SP 3600SF

SP 3610SF

A4 B/W MFP

Printer Copier Scanner Fax

SP 3610SF

30 SPDF

ppm

SP 3600SF

30 ADF

ppm

Compact and durable A4 MFPs for daily use

The SP 3600SF/SP 3610SF offer everything you need for cost-effective black-and-white printing,

copying, scanning and faxing. With an attractive purchase price and low Total Cost of Ownership these

multifunctional devices are a sensible long-term investment. To optimise your office productivity, Ricoh’s

new controller offers outstanding speeds and performance. In addition, these devices fit easily on a

desktop for quick operation and easy maintenance thanks to their small footprint and full front access. In

short, the SP 3600SF/SP 3610SF will help you become even more productive, day in, day out, in an

environmentally responsible manner.

Save money with a low Total Cost of Ownership.

Save space thanks to a compact, small footprint.

Create high quality documents with 1,200 dpi printing.

Easy operation and maintenance.

Reduce your environmental impact: low power consumption.

High productivity; low environmental

impact

Highly productive

Equipped with the latest Ricoh controller, the SP

3600SF/SP 3610SF offer high performance as well

as fit-for-purpose functionality. Your first printout is

ready in just 6.5 seconds, after which these devices

speed along at 30 pages per minute. The single

pass duplex scanner (SP 3610SF) ensures further

productivity. Print resolution on the other hand is a

high 1,200 x 1,200 dpi. To top it off, both devices

are suitable for a duty cycle of 50,000 prints while

@Remote is included as standard and WiFi

connectivity is optional.

Low Total Cost of Ownership

With a competitive price and low Total Electricity

Consumption, the SP 3600SF/SP 3610SF are

attractive purchases for small- to medium-sized

offices. The PxP toner fuses at a lower temperature

than normal, reducing energy costs. Toner

consumption can be limited by using the ‘toner

save’ feature. Running costs are driven down

further thanks to the separate PCDU and toner.

This means you can change them independently,

instead of having to replace the complete all-in-one

cartridge.

Compact and easy to operate

Thanks to their small footprint, the SP 3600SF/SP

3610SF easily fit on any office desktop. Full front

access is guaranteed for trouble-free maintenance.

These devices are also a delight to use thanks to

the 4-line LCD panel and short recovery from

sleep: ready for action in no time!

Environmentally friendly

The Ricoh philosophy is to provide optimal

performance with the lowest environmental impact.

With the SP 3600SF/SP 3610SF’s ultra-sleep and

ECO modes energy consumption and CO2

emissions are reduced to a minimum. During the

design phase, recycled and bio-plastic components

are used wherever possible. In addition, power

consumption during operation is lowest in class and

the use of toner and paper is efficiently managed to

save resources.

SP 3600SF/SP 3610SF

MAIN SPECIFICATIONS

GENERAL

Warm-up time: 19 seconds

First output speed: 6.5 seconds

Continuous output speed: 30 pages per minute

Memory: Standard: 512 MB

Duty cycle: 50,000 prints per month

Dimensions (W x D x H): 400 x 392 x 406 mm

Weight: 19 kg

Power source: 220 - 240 V, 50/60 Hz

COPIER

Copying process: Laser beam scanning and electro-

photographic printing

Multiple copying: Up to 99 copies

Resolution: 600 x 600 dpi

Zoom: From 25% to 400% in 1% steps

PRINTER

Printer language: Standard: PCL5ePCL6Adobe®

PostScript® 3™

Print resolution: 300 x 300 dpi, 600 x 600 dpi, 1,200 x

1,200 dpi

Fonts: PCL (45 fonts, International fonts: 13

Intellifonts), PS3 (136 fonts)

Interface: Standard: USB 2.0Gigabit Ethernet

Option: Wireless LAN (IEEE

802.11a/b/g/n)

Network protocol: TCP/IP (IP v4, IP v6)

Windows® environments: Windows® XP, Windows® Vista,

Windows® 7, Windows® 8, Windows®

8.1, Windows® Server 2003,

Windows® Server 2003R2, Windows®

Server 2008, Windows® Server

2008R2, Windows® Server 2012,

Windows® Server 2012R2

Mac OS environments: Macintosh OS X Native v10.6 or later

SCANNER

Scanning speed: Full colour: A4 (Maximum 6 originals

per minute)

B/W: A4 (Maximum 20 originals per

minute)

Resolution: Standard: 100 dpi200 dpi300 dpi400

dpi600 dpi

Default: 200dpi

Original size: A4

Bundled drivers: Network TWAIN

Scan to: E-mail (SMTP Auth, POP before

SMTP), USB, SMB, FTP

PAPER HANDLING

Recommended paper size: A4

A5

A6

B5

B6

Paper input capacity: Standard: 350 sheets

Maximum: 850 sheets

Paper output capacity: Maximum: 125 sheets

Paper weight: Standard paper tray(s): 52 - 162 g/m²

Optional paper tray(s): 52 - 162 g/m²

Bypass tray: 52 - 162 g/m²

Duplex: 52 - 162 g/m²

ECOLOGY

Power consumption: Maximum: 1,006 W

Energy Saver mode: 1 W

OPTIONS

1 x 250-sheet paper tray, 1 x 500-sheet paper tray, Wireless LAN (IEEE

802.11a/b/g/n)

CONSUMABLES

Starter toner: Black: 1,500 prints

PCU yield: Black: 20,000 prints

Toner cartridge (regular yield): Black: 3,000 prints

Toner cartridge (high yield): Black: 6,000 prints

For availability of models, options and software, please consult your

local Ricoh supplier.
