Test Report.No. CANEC1404758804 A01 Date: 16 Apr 2014 .Page 1 of 5.
EAST SEMICONDUCTOR TECHNOLOGY CO.,LTD .
RM 608,BUILDING 1,YUEHUA INDUSTRIAL PARK,YUEHUA ROAD,SHANG MEI LIN,FUTIAN
DISTRICT,SHENZHEN
CHINA.
This report is to supersede test report CANEC1404758801.
The following sample(s) was/were submitted and identified on behalf of the clients as : IC Integrated Circuit .
SGS Job No. : CP14-016460 - SZ .
Model No. :.SOP-8.
Client Ref. Info. : .SOP-10、SOP-12、SOP-14、SOP-16、SOP-18、SOP-20、SOP-22、SOP-24.
SOP-26、SOP-28、SOP-30、SOT-23、SOT23-5、SOT23-6.
Date of Sample Received : .09 Apr 2014.
Testing Period :.09 Apr 2014 - 14 Apr 2014 .
Test Requested : .Selected test(s) as requested by client. .
Please refer to next page(s). .
Please refer to next page(s). .
Test Method :.
Test Results :.
Signed for and on behalf of
SGS-CSTC Ltd..
Almay Gao.
Approved Signatory .
Test Report.No. CANEC1404758804 A01 Date: 16 Apr 2014 .Page 2 of 5.
Test Results :.
Test Part Description : .
Specimen No..
SGS Sample ID.
Description.
SN1.CAN14-047588.001 Black body w/ brown printing&silvery metal pin(mixed) .
Remarks :.
(1) 1 mg/kg = 1 ppm = 0.0001% .
(2) MDL = Method Detection Limit .
(3) ND = Not Detected ( < MDL ) .
(4) "-" = Not Regulated .
Elementary Analysis & Flame Retardants.
Test Method :.(1)With reference to IEC 62321-5:2013, determination of Cadmium by ICP-OES.
(2)With reference to IEC 62321-5:2013, determination of Lead by ICP-OES.
(3)With reference to IEC 62321-4:2013, determination of Mercury by ICP-OES.
(4)With reference to IEC 62321:2008, determination of Hexavalent Chromium by Colorimetric
Method using UV-Vis.
(5)With reference to IEC 62321:2008, determination of PBBs and PBDEs by GC-MS. .
001.
Cadmium (Cd).mg/kg.2 ND
Lead (Pb).mg/kg.2 ND
Mercury (Hg).mg/kg.2 ND
Hexavalent Chromium (CrVI) .mg/kg.2 ND
Sum of PBBs.mg/kg.- ND
Monobromobiphenyl .mg/kg.5 ND
Dibromobiphenyl .mg/kg.5 ND
Tribromobiphenyl .mg/kg.5 ND
Tetrabromobiphenyl .mg/kg.5 ND
Pentabromobiphenyl .mg/kg.5 ND
Hexabromobiphenyl .mg/kg.5 ND
Heptabromobiphenyl .mg/kg.5 ND
Octabromobiphenyl .mg/kg.5 ND
Nonabromobiphenyl .mg/kg.5 ND
Decabromobiphenyl .mg/kg.5 ND
Sum of PBDEs .mg/kg.- ND
Monobromodiphenyl ether .mg/kg.5 ND
Test Item(s).Unit.MDL.
Test Report.No. CANEC1404758804 A01 Date: 16 Apr 2014 .Page 3 of 5.
Test Item(s).Unit.MDL.
001.
Dibromodiphenyl ether .mg/kg.5 ND
Tribromodiphenyl ether .mg/kg.5 ND
Tetrabromodiphenyl ether .mg/kg.5 ND
Pentabromodiphenyl ether .mg/kg.5 ND
Hexabromodiphenyl ether .mg/kg.5 ND
Heptabromodiphenyl ether .mg/kg.5 ND
Octabromodiphenyl ether .mg/kg.5 ND
Nonabromodiphenyl ether .mg/kg.5 ND
Decabromodiphenyl ether .mg/kg.5 ND
Remark: The sample(s) was/were analyzed on behalf of the applicant as mixing sample in one testing. The
above result(s) was/were only given as the informality value and only for reference. .
Test Report.No. CANEC1404758804 A01 Date: 16 Apr 2014 .Page 4 of 5.
ATTACHMENTS
RoHS Testing Flow Chart
1) Name of the person who made testing: Michael Tso / Cutey Yu
2) Name of the person in charge of testing: Adams Yu / Yolanda Wei
3) These samples were dissolved totally by pre -conditioning method according to below flow chart
(Cr6+ and PBBs/PBDEs test method excluded ).
Sample Preparation
Sample Measurement
Acid digestion with
microwave/ hotplate
Filtration
Solution
Residue
1) Alkali Fusion /
Dry Ashing
2) Acid to
dissolve
ICP-OES/AAS
DATA
Sample solvent
extraction
Filtration
GC-MS
DATA
Nonmetallic
material
Metallic
material
Adding digestion
reagent
Heating to
90~95℃ for
extraction
Filtration and
pH adjustment
Adding 1,5-
diphenylcarbazide
for color
development
UV-Vis
DATA
Spot test
Boiling water
extraction
Adding 1,5-
diphenylcarbazide
for color
development
A red color
indicates the
presence of Cr 6+. If
necessary, confirm
with UV-Vis.
DATA
Positive
Negative
Pb/Cd/Hg
PBBs/PBDEs
Cr6+
Concentration/
Dilution of extraction
solution
Test Report.No. CANEC1404758804 A01 Date: 16 Apr 2014 .Page 5 of 5.
Sample photo:.
CANEC1404758804 A01
CAN14-047588.001 .
SGS authenticate the photo on original report only .
*** End of Report *** .
