Understanding Azure
A GUIDE FOR DEVELOPERS
2
There is no time better to be a developer. With the cloud,
you can compose solutions that were never possible
before. You can release new features to millions of users within
minutes. You can push the boundaries of current technological
limitations in days. Developers can turn ideas from the ground
up to successful businesses in only months. Companies need
apps that allow them to maximize customer engagement and
dierentiate against competitors. Teams must have agility with
app development for faster time to market. Developers need
a exible platform to scale up and down based on business
demands, yet rock-solid resources that can withstand failure.
Microsoft Azure oers a cloud platform designed for developers
to build the most innovative apps.
This guide breaks down the “why” and “how” for scenarios
suited to the cloud with a focus on building apps using platform
services available in Microsoft Azure. The second half of the
guide showcases the breadth and depth of the Azure platform
and services designed to help developers make truly competitive
and dierentiated applications.
The intended audience for this guide includes:
• Developers wanting to understand why Azure is the best
cloud platform for creating applications and how to get
started quickly based on the app you want to build today.
Technical leaders considering Azure to support new or
existing application development.
Abstract
PUBLISHED BY
Microsoft Corporation
One Microsoft Way
Redmond, Washington 98052-6399
Copyright © 2016 by Microsoft Corporation
All rights reserved.
This document is provided “as-is.” Information and views expressed in this
document, including URL and other Internet Web site references, may change
without notice. You bear the risk of using it.
Some examples are for illustration only and are ctitious. No real association is
intended or inferred.
This document does not provide you with any legal rights to any intellectual
property in any Microsoft product. You may copy and use this document for your
internal, reference purposes.
3
Table of Contents
Abstract .......................................................................................................... 2
Table of Contents ...................................................................................... 3
Overview ........................................................................................................ 4
Introduction ............................................................................................. 4
The Changing World of App Development ...................................... 4
Azure—the Cloud Platform Designed for You, the Developer ..... 5
Summary ................................................................................................ 8
Common Cloud App Scenarios ............................................................ 9
Scenario 1: Building a Web App .......................................................... 9
Scenario 2: Building a Mobile App Back end ................................... 16
Scenario 3: Building an Internet of Things (IoT) App .....................20
Scenario 4: Building a Custom Microservice-based App ...............23
The Azure Platform Services .................................................................. 25
App Service .............................................................................................. 25
Azure Service Fabric ..............................................................................26
Cloud Services ......................................................................................... 27
Azure Functions ...................................................................................... 27
Building on IaaS .......................................................................................... 29
Docker and Containers ........................................................................ 30
Adding Superpowers to your Apps .................................................... 31
Database Services .................................................................................. 32
Developer Services .................................................................................33
Identity ......................................................................................................34
Advanced Analytics & IoT ....................................................................35
Integration ...............................................................................................37
Media Services & CDN .........................................................................38
Conclusion ....................................................................................................39
Recommended next steps ....................................................................39
4
Introduction
The cloud is changing expectations. Your customers expect
more. Your business expects more. You expect more.
Companies you already know, such as Uber and Facebook,
were born in the cloud, and almost every industry sector is
adopting the cloud to drive business growth. These companies
move faster, deliver more value, and meet our ever-changing
needs more eectively than those constrained by more
traditional approaches. They nd new ways to use the exibility
of the cloud to their advantage. They design ways to almost
innitely scale out and gain deeper insights into their customers
that other companies can only dream about.
Now you want to move to the cloud, too. And you’re
wondering how to go about it. You want the benets, but
where do you start and how do you avoid the pitfalls that
cloud pioneers faced?
British computer scientist David Wheeler famously said, “All
problems in computer science can be solved by another layer
of indirection.And indeed, once companies gured out how
to massively scale while controlling costs, it was just a matter
of time before that layer would come to cloud computing.
That layer is the application platform—and it’s here today.
You can still control the maintenance, scaling, and redundancy
Overview
of your application across a farm of commodity servers that
expands and contracts to suit your needs. But now you can
deploy on a platform that handles all that for you. This is the
second wave” of cloud computing— where you focus on
delivering the innovation your customers demand, not the
infrastructure required to run it.
This guide is an introduction to the Azure application platform.
It will provide the guidance and direction you need to start
building new applications or moving your existing applications
to the cloud.
The Changing World of App
Development
In the beginning, there were physical machines. They were
expensive and developers loaded them up with multiple
applications to save costs. This caused no end of conicts
and unexpected bugs, yet eective machine utilization was
still low. Developers struggled to make sure changes to one
application didn’t break an unrelated application.
Then came virtual machines. Since multiple virtual machines
could be run on a single physical box, developers installed
their applications in contained virtual machines, which
reduced conicts and improved utilization, but welcome to
5
shared memory and unpredictable performance. And since
provision had to be made for the largest loads, “scaling in”
wouldn’t really save money.
Enter the cloud. Suddenly, companies could rent the virtual
machines they needed, when they needed them. They could
scale applications up and down on demand. You still needed
to install and congure OS level patches and updates, and
you still had to contend with low-level networking. Still,
hundreds of companies adopted infrastructure as a service
(IaaS) and successfully leveraged the flexibility to
dramatically improve speed to market and scalability while
controlling costs. But most of the benets of this model
accrued to operations and infrastructure, not app
development. As more companies realize that app
innovation needs to move faster than ever because of
customer and competitive demand, focus is shifting from
traditional infrastructure cost savings to how to make app
development more productive.
Azure—the Cloud Platform
Designed for You, the Developer
The history of Microsoft is a history of developers. No other
cloud provider is as steeped in development and developers
as Microsoft. A BASIC interpreter was the very rst Microsoft
product back in 1975, and we have relentlessly focused on
the needs of developers since. We don’t just build the
world’s best platforms and developer tools, we use them
ourselves to build software and services for our customers.
And we didn’t just build the world’s most developer-friendly
cloud, we use it ourselves. We are a cloud-rst company,
focusing on building next gen products and services for
the cloud. Our services need to be always on, scale to
millions of users, and update seamlessly with new
capabilities. Just like our customers, we need an application
platform to work hard for us. We designed Azure to
accelerate developer productivity.
So what dierentiates a developer platform from an
infrastructure platform?
It’s pretty simple, there are tiers of responsibility with benets
and tradeos between them. For example, to use a car analogy,
if you own a car you have to go through the purchase process,
buy insurance, maintain and service it over a long period of
time, and provide parking or garaging.
If you’re renting a car, you get the benet of a car at your
disposal for a xed time period without any of the overhead
of ownership. And, of course, an Uber or a taxi is likely to be
the most aordable option, but can have limits on exibility—
Overview
Uber
Rental Car
Own your
own car
Alaska Airlines needed to make an internal web app
to book standby travel available to mobile employees
outside of the corporate rewall. Developers took the
existing logic and moved the application to Azure App
Service, created a mobile front end with Xamarin, and
made the app available to employees in record time.
More about Alaska and Azure
6
you might have to wait ve minutes, or maybe stand out in
the rain waiting for a ride.
You can get more from your scarce developer time by using
an application platform that removes complexity and
maintenance responsibility. There might be some tradeo
considerations around exibility, but overall, you can get
more done faster and with lower total cost of ownership
building on platform as a service (PaaS).
(There are still some situations where it makes sense to build
apps on IaaS that we’ll discuss later.)
Let’s get down to the details with a short tour through the main
Azure platform services, explain where and when you might
use them, then we’ll guide you through some common customer
app scenarios that will help you make the best design decisions.
App Service—Web and Mobile Apps
Azure App Service is a set of services that
has everything you need to build apps that
target both web and mobile clients from a
single app back end. Supporting a range of
language options—.NET, Node.js, Java, PHP,
and Python—it consists of Web Apps, Mobile Apps, Logic Apps,
and API Apps. Web Apps and Mobile Apps provide back-end
services for web and mobile applications. API Apps allow you
expose APIs that can be securely consumed by any application
and connect your app to dozens of popular services, like Oce
365 and Salesforce.com. And Logic Apps let you automate
business processes and coordinate workows using tools ranging
from a no-code experience to the full power of Visual Studio.
Fully integrated DevOps allow you to deploy app updates with
Overview
built-in staging, roll-back, testing-in-production, and
performance testing capabilities. You can monitor all aspects
of your apps in real time and historically with detailed operational
logs. App Service handles the underlying infrastructure, removing
the need for you to maintain and patch your infrastructure.
When to use it
App Service is the preferred option for building web or mobile
back ends because it provides the productivity, scale,
performance, and deployment options for most requirements.
Use App Service when you want to focus on building unique
features for your app and need the infrastructure to just
work. Additionally, it’s great for building an API layer which
can be exposed to customers, partners and employees
securely using the related API Management service. You can
use App Service in conjunction with the many other Azure
services (Redis Cache or Azure Trac Manager, for instance)
to quickly build and deploy powerful apps.
Jet.com needed to innovate extremely rapidly to build
an eective e-commerce platform. Starting from a
blank canvas they could choose any platform, and
thanks to Microsoft Azure and its rich application
platform services, the company was able to release in
12 months instead of two years.
More about Jet.com and Azure
7
Service Fabric—Microservice Based Apps
Azure Service Fabric is a platform that
developers and ISVs can use to build and
manage custom microservice-based
applications at cloud scale and with 24x7
availability. Microservices are an
architectural approach based on ne-grained, loosely coupled
services that can enable advanced developer agility, cloud
scale, self-healing resilience and always on availability. Service
Fabric is the foundation for many Microsoft services such as
Azure SQL Database, Azure Document DB, Cortana, Windows
Intune, and Skype for Business. We’ve taken the exact same
technology and made it available to you. And use Service
Fabric wherever you want to run your microservice based
apps—whether in Azure, in your own datacenter or in other
clouds—giving you maximum exibility.
When to use it
The primary Service Fabric scenario is for building highly
scalable, always on services that can be updated with zero
downtime (like the Microsoft rst party services mentioned
previously). Use Service Fabric when you are creating a new
app or re-writing an existing app to leverage microservices,
have committed to a cloud-rst architecture, and require
rolling version updates with no downtime, distributed
scalability and high performance, and low-latency data read
and write.
Cloud Services – Monolithic Apps
Azure Cloud Services was the original
Microsoft platform as a service (PaaS)
service launched in 2010. Inspired by the
needs of developers, Cloud Services
enabled them to easily deploy .NET
applications, taking advantage of cloud infrastructure like
Virtual Machines and Virtual Networks without having to
manage the low-level details and conguration of Windows
Server and the underlying infrastructure.
When to use it
Cloud Services is an eective solution when you need
direct access to the underlying infrastructure or need to
congure Internet Information Services (IIS) directly. Like
App Service, you don’t need to deal with patching or
updating the underlying OS. Cloud Services is sometimes
used to migrate existing web apps with dependencies on
IIS congurations or required third party components—it
provides autoscaling while still allowing for many developer-
focused platform benets. Since Cloud Services was
introduced, design options have evolved signicantly. App
Service and Service Fabric reect a more modern approach
to PaaS that you should consider as the foundation for
your application development.
Azure Functions—Event Driven Execution
Azure Functions provides serverless,
compute for event-driven solutions that
extends the existing Azure application
platform with capabilities to implement
code triggered by events occurring in other
Azure services, SaaS products (like Oce365 and Salesforce.
com), and on-premises systems. With Functions, you only pay
while your function is actually executing. It provides an intuitive,
browser-based user interface allowing you to create scheduled
or triggered pieces of code implemented in a variety of
programming languages.
When to use it
When you want to create independent, unattended functions
that respond to events across Azure, SaaS products and your
on-premises services. Use them to add housekeeping or
value-add features to your application without directly
requiring a modication of your codebase. For instance, if
your family-friendly site allows people to post their own
photos, you could add an Azure Function that listens to the
storage area for new photos and uses some of the advanced
Azure APIs to identify images that contain inappropriate
Overview
Containers
Containers are top of mind for developers, enabling
you to run your apps anywhere with agility and
eciency. Microsoft is working closely with partners
like Docker and Mesosphere to oer solutions in
this space. Containers are often use in the IaaS layer
but are also popular for implementing microservices
based solutions like Service Fabric. Read more about
Docker and Containers and Azure Container Service
in this guide.
8
content to replace the photo with a redacted version. All
this can be achieved with no code changes at all to your
existing application—it can be deployed completely
independently with no impact on the existing application.
Summary
As a developer, you’re always curious about new technology.
You want to experiment with new and interesting ideas to
make your apps better or create new apps. Previously, you
had to do much of the heavy lifting yourself—writing your
own capabilities or recreating a feature or service for every
app you wrote.
But now you can implement modern solutions in a few lines
of code. In addition to a rich application platform, Azure has
powerful services like machine learning, mobile engagement
and analytics, and notications ready for you to plug into
your app and be on your way. You can always write your own
mobile notication service, but why not take advantage of
pre-built platform services and spend your time on the
features that make your app great?
On Azure, you’ll nd open source and cross-platform support
across the broadest selection of programming languages,
frameworks, tools, databases and architectures allowing you
to realize the maximum reach for every line of code. Write
once, run anywhere has been an industry mantra forever, but
with Azure you have unparalleled options through products
like Azure Stack that allow you to run your code in more places,
unchanged. You bring the tools you love and skills you already
have, and run virtually any application, using your data source,
with your operating system, on your device.
The modern developer is a solution composer, combining
custom code with the best of nished services to create apps
that were unimaginable not so long ago. And delivering those
applications at amazing speed. Companies around the world
are using Azure to build new apps and extend existing apps
to support and transform their business. How can you be next?
Overview
TalkTalk TV, the U.K.s third largest cable TV provider,
chose to redesign parts of their IaaS application to a
take advantage of a microservices architecture with
Azure Service Fabric. The new content management
and resolution platform allowed them to achieve faster
delivery cycles and maintain uptime during upgrades
More about TalkTalk and Azure
9
You’re ready to move to the cloud. You want the benets,
but are unsure where to start. The following scenarios are
designed to give you a jumping-o point using common
app workloads that many customers have.
Note: Be sure to download the latest version of the Azure
SDK. Check out this link to nd all available downloads.
Scenario 1: Building a Web App
Building a web app is maybe the most common app pattern.
In this section we’ll look at how to migrate, scale, and secure
an existing web app.
A. Building a Simple Web App
Overview
You have an internal line-of-business application with a web
front end and a relational database back end. The application
doesn’t need to scale to millions of users, but is a critical
component of your business. Currently, it’s accessed only
inside the rewall, but you’d love it if people could reach into
the application from outside the LAN while still maintaining
good security principles.
Common Cloud
App Scenarios
The problem
Hosting an application yourself imposes very real, but
somewhat hidden, costs. Some of these costs may include
manually deploying updates, patching operating systems,
and using VPN connections required outside of the rewall.
The cost is not overwhelming and is likely hidden in the
overall budgets and current assigned workloads. But that
doesn’t make it any less real.
The solution
For this type of application, moving to Azure is relatively easy,
and the benets can be large. When on-premises, developers
may need to work with infrastructure teams whenever new
versions of the application need to be rolled out to validate
that the application won’t interfere with other, potentially more
critical applications. In Azure, developers can deploy updates
earlier and more often using continuous deployment with
on-premises and online version control systems like TFS,
GitHub, BitBucket, and Visual Studio Team Services.
Services Used
Web Apps
SQL Database
Azure Active Directory
10
Patching operating systems is a necessary task. Poorly
managed infrastructure can have serious security
consequences or software implications. In Azure, the machines
that sit under Azure Web Apps are automatically patched
and managed for you.
Accessing company websites that require authentication
outside of a rewall requires some form of a VPN connection.
In Azure, integrating Azure Active Directory with your on-
premises Active Directory can enable users to connect with
their same credentials and even use multi-factor authentication
without the need for a VPN connection.
The how
Instinctively, you might consider shifting your virtual machines
into Azure, setting up SQL Server, and conguring IIS. It may
take more time for you to congure everything just the way
you want, but you have the control to do so. Your team will
need to be in charge of patching, maintenance, and
administration. This lift-and-shift model gives you the same
functionality that you would expect from on-premises
deployments. It may even be the fastest way to get to the
cloud. But the cost and resource requirements are probably
similar to your on-premises solution, just hosted in the cloud.
Instead, you can bypass virtual machines and use an Azure
Web App in App Service to host your web app, Azure SQL
Database for your database, and secure your web app by
using Azure Active Directory. This means you can take
advantage of continuous deployment options to get up and
running faster and maintain your app over time.
Hosting a web app in the cloud
Whether your app is written in .NET, Java, PHP, Node.js, or
Python, you can deploy your web app to an Azure Web App
in App Service. You can manage multiple Web, Mobile, API,
and Logic Apps in App Service. For most web application
needs, App Service is the answer.
Deploy, copy, or migrate your web app to an Azure
Web App.
Upload an SSL certicate and congure a custom domain
name to the Web App.
Deploy to the Web App repo continuously through
BitBucket, TFS, GitHub, or Mercurial.
You can set up Azure Active Directory to sync with your
organization’s on-premises Active Directory and connect
users to the web app through Windows authentication
outside of the rewall.
• Download and install Azure AD Connect to integrate on-
premises identities.
Congure features of Azure AD Connect, such as ltering
or password synchronization.
Activate directory sync for Azure Active Directory in the
portal.
Enable authentication with Azure Active Directory for the
Web App and Azure SQL Database in the Azure
Management Portal.
Storing data in the cloud
Azure SQL Database is a managed relational SQL database-
as-a-service (DBaaS) solution in Azure – and distinct from
SQL Server running on Azure Virtual Machines. You don’t
have to manage any virtual machines, operating systems,
database software, or worry about upgrades, high availability,
and backups. In general, Azure SQL Database can dramatically
increase the number of databases managed by a single IT
or development resource.
Deploy to SQL Database using SQL Server Management
Common Cloud App Scenarios
Pro Tip
Implement staged deployment to swap staging
and production slots of your web apps with zero
downtime, and run A/B testing in production with
a congurable fraction of your live trac.
11
Studio, export the database to a BACPAC le then import
or use BCP, or use SQL Server transaction replication with
minimal downtime.
Once the database is up in Azure, connect to it the same
way you did on-premises through SQL Server
Management Studio.
Copy the connection string and place it into the connection
strings area for the Web App in Azure or other resources
that connect to it.
Architecture diagram
Additional resources
Deploy your app to Azure App Service
Continuous delivery to Azure using Visual Studio
Team Services
Integrating your on-premises identities with
Azure Active Directory
SQL Server database migration to SQL Database in
the cloud
Azure Web App Azure Active Directory
Azure SQL Database
Common Cloud App Scenarios
12
B. Scaling a web app
Creating a simple web app in Azure is easy enough, but any
growing company wants to be able to scale and provide
global reach for their web apps.
The solution
To scale your Azure Web App in App Service, you only need
to slide a horizontal bar to increase the instance count of
the web apps available. But you also want a consistent
experience for all users, whether your customer is at an
Internet café in Rabat or in a hotel in Mexico City. Choose
an Azure datacenter where your web app and database get
deployed, and Azure Trac Manager will route users to the
instance of your app closest to their location. Geographic
expansion is a priority for Azure with support for new regions
being added over time.
The how
One way to achieve scalability and availability is through
virtual machines, load balancers and redundant resources.
However, if you want your web app to always be available,
you need to pay for the virtual machine and replicas to be
always available.
In the same way that App Service removes the burden of
managing infrastructure it also makes it easier to scale out.
Use an Azure Web App to host your web app, the database
in Azure SQL Database, and use Azure Trac Manager to
route users to copies of the web app globally. Enable Active
Geo-Replication in SQL Database for synchronizing replicas
of databases. Use Azure Redis Cache to improve performance
by loading frequently accessed data and state information.
Scaling and replicating an application
Azure Web Apps allows you to scale the maximum number
of instances of your app up and down with a slider bar. Set
a schedule for scaling up/down (such as during business
hours) or set a target CPU percentage and Azure will handle
the rest. Then quickly deploy the same code to Web Apps
around the world.
Deploy, copy, or migrate your web app to an Azure Web
App in App Service.
Set scheduled times for auto-scaling the web app up or
down or choose to scale by CPU load.
Create at least one other Web App in another region.
If pointing to another database, update the connection
strings.
Azure Web Apps already provides failover and round-robin
trac routing functionality for Web Apps within a datacenter.
Trac Manager allows you to specify failover and round-
robin trac routing for Web Apps in dierent datacenters.
Routing global users to a web app
Azure Trac Manager allows you to control the distribution
of user trac to your specied endpoints, such as Web Apps.
The service applies an intelligent policy engine to Domain
Name System (DNS) queries for the domain names of your
Internet resources so that you can run your web apps in
datacenters anywhere.
Create a unique Trac Manager prole and choose the
load balancing method.
In the Endpoints tab, add the Web App to point to.
Set the monitoring settings for the Trac Manager prole
to ensure that the endpoints are available. You can specify
the protocol, the port, and the relative path.
Services Used
Web Apps
SQL Database
Trac Manager
Azure Redis Cache
Common Cloud App Scenarios
13
Point your company domain name to a Trac Manager
domain name.
Storing data across the world
Azure SQL Database is distinct from SQL Server in an Azure
Virtual Machine because it provides Active Geo-Replication.
Active Geo-Replication asynchronously replicates committed
transactions from a database to up to four copies of the
primary database on dierent servers. Use this feature for
disaster recovery or use an online secondary readable
database as a load balancer for read-only workloads serving
clients distributed across several regions.
Deploy your database to SQL Database using SQL Server
Management Studio, export the database to a BACPAC
le then import or use BCP, or use SQL Server transaction
replication with minimal downtime.
Scale to the Premium service tier to choose the location
where the SQL Database is replicated.
In Geo-Replication, add at least one secondary database,
the target region, and target server.
Boosting an application’s responsiveness
Azure Redis Cache is based on the popular open-source
Redis cache, an advanced key-value store that lets you operate
on values (strings, hashes, lists, sets, and sorted sets) and
has master-subordinate replication and other performance-
boosting features. This separate, distributed cache layer
allows your data tier to scale independently for more ecient
use of compute resources in your application layer.
Create the cache and congure the cache client.
Pro Tip
Learn how the viral site “How-Old.NET” was
created and scaled with Trac Manager in this
Azure Friday session.
Common Cloud App Scenarios
Connect to the cache and store the credentials in the
connection strings area in the Web App.
Add and retrieve objects from the cache and specify
expiration of items in the cache.
Enable cache diagnostics to monitor the health of the cache.
Architecture diagram
Additional resources
About Trac Manager Monitoring
Active Geo-Replication for Azure SQL Database
How to use Azure Redis Cache
14
C. Isolating a web app
Many companies are faced with the requirement of securing
apps that hold personally identiable information (PII). A
simple web app hosted publicly in Azure might not meet
your security requirements. Instead, you need a locked-down
environment with one door to the outside world and active
defenses against potential threats.
The solution
If your organization hosts highly sensitive information, the
number-one priority is having a fully-isolated and dedicated
environment for only your organization’s applications. Using
an App Service Environment, your organization can have
security and isolation for your web apps and use a virtual
network for control over trac. From a single open port, one
option to block most trac would be a product like Barracuda
Web Application Firewall to protect your App Service
Environment. Connect to on-premises resources with a site-
to-site VPN or with Azure ExpressRoute.
The how
One option to host your application in Azure in an isolated
way is to deploy the existing web app and database into an
Azure Virtual Machine surrounded by an Azure Virtual Network.
It would be fast to deploy, but you would need to patch and
maintain those machines, likely the very same issues you have
to deal with today.
Another option is to use an App Service Environment,
surrounded with an Azure Virtual Network. Open one port to
the public and use a product like Barracuda Web Application
Firewall in front of the App Service Environment so that only
approved users can access the apps in the environment. This
option gives you the most exibility in scaling up and down
resources that are locked down in an isolated environment,
while being able to take advantage of the rich features of App
Service apps.
Isolating a web app in the cloud
An App Service Environment is a premium service plan option
of Azure App Service that provides a fully isolated and dedicated
environment. App Service Environments are isolated to run
only a single customers applications and are always deployed
into an Azure Virtual Network. At a high level, an App Service
Environment consists of compute resources running in the
Azure Hosted Service, Storage, Database, a Virtual Network,
and a subnet with the hosted service running in it.
To host an Azure Web App in an App Service Environment,
create the App Service Environment rst and then add the
Web App into it.
Create an App Service Environment and choose the Virtual
Network, scale of the front end and worker pools, and
specify the instance counts and number of IP addresses
to use.
Set up alerts for monitoring CPU and memory for the App
Service Environment.
Add or remove IP addresses to your App Service Environment
for your apps to use.
Specify auto-scaling individual worker pools based on
metrics or schedule.
Create a new Azure Web App and add it to an existing App
Service plan or create a new plan in the App Service
Environment.
Services Used
Web Apps
App Service Environment
A third party rewall
Virtual Network
Optional: ExpressRoute
Common Cloud App Scenarios
Web App
15
If creating a new App Service plan, select the App Service
Environment and a worker pool.
Protecting a web app in the cloud
You can use a third party web application rewall (WAF) that
helps secure your web apps by inspecting inbound web trac
to block malicious requests. Many of these rewalls also
inspect the responses from the back-end web servers for
data loss prevention (DLP). Combined with the isolation and
additional scaling from App Service Environments, this
provides an ideal environment for securing apps. The WAF
is hosted on an Azure Virtual Machine, and you may consider
deploying at least two instances of the virtual machines for
redundancy and no single point of failure.
Create and deploy the Barracuda Web Application Firewall
(or similar rewall) and assign it a static IP address.
Add HTTP and HTTPS endpoints that are used by your
Azure Web App.
Congure your rewall through its Management portal
(adding and removing TCP/8000).
Congure the rewall to protect your Web App.
Create a network security group and assign it to a subnet
in your Azure Virtual Network to restrict trac to the
App Service Environment from the WAF only by using
the VIP address.
Accessing on-premises resources securely
To access on-premises resources, you can either use a site-
to-site VPN with the Azure Virtual Network that surrounds
the App Service Environment and the rewall, or you can
add Azure ExpressRoute to the virtual network for a larger
pipe to transfer data between resources.
If using a site-to-site VPN, add a gateway subnet to the
Azure Virtual Network, add your local site, request a public
IP for the gateway, create the gateway IP addressing
conguration, create the gateway, congure your VPN
device, and create the VPN connection.
Common Cloud App Scenarios
If using ExpressRoute, create and modify a circuit and
routing conguration, and link and congure a Virtual
Network for ExpressRoute.
Architecture diagram
Additional resources
App Service Environment Overview
Barracuda Web Application Firewall on Azure
Marketplace
Network Architecture Overview of App Service
Environments
Pro Tip
You can use site-to-site, point-to-site, VNet-to-
VNet, multi-site, and ExpressRoute connections
cross-premises. Check out this link for the
dierences between them.
16
Scenario 2: Building a Mobile App
Back end
In this section, learn how to extend your mobile app functionality
with back end features and how to analyze user behavior.
A. Adding mobile features in your web app
Overview
You have an existing Azure Web App that connects to a
storage back end. Your customers expect a mobile experience,
so you need to build a mobile app. You would also like to
have the mobile app share data and APIs with an existing
Web App. Being able to send notications to users through
the mobile app would improve user engagement.
The problem
Building mobile client apps that target multiple platforms
can be time consuming. Developers need to become familiar
with various languages, platforms and IDEs , such as Xcode
and Eclipse. You want a common way to add back end features
like push notications, oine data sync, and auto-scaling
for those mobile apps as well. Creating a solution to expose
your web apps API and reusing it in your native mobile app
isn’t a trivial task.
The solution
Microsoft provides comprehensive solutions for both front
end and cloud-enabled back end development of cross-
platform, mobile solutions. You can build native mobile app
front ends in Objective-C, Swift, and Java, but if you’re a
.NET developer, you can use Xamarin to create mobile client
apps in C# and share your client business logic across iOS,
Android, and Windows Phone.
When creating mobile apps, you need to think about the
client app functionality and user experience—and also adding
shared back-end features like push notications. You can add
these pre-built mobile features and others with Mobile Apps
in App Service. Hook in Azure Notication Hubs to send
personalized push notications to users. Then, share data
with your Web App and use those back-end features for a
complete mobile solution.
Create an API for your web app or, if you have an existing one,
extract and deploy your API as an API App in App Service and
share the API between the apps in the same App Service plan.
The how
When creating a mobile app, you’re going to want to take
advantage of services like auto-scaling and authentication.
An eective approach is to create your mobile client app and
connect it to an Azure Mobile App in App Service back end,
tying in Notication Hubs for push notications. Deploy your
API as-is to API Apps in the same App Service plan, then share
the API and data between both apps.
Creating a mobile app
Azure Mobile Apps is designed to allow you to build highly
scalable, globally available mobile app back ends. Azure Mobile
Apps supports native client apps as well as cross-platform
Xamarin native and Cordova hybrid mobile client apps.
Create a mobile client app (here’s a Xamarin example) and
connect it to your Azure Mobile App back end.
• Add oine data sync, allowing end-users to interact with
the mobile app even without a network connection.
Services Used
Mobile Apps
API Apps
Xamarin
Notication Hubs
Common Cloud App Scenarios
17
• In the Mobile area in Settings, choose the Storage account
used by your Web App to add a data connection.
Add auto-scaling properties, authentication (such as with
Active Directory), Web Jobs, trac routing, custom domains,
and SSL to your Mobile App.
Sending push notications to users
Azure Notication Hubs allows you to send cross-platform,
personalized mobile push notications with a single API
call. Developers can easily integrate Notication Hubs into
their apps.
Here’s how to create a Notication Hub:
Create a new Notication Hub and congure the mobile
back end to point to that hub.
Register your app to use push notications and create an
SSL certicate.
Update the server project to send push notications and
add push notications to the app.
Hosting an API in the cloud
If you have existing APIs, deploy them as-is to API Apps in
App Service and benet from enterprise-grade security,
simple access control, hybrid connectivity, automatic SDK
generation, and integration with tools like Visual Studio. With
support for Swagger API metadata, you can consume the
APIs through a variety of clients and automatically generate
client code. If you need additional access management
capabilities, you can use Azure API Management to control
client access to APIs hosted by App Service.
Pro Tip
Learn about connecting your mobile app with
Azure in two minutes with this Channel 9 video.
Common Cloud App Scenarios
Download the latest Azure SDK for your language and tool
of choice.
Install the Swashbuckle package to work with Swagger
API metadata.
Publish your API (Visual Studio example) to a new API app
in the same App Service plan as the existing Web App.
Generate REST API client code through the Swagger URL.
Architecture diagram
Additional resources
I use Mobile Services: How does App Service help?
Enterprise push architecture for Notication Hubs
Get started with API Apps and ASP.NET in
Azure App Service
18
B. Analyzing user behavior with your
mobile back end
Once you’ve built a mobile back end, you need to know what
to improve to keep your users happy. You want to receive
fast feedback through real-time analytics of users’ behavior,
targeted push notications for feature requests, and you
might want to post tweets about your product to your internal
#UserFeedback Slack channel in order to quickly change
course and improve your apps based on user feedback.
The solution
Connect Azure Mobile Engagement with an Azure Mobile App
back end to collect real-time user behavior analytics and send
personalized notications. Create a Logic App with a user-
friendly designer that searches for particular tweet content
and sends a message to Slack using a conditional statement.
The how
You could decide to build your own tools and utilities to
provide analytics for your mobile app, and use custom code
to connect to external resources like Twitter and Slack APIs.
Instead of building these solutions yourself, you can use
existing solutions in Azure so you can focus on improving
the things that make your app unique.
Add Mobile Engagement to the Mobile App to collect
analytics and send personalized notications. Use Logic Apps
in the same App Service to create if-this-then-that functionality
for tweets and posting messages in a Slack channel.
Hosting your mobile app back end
Use Azure Mobile Apps to host the back end for your mobile
apps in Azure.
Create a new Azure Mobile App in App Service.
Congure the server project.
Better engage users with analytics
Mobile Engagement is a software as a service (SaaS) user-
engagement platform that provides data-driven insights into
app usage, real-time user segmentation, and enables
contextually-aware push notications and in-app messaging.
For example, you can create custom dashboards to measure
key performance indicators (KPIs), rapidly nd and x usage
bottlenecks in a user funnel path, track retention and user
stickiness, and by that determine what campaigns are driving
the highest return on investment. Mobile Engagement provides
in-app messaging capabilities and works seamlessly with native
push notications gateways such as Google’s GCM, Apple’s
APNS, and Microsoft MPNS.
Create a new Mobile Engagement application.
Copy the connection string for the Mobile Engagement app
and connect your Mobile App to it.
Enable and connect your Mobile App to real-time monitoring.
Enable push notications for the Mobile App with
Mobile Engagement.
Connect data sources for events
Logic Apps allow developers to design workows that start
from a trigger and then execute a series of steps. Each step
invokes an API while taking care of authentication, security,
creating checkpoints, and durable execution.
Create a new Logic App in the same App Service as your
Mobile App.
Create a new action to query tweet content related to your
product and sign into Twitter.
Create a conditional statement for if the tweet text containing
bugs, then perform an action.
Create a new action in the conditional statement for posting
to a Slack channel for your team.
Common Cloud App Scenarios
19
Architecture diagram
Additional resources
Send personalized notications with Mobile
Engagement
List of managed APIs in Logic Apps
Pro Tip
Take a deep dive into the end-to-end platform
and tools from Microsoft for creating mobile
enterprise apps.
Common Cloud App Scenarios
Services Used
Mobile Apps
Mobile Engagement
Logic Apps
20
Scenario 3: Building an Internet of
Things (IoT) App
Overview
You develop applications that collect large amounts of
information from connected devices. You want to monitor
for usage and anomalies by pushing real-time data to
dashboards for business and infrastructure users. You also
want to predict trends for growth and avoiding failures for
the connected devices with predictive analytics. And, you
want to archive raw data and clean up the data automatically.
The problem
Although many companies are using analytics as part of their
business models, there can be a lot of useful data that is going
to waste within organizations. The task of processing a lot of
data, especially IoT data, sounds daunting. When developers
often think of machine learning, they think of using R
programming and needing an advanced degree in data science.
The solution
Do you need to understand R and get a doctoral degree to
work with Azure Machine Learning? Both of those certainly
wouldn’t hurt. But Microsoft has intentionally made Machine
Learning with developers in mind, being both accessible to
curious beginners and powerful enough for data scientists.
You can connect various Azure technologies together to ingest,
predict, and output data to a dashboard. Use Azure IoT Hub
and Stream Analytics to connect to your devices, grab, and
process those events. Store that data in Azure Storage for
archival use while using Azure Machine Learning to create
models for predictions. Connect Power BI to Stream Analytics
directly and view those predictions in a dashboard in real-time
for your business users. Use Azure Functions to clean up data
by responding to changes in Azure Storage.
The how
Competitive businesses are able to take data that they already
have and turn it into valuable predictions. Those companies are
able to use those predictions for creating product
recommendations, fraud detection, and preemptive maintenance.
But how do you get from point A with just raw data to point Z,
creating predictive analytics solutions from your data?
Use IoT Hub to log millions of events per second from
connected devices. Implement Stream Analytics to ingest
those events and process them in real-time, and add in a
Machine Learning function to create a Machine Learning
model and output the Stream Analytics job result to Azure
Blob Storage for archiving. Then, add a Power BI output to
your Stream Analytics job and create a dashboard from the
dataset. Create a function to execute cleanup functions when
Blob Storage reaches a certain threshold in size.
Collecting data from connected devices
IoT Hub is a new service we’ve introduced to meet the needs
of IoT. The IoT Hub is the centerpiece of an Azure IoT solution,
serving as the cloud gateway for your “things” to connect to.
It can scale to millions of connections per hub and can process
massive volumes of data. It also provides the ability to
communicate from the Cloud back to the devices it knows,
thus enabling command and control capabilities. The IoT Hub
speaks multiple protocols, including HTTP, MQTT, and AMPQ.
The IoT Hub also plays an important role in helping to secure
Common Cloud App Scenarios
Services Used
IoT Hub
Stream Analytics
Machine Learning
Storage
Power BI
Functions
21
your solution by providing per-device authentication support.
Get started with our step-by-step guide to connecting
your IoT devices.
• Add rules with send, and manage, send, and listen rights
and copy the two connection strings.
Processing data in real time
Stream Analytics is a fully-managed, cost-eective, and
real-time event processing engine that helps to unlock deep
insights from data. Stream Analytics makes it easy to set up
real-time analytic computations on data streaming from
devices, sensors, web sites, infrastructure systems, and more.
Stream Analytics connects directly to IoT Hub for stream
ingestion, and results can be written from Stream Analytics
to Storage Blobs or Tables, among other solutions in Azure.
You can also optionally output directly to Power BI.
Create a new Stream Analytics job.
Specify the job input for the Stream Analytics job.
Specify the job query (or queries) for describing
transformations for real-time processing.
Specify the job output of the Storage blob container to
store the processed data.
Specify another job output for Power BI as well to post real-
time data to a dashboard.
Storing processed output data
Table or Blob Storage is available for storing processed data
from Stream Analytics. Storage is a much lower-cost solution
for storing large amounts of data over a traditional relational
data store.
• Create a unique Storage account in the portal.
• Create a new container, and set its access for the container
to be Public Blob.
Create Shared Access Signatures to lock down storage
containers.
Common Cloud App Scenarios
Set the job output of Stream Analytics to the storage
container.
Creating predictive solutions from data
Azure Machine Learning not only provides tools to model
predictive analytics, but also provides a fully-managed service
you can use to deploy your predictive models as ready-to-
consume web services. You can either use Machine Learning
as a function in Stream Analytics (which then stores results
in Blob storage), or you can use the Machine Learning REST
API and connect that to the Power BI REST API.
Build a new experiment through Azure Machine
Learning Studio.
Create a model by getting data from Storage, pre-processing
data, and dening features.
Train the model by applying a learning algorithm.
Score and test the model to create predictive solutions.
Displaying your predictions in a dashboard
Microsoft Power BI helps you connect to multiple datasets to
bring all of your relevant data together in one place. Power BI
dashboards display tiles that you can click to open reports for
exploring further. Use the REST API for Power BI to connect
to other REST APIs, and transform data on your machine with
Power BI Desktop.
Add the job output for the Stream Analytics job to Power
BI and authorize the connection.
Query the data for what you want in a report or dashboard
(if using a new job).
Create the dashboard in Power BI online.
Running scalable event-driven functions
Azure Functions is a new server-less compute service that
allows you to create a function in a variety of languages that
can respond to events such as HTTP requests, or Azure
services events like Azure Blob Storage updates. Your Azure
22
Functions run in a dynamic compute environment which
automatically scales out to meet demand, and you’re only
charged for the time your function runs. Learn more about
using Azure Functions.
Architecture diagram
Additional resources
Azure IoT Developer Center
Machine learning algorithm cheat sheet
Power BI overview and learning
Common Cloud App Scenarios
Pro Tip
Learn how to perform sentiment analysis
using Stream Analytics and Machine Learning
functions here.
23
Scenario 4: Building a Custom
Microservice-based App
Overview
Your startup, ISV, or enterprise business faces explosive
growth and you want the condence that key applications
and services supporting the business will scale and be
available around-the-clock while your developers continually
patch the code and add new features. You want to build new
applications and services with cloud-native architectures
optimized for the dynamic, unlimited scale of the cloud.
If your organization’s application needs don’t t the standard
approaches mentioned previously, then a custom approach
is called for to build a unique solution that will drive the
success of your business. If you are a startup ISV company
or enterprise whose core business depends on a specic
service being available, you want a higher degree of control
and customization to ensure success.
The problem
Whether you’re building nancial trading systems, instant
messaging services, data collection hubs, dynamic video
ad-serving, or managing patient records at national scale,
you want more control and exibility than the typical web
or mobile app platform can provide.
You’re willing to invest in the ongoing development and
operation of a custom architecture to create an application
matched exactly to the success of your business. However,
you want your developers to build on a platform that lets
them focus on delivering business value in an agile way
without having to manage the underlying infrastructure.
The solution
Build your application using a microservice approach and deploy
it onto Azure Service Fabric. The microservice architecture breaks
down an application into small, independently executing
microservices resulting in the following benets:
Services are easier for developers to understand and
build/rebuild.
• Services can be developed and deployed in a more
independent way speeding development.
Services start and stop quickly speeding deployments and
increasing developer productivity.
It’s easier to dynamically scale only those components that
are needed to meet demand.
The system is more tolerant to faults and therefore has
higher availability.
Individual microservices can be upgraded live without
interruption to the service.
But microservice architectures have a higher degree of
complexity which requires a PaaS layer to eectively deploy
and manage them at scale. That’s what deployment onto Azure
Service Fabric does for you – so your developers can focus on
building business value. (For a deeper look at Service Fabric
and microservices see “Service Fabric” later in the guide)
The how
Architect your application using a collection of smaller
microservices. Each service should:
• Be independently deployable and isolated
• Maintain its own data
• Publish at least one secured API endpoint
To make the process of building microservices simpler, Service
Fabric supports the Actor programming model which allows
developers to model object-oriented services and their
interactions as a means to abstract away from explicit data
and networking operations and be very productive building
microservice based applications.
Common Cloud App Scenarios
24
Architecture diagram
Service Fabric supports both stateless and stateful services,
where stateful services have local data that persists even if
the service fails. The potential dierent architectures are
limitless. However, as an example, the above gure shows
how a customer, TalkTalk TV, built a microservices application
on Service Fabric while leveraging multiple other Azure
services such as Azure Web Apps for the Admin website and
Azure AD for authentication.
Common Cloud App Scenarios
Additional resources
TalkTalk Case Study
Azure Service Fabric Website
25
Azure App Service
Azure App Service is a cloud platform to build powerful web
and mobile apps, for any platform and any device, that
connect to data anywhere, in the cloud or on-premises. Built
for developers, App Service is a fully managed platform with
powerful capabilities such as built-in DevOps, continuous
integration with Visual Studio Team Services and GitHub,
staging and production support, and automatic patching.
App Service allows you to create the following app types
from a single development experience:
Web Apps—Quickly create and deploy mission critical
web apps that scale with your business.
Mobile Apps—Build mobile app back ends with
notications, data sync, and authentication.
API Apps—Easily build and consume cloud APIs.
Logic Apps—Automate the access and use of data across
clouds without writing code.
App Service provides an integrated set of enterprise
capabilities through a single development and management
experience oering you the following benets:
Build web and mobile apps fast. Rapidly build, deploy
and manage web and mobile back end apps for employees
The Azure Platform
Services
or customers. Use your existing languages skills—.NET,
Java, NodeJS, PHP, or Python. Accelerate development with
access to a rich gallery of APIs, connectors, and logic
available in the Azure Marketplace.
Connect to any service and unlock your data. Connect
your web or mobile app to enterprise systems or SaaS in
minutes with built-in connectors. Choose from more than
50 connectors for enterprise systems such as SAP, Siebel,
and Oracle to popular enterprise SaaS services like
Salesforce and Oce 365 to popular internet services such
as Facebook, Twitter, and Dropbox.
Integrate more easily. Logic Apps lets you integrate data
across clouds and automate business processes in minutes
using a visual design experience. Easily integrate your logic
with any mobile or web app via standard REST APIs. Build
sophisticated enterprise application integration, B2B
solutions using Electronic Data Interchange (EDI) and
business policies (rules engine).
Increase developer productivity. Optimized for DevOps,
with continuous integration support for Visual Studio Team
Services and GitHub, so you can focus on rapidly improving
your apps without worrying about infrastructure. Deploy
app updates with built-in staging, roll-back, and in-
production testing capabilities.
26
Rely on Enterprise-grade services – App Service has full
enterprise-grade security and management. Provide
delegated and role-based administration; easily secure and
manage data owing to your mobile apps; and protect
your assets with built-in backup and restore capability. Fully
PCI-compliant with dedicated environments, and the ability
to deploy across public and private clouds.
As a single integrated service, App Service makes it easy to
compose the above app types into a single solution, allowing
you to easily build apps that target both web and mobile
clients using the same back end and integrate with on-
premises systems as well as popular SaaS services.
App Service Plans represent a set of features and capabilities
that you can share across your apps. App Service Plans
support a number of pricing tiers (e.g. Free, Shared, Basic,
Standard, and Premium) where each tier has its own
capabilities. You can quickly change which App Service Plan
an app is hosted on with no downtime.
Azure Service Fabric
Azure Service Fabric is a mature, feature-rich microservices
application platform with built-in support for lifecycle
management, stateful and stateless performance at scale,
hybrid deployments, 24x7 availability, and cost eciency.
Microservices are an application development and deployment
approach perfectly suited to the agility, scale, and reliability
requirements of modern cloud applications. In a microservices
model, you individually build and deploy small, independently-
executing services or “microservices,” that collaborate using
published API calls across the network to deliver the overall
application’s functionality. This results in a ne-grained,
loosely coupled application that can easily be distributed
across multiple host machines for scale and reliability. Contrast
this with the monolithic three-tier approach common in many
applications today.
The term “microservice” emphasizes the fact that applications
should be composed of services small enough to truly
implement a single role. Each has well-dened contracts (API
contracts) for other microservices to communicate and share
data with it. Microservices must also be able to version and
update independently of each other. This loose coupling is
key to supporting rapid and reliable evolution of an
application. What would have been a single tier of a monolithic
application decomposes into many discrete microservices,
each independent and isolated.
In its initial public release, Azure Service Fabric runs on
Windows and include C++ and C# language integration, but
Linux and Java support are under development. Service Fabric
has built-in support for lifecycle management, hybrid
deployments, and 24x7. The platform oers extensible health
models for both the infrastructure and microservices to
enable automated health-based upgrades and automatic
rollback, simplifying DevOps. It supports both stateless and
stateful microservices with leadership election to support
data consistency and a state replication framework that
supports transactions for stateful data guarantees. Learn
more about running Service Fabric on Azure.
Service Fabric applications can be composed of both stateless
and stateful microservices. The reliable stateful data
management Service Fabric is highly tuned to provide
maximum availability and durability of data, while optimizing
every cycle and I/O operation for high performance.
The Azure Platform Services
27
To make microservice development more productive, Service
Fabric includes an approach called the actor programming
model. This approach enables you to think about microservices
as “actors”, each representing a logical entity functions and
state, whether it’s an IoT device, a game player, game session,
or patients and doctors in a health provider network. One way
to look at the actor programming model is as object-oriented
microservices, and it can greatly simplify the app development.
Service Fabric has been in production use at Microsoft since
2010 and powers many of our applications and services,
including Azure SQL Database, DocumentDB, Intune, Cortana
and Skype for Business. In its largest deployments, it manages
hundreds of thousands of microservices across thousands
of servers. We’ve taken the exact same technology and
released Service Fabric directly, as a service on Azure and it
will soon be available to run on-premises and in other clouds.
Visual Studios integration with Service Fabric makes coding
and deployment easy, and there’s a complete developer-
machine experience that runs the actual Service Fabric runtime
on a single box, simulating a multi-server Service Fabric
cluster for validation and diagnostics.
Finally, Service Fabric can be easily plugged into your
application lifecycle allowing for a seamless continuous
integration (CI) / continuous delivery (CD) of both stateless
and stateful updates. To help manage the application lifecycle,
Service Fabric supports both rolling and side-by-side upgrades
(e.g. scaling up version 2 while scaling down version 1), and
automatically rolls back updates if it detects that the upgrade
has degraded application health.
Cloud Services
Cloud Services is designed to support applications that are
scalable, reliable, and cheap to operate. Just like an App
Service is hosted on virtual machines, so too are Azure Cloud
Services, however, you have more control over the virtual
machines. You can install your own software on Azure Cloud
Service virtual machines and connect into them remotely.
More control also means less ease of use; unless you need
the additional control options, it’s typically quicker and easier
to get a web application up and running in Web Apps in App
Service compared to Azure Cloud Services.
The technology provides two slightly dierent virtual machine
options: instances of web roles run a variant of Windows
Server with IIS, while instances of worker roles run the same
Windows Server variant without IIS. A Cloud Services
application relies on some combination of these two options.
For example, a simple application might use just a web role,
while a more complex application might use a web role to
handle incoming requests from users, then pass the work
those requests create to a worker role for processing. (This
communication could use Service Bus or Azure Queues.)
Even though applications run in virtual machines, it’s important
to understand that Azure Cloud Services provides PaaS, not
IaaS. All you have to do is deploy your application.
Management of the platform it runs on, including deploying
new versions of the operating system, is handled for you.
The Azure Platform Services
Azure Functions
Azure Functions is a serverless, event-driven experience
that extends the existing Azure application platform with
capabilities to implement code triggered by events
occurring in other Azure services, SaaS products, and on-
premises systems.
Storage (Azure)
28
Azure Functions extends our market leading PaaS platform,
building on the existing WebJobs infrastructure to let
developers easily implement code that reacts to events
generated from across the breadth of Azure. Whether you
want to respond to changes in Azure storage containers,
events emitted in SaaS products that support Web Hooks,
or by calls to an HTTP endpoint, they’re all easy to set up
and require minimal conguration.
You can implement your functions in a variety of languages
including JavaScript, C#, Python and PHP. In addition, you
can choose scripting options like Bash scripts, PowerShell
scripts, or Windows batch les. Azure Functions provides an
intuitive web-based code editing experience or you upload
and trigger pre-compiled executables built in the development
tool of your choice. You can quickly and easily iterate on your
Azure Functions with continuous deployment using Visual
Studio Team Services, GitHub, or BitBucket. Monitor and
troubleshoot your Azure Functions using the embedded
logging environment.
Azure Functions introduces a new pricing model where you
will only be charged for the time your code is running. When
an Azure Function is invoked it will be provided with as many
resources as it needs to execute only for as long as it is
executing. You can help secure your Azure Functions by
hosting them on an App Service Environment that can be
congured to be addressable only from internal networks.
The Azure Platform Services
29
The host operating system is the original application platform,
and many developers continue to write applications that run
natively on Windows Server, Linux, or other operating systems.
Traditionally the operating system would be installed on a
single physical host machine and the application installed
and run using resources, such as les, networking, time-slicing,
memory, and security, provided by the operating system.
Today the operating system would most likely be running
on a virtual machine rather than physical host but the pattern
is the same; the application runs on a single machine
consuming services provided by the OS.
This arrangement provides developers with a very detailed
level of control over the environment in which their application
executes and, depending on the programming environment,
can aord the maximum level of customization where aspects
like performance are critical. However, the developer or their
IT coworker are now responsible for the upkeep and
conguration of the operating system and the intricate details
that make it compatible with the application. When the OS
needs to be upgraded, the application will need to be tested
for compatibility before putting into production.
One serious limitation of this style of application that’s
highlighted with the advent of application servers and now
the cloud is that while the application can be scaled-up by
adding capacity to the host machine, the application can’t
be easily scaled-out to run across multiple machines without
Building on IaaS
developers moving to stateless, load balanced models and
making other code changes just to suit the infrastructure.
Applications also become entangled with the OS, making the
task of migrating applications between OS versions very risky
without fully testing on the new OS version. Dockers packaging
format and tools have become popular because they provide
a means to build portable images of applications and OS
dependencies that can be moved around virtual machines
and containers without the risk of incompatible dependencies.
Azure provides a range of options for developers looking to
build directly on the operating system:
Virtual Machines—Azure provides a wide range of
Windows Server and Linux base operating system images.
Virtual Machine Scale Sets—Virtual Machine Scale Sets
provide an easy to use sliderbased mechanism for scaling
identical groups of stateless virtual machines.
Azure Container Service—Container Service is a fully
open-source based service providing deployment,
orchestration and failover for Docker-based images across
a cluster of virtual machines, using Apache Mesos,
Mesosphere’s Marathon, or Docker Swarm.
Azure Marketplace—Azure Marketplace includes many
popular application platform/PaaS platforms in virtual
machine images that you can operate and manage for
yourself, including Pivotal’s Cloud Foundry.
30
Docker and Containers
You can’t have a discussion on cloud computing without
talking about containers and the Docker toolset. Organizations
across all business segments want to understand what
containers are, what they mean for applications in the cloud,
and how to best use them for their specic development
and IT operations scenarios.
Containers are a form of OS virtualization, similar to Virtual
Machines but operating inside an instance of the OS, creating
the perception of a fully isolated and independent OS. To
the application running in the container the local disk looks
like a pristine copy of the OS les, the memory appears only
to hold les and data of a freshly-booted OS, and the only
thing running is the OS. The host OS also controls resources
like CPU, RAM and network bandwidth to ensure a container
gets the resources it expects and that it doesn’t impact the
performance of other containers running on the host.
The combination of instant startup that comes from OS
virtualization and reliable execution that comes from isolation
and resource governance makes containers ideal for application
development and testing and developers can quickly iterate.
Because its environment and resource usage are consistent
across systems, a containerized application that works on a
developers system will work the same way on a production
system. The instant-start and small footprint also benets cloud
scenarios, since applications can scale-out quickly and many
more application instances can t onto a machine than if they
were each in a virtual machine, maximizing resource utilization.
Azure Container Service
Containers oer a compact form of virtualization with fast start-
up times, highly-ecient system utilization (enabling hundreds
of containers on a single machine) and, in Docker images, a
packaging format that is fully portable across environments.
Using this common image format, you can test your
application on a local development box, using the exact same
deployment artefact as will eventually run in production,
Building on IaaS
reducing the need for further testing on production
environments. However, the agility and scale oered by
containers presents a management challenge for developers
and IT administrators when deploying applications into
production at scale.
Azure Container Service provides a way to simplify the
creation, conguration, and management of a cluster of
virtual machines that are precongured to run containerized
applications. Using an optimized conguration of popular
open-source scheduling and orchestration tools, Container
Service enables you to use your existing skills or draw upon
a large and growing body of community expertise to deploy
and manage container-based applications on Microsoft Azure.
Container Service uses the Docker container format to ensure
that your application containers are fully portable. It also
supports your choice of Marathon and Apache Mesos or
Docker Swarm to ensure that these applications can be scaled
to thousands, even tens of thousands, of containers.
Azure Container Service exposes the standard API endpoints
for your chosen orchestrator. Using these endpoints you can
take advantage of any software that is capable of talking to
those endpoints. For example, in the case of the Docker
Swarm endpoint you might choose to use Docker Compose,
while for Apache Mesos you may choose to use the
Mesosphere DCOS command-line interface.
At this time, the service supports Linux containers only.
Microsoft has committed to providing Windows Server
Containers using Docker and Apache Mesos is being ported
to Windows. This work will allow us to add Windows Server
Container support to Azure Container Service in the future.
31
Once you’ve addressed the question of what is nature of
your app, where will it run and what design approach you
should take, you have a world of powerful Azure services at
your disposal to make your app truly great.
There are more than sixty—and growing—Azure services
today that you can use to develop, host, manage, support,
secure, integrate, extend, and complement your application
development. In this section we’ll take a look at some of the
most common services you should consider when building
modern apps.
View a complete list of all Azure services.
Adding Superpowers
to your Apps
32
built-in scalability, and built-in high availability.
DocumentDB is an attractive choice for developers working in
JavaScript and other modern languages, all of which provide
built-in JSON serializers. It’s also good for situations where the
data’s structure changes frequently, because unlike a relational
database, DocumentDB doesn’t dene a xed schema.
HDInsight HBase
HBase is part of the Hadoop technology family, and so it’s
designed for processing big data. HBase can be viewed as a
column-family store. The columns in each table are grouped
into families, and requests for data can specify which column
family to look in. Unlike relational tables, however, HBase
allows adding a new column to a column family at runtime—
the schema isn’t xed. It’s also designed to be highly scalable,
letting applications create tables with millions of columns
and billions of rows.
HBase is an excellent choice for applications that need to
create big but sparse tables. It’s also a good option when
the data it stores will be processed with Hive or another
HDInsight technology, since all of these rely on the same
underlying clustering technology.
Tables
Some situations need the full power of a relational database,
including SQL queries against relational tables. Others,
however, can get by with a much simpler approach to storing
and accessing data. Despite the name of this PaaS database
service, it doesn’t really store data in tables. Instead, an
application accesses data by providing a unique key. This
service then returns whatever set of values are associated
with that key.
This simple approach works well in a surprising number of
situations. Think about storing user prole data, for example.
Each user can have a unique key, with each key providing
access to whatever prole data is stored for that user. Dierent
users can have dierent data—there’s no xed schema—and
Adding Superpowers to your Apps
Database Services
PaaS database services (sometimes referred to as database
as a service) have a number of advantages over the IaaS
approach of running a database management system (DBMS)
in a virtual machine:
Fully managed—You don’t need to install, patch, or
manage a DBMS.
Built-in scalability—Rather than adding database servers
manually as your application’s load increases, a PaaS
database service can do this on demand with no downtime.
Built-in reliability and fault tolerance—Rather than
requiring specialized skills and plenty of time to set up a
clustered DBMS, a PaaS database service can do this for
you.
Service level agreements (SLAs)—Rely on Azure to meet
your availability targets, instead of worrying about
availability yourself.
SQL Database
Based on SQL Server, Azure SQL Database oers a familiar
relational store, including support for SQL queries, transactions
across an entire database, and stored procedures. It also
provides built-in fault tolerance and scalability.
SQL Database is a good choice when an application needs
the full power of a relational system. It’s also a good choice
when the development team is already familiar with SQL and
relational technologies. Since this PaaS database service is
based on SQL Server, learning it commonly isn’t dicult.
DocumentDB
As its name suggests, Azure DocumentDB stores documents,
each containing JSON data. This PaaS database service allows
RESTful access to the documents it contains, and it also lets
applications issue queries using an extended subset of SQL.
And like SQL Database, DocumentDB provides transactions,
33
so Tables provides a exible approach.
Other data services
Along with the technologies described so far, Azure also
provides two other PaaS database services for working with
operational data. Neither one addresses the same type of
problem as the ones already mentioned, but they’re both
important to understand. Those two services are Azure Search
and Azure Redis Cache.
Azure Search
For many people, search has become the most attractive way
to interact with applications. Rather than choose items from
menus, why not let an application’s users search for what
they’re interested in, much as they would on the Internet?
Allowing this would make many applications easier to use.
Azure Search helps developers add search capabilities to
their application and provides things such as automatic
bolding of search terms in results and a way to control the
order in which these results are returned. It also supports
the ability to provide suggestions, oering possible search
phrases based on a users initial entry.
Redis Cache
With Redis Cache, an application can access data from any
Azure PaaS database service, as usual. The application can
then store a copy of that or other data in Redis Cache. When
the application needs this data in the future, it can access
the data in the in-memory cache rather than going back to
the PaaS database service. Doing this is faster, letting
applications have better response time and handle more
simultaneous users.
(Database Services section adapted from “Data in a PaaS
World: A Guide for New Applications” by David Chappell)
Adding Superpowers to your Apps
Advanced Analytics & IoT
Advanced analytics helps transform data into intelligent
action through collecting and managing unlimited data,
extending apps with predictive insights, and operationalizing
data science pipelines for iterative learning.
Cortana Intelligence Suite
A fully managed big data and advanced analytics suite that
enables you to transform your data into intelligent action:
Information management—Orchestrate data movement
on a fully managed, end-to-end platform. Use Azure Data
Factory to build pipelines and collect and orchestrate
data from the services you use for easier analysis. Plus,
use Azure Data Catalog to eectively manage data sources
and Azure Event Hubs to provide a staging area for
incoming streaming data.
Big data stores—Store and manage structured data using
Azure SQL Data Warehouse that elastically scales with
massively parallel processing. Implement a hyper-scale
repository with no le size limits for unstructured data
using Azure Data Lake Store to attain massive throughput
and analytic performance.
Machine learning and analytics—Design and publish
predictive models with Azure Machine Learning, use Azure
HDInsight to analyze data in Storm and Spark for Hadoop
environments, integrate your code from R or Python, and
analyze any kind or any size of data you need with Azure
Data Lake Analytics and Azure Stream Analytics. Plus, use
Microsoft Power BI to create rich visualizations that bring
your data to life.
Intelligence—Explore the Cortana Intelligence Gallery
for downloadable, fully managed APIs to quickly implement
predictive APIs for business scenarios (recommendation,
forecasting, anomaly detection, and customer churn), as
well as Cognitive Services APIs (vision, face, text, and
speech) to interact in new ways with customers. Get started
34
with solution templates tailored to your specic business
needs. Plus, integrate your analytics services and models
with Cortana, our personal digital assistant, to let users
naturally interact via speech or receive proactive
notications. Integrate your analytics services and models
with intelligent agents (Bot Framework) as well as Cortana,
our personal digital assistant, to let users naturally interact
via speech or receive proactive notications.
Common Scenarios
Healthcare: The proliferation of healthcare data available—
from new data sources streaming in real time to historical
data stored on health provider systems—combined with
the power of advanced analytics can help transform current
healthcare business challenges into predictive and
prescriptive solutions.
Financial Services: Existing anti-money-laundering systems
are robust and well developed through years of iteration
and improvement, yet trillions of dollars are still lost to
money laundering every year. Using big data tools to
manage unstructured data, the Cortana Intelligence Suite
augment existing systems to provide additional clarity in
combatting money laundering.
Retail: The proliferation of structured and unstructured
data available combined with the power of advanced
analytics solutions provides an opportunity for big data
to solve problems. The technologies united within the
Cortana Intelligence Suite can help retail organizations
successfully turn big data into insights into personalized
customer experiences.
Internet of Things (IoT)
Azure IoT Suite is an enterprise-grade solution that enables
developers to get started quickly through a set of extensible
precongured solutions that address common IoT scenarios,
such as remote monitoring and predictive maintenance.
These are complete, working end-to-end solutions, including
simulated devices that make use of Azure services.
Adding Superpowers to your Apps
Azure IoT Hub—Developers can easily and securely
connect new devices, and connect existing ones, using
open-source device SDKs for multiple platforms, including
Linux, Windows, to reliably (intermittent connection) and
securely send commands and notications to connected
devices and track message delivery.
Azure Event Hubs—A highly scalable publish-subscribe
service that can ingest millions of events per second and
stream them into multiple apps. This lets developers process
and analyze the data produced by connected devices and
apps and transform and store it by using any real-time
analytics provider or with batching/storage adapters.
Azure Stream Analytics—Developers can rapidly develop
and deploy low-cost solutions to gain real-time insights
from devices, sensors, infrastructure, and applications,
e.g. real-time remote management and monitoring or
gaining insights from devices like mobile phones and
connected cars.
Azure Machine Learning—A powerful cloud-based
predictive analytics service that makes it possible to quickly
create and deploy predictive models as analytics solutions.
It provides tools to model predictive analytics, but also
provides a fully-managed service to deploy predictive
models as ready-to-consume web services. Quickly create,
test, operationalize, and manage predictive models.
35
machines in few a clicks either with reusable templates or
Azure marketplace. This allows users to use Azure Marketplace
images as virtual machine base in the lab in addition to their
custom images (VHDs) uploaded to the lab. You minimize
waste with quotas and policies, and you can set automated
shutdowns to minimize costs—all benets of using the cloud
for your development and test environments—whether for
Windows or Linux workloads.
HockeyApp
HockeyApp makes distributing, testing and getting feedback
on your client mobile apps simple. With support for iOS,
Android, or Windows; and native code, along with Xamarin,
Cordova, and Unityyou are covered with the open source
HockeyApp SDKs.
HockeyApp provides webhooks and an API to support
integration with your existing ALM tools. This allows you to
adopt a Mobile DevOps practice without needing to change
your existing workows. HockeyApp supports work item
creation based on app feedback and crashes so you can
manage your backlog in one place.
Application Insights
Application Insights gives you rich web app and web service
performance monitoring capabilities and deep diagnostics
information, enabling you to quickly respond to web app
and service issues. With support for public, private, and
hybrid clouds and on-premises deployments—and nearly
any web development language—Application Insights can
provide you the detect, triage and diagnose capabilities you
need to always have condence in your web apps and services.
Adding Superpowers to your Apps
Developer Services
Visual Studio Team Services
Visual Studio Team Services provides a set of cloud-powered
collaboration tools that work with your existing IDE or editor,
so your team can work eectively on software projects of all
shapes and sizes, in any language and on any platform. These
tools cover the entire software lifecycle—right from the time
you add a task to the backlog/plans, to the time when the
task gets coded and delivered in a release.
Tools for agile teams—Capture, prioritize, and track work
with backlogs and customizable Kanban boards. Work items
link directly to code to ensure transparency, and can be used
to build rich dashboards for easy reporting.
Version control—Store and collaborate on code with
unlimited private repositories and Nuget package
management service. Use Git for distributed version control
to maximize collaboration or use Team Foundation Version
Control (TFVC) for centralized version control.
Continuous Integration and cross-platform builds—Catch
quality issues early with continuous integration (CI) builds
that compile and test your application automatically after
any code change. Use continuous delivery to automatically
deploy applications or websites that pass tests. Set up release
environments and policies to manage release pipelines.
IDE integration—Use your favorite language and
development tool. Version control supports any language,
as well as any Git client (including Xcode). Java teams can
access code and work items through free plugins for Eclipse,
Android Studio and IntelliJ—and run continuous integration
builds based on cong les from Ant or Maven.
Dev-Test Labs
Dev-Test Labs allows for fast, easy, and lean Dev/Test
environments in the cloud. You can quickly provision
development and test environments by creating virtual
36
Use Azure AD to control who has access to your
application. Administrators can assign access to
applications to specic users and groups. Read this list and
use it to control provisioning and de-provisioning of
resources and access within your application.
Advanced Security Features
Multi-factor authentication. Azure AD provides native
multi-factor authentication. IT administrators can require
multi-factor authentication to access your application, so
that you don’t have to code it yourself. Learn more about
Multi-Factor Authentication.
Anomalous sign in detection. Azure AD processes more
than a billion sign ins a day, using machine learning algorithms
to detect suspicious activity and notify IT administrators of
possible problems. By supporting Azure AD sign in, your
application gets the benet of this protection. Learn more
about viewing Azure Active Directory access report.
Microsoft Graph
Microsoft Graph exposes multiple APIs from Microsoft cloud
services through a single REST API endpoint (https://graph.
microsoft.com). Microsoft Graph gives you:
A unied API endpoint for accessing aggregated data from
multiple Microsoft cloud services in a single response
Seamless navigation between entities and the relationships
among them
Access to intelligence and insights coming from the
Microsoft cloud
Adding Superpowers to your Apps
Identity
Azure Active Directory (AD) provides organizations with
enterprise-grade identity management for cloud applications.
Azure AD integration gives your users a streamlined sign-in
experience, and helps your application conform to IT policy.
Support Azure AD as a way to sign in to
your application
Use Azure AD to sign in to your application. Your users
won’t have one more name and password to remember,
and you’ll have one less password to store and protect.
Azure AD powers sign in for some of the world’s most
popular cloud applications, including Oce 365 and
Microsoft Azure. Learn more about adding support for
Azure AD sign in.
Simplify sign up for your application. During sign up
for your application, Azure AD can send essential information
about a user so that you can pre-ll your sign up form or
eliminate it completely. Users can sign up for your
application using their Azure AD account via a familiar
consent experience similar to those found in social media
and mobile applications. Learn more about signing up your
application for Azure AD Account login.
Browse for users, manage user provisioning,
and control access to your application
Browse for users in the directory. Use the Graph API to
help users search for other people in their organization when
inviting others or granting access, instead of requiring them
to type email addresses. Learn more about the Graph API.
Re-use existing Azure AD groups and distribution lists.
Azure AD contains the groups that your customer is already
using for email distribution and managing access. Re-use
these groups instead of requiring your customer to create
and manage a separate set of groups in your application.
37
Adding Superpowers to your Apps
Integration
Azure provides a wide variety of integration services allowing
you to you to extend integration solutions to the cloud:
BizTalk Services
BizTalk Services provides out-of-the box, cloud to on-premises
and line-of-business application integration for SAP, Oracle
EBS, SQL Server, and PeopleSoft. It lets you connect with any
HTTP, FTP, SFTP, or REST data source. You can route messages
by using various Azure artifacts such as Service Bus queues,
Topics, SQL Database, and Blob storage.
Hybrid Connections
The Hybrid Connections feature of BizTalk Services lets you
connect Azure Websites or Azure Mobile Services to any
on-premises TCP or HTTP resource—such as Microsoft SQL
Server, MySQL, or any web service—with just a few
conguration changes and without using any custom code.
Service Bus
Azure Service Bus is a generic, cloud-based messaging system
for connecting just about anything—applications, services,
and devices—wherever they are. You can connect apps
running on Azure, on-premises systems, or both. You can
even use Service Bus to connect household appliances,
sensors, and other devices like tablets or phones to a central
application or to each other.
Queues
Azure supports two types of queue mechanisms: Azure Queues
and Service Bus Queues.
Azure Queues, part of the Azure storage infrastructure,
feature a simple REST-based Get/Put/Peek interface,
providing reliable, persistent messaging within and between
services.
• Service Bus queues are part of a broader Azure messaging
infrastructure that supports queuing as well as publish/
subscribe, Web service remoting, and integration patterns.
For more see the overview of Service Bus messaging.
Azure Queues were introduced rst, as a dedicated queue
storage mechanism built on top of the Azure storage services.
Service Bus queues are built on top of the broader “brokered
messaging” infrastructure designed to integrate applications
or application components that may span multiple
communication protocols, data contracts, trust domains,
and/or network environments.
38
Adding Superpowers to your Apps
Stream broadcast and OTT video. Build your online
audience and extend your reach by distributing your content
to viewers on phones, tablets, and all their digital devices.
Plus, take advantage of current event or niche markets by
bringing new channels to market quickly and encoding
over-the-top (OTT) video to multiple formats.
Deliver government content. Government agencies can
deliver secure video streaming to mobile devices by using
Azure Media Services and Azure Government, a CJIS-
compliant and secure platform.
Get Content Closer to your Users. Azure Content Delivery
Network lets you deliver high-bandwidth content to users
around the world with low latency and high availability via
a robust network of global data centers. It sends audio,
video, applications, images, and other les to users from
the nearest servers.
Media Services & CDN
Media Services
Azure Media Services combines powerful and highly scalable
cloud-based encoding, encryption, and streaming components
to help customers deliver premium video content to larger
audiences on today’s most popular digital devices, such as
tablets and mobile phones.
Encoding—From simple web delivery for HTML5 to
complex media decision logic that solves demanding studio
workows, Azure Media Services allows you to dene your
own encoding workows.
Indexing—Make your media content deeply searchable.
Using deep neural net (DNN)-based speech recognition
technology from Microsoft Research, Media Indexer converts
digital audio into natural language and automatically extracts
meaningful metadata from your media.
Content protection—Azure Media Services is the only
cloud media solution oering on-the-y encryption for
both video on demand (VOD) and live streams
Azure Media Player—Automatically picks the best format
for a browser or device, using the dynamic packaging
capabilities of Azure Media Services to play adaptive
streaming content in multiple formats. For developers
there’s a simple, unied interface to access APIs.
Common Scenarios
Deliver business video in your organization. The
platform capabilities, combined with partner solutions,
make it easy to integrate video into your apps and
organization - for training, corporate communication,
and meetings. Media Services provides scalable, always-
available, secure delivery of video to both employees and
external customers via Azure.
39
Like developers, apps come in all sizes. Apps once thought
impossible due to scale, complexity, or because they simply
couldn’t be imagined, are now a reality with the cloud. In
this guide we’ve explored the Azure app platform services
and highlighted Azure’s support for platform as a service
(PaaS) in particular. So why consider PaaS as your default
choice? Let’s consider one last analogy.
Phones provide huge social and business advantages. But
laying and maintaining the millions of miles of wire to support
a ubiquitous infrastructure is expensive. Today, phone usage
is growing fastest in Africa. But are they following the path
of Europe, America and others who laid down land lines?
No! In fact, line installation peaked in 2009 with 4 percent
of the population having access to a land line. Instead, they
are leapfrogging landlines and moving directly to cell phones,
which are far cheaper to install and maintain.
In many ways, PaaS is a like the cell phone. It provides greater
functionality, lower upfront investment, and greater developer
productivity than IaaS, eliminating much of the initial
infrastructure requirements and reducing ongoing
maintenance costs. Azure gives developers a comprehensive
PaaS application platform for building, deploying and
managing apps of all kinds, from the simplest website to the
most complex business solution.
Welcome to the developer wave. Welcome to Azure.
Conclusion
Recommended next steps
Be our guest for up to an hour of Azure App Service
experience with no subscription, free of charge and
commitment.
Explore the range of free options available to get you started,
like hosting up to ten free web and mobile apps on Azure
App Service, sending up to one million notications with
Notication Hubs or creating Machine Learning experiments.
Create an Azure account and get started for free with $200
in Azure credit.

Navigation menu
