SP 5300DN

SP 5310DN

B/W Printer

Printer

SP 5310DN

60 B/W

ppm

SP 5300DN

50 B/W

ppm

A powerful yet durable addition to your workspace.

Both the SP 5300DN and SP 5310DN models are the types of fast, reliable, hardworking, everyday

printers that will form the backbone of your company’s document output. In fact, they’re probably both

best described as powerful, efficient and durable workhorses. And although they’re both compact, these

A4 Black and White Printers will quite simply get the job done. An added bonus is their durable design

combined with their class-leading reliability – and their powerful controller and advanced processor

means superfast output too.

Small footprint

Advanced controller and processor

An almost maintenance free device

Print speed options of 50 and 60 ppm

ECO friendly with low power consumption

Working hard. Every day of the week.

All the power, with added control.

With a powerful Intel 1.46 Ghz processor and 2 GB

memory, you can complete even the most complex

of print jobs with the minimum of fuss. And because

all this technology is working in the background, all

you see is your productivity, speed and output

increasing – which helps your business become

even more efficient.

Just keeps on printing.

When your printers are always in use, you need to

have a machine you can rely on. And that’s why

both these models are advanced enough to give

you all the features you want, but robust enough to

simply get every job done. They’re also both

designed to have almost no maintenance –

allowing you to keep your business moving.

Packed full of features.

Thanks to their compact design, you don’t have to

worry about space, or set aside a specific area in

the office. Their small footprint disguises just how

much they can do – and these printers can be

located almost anywhere. You can even print

directly from your phone or tablet, or direct from

mainframes using the IPDS option.

Low energy. Lower costs for your

business.

Ricoh puts the environment first and helps you do

that too. So these printers offer the best

combination of technological features, value for

money and also help you reduce your energy

costs.

SP 5300DN/SP 5310DN

MAIN SPECIFICATIONS

GENERAL

Configuration: Desktop

Technology: Laser

Warm-up time: 21/25.4 seconds

First output speed: 6/6 seconds

Print speed: B/W: 50/60 pages per minute

CPU: Intel Celeron-M: 1.46 GHz

Memory: Standard: 2 GB

Maximum: 2 GB

HDD (Option): 320 GB

Dimensions (W x D x H): 420 x 410 x 345 mm

Weight: 18 kg

Power source: 220 - 240 V, 50/60 Hz

PRINTER

Printer language: Standard: PCL5e, PCL6, Adobe®

PostScript® 3™, PDF

Option: XPS

Print resolution: 1,200 x 1,200 dpi

Interface: Standard: USB2.0 Type A, Ethernet 10

base-T/100 base-TX/1000 base-T

Option: Bi-directional IEEE 1284,

Wireless LAN (IEEE 802.11a/b/g/n),

USB Server for Second Network

Interface

Network protocol: TCP/IP (IP v4, IP v6)

Windows® environments: Windows® 2000, Windows® Vista,

Windows® 7, Windows® 8, Windows®

8.1, Windows® 10, Windows® Server

2003, Windows® Server 2003R2,

Windows® Server 2008, Windows®

Server 2008R2, Windows® Server

2012, Windows® Server 2012R2

Mac OS environments: Macintosh OS X v10.7 or later

PAPER HANDLING

Recommended paper size: Standard paper tray(s): A4, A5, A6, B5,

B6

Bypass tray: A4, A5, A6, B5, B6,

Letter, Half Letter

Paper input capacity: Maximum: 2,600 sheets

Paper output capacity: Maximum: 500 sheets

Paper weight: Paper tray(s): 64 - 120 g/m²

Bypass tray: 60 - 220 g/m²

Duplex: 64 - 120 g/m²

Media capability: Plain paper, Middle thick paper, Thick

paper, Recycled paper, Colour paper,

Letterhead, Pre-printed paper, Thin

paper, Special paper, Label paper,

Envelopes, Bond, Transparencies

SECURITY

Authentication: Windows® authentication, LDAP

authentication, Basic authentication,

User code authentication, 802.1.x

wired authentication, Integration server

authentication, SMTP authentication,

POP before SMTP

Network security: Disable/Enable ports and protocols,

SSL support, SNMPv3 support

ECOLOGY

Power consumption: Maximum: 1.4 kW

Ready mode: 80.4/75.1 W or less

Sleep mode: Less than 0.63/0.68 W

TEC (Typical Electricity Consumption):

2.6/3.1 kWh

OPTIONS

1 x 500-sheet paper tray, Caster table

CONSUMABLES

Toner capacity: Black: 25,000 prints

Declared yield value: Declared yield

value in accordance with ISO/IEC

19752

Starter kit: 10,000 prints

For availability of models, options and software, please consult your

local Ricoh supplier.

ISO9001 certified, ISO14001

certified, ISO27001 certified
