

J. van de Beek, M. Sandell, and P. O. Borjesson, "ML Estimation

of Time and Frequency Offset in OFDM Systems," IEEE Trans.

Signal Processing, vol. 45, no. 7, pp. 1800-1805, 1997.

Usage blks.ofdm_sync_ml(fg, fft_length, cp_length, snr, logging)

Parameters

Note Needs more documentation

Simple Gnuradio User Manual Page 32 of 208

1.1.16) gnuradio/blksimpl/ofdm_sync_pn.py

Type Python file

Description OFDM synchronization using PN Correlation

Examples

1.1.16.1) ofdm_sync_pn ( )

Type Function

Description OFDM synchronization using PN Correlation:

T. M. Schmidl and D. C. Cox, "Robust Frequency and Timing

Synchonization for OFDM," IEEE Trans. Communications, vol. 45, no. 12, 1997.Signal

Processing, vol. 45, no. 7, pp. 1800-1805, 1997.

Usage blks.ofdm_sync_pn(fg, fft_length, cp_length, logging=False)

Parameters

Note Needs more documentation

1.1.17) gnuradio/blksimpl/ofdm_sync_pnac.py

Type Python file

Description OFDM synchronization using PN Autocorrelation

Examples

1.1.17.1) ofdm_sync_pnac ( )

Type Function

Description OFDM synchronization using Autocorrelation PN

Usage blks.ofdm_sync_pnac(fg, fft_length, cp_length, ks)

Parameters

Note Needs more documentation

1.1.18) gnuradio/blksimpl/ofdm_receiver.py

Type Python file

Description OFDM Receiver

Examples

Note Needs more documentation

1.1.18.1) ofdm_receiver ( )

Type Function

Description

Usage blks.ofdm_receiver(fg, fft_length, cp_length, occupied_tones, snr, ks, logging=False)

Parameters

Note Needs more documentation

Simple Gnuradio User Manual Page 33 of 208

1.1.19) gnuradio/blksimpl/pkt.py

Type Python file

Description mod/demod with packets as i/o (sending packets and demodulating /deframing

packets)

Examples

Note

1.1.19.1) mod_pkts ( )

Type Function

Description Wrap an arbitrary digital modulator in our packet handling framework.Send packets by calling

send_pkt. Hierarchical block for sending packets.Packets to be sent are enqueued by calling

send_pkt.The output is the complex modulated signal at baseband.

Usage blks.mod_pkts(fg, modulator, access_code=None, msgq_limit=2, pad_for_usrp=True,

use_whitener_offset=False)

Parameters fg: flow graph

type fg: flow graph

modulator: instance of modulator class (gr_block or hier_block)

type modulator: complex baseband out

access_code: AKA sync vector

type access_code: string of 1's and 0's between 1 and 64 long

msgq_limit: maximum number of messages in message queue

type msgq_limit: int

pad_for_usrp: If true, packets are padded such that they end up a multiple of 128 samples

use_whitener_offset: If true, start of whitener XOR string is incremented each packet

see gmsk_mod for remaining parameters

Sub Function

blks.mod_pkts.send_pkt(payload, eof=False)

Description Send the payload

Parameters payload: data to send

type payload: string

eof : To signal end of transmission

Type eof : Bool True or False

1.1.19.1) demod_pkts ( )

Type Function

Description Wrap an arbitrary digital demodulator in our packet handling framework. The input is complex

baseband. When packets are demodulated, they are passed to the app via the callback.

Hierarchical block for demodulating and deframing packets. The input is the complex

modulated signal at baseband. Demodulated packets are sent to the handler.

Usage blks.demod_pkts(fg,demodulator,access_code=None,callback=None, threshold=-1)

Parameters fg: flow graph

type fg: flow graph

demodulator: instance of demodulator class (gr_block or hier_block)

type demodulator: complex baseband in

access_code: AKA sync vector

type access_code: string of 1's and 0's

callback: function of two args: ok, payload

type callback: ok: bool; payload: string

threshold: detect access_code with up to threshold bits wrong (-1 -> use default)

type threshold: int

Simple Gnuradio User Manual Page 34 of 208

1.1.20) gnuradio/blksimpl/psk.py

Type Python file

Description Define different kinds of constellations for Tx and Rx for the PSK (BPSK, QPSK,

8PSK)

Examples

Note Needs more Documentation

1.1.21) gnuradio/blksimpl/qam.py

Type Python file

Description Define different kinds of constellations for Tx and Rx for the QAM

(QAM4,QAM8,QAM16,QAM64,QAM256)

Examples

Note Needs more Documentation

1.1.22) gnuradio/blksimpl/qam8.py

Type Python file

Description QAM8 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.1.22.1) qam8_mod ( )

Type Function QAM8 modulator

Description Hierarchical block for RRC-filtered QAM8 modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks.qam8_mod(fg, samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.22.2) qam8_demod ( )

Type Function , QAM8 demodulator

Description Hierarchical block for QAM8 demodulation. The input is the complex modulated signal at

Simple Gnuradio User Manual Page 35 of 208

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks.qam8_demod(fg,

samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.1.23) gnuradio/blksimpl/qam16.py

Type Python file

Description QAM16 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.1.23.1) qam16_mod ( )

Type Function QAM16 modulator

Description Hierarchical block for QAM16 modulation. The input is a byte stream (unsigned char) and the

output is the complex modulated signal at baseband.

Usage blks.qam16_mod(fg, samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

Simple Gnuradio User Manual Page 36 of 208

1.1.23.2) qam16_demod ( )

Type Function , QAM16 demodulator

Description Hierarchical block for QAM16 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks.qam16_demod(fg,

samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.1.24) gnuradio/blksimpl/qam64.py

Type Python file

Description QAM64 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.1.24.1) qam64_mod ( )

Type Function QAM64 modulator

Description Hierarchical block for QAM64 modulation. The input is a byte stream (unsigned char) and the

output is the complex modulated signal at baseband.

Usage blks.qam64_mod(fg, samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

Simple Gnuradio User Manual Page 37 of 208

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.24.2) qam64_demod ( )

Type Function , QAM64 demodulator

Description Hierarchical block for QAM64 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks.qam64_demod(fg,

samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.1.25) gnuradio/blksimpl/qam256.py

Type Python file

Description QAM256 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.1.25.1) qam256_mod ( )

Type Function QAM256 modulator

Description Hierarchical block for QAM256 modulation. The input is a byte stream (unsigned char) and

the output is the complex modulated signal at baseband.

Usage blks.qam256_mod(fg, samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

Simple Gnuradio User Manual Page 38 of 208

type fg: flow graph

samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.1.25.2) qam256_demod ( )

Type Function , QAM256 demodulator

Description Hierarchical block for QAM256 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks.qam256_demod(fg,

samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters fg: flow graph

type fg: flow graph

samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.1.26) gnuradio/blksimpl/rational_resampler.py

Type Python file

Description Rational resample polyphase FIR filter

Examples

Note

1.1.26.1) rational_resampler ( )

Type Function

Description rational_resampler_fff :Rational resampling polyphase FIR filter with float input, float output

and float taps.

rational_resampler_ccf : Rational resampling polyphase FIR filter with complex input,

complex output and float taps.

Simple Gnuradio User Manual Page 39 of 208

rational_resampler_ccc : Rational resampling polyphase FIR filter with complex input,

complex output and complex taps.

Usage blks.rational_resampler_xxx(fg,interpolation, decimation, taps=None,

fractional_bw=None)

Parameters fg: flow graph

interpolation: interpolation factor

type interpolation: integer > 0

decimation: decimation factor

type decimation: integer > 0

taps: optional filter coefficients see blks.filter_design

type taps: sequence

fractional_bw: fractional bandwidth in (0, 0.5), measured at final freq (use 0.4)

type fractional_bw: float

Note Either taps or fractional_bw may be specified, but not both.

If neither is specified, a reasonable default, 0.4, is used as the fractional_bw.

1.1.26.2) design_filter ( )

Type Function

Description Given the interpolation rate, decimation rate and a fractional bandwidth, design a set of taps.

returns: sequence of numbers

Usage blks.design_filter(design_filter(interpolation,decimation, fractional_bw)

Parameters interpolation: interpolation factor

type interpolation: integer > 0

decimation: decimation factor

type decimation: integer > 0

fractional_bw: fractional bandwidth in (0, 0.5) 0.4 works well.

type fractional_bw: float

1.1.27) gnuradio/blksimpl/standard_squelch.py

Type Python file

Description Implement the squelch function

Examples

Note Needs more Documentation

1.1.27.1) standard_squelch ( )

Type Function

Description Implement the squelch function with 100msec time constant.

Usage blks.standard_squelch(fg, audio_rate)

Parameters fg: flow graph

audio_rate : Sample rate of audio stream

Sub Function 1 blks. standard_squelch.set_threshold(threshold)

Description Set Squelch Threshold value

Sub Function 2 blks. standard_squelch.threshold()

Description Return Squelch Threshold value

Sub Function 3 blks. standard_squelch.squelch_range()

Description Return Squelch range

1.1.28) gnuradio/blksimpl/wfm_rcv.py

Type Python file

Description Demodulating a broadcast FM signal with a deemphasis

Simple Gnuradio User Manual Page 40 of 208

Examples

Note

1.1.28.1) wfm_rcv ( )

Type Function

Description Hierarchical block for demodulating a broadcast FM signal. The input is the down converted

complex baseband signal (gr_complex).The output is the demodulated audio (float).

Usage blks.wfm_rcv(fg, quad_rate, audio_decimation)

Parameters fg: flow graph.

type fg: flow graph

quad_rate: input sample rate of complex baseband input.

type quad_rate: float

audio_decimation: how much to decimate quad_rate to get to audio.

type audio_decimation: integer

1.1.29) gnuradio/blksimpl/wfm_rcv_pll.py

Type Python file

Description Stereo demodulating a broadcast FM signal with a deemphasis

Examples

Note

1.1.29.1) wfm_rcv_pll ( )

Type Function

Description Hierarchical block for demodulating a broadcast FM signal. The input is the down converted

complex baseband signal (gr_complex).The output is two streams of the demodulated audio

(float) 0=Left, 1=Right.

Usage blks.wfm_rcv_pll(fg, demod_rate, audio_decimation)

Parameters fg: flow graph.

type fg: flow graph

demod_rate: input sample rate of complex baseband input.

type demod_rate: float

audio_decimation: how much to decimate demod_rate to get to audio.

type audio_decimation: integer

1.1.30) gnuradio/blksimpl/wfm_tx.py

Type Python file

Description Wide Band FM Transmitter with a preemphasis

Examples

Note

1.1.30.1) wfm_tx ( )

Type Function

Description Wide Band FM Transmitter. Takes a single float input stream of audio samples in the range [-

1,+1]and produces a single FM modulated complex baseband output.

Usage blks. wfm_tx(fg, audio_rate, quad_rate, tau=75e-6, max_dev=75e3)

Simple Gnuradio User Manual Page 41 of 208

Parameters fg: flow graph

audio_rate: sample rate of audio stream, >= 16k

type audio_rate: integer

quad_rate: sample rate of output stream, quad_rate must be an integer multiple of

audio_rate.

type quad_rate: integer

tau: preemphasis time constant (default 75e-6)

type tau: float

max_dev: maximum deviation in Hz (default 75e3)

type max_dev: float

1.1.31) gnuradio/blksimpl/cvsd.py

Type Python file

Description CVSD encoder and decoder

Examples

Note Needs more documentation

1.1.31.1) cvsd_encode ( )

Type Function

Description This is a wrapper for the CVSD encoder that performs interpolation and filtering necessary to

work with the vocoding. It converts an incoming float (+-1) to a short, scales it (to 32000;

slightly below the maximum value), interpolates it, and then vocodes it.

The incoming sampling rate can be anything, though, of course, the higher the sampling rate

and thehigher the interpolation rate are, the better the sound quality. When using the CVSD

vocoder, appropriate sampling rates are from 8k to 64k with resampling rates from 1 to 8. A

rate of 8k with a resampling rate of 8 provides a good quality signal.

Usage blks2. cvsd_encode(resample=8, bw=0.5)

Parameters

1.1.31.2) cvsd_decode ( )

Type Function

Description This is a wrapper for the CVSD decoder that performs decimation and filtering necessary to

work with the vocoding. It converts an incoming CVSD-encoded short to a float, decodes it to

a float, decimates it, and scales it (by 32000; slightly below the maximum value to avoid

clipping). The sampling rate can be anything, though, of course, the higher the sampling rate

and the higher the interpolation rate are, the better the sound quality. When using the CVSD

vocoder, appropriate sampling rates are from 8k to 64k with resampling rates from 1 to 8. A

rate of 8k with a resampling rate of 8 provides a good quality signal.

Usage blks2. cvsd_decode(resample=8, bw=0.5)

Parameters

1.2) gnuradio/blks2 sub package

Type Folder

Description Semi-hideous kludge to import everything in the blk2simpl directory into the gnuradio.blks2

namespace. The blocks were implemented using hier_block2.

Simple Gnuradio User Manual Page 42 of 208

1.2.1) gnuradio/blks2impl/am_demod.py

Type Python file

Description AM demodulation block

Examples

Note

1.2.1.1) am_demod_cf ( )

Type Function

Description Generalized AM demodulation block with audio filtering. This block demodulates a band-

limited, complex down-converted AM channel into the the original baseband signal,

applying low pass filtering to the audio output. It produces a float stream in the range [-1.0,

+1.0].

Usage blks2.am_demod_cf (channel_rate, audio_decim, audio_pass, audio_stop)

Parameters channel_rate: incoming sample rate of the AM baseband

type sample_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

audio_pass: audio low pass filter passband frequency

type audio_pass: float

audio_stop: audio low pass filter stop frequency

type audio_stop: float

1.2.1.2) demod_10k0a3e_cf()

Type Function

Description AM demodulation block, 10 KHz channel.This block demodulates an AM channel conformant

to 10K0A3E emission standards, such as broadcast band AM transmissions.

Usage blks2.demod_10k0a3e_cf(channel_rate, audio_decim)

Parameters channel_rate: incoming sample rate of the AM baseband

type sample_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

1.2.2) gnuradio/blks2impl/channel_model.py

Type Python file

Description Creates a channel model

Examples

Note

1.2.2.1) channel_model ( )

Type Function

Description Creates a channel model that includes:

- AWGN noise power in terms of noise voltage

Simple Gnuradio User Manual Page 43 of 208

- A frequency offset in the channel in ratio

- A timing offset ratio to model clock difference (clock rate ratio) (epsilon). It is sample

rate difference between tx and rx

- Multipath taps

Usage blks2.channel_model(noise_voltage=0.0, frequency_offset=0.0, epsilon=1.0,

taps=[1.0,0.0])

Parameters

Sub Function 1 blks2.channel_model.set_noise_voltage(noise_voltage)

Sub Function 2 blks2.channel_model.set_frequency_offset(frequency_offset)

Sub Function 3 blks2.channel_model.set_taps(taps)

1.2.3) gnuradio/blks2impl/cpm.py

Type Python file

Description Continuous Phase modulation.

Examples See gnuradio-examples/python/digital for examples

Note

1.2.3.1) cpm_mod ( )

Type Function

Description Hierarchical block for Continuous Phase Modulation.

The input is a byte stream (unsigned char) representing packed bits and the output is

the complex modulated signal at baseband.

See Proakis for definition of generic CPM signals:

s(t)=exp(j phi(t))

phi(t)= 2 pi h int_0^t f(t') dt'

f(t)=sum_k a_k g(t-kT)

(normalizing assumption: int_0^infty g(t) dt = 1/2)

Usage blks2.cpm_mod(samples_per_symbol=2,bits_per_symbol=1,

h_numerator=1, h_denominator=2,

cpm_type=0,bt=_def_bt, symbols_per_pulse=1, generic_taps

numpy.empty(1), verbose=False, log=False)

Parameters samples_per_symbol: samples per baud >= 2

type samples_per_symbol: integer

bits_per_symbol: bits per symbol

type bits_per_symbol: integer

h_numerator: numerator of modulation index

type h_numerator: integer

h_denominator: denominator of modulation index (numerator and denominator must

be relative primes)

type h_denominator: integer

cpm_type: supported types are: 0=CPFSK, 1=GMSK, 2=RC, 3=GENERAL

type cpm_type: integer

bt: bandwidth symbol time product for GMSK

type bt: float

symbols_per_pulse: shaping pulse duration in symbols

type symbols_per_pulse: integer

generic_taps: define a generic CPM pulse shape (sum = samples_per_symbol/2)

type generic_taps: array of floats

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

Simple Gnuradio User Manual Page 44 of 208

1.2.4) gnuradio/blks2impl/d8psk.py

Type Python file

Description differential 8PSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.2.4.1) d8psk_mod ( )

Type Function , D8PSK modulator

Description Hierarchical block for RRC-filtered QPSK modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks2.d8psk_mod(samples_per_symbol=3,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files!

type debug: bool

1.2.4.2) d8psk_demod ( )

Type Function , D8PSK demodulator

Description Differentially coherent detection of differentially encoded 8psk. Hierarchical block for RRC-

filtered DQPSK demodulation. The input is the complex modulated signal at baseband. The

output is a stream of bits packed 1 bit per byte (LSB)

Usage blks2.d8psk_demod(samples_per_symbol=3,

excess_bw=.35,

costas_alpha=.175,

gain_mu=.175,

mu=0.5,

omega_relative_limit=.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: float

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

costas_alpha: loop filter gain

type costas_alpha: float

gain_mu: for M&M block

type gain_mu: float

mu: for M&M block

type mu: float

omega_relative_limit: for M&M block

type omega_relative_limit: float

gray_code: Tell modulator to Gray code the bits

Simple Gnuradio User Manual Page 45 of 208

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print demodulation data to files?

type debug: bool

1.2.5) gnuradio/blks2impl/dbpsk.py

Type Python file

Description Differential BPSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.2.5.1) dbpsk_mod ( )

Type Function , DBPSK modulator

Description Hierarchical block for RRC-filtered BPSK modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks2.dbpsk_mod(samples_per_symbol=2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

log: Log modulation data to files?

type log: bool

1.2.5.2) dbpsk_demod ( )

Type Function , DBPSK demodulator

Description Differentially coherent detection of differentially encoded BPSK. Hierarchical block for RRC-

filtered DBPSK demodulation. The input is the complex modulated signal at baseband. The

output is a stream of bits packed 1 bit per byte (LSB).

Usage blks2.d8psk_demod(samples_per_symbol=2,

excess_bw=.35,

costas_alpha=.1,

gain_mu=None,

mu=0.5,

omega_relative_limit=.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: float

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

costas_alpha: loop filter gain

type costas_alpha: float

Simple Gnuradio User Manual Page 46 of 208

gain_mu: for M&M block

type gain_mu: float

mu: for M&M block

type mu: float

omega_relative_limit: for M&M block

type omega_relative_limit: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print demodulation data to files?

type debug: bool

1.2.6) gnuradio/blks2impl/dqpsk.py

Type Python file

Description differential QPSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.2.6.1) dqpsk_mod ( )

Type Function , DQPSK modulator

Description Hierarchical block for RRC-filtered QPSK modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks2.dqpsk_mod(samples_per_symbol=2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.6.2) dqpsk_demod ( )

Type Function , DQPSK demodulator

Description Differentially coherent detection of differentially encoded QPSK. Hierarchical block for RRC-

filtered DQPSK demodulation. The input is the complex modulated signal at baseband. The

output is a stream of bits packed 1 bit per byte (LSB)

Usage blks2.d8psk_demod(samples_per_symbol=2,

excess_bw=.35,

costas_alpha=.15,

gain_mu=None,

Simple Gnuradio User Manual Page 47 of 208

mu=0.5,

omega_relative_limit=.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: float

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

costas_alpha: loop filter gain

type costas_alpha: float

gain_mu: for M&M block

type gain_mu: float

mu: for M&M block

type mu: float

omega_relative_limit: for M&M block

type omega_relative_limit: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.7) gnuradio/blks2impl/filterbank.py

Type Python file

Description Include Both Filter Synthesis and Analysis

Examples See gnuradio-examples/python/usrp folder

Note

1.2.7.1) synthesis_filterbank ( )

Type Function

Description Uniformly modulated polyphase DFT filter bank: synthesis

See http://cnx.rice.edu/content/m10424/latest

Takes M complex streams in, produces single complex stream out that runs at M times the

input sample rate

The channel spacing is equal to the input sample rate.

The total bandwidth and output sample rate are equal the

input sample rate * nchannels.

Output stream to frequency mapping:

channel zero is at zero frequency.

if mpoints is odd:

Channels with increasing positive frequencies come from

channels 1 through (N-1)/2.

Channel (N+1)/2 is the maximum negative frequency, and

frequency increases through N-1 which is one channel lower

than the zero frequency.

if mpoints is even:

Simple Gnuradio User Manual Page 48 of 208

Channels with increasing positive frequencies come from

channels 1 through (N/2)-1.

Channel (N/2) is evenly split between the max positive

and negative bins.

Channel (N/2)+1 is the maximum negative frequency, and

frequency increases through N-1 which is one channel lower

than the zero frequency.

Channels near the frequency extremes end up getting cut

off by subsequent filters and therefore have diminished utility.

Usage blks2.synthesis_filterbank (mpoints, taps=None)

Parameters mpoints: Number of freq bins/interpolation factor/subbands

taps: Filter taps for subband filter

Example See ayfabtu.py

1.2.7.2) analysis_filterbank ( )

Type Function

Description Uniformly modulated polyphase DFT filter bank: analysis.

See http://cnx.rice.edu/content/m10424/latest

Takes 1 complex stream in, produces M complex streams out that runs at 1/M times the

input sample rate. Same channel to frequency mapping as described in filter synthesis.

Usage blks2.analysis_filterbank ( mpoints,taps)

Parameters mpoints: number of freq bins/interpolation factor/subbands

taps: filter taps for subband filter

Examples See test_dft_analysis

1.2.8) gnuradio/blks2impl/fm_demod.py

Type Python file

Description FM demodulation block

Examples

Note

1.2.8.1) fm_demod_cf ( )

Type Function

Description Generalized FM demodulation block with deemphasis and audio filtering. This block

demodulates a band-limited, complex down-converted FM channel into the original baseband

signal, optionally applying deemphasis. Low pass filtering is done on the resultant signal. It

produces an output float stream in the range of [-1.0, +1.0].

Usage blks2.fm_demod_cf (channel_rate, audio_decim, deviation,

audio_pass, audio_stop, gain=1.0, tau=75e-6)

Parameters channel_rate: incoming sample rate of the FM baseband

type sample_rate: integer

deviation: maximum FM deviation (default = 5000)

type deviation: float

audio_decim: input to output decimation rate

type audio_decim: integer

audio_pass: audio low pass filter passband frequency

type audio_pass: float

audio_stop: audio low pass filter stop frequency

type audio_stop: float

gain: gain applied to audio output (default = 1.0)

type gain: float

tau: deemphasis time constant (default = 75e-6), specify 'None' to prevent deemphasis

Simple Gnuradio User Manual Page 49 of 208

1.2.8.2) demod_20k0f3e_cf ()

Type Function

Description NBFM demodulation block, 20 KHz channels

Usage blks2.demod_20k0f3e_cf(channel_rate, audio_decim)

Parameters sample_rate: incoming sample rate of the FM baseband

type sample_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

1.2.8.3) demod_200kf3e_cf ()

Type Function

Description WFM demodulation block, mono. This block demodulates a complex, down converted,

wideband FM channel conforming to 200KF3E emission standards, outputting floats in the

range [-1.0, +1.0].

Usage blks2.demod_200kf3e_cf(channel_rate, audio_decim)

Parameters sample_rate: incoming sample rate of the FM baseband

type sample_rate: integer

audio_decim: input to output decimation rate

type audio_decim: integer

1.2.9) gnuradio/blks2impl/fm_emph.py

Type Python file

Description FM deemphasis and preemphasis IIR filter

Examples

Note

1.2.9.1) fm_deemph ( )

Type Function

Description FM Deemphasis IIR filter.

H(s) = -------

1 + s

tau is the RC time constant.

critical frequency: w_p = 1/tau

We prewarp and use the bilinear z-transform to get our IIR coefficients.

See "Digital Signal Processing: A Practical Approach" by Ifeachor and Jervis

Usage blks2.fm_deemph(fs, tau=75e-6)

Parameters fs: sampling frequency in Hz

type fs: float

tau: Time constant in seconds (75us in US, 50us in EUR)

type tau: float

Simple Gnuradio User Manual Page 50 of 208

1.2.9.2) fm_preemph ()

Type Function

Description FM Preemphasis IIR filter.

1 + s*t1

H(s) = ----------

1 + s*t2

I think this is the right transfer function.

This fine ASCII rendition is based on Figure 5-15

in "Digital and Analog Communication Systems", Leon W. Couch II

+-----||------+

| |

o------+ +-----+--------o

| C1 | |

+----/\/\/\/--+ \

\ R2

o--------------------------+--------o

f1 = 1/(2*pi*t1) = 1/(2*pi*R1*C)

1 R1 + R2

f2 = ------- = ------------

2*pi*t2 2*pi*R1*R2*C

t1 is 75us in US, 50us in EUR

f2 should be higher than our audio bandwidth.

The Bode plot looks like this:

/----------------

/ <-- slope = 20dB/decade

-------------/

f1 f2

We prewarp and use the bilinear z-transform to get our IIR coefficients.

See "Digital Signal Processing: A Practical Approach" by Ifeachor and Jervis

Usage blks2.fm_deemph(fs, tau=75e-6)

Parameters fs: sampling frequency in Hz

type fs: float

tau: Time constant in seconds (75us in US, 50us in EUR)

type tau: float

Simple Gnuradio User Manual Page 51 of 208

1.2.10) gnuradio/blks2impl/gmsk.py

Type Python file

Description differential QPSK modulation and demodulation

Examples See gnuradio-examples/python/digital for examples

Note

1.2.10.1) gmsk_mod ( )

Type Function , GMSK modulator

Description Hierarchical block for Gaussian Minimum Shift Key (GMSK) modulation. The input is a byte

stream (unsigned char) and the output is the complex modulated signal at baseband.

Usage blks2.gmsk_mod(samples_per_symbol =2,

bt=.35,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud >= 2

type samples_per_symbol: integer

bt: Gaussian filter bandwidth * symbol time

type bt: float

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.10.2) gmsk_demod ( )

Type Function , GMSK demodulator

Description Hierarchical block for Gaussian Minimum Shift Key (GMSK) demodulation. The input is the

complex modulated signal at baseband. The output is a stream of bits packed 1 bit per byte

(the LSB)

Usage blks2.gmsk_demod(samples_per_symbol=2,

gain_mu=None,

mu=0.5,

omega_relative_limit=0.005,

freq_error=0.0,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

Clock recovery parameters. These all have reasonable defaults.

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

Simple Gnuradio User Manual Page 52 of 208

type omega_relative_limit: float, typically 0.000200 (200 ppm)

freq_error: bit rate error as a fraction

type freq_error :float

1.2.11) gnuradio/blks2impl/nbfm_rx.py

Type Python file

Description Narrow Band FM Receiver

Examples

Note

1.2.11.1) nbfm_rx ( )

Type Function

Description Narrow Band FM Receiver. Takes a single complex baseband input stream and produces a

single float output stream of audio sample in the range [-1, +1].

Usage blks2.nbfm_rx(audio_rate, quad_rate, tau=75e-6, max_dev=5e3)

Parameters audio_rate: sample rate of audio stream, >= 16k

type audio_rate: integer

quad_rate: sample rate of output stream, quad_rate must be an integer multiple of

audio_rate.

type quad_rate: integer

tau: preemphasis time constant (default 75e-6)

type tau: float

max_dev: maximum deviation in Hz (default 5e3)

type max_dev: float

1.2.12) gnuradio/blks2impl/nbfm_tx.py

Type Python file

Description Narrow Band FM Transmitter

Examples

Note

1.2.12.1) nbfm_tx ( )

Type Function

Description Narrow Band FM Transmitter. Takes a single float input stream of audio samples in the

range [-1,+1] and produces a single FM modulated complex baseband output.

Usage blks2.nbfm_tx (audio_rate, quad_rate, tau=75e-6, max_dev=5e3)

Parameters audio_rate: sample rate of audio stream, >= 16k

type audio_rate: integer

quad_rate: sample rate of output stream, quad_rate must be an integer multiple of

audio_rate.

type quad_rate: integer

tau: preemphasis time constant (default 75e-6)

type tau: float

max_dev: maximum deviation in Hz (default 5e3)

type max_dev: float

Simple Gnuradio User Manual Page 53 of 208

1.2.13) gnuradio/blks2impl/ofdm.py

Type Python file

Description OFDM mod/demod with packets as i/o

Examples

Note

1.2.13.1) ofdm_mod ( )

Type Function

Description Modulates an OFDM stream. Based on the options fft_length, occupied_tones, and

cp_length, this block creates OFDM symbols using a specified modulation option. Send

packets by calling send_pkt Hierarchical block for sending packets. Packets to be sent are

enqueued by calling send_pkt. The output is the complex modulated signal at baseband.

Usage blks2.ofdm_mod (options, msgq_limit=2, pad_for_usrp=True)

Parameters options: pass modulation options from higher layers (fft length, occupied tones, etc.)

msgq_limit: maximum number of messages in message queue

type msgq_limit: int

pad_for_usrp: If true, packets are padded such that they end up a multiple of 128 samples

Sub Function

blks.ofdm_mod.send_pkt(payload, eof=False)

Description Send the payload

Parameters payload: data to send

type payload: string

eof : To signal end of transmission

Type eof : Bool True or False

1.2.13.2) ofdm_demod ( )

Type Function

Description Demodulates a received OFDM stream. Based on the options fft_length, occupied_tones,

and cp_length, this block performs synchronization, FFT, and demodulation of incoming

OFDM symbols and passes packets up the a higher layer. The input is complex baseband.

When packets are demodulated, they are passed to the app via the callback. Hierarchical

block for demodulating and deframing packets. The input is the complex modulated signal at

baseband. Demodulated packets are sent to the handler.

Usage blks2.ofdm_demod (options, callback=None)

Parameters options: pass modulation options from higher layers (fft length, occupied tones, etc.)

callback: function of two args: ok, payload

type callback: ok: bool; payload: string

Simple Gnuradio User Manual Page 54 of 208

1.2.14) gnuradio/blks2impl/pkt.py

Type Python file

Description mod/demod with packets as i/o (sending packets and demodulating /deframing

packets)

Examples

Note

1.2.14.1) mod_pkts ( )

Type Function

Description Wrap an arbitrary digital modulator in our packet handling framework. Send packets by

calling send_pkt. Hierarchical block for sending packets. Packets to be sent are enqueued by

calling send_pkt. The output is the complex modulated signal at baseband.

Usage blks2.mod_pkts(modulator, access_code=None, msgq_limit=2, pad_for_usrp=True,

use_whitener_offset=False)

Parameters modulator: instance of modulator class (gr_block or hier_block)

type modulator: complex baseband out

access_code: AKA sync vector

type access_code: string of 1's and 0's between 1 and 64 long

msgq_limit: maximum number of messages in message queue

type msgq_limit: int

pad_for_usrp: If true, packets are padded such that they end up a multiple of 128 samples

use_whitener_offset: If true, start of whitener XOR string is incremented each packet

see gmsk_mod for remaining parameters

Sub Function

blks.mod_pkts.send_pkt(payload, eof=False)

Description Send the payload

Parameters payload: data to send

type payload: string

eof : To signal end of transmission

Type eof : Bool True or False

1.2.14.2) demod_pkts ( )

Type Function

Description Wrap an arbitrary digital demodulator in our packet handling framework. The input is complex

baseband. When packets are demodulated, they are passed to the app via the callback.

Hierarchical block for demodulating and deframing packets. The input is the complex

modulated signal at baseband. Demodulated packets are sent to the handler.

Usage blks2.demod_pkts(demodulator,access_code=None,callback=None, threshold=-1)

Parameters demodulator: instance of demodulator class (gr_block or hier_block)

type demodulator: complex baseband in

access_code: AKA sync vector

type access_code: string of 1's and 0's

callback: function of two args: ok, payload

type callback: ok: bool; payload: string

threshold: detect access_code with up to threshold bits wrong (-1 -> use default)

type threshold: int

1.2.15) gnuradio/blks2impl/psk.py

Type Python file

Description Define different kinds of constellations for Tx and Rx for the PSK (BPSK, QPSK,

8PSK)

Examples

Note Needs more Documentation

Simple Gnuradio User Manual Page 55 of 208

1.2.16) gnuradio/blks2impl/qam.py

Type Python file

Description Define different kinds of constellations for Tx and Rx for the QAM

(QAM4,QAM8,QAM16,QAM64,QAM256)

Examples

Note Needs more Documentation

1.2.17) gnuradio/blks2impl/qam8.py

Type Python file

Description QAM8 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.2.17.1) qam8_mod ( )

Type Function QAM8 modulator

Description Hierarchical block for RRC-filtered QAM8 modulation. The input is a byte stream (unsigned

char) and the output is the complex modulated signal at baseband.

Usage blks2.qam8_mod(samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.17.2) qam8_demod ( )

Type Function , QAM8 demodulator

Description Hierarchical block for QAM8 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks2.qam8_demod(samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

Simple Gnuradio User Manual Page 56 of 208

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.2.18) gnuradio/blks2impl/qam16.py

Type Python file

Description QAM16 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.2.18.1) qam16_mod ( )

Type Function QAM16 modulator

Description Hierarchical block for QAM16 modulation. The input is a byte stream (unsigned char) and the

output is the complex modulated signal at baseband.

Usage blks2.qam16_mod(samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.18.2) qam16_demod ( )

Type Function , QAM16 demodulator

Description Hierarchical block for QAM16 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks2.qam16_demod(samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

type log: bool

gain_mu: controls rate of mu adjustment

Simple Gnuradio User Manual Page 57 of 208

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.2.19) gnuradio/blks2impl/qam64.py

Type Python file

Description QAM64 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.2.19.1) qam64_mod ( )

Type Function QAM64 modulator

Description Hierarchical block for QAM64 modulation. The input is a byte stream (unsigned char) and the

output is the complex modulated signal at baseband.

Usage blks2.qam64_mod(samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.19.2) qam64_demod ( )

Type Function , QAM64 demodulator

Description Hierarchical block for QAM64 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks2.qam64_demod(samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

Simple Gnuradio User Manual Page 58 of 208

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.2.20) gnuradio/blks2impl/qam256.py

Type Python file

Description QAM256 modulation and demodulation.

Examples See gnuradio-examples/python/digital for examples

Note Needs more Documentation

1.2.20.1) qam256_mod ( )

Type Function QAM256 modulator

Description Hierarchical block for QAM256 modulation. The input is a byte stream (unsigned char) and

the output is the complex modulated signal at baseband.

Usage blks2.qam256_mod(samples_per_symbol =2,

excess_bw=.35,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per symbol >= 2

type samples_per_symbol: integer

excess_bw: Root-raised cosine filter excess bandwidth

type excess_bw: float

gray_code: Tell modulator to Gray code the bits

type gray_code: bool

verbose: Print information about modulator?

type verbose: bool

debug: Print modulation data to files?

type debug: bool

1.2.20.2) qam256_demod ( )

Type Function , QAM256 demodulator

Description Hierarchical block for QAM256 demodulation. The input is the complex modulated signal at

baseband. The output is a stream of bits packed 1 bit per byte (the LSB)

Usage blks2.qam256_demod(samples_per_symbol=2,

excess_bw=.35,

costas_alpha=None,

gain_mu=0.03,

mu=0.05,

omega_relative_limit=0.005,

gray_code=True,

verbose=False,

log=False)

Parameters samples_per_symbol: samples per baud

type samples_per_symbol: integer

verbose: Print information about modulator?

type verbose: bool

log: Print modulation data to files?

Simple Gnuradio User Manual Page 59 of 208

type log: bool

gain_mu: controls rate of mu adjustment

type gain_mu: float

mu: fractional delay [0.0, 1.0]

type mu: float

omega_relative_limit: sets max variation in omega

type omega_relative_limit: float, typically 0.000200 (200 ppm)

1.2.21) gnuradio/blks2impl/rational_resampler.py

Type Python file

Description Rational resample polyphase FIR filter

Examples

Note

1.2.21.1) rational_resampler ( )

Type Function

Description rational_resampler_fff :Rational resampling polyphase FIR filter with float input, float output

and float taps.

rational_resampler_ccf : Rational resampling polyphase FIR filter with complex input,

complex output and float taps.

rational_resampler_ccc : Rational resampling polyphase FIR filter with complex input,

complex output and complex taps.

Usage blks2.rational_resampler_xxx(interpolation, decimation, taps=None,

fractional_bw=None)

Parameters interpolation: interpolation factor

type interpolation: integer > 0

decimation: decimation factor

type decimation: integer > 0

taps: optional filter coefficients see blks2.design_filter

type taps: sequence

fractional_bw: fractional bandwidth in (0, 0.5), measured at final freq (use 0.4)

type fractional_bw: float

Note Either taps or fractional_bw may be specified, but not both.

If neither is specified, a reasonable default, 0.4, is used as the fractional_bw.

1.2.21.2) design_filter ( )

Type Function

Description Given the interpolation rate, decimation rate and a fractional bandwidth, design a set of taps.

returns: sequence of numbers

Usage blks2.design_filter(design_filter(interpolation,decimation, fractional_bw)

Parameters interpolation: interpolation factor

type interpolation: integer > 0

decimation: decimation factor

type decimation: integer > 0

fractional_bw: fractional bandwidth in (0, 0.5) 0.4 works well.

type fractional_bw: float

Simple Gnuradio User Manual Page 60 of 208

1.2.22) gnuradio/blks2impl/standard_squelch.py

Type Python file

Description Implement the squelch function

Examples

Note Needs more Documentation

1.2.22.1) standard_squelch ( )

Type Function

Description Implement the squelch function with 100msec time constant

Usage blks2. standard_squelch(audio_rate)

Parameters audio_rate : Audio rate

Sub Function 1 blks2. standard_squelch.set_threshold(threshold)

Description Set Squelch Threshold value

Sub Function 2 blks2. standard_squelch.threshold()

Description Return Squelch Threshold value

Sub Function 3 blks2. standard_squelch.squelch_range()

Description Return Squelch range

1.2.23) gnuradio/blks2impl/wfm_rcv.py

Type Python file

Description Demodulating a broadcast FM signal with a deemphasis

Examples

Note

1.2.23.1) wfm_rcv ( )

Type Function

Description Hierarchical block for demodulating a broadcast FM signal. The input is the down converted

complex baseband signal (gr_complex).The output is the demodulated audio (float).

Usage blks2.wfm_rcv(quad_rate, audio_decimation)

Parameters quad_rate: input sample rate of complex baseband input.

type quad_rate: float

audio_decimation: how much to decimate quad_rate to get to audio.

type audio_decimation: integer

1.2.24) gnuradio/blks2impl/wfm_rcv_pll.py

Type Python file

Description Stereo demodulating a broadcast FM signal with a deemphasis

Examples

Note

Simple Gnuradio User Manual Page 61 of 208

1.2.24.1) wfm_rcv_pll ( )

Type Function

Description Hierarchical block for demodulating a broadcast FM signal. The input is the down converted

complex baseband signal (gr_complex).The output is two streams of the demodulated audio

(float) 0=Left, 1=Right.

Usage blks2.wfm_rcv_pll(demod_rate, audio_decimation)

Parameters demod_rate: input sample rate of complex baseband input.

type demod_rate: float

audio_decimation: how much to decimate demod_rate to get to audio.

type audio_decimation: integer

1.2.25) gnuradio/blks2impl/wfm_tx.py

Type Python file

Description Wide Band FM Transmitter with a preemphasis

Examples

Note

1.2.25.1) wfm_tx ( )

Type Function

Description Wide Band FM Transmitter. Takes a single float input stream of audio samples in the range [-

1,+1]and produces a single FM modulated complex baseband output.

Usage blks2. wfm_tx(audio_rate, quad_rate, tau=75e-6, max_dev=75e3)

Parameters audio_rate: sample rate of audio stream, >= 16k

type audio_rate: integer

quad_rate: sample rate of output stream, quad_rate must be an integer multiple of

audio_rate.

type quad_rate: integer

tau: preemphasis time constant (default 75e-6)

type tau: float

max_dev: maximum deviation in Hz (default 75e3)

type max_dev: float

1.3) gnuradio/wxgui sub package

Type Folder

Description Wxpython based gnuradio extension

1.3.1) gnuradio/wxgui/fftsink.py

Type Python file

Description Gnuradio spectrum analyzer

Examples

Note

1.3.1.1) fft_sink_x ( )

Type Function

Description FFT sink block.

fft_sink_c () : fft sink block for complex data samples.

Simple Gnuradio User Manual Page 62 of 208

fft_sink_f () : fft sink block for real floating data samples.

Usage fftsink.fft_sink_x(fg, parent, baseband_freq=0,

y_per_div=10, ref_level=50, sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None,

title='', size=(640,240), peak_hold=False)

Parameters

1.3.2) gnuradio/wxgui/fftsink2.py

Type Python file

Description Gnuradio spectrum analyzer using stdgui2 and heir_block2

Examples

Note

1.3.2.1) fft_sink_x ( )

Type Function

Description FFT sink block.

fft_sink_c () : fft sink block for complex data samples.

fft_sink_f () : fft sink block for real floating data samples.

Usage fftsink2.fft_sink_x(parent, baseband_freq=0,

y_per_div=10, ref_level=50, sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None,

title='', size=(640,240), peak_hold=False)

Parameters

1.3.3) gnuradio/wxgui/scopesink.py

Type Python file

Description Building block for python oscilloscope module.

Examples

Note

1.3.3.1) scope_sink_x ( )

Type Function

Description Oscilloscope sink block.

scope_sink_c () : scope sink block for complex data samples.

scope_sink_f () : scope sink block for real floating data samples. Accepts 1 to 16 float

streams.

Usage scopesink.scope_sink_x(fg, parent, title='', sample_rate=1,

size=(640,240), frame_decim=1,

v_scale=1000, t_scale=None)

Parameters

1.3.4) gnuradio/wxgui/scopesink2.py

Type Python file

Description Gnuradio Oscilloscope using stdgui2 and heir_block2

Examples

Note

Simple Gnuradio User Manual Page 63 of 208

1.3.4.1) scope_sink_x ( )

Type Function

Description Scope sink block.

scope_sink_c () : scope sink block for complex data samples.

scope_sink_f () : scope sink block for real floating data samples. Accepts 1 to 16 float

streams.

Usage scopesink2.scope_sink_x(parent, title='', sample_rate=1,

size=default_scopesink_size, frame_decim=1,

v_scale=1000, t_scale=None, num_inputs=1)

Parameters

1.3.4.2) constellation_sink ( )

Type Function

Description Constellation sink block.

Usage scopesink2.constellation_sink(parent,title='Constellation', sample_rate=1,

size=(640,240), frame_decim=1)

Parameters

1.3.5) gnuradio/wxgui/form.py

Type Python file

Description Gnuradio wxgui form

Examples

Note

1.3.6) gnuradio/wxgui/numbersink.py

Type Python file

Description Gnuradio Number Sink

Examples

Note

1.3.6.1) number_sink_x ( )

Type Function

Description Number sink block.

number_sink_c () : number sink block for complex data samples.

number_sink_f () : number sink block for real floating data samples.

Usage numbersink.number_sink_x(fg, parent, unit='',base_value=0,minval=-

100.0,maxval=100.0,factor=1.0,

decimal_places=10, ref_level=50, sample_rate=1,

number_rate=15, average=False, avg_alpha=None,

label='', size=(640,240), peak_hold=False)

Parameters

1.3.7) gnuradio/wxgui/numbersink2.py

Type Python file

Description Gnuradio Number Sink using hier_block2

Simple Gnuradio User Manual Page 64 of 208

Examples

Note

1.3.7.1) number_sink_x ( )

Type Function

Description Number sink block.

number_sink_c () : number sink block for complex data samples.

number_sink_f () : number sink block for real floating data samples.

Usage numbersink2.number_sink_x(fg, parent, unit='',base_value=0,minval=-

100.0,maxval=100.0,factor=1.0,

decimal_places=10, ref_level=50, sample_rate=1,

number_rate=15, average=False, avg_alpha=None,

label='', size=(640,240), peak_hold=False)

Parameters

1.3.8) gnuradio/wxgui/waterfallsink.py

Type Python file

Description Gnuradio Waterfall Sink

Examples

Note

1.3.8.1) waterfall_sink_x ( )

Type Function

Description Waterfall sink block.

waterfall_sink_c () : waterfall sink block for complex data samples.

waterfall_sink_f () : waterfall sink block for real floating data samples.

Usage waterfallsink.number_sink_x(fg, parent, baseband_freq=0,

y_per_div=10, ref_level=50, sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None,

title='', size=(640,240))

Parameters

1.3.9) gnuradio/wxgui/waterfallsink2.py

Type Python file

Description Gnuradio Waterfall Sink using hier_block2

Examples

Note

1.3.9.1) waterfall_sink_x ( )

Type Function

Description Waterfall sink block.

waterfall_sink_c () : waterfall sink block for complex data samples.

waterfall_sink_f () : waterfall sink block for real floating data samples.

Usage waterfallsink2.number_sink_x(fg, parent, baseband_freq=0,

y_per_div=10, ref_level=50, sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None,

title='', size=(640,240))

Parameters

Simple Gnuradio User Manual Page 65 of 208

1.3.10) gnuradio/wxgui/plot.py

Type Python file

Description This is a simple light weight plotting module that is used with gnuradio.

Examples

Note

1.3.11) gnuradio/wxgui/powermate.py

Type Python file

Description Handler for Griffin PowerMate, Contour ShuttlePro & ShuttleXpress USB knobs.This

is Linux and wxPython specific

Examples

Note Needs more documentation

1.3.12) gnuradio/wxgui/silder.py

Type Python file

Description Return a wx.Slider object

Examples

Note Needs more documentation

1.3.13) gnuradio/wxgui/stdgui.py

Type Python file

Description A simple wx gui for GNU Radio applications

Examples

Note Needs more documentation

1.3.14) gnuradio/wxgui/stdgui2.py

Type Python file

Description A simple wx gui for GNU Radio applications using hier_block2

Examples

Note Needs more documentation

1.3.15) gnuradio/wxgui/ra_fftsink.py

Type Python file

Description Radio astronomy gnuradio spectrum analyzer

Examples

Note

1.3.15.1) ra_fft_sink_x ( )

Type Function

Description FFT sink block.

ra_fft_sink_c () : fft sink block for complex data samples.

Simple Gnuradio User Manual Page 66 of 208

ra_fft_sink_f () : fft sink block for real floating data samples.

Usage ra_fftsink.ra_fft_sink_x(fg, parent, baseband_freq=0,

y_per_div=10, sc_y_per_div=0.5, sc_ref_level=40, ref_level=50,

sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None, title='',

size=(640,140), peak_hold=False, ofunc=None,

xydfunc=None)

Parameters

1.3.16) gnuradio/wxgui/ra_fftsink.py

Type Python file

Description Radio astronomy gnuradio spectrum analyzer

Examples

Note

1.3.16.1) ra_fft_sink_x ( )

Type Function

Description FFT sink block.

ra_fft_sink_c () : fft sink block for complex data samples.

ra_fft_sink_f () : fft sink block for real floating data samples.

Usage ra_fftsink.ra_fft_sink_x(fg, parent, baseband_freq=0,

y_per_div=10, sc_y_per_div=0.5, sc_ref_level=40, ref_level=50,

sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None, title='',

size=(640,140), peak_hold=False, ofunc=None,

xydfunc=None)

Parameters

1.3.17) gnuradio/wxgui/ra_waterfallsink.py

Type Python file

Description Radio Astronomy gnuradio Waterfall Sink

Examples

Note

1.3.17.1) waterfall_sink_x ( )

Type Function

Description Waterfall sink block.

waterfall_sink_c () : waterfall sink block for complex data samples.

waterfall_sink_f () : waterfall sink block for real floating data samples.

Usage ra_waterfallsink.number_sink_x(fg, parent, baseband_freq=0,

ref_level=0, sample_rate=1, fft_size=512,

fft_rate=15, average=False, avg_alpha=None,

title='', size=(640,240), report=None, span=40, ofunc=None, xydfunc=None)

Parameters

1.3.18) gnuradio/wxgui/ra_stripcharsink.py

Type Python file

Description Radio Astronomy gnuradio ??????????????????????

Examples

Note Needs more documentation

Simple Gnuradio User Manual Page 67 of 208

1.3.18.1) stripchar_sink_x ( )

Type Function

Description ???????????????

Usage ra_stripcharsink.stripchart_sink_f(fg, parent,

y_per_div=10, ref_level=50, sample_rate=1,

title='', stripsize=4,

size=(640,140),xlabel="X",

ylabel="Y", divbase=0.025,

parallel=False, scaling=1.0, autoscale=False)

Parameters

1.4) gnuradio/vocoder sub package

Type Folder

Description GSM and CVSD blocks

1.4.1) gnuradio/vocoder/gsm_full_rate.py

Type Python file

Description GSM 6.10 Full rate encoder decoder blocks

Examples

Note Needs more documentation

1.4.1.1) encode_sp ( )

Type Function

Description GSM 06.10 Full Rate Vocoder Encoder block input type is short, output type packets.

Usage gsm_full_rate.encode_sp()

Parameters shorts in

33 byte packets out

1.4.1.2) decode_ps ( )

Type Function

Description GSM 06.10 Full Rate Vocoder Decoder block input type is packets, output type short.

Usage gsm_full_rate.decode_ps()

Parameters 33 byte packets in

shorts out

1.4.2) gnuradio/vocoder/cvsd_vocoder.py

Type Python file

Description CVSD encoder decoder blocks

Examples

Note Needsmore documentation

Simple Gnuradio User Manual Page 68 of 208

1.4.2.1) encode_sb ( )

Type Function

Description This block performs CVSD audio encoding. Its design and implementation is modeled after

the CVSD encoder/decoder specifications defined in the Bluetooth standard.

CVSD Vocoder Encoder block input type is shorts, output type bytes.

Usage cvsd_vocoder.encode_sb()

Parameters shorts in

bytes out

1.4.2.2) decode_bs ( )

Type Function

Description This block performs CVSD audio decoding. Its design and implementation is modeled after

the CVSD encoder/decoder specifications defined in the Bluetooth standard

CVSD Vocoder Decoder block input type is bytes, output type shorts.

Usage cvsd_vocoder.decode_bs()

Parameters Bytes in

shorts out

1.5) gnuradio/pager sub package

Type Folder

Description Radio Pager receiver blocks

1.5.1) gnuradio/pager/flex_demod.py

Type Python file

Description This GNU Radio component implements a FLEX radio pager receiver/demodulator.

FLEX pager towers are between 929 MHz and 932 MHz at 25 KHz centers.

Current status (7/16/07):

FLEX receiving is completed except for addition of BCH error correction.

Examples See /gnuradio/gr-pager

Note Needs more documentaion

1.5.1.1) flex_demod ( )

Type Function

Description FLEX pager protocol demodulation block. This block demodulates a band-limited, complex

down-converted baseband channel into FLEX protocol frames.

Usage pager.flex_demod(queue, freq=0.0, verbose=False, log=False)

Parameters

1.5.2) gnuradio/pager/pager_swig.py

Type Python file

Description This file was automatically generated by SWIG. It contains all the necessary

software components to implement pager flex demodulation block.

Simple Gnuradio User Manual Page 69 of 208

Examples

Note Needs more documentation

Sub Function 1 pager_flex_deinterleave()

Sub Function 2 pager_flex_frame()

Sub Function 3 pager_flex_parse()

Sub Function 4 pager_flex_sync()

Sub Function 5 pager_slicer_fb()

1.5.3) gnuradio/pager/aypabtu.py

Type Python file

Description All your pager applications belong to us.

This is a general program that uses the USRP to demodulate any pager bandwidth.

Program options are :

--upper-freq", type="eng_float", help="lower Rx frequency

--lower-freq", type="eng_float", help="upper Rx frequency --rx-board",

type="subdev", help="select USRP Rx side A or B (default=first daughterboard

found)”

--calibration", type="eng_float", default=0.0, help="set frequency offset to Hz”

--gain", type="int", help="set RF gain"

Examples See gnuradio/gr-pager/README

Note

1.5.4) gnuradio/pager/usrp_flex.py

Type Python file

Description This example application demonstrates receiving and demodulating the

FLEX pager protocol.

Examples See gnuradio/gr-pager/README

Note

1.5.5) gnuradio/pager/usrp_flex_all.py

Type Python file

Description This application demonstrates receiving and demodulating the FLEX pager protocol

for the entire 3 MHz band.

Examples See gnuradio/gr-pager/README

Note

1.5.6) gnuradio/pager/usrp_flex_band.py

Type Python file

Description This application demonstrates receiving and demodulating the FLEX pager protocol

for 1 MHz band.

Examples See gnuradio/gr-pager/README

Note

Simple Gnuradio User Manual Page 70 of 208

1.6) gnuradio/gruimpl sub package

Type Folder

Description Gnuradio Utility implementation package

1.6.1) gnuradio/ gruimpl /crc.py

Type Python file

Description This GNU Radio component implements CRC generation and checking

Examples

Note Needs more documentation

1.6.1.1) gen_and_append_crc32 ( )

Type Function

Description Generate CRC

Usage gru.gen_and_append_crc32(s)

Parameters s: String

1.6.1.2) check_crc32 ( )

Type Function

Description Generate CRC

Usage gru.check_crc32(s)

Parameters s: String

1.6.2) gnuradio/ gruimpl /freqz.py

Type Python file

Description Compute frequency response of a digital filter

Examples

Note Needs more documentation

1.6.2.1) freqz ( )

Type Function

Description Given the numerator (b) and denominator (a) of a digital filter compute its frequency

response.

jw -jw -jmw

jw B(e) b[0] + b[1]e + .... + b[m]e

H(e) = ---- = ------------------------------------

jw -jw -jnw

A(e) a[0] + a[2]e + .... + a[n]e

Inputs:

b, a --- the numerator and denominator of a linear filter.

worN --- If None, then compute at 512 frequencies around the unit circle.

If a single integer, the compute at that many frequencies.

Otherwise, compute the response at frequencies given in worN

whole -- Normally, frequencies are computed from 0 to pi (upper-half of

unit-circle. If whole is non-zero compute frequencies from 0

to 2*pi.

Simple Gnuradio User Manual Page 71 of 208

Outputs: (h,w)

h -- The frequency response.

w -- The frequencies at which h was computed.

Usage gru.freqz(b, a, worN=None, whole=0, plot=None)

Parameters b, a : The numerator and denominator of a linear filter.

worN : If None, then compute at 512 frequencies around the unit circle. If a single integer,

the compute at that many frequencies. Otherwise, compute the response at frequencies

given in worn

whole : Normally, frequencies are computed from 0 to pi (upper-half of unit-circle. If whole

is non-zero compute frequencies from 0 to 2*pi.

1.6.3) gnuradio/ gruimpl /gnuplot_freqz.py

Type Python file

Description Plot the frequency response of a digital filter using Gnuplot

Usage gru.gnuplot_freqz(taps, sample_rate)

Parameters taps : taps generated by gru.freqz

sample_rate : ??????

Examples See ayfabtu.py

Note Needs more documentation

1.6.3.1) gnuplot_freqz ( )

Type Function

Description Plot the frequency response of a digital filter using Gnuplot.

Returns a handle to the gnuplot graph. When the handle is reclaimed the graph is torn

down

Usage gru.gnuplot_freqz (hw, Fs=None, logfreq=False)

Parameters hw : is a tuple of the form (h, w) where h is sequence of complex freq responses, and w is

a sequence of corresponding frequency points. Plot the frequency response using

gnuplot.

Fs : If Fs is provided, use it as the sampling frequency, else use 2*pi.

1.6.4) gnuradio/ gruimpl /gnuplot_freqz.py

Type Python file

Description Plot the frequency response of a digital filter using Gnuplot

Examples

Note Needs more documentation

1.6.4.1) gnuplot_freqz ( )

Type Function

Description Plot the frequency response of a digital filter using gnuplot.

Returns a handle to the gnuplot graph. When the handle is reclaimed the graph is torn

down

Usage gru.gnuplot_freqz (hw, Fs=None, logfreq=False)

Parameters hw : is a tuple of the form (h, w) where h is sequence of complex freq responses, and w is

a sequence of corresponding frequency points. Plot the frequency response using

gnuplot.

Fs : If Fs is provided, use it as the sampling frequency, else use 2*pi.

Simple Gnuradio User Manual Page 72 of 208

1.6.5) gnuradio/ gruimpl /hexint.py

Type Python file

Description Convert unsigned masks into signed integers

Examples

Note

1.6.5.1) hexint ( )

Type Function

Description Convert unsigned masks into signed integets. This allows us to use hex constants like

0xf0f0f0f2 when talking to our hardware and not get screwed by them getting treated as

python longs.

Usage gru.hexint(mask)

Parameters mask : hex string

1.6.6) gnuradio/ gruimpl /listmsc.py

Type Python file

Description Return a copy of x that is reverse order

Examples

Note

1.6.6.1) list_revers ( )

Type Function

Description Return a copy of x that is reverse order

Usage gru.list_revers(x)

Parameters x : list

1.6.7) gnuradio/ gruimpl /lmx2306.py

Type Python file

Description '''Control National LMX2306 based frequency synthesizer using PC Parallel port

Examples

Note

1.6.7.1) lmx2306 ( )

Type Function

Description Control the National LMX2306 PLL

Usage gru.lmx2306(fosc, step_size, which_pp = 0)

Parameters fosc : is the frequency of the reference oscillator,

step_size : is the step between valid frequencies,

which_pp : specifies which parallel port to use

Simple Gnuradio User Manual Page 73 of 208

1.6.8) gnuradio/ gruimpl /mathmisc.py

Type Python file

Description Some Math functions like GCD, LCM, Log2

Examples

Note

Sub Function 1 gru.gcd(a.b)

Sub Function 2 gru.lcm(a.b)

Sub Function 3 gru.log2(x)

1.6.9) gnuradio/ gruimpl /os_read_exactly.py

Type Python file

Description Replacement for os.read that blocks until it reads exactly nbytes.

Examples

Note

1.6.9.1) os_read_exactly ( )

Type Function

Description Replacement for os.read that blocks until it reads exactly nbytes.

Usage gru.os_read_exactly(file_descriptor, nbytes)

Parameters

1.6.10) gnuradio/ gruimpl /sdr_1000.py

Type Python file

Description Control the DDS on the SDR-1000

Examples

Note

1.6.10.1) sdr_1000 ( )

Type Function

Description Control the DDS on the SDR-1000

Usage gru.sdr_1000(pport=0)

Parameters

Sub Function 1 gru.sdr_1000.write_reg(addr, data)

Sub Function 2 gru.sdr_1000.set_freq(freq)

Sub Function 3 gru.sdr_1000.set_band(freq)

Sub Function 4 gru.sdr_1000.set_bit (reg, bit, state)

Sub Function 5 gru.sdr_1000.set_tx(on=1)

Sub Function 6 gru.sdr_1000.set_rx()

Sub Function 7 gru.sdr_1000.set_gain (high)

Sub Function 8 gru.sdr_1000.set_mute (mute = 1)

Sub Function 9 gru.sdr_1000.set_unmute ()

Sub Function 10 gru.sdr_1000.set_external_pin (pin, on = 1)

Simple Gnuradio User Manual Page 74 of 208

1.6.11) gnuradio/ gruimpl /seq_with_cursor.py

Type Python file

Description ?????????????, I think it is like a loopup table item selector.

Return a list item indexed by cursor

Usage gru.seq_with_cursor(list_array, cursor)

Parameters list_array : list holds data ???????????

cursor : list index ???????

Examples

Note Needs more documentation

1.6.12) gnuradio/ gruimpl /socket_stuff.py

Type Python file

Description Setup sockets for TCP/UDP connections

Examples

Note

1.6.12.1) tcp_connect_or_die ( )

Type Function

Description Setup sockets for TCP connections.

returns: socket or exits

Usage gru.tcp_connect_or_die(sock_addr)

Parameters sock_addr: (host, port) to connect to

type sock_addr: tuple

1.6.12.2) udp_connect_or_die ( )

Type Function

Description Setup sockets for UDP connections.

returns: socket or exits

Usage gru.udp_connect_or_die(sock_addr)

Parameters sock_addr: (host, port) to connect to

type sock_addr: tuple

1.7) gnuradio/gru sub package

Type Folder

Description Semi-hideous kludge to import everything in the gruimpl directory into the gnuradio.gru

namespace.

1.8) gnuradio/gr sub package

Type Folder

Description This is the main GNU Radio python module. We pull the swig output and the other

modules into the gnuradio.gr namespace

Simple Gnuradio User Manual Page 75 of 208

1.8.1) gnuradio/ gr / basic_flow_graph.py

Type Python file

Description Constructs the basic flow graph and provides basic operations on the graph.

Examples

Note

Sub Function 1 connect () : Connect blocks. connect requires two or more arguments that can be

coerced to endpoints

Sub Function 2 disconnect () : Disconnect blocks. disconnect requires two arguments

Sub Function 3 disconnect_all() : disconnect all graph blocks.

1.8.2) gnuradio/ gr / flow_graph.py

Type Python file

Description Add physical connection info to basic_flow_graph and play

Examples

Note

Sub Function 1 start() : Start graph, forking thread(s), return immediately

Sub Function 2 stop() : Tells scheduler to stop and waits for it to happen

Sub Function 3 wait() : Waits for scheduler to stop.

Sub Function 4 run(): Start graph, wait for completion

Sub Function 5 is_running() : Check if the graph is still running

1.8.3) gnuradio/ gr / exceptions.py

Type Python file

Description Exception handling

Examples

Note

Sub Function 1 NotDAG (Exception):Not a directed acyclic graph

Sub Function 2 CantHappen (Exception):Can't happen

1.8.4) gnuradio/ gr / gnuradio_swig_py_filter.py

Type Python file

Description This file was automatically generated by SWIG. All digital IIR and FIR filter blocks

implemented here.

Examples

Note

1.8.4.1) iir_filter_ffd ( )

Type Function

Description IIR filter with float input, float output and double taps. This filter uses the Direct Form I

implementation, where fftaps contains the feed-forward taps, and fbtaps the feedback

ones.

Usage gr.iir_filter_ffd(fftaps,fbtaps)

Parameters Fftaps : contains the feed-forward taps

Simple Gnuradio User Manual Page 76 of 208

fbtaps : the feedback taps

Sub Function 1 gr.iir_filter_ffd.set_taps(fftaps,fbtaps)

Example See hfx2.py in apps

1.8.4.2) single_pole_iir_filter_xx ( )

Type Function

Description Used to do averaging for input vector

single_pole_iir_filter_ff: single pole IIR filter with float input, float output

single_pole_iir_filter_cc: single pole IIR filter with complex input, complex output.

When alpha =1, no averaging is done.

The input and output satisfy a difference equation of the form :

y(n)=alpha* x(n)+(1-alpha)y(n-1)

Usage gr. single_pole_iir_filter_xx(alpha,vlen)

Parameters alpha : double , time costant.

vlen : unsigned integer, vector length

Sub Function 1 gr. single_pole_iir_filter_xx.set_taps(alpha)

1.8.4.3) hilbert_fc ( )

Type Function

Description Hilbert transformer FIR filter. Real output is input appropriately delayed. Imaginary output

is hilbert filtered (90 degree phase shift) version of input.

Usage gr. hilbert_fc(ntaps)

Parameters ntaps : unsigned integer, number of taps (odd)

1.8.4.4) filter_delay_fc ( )

Type Function

Description Filter-Delay Combination Block. The block takes one or two float stream and outputs a

complex stream. If only one float stream is input, the real output is a delayed version of

this input and the imaginary output is the filtered output. If two floats are connected to the

input, then the real output is the delayed version of the first input, and the imaginary

output is the filtered output. The delay in the real path accounts for the group delay

introduced by the filter in the imaginary path. The filter taps needs to be calculated before

initializing this block.

Usage gr. filter_delay_fc (taps)

Parameters taps : vector of float taps

1.8.4.5) fft _filter_xx ( )

Type Function

Description fft_filter_ccc: Fast FFT filter with complex input, complex output and complex taps.

fft_filter_fff: Fast FFT filter with float input, float output and float taps

Usage gr. fft_filter _xx(decimation, taps)

Parameters decimation : integer

taps : float

Sub Function 1 gr. fft_filter _xx.set_taps(taps)

1.8.4.6) fractional_interpolator_xx ( )

Type Function

Description

fractional_interp

olator_

cc : Interpolating mmse filter with complex input, complex

Simple Gnuradio User Manual Page 77 of 208

output..

fractional_interpolator_ff : Interpolating mmse filter with float input, float output.

Usage gr. fractional_interpolator(phase_shift,inter_ratio)

Parameters phase_shift :float

inter_ratio : float

Sub Function 1 gr. fractional_interpolator_xx.mu() : return mu (phase shift) as a float number

Sub Function 2 gr. fractional_interpolator_xx.inter_ratio() : return interpolation ratio as a float number

Sub Function 3 gr. fractional_interpolator_xx.set_mu( mu) : set float mu (phase shift)

Sub Function 4 gr. fractional_interpolator_xx.set_inter_ratio(inter_ratio) : set float interpolation ratio

1.8.4.7) goertzel_fc ( )

Type Function

Description Do the Goertzel single-bin DFT calculation.

Usage gr. goertzel_fc (rate, len, freq)

Parameters rate :integer

len :integer

freq: float

1.8.4.8) cma_equalizer_cc ( )

Type Function

Description Implements constant modulus adaptive filter on complex stream

Usage gr. cma_equalizer_cc(num_taps, modulus,mu)

Parameters num_taps :integer

modulus: float

mu: float (phase shift)

1.8.4.9) adaptive_fir_ccf ( )

Type Function

Description Adaptive FIR filter with gr_complex input, gr_complex output and float taps.

Usage gr. adaptive_fir_ccf (name, decimation, taps)

Parameters name : string

decimation :integer

taps :list of float

Sub Function 1 gr. adaptive_fir_ccf.set_taps(taps): set a float filter taps

Note Needs more documentation

1.8.4.10) fir_filter_xxx ( )

Type Function

Description fir_filter_ccc: FIR filter with gr_complex input, gr_complex output and gr_complex taps

fir_filter_ccf: FIR filter with gr_complex input, gr_complex output and float taps

fir_filter_fcc: FIR filter with float input, gr_complex output and gr_complex taps

fir_filter_fff: FIR filter with float input, float output and float taps

fir_filter_fsf: FIR filter with float input, short output and float taps

fir_filter_scc: FIR filter with short input, gr_complex output and gr_complex taps

Usage gr. fir_filter_xxx (decimation, taps)

Parameters decimation :integer

taps: depends on function

Simple Gnuradio User Manual Page 78 of 208

Sub Function 1 gr.fir_filter_xxx.set_taps(taps): set filter taps

Note Needs more documentation

1.8.4.11) freq_xlating_fir_filter_xxx ( )

Type Function

Description Software frequency (DDC or DUC) translation filter. This class efficiently combines a

frequency translation (typically "down conversion") with a FIR filter (typically low-pass)

and decimation. It is ideally suited for a "channel selection filter" and can be efficiently

used to select and decimate a narrow band signal out of wide bandwidth input. Uses a

single input array to produce a single output array. Additional inputs and/or outputs are

ignored.

freq_xlating_fir_filter_ccc: FIR filter combined with frequency translation with

gr_complex input, gr_complex output and gr_complex taps

freq_xlating_fir_filter _ccf: FIR filter combined with frequency translation with

gr_complex input, gr_complex output and float taps

freq_xlating_fir_filter _fcc: FIR filter combined with frequency translation with float

input, gr_complex output and gr_complex taps

freq_xlating_fir_filter _fcf: FIR filter combined with frequency translation with float

input, complex output and float taps

freq_xlating_fir_filter _scf: FIR filter combined with frequency translation with short

input, complex output and float taps

freq_xlating_fir_filter _scc: FIR filter combined with frequency translation with short

input, gr_complex output and gr_complex taps

Usage gr. freq_xlating_fir_filter _xxx (decimation, taps, center_freq, sampling_freq)

Parameters decimation :integer

taps: depends on function

center_freq : double

sampling_freq : double

Sub Function 1 gr. freq_xlating_fir_filter_xxx.set_taps(taps): set filter taps

Sub Function 2 gr. freq_xlating_fir_filter_xxx.set_center_freq(center_freq): set (type double)

center_frequency

1.8.4.12) interp_fir_filter_xxx ( )

Type Function

Description interp_fir_filter_ccc: Interpolating FIR filter with gr_complex input, gr_complex output

and gr_complex taps

interp_fir_filter_ccf: Interpolating FIR filter with gr_complex input, gr_complex output

and float taps

interp_fir_filter_fcc: Interpolating FIR filter with float input, gr_complex output and

gr_complex taps

interp_fir_filter_fff: Interpolating FIR filter with float input, float output and float taps

interp_fir_filter_fsf: Interpolating FIR filter with float input, short output and float taps

interp_fir_filter_scc: Interpolating FIR filter with short input, gr_complex output and

gr_complex taps

Usage gr. interp_fir_filter _xxx (interpolation, taps)

Parameters interpolation :integer

taps: depends on function

Sub Function 1 gr. interp_fir_filter _xxx.set_taps(taps): set filter taps

Note

Simple Gnuradio User Manual Page 79 of 208

1.8.4.13) rational_resampler_base_xxx ( )

Type Function

Description rational_resampler_base_ccc: Rational Resampling Polyphase FIR filter with

gr_complex input, gr_complex output and gr_complex taps

rational_resampler_base_ccf: Rational Resampling Polyphase FIR filter with

gr_complex input, gr_complex output and float taps

rational_resampler_base_fcc: Rational Resampling Polyphase FIR filter with float

input, gr_complex output and gr_complex taps

rational_resampler_base_fff: Rational Resampling Polyphase FIR filter with float input,

float output and float taps

rational_resampler_base_fsf: Rational Resampling Polyphase FIR filter with float input,

short output and float taps

rational_resampler_base_scc: Rational Resampling Polyphase FIR filter with short

input, gr_complex output and gr_complex taps

Usage gr. rational_resampler_base _xxx (interpolation, decimation, taps)

Parameters interpolation :unsigned

decimation : unsigned

taps: depends on function

Sub Function 1 gr rational_resampler_base _xxx.set_taps(taps): set filter taps

Sub Function 2 gr rational_resampler_base _xxx.intrpolation(): return interpolation value

Sub Function 1 gr rational_resampler_base _xxx.decimation(): return decimation value

Note

1.8.5) gnuradio/ gr / gnuradio_swig_py_gengen.py

Type Python file

Description This file was automatically generated by SWIG. Some mathematical, source and

sink blocks are defined here.

Examples

Note

1.8.5.1) add_xx ( )

Type Function

Description add_cc : output = sum (input_0, input_1, ...). Add across all input complex streams.

add_ii : output = sum (input_0, input_1, ...). Add across all input integer streams.

add_ss : output = sum (input_0, input_1, ...). Add across all input short streams.

add_ff : output = sum (input_0, input_1, ...). Add across all input float streams.

Usage gr.add _xx ()

Parameters

Note

1.8.5.2) add_vxx ( )

Type Function

Description add_vcc : output = sum (input_0, input_1, ...). Add across all input complex vectors.

add_vii : output = sum (input_0, input_1, ...). Add across all input integer vectors.

add_vff : output = sum (input_0, input_1, ...). Add across all input float vectors.

add_vss : output = sum (input_0, input_1, ...). Add across all input short vectors.

Usage gr.add _vxx()

Parameters

Note

Simple Gnuradio User Manual Page 80 of 208

1.8.5.3) add_const_xx ( )

Type Function

Description add_const_cc : output = input + complex constant. Add constant to input complex

streams.

add_ const_ii : output = input + integer constant. Add constant to input integer streams.

add_ const_ss : output = input + short constant. Add constant to input short streams.

add_ const_ff : output = input + float constant. Add constant to input float streams.

add_ const_sf : output = input + float constant. Add constant to input short streams.

Usage gr.add_const _xx (k)

Parameters k: constant value, type depends on the function type

Note

Sub Function 1 gr.add_const_xx.set_k(k): set the constant value on the fly.

1.8.5.4) add_const_vxx ( )

Type Function

Description add_const_vcc : output vector = input complex vector + constant complex vector.

add_ const_vii : output vector = input integer vector + constant integer vector.

add_ const_vss : output vector = input short vector + constant short vector.

add_ const_vff : output vector = input float vector + constant float vector.

Usage gr.add_const _vxx (k)

Parameters k: constant value, type depends on the function type

Note

Sub Function 1 gr.add_const_vxx.set_k (k): set the constant value on the fly.

Sub Function 2 gr.add_const_vxx.k(): return the constant vector

1.8.5.5) argmax_xx ( )

Type Function

Description argmax_fs : ????????????????

argmax_is : ????????????????

argmax_ss: ????????????????

Usage gr.argmax _xx (vlen)

Parameters vlen : vector length

Note Needs more documentation

1.8.5.6) chunks_to_symbols _xx( )

Type Function

Description Map a stream of symbol indexes (unpacked bytes or shorts) to stream of float or complex

onstellation points.in D dimensions (D = 1 by default).

out[n D + k] = symbol_table[in[n] D + k], k=0,1,...,D-1

The combination of gr_packed_to_unpacked_XX followed by gr_chunks_to_symbols_XY

handles the general case of mapping from a stream of bytes or shorts into arbitrary float

or complex symbols.

chunks_to_symbols_bf : input: stream of unsigned char; output: stream of float

chunks_to_symbols_bc : input: stream of unsigned char; output: stream of gr_complex

chunks_to_symbols_sf : input: stream of shorts; output: stream of float

chunks_to_symbols_sc : input: stream of shorts; output: stream of gr_complex

chunks_to_symbols_if : input: stream of integers; output: stream of float

chunks_to_symbols_ic : input: stream of integers; output: stream of gr_complex

Usage gr.chunks_to_symbols _xx(symbol_table, D)

Simple Gnuradio User Manual Page 81 of 208

Parameters symbol_table : ????????????

D : dimensions, const integer

Note

Sub Function 1 gr. chunks_to_symbols_xx.symbol_table(): return symbol table

Sub Function 2 gr. chunks_to_symbols_xx.D(): return dimension

1.8.5.7) packed_to_unpacked _xx( )

Type Function

Description Convert a stream of packed bytes or shorts to stream of unpacked bytes or shorts.

This is the inverse of gr_unpacked_to_packed_XX. The bits in the bytes or shorts input

stream are grouped into chunks of bits_per_chunk bits and each resulting chunk is

written right- justified to the output stream of bytes or shorts. All b or 16 bits of the each

input bytes or short are processed. The right thing is done if bits_per_chunk is not a

power of two. The combination of gr_packed_to_unpacked_XX_ followed by

gr_chunks_to_symbols_Xf or gr_chunks_to_symbols_Xc handles the general case of

mapping from a stream of bytes or shorts into arbitrary float or complex symbols.

packed_to_unpacked _bb: input: stream of unsigned char; output: stream of unsigned

char

packed_to_unpacked _ii: input: stream of integers; output: stream of intergers

packed_to_unpacked _ss: input: stream of shorts; output: stream of shorts

Usage gr. packed_to_unpacked _xx(bits_per_chunk, endianness)

Parameters bits_per_chunk :unsigned int

endianness : GR_MSB_FIRST, GR_LSB_FIRST

Note

1.8.5.8) unpacked_to_packed _xx( )

Type Function

Description Convert a stream of unpacked bytes or shorts into a stream of packed bytes or shorts.

This is the inverse of gr_packed_to_unpacked_XX. The low bits_per_chunk bits are

extracted from each input byte or short. These bits are then packed densely into the

output bytes or shorts, such that all 8 or 16 bits of the output bytes or shorts are filled

with valid input bits. The right thing is done if bits_per_chunk is not a power of two.

The combination of gr_packed_to_unpacked_XX followed by gr_chunks_to_symbols_Xf

or gr_chunks_to_symbols_Xc handles the general case of mapping from a stream of

bytes or shorts into arbitrary float or complex symbols.

unpacked_to_packed _bb: input: stream of unsigned char; output: stream of unsigned

char

unpacked_to_packed _ii: input: stream of integers; output: stream of intergers

unpacked_to_packed _ss: input: stream of shorts; output: stream of shorts

Usage gr. unpacked_to_packed _xx(bits_per_chunk, endianness)

Parameters bits_per_chunk :unsigned int

endianness : GR_MSB_FIRST, GR_LSB_FIRST

Note

1.8.5.9) divide_xx( )

Type Function

Description divide_cc : output = input_0 / input_1 / input_x ...) .Divide across all input complex

streams.

divide_ss : output = input_0 / input_1 / input_x ...) .Divide across all input short streams.

divide_ii : output = input_0 / input_1 / input_x ...) .Divide across all input integer streams.

divide_ff : output = input_0 / input_1 / input_x ...) .Divide across all input float streams.

Usage gr.divide_xx()

Parameters

Note

Simple Gnuradio User Manual Page 82 of 208

1.8.5.10) max_xx ( )

Type Function

Description max_ff : ????????????????

max_ii : ????????????????

max_ss: ????????????????

Usage gr.max _xx (vlen)

Parameters vlen : Vecter length

Note Needs more documentation

1.8.5.11) multiply_xx ( )

Type Function

Description multiply_cc : output = prod (input_0, input_1, ...). Multiply across all input complex

streams.

multiply _ii : output = prod (input_0, input_1, ...). Multiply across all input integer

streams.

multiply _ss : output = prod (input_0, input_1, ...). Multiply across all input short

streams.

multiply _ff : output = prod (input_0, input_1, ...). Multiply across all input float streams.

Usage gr.multiply _xx ()

Parameters

Note

1.8.5.12) multiply_vxx ( )

Type Function

Description multiply_vcc : output = prod (input_0, input_1, ...). Element-wise multiply across all

input complex vectors

multiply _vii : output = prod (input_0, input_1, ...). Element-wise multiply across all input

integer vectors

multiply _vss : output = prod (input_0, input_1, ...). Element-wise multiply across all

input short vectors

multiply _vff : output = prod (input_0, input_1, ...). Element-wise multiply across all input

float vectors.

Usage gr.multiply _vxx ()

Parameters

Note

1.8.5.13) multiply_const_xx ( )

Type Function

Description multiply_const_cc : output = input * complex constant. Multiply constant by input

complex streams.

multiply_const_ss : output = input * short constant. Multiply constant by input short

streams.

multiply_const_ii : output = input * integer constant. Multiply constant by input integer

streams.

multiply_const_ff : output = input * float constant. Multiply constant by input float

streams.

Usage gr.multiply_const _xx (k)

Parameters k: constant value, type depends on the function type

Note

Sub Function 1 gr.multiply_const_xx.set_k(k): set the constant value on the fly.

Simple Gnuradio User Manual Page 83 of 208

1.8.5.14) multiply_const_vxx ( )

Type Function

Description multiply_const_vcc : output vector = input complex vector * constant complex vector

(element-wise)

multiply_const_vii : output vector = input integer vector * constant integer vector

(element-wise)

multiply_const_vss : output vector = input short vector * constant short vector

(element-wise)

multiply_const_vff : output vector = input float vector * constant float vector (element-

wise)

Usage gr.multiply_const _vxx (k)

Parameters k: constant value, type depends on the function type

Note

Sub Function 1 gr.multiply_const_vxx.set_k (k): set the constant value on the fly.

Sub Function 2 gr.multiply_const_vxx.k(): return the constant vector

1.8.5.15) mute_xx ( )

Type Function

Description mute_cc: output = input or zero if muted ,input is complex, output is complex

mute_ss: output = input or zero if muted ,input is short, output is short

mute_ii: output = input or zero if muted ,input is integer, output is integer

mute_ff: output = input or zero if muted ,input is float, output is float

Usage gr.mute_xx (mute)

Parameters mute : bool, True or False

Note

Sub Function 1 gr.mute_xx.set_mute(mute): set mute on the fly.

Sub Function 2 gr.mute_xx.mute(): return mute status, True or false

1.8.5.16) noise_source_x ( )

Type Function

Description noise_source_c : complex random number source with predefined distribution

noise_source_f : float random number source with predefined distribution

noise_source_i : integer random number source with predefined distribution

noise_source_s : short random number source with predefined distribution

Usage gr.noise_source_x(type, ampl, seed)

Parameters type : GR_UNIFORM, GR_GAUSSIAN, GR_LAPLACIAN, GR_IMPULSE

ampl : float, max signal amplitude

seed : long, random function seed value

Note Noise types should be used as follows :

gr.GR_UNIFORM

gr.GR_GAUSSIAN

gr.GR_LAPLACIAN

gr.GR_IMPULSE

Sub Function 1 gr.noise_source_x.set_type(type): set noise type.

Sub Function 2 gr.noise_source_x.set_amplitude(ampl): set float amplitude

1.8.5.17) peak_detector_xb ( )

Type Function

Description Detect the peak of a signal. If a peak is detected, this block outputs a 1, or it outputs 0's.

peak_detector_fb : Float input stream.

peak_detector_ib : Integer input stream.

Simple Gnuradio User Manual Page 84 of 208

peak_detector_sb : Short input stream.

Usage gr.peak_detector_xb(threshold_factor_rise, threshold_factor_fall, look_ahead,

alpha)

Parameters threshold_factor_rise: The threshold factor (float) determines when a peak has started.

An average of the signal is calculated and when the value of the signal goes over

threshold_factor_rise*average, we start looking for a peak.

threshold_factor_fall :The threshold factor (float) determines when a peak has ended.

An average of the signal is calculated and when the value of the signal goes bellow

threshold_factor_fall*average, we stop looking for a peak.

look_ahead: The look-ahead (integer) value is used when the threshold is found to look

if there another peak within this step range. If there is a larger value, we set that as the

peak and look ahead again. This is continued until the highest point is found with This

look-ahead range.

alpha : The gain value (float) of a moving average filter (Time Constant in sec)

Note

Sub Function 1 gr.peak_detector_xb.set_threshold_factor_rise(thr): Set the threshold factor value for the

rise time.

Sub Function 2 gr.peak_detector_xb.set_threshold_factor_fall(thr): Set the threshold factor value for the

fall time.

Sub Function 3 gr.peak_detector_xb.set_look_ahead(look): Set the look ahead factor value

Sub Function 4 gr.peak_detector_xb.set_alpha(alpha): Set the running average alpha

Sub Function 5 gr.peak_detector_xb.threshold_factor_rise(): return the threshold factor value for the rise

time.

Sub Function 6 gr.peak_detector_xb.threshold_factor_fall():return the threshold factor value for the fall

time.

Sub Function 7 gr.peak_detector_xb._look_ahead():return the look ahead factor value

Sub Function 8 gr.peak_detector_xb.alpha():return the running average alpha

1.8.5.18) sample_and_hold_xx ( )

Type Function

Description Sample and hold circuit. Samples the data stream (input stream 0) and holds the value if

the control signal is 1 (intput stream 1).

sample_and_hold_bb : input stream is unsigned char

sample_and_hold_ff : input stream is float

sample_and_hold_ii : input stream is integer

sample_and_hold_ss : input stream is short

Usage gr.sample_and_hold_xx()

Parameters

Note

1.8.5.19) sig_source_x ( )

Type Function

Description sig_source_c : signal generator with gr_complex output.

sig_source_f : signal generator with float output.

sig_source_i : signal generator with integer output.

sig_source_s : signal generator with short output.

Usage gr.sig_source_x(sampling_freq, waveform, frequency, ampl, offset)

Parameters sampling_freq : double

waveform : GR_CONST_WAVE GR_SIN_WAVE GR_COS_WAVE

GR_SQR_WAVE GR_TRI_WAVE GR_SAW_WAVE

frequency : double, signal frequency

ampl : double, signal max amplitude

offset : DC offset, value type depends on signal type

Note Waveform types should be used as follows :

gr.GR_CONST_WAVE

gr.GR_SIN_WAVE

gr.GR_COS_WAVE

Simple Gnuradio User Manual Page 85 of 208

gr.GR_SQR_WAVE

gr.GR_TRI_WAVE

gr.GR_SAW_WAVE

Sub Function 1 gr.sig_source_x.set_sampling_freq(sampling_freq): set sampling frequency

Sub Function 2 gr.sig_source_x.set_waveform(waveform): set signal waveform

Sub Function 3 gr.sig_source_x.set_frequency(frequency): set signal frequency

Sub Function 4 gr.sig_source_x.set_amplitude(ampl): set signal amplitude

Sub Function 5 gr.sig_source_x.set_offset(offset): set DC offset

Sub Function 6 gr.sig_source_x.sampling_freq(): return sampling frequency

Sub Function 7 gr.sig_source_x.set_waveform(waveform): return signal waveform

Sub Function 8 gr.sig_source_x.set_frequency(frequency): return signal frequency

Sub Function 9 gr.sig_source_x.set_amplitude(ampl): return signal amplitude

Sub Function 10 gr.sig_source_x.set_offset(offset): return DC offset

1.8.5.20) sub_xx ( )

Type Function

Description sub _cc : output = sub (input_0, input_1, ...). Subtruct across all input complex streams.

sub _ii : output = sub (input_0, input_1, ...). Subtruct across all input integer streams.

sub _ss : output = sub (input_0, input_1, ...). Subtruct across all input short streams.

sub _ff : output = sub (input_0, input_1, ...). Subtruct across all input float streams.

Usage gr.sub _xx ()

Parameters

Note

1.8.5.21) vector_sink_x ( )

Type Function

Description vector_sink_f : Float sink that writes to a vector.

vector_sink_c : Complex sink that writes to a vector.

vector_sink_i : Integer sink that writes to a vector.

vector_sink_s : Short sink that writes to a vector.

vector_sink_b : unsigned char sink that writes to a vector.

Usage gr.vector _sink_x ()

Parameters

Note

Sub Function 1 gr.vector_sink_x .data() : Give us the stored vector data

1.8.5.22) vector_source_x ( )

Type Function

Description vector_source_f : Source of float that gets its data from a vector

vector_source_c : Source of complex that get its data from a vector

vector_source_i : Source of integer that gets its data from a vector

vector_source_s: Source of short that gets its data from a vector

vector_source_b : Source of unsigned char that gets its data from a vector

Usage gr.vector _source_x (data, repeat=false)

Parameters data : data to be used to form the vector, type depends on function type.

repeat: bool True, or False, keep the source running by cyclicly repeating the data

Note

Simple Gnuradio User Manual Page 86 of 208

1.8.6) gnuradio/ gr / gnuradio_swig_py_runtime.py

Type Python file

Description This file was automatically generated by SWIG. Some mathematical, source and

sink blocks are defined here.

Examples

Note

1.8.6.1) io_signature ( )

Type Function

Description Create an i/o signature for input and output ports.

Usage gr.io_signature(min_streams, max_streams, sizeof_stream_item)

Parameters min_streams : specify minimum number of streams (>= 0)

max_streams : specify maximum number of streams (>= min_streams or -1 -> infinite)

sizeof_stream_items : specify the size of the items in the streams

Note

Sub Function 1 gr.io_signature.min_streams() : return min number of streams

Sub Function 2 gr.io_signature.max_streams() : return max number of streams

Sub Function 3 gr.io_signature.sizeof_stream_item() : return stream size

1.8.6.2) buffer ()

Type Function

Description Single writer, multiple reader fifo. Allocate a buffer that holds at least nitems of size

sizeof_item. The total size of the buffer will be rounded up to a system dependent

boundary. This is typically the system page size, but under MS windows is 64KB.

Usage gr.buffer(nitems, sizeof_item)

Parameters nitem: Integer, number of items

sizeof_item : 8 if the data is complex, 4 if the data isinteger, 4 if the data is float, 2 if the

data is short, 1 if the data is unsigned character.

Note

Sub Function 1 gr.buffer.space_availaible () :Integer, return number of items worth of space available for

writing

Sub Function 2 gr.buffer.write_pointer (): return pointer to write buffer.

Sub Function 3 gr.buffer.update_write_pointer():tell buffer that we wrote nitems into it

Sub Function 4 gr.buffer.set_done(true or false)

Sub Function 5 gr.buffer.done() : return True or false

1.8.6.3) buffer_reader ( )

Type Function

Description Used to let us keep track of the readers of a gr_buffer.

Usage gr.buffer_reader(buf, nzero_preload)

Parameters buf : gr_buffer pointer

nzero_preload : number of zero items to "preload" into buffer

Note

Sub Function 1 gr.buffer_reader.items_availaible () :Integer, Return number of items available for

reading

Sub Function 2 gr.buffer_reader.buffer ():Return buffer this reader reads from.

Sub Function 3 gr.buffer_reader.maximum_possible_items_available():Return maximum number of

items that could ever be available for reading. This is used as a sanity check in the

Simple Gnuradio User Manual Page 87 of 208

scheduler to avoid looping forever.

Sub Function 4 gr.buffer_reader.read_pointer() : return pointer to read buffer

Sub Function 5 gr.buffer_reader.update_read_pointer(nitems) : integer

Sub Function 6 gr.buffer_reader.set_done(true or false)

Sub Function 7 gr.buffer_reader.done() : return True or false

1.8.6.4) basic_block ( )

Type Function

Description The abstract base class for all signal processing blocks. Basic blocks are the bare

abstraction of an entity that has a name and a set of inputs and outputs. These are never

instantiated directly; rather, this is the abstract parent class of both gr_hier_block, which

is a recursive container, and gr_block, which implements actual signal processing

functions.

Usage

Parameters

Note Needs more documentation

Sub Function 1

Sub Function 2

1.8.6.5) block ( )

Type Function

Description The abstract base class for all 'terminal' processing blocks. A signal processing flow is

constructed by creating a tree of hierarchical blocks, which at any level may also contain

terminal nodes that actually implement signal processing functions. This is the base

class for all such leaf nodes. Blocks have a set of input streams and output streams. The

input_signature and output_signature define the number of input streams and output

streams respectively, and the type of the data items in each stream.

Although blocks may consume data on each input stream at a different rate, all outputs

streams must produce data at the same rate. That rate may be different from any of the

input rates. User derived blocks override two methods, forecast and general_work, to

implement their signal processing behavior.

forecast () is called by the system scheduler to determine how many items are required

on each input stream in order to produce a given number of output items.

general_work () is called to perform the signal processing in the block. It reads the input

items and writes the output items.

Usage

Parameters

Note Needs more documentation

Sub Function 1

Sub Function 2

1.8.6.6) block_detail ( )

Type Function

Description Implementation details to support the signal processing abstraction. This class contains

implementation detail that should be "out of sight" of almost all users of GNU Radio. This

decoupling also means that we can make changes to the guts without having to

recompile everything.

Usage

Parameters

Note Needs more documentation

Sub Function 1

Sub Function 2

Simple Gnuradio User Manual Page 88 of 208

1.8.6.7) hier_block2 ( )

Type Function

Description New Hierarchical container class for gr_block's.

Usage

Parameters

Note Needs more documentation

Sub Function 1

Sub Function 2

1.8.6.8) single_threaded_scheduler ( )

Type Function

Description Simple scheduler for stream computations.

Usage

Parameters

Note Needs more documentation

Sub Function 1

Sub Function 2

1.8.6.9) message ( )

Type Function

Description Creat Message

Usage gr.message (type, arg1, arg2, length)

Parameters type :Long, message type usually =0

arg1 : Double, any numeric argument

arg2 : Double, any numeric argument

length : Message length in bytes

Note Needs more documentation

Sub Function 1 gr.message.type() : return long

Sub Function 2 gr.message.arg1() : return double

Sub Function 3 gr.message.arg2() : return double

Sub Function 4 gr.message.set_type(type)

Sub Function 5 gr.message.set_arg1(arg1)

Sub Function 6 gr.message.set_arg2(arg2)

Sub Function 7 gr.message.length() : return message length

Sub Function 8 gr.message.msg (): Put the message here. Return the msg

Sub Function 9 gr.message.to_string() : Return the body of message as string

1.8.6.9) message_from_string ( )

Type Function

Description ???????? Generate message from string

Usage gr.message_from_string(s, type, arg1, arg2)

Parameters s : String

type :long

arg1 : Double, any numeric argument

arg2 : Double, any numeric argument

Note Needs more documentation

Sub Function 1 gr.message from_string.type() : return long

Sub Function 2 gr.message from_string.arg1() : return double

Sub Function 3 gr.message from_string.arg2() : return double

Sub Function 4 gr.message from_string.set_type(type)

Simple Gnuradio User Manual Page 89 of 208

Sub Function 5 gr.message from_string.set_arg1(arg1)

Sub Function 6 gr.message from_string.set_arg2(arg2)

Sub Function 7 gr.message from_string.msg() : return pointer of type unsigned char to the message

Sub Function 8 gr.message from_string.to_string() : return string

1.8.6.10) message_handler ( )

Type Function

Description ???????? Abstract class of message handlers

Usage gr.message_handler.handle(msg)

Parameters msg : handle

Note Needs more documentation

1.8.6.11) msg_queue ( )

Type Function

Description Thread-safe message queue.

Retuen a pointer to the created message queue

Usage gr.msg_queue(limit)

Parameters limit : Set the number of holded messages in the queue

Note Needs more documentation

Sub Function 1 gr.msg_queue.handle (msg) : Generic msg_handler method: insert the message.

Sub Function 2 gr.msg_queue.insert_tail (msg) : Insert message at tail of queue.

Sub Function 3 gr.msg_queue.delete_head () : Delete message from head of queue and return it. Block

if no message is available.

Sub Function 4 gr.msg_queue.delete_head_nowait () : If there's a message in the queue, delete it and

return it. If no message is available, return 0.

Sub Function 5 gr.msg_queue.flush () : Delete all messages from the queue.

Sub Function 6 gr.msg_queue.empty_p () : is the queue empty?

Sub Function 7 gr.msg_queue.full_p () : is the queue full?

Sub Function 8 gr.msg_queue.count() : return (unsigned integer) number of messages in queue

Sub Function 9 gr.msg_queue.limit (): return (unsigned integer) limit on number of message in queue. 0

means unbounded

1.8.6.12) dispatcher ( )

Type Function

Description Invoke callbacks based on select.

Note Needs more documentation

Sub Function 1 gr.dispatcher.loop (timeout=10): Event dispatching loop.

Enter a polling loop that only terminates after all gr_select_handlers have been removed.

timeout sets the timeout parameter to the select() call, measured in seconds.

timeout: maximum number of seconds to block in select.

Sub Function 2 gr.dispatcher.add_handler(handler) :

Sub Function 3 gr.dispatcher.del_handler(handler) :

Sub Function 4 gr.dispatcher.del_handler(handler) :

1.8.6.13) error_handler ( )

Type Function

Description Abstract for error handler

Note Needs more documentation

Sub Function 1

Simple Gnuradio User Manual Page 90 of 208

Sub Function 2

Sub Function 3

Sub Function 4

1.8.6.14) file_error_handler ( )

Type Function

Description File error handler

Note Needs more documentation

1.8.6.15) sync_block ( )

Type Function

Description Synchronous 1:1 input to output with history .Override work to provide the signal

processing implementation.

Note Needs more documentation

1.8.6.16) sync_decimator ( )

Type Function

Description Synchronous N:1 input to output with history. Override work to provide the signal

processing implementation.

Note Needs more documentation

1.8.6.16) sync_interpolator ( )

Type Function

Description Synchronous 1:N input to output with history. Override work to provide the signal

processing implementation.

Note Needs more documentation

1.8.6.17) top_block ( )

Type Function

Description Top-level hierarchical block representing a flowgraph.

Usage gr.top_block(name)

Parameters name : string

Note Needs more documentation

Sub Function 1 gr.top_block.run () : The simple interface to running a flowgraph.

Calls start () then wait () . Used to run a flowgraph that will stop on its own, or to run a

flowgraph indefinitely until SIGINT is received.

Sub Function 2 gr.top_block.start () : Start the contained flowgraph. Creates one or more threads to

execute the flow graph. Returns to the caller once the threads are created.

Sub Function 3 gr.top_block.stop () : Stop the running flowgraph. Notifies each thread created by the

scheduler to shutdown, then returns to caller.

Sub Function 4 gr.top_block.wat () : Wait for a flowgraph to complete. Flowgraphs complete when either

(1) all blocks indicate that they are done (typically only when using gr.file_source, or

gr.head, or (2) after stop has been called to request shutdown.

Sub Function 5 gr.top_block.is_running() : Returns true if flowgraph is running

Simple Gnuradio User Manual Page 91 of 208

1.8.6.18) enable_realtime_scheduling ( )

Type Function

Description If possible, enable high-priority "real time" scheduling.

Return gr.RT_Ok if successful,

Usage gr.enable_realtime_scheduling()

Parameters

Note The possible Return values are : RT_NOT_IMPLEMENTED,RT_NO_PRIVS,

RT_OTHER_ERROR

1.8.7) gnuradio/ gr / threading.py

Type Python file

Description Choose load gr_threading_23.py or gr_threading_24.py

Examples

Note

1.8.8) gnuradio/ gr / threading_23.py

Type Python file

Description Threading module for version 2.3

Examples

Note

1.8.9) gnuradio/ gr / threading_24.py

Type Python file

Description Threading module for version 2.4

Examples

Note

1.8.10) gnuradio/ gr / hier_block2.py

Type Python file

Description Construct new hierarchical blocks for flowgraph

Examples

Note

1.8.11) gnuradio/ gr / hier_block.py

Type Python file

Description Simple concrete class for building hierarchical blocks.This class assumes that there is at

most a single block at the head of the chain and a single block at the end of the chain.

Either head or tail may be None indicating a sink or source respectively. It can compose

one or more blocks (primitive or hierarchical) into a new hierarchical block.

Usage gr.hier_block(fg, head_block, tail_block)

Parameters fg: The flow graph that contains this hierarchical block.

type fg: flow_graph

head_block: the first block in the signal processing chain.

type head_block: None or subclass of gr.block or gr.hier_block_base

Simple Gnuradio User Manual Page 92 of 208

tail_block: the last block in the signal processing chain.

type tail_block: None or subclass of gr.block or gr.hier_block_base

Examples

Note

1.8.12) gnuradio/ gr / prefs.py

Type Python file

Description Base class for representing user preferences in the windows INI files.

The real implementation is in Python, and is accessable from C++ via the magic of SWIG

directors. Derive our 'real class' from the stubbed out base class that has support for

SWIG directors. This allows C++ code to magically and transparently invoke the

methods in this python class.

Sub Function 1 gr.prefs ().has_section (section) : Does section exist? Section is string, return bool

True or False

Sub Function 2 gr.prefs ().has_option (section, option) : Does option exist? option is string, return

bool True or False

Sub Function 3 gr.prefs().get_string (section,option, default_val) : If option exists return associated

value; else return the string default_val.

Sub Function 4 gr.prefs().get_bool (section,option, default_val) : If option exists and value can be

converted to bool, return it; else return the bool default_val.

Sub Function 5 gr.prefs().get_long (section,option, default_val) : If option exists and value can be

converted to long, return it; else return the long default_val.

Sub Function 6 gr.prefs().get_double (section,option, default_val) : If option exists and value can be

converted to double, return it; else return the double default_val.

Examples See usrp_spectrum_sense.py

Note Needs more documenation

1.8.13) gnuradio/ gr / scheduler.py

Type Python file

Description Schedule the threads.Invoke the single threaded scheduler's run method

Note that we're in a new thread, and that sts_pyrun releases the global interpreter lock.

This has the effect of evaluating the graph in parallel to the main line control code.

Examples

Note

1.8.14) gnuradio/ gr / top_block.py

Type Python file

Description This hack forces a 'has-a' relationship to look like an 'is-a' one. It allows Python classes

to subclass this one, while passing through method calls to the C++ class shared pointer

from SWIG.It also allows us to intercept method calls if needed. This allows the

'run_locked' methods, which are defined in gr_top_block.i, to release the Python global

interpreter lock before calling the actual method in gr_top_block

Examples

Note Needs more documentation

1.8.15) gnuradio/ gr / gnuradio_swig_python.py

Type Python file

Description This file implements the old gnuradio_swig_python namespace

Examples

Note

Simple Gnuradio User Manual Page 93 of 208

1.8.16) gnuradio/ gr / gnuradio_swig_io.py

Type Python file

Description This file implements many sink and source blocks

Examples

Note

1.8.16.1) file_sink_base ( )

Type Function

Description Common base class for file sinks.

Usage gr.file_sink_base(filename, is_binary)

Parameters filename: File Name

is_binary : bool True or False

Note

Sub Function 1 gr.gr_file_sink_base.open (filename) : Open filename and begin output to it.

Sub Function 2 gr.gr_file_sink_base.close () : Close current output file. Closes current output file and

ignores any output until open is called to connect to another file.

Sub Function 3 gr.gr_file_sink_base.do_update () : if we've had an update, do it now.

1.8.16.2) file_sink ( )

Type Function

Description Write a stream to a binary file.

Usage gr.file_sink(itemzize,filename)

Parameters itemsize: one of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

filename: File name

Note

1.8.16.3) file_source ( )

Type Function

Description Read stream from binary file.

Usage gr.file_source(itemzize,filename, repeat)

Parameters itemsize: gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

filename: File name

repeat : Bool True, or False, repeat file reading when EOF reached.

Note

Sub Function 1 gr.file_source.seek (seek_point,whence) : seek file to seek_point relative to whence

seek_point : sample offset in file

whence : one of gr.SEEK_SET, gr.SEEK_CUR, gr.SEEK_END

Simple Gnuradio User Manual Page 94 of 208

1.8.16.4) file_descriptor_sink ( )

Type Function

Description Write stream to file descriptor.

Usage gr.file_descriptor_sink(itemzize, fd)

Parameters itemsize: one of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

fd: File descriptor, integer

Note Needs more documenation

1.8.16.5) file_descriptor_source ( )

Type Function

Description Read stream from file descriptor.

Usage gr.file_descriptor_source(itemzize,fd, reapeat)

Parameters itemsize: gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

fd: File descriptor, integer

repeat : Bool True, or False repeat file reading when EOF reached.

Note Needs more documenation

1.8.16.6) microtune_xxxx_eval_board ( )

Type Function

Description Abstract class for controlling microtune xxxx eval board

Usage

Parameters

Note Needs more documentation

1.8.16.7) microtune_4702_eval_board ( )

Type Function

Description Control microtune 4702 eval board

Usage

Parameters

Note Needs more documentation

1.8.16.8) microtune_4937_eval_board ( )

Type Function

Description Control microtune 4937 eval board

Usage

Parameters

Note Needs more documentation

Simple Gnuradio User Manual Page 95 of 208

1.8.16.8) sdr_1000_base ( )

Type Function

Description Very low level interface to SDR 1000 xcvr hardware. See sdr_1000.py for a higher level

interface.

Usage

Parameters

Note

1.8.16.9) oscope_sink_f ( )

Type Function

Description Building block for python oscilloscope module. Accepts 1 to 16 float streams.

Usage gr.oscope_sink_f(sampling_rate,msgq)

Parameters sampling_rate : Double represent sampling rate

msgq : Message queue

Note Needs more documentation

1.8.16.10) ppio ( )

Type Function

Description Abstract class that provides low level access to parallel port bits.

Usage

Parameters

Note Needs more documentation

1.8.16.11) message_source ( )

Type Function

Description Turn received messages into a stream.

Usage gr.message_source(itemsize,msgq_limit)

Parameters itemsize: Size of data

msgq_limit : Integer, number of messages to hold in the queue

Note Needs more documentation

1.8.16.12) message_sink ( )

Type Function

Description Gather (convert) the received items into messages and insert into a message queue.

Message type is 0, msg.arg1 will hold the itemsize, and msg.arg2 will hold number of

items in the message.

Usage gr.message_sink(itemsize,msgq,dont_block)

Parameters itemsize: Size of data

msgq : Message queue

don’t_block : bool True or False

Note Needs more documentation

Simple Gnuradio User Manual Page 96 of 208

1.8.16.13) udp_sink ( )

Type Function

Description Write stream to an UDP socket.

Usage gr.udp_sink(itemsize, src, port_src, dst, port_dst, payload_size)

Parameters itemsize : The size (in bytes) of the item datatype

src : The source address as either the host name or the 'numbers-and-dots' IP address

port_src : Destination port to bind to (0 allows socket to choose an appropriate port)

dst : The destination address as either the host name or the 'numbers-and-dots' IP

address

port_dst : Destination port to connect to

payload_size : UDP payload size by default set to 1472 = (1500 MTU - (8 byte UDP

header) - (20 byte IP header))

Note

Sub Function 1 gr.udp_sink.open() : open a socket specified by the port and ip address info

Opens a socket, binds to the address, and makes connectionless association over UDP.

If any of these fail, the fuction retuns the error and exits.

Sub Function 2 gr.udp_sink.close () : Close current socket. Shuts down read/write on the socket

Sub Function 3 gr.udp_sink.payload_size() : return the PAYLOAD_SIZE of the socket

1.8.16.14) udp_source ( )

Type Function

Description Read stream from UDP socket.

Usage gr.udp_source(itemsize, src, port_src, payload_size)

Parameters itemsize : The size (in bytes) of the item datatype

src : The source address as either the host name or the 'numbers-and-dots' IP address

port_src : Destination port to bind to (0 allows socket to choose an appropriate port)

payload_size : UDP payload size by default set to 1472 = (1500 MTU - (8 byte UDP

header) - (20 byte IP header))

Note

Sub Function 1 gr.udp_source.open() : open a socket specified by the port and ip address info

Opens a socket, binds to the address, and makes connectionless association over UDP.

If any of these fail, the fuction retuns the error and exits.

Sub Function 2 gr.udp_source.close () : Close current socket. Shuts down read/write on the socket

Sub Function 3 gr.udp_source.payload_size() : return the PAYLOAD_SIZE of the socket

1.8.17) gnuradio/ gr / gnuradio_swig_general.py

Type Python file

Description This file implements the general gnuradio blocks

Examples

Note

1.8.17.1) nop ( )

Type Function

Description Does nothing. Used for testing only.

Usage gr.nop(sizeof_stream_item)

Simple Gnuradio User Manual Page 97 of 208

Parameters sizeof_stream_item: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float

,gr_sizeof_char

Note

1.8.27.2) null_sink ( )

Type Function

Description Null sink block.

Usage gr.null_sink (sizeof_stream_item)

Parameters sizeof_stream_item: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float

,gr_sizeof_char

Note

1.8.27.3) null_source ( )

Type Function

Description Null source block. A source of zeros.

Usage gr.null_source (sizeof_stream_item)

Parameters sizeof_stream_item: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float

,gr_sizeof_char

Note

1.8.27.4) head ( )

Type Function

Description Copies the first N items to the output then signals done.

Usage gr.head (sizeof_stream_item, nitems)

Parameters sizeof_stream_item: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float

,gr_sizeof_char

nitems : Integer, number of samples to collect.

Note

1.8.27.5) skiphead ( )

Type Function

Description Skips the first N items, from then on copies items to the output. Useful for building test

cases and sources which have metadata or junk at the start

Usage gr.skiphead (sizeof_stream_item, nitems_to_skip)

Parameters sizeof_stream_item: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float

,gr_sizeof_char

nitems_to_skip : Integer, number of samples to skip

Note

1.8.27.6) quadrature_demod_cf ( )

Type Function

Description Quadrature demodulator: complex in, float out.This can be used to demod FM, FSK,

GMSK, etc. The input is complex baseband.

Usage gr.quadrature_demod_cf(gain)

Simple Gnuradio User Manual Page 98 of 208

Parameters gain : float

Note Needs more documenation

1.8.27.7) float_to_complex ( )

Type Function

Description Convert 1 or 2 streams of float to a stream of gr_complex.

Usage gr.float_to_complex()

Parameters

Note

1.8.27.8) check_counting_s ( )

Type Function

Description Sink that checks if its input stream consists of a counting sequence. This sink is typically

used to test the USRP "Counting Mode" or "Counting mode 32 bit".

Usage gr.check_counting_s(do_32bit)

Parameters do_32bit : Bool True or False, expect an interleaved 32 bit counter in stead of 16 bit

counter (default false)

Note

1.8.27.9) lfsr_32k_source_s ( )

Type Function

Description LFSR pseudo-random source with period of 2^15 bits (2^11 shorts). This source is

typically used along with gr_check_lfsr_32k_s to test the USRP using its digital loopback

mode.

Usage gr.lfsr_32k_source_s()

Parameters

Note

1.8.27.10) check_lfsr_32k_s ( )

Type Function

Description Sink that checks if its input stream consists of a lfsr_32k sequence. This sink is typically

used along with gr_lfsr_32k_source_s to test the USRP using its digital loopback mode.

Usage gr.check_lfsr_32k_s()

Parameters

Note

Sub Function 1 gr.check_lfsr_32k_s.ntotal() : Return long represent total number of elements

Sub Function 2 gr.check_lfsr_32k_s.nright() : Return long represent correct number of elements

Sub Function 3 gr.check_lfsr_32k_s.runlength () : Return long represent ????????????

Simple Gnuradio User Manual Page 99 of 208

1.8.27.11) stream_to_vector ( )

Type Function

Description Convert a stream of items into a stream of blocks containing nitems_per_block

Usage gr.stream_to_vector(item_size,nitems_per_block)

Parameters item_size: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

nitems_per_block : vector length

Note

1.8.27.12) vector_to_stream ( )

Type Function

Description Convert a stream of blocks of nitems_per_block items into a stream of items

Usage gr.vector_to_stream(item_size,nitems_per_block)

Parameters item_size: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

nitems_per_block : vector length

Note

1.8.27.13) keep_one_in_n ( )

Type Function

Description Decimate a stream, keeping one item of size (itemsize) out of every n.

Usage gr.keep_one_in_n(item_size, n)

Parameters item_size: Item size we wish to keep

n : integer

Note

Sub Function 1 gr.keep_one_in_n.set_n(n)

1.8.27.14) fft_vcc ( )

Type Function

Description Compute forward or reverse FFT, complex vector in / complex vector out.

Usage gr.fft_vcc(fft_size,forward, window, shift=false)

Parameters fft_size : integer

forward : bool True for forward FFT, False for inverse FFT

window : window vector,

shift : bool True or false

Note

Sub Function 1 gr.fft_vcc.set_window(window)

Example See usrp_spectrum_sense.py

1.8.27.15) fft_vfc ( )

Type Function

Description Compute forward or reverse FFT, float vector in / complex vector out.

Usage gr.fft_vfc(fft_size,forward, window)

Parameters fft_size : integer

Simple Gnuradio User Manual Page 100 of 208

forward : bool True for forward FFT, False for inverse FFT

window : window vector

Note

Sub Function 1 gr.fft_vfc.set_window(window)

1.8.27.16) float_to_short ( )

Type Function

Description Convert stream of float to a stream of short.

Usage gr.float_to_short()

Parameters

Note

1.8.27.17) float_to_uchar ( )

Type Function

Description Convert stream of float to a stream of unsigned character.

Usage gr.float_to_uchar()

Parameters

Note

1.8.27.18) short_ to_float ( )

Type Function

Description Convert stream of short to a stream of float.

Usage gr.short_to_float()

Parameters

Note

1.8.27.19) char_to_float ( )

Type Function

Description Convert stream of characters to a stream of float.

Usage gr.char_to_float()

Parameters

Note

1.8.27.20) uchar_to_float ( )

Type Function

Description Convert stream of unsigned characters to a stream of float.

Usage gr.uchar_to_float()

Parameters

Note

Simple Gnuradio User Manual Page 101 of 208

1.8.27.21) frequency_modulator_fc ( )

Type Function

Description Frequency modulator block. float input; complex baseband output

Usage gr.frequency_modulator_fc(sensitivity)

Parameters sensitivity : double

Note

1.8.27.22) phase_modulator_fc ( )

Type Function

Description Phase modulator block. output=complex(cos(in*sensitivity),sin(in*sensitivity))

Usage gr.phase_modulator_fc(sensitivity)

Parameters sensitivity : double

Note

1.8.27.23) bytes_to_syms ( )

Type Function

Description Convert stream of bytes to stream of +/- 1 symbols (Turn it to NRZ data format). Input is

a stream of bytes; output: stream of float. The combination of

gr_packed_to_unpacked_bb followed by gr_chunks_to_symbols_bf or

gr_chunks_to_symbols_bc handles the general case of mapping from a stream of bytes

into arbitrary float or complex symbols.

Usage gr.bytes_to_syms()

Parameters

Note

1.8.27.24) simple_framer ( )

Type Function

Description add sync field, seq number and command field to payload

Usage gr.simple_framer(payload_bytesize)

Parameters payload_bytesize : Integer

Note Needs more documenation

1.8.27.25) simple_correlator ( )

Type Function

Description Inverse of gr_simple_framer (more or less).

Usage gr.simple_framer(payload_bytesize)

Parameters payload_bytesize : Integer

Note Needs More documenation

Simple Gnuradio User Manual Page 102 of 208

1.8.27.26) align_on_samplenumbers_ss ( )

Type Function

Description Align several complex short (interleaved short) input channels with corresponding

unsigned 32 bit sample_counters (provided as interleaved 16 bit values). Pay attention

on how you connect this block. It expects a minimum of 2 usrp_source_s with nchan

number of channels and FPGA_MODE_COUNTING_32BIT enabled. This means that

the first complex_short channel on every input is an interleaved 32 bit counter. The

samples are aligned by dropping samples untill the samplenumbers match.

Usage gr.align_on_samplenumbers_ss(nchan, align_interval)

Parameters nchan : of complex_short input channels (including the 32 bit counting channel)

align_interval : is after how much samples (minimally) the sample-alignement is

refreshed. Default is 128. A bigger value means less processing power but also requests

more buffer space, which has a maximum. Decrease the align_interval if you get an error

like: "sched: <gr_block align_on_samplenumbers_ss (0)> is requesting more input data

than we can provide. ninput_items_required = 32768 max_possible_items_available =

16383 If this is a filter, consider reducing the number of taps."

Note Needs More documenation

1.8.27.27) complex_to_float ( )

Type Function

Description Convert a stream of gr_complex to 1 or 2 streams of float

Usage gr.complex_to_float(vlen)

Parameters vlen :vector len (default 1)

Note

1.8.27.28) complex_to_real ( )

Type Function

Description Complex in, real part out (float)

Usage gr.complex_to_real(vlen)

Parameters vlen :vector len (default 1)

Note

1.8.27.29) complex_to_imag ( )

Type Function

Description Complex in, imaginary part out (float)

Usage gr.complex_to_imag(vlen)

Parameters vlen :vector len (default 1)

Note

1.8.27.30) complex_to_mag ( )

Type Function

Description Complex in, magnitude out (float)

Usage gr.complex_to_mag(vlen)

Parameters vlen :vector len (default 1)

Note

Simple Gnuradio User Manual Page 103 of 208

1.8.27.31) complex_to_mag_squared ( )

Type Function

Description Complex in, magnitude squared out (float)

Usage gr.complex_to_mag_squared(vlen)

Parameters vlen :vector len (default 1)

Note

1.8.27.32) complex_to_arg ( )

Type Function

Description complex in, angle out (float)

Usage gr.complex_to_arg(vlen)

Parameters vlen :vector len (default 1)

Note

1.8.27.33) complex_to_interleaved_short ( )

Type Function

Description Convert stream of complex to a stream of interleaved shorts.

Usage gr.complex_to_interleaved_short()

Parameters

Note

1.8.27.34) interleaved_short_to_complex ( )

Type Function

Description Convert stream of interleaved shorts to a stream of complex.

Usage gr.interleaved_short_to_ complex ()

Parameters

Note

1.8.27.35) firdes ( )

Type Function

Description Finite Impulse Response (FIR) filter design functions.

Note

1.8.27.35.1) firdes.low_pass ( )

Type Sub Function

Description Design low pass FIR filter by using "window method"

Usage gr.firdes. low_pass (gain,sampling_freq,cutoff_freq, transition_width, window =

WIN_HAMMING,beta = 6.76)

Parameters gain: overall gain of filter (typically 1.0)

sampling_freq: sampling freq (Hz)

cutoff_freq: center of transition band (Hz)

Simple Gnuradio User Manual Page 104 of 208

transition_width: width of transition band (Hz). The normalized width of the transition

band is what sets the number of taps required. Narrow --> more taps

window: What kind of window to use. Determines maximum attenuation and passband

ripple. Available window types are:WIN_HAMMING, WIN_HANN ,

WIN_BLACKMAN ,WIN_RECTANGULAR ,WIN_KAISER

beta: parameter for Kaiser window (used only for Kaiser)

Note See firdes.window for windowing information

1.8.27.35.2) firdes.high_pass ( )

Type Sub Function

Description Design high pass FIR filter by using "window method"

Usage gr.firdes. high_pass (gain,sampling_freq,cutoff_freq, transition_width, window =

WIN_HAMMING,beta = 6.76)

Parameters gain: overall gain of filter (typically 1.0)

sampling_freq: sampling freq (Hz)

cutoff_freq: center of transition band (Hz)

transition_width: width of transition band (Hz). The normalized width of the transition

band is what sets the number of taps required. Narrow --> more taps

window: What kind of window to use. Determines maximum attenuation and passband

ripple. Available window types are:WIN_HAMMING, WIN_HANN ,

WIN_BLACKMAN ,WIN_RECTANGULAR ,WIN_KAISER

beta: parameter for Kaiser window (used only for Kaiser)

Note See firdes.window for windowing information

1.8.27.35.3) firdes.band_pass ( )

Type Sub Function

Description Design band pass FIR filter by using "window method"

Usage gr.firdes.band_pass (gain,sampling_freq,low_cutoff_freq, high_cutoff_freq,

transition_width, window = WIN_HAMMING,beta = 6.76)

Parameters gain: overall gain of filter (typically 1.0)

sampling_freq: sampling freq (Hz)

low_cutoff_freq: center of low transition band (Hz)

high_cutoff_freq: center of high transition band (Hz)

transition_width: width of transition band (Hz). The normalized width of the transition

band is what sets the number of taps required. Narrow --> more taps

window: What kind of window to use. Determines maximum attenuation and passband

ripple. Available window types are:WIN_HAMMING, WIN_HANN ,

WIN_BLACKMAN ,WIN_RECTANGULAR ,WIN_KAISER

beta: parameter for Kaiser window (used only for Kaiser)

Note See firdes.window for windowing information

1.8.27.35.4) firdes.complex_band_pass ( )

Type Sub Function

Description Design complex band pass FIR filter by using "window method"

Usage gr.firdes.complex_band_pass (gain,sampling_freq,low_cutoff_freq,

high_cutoff_freq, transition_width, window = WIN_HAMMING,beta = 6.76)

Parameters gain: overall gain of filter (typically 1.0)

sampling_freq: sampling freq (Hz)

Simple Gnuradio User Manual Page 105 of 208

low_cutoff_freq: center of low transition band (Hz)

high_cutoff_freq: center of high transition band (Hz)

transition_width: width of transition band (Hz). The normalized width of the transition

band is what sets the number of taps required. Narrow --> more taps

window: What kind of window to use. Determines maximum attenuation and passband

ripple. Available window types are:WIN_HAMMING, WIN_HANN ,

WIN_BLACKMAN ,WIN_RECTANGULAR ,WIN_KAISER

beta: parameter for Kaiser window (used only for Kaiser)

Note See firdes.window for windowing information

1.8.27.35.5) firdes.band_reject ( )

Type Sub Function

Description Design band reject FIR filter by using "window method"

Usage gr.firdes.band_reject (gain,sampling_freq,low_cutoff_freq, high_cutoff_freq,

transition_width, window = WIN_HAMMING,beta = 6.76)

Parameters gain: overall gain of filter (typically 1.0)

sampling_freq: sampling freq (Hz)

low_cutoff_freq: center of low transition band (Hz)

high_cutoff_freq: center of high transition band (Hz)

transition_width: width of transition band (Hz). The normalized width of the transition

band is what sets the number of taps required. Narrow --> more taps

window: What kind of window to use. Determines maximum attenuation and passband

ripple. Available window types are:WIN_HAMMING, WIN_HANN ,

WIN_BLACKMAN ,WIN_RECTANGULAR ,WIN_KAISER

beta: parameter for Kaiser window (used only for Kaiser)

Note See firdes.window for windowing information

1.8.27.35.6) firdes.hilbert ( )

Type Sub Function

Description Design Hilbert Transform FIR filter by using "window method"

Usage gr.firdes.hilbert (ntaps=19, windowtype = WIN_ RECTANGULAR,beta = 6.76)

Parameters ntaps: Number of taps, must be odd

windowtype: What kind of window to use. Determines maximum attenuation and

passband ripple. Available window types are:WIN_HAMMING, WIN_HANN ,

WIN_BLACKMAN ,WIN_RECTANGULAR ,WIN_KAISER

beta: parameter for Kaiser window (used only for Kaiser)

Note See firdes.window for windowing information

1.8.27.35.7) firdes.root_raised_cosine ( )

Type Sub Function

Description Design a root raised cosine FIR filter

Usage gr.firdes.root_raised_cosine (gain, sampling_freq, symbol_rate, alpha, taps)

Parameters gain: overall gain of filter (typically 1.0)

sampling_freq: sampling freq (Hz)

symbol_rate: symbol rate NOT bitrate (unless BPSK), must be a factor of sample rate

alpha: excess bandwidth factor

ntaps: number of taps

Note

Simple Gnuradio User Manual Page 106 of 208

1.8.27.35.8) firdes.gaussian ( )

Type Sub Function

Description Design a gaussian FIR filter

Usage gr.firdes.gaussian (gain, spb, bt, ntaps)

Parameters gain: overall gain of filter (typically 1.0)

spb: symbols per bit, symbol rate, must be a factor of sample rate

bt : Bandwidth to bit rate ratio (bandwidth * symbol time)

ntaps: number of taps

Note

1.8.27.35.9) firdes.window ( )

Type Sub Function

Description Window taps maker

Usage gr.firdes.window (type, ntaps, beta)

Parameters type: window type, one of :

WIN_HAMMING : Maximum Attenuation 53dB

WIN_HANN : Maximum Attenuation 44dB

WIN_BLACKMAN : Maximum Attenuation 74dB

WIN_RECTANGULAR ,

WIN_KAISER : max attenuation a function of beta, google it

ntaps: number of taps

beta: parameter for Kaiser window (used only for Kaiser)

Note The usage of these window types is as followes :

gr.firdes. WIN_HAMMING

gr.firdes. WIN_HANN

gr.firdes. WIN_BLACKMAN

gr.firdes. WIN_RECTANGULAR ,

gr.firdes. WIN_KAISER

1.8.27.36) interleave ()

Type Function

Description Interleave N inputs to a single output

Usage gr.interleave(item_size)

Parameters Item_size: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

Note

1.8.27.37) deinterleave ()

Type Function

Description Deinterleave a single input into N outputs

Usage gr.deinterleave(item_size)

Parameters Item_size: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

Note

Simple Gnuradio User Manual Page 107 of 208

1.8.27.38) delay ()

Type Function

Description Delay the input by a certain number of samples

Usage gr.delay(itemsize, delay)

Parameters Itemsize: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

delay : Integer, number of samples

Note

Sub Function 1 gr.delay.set_delay (delay) : Set block delay.

Sub Function 2 gr.delay.delay () : Return block delay.

1.8.27.39) simple_sequelch_cc ()

Type Function

Description Simple squelch block based on average signal power and threshold in dB. Output equal

input if not muted.

Usage gr.simple_squelch_cc(threshold_db, alpha)

Parameters threshold_db : double

alpha : Double , the gain value of a moving average filter (Time Constant in sec)

Note Needs more documenation

Sub Function 1 gr.simple_sequelch_cc.set_threshold(decibels)

Sub Function 2 gr.simple_sequelch_cc.set_alpha(alpha)

Sub Function 3 gr.simple_sequelch_cc.threshold() : Return block threshold

Sub Function 4 gr.simple_sequelch_cc.unmuted() : Return bool True or False

Sub Function 5 gr.simple_sequelch_cc.squelch_range() : Return float vector represents sequelch range

1.8.27.40) agc_xx ()

Type Function

Description High performance Automatic Gain Control class.

agc_cc : The Power is calculated by the absolute value of the complex number.

agc_ff : Power is approximated by absolute value.

Usage gr.agc_xx (rate, refrence, gain, max_gain)

Parameters rate :float (Time Constant in Sec)

refrence : float refrence power

gain : float Initial gain

max_gain : float maximum gain

Note Needs more documentation

1.8.27.41) gri_agc_xx ()

Type Function

Description High performance Automatic Gain Control class

gri_agc_cc: The Power is calculated by the absolute value of the complex number.

gri_agc_ff : Power is approximated by absolute value

Usage gr.gri_agc_xx(rate=1e-4, refrence=1.0, gain=1.0, max_gain=0.0)

Parameters rate :float (Time Constant in Sec)

refrence : float refrence power

gain : float Initial gain

max_gain : float maximum gain

Simple Gnuradio User Manual Page 108 of 208

Note Needs more documentation

Sub Function 1 gr.gri_agc_xx.rate() : Return rate

Sub Function 2 gr.gri_agc_xx.refrence() : Return refrence

Sub Function 3 gr.gri_agc_xx.gain() : Return gain

Sub Function 4 gr.gri_agc_xx.max_gain() : Return max gain

Sub Function 5 gr.gri_agc_xx.set_rate() : Set rate

Sub Function 6 gr.gri_agc_xx.set_refrence() : Set refrence

Sub Function 7 gr.gri_agc_xx.set_gain() : Set gain

Sub Function 8 gr.gri_agc_xx.set_max_gain() : Set max gain

Sub Function 9 gr.gri_agc_xx.scale (input) : ?????????????

Sub Function 10 gr.gri_agc_xx.scaleN (output [ ], input [ ], n) : ?????????????

1.8.27.42) gri_agc2_xx ()

Type Function

Description High performance Automatic Gain Control class

gri_agc2_cc : For Power the absolute value of the complex number is used.

gri_agc2_ff : Power is approximated by absolute value

Usage gr.gri_agc2_xx(attack_rate=1e-1, decay_rate=1e-2,refrence=1, gain=1,

max_gain=0.0)

Parameters attack_rate :float

decay_rate : float

refrence : float refrence power

gain : float initial gain

max_gain : float

Note Needs more documentation

Sub Function 1 gr.gri_agc_xx.attack_rate() : Return attack_rate

Sub Function 2 gr.gri_agc_xx.refrence() : Return refrence

Sub Function 3 gr.gri_agc_xx.gain() : Return gain

Sub Function 4 gr.gri_agc_xx.max_gain() : Return max gain

Sub Function 5 gr.gri_agc_xx.set_attack_rate() : Set attack_rate

Sub Function 6 gr.gri_agc_xx.set_refrence() : Set refrence

Sub Function 7 gr.gri_agc_xx.set_gain() : Set gain

Sub Function 8 gr.gri_agc_xx.set_max_gain() : Set max gain

Sub Function 9 gr.gri_agc_xx.scale (input) : ?????????????

Sub Function 10 gr.gri_agc_xx.scaleN (output [ ], input [ ], n) : ?????????????

Sub Function 11 gr.gri_agc_xx.decay_rate() : Return decay_rate

Sub Function 12 gr.gri_agc_xx.set_decay_rate() : Set decay_rate

1.8.27.43) rms_xx ()

Type Function

Description RMS average power.

rms_cf : Input is complex, output is float

rms_ff : Input is float, output is float.

Usage gr.rms_xx(alpha)

Parameters alpha : Double , the gain value of a moving average filter (Time Constant in sec)

Note Needs more documentation

Sub Function 1 gr.rms_xx.unmuted() : Return bool True or False

Sub Function 2 gr.rms_xx_set_alpha(alpha) : Set alpha

Simple Gnuradio User Manual Page 109 of 208

1.8.27.44) nlog10_ff ()

Type Function

Description Output = n*log10(input) + k

Usage gr.nlog10_ff(n, vlen, k)

Parameters n : Float

vlen : Unsigned Integer vector length

k : float

Note

1.8.27.45) fake_channel_encoder_pp ()

Type Function

Description Pad packet with alternating 1,0 pattern. Input: stream of byte vectors; output: stream of

byte vectors

Usage gr.fake_channel_encoder_pp(input_vlen, output_vlen)

Parameters input_vlen : Integer

output_vlen : Integer

Note

1.8.27.46) fake_channel_decoder_pp ()

Type Function

Description Remove fake padding from packet. Input: stream of byte vectors; output: stream of byte

vectors

Usage gr.fake_channel_decoder_pp(input_vlen, output_vlen)

Parameters input_vlen : Integer

output_vlen : Integer

Note

1.8.27.47) throttle ()

Type Function

Description Throttle flow of samples such that the average rate does not exceed samples_per_sec.

Input: one stream of itemsize; output: one stream of itemsize

Usage gr.throttle(item_size, samples_per_sec)

Parameters itemsize: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

samples_per_sec : Double

Note

1.8.27.48) mpsk_receiver_cc ()

Type Function

Description This block takes care of receiving M-PSK modulated signals through phase, frequency,

Simple Gnuradio User Manual Page 110 of 208

and symbol synchronization. It performs carrier frequency and phase locking as well as

symbol timing recovery. It works with (D) BPSK, (D)QPSK, and (D)8PSK as tested

currently. It should also work for OQPSK and PI/4 DQPSK.

The phase and frequency synchronization are based on a Costas loop that finds the

error of the incoming signal point compared to its nearest constellation point. The

frequency and phase of the NCO are updated according to this error. There are

optimized phase error detectors for BPSK and QPSK, but 8PSK is done using a brute-

force computation of the constellation points to find the minimum.

The symbol synchronization is done using a modified Mueller and Muller circuit from

the paper:

G. R. Danesfahani, T.G. Jeans, "Optimisation of modified Mueller and Muller

algorithm," Electronics Letters, Vol. 31, no. 13, 22 June 1995, pp. 1032 - 1033.

This circuit interpolates the downconverted sample (using the NCO developed by the

Costas loop) every mu samples, then it finds the sampling error based on this and the

past symbols and the decision made on the samples. Like the phase error detector,

there are optimized decision algorithms for BPSK and QPKS, but 8PSK uses another

brute force computation against all possible symbols. The modifications to the M&M

used here reduce self-noise.

Usage gr.mpsk_receiver_cc(M, theta, alpha, beta, fmin, fmax, mu, gain_mu, omega,

gain_omega, omega_rel)

Parameters M : Modulation order of the M-PSK modulation. The constructor also chooses which

phase detector and decision maker to use in the work loop based on the value of M.

theta : Any constant phase rotation from the real axis of the constellation

alpha gain parameter to adjust the phase in the Costas loop (~0.01)

beta : Gain parameter to adjust the frequency in the Costas loop (~alpha^2/4)

fmin : Minimum normalized frequency value the loop can achieve

fmax : Maximum normalized frequency value the loop can achieve

mu : Initial parameter for the interpolator [0,1]

gain_mu : Gain parameter of the M&M error signal to adjust mu (~0.05)

omega :Initial value for the number of symbols between samples (~number of

samples/symbol)

gain_omega : Gain parameter to adjust omega based on the error (~omega^2/4)

omega_rel :Sets the maximum (omega*(1+omega_rel)) and minimum

(omega*(1+omega_rel)) omega (~0.005)

Note

Sub Function 1 gr.mpsk_receiver_cc.mu() : (M&M) Returns current value of mu

Sub Function 2 gr.mpsk_receiver_cc.omega() : (M&M) Returns current value of omega

Sub Function 3 gr.mpsk_receiver_cc.gain_mu() : M&M) Returns mu gain factor

Sub Function 4 gr.mpsk_receiver_cc.gain_omega() : (M&M) Returns omega gain factor

Sub Function 5 gr.mpsk_receiver_cc.set_mu() : (M&M) Set value of mu

Sub Function 6 gr.mpsk_receiver_cc. set_omega() : (M&M) Set value of omega

Sub Function 7 gr.mpsk_receiver_cc. set_gain_mu() : M&M) Set mu gain factor

Sub Function 8 gr.mpsk_receiver_cc. set_gain_omega() : (M&M) Set omega gain factor

Sub Function 9 gr.mpsk_receiver_cc.alpha() : (CL) Returns the value for alpha (the phase gain term)

Sub Function 10 gr.mpsk_receiver_cc.beta() : (CL) Returns the value of beta (the frequency gain term)

Sub Function 11 gr.mpsk_receiver_cc.freq() : (CL) Returns the current value of the frequency of the

NCO in the Costas loop

Sub Function 12 gr.mpsk_receiver_cc.phase() : (CL) Returns the current value of the phase of the NCO

in the Costal loop

Sub Function 13 gr.mpsk_receiver_cc.set_alpha() : (CL) Sets the value for alpha (the phase gain term)

Sub Function 14 gr.mpsk_receiver_cc. set_beta() : (CL) (CL) Setss the value of beta (the frequency

gain term)

Sub Function 15 gr.mpsk_receiver_cc. set_freq() : (CL) (CL) Sets the current value of the frequency of

the NCO in the Costas loop

Sub Function 16 gr.mpsk_receiver_cc. set_phase() : (CL) Setss the current value of the phase of the

NCO in the Costal loop

Simple Gnuradio User Manual Page 111 of 208

1.8.27.49) stream_mux ()

Type Function

Description Creates a stream muxing block to multiplex many streams into one with a specified

format. Muxes N streams together producing an output stream that contains N0 items

from the first stream, N1 items from the second, etc. and repeats:[N0, N1, N2, ..., Nm,

N0, N1, ...]

Usage gr.stream_mux(item_size, lengths)

Parameters itemsize : The item size of the stream

lengths : A vector (list/tuple) specifying the number of items from each stream the mux

together. Warning: this requires that at least as many items per stream are available or

the system will wait indefinitely for the items.

Note

1.8.27.50) stream_to_streams ()

Type Function

Description Convert a stream of items into a N streams of items. Converts a stream of N items into N

streams of 1 item. Repeat and infinitum

Usage gr.stream_to_streams(item_size, nstreams)

Parameters itemsize : The item size of the stream

nstreams : Number of streams

Note

1.8.27.51) streams_to_stream ()

Type Function

Description Convert N streams of 1 item into a 1 stream of N items. Convert N streams of 1 item into

1 stream of N items. Repeat and infinitum.

Usage gr.streams_to_stream(item_size, nstreams)

Parameters itemsize : The item size of the stream

nstreams : Number of streams

Note

1.8.27.52) streams_to_vector ()

Type Function

Description Convert N streams of items to 1 stream of vector length N

Usage gr.streams_to_vector(item_size, nstreams)

Parameters itemsize : The item size of the stream

nstreams : Number of streams

Note

1.8.27.53) stream_to_vector ()

Type Function

Description Convert a stream of items into a stream of blocks containing nitems_per_block

Usage gr.stream_to_vector(item_size, nitems_per_block)

Parameters itemsize : The item size of the stream

Simple Gnuradio User Manual Page 112 of 208

nitems_per_block : Number of items in the vector

Note

1.8.27.54) vector_to_ streams ()

Type Function

Description Convert 1 stream of vectors of length N to N streams of items.

Usage gr.vector_to_streams(item_size, nstreams)

Parameters itemsize : The item size of the stream

nstreams : Number of streams

Note

1.8.27.55) vector_to_stream ()

Type Function

Description Convert a stream of blocks of nitems_per_block items into a stream of items

Usage gr. vector_to_stream(item_size, nitems_per_block)

Parameters itemsize : The item size of the stream

nitems_per_block : Number of items in the vector

Note

1.8.27.56) conjugate_cc ()

Type Function

Description output = complex conjugate of input

Usage gr. conjugate_cc()

Parameters

Note

1.8.27.57) vco_f ()

Type Function

Description VCO - Voltage controlled oscillator. input: float stream of control voltages; output: float

oscillator output

Usage gr. vco_f(sampling_rate, sensitivity, amplitude)

Parameters sampling_rate : sampling rate (Hz)

sensitivity : units are radians/sec/volt

amplitude : output amplitude

Note

1.8.27.58) threshold_ff ()

Type Function

Description ??????????????????????

Simple Gnuradio User Manual Page 113 of 208

Usage gr. threshold_ff(lo,hi,initial_state)

Parameters lo : Low threshold value

hi : High threshold value

initial_state: ???????????????

Note Needs more documentation

Sub Function 1 gr.threshold_ff.lo() :

Sub Function 2 gr.threshold_ff.hi() :

Sub Function 3 gr.threshold_ff.last_state() :

Sub Function 4 gr.threshold_ff.set_lo() :

Sub Function 5 gr.threshold_ff.set_hi() :

Sub Function 6 gr.threshold_ff.set_last_state() :

1.8.27.59) clock_recovery_mm_xx ()

Type Function

Description This implements the Mueller and Müller (M&M) discrete-time error-tracking synchronizer.

The clock recovery block trucks the symbol clock and resamples as needed. The output

of the block is a stream of soft symbols.

The complex version here is based on: Modified Mueller and Muller clock recovery circuit

Based: G. R. Danesfahani, T.G. Jeans, "Optimisation of modified Mueller and Muller

algorithm," Electronics Letters, Vol. 31, no. 13, 22 June 1995, pp. 1032 - 1033.

clock_recovery_mm_cc : Mueller and Müller (M&M) based clock recovery block with

complex input, complex output.

clock_recovery_mm_ff : Mueller and Müller (M&M) based clock recovery block with

float input, float output.

Usage gr. clock_recovery_mm_xx(omega, gain_omega, mu, gain_mu,

omega_relative_limit)

Parameters omega :initial value for the number of symbols between samples (~number of

samples/symbol)

gain_omega : Gain parameter to adjust omega based on the error

mu : Initial parameter for the interpolator

gain_mu : Gain parameter of the M&M error signal to adjust mu

omega_relative_limit :Sets the maximum and minimum omega

Note Needs more documentation

Sub Function 1 gr. clock_recovery_mm_xx.omega() : Return omega

Sub Function 2 gr. clock_recovery_mm_xx.mu() : Return mu

Sub Function 3 gr. clock_recovery_mm_xx.gain_omega() : Return gain_omega

Sub Function 4 gr. clock_recovery_mm_xx.gain_mu() : Return gain_mu

Sub Function 5 gr. clock_recovery_mm_xx.set_omega(omega) : Set omega

Sub Function 6 gr. clock_recovery_mm_xx.set_mu(mu) : Set mu

Sub Function 7 gr. clock_recovery_mm_xx.set_gain_omega(gain_omega) : Set gain_omega

Sub Function 8 gr. clock_recovery_mm_xx.set_gain_mu(gain_mu) : Set gain_mu

Sub Function 9 gr. clock_recovery_mm_xx.set_verbose(verbose) : Set printing

1.8.27.60) dd_mpsk_sync_cc ()

Type Function

Description Decision directed M-PSK synchronous demod This block performs joint carrier tracking

and symbol timing recovery. Input: complex baseband; output: properly timed complex

samples ready for slicing. At this point, it handles only QPSK.

Usage gr.dd_mpsk_sync_cc(alpha, beta, max_freq, min_freq, ref_phase, omega,

gain_omega,mu, gain_mu)

Parameters alpha : Gain parameter to adjust the phase in the Costas loop

beta : Gain parameter to adjust the frequency in the Costas loop

Simple Gnuradio User Manual Page 114 of 208

min_freq : Minimum normalized frequency value the loop can achieve

max_freq : Maximum normalized frequency value the loop can achieve

ref_phase: ??????????????

mu : Initial parameter for the interpolator

gain_mu : Gain parameter of the M&M error signal to adjust mu

omega :Initial value for the number of symbols between samples (~number of

samples/symbol)

gain_omega : Gain parameter to adjust omega based on the error

Note Needs more documentation

Sub Function 1 gr.mpsk_ sync _cc.mu() : (M&M) Returns current value of mu

Sub Function 2 gr.mpsk_ sync_cc.omega() : (M&M) Returns current value of omega

Sub Function 3 gr.mpsk_ sync _cc.gain_mu() : M&M) Returns mu gain factor

Sub Function 4 gr.mpsk_ sync _cc.gain_omega() : (M&M) Returns omega gain factor

Sub Function 5 gr.mpsk_ sync _cc.set_mu() : (M&M) Set value of mu

Sub Function 6 gr.mpsk_ sync _cc. set_omega() : (M&M) Set value of omega

Sub Function 7 gr.mpsk_ sync _cc. set_gain_mu() : M&M) Set mu gain factor

Sub Function 8 gr.mpsk_ sync _cc. set_gain_omega() : (M&M) Set omega gain factor

1.8.27.61) packet_sink ()

Type Function

Description Process received bits looking for packet sync, header, and process bits into packet

Usage gr.packet_sink(sync_vector, target_queue, threshold)

Parameters sync_vector: vector of unsigned charaters.

target_gueue : message queue

threshold : Integer

Note Needs more documentation

Sub Function 1 gr.packet_sink.carrier_sensed() : Return true if we detect carrier

1.8.27.62) lms_dfe_xx ()

Type Function

Description Least-Mean-Square Decision Feedback Equalizer.

lms_dfe_cc : complex in/out

lms_dfe_ff : float in/out

Usage gr.lms_dfe_xx(lambda_ff, lambda_fb, num_fftaps, num_fbtaps)

Parameters

Note Needs more documentation

1.8.27.63) dpll_bb ()

Type Function

Description Detect the peak of a signal. If a peak is detected, this block outputs a 1, else it outputs

0's.

Usage gr.dpll_bb(period, gain)

Parameters period : ????????

gain : ???????

Note Needs more documentation

Simple Gnuradio User Manual Page 115 of 208

1.8.27.64) pll_freqdet_cf ()

Type Function

Description Implements a PLL which locks to the input frequency and outputs an estimate of that

frequency. Useful for FM Demod. input: stream of complex; output: stream of floats.

This PLL locks onto a [possibly noisy] reference carrier on the input and outputs an

estimate of that frequency in radians per sample. All settings max_freq and min_freq are

in terms of radians per sample, NOT HERTZ. Alpha is the phase gain (first order, units of

radians per radian) and beta is the frequency gain (second order, units of radians per

sampl per radian)

Usage gr.pll_freqdet_cf(alpha, beta, max_freq, min_freq)

Parameters alpha :

beta :

max_freq :

min_freq :

Note Needs more documentation

1.8.27.65) pll_refout_cc ()

Type Function

Description Implements a PLL which locks to the input frequency and outputs a carrier.

input: stream of complex; output: stream of complex. This PLL locks onto a [possibly

noisy] reference carrier on the input and outputs a clean version which is phase and

frequency aligned to it.

All settings max_freq and min_freq are in terms of radians per sample, NOT HERTZ.

Alpha is the phase gain (first order, units of radians per radian) and beta is the frequency

gain (second order, units of radians per sample per radian)

Usage gr.pll_refout_cc(alpha, beta, max_freq, min_freq)

Parameters alpha :

beta :

max_freq :

min_freq :

Note 1) Needs more documentation

2) If alpha = x, it was suggested that beta = 0.25 * x * x

Example See hfx2.py in apps

1.8.27.66) pll_carriertracking_cc()

Type Function

Description Implements a PLL which locks to the input frequency and outputs the input signal mixed

with that carrier. input: stream of complex; output: stream of complex

This PLL locks onto a [possibly noisy] reference carrier on the input and outputs that

signal, downconverted to DC

All settings max_freq and min_freq are in terms of radians per sample, NOT HERTZ.

Alpha is the phase gain (first order, units of radians per radian) and beta is the frequency

gain (second order, units of radians per sample per radian)

Usage gr.pll_carriertracking_cc(alpha, beta, max_freq, min_freq)

Parameters alpha :

beta :

max_freq :

min_freq :

Simple Gnuradio User Manual Page 116 of 208

Note Needs more documentation

Sub Function 1 gr.pll_carriertracking_cc.lock_detector() : Return bool True or False

Sub Function 2 gr.pll_carriertracking_cc.set_lock_threshold(value) : Set threshold value

Sub Function 3 gr.pll_carriertracking_cc.squelch_enable(on) : Set /reset squelch

1.8.27.67) pn_correlator_cc ()

Type Function

Description PN code sequential search correlator. Receives complex baseband signal, outputs

complex correlation against reference PN code, one sample per PN code period

Usage gr.pn_correlator_cc(degree, mask, seed)

Parameters degree:

mask :

seed :

Note Needs more documentation

1.8.27.68) probe_signal_f ()

Type Function

Description Sink that allows a samples ruuning in stream to be grabbed from Python.

Usage gr.probe_signal_f()

Parameters

Note Needs more documenation

Sub Function 1 gr.probe_signal_f.level() : Return probed signal level

Example See radio.py in apps

1.8.27.69) probe_avg_mag_sqrd_xx ()

Type Function

Description Sink that allows a samples ruuning in stream to be grabbed from Python. It computes

avg magnitude squared. Compute a running average of the magnitude squared of the

the input. The level and indication as to whether the level exceeds threshold can be

retrieved with the level and unmuted accessors.

probe_avg_mag_sqrd_c : input: gr_complex

probe_avg_mag_sqrd_f : input: float

probe_avg_mag_sqrd_cf : input: gr_complex, output : gr_float

Usage gr.proble_avg_mag_sqrd_xx(threshold_db, alpha)

Parameters threshold_db : The threshold value in dB

alpha: The gain value (float) of a moving average filter (Time Constant in sec)

Note Needs more documenation

Sub Function 1 gr.probe_ avg_mag_sqrd_xx.level() : Return double represent the probed level

Sub Function 2 gr.probe_ avg_mag_sqrd_xx.thresholdl() : Return double represent block threshold

Sub Function 3 gr.probe_ avg_mag_sqrd_xx.unmuted() : Return bool True or False

Sub Function 4 gr.probe_ avg_mag_sqrd_xx.set_thresholdl() : Set threshold

Sub Function 5 gr.probe_ avg_mag_sqrd_xx.set_alpha() : Set alpha

Example See receive-path.py in digital folder

Simple Gnuradio User Manual Page 117 of 208

1.8.27.70) ofdm_correlator ()

Type Function

Description Build an OFDM correlator and equalizer.Take a vector of complex constellation points in

from an FFT and performs a correlation and equalization. blocks

This block takes the output of an FFT of a received OFDM symbol and finds the start of a

frame based on two known symbols. It also looks at the surrounding bins in the FFT

output for the correlation in case there is a large frequency shift in the data. This block

assumes that the fine frequency shift has already been corrected and that the samples

fall in the middle of one FFT bin.

It then uses one of those known symbols to estimate the channel response over all

subcarriers and does a simple 1-tap equalization on all subcarriers. This corrects for the

phase and amplitude distortion caused by the channel.

Usage gr.ofdm_correlator(occupied_carriers, fft_length, cplen, known_symbol1,

known_symbol2, max_fft_shift_len)

Parameters occupied_carriers The number of subcarriers with data in the received symbol

fft_length The size of the FFT vector (occupied_carriers + unused carriers)

known_symbol1 A vector of complex numbers representing a known symbol at the start

of a frame (usually a BPSK PN sequence)

known_symbol2 A vector of complex numbers representing a known symbol at the start

of a frame after known_symbol1 (usually a BPSK PN sequence). Both of these start

symbols are differentially correlated to compensate for phase changes between symbols.

max_fft_shift_len Set's the maximum distance you can look between bins for

correlation

Note Needs more documenation

Sub Function 1 gr. ofdm_correlator.snr () : Return an estimate of the SNR of the channel.

Example

1.8.27.71) ofdm_cyclic_prefixer ()

Type Function

Description Adds a cyclic prefix vector to an input size long ofdm symbol (vector) and converts vector

to a stream output_size long.

Usage gr.ofdm_cyclic_prefixer(input_size, output_size)

Parameters input_size: ??????????

output_size: ????????????

Note Needs more documenation

Example

1.8.27.72) ofdm_bpsk_mapper ()

Type Function

Description Take a message in and map to a vector of complex constellation points suitable for IFFT

input to be used in an ofdm modulator. Simple BPSK version.

Usage gr.ofdm_bpsk_mapper (msgq_limit, occupied_carriers, fft_length)

Parameters msgq_limit: maximum number of messages in message queue

occupied_carriers: ????????

fft_length : FFT length

Note Needs more documentation

Sub Function 1 gr.ofdm_bpsk_mapper.msgq() : Return a pointer to msg queue

Example

Simple Gnuradio User Manual Page 118 of 208

1.8.27.73) ofdm_bpsk_demapper ()

Type Function

Description Take a vector of complex constellation points in from an FFT and demodulate to a

stream of bits. Simple BPSK version.

Usage gr.ofdm_bpsk_demapper (occupied_carriers)

Parameters occupied_carriers: ????????

Note Needs more documentation

Example

1.8.27.74) ofdm_ mapper_bcv ()

Type Function

Description Take a stream of bytes in and map to a vector of complex constellation points suitable for

IFFT input to be used in an ofdm modulator. Abstract class must be subclassed with

specific mapping.

Usage gr.ofdm_mapper_bcv (constellation, msgq_limit, occupied_carriers, fft_length)

Parameters constellation : vector of complex data

msgq_limit: maximum number of messages in message queue

occupied_carriers:????????

fft_length : FFT length

Note Needs more documentation

Sub Function 1 gr.ofdm_mapper_bcv.msgq() : Return a pointer to msg queue

Example

1.8.27.75) ofdm_qpsk_mapper ()

Type Function

Description Take a message in and map to a vector of complex constellation points suitable for IFFT

input to be used in an ofdm modulator. Simple QPSK version.

Usage gr.ofdm_qpsk_mapper (msgq_limit, occupied_carriers, fft_length)

Parameters msgq_limit: maximum number of messages in message queue

occupied_carriers: ????????

fft_length : FFT length

Note Needs more documentation

Sub Function 1 gr.ofdm_qpsk_mapper.msgq() : Return a pointer to msg queue

Example

1.8.27.76) ofdm_qam_mapper ()

Type Function

Description Take a message in and map to a vector of complex constellation points suitable for IFFT

input to be used in an ofdm modulator. Simple QAM version.

Usage gr.ofdm_qam_mapper (msgq_limit, occupied_carriers, fft_length, m)

Parameters msgq_limit: maximum number of messages in message queue

occupied_carriers : ????????

fft_length : FFT length

m : ??????????

Note Needs more documentation

Sub Function 1 gr.ofdm_qam_mapper.msgq() : Return a pointer to msg queue

Example

Simple Gnuradio User Manual Page 119 of 208

1.8.27.77) ofdm_frame_sink ()

Type Function

Description Takes an OFDM symbol in, demaps it into bits of 0's and 1's, packs them into packets,

and sends to to a message queue sink.

NOTE: The mod input parameter simply chooses a pre-defined demapper/slicer.

Eventually, we want to be able to pass in a reference to an object to do the demapping

and slicing for a given modulation type.

Usage gr.ofdm_frame_sink (sym_position, sym_value_out, target_queue,

occupied_tones)

Parameters sym_position : vector of complex

sym_value_out : vector of unsigned characters

target_queue : point to message queue

occupied_tones : Integer

Note Needs more documentation

Example

1.8.27.78) ofdm_insert_preamble ()

Type Function

Description Insert "pre-modulated" preamble symbols before each payload.

Input 1: stream of vectors of gr_complex [fft_length]. These are the modulated symbols

of the payload.

Input 2: stream of char. The LSB indicates whether the corresponding symbol on input 1

is the first symbol of the payload or not. It's a 1 if the corresponding symbol is the first

symbol; otherwise 0.This implies that there must be at least 1 symbol in the payload.

Output 1: stream of vectors of gr_complex [fft_length] These include the preamble

symbols and the payload symbols.

Output 2: stream of char. The LSB indicates whether the corresponding symbol on input

1 is the first symbol of a packet (i.e., the first symbol of the preamble.) It's a 1 if the

corresponding symbol is the first symbol, otherwise 0.

Usage gr.ofdm_insert_preamble(fft_length, preamble)

Parameters fft_length : FFT length

preamble : vector of complex vectors

Note Needs more documentation

Example

1.8.27.79) ofdm_sampler ()

Type Function

Description Does the rest of the OFDM stuff ??????????????

Usage gr.ofdm_sampler(fft_length, symbol_length)

Parameters fft_length : FFT length

symbol_length: ??????????????????

Note Needs more documentation

Example

Simple Gnuradio User Manual Page 120 of 208

1.8.27.80) regenerate_bb ()

Type Function

Description Make a regenerate block. Detect the peak of a signal and repeat every period samples.

If a peak is detected, this block outputs a 1 repeated every period samples until reset by

detection of another 1 on the input or stopped after max_regen regenerations have

occurred.

Note that if max_regen= (-1)/ULONG_MAX, then the regeneration will run forever.

Usage gr.regenerate_bb(period, max_regen)

Parameters period : The number of samples between regenerations

max_regen : The maximum number of regenerations to perform; if set to ULONG_MAX,

it will regenerate continuously.

Note Needs more documentation

Sub Function 1 gr.regenerate_bb.set_max_regen (regen) : Reset the maximum regeneration count; this

will reset the current regen.

Sub Function 2 gr.regenerate_bb.set_period (period) : Reset the period of regenerations; this will reset

the current regen.

Example

1.8.27.81) costas_loop_cc ()

Type Function

Description A Costas loop carrier recovery module. Carrier tracking PLL for QPSK. Input: complex;

output: complex .The Costas loop can have two output streams: stream 1 is the

baseband I and Q; stream 2 is the normalized frequency of the loop order must be 2 or 4.

The Costas loop locks to the center frequency of a signal and downconverts it to

baseband. The second (order=2) order loop is used for BPSK where the real part of the

output signal is the baseband BPSK signal and the imaginary part is the error signal.

When order=4, it can be used for quadrature modulations where both I and Q (real and

imaginary) are outputted.

More details can be found online:

J. Feigin, "Practical Costas loop design: Designing a simple and inexpensive BPSK

Costas loop carrier recovery circuit," RF signal processing, pp. 20-36, 2002.

http://rfdesign.com/images/archive/0102Feigin20.pdf

Usage gr.costas_loop_cc(alpha, beta, max_freq, min_freq, order)

Parameters alpha : The loop gain used for phase adjustment

beta : The loop gain for frequency adjustments

max_freq:The maximum frequency deviation (normalized frequency) the loop can

handle

min_freq : The minimum frequency deviation (normalized frequency) the loop can

handle

order : The loop order, either 2 or 4

Note Needs more documentation

Example

1.8.27.82) pa_2x2_phase_combiner ()

Type Function

Description pa_2x2 phase combiner. Anntenas are arranged like this: 2 3 0 1

dx and dy are lambda/2.

Usage gr.pa_2x2_phase_combiner()

Parameters

Note Needs more documentation

Sub Function 1 gr.pa_2x2_phase_combiner.theta() : Return theta

Sub Function 2 gr.pa_2x2_phase_combiner.set_theta(theta) : Set theta (float)

Example

Simple Gnuradio User Manual Page 121 of 208

1.8.27.83) kludge_copy ()

Type Function

Description output[i] = input[i] .This is a short term kludge to work around a problem with the

hierarchical block impl.

Usage gr.kludge_copy(itemsize)

Parameters itemsize: One of gr.sizeof_short, gr.sizeof_gr_complex, gr.sizeof_float ,gr_sizeof_char

Note

Example

1.8.27.84) prefs ()

Type Function

Description Base class for representing user preferences in windows INI files. The real

implementation is in Python, and is accessable from C++ via the magic of SWIG

directors.

Usage

Parameters

Note Needs more documentation

Example

1.8.27.85) test ()

Type Function

Description Test class for testing runtime system (setting up buffers and such.). This block does not

do any usefull actual data processing. It just exposes setting all standard block

parameters using the contructor or public methods. This block can be usefull when

testing the runtime system. You can force this block to have a large history, decimation

factor and/or large output_multiple. The runtime system should detect this and create

large enough buffers all through the signal chain.

Usage

Parameters

Note Needs more documentation

Example

1.8.27.86) unpack_k_bits_bb ()

Type Function

Description Converts a byte with k relevent bits to k output bytes with 1 bit in the LSB.

Usage gr.unpack_k_bits_bb(k)

Parameters

Note Needs more documentation

Example

Simple Gnuradio User Manual Page 122 of 208

1.8.27.87) correlate_access_code_bb ()

Type Function

Description Examine input for specified access code, one bit at a time. Input: stream of bits, 1 bit per

input byte (data in LSB), output: stream of bits, 2 bits per output byte (data in LSB, flag in

next higher bit). Each output byte contains two valid bits, the data bit, and the flag bit.

The LSB (bit 0) is the data bit, and is the original input data, delayed 64 bits. Bit 1 is the

flag bit and is 1 if the corresponding data bit is the first data bit following the access code.

Otherwise the flag bit is 0.

Usage gr.correlate_access_code_bb(access_code, threshold)

Parameters access_code : is string represented with 1 byte per bit, e.g., "010101010111000100"

threshold : maximum number of bits that may be wrong

Note Needs more documentation

Sub Function 1 gr.correlate_access_code_bb.set_access_code(access_code)

Example

1.8.27.88) diff_phasor_cc ()

Type Function

Description ????????????????????

Usage

Parameters

Note Needs more documentation

Example

1.8.27.89) constellation_decoder_cb ()

Type Function

Description ????????????????????

Usage gr. constellation_decoder_cb(sym_position, sym_value_out)

Parameters sym_position : vector of complex

sym_value_out : vector of unsigned charaters

Note Needs more documentation

Sub Function 1 gr. constellation_decoder_cb.set_constellation(sym_position, sym_value_out)

Example

1.8.27.90) binary_slicer_fb ()

Type Function

Description Slice float binary symbol outputting 1 bit output (the LSB of the output byte) per sample.

If x <0 then output 0. If x >=0 then output 1

Usage gr. binary_slicer_fb()

Parameters

Note

Example

Simple Gnuradio User Manual Page 123 of 208

1.8.27.91) diff_encoder_bb ()

Type Function

Description Differential encoder.y[0] = (x[0] + y[-1]) % M

Usage gr. diff_encoder_bb(modulus)

Parameters

Note

Example

1.8.27.92) diff_decoder_bb ()

Type Function

Description Differential decoder.y[0] = (x[0] - x[-1]) % M

Usage gr. diff_decoder_bb(modulus)

Parameters

Note

Example

1.8.27.93) framer_sink_1 ()

Type Function

Description Given a stream of bits and access_code flags, assemble packets.

Input: stream of bytes from gr_correlate_access_code_bb, output: none. Pushes

assembled packet into target queue. The framer expects a fixed length header of 2 16-bit

shorts containing the payload length, followed by the payload. If the 2 16-bit shorts are

not identical, this packet is ignored. Better algs are welcome. The input data consists of

bytes that have two bits used. Bit 0, the LSB, contains the data bit. Bit 1 if set, indicates

that the corresponding bit is the the first bit of the packet. That is, this bit is the first one

after the access code.

Usage gr. framer_sink_1(target_queue)

Parameters target_queue : pointer to message queue

Note Needs more documenation

Example

1.8.27.94) map_bb ()

Type Function

Description output[i] = map[input[i]]

Usage gr. map_bb(map)

Parameters map : a vector of intgers

Note Needs more documenation

Example

1.8.27.95) feval ()

Type Function

Description Base class for evaluating a function: void -> void

This class is designed to be subclassed in Python or C++ and is callable from both

places. It uses SWIG's "director" feature to implement the magic. It's slow. Don't use it in

Simple Gnuradio User Manual Page 124 of 208

a performance critical path. Override eval to define the behavior. Use calleval to invoke

eval (this kludge is required to allow a python specific "shim" to be inserted.

Usage gr. feval()

Parameters

Sub Function 1 ge.feval.calleval()

Note Needs more documenation

Example

1.8.27.96) feval_xx ()

Type Function

Description Base class for evaluating a function.This class is designed to be subclassed in Python or

C++ and is callable from both places. It uses SWIG's "director" feature to implement the

magic. It's slow. Don't use it in a performance critical path. Override eval to define the

behavior. Use calleval to invoke eval (this kludge is required to allow a python specific

"shim" to be inserted.

feval_cc : complex to complex

feval_dd : double to double

feval_ll : long to long

Usage gr. feval_xx()

Parameters

Sub Function 1 ge.feval_xx.calleval()

Note Needs more documenation

Example

1.8.27.97) pwr_squelch_xx ()

Type Function

Description Gate or zero output when input power below threshold.

pwr_squelch_cc : complex input, complex output

pwr_squelch_ff : float input, float output

Usage gr. pwr_squelch_xx(db, alpha, ramp, gate)

Parameters db : threshold value

alpha: The gain value (float) of a moving average filter (Time Constant in sec)

ramp : integer represents rise/fail time im msec

gate : bool True or False

Sub Function 1 gr.pwr_squelch_xx.threshold() : Return threshold

Sub Function 2 gr.pwr_squelch_xx.set_threshold(db) : Set threshold

Sub Function 3 gr.pwr_squelch_xx.set_alpha(alpha) : Set alpha

Sub Function 4 gr.pwr_squelch_xx.ramp() : Return ramp

Sub Function 5 gr.pwr_squelch_xx.set_ramp(ramp) : Set ramp

Sub Function 6 gr.pwr_squelch_xx.gate() : Return bool True or False

Sub Function 7 gr.pwr_squelch_xx.set_gate(on) : Set threshold

Sub Function 8 gr.pwr_squelch_xx.unmuted() : Return bool True or False

Note Needs more documenation

Example

1.8.27.98) squelch_base_xx ()

Type Function

Description ??????????????????????????????

squelch_base_cc : complex input, complex output

Simple Gnuradio User Manual Page 125 of 208

squelch_base_ff : float input, float output

Usage gr. squelch_base_xx(name, ramp, gate)

Parameters name : ?????

ramp : integer represents rise/fail time im msec

gate : bool True or False

Sub Function 1 gr.squelch_ base_xx.squelch_range() : Return range

Sub Function 2 gr. squelch_ base_xx.ramp() : Return ramp

Sub Function 3 gr. squelch_ base_xx.set_ramp(ramp) : Set ramp

Sub Function 4 gr. squelch_ base_xx.gate() : Return bool True or False

Sub Function 5 gr. squelch_ base_xx.set_gate(on) : Set threshold

Sub Function 6 gr. squelch_ base_xx.unmuted() : Return bool True or False

Note Needs more documenation

Example

1.8.27.99) ctcss_squelch_ff ()

Type Function

Description Gate or zero output if ctcss tone not present

Usage gr. ctcss_squelch_ff(rate, freq, level, len, ramp, gate)

Parameters rate : sampling rate

freq : tone frequency

level : tone level

ramp : integer represents rise/fail time im msec

gate : bool True or False

Sub Function 1 gr.ctcss_squelch_ff.level() : Return level

Sub Function 2 gr.ctcss_squelch_ff.set_level(level) : Set level

Sub Function 3 gr.ctcss_squelch_ff.len() : Return length

Sub Function 4 gr.ctcss_squelch_ff.squelch_range() : Return squelch range

Sub Function 5 gr.ctcss_squelch_ffr_amp() : Return ramp

Sub Function 6 gr.ctcss_squelch_ff.set_ramp(ramp) : Set ramp

Sub Function 7 gr.ctcss_squelch_ff.gate() : Return True or False

Sub Function 8 gr.ctcss_squelch_ff.set_gate(gate) : Set Gate

Sub Function 9 gr.ctcss_squelch_ff.unmuted() : Return True or False

Note Needs more documenation

Example

1.8.27.100) feedforward_agc_cc ()

Type Function

Description Non-causal AGC which computes required gain based on max absolute value over

nsamples.

Usage gr. feedforward_agc_cc(nsamples, refrence)

Parameters nsamples : number of samples

refrence : refrence value

Note

Example

Simple Gnuradio User Manual Page 126 of 208

1.8.27.101) bin_statistics_f ()

Type Function

Description Sink block that controls frequency scanning and record frequency domain statistics.

Usage gr. bin_statistics(vlen, msgq, tune, tune_delay, dwell_delay)

Parameters vlen : vector length (fft size)

msgq : pointer to msg queue

tune : python callback function (tune type is gr.feval_dd())

tune_delay : Time to delay (in number of samples) after changing frequency

dwell_delay : Time to dwell (in number of samples) at a given frequncy

Note Needs more documenation

Example See usrp_spectrum_sense.py

1.8.27.102) glfsr_source_x ()

Type Function

Description glfsr_source_f : Galois LFSR pseudo-random source generating float outputs -1.0 - 1.0.

glfsr_source_b : Galois LFSR pseudo-random source generating 0 or 1.

Usage gr. glfsr_source_x(degree, repeat, mask, seed)

Parameters degree :

repeat : bool True or False

mask :

seed :

Sub Function 1 gr. glfsr_source_x.period() : Return period

Sub Function 2 gr. glfsr_source_x.mask() : Return mask

Note Needs more documenation

Example

1.9) gnuradio/ window.py

Type Python file

Description Routines for designing window functions for FFT.

Examples

Note

1.9.1) hamming()

Type Function

Description Design Hamming window

Usage window.hamming(fft_size)

Parameters fft_size : number of window taps

Examples

Note

Simple Gnuradio User Manual Page 127 of 208

1.9.2) hanning()

Type Function

Description Design Hanning window

Usage window.hanning(fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.3) welch()

Type Function

Description Design Welch window

Usage window.welch(fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.4) parzen()

Type Function

Description Design Parzen window

Usage window.parzen(fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.5) bartlett()

Type Function

Description Design Bartlett window

Usage window.bartlett(fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.6) blackman2()

Type Function

Description Design Blackman2 window

Usage window.blackman2(fft_size)

Parameters fft_size : number of window taps

Examples

Note

Simple Gnuradio User Manual Page 128 of 208

1.9.7) blackman3()

Type Function

Description Design Blackman3 window

Usage window.blackman3(fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.8) blackman4()

Type Function

Description Design Blackman4 window

Usage window.blackman4(fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.9) exponential()

Type Function

Description Design Exponential window

Usage window.exponential (fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.10) riemann()

Type Function

Description Design Riemann window

Usage window.riemann (fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.11) blackmanharris ()

Type Function

Description Design Blackmanharris window

Usage window.blackmanharris (fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.9.12) nuttall()

Type Function

Description Design Nuttall window

Usage window.nuttal (fft_size)

Parameters fft_size : number of window taps

Examples

Note

Simple Gnuradio User Manual Page 129 of 208

1.9.13) kaiser()

Type Function

Description Design Kaiser window

Usage window.kaiser (fft_size)

Parameters fft_size : number of window taps

Examples

Note

1.10) gnuradio/ video_sdl.py

Type Python file

Description Simple Direct Media Layer (SDL) routines for displaying video.

Examples

Note

1.10.1) video_sdl_sink_uc()

Type Function

Description Video sink using SDL. Input signature is one, two or three streams of unsigned char. One

stream: stream is grey (Y) two streems: first is grey (Y), second is alternating U and V

Three streams: first is grey (Y), second is U, third is V Input samples must be in the

range [0,255].

Usage video_sdl.video_sdl_sink_uc( framerate, width, height, format, dst_width,

dst_height)

Parameters framerate : double

width : integer

height : integer

format : unsigned integer

dst_width : integer

dst_height : integer

Examples

Note

1.10.2) video_sdl_sink_s()

Type Function

Description Video sink using SDL. Input signature is one, two or three streams of signed shorts. One

stream: stream is grey (Y) two streems: first is grey (Y), second is alternating U and V

Three streams: first is grey (Y), second is U, third is V Input samples must be in the

range [0,255].

Usage video_sdl.video_sdl_sink_s( framerate, width, height, format, dst_width,

dst_height)

Parameters framerate : double

width : integer (640)

height : integer (480)

format : unsigned integer

dst_width : integer

dst_height : integer

Examples

Note

Simple Gnuradio User Manual Page 130 of 208

1.10.3) sink_uc()

Type Function

Description Video sink using SDL. Input signature is one, two or three streams of unsigned char. One

stream: stream is grey (Y) two streems: first is grey (Y), second is alternating U and V

Three streams: first is grey (Y), second is U, third is V Input samples must be in the

range [0,255].

Usage video_sdl.sink_uc( framerate, width, height, format, dst_width, dst_height)

Parameters framerate : double

width : integer

height : integer

format : unsigned integer

dst_width : integer

dst_height : integer

Examples

Note

1.10.4) sink_s()

Type Function

Description Video sink using SDL. Input signature is one, two or three streams of signed shorts. One

stream: stream is grey (Y) two streems: first is grey (Y), second is alternating U and V

Three streams: first is grey (Y), second is U, third is V Input samples must be in the

range [0,255].

Usage video_sdl. sink_s( framerate, width, height, format, dst_width, dst_height)

Parameters framerate : double

width : integer

height : integer

format : unsigned integer

dst_width : integer

dst_height : integer

Examples

Note

1.11) gnuradio/ trellis.py

Type Python file

Description Trellis coding ??????????????????

Examples

Note

1.11.1) fsm()

Type Function

Description Finite state machine ????????????

Usage trellis.fsm()

Parameters

Examples

Note Needs more documentation

Simple Gnuradio User Manual Page 131 of 208

1.11.2) interleaver()

Type Function

Description ??????????

Usage trellis.interleaver()

Parameters

Examples

Note Needs more documentation

1.11.3) trellis_permutation ()

Type Function

Description Permutation ?????????????

Usage trellis.trellis_permutation()

Parameters

Examples

Note Needs more documentation

1.11.4) trellis_siso_f ()

Type Function

Description ???????????????

Usage trellis.trellis_siso_f()

Parameters

Examples

Note Needs more documentation

1.11.5) trellis_encoder_xx ()

Type Function

Description ???????????????

trellis_encoder_bb

trellis_encoder_bi

trellis_encoder_bs

trellis_encoder_ii

trellis_encoder_si

trellis_encoder_ss

trellis_encoder_bb

Usage

Parameters

Examples

Note Needs more documentation

Simple Gnuradio User Manual Page 132 of 208

1.11.6) trellis_metrics_x ()

Type Function

Description ???????????????

trellis_metrics_c

trellis_metrics_f

trellis_metrics_i

trellis_metrics_s

Usage

Parameters

Examples

Note Needs more documentation

1.11.7) trellis_viterbi_x ()

Type Function

Description ???????????????

trellis_viterbi_b

trellis_viterbi_i

trellis_viterbi_s

Usage

Parameters

Examples

Note Needs more documentation

1.11.8) trellis_viterbi_combined_xx ()

Type Function

Description ???????????????

trellis_viterbi_combined_cb

trellis_viterbi_combined_ci

trellis_viterbi_combined_cs

trellis_viterbi_combined_fb

trellis_viterbi_combined_fi

trellis_viterbi_combined_fs

trellis_viterbi_combined_ib

trellis_viterbi_combined_ii

trellis_viterbi_combined_is

trellis_viterbi_combined_sb

trellis_viterbi_combined_si

trellis_viterbi_combined_ss

Usage

Parameters

Examples

Note Needs more documentation

1.12) gnuradio/ sounder.py

Type Python file

Description This is a work-in-progress implementation of a m-sequence based channel sounder for

GNU Radio and the USRP.

In typical use, the user would run the sounder as a transmitter on oneUSRP, and a

receiver on another at a different location. The receiver will determine the impulse

response of the RF channel in between.

Simple Gnuradio User Manual Page 133 of 208

The sounder uses a custom FPGA bitstream that is able to generate and receive a

sounder waveform across a full 32 MHz wide swath of RF spectrum; the waveform

generation and impulse response processing occur in logic in the USRP FPGA and not

in the host PC. This avoids the USB throughput bottleneck entirely. Unfortunately, there

is still roll-off in the AD9862 digital up-converter interpolation filter that impacts the outer

20% of bandwidth, but this can be compensated for by measuring and subtracting

out this response during calibration.

The sounder is based on sending a maximal-length PN code modulated as BPSK with

the supplied center frequency, with a chip-rate of 32 MHz. The receiver correlates the

received signal across all phases of the PN code and outputs an impulse response

vector. As auto-correlation of an m-sequence is near zero for any relative phase shift,

the actual measured energy at a particular phase shift is related to the impulse response

for that time delay. This is the same principle used in spread-spectrum RAKE receivers

such as are used with GPS and CDMA.

The transmitter is designed to work only with the board in side A. The receiver may be in

side A or side B. The boards may be standalone LFTX/LFRXs or RFX daughterboards.

To use, the following script is installed into $prefix/bin:

Usage: usrp_sounder.py [options]

Options:

-h, --help show this help message and exit

-R RX_SUBDEV_SPEC, --rx-subdev-spec=RX_SUBDEV_SPEC

select USRP Rx side A or B

-f FREQ, --frequency=FREQ

set frequency to FREQ in Hz, default is 0.0

-d DEGREE, --degree=DEGREE

set sounding sequence degree (2-12), default is 12,

-t, --transmit enable sounding transmitter

-r, --receive enable sounding receiver

-l, --loopback enable digital loopback, default is disabled

-v, --verbose enable verbose output, default is disabled

-D, --debug enable debugging output, default is disabled

-F FILENAME, --filename=FILENAME

log received impulse responses to file

To use with an LFTX board, set the center frequency to 16M:

$ usrp_sounder.py -f 16M -t

The sounder receiver command line is:

$ usrp_sounder.py -f 16M -r -F output.dat

You can vary the m-sequence degree between 2 and 12, which will create sequence

lengths between 3 and 4095 (128 us). This will affect how frequently the receiver can

calculate impulse response vectors.

The correlator uses an O(N^2) algorithm, by using an entire PN period of the received

signal to correlate at each lag value. Thus, using a degree 12 PN code of length 4095, it

takes 4095*4095/32e6 seconds to calculate a single impulse response vector, about a

half a second. One can reduce this time by a factor of 4 for each decrement in PN code

degree, but this also reduces the inherent processing gain by 6 dB as well.

The impulse response vectors are written to a file in complex float format, and consist of

the actual impulse response with a noise floor dependent on the PN code degree in use.

There is a loopback test mode that causes the sounding waveform to be routed back to

the receiver inside the USRP:

Simple Gnuradio User Manual Page 134 of 208

$ usrp_sounder.py -r -t -l -F output.dat

The resulting impulse response will be a spike followed by a near zero value for the rest

of the period.

Synchronization at the receiver is not yet implemented, so the actual impulse response

may be time shifted an arbitrary value within the the impulse response vector. If one

assumes the first to arrive signal is the strongest, then one can circularly rotate the

vector until the peak is at time zero.

Examples

Note

1.12.1) sounder_tx ()

Type Function

Description Sounder_tx function

Usage sounder.sounder_tx (loopback=False, ampl=4096,verbose=False, debug=False)

Parameters

Examples

Note Needs more documentation

1.12.2) sounder_rx ()

Type Function

Description Sounder_rx function

Usage sounder.sounder_rx(subdev_spec=None,gain=None,length=1,alpha=1.0,msgq=Non

e,loopback=False,verbose=False,debug=False)

Parameters

Examples

Note Needs more documentation

1.12.3) sounder ()

Type Function

Description

Usage sounder.sounder(transmit=False,receive=False,loopback=False,rx_subdev_spec=N

one,ampl=0x1FFF,frequency=0.0,rx_gain=None,degree=12,length=1,alpha=1.0,msgq

=None,verbose=False,debug=False)

Parameters

Examples

Note Needs more documentation

1.13) gnuradio/ radar_mono.py

Type Python file

Description This GNU Radio component implements a monostatic radar transmitter and receiver. It

uses a custom FPGA build to generate a linear FM chirp waveform directly in the USRP.

Echo returns are recorded to a file for offline analysis.

The LFM chirp can be up to 32 MHz in width, whose center frequency is set by which

transmit daughter board is installed. This gives a range resolution of approximately 5

meters.

Examples

Note

Simple Gnuradio User Manual Page 135 of 208

1.13.1) radar_tx ()

Type Function

Description Transmitter object. Uses usrp_sink, but only for a handle to the FPGA registers.

Usage radar_mono.radar_tx(options)

Parameters

Examples

Note

1.13.2) radar_rx ()

Type Function

Description Receiver object. Uses usrp_source_c to receive echo records.

Usage radar_mono.radar_rx(options,callback)

Parameters

Examples

Note

1.13.3) radar ()

Type Function

Description ???????

Usage radar_mono.radar(options,callback)

Parameters

Examples

Note

1.14) gnuradio/ ra.py

Type Python file

Description Radio astronomy. This file was automatically generated by SWIG

Examples

Note Needs more documentation

1.15) gnuradio/ packet_util.py

Type Python file

Description Utilities for packet handling

Examples

Note

1.15.1) conv_packed_binary_string_to_1_0_string ()

Type Function

Description '\xAF' --> '10101111'

Simple Gnuradio User Manual Page 136 of 208

Usage packet_util.conv_packed_binary_string_to_1_0_string(s)

Parameters s: string

Examples

Note

1.15.2) conv_1_0_string_to_packed_binary_string ()

Type Function

Description '10101111' -> ('\xAF', False)

Basically the inverse of conv_packed_binary_string_to_1_0_string, but also returns a

flag indicating if we had to pad with leading zeros to get to a multiple of 8.

Usage packet_util. conv_1_0_string_to_packed_binary_string (s)

Parameters s: string

Examples

Note

1.15.3) make_packet ()

Type Function

Description Build a packet, given access code, payload, and whitener offset. Packet will have access

code at the beginning, followed by length, payload and finally CRC-32.

Usage packet_util. make_packet(payload, samples_per_symbol, bits_per_symbol,

access_code=default_access_code, pad_for_usrp=True,

whitener_offset=0, whitening=True)

Parameters payload: Packet payload, len [0, 4096]

samples_per_symbol: samples per symbol (needed for padding calculation)

type samples_per_symbol: int

bits_per_symbol: (needed for padding calculation)

type bits_per_symbol: int

access_code: string of ascii 0's and 1's

pad_for_usrp: If true, packets are padded such that they end up a multiple of 128

samples

whitener_offset : offset into whitener string to use [0-16)

whitening: Turn whitener on or off

type whitening: bool

Examples

Note

1.15.4) unmake_packet ()

Type Function

Description Return (ok, payload)

Usage packet_util. unmake_packet(whitened_payload_with_crc, whitener_offset=0,

dewhitening=True)

Parameters whitened_payload_with_crc: string

whitener_offset: offset into whitener string to use [0-16)

dewhitening: Turn whitener on or off

type dewhitening: bool

Examples

Note

Simple Gnuradio User Manual Page 137 of 208

1.15.5) _npadding_bytes ()

Type Function

Description Generate sufficient padding such that each packet ultimately ends up being a multiple of

512 bytes when sent across the USB. We send 4-byte samples across the USB (16-bit I

and 16-bit Q), thus we want to pad so that after modulation the resulting packet is a

multiple of 128 samples.

Returns number of bytes of padding to append.

Usage packet_util. _npadding_bytes(pkt_byte_len, samples_per_symbol,

bits_per_symbol)

Parameters ptk_byte_len: len in bytes of packet, not including padding.

samples_per_symbol: samples per bit (1 bit / symbolwidth GMSK)

type samples_per_symbol: int

bits_per_symbol: bits per symbol (log2(modulation order))

type bits_per_symbol: int

Examples

Note

1.16) gnuradio/ optfir.py

Type Python file

Description Routines for designing optimal FIR filters. For a great intro to how all this stuff works, see

section 6.6 of "Digital Signal Processing: A Practical Approach", Emmanuael C. Ifeachor

and Barrie W. Jervis, Adison-Wesley, 1993. ISBN 0-201-54413-X.

Examples

Note

1.16.1) low_pass ()

Type Function

Description Low pass filter design.

Usage optfir.low_pass (gain, Fs, freq1, freq2, passband_ripple_db, stopband_atten_db,

nextra_taps=0)

Parameters

Examples See ayfabtu.py

Note Needs more documentation

1.16.2) high_pass ()

Type Function

Description High pass filter design.

Usage optfir.high_pass (Fs, freq1, freq2, stopband_atten_db, passband_ripple_db,

nextra_taps=0)

Parameters

Examples

Note 1) FIXME : The high_pass is broken

2) Needs more documentation

Simple Gnuradio User Manual Page 138 of 208

1.17) gnuradio/ ofdm_packet_util.py

Type Python file

Description Utilities for OFDM packet handling

Examples

Note

1.17.1) conv_packed_binary_string_to_1_0_string ()

Type Function

Description '\xAF' --> '10101111'

Usage ofdm_packet_util.conv_packed_binary_string_to_1_0_string(s)

Parameters s: string

Examples

Note

1.17.2) conv_1_0_string_to_packed_binary_string ()

Type Function

Description '10101111' -> ('\xAF', False)

Basically the inverse of conv_packed_binary_string_to_1_0_string, but also returns a

flag indicating if we had to pad with leading zeros to get to a multiple of 8.

Usage ofdm_packet_util. conv_1_0_string_to_packed_binary_string (s)

Parameters s: string

Examples

Note

1.17.3) make_packet ()

Type Function

Description Build a packet, given access code, payload, and whitener offset. Packet will have access

code at the beginning, followed by length, payload and finally CRC-32.

Usage ofdm_packet_util. make_packet(payload, samples_per_symbol, bits_per_symbol,

pad_for_usrp=True, whitener_offset=0, whitening=True)

Parameters payload: packet payload, len [0, 4096]

samples_per_symbol: samples per symbol (needed for padding calculation)

type samples_per_symbol: int

bits_per_symbol: (needed for padding calculation)

type bits_per_symbol: int

whitener_offset : offset into whitener string to use [0-16)

pad_for_usrp: If true, packets are padded such that they end up a multiple of 128

samples

whitening: Turn whitener on or off

type whitening: bool

Examples

Note

1.17.4) unmake_packet ()

Type Function

Description Return (ok, payload)

Usage ofdm_packet_util. unmake_packet(whitened_payload_with_crc, whitener_offset=0,

dewhitening=True)

Simple Gnuradio User Manual Page 139 of 208

Parameters whitened_payload_with_crc: string

whitener_offset : offset into whitener string to use [0-16)

dewhitening: Turn whitener on or off

type dewhitening: bool

Examples

Note

1.17.5) _npadding_bytes ()

Type Function

Description Generate sufficient padding such that each packet ultimately ends up being a multiple of

512 bytes when sent across the USB. We send 4-byte samples across the USB (16-bit I

and 16-bit Q), thus we want to pad so that after modulation the resulting packet is a

multiple of 128 samples.

Returns number of bytes of padding to append.

Usage ofdm_packet_util. _npadding_bytes(pkt_byte_len, samples_per_symbol,

bits_per_symbol)

Parameters ptk_byte_len: len in bytes of packet, not including padding.

samples_per_symbol: samples per bit (1 bit / symbolwidth GMSK)

type samples_per_symbol: int

bits_per_symbol: bits per symbol (log2(modulation order))

type bits_per_symbol: int

Examples

Note

1.18) gnuradio/ modulation_utils.py

Type Python file

Description Miscellaneous utilities for managing modulations and demodulations, as well as other

items useful in dealing with generalized handling of different modulations and demods.

Examples

Note

1.18.1) type_1_mods ()

Type Function

Description Type 1 modulators accept a stream of bytes on their input and produce complex

baseband output

Usage modulation_utils.type_1_mods()

Parameters

Examples See tunnel.py

Note Needs more documentation

1.18.2) type_1_demods ()

Type Function

Description Type 1 demodulators accept complex baseband input and produce a stream of bits,

packed1 bit / byte as their output. Their output is completely unambiguous. There is no

Needsto resolve phase or polarity ambiguities.

Usage modulation_utils.type_1_demods()

Simple Gnuradio User Manual Page 140 of 208

Parameters

Examples See tunnel.py

Note Needs more documentation

1.19) gnuradio/ local_calibrator.py

Type Python file

Description Simple class for allowing local definition of a calibration function for raw samples coming

from the RA detector chain. Each observatory is different, and rather than hacking up

the main code in usrp_ra_receiver we define the appropriate function here. For example,

one could calibrate the output in Janskys, rather than dB.

Examples

Note NO LONGER USED

1.20) gnuradio/gr_unittest.py

Type Python file

Description Add support for unit testing

Examples

Note

1.21) gnuradio/eng_option.py

Type Python file

Description Add support for engineering notation to optparse.OptionParser

Examples

Note

1.22) gnuradio/eng_notation.py

Type Python file

Description Change engineering notation (example 5e-9 <==> 5n )

Examples

Note

1.22.1) num_to_str ()

Type Function

Description Convert a number to a string in engineering notation. E.g., 5e-9 -> 5n

Usage eng_notation.num_to_str(n)

Parameters

Examples

Note

Simple Gnuradio User Manual Page 141 of 208

1.22.2) str_to_num ()

Type Function

Description Convert a string in engineering notation to a number. E.g., '15m' -> 15e-3

Usage eng_notation.str_to_num(value)

Parameters

Examples

Note

1.23) gnuradio/audio_oss.py

Type Python file

Description Open Sound System (oss) sound interface for audio sink and source.This file was

automatically generated by SWIG

Examples

Note

1.24) gnuradio/audio_alsa.py

Type Python file

Description Advanced Linux Sound Architecture (ALSA) sound interface for audio sink and

source.This file was automatically generated by SWIG

Examples

Note

1.25) gnuradio/audio.py

Type Python file

Description This is the 'generic' audio or soundcard interface. known_modules = ( 'audio_alsa',

'audio_oss', 'audio_osx', 'audio_jack', 'audio_portaudio'). The behavior of this module is

controlled by the [audio] audio_module configuration parameter. If it is 'auto' we attempt

to import modules from the known_modules list, using the first one imported

successfully. If [audio] audio_module is not 'auto', we assume it's the name of an audio

module and attempt to import it.

Examples

Note

1.25.1) source ()

Type Function

Description Audio source. Output signature is one or two streams of floats. Output samples will be in

the range [-1,1].

Usage audio.source(sampling_rate, device_name=””, ok_to_block=true)

Parameters sampling_rate : integer

device_name : string

ok_to_block : bool

Examples

Note

Simple Gnuradio User Manual Page 142 of 208

1.25.2) sink ()

Type Function

Description Audio sink. Input signature is one or two streams of floats. Input samples must be in the

range [-1, 1].

Usage audio.sink(sampling_rate, device_name=””, ok_to_block=true)

Parameters sampling_rate : integer

device_name : string

ok_to_block : bool

Examples sink = audio.sink(sample_rate, "plughw:0,0")

Note

1.26) gnuradio/atsc.py

Type Python file

Description Support for ATSC signal handling. This file was automatically generated by SWIG.

Examples

Note Needs more documentation

1.27) gnuradio/usrp.py

Type Python file

Description Configuration interface for the USRP

Examples

Note

1.27.1) source_x()

Type Function

Description interface to Universal Software Radio Peripheral Rx path

source_c() : complex data source

source_s() : short interleaved data source

Usage usrp.source_x(which=0, decim_rate=64, nchan=1, mux=0x32103210, mode=0,

fusb_block_size=0, fusb_nblocks=0,

fpga_filename="", firmware_filename="")

Parameters

Examples

Note

1.27.1.1) tune()

Type Sub Function

Description Set the center frequency we're interested in.

Tuning is a two step process. First we ask the front-end to tune as close to the desired

frequency as it can. Then we use the result of that operation and our target_frequency to

determine the value for the digital down converter.

Returns False if failure else tune_result

Usage usrp.source_x.tune(u, chan, subdev, target_freq)

Parameters u: instance of usrp.source_*

chan: DDC number

Simple Gnuradio User Manual Page 143 of 208

type chan: int

subdev: daughterboard subdevice

target_freq: frequency in Hz

Examples

Note

1.27.1.2) has_rx_halfband()

Type Sub Function

Description To check if the FPGA implement a final Rx half-band filter? If it doesn't, the maximum

decimation factor with proper gain is 1/2 of what it would otherwise be.

Usage usrp.source_x.has_rx_halfband()

Parameters

Examples

Note

1.27.1.3) nddcs()

Type Sub Function

Description Return number of Digital Down Converters implemented in FPGA, this will be 0, 1, 2, or

Usage usrp.source_x.nddcs()

Parameters

Examples

Note

1.27.2) sink_x()

Type Function

Description Interface to Universal Software Radio Peripheral Tx path

sink_c() : complex data source

sink _s() : short interleaved data source

Usage usrp.sink _x(which=0, interp_rate=128, nchan=1, mux=0x98,

fusb_block_size=0, fusb_nblocks=0,

fpga_filename="", firmware_filename="")

Parameters

Examples

Note

1.27.2.1) tune()

Type Sub Function

Description Set the center frequency we're interested in. Tuning is a two step process. First we ask

the front-end to tune as close to the desired frequency as it can. Then we use the result

of that operation and our target_frequency to determine the value for the digital down

converter.

Returns False if failure else tune_result

Usage usrp.sink_x.tune(u, chan, subdev, target_freq)

Parameters u: instance of usrp.sink_*

chan: DUC number

Simple Gnuradio User Manual Page 144 of 208

type chan: int

subdev: daughterboard subdevice

target_freq: frequency in Hz

Examples

Note Needs more documentation

1.27.2.2) has_tx_halfband()

Type Sub Function

Description To check if the FPGA implement a final Tx half-band filter?

Usage usrp.sink_x.has_tx_halfband()

Parameters

Examples

Note

1.27.2.3) nducs()

Type Sub Function

Description Return number of Digital up Converters implemented in FPGA, this will be 0,1,or 2,.

Usage usrp.sink_x.nducs()

Parameters

Examples

Note

1.27.3) determine_rx_mux_value ()

Type Function

Description A utility to determine appropriate Rx mux value as a function of the subdevice choosen

and thecharacteristics of the respective daughterboard.

Returns: the Rx mux value

Figure out which A/D's to connect to the DDC. Each daughterboard consists of 1 or 2

subdevices. (At this time, all but the Basic Rx have a single subdevice. The Basic Rx

has two independent channels, treated as separate subdevices). subdevice 0 of a

daughterboard may use 1 or 2 A/D's. We determine this by checking the is_quadrature()

method. If subdevice 0 uses only a single A/D, it's possible that the daughterboard has a

second subdevice, subdevice 1, and it uses the second A/D. If the card uses only a

single A/D, we wire a zero into the DDC Q input.

(side, 0) says connect only the A/D's used by subdevice 0 to the DDC.

(side, 1) says connect only the A/D's used by subdevice 1 to the DDC.

Usage usrp.determine_rx_mux_value(u, subdev_spec)

Parameters u: Instance of USRP source

subdev_spec: Tuple represent (side, subdev).

type subdev_spec: (side, subdev), where side is 0 or 1 and subdev is 0 or 1

Examples

Note

Simple Gnuradio User Manual Page 145 of 208

1.27.4) tune_result ()

Type Function

Description Container for intermediate tuning information. Return tunning informations

Usage tune_result.baseband_freq : Return the resultant baseband frequency

tune_result .dxc_freq : Return the used DDC or DUC frequency

tune_result.residual_freq : Return the residual frequency after tunning

tune_result .inverted : Return True if the spectrum is inverted, otherwise return False

Parameters

Examples

Note

1.27.5) determine_tx_mux_value ()

Type Function

Description A utility to determine the appropriate Tx mux value as a function of the subdevice

choosen.

Returns: The Tx mux value

This is simpler than the rx case. Either you want to talk to side A or side B. If you want

to talk to both sides at once, determine the value manually.

Usage usrp.determine_tx_mux_value(u, subdev_spec):

Parameters u: instance of USRP sink

subdev_spec: Tuple represent (side, subdev). .

type subdev_spec: (side, subdev), where side is 0 or 1 and subdev is 0

Examples

Note

1.27.6) selected_subdev ()

Type Function

Description A utility to return the user specified daughterboard subdevice.

Returns: An instance derived from db_base.

Usage usrp.selected_subdev (u, subdev_spec)

Parameters u: Instance of USRP sink or source

subdev_spec: Tuple represent (side, subdev)

type subdev_spec: (side, subdev), where side is 0 or 1 and subdev is 0 or 1

Examples

Note

1.27.7) calc_dxc_freq ()

Type Function

Description A utility to calculate the frequency to be used for setting the digital up or down converter.

Return: 2-tuple (ddc_freq, inverted) where ddc_freq is the value for the ddc and inverted

is True if we're operating in an inverted Nyquist zone

Usage usrp.calc_dxc_freq(target_freq, baseband_freq, fs)

Simple Gnuradio User Manual Page 146 of 208

Parameters target_freq: desired RF frequency (Hz)

type target_freq: number

baseband_freq: The RF frequency that corresponds to DC in the IF.

type baseband_freq: number

fs: converter sample rate

type fs: number

Examples

Note

1.27.8) pick_rx_subdevice()

Type Function

Description If the user didn't specify an rx subdevice on the command line, try for one of these, in

order: FLEX_400, FLEX_900, FLEX_1200, FLEX_1800, FLEX_2400, TV_RX, DBS_RX,

and BASIC_RX, whatever's on side A.

Return a subdev_spec

Usage usrp.pick_rx_subdevice(u)

Parameters u: Instance of USRP source

Examples

Note

1.27.9) pick_tx_subdevice()

Type Function

Description If the user didn't specify a tx subdevice on the command line, try for one of these, in

order: FLEX_400, FLEX_900, FLEX_1200, FLEX_1800, FLEX_2400, BASIC_TX,

whatever's on side A.

Return a subdev_spec

Usage usrp.pick_rx_subdevice(u)

Parameters u: Instance of USRP source

Examples

Note

1.27.10) pick_ subdev()

Type Function

Description Pick whatever in side A

Return: subdev specification

Usage usrp.pick_subdev(u, candidates)

Parameters u: usrp instance sink or source

candidates: list of usrp dbids which are :

usrp_dbid.BASIC_TX = 0x0000

usrp_dbid.BASIC_RX = 0x0001

usrp_dbid.DBS_RX = 0x0002

usrp_dbid.TV_RX = 0x0003

usrp_dbid.FLEX_400_RX = 0x0004

usrp_dbid.FLEX_900_RX = 0x0005

usrp_dbid.FLEX_1200_RX = 0x0006

usrp_dbid.FLEX_2400_RX = 0x0007

usrp_dbid.FLEX_400_TX = 0x0008

usrp_dbid.FLEX_900_TX = 0x0009

usrp_dbid.FLEX_1200_TX = 0x000a

usrp_dbid.FLEX_2400_TX = 0x000b

usrp_dbid.TV_RX_REV_2 = 0x000c

usrp_dbid.DBS_RX_REV_2_1 = 0x000d

Simple Gnuradio User Manual Page 147 of 208

usrp_dbid.LF_TX = 0x000e

usrp_dbid.LF_RX = 0x000f

usrp_dbid.FLEX_400_RX_MIMO_A = 0x0014

usrp_dbid.FLEX_900_RX_MIMO_A = 0x0015

usrp_dbid.FLEX_1200_RX_MIMO_A = 0x0016

usrp_dbid.FLEX_2400_RX_MIMO_A = 0x0017

usrp_dbid.FLEX_400_TX_MIMO_A = 0x0018

usrp_dbid.FLEX_900_TX_MIMO_A = 0x0019

usrp_dbid.FLEX_1200_TX_MIMO_A = 0x001a

usrp_dbid.FLEX_2400_TX_MIMO_A = 0x001b

usrp_dbid.FLEX_400_RX_MIMO_B = 0x0024

usrp_dbid.FLEX_900_RX_MIMO_B = 0x0025

usrp_dbid.FLEX_1200_RX_MIMO_B = 0x0026

usrp_dbid.FLEX_2400_RX_MIMO_B = 0x0027

usrp_dbid.FLEX_400_TX_MIMO_B = 0x0028

usrp_dbid.FLEX_900_TX_MIMO_B = 0x0029

usrp_dbid.FLEX_1200_TX_MIMO_B = 0x002a

usrp_dbid.FLEX_2400_TX_MIMO_B = 0x002b

usrp_dbid.FLEX_1800_RX = 0x0030

usrp_dbid.FLEX_1800_TX = 0x0031

usrp_dbid.FLEX_1800_RX_MIMO_A = 0x0032

usrp_dbid.FLEX_1800_TX_MIMO_A = 0x0033

usrp_dbid.FLEX_1800_RX_MIMO_B = 0x0034

usrp_dbid.FLEX_1800_TX_MIMO_B = 0x0035

usrp_dbid.TV_RX_REV_3 = 0x0040

usrp_dbid.WBX_LO_TX = 0x0050

usrp_dbid.WBX_LO_RX = 0x0051

Examples

Note

1.28) gnuradio/usrp1.py

Type Python file

Description Configuration interface for the USRP Rev 1 and later

Examples

Note

1.28.1) source_x()

Type Function

Description Interface to Universal Software Radio Peripheral Rx path

source_c() : complex data source

source_s() : short interleaved data source

Usage usrp.source_x(which=0, decim_rate=64, nchan=1, mux=0x32103210, mode=0,

fusb_block_size=0, fusb_nblocks=0,

fpga_filename="", firmware_filename="")

Parameters

Examples

Note

1.28.1.1) set_decim_rate()

Type Sub Function

Description Set decimator rate. Rate must be EVEN and in [8, 256]. The final complex sample rate

across the USB is adc_freq () / decim_rate () *nchannels()

Simple Gnuradio User Manual Page 148 of 208

Usage usrp.source_x.set_decim_rate(rate)

Parameters rate : unsigned integer represents the decimation rate

Examples

Note

1.28.1.2) set_nchannels()

Type Sub Function

Description Set number of active ddc channels. Nchannels must be 1, 2, 3 or 4.

Usage usrp.source_x.set_nchannels(nchan)

Parameters nchan : integer

Examples

Note

1.28.1.3) set_mux()

Type Sub Function

Description This determines which ADC (or constant zero) is connected to each DDC input. There

are 4 DDCs. Each has two inputs.

Mux value:

3 2 1

1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0

+-------+-------+-------+-------+-------+-------+-------+-------+

| Q3 | I3 | Q2 | I2 | Q1 | I1 | Q0 | I0 |

+-------+-------+-------+-------+-------+-------+-------+-------+

Each 4-bit I field is either 0,1,2,3

Each 4-bit Q field is either 0,1,2,3 or 0xf (input is const zero)

All Q's must be 0xf or none of them may be 0xf

Usage usrp.source_x.set_mux(mux)

Parameters mux : integer

Examples

Note To specify an integer value using hex format using gru.hexint() function

1.28.1.4) set_rx_freq()

Type Sub Function

Description Set the center frequency of the digital down converter. Channel must be in the range

[0,3]. freq is the center frequency in Hz. freq may be either negative or postive. The

frequency specified is quantized. Use rx_freq to retrieve the actual value used.

Usage usrp.source_x.set_rx_freq(channel,freq)

Parameters channel: which ddc channel [0, 3]

freq : double, the frequency

Examples

Note

1.28.1.5) set_ddc_phase()

Type Sub Function

Description Set the digital down converter phase register.

Usage usrp.source_x.set_ddc_phase(channel,phase)

Parameters channel: which ddc channel [0, 3]

phase : 32-bit integer phase value.

Simple Gnuradio User Manual Page 149 of 208

Examples

Note

1.28.1.6) set_fpga_mode()

Type Sub Function

Description Set fpga special modes

Usage usrp.source_x.set_fpga_mode(mode)

Parameters mode : one of

FPGA_MODE_NORMAL , FPGA_MODE_LOOPBACK, FPGA_MODE_COUNTING,

FPGA_MODE_COUNTING_32BIT

Examples

Note

1.28.1.7) set_verbose()

Type Sub Function

Description Print usrp configuration

Usage usrp.source_x.set_verbose(verbose)

Parameters verbose : bool true or false

Examples

Note

1.28.1.8) set_pga()

Type Sub Function

Description Set A/D Programmable Gain Amplifier (PGA). Gain is rounded to closest setting

supported by hardware.

Return true if sucessful

Usage usrp.source_x.set_pga(which, gain_in_db)

Parameters which : which A/D [0,3]

gain_in_db : double gain value (linear in dB) in range [0.0,20.0]

Examples

Note

1.28.1.9) pga()

Type Sub Function

Description Return programmable gain amplifier gain setting in dB.

Usage usrp.source_x.pga (which)

Parameters which : which A/D [0,3]

Examples

Note

1.28.1.10) pga_min()

Type Sub Function

Description Return minimum legal PGA setting in dB.

Simple Gnuradio User Manual Page 150 of 208

Usage usrp.source_x.pga_min()

Parameters

Examples

Note

1.28.1.11) pga_max()

Type Sub Function

Description Return maximum legal PGA setting in dB.

Usage usrp.source_x.pga_max()

Parameters

Examples

Note

1.28.1.12) pga_db_per_step()

Type Sub Function

Description Return hardware step size of PGA (linear in dB).

Usage usrp.source_x.pga_db_per_step()

Parameters

Examples

Note

1.28.1.13) fpga_master_clock_freq()

Type Sub Function

Description Return fpga master clock frequency

Usage usrp.source_x.fpga_master_clock_freq()

Parameters

Examples

Note

1.28.1.14) converter_rate()

Type Sub Function

Description Return A/D converter rate

Usage usrp.source_x.converter_rate()

Parameters

Examples

Note

1.28.1.15) decim_rate()

Type Sub Function

Description Return decimation rate

Usage usrp.source_x.decim_rate()

Parameters

Examples

Simple Gnuradio User Manual Page 151 of 208

Note

1.28.1.16) nchannels()

Type Sub Function

Description Return number of active ddc channels

Usage usrp.source_x.nchannels()

Parameters

Examples

Note

1.28.1.17) mux()

Type Sub Function

Description Return mux setting

Usage usrp.source_x.mux()

Parameters

Examples

Note

1.28.1.18) rx_freq()

Type Sub Function

Description Return channels ddc frequency

Usage usrp.source_x.rx_freq(channel)

Parameters channel : which ddc channel [0,3]

Examples

Note

1.28.1.19) daughterboard_id()

Type Sub Function

Description Return daughterboard ID for given Rx daughterboard slot. Slot A =0, Slot B=1.

daughterboard id >= 0 if successful

-1 if no daugherboard

-2 if invalid EEPROM on daughterboard

Usage usrp.source_x.daughterboard_id(which_dboardl)

Parameters which_dboard : Which slot o or 1

Examples

Note

1.28.1.20) write_aux_dac()

Type Sub Function

Description Write auxiliary digital to analog converter.

Usage usrp.source_x. write_aux_dac ( which_dboard, which_dac, value )

Parameters which_dboard: [0,1] which slot , SLOT_TX_A and SLOT_RX_A share the same AUX

Simple Gnuradio User Manual Page 152 of 208

DAC's. SLOT_TX_B and SLOT_RX_B share the same AUX DAC's.

which_dac: [2,3] TX slots must use only 2 and 3.

value : in range of [0,4095]

Examples

Note

1.28.1.21) read_aux_dac()

Type Sub Function

Description Read auxiliary analog to digital converter.

Return value in the range [0, 4095] if successful, else READ_FAILED.

Usage usrp.source_x. read_aux_dac ( which_dboard, which_adc )

Parameters which_dboard : [0,1] which slot

which_adc : [0,1]

Examples

Note

1.28.1.22) write_eeprom()

Type Sub Function

Description Write EEPROM on motherboard or any daughterboard.

Return true if successful

Usage usrp.source_x. write_eeprom(i2c_addr, eeprom_offset, buf)

Parameters i2c_addr : I2C bus address of EEPROM

eeprom_offset : byte offset in EEPROM to begin writing

buf : the data to write

Examples

Note

1.28.1.23) read_eeprom()

Type Sub Function

Description Read bytes from EEPROM on motherboard or any daughterboard.

Return the data read if successful, else a zero length string.

Usage usrp.source_x. read_eeprom(i2c_addr, eeprom_offset, len)

Parameters i2c_addr : I2C bus address of EEPROM

eeprom_offset : byte offset in EEPROM to begin reading

buf : number of bytes to read

Examples

Note

1.28.1.24) write_i2c()

Type Sub Function

Description Write to I2C peripheral. Writes are limited to a maximum of of 64 bytes.

Return true ff successful.

Usage usrp.source_x. write_i2c(i2c_addr, buf)

Parameters i2c_addr : I2C bus address (7-bits)

buf : The data to write

Simple Gnuradio User Manual Page 153 of 208

Examples

Note

1.28.1.25) read_i2c()

Type Sub Function

Description Read from I2C peripheral. Reads are limited to a maximum of of 64 bytes.

Return the data read if successful, else a zero length string.

Usage usrp.source_x.read_i2c(i2c_addr, len)

Parameters i2c_addr : I2C bus address (7-bits)

len : number of bytes to read

Examples

Note

1.28.1.26) set_adc_offset()

Type Sub Function

Description Set ADC offset correction.

Usage usrp.source_x.set_adc_offset(which, offset)

Parameters which : which ADC[0,3]:

offset: 16-bit value to subtract from raw ADC input.

Examples

Note

1.28.1.27) set_dac_offset()

Type Sub Function

Description Set DAC offset correction.

Usage usrp.source_x.set_dac_offset(which, offset, offset_pin)

Parameters which : which DAC[0,3]

offset: 10-bit offset value (ambiguous format: See AD9862 datasheet).

offset_pin: 1-bit value. If 0 offset applied to -ve differential pin; If 1 offset applied to +ve

differential pin.

Examples

Note

1.28.1.28) set_adc_buffer_bypass()

Type Sub Function

Description Control ADC input buffer.

Usage usrp.source_x.set_adc_buffer_bypass(which, bypass)

Parameters which : which ADC [0,3]

bypass : if non-zero, bypass input buffer and connect input directly to switched cap SHA

input of RxPGA.

Examples

Note

Simple Gnuradio User Manual Page 154 of 208

1.28.1.29) serial_number()

Type Sub Function

Description Return the usrp's serial number. Return non-zero length string iff successful.

Usage usrp.source_x.serial_number()

Parameters

Examples

Note

1.28.1.30) _write_oe()

Type Sub Function

Description Write direction register (output enables) for pins that go to daughterboard. Each d'board

has 16-bits of general purpose i/o. Setting the bit makes it an output from the FPGA to

the d'board.This register is initialized based on a value stored in the d'board EEPROM. In

general, you shouldn't be using this routine without a very good reason. Using this

method incorrectly will kill your USRP motherboard and/or daughterboard.

Usage usrp.source_x._write_oe(which_dboard, value, mask)

Parameters which_dboard : [0,1] which d'board

value : value to write into register

mask : which bits of value to write into reg

Examples

Note

1.28.1.31) write_io()

Type Sub Function

Description Write daughterboard i/o pin value.

Usage usrp.source_x.write_io(which_dboard, value, mask)

Parameters which_dboard : [0,1] which d'board

value : value to write into register

mask : which bits of value to write into reg

Examples

Note

1.28.1.32) read_io()

Type Sub Function

Description Read daughterboard i/o pin value.

Return register value if successful, else READ_FAILED

Usage usrp.source_x.read_io(which_dboard)

Parameters which_dboard : [0,1] which d'board

Examples

Note

Simple Gnuradio User Manual Page 155 of 208

1.28.1.33) set_dc_offset_cl_enable()

Type Sub Function

Description Enable/disable automatic DC offset removal control loop in FPGA. If the corresponding

bit is set, enable the automatic DC offset correction control loop. The 4 low bits are

significant:

ADC0 = (1 << 0)

ADC1 = (1 << 1)

ADC2 = (1 << 2)

ADC3 = (1 << 3)

By default the control loop is enabled on all ADC's.

Usage usrp.source_x.set_dc_offset_cl_enable(bits, mask)

Parameters bits : which control loops to enable

mask : which bits to pay attention to

Examples

Note

1.28.1.34) set_format()

Type Sub Function

Description Specify Rx data format. Rx data format control register

3 2 1 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 +----------------------------

-------------+-+-+---------+-------+ | Reserved (Must be zero) |B|Q| WIDTH | SHIFT | +---------

--------------------------------+-+-+---------+-------+

SHIFT specifies arithmetic right shift [0, 15] WIDTH specifies bit-width of I & Q samples

across the USB [1, 16] (not all valid) Q if set deliver both I & Q, else just I B if set bypass

half-band filter.

Right now the acceptable values are:

B Q WIDTH SHIFT 0 1 16 0 0 1 8 8

More valid combos to come.

Default value is 0x00000300 16-bits, 0 shift, deliver both I & Q.

Usage usrp.source_x.set_format( format)

Parameters format : unsigned integer format specifier

Examples See usrp_fft.py

Note

1.28.1.35) make_format()

Type Sub Function

Description Make data format.

Usage usrp.source_x.makeformat(width=16, shift=0, want_q=true,bypass_halfband=false)

Parameters width : integer

shift : integer

want_q : bool true or false, Do you want data Q channel or only the I Channel?.

bypass_halfband : bool true or false

Examples See usrp_fft.py

Note

1.28.1.36) format()

Simple Gnuradio User Manual Page 156 of 208

Type Sub Function

Description Return current data format.

Usage usrp.source_x.format()

Parameters

Examples

Note

1.28.1.37) format_width()

Type Sub Function

Description Retuen format data width

Usage usrp.source_x.format_width(format)

Parameters

Examples

Note

1.28.1.38) format_shift()

Type Sub Function

Description Return format data shift

Usage usrp.source_x.format_shift(format)

Parameters

Examples

Note

1.28.1.39) format_want_q()

Type Sub Function

Description Return format want_q. Do you want Q samples?!

Usage usrp.source_x.format_want_q(format)

Parameters

Examples

Note

1.28.1.40) format_bypass_halfband()

Type Sub Function

Description Retuen format bypass halfband filter

Usage usrp.source_x.format_bypass_halfband(format)

Parameters

Examples

Note

1.28.1.41) _write_fpga_reg()

Type Sub Function

Description Write FPGA register.

Return True if successful

Usage usrp.source_x._write_fpga_reg(regno,value)

Parameters regno : 7-bit register number

Simple Gnuradio User Manual Page 157 of 208

value : 32-bit value

Examples

Note

1.28.1.42) _write_fpga_reg_masked()

Type Sub Function

Description Write FPGA register masked.

Return True if successful

Usage usrp.source_x._write_fpga_reg_masked(regno, value, mask)

Parameters regno : 7-bit register number

value : 16-bit value

mask : 16 bit mask

Examples

Note

1.28.1.43) _read_fpga_reg()

Type Sub Function

Description Read FPGA registers.

Return register value if successful, else READ_FAILED

Usage usrp.source_x._read_fpga_reg(regno)

Parameters regno : 7-bit register number

Examples

Note READ_FAILED = -99999

1.28.1.44) _write_9862()

Type Sub Function

Description Write AD9862 register.

Return true if successful

Usage usrp.source_x._write_9862(which_codec, regno, value)

Parameters which_codec : 0 or 1

regno : 6-bit register number

value : 8-bit value

Examples

Note

1.28.1.45) _read_9862()

Type Sub Function

Description Read AD9862 registers.

Return register value if successful, else READ_FAILED

Usage usrp.source_x._read_9862(which_codec, regno)

Parameters which_codec : 0 or 1

Simple Gnuradio User Manual Page 158 of 208

regno : 6-bit register number

Examples

Note

1.28.1.46) _write_spi()

Type Sub Function

Description Write data to SPI bus peripheral.

SPI == "Serial Port Interface". SPI is a 3 wire bus plus a separate enable for each

peripheral. The common lines are SCLK,SDI and SDO. The FX2 always drives SCLK

and SDI, the clock and data lines from the FX2 to the peripheral. When enabled, a

peripheral may drive SDO, the data line from the peripheral to the FX2.

The SPI_READ and SPI_WRITE commands are formatted identically.

Each specifies which peripherals to enable, whether the bits should be transmistted Most

Significant Bit first or Least Significant Bit first, the number of bytes in the optional

header, and the number of bytes to read or write in the body.

The body is limited to 64 bytes. The optional header may contain 0, 1 or 2 bytes. For an

SPI_WRITE, the header bytes are transmitted to the peripheral followed by the the body

bytes. For an SPI_READ, the header bytes are transmitted to the peripheral, then len

bytes are read back from the peripheral.(see : usrp_spi_defs.h file). If format specifies

that optional_header bytes are present, they are written to the peripheral immediately

prior to writing buf.

Return true if successful. Writes are limited to a maximum of 64 bytes.

Usage usrp.source_x._write_spi(optional_header, enables, format, buf)

Parameters optional_header: 0,1 or 2 bytes to write before buf.

enables: bitmask of peripherals to write.

format: transaction format. SPI_FMT_*

buf : the data to write

Examples

Note

1.28.1.47) _read_spi()

Type Sub Function

Description Read data from SPI bus peripheral.

Return the data read if successful, else a zero length string.

Usage usrp.source_x._read_spi(optional_header, enables, format, len)

Parameters optional_header : 0,1 or 2 bytes to write before buf.

enables : bitmask of peripherals to write.

format : transaction format. SPI_FMT_*

len : number of bytes to read.

Examples

Note

1.28.2) sink_x()

Type Function

Description interface to Universal Software Radio Peripheral Rx path

sink_c() : complex data source

sink_s() : short interleaved data source

Simple Gnuradio User Manual Page 159 of 208

Usage usrp.sink_x(which=0, interp_rate=128, nchan=1, mux=0x98,

fusb_block_size=0, fusb_nblocks=0,

fpga_filename="", firmware_filename="")

Parameters

Examples

Note

1.28.2.1) set_interp_rate()

Type Sub Function

Description Set interpolator rate. Rate must be in [4, 512] and a multiple of 4. The final complex

sample rate across the USB is dac_freq () / interp_rate () * nchannels ()

Usage usrp.sink_x.set_interp_rate(rate)

Parameters rate : unsigned integer

Examples

Note

1.28.2.2) set_nchannels()

Type Sub Function

Description Set number of active duc channels, nchannels must be 1 or 2.

Usage usrp.sink_x.set_nchannels(nchan)

Parameters nchan : integer

Examples

Note

1.28.2.3) set_mux()

Type Sub Function

Description This determines which DAC is connected to each DUC input. There are 2 DUCs. Each

has two inputs.

Mux value:

3 2 1

1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0

+-------------------------------+-------+-------+-------+-------+

| | DAC3 | DAC2 | DAC1 | DAC0 |

+-------------------------------+-------+-------+-------+-------+

There are two interpolators with complex inputs and outputs.

There are four DACs.

Each 4-bit DACx field specifies the source for the DAC and whether or not that DAC is

enabled. Each subfield is coded like this:

3 2 1 0

+-+-----+

|E| N |

+-+-----+

Where E is set if the DAC is enabled, and N specifies which interpolator output is

connected to this DAC.

N which interp output

Simple Gnuradio User Manual Page 160 of 208

--- -------------------

0 chan 0 I

1 chan 0 Q

2 chan 1 I

3 chan 1 Q

Usage usrp.sink_x.set_mux(mux)

Parameters mux : integer

Examples

Note

1.28.2.4) set_tx_freq()

Type Sub Function

Description Set the frequency of the digital up converter, channel must be 0,1and freq is the center

frequency in Hz. It must be in the range [-44M, 44M]. The frequency specified is

quantized. Use tx_freq to retrieve the actual value used.

Usage usrp.sink_x.set_tx_freq(channel,freq)

Parameters channel: which duc channel [0, 1]

freq : double

Examples

Note

1.28.2.5) set_verbose()

Type Sub Function

Description Print usrp configuration

Usage usrp.sink_x.set_verbose(verbose)

Parameters verbose : bool true or false

Examples

Note

1.28.2.6) set_pga()

Type Sub Function

Description Set D/A Programmable Gain Amplifier (PGA). Gain is rounded to closest setting

supported by hardware. Note that DAC 0 and DAC 1 share a gain setting as do DAC 2

and DAC 3. Setting DAC 0 affects DAC 1 and vice versa. Same with DAC 2 and DAC 3.

Return true if sucessful

Usage usrp.sink_x.set_pga(which, gain_in_db)

Parameters which : which D/A [0,3]

gain_in_db : double gain value (linear in dB) in range [0.0,20.0]

Examples

Note

1.28.2.7) pga()

Type Sub Function

Description Return programmable gain amplifier gain setting in dB.

Simple Gnuradio User Manual Page 161 of 208

Usage usrp.sink_x.pga(which)

Parameters which : which D/A [0,3]

Examples

Note

1.28.2.8) pga_min()

Type Sub Function

Description Return minimum legal PGA setting in dB.

Usage usrp.sink_x.pga_min()

Parameters

Examples

Note

1.28.2.9) pga_max()

Type Sub Function

Description Return maximum legal PGA setting in dB.

Usage usrp.sink_x.pga_max()

Parameters

Examples

Note

1.28.2.10) pga_db_per_step()

Type Sub Function

Description Return hardware step size of PGA (linear in dB).

Usage usrp.sink_x.pga_db_per_step()

Parameters

Examples

Note

1.28.2.11) fpga_master_clock_freq()

Type Sub Function

Description Return fpga master clock frequency

Usage usrp.sink_x.fpga_master_clock_freq()

Parameters

Examples

Note

1.28.2.12) converter_rate()

Type Sub Function

Description Return D/A converter rate

Usage usrp.sink_x.converter_rate()

Parameters

Simple Gnuradio User Manual Page 162 of 208

Examples

Note

1.28.2.13) interp_rate()

Type Sub Function

Description Return interpolation rate

Usage usrp.sink_x.interp_rate()

Parameters

Examples

Note

1.28.2.14) nchannels()

Type Sub Function

Description Return number of active duc channels

Usage usrp.sink_x.nchannels()

Parameters

Examples

Note

1.28.2.15) mux()

Type Sub Function

Description Return mux setting

Usage usrp.sink_x.mux()

Parameters

Examples

Note

1.28.2.16) tx_freq()

Type Sub Function

Description Return channels duc frequency

Usage usrp.sink_x.tx_freq(channel)

Parameters channel : which duc channel [0,3]

Examples

Note

Simple Gnuradio User Manual Page 163 of 208

1.28.2.17) daughterboard_id()

Type Sub Function

Description Return daughterboard ID for given Rx daughterboard slot. Slot A =0, Slot B=1.

daughterboard id >= 0 if successful

-1 if no daugherboard

-2 if invalid EEPROM on daughterboard

Usage usrp.sink_x.daughterboard_id(which_dboardl)

Parameters which_dboard : o or 1, Slot number

Examples

Note

1.28.2.18) write_aux_dac()

Type Sub Function

Description Write auxiliary digital to analog converter.

Usage usrp.sink_x. write_aux_dac ( which_dboard, which_dac, value )

Parameters which_dboard : [0,1] which slot , SLOT_TX_A and SLOT_RX_A share the same AUX

DAC's. SLOT_TX_B and SLOT_RX_B share the same AUX DAC's.

which_dac : [2,3] TX slots must use only 2 and 3.

value : in range of [0,4095]

Examples

Note

1.28.2.19) read_aux_dac()

Type Sub Function

Description Read auxiliary analog to digital converter.

Return value in the range [0,4095] if successful, else READ_FAILED.

Usage usrp.sink_x. read_aux_dac ( which_dboard, which_adc )

Parameters which_dboard : [0,1] which slot

which_adc : [0,1]

Examples

Note

1.28.2.20) write_eeprom()

Type Sub Function

Description Write EEPROM on motherboard or any daughterboard.

Return true if successful

Usage usrp.sink_x. write_eeprom(i2c_addr, eeprom_offset, buf)

Parameters i2c_addr : I2C bus address of EEPROM

eeprom_offset : byte offset in EEPROM to begin writing

buf : the data to write

Examples

Note

Simple Gnuradio User Manual Page 164 of 208

1.28.2.21) read_eeprom()

Type Sub Function

Description Read bytes from EEPROM on motherboard or any daughterboard.

Return the data read if successful, else a zero length string.

Usage usrp.sink_x. read_eeprom(i2c_addr, eeprom_offset, len)

Parameters i2c_addr : I2C bus address of EEPROM

eeprom_offset : byte offset in EEPROM to begin reading

buf : number of bytes to read

Examples

Note

1.28.2.22) write_i2c()

Type Sub Function

Description Write to I2C peripheral.

Return true ff successful. Writes are limited to a maximum of of 64 bytes.

Usage usrp.sink_x. write_i2c(i2c_addr, buf)

Parameters i2c_addr : I2C bus address (7-bits)

buf : the data to write

Examples

Note

1.28.2.23) read_i2c()

Type Sub Function

Description Read from I2C peripheral.

Return the data read if successful, else a zero length string. Reads are limited to a

maximum of of 64 bytes.

Usage usrp.sink_x.read_i2c(i2c_addr, len)

Parameters i2c_addr : I2C bus address (7-bits)

len : number of bytes to read

Examples

Note

1.28.2.24) set_adc_offset()

Type Sub Function

Description Set ADC offset correction.

Usage usrp.sink_x.set_adc_offset(which, offset)

Parameters which : which ADC[0,3]:

offset : 16-bit value to subtract from raw ADC input.

Examples

Note

1.28.2.25) set_dac_offset()

Type Sub Function

Description Set DAC offset correction.

Usage usrp.sink_x.set_dac_offset(which, offset, offset_pin)

Parameters which : which DAC[0,3]

Simple Gnuradio User Manual Page 165 of 208

offset : 10-bit offset value (ambiguous format: See AD9862 datasheet).

offset_pin : 1-bit value. If 0 offset applied to -ve differential pin; If 1 offset applied to +ve

differential pin.

Examples

Note

1.28.2.26) set_adc_buffer_bypass()

Type Sub Function

Description Control ADC input buffer.

Usage usrp.sink_x.set_adc_buffer_bypass(which, bypass)

Parameters which : which ADC [0,3]

bypass : if non-zero, bypass input buffer and connect input directly to switched cap SHA

input of RxPGA.

Examples

Note

1.28.2.27) serial_number()

Type Sub Function

Description Return the usrp's serial number. Return non-zero length string iff successful.

Usage usrp.sink_x.serial_number()

Parameters

Examples

Note

1.28.2.28) _write_oe()

Type Sub Function

Description Write direction register (output enables) for pins that go to daughterboard. Each d'board

has 16-bits of general purpose i/o. Setting the bit makes it an output from the FPGA to

the d'board.This register is initialized based on a value stored in the d'board EEPROM. In

general, you shouldn't be using this routine without a very good reason. Using this

method incorrectly will kill your USRP motherboard and/or daughterboard.

Usage usrp.sink_x._write_oe(which_dboard, value, mask)

Parameters which_dboard : [0,1] which d'board

value : value to write into register

mask : which bits of value to write into reg

Examples

Note

1.28.2.29) write_io()

Type Sub Function

Description Write daughterboard i/o pin value.

Usage usrp.sink_x.write_io(which_dboard, value, mask)

Parameters which_dboard : [0,1] which d'board

Simple Gnuradio User Manual Page 166 of 208

value : value to write into register

mask : which bits of value to write into reg

Examples

Note

1.28.2.30) read_io()

Type Sub Function

Description Read daughterboard i/o pin value.

Return register value if successful, else READ_FAILED

Usage usrp.sink_x.read_io(which_dboard)

Parameters which_dboard : [0,1] which d'board

Examples

Note READ_FAILED =-99999

1.28.2.31) _write_fpga_reg()

Type Sub Function

Description Write FPGA register.

Return True if successful

Usage usrp.sink_x._write_fpga_reg(regno,value)

Parameters regno : 7-bit register number

value : 32-bit value

Examples

Note

1.28.2.32) _write_fpga_reg_masked()

Type Sub Function

Description Write FPGA register masked.

Return True if successful

Usage usrp.sink_x._write_fpga_reg_masked(regno, value, mask)

Parameters regno : 7-bit register number

value : 16-bit value

mask : 16 bit mask

Examples

Note

1.28.2.33) _read_fpga_reg()

Type Sub Function

Description Read FPGA registers.

Return register value if successful, else READ_FAILED

Usage usrp.sink_x._read_fpga_reg(regno)

Simple Gnuradio User Manual Page 167 of 208

Parameters regno : 7-bit register number

Examples

Note

1.28.2.34) _write_9862()

Type Sub Function

Description Write AD9862 registers.

Return true if successful

Usage usrp.sink_x._write_9862(which_codec, regno, value)

Parameters which_codec : 0 or 1

regno : 6-bit register number

value : 8-bit value

Examples

Note

1.28.2.35) _read_9862()

Type Sub Function

Description Read AD9862 registers.

Return register value if successful, else READ_FAILED

Usage usrp.sink_x._read_9862(which_codec, regno)

Parameters which_codec : 0 or 1

regno : 6-bit register number

Examples

Note

1.28.2.36) _write_spi()
