S2-7 GND
S2-20 DTR
S2-6 DSR
S2-5 CTS
S2-4 RTS
S2-2 TXD
S2-3 RXD
25 PIN "D" RANGE
TO COMPUTER
VOUT (2)VIN (3)
GND (1)
R1 1k
C1 1yF
C3 10yF
C4 10yF
C5 10yF
C6 10yF
C2 10yF
(16) +ve
(1) C1+
(3) C1-
(4) C2+
(5) C2-
(2
) V+
(6
) V-
(11) T1 in
(10) T2 in
(12) R1 out
(9) R2 out
(15) GND
(7) T2 out
(8) R2 in
(14) T1 out
(13) R1 in
11 12V+
9 -Ve
12 RX
data
4 TX
data
15 pin "D" range female
IC2
MAX
232
T700 PROGRAMMING LEAD
FILE NAME = T700 PROGRAMMING LEAD CCT.doc
IC1
78L05
