ELECTRONIC PRODUCT FORM
Designation CD4
Reference ECDT50000A
Range Separate electronic
Box Material ABS
Colour Beige
Size 112 X 52 X 106 mm
Protection factor against solid IP 40
and splashproof
Supply Nominal 220 - 240 V~
Limits 198 - 255 V~
Frequency 50 - 60 Hz
Consumption Main 7 mA at 230 V~
Fuse accessible by user 3,15 A, 250V~
Output relays 250 V AC, 5 A
Electromagnetic compatibility CEI 1000-4-2 8 kV minimum
CEI 1000-4-3 level III guaranteed
CEI 1000-4-4 level III guaranteed
Temperature range Working 0°C à +40°C
Storing -20°C à +70°C
Rate of relative humidity 90% maxi. with 25°C
Connectors screw / pull-out base
Weight 320 g
CE marking yes
Control of an actuator or a group of actuators by a double push-button and general control by a
Somfy general bus line.
Possibility to connect a "AUTO ON/OFF" selector.
"STOP" function by simultaneously depressing both the "UP" & "DOWN" switch buttons.
DELAY TIME :
08.01.97 DMKI-FPTE ECDT50000A
Outputs
delays Inhibition of the
individual control
impulse control 3 min no
control > 2s or permanent 3 min no
impulse control 3 min no
control > 2s or permanent 3 min yes
Individual control
General control
Switch in the ON position:
Outputs
delays Inhibition of the
individual control
impulse control 3 min no
control > 2s or permanent 3 min no
impulse control no control no
control > 2s or permanent 3 min yes
Individual control
General control
Switch in the OFF position:
MKI
FUNCTIONS
TECHNICAL SPECIFICATIONS
Input : any switch or control system compatible
with the SOMFY general control line.
Output : 130150, 128617/3, RK2, RK3.
Input : any control or control system compatible in
with the SOMFY general control line :
RC9433, SL 2017n, SL 1011n, Chronis IB,
Soliris IB ...
IN THE RANGE IN THE OTHER RANGES
- Do not connect more than one sub-group control level.
- The cable of the bus line must be insulated to 1750V.
WIRING AND CONFIGURATION COMPATIBILITIES INSTALLATION LIMITS
