View Security
Modified on 4 JAN 2018
VMware Horizon 7 7.4
View Security
VMware, Inc. 2
You can find the most up-to-date technical documentation on the VMware website at:
https://docs.vmware.com/
If you have comments about this documentation, submit your feedback to
docfeedback@vmware.com
Copyright © 2009–2018 VMware, Inc. All rights reserved. Copyright and trademark information.
VMware, Inc.
3401 Hillview Ave.
Palo Alto, CA 94304
www.vmware.com
Contents
View Security 4
1Horizon 7 Accounts, Resources, and Log Files 5
Horizon 7 Accounts 5
Horizon 7 Resources 6
Horizon 7 Log Files 6
2View Security Settings 8
Security-Related Global Settings in View Administrator 9
Security-Related Server Settings in View Administrator 11
Security-Related Settings in View LDAP 12
3Ports and Services 13
View TCP and UDP Ports 13
Services on a View Connection Server Host 18
Services on a Security Server 18
4Configuring Security Protocols and Cipher Suites on a View Connection Server
Instance or on a Security Server 20
Default Global Policies for Security Protocols and Cipher Suites 21
Configuring Global Acceptance and Proposal Policies 21
Configure Acceptance Policies on Individual Servers 23
Configure Proposal Policies on Remote Desktops 24
Older Protocols and Ciphers Disabled in View 25
5Configuring Security Protocols and Cipher Suites for Blast Secure Gateway 27
Configure Security Protocols and Cipher Suites for Blast Secure Gateway (BSG) 27
6Deploying USB Devices in a Secure Horizon 7 Environment 29
Disabling USB Redirection for All Types of Devices 29
Disabling USB Redirection for Specific Devices 30
7HTTP Protection Measures on Connection Servers and Security Servers 33
Internet Engineering Task Force Standards 33
World Wide Web Consortium Standards 34
Other Protection Measures 37
Configure HTTP Protection Measures 40
VMware, Inc. 3
View Security
View Security provides a concise reference to the security features of VMware Horizon 7.
nRequired system and database login accounts.
nConfiguration options and settings that have security implications.
nResources that must be protected, such as security-relevant configuration files and passwords, and
the recommended access controls for secure operation.
nLocation of log files and their purpose.
nExternal interfaces, ports, and services that must be open or enabled for the correct operation of
View.
Intended Audience
This information is intended for IT decision makers, architects, administrators, and others who must
familiarize themselves with the security components of View.
VMware, Inc. 4
Horizon 7 Accounts, Resources,
and Log Files 1
Having different accounts for specific components protects against giving individuals more access and
permissions than they need. Knowing the locations of configuration files and other files with sensitive data
aids in setting up security for various host systems.
Note Starting with Horizon 7.0, View Agent is renamed Horizon Agent.
This section includes the following topics:
nHorizon 7 Accounts
nHorizon 7 Resources
nHorizon 7 Log Files
Horizon 7 Accounts
You must set up system and database accounts to administer Horizon 7 components.
Table 1‑1. Horizon 7 System Accounts
Horizon Component Required Accounts
Horizon Client Configure user accounts in Active Directory for the users who have access to remote desktops and
applications. The user accounts must be members of the Remote Desktop Users group, but the
accounts do not require Horizon administrator privileges.
vCenter Server Configure a user account in Active Directory with permission to perform the operations in vCenter
Server that are necessary to support Horizon 7.
For information about the required privileges, see the View Installation document.
View Composer Create a user account in Active Directory to use with View Composer. View Composer requires this
account to join linked-clone desktops to your Active Directory domain.
The user account should not be a Horizon administrative account. Give the account the minimum
privileges that it requires to create and remove computer objects in a specified Active Directory
container. For example, the account does not require domain administrator privileges.
For information about the required privileges, see the View Installation document.
Connection Server When you install Horizon 7, you can specify a specific domain user, the local Administrators group, or a
specific domain user group as Horizon administrators. We recommend creating a dedicated domain
user group of Horizon administrators. The default is the currently logged in domain user.
In Horizon Administrator, you can use View Configuration > Administrators to change the list of
Horizon administrators.
See the View Administration document for information about the privileges that are required.
VMware, Inc. 5
Table 1‑2. Horizon Database Accounts
Horizon Component Required Accounts
View Composer
database
An SQL Server or Oracle database stores View Composer data. You create an administrative account
for the database that you can associate with the View Composer user account.
For information about setting up a View Composer database, see the View Installation document.
Event database used by
Horizon Connection
Server
An SQL Server or Oracle database stores Horizon event data. You create an administrative account for
the database that Horizon Administrator can use to access the event data.
For information about setting up a View Composer database, see the View Installation document.
To reduce the risk of security vulnerabilities, take the following actions:
nConfigure Horizon 7 databases on servers that are separate from other database servers that your
organization uses.
nDo not allow a single user account to access multiple databases.
nConfigure separate accounts for access to the View Composer and event databases.
Horizon 7 Resources
Horizon 7 includes several configuration files and similar resources that must be protected.
Table 1‑3. Horizon Connection Server and Security Server Resources
Resource Location Protection
LDAP settings Not applicable. LDAP data is protected automatically as
part of role-based access control.
LDAP backup files %ProgramData%\VMWare\VDM\backups Protected by access control.
locked.properties
(secure gateway
configuration file)
install_directory\VMware\VMware
View\Server\sslgateway\conf
Ensure that this file is secured against
access by any user other than Horizon
administrators.
absg.properties
(Blast Secure Gateway
configuration file)
install_directory\VMware\VMware
View\Server\appblastgateway
Ensure that this file is secured against
access by any user other than Horizon
administrators.
Log files See Horizon 7 Log Files Protected by access control.
web.xml
(Tomcat configuration
file)
install_directory\VMware View\Server\broker\web
apps\ROOT\Web INF
Protected by access control.
Horizon 7 Log Files
Horizon 7 creates log files that record the installation and operation of its components.
Note Horizon 7log files are intended for use by VMware Support. VMware recommends that you
configure and use the event database to monitor Horizon 7. For more information, see the View
Installation and View Integration documents.
View Security
VMware, Inc. 6
Table 1‑4. Horizon 7 Log Files
Horizon Component File Path and Other Information
All components (installation
logs)
%TEMP%\vminst.log_date_timestamp
%TEMP%\vmmsi.log_date_timestamp
Horizon Agent <Drive Letter>:\ProgramData\VMware\VDM\logs
To access Horizon 7 log files that are stored in <Drive
Letter>:\ProgramData\VMware\VDM\logs, you must open the logs from a program with elevated
administrator privileges. Right-click the program file and select Run as administrator.
If a User Data Disk (UDD) is configured, <Drive Letter> might correspond to the UDD.
The logs for PCoIP are named pcoip_agent*.log and pcoip_server*.log.
Published Applications View Event Database configured on an SQL Server or Oracle database server.
Windows Application Event logs. Disabled by default.
View Composer %system_drive%\Windows\Temp\vmware-viewcomposer-ga-new.log on the linked-clone
desktop.
The View Composer log contains information about the execution of QuickPrep and Sysprep scripts.
The log records the start time and end time of script execution, and any output or error messages.
Connection Server or
Security Server
<Drive Letter>:\ProgramData\VMware\VDM\logs.
The log directory is configurable in the log configuration settings of the View Common Configuration
ADMX template file (vdm_common.admx) .
PCoIP Secure Gateway logs are written to files named SecurityGateway_*.log in the PCoIP
Secure Gateway subdirectory.
Blast Secure Gateway logs are written to files named absg*.log in the Blast Secure Gateway
subdirectory.
Horizon Services Horizon Event Database configured on an SQL Server or Oracle database server.
Windows System Event logs.
View Security
VMware, Inc. 7
View Security Settings 2
View includes several settings that you can use to adjust the security of the configuration. You can access
the settings by using View Administrator or by using the ADSI Edit utility, as appropriate.
Note For information about security settings for Horizon Client and Horizon Agent, see the Horizon
Client and Agent Security document.
This section includes the following topics:
nSecurity-Related Global Settings in View Administrator
nSecurity-Related Server Settings in View Administrator
nSecurity-Related Settings in View LDAP
VMware, Inc. 8
Security-Related Global Settings in View Administrator
Security-related global settings for client sessions and connections are accessible under View
Configuration > Global Settings in View Administrator.
Table 2‑1. Security-Related Global Settings
Setting Description
Change data recovery
password
The password is required when you restore the View LDAP configuration from an encrypted
backup.
When you install View Connection Server version 5.1 or later, you provide a data recovery
password. After installation, you can change this password in View Administrator.
When you back up View Connection Server, the View LDAP configuration is exported as encrypted
LDIF data. To restore the encrypted backup with the vdmimport utility, you must provide the data
recovery password. The password must contain between 1 and 128 characters. Follow your
organization's best practices for generating secure passwords.
Message security mode Determines the security mechanism used when JMS messages are passed between View
components.
nIf set to Disabled, message security mode is disabled.
nIf set to Enabled, legacy message signing and verification of JMS messages takes place. View
components reject unsigned messages. This mode supports a mix of SSL and plain JMS
connections.
nIf set to Enhanced, SSL is used for all JMS connections, to encrypt all messages. Access
control is also enabled to restrict the JMS topics that View components can send messages to
and receive messages from.
nIf set to Mixed, message security mode is enabled, but not enforced for View components that
predate View Manager 3.0.
The default setting is Enhanced for new installations. If you upgrade from a previous version, the
setting used in the previous version is retained.
Important VMware strongly recommends setting the message security mode to Enhanced after
you upgrade all View Connection Server instances, security servers, and View desktops to this
release. The Enhanced setting provides many important security improvements and MQ (message
queue) updates.
Enhanced Security Status
(Read-only)
Read-only field that appears when Message security mode is changed from Enabled to
Enhanced. Because the change is made in phases, this field shows the progress through the
phases:
nWaiting for Message Bus restart is the first phase. This state is displayed until you manually
restart either all Connection Server instances in the pod or the VMware Horizon View Message
Bus Component service on all Connection Server hosts in the pod.
nPending Enhanced is the next state. After all View Message Bus Component services have
been restarted, the system begins changing the message security mode to Enhanced for all
desktops and security servers.
nEnhanced is the final state, indicating that all components are now using Enhanced message
security mode.
View Security
VMware, Inc. 9
Table 2‑1. Security-Related Global Settings (Continued)
Setting Description
Reauthenticate secure
tunnel connections after
network interruption
Determines if user credentials must be reauthenticated after a network interruption when
Horizon Clients use secure tunnel connections to View desktops and applications.
This setting offers increased security. For example, if a laptop is stolen and moved to a different
network, the user cannot automatically gain access to the View desktops and applications because
the network connection was temporarily interrupted.
This setting is disabled by default.
Forcibly disconnect users Disconnects all desktops and applications after the specified number of minutes has passed since
the user logged in to View. All desktops and applications will be disconnected at the same time
regardless of when the user opened them.
The default is 600 minutes.
For clients that support
applications.
If the user stops using the
keyboard and mouse,
disconnect their
applications and discard
SSO credentials
Protects application sessions when there is no keyboard or mouse activity on the client device. If
set to After ... minutes, View disconnects all applications and discards SSO credentials after the
specified number of minutes without user activity. Desktop sessions are disconnected. Users must
log in again to reconnect to the applications that were disconnected or launch a new desktop or
application.
If set to Never, View never disconnects applications or discards SSO credentials due to user
inactivity.
The default is Never.
Other clients.
Discard SSO credentials
Discards the SSO credentials after a certain time period. This setting is for clients that do not
support application remoting. If set to After ... minutes, users must log in again to connect to a
desktop after the specified number of minutes has passed since the user logged in to View,
regardless of any user activity on the client device.
The default is After 15 minutes.
Enable IPSec for Security
Server pairing
Determines whether to use Internet Protocol Security (IPSec) for connections between security
servers and View Connection Server instances. This setting must be disabled before installing a
security server in FIPS mode; otherwise pairing will fail.
By default, IPSec for security server connections is enabled.
View Administrator session
timeout
Determines how long an idle View Administrator session continues before the session times out.
Important Setting the View Administrator session timeout to a high number of minutes increases
the risk of unauthorized use of View Administrator. Use caution when you allow an idle session to
persist a long time.
By default, the View Administrator session timeout is 30 minutes. You can set a session timeout
from 1 to 4320 minutes.
For more information about these settings and their security implications, see the View Administration
document.
Note SSL is required for all Horizon Client connections and View Administrator connections to View. If
your View deployment uses load balancers or other client-facing, intermediate servers, you can off-load
SSL to them and then configure non-SSL connections on individual View Connection Server instances
and security servers. See "Off-load SSL Connections to Intermediate Servers" in the View Administration
document.
View Security
VMware, Inc. 10
Security-Related Server Settings in View Administrator
Security-related server settings are accessible under View Configuration > Servers in View
Administrator.
Table 2‑2. Security-Related Server Settings
Setting Description
Use PCoIP Secure Gateway
for PCoIP connections to
machine
Determines whether Horizon Client makes a further secure connection to the View Connection
Server or security server host when users connect to View desktops and applications with the
PCoIP display protocol.
If this setting is disabled, the desktop or application session is established directly between the
client and the View desktop or the Remote Desktop Services (RDS) host, bypassing the View
Connection Server or security server host.
This setting is disabled by default.
Use Secure Tunnel
connection to machine
Determines whether Horizon Client makes a further HTTPS connection to the View Connection
Server or security server host when users connect to a View desktop or an application.
If this setting is disabled, the desktop or application session is established directly between the
client and the View desktop or the Remote Desktop Services (RDS) host, bypassing the View
Connection Server or security server host.
This setting is enabled by default.
Use Blast Secure Gateway
for Blast connections to
machine
Determines whether clients that use a Web browser or the Blast Extreme display protocol to
access desktops use Blast Secure Gateway to establish a secure tunnel to View Connection
Server.
If not enabled, clients using a Blast Extreme session and Web browsers make direct connections
to View desktops, bypassing View Connection Server.
This setting is disabled by default.
For more information about these settings and their security implications, see the View Administration
document.
View Security
VMware, Inc. 11
Security-Related Settings in View LDAP
Security-related settings are provided in View LDAP under the object path
cn=common,ou=global,ou=properties,dc=vdi,dc=vmware,dc=int. You can use the ADSI Edit utility
to change the value of these settings on a View Connection Server instance. The change propagates
automatically to all other View Connection Server instances in a group.
Table 2‑3. Security-Related Settings in View LDAP
Name-value pair Description
cs-
allowunencryptedstartsession
The attribute is pae-NameValuePair.
This attribute controls whether a secure channel is required between a View Connection
Server instance and a desktop when a remote user session is being started.
When View Agent 5.1 or later, or Horizon Agent 7.0 or later, is installed on a desktop computer,
this attribute has no effect and a secure channel is always required. When a View Agent older
than View 5.1 is installed, a secure channel cannot be established if the desktop computer is
not a member of a domain with a two-way trust to the domain of the View Connection Server
instance. In this case, the attribute is important to determine whether a remote user session
can be started without a secure channel.
In all cases, user credentials and authorization tickets are protected by a static key. A secure
channel provides further assurance of confidentiality by using dynamic keys.
If set to 0, a remote user session will not start if a secure channel cannot be established. This
setting is suitable if all the desktops are in trusted domains or all desktops have View Agent 5.1
or later installed.
If set to 1, a remote user session can be started even if a secure channel cannot be
established. This setting is suitable if some desktops have older View Agents installed and are
not in trusted domains.
The default setting is 1.
View Security
VMware, Inc. 12
Ports and Services 3
Certain UDP and TCP ports must be open so that View components can communicate with each other.
Knowing which Windows services run on each type of View server helps identify services that do not
belong on the server.
This section includes the following topics:
nView TCP and UDP Ports
nServices on a View Connection Server Host
nServices on a Security Server
View TCP and UDP Ports
View uses TCP and UDP ports for network access between its components.
During installation, View can optionally configure Windows firewall rules to open the ports that are used
by default. If you change the default ports after installation, you must manually reconfigure Windows
firewall rules to allow access on the updated ports. See "Replacing Default Ports for View Services" in the
View Installation document.
Table 3‑1. TCP and UDP Ports Used by View
Source Port Target Port
Protoco
l Description
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
55000 Horizon Agent 4172 UDP PCoIP (not SALSA20) if PCoIP Secure Gateway is
used.
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
4172 Horizon Client * UDP PCoIP (not SALSA20) if PCoIP Secure Gateway is
used.
Note Because the target port varies, see the note
below this table.
Security server 500 View Connection
Server
500 UDP IPsec negotiation traffic.
VMware, Inc. 13
Table 3‑1. TCP and UDP Ports Used by View (Continued)
Source Port Target Port
Protoco
l Description
Security server * View Connection
Server
4001 TCP JMS traffic.
Security server * View Connection
Server
4002 TCP JMS SSL traffic.
Security server * View Connection
Server
8009 TCP AJP13-forwarded Web traffic, if not using IPsec.
Security server * View Connection
Server
* ESP AJP13-forwarded Web traffic, when using IPsec without
NAT.
Security server 4500 View Connection
Server
4500 UDP AJP13-forwarded Web traffic, when using IPsec through
a NAT device.
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
* Horizon Agent 3389 TCP Microsoft RDP traffic to View desktops when tunnel
connections are used.
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
* Horizon Agent 9427 TCP Windows Media MMR redirection and client drive
redirection when tunnel connections are used.
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
* Horizon Agent 32111 TCP USB redirection and time zone synchronization when
tunnel connections are used.
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
* Horizon Agent 4172 TCP PCoIP if PCoIP Secure Gateway is used.
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
* Horizon Agent 22443 TCP VMware Blast Extreme if Blast Secure Gateway is used.
View Security
VMware, Inc. 14
Table 3‑1. TCP and UDP Ports Used by View (Continued)
Source Port Target Port
Protoco
l Description
Security server,
View Connection
Server, or
Unified Access
Gateway
appliance
* Horizon Agent 22443 TCP HTML Access if Blast Secure Gateway is used.
Horizon Agent 4172 Horizon Client * UDP PCoIP, if PCoIP Secure Gateway is not used.
Note Because the target port varies, see the note
below this table.
Horizon Agent 4172 View Connection
Server, security
server, or
Unified Access
Gateway
appliance
55000 UDP PCoIP (not SALSA20) if PCoIP Secure Gateway is
used.
Horizon Agent 4172 Unified Access
Gateway
appliance
* UDP PCoIP. View desktops and applications send PCoIP
data back to an Unified Access Gateway appliance from
UDP port 4172 .
The destination UDP port will be the source port from
the received UDP packets and so as this is reply data, it
is normally unnecessary to add an explicit firewall rule
for this.
Horizon Client * View Connection
Server or
security server or
Unified Access
Gateway
appliance
80 TCP SSL (HTTPS access) is enabled by default for client
connections, but port 80 (HTTP access) can be used in
certain cases. See HTTP Redirection in View.
Horizon Client * View Connection
Server, security
server, or
Unified Access
Gateway
appliance
443 TCP HTTPS for logging in to View. (This port is also used for
tunnelling when tunnel connections are used.)
Horizon Client * View Connection
Server or
security server or
Unified Access
Gateway
appliance
4172 TCP
and
UDP
PCoIP if PCoIP Secure Gateway is used.
Horizon Client * Horizon Agent 3389 TCP Microsoft RDP traffic to View desktops if direct
connections are used instead of tunnel connections.
Horizon Client * Horizon Agent 9427 TCP Windows Media MMR redirection and client drive
redirection, if direct connections are used instead of
tunnel connections.
View Security
VMware, Inc. 15
Table 3‑1. TCP and UDP Ports Used by View (Continued)
Source Port Target Port
Protoco
l Description
Horizon Client * Horizon Agent 32111 TCP USB redirection and time zone synchronization if direct
connections are used instead of tunnel connections.
Horizon Client * Horizon Agent 4172 TCP
and
UDP
PCoIP if PCoIP Secure Gateway is not used.
Note Because the source port varies, see the note
below this table.
Horizon Client * Horizon Agent 22443 TCP
and
UDP
VMware Blast
Horizon Client * View Connection
Server, security
server, or
Unified Access
Gateway
appliance
4172 TCP
and
UDP
PCoIP (not SALSA20) if PCoIP Secure Gateway is
used.
Note Because the source port varies, see the note
below this table.
Web Browser * Security server
or
Unified Access
Gateway
appliance
8443 TCP HTML Access.
View Connection
Server
* View Connection
Server
48080 TCP For internal communication between View Connection
Server components.
View Connection
Server
* vCenter Server
or View
Composer
80 TCP SOAP messages if SSL is disabled for access to
vCenter Servers or View Composer.
View Connection
Server
* vCenter Server 443 TCP SOAP messages if SSL is enabled for access to
vCenter Servers.
View Connection
Server
* View Composer 18443 TCP SOAP messages if SSL is enabled for access to View
Composer.
View Connection
Server
* View Connection
Server
4100 TCP JMS inter-router traffic.
View Connection
Server
* View Connection
Server
4101 TCP JMS SSL inter-router traffic.
View Connection
Server
* View Connection
Server
8472 TCP For interpod communication in Cloud Pod Architecture.
View Connection
Server
* View Connection
Server
22389 TCP For global LDAP replication in Cloud Pod Architecture.
View Connection
Server
* View Connection
Server
22636 TCP For secure global LDAP replication in Cloud Pod
Architecture.
View Connection
Server
* View Connection
Server
32111 TCP Key sharing traffic.
View Security
VMware, Inc. 16
Table 3‑1. TCP and UDP Ports Used by View (Continued)
Source Port Target Port
Protoco
l Description
Unified Access
Gateway
appliance
* View Connection
Server or load
balancer
443 TCP HTTPS access. Unified Access Gateway appliances
connect on TCP port 443 to communicate with a View
Connection Server instance or load balancer in front of
multiple View Connection Server instances.
View Composer
service
* ESXi host 902 TCP Used when View Composer customizes linked-clone
disks, including View Composer internal disks and, if
they are specified, persistent disks and system
disposable disks.
Note The UDP port number that clients use for PCoIP might change. If port 50002 is in use, the client
will pick 50003. If port 50003 is in use, the client will pick port 50004, and so on. You must configure
firewalls with ANY where an asterisk (*) is listed in the table.
Note Microsoft Windows Server requires a dynamic range of ports to be open between all Connection
Servers in the Horizon 7 environment. These ports are required by Microsoft Windows for the normal
operation of Remote Procedure Call (RPC) and Active Directory replication. For more information about
the dynamic range of ports, see the Microsoft Windows Server documentation.
HTTP Redirection in View
Connection attempts over HTTP are silently redirected to HTTPS, except for connection attempts to View
Administrator. HTTP redirection is not needed with more recent Horizon clients because they default to
HTTPS, but it is useful when your users connect with a Web browser, for example to download Horizon
Client.
The problem with HTTP redirection is that it is a non-secure protocol. If a user does not form the habit of
entering https:// in the address bar, an attacker can compromise the Web browser, install malware, or
steal credentials, even when the expected page is correctly displayed.
Note HTTP redirection for external connections can take place only if you configure your external
firewall to allow inbound traffic to TCP port 80.
Connection attempts over HTTP to View Administrator are not redirected. Instead, an error message is
returned indicating that you must use HTTPS.
To prevent redirection for all HTTP connection attempts, see "Prevent HTTP Redirection for Client
Connections to Connection Server" in the View Installation document.
Connections to port 80 of a View Connection Server instance or security server can also take place if you
off-load SSL client connections to an intermediate device. See "Off-load SSL Connections to Intermediate
Servers" in the View Administration document.
To allow HTTP redirection when the SSL port number was changed, see "Change the Port Number for
HTTP Redirection to Connection Server" in the View Installation document.
View Security
VMware, Inc. 17
Services on a View Connection Server Host
The operation of View depends on several services that run on a View Connection Server host.
Table 3‑2. View Connection Server Host Services
Service Name Startup Type Description
VMware Horizon
View Blast Secure
Gateway
Automatic Provides secure HTML Access and Blast Extreme services. This service must be running if
clients connect to View Connection Server through the Blast Secure Gateway.
VMware Horizon
View Connection
Server
Automatic Provides connection broker services. This service must always be running. If you start or
stop this service, it also starts or stops the Framework, Message Bus, Security Gateway,
and Web services. This service does not start or stop the VMwareVDMDS service or the
VMware Horizon View Script Host service.
VMware Horizon
View Framework
Component
Manual Provides event logging, security, and COM+ framework services. This service must always
be running.
VMware Horizon
View Message Bus
Component
Manual Provides messaging services between the View components. This service must always be
running.
VMware Horizon
View PCoIP Secure
Gateway
Manual Provides PCoIP Secure Gateway services. This service must be running if clients connect
to View Connection Server through the PCoIP Secure Gateway.
VMware Horizon
View Script Host
Disabled Provides support for third-party scripts that run when you delete virtual machines. This
service is disabled by default. You should enable this service if you want to run scripts.
VMware Horizon
View Security
Gateway Component
Manual Provides common gateway services. This service must always be running.
VMware Horizon
View Web
Component
Manual Provides web services. This service must always be running.
VMwareVDMDS Automatic Provides LDAP directory services. This service must always be running. During upgrades
of View, this service ensures that existing data is migrated correctly.
Services on a Security Server
The operation of View depends on several services that run on a security server.
Table 3‑3. Security Server Services
Service Name Startup Type Description
VMware Horizon
View Blast Secure
Gateway
Automatic Provides secure HTML Access and Blast Extreme services. This service must be running if
clients connect to this security server through the Blast Secure Gateway.
VMware Horizon
View Security Server
Automatic Provides security server services. This service must always be running. If you start or stop
this service, it also starts or stops the Framework and Security Gateway services.
View Security
VMware, Inc. 18
Table 3‑3. Security Server Services (Continued)
Service Name Startup Type Description
VMware Horizon
View Framework
Component
Manual Provides event logging, security, and COM+ framework services. This service must always
be running.
VMware Horizon
View PCoIP Secure
Gateway
Manual Provides PCoIP Secure Gateway services. This service must be running if clients connect
to this security server through the PCoIP Secure Gateway.
VMware Horizon
View Security
Gateway Component
Manual Provides common gateway services. This service must always be running.
View Security
VMware, Inc. 19
Configuring Security Protocols
and Cipher Suites on a View
Connection Server Instance or
on a Security Server 4
You can configure the security protocols and cipher suites that are accepted by View Connection Server.
You can define a global acceptance policy that applies to all View Connection Server instances in a
replicated group, or you can define an acceptance policy for individual View Connection Server instances
and security servers.
You also can configure the security protocols and cipher suites that View Connection Server instances
propose when connecting to vCenter Server and View Composer. You can define a global proposal policy
that applies to all View Connection Server instances in a replicated group. You cannot define individual
instances to opt out of a global proposal policy.
Note The security settings for View Connection Server do not apply to Blast Secure Gateway (BSG).
You must configure security for BSG separately. See Chapter 5 Configuring Security Protocols and
Cipher Suites for Blast Secure Gateway.
Oracle's Unlimited Strength Jurisdiction Policy files are included as standard, allowing 256-bit keys by
default.
This section includes the following topics:
nDefault Global Policies for Security Protocols and Cipher Suites
nConfiguring Global Acceptance and Proposal Policies
nConfigure Acceptance Policies on Individual Servers
nConfigure Proposal Policies on Remote Desktops
nOlder Protocols and Ciphers Disabled in View
VMware, Inc. 20
Default Global Policies for Security Protocols and Cipher
Suites
Global acceptance and proposal policies enable certain security protocols and cipher suites by default.
Table 4‑1. Default Global Policies
Default Security Protocols Default Cipher Suites
nTLS 1.2
nTLS 1.1
nTLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256
nTLS_ECDHE_RSA_WITH_AES_128_CBC_SHA
nTLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384
nTLS_ECDHE_RSA_WITH_AES_256_CBC_SHA
nTLS_RSA_WITH_AES_128_CBC_SHA
nTLS_RSA_WITH_AES_256_CBC_SHA
GCM cipher suites are not enabled by default for performance reasons.
Configuring Global Acceptance and Proposal Policies
Global acceptance and proposal policies are defined in View LDAP attributes. These policies apply to all
View Connection Server instances and security servers in a replicated group. To change a global policy,
you can edit View LDAP on any View Connection Server instance.
Each policy is a single-valued attribute in the following View LDAP location:
cn=common,ou=global,ou=properties,dc=vdi,dc=vmware,dc=int
Global Acceptance and Proposal Policies Defined in View LDAP
You can edit the View LDAP attributes that define global acceptance and proposal policies.
Global Acceptance Policies
The following attribute lists security protocols. You must order the list by placing the latest protocol first:
pae-ServerSSLSecureProtocols = \LIST:TLSv1.2,TLSv1.1,TLSv1
The following attribute lists the cipher suites. This example shows an abbreviated list:
pae-ServerSSLCipherSuites = \LIST:TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256,TLS_RSA_WITH_AES_128_CBC_SHA
The following attribute controls the precedence of cipher suites. Normally, the server's ordering of cipher
suites is unimportant and the client's ordering is used. To use the server's ordering of cipher suites
instead, set the following attribute:
pae-ServerSSLHonorClientOrder = 0
View Security
VMware, Inc. 21
Global Proposal Policies
The following attribute lists security protocols. You must order the list by placing the latest protocol first:
pae-ClientSSLSecureProtocols = \LIST:TLSv1.2,TLSv1.1,TLSv1
The following attribute lists the cipher suites. This list should be in order of preference. Place the most
preferred cipher suite first, the second-most preferred suite next, and so on. This example shows an
abbreviated list:
pae-ClientSSLCipherSuites = \LIST:TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256,TLS_RSA_WITH_AES_128_CBC_SHA
Change the Global Acceptance and Proposal Policies
To change the global acceptance and proposal policies for security protocols and cipher suites, you use
the ADSI Edit utility to edit View LDAP attributes.
Prerequisites
nFamiliarize yourself with the View LDAP attributes that define the acceptance and proposal policies.
See Global Acceptance and Proposal Policies Defined in View LDAP.
nSee the Microsoft TechNet Web site for information on how to use the ADSI Edit utility on your
Windows Server operating system version.
Procedure
1Start the ADSI Edit utility on your View Connection Server computer.
2In the console tree, select Connect to.
3In the Select or type a Distinguished Name or Naming Context text box, type the distinguished
name DC=vdi, DC=vmware, DC=int.
4In the Select or type a domain or server text box, select or type localhost:389 or the fully
qualified domain name (FQDN) of the View Connection Server computer followed by port 389.
For example: localhost:389 or mycomputer.mydomain.com:389
5Expand the ADSI Edit tree, expand OU=Properties, select OU=Global, and select OU=Common in
the right pane.
6On the object CN=Common, OU=Global, OU=Properties, select each attribute that you want to
change and type the new list of security protocols or cipher suites.
7Restart the Windows service VMware Horizon View Security Gateway Component on each
Connection Server instance and security server if you modified pae-ServerSSLSecureProtocols.
You do not need to restart any service after modifying pae-ClientSSLSecureProtocols.
View Security
VMware, Inc. 22
Configure Acceptance Policies on Individual Servers
To specify a local acceptance policy on an individual Connection Server instance or security server, you
must add properties to the locked.properties file. If the locked.properties file does not yet exist on
the server, you must create it.
You add a secureProtocols.n entry for each security protocol that you want to configure. Use the
following syntax: secureProtocols.n=security protocol.
You add an enabledCipherSuite.n entry for each cipher suite that you want to configure. Use the
following syntax: enabledCipherSuite.n=cipher suite.
The variable n is an integer that you add sequentially (1, 2, 3) to each type of entry.
You add an honorClientOrder entry to control the precedence of cipher suites. Normally, the server's
ordering of cipher suites is unimportant and the client's ordering is used. To use the server's ordering of
cipher suites instead, use the following syntax:
honorClientOrder=false
Make sure that the entries in the locked.properties file have the correct syntax and the names of the
cipher suites and security protocols are spelled correctly. Any errors in the file can cause the negotiation
between the client and server to fail.
Procedure
1Create or edit the locked.properties file in the SSL gateway configuration folder on the
Connection Server or security server computer.
For example: install_directory\VMware\VMware View\Server\sslgateway\conf\
2Add secureProtocols.n and enabledCipherSuite.n entries, including the associated security
protocols and cipher suites.
3Save the locked.properties file.
4Restart the VMware Horizon View Connection Server service or VMware Horizon View Security
Server service to make your changes take effect.
Example: Default Acceptance Policies on an Individual Server
The following example shows the entries in the locked.properties file that are needed to specify the
default policies:
# The following list should be ordered with the latest protocol first:
secureProtocols.1=TLSv1.2
secureProtocols.2=TLSv1.1
# This setting must be the latest protocol given in the list above:
View Security
VMware, Inc. 23
preferredSecureProtocol=TLSv1.2
# The order of the following list is unimportant unless honorClientOrder is false:
enabledCipherSuite.1=TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256
enabledCipherSuite.2=TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA
enabledCipherSuite.3=TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384
enabledCipherSuite.4=TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA
enabledCipherSuite.5=TLS_RSA_WITH_AES_128_CBC_SHA
enabledCipherSuite.6=TLS_RSA_WITH_AES_256_CBC_SHA
# Use the client's ordering of cipher suites (ignores the ordering given above):
honorClientOrder=true
Configure Proposal Policies on Remote Desktops
You can control the security of Message Bus connections to Connection Server by configuring the
proposal policies on remote desktops that run Windows.
Make sure that Connection Server is configured to accept the same policies to avoid a connection failure.
Procedure
1Start the Windows Registry Editor on the remote desktop.
2Navigate to the HKEY_LOCAL_MACHINE\Software\VMware, Inc.\VMware
VDM\Agent\Configuration registry key.
3Add a new String (REG_SZ) value, ClientSSLSecureProtocols.
4Set the value to a list of cipher suites in the format \LIST:protocol_1,protocol_2,....
List the protocols with the latest protocol first. For example:
\LIST:TLSv1.2,TLSv1.1,TLSv1
5Add a new String (REG_SZ) value, ClientSSLCipherSuites.
6Set the value to a list of cipher suites in the format \LIST:cipher_suite_1,cipher_suite_2,....
The list should be in order of preference, with the most preferred cipher suite first. For example:
\LIST:TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256,TLS_RSA_WITH_AES_128_CBC_SHA
View Security
VMware, Inc. 24
Older Protocols and Ciphers Disabled in View
Some older protocols and ciphers that are no longer considered secure are disabled in View by default. If
required, you can enable them manually.
DHE Cipher Suites
For more information, see http://kb.vmware.com/kb/2121183. Cipher suites that are compatible with DSA
certificates use Diffie-Hellman ephemeral keys, and these suites are no longer enabled by default,
starting with Horizon 6 version 6.2.
For Connection Server instances, security servers, and View desktops, you can enable these cipher
suites by editing the View LDAP database, locked.properties file, or registry, as described in this
guide. See Change the Global Acceptance and Proposal Policies, Configure Acceptance Policies on
Individual Servers, and Configure Proposal Policies on Remote Desktops. You can define a list of cipher
suites that includes one or more of the following suites, in this order:
nTLS_DHE_DSS_WITH_AES_128_GCM_SHA256 (TLS 1.2 only, not FIPS)
nTLS_DHE_DSS_WITH_AES_256_GCM_SHA384 (TLS 1.2 only, not FIPS)
nTLS_DHE_DSS_WITH_AES_128_CBC_SHA256 (TLS 1.2 only)
nTLS_DHE_DSS_WITH_AES_128_CBC_SHA
nTLS_DHE_DSS_WITH_AES_256_CBC_SHA256 (TLS 1.2 only)
nTLS_DHE_DSS_WITH_AES_256_CBC_SHA
For View Composer and View Agent Direct-Connection (VADC) machines, you can enable DHE cipher
suites by adding the following to the list of ciphers when you follow the procedure "Disable Weak Ciphers
in SSL/TLS for View Composer and Horizon Agent Machines" in the View Installation document.
TLS_DHE_RSA_WITH_AES_256_GCM_SHA384
TLS_DHE_RSA_WITH_AES_128_GCM_SHA256
Note It is not possible to enable support for ECDSA certificates. These certificates have never been
supported.
SSLv3
In Horizon 7, SSL version 3.0 has been removed.
For more information, see http://tools.ietf.org/html/rfc7568.
RC4
For more information, see http://tools.ietf.org/html/rfc7465.
View Security
VMware, Inc. 25
For Connection Server instances, security servers, and View desktops, you can enable RC4 on a
Connection Server, security server, or a Horizon Agent machine by editing the configuration file
C:\Program Files\VMware\VMware View\Server\jre\lib\security\java.security. At the end of
the file is a multi-line entry called jdk.tls.legacyAlgorithms. Remove RC4_128 and the comma that
follows it from this entry and restart the Connection Server, security server, or the Horizon Agent machine,
as the case may be.
For View Composer and View Agent Direct-Connection (VADC) machines, you can enable RC4 by
adding the following to the list of ciphers when you follow the procedure "Disable Weak Ciphers in
SSL/TLS for View Composer and Horizon Agent Machines" in the View Installation document.
TLS_RSA_WITH_RC4_128_SHA
TLS 1.0
In Horizon 7, TLS 1.0 is disabled by default.
For more information, see https://www.pcisecuritystandards.org/documents/PCI_DSS_v3-1.pdf and
http://nvlpubs.nist.gov/nistpubs/SpecialPublications/NIST.SP.800-52r1.pdf. For instructions on how to
enable TLS 1.0, see the sections "Enable TLSv1 on vCenter Connections from Connection Server" and
"Enable TLSv1 on vCenter and ESXi Connections from View Composer" in the View Upgrades document.
View Security
VMware, Inc. 26
Configuring Security Protocols
and Cipher Suites for Blast
Secure Gateway 5
The security settings for View Connection Server do not apply to Blast Secure Gateway (BSG). You must
configure security for BSG separately.
Configure Security Protocols and Cipher Suites for Blast
Secure Gateway (BSG)
You can configure the security protocols and cipher suites that BSG's client-side listener accepts by
editing the file absg.properties.
The protocols that are allowed are, from low to high, tls1.0, tls1.1, and tls1.2. Older protocols such as
SSLv3 and earlier are never allowed. Two properties, localHttpsProtocolLow and
localHttpsProtocolHigh, determine the range of protocols that the BSG listener will accept. For
example, setting localHttpsProtocolLow=tls1.0 and localHttpsProtocolHigh=tls1.2 will cause
the listener to accept tls1.0, tls1.1, and tls1.2. The default settings are localHttpsProtocolLow=tls1.1
and localHttpsProtocolHigh=tls1.2. You can examine the BSG's absg.log file to discover the
values that are in force for a specific BSG instance.
You must specify the list of ciphers using the format that is defined in
https://www.openssl.org/docs/manmaster/man1/ciphers.html, under the section CIPHER LIST FORMAT.
The following cipher list is the default:
ECDHE-RSA-AES256-SHA:AES256-SHA:HIGH:!AESGCM:!CAMELLIA:!3DES:!EDH:!EXPORT:!MD5:!PSK:!RC4:!SRP:!aNULL:!
eNULL
Procedure
1On the Connection Server instance, edit the file install_directory\VMware\VMware
View\Server\appblastgateway\absg.properties.
By default, the install directory is %ProgramFiles%.
VMware, Inc. 27
2Edit the properties localHttpsProtocolLow and localHttpsProtocolHigh to specify a range of
protocols.
For example,
localHttpsProtocolLow=tls1.0
localHttpsProtocolHigh=tls1.2
To enable only one protocol, specify the same protocol for both localHttpsProtocolLow and
localHttpsProtocolHigh.
3Edit the localHttpsCipherSpec property to specify a list of cipher suites.
For example,
localHttpsCipherSpec=ECDHE-RSA-AES256-SHA:HIGH:!AESGCM:!CAMELLIA:!3DES:!EDH:!EXPORT:!MD5:!PSK:!
RC4:!SRP:!aNULL:!eNULL
4Restart the Windows service VMware Horizon View Blast Secure Gateway.
View Security
VMware, Inc. 28
Deploying USB Devices in a
Secure Horizon 7 Environment 6
USB devices can be vulnerable to a security threat called BadUSB, in which the firmware on some USB
devices can be hijacked and replaced with malware. For example, a device can be made to redirect
network traffic or to emulate a keyboard and capture keystrokes. You can configure the USB redirection
feature to protect your Horizon 7 deployment against this security vulnerability.
By disabling USB redirection, you can prevent any USB devices from being redirected to your users'
Horizon 7 desktops and applications. Alternatively, you can disable redirection of specific USB devices,
allowing users to have access only to specific devices on their desktops and applications.
The decision whether to take these steps depends on the security requirements in your organization.
These steps are not mandatory. You can install USB redirection and leave the feature enabled for all USB
devices in your Horizon 7 deployment. At a minimum, consider seriously the extent to which your
organization should try to limit its exposure to this security vulnerability.
This section includes the following topics:
nDisabling USB Redirection for All Types of Devices
nDisabling USB Redirection for Specific Devices
Disabling USB Redirection for All Types of Devices
Some highly secure environments require you to prevent all USB devices that users might have
connected to their client devices from being redirected to their remote desktops and applications. You can
disable USB redirection for all desktop pools, for specific desktop pools, or for specific users in a desktop
pool.
Use any of the following strategies, as appropriate for your situation:
nWhen you install Horizon Agent on a desktop image or RDS host, deselect the USB redirection
setup option. (The option is deselected by default.) This approach prevents access to USB devices
on all remote desktops and applications that are deployed from the desktop image or RDS host.
nIn Horizon Administrator, edit the USB access policy for a specific pool to either deny or allow
access. With this approach, you do not have to change the desktop image and can control access to
USB devices in specific desktop and application pools.
Only the global USB access policy is available for RDS desktop and application pools. You cannot
set this policy for individual RDS desktop or application pools.
VMware, Inc. 29
nIn View Administrator, after you set the policy at the desktop or application pool level, you can
override the policy for a specific user in the pool by selecting the User Overrides setting and
selecting a user.
nSet the Exclude All Devices policy to true, on the Horizon Agent side or on the client side, as
appropriate.
nUse Smart Policies to create a policy that disables the USB redirection Horizon Policy setting. With
this approach, you can disable USB redirection on a specific remote desktop if certain conditions are
met. For example, you can configure a policy that disables USB redirection when users connect to a
remote desktop from outside your corporate network.
If you set the Exclude All Devices policy to true, Horizon Client prevents all USB devices from being
redirected. You can use other policy settings to allow specific devices or families of devices to be
redirected. If you set the policy to false, Horizon Client allows all USB devices to be redirected except
those that are blocked by other policy settings. You can set the policy on both Horizon Agent and
Horizon Client. The following table shows how the Exclude All Devices policy that you can set for
Horizon Agent and Horizon Client combine to produce an effective policy for the client computer. By
default, all USB devices are allowed to be redirected unless otherwise blocked.
Table 6‑1. Eect of Combining Exclude All Devices Policies
Exclude All Devices Policy on Horizon
Agent
Exclude All Devices Policy on
Horizon Client
Combined Effective Exclude All
Devices Policy
false or not defined (include all USB
devices)
false or not defined (include all USB
devices)
Include all USB devices
false (include all USB devices) true (exclude all USB devices) Exclude all USB devices
true (exclude all USB devices) Any or not defined Exclude all USB devices
If you have set Disable Remote Configuration Download policy to true, the value of Exclude All
Devices on Horizon Agent is not passed to Horizon Client, but Horizon Agent and Horizon Client enforce
the local value of Exclude All Devices.
These policies are included in the Horizon Agent Configuration ADMX template file (vdm_agent.admx).
For more information, see "USB Settings in the Horizon Agent Configuration ADMX Template" in
Configuring Remote Desktop Features in Horizon 7.
Disabling USB Redirection for Specific Devices
Some users might have to redirect specific locally-connected USB devices so that they can perform tasks
on their remote desktops or applications. For example, a doctor might have to use a Dictaphone USB
device to record patients' medical information. In these cases, you cannot disable access to all USB
devices. You can use group policy settings to enable or disable USB redirection for specific devices.
Before you enable USB redirection for specific devices, make sure that you trust the physical devices that
are connected to client machines in your enterprise. Be sure that you can trust your supply chain. If
possible, keep track of a chain of custody for the USB devices.
View Security
VMware, Inc. 30
In addition, educate your employees to ensure that they do not connect devices from unknown sources. If
possible, restrict the devices in your environment to those that accept only signed firmware updates, are
FIPS 140-2 Level 3-certified, and do not support any kind of field-updatable firmware. These types of
USB devices are hard to source and, depending on your device requirements, might be impossible to
find. These choices might not be practical, but they are worth considering.
Each USB device has its own vendor and product ID that identifies it to the computer. By configuring
Horizon Agent Configuration group policy settings, you can set an include policy for known device types.
With this approach, you remove the risk of allowing unknown devices to be inserted into your
environment.
For example, you can prevent all devices except a known device vendor and product ID,
vid/pid=0123/abcd, from being redirected to the remote desktop or application:
ExcludeAllDevices Enabled
IncludeVidPid o:vid-0123_pid-abcd
Note This example configuration provides protection, but a compromised device can report any vid/pid,
so a possible attack could still occur.
By default, Horizon 7 blocks certain device families from being redirected to the remote desktop or
application. For example, HID (human interface devices) and keyboards are blocked from appearing in
the guest. Some released BadUSB code targets USB keyboard devices.
You can prevent specific device families from being redirected to the remote desktop or application. For
example, you can block all video, audio, and mass storage devices:
ExcludeDeviceFamily o:video;audio;storage
Conversely, you can create a whitelist by preventing all devices from being redirected but allowing a
specific device family to be used. For example, you can block all devices except storage devices:
ExcludeAllDevices Enabled
IncludeDeviceFamily o:storage
Another risk can arise when a remote user logs into a desktop or application and infects it. You can
prevent USB access to any Horizon 7 connections that originate from outside the company firewall. The
USB device can be used internally but not externally.
Be aware that if you block TCP port 32111 to disable external access to USB devices, time zone
synchronization will not work because port 32111 is also used for time zone synchronization. For zero
clients, the USB traffic is embedded inside a virtual channel on UDP port 4172. Because port 4172 is
used for the display protocol as well as for USB redirection, you cannot block port 4172. If required, you
can disable USB redirection on zero clients. For details, see the zero client product literature or contact
the zero client vendor.
View Security
VMware, Inc. 31
Setting policies to block certain device families or specific devices can help to mitigate the risk of being
infected with BadUSB malware. These policies do not mitigate all risk, but they can be an effective part of
an overall security strategy.
These policies are included in the Horizon Agent Configuration ADMX template file (vdm_agent.admx).
For more information, see Configuring Remote Desktop Features in Horizon 7.
View Security
VMware, Inc. 32
HTTP Protection Measures on
Connection Servers and
Security Servers 7
Horizon 7 employs certain measures to protect communication that uses the HTTP protocol.
This section includes the following topics:
nInternet Engineering Task Force Standards
nWorld Wide Web Consortium Standards
nOther Protection Measures
nConfigure HTTP Protection Measures
Internet Engineering Task Force Standards
Connection Server and security server comply with certain Internet Engineering Task Force (IETF)
standards.
nRFC 5746 Transport Layer Security (TLS) – Renegotiation Indication Extension, also known as
secure renegotiation, is enabled by default.
Note Client-initiated renegotiation is disabled by default on Connection Servers and security
servers. To enable, edit registry value [HKLM\SOFTWARE\VMware, Inc.\VMware
VDM\plugins\wsnm\TunnelService\Params]JvmOptions and remove
-Djdk.tls.rejectClientInitiatedRenegotiation=true from the string.
nRFC 6797 HTTP Strict Transport Security (HSTS), also known as transport security, is enabled by
default. This setting cannot be disabled.
nRFC 7034 HTTP Header Field X-Frame-Options, also known as counter clickjacking, is enabled by
default. You can disable it by adding the entry x-frame-options=OFF to the file
locked.properties. For information on how to add properties to the file locked.properties, see
Configure HTTP Protection Measures.
Note In releases earlier than Horizon 7 version 7.2, changing this option did not affect connections
to HTML Access.
VMware, Inc. 33
nRFC 6454 Origin Checking, which protects against cross-site request forging, is enabled by default.
You can disable it by adding the entry checkOrigin=false to locked.properties. For more
information, see Cross-Origin Resource Sharing.
Note In earlier releases, this protection was disabled by default.
World Wide Web Consortium Standards
Connection Server and security server comply with certain World Wide Web Consortium (W3) standards.
nCross-Origin Resource Sharing (CORS), which constrains client-side cross-origin requests, is
enabled by default. You can disable it by adding the entry enableCORS=false to
locked.properties.
nContent Security Policy (CSP), which mitigates a broad class of content injection vulnerabilities, is
enabled by default. You can disable it by adding the entry enableCSP=false to
locked.properties.
Cross-Origin Resource Sharing
The Cross-Origin Resource Sharing (CORS) feature regulates client-side cross-origin requests by
providing policy statements to the client on demand and by checking requests for compliance with the
policy. This feature is enabled by default.
Policies include the set of HTTP methods that can be accepted, where requests can originate, and which
content types are valid. These vary according to the request URL, and can be reconfigured as needed by
adding entries to locked.properties.
An ellipsis after a property name indicates that the property can accept a list.
Table 7‑1. CORS Properties
Property Value Type Master Default Other Defaults
enableCORS true
false
true n/a
acceptContentType... http-content-type application/x-www-form-
urlencoded,application/x
ml,text/xml
nadmin=application/x-
amf
nhelpdesk=applicatio
n/json,application/te
xt,application/x-www-
form-urlencoded
nview-vlsi-
rest=application/json
acceptHeader... http-header-name * n/a
exposeHeader... http-header-name * n/a
filterHeaders true
false
true n/a
View Security
VMware, Inc. 34
Table 7‑1. CORS Properties (Continued)
Property Value Type Master Default Other Defaults
checkOrigin true
false
true n/a
allowCredentials true
false
false admin=true
broker=true
helpdesk=true
misc=true
portal=true
saml=true
tunnel=true
view-vlsi=true
view-vlsi-rest=true
allowMethod... http-method-name GET,HEAD,POST misc=GET,HEAD
saml=GET,HEAD
allowPreflight true
false
true n/a
maxAge cache-time 0 n/a
balancedHost load-balancer-name OFF n/a
portalHost... gateway-name OFF n/a
chromeExtension... chrome-extension-hash OFF n/a
Example CORS properties in the locked.properties file:
enableCORS = true
allowPreflight = true
checkOrigin = true
checkOrigin-misc = false
allowMethod.1 = GET
allowMethod.2 = HEAD
allowMethod.3 = POST
allowMethod-saml.1 = GET
allowMethod-saml.2 = HEAD
acceptContentType.1 = application/x-www-form-urlencoded
acceptContentType.2 = application/xml
acceptContentType.3 = text/xml
Origin Checking
Origin checking is enabled by default. When it is enabled, a request will be accepted only without an
Origin, or with an Origin equal to the address given in the External URL, to the balancedHost address, to
any portalHost address, to any chromeExtension hash, to null, or to localhost. If Origin is not one
of these possibilities, then an error "Unexpected Origin" is logged and a status of 404 is returned.
If multiple Connection Servers or security servers are load balanced, you must specify the load balancer
address by adding a balancedHost entry to locked.properties. Port 443 is assumed for this address.
View Security
VMware, Inc. 35
If clients need to connect through a Unified Access Gateway or another gateway, you must specify all of
the gateway addresses by adding portalHost entries to locked.properties. Port 443 is assumed for
these addresses too. Do the same if you want to provide access to a Connection Server or security
server by a name that is different from the one that is specified in the External URL.
Chrome Extension clients set their initial Origin to their own identity. To allow connections to succeed,
register the extension by adding a chromeExtension entry to locked.properties.
Content Security Policy
The Content Security Policy (CSP) feature mitigates a broad class of content injection vulnerabilities,
such as cross-site scripting (XSS), by providing policy directives to compliant browsers. This feature is
enabled by default. You can reconfigure the policy directives by adding entries to locked.properties.
Table 7‑2. CSP Properties
Property Value Type Master Default Other Defaults
enableCSP true
false
true n/a
content-security-policy directives-list default-src
'self';script-src 'self'
'unsafe-inline' 'unsafe-
eval' data:;style-src
'self' 'unsafe-
inline';font-src 'self'
data:
portal=child-src 'self'
blob:;default-src
'self';connect-src 'self'
wss:;font-src 'self'
data:;img-src 'self'
data: blob:;media-src
'self' blob:;object-src
'self' blob:;script-src
'self' 'unsafe-inline'
'unsafe-eval'
data:;style-src 'self'
'unsafe-inline';frame-
ancestors 'self'
x-frame-options OFF
specification
deny portal=sameorigin
x-content-type-options OFF
specification
nosniff n/a
x-xss-protection OFF
specification
1; mode=block n/a
You can add CSP properties to the locked.properties file. Example CSP properties:
enableCSP = true
content-security-policy = default-src 'self';script-src 'self' data:
content-security-policy-portal = default-src 'self';frame-ancestors 'self'
x-frame-options = deny
x-frame-options-portal = sameorigin
x-xss-protection = 1; mode=block
View Security
VMware, Inc. 36
Other Protection Measures
Besides the Internet Engineering Task Force and W3 standards, Horizon 7 employs other measures to
protect communication that uses the HTTP protocol.
Reducing MIME Type Security Risks
By default, Horizon 7 sends the header x-content-type-options: nosniff in its HTTP responses to
help prevent attacks based on MIME-type confusion.
You can disable this feature by adding the following entry to the file locked.properties:
x-content-type-options=OFF
Mitigating Cross-Site Scripting Attacks
By default, Horizon 7 employs the XSS (cross-site scripting) Filter feature to mitigate cross-site scripting
attacks by sending the header x-xss-protection=1; mode=block in its HTTP responses.
You can disable this feature by adding the following entry to the file locked.properties:
x-xss-protection=OFF
Content Type Checking
By default, Horizon 7 accepts requests with the following declared content types only:
napplication/x-www-form-urlencoded
napplication/xml
ntext/xml
Note In earlier releases, this protection was disabled by default.
To restrict the content types that View accepts, add the following entry to the file locked.properties:
acceptContentType.1=content-type
For example:
acceptContentType.1=x-www-form-urlencoded
To accept another content type, add the entry acceptContentType.2=content-type, and so on
View Security
VMware, Inc. 37
To accept requests with any declared content type, specify acceptContentType=*.
Note In releases earlier than Horizon 7 version 7.2, changing this list does not affect connections to
Horizon Administrator.
Handshake Monitoring
TLS handshakes on port 443 must complete within a configurable period, otherwise they will be forcibly
terminated. By default, this period is 10 seconds. If smart card authentication is enabled, TLS
handshakes on port 443 can complete within 100 seconds.
If required, you can adjust the time for TLS handshakes on port 443 by adding the following property to
the locked.properties file:
handshakeLifetime = lifetime_in_seconds
For example:
handshakeLifetime = 20
Optionally, the client that is responsible for an over-running TLS handshake can be automatically added
to a blacklist. New connections from blacklisted clients are delayed for a configurable period before being
processed so that connections from other clients take priority. You can enable this feature by adding the
following property to the locked.properties file:
secureHandshakeDelay = delay_in_milliseconds
For example:
secureHandshakeDelay = 2000
To disable blacklisting of HTTPS connections, remove the secureHandshakeDelay entry or set it to 0.
The IP address of a misbehaving client is added to the blacklist for a minimum period equal to the sum of
handshakeLifetime and secureHandshakeDelay.
Using the values in the examples above, the IP address of a misbehaving client is 22 seconds
(20 * 1000) + 2000 = 22 seconds
The minimum period is extended each time a connection from the same IP address misbehaves. The IP
address is removed from the blacklist after the minimum period has expired and after the last delayed
connection from that IP address has been processed.
View Security
VMware, Inc. 38
A TLS handshake over-run is not the only reason to blacklist a client. Other reasons include a series of
abandoned connections, or a series of requests ending in error, such as multiple attempts to access non-
existent URLs. These various triggers have differing minimum blacklist periods. To extend monitoring of
these additional triggers to port 80, add the following entry to the locked.properties file:
insecureHandshakeDelay = delay_in_milliseconds
For example:
insecureHandshakeDelay = 1000
To disable blacklisting of HTTP connections, remove the insecureHandshakeDelay entry or set it to 0.
User Agent Whitelisting
Set a whitelist to restrict user agents that can interact with Horizon 7. By default, all user agents are
accepted.
Note This is not strictly a security feature. User agent detection relies on the user-agent request header
provided by the connecting client or browser, which can be spoofed. Some browsers allow the request
header to be modified by the user.
A user agent is specified by its name and a minimum version. For example:
clientWhitelist-portal.1 = Chrome-14
clientWhitelist-portal.2 = Safari-5.1
This means that only Google Chrome version 14 and later, and Safari version 5.1 and later are allowed to
connect using HTML Access. All browsers can connect to other services.
You can enter the following recognised user agent names:
nAndroid
nChrome
nEdge
nIE
nFirefox
nOpera
nSafari
Note Not all of these user agents are supported by Horizon 7. These are examples.
View Security
VMware, Inc. 39
Configure HTTP Protection Measures
To configure HTTP protection measures you must create or edit the locked.properties file in the SSL
gateway configuration folder on the Connection Server or security server instance.
For example: install_directory\VMware\VMware
View\Server\sslgateway\conf\locked.properties
nUse the following syntax to configure a property in locked.properties:
myProperty = newValue
nThe property name is always case-sensitive and the value might be case-sensitive. Whitespace
around the = sign is optional.
nFor CORS and CSP properties, it is possible to set service-specific values as well as a master value.
For example, the admin service is responsible for handling Horizon Administrator requests, and a
property can be set for this service without affecting other services by appending -admin after the
property name.
myProperty-admin = newValueForAdmin
nIf both a master value and a service-specific value are specified, then the service-specific value
applies to the named service, and the master value applies to all other services. The sole exception
to this is the special value "OFF". If the master value for a property is set to "OFF", then all service-
specific values for this property are ignored.
For example:
myProperty = OFF
myProperty-admin = newValueForAdmin ; ignored
nSome properties can accept a list of values.
To set a single value, enter the following property:
myProperty = newValue
myProperty-admin = newValueForAdmin
To set multiple values for a property that accepts list values, you can specify each value on a
separate line:
myProperty.1 = newValue1
myProperty.2 = newValue2
myProperty-admin.1 = newValueForAdmin1
myProperty-admin.2 = newValueForAdmin2
View Security
VMware, Inc. 40
nTo determine the correct service name to use when making a service-specific configuration, look in
the debug logs for lines containing the following sequence:
(ajp:admin:Request21) Request from abc.def.com/10.20.30.40: GET /admin/
In this example, the service name is admin. You can use the following typical service names:
nadmin for Horizon Administrator
nbroker for Connection Server
ndocroot for Local file serving
nhelpdesk for Helpdesk
nportal for HTML Access
nsaml for SAML communication (vIDM)
ntunnel for Secure Tunnel
nview-vlsi for View API
nmisc for Other
View Security
VMware, Inc. 41

Navigation menu
