Applicability This technical note applies to all current Tait mobile radios in the T2000 product range.
1. Introduction
This document is designed to provide support for servicing and fault diagnosis of
Tait mobile radio (T2000) product.
Tait radios have an inbuilt software diagnostic tool that will indicate error codes if there is
a failure in the software or hardware platforms.
When a system error occurs, normal operation of the radio ceases and the software then
enters an error mode to display the error number on the front panel.
Error codes can also be viewed in Terminal application format (via serial interface) if
appropriate.
It should be noted that system errors are reported out of the serial port as Cnn for
software errors, and Xnn for hardware errors. (Where nn = error number).
(Refer to TN -1011 Terminal Application operation for more information).
Outlined below is code numbering and description for system errors.
Applicable model numbers are given in the left-hand column for code variants.
It should also be noted that error codes can occur for any number of reasons, therefore
no suggestions are provided as to what the specific cause of any given error may be.
2. Code Definitions
HEAP_OVERLAP_ERROR: ERROR 1
HEAP_EXHAUSTED_ERROR: ERROR 2
INVALID_HEAP_ADDRESS_ERROR ERROR 3
INVALID_TASK_NUMBER_ERROR: ERROR 4
INVALID_TIMER_NUMBER_ERROR: ERROR 5
(T2020) INVALID_TIME_ERROR: ERROR 6
(T2040) TASK_QUEUE_ERROR : ERROR 6
INVALID_MESSAGE_CATEGORY_ERROR: ERROR 7
INVALID_MESSAGE_PATH_ERROR: ERROR 7
INVALID_MESSAGE_CODE_ERROR: ERROR 8
INVALID_MESSAGE_TYPE_ERROR: ERROR 8
SOFTWARE_INTERRUPT_ERROR ERROR 9
INVALID_QUEUE_NUMBER_ERROR: ERROR 10
(T2020) INVALID_USER_CHAR_ERROR: ERROR 11
(T2040) INVALID_TASK_SUSPENSION: ERROR 11
INAPPROPRIATE_TASK_TYPE_ERROR: ERROR 12
ILLEGAL_OPCODE_ERROR: ERROR 13
XIRQ_INTERRUPT_ERROR: ERROR 14
CANT_CREATE_ANY_MORE_TIMERS_ERROR: ERROR 15
CANT_CREATE_ANY_TIMERS_ERROR: ERROR 16
TIMER_DOES_NOT_EXIST_ERROR: ERROR 17
TIMER_ALREADY_EXISTS_ERROR: ERROR 18
INVALID_TIMER_VECTOR_ERROR: ERROR 19
INVALID_PARAMETER_ERROR: ERROR 20
INVALID_PROGRAMMING_ERROR: ERROR 21
TECHNICAL NOTE TN-1007
T2000 System Error Codes
12 April 2005
Tait Confidential Tait Electronics Ltd
Telephone:+64-3-357-9991 TN-1007_T2000ErrorCodes.doc
support@taitworld.com
http://support.taitworld.com Date of Print: 24/05/05 Page 2 of 3
(T2020) TASK_QUEUE_ERROR: ERROR 22
(T2040) TRANSMISSION_TIMEOUT: ERROR 22
RAM_EXCEEDED_ERROR: ERROR 23
(T2020) TEST_MODE_RESET_VECTOR_INCORRECT: ERROR 24
(T2040) INVALID_CALL_RERROREST ERROR 24
TASK_SUSPENSION_CALL_ERROR: ERROR 25
FLASH_DATA_CORRUPTION_ERROR: ERROR 26
Signalling System Errors (30-39)
(T2020) INVALID_DTMF_TONE_NUMBER_ERROR: ERROR 30
(T2040) RECEIVED_CODEWORD_CRC_NOT_COMPLETE: ERROR 30
(T2040) FFSK_TRANSMIT_TIMING_ERROR: ERROR 31
(T2040) INVALID_FFSK_TX_INTERRUPT: ERROR 32
(T2040) TRANSMIT_CODEWORD_CRC NOT_COMPLETE: ERROR 33
(T2040) SYNTHESISER_NOT_LOCKED: ERROR 34
Personality Module errors (40-49)
(T2020) STRING_BUFFER_OVERFLOW_ERROR: ERROR 40
(T2040) INVALID_MESSAGE: ERROR 40
(T2020) TX_COMM_BUFFER_ERROR: ERROR 41
(T2040) INVALID_PERSONALITY ERROR 41
INVALID_DATA_ERROR: ERROR 42
INVALID_DISPLAY_CHARACTER_ERROR: ERROR 43
INVALID_LOGON_STATUS: ERROR 44
Functionality Module Errors (50-59)
(T2020) FUNCTION_NOT_SUPPORTED_ERROR: ERROR 50
(T2040) INVALID_TIMER_NUMBER: ERROR 50
INVALID_MESSAGE_DATA: ERROR 51
INPUT_STRING_STORE_OVERFLOW: ERROR 53
INVALID_DISPLAY_MODE: ERROR 56
INVALID_DATA ERROR 59
Unused (60-67)
(T2040) INVALID_TRUNKING_PERSONALITY_MODE: ERROR 60
(T2020) FLASH_PERSONALITY_INVALID_ERROR: ERROR 63
Input Output module errors
(T2020) INVALID_CHANNEL_NUMBER_ERROR: ERROR 68
(T2040) INVALID_CHANNEL_BARRING: ERROR 68
(T2020) CHANNEL_BLOCK_CALCULATION_ERROR: ERROR 69
Interface System Errors (70-79)
(T2020) SYNTH_FREQ_NUM_TOO_BIG_ERROR: ERROR 70
(T2040) INVALID_CHANNEL_NUMBER: ERROR 70
(T2020) ILLEGAL_TRANSMITTER_POWER_LEVEL_ERROR: ERROR 71
(T2040) CHANNEL_BLOCK_CALCULATION_ERROR: ERROR 71
(T2040) IN_OUT_DATA_ERROR: ERROR 73
(T2040) UNPROGRAMMED_DYNAMIC_DATABASE_ITEM: ERROR 75
(T2040) NON-EXISTANT_GROUP_ADDRESS: ERROR 76
(T2040) INVALID_PRESET_CALL_STRING: ERROR 77
Tait Confidential Tait Electronics Ltd
Telephone:+64-3-357-9991 TN-1007_T2000ErrorCodes.doc
support@taitworld.com
http://support.taitworld.com Date of Print: 24/05/05 Page 3 of 3
Interface System Errors (80-89)
RX_OVERRUN_ERROR: ERROR 80
AUDIO_TONE_FUNCTION_ERROR: ERROR 81
INVALID_AUDIO_TONE_NUMBER_ERROR: ERROR 82
CCI_RX_BUFFER_OVERFLOW_ERROR: ERROR 83
Hardware Errors (90-99)
HARDWARE_ERRORNUM_BASE: ERROR 90
INVALID_AUDIO_TONE_PARAMETER: ERROR 92
SERIAL_FLASH_DETECT_ERROR: HARDWARE_ERRORNUM_BASE+00
SERIAL_FLASH_TIMEOUT_ERROR: HARDWARE_ERRORNUM_BASE+01
CSO Instruction “Commercial Information in Strictest confidence. Not for information of
persons other than direct Employees of Tait Electronics”
Compliance Issues None
