eProtect™ Integration Guide - Enterprise
January 2018
cnpAPI Release V12.0
eProtect API V3.0
Document Version: 2.7
Vantiv eProtect™ Integration Guide Document Version: 2.7
All information whether text or graphics, contained in this manual is confidential and proprietary information of Vantiv, LLC and is
provided to you solely for the purpose of assisting you in using a Vantiv, LLC product. All such information is protected by copyright laws
and international treaties. No part of this manual may be reproduced or transmitted in any form or by any means, electronic, mechanical or
otherwise for any purpose without the express written permission of Vantiv, LLC. The possession, viewing, or use of the information
contained in this manual does not transfer any intellectual property rights or grant a license to use this information or any software
application referred to herein for any purpose other than that for which it was provided. Information in this manual is presented "as is" and
neither Vantiv, LLC or any other party assumes responsibility for typographical errors, technical errors, or other inaccuracies contained in
this document. This manual is subject to change without notice and does not represent a commitment on the part Vantiv, LLC or any other
party. Vantiv, LLC does not warrant that the information contained herein is accurate or complete.
All trademarks are the property of their respective owners and all parties herein have consented to their trademarks appearing in this
manual. Any use by you of the trademarks included herein must have express written permission of the respective owner.
Copyright © 2003-2018, Vantiv, LLC - ALL RIGHTS RESERVED.
Document Version: 2.7 — cnpAPI Release: 12.0 iii
CONTENTS
© 2018 Worldpay, Inc. - All Rights Reserved.
About This Guide
Intended Audience .............................................................................................................v
Revision History .................................................................................................................v
Document Structure ..........................................................................................................xi
Documentation Set ...........................................................................................................xi
Typographical Conventions ............................................................................................. xii
Contact Information.......................................................................................................... xii
Chapter 1 Introduction
eProtect Overview............................................................................................................. 2
How eProtect Works ......................................................................................................... 4
Getting Started with eProtect ............................................................................................ 6
Migrating From Previous Versions of the eProtect API............................................... 6
From eProtect with jQuery 1.4.2 ........................................................................... 6
From JavaScript Browser API to iFrame............................................................... 7
Browser and Mobile Operating System Compatibility................................................. 8
Communication Protocol Requirement ................................................................. 8
eProtect Support for Apple Pay™ / Apple Pay on the Web ........................................ 8
eProtect Support for Android Pay™............................................................................ 9
eProtect Support for Pay with Google™ ................................................................... 10
eProtect Support for Visa Checkout™ ...................................................................... 10
Getting Started with Visa Checkout .................................................................... 10
Requirements for Using Visa Checkout .............................................................. 11
jQuery Version .......................................................................................................... 12
Certification and Testing Environment ...................................................................... 12
Pre-Live Environment Limitations and Maintenance Schedule........................... 13
Transitioning from Certification to Production ........................................................... 14
eProtect-Specific Response Codes .......................................................................... 14
eProtect Registration ID Duplicate Detection............................................................ 15
Creating a Customized CSS for iFrame.......................................................................... 16
CSS iFrame Validation and Customization Features................................................ 16
Using Web Developer Tools ..................................................................................... 20
Reviewing your CSS with Vantiv............................................................................... 20
Chapter 2 Integration and Testing
Integrating Customer Browser JavaScript API Into Your Checkout Page ...................... 24
Integration Steps....................................................................................................... 24
Loading the eProtect API and jQuery........................................................................ 25
eProtect™ Integration Guide - Enterprise Contents
iv Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
Specifying the eProtect API Request Fields ............................................................. 26
Specifying the eProtect API Response Fields........................................................... 27
Handling the Mouse Click ......................................................................................... 27
Intercepting the Checkout Form Submission ............................................................ 29
Handling Callbacks for Success, Failure, and Timeout............................................. 30
Success Callbacks .............................................................................................. 30
Failure Callbacks................................................................................................. 31
Timeout Callbacks............................................................................................... 32
Detecting the Availability of the eProtect API............................................................ 32
Using the Customer Browser JavaScript API for Apple Pay on the Web.................. 33
Using the Customer Browser JavaScript API for Visa Checkout .............................. 35
Adding Visa Checkout to the eProtect Customer Browser JavaScript API ............... 36
Requesting and Configuring the API Key and externalClientId........................... 36
Sending Vantiv the Required Fields.................................................................... 37
Integrating iFrame into your Checkout Page .................................................................. 38
Integration Steps....................................................................................................... 38
Loading the iFrame ................................................................................................... 38
Configuring the iFrame.............................................................................................. 39
Calling the iFrame for the Registration ID ................................................................. 41
Calling the iFrame for the Checkout ID..................................................................... 42
Notes on the PCI Non-Sensitive Value Feature.................................................. 43
Handling Callbacks ................................................................................................... 43
Handling Errors ................................................................................................... 44
Integrating eProtect Into Your Mobile Application........................................................... 46
Creating the POST Request ..................................................................................... 46
Sample Request.................................................................................................. 47
Sample Response............................................................................................... 48
Using the Vantiv Mobile API for Apple Pay ............................................................... 48
Creating a POST Request for an Apple Pay Transaction ................................... 51
Sample Apple Pay POST Request ..................................................................... 52
Sample Apple Pay POST Response................................................................... 53
Using the Vantiv Mobile API for Visa Checkout ........................................................ 53
Sending Vantiv the Required Fields.................................................................... 55
Sample Visa Checkout POST Request............................................................... 55
Sample Visa Checkout POST Response............................................................ 56
Using the Vantiv Mobile API for Android Pay............................................................ 56
Using the Vantiv Mobile API for Pay with Google ..................................................... 59
Collecting Diagnostic Information ................................................................................... 62
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS ........................... 63
Vantiv Online Systems - Acquirer ISO 8583 Message Format ................................. 64
Vantiv Online Systems - 610 Message Format......................................................... 67
eProtect™ Integration Guide - Enterprise Contents
Document Version: 2.7 — cnpAPI Release: 12.0 v
© 2018 Worldpay, Inc. - All Rights Reserved.
Response ............................................................................................................ 68
(HHMI) Host-to-Host Format ..................................................................................... 70
Payment Web Services (PWS) External Payments .................................................. 71
Transaction Examples When Using cnpAPI ................................................................... 75
Transaction Types and Examples............................................................................. 75
Authorization Transactions........................................................................................ 76
Authorization Request Structure ......................................................................... 76
Authorization Response Structure ...................................................................... 77
Sale Transactions ..................................................................................................... 79
Sale Request Structure ....................................................................................... 79
Sale Response Structure .................................................................................... 80
Register Token Transactions .................................................................................... 82
Register Token Request ..................................................................................... 82
Register Token Response................................................................................... 83
Force Capture Transactions...................................................................................... 84
Force Capture Request....................................................................................... 84
Force Capture Response .................................................................................... 85
Capture Given Auth Transactions............................................................................. 86
Capture Given Auth Request .............................................................................. 86
Capture Given Auth Response ........................................................................... 88
Credit Transactions ................................................................................................... 89
Credit Request Transaction ................................................................................ 89
Credit Response ................................................................................................. 90
Testing and Certification ................................................................................................. 92
Testing eProtect Transactions .................................................................................. 93
Appendix A Code Samples and Other Information
HTML Checkout Page Examples.................................................................................... 98
HTML Example for Non-eProtect Checkout Page .................................................... 98
HTML Example for JavaScript API-Integrated Checkout Page................................. 99
HTML Example for Hosted iFrame-Integrated Checkout Page............................... 102
Information Sent to Order Processing Systems............................................................ 106
Information Sent Without Integrating eProtect ........................................................ 106
Information Sent with Browser-Based eProtect Integration .................................... 106
Information Sent with Mobile API-Based Application Integration ............................ 107
cnpAPI Elements for eProtect....................................................................................... 108
cardValidationNum.................................................................................................. 109
checkoutId............................................................................................................... 110
expDate................................................................................................................... 111
paypage .................................................................................................................. 112
paypageRegistrationId ............................................................................................ 113
eProtect™ Integration Guide - Enterprise Contents
vi Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
registerTokenRequest............................................................................................. 114
registerTokenResponse .......................................................................................... 115
token ....................................................................................................................... 116
Appendix B CSS Properties for iFrame API
CSS Property Groups ................................................................................................... 118
Properties Excluded From White List............................................................................ 132
Appendix C Sample eProtect Integration Checklist
Index
Document Version: 2.7 — cnpAPI Release: 12.0 v
© 2018 Worldpay, Inc. - All Rights Reserved.
ABOUT THIS GUIDE
This guide provides information on integrating eProtect, which, when used together with
Omnitoken, will reduce your exposure to sensitive cardholder data and significantly reduce your
risk of payment data theft. It also explains how to perform eProtect transaction testing and
certification with Vantiv.
Intended Audience
This document is intended for technical personnel who will be setting up and maintaining
payment processing.
Revision History
This document has been revised as follows:
NOTE:The PayPage product is now known as Vantiv eProtect. The term
‘PayPage’ however, is still used in this guide in certain text descriptions,
along with many data elements, JS code, and URLs. Use of these data
elements, etc., with the PayPage name is still valid with this release, but
will transition to ‘eProtect’ in a future release.
TABLE 1 Document Revision History
Doc.
Version Description Location(s)
1.0 Initial Release All
1.1 Updated with revised URL for sample POST. 2.2
About This Guide Revision History
vi Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.2 Updated to include Vantiv-Hosted PayPage iFrame solution
(many changes and re-arrangement of sections). Also includes
addition of Appendix B, and new HTML and JavaScript samples
in Appendix A, PayPage iFrame Solution (many changes and
re-arrangement of sections).
All
‘Migrating From Previous Versions of the PayPage API.’
‘PayPage Certification, Testing, and Production URLs for mobile
POST.'
Example for credit response code mappings for ISO 8583.
1.3 Support for PCI Non-Sensitive values through PayPage. Sections
2.1.5, 2.2.4,
2.2.5, 2.3.1,
2.3.1.1
Updating Handling Callbacks section for handling errors
differently depending on whether they are user error
(recoverable) and non-user error (non-recoverable).
1.4 Added link for iFrame CSS demo site. Sections
1.3.6, 1.3.7,
2.2.3, 2.2.5,
2.3.1
Added PayPage iFrame-Specific Response Codes.
Added new optional Common Property parameters for
configuring iFrame.
Updated code to reflect revisions.
Updated information on testing URLs and User Agent examples.
1.5 Added new Native Applications on Mobile Operating Systems. Sections
1.3.2, 1.3.1.2
Added step for JavaScript Browser API to Vantiv-Hosted iFrame
on creating cascade style sheet.
1.6 Updated product name in applicable areas throughout the guide
from PayPage to eProtect (Phase 1). Updated many instances
of PayFrame to iFrame.
ALL, Sections
1.1, 1.3.4,
Documen-
tation Set,
Chapter 2
Updated the eProtect workflow diagrams and steps.
Change term to iFrame from Vantiv-Hosted.
Update with applicable support & contact information.
1.3.4 - Corrected iFrame link in Certification and Testing
Environments.
Added Online Developer Platform (ODP).
TABLE 1 Document Revision History (Continued)
Doc.
Version Description Location(s)
Revision History About This Guide
Document Version: 2.7 — cnpAPI Release: 12.0 vii
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.7 Added information on obtaining CSS sample files from Vantiv. Chapter 1,
Appendix B
Increased recommended transaction timeout value to 15000 (15
seconds) from 5000 (five seconds).
Chapter 2,
Appendix A
and C
'CC Num - Token Generated' field has '1' value replaced with
'&#' to avoid PCI sensitive values within document.
Appendix A,
Section 1.3
1.8 Updated the paypageRegistrationId value to
‘1111222233330001.’
Section
2.3.1.2
Added information on using the pciNonSensitive value in the
iFrame and POST requests.
Sections
2.2.4 and
2.3.1
1.9 Added information on maximum length and data type for
orderId and id parameters.
Sections
2.1.3, 2.2.4,
and 2.3.1
1.10 Added additional information on the PCI non-sensitive value. Section 2.2.4.
1.11 Re-arranged the example section and added a note related to
eProtect and PWS (only available to existing PWS customers).
Section 2.6
Removed the sample JavaScripts in Appendix A. Sample scripts
are available at the pre-live, post-live, and production eProtect
URLs.
Section 1.3.4,
Appendix A.3
1.12 Added information on LitleXML elements, example transactions,
response codes used for eProtect.
Section 1.3,
2.6, 2.7,
Appendix A
Added notes to LitleXML transaction examples related to
expiration dates (required for eProtect transactions).
Section 2.7
1.13 Added information on loading the JavaScript API (must be
loaded daily to your checkout page).
Chapter 2
1.14 Added notes to recommend eProtect testing using different
devices and all browsers.
Chapter 1
and 2
TABLE 1 Document Revision History (Continued)
Doc.
Version Description Location(s)
About This Guide Revision History
viii Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.15 Added information on API V3 JavaScript (updated URLs and
code examples); updated the XML examples to reference
LitleXML 11.0.
Chapter 1
and 2
Updated testing information with card numbers; added
information on testing on multiple devices and browsers.
Chapter 2
Updated the descriptions of id and orderId fields/elements. Chapter 2
Added a table of TPS Response Codes to the example section
for the 610 messaging format.
Chapter 2
Added recommendation on avoiding ‘Flash of Un-styled Content’
(FOUC) issues.
Chapter 2
1.16 Added information on new support for Apple Pay and Android
Pay.
Chapter 1
and 2
2.0 Updated all URLs (JavaScript library request, submission
request, etc.) due to retirement of Litle domain.
Chapter 1
and 2
Added note on informing customer of JavaScript requirement. Chapter 2
Added additional information on using the eCommerce option in
610 messages.
Chapter 2
Updated most instances of ‘PayFrame’ with ‘iFrame.’ All
Updated numerous function and object names (due to
retirement of Litle name) with Vaniv, Vantivcnp or eProtect, etc.;
also changed instances of ‘LitleXML’ to ‘’ due to change in
product name.
All
Updated cnpAPI version to 11.1. Chapter 2
2.1 Added information on new enhancements to iFrame for greater
iFrame and CSS customizations, including in-line field
validations, tool tip additions and customizations, etc.
Chapter 1
and Chapter
2
Added information on support for Visa Checkout™. Note: the
new sections are for information purposes only, as Visa
Checkout is not generally available with this release.
Chapter 1
and Chapter
2
2.2 Updated the testlitle.com sample page URLs to
testvantivcnp.com. Added further information on which sample
page URL to view when using the new enhanced iFrame
features.
Chapter 1
TABLE 1 Document Revision History (Continued)
Doc.
Version Description Location(s)
Revision History About This Guide
Document Version: 2.7 — cnpAPI Release: 12.0 ix
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3 Added information on the new CVV low-value token
(checkoutId) feature for iFrame and JS Customer Browser API,
including new response codes, checkoutIdMode and the
getCheckoutId function.
Chapter 1
and 2
Added information on the new cnpAPI element, <checkoutId>. Appendix A
Removed information and the URL for post-live regression
testing as it is not applicable to Enterprise merchants.
Chapter 1
Corrected the Request Submission URL in Table 1-2 from
https://request-eprotect.vantivprelive.com to
https://request.eprotect.vantivprelive.com.
Chapter 1
Added information on Pre-Live Certification Environment
maintenance and limitations.
Chapter 1
Removed notes on non-general availability for Visa Checkout; it
is now generally available to all merchants.
Chapter 1
and 2
Added information on eProtect Registration ID Duplicate
Detection.
Chapter 1
2.4 Added information on required communication protocol. Chapter 1
Corrected some instances of ‘eProtect’ in code samples. Appendix A
2.5 Minor correction to code examples in section A.1.3. Appendix A
2.6 Updated all cnpAPI element names to replace Litle with cnp. For
example, litleToken is now cnpToken, litleOnlineRequest is now
cnpOnlineRequest, etc. This includes the namespace:
http://www.litle.com/schema is now
http://www.vantivcnp.com/schema.
Chapter 2
Corrected various eProtect element spelling errors, cleaned up
miscellaneous coding in the HTML examples.
Chapter 2
and Appendix
A
Re-worked Section 1.3.9, Creating a Customized CSS for
iFrame for better clarification.
Chapter 1
Added information on new CSS-allowed Appearance properties. Appendix B
TABLE 1 Document Revision History (Continued)
Doc.
Version Description Location(s)
About This Guide Revision History
xDocument Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.7 Re-arranged and relocated the Creating a Customized CSS for
iFrame section for better understanding.
Chapter 1
Added information on including a ‘Trust Icon’ on your payment
page when customizing iFrame CSS files.
Chapter 1
Removed workaround information for Flash of Unstyled Content
(FOUC) as this issue has been corrected.
Chapter 2
Added information on Pay With Google. Chapter 1
and 2
TABLE 1 Document Revision History (Continued)
Doc.
Version Description Location(s)
Document Structure About This Guide
Document Version: 2.7 — cnpAPI Release: 12.0 xi
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Document Structure
This manual contains the following sections:
Chapter 1, "Introduction"
This chapter provides an overview of the eProtect feature, and the initial steps required to get
started with eProtect.
Chapter 2, "Integration and Testing"
This chapter describes the steps required to integrate the eProtect feature as part of your checkout
page, transaction examples, and information on eProtect Testing and Certification.
Appendix A, "Code Samples and Other Information"
This appendix provides code examples and reference material related to integrating the eProtect
feature.
Appendix B, "CSS Properties for iFrame API"
This appendix provides a list of CSS Properties for use with the iFrame implementation of
eProtect.
Appendix C, "Sample eProtect Integration Checklist"
This appendix provides a sample of the eProtect Integration Checklist for use during your
Implementation process.
Documentation Set
For additional information, see the following Vantiv documentation:
Acquirer ISO 8583 Message Format (Effective 02.15.2017)
Vantiv Online Systems 610 Interface Reference Guide (Effective 02.15.2017)
HHMI: Host-To-Host Format Specification (Effective Date 02.15.2017)
""
Payment Web Services (PWS) External Payments Developers' Guide (V6.1.2)
Payment Web Services (PWS) Release Notes v6.1.2 and higher
Payment Web Services (PWS) Frequently Asked Questions
Vantiv cnpAPI Reference Guide
NOTE:Using eProtect in combination with PWS is available to existing PWS
customers only.
About This Guide Typographical Conventions
xii Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Typographical Conventions
Table 2 describes the conventions used in this guide.
Contact Information
This section provides contact information for organizations within Vantiv.
Implementation - For technical assistance related to eProtect issues encountered during the
testing and certification process, please contact your assigned Vantiv Conversion Manager or
eProtect Implementation Consultant. If you do not have an assigned Implementation Consultant,
please contact your Relationship Manager.
Vantiv Contact Center - For technical issues related to eProtect in production.
Relationship Management- For non-technical issues, please contact your Vantiv Relationship
Manager.
TABLE 2 Typographical Conventions
Convention Meaning
.
.
.
Vertical ellipsis points in an example mean that information not directly
related to the example has been omitted.
. . . Horizontal ellipsis points in statements or commands mean that parts of
the statement or command not directly related to the example have been
omitted.
< > Angle brackets are used in the following situations:
user-supplied values (variables)
XML elements
[ ] Brackets enclose optional clauses from which you can choose one or
more option.
bold text Bold text indicates emphasis.
Italicized text Italic type in text indicates a term defined in the text, the glossary, or in
both locations.
blue text Blue text indicates a hypertext link.
Contact 1-866-622-2390
Hours Available 24/7 (seven days a week, 24 hours a day)
Document Version: 2.7 — cnpAPI Release: 12.0 1
© 2018 Worldpay, Inc. - All Rights Reserved.
1
INTRODUCTION
This chapter provides an introduction and an overview of Vantiv eProtect™. The topics discussed
in this chapter are:
eProtect Overview
How eProtect Works
Getting Started with eProtect
Migrating From Previous Versions of the eProtect API
eProtect Support for Apple Pay™ / Apple Pay on the Web
eProtect Support for Android Pay™
eProtect Support for Pay with Google™
eProtect Support for Visa Checkout™
Creating a Customized CSS for iFrame
NOTE:The PayPage product is now known as Vantiv eProtect. The term
‘PayPage’ however, is still used in this guide in certain text descriptions,
along with many data elements, JS code, and URLs. Use of these data
elements, etc., with the PayPage name is still valid with this release, but
will transition to ‘eProtect’ in a future release.
Introduction eProtect Overview
2Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.1 eProtect Overview
Vantiv's eProtect and OmniToken solutions help solve your card-not-present challenges by
virtually eliminating payment data from your order handling systems, transferring the ownership
to Vantiv and reducing PCI applicable controls.
The eProtect feature controls the fields on your checkout page that hold sensitive card data. When
the cardholder submits their account information, your checkout page calls the eProtect
JavaScript to register the provided credit card for a token. The JavaScript API validates, encrypts,
and passes the account number to our system as the first step in the form submission. The return
message includes the Registration ID in place of the account number. No card data is actually
transmitted via your web server.
Vantiv ensures high service availability for eProtect by implementing primary and secondary
endpoints (i.e., routing to a secondary site if the primary site is unavailable). High availability is
supported when using the eProtect JavaScript API V.3; it is not available for the Mobile API
option.
Vantiv provides three integration options for eProtect:
iFrame API - this solution builds on the same architecture of risk- and PCI scope-reducing
technologies of eProtect by fully hosting fields with PCI-sensitive values. Payment card
fields, such as primary account number (PAN), expiration date, and CVV2 values are hosted
from our PCI-Compliance environment, rather than embedded as code into your checkout
page within your environment.
JavaScript Customer Browser API - controls the fields on your checkout page that hold
sensitive card data. When the cardholder submits his/her account information, your checkout
page calls the eProtect JavaScript to register the provided credit card for a token. The
JavaScript validates, encrypts, and passes the account number to our system as the first step
in the form submission. The return message includes the Registration ID in place of the
account number. No card data is actually transmitted via your web server.
Mobile API - eProtect Mobile Native Application allows you to use the eProtect solution to
handle payments without interacting with the eProtect JavaScript in a browser. With Mobile
Native Application, you POST an account number to our system and receive a Registration
ID in response. You can use it in native mobile applications--where the cross-domain
limitations of a browser don't apply--to replace payment card data from your web servers.
For more information on PCI compliance and the Vantiv eProtect product, see the Vantiv eProtect
iFrame Technical Assessment Paper, prepared by Coalfire IT Audit and Compliance.
Figure 1-1 illustrates eProtect with Omnitoken. See the section, How eProtect Works on page 4
for additional details.
NOTE:In order to optimally use the eProtect feature for risk reduction, this
feature must be used at all times, without exception.
eProtect Overview Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 3
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
FIGURE 1-1 eProtect
Introduction How eProtect Works
4Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.2 How eProtect Works
This section illustrates the eProtect process.
1. When your customer is ready to finalize a purchase from your website or mobile application,
your web server delivers your Checkout form to the customers web browser or mobile
device.
2. If using the iFrame API, the browser loads the iFrame URL hosted by the eProtect server. If
using the JavaScript API, the browser loads the eProtect Client code (JavaScript) from the
eProtect server. The API validates credit cards, submits account numbers to the eProtect
Service, encrypts account numbers, and adds the Registration IDs to the form. It also contains
Vantiv' s public encryption key.
(continued on next page)
Step 1
Step 2
How eProtect Works Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 5
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
3. After the customer enters their card number and clicks or taps the submit button, the eProtect
APIs sends the card number data to our eProtect service which calls our Security Services
vault or submits a cnpAPI transaction to register an OmniToken for the card number
provided. The token is securely stored in Enterprise Security Services for processing (when
your payment processing system submits an authorization or sale transaction). A Registration
ID is generated and returned to the customer's browser as a hidden field for web processing,
or to their mobile device as a POST response.
4. All of the customer-provided information is then delivered to your web server along with the
Registration ID. Your payment processing system sends the payment with the Registration
ID, and Enterprise Security Services vault maps the Registration ID to the OmniToken and
card number, processing the payment as usual. The response message from the applicable
Vantiv front end contains the OmniToken value, which you store as you would a credit card.
Step 3
Step 4
Introduction Getting Started with eProtect
6Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.3 Getting Started with eProtect
Before you start using the eProtect feature, you must complete the following:
Ensure that your organization is enabled and certified to process OmniTokens, using the
OmniToken solution.
Complete and return the eProtect Integration Checklist provided by your Implementation
Consultant and return to Implementation. See Appendix C, "Sample eProtect Integration
Checklist".
Obtain a PayPage ID from your eProtect Implementation Consultant.
If you are implementing the iFrame solution, create a Cascading Style Sheet (CSS) to
customize the look and feel of the iFrame to match your checkout page, then submit the Style
Sheet to Vantiv for verification. See Creating a Customized CSS for iFrame on page 16 for
more information.
Modify your checkout page or mobile native application--and any other page that receives
credit card data from your customers--to integrate the eProtect feature (execute an API call or
POST to our system). See one of the following sections, depending on your application:
Integrating Customer Browser JavaScript API Into Your Checkout Page on page 24
Integrating iFrame into your Checkout Page on page 38
Integrating eProtect Into Your Mobile Application on page 46 for more information.
Modify your system to accept the response codes listed in Table 1-3, eProtect-Specific
Response Codes Received in Browsers or Mobile Devices and Table 1-4, eProtect Response
Codes Received in cnpAPI Responses.
Test and certify your checkout process. See Transaction Examples When Using ISO 8583,
610, HHMI, and PWS on page 63 for more information.
1.3.1 Migrating From Previous Versions of the eProtect API
1.3.1.1 From eProtect with jQuery 1.4.2
Previous versions of the eProtect API included jQuery 1.4.2 (browser-based use only). Depending
on the implementation of your checkout page and your use of other versions of jQuery, this may
result in unexpected behavior. This document describes version 2 of the eProtect API, which
requires you to use your own version of jQuery, as described within.
If you are migrating, you must:
Include a script tag to download jQuery before loading the eProtect API.
Construct a new eProtect API module when calling sendToEprotect.
Getting Started with eProtect Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 7
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.3.1.2 From JavaScript Browser API to iFrame
When migrating from the JavaScript Customer Browser API eProtect solution to the iFrame
solution, complete the following steps. For a full HTML code example a iFrame eProtect
implementation, see the HTML Example for Hosted iFrame-Integrated Checkout Page on page
102.
1. Remove the script that was downloading eProtect-api3.js.
2. Add a script tag to download eprotect-iframe-client3.min.js.
3. On your form, remove the inputs for account number, cvv, and expiration date. Put an empty
div in its place.
4. Consolidate the three callbacks (submitAfterEprotect, onErrorAfterEprotect and
onTimeoutAfterEprotect in our examples) into one callback that accepts a single
argument. In our example, this is called eProtectiframeClientCallback.
5. To determine success or failure, inspect response.response in your callback. If
successful, the response is ‘870.’ Check for time-outs by inspecting the
response.timeout; if it is defined, a timeout has occurred.
6. In your callback, add code to retrieve the paypageRegistrationId, bin, expMonth and
expYear. Previously, paypageRegistrationId and bin were placed directly into your
form by our API, and we did not handle expMonth and expYear (we’ve included these
inside our form to make styling and layout simpler).
7. Create a Cascading Style Sheet (CSS) to customize the look and feel of the iFrame to match
your checkout page, then submit the Style Sheet to Vantiv for verification. See Creating a
Customized CSS for iFrame on page 16 and Configuring the iFrame on page 39 for more
information.
8. See Calling the iFrame for the Registration ID on page 41 to retrieve the
paypageRegistrationId.
Introduction Getting Started with eProtect
8Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.3.2 Browser and Mobile Operating System Compatibility
The eProtect feature is compatible with the following (see Table 1-1, "Apple Pay on the Web
Compatible Devices" for information on Apple Pay web):
Browsers (when JavaScript is enabled):
Mozilla Firefox 3 and later
Internet Explorer 8 and later
Safari 4 and later
Opera 10.1 and later
Chrome 1 and later
Native Applications on Mobile Operating Systems:
Chrome Android 40 and later
Android 2.3 and later
Apple iOS 3.2 and later
Windows Phone 10 and later
Blackberry 7, 10 and later
Other mobile OS
1.3.2.1 Communication Protocol Requirement
If you are using an MPLS network, Vantiv requires that you use TLS 1.2 encryption.
1.3.3 eProtect Support for Apple Pay™ / Apple Pay on the Web
Vantiv supports Apple Pay for in-app and in-store purchases initiated on compatible versions of
iPhone and iPad, as well as purchases from your desktop or mobile website initiated from
compatible versions of iPhone, iPad, Apple Watch, MacBook and iMac (Apple Pay on the Web).
If you wish to allow Apple Pay transactions from your native iOS mobile applications, you must
build the capability to make secure purchases using Apple Pay into your mobile application. The
operation of Apple Pay on the iPhone and iPad is relatively simple: either the development of a
new native iOS application or modification of your existing application that includes the use of
IMPORTANT:Because browsers differ in their handling of eProtect transactions,
Vantiv recommends testing eProtect on various devices (including
smart phones and tablets) and all browsers, including Internet
Explorer/Edge, Google Chrome, Apple Safari, and Mozilla Firefox.
Getting Started with eProtect Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 9
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
the Apple PassKit Framework, and the handling of the encrypted data returned to your application
by Apple Pay. See Using the Vantiv Mobile API for Apple Pay on page 42 for more information.
For Apple Pay on the Web, integration requires that the <applepay> field be included in the
sendToEprotect call when constructing your checkout page with the JavaScript Customer
Browser API. See Integrating Customer Browser JavaScript API Into Your Checkout Page on
page 22 and Using the Customer Browser JavaScript API for Apple Pay on the Web on page 30
for more information on the complete process. Also, see Table 1-1, Apple Pay on the Web
Compatible Devices for further information on supported Apple devices.
1.3.4 eProtect Support for Android Pay™
Android Pay is an in-store and in-app (mobile or web) payment method, providing a secure
process for consumers to purchase goods and services. In-store purchases are done by using Near
Field Communication (NFC) technology built into the Android Smart phone with any
NFC-enabled terminal at the retail POS. For in-app purchases, the consumer need only select
Android Pay as the payment method in your application. You will need to modify your
application to use Android Pay as a payment method.
NOTE:Table 1-1 represents data available at the time of publication, and is
subject to change. See the latest Apple documentation for current
information.
TABLE 1-1 Apple Pay on the Web Compatible Devices
Apple Device Operating System Browser
iPhone 6 and later
iPhone SE
iOS 10 and later
Safari only
iPad Pro
iPad Air 2 and later
iPad Mini 3 and later
iOS 10 and later
Apple Watch
Paired with iPhone 6 and later
Watch OS 3 and later
iMac
Paired with any of the above mobile
devices with ID Touch for
authentication
macOS Sierra and later
MacBook
Paired with any of the above mobile
devices with ID Touch for
authentication
macOS Sierra and later
Introduction Getting Started with eProtect
10 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Vantiv supports two methods for merchants to submit Android Pay transactions from Web/Mobile
applications to the eCommerce platform. The preferred method involves you sending certain
Vantiv specific parameters to Google®. The response from Google includes a Vantiv
paypageRegistrationId, which you use in you payment transaction submission to Vantiv.
With the alternate method, you receive encrypted information from Google, decrypt it on your
servers, and submit the information to Vantiv in a payment transaction. See Using the Vantiv
Mobile API for Android Pay on page 56 for more information.
1.3.5 eProtect Support for Pay with Google™
Pay With Google is an on-line payment method that lets your customers use the cards they've
saved to their Google Account to pay quickly and easily in your apps. and on your websites. By
clicking the Pay with Google button, customers can choose a payment method saved in their
Google Account and finish checkout in a few, simple steps.
You can use the Google Payment API to simplify payments for customers who make purchases in
Android apps or on Chrome with a mobile device.
Vantiv supports two methods for merchants to submit Pay with Google transactions from Mobile
applications to the eCommerce platform. The preferred method involves you sending certain
Vantiv-specific parameters to Google. The response from Google includes a Vantiv
paypageRegistrationId, which you use normally in your payment transaction submission to
Vantiv. With the alternate method, you receive encrypted information from Google, decrypt it on
your servers, and submit the information to Vantiv in a payment transaction. See Using the Vantiv
Mobile API for Pay with Google on page 59 for more information.
1.3.6 eProtect Support for Visa Checkout™
Visa Checkout™ is a digital payment service in which consumers can store card information for
Visa, MasterCard, Discover, and American Express cards. Visa Checkout provides quick
integration for merchants that want to accept payments from these card holders. Visa Checkout is
flexible and imposes only a few requirements for its use, leveraging your existing
environments--web site and mobile applications--where you add Visa Checkout buttons to
existing pages and implement business and event logic using programming languages, tools, and
techniques in the same way you currently do. Vantiv supports Visa Checkout purchases from your
website or mobile app. initiated from compatible devices.
1.3.6.1 Getting Started with Visa Checkout
NOTE:Parts of this section are excerpts from Visa Checkout documentation and
represents data available at the time of publication of this document, and
is therefore subject to change. See the latest Visa documentation
(https://developer.visa.com/products/visa_checkout/reference) for current
information.
Getting Started with eProtect Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 11
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
The simplest approach to integrating Visa Checkout takes three steps and can be done entirely
from your web page (with the exception of decrypting the consumer information payload on a
secure server). Figure 1-2 illustrates the main steps for getting started with Visa Checkout.
FIGURE 1-2 Getting Started with Visa Checkout
1. Place a Visa Checkout button on your web page and include the necessary JavaScript to
handle events associated with the button.
2. Handle the payment event returned by Visa Checkout by decrypting the consumer
information payload.
3. Update Visa Checkout with the final payment information after the payment has been
processed.
All integration options require that you perform step 1. Sections in this document describes the
method using Vantiv eProtect.
1.3.6.2 Requirements for Using Visa Checkout
This section describes the various requirements for using Visa Checkout.
Usage and Placement of Visa Checkout Buttons: You are required to implement the Visa
Checkout branding requirements on all pages where the consumer is presented payment
method options, such as Visa Checkout or another payment method. Common examples
include shopping cart page, login page, product page, and payment page. Your actual
implementation depends on your specific flow.
You can use Visa Checkout on any web page or in any flow on your site or native mobile
application where a consumer is asked to type in their billing and payment information.
Common examples include cart pages (both full and mini) pages, payment pages, card-on-file
management pages, or immediately before a flow where a consumer is prompted for personal
information, which may be available, at least partially, within Visa Checkout.
Introduction Getting Started with eProtect
12 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
See the latest Visa Checkout Integration Guide for more information and to learn how placing
Visa Checkout buttons on the shopping cart page and your login page might work.
Clickjacking Prevention Steps: To prevent clickjacking of your pages, each page must
contain JavaScript to verify that there are no transparent layers, such as might be the case if
your page was loaded as an iFrame of a page containing malicious code, and that only your
site can load your pages.
See the latest Visa Checkout Integration Guide for more information on preventing
clickjacking.
Obtaining the externalClientId from Vantiv: During the on-boarding process, Vantiv
Implementation assigns an externalClientId to denote the relationship between Vantiv,
your organization and Visa.
Updating Visa Checkout with the Payment Information: After you finish making a
payment (and perhaps using the information from the payload), you must update the payment
information in Visa Checkout. To update Visa Checkout from a Thank You page (next page to
load after making the payment), you add a one-pixel image to the page.
For more information about the Update Payment Info pixel image, see the latest Visa
Checkout Integration Guide.
See additional information on Using the Customer Browser JavaScript API for Visa Checkout on
page 35 and Using the Vantiv Mobile API for Visa Checkout on page 53.
1.3.7 jQuery Version
If you are implementing a browser-based solution, you must load a jQuery library before loading
the eProtect API. We recommend using jQuery 1.4.2 or higher. Refer to http://jquery.com for
more information on jQuery.
1.3.8 Certification and Testing Environment
For certification and testing of Vantiv feature functionality, Vantiv uses the Pre-Live testing
environment. This environment should be used by both newly on-boarding Vantiv merchants, and
existing merchants seeking to incorporate additional features or functionalities (for example,
eProtect) into their current integrations.
Use the URLs listed in Table 1-2 when testing and submitting eProtect transactions. Sample
JavaScripts are available at pre-live and production eProtect URLs. The following sample scripts
are available:
eProtect JavaScript (eProtect-api3.js)
iFrame Client (eprotect-iframe-client3.js)
iFrame JavaScript (eProtect-iframe.js)
Getting Started with eProtect Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 13
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.3.8.1 Pre-Live Environment Limitations and Maintenance Schedule
When using the pre-live environment for testing, please keep in mind the following limitations
and maintenance schedules:
The number of merchants configured per organization is limited to the number necessary to
perform the required certification testing.
Data retention is limited to a maximum of 30 days.
Merchant profile and data is deleted after seven (7) consecutive days with no activity.
Maintenance window - every other Thursday from 10:00 PM to 6:00 AM ET.
Daily limit of 1,000 Online transactions.
Daily limit of 10,000 Batch transactions.
TABLE 1-2 eProtect Certification, Testing, and Production URLs
Environment URL Purpose URL
Pre-Live
(Testing and
Certification)
JavaScript Library https://request.eprotect.vantivprelive.com/eProtect/eProtect-
api3.js
Request
Submission
(excluding POST)
https://request.eprotect.vantivprelive.com
iFrame https://request.eprotect.vantivprelive.com/eProtect/js/eProtect-
iframe-client3.min.js
POST Request
Submission (for
Mobile API)
https://request.eprotect.vantivprelive.com/eProtect/paypage
API Key Request
(Visa Checkout
only)
https://request.eprotect.vantivprelive.com/eProtect/keys.json
Live
Production
Production Contact your Implementation Consultant for the eProtect
Production URL.
NOTE:Depending upon overall system capacity and/or system maintenance
requirements, data purges may occur frequently. Whenever possible, we will
provide advanced notification.
NOTE:Due to the planned maintenance windows, you should not use this
environment for continuous regression testing.
Introduction Getting Started with eProtect
14 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.3.9 Transitioning from Certification to Production
Before using your checkout form with eProtect in a production environment, replace all instances
of the Testing and Certification URLs listed in Table 1-2 with the production URL. Contact
Implementation for the appropriate production URL. The URLs in the above table and in the
sample scripts throughout this guide should only be used in the certification and testing
environment.
1.3.10 eProtect-Specific Response Codes
Table 1-3 lists response codes specific to the eProtect feature, received in the browser or mobile
device, and those received via the applicable Vantiv message specification responses. Table 1-4
lists those received via a cnpAPI Response. For further information on response codes specific to
token transactions, see the publications listed in Documentation Set on page xi.
TABLE 1-3 eProtect-Specific Response Codes Received in Browsers or Mobile Devices
Response
Code Description Error Type Error Source
870 Success -- --
871 Account Number not Mod10 Validation User
872 Account Number too short Validation User
873 Account Number too long Validation User
874 Account Number not numeric Validation User
875 Unable to encrypt field System JavaScript
876 Account number invalid Validation User
881 Card Validation number not numeric Validation User
882 Card Validation number too short Validation User
883 Card Validation number too long Validation User
884 eProtect iFrame HTML failed to load System Vantiv eComm
885 eProtect iFrame CSS failed load -
<number>
System Vantiv eComm
889 Failure System Vantiv eComm
Getting Started with eProtect Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 15
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.3.11 eProtect Registration ID Duplicate Detection
Vantiv performs duplicate detection reviews on all form fields such as the card number, CVV,
order ID, and Transaction ID. In the event that multiple eProtect registrations are submitted
within a five-minute period containing identical form fields, subsequent requests are flagged as
duplicates, and processed by returning the originating callback response and Registration ID
value.
With this, false positives may occur if your organization has not implemented a policy that
provides a unique Order ID and Transaction ID for every request. If not implemented, you could
potentially receive an incorrect CVV value, which could be disruptive to chargeback processing.
Vantiv strongly recommends that the order ID and transaction ID data elements be unique for
every registration request.
NOTE:For information on response codes specific to OmniToken transactions,
see the applicable Vantiv message interface specification.
TABLE 1-4 eProtect Response Codes Received in cnpAPI Responses
Response
Code Response Message
Response
Type Description
826 Checkout ID was
invalid
Soft
Decline
An eProtect response indicating that the
Checkout ID submitted was too long, too
short, non-numeric, etc.
827 Checkout ID was not
found
Soft
Decline
An eProtect response indicating that the
Checkout ID submitted was expired, or
valid but not found.
828 Generic Checkout ID
error
Soft
Decline
There is an unspecified Checkout ID
error; contact your Relationship
Manager.
877 Invalid PayPage
Registration ID
Hard
Decline
An eProtect response indicating that the
Registration ID submitted is invalid.
878 Expired PayPage
Registration ID
Hard
Decline
An eProtect response indicating that the
Registration ID has expired (Registration
IDs expire 24 hours after being issued).
879 Merchant is not
authorized for
PayPage
Hard
Decline
A response indicating that your
organization is not enabled for the
eProtect feature.
Introduction Creating a Customized CSS for iFrame
16 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.4 Creating a Customized CSS for iFrame
Before you begin using the iFrame solution, you must create a Cascading Style Sheet (CSS) to
customize the look and feel of the iFrame to match your checkout page. After creating and
customizing your style sheet, you then submit the style sheet to Vantiv, where it will be tested
before it is deployed into production. This section describes the various tools and customizations
available for creating your CSS for iFrame and submitting your CSS for review:
CSS iFrame Validation and Customization Features
Using Web Developer Tools
Reviewing your CSS with Vantiv
1.4.1 CSS iFrame Validation and Customization Features
Vantiv offers a set of iFrame validation and customization features to reduce cart abandonment,
increase conversions, and help simplify the payment experience for your customers. See
Configuring the iFrame on page 33 for further information on placement of these properties in
your checkout page.
These features include:
Real-Time In-line Field Validations - while traditional web forms use submit-and-refresh rules
that respond once you click the Submit button, real-time in-line validations can help your
customers fill out web forms faster and with fewer errors. By guiding them with real-time
feedback that instantly confirms whether the values they input are valid, transactions can be more
successful and less error-prone, and customers are more satisfied with their checkout experience.
Payment Form Behaviors - customizable behaviors include:
Empty Input - if your customer clicks back after leaving a payment form (for example, if they
want to edit their payment information or in the case of a timeout, etc.), eProtect detects
whether your customer has attempted to enter new form data.
If they have not entered any new values, you can use the original token for the transaction. If
your customer attempts to enter new values, eProtect clears the form—instead of leaving the
previous entries in place—eliminating the need to erase the old values before re-entering new
values.
Disallowed Characters - allows only numeric values to be entered for the Account Number
and CVC fields (no alpha or special characters are permitted).
Auto-Formatting of account numbers based on the type of card.
NOTE:If you are evaluating your styling options and/or having trouble creating
your own style sheet, Vantiv can provide sample CSS files. Please contact
your assigned Implementation Consultant for sample CSS files.
Creating a Customized CSS for iFrame Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 17
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Client Driven Behaviors - additional capabilities include:
Tooltips - you can add a tool tip for any field (not just security code) activated by hovering, or
when clicking 'What's This?’
Font Library and Icons - Vantiv hosts SVG Icons (Font Awesome, v4.7.0) font library on our
servers for you to leverage in your CSS, using an industry standard icon library for all icons.
Trust Badge - you can add a ‘trust’ badge (e.g., a padlock or shield icon) on the payment form
to reassure your customers that your site is legitimate and that all their personal data is
collected securely through trusted third-party service providers. Note that the trust badge can
be displayed in place of the card graphic; your page cannot display both.
Table 1-5, "iFrame Checkout Page Customizations - In-Line Field Validations" and Table 1-6,
"Style Sheet and iFrame Customizations" show samples of these CSS iFrame customizations and
describes the implementation of each.
When you set the optional enhancedUxFeatures.inlineFieldValidations property to
true when configuring your iFrame, the behaviors listed in Table 1-5 are all included.
TABLE 1-5 iFrame Checkout Page Customizations - In-Line Field Validations
Field Validation Behavior Samples
Card
Number
The iFrame checks the card number for
correct size (too short or too long) and
against the Luhn/Mod10 algorithm.
In this example, if the consumer’s inputs
are valid, you can configure the iFrame to
display green field borders and include a
green check mark. Red borders and a
red ‘X’ can indicate invalid input.
The error messages and frame colors are
customizable in your style sheet.
The iFrame identifies the card type (Visa,
MasterCard, Amex, etc.) based on the
first few digits entered, and displays the
appropriate card graphic. If the card type
is unknown, the iFrame displays a
generic card graphic.
You can configure your style sheet to
hide the card graphic.
In addition, the iFrame auto-formats the
arrangement of the card digits based on
the initial entry.
Introduction Creating a Customized CSS for iFrame
18 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
The items listed in Table 1-6 are also available as optional features controlled by the your style
sheet and via iFrame function. By default, the Tool Tip features are active, but can be suppressed
with the CSS.
Expiration
Date
The iFrame checks the expiration month
to determine if the selected month is prior
to the current month.
Security
Code
The iFrame confirms the logic against the
account number type. For example, if the
card is an American Express card and
the consumer enters only three digits
(should be four digits), an error is
indicated.
TABLE 1-6 Style Sheet and iFrame Customizations
Customization Samples
Trust Badge - You can add a ‘trust badge’
(e.g., a padlock or shield icon) to the
payment form, using the Font Awesome
(V4.7.0) icon library. Note that the trust
badge can be displayed in place of the card
graphic; your page cannot display both.
Tool Tips - you control the following tool tip behavior in your style sheet:
You can add a tool tip for any field (not just
security code) activated by hovering, or
when clicking 'What's This?’
Tool tip displayed after clicking ‘What’s This?’
TABLE 1-5 iFrame Checkout Page Customizations - In-Line Field Validations (Continued)
Field Validation Behavior Samples
Creating a Customized CSS for iFrame Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 19
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
You can configure your style sheet to
activate a tool tip by hovering over the ‘?’
icon (rather than clicking). This is useful for
short statements.
You can also configure a modal dialog to
activate on the click of the second ‘?’ icon
to display more lengthy CSS content.
Modal dialog displayed upon clicking second ‘?’ icon.
Tool Tips (continued)
You can configure your CSS to display a
Security code modal dialog where the tool
tip displays generic card art showing the
placement of CVC on cards. You can hide
this with the CSS, if you choose.
You can also remove the scrollbars, as well
as direct your CSS to auto-size the dialog
based on content.
Modal dialog displayed upon clicking first or second ‘?’
icon at the security code field.
TABLE 1-6 Style Sheet and iFrame Customizations (Continued)
Customization Samples
Introduction Creating a Customized CSS for iFrame
20 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1.4.2 Using Web Developer Tools
By using standard browser-provided web developer tools, you can develop and customize your
CSS prior to sending it to Vantiv for boarding.
To access the developer tool and to customize your CSS:
1. Go to https://www.testvantivcnp.com/iframe/ to access the demo URL and review the
provided style sheet.
If you are using the enhanced iFrame features described in the previous section, CSS iFrame
Validation and Customization Features, use the following URL:
https://www.testvantivcnp.com/checkout/checkout-iframe-enhanced-demo.jsp
2. Right click the Account Number text field, then click Inspect or Inspect Element
(depending on your browser). The browser splits the window into two or more
browser-specific developer frames.
3. Locate the highlighted HTML section in the developer tool frame of the browser where it
shows <input type="text" id="accountNumber"...
4. Scroll up a few lines, and locate the HTML section, <head>…</head>. Expand the section
with the arrow icon (if it is not already expanded).
5. Locate the HTML section <style>…</style>, which is the last child of the <head/>
element, and expand it.
6. Double click the content, delete it, then paste in your new style sheet. To make the new CSS
style effective, simply click somewhere else to exit the editing mode.
7. Copy and paste the CSS file and send it to your Vantiv Implementation Consultant for review.
1.4.3 Reviewing your CSS with Vantiv
Vantiv reviews your CSS by an automatic process which has white-listed allowed CSS properties
and black-listed, ‘dangerous’ CSS values (such as URL, JavaScript, expression). Properties
identified as such have been removed from the white list, and if used, will fail verification of the
CSS. See Table B-24, "CSS Properties Excluded From the White List (not allowed)" for those
properties not allowed.
If an error is detected, Vantiv returns the CSS for correction. If the CSS review is successful, the
CSS is uploaded to the your eProtect configuration.
Note the following:
If additional properties and/or values are introduced in future CSS versions, those properties
and values will be automatically black-listed until Vantiv can review and supplement the
white-listed properties and values.
Certain properties allow unacceptable values, including URL, JavaScript, or expression. This
includes the content property, which allows you to enter ‘Exp Date’ instead of our provided
Creating a Customized CSS for iFrame Introduction
Document Version: 2.7 — cnpAPI Release: 12.0 21
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
‘Expiration Date’ label. If the property contains a URL, JavaScript, expression, or
attr(href), Vantiv will fail verification of the CSS.
Any property in the white list also allows its browsers extended values, where applicable.
See https://www.testvantivcnp.com/iframe/ to view a simple iFrame example.
To view an iFrame example checkout page using the enhanced features described in CSS iFrame
Validation and Customization Features on page 16, use the following URL:
https://www.testvantivcnp.com/checkout/checkout-iframe-enhanced-demo.jsp
Introduction Creating a Customized CSS for iFrame
22 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Document Version: 2.7 — cnpAPI Release: 12.0 23
© 2018 Worldpay, Inc. - All Rights Reserved.
2
INTEGRATION AND TESTING
This chapter describes the steps required to integrate the eProtect™ feature as part of your
checkout page, transaction examples, and information on eProtect testing and certification. The
sections included are:
Integrating Customer Browser JavaScript API Into Your Checkout Page
Integrating iFrame into your Checkout Page
Integrating eProtect Into Your Mobile Application
Collecting Diagnostic Information
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
Transaction Examples When Using cnpAPI
Testing and Certification
NOTE:The PayPage product is now known as Vantiv eProtect. The term
‘PayPage’ however, is still used in this guide in certain text descriptions,
along with many data elements, JS code, and URLs. Use of these data
elements, etc., with the PayPage name is still valid with this release, but
will transition to ‘eProtect’ in a future release.
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
24 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1 Integrating Customer Browser JavaScript API Into
Your Checkout Page
This section provides step-by-step instructions for integrating the Customer Browser JavaScript
API eProtect solution into your checkout page. This section also provides information on the
following payment methods:
Using the Customer Browser JavaScript API for Apple Pay on the Web
Using the Customer Browser JavaScript API for Visa Checkout
See Integrating eProtect Into Your Mobile Application on page 46 for more information on the
mobile solution.
See Integrating iFrame into your Checkout Page on page 38 for more information on the iFrame
solution.
2.1.1 Integration Steps
Integrating eProtect into your checkout page includes these steps, described in detail in the
sections to follow:
1. Loading the eProtect API and jQuery
2. Specifying the eProtect API Request Fields
3. Specifying the eProtect API Response Fields
4. Handling the Mouse Click
5. Intercepting the Checkout Form Submission
6. Handling Callbacks for Success, Failure, and Timeout
7. Detecting the Availability of the eProtect API
The above steps make up the components of the sendToEprotect call:
sendToEprotect(eProtectRequest, eProtectFormFields, successCallback, errorCallback,
timeoutCallback, timeout)
• eProtectRequest - captures the form fields that contain the request parameters (paypageId ,
url, etc.)
• eProtectFormFields - captures the form fields used to set various portions of the eProtect
registration response (Registration Id, Checkout Id, response reason code, response reason
message, etc.).
• successCallback - specifies the method used to handle a successful eProtect registration.
• errorCallback - specifies the method used to handle a failure event (if error code is
received).
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 25
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
• timeoutCallback - specifies the method used to handle a timeout event (if the
sendToEprotect
exceeds the timeout threshold).
•timeout - specifies the number of milliseconds before the timeoutCallback is invoked.
JavaScript code examples are included with each step. For a full HTML code example of the
eProtect implementation, see the HTML Checkout Page Examples on page 98.
2.1.2 Loading the eProtect API and jQuery
To load the eProtect client JavaScript library from the eProtect application server to your
customer's browser, insert the following JavaScript into your checkout page. Note that a version
of the jQuery JavaScript library must be loaded by your checkout page before loading the
eProtect client JavaScript library.
This example uses a Google-hosted version of the jQuery JavaScript library. You may choose to
host the library locally. We recommend using version 1.4.2 or higher.
<head>
...
<script
src="https://ajax.googleapis.com/ajax/libs/jquery/1.4.2/jquery.min.js"
type="text/javascript">
</script>
<script
src="https://request.eprotect.vantivprelive.com/eProtect/eProtect-api3.js"
type="text/javascript">
</script>
...
</head>
NOTE:To avoid disruption to transaction processing, Vantiv recommends you
download the latest JavaScript client to your checkout page a minimum of
once per day (due to frequent changes to the JavaScript client). Vantiv
does not recommend caching the eProtect JavaScript client on your
servers.
NOTE:The URL in this example script (in red) should only be used in the
certification and testing environment. Before using your checkout page
with eProtect in a production environment, replace the certification URL
with the production URL (contact your Implementation Consultant for the
appropriate production URL).
Do not use this URL in a
production environment.
Contact Implementation for the
appropriate production URL.
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
26 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1.3 Specifying the eProtect API Request Fields
To specify the eProtect API request fields, add hidden request fields to your checkout form for
paypageId (a unique number assigned by eProtect Implementation), merchantTxnId,
orderId, and reportGroup (cnpAPI elements). Optionally, you can include the checkoutId
when CheckoutIdMode is set to true. You have control over the naming of these fields.
The values for paypageId and reportGroup will likely be constant in the HTML. The value
for the orderId passed to the eProtect API can be generated dynamically.
<form
<input type="text" id="ccNum" size="20">
<input type="text" id="cvv2Num" size="4">
<input type="text" id="paypageRegistrationId" name="paypageRegistrationId"
readonly="true" hidden>
<input type="text" id="checkoutId" name="checkoutId" readonly="true" hidden>
<input type="text" id="bin" name="bin" readonly="true" hidden>
<input type="hidden" id="request$paypageId" name="request$paypageId"
value="a2y4o6m8k0"/>
<input type="hidden" id="request$merchantTxnId" name="request$merchantTxnId"
value="987012"/>
<input type="hidden" id="request$orderId" name="request$orderId" value="order_123"/>
<input type="hidden" id="request$reportGroup" name="request$reportGroup"
value="*merchant1500"/>
...
</form>
NOTE:The orderId field must be a text string with a maximum of 25 characters.
The values for either the merchantTxnId or the orderId must be unique
so that we can use these identifiers for reconciliation or troubleshooting.
TABLE 2-1 eProtectFormFields Definitions
Field Description
ccNum (Optional) The credit card account number. Not applicable
when checkoutIdMode is set to true.
cvv2Num (Optional) The card validation number, either the CVV2
(Visa), CVC2 (MasterCard), or CID (American Express and
Discover) value.
paypageRegistrationId (Required) The temporary identifier used to facilitate the
mapping of a token to a card number. Not applicable when
checkoutIdMode is set to true.
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 27
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1.4 Specifying the eProtect API Response Fields
To specify the eProtect API Response fields, add hidden response fields on your checkout form
for storing information returned by eProtect: paypageRegistrationId, checkoutId, bin,
code, message, responseTime, type, and vantivTxnId. You have flexibility in the naming
of these fields.
<form
...
<input type="hidden" id="response$paypageRegistrationId"
name="response$paypageRegistrationId" readOnly="true" value=""/>
<input type="hidden" id="response$checkoutId" name="response$checkoutId"
readOnly="true" value=""/>
<input type="hidden" id="response$bin" name="response$bin" readOnly="true"/>
<input type="hidden" id="response$code" name="response$code" readOnly="true"/>
<input type="hidden" id="response$message" name="response$message"
readOnly="true"/>
<input type="hidden" id="response$responseTime" name="response$responseTime"
readOnly="true"/>
<input type="hidden" id="response$type" name="response$type" readOnly="true"/>
<input type="hidden" id="response$vantivTxnId" name="response$vantivTxnId"
readOnly="true"/>
<input type="hidden" id="response$firstSix" name="response$firstSix"
readOnly="true"/>
<input type="hidden" id="response$lastFour" name="response$lastFour"
readOnly="true"/>
...
</form>
2.1.5 Handling the Mouse Click
In order to call the eProtect JavaScript API on the checkout form when your customer clicks the
submit button, you must add a jQuery selector to handle the submission click JavaScript event.
The addition of the click event creates a eProtect Request and calls sendToEprotect.
The sendToEprotect call includes a timeout value in milliseconds. If the response from the
primary server takes more than five (5) seconds, the request is automatically sent to our
checkoutId (Optional) The low-value token ID exchanged for the CVV
value, when checkoutIdMode is set to true. (Checkout Id
Mode can be used when you store the high-value token
(Registration Id) on file for a consumer, but still want that
consumer to populate the CVV with each eProtect
transaction.)
bin (Optional) The bank identification number (BIN), which is the
first six digits of the credit card number. Not applicable when
checkoutIdMode is set to true.
TABLE 2-1 eProtectFormFields Definitions
Field Description
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
28 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
secondary server. To ensure the secondary server has time to respond, we recommend a timeout
value of 15000 (15 seconds).
<head>
...
<script>
...
$("#submitId").click(
function(){
setEprotectResponseFields({"response":"", "message":""});
var eProtectRequest = {
"paypageId" : document.getElementById("request$paypageId").value,
"reportGroup" : document.getElementById("request$reportGroup").value,
"orderId" : document.getElementById("request$orderId").value,
"id" : document.getElementById("request$merchantTxnId").value,
"checkoutIdMode": true
"applepay" : applepay”
"url" : "https://request.eprotect.vantivprelive.com"
};
new eProtect().sendToEprotect(eProtectRequest, formFields, submitAfterEprotect,
onErrorAfterEprotect, timeoutOnEprotect, 15000);
return false;
...
</script>
...
</head>
NOTE:The URL in this example script (in red) should only be used in the
certification and testing environment. Before using your checkout page
with eProtect in a production environment, replace the certification URL
with the production URL (contact your Implementation Consultant for the
appropriate production URL).
TABLE 2-2 eProtectRequest Fields
Field Description
paypageId (Required) The unique number assigned by Implementation.
reportGroup (Required) The cnpAPI required attribute that defines under which
merchant sub-group this transaction will be displayed in
eCommerce iQ Reporting and Analytics.
Do not use this URL
in a production
environment. Contact
Implementation for
the appropriate
production URL.
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 29
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1.6 Intercepting the Checkout Form Submission
Without the eProtect implementation, order data is sent to your system when the submit button is
clicked. With the eProtect feature, a request must be sent to our server to retrieve the Registration
ID for the card number before the order is submitted to your system. To intercept the checkout
form, you change the input type from submit to button. The checkout button is built inside of a
<script>/<noscript> pair, but the <noscript> element uses a message to alert the customer
instead of providing a default submit.
Note that this also serves as a method for detecting JavaScript and informing customers that
JavaScript must be enabled in this checkout process.
<BODY>
...
<table>
...
orderId The merchant-assigned unique value representing the order in your
system (used when linking authorizations, captures, and refunds,
and for retries).
Vantiv recommends that the values for id and orderId be
different and unique so that we can use these identifiers for
reconciliation or troubleshooting. If you do not have the order
number available at this time, please generate another unique
number to send as the orderId (and send it to your servers to
map it to the order number that you generate later).
id The merchant-assigned unique value representing this transaction
in your system. The same value must be used for retries of the
same failed eProtect transaction but must be unique between the
eProtect transaction, authorization, capture, and refund for the
same order.
Vantiv recommends that the values for id and orderId must be
different and unique so that we can use these identifiers for
reconciliation or troubleshooting.
checkoutIdMode (Optional) Determines whether checkoutId mode is activated.
Setting the value to true causes only the cvv2 form field to be
exchanged with eProtect, and returns a checkoutId upon a
successful callback (instead of the paypageRegistrationId).
applepay (Optional). The Apple Pay PKPaymentToken. Required for Apple
Pay on the Web.
url (Required) The URL to request submission for eProtect. See
Table 1-2, eProtect Certification, Testing, and Production URLs on
page 13.
TABLE 2-2 eProtectRequest Fields (Continued)
Field Description
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
30 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<tr><td></td><td align="right">
<script>
document.write('<button type="button" id="submitId" onclick="callEprotect()">
Check out with paypage</button>');
</script>
<noscript>
<button type="button" id="submitId">Enable JavaScript or call us at
555-555-1212</button></noscript>
</td></tr>
...
</table>
...
</BODY>
2.1.7 Handling Callbacks for Success, Failure, and Timeout
Your checkout page must include instructions on what methods we should use to handle callbacks
for success, failure, and timeout events. Add the code in the following three sections to achieve
this.
2.1.7.1 Success Callbacks
The success callback stores the responses in the hidden form response fields and submits the
form. The card number is scrubbed from the submitted form, and all of the hidden fields are
submitted along with the other checkout information.
<head>
...
<script>
...
function setEprotectResponseFields(response) {
document.getElementById('response$code').value = response.response;
document.getElementById('response$message').value = response.message;
document.getElementById('response$responseTime').value = response.responseTime;
document.getElementById('response$vantivTxnId').value = response.vantivTxnId;
document.getElementById('response$checkoutId').value = response.checkoutId;
document.getElementById('response$type').value = response.type;
document.getElementById('response$firstSix').value = response.firstSix;
document.getElementById('response$lastFour').value = response.lastFour;
}
function submitAfterEprotect (response) {
setEprotectResponseFields(response);
document.forms['fCheckout'].submit();
}
...
</script>
...
</head>
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 31
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1.7.2 Failure Callbacks
There are two types of failures that can occur when your customer enters an order: validation
(user) errors, and system (non-user) errors (see Table 1-3, "eProtect-Specific Response Codes
Received in Browsers or Mobile Devices" on page 14). The failure callback stops the transaction
for non-user errors and nothing is posted to your order handling system.
You have flexibility in the wording of the error text.
<head>
...
<script>
...
function onErrorAfterEprotect (response) {
setEprotectResponseFields(response);
if(response.response == '871') {
alert("Invalid card number. Check and retry. (Not Mod10)");
}
else if(response.response == '872') {
alert("Invalid card number. Check and retry. (Too short)");
}
else if(response.response == '873') {
alert("Invalid card number. Check and retry. (Too long)");
}
else if(response.response == '874') {
alert("Invalid card number. Check and retry. (Not a number)");
}
else if(response.response == '875') {
alert("We are experiencing technical difficulties. Please try again later or call
555-555-1212");
}
else if(response.response == '876') {
alert("Invalid card number. Check and retry. (Failure from Server)");
}
else if(response.response == '881') {
alert("Invalid card validation code. Check and retry. (Not a number)");
}
else if(response.response == '882') {
alert("Invalid card validation code. Check and retry. (Too short)");
}
else if(response.response == '883') {
alert("Invalid card validation code. Check and retry. (Too long)");
}
else if(response.response == '889') {
alert("We are experiencing technical difficulties. Please try again later or call
555-555-1212");
}
return false;
}
NOTE:When there is a timeout or you receive a validation-related error response
code, be sure to submit enough information to your order processing
system to identify transactions that could not be completed. This will help
you monitor problems with the eProtect Integration and also have enough
information for debugging.
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
32 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
...
</script>
...
</head>
2.1.7.3 Timeout Callbacks
The timeout callback stops the transaction and nothing is posted to your order handling system.
Timeout values are expressed in milliseconds and defined in the sendToEprotect call,
described in the section, Handling the Mouse Click on page 27. We recommend a timeout value
of 15000
(15 seconds).
You have flexibility in the wording of the timeout error text.
<head>
...
<script>
...
function timeoutOnEprotect () {
alert("We are experiencing technical difficulties. Please try again later or
call 555-555-1212 (timeout)");
}
...
</script>
...
</head>
2.1.8 Detecting the Availability of the eProtect API
In the event that the eProtect-api3.js cannot be loaded, add the following to detect
availability. You have flexibility in the wording of the error text.
</BODY>
...
<script>
function callEprotect() {
if(typeof eProtect !== 'function') {
alert("We are experiencing technical difficulties. Please try again later or
call 555-555-1212 (API unavailable)" );
</script>
...
</HTML>
A full HTML code example of a simple checkout page integrated with eProtect is shown in
Appendix A, "Code Samples and Other Information".
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 33
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1.9 Using the Customer Browser JavaScript API for Apple Pay
on the Web
In this scenario, the Vantiv eProtect Customer Browser JavaScript API controls the fields on your
checkout page that hold sensitive card data. When the cardholder clicks the Apple Pay button,
communication is exchanged with Apple Pay via the JavaScript API to obtain the
PKPaymentToken. From this point forward, your handling of the transaction is identical to any
other eProtect transaction. The eProtect server returns a Registration ID (low-value token) and
your server constructs the cnpAPI transaction using that ID. See the Vantiv eProtect Integration
Guide for JavaScript and HTML page examples and more information on using the browser
JavaScript API.
The steps that occur when a consumer initiates an Apple Pay purchase using your website
application are detailed below and shown in Figure 2-3.
1. When the consumer selects the Apple Pay option from your website, your site makes use of
the Apple Pay JavaScript to request payment data from Apple Pay.
2. When Apple Pay receives the call from your website and after the consumer approves the
Payment Sheet (using Touch ID), Apple creates a PKPaymentToken using your public key.
Included in the PKPaymentToken is a network (Visa, MasterCard, American Express, or
Discover) payment token and a cryptogram.
3. Apple Pay returns the Apple PKPaymentToken (defined in Apple documentation; please refer
to https://developer.apple.com/library/content/documentation/PassKit/Reference/
PaymentTokenJSON/PaymentTokenJSON.html) to your website.
4. Your website sends the PKPaymentToken to our secure server via the JavaScript Browser
API and eProtect returns a Registration ID.
5. Your website forwards the transaction data along with the Registration ID to your order
processing server, as it would with any eProtect transaction.
6. Your server constructs/submits a standard cnpAPI Authorization/Sale transaction using the
Registration ID, setting the <orderSource> element to applepay.
7. Using the private key, Vantiv decrypts the PKPaymentToken associated with the Registration
ID and submits the transaction with the appropriate information to the card networks for
approval.
8. Vantiv sends the Approval/Decline message back to your system. This message is the
standard format for an Authorization or Sale response and includes the Vantiv token.
9. You return the Approval/Decline message to your website.
NOTE:This section is an excerpt from the Vantiv eCommerce Technical
Publication, Vantiv eCommerce Solution for Apple Pay. Refer to the full
document for further information.
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
34 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
FIGURE 2-1 Data/Transaction Flow - Customer Browser JavaScript API for Apple Pay Web
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 35
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.1.10 Using the Customer Browser JavaScript API for Visa
Checkout
The operation of Visa Checkout is simple, but requires either the modification of your existing
website or development of new website that include the use of the Visa Checkout SDK and
handling of the encrypted data returned to your website by Visa Checkout. The basic steps that
occur when a consumer initiates an Visa Checkout purchase using your website are:
1. When the consumer selects the Visa Checkout option from your website, your site makes use
of the Visa Checkout SDK to request payment data from Visa Checkout.
2. When Visa Checkout receives the call from your website, Visa creates a Payment Success
event using the Vantiv API key. Included in the Payment Success event is encrypted PAN
data.
3. Visa Checkout returns the Payment Success event (defined in Visa documentation; see
https://developer.visa.com/products/visa_checkout/guides) to your website.
In this scenario, the Vantiv eProtect Customer Browser JavaScript API controls the fields on your
checkout page that hold sensitive card data. When the cardholder clicks the Visa Checkout button,
communication is exchanged with Visa Checkout via the JavaScript API to obtain the Payment
Success event.
From this point forward, your handling of the transaction is identical to any other eProtect
transaction. The eProtect server returns a Registration ID (low-value token) and your server
constructs the transaction using that ID (outlined in the following steps)
4. Your website sends the Payment Success event to our secure server via the JavaScript
Browser API and Vantiv decrypts the Payment Success event associated with the Registration
ID. eProtect then returns a Registration ID along with customer information from the
decrypted data.
5. Your website forwards the transaction data along with the Registration ID to your order
processing server, as it would with any eProtect transaction.
6. Your server constructs/submits an Authorization/Sale transaction using the Registration ID.
7. Vantiv submits the transaction with the appropriate information to the card networks for
approval.
8. Vantiv sends the Approval/Decline message back to your system. This message is the
standard format for an Authorization or Sale response and includes the Vantiv token.
9. You return the Approval/Decline message to your website.
After you finish making a payment, you update the payment information in Visa Checkout.
To update Visa Checkout from a Thank You page (next page to load after making the
payment), you add a one-pixel image to the page.
Integration and Testing Integrating Customer Browser JavaScript API Into Your Checkout Page
36 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
FIGURE 2-2 Data/Transaction Flow - Vantiv Browser JavaScript API for Visa Checkout
2.1.11 Adding Visa Checkout to the eProtect Customer Browser
JavaScript API
Integrating Visa Checkout into your web page includes the following:
Requesting and Configuring the API Key and externalClientId
Sending Vantiv the Required Fields
2.1.11.1 Requesting and Configuring the API Key and externalClientId
To request and configure the API Key and externalClientId, insert the following JavaScript
into your checkout page:
<script type="text/javascript"
src="https://request.eprotect.vantivprelive.com/eProtect/eProtect-api3.js"></script>
<script>
function onVisaCheckoutReady() {
var ep = new eProtect();
Do not use this URL in a
production environment.
Contact Implementation for the
appropriate production URL.
Integrating Customer Browser JavaScript API Into Your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 37
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
V.init({
apikey: ep.getVisaCheckoutApiKey(), //Vantiv's current Visa Checkout API Key
sourceId: "Merchant Defined Source ID",
externalClientId: "stefan_sandwiches", //Merchant's client id - get this
from Vantiv's implementations team
settings: {
...
},
paymentRequest: {
...
}
});
...
}
</script>
2.1.11.2 Sending Vantiv the Required Fields
Insert the following to send the required fields to Vantiv:
V.on("payment.success", function(payment){
var eProtectRequest = {
...,
"visaCheckout": payment
};
new eProtect().sendToEprotect(eProtectRequest, formFields, submitAfterEprotect,
onErrorAfterEprotect, timeout);
}
For an example of a completed checkout page with these components, go here:
https://www.testvantivcnp.com/checkout/checkout3VisaCheckout-prelive-sandbox.jsp.
Integration and Testing Integrating iFrame into your Checkout Page
38 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.2 Integrating iFrame into your Checkout Page
This section provides information and instructions for integrating the iFrame eProtect solution
into your checkout page. Review the section Creating a Customized CSS for iFrame on page 16
for information on creating a style sheet. Also see https://www.testvantivcnp.com/iframe/ to view
our iFrame example page.
2.2.1 Integration Steps
Integrating the iFrame into you checkout page includes the following steps, described in the
sections to follow. For a full HTML code example a iFrame eProtect implementation, see the
HTML Example for Hosted iFrame-Integrated Checkout Page on page 102.
1. Loading the iFrame
2. Configuring the iFrame
3. Calling the iFrame for the Registration ID
4. Handling Callbacks
2.2.2 Loading the iFrame
To load the iFrame from the eProtect application server to your customer's browser, insert the
following script tag into your checkout page:
<script src="https://request.eprotect.vantivprelive.com/eProtect/js/eProtect-iframe-
client3.min.js"></script>
NOTE:The URL in this example (in red) should only be used in the certification
and testing environment. Before using your checkout page with eProtect
in a production environment, replace the certification URL with the
production URL (contact your Implementation Consultant for the
appropriate production URL).
Do not use this URL in a
production environment.
Contact Implementation for the
appropriate production URL.
Integrating iFrame into your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 39
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.2.3 Configuring the iFrame
To configure the iFrame after the page is loaded, you specify the required properties listed in
Table 2-3 (other properties shown in the example below, are optional). You define a callback for
errors, time-outs, and to retrieve the paypageRegistrationId. In this example, this is called
eProtectiframeClientCallback.
If you wish to prevent the occurrence of ‘Flash of Un-styled Content’ (FOUC), structure your
code to load the iFrame and all related surrounding host page content in a hidden div. Once the
iFrame reports it is ready, your site shows the whole div.
$( document ).ready(function() {
var configure = {
"paypageId":document.getElementById("request$paypageId").value,
"style":"test",
"reportGroup":document.getElementById("request$reportGroup").value,
"timeout":document.getElementById("request$timeout").value,
"div": "eProtectiframe",
"callback": eProtectiframeClientCallback,
"checkoutIdMode": true,
"showCvv": true,
"months": {
"1":"January",
"2":"February",
"3":"March",
"4":"April",
"5":"May",
"6":"June",
"7":"July",
"8":"August",
"9":"September",
"10":"October",
"11":"November",
"12":"December"
},
"numYears": 8,
"tooltipText": "A CVV is the 3 digit code on the back of your Visa, MasterCard and Discover or a
4 digit code on the front of your American Express",
"tabIndex": {
"cvv":1,
"accountNumber":2,
"expMonth":3,
"expYear":4
},
"placeholderText": {
"cvv":"CVV",
"accountNumber":"Account Number"
},
"inputsEmptyCallback": inputsEmptyCallback,
"enhancedUxFeatures" : {
"inlineFieldValidations": true,
}
};
if(typeof eProtectiframeClient === 'undefined') {
alert("We are experiencing technical difficulties. Please try again or call us to complete
your order");
//You may also want to submit information you have about the consumer to your servers to
facilitate debugging like customer ip address, user agent, and time
}
Integration and Testing Integrating iFrame into your Checkout Page
40 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
else {
var eProtectiframeClient = new EprotectIframeClient(configure);
eProtectiframeClient.autoAdjustHeight();
});
TABLE 2-3 Common Properties
Property Description
paypageId (Required) The unique number assigned by Implementation.
style (Required) The CSS filename (excluding the ‘.css’). For
example, if the style sheet filename is mysheet1.css, the
value for this property is mysheet1.
reportGroup (Required) The cnpAPI required attribute that defines under
which merchant sub-group this transaction will be displayed in
eCommerce iQ Reporting and Analytics.
timeout (Required) The number of milliseconds before a transaction
times out and the timeout callback in invoked. If the response
from the primary server takes more than five (5) seconds, the
request is automatically sent to our secondary server. To
ensure the secondary server has time to respond, Vantiv
recommends a timeout value of 15000 (15 seconds).
div (Required) The ID of the HTML div element where our
iFrame is embedded as innerHTML.
callback (Required) The function element that our iFrame calls with a
single parameter representing a JSON dictionary. The keys in
the callback are:
*paypageRegistrationId
*bin
*type
*firstSix
*lastFour
*expDate
*vantivTxnId
*orderId
*response
*responseTime
*message
*reportGroup
*id
*timeout
checkoutIdMode (Optional) Determines whether checkoutId mode is
activated. Set the value to true to establish a rule allowing the
capture of the CVV only (in order to receive the
checkoutId). Adding this field hides all fields in the iFrame,
except CVV and CVV-related fields (including tooltips, etc.).
inputsEmptyCallback (Optional) When a consumer returns to your checkout page to
edit non-payment information, this function determines
whether the Card number and security code fields are empty,
and indicates whether to return this information in your
callback. See Creating a Customized CSS for iFrame on page
14 for more information.
Integrating iFrame into your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 41
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.2.4 Calling the iFrame for the Registration ID
After your customer clicks the Submit/Complete Order button, your checkout page must call the
iFrame to get a eProtect Registration ID. In the onsubmit event handler of your button, add code
to call eProtect to get a Registration ID for the account number and CVV2. Include the
parameters listed in Table 2-4.
document.getElementById("fCheckout").onsubmit = function(){
var message = {
"id":document.getElementById("request$merchantTxnId").value,
"orderId":document.getElementById("request$orderId").value
"pciNonSensitive": true
};
eProtectiframeClient.getPaypageRegistrationId(message);
return false;
};
inlineFieldValidations (Optional) Determines whether in-field validations are
performed (set value to true). See Creating a Customized
CSS for iFrame on page 14 for more information.
height (Optional) The height (in pixels) of the iFrame. There are
three options:
You can pass height as an optional parameter when
configuring the client.
You can call autoAdjustHeight in the client to tell the
iFrame to adjust the height to exactly the number of pixels
needed to display everything in the iFrame without
displaying a vertical scroll bar (recommended).
You can ignore height. The iFrame may display a vertical
scroll bar, depending upon your styling of the div
containing the iFrame.
htmlTimeout (Optional) The amount of time (in milliseconds) to wait for the
iFrame to load before responding with an ‘884’ error code.
TABLE 2-3 Common Properties (Continued)
Property Description
Integration and Testing Integrating iFrame into your Checkout Page
42 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.2.5 Calling the iFrame for the Checkout ID
Additionally, your checkout page can call the iFrame to exchange the CVV value for a
checkoutId (low-value-token with a 24-hour lifespan). Use this when you store the high-value
token (registrationId) on file for a consumer, but still want that consumer to populate the
CVV with each eProtect transaction. See the parameters listed in Table 2-4 for more information.
Note that the PCI non-sensitive flag is not applicable for the getCheckoutId function.
var message = {
"id":document.getElementById("request$merchantTxnId").value,
"orderId":document.getElementById("request$orderId").value
};
startTime = new Date().getTime();
iframeClient.getCheckoutId(message);
TABLE 2-4 Event Handler Parameters
Parameter Description
id The merchant-assigned unique value representing this transaction in
your system. The same value must be used for retries of the same
failed eProtect transaction but must be unique between the eProtect
transaction, authorization, capture, and refund for the same order.
Type: String
Max Length: 25 characters
Vantiv recommends that the values for id and orderId must be
different and unique so that we can use these identifiers for
reconciliation or troubleshooting.
orderId The merchant-assigned unique value representing the order in your
system (used when linking authorizations, captures, and refunds, and
for retries).
Type: String
Max Length: 25 characters
Vantiv recommends that the values for id and orderId be different
and unique so that we can use these identifiers for reconciliation or
troubleshooting. If you do not have the order number available at this
time, please generate another unique number to send as the orderId
(and send it to your servers to map it to the order number that you
generate later).
pciNonSensitive (Optional) Bypasses existing MOD10 validation for only non-sensitive
cardholder data as defined by PCI (e.g. Private Label) for tokenization.
A value of true bypasses MOD10 validation.See Notes on the PCI
Non-Sensitive Value Feature, next.
Note: If you use this parameter with a value of true, the card type and
BIN are not returned in the response.
Integrating iFrame into your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 43
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.2.5.1 Notes on the PCI Non-Sensitive Value Feature
eProtect is designed to capture branded credit cards from the major card networks including Visa,
MasterCard, American Express, Discover, and JCB. The eProtect PCI Non-Sensitive feature has
the capability to capture and tokenize non-network branded payment types, such as private label
and Vantiv gift cards. The PCI Non-Sensitive feature can tokenize 13-19 digit values, as long as
the Vantiv message interface specification supports that payment type.
Implementation of the pciNonSensitive parameter may require augmentation of your
checkout page to include a method whereby your customer chooses a payment type (e.g., a
drop-down box). You must capture the non-network branded payment type in order to send the
appropriate flag when calling eProtect.
2.2.6 Handling Callbacks
After the iFrame has received the paypageRegistrationId or checkoutId, or has received
an error or timed out, the iFrame calls the callback specified when the client was constructed. In
your callback, you can determine success or failure by inspecting response.response (870
indicates success). You can check for a timeout by inspecting response.timeout (if it is
defined, a timeout has occurred).
var eProtectiframeClientCallback = function(response) {
if (response.timeout) {
alert("We are experiencing technical difficulties. Please try again or call us to complete your
order");
//You may also want to submit information you have about the consumer to your servers to
facilitate debugging like customer ip address, user agent, and time
}
else {
document.getElementById('response$code').value = response.response;
document.getElementById('response$message').value = response.message;
document.getElementById('response$responseTime').value = response.responseTime;
document.getElementById('response$reportGroup').value = response.reportGroup;
document.getElementById('response$merchantTxnId').value = response.id;
document.getElementById('response$orderId').value = response.orderId;
document.getElementById('response$vantivTxnId').value = response.vantivTxnId;
document.getElementById('response$checkoutId').value = response.checkoutId;
document.getElementById('response$type').value = response.type;
document.getElementById('response$lastFour').value = response.lastFour;
document.getElementById('response$firstSix').value = response.firstSix;
document.getElementById('paypageRegistrationId').value = response.paypageRegistrationId;
document.getElementById('bin').value = response.bin;
document.getElementById('response$expMonth').value = response.expMonth;
NOTE:When there is a timeout or you receive a validation-related error response
code, be sure to submit enough information (for example, customer IP
address, user agent, and time) to your order processing system to identify
transactions that could not be completed. This will help you monitor
problems with the eProtect Integration and also have enough information
for debugging.
Integration and Testing Integrating iFrame into your Checkout Page
44 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
document.getElementById('response$expYear').value = response.expYear;
if(response.response === '870') {
//Submit the form
}
else if(response.response === '871' || response.response === '872' || response.response ===
'873' || response.response === '874' || response.response === '876') {
//Recoverable error caused by user mis-typing their credit card
alert("Please check and re-enter your credit card number and try again.");
}
else if(response.response === '881' || response.response === '882' || response.response === 883)
{
//Recoverable error caused by user mis-typing their credit card
alert("Please check and re-enter your card validation number and try again.");
}
else if(response.response === '884') {
//Frame failed to load, so payment can't proceed.
//You may want to consider a larger timeout value for the htmlTimeout property
//You may also want to log the customer ip, user agent, time, paypageId and style that failed
to load for debugging.
//Here, we hide the frame to remove the unsightly browser error message from the middle of
our payment page that may eventually display
$('#eProtectiframe').hide();
// and disable the checkout button
$('#submitButton').attr('disabled','disabled');
}
else if(response.response === '885') {
//CSS Failed to load, so the page will look unsightly but will function.
//We are going to continue with the order
$('#submitButton').removeAttr('disabled');
//You may also want to log the customer ip, user agent, time, and style that failed to load
for debugging
}
else {
//Non-recoverable or unknown error code
alert("We are experiencing technical difficulties. Please try again or call us to complete
your order");
//You may also want to submit the vantivTxnId and response received, plus information you
have about the consumer to your servers to facilitate debugging, i.e., customer ip address, user
agent and time
}
}
};
2.2.6.1 Handling Errors
In case of errors in the iFrame, the iFrame adds an error class to the field that had the error. You
can use those classes in the CSS you give Vantiv Implementation to provide error styles. The
codes correspond to the response codes outlined in eProtect-Specific Response Codes on page 14.
In case of error on the accountNumber field, these classes are added to the div in the
iFrame with the existing class numberDiv.
• error-871
error-872
• error-874
• error-876
Integrating iFrame into your Checkout Page Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 45
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
In case of error on the cvv field, these classes are added to the div in the iFrame with the
existing class cvvDiv.
• error-881
error-882
In either case, the callback is still invoked. When the input field with the error receives the focus
event, we clear the error classes. Some sample CSS to indicate an error given these classes is as
follows:
.error-871::before {
content: "Account number not Mod10";
}
.error-871>input {
background-color:red;
}
Integration and Testing Integrating eProtect Into Your Mobile Application
46 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3 Integrating eProtect Into Your Mobile Application
This section provides instructions for integrating the eProtect feature into your native mobile
application. Unlike the eProtect browser checkout page solution, the native mobile application
does not interact with the eProtect JavaScript in a browser. Instead, you use an HTTP POST in a
native mobile application to send account numbers to Vantiv and receive a Registration ID in the
response. This section also provides information on the following payment methods:
Using the Vantiv Mobile API for Apple Pay
Using the Vantiv Mobile API for Visa Checkout
Using the Vantiv Mobile API for Android Pay
2.3.1 Creating the POST Request
You structure your POST request as shown in the Sample Request. Use the components listed in
Table 2-5. The URLs and User Agent examples in this table (in red) should only be used in the
certification and testing environment. For more information on the appropriate User Agent (iOS
and Android versions can differ), see the HTTP standard at http://www.ietf.org/rfc/rfc2616.txt
section 14.43..
TABLE 2-5 POST Headers, Parameters, and URL
Component Element Description
Headers
(optional)
Content-Type: application/x-www-form-urlencoded
Host: request.eprotect.vantivprelive.com
User-Agent = "User-Agent" ":" 1*( product | comment )
For example:
User-Agent: Vantiv/1.0 CFNetwork/459 Darwin/10.0.0.d3
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 47
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.1.1 Sample Request
The following is an example POST to request a Registration ID:
$ curl --verbose -H "Content-Type: application/x-www-form-urlencoded" -H "Host:
request.eprotect.vantivprelive.com/eProtect/paypage
" -H "User-Agent: Vantiv/1.0
CFNetwork/459 Darwin/10.0.0.d3" -d"paypageId=a2y4o6m8k0&
reportGroup=*merchant1500&orderId=PValid&id=12345&accountNumber=ACCOUNT_NUMBER&cvv=CVV&pc
iNonSensitive=true"
https://request.eprotect.vantivprelive.com/eProtect/paypage
Parameters
(required)
(optional)
paypageId The unique number assigned by Implementation.
reportGroup A unique value that you assign.
orderId A unique value that you assign (string, max length: 25 char.).
See full definition on page 29.
id A unique value that you assign (string, max length: 25 char.).
See full definition on on page 29.
accountNumber A unique value that you assign. (Not used in Apple Pay
transactions.)
pciNonSensitive Bypasses the existing MOD10 validation for only non-sensitive
cardholder data as defined by PCI (e.g., Private Label) for
tokenization. A value of true bypasses MOD10 validation. See
Notes on the PCI Non-Sensitive Value Feature on page 43.
Note: If you use this parameter with a value of true, the card
type and BIN are not returned in the response.
cvv2 The card validation number, either the CVV2 (Visa), CVC2
(MasterCard), or CID (American Express and Discover) value.
URL
https://request.eprotect.vantivprelive.com/eProtect/paypage
NOTE:The URL in this example script (in red) should only be used in the
certification and testing environment. Before using your checkout page
with eProtect in a production environment, replace the certification URL
with the production URL (contact your Implementation Consultant for the
appropriate production URL).
TABLE 2-5 POST Headers, Parameters, and URL (Continued)
Component Element Description
Do not use this URL in a
production environment.
Contact Implementation for the
appropriate production URL.
Integration and Testing Integrating eProtect Into Your Mobile Application
48 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.1.2 Sample Response
The response received in the body of the POST response is a JSON string similar to the
following:
{"bin":"410000","firstSix":"410000","lastFour":"0001","paypageRegistrationId":"amNDNkpWck
VGNFJoRmdNeXJUOHl4Skh1TTQ1Z0t6WE9TYmdqdjBJT0F5N28zbUpxdlhGazZFdmlCSzdTN3ptKw\u003d\u003d"
,"type":"VI","id":"12345","vantivTxnId":"83088059521107596","message":"Success","orderId"
:"PValid","reportGroup":"*merchant1500","response":"870","responseTime":"2014-02-07T17:04
:04"}
Table 2-6 lists the parameters included in the response.
2.3.2 Using the Vantiv Mobile API for Apple Pay
TABLE 2-6 Parameters Returned in POST Response
Parameter Description
paypageRegistrationId The temporary identifier used to facilitate the mapping of a
token to a card number.
reportGroup (Mirrored back from the request) The cnpAPI required attribute
that defines under which merchant sub-group this transaction
will be displayed in eCommerce iQ Reporting and Analytics.
orderId (Mirrored back from the request) The merchant-assigned
unique value representing the order in your system.
Type: String
Max Length: 25 characters
id (Mirrored back from the request) The merchant-assigned
unique value representing this transaction in your system.
Type: String
Max Length: 25 characters
vantivTxnId The automatically-assigned unique transaction identifier.
firstSix (Mirrored back from the request) The first six digits of the credit
card number.
lastFour (Mirrored back from the request) The last four digits of the
credit card number.
NOTE:This section is an excerpt from the Vantiv eCommerce Technical
Publication, Vantiv eCommerce Solution for Apple Pay. Refer to the full
document for further information.
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 49
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
In this scenario, your native iOS application performs an HTTPS POST of the Apple Pay
PKPaymentToken using the Vantiv Mobile API for Apple Pay. From this point forward, your
handling of the transaction is identical to any other eProtect transaction. The eProtect server
returns a Registration ID and your Mobile App (or server) constructs the cnpAPI transaction
using that ID.
The steps that occur when a consumer initiates an Apple Pay purchase using your mobile
application are detailed below and shown in Figure 2-3.
1. When the consumer selects the Apple Pay option from your application or website, your
application/site makes use of the Apple PassKit Framework to request payment data from
Apple Pay.
2. When Apple Pay receives the call from your application or website and after the consumer
approves the Payment Sheet (using Touch ID), Apple creates a PKPaymentToken using your
public key. Included in the PKPaymentToken is a network (Visa, MasterCard, American
Express, or Discover) payment token and a cryptogram.
3. Apple Pay returns the Apple PKPaymentToken (defined in Apple documentation; please refer
to https://developer.apple.com/library/content/documentation/PassKit/Reference/
PaymentTokenJSON/PaymentTokenJSON.html) to your application.
4. Your native iOS application sends the PKPaymentToken to our secure server via an HTTPS
POST (see Creating a POST Request for an Apple Pay Transaction on page 51) and eProtect
returns a Registration ID.
5. Your native iOS application forwards the transaction data along with the Registration ID to
your order processing server, as it would with any eProtect transaction.
6. Your server constructs/submits a standard cnpAPI Authorization/Sale transaction using the
Registration ID.
7. Using the private key, Vantiv decrypts the PKPaymentToken associated with the Registration
ID and submits the transaction with the appropriate information to the card networks for
approval.
8. Vantiv sends the Approval/Decline message back to your system. This message is the
standard format for an Authorization or Sale response and includes the Vantiv token.
9. You return the Approval/Decline message to your mobile application.
NOTE:If you subscribe to both Vault tokenization and Apple Pay, Vantiv will
tokenize Apple Pay token values to ensure a consistent token value is
returned. As a result, tokenized value returned in the response is based
off the Apple Pay token, not the original PAN value. Format preserving
components of the Vault token value such as the Last-four and BIN will be
from the Apple Pay token, not the PAN.
Integration and Testing Integrating eProtect Into Your Mobile Application
50 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
FIGURE 2-3 Data/Transaction Flow using the Vantiv Mobile API for Apple Pay
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 51
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.2.1 Creating a POST Request for an Apple Pay Transaction
Construct your HTTPS POST as detailed in Creating the POST Request on page 46, using the
components listed in the Table 2-5 as well as those listed in Table 2-7 (all required). See the
Sample Apple Pay POST Request and Sample Apple Pay POST Response below.
TABLE 2-7 Vantiv Mobile API for Apple Pay HTTPS POST Required Components
Parameter Name Description
applepay.data Payment data dictionary, Base64 encoded
as a string. Encrypted Payment data.
applepay.signature Detached PKCS #7 signature, Base64
encoded as string. Signature of the payment
and header data.
applepay.version Version information about the payment
token.
applepay.header.applicationData SHA-256 hash, Base64 encoded as a string.
Hash of the applicationData property of the
original PKPaymentRequest.
applepay.header.ephemeralPublicKey X.509 encoded key bytes, Base64 encoded
as a string. Ephemeral public key bytes.
applepay.header.publicKeyHash SHA-256 hash, Base64 encoded as a string.
Hash of the X.509 encoded public key bytes
of the merchant's certificate.
applepay.header.transactionId Hexademical identifier, as a string.
Transaction identifier, generated on the
device.
Integration and Testing Integrating eProtect Into Your Mobile Application
52 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.2.2 Sample Apple Pay POST Request
The following is an example POST to request a Registration ID for Apple Pay:
curl --verbose -H "Content-Type: application/x-www-form-urlencoded" -H "Host:MerchantApp"
-H "User-Agent:Vantiv/1.0 CFNetwork/459 Darwin/10.0.0.d3"
-d"paypageId=a2y4o6m8k0&reportGroup=*merchant1500&orderId=PValid&id=1234&applepay.data=HT
897mACd%2F%2FTpWe10A5y9RmL5UfboTiDIvjni3zWFtyy8dtv72RJL1bk%2FU4dTDlrq1T1V2l0TSnI%0APLdOnn
HBO51bt9Ztj9odDTQ5LD%2F4hMZTQj3lBRvFOtTtjp9ysBAsydgjEjcCcbnkx7dCqgnwgzuz%0Ay7bX%2B5Fo8a8R
KqoprkDPwIMWOC9yWe7MQw%2FboM5NY2QtIcIvzbLFcYUxndYTg0IXNBHNzsvUOjmw%0AvEnMhXxeCH%2BC4KoC6M
EsAGK5rH1T5dSvTZzHF5c12dpsqdI73%2FBk6qEcdlT7gJKVmyDQC%2FNFxJ0X%0AF993Of6ejQDJq6BZsz8X7kYC
yJdI%2FPFJPZp4e3L%2FtCsBDUTJAgFLt2xF8HWaPoW8psILOGCCvJQm%0ATR1m7ODtSChaWOb7eYm1BpNiD3wkCH
8nmIMrlnt3KP4SeQ%3D%3D&applepay.signature=MIAGCSqGSIb3DQEHAqCAMIACAQExDzANBglghkgBZQMEAgE
FADCABgkqhkiG9w0BBwEAAKCAMIICvzCCAmWgAwIBAgIIQpCV6UIIb4owCgYIKoZIzj0EAwIwejEuMCwGA1UEAwwl
QXBwbGUgQXBwbGljYXRpb24gSW50ZWdyYXRpb24gQ0EgLSBHMzEmMCQGA1UECwwdQXBwbGUgQ2VydGlmaWNhdGlvb
iBBdXRob3JpdHkxEzARBgNVBAoMCkFwcGxlIEluYy4xCzAJBgNVBAYTAlVTMB4XDTE0MDUwODAxMjMzOVoXDTE5MD
UwNzAxMjMzOVowXzElMCMGA1UEAwwcZWNjLXNtcC1icm9rZXItc2lnbl9VQzQtUFJPRDEUMBIGA1UECwwLaU9TIFN
5c3RlbXMxEzARBgNVBAoMCkFwcGxlIEluYy4xCzAJBgNVBAYTAlVTMFkwEwYHKoZIzj0CAQYIKoZIzj0DAQcDQgAE
whV37evWx7Ihj2jdcJChIY3HsL1vLCg9hGCV2Ur0pUEbg0IO2BHzQH6DMx8cVMP36zIg1rrV1O%2F0komJPnwPE6O
B7zCB7DBFBggrBgEFBQcBAQQ5MDcwNQYIKwYBBQUHMAGGKWh0dHA6Ly9vY3NwLmFwcGxlLmNvbS9vY3NwMDQtYXBw
bGVhaWNhMzAxMB0GA1UdDgQWBBSUV9tv1XSBhomJdi9%2BV4UH55tYJDAMBgNVHRMBAf8EAjAAMB8GA1UdIwQYMBa
AFCPyScRPk%2BTvJ%2BbE9ihsP6K7%2FS5LMDQGA1UdHwQtMCswKaAnoCWGI2h0dHA6Ly9jcmwuYXBwbGUuY29tL2
FwcGxlYWljYTMuY3JsMA4GA1UdDwEB%2FwQEAwIHgDAPBgkqhkiG92NkBh0EAgUAMAoGCCqGSM49BAMCA0gAMEUCI
QCFGdtAk%2B7wXrBV7jTwzCBLE%2BOcrVL15hjif0reLJiPGgIgXGHYYeXwrn02Zwcl5TT1W8rIqK0QuIvOnO1THC
bkhVowggLuMIICdaADAgECAghJbS%2B%2FOpjalzAKBggqhkjOPQQDAjBnMRswGQYDVQQDDBJBcHBsZSBSb290IEN
BIC0gRzMxJjAkBgNVBAsMHUFwcGxlIENlcnRpZmljYXRpb24gQXV0aG9yaXR5MRMwEQYDVQQKDApBcHBsZSBJbmMu
MQswCQYDVQQGEwJVUzAeFw0xNDA1MDYyMzQ2MzBaFw0yOTA1MDYyMzQ2MzBaMHoxLjAsBgNVBAMMJUFwcGxlIEFwc
GxpY2F0aW9uIEludGVncmF0aW9uIENBIC0gRzMxJjAkBgNVBAsMHUFwcGxlIENlcnRpZmljYXRpb24gQXV0aG9yaX
R5MRMwEQYDVQQKDApBcHBsZSBJbmMuMQswCQYDVQQGEwJVUzBZMBMGByqGSM49AgEGCCqGSM49AwEHA0IABPAXEYQ
Z12SF1RpeJYEHduiAou%2Fee65N4I38S5PhM1bVZls1riLQl3YNIk57ugj9dhfOiMt2u2ZwvsjoKYT%2FVEWjgfcw
gfQwRgYIKwYBBQUHAQEEOjA4MDYGCCsGAQUFBzABhipodHRwOi8vb2NzcC5hcHBsZS5jb20vb2NzcDA0LWFwcGxlc
m9vdGNhZzMwHQYDVR0OBBYEFCPyScRPk%2BTvJ%2BbE9ihsP6K7%2FS5LMA8GA1UdEwEB%2FwQFMAMBAf8wHwYDVR
0jBBgwFoAUu7DeoVgziJqkipnevr3rr9rLJKswNwYDVR0fBDAwLjAsoCqgKIYmaHR0cDovL2NybC5hcHBsZS5jb20
vYXBwbGVyb290Y2FnMy5jcmwwDgYDVR0PAQH%2FBAQDAgEGMBAGCiqGSIb3Y2QGAg4EAgUAMAoGCCqGSM49BAMCA2
cAMGQCMDrPcoNRFpmxhvs1w1bKYr%2F0F%2B3ZD3VNoo6%2B8ZyBXkK3ifiY95tZn5jVQQ2PnenC%2FgIwMi3VRCG
wowV3bF3zODuQZ%2F0XfCwhbZZPxnJpghJvVPh6fRuZy5sJiSFhBpkPCZIdAAAxggFfMIIBWwIBATCBhjB6MS4wLA
YDVQQDDCVBcHBsZSBBcHBsaWNhdGlvbiBJbnRlZ3JhdGlvbiBDQSAtIEczMSYwJAYDVQQLDB1BcHBsZSBDZXJ0aWZ
pY2F0aW9uIEF1dGhvcml0eTETMBEGA1UECgwKQXBwbGUgSW5jLjELMAkGA1UEBhMCVVMCCEKQlelCCG%2BKMA0GCW
CGSAFlAwQCAQUAoGkwGAYJKoZIhvcNAQkDMQsGCSqGSIb3DQEHATAcBgkqhkiG9w0BCQUxDxcNMTQxMDAzMjE1NjQ
zWjAvBgkqhkiG9w0BCQQxIgQgg8i4X6yRAU7AXS1lamCf02UIQlpUvNPToXUaamsFUT8wCgYIKoZIzj0EAwIERzBF
AiBe17NGTuuk%2BW901k3Oac4Z90PoMhN1qRqnij9KNEb%2FXAIhALELZyDWw0fQM8t0pXO86gg9xXFz424rEMlJ0
1TM1VxhAAAAAAAA&applepay.version=EC_v1&applepay.header.applicationData=496461ea64b50527d2
d792df7c38f301300085dd463e347453ae72debf6f4d14&applepay.header.ephemeralPublicKey=MFkwEwY
HKoZIzj0CAQYIKoZIzj0DAQcDQgAEarp8xOhLX9QliUPS9c54i3cqEfrJD37NG75ieNxncOeFLkjCk%2FBn3jVxHl
ecRwYqe%2BAWQxZBtDyewaZcmWz5lg%3D%3D&applepay.header.publicKeyHash=zoV5b2%2BmqnMIxU9avTeq
Wxc7OW3fnKXFxyhY0cyRixU%3D&applepay.header.transactionId=23e26bd8741fea9e7a4d78a69f4255b3
15d39ec14233d6f1b32223d1999fb99f"https://request.eprotect.vantivprelive.com/eProtect/payp
age
Do not use this URL in a
production environment.
Contact Implementation for the
appropriate production URL.
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 53
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.2.3 Sample Apple Pay POST Response
The response received in the body of the POST response is a JSON string similar to the
following:
{"bin":"410000","firstSix":"410000","lastFour":"0001","paypageRegistrationId":"S0ZBUURMTl
ZkMTgrbW1IL3BZVFFmaDh0M0hjdDZ5RXcxQzRQUkJRKzdVc3JURXp0N0JBdmhDN05aTllUQU5rY1RCMDhLNXg2clI
0cDV3Sk5vQmlPTjY3V2plbDVac0lqd0FkblYwVTdQWms9","type":"VI","id":"1234","vantivTxnId":"828
26626153431509","message":"Success","orderId":"PValid","reportGroup":"*merchant1500","res
ponse":"870","responseTime":"2015-01-19T18:35:27","expDate":"0718"}
2.3.3 Using the Vantiv Mobile API for Visa Checkout
The operation of Visa Checkout is simple, but requires either the modification of your existing
application or development of new native applications that include the use of the Visa Checkout
SDK and handling of the encrypted data returned to your application by Visa Checkout. The basic
steps that occur when a consumer initiates an Visa Checkout purchase using your mobile
application are:
1. When the consumer selects the Visa Checkout option from your application, your application
makes use of the Visa Checkout SDK to request payment data from Visa Checkout.
2. When Visa Checkout receives the call from your application, Visa creates a Payment Success
event using the Vantiv API key. Included in the Payment Success event is encrypted PAN
data.
3. Visa Checkout returns the Payment Success event (defined in Visa documentation; see
https://developer.visa.com/products/visa_checkout/guides) to your application.
In this scenario, your native application performs an HTTPS POST of the Visa Checkout SDK
using the Vantiv Mobile API for Visa Checkout. From this point forward, your handling of the
transaction is identical to any other eProtect transaction. The eProtect server returns a
Registration ID (low-value token) and your Mobile Application (or server) constructs the
transaction using that ID (outlined in the following steps).
4. Your native mobile application sends the Payment Success event to our secure server via an
HTTPS POST (see HTTPS POST Required Components - Vantiv Mobile API for Visa
Checkout), Vantiv decrypts the Payment Success event associated with the Registration ID
and eProtect then returns a Registration ID along with customer information from the
decrypted data.
5. Your native mobile application forwards the transaction data along with the Registration ID to
your order processing server, as it would with any eProtect transaction.
6. Your server constructs/submits a standard Authorization/Sale transaction using the
Registration ID.
7. Vantiv submits the transaction with the appropriate information to the card networks for
approval.
8. Vantiv sends the Approval/Decline message back to your system. This message is the
standard format for an Authorization or Sale response and includes the Vantiv token.
Integration and Testing Integrating eProtect Into Your Mobile Application
54 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
9. You return the Approval/Decline message to your mobile application.
After you finish making a payment, you update the payment information in Visa Checkout.
To update Visa Checkout from a Thank You page (next page to load after making the
payment), you add a one-pixel image to the page.
FIGURE 2-4 Data/Transaction Flow using the Vantiv Mobile API for Visa Checkout
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 55
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.3.1 Sending Vantiv the Required Fields
Construct your HTTPS POST as detailed above using the components listed in Table 2-8 below.
These fields take the place of the accountNumber and cvv fields from the Mobile API (encoded
as form fields). See the Sample Apple Pay POST Request and Sample Visa Checkout POST
Response below.
2.3.3.2 Sample Visa Checkout POST Request
The following is an example POST to request a Registration ID for Visa Checkout:
paypageId=VgrJZt5GfhX9DYQq&reportGroup=VIReportGroup&orderId=TC7976_1_viCheckoutPPPost
&id=12345&visaCheckout.apiKey=ENIWGH9WQ4RZMHU9TPKX21EwEluZeS4zp252_mnXTRKuuvUG4&visaCh
eckout.encKey=I7Q2OFSekX8PZ239ZSX8T8AqAZwOtyzTS%2BH%2F9Rj4%2FOXQn2uDTbNIPHJY4KXu5e9UV2
Gphi3Mm2DY%2Fb947DaTUO7eD0ijwIUi8wcJQZjddtoe3oC7TLVSqIvtwNb0UjXf&visaCheckout.callid=1
111111111111111111&visaCheckout.encPaymentData=YnIJmecBIamQMxbUTVjNXJbxf%2BGarZSqvC8T%
2FWRz1AqG1jGHA3TCbu3V268uNIEDKFX4cbgHF6pxSCJjNPMrUeMef3Y3%2Fvd08GgSsucrLS4MLPwj4LBtX7G
4mt1HFiij4E0ESMedNxywH%2BJ68Oqu%2BTkN%2FwHIJNfAjg2F7pHx3qDuisCih%2BPkCAWOAjrHxOS1LKf%2
FzkerBfR0U0RYZBuxsD4zWJIUfhSbtrbnmVhD%2BIIZSr%2BT%2F6zvPVtInnND3yqFf%2Bmy7IymV5RUV9Ta4
1yVuEc&pciNonSensitive=false
TABLE 2-8 HTTPS POST Required Components - Vantiv Mobile API for Visa Checkout
Parameter Name Description
visaCheckout.apiKey The API key used to identify the shared secret used by
Visa Checkout and Vantiv to decrypt the
encPaymentData and encKey fields. You use both a
live key and a sandbox key, which are different from
each other.
visaCheckout.encKey Encrypted key to be used to decrypt
encPaymentData. Vantiv uses its shared secret
identified by the apiKey to decrypt this key.
visaCheckout.encPaymentData Encrypted consumer and payment data that can be
used to process the transaction. Vantiv uses the
decrypted encKey decrypt this value. The decrypted
value will be returned in the eProtect response.
visaCheckout.callid Visa Checkout transaction ID associated with a
payment request.
Integration and Testing Integrating eProtect Into Your Mobile Application
56 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.3.3.3 Sample Visa Checkout POST Response
The response received in the body of the POST response is a JSON string similar to the
following:
{"paypageRegistrationId":"1479321767965480923","bin":"400552","type":"VI","firstSix":"4005
52","lastFour":"4821","visaCheckoutResponse":"{\"userData\":{\"userFirstName\":\"Jonathon\
",\"userLastName\":\"Ross\",\"userFullName\":\"Jonathon Ross\",\"userName\":\"jross@
vantiv.com\",\"encUserId\":\"s/XZjc5uAHsIHCrH+NwOkqfIrWmM1oO4lcj3Tkw/3eA\\u003d\",\"userEm
ail\":\"jross@vantiv.com\"},\"paymentRequest\":{\"merchantRequestId\":\"Merchant defined
requestID\",\"currencyCode\":\"USD\",\"subtotal\":\"10\",\"shippingHandling\":\"2\",\"tax\
":\"2\",\"discount\":\"1\",\"giftWrap\":\"2\",\"misc\":\"1\",\"total\":\"16\",\"orderId\":
\"Merchant defined order ID\",\"description\":\"...corp Product\",\"promoCode\":\"Merchant
defined promo code\"},\"paymentInstrument\":{\"id\":\"QexjXZ5cNF/+v2nb50kXCTN2as05wC7G+
gXh8iN/kaY\\u003d\",\"lastFourDigits\":\"4821\",\"binSixDigits\":\"400552\",\"paymentType\
":{\"cardBrand\":\"VISA\",\"cardType\":\"CREDIT\"},\"billingAddress\":{\"personName\":\"Jo
nathon Ross\",\"firstName\":\"Jonathon\",\"lastName\":\"Ross\",\"line1\":\"900 Chelmsford
Street\",\"line2\":\"Floor 11 co Vantiv eCommerce\",\"city\":\"Lowell\",\"stateProvince
Code\":\"MA\",\"postalCode\":\"01851\",\"countryCode\":\"US\",\"phone\":\"9782756684\",\"d
efault\":false},\"verificationStatus\":\"VERIFIED\",\"expired\":false,\"cardArts\":{},\"is
suerBid\":\"14\",\"nameOnCard\":\"Jonathon Ross\",\"cardFirstName\":\"Jonathon\",\"card
LastName\":\"Ross\",\"expirationDate\":{\"month\":\"12\",\"year\":\"2020\"}},\"shippingAdd
ress\":{\"id\":\"lY6VPBAi7ajTAS0XqKizskaC0GuTrYzYOtxiC5URnDY\\u003d\",\"verificationStatus
\":\"VERIFIED\",\"personName\":\"Jonathon Ross\",\"firstName\":\"Jonathon\",\"lastName
\":\"Ross\",\"line1\":\"900 Chelmsford Street\",\"line2\":\"Floor 11 co Vantiv eCommerce\
",\"city\":\"Lowell\",\"stateProvinceCode\":\"MA\",\"postalCode\":\"01851\",\"countryCode\
":\"US\",\"phone\":\"9782756684\",\"default\":false},\"riskData\":{\"advice\":\"UNAVAILABL
E\",\"score\":\"0\",\"avsResponseCode\":\"0\",\"cvvResponseCode\":\"0\",\"ageOfAccount\":\
"1\"},\"newUser\":false}","cnpTxnId":"82832924191048159","orderId":"TC7976_1_viCheckoutPPP
ost","response":"870","responseTime":"2017-06-27T19:53:24","message":"Success","reportGrou
p":"VIReportGroup","id":"12345"}
2.3.4 Using the Vantiv Mobile API for Android Pay
This is the recommended and typical method of implementing Android Pay for Web and Mobile
Applications on the Vantiv eCommerce platform. The steps that follow, along with Figure 2-5,
illustrate the high level flow of messages associated with an Android Pay purchase, when
utilizing the Vantiv eProtect service.
1. When the consumer clicks the Android Pay button in your application, the action triggers a
MaskedWalletRequest to Google. In the MaskedWalletRequest, you must set a new
NOTE:This section is an excerpt from the Vantiv eCommerce Technical
Publication, Vantiv eCommerce Solution for Android Pay. Refer to the full
document for further information.
NOTE:This process assumes you have integrated with Google using the method
that returns the Vantiv low-value token (paypageRegistrationId) from
Google following the Full Wallet request.
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 57
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
object PaymentMethodTokenizationParameters indicating that you are using Vantiv.
Use the following code sample as a guide to setting this field.
Setting the PaymentMethodTokenizationParameters
PaymentMethodTokenizationParameters parameters =
PaymentMethodTokenizationParameters .newBuilder()
.setPaymentMethodTokenizationType(PaymentMethodTokenizationType.PAYMENT_GATEWAY)
.addParameter("gateway","vantiv")
.addParameter("vantiv:merchantPayPageId",payPageId)
.addParameter("vantiv:merchantOrderId",orderId)
.addParameter("vantiv:merchantTransactionId",id)
.addParameter("vantiv:merchantReportGroup",reportGroup)
.build();
Setting New Object in the MaskedWalletRequest
MaskedWalletRequest request = MaskedWalletRequest.newBuilder()
.setMerchantName(Constants.MERCHANT_NAME)
.setPhoneNumberRequired(true)
.setShippingAddressRequired(true)
.setCurrencyCode(Constants.CURRENCY_CODE_USD)
.setEstimatedTotalPrice(cartTotal)
.setCart(Car.newBuilder()
.setCurrencyCode(Constants.CURRENCY_CODE_USD)
.setTotalPrice(cartTotal)
.setLineItems(lineItems)
.build())
.setPaymentMethodTokenizationParameters(parameters)
.build();
The information returned by Google in the MaskedWallet object may include a masked
card number (last-four digits exposed) and shipping information. The consumer has the
option of changing this information. If any info changes, Android Pay returns an updated
MaskedWallet object.
IMPORTANT:You must use the same orderId value on all calls (i.e., Google,
Register Token, Authorization, Sale, etc.). Failure to use the same
orderId can prevent customers from tracking their orders using the
Android Pay application.
Integration and Testing Integrating eProtect Into Your Mobile Application
58 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2. Upon confirmation of the order by the consumer your application initiates a
FullWalletRequest to Google.
3. After receiving the FullWalletRequest from your application, Google submits the card
information to Vantiv eProtect. The eProtect servers return a low-value token
(paypageRegistrationId).
4. Google returns the low-value token to your application along with the Full Wallet
information.
5. Your applications sends the transaction information to your servers along with the low-value
token. Your servers submit the Auth/Sale transaction to the Vantiv eCommerce platform. You
must set the orderSource to androidpay in the transaction.
6. Vantiv processes your transaction normally and returns the results along with a high-value
token.
NOTE:Instead of submitting a Auth/Sale transaction, you can submit a Register
Token transaction to convert the low-value token to a Vantiv high-value
token. You would then use the high-value token in subsequent
transactions submitted to the eCommerce platform.
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 59
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
FIGURE 2-5 High Level Message Flow for Android Pay and Pay with Google™ using eProtect
2.3.5 Using the Vantiv Mobile API for Pay with Google
This is the recommended and typical method of implementing Pay with Google for Mobile
Applications on the Vantiv eCommerce platform. The steps that follow, along with Figure 2-5,
illustrate the high level flow of messages associated with an Pay with Google purchase, when
utilizing the Vantiv eProtect™ service.
Web App/
Mobil App
Merchant
Server eComm
Card
Networks
1
2
3
4
5
6
eProtect
Integration and Testing Integrating eProtect Into Your Mobile Application
60 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
1. When the consumer clicks the Pay with Google button in your application, the action triggers
a PaymentDataRequest to Google. In the PaymentDataRequest, you must set a new
object PaymentMethodTokenizationParameters indicating that you are using Vantiv.
Use the following code sample as a guide to setting this field.
Setting the PaymentMethodTokenizationParameters
PaymentMethodTokenizationParameters parameters =
PaymentMethodTokenizationParameters .newBuilder()
.setPaymentMethodTokenizationType(PaymentMethodTokenizationType.PAYMENT_GATEWAY)
.addParameter("gateway","vantiv")
.addParameter("vantiv:merchantPayPageId",payPageId)
.addParameter("vantiv:merchantOrderId",orderId)
.addParameter("vantiv:merchantTransactionId",id)
.addParameter("vantiv:merchantReportGroup",reportGroup)
.build();
Setting New Object in the PaymentDataRequest
PaymentDataRequest request = PaymentDataRequest.newBuilder()
.addAllowedPaymentMethods (new List,int.(){
WalletConstants.PAYMENT_METHOD_CARD,
WalletConstants.PAYMENT_METHOD_TOKENIZED_CARD)
.setMerchantName(Constants.MERCHANT_NAME)
.setPhoneNumberRequired(true)
.setShippingAddressRequired(true)
.setCurrencyCode(Constants.CURRENCY_CODE_USD)
.setEstimatedTotalPrice(cartTotal)
.setCart(Cart.newBuilder()
.setCurrencyCode(Constants.CURRENCY_CODE_USD)
.setTotalPrice(cartTotal)
NOTE:This process assumes you have integrated with Google using the method
that returns the Vantiv low-value token (paypageRegistrationId) from
Google following the Full Wallet request.
IMPORTANT:Use the same orderId value on all calls (i.e., Google, Register Token,
Authorization, Sale, etc.). By using the same orderId, customers can
track their orders when using a Google-provided app.
Integrating eProtect Into Your Mobile Application Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 61
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
.setLineItems(lineItems)
.build())
.setPaymentMethodTokenizationParameters(parameters)
.build();
The information returned by Google in the PaymentDataRequest object may include a
masked card number (last-four digits exposed) and shipping information. The consumer has
the option of changing this information. If any info changes, Pay with Google returns an
updated PaymentDataRequest object.
2. Upon confirmation of the order by the consumer your application initiates a
FullWalletRequest to Google.
3. After receiving the FullWalletRequest from your application, Google submits the card
information to Vantiv eProtect. The eProtect servers return a low-value token
(paypageRegistrationId).
4. Google returns the low-value token to your application along with the Full Wallet
information.
5. Your applications sends the transaction information to your servers along with the low-value
token. Your servers submit the Auth/Sale transaction to the Vantiv eComm platform. You
must set the orderSource to androidpay in the transaction.
6. Vantiv processes your transaction normally and returns the results along with a high-value
token.
NOTE:Instead of submitting a Auth/Sale transaction, you can submit a Register
Token transaction to convert the low-value token to a Vantiv high-value
token. You would then use the high-value token in subsequent
transactions submitted to the eComm platform.
Integration and Testing Collecting Diagnostic Information
62 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.4 Collecting Diagnostic Information
In order to assist Vantiv in determining the cause of failed eProtect transactions (and avoid
potential lost sales), please collect the following diagnostic information when you encounter a
failure during the testing and certification process, and provide it to your eProtect
Implementation Consultant or your Relationship Manager if you are currently in production.
Error code returned and reason for the failure:
JavaScript was disabled on the customers browser.
JavaScript could not be loaded.
JavaScript was loaded properly, but the sendToEprotect call did not return a response,
or timed out (JavaScript API and Mobile API only).
JavaScript was loaded properly, but the sendToEprotect call returned a response code
indicating an error (JavaScript API and Mobile API only).
JavaScript was loaded properly, but the call to construct the EprotectIframeClient
failed (iFrame only).
JavaScript was loaded properly, but the getPaypageRegistrationId call failed
(iFrame only).
The orderId and merchantTxnId for the transaction.
Where in the process the failure occurred.
Information about the customers browser, including the version.
For further information on methods for collecting diagnostic information, contact your eProtect
Implementation Consultant or Vantiv Implementation Consultant if you are currently in the
testing and certification process, or your Relationship Manager if you are currently in production.
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 63
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.5 Transaction Examples When Using ISO 8583, 610,
HHMI, and PWS
This section describes how to format the Registration ID to the applicable message interface
specification. These transactions are submitted by your payment processing system after your
customer clicks the submit button on your checkout page. Your payment processing system sends
the transactions to Vantiv with the <paypageRegistrationId> returned by eProtect and the
Vantiv maps the Registration ID to the OmniToken and card number.
Examples are included for the following message interface types on the following pages:
Vantiv Online Systems - Acquirer ISO 8583 Message Format on page 64
Vantiv Online Systems - 610 Message Format on page 67
(HHMI) Host-to-Host Format on page 70
Payment Web Services (PWS) External Payments on page 71
For further information on transaction examples with Registration ID, see the following
documentation:
Acquirer ISO 8583 Message Format (Effective 02.15.2017)
Vantiv Online Systems 610 Interface Reference Guide (Effective 02.15.2017)
HHMI: Host-To-Host Format Specification (Effective Date 02.15.2017)
Payment Web Services (PWS) External Payments Developers' Guide (V6.1.2)
NOTE:The Registration ID is a temporary identifier used to facilitate the mapping
of a token to a card number, and expires within 24-hours of issuance. If
you do not submit an Authorization, Sale, or Register Token transaction
containing the <paypageRegistrationId> within 24-hours, the system
returns an unsuccessful response code based on the applicable message
specification, and no token is issued.
Integration and Testing Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
64 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.5.1 Vantiv Online Systems - Acquirer ISO 8583 Message Format
Example: Request
The following example contains an authorization request with the Registration ID in field 120. If
you are planning on converting a Registration ID to a network token with an Apple Pay or
Android Pay cryptogram, set field 25 to ‘59,’ (indicates eCommerce). Conversion to a network
token is not accepted unless it is an eCommerce transaction.
Note that you can send the Registration ID without using 59 in field 25 (for example, if you are
not using Apple Pay or Android Pay); the use of a Registration ID in general, is not specific to
eCommerce.
PARSE FORMAT: MISD USER: O3 DATE: 10/16/14 TIME: 14.45.35
NUM |FLDNAME |FIELD DESCRIPTION |LEN |T|FIELD VALUE
-----|--------|-------------------------------|----|-|--------------------------
N/A |MSGTYPE |MESSAGE TYPE |F2 |H|0200`
N/A |BITMAP1 |FIRST BITMAP |B8 |H|B238648108E080B4`
1 |BITMAP2 |SECOND BITMAP |B8 |H|0000000000000120`
3 |MISDPRCD|PROCESSING CODE |F3 |H|003000`
4 |MISDTRNA|AMOUNT, TRANSACTION |F6 |H|000000001000`
7 |MISDTMDT|TRANSMISSION DATE AND TIME |F5 |H|`
7 | |TRANSMISSION DATE (MMDD) |F2 |H|1015`
7 | |TRANSMISSION TIME (HHMMSS) |F3 |H|091508`
11 |MISDSTAN|SYSTEM TRACE AUDIT NUMBER |F3 |H|091508`
12 |MISDLCTM|LOCAL TRANSACTION TIME(HHMMSS) |F3 |H|091508`
13 |MISDLCDT|LOCAL TRANSACTION DATE (MMDD) |F2 |H|1015`
18 |MISDMRHT|MERCHANT TYPE |F2 |H|5541`
19 |MISDAQCC|ACQUIRER INST. COUNTRY CODE |F2 |H|0840`
22 |MISDPOSE|POS ENTRY MODE |F2 |H|`
22 | |PAN/DATE ENTRY MODE |F1 |H|01`
22 | |PIN ENTRY CAPABILITY |F1 |H|20`
25 |MISDPOSC|POS CONDITION CODE |F1 |H|00`
32 |MISDAIID|ACQUIRING INST ID CODE |1V10|H|1042000314`
37 |MISDRRN |RETRIEVAL REFERENCE NUMBER |F12 |C|218510080021`
41 |MISDTMID|TERMINAL ID |F15 |C|XXX12345 `
42 |MISDCAID|CARD ACCEPTOR INSTITUTION ID |F15 |C|123456789 `
43 |MISDTMAD|CARD ACCEPTOR NAME/LOCATION |F40 |C|`
43 | |STREET ADDRESS |F23 |C|123 MAIN ST `
43 | |CITY |F13 |C|CINCINNATI `
43 | |STATE |F2 |C|OH`
43 | |COUNTRY |F2 |C|US`
49 |MISDCCTR|CURRENCY CODE, TRANSACTION |F2 |H|0840`
57 | |PRODUCT TYPE |F3 |C|REQ`
59 |MISDPGEO|NATIONAL POS GEOGRAPHIC DATA |2V14|C|2600049770 `
60 |MISDARRC|ADDITIONAL POS DATA |2V36|C|`
60.1 | |TERMINAL TYPE |F1 |C|4`
60.2 | |PHYSICAL TERMINAL LOCATION |F1 |C|1`
60.3 | |TERMINAL ENTRY CAPABILITY |F1 |C|2`
60.4 | |MERCHANT TYPE INDICATOR |F1 |C| `
60.5 | |POS CARD RETENTION INDICATOR |F1 |C|0`
60.6 | |POS TRANS STATUS INDICATOR |F1 |C|P`
60.7 | |POS TRANS ROUTING INDICATOR |F1 |C|0`
60.8 | |CHAIN NUMBER |F6 |C|012345`
60.9 | |DIVISION NUMBER |F3 |C|000`
60.10| |STORE NUMBER |F8 |C|00000123`
60.11| |LANE NUMBER |F3 |C|082`
60.12| |EMPLOYEE NUMBER |F9 |C|000000000`
62 |MISDREF |5/3 TRANSACTION DATA |2V23|C|`
62 | |5/3 TRANSACTION DATA BITMAP 1 |B8 |H|4000000404004000`
62.2 | |TERMINAL SEQUENCE NUMBER |F3 |H|091508`
62.30| |PREFERRED DEBIT ROUTING FLAG |F1 |C|0`
62.38| |SALES TAX |F10 |C|0000000035`
62.50| |SALES TAX ADDENDUM FLAG |F1 |C|1`
120 |MISDADDD|ADDITIONAL REQUEST DATA |2V24|C|RG0197239326028935438868'
123 |MISDMRHN|MERCHANT NAME |F15 |C|VANTIV TEST
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 65
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Example: Response
The following example contains a response with the OmniToken in field 120.
PARSE FORMAT: MISD USER: O3 DATE: 10/16/14 TIME: 14.42.39
NUM |FLDNAME |FIELD DESCRIPTION |LEN |T|FIELD VALUE
-----|--------|-------------------------------|----|-|--------------------------
N/A |MSGTYPE |MESSAGE TYPE |F2 |H|0210`
N/A |BITMAP1 |FIRST BITMAP |B8 |H|B23A64010EF080B4`
1 |BITMAP2 |SECOND BITMAP |B8 |H|0000000000000120`
3 |MISDPRCD|PROCESSING CODE |F3 |H|003000`
4 |MISDTRNA|AMOUNT, TRANSACTION |F6 |H|000000001000`
7 |MISDTMDT|TRANSMISSION DATE AND TIME |F5 |H|`
7 | |TRANSMISSION DATE (MMDD) |F2 |H|1015`
7 | |TRANSMISSION TIME (HHMMSS) |F3 |H|091508`
11 |MISDSTAN|SYSTEM TRACE AUDIT NUMBER |F3 |H|091508`
12 |MISDLCTM|LOCAL TRANSACTION TIME(HHMMSS) |F3 |H|091508`
13 |MISDLCDT|LOCAL TRANSACTION DATE (MMDD) |F2 |H|1015`
15 |MISDSTLD|SETTLEMENT DATE (MMDD) |F2 |H|1016`
18 |MISDMRHT|MERCHANT TYPE |F2 |H|5541`
19 |MISDAQCC|ACQUIRER INST. COUNTRY CODE |F2 |H|0840`
22 |MISDPOSE|POS ENTRY MODE |F2 |H|`
22 | |PAN/DATE ENTRY MODE |F1 |H|01`
22 | |PIN ENTRY CAPABILITY |F1 |H|20`
32 |MISDAIID|ACQUIRING INST ID CODE |1V10|H|1042000314`
37 |MISDRRN |RETRIEVAL REFERENCE NUMBER |F12 |C|218510080021`
38 |MISDATID|AUTH. IDENTIFICATION RESPONSE |F6 |C|493936`
39 |MISDRSPC|RESPONSE CODE |F2 |C|00`
41 |MISDTMID|TERMINAL ID |F15 |C|XXX12345 `
42 |MISDCAID|CARD ACCEPTOR INSTITUTION ID |F15 |C|123456789 `
43 |MISDTMAD|CARD ACCEPTOR NAME/LOCATION |F40 |C|`
43 | |STREET ADDRESS |F23 |C|123 MAIN ST `
43 | |CITY |F13 |C|CINCINNATI `
43 | |STATE |F2 |C|OH`
43 | |COUNTRY |F2 |C|US`
44 |MISDRDTA|ADDITIONAL RESPONSE DATA |2V4 |C|`
44.1 | |AUTHORIZATION SOURCE |F1 |C| `
44.2 | |ADDRESS VERIFICATION RESULT |F1 |C| `
44.3 | |CVV2/CVC2 RESPONSE CODE |F1 |C|N`
44.4 | |RECURRING PAYMENT ADVICE |F1 |C| `
49 |MISDCCTR|CURRENCY CODE, TRANSACTION |F2 |H|0840`
57 | |PRODUCT TYPE |F3 |C|A C
59 |MISDPGEO|NATIONAL POS GEOGRAPHIC DATA |2V14|C|2600049770 `
60 |MISDARRC|ADDITIONAL POS DATA |2V7 |C|`
60.1 | |TERMINAL TYPE |F1 |C|4`
60.2 | |PHYSICAL TERMINAL LOCATION |F1 |C|0`
60.3 | |TERMINAL ENTRY CAPABILITY |F1 |C|0`
60.4 | |MERCHANT TYPE INDICATOR |F1 |C| `
60.5 | |POS CARD RETENTION INDICATOR |F1 |C|0`
60.6 | |POS TRANS STATUS INDICATOR |F1 |C|0`
60.7 | |POS TRANS ROUTING INDICATOR |F1 |C|0`
62 |MISDREF |5/3 TRANSACTION DATA |2V29|C|`
62 | |5/3 TRANSACTION DATA BITMAP 1 |B8 |H|5E40000000000000`
62.2 | |TERMINAL SEQUENCE NUMBER |F3 |H|091508`
62.4 | |ACQUIRING INST ACRONYM |F4 |C|MPSM`
62.5 | |ISSUING INST ACRONYM |F4 |C|VISN`
62.6 | |OWNER SETTLEMENT AGENT |F4 |C|MPSM`
62.7 | |CARDHOLDER SETTLEMENT AGENT |F4 |C|VISN`
62.10| |POS BATCH REFERENCE NUMBER |F2 |H|0000`
120 |MISDADDD|ADDITIONAL REQUEST DATA |2V24|C|TK1234567890120007 `
123 |MISDMRHN|MERCHANT NAME |F15 |C|VANTIV TEST
Integration and Testing Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
66 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Table 2-9 lists the Credit Response Code Mappings for ISO 8583.
TABLE 2-9 Example Credit Response Code Mappings for ISO 8583
Response
Code Action Card Disp. Description
00 Approve Return Transaction Approved
01 Refer Return Refer to Card Issuer
02 Refer Return Refer to Card Issuer, Special Conditions
03 Decline Return Invalid Merchant ID
04 Decline Keep Pick up Card
05 Decline Return Generic Authorization Decline
06 Decline Return Error
07 Decline Keep Pick up Card, Special Conditions
08 Approve Return Honor with Identification
10 Approve Return Approved for Partial Amount
11 Approve Return VIP Approval
12 Decline Return Invalid Transaction
13 Decline Return Invalid Amount
14 Decline Return Invalid Account Number
15 Decline Return No Such Issuer
17 Decline Return Customer Cancellation
19 Decline Return Re-try Transaction
21 Decline Return Reversal Unsuccessful
25 Decline Return Unable to locate record on file
27 Decline Return File update field edit error
28 Decline Return Update file temporarily unavailable
30 Decline Return Message Format Error
32 Decline Return Partial Reversal
33 Decline Keep Pick Up Card - Expired
38 Decline Keep Allowable Number of PIN Tries Exceeded
39 Decline Return No Credit Amount
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 67
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.5.2 Vantiv Online Systems - 610 Message Format
This section contains examples of an Authorization with a Registration ID, a Sale with a
Registration ID request, and a Token Conversion Request using the 610 Interface format (where *
= space, <rs> = record separator, <gs>= group separator).
Example: Authorization Request
Example of Credit Card Authorization Request using Registration-ID:
|I2.|123456|0100|21|004000|123456789|123456|1234|123456|123456|123456|011|0000000600|11
11|222|333333333333|123|******************************************************************
**********|12345678|12345678|123456789|123|12|PO#/CUSTOMER*CODE***|123456789|TRACE*DATA*1*
***|<rs>G028|1234567890123456789|R*****|1234|<gs>
Example: Registration ID Request through Financial Transaction (sale)
Example of Credit Card Sale Request using Registration-ID:
|I2.|123456|0200|22|004000|000001500|0321031116|123456|032103|111600|812|0000000600|1111|2
22|333333333333|001|**********************************************************************
******|12345678|00000001|000000000|00|000|40|PO#/CUSTOMER*CODE***|000000000|TRACE*DATA*1**
**|<rs>G028|1234567890123456789|R*****|1234|<gs>
40 Decline Return Requested Function Not Supported
41 Decline Keep Pick up Card - Lost
43 Decline Keep Pick up Card - Stolen
51 Decline Return Insufficient Funds
52 Decline Return No Checking Account
53 Decline Return No Savings Account
54 Decline Return Expired Card
55 Decline Return Incorrect PIN
56 Decline Return Cannot Process
57 Decline Return Transaction not Permitted to Cardholder
58 Decline Return Transaction not Permitted to Acquirer
61 Decline Return Exceeds Withdrawal Limit
TABLE 2-9 Example Credit Response Code Mappings for ISO 8583 (Continued)
Response
Code Action Card Disp. Description
Integration and Testing Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
68 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Example: Token Conversion Request
Example of Token Conversion Request for a low-value token:
|I2.|123456|0100|50|800000|0321031116|123456|032103|111600|812|0000000600|1111|222|3333333
33333|001|****************************************************************************|123
45678|00001234|000|00|TRACE*DATA*1****|99999999|999999|
For more information, see Appendix B, “Special Transaction Provisioning,” in the Vantiv Online
Systems 610 Interface Reference Guide (Effective 02.15.2017).
2.5.2.1 Response
Example: Token Approval Response
|0110|53|123456|0321031116|123456|TRACE*DATA*1****|138001|N|
If host tokenization fails (F value) when processing Legacy or Omni tokens, the token contains
spaces and the Token ID contains ZZZZZZ. The host attempts to process transaction requests
without token data (using clear PAN or Track) when applicable. The transaction may result in an
approval or decline using E2EE and/or clear PAN/track data.
If host tokenization fails when processing the Registration ID, the token field and token-id field is
not returned in R017. The error is indicated by presence of this Field Type 4, Value F. The
transaction results in a decline if a token can not be created using the Registration ID.
Table 2-10 lists some of the most common TPS codes, including 416 - REGISTRATION ID NOT
FOUND. These codes are not necessarily tied to a specific network or product. Vantiv returns
them for any card type depending on the transaction disposition.
TABLE 2-10 TPS Global Response Codes
TPS
Response
Message Description
001 AUTH DOWN This is the TPS response when no external authorizer is
available.
307 CONVERSION
TRAN ERR
Description: Token/De-token conversion transaction not allowed
Action: Check Host tokenization configuration settings and
request message
307 PAYMENT
TYPE ERROR
Description: Host payment type setup configured to decline
token transaction request
Action: Check Host tokenization configuration settings and
request message
307 ADDITIONAL
TRAN ERR
Description: Transaction not allowed to use token
Action: Check Host tokenization configuration settings and
request message
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 69
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
For more information and a complete list, see Appendix A, “TPS Response Codes,” in the Vantiv
Online Systems 610 Interface Reference Guide (Effective 02.15.2017).
307 RESTRICT
TRAN ERROR
Description: Restricted transactions not allowed to process
Action: Check Host tokenization configuration settings and
request message
307 INVALID
TRACK DATA
Description: Track data is blank, unable to tokenize transaction
request
Action: Verify values for clear PAN or Track data - retry
transaction
307 INV POS COND
CODE
Description: POS condition code is invalid for request message
Action: Verify values for POS condition code field - retry
transaction
307 INV ORIG DATE
TIME
Description: Invalid token original date or time values, not
numeric or format issue
Action: Verify POS values for token original date and time fields
- retry transaction
307 TRAN NOT
ALLOWED
Description: Transaction requesting or using token is not
allowed
Action: Verify POS request message - retry transaction
307 POS ENTRY
MODE ERROR
Description: Transaction request using token must set manual
POS entry mode
Action: Verify POS request message - retry transaction
307 PAN OR TRACK
ERROR
Description: Transaction using token must initialize track and/or
PAN to spaces
Action: Verify POS request message - retry transaction
416 REGISTRATION
-ID NOT
FOUND
Description: The Registration-ID used in the transaction could
not be found in the ES data base. It may have expired.
Action: Check the Registration-ID and retry the transaction.
714 INV CARD
NUMBER
This is the TPS response code that will most commonly be
presented when a transaction fails to locate a viable routing
option.
796 AUTH DOWN System malfunction
TABLE 2-10 TPS Global Response Codes (Continued)
TPS
Response
Message Description
Integration and Testing Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
70 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.5.3 (HHMI) Host-to-Host Format
The following example contains an authorization request with the Registration ID in field 25,
using HOST-to-HOST Format.
Example: Request
PARSE FORMAT: HHMI USER: O3 DATE: 10/16/14 TIME: 14.25.51
NUM |FLDNAME |FIELD DESCRIPTION |LEN |T|FIELD VALUE
-----|--------|-------------------------------|----|-|--------------------------
N/A |1 |MESSAGE ID |F4 |C|EFQC`
N/A |2 |MESSAGE SEQUENCE NUMBER |F6 |C|164259`
N/A |3 |TRANSACTION DATE (YYMMDD) |F6 |C|141015`
N/A |4 |TRANSACTION TIME (HHMMSS) |F6 |C|164259`
N/A |5 |TERMINAL OWNER ID |F4 |C|MPSM`
N/A |9 |TERMINAL OWNER |F10 |C|9222222222`
N/A |10 |TERMINAL TYPE |F2 |C|03`
N/A |12 |TERMINAL NUMBER (RESP ONLY) |F6 |C| `
N/A |13 |TERMINAL SEQUENCE NUMBER |F6 |C|164259`
N/A |15 |SETTLEMENT DATE (RESP ONLY) |F6 |C| `
N/A |16 |TRANSMISSION DATE (YYMMDD) |F6 |C|141015`
N/A |17 |SHARING GROUP |F6 |C|9E80EA`
N/A |18 |REGIONAL MAP NUMBER |F2 |C|18`
N/A |19 |CARDHOLDER ID |F4 |C|SWTH`
N/A |21 |CARDHOLDER R&T NUM (RESP ONLY) |F10 |C| `
N/A |22 |CARDHOLDER NTWK ID (RESP ONLY) |F4 |C| `
N/A |23 |RESERVED |F10 |C| `
N/A |23 |RESERVED |F10 |C| `
N/A |24 |TRANSACTION TYPE |F2 |C|46`
N/A |25 |TRANSACTION AMOUNT |F10 |C|0000000100`
N/A |26 |FROM ACCOUNT |F3 |C|CC `
N/A |27 |TO ACCOUNT |F3 |C| `
N/A |28 |TRAN PROGRESS IND / PATH ID |F2 |C|01`
N/A | |VARIABLE ADDENDUM FIELDS |D2 |C|`
NA.04|31 |ACQUIRER TERMINAL IDENT. |3V8 |C|XXX12345`
NA.05|32 |TERMINAL LOCATION LENGTH |F3 |C|044`
NA.05|32 |TERMINAL STREET ADDR |F27 |C|123 MAIN ST `
NA.05|32 |TERMINAL CITY |F15 |C|CINCINNATI `
NA.05|32 |TERMINAL STATE |F2 |C|OH`
NA.07|34 |TERMINAL BUSINESS DATE (YYMMDD)|3V6 |C|141015`
NA.09|99 |SALES TAX ADDENDUM FLAG |3V1 |C|0`
NA.25|126 |E2E / TOKEN DATA |3V24|C|RG0197239326028935438868`
NA.41|44 |MERCHANT ACCOUNT NUMBER |3V20|C|123456789 `
NA.42|45 |POS MERCHANT DATA |3V20|C|840010000005411 `
NA.47|47 |MERCHANT REPORTING IDENT. |3V24|C|800200000001008000000000`
NA.99|56 |END SENTINEL |F0 |C|`
The following example contains an authorization response in field 25, using HOST-to-HOST
Format.
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 71
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Example: Response
PARSE FORMAT: HHMI USER: O3 DATE: 10/16/14 TIME: 14.34.40
NUM |FLDNAME |FIELD DESCRIPTION |LEN |T|FIELD VALUE
-----|--------|-------------------------------|----|-|--------------------------
N/A |1 |MESSAGE ID |F4 |C|EFRC`
N/A |2 |MESSAGE SEQUENCE NUMBER |F6 |C|164259`
N/A |3 |TRANSACTION DATE (YYMMDD) |F6 |C|141015`
N/A |4 |TRANSACTION TIME (HHMMSS) |F6 |C|164259`
N/A |5 |TERMINAL OWNER ID |F4 |C|MPSM`
N/A |9 |TERMINAL OWNER |F10 |C|9222222222`
N/A |10 |TERMINAL TYPE |F2 |C|03`
N/A |12 |TERMINAL NUMBER (RESP ONLY) |F6 |C|016731`
N/A |13 |TERMINAL SEQUENCE NUMBER |F6 |C|164259`
N/A |15 |SETTLEMENT DATE (RESP ONLY) |F6 |C|141015`
N/A |16 |TRANSMISSION DATE (YYMMDD) |F6 |C|141015`
N/A |17 |SHARING GROUP |F6 |C|9E80EA`
N/A |18 |REGIONAL MAP NUMBER |F2 |C|18`
N/A |19 |CARDHOLDER ID |F4 |C|VISN`
N/A |21 |CARDHOLDER R&T NUM (RESP ONLY) |F10 |C|1000000000`
N/A |22 |CARDHOLDER NTWK ID (RESP ONLY) |F4 |C|VISN`
N/A |23 |RESERVED |F10 |C| `
N/A |24 |TRANSACTION TYPE |F2 |C|46`
N/A |25 |TRANSACTION AMOUNT |F10 |C|0000000100`
N/A |26 |FROM ACCOUNT |F3 |C|CC `
N/A |27 |TO ACCOUNT |F3 |C| `
N/A |28 |TRAN PROGRESS IND / PATH ID |F2 |C|01`
N/A | |VARIABLE ADDENDUM FIELDS |D2 |C|`
NA.04|31 |ACQUIRER TERMINAL IDENT. |3V8 |C|XXX12345`
NA.06|33 |RESPONSE ADVICE |3V5 |C|0R000`
NA.08|35 |PROCESSOR BUSINESS DATE |3V6 |C|141015`
NA.12|37 |FROM ACCOUNT |3V22|C|CC `
NA.25|126 |E2E / TOKEN DATA |3V24|C|TK1234567890120007
NA.40|43 |AUTHORIZATION STATUS |3V8 |C|AA241586`
NA.41|44 |MERCHANT ACCOUNT NUMBER |3V20|C|123456789 `
NA.47|47 |MERCHANT REPORTING IDENT. |3V15|C|800200000001008`
NA.63|53 |POS BATCH REFERENCE NUMBER |3V4 |C|0000`
NA.85|85 |CVV2 |3V1 |C|N`
NA.99|56 |END SENTINEL |F0 |C|`
2.5.4 Payment Web Services (PWS) External Payments
The example below contains an authorization request with Registration ID.
For response codes, please see the “Response” section of the Payment Web Services (PWS)
External Payments Developers' Guide - V6.1.2. For unsuccessful attempts, see the
Troubleshooting section for SOAP Faults List.
NOTE:eProtect in combination with PWS is available to existing PWS customers
only.
Integration and Testing Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
72 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Example: Authorization Request
Transaction Examples When Using ISO 8583, 610, HHMI, and PWS Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 73
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Integration and Testing Transaction Examples When Using ISO 8583, 610, HHMI, and PWS
74 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
The example below contains an authorization response.
Example: Authorization Response
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 75
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.6 Transaction Examples When Using cnpAPI
This section describes how to format cnpAPI transactions when using the eProtect feature of the
Vault solution. These standard cnpAPI transactions are submitted by your payment processing
system after your customer clicks the submit button on your checkout page. Your payment
processing system sends the transactions to Vantiv with the <paypageRegistrationId> from
the response message, and the Vault maps the Registration ID to the token and card number,
processing the payment as usual.
See cnpAPI Elements for eProtect on page 108 for definitions of the eProtect-related elements
used in these examples.
This section is meant as a supplement to the Vantiv cnpAPI Reference Guide. Refer to the Vantiv
cnpAPI Reference Guide for comprehensive information on all elements used in these examples.
2.6.1 Transaction Types and Examples
This section contains examples of the following transaction types:
Authorization Transactions
Sale Transactions
Register Token Transactions
Force Capture Transactions
Capture Given Auth Transactions
Credit Transactions
For each type of transaction, only online examples are shown, however batch transactions for all
the above transaction types are also supported when using the eProtect feature. See the Vantiv
cnpAPI Reference Guide for information on forming batch transactions.
NOTE:The PayPage Registration ID is a temporary identifier used to facilitate the
mapping of a token to a card number, and consequently expires within 24
hours of issuance. If you do not submit an Authorization, Sale, or Register
Token transaction containing the <paypageRegistrationId> within 24
hours, the system returns a response code of 878 - Expired PayPage
Registration ID, and no token is issued.
Integration and Testing Transaction Examples When Using cnpAPI
76 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.6.2 Authorization Transactions
The Authorization transaction enables you to confirm that a customer has submitted a valid
payment method with their order and has sufficient funds to purchase the goods or services they
ordered.
This section describes the format you must use for an Authorization request when using the
eProtect feature, as well as the Authorization Response format.
2.6.2.1 Authorization Request Structure
You must structure an Authorization request as shown in the following examples when using
eProtect.
<
authorization
id="Authorization Id"
reportGroup
="UI Report Group"
customerId
="Customer Id">
<
orderId
>Order Id</
orderId
>
<
amount
>Authorization Amount</
amount
>
<
orderSource
>ecommerce</
orderSource
>
<
billToAddress
>
<
shipFromPostalCode
>
<paypage>
<paypageRegistrationId>Registation ID returned</paypageRegistrationId>
<expDate>Card Expiration Date</
expDate
>
<cardValidationNum>Card Validation Number</cardValidationNum>
</paypage>
</
authorization
>
Example: Online Authorization Request
<cnpOnlineRequest version="12.0" xmlns="http://www.vantivcnp.com/schema"
merchantId="100">
<authentication>
<user>User Name</user>
<password>Password</password>
</authentication>
<authorization id="834262" reportGroup="ABC Division" customerId="038945">
NOTE:Although the schema defines the <expDate> element as an optional child
of <paypage> element, Vantiv does not store expiration dates. Therefore,
you must always submit an expiration date value with each eProtect
cnpAPI transaction.
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 77
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<orderId>65347567</orderId>
<amount>40000</amount>
<orderSource>ecommerce</orderSource>
<billToAddress>
<name>John Smith</name>
<addressLine1>100 Main St</addressLine1>
<city>Boston</city>
<state>MA</state>
<zip>12345</zip>
<email>jsmith@someaddress.com</email>
<phone>555-123-4567</phone>
</billToAddress>
<paypage>
<paypageRegistrationId>cDZJcmd1VjNlYXNaSlRMTGpocVZQY1NNlYE4ZW5UTko4NU
9KK3p1L1p1VzE4ZWVPQVlSUHNITG1JN2I0NzlyTg=</paypageRegistrationId>
<expDate>1012</expDate>
<cardValidationNum>000</cardValidationNum>
</paypage>
</authorization>
</cnpOnlineRequest>
2.6.2.2 Authorization Response Structure
An Authorization response has the following structure:
<
authorizationResponse
id="Authorization Id" reportGroup="UI Report
Group" customerId="Customer Id">
<
cnpTxnId
>
Transaction Id
</
cnpTxnId
>
<
orderId
>Order Id</
orderId
>
<
response
>Response Code</
response
>
<
responseTime
>Date and Time in GMT</
responseTime
>
<
postDate
>Date transaction posted</
postDate
> (Online Only)
<
message
>Response Message</
message
>
<
authCode
>Approval Code</
authCode
>
<accountInformation>
<fraudResult>
<tokenResponse>
</
authorizationResponse
>
Integration and Testing Transaction Examples When Using cnpAPI
78 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Example: Online Authorization Response
<cnpOnlineResponse version="12.0" xmlns="http://www.vantivcnp.com/schema"
response="0" message="Valid Format">
<authorizationResponse id="834262" reportGroup="ABC Division"
customerId="038945">
<cnpTxnId>969506</cnpTxnId>
<orderId>65347567</orderId>
<response>000</response>
<responseTime>2009-07-25T15:13:43</responseTime>
<postDate>2009-07-25</postDate>
<message>Approved</message>
<authCode>123457</authCode>
<fraudResult>
<avsResult>11</avsResult>
<cardValidationResult>P</cardValidationResult>
</fraudResult>
<tokenResponse>
<cnpToken>1111000100090005</cnpToken>
<tokenResponseCode>801</tokenResponseCode>
<tokenMessage>Account number was successfully registered</tokenMessage>
<type>VI</type>
<bin>402410</bin>
</tokenResponse>
</authorizationResponse>
</cnpOnlineResponse>
NOTE:The online response format contains a <postDate> element, which
indicates the date the financial transaction will post (specified in
YYYY-MM-DD format).
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 79
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.6.3 Sale Transactions
The Sale transaction enables you to both authorize fund availability and deposit those funds by
means of a single transaction. The Sale transaction is also known as a conditional deposit,
because the deposit takes place only if the authorization succeeds. If the authorization is declined,
the deposit will not be processed.
This section describes the format you must use for a sale request, as well as the format of the Sale
Response.
2.6.3.1 Sale Request Structure
You must structure a Sale request as shown in the following examples when using eProtect:
<
sale
id="Authorization Id"
reportGroup
="UI Report Group"
customerId
="Customer Id">
<
orderId
>Order Id</
orderId
>
<
amount
>Authorization Amount</
amount
>
<
orderSource
>ecommerce</
orderSource
>
<
billToAddress
>
<
shipFromPostalCode
>
<paypage>
<paypageRegistrationId>Registation ID returned</paypageRegistrationId>
<expDate>Card Expiration Date</
expDate
>
<cardValidationNum>Card Validation Number</cardValidationNum>
</paypage>
</
sale
>
Example: Online Sale Request
<cnpOnlineRequest version="12.0" xmlns="http://www.vantivcnp.com/schema"
merchantId="100">
<authentication>
<user>User Name</user>
NOTE:Although the schema defines the <expDate> element as an optional child
of <paypage> element, Vantiv does not store expiration dates. Therefore,
you must always submit an expiration date value with each eProtect
cnpAPI transaction.
Integration and Testing Transaction Examples When Using cnpAPI
80 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<password>Password</password>
</authentication>
<sale id="834262" reportGroup="ABC Division" customerId="038945">
<orderId>65347567</orderId>
<amount>40000</amount>
<orderSource>ecommerce</orderSource>
<billToAddress>
<name>John Smith</name>
<addressLine1>100 Main St</addressLine1>
<city>Boston</city>
<state>MA</state>
<zip>12345</zip>
<email>jsmith@someaddress.com</email>
<phone>555-123-4567</phone>
</billToAddress>
<paypage>
<paypageRegistrationId>cDZJcmd1VjNlYXNaSlRMTGpocVZQY1NNlYE4ZW5UTko4NU
9KK3p1L1p1VzE4ZWVPQVlSUHNITG1JN2I0NzlyTg=</paypageRegistrationId>
<expDate>1012</expDate>
<cardValidationNum>000</cardValidationNum>
</paypage>
</sale>
</cnpOnlineRequest>
2.6.3.2 Sale Response Structure
A Sale response has the following structure:
<
SaleResponse
id="Authorization Id" reportGroup="UI Report Group"
customerId="Customer Id">
<
cnpTxnId
>
Transaction Id
</
cnpTxnId
>
<
response
>
Response Code
</
response
>
<
orderId
>
Order Id
</
orderId
>
<
responseTime
>
Date and Time in GMT
</
responseTime
>
<
postDate
>
Date transaction posted
</
postDate
> (Online Only)
<
message
>
Response Message
</
message
>
<
authCode
>
Approval Code
</
authCode
>
<accountInformation>
<fraudResult>
<tokenResponse>
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 81
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
</SaleResponse>
Example: Online Sale Response
<cnpOnlineResponse version="12.0" xmlns="http://www.vantivcnp.com/schema"
response="0" message="Valid Format">
<saleResponse id="834262" reportGroup="ABC Division" customerId="038945">
<cnpTxnId>969506</cnpTxnId>
<response>000</response>
<orderId>65347567</orderId>
<responseTime>2017-07-25T15:13:43</responseTime>
<postDate>2017-07-25</postDate>
<message>Approved</message>
<authCode>123457</authCode>
<fraudResult>
<avsResult>11</avsResult>
<cardValidationResult>P</cardValidationResult>
</fraudResult>
<tokenResponse>
<cnpToken>1111000100090005</cnpToken>
<tokenResponseCode>801</tokenResponseCode>
<tokenMessage>Account number was successfully registered</tokenMessage>
<type>VI</type>
<bin>402410</bin>
</tokenResponse>
</saleResponse>
</cnpOnlineResponse>
NOTE:The online response format contains a <postDate> element, which
indicates the date the financial transaction will post (specified in
YYYY-MM-DD format).
Integration and Testing Transaction Examples When Using cnpAPI
82 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.6.4 Register Token Transactions
The Register Token transaction enables you to submit a credit card number, or in this case, a
PayPage Registration Id to our system and receive a token in return.
2.6.4.1 Register Token Request
You must specify the Register Token request as follows. The structure of the request is identical
for either an Online or a Batch submission. The child elements used differ depending upon
whether you are registering a credit card account or a PayPage Registration Id.
When you submit the CVV2/CVC2/CID in a registerTokenRequest, our platform encrypts
and stores the value on a temporary basis (24 hours) for later use in a tokenized Authorization or
Sale transaction submitted without the value. This is done to accommodate merchant
systems/workflows where the security code is available at the time of token registration, but not
at the time of the Authorization/Sale. If for some reason you need to change the value of the
security code supplied at the time of the token registration, use an
updateCardValidationNumOnToken transaction. To use the stored value when submitting an
Auth/Sale transaction, set the cardValidationNum value to 000.
For PayPage Registration IDs:
<registerTokenRequest id="Id" reportGroup="UI Report Group">
<orderId>Order Id</orderId>
<paypageRegistrationId>PayPage Registration Id</paypageRegistrationId>
</registerTokenRequest>
For Credit Card Register Token request structures, see the Vantiv cnpAPI Reference Guide.
Example: Online Register Token Request - eProtect
<cnpOnlineRequest version="12.0" xmlns="http://www.vantivcnp.com/schema"
merchantId="100">
<authentication>
<user>userName</user>
<password>password</password>
</authentication>
<registerTokenRequest id="99999" reportGroup="RG1">
<orderId>F12345</orderId>
<paypageRegistrationId>cDZJcmd1VjNlYXNaSlRMTGpocVZQY1NNlYE4ZW5UTko4NU
NOTE:The use of the <cardValidationNum> element in the
<registertokenRequest> only applies when you submit an
<accountNumber> element.
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 83
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
9KK3p1L1p1VzE4ZWVPQVlSUHNITG1JN2I0NzlyTg=</paypageRegistrationId>
</registerTokenRequest>
</cnpOnlineRequest>
2.6.4.2 Register Token Response
There is no structural difference an Online and Batch response; however, some child elements
change depending upon whether the token is for a credit card account, or PayPage registration Id.
The response for the will have one of the following structures.
Register Token response for PayPage Registration Ids (and Credit Cards):
<registerTokenResponse id="99999" reportGroup="RG1">
<cnpTxnId>Transaction ID</cnpTxnId>
<cnpToken>Token</cnpToken>
<bin>BIN</bin>
<type>Method of Payment</type>
<response>Response Code</response>
<responseTime>Response Time</responseTime>
<message>Response Message</message>
</registerTokenResponse>
Example: Online Register Token Response - PayPage
<cnpOnlineResponse version="12.0" xmlns="http://www.vantivcnp.com/schema"
id="123" response="0" message="Valid Format" cnpSessionId="987654321">
<registerTokenResponse id="99999" reportGroup="RG1">
<cnpTxnId>21122700</cnpTxnId>
<cnpToken>1111000100360002</cnpToken>
<bin>400510</bin>
<type>VI</type>
<response>801</response>
<responseTime>2010-10-26T17:21:51</responseTime>
<message>Account number was successfully registered</message>
</registerTokenResponse>
</cnpOnlineResponse>
Integration and Testing Transaction Examples When Using cnpAPI
84 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.6.5 Force Capture Transactions
A Force Capture transaction is a Capture transaction used when you do not have a valid
Authorization for the order, but have fulfilled the order and wish to transfer funds. You can use a
<paypageRegistrationID> with a Force Capture transaction.
2.6.5.1 Force Capture Request
You must structure a Force Capture request as shown in the following examples when using
eProtect. The structure of the request is identical for either an Online or a Batch submission
<forceCapture id="Id" reportGroup="UI Report Group" customerId="Customer Id">
<orderId>Order Id</orderId>
<amount>Force Capture Amount</amount>
<orderSource>Order Entry Source</orderSource>
<billToAddress>
<paypage>
<paypageRegistrationId>Registation ID returned</paypageRegistrationId>
<expDate>Card Expiration Date</
expDate
>
<cardValidationNum>Card Validation Number</cardValidationNum>
</paypage>
</forceCapture>
Example: On-Line Force Capture Request
<cnpOnlineRequest version="12.0" xmlns="http://www.vantivcnp.com/schema"
merchantId="100">
<authentication>
<user>User Name</user>
<password>Password</password>
</authentication>
CAUTION:Merchants must be authorized by Vantiv before submitting transactions of
this type. In some instances, using a Force Capture transaction can lead
to chargebacks and fines.
NOTE:Although the schema defines the <expDate> element as an optional child
of <paypage> element, Vantiv does not store expiration dates. Therefore,
you must always submit an expiration date value with each eProtect
cnpAPI transaction.
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 85
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<forceCapture id="834262" reportGroup="ABC Division" customerId="038945">
<orderId>65347567</orderId>
<amount>40000</amount>
<orderSource>ecommerce</orderSource>
<billToAddress>
<name>John Smith</name>
<addressLine1>100 Main St</addressLine1>
<city>Boston</city>
<state>MA</state>
<zip>12345</zip>
<country>USA</country>
<email>jsmith@someaddress.com</email>
<phone>555-123-4567</phone>
</billToAddress>
<paypage>
<paypageRegistrationId>cDZJcmd1VjNlYXNaSlRMTGpocVZQY1NNlYE4ZW5UTko4NU
9KK3p1L1p1VzE4ZWVPQVlSUHNITG1JN2I0NzlyTg=</paypageRegistrationId>
<expDate>1012</expDate>
<cardValidationNum>712</cardValidationNum>
</paypage>
</forceCapture>
</cnpOnlineRequest>
2.6.5.2 Force Capture Response
The Force Capture response message is identical for Online and Batch transactions, except Online
includes the <postDate> element and may include a duplicate attribute. The Force Capture
response has the following structure:
<forceCaptureResponse id="Capture Id" reportGroup="UI Report Group"
customerId="Customer Id">
<cnpTxnId>Transaction Id</cnpTxnId>
<response>Response Code</response>
<responseTime>Date and Time in GMT</responseTime>
<postDate>Date of Posting</postDate>
(Online Only)
<message>Response Message</message>
<tokenResponse>
<accountUpdater>
</forceCaptureResponse>
Integration and Testing Transaction Examples When Using cnpAPI
86 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Example: Force Capture Response
<cnpOnlineResponse version="12.0" xmlns="http://www.vantivcnp.com/schema"
response="0" message="Valid Format">
<forceCaptureResponse id="2" reportGroup="ABC Division"
customerId="038945">
<cnpTxnId>1100030204</cnpTxnId>
<response>000</response>
<responseTime>2009-07-11T14:48:48</responseTime>
<postDate>2009-07-11</postDate>
<message>Approved</message>
<tokenResponse>
<cnpToken>1111000100090005</cnpToken>
<tokenResponseCode>801</tokenResponseCode>
<tokenMessage>Account number was successfully registered</tokenMessage>
<type>VI</type>
<bin>402410</bin>
</tokenResponse>
</forceCaptureResponse>
</cnpOnlineResponse>
2.6.6 Capture Given Auth Transactions
You can use a Capture Given Auth transaction with a <paypageRegistrationID> if the
<cnpTxnId> is unknown and the Authorization was processed using COMAAR data (Card
Number, Order Id, Merchant Id, Amount, Approval Code, and (Auth) Response Date).
2.6.6.1 Capture Given Auth Request
<captureGivenAuth id="Capture Given Auth Id" reportGroup="UI Report Group"
customerId="Customer Id">
<orderId>Order Id</orderId>
<authInformation>
<amount>Authorization Amount</amount>
<orderSource>Order Entry Source</orderSource>
NOTE:Although the schema defines the <expDate> element as an optional child
of <paypage> element, Vantiv does not store expiration dates. Therefore,
you must always submit an expiration date value with each eProtect
cnpAPI transaction.
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 87
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<billToAddress>
<shipToAddress>
<paypage>
<paypageRegistrationId>Registation ID returned</paypageRegistrationId>
<expDate>Card Expiration Date</
expDate
>
<cardValidationNum>Card Validation Number</cardValidationNum>
</paypage>
</captureGivenAuth>
Example: Online Capture Given Auth Request
<cnpOnlineRequest version="12.0" xmlns="http://www.vantivcnp.com/schema"
merchantId="100">
<authentication>
<user>User Name</user>
<password>Password</password>
</authentication>
<captureGivenAuth id="834262" reportGroup="ABC Division"
customerId="038945">
<orderId>65347567</orderId>
<authInformation>
<authDate>2017-06-22</authDate>
<authCode>111111</authCode>
</authInformation>
<amount>40000</amount>
<orderSource>ecommerce</orderSource>
<billToAddress>
<name>John Smith</name>
<addressLine1>100 Main St</addressLine1>
<city>Boston</city>
<state>MA</state>
<zip>12345</zip>
<country>USA</country>
<email>jsmith@someaddress.com</email>
<phone>555-123-4567</phone>
</billToAddress>
<paypage>
<paypageRegistrationId>cDZJcmd1VjNlYXNaSlRMTGpocVZQY1NNlYE4ZW5UTko4NU
9KK3p1L1p1VzE4ZWVPQVlSUHNITG1JN2I0NzlyTg=</paypageRegistrationId>
<expDate>1012</expDate>
<cardValidationNum>000</cardValidationNum>
</paypage>
</captureGivenAuth>
Integration and Testing Transaction Examples When Using cnpAPI
88 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
</cnpOnlineRequest>
2.6.6.2 Capture Given Auth Response
A Capture Given Auth response has the following structure. The response message is identical for
Online and Batch transactions except Online includes the <postDate> element and may include
a duplicate attribute.
<captureGivenAuthResponse id="Capture Id" reportGroup="UI Report Group"
customerId="Customer Id">
<cnpTxnId>Transaction Id</cnpTxnId>
<response>Response Code</response>
<responseTime>Date and Time in GMT</responseTime>
<postDate>Date of Posting</postDate>
(Online Only)
<message>Response Message</message>
<tokenResponse>
</captureGivenAuthResponse>
Example: Online Capture Given Auth Response
<cnpOnlineResponse version="12.0" xmlns="http://www.vantivcnp.com/schema"
response="0" message="Valid Format">
<captureGivenAuthResponse id="2" reportGroup="ABC Division"
customerId="038945">
<cnpTxnId>1100030204</cnpTxnId>
<response>000</response>
<responseTime>2011-07-11T14:48:48</responseTime>
<postDate>2011-07-11</postDate>
<message>Approved</message>
<tokenResponse>
<cnpToken>1111000100090005</cnpToken>
<tokenResponseCode>801</tokenResponseCode>
<tokenMessage>Account number was successfully registered</tokenMessage>
<type>VI</type>
<bin>402410</bin>
</tokenResponse>
</captureGivenAuthResponse>
</cnpOnlineResponse>
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 89
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.6.7 Credit Transactions
The Credit transaction enables you to refund money to a customer. You can submit refunds
against any of the following payment transactions using a <paypageRegistrationId>:
Capture Given Auth Transactions
Force Capture Transactions
Sale Transactions
2.6.7.1 Credit Request Transaction
You must specify a Credit request for transaction processed by our system as follows. The
structure of the request is identical for either an Online or a Batch submission.
<credit id="Credit Id" reportGroup="UI Report Group" customerId="Customer Id">
<orderId>Order Id</orderId>
<amount>Authorization Amount</amount>
<orderSource>Order Entry Source</orderSource>
<billToAddress>
<paypage>
<paypageRegistrationId>Registation ID returned</paypageRegistrationId>
<expDate>Card Expiration Date</
expDate
>
<cardValidationNum>Card Validation Number</cardValidationNum>
</paypage>
<customBilling>
<enhancedData>
</credit>
Example: Online Credit Request Transaction
<cnpOnlineRequest version="12.0" xmlns="http://www.vantivcnp.com/schema"
merchantId="100">
<authentication>
<user>User Name</user>
<password>Password</password>
NOTE:Although the schema defines the <expDate> element as an optional child
of <paypage> element, Vantiv does not store expiration dates. Therefore,
you must always submit an expiration date value with each eProtect
cnpAPI transaction.
Integration and Testing Transaction Examples When Using cnpAPI
90 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
</authentication>
<credit id="834262" reportGroup="ABC Division" customerId="038945">
<orderId>65347567</orderId>
<amount>40000</amount>
<orderSource>ecommerce</orderSource>
<billToAddress>
<name>John Smith</name>
<addressLine1>100 Main St</addressLine1>
<city>Boston</city>
<state>MA</state>
<zip>12345</zip>
<email>jsmith@someaddress.com</email>
<phone>555-123-4567</phone>
</billToAddress>
<paypage>
<paypageRegistrationId>cDZJcmd1VjNlYXNaSlRMTGpocVZQY1NNlYE4ZW5UTko4NU
9KK3p1L1p1VzE4ZWVPQVlSUHNITG1JN2I0NzlyTg=</paypageRegistrationId>
<expDate>1012</expDate>
<cardValidationNum>000</cardValidationNum>
</paypage>
</credit>
</cnpOnlineRequest>
2.6.7.2 Credit Response
The Credit response message is identical for Online and Batch transactions except Online
includes the postDate element and may include a duplicate attribute.
<creditResponse id="Credit Id" reportGroup="UI Report Group"
customerId="Customer Id">
<cnpTxnId>Transaction Id</cnpTxnId>
<response>Response Code</response>
<responseTime>Date and Time in GMT</responseTime>
<postDate>Date of Posting</postDate>
(Online Only)
<message>Response Message</message>
<tokenResponse>
</creditResponse>
Example: Online Credit Response
<cnpOnlineResponse version="12.0" xmlns="http://www.vantivcnp.com/schema"
response="0" message="Valid Format">
Transaction Examples When Using cnpAPI Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 91
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<creditResponse customerId="038945" id="5" reportGroup="ABC Division">
<cnpTxnId>1100030204</cnpTxnId>
<response>001</response>
<responseTime>2009-08-11T14:48:48</responseTime>
<postDate>2009-08-11</postDate>
<message>Transaction received</message>
<tokenResponse>
<cnpToken>1111000100090005</cnpToken>
<tokenResponseCode>801</tokenResponseCode>
<tokenMessage>Account number was successfully registered</tokenMessage>
<type>VI</type>
<bin>402410</bin>
</tokenResponse>
</creditResponse>
</cnpOnlineResponse>
Integration and Testing Testing and Certification
92 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.7 Testing and Certification
Vantiv requires successful certification testing for the eProtect transactions before you can use
them in production. During certification testing, you will work through each required test scenario
with your eProtect Implementation Consultant and Vantiv Conversion Manager.
The testing process for eProtect includes browser and/or mobile native application interaction,
JavaScript interaction, and transaction requests as well as cnpAPI responses with the Registration
ID.
See Certification and Testing Environment on page 12 for information, maintenance windows,
and limitations for the pre-live testing environment.
The eProtect Certification tests the following:
For browser-based checkout pages and mobile native applications:
Request and receive Registration ID from eProtect.
Submit Registration ID to Vantiv for authorization (or non-financial) request for OmniToken
and response.
For browser-based checkout pages only:
The timeout period
The error handler and JavaScript error codes
See the section, eProtect-Specific Response Codes on page 14 for definitions of the response
codes.
IMPORTANT:Because browsers differ in their handling of eProtect transactions,
Vantiv recommends testing eProtect on various devices (including
smart phones and tablets) and all browsers, including Internet
Explorer/Edge, Google Chrome, Apple Safari, and Mozilla Firefox.
Testing and Certification Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 93
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
2.7.1 Testing eProtect Transactions
To request and receive a Registration ID from eProtect:
1. Verify that your checkout page or mobile native application is coded correctly. See one of the
following sections for more information:
Integrating Customer Browser JavaScript API Into Your Checkout Page on page 24.
Integrating iFrame into your Checkout Page on page 38.
Integrating eProtect Into Your Mobile Application on page 46.
2. Verify that you are using the appropriate URL (see Table 1-2, "eProtect Certification, Testing,
and Production URLs" on page 13) for the testing and certification environment, for example:
https://request.eprotect.vantivprelive.com/eProtect/eProtect-api3.js
3. Submit transactions from your checkout page or mobile application using the Card Numbers
and Card Validation Numbers fromTable 2-11. When performing these tests, you can use
any expiration date and card type.
4. Verify that your results match the Result column in Table 2-11.
NOTE:These URLs should only be used in the testing and certification
environment. Do not use this URL in a production environment. Contact
your Implementation Consultant for the appropriate production URL.
TABLE 2-11 Expected eProtect Test Results
Test
Case Card Number
Card
Validation
Number
Response
Code Result
NOTE: Card Numbers are split into two parts; join Part 1 and Part 2 to obtain actual number to use.
1 Part 1: 51120100
Part 2: 00000003
Any 3-digit 870
(Success)
Registration ID is generated and the
card is scrubbed before the form is
submitted.
2 Part 1: 445701000
Part 2: 00000009
Any 3-digit 871 Checkout form displays error
message to card holder, for example,
“Invalid Card Number - Check and
retry (not Mod10).”
3 Part 1: 44570100000
Part 2: 0000000006
Any 3-digit 873 Checkout form displays error
message to card holder, for example,
“Invalid Card Number - Check and
retry (too long).”
Note: Do not use when testing
iFrame.
Integration and Testing Testing and Certification
94 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
4 Part 1: 601101
Part 2: 000003
Any 3-digit 872 Checkout form displays error
message to card holder, for example,
“Invalid Card Number - Check and
retry (too short).”
5 Part 1: 44570100
Part 2: B00000006
Any 3-digit 874 Checkout form displays error
message to card holder, for example,
“Invalid Card Number - Check and
retry (not a number).”
6 Part 1: 60110100
Part 2: 00000003
Any 3-digit 875 Checkout form displays error
message to card holder, for example,
“We are experiencing technical
difficulties. Please try again later or
call 555-555-1212.”
7 Part 1: 51234567
Part 2: 898010003
Any 3-digit 876 Checkout form displays error
message to card holder, for example,
“Invalid Card Number - Check and
retry (failure from server).”
8 Part 1: 3750010
Part 2: 00000005
Any 3-digit None
(Timeout
error)
Checkout form displays error
message to card holder, for example,
“We are experiencing technical
difficulties. Please try again later or
call 555-555-1212 (timeout).”
9 Part 1: 44570102
Part 2: 00000007
Any 3-digit 889 Checkout form displays error
message to card holder, for example,
“We are experiencing technical
difficulties. Please try again later or
call 555-555-1212.”
10 Part 1: 51120100
Part 2: 00000003
abc 881 Checkout form displays error
message to card holder, for example
“Invalid Card Validation Number -
Check and retry (not a number)”.
11 Part 1: 51120100
Part 2: 00000003
12 882 Checkout form displays error
message to card holder, for example
“Invalid Card Validation Number -
Check and retry (too short)”.
TABLE 2-11 Expected eProtect Test Results (Continued)
Test
Case Card Number
Card
Validation
Number
Response
Code Result
Testing and Certification Integration and Testing
Document Version: 2.7 — cnpAPI Release: 12.0 95
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
To test the submission of eProtect data using cnpAPI Authorization transactions:
1. Verify that your cnpAPI template is coded correctly for this transaction type (see
Authorization Transactions on page 76).
2. Submit three Authorization transactions using the eProtect data from Table 2-11.
3. Verify that your authorizationResponse values match the Response Code column.
To test the submission of the Registration ID to Vantiv for authorization, or a non-financial
request for an OmniToken and the response:
1. Verify that your applicable message specification template is coded correctly for this
transaction type.
2. Submit transactions using the eProtect Registration ID.
Verify that your response values match the expected results provided by your Vantiv Conversion
Manager.
12 Part 1: 51120100
Part 2: 00000003
12345 883 Checkout form displays error
message to card holder, for example
“Invalid Card Validation Number -
Check and retry (too long)”.
Note: Do not use when testing
iFrame.
TABLE 2-11 Expected eProtect Test Results (Continued)
Test
Case Card Number
Card
Validation
Number
Response
Code Result
Integration and Testing Testing and Certification
96 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
Document Version: 2.7 — cnpAPI Release: 12.0 97
© 2018 Worldpay, Inc. - All Rights Reserved.
A
CODE SAMPLES AND OTHER INFORMATION
This appendix provides code examples and reference material related to integrating the eProtect™
Solution. The following sections are included:
HTML Checkout Page Examples
Information Sent to Order Processing Systems
cnpAPI Elements for eProtect
NOTE:The PayPage product is now known as Vantiv eProtect. The term
‘PayPage’ however, is still used in this guide in certain text descriptions,
along with many data elements, JS code, and URLs. Use of these data
elements, etc., with the PayPage name is still valid with this release, but
will transition to ‘eProtect’ in a future release.
Code Samples and Other Information HTML Checkout Page Examples
98 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.1 HTML Checkout Page Examples
This section provides three HTML checkout page examples:
HTML Example for Non-eProtect Checkout Page
HTML Example for JavaScript API-Integrated Checkout Page
HTML Example for Hosted iFrame-Integrated Checkout Page
A.1.1 HTML Example for Non-eProtect Checkout Page
For comparison purposes, the following HTML sample is for a simple check-out page that is not
integrated with eProtect. The check-out form requests the cardholder's name, CVV code, credit
card account number, and expiration date.
<HTML>
<head>
<title>Non-PayPage Merchant Checkout</title>
</head>
<BODY>
<h2>Checkout Form</h2>
<form method=post id="fCheckout" name="fCheckout"
action="/merchant101/Merchant101CheckoutServlet">
<table>
<tr><td>First Name</td><td><input type="text" id="fName" name="fName" size="20">
</td></tr>
<tr><td>Last Name</td><td><input type="text" id="lName" name="lName" size="20">
</td></tr>
<tr><td>Credit Card</td><td><input type="text" id="ccNum" name="ccNum"
size="20"> </td></tr>
<tr><td>CVV/td><td><input type="text" id="cvv" name="cvv" size="5"> </td></tr>
<tr><td>Exp Date</td><td><input type="text" id="expDate" name="expDate"
size="5"></td></tr>
<tr><td>&nbsp;</td><td></tr>
<tr><td></td><td align="right"><input type="submit"
value="Check out" id="submitId"/></td></tr>
</table>
</form>
</BODY>
</HTML>
NOTE:This section does not apply to eProtect solutions in a mobile application.
HTML Checkout Page Examples Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 99
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.1.2 HTML Example for JavaScript API-Integrated Checkout
Page
The HTML code below is an example of a simple checkout page integrated with the JavaScript
Customer Browser eProtect solution.
<HTML>
<head>
<title>eProtect Merchant Simple Checkout</title>
<script src="https://ajax.googleapis.com/ajax/libs/jquery/1.4.2/jquery.min.js"
type="text/javascript"></script>
<script
src="https://request.eprotect.vantivprelive.com/eProtect/eProtect-api3.js"
type="text/javascript"></script>
<script>
$(document).ready(
function(){
function setEprotectResponseFields(response) {
document.getElementById('response$code').value = response.response;
document.getElementById('response$message').value = response.message;
document.getElementById('response$responseTime').value =
response.responseTime;
document.getElementById('response$vantivTxnId').value =
response.vantivTxnId;
document.getElementById('response$type').value = response.type;
document.getElementById('response$firstSix').value = response.firstSix;
document.getElementById('response$lastFour').value = response.lastFour;
}
function submitAfterEprotect (response) {
setEprotectResponseFields(response);
document.forms['fCheckout'].submit();
}
function timeoutOnEprotect () {
alert("We are experiencing technical difficulties. Please try again later or
call 555-555-1212 (timeout)");
}
function onErrortAfterEprotect (response) {
setEprotectResponseFields(response);
if(response.response == '871') {
alert("Invalid card number. Check and retry. (Not Mod10)");
}
else if(response.response == '872') {
alert("Invalid card number. Check and retry. (Too short)");
}
else if(response.response == '873') {
alert("Invalid card number. Check and retry. (Too long)");
}
else if(response.response == '874') {
alert("Invalid card number. Check and retry. (Not a number)");
}
NOTE:The URL in this example (in red) should only be used in the certification
and testing environment. Before using your checkout page with eProtect
in a production environment, replace the certification URL with the
production URL (contact your eProtect Implementation Consultant for the
appropriate production URL).
Do not use this URL in a
production environment.
Contact Implementation for the
appropriate production URL.
Code Samples and Other Information HTML Checkout Page Examples
100 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
else if(response.response == '875') {
alert("We are experiencing technical difficulties. Please try again later
or call 555-555-1212");
}
else if(response.response == '876') {
alert("Invalid card number. Check and retry. (Failure from Server)");
}
else if(response.response == '881') {
alert("Invalid
card validation
code. Check and retry. (Not a number)");
}
else if(response.response == '882') {
alert("Invalid
card validation
code. Check and retry. (Too short)");
}
else if(response.response == '883') {
alert("Invalid
card validation
code. Check and retry. (Too long)");
}
else if(response.response == '889') {
alert("We are experiencing technical difficulties. Please try again later or
call 555-555-1212");
}
return false;
}
var formFields = {
"accountNum" :document.getElementById('ccNum'),
"cvv2" :document.getElementById('cvv2Num'),
"paypageRegistrationId":document.getElementById('response$paypageRegistrationId'),
"bin" :document.getElementById('response$bin')
};
$("#submitId").click(
function(){
// clear test fields
setEprotectResponseFields({"response":"", "message":""});
var eProtectRequest = {
"paypageId" : document.getElementById("request$paypageId").value,
"reportGroup" : document.getElementById("request$reportGroup").value,
"orderId" : document.getElementById("request$orderId").value,
"id" : document.getElementById("request$merchantTxnId").value
"url" : "https://request.eprotect.vantivprelive.com"
};
new eProtect().sendToEprotect(eProtectRequest, formFields,
submitAfterEprotect, onErrortAfterEprotect, timeoutOnEprotect, 15000);
return false;
}
);
}
);
</script>
</head>
<BODY>
<h2>Checkout Form</h2>
<form method=post id="fCheckout" name="fCheckout"
action="/merchant101/Merchant101CheckoutServlet">
<input type="hidden" id="request$paypageId" name="request$paypageId"
value="a2y4o6m8k0"/>
<input type="hidden" id="request$merchantTxnId" name="request$merchantTxnId"
value="987012"/>
<input type="hidden" id="request$orderId" name="request$orderId" value="order_123"/>
<input type="hidden" id="request$reportGroup" name="request$reportGroup"
value="*merchant1500"/>
Do not use this URL
in a production
environment. Contact
Implementation for
the appropriate
production URL.
HTML Checkout Page Examples Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 101
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
<table>
<tr><td>First Name</td><td><input type="text" id="fName" name="fName"
size="20"></td></tr>
<tr><td>Last Name</td><td><input type="text" id="lName" name="lName"
size="20"></td></tr>
<tr><td>Credit Card</td><td><input type="text" id="ccNum" name="ccNum"
size="20"></td></tr>
<tr><td>CVV</td><td><input type="text" id="cvv2num" name="cvv2num"
size="5"></td></tr>
<tr><td>Exp Date</td><td><input type="text" id="expDate" name="expDate"
size="5"></td></tr>
<tr><td>&nbsp;</td><td></tr>
<tr><td></td><td align="right">
<script>
document.write('<button type="button" id="submitId" onclick="callEprotect()">Check
out with PayPage</button>');
</script>
<noscript>
<button type="button" id="submitId">Enable JavaScript or call us at
555-555-1212</button>
</noscript>
</td></tr>
</table>
<input type="hidden" id="response$paypageRegistrationId"
name="response$paypageRegistrationId" readOnly="true" value=""/>
<input type="hidden" id="response$bin" name="response$bin" readOnly="true"/>
<input type="hidden" id="response$code" name="response$code" readOnly="true"/>
<input type="hidden" id="response$message" name="response$message" readOnly="true"/>
<input type="hidden" id="response$responseTime" name="response$responseTime"
readOnly="true"/>
<input type="hidden" id="response$type" name="response$type" readOnly="true"/>
<input type="hidden" id="response$vantivTxnId" name="response$vantivTxnId"
readOnly="true"/>
<input type="hidden" id="response$firstSix" name="response$firstSix"
readOnly="true"/>
<input type="hidden" id="response$lastFour" name="response$lastFour"
readOnly="true"/>
</form>
</BODY>
<script>
/* This is an example of how to handle being unable to download the eProtect-api3 */
function callEprotect() {
if(typeof new eProtect() != 'object') {
alert("We are experiencing technical difficulties. Please try again later or call
555-555-1212 (API unavailable)" );
}
}
</script>
</HTML>
Code Samples and Other Information HTML Checkout Page Examples
102 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.1.3 HTML Example for Hosted iFrame-Integrated Checkout
Page
The HTML code below is an example of a simple checkout page integrated with the iFrame API
solution.
<HTML>
<head>
<title>Merchant1 checkout</title>
<style>
body {
font-size:10pt;
}
.checkout {
background-color:lightgreen;
width: 50%;
}
.testFieldTable {
background-color:lightgrey;
}
#submitId {
font-weight:bold;
font-size:12pt;
}
form#fCheckout {
}
</style>
<script src=https://ajax.googleapis.com/ajax/libs/jquery/1.4.2/jquery.min.js
type="text/javascript"></script>
<script src="https://request.eprotect.vantivprelive.com/eProtect/js/
eProtect-iframe-client3.min.js"></script>
</head>
<body>
<div class="checkout">
<h2>Checkout Form</h2>
<form method=post id="fCheckout" name="fCheckout" onsubmit="return false;">
<table>
<tr><td colspan="2">
<div id="eProtectiframe">
</div>
</td></tr>
<tr><td>Paypage Registration ID</td><td><input type="text"
id="paypageRegistrationId" name="paypageRegistrationId" readOnly="true"/>
<--Hidden</td></tr>
<tr><td>Bin</td><td><input type="text" id="bin" name="bin" readOnly="true"/>
<--Hidden</td></tr>
<tr><td></td><td align="right"><button type="submit" id="submitId">Check
out</button></td></tr>
NOTE:The URL in this example (in red) should only be used in the certification
and testing environment. Before using your checkout page with eProtect
in a production environment, replace the certification URL with the
production URL (contact your Implementation Consultant for the
appropriate production URL).
Do not use this URL in a
production environment.
Contact Implementation for
the appropriate production
URL.
HTML Checkout Page Examples Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 103
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
</table>
</form>
</div>
<br/>
<h3>Test Input Fields</h3>
<table class="testFieldTable">
<tr>
<td>Paypage ID</td><td><input type="text" id="request$paypageId"
name="request$paypageId" value="a2y4o6m8k0" disabled/></td>
<td>Merchant Txn ID</td><td><input type="text" id="request$merchantTxnId"
name="request$merchantTxnId" value="987012"/></td>
</tr>
<tr>
<td>Order ID</td><td><input type="text" id="request$orderId"
name="request$orderId" value="order_123"/></td>
<td>Report Group</td><td><input type="text" id="request$reportGroup"
name="request$reportGroup" value="*merchant1500" disabled/></td>
</tr>
<tr>
<td>JS Timeout</td><td><input type="text" id="request$timeout"
name="request$timeout" value="15000" disabled/></td>
</tr>
</table>
<h3>Test Output Fields</h3>
<table class="testFieldTable">
<tr>
<td>Response Code</td><td><input type="text" id="response$code"
name="response$code" readOnly="true"/></td>
<td>ResponseTime</td><td><input type="text" id="response$responseTime"
name="response$responseTime" readOnly="true"/></td>
</tr>
<tr>
<td>Response Message</td><td colspan="3"><input type="text"
id="response$message" name="response$message" readOnly="true" size="100"/></td>
</tr>
<tr><td>&nbsp;</td><td></tr>
<tr>
<td>Vantiv Txn ID</td><td><input type="text" id="response$vantivTxnId"
name="response$vantivTxnId" readOnly="true"/></td>
<td>Merchant Txn ID</td><td><input type="text" id="response$merchantTxnId"
name="response$merchantTxnId" readOnly="true"/></td>
</tr>
<tr>
<td>Order ID</td><td><input type="text" id="response$orderId"
name="response$orderId" readOnly="true"/></td>
<td>Report Group</td><td><input type="text" id="response$reportGroup"
name="response$reportGroup" readOnly="true"/></td>
</tr>
<tr><td>Type</td><td><input type="text" id="response$type" name="response$type"
readOnly="true"/></td></tr>
<tr>
<td>Expiration Month</td><td><input type="text" id="response$expMonth"
name="response$expMonth" readOnly="true"/></td>
<td>Expiration Year</td><td><input type="text" id="response$expYear"
name="response$expYear" readOnly="true"/></td>
</tr>
<tr><td>&nbsp;</td><td></tr>
<tr>
<td>First Six</td><td><input type="text"
id="response$firstSix"name="response$firstSix" readOnly="true"/></td>
<td>Last Four</td><td><input type="text"
id="response$lastFour"name="response$lastFour" readOnly="true"/></td>
Code Samples and Other Information HTML Checkout Page Examples
104 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
</tr>
<tr><td>Timeout Message</td><td><input type="text" id="timeoutMessage"
name="timeoutMessage" readOnly="true"/></td></tr>
<tr><td>Expected Results</td>
<td colspan="3">
<textarea id="expectedResults" name="expectedResults" rows="5" cols="100"
readOnly="true">
CC Num - Token Generated (with simulator)
410000&#48;00000001 - 1111222&#50;33330001
5123456&#55;89012007 - 1112333&#51;44442007
3783102&#48;3312332 - 11134444&#53;552332
601100&#48;990190005 - 1114555&#53;66660005
</textarea></td>
</tr>
<tr>
<td>Encrypted Card</td>
<td colspan="3"><textarea id="base64enc" name="base64enc" rows="5"
cols="100" readOnly="true"></textarea></td>
</tr>
</table>
<script>
$( document ).ready(function() {
var startTime;
var eProtectiframeClientCallback = function(response) {
if (response.timeout) {
var elapsedTime = new Date().getTime() - startTime;
document.getElementById('timeoutMessage').value = 'Timed out after ' +
elapsedTime + 'ms';// handle timeout
}
else {
document.getElementById('response$code').value = response.response;
document.getElementById('response$message').value = response.message;
document.getElementById('response$responseTime').value =
response.responseTime;
document.getElementById('response$reportGroup').value =
response.reportGroup;
document.getElementById('response$merchantTxnId').value = response.id;
document.getElementById('response$orderId').value = response.orderId;
document.getElementById('response$vantivTxnId').value =
response.vantivTxnId;
document.getElementById('response$type').value = response.type;
document.getElementById('response$lastFour').value = response.lastFour;
document.getElementById('response$firstSix').value = response.firstSix;
document.getElementById('paypageRegistrationId').value =
response.paypageRegistrationId;
document.getElementById('bin').value = response.bin;
document.getElementById('response$expMonth').value = response.expMonth;
document.getElementById('response$expYear').value = response.expYear;
}
};
var configure = {
"paypageId":document.getElementById("request$paypageId").value,
"style":"test",
"height":"200px",
"reportGroup":document.getElementById("request$reportGroup").value,
"timeout":document.getElementById("request$timeout").value,
"div": "eProtectiframe",
"callback": eProtectiframeClientCallback,
"showCvv": true,
"months": {
HTML Checkout Page Examples Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 105
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
"1":"January",
"2":"February",
"3":"March",
"4":"April",
"5":"May",
"6":"June",
"7":"July",
"8":"August",
"9":"September",
"10":"October",
"11":"November",
"12":"December"
},
"numYears": 8,
"tooltipText": "A CVV is the 3 digit code on the back of your Visa, MasterCard
and Discover or a 4 digit code on the front of your American Express",
"tabIndex": {
"cvv":1,
"accountNumber":2,
"expMonth":3,
"expYear":4
},
"placeholderText": {
"cvv":"CVV",
"accountNumber":"Account Number"
}
,
"inputsEmptyCallback": inputsEmptyCallback,
"enhancedUxFeatures" : {
"inlineFieldValidations": true,
}
};
if(typeof eProtectiframeClient === 'undefined') {
//This means we couldn't download the eprotect-iframe-client javascript library
alert("Couldn't download eprotect-iframe-client3.min javascript");
}
var eProtectiframeClient = new EprotectIframeClient(configure);
eProtectiframeClient.autoAdjustHeight();
document.getElementById("fCheckout").onsubmit = function(){
var message = {
"id":document.getElementById("request$merchantTxnId").value,
"orderId":document.getElementById("request$orderId").value
};
startTime = new Date().getTime();
eProtectiframeClient.getPaypageRegistrationId(message);
return false;
};
});
</script>
</body>
</HTML>
Code Samples and Other Information Information Sent to Order Processing Systems
106 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.2 Information Sent to Order Processing Systems
This section describes the information sent to your order processing system, with and without
integrating the eProtect solution.
A.2.1 Information Sent Without Integrating eProtect
If you have already integrated the Vault solution, an XML authorization is submitted with the
sensitive card data after your customer completes the checkout form, and a token is stored in its
place. The following is an example of the information sent to your order handling system:
cvv - 123
expDate - 1210
fName - Joe
ccNum - <account number here>
lName - Buyer
A.2.2 Information Sent with Browser-Based eProtect Integration
When you integrate the eProtect solution, your checkout page stops a transaction when a failure
or timeout occurs, thereby not exposing your order processing system to sensitive card data. The
success callback stores the response in the hidden form response fields, scrubs the card number,
and submits the form. The timeout callback stops the transaction, and the failure callback stops
the transaction for non-user errors. In timeout and failure scenarios, nothing is sent to your order
handling system.
The following is an example of the information sent to your order handling system on a
successful transaction:
cvv - 000
expDate - 1210
fName - Joe
ccNum - xxxxxxxxxxxx0001
lName - Buyer
request$paypageId - a2y4o6m8k0
request$merchantTxnId - 987012
request$orderId - order_123
request$reportGroup - *merchant1500
response$paypageRegistrationId - 1111222233330001
response$bin - 410000
response$code - 870
response$message - Success
response$responseTime - 2010-12-21T12:45:15Z
response$type - VI
response$vantivTxnId - 21200000051806
Information Sent to Order Processing Systems Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 107
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
response$firstSix - 410000
response$lastFour - 0001
A.2.3 Information Sent with Mobile API-Based Application
Integration
The following is an example of the information sent to your order handling system on a
successful transaction from an application on a mobile device.
cvv - 123
accountNum - <account number here>
paypageId - a2y4o6m8k0
id - 12345
orderId - order_123
reportGroup - *merchant1500
firstSix - 410000
lastFour - 0001
Code Samples and Other Information cnpAPI Elements for eProtect
108 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3 cnpAPI Elements for eProtect
This section provides definitions for the elements used in the cnpAPI for eProtect transactions.
Use this information in combination with the various cnpAPI schema files to assist you as you
build the code necessary to submit eProtect transactions to our transaction processing systems.
Each section defines a particular element, its relationship to other elements (parents and children),
as well as any attributes associated with the element.
For additional information on the structure of cnpAPI requests and responses using these
elements, as well as XML examples, see Transaction Examples When Using cnpAPI on page 75.
For a comprehensive list of all cnpAPI elements and usage, see Chapter 4, “cnpAPI Elements” in
the Vantiv cnpAPI Reference Guide.
The XML elements defined in this section are as follows (listed alphabetically):
cardValidationNum
checkoutId
expDate
paypage
paypageRegistrationId
registerTokenRequest
registerTokenResponse
token
cnpAPI Elements for eProtect Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 109
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.1 cardValidationNum
The <cardValidationNum> element is an optional child of the <card>, <paypage>,
<token>, <registerTokenRequest>, or <updateCardValidatinNumOnToken> element,
which you use to submit either the CVV2 (Visa), CVC2 (MasterCard), or CID (American Express
and Discover) value.
When you submit the CVV2/CVC2/CID in a registerTokenRequest, our platform encrypts
and stores the value on a temporary basis (24 hours) for later use in a tokenized Authorization or
Sale transaction submitted without the value. This is done to accommodate merchant
systems/workflows where the security code is available at the time of token registration, but not
at the time of the Auth/Sale. If for some reason you need to change the value of the security code
supplied at the time of the token registration, use an <updateCardValidationNumOnToken>
transaction. To use the stored value when submitting an Auth/Sale transaction, set the
<cardValidationNum> value to 000.
The cardValidationNum element is an optional child of the virtualGiftCardResponse
element, where it defines the value of the validation Number associated with the Virtual Gift Card
requested
Type = String; minLength = N/A; maxLength = 4
Parent Elements:
card, paypage, token, registerTokenRequest, updateCardValidationNumOnToken,
virtualGiftCardResponse
Attributes:
None
Child Elements:
None
NOTE:Some American Express cards may have a 4-digit CID on the front of the
card and/or a 3-digit CID on the back of the card. You can use either of the
numbers for card validation, but not both.
NOTE:The use of the <cardValidationNum> element in the
registertokenRequest only applies when you submit an
<accountNumber> element.
Code Samples and Other Information cnpAPI Elements for eProtect
110 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.2 checkoutId
The checkoutId element is an optional child of the token element specifying the low-value
token replacing the CVV value. You use this feature when you already have the consumers card
(i.e., token) on file, but wish the consumer to supply the CVV value for a new transaction. This
LVT remains valid for 24 hours from the time of issue.
Type = String; minLength = 18; maxLength = 18
Parent Elements:
token
Attributes:
None
Child Elements:
None
cnpAPI Elements for eProtect Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 111
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.3 expDate
The <expDate> element is a child of the <card>, <paypage>, <token>, or other element listed
below, which specifies the expiration date of the card and is required for card-not-present
transactions.
Type = String; minLength = 4; maxLength = 4
Parent Elements:
card, newCardInfo, newCardTokenInfo, originalCard, originalCardInfo, originalCardTokenInfo,
originalToken, paypage, token, updatedCard, updatedToken
Attributes:
None
Child Elements:
None
NOTE:Although the schema defines the <expDate> element as an optional child
of the <card>, <token> and <paypage> elements, you must submit a
value for card-not-present transactions.
NOTE:You should submit whatever expiration date you have on file, regardless
of whether or not it is expired/stale.
We recommend all merchant with recurring and/or installment payments
participate in the Automatic Account Updater program.
Code Samples and Other Information cnpAPI Elements for eProtect
112 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.4 paypage
The <paypage> element defines eProtect account information. It replaces the <card> or
<token> elements in transactions using the eProtect feature of the Vault solution.
Parent Elements:
authorization, sale, captureGivenAuth, forceCapture, credit, updateSubscription
Attributes:
None
Child Elements:
Required: paypageRegistrationId
Optional: cardValidationNum, expDate, type
Example: paypage Structure
<paypage>
<paypageRegistrationId>Registration ID from PayPage</paypageRegistrationId>
<expDate>Expiration Date</expDate>
<cardValidationNum>Card Validation Number</cardValidationNum>
<type>Method of Payment</type>
</paypage>
NOTE:Although the schema defines the <expDate> element as an optional child
of the <card>, <token> and <paypage> elements, you must submit a
value for card-not-present transactions.
cnpAPI Elements for eProtect Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 113
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.5 paypageRegistrationId
The <paypageRegistrationId> element is a required child of the <paypage> element. It
specifies the Registration ID generated by eProtect. It can also be used in a Register Token
Request to obtain a token based on eProtect activity prior to submitting an Authorization or Sale
transaction.
Type = String; minLength = N/A; maxLength = 512
Parent Elements:
paypage, registerTokenRequest
Attributes:
None
Child Elements:
None
Code Samples and Other Information cnpAPI Elements for eProtect
114 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.6 registerTokenRequest
The <registerTokenRequest> element is the parent element for the Register Token
transaction. You use this transaction type when you wish to submit an account number or
Registration Id for tokenization, but there is no associated payment transaction.
You can use this element in either Online or Batch transactions.
Parent Elements:
cnpOnlineRequest, batchRequest
Attributes:
Child Elements:
Required: either accountNumber, mpos, echeckForToken, paypageRegistrationId, or applepay
Optional: orderId, cardValidationNum
NOTE:When submitting <registerTokenRequest> elements in a
batchRequest, you must also include a numTokenRegistrations=
attribute in the <batchRequest> element.
Attribute Name Type Required? Description
id String No A unique identifier assigned by the presenter and mirrored
back in the response.
minLength = N/A maxLength = 25
customerId String No A value assigned by the merchant to identify the
consumer.
minLength = N/A maxLength = 50
reportGroup String Yes Required attribute defining the merchant sub-group in
eCommerce iQ where this transaction displays.
minLength = 1 maxLength = 25
NOTE:The use of the <cardValidationNum> element in the
<registertokenRequest> only applies when you submit an
<accountNumber> element.
cnpAPI Elements for eProtect Code Samples and Other Information
Document Version: 2.7 — cnpAPI Release: 12.0 115
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.7 registerTokenResponse
The <registerTokenResponse> element is the parent element for the response to
<registerTokenRequest> transactions. You receive this transaction type in response to the
submission of an account number or registration ID for tokenization in a Register Token
transaction.
Parent Elements:
cnpOnlineResponse, batchResponse
Attributes:
Child Elements:
Required: cnpTxnId, response, message, responseTime
Optional: eCheckAccountSuffix, cnpToken, bin, type, applepayResponse, androidpayResponse
Attribute Name Type Required? Description
id String No The response returns the same value submitted in the
registerTokenRequest transaction.
minLength = N/A maxLength = 25
customerId String No The response returns the same value submitted in the
registerTokenRequest transaction.
minLength = N/A maxLength = 50
reportGroup String Yes The response returns the same value submitted in the
registerTokenRequest transaction.
minLength = 1 maxLength = 25
Code Samples and Other Information cnpAPI Elements for eProtect
116 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
A.3.8 token
The token element replaces the card element in tokenized card transactions or the echeck
element in eCheck transactions, and defines the tokenized payment card/account information.
Parent Elements:
authorization, captureGivenAuth, credit, forceCapture, sale, accountUpdate, updateSubscription
Attributes:
None
Child Elements:
Required: cnpToken
Optional: expDate, cardValidationNum, type, checkoutId
Example: token Structure with CVV
<token>
<cnpToken>Token</cnpToken>
<expDate>Card Expiration Date</expDate>
<cardValidationNum>Card Validation Number</cardValidationNum>
<type>Method of Payment</type>
</token>
Example: token Structure with checkoutId instead of CVV
<token>
<cnpToken>Token</cnpToken>
<expDate>Card Expiration Date</expDate>
<type>Method of Payment</type>
<checkoutId>Low Value Token for CVV</checkoutId>
</token>
IMPORTANT:Although not a required element, Vantiv recommends you include the
expDate element. If you converted PAN information to tokens using the
registerTokenRequest transaction, we do not have the expDate value stored,
so cannot add it to the transaction. Transactions without expDate have a high
likelihood of decline.
Document Version: 2.7 — cnpAPI Release: 12.0 117
© 2018 Worldpay, Inc. - All Rights Reserved.
B
CSS PROPERTIES FOR IFRAME API
This appendix provides a list of Cascading Style Sheet (CSS) properties, for use when creating
your iFrame implementation of eProtect™, as listed in the CSS specification V1-3.
See the section Creating a Customized CSS for iFrame on page 16 before using the properties
listed here.
Except as marked (shaded items), the properties listed in the tables below are allowable when
styling your CSS for eProtect iFrame. Allowable values have been ‘white-listed’
programmatically. See Table B-24, "CSS Properties Excluded From the White List (not allowed)"
for more information.
NOTE:If you are evaluating your styling options and/or having trouble creating
your own style sheet, Vantiv can provide sample CSS files. Please contact
your assigned Implementation Consultant for sample CSS files.
CSS Properties for iFrame API CSS Property Groups
118 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
B.1 CSS Property Groups
For additional detail on each property type, click the desired link below to navigate to the
corresponding section:
Color Properties Table Properties Generated Content for
Paged Media
Background and Border
Properties
Lists and Counters
Properties
Filter Effects Properties
Basic Box Properties Animation Properties Image Values and
Replaced Content
Flexible Box Layout Transform Properties Masking Properties
Text Properties Transitions Properties Speech Properties
Text Decoration
Properties
Basic User Interface
Properties
Marquee Properties
Font Properties Multi-Column Layout
Properties
Appearance Properties
Writing Modes
Properties
Paged Media
TABLE B-1 Color Properties
Property Description
color Sets the color of text
opacity Sets the opacity level for an element
TABLE B-2 Background and Border Properties
Property Description
background
(Do not use)
Sets all the background properties in one declaration
background-attachment
(Do not use)
Sets whether a background image is fixed or scrolls with the rest
of the page
background-color Sets the background color for an element
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 119
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
background-image Sets the background image for an element
background-position
(Do not use)
Sets the starting position of a background image
background-repeat
(Do not use)
Sets how a background image will be repeated
background-clip Specifies the painting area of the background
background-origin
(Do not use)
Specifies the positioning area of the background images
background-size
(Do not use)
Specifies the size of the background images
border Sets all the border properties in one declaration
border-bottom Sets all the bottom border properties in one declaration
border-bottom-color Sets the color of the bottom border
border-bottom-left-radius Defines the shape of the border of the bottom-left corner
border-bottom-right-radius Defines the shape of the border of the bottom-right corner
border-bottom-style Sets the style of the bottom border
border-bottom-width Sets the width of the bottom border
border-color Sets the color of the four borders
border-image
(Do not use)
A shorthand property for setting all the border-image-*
properties
border-image-outset
(Do not use)
Specifies the amount by which the border image area extends
beyond the border box
border-image-repeat
(Do not use)
Specifies whether the image-border should be repeated,
rounded or stretched
border-image-slice Specifies the inward offsets of the image-border
border-image-source
(Do not use)
Specifies an image to be used as a border
border-image-width
(Do not use)
Specifies the widths of the image-border
border-left Sets all the left border properties in one declaration
TABLE B-2 Background and Border Properties (Continued)
Property Description
CSS Properties for iFrame API CSS Property Groups
120 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
border-left-color Sets the color of the left border
border-left-style Sets the style of the left border
border-left-width Sets the width of the left border
border-radius A shorthand property for setting all the four border-*-radius
properties
border-right Sets all the right border properties in one declaration
border-right-color Sets the color of the right border
border-right-style Sets the style of the right border
border-right-width Sets the width of the right border
border-style Sets the style of the four borders
border-top Sets all the top border properties in one declaration
border-top-color Sets the color of the top border
border-top-left-radius Defines the shape of the border of the top-left corner
border-top-right-radius Defines the shape of the border of the top-right corner
border-top-style Sets the style of the top border
border-top-width Sets the width of the top border
border-width Sets the width of the four borders
box-decoration-break Sets the behavior of the background and border of an element
at page-break, or, for in-line elements, at line-break.
box-shadow Attaches one or more drop-shadows to the box
TABLE B-3 Basic Box Properties
Property Description
bottom Specifies the bottom position of a positioned element
clear Specifies which sides of an element where other floating
elements are not allowed
clip Clips an absolutely positioned element
display Specifies how a certain HTML element should be displayed
float Specifies whether or not a box should float
height Sets the height of an element
TABLE B-2 Background and Border Properties (Continued)
Property Description
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 121
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
left Specifies the left position of a positioned element
overflow Specifies what happens if content overflows an element's box
overflow-x Specifies whether or not to clip the left/right edges of the
content, if it overflows the element's content area
overflow-y Specifies whether or not to clip the top/bottom edges of the
content, if it overflows the element's content area
padding Sets all the padding properties in one declaration
padding-bottom Sets the bottom padding of an element
padding-left Sets the left padding of an element
padding-right Sets the right padding of an element
padding-top Sets the top padding of an element
position Specifies the type of positioning method used for an element
(static, relative, absolute or fixed)
right Specifies the right position of a positioned element
top Specifies the top position of a positioned element
visibility Specifies whether or not an element is visible
width Sets the width of an element
vertical-align Sets the vertical alignment of an element
z-index Sets the stack order of a positioned element
TABLE B-4 Flexible Box Layout
Property Description
align-content Specifies the alignment between the lines inside a flexible
container when the items do not use all available space.
align-items Specifies the alignment for items inside a flexible container.
align-self Specifies the alignment for selected items inside a flexible
container.
display Specifies how a certain HTML element should be displayed
flex Specifies the length of the item, relative to the rest
flex-basis Specifies the initial length of a flexible item
flex-direction Specifies the direction of the flexible items
TABLE B-3 Basic Box Properties (Continued)
Property Description
CSS Properties for iFrame API CSS Property Groups
122 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
flex-flow A shorthand property for the flex-direction and the flex-wrap
properties
flex-grow Specifies how much the item will grow relative to the rest
flex-shrink Specifies how the item will shrink relative to the rest
flex-wrap Specifies whether the flexible items should wrap or not
justify-content Specifies the alignment between the items inside a flexible
container when the items do not use all available space.
margin Sets all the margin properties in one declaration
margin-bottom Sets the bottom margin of an element
margin-left Sets the left margin of an element
margin-right Sets the right margin of an element
margin-top Sets the top margin of an element
max-height Sets the maximum height of an element
max-width Sets the maximum width of an element
min-height Sets the minimum height of an element
min-width Sets the minimum width of an element
order Sets the order of the flexible item, relative to the rest
TABLE B-5 Text Properties
Property Description
hanging-punctuation Specifies whether a punctuation character may be placed
outside the line box
hyphens Sets how to split words to improve the layout of paragraphs
letter-spacing Increases or decreases the space between characters in a
text
line-break Specifies how/if to break lines
line-height Sets the line height
overflow-wrap Specifies whether or not the browser may break lines within
words in order to prevent overflow (when a string is too long
to fit its containing box)
TABLE B-4 Flexible Box Layout (Continued)
Property Description
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 123
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
tab-size Specifies the length of the tab-character
text-align Specifies the horizontal alignment of text
text-align-last Describes how the last line of a block or a line right before a
forced line break is aligned when text-align is “justify”
text-combine-upright Specifies the combination of multiple characters into the
space of a single character
text-indent Specifies the indentation of the first line in a text-block
text-justify Specifies the justification method used when text-align is
“justify”
text-transform Controls the capitalization of text
white-space Specifies how white-space inside an element is handled
word-break Specifies line breaking rules for non-CJK scripts
word-spacing Increases or decreases the space between words in a text
word-wrap Allows long, unbreakable words to be broken and wrap to the
next line
TABLE B-6 Text Decoration Properties
Property Description
text-decoration Specifies the decoration added to text
text-decoration-color Specifies the color of the text-decoration
text-decoration-line Specifies the type of line in a text-decoration
text-decoration-style Specifies the style of the line in a text decoration
text-shadow Adds shadow to text
text-underline-position Specifies the position of the underline which is set using the
text-decoration property
TABLE B-7 Font Properties
Property Description
@font-face
(Do not use)
A rule that allows websites to download and use fonts other
than the “web-safe” fonts
TABLE B-5 Text Properties (Continued)
Property Description
CSS Properties for iFrame API CSS Property Groups
124 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
@font-feature-values Allows authors to use a common name in
font-variant-alternate for feature activated differently in
OpenType
font Sets all the font properties in one declaration
font-family Specifies the font family for text
font-feature-settings Allows control over advanced typographic features in
OpenType fonts
font-kerning Controls the usage of the kerning information (how letters are
spaced)
font-language-override Controls the usage of language-specific glyphs in a typeface
font-size Specifies the font size of text
font-size-adjust Preserves the readability of text when font fallback occurs
font-stretch Selects a normal, condensed, or expanded face from a font
family
font-style Specifies the font style for text
font-synthesis Controls which missing typefaces (bold or italic) may be
synthesized by the browser
font-variant Specifies whether or not a text should be displayed in a
small-caps font
font-variant-alternates Controls the usage of alternate glyphs associated to
alternative names defined in @font-feature-values
font-variant-caps Controls the usage of alternate glyphs for capital letters
font-variant-east-asian Controls the usage of alternate glyphs for East Asian scripts
(e.g Japanese and Chinese)
font-variant-ligatures Controls which ligatures and contextual forms are used in
textual content of the elements it applies to
font-variant-numeric Controls the usage of alternate glyphs for numbers, fractions,
and ordinal markers
font-variant-position Controls the usage of alternate glyphs of smaller size
positioned as superscript or subscript regarding the baseline
of the font
font-weight Specifies the weight of a font
TABLE B-7 Font Properties (Continued)
Property Description
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 125
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
TABLE B-8 Writing Modes Properties
Property Description
direction Specifies the text direction/writing direction
text-orientation Defines the orientation of the text in a line
text-combine-upright Specifies the combination of multiple characters into the
space of a single character
unicode-bidi Used together with the direction property to set or return
whether the text should be overridden to support multiple
languages in the same document
writing-mode
TABLE B-9 Table Properties
Property Description
border-collapse Specifies whether or not table borders should be collapsed
border-spacing Specifies the distance between the borders of adjacent cells
caption-side Specifies the placement of a table caption
empty-cells Specifies whether or not to display borders and background
on empty cells in a table
table-layout Sets the layout algorithm to be used for a table
TABLE B-10 Lists and Counters Properties
Property Description
counter-increment Increments one or more counters
counter-reset Creates or resets one or more counters
list-style Sets all the properties for a list in one declaration
list-style-image
(Do not use)
Specifies an image as the list-item marker
list-style-position Specifies if the list-item markers should appear inside or
outside the content flow
list-style-type Specifies the type of list-item marker
CSS Properties for iFrame API CSS Property Groups
126 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
TABLE B-11 Animation Properties
Property Description
@keyframes Specifies the animation
animation A shorthand property for all the animation properties below,
except the animation-play-state property
animation-delay Specifies when the animation will start
animation-direction Specifies whether or not the animation should play in reverse
on alternate cycles
animation-duration Specifies how many seconds or milliseconds an animation
takes to complete one cycle
animation-fill-mode Specifies what values are applied by the animation outside
the time it is executing
animation-iteration-count Specifies the number of times an animation should be played
animation-name Specifies a name for the @keyframes animation
animation-timing-function Specifies the speed curve of the animation
animation-play-state Specifies whether the animation is running or paused
TABLE B-12 Transform Properties
Property Description
backface-visibility Defines whether or not an element should be visible when not
facing the screen
perspective Specifies the perspective on how 3D elements are viewed
perspective-origin Specifies the bottom position of 3D elements
transform Applies a 2D or 3D transformation to an element
transform-origin Allows you to change the position on transformed elements
transform-style Specifies how nested elements are rendered in 3D space
TABLE B-13 Transitions Properties
Property Description
transition A shorthand property for setting the four transition properties
transition-property Specifies the name of the CSS property the transition effect is
for
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 127
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
transition-duration Specifies how many seconds or milliseconds a transition
effect takes to complete
transition-timing-function Specifies the speed curve of the transition effect
transition-delay Specifies when the transition effect will start
TABLE B-14 Basic User Interface Properties
Property Description
box-sizing Tells the browser what the sizing properties (width and height)
should include
content Used with the :before and :after pseudo-elements, to insert
generated content
cursor
(Do not use)
Specifies the type of cursor to be displayed
icon
(Do not use)
Provides the author the ability to style an element with an
iconic equivalent
ime-mode Controls the state of the input method editor for text fields
nav-down Specifies where to navigate when using the arrow-down
navigation key
nav-index Specifies the tabbing order for an element
nav-left Specifies where to navigate when using the arrow-left
navigation key
nav-right Specifies where to navigate when using the arrow-right
navigation key
nav-up Specifies where to navigate when using the arrow-up
navigation key
outline Sets all the outline properties in one declaration
outline-color Sets the color of an outline
outline-offset Offsets an outline, and draws it beyond the border edge
outline-style Sets the style of an outline
outline-width Sets the width of an outline
resize Specifies whether or not an element is resizable by the user
TABLE B-13 Transitions Properties
Property Description
CSS Properties for iFrame API CSS Property Groups
128 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
text-overflow Specifies what should happen when text overflows the
containing element
TABLE B-15 Multi-Column Layout Properties
Property Description
break-after Specifies the page-, column-, or region-break behavior after
the generated box
break-before Specifies the page-, column-, or region-break behavior before
the generated box
break-inside Specifies the page-, column-, or region-break behavior inside
the generated box
column-count Specifies the number of columns an element should be
divided into
column-fill Specifies how to fill columns
column-gap Specifies the gap between the columns
column-rule A shorthand property for setting all the column-rule-*
properties
column-rule-color Specifies the color of the rule between columns
column-rule-style Specifies the style of the rule between columns
column-rule-width Specifies the width of the rule between columns
column-span Specifies how many columns an element should span across
column-width Specifies the width of the columns
columns A shorthand property for setting column-width and
column-count
widows Sets the minimum number of lines that must be left at the top
of a page when a page break occurs inside an element
TABLE B-16 Paged Media
Property Description
orphans Sets the minimum number of lines that must be left at the
bottom of a page when a page break occurs inside an
element
TABLE B-14 Basic User Interface Properties (Continued)
Property Description
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 129
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
page-break-after Sets the page-breaking behavior after an element
page-break-before Sets the page-breaking behavior before an element
page-break-inside Sets the page-breaking behavior inside an element
TABLE B-17 Generated Content for Paged Media
Property Description
marks Adds crop and/or cross marks to the document
quotes Sets the type of quotation marks for embedded quotations
TABLE B-18 Filter Effects Properties
Property Description
filter Defines effects (e.g. blurring or color shifting) on an element
before the element is displayed
TABLE B-19 Image Values and Replaced Content
Property Description
image-orientation Specifies a rotation in the right or clockwise direction that a
user agent applies to an image (This property is likely going to
be deprecated and its functionality moved to HTML)
image-rendering Gives a hint to the browser about what aspects of an image
are most important to preserve when the image is scaled
image-resolution Specifies the intrinsic resolution of all raster images used
in/on the element
object-fit Specifies how the contents of a replaced element should be
fitted to the box established by its used height and width
object-position Specifies the alignment of the replaced element inside its box
TABLE B-16 Paged Media
Property Description
CSS Properties for iFrame API CSS Property Groups
130 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
TABLE B-20 Masking Properties
Property Description
mask
mask-type
TABLE B-21 Speech Properties
Property Description
mark A shorthand property for setting the mark-before and
mark-after properties
mark-after Allows named markers to be attached to the audio stream
mark-before Allows named markers to be attached to the audio stream
phonemes Specifies a phonetic pronunciation for the text contained by
the corresponding element
rest A shorthand property for setting the rest-before and rest-after
properties
rest-after Specifies a rest or prosodic boundary to be observed after
speaking an element's content
rest-before Specifies a rest or prosodic boundary to be observed before
speaking an element's content
voice-balance Specifies the balance between left and right channels
voice-duration Specifies how long it should take to render the selected
element's content
voice-pitch Specifies the average pitch (a frequency) of the speaking
voice
voice-pitch-range Specifies variation in average pitch
voice-rate Controls the speaking rate
voice-stress Indicates the strength of emphasis to be applied
voice-volume Refers to the amplitude of the waveform output by the speech
synthesises
CSS Property Groups CSS Properties for iFrame API
Document Version: 2.7 — cnpAPI Release: 12.0 131
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
TABLE B-22 Marquee Properties
Property Description
marquee-direction Sets the direction of the moving content
marquee-play-count Sets how many times the content move
marquee-speed Sets how fast the content scrolls
marquee-style Sets the style of the moving content
TABLE B-23 Appearance Properties
Property Description
webkit-appearance Used by WebKit-based (e.g., Safari) and Blink-based (e.g.,
Chrome, Opera) browsers to display an element using
platform-native styling based on the operating system's
theme.
moz-appearance Used in Firefox to display an element using platform-native
styling based on the operating system's theme.
appearance Allows you to make an element look like a standard user
interface element.
CSS Properties for iFrame API Properties Excluded From White List
132 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
B.2 Properties Excluded From White List
Table B-24 lists the CSS Properties that are not permitted for use when building a CSS for
eProtect iFrame.
TABLE B-24 CSS Properties Excluded From the White List (not allowed)
Property Name Why excluded from white list?
background The other properties of background like color or size can still
be set with the more specific properties
background-attachment Only makes sense in the context of background-image
background-image Allows URL
background-origin Only makes sense in the context of background-position
background-position Only makes sense in the context of background-image
background-repeat Only makes sense in the context of background-image
background-size Only makes sense in the context of background-image
border-image This also includes the extensions like -webkit-border-image
and -o-border-image
border-image-outset Only makes sense in the context of border-image
border-image-repeat Only makes sense in the context of border-image
border-image-source Allows URL
border-image-width Only makes sense in the context of border-image
@font-face Allows URL
list-style-image Allows URL
cursor Allows URL
icon Allows URL
Document Version: 2.7 — cnpAPI Release: 12.0 133
© 2018 Worldpay, Inc. - All Rights Reserved.
C
SAMPLE EPROTECT INTEGRATION CHECKLIST
This appendix provides a sample of the eProtect™ Integration Checklist for use during your
Implementation process. It is intended to provide information to Vantiv on your eProtect setup.
Sample eProtect Integration Checklist
134 Document Version: 2.7 — cnpAPI Release: 12.0
© 2018 Worldpay, Inc. - All Rights Reserved.
eProtect™ Integration Guide - Enterprise
FIGURE C-1 Sample eProtect Integration Checklist
eProtect Integration Checklist
This document is intended to provide information to Vantiv on your eProtect setup. Please complete and send a
copy to your Implementation Consultant prior to going live. This will be kept on file and used in the event of
issues with eProtect production processing.
Merchant/Organization __________________________Contact Name_______________________________
Phone__________________________________Date Completed____________________________________
1. What timeout value do you plan to use in the event of an eProtect transaction timeout?
If the response from the primary server takes more than five (5) seconds, the request is automatically sent to
our secondary server. To ensure the secondary server has time to respond, we recommend a
timeout value of
15000 (15 seconds).
____ 15000 (15 seconds) – recommended, where the timeout callback stops the transaction.
____ Other: ______________________
2. Which unique identifier(s) do you plan to send with each eProtect Request? (Check all that apply.)
The values for either the <merchantTxnId> or the <orderId> must be unique so that we can use these
identifiers for reconciliation or troubleshooting. You can code your systems to send either or both.
____ orderID
____ merchantTxnId
3. What diagnostic information do you plan to collect in the event of a failed eProtect transaction
? (Check all
that apply.)
In order to assist us in determining the cause of failed eProtect transactions, we request that you collect
some or all of the following diagnostic information when you encounter a failure. You will be asked to
provide it to your Implementation Analyst (if you are currently in testing and certification) or Customer
Support (if you are currently in production).
____ Error code returned and reason for the failure. For example, JavaScript was dis
abled on the customer’s
browser, or could not loaded, or did not return a response, etc.
____ The orderId for the transaction.
____ The merchantTxnId for the transaction.
____ Where in the process the failure occurred.
____ Information about the customer’s browser, including the version.
Document Version: 2.7 — cnpAPI Release: 12.0 135
© 2018 Worldpay, Inc. - All Rights Reserved.
Index
A
Android Pay, 9, 56
Apple Pay
data/transaction flow, 50, 54
using mobile API, 48
Apple Pay Web, 8
compatible devices, 9
data/transaction flow, customer Browser
JavaScript API, 34
Authorizations
request structure, 76
response structure, 77
Availability of the PayPage API
detecting, 32
C
Callbacks
failure, 31
handling, 30
success, 30
timeout, 32
Capture Given Auth Transactions, 86
request structure, 86
response structure, 88
Checkout Form Submission
intercepting, 29
cnpAPI Elements
checkoutId, 110
expDate, 111
paypage, 109
paypageRegistrationId, 113
registerTokenRequest, 114
registerTokenResponse, 115
token, 116
Collecting Diagnostic Information, 62
Contact Information, xii
Credit Transactions, 89
request structure, 89
