Product Specifications
www.shure.com ©2015 Shure Incorporated
Beta® 52A Supercardioid Dynamic Kick Drum Microphone
Overview
Features
Specifications
Polar Pattern Frequency Response
Available Models
Accessories and Replacement Parts
Cartridge Type Dynamic (moving coil)
Frequency Response 20 to 10,000 Hz
Polar Pattern Supercardioid
Output Impedance 150 Ω
Sensitivity
(at 1kHz, open circuit voltage)
−64 dBV/Pa (0.6 mV)
1 Pascal=94 dB SPL
Maximum SPL
(1 kHz at 1% THD, 1kΩ load) 174 dB
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Weight Net: 0.605 kg (1.35 lbs)
Connector Three-pin professional audio (XLR), male
Case 134 dB (159 dB, -25 Pad)
• Premier live performance microphone with Shure quality, ruggedness, and reliability
• Modified supercardioid pick-up pattern for maximum gain before feedback and superior rejection of off-axis sound
• Tailored frequency response specifically shaped for kick drums and bass instruments
• Neodymium magnet for greater sensitivity and higher output
• Advanced pneumatic shock mount system that minimizes transmission of mechanical noise and vibration
• Dent-resistant, steel mesh grille and enamel coated die-cast metal construction resist wear and abuse
• Studio quality performance, even at high SPL
• Built-in stand adapter with dynamic locking system and XLR connector simplifies setup and provides greater flexibility
The Shure Beta 52A is a precision-engineered dynamic microphone with a tailored frequency response and integrated swivel-mount with XLR
connector designed specifically for kick drums and other bass instruments. It provides superb attack and “punch,” and delivers studio quality
sound even at extremely high sound pressure levels.
RK321 Replacement grille R175 Replacement cartridge
BETA 52A Supercardioid Swivel-mount Dynamic Kick Drum Microphone with high-output Neodymium Element
250 Hz
500 Hz
1000 Hz
2500 Hz
98765432 98765432
+20
+10
0
–10
–20
dB
20 50 100 1000 10000 20000
Hz
3 mm
(1/8 in.)
25 mm
(1 in.)
51 mm
(2 in.)
0.06 m
(2 ft)
Beta 52A
