UNIVERSAL ETHERNET EXTENDER

Universal Ethernet network

range extender

An easy way to double your network cable range without having to install

power cables to an intermediate switch

Instantly doubles cable range to 200 metres

No local power required

Full unrestricted network bandwidth

Universal 10/100 compatibility

POE powered device

IMAGINATION INNOVATION INTEGRATION DATASHEET

Diagram 1. OUTREACH Lite is powered by POE, so it can double Ethernet range

without requiring a local power outlet.

Ethernet is the ubiquitous technology for

Local Area Network (LAN) installation,

and the majority of networks in place

use the 100BASE-T network standards.

However, many security installations

demand network connections that exceed

the maximum 100 metres (328 feet)

distance limit for wired Ethernet.

OUTREACH Lite provides an instant

solution to this restriction. Simply

connect an OUTREACH Lite in line with

the network cable - adding a Power

over Ethernet (POE) injector if required

- to double the available range to 200

metres (656 feet).

Simple installation

OUTREACH Lite takes advantage of

the universal 802.3af POE standard,

so it can draw its own power from the

network connection.  No local power is

required, so OUTREACH Lite can be

located exactly where it is needed.

OUTREACH Lite overcomes the

distance limits of Ethernet, instantly

Simply connect an OUTREACH Lite in line with the network cable and instantly

double its range to 200 metres (656 ft). No set-up or network configuration

is required.

IMAGINATION INNOVATION INTEGRATION

If your network switch has POE, simply

connect OUTREACH Lite up to 100

metres from the switch, and it will

deliver another 100 metres’ reach

over regular Cat 5e or similar cable

(Diagram 1). If POE is not available, the

link can easily be upgraded using a low-

cost POE injector such as Veracity’s

OUTSOURCE (Diagram 2).

No set-up or network configuration is

required, as OUTREACH Lite automatically

sets up network speed, duplex and

crossover on connection, and does not

require an IP or MAC address.

Go further

If POE and network extension beyond

200 metres (656 feet) is required,

Veracity’s OUTREACH Max may be

installed to extend Ethernet and POE to

OUTREACH Lite.

For example, a 400 metre (1312 feet)

connection between a POE switch and

another network device can be achieved

by fitting two OUTREACH Maxes at 100

metre intervals along the cable, followed

by an OUTREACH Lite. 

Unrestricted network connections up to

2.2 kilometres (1.4 miles) are possible,

depending on configuration and POE

source.  See the OUTREACH MAX XT

datasheet, or read Veracity’s “Long

Range Ethernet Extension” white paper.

No restrictions

Because OUTREACH Max and

OUTREACH Lite simply restore the

network connection every 100 metres,

the full (200Mbit/s) bandwidth of

100BASE-T Ethernet is maintained

across the entire link.  This maximises

performance and transparency, with

no risk of a reduced or unpredictable

bandwidth, even at distances of several

hundred metres or more.

NETWORK OUTLET

POE NETWORK

SWITCH

POWER

NETWORK DATA

100M

ETHERNET WITH POE ETHERNET DATA ONLY

VOR-ORL

POE

100M

www.veracityglobal.com

If only Ethernet

extension is required,

use OUTREACH Lite

OUTREACH Lite extends Ethernet only

and does not forward POE.

Diagram 3. OUTREACH Max extends POE as well, so it can be used in combination

with OUTREACH Lite for even greater extension range.

If POE forwarding is

also required, use

OUTREACH Max

OUTREACH Max supports all standards

of POE forwarding, but does not support

data-only extension.

For outdoor LAN extension, please see

OUTREACH Max XT and OUTREACH Lite

XT versions.

For network extension to devices which

are unknown or may change, please

consider OUTREACH Quad.

Diagram 2. If POE is not already available, it can easily be added using Veracity’s

OUTSOURCE injector.

NETWORK DATA

NETWORK

OUTLET

POWER

NETWORK

SWITCH

POWER

NETWORK DATA

ETHERNET WITH POE ETHERNET DATA ONLY

VOR-OS VOR-ORL 100M 100M

POE NETWORK

SWITCH

POWER

NETWORK DATA

100M100M 100M100M

ETHERNET WITH POE ETHERNET DATA ONLY

VOR-ORM VOR-ORM VOR-ORL

POE

Combine Veracity IP transmission

products for the solution you need

Which type of OUTREACH do I need ?

Choosing between OUTREACH Max and OUTREACH Lite

is straightforward:

TECHNICAL SPECIFICATION

EMEA Sales :

Veracity UK Ltd

Prestwick International Aerospace Park

4 Dow Road

Prestwick

KA9 2TU

UK

Tel +44 (0) 1292 264967

Fax +44 (0) 845 528 1081

www.veracityglobal.com

sales@veracityuk.com

Americas & Asia Sales :

Veracity USA Inc.

65 Harristown Road

Glen Rock

NJ 07452

USA

Tel: 1-800-679-1590

Fax: 1-800-679-0714

www.veracityglobal.com

sales@veracityusa.com

© Veracity UK Ltd 2013 WV2.0 UK

OUTREACH MAX and OUTREACH LITE are trademarks of Veracity UK Ltd

POWER

Power consumption 1.3 watts via POE

POE STANDARDS IEEE 802.3af POE

Class 2 powered device

No POE forwarding

ETHERNET INTERFACE Two independently auto-configuring 10/100 ports

(10BASE-T/100BASE-TX, half/full duplex)

Patch or crossover cables supported

LEDS

Status Indicators Power good, network link/activity (both ports)

PHYSICAL/ENVIRONMENTAL

Dimensions L 105mm W 40mm H 22mm

Weight 45g [1.6 oz]

Mounting Two 7mm diameter mounting holes. Centres 89mm apart

Operating temperature -10oC to 50oC [14oF to 122oF]

Relative humidity Up to 85%, non-condensing

Compliance CE, FCC, RoHS

PRODUCT CODES VOR-ORL OUTREACH LITE Ethernet extender

VOR-ORM OUTREACH MAX Ethernet and POE extender

VOR-ORM-XT OUTREACH MAX XT Outdoor Ethernet & POE extender

VOR-ORL-XT OUTREACH LITE XT Outdoor Ethernet extender

VOR-OS OUTSOURCE POE injector

VOR-OSP OUTSOURCE PLUS POE Plus injector
