VMware Horizon Client for Chrome OS
Installation and Setup Guide
Modified on 21 SEP 2017
VMware Horizon Client for Chrome OS 4.6
VMware Horizon Client for Chrome OS Installation and Setup Guide
2 VMware, Inc.
You can find the most up-to-date technical documentation on the VMware Web site at:
hps://docs.vmware.com/
The VMware Web site also provides the latest product updates.
If you have comments about this documentation, submit your feedback to:
docfeedback@vmware.com
Copyright © 2015–2017 VMware, Inc. All rights reserved. Copyright and trademark information.
VMware, Inc.
3401 Hillview Ave.
Palo Alto, CA 94304
www.vmware.com
Contents
VMware Horizon Client for Chrome OS Installation and Setup Guide 5
1Setup and Installation 7
System Requirements for Chrome OS Devices 7
System Requirements for Real-Time Audio-Video 8
Preparing Connection Server for Horizon Client 8
Using Embedded RSA SecurID Software Tokens 9
Congure Advanced TLS/SSL Options 10
Supported Desktop Operating Systems 10
Install or Upgrade Horizon Client for Chrome OS 10
Congure Decoding for VMware Blast Sessions 11
Congure the Horizon Client Default View 11
Enable the Multiple Monitor Feature for Horizon Client 11
Conguring a Default Connection Server URL 12
Horizon Client Data Collected by VMware 13
2Managing Remote Desktop and Application Connections 17
Seing the Certicate Checking Mode in Horizon Client 17
Connect to a Remote Desktop or Application 18
Use Unauthenticated Access to Connect to Remote Applications 20
Manage Server Shortcuts 21
Select a Favorite Remote Desktop or Application 21
Disconnecting From a Remote Desktop or Application 22
Log O From a Remote Desktop 22
Manage Desktop and Application Shortcuts 23
3Using a Remote Desktop or Application on a Chrome OS Device 25
Feature Support Matrix 25
Gestures 27
Using the Unity Touch Sidebar with a Remote Desktop 28
Using the Unity Touch Sidebar with a Remote Application 30
Using the Onscreen Keyboard 31
Screen Resolutions and Using External Displays 31
Using the Real-Time Audio-Video Feature 32
Saving Documents in a Remote Application 32
Internationalization 32
4Troubleshooting Horizon Client 33
Restart a Remote Desktop 33
Reset a Remote Desktop or Remote Applications 34
Uninstall Horizon Client 34
VMware, Inc. 3
Horizon Client Stops Responding or the Remote Desktop Freezes 35
Problem Establishing a Connection When Using a Proxy 35
Index 37
VMware Horizon Client for Chrome OS Installation and Setup Guide
4 VMware, Inc.
VMware Horizon Client for Chrome OS
Installation and Setup Guide
This document, VMware Horizon Client for Chrome OS Installation and Setup Guide, provides information about
installing, conguring, and using VMware Horizon® Client™ for Chrome OS on a Chrome OS device.
This information is intended for administrators who need to set up a Horizon deployment that includes
Chrome OS client devices. The information is wrien for experienced system administrators who are
familiar with virtual machine technology and datacenter operations.
VMware, Inc. 5
VMware Horizon Client for Chrome OS Installation and Setup Guide
6 VMware, Inc.
Setup and Installation 1
Seing up a Horizon deployment for Chrome OS clients involves using certain Connection Server
conguration seings, meeting the system requirements for Horizon servers and Chrome OS clients, and
downloading and installing Horizon Client for Chrome OS.
Beginning with Horizon Client 4.3 for Android, you can install Horizon Client for Android on certain
Chromebook models. For information, see the VMware Horizon Client for Android Installation and Setup Guide
document.
This chapter includes the following topics:
n“System Requirements for Chrome OS Devices,” on page 7
n“System Requirements for Real-Time Audio-Video,” on page 8
n“Preparing Connection Server for Horizon Client,” on page 8
n“Using Embedded RSA SecurID Software Tokens,” on page 9
n“Congure Advanced TLS/SSL Options,” on page 10
n“Supported Desktop Operating Systems,” on page 10
n“Install or Upgrade Horizon Client for Chrome OS,” on page 10
n“Congure Decoding for VMware Blast Sessions,” on page 11
n“Congure the Horizon Client Default View,” on page 11
n“Enable the Multiple Monitor Feature for Horizon Client,” on page 11
n“Conguring a Default Connection Server URL,” on page 12
n“Horizon Client Data Collected by VMware,” on page 13
System Requirements for Chrome OS Devices
The device on which you install Horizon Client must meet certain system requirements.
Device models Chromebook
Operating systems Chrome OS, stable channel, ARC version 41.4410.244.13 or later
CPU architecture nARM
nx86
VMware, Inc. 7
Connection Server,
security server, and
View Agent or
Horizon Agent
Latest maintenance release of Horizon 6 version 6.x and later releases.
VMware recommends that you use a security server or
Unied Access Gateway appliance so that client devices do not require a
VPN connection.
Display protocols nPCoIP
nVMware Blast (requires Horizon Agent 7.0 or later)
System Requirements for Real-Time Audio-Video
Real-Time Audio-Video works with standard audio and video devices and with standard conferencing
applications such as Skype, WebEx, and Google Hangouts. To support Real-Time Audio-Video, your
Horizon environment must meet certain software and hardware requirements.
Remote desktops and
applications
To use Real-Time Audio-Video with published desktops and remote
applications, you must have Horizon Agent 7.0.2 or later.
Client access device Real-Time Audio Video is supported on all Chromebooks that run
Horizon Client for Chrome OS.
Preparing Connection Server for Horizon Client
A Horizon administrator must perform specic tasks to enable end users to connect to remote desktops and
applications.
Before end users can connect to a Connection Server instance or a security server and access a remote
desktop or application, a Horizon administrator must congure certain pool seings and security seings:
nIf you plan to use Unied Access Gateway, congure Connection Server to work with
Unied Access Gateway. See the Deploying and Conguring Unied Access Gateway document.
Unied Access Gateway appliances fulll the same role that was previously played by only security
servers.
nIf you are using a security server, verify that you are using the latest maintenance releases of
Connection Server 6.x and Security Server 6.x or later releases. For more information, see the View
Installation document.
nIf you plan to use a secure tunnel connection for client devices and if the secure connection is
congured with a DNS host name for Connection Server or a security server, verify that the client
device can resolve this DNS name.
To enable or disable the secure tunnel, in Horizon Administrator, go to the Edit Horizon Connection
Server Seings dialog box and use the check box called Use secure tunnel connection to desktop.
nVerify that a desktop or application pool has been created and that the user account that you plan to use
is entitled to access the pool. For information, see the Seing Up Virtual Desktops in Horizon 7 or Seing
Up Published Desktops and Applications in Horizon 7 document.
nTo use two-factor authentication with Horizon Client, such as RSA SecurID or RADIUS authentication,
you must enable this feature on Connection Server. For more information, see the topics about two-
factor authentication in the View Administration document.
nTo hide security information in Horizon Client, including server URL information and the Domain
drop-down menu, enable the Hide server information in client user interface and Hide domain list in
client user interface seings in Horizon Administrator. These global seings are available in Horizon 7
version 7.1 and later. For information about conguring global seings, see the View Administration
document.
VMware Horizon Client for Chrome OS Installation and Setup Guide
8 VMware, Inc.
To authenticate when the Domain drop-down menu is hidden, users must provide domain information
by entering their user name in the format domain\username or username@domain in the User name text
box.
I If you enable the Hide server information in client user interface and Hide domain list
in client user interface seings and select two-factor authentication (RSA SecureID or RADIUS) for the
Connection Server instance, do not enforce Windows user name matching. Enforcing Windows user
name matching will prevent users from being able to enter domain information in the user name text
box and login will always fail. For more information, see the topics about two-factor authentication in
the View Administration document.
nTo provide end users unauthenticated access to published applications in Horizon Client, you must
enable this feature in Connection Server. For more information, see the topics about unauthenticated
access in the View Administration document.
Using Embedded RSA SecurID Software Tokens
If you create and distribute RSA SecurID software tokens to end users, they need enter only their PIN, rather
than their PIN and a token code, to authenticate.
Setup Requirements
You can use Compressed Token Format (CTF) or dynamic seed provisioning, which is also called CT-KIP
(Cryptographic Token Key Initialization Protocol), to set up an easy-to-use RSA authentication system. With
this system, you generate a URL to send to end users. To install the token, end users paste this URL directly
into Horizon Client on their client devices. The dialog box for pasting this URL appears when end users
connect to a Connection Server instance with Horizon Client.
After the software token is installed, end users enter a PIN to authenticate. With external RSA tokens, end
users must enter a PIN and the token code generated by a hardware or software authentication token.
The following URL prexes are supported for end users that copy and paste the URL into Horizon Client
when Horizon Client is connected to an RSA-enabled Connection Server instance:
nviewclient-securid://
nhttp://127.0.0.1/securid/
End users can install the token by tapping the URL. Both the viewclient-securid:// and
http://127.0.0.1/securid/ prexes are supported. Not all browsers support hyperlinks that begin with
http://127.0.0.1. Some le browsers, such as the File Manager app on the ASUS Transformer Pad, cannot
link the SDTID le with Horizon Client.
For information about using dynamic seed provisioning or le-based (CTF) provisioning, see the Web page
RSA SecurID Software Token for iPhone Devices at hp://www.rsa.com/node.aspx?id=3652 or RSA SecurID
Software Token for Android at hp://www.rsa.com/node.aspx?id=3832.
Instructions to End Users
When you create a CTFString URL or CT-KIP URL to send to end users, you can generate a URL with or
without a password or activation code. You send this URL to end users in an email that must include the
following information:
nInstructions for navigating to the Install Software Token dialog box.
Tell end users to tap External Token in the Horizon Client dialog box that prompts them for RSA
SecurID credentials when they connect to a Connection Server instance.
Chapter 1 Setup and Installation
VMware, Inc. 9
nCTFString URL or CT-KIP URL in plain text.
If the URL has formaing on it, end users will get an error message when they try to use it in
Horizon Client.
nActivation code, if the CT-KIP URL that you create does not already include the activation code.
End users must enter this activation code in a text eld of the dialog box.
nIf the CT-KIP URL includes an activation code, tell end users that they need not enter anything in the
Password or Activation Code text box in the Install Software Token dialog box.
Configure Advanced TLS/SSL Options
You can select the security protocols and cryptographic algorithms that are used to encrypt communications
between Horizon Client and Horizon servers and between Horizon Client and the agent in the remote
desktop.
By default, TLSv1.0, TLSv1.1, and TLSv1.2 are enabled. SSL v2.0 and 3.0 are not supported. The default
cipher control string is "!aNULL:kECDH+AESGCM:ECDH+AESGCM:RSA+AESGCM:kECDH+AES:ECDH
+AES:RSA+AES".
If you congure a security protocol for Horizon Client that is not enabled on the Horizon server to which the
client connects, a TLS/SSL error occurs and the connection fails.
For information about conguring the security protocols that are accepted by Connection Server instances,
see the View Security document.
Procedure
1 Tap the  (gear) icon in the upper-right corner of the Horizon Client window and tap Security
options.
2 Tap Advanced SSL Options.
3 Make sure that Use Default  is unchecked.
4 To enable or disable a security protocol, tap the check box next to the security protocol name.
5 To change the cipher control string, replace the default string.
6 (Optional) If you need to revert to the default seings, tap to select the Use Default  option.
7 Tap OK to save your changes.
Your changes take eect the next time you connect to the server.
Supported Desktop Operating Systems
A Horizon administrator creates virtual machines that have a guest operating system and installs agent
software in the guest operating system. End users can log in to these virtual machines from a client device.
For a list of the supported Windows guest operating systems, see the View Installation document.
Install or Upgrade Horizon Client for Chrome OS
Horizon Client for Chrome OS is a Chrome OS app, and you install it just as you do other Chrome OS apps.
Prerequisites
If you have not already set up the Chrome OS device, do so. See the manufacturer's user's guide for your
device.
VMware Horizon Client for Chrome OS Installation and Setup Guide
10 VMware, Inc.
Procedure
1 Log in to your Chromebook.
2 Download and install the Horizon Client for Chrome OS app from the Chrome Web Store.
3 To determine that the installation succeeded, verify that the Horizon Client for Chrome OS app icon
appears in the Chrome App Launcher.
Configure Decoding for VMware Blast Sessions
You can congure decoding for remote desktop and application sessions that use the VMware Blast display
protocol.
Prerequisites
This feature requires Horizon Agent 7.0 or later.
Procedure
1 Tap the  (gear) icon in the upper-right corner of the Horizon Client screen and tap VMware
Blast.
2 Select the H.264 check box to allow H.264 decoding, or deselect the H.264 check box to disable H.264
decoding.
When the check box is selected, Horizon Client uses H.264 decoding if the agent supports H.264
software encoding. If the agent does not support H.264 software encoding, Horizon Client uses
JPG/PNG decoding. When the check box is not selected, Horizon Client always use JPG/PNG decoding.
Your changes take eect the next time a user connects to a remote desktop or application and selects the
VMware Blast display protocol. Your changes do not aect existing VMware Blast sessions.
Configure the Horizon Client Default View
You can congure whether recently used desktops and applications or server shortcuts appear when you
launch Horizon Client.
Procedure
1 Tap the  (gear) icon in the upper-right corner of the Horizon Client window and tap Display.
2 Tap Default launch view.
The default view you selected takes eect immediately.
Enable the Multiple Monitor Feature for Horizon Client
With the multiple monitor feature, you can extend a remote desktop to one external monitor.
To enable the multiple monitor feature for Horizon Client, you install a helper extension and enable Unied
Desktop Mode on your Chromebook.
You must install the helper extension to make the remote desktop window display correctly on an external
monitor when the Chromebook display and the external display have dierent width-to-length ratios.
Procedure
1 Log in to your Chromebook.
2 Download and install the VMware Horizon Client Helper extension from the Chrome Web Store.
3 Open a browser window on your Chromebook and type chrome://flags in the URL bar.
Chapter 1 Setup and Installation
VMware, Inc. 11
4 Scroll down to  desktop mode and tap Enable.
5 Tap Restart Now to restart your Chromebook and make the change take eect.
What to do next
After your Chromebook restarts, you can open the Chromebook Seings and tap Display  to
congure Unied Desktop display options.
To extend a remote desktop window to the external monitor, tap the Maximize buon. You can tap the
Restore buon to make the remote desktop window go back to the Chromebook monitor.
Configuring a Default Connection Server URL
A Chrome administrator can congure a default Connection Server URL for Horizon Client on enrolled
Chromebooks. When a default Connection Server URL is congured, Horizon Client always connects to the
default server.
Requirements and Prerequisites
The default Connection Server URL feature has the following requirements and prerequisites.
nThe feature is supported only on Chromebooks that are enrolled and managed by G Suite
administration.
nA Chrome administrator must install the Horizon Client for Chrome OS app and the VMware Horizon
Client Helper extension through Chrome device management. Both the app and the extension are
available in the Chrome Web Store.
When a default Connection Server URL is set, the Horizon Client  (gear icon) is not visible before a
user logs in to a remote session and certain seings, such as VMware Blast and Unauthenticated access,
cannot be changed.
Creating a JSON Configuration File
A Chrome administrator must specify the default Connection Server URL in a JSON conguration le. For
example, the following JSON conguration le sets the default Connection Server URL to connection-
server.mycompany.com.
{
"Default Server URL":{
"Value":"connection-server.mycompany.com"
}
}
The following URL formats are supported.
Format Example
Domain name only connection-server.mycompanycom
Domain name and port connection-server.mycompany.com:443
HTTPS scheme and domain name https://connection-server.mycompany.com
HTTPS scheme, domain name, and port number https://connection-server.mycompany.com:443
VMware Horizon Client for Chrome OS Installation and Setup Guide
12 VMware, Inc.
Creating a Policy to Set the Default Connection Server URL
To set the Connection Server URL for Horizon Client users, a Chrome administrator must create a policy. To
create the policy, the Chrome administrator must sign in to the Google Admin console, select the VMware
Horizon Client Helper extension, select User , and then upload the JSON conguration le that
species the default Connection Server URL.
For detailed information about using the Google Admin console, see the G Suite Administrator Help.
Horizon Client Data Collected by VMware
If your company participates in the customer experience improvement program, VMware collects data from
certain Horizon Client elds. Fields that contain sensitive information are anonymous.
VMware collects data on client systems to prioritize hardware and software compatibility. If your company's
administrator has opted to participate in the customer experience improvement program, VMware collects
anonymous data about your deployment to respond beer to customer requirements. VMware does not
collect data that identies your organization. Horizon Client information is sent rst to the Connection
Server instance and then to VMware, with data from Connection Server, desktop pools, and remote
desktops.
The administrator who installs Connection Server can select whether to participate in the VMware customer
experience improvement program while running the Connection Server installation wizard, or an
administrator can set an option in Horizon Administrator after the installation.
Table 1‑1. Data Collected from Horizon Clients for the Customer Experience Improvement Program
Description
Is This Field
Made
Anonymous
? Example Value
Company that produced the
Horizon Client application
No VMware
Product name No VMware Horizon Client
Client product version No (The format is x.x.x-yyyyyy, where x.x.x is the client version
number and yyyyyy is the build number.)
Client binary architecture No Examples include the following:
ni386
nx86_64
narm
Client build name No Examples include the following:
nVMware-Horizon-Client-Win32-Windows
nVMware-Horizon-Client-Linux
nVMware-Horizon-Client-iOS
nVMware-Horizon-Client-Mac
nVMware-Horizon-Client-Android
nVMware-Horizon-Client-WinStore
Host operating system No Examples include the following:
nWindows 8.1
nWindows 7, 64-bit Service Pack 1 (Build 7601 )
niPhone OS 5.1.1 (9B206)
nUbuntu 12.04.4 LTS
nMac OS X 10.8.5 (12F45)
Chapter 1 Setup and Installation
VMware, Inc. 13
Table 1‑1. Data Collected from Horizon Clients for the Customer Experience Improvement Program
(Continued)
Description
Is This Field
Made
Anonymous
? Example Value
Host operating system kernel No Examples include the following:
nWindows 6.1.7601 SP1
nDarwin Kernel Version 11.0.0: Sun Apr 8 21:52:26 PDT
2012; root:xnu-1878.11.10~1/RELEASE_ARM_S5L8945X
nDarwin 11.4.2
nLinux 2.6.32-44-generic #98-Ubuntu SMP Mon Sep 24
17:27:10 UTC 2012
nunknown (for Windows Store)
Host operating system architecture No Examples include the following:
nx86_64
ni386
narmv71
nARM
Host system model No Examples include the following:
nDell Inc. OptiPlex 960
niPad3,3
nMacBookPro8,2
nDell Inc. Precision WorkStation T3400 (A04 03/21/2008)
Host system CPU No Examples include the following:
nIntel(R) Core(TM)2 Duo CPU E8400 @ 3.00GH
nIntel(R) Core(TM)2 Quad CPU Q6600 @ 2.40GH
nunknown (for iPad)
Number of cores in the host system's
processor
No For example: 4
MB of memory on the host system No Examples include the following:
n4096
nunknown (for Windows Store)
Number of USB devices connected No 2 (USB device redirection is supported only for Linux,
Windows, and Mac clients.)
Maximum concurrent USB device
connections
No 2
USB device vendor ID No Examples include the following:
nKingston
nNEC
nNokia
nWacom
USB device product ID No Examples include the following:
nDataTraveler
nGamepad
nStorage Drive
nWireless Mouse
VMware Horizon Client for Chrome OS Installation and Setup Guide
14 VMware, Inc.
Table 1‑1. Data Collected from Horizon Clients for the Customer Experience Improvement Program
(Continued)
Description
Is This Field
Made
Anonymous
? Example Value
USB device family No Examples include the following:
nSecurity
nHuman Interface Device
nImaging
USB device usage count No (Number of times the device was shared)
Chapter 1 Setup and Installation
VMware, Inc. 15
VMware Horizon Client for Chrome OS Installation and Setup Guide
16 VMware, Inc.
Managing Remote Desktop and
Application Connections 2
End users can use Horizon Client to connect to a server, edit the list of servers they connect to, log in to or
o of remote desktops, and use remote applications. For troubleshooting purposes, end users can also reset
remote desktops and applications.
Depending on how you congure policies for remote desktops, end users might be able to perform many
operations on their desktops.
This chapter includes the following topics:
n“Seing the Certicate Checking Mode in Horizon Client,” on page 17
n“Connect to a Remote Desktop or Application,” on page 18
n“Use Unauthenticated Access to Connect to Remote Applications,” on page 20
n“Manage Server Shortcuts,” on page 21
n“Select a Favorite Remote Desktop or Application,” on page 21
n“Disconnecting From a Remote Desktop or Application,” on page 22
n“Log O From a Remote Desktop,” on page 22
n“Manage Desktop and Application Shortcuts,” on page 23
Setting the Certificate Checking Mode in Horizon Client
You can determine whether client connections are rejected if any or some server certicate checks fail by
conguring a seing in Horizon Client.
Certicate checking occurs for SSL connections between the server and Horizon Client. Certicate
verication includes the following checks:
nIs the certicate intended for a purpose other than verifying the identity of the sender and encrypting
server communications? That is, is it the correct type of certicate?
nHas the certicate expired, or is it valid only in the future? That is, is the certicate valid according to
the computer clock?
nDoes the common name on the certicate match the host name of the server that sends it? A mismatch
can occur if a load balancer redirects Horizon Client to a server that has a certicate that does not match
the host name entered in Horizon Client. Another reason a mismatch can occur is if you enter an IP
address rather than a host name in the client.
VMware, Inc. 17
nIs the certicate signed by an unknown or untrusted certicate authority (CA)? Self-signed certicates
are one type of untrusted CA.
To pass this check, the certicate's chain of trust must be rooted in the device's local certicate store.
N For information about distributing a self-signed root certicate that users can install on their Chrome
OS devices, as well as instructions for installing a certicate on a Chrome OS device, see the documentation
on the Google Web site.
To set the certicate checking mode, start Horizon Client and tap the  (gear) icon in the upper-right
corner of the Horizon Client window, tap Security options, and tap Security mode. You have three choices:
nNever connect to untrusted servers. If any of the certicate checks fails, the client cannot connect to the
server. An error message lists the checks that failed.
nWarn before connecting to untrusted servers. If a certicate check fails because the server uses a self-
signed certicate, you can click Continue to ignore the warning. For self-signed certicates, the
certicate name is not required to match the server name you entered in Horizon Client.
nDo not verify server identity . This seing means that no certicate checking occurs.
If the certicate checking mode is set to Warn, you can still connect to a server that uses a self-signed
certicate.
If an administrator later installs a security certicate from a trusted certicate authority, so that all certicate
checks pass when you connect, this trusted connection is remembered for that specic server. In the future,
if that server ever presents a self-signed certicate again, the connection fails. After a particular server
presents a fully veriable certicate, it must always do so.
Connect to a Remote Desktop or Application
To connect to a remote desktop or application, you must provide the name of a server and supply
credentials for your user account.
Before you have end users access their remote desktops and applications, test that you can connect to a
remote desktop or application from a client device. You might need to specify a server and supply
credentials for your user account.
Prerequisites
nObtain login credentials, such as an Active Directory user name and password, RSA SecurID user name
and passcode, or RADIUS authentication user name and passcode.
nPerform the administrative tasks described in “Preparing Connection Server for Horizon Client,” on
page 8.
nIf you are outside the corporate network and require a VPN connection to access remote desktops and
applications, verify that the client device is set up to use a VPN connection and turn on that connection.
nVerify that you have the fully qualied domain name (FQDN) of the server that provides access to the
remote desktop or application. Underscores (_) are not supported in server names. If the port is not 443,
you also need the port number.
nIf you plan to use embedded RSA SecurID software, verify that you have the correct CT-KIP URL and
activation code. See “Using Embedded RSA SecurID Software Tokens,” on page 9.
nCongure the certicate checking mode for the SSL certicate presented by the server. See “Seing the
Certicate Checking Mode in Horizon Client,” on page 17.
Procedure
1 If a VPN connection is required, turn on the VPN.
VMware Horizon Client for Chrome OS Installation and Setup Guide
18 VMware, Inc.
2 On the Chrome OS device, tap the Chrome App Launcher icon in the taskbar and tap the Horizon
Client for Chrome OS app.
The Horizon Client window opens.
3 Connect to a server.
Option Action
Connect to a new server Enter the name of a server, enter a description (optional), and tap Connect.
Connect to a existing server Tap the server shortcut on the Servers tab.
Connections between Horizon Client and servers always use SSL. The default port for SSL connections
is 443. If the sever is not congured to use the default port, use the format shown in this example:
view.company.com:1443.
4 If you are prompted for RSA SecurID credentials or RADIUS authentication credentials, either type
your credentials or, if you plan to use an embedded RSA SecurID token, install an embedded token.
Option Action
Existing token If you use a hardware authentication token or software authentication
token on a smart phone, enter your user name and passcode. The passcode
might include both a PIN and the generated number on the token.
Install software token Tap External Token. In the Install Software Token dialog box, paste the CT-
KIP URL or CTFString URL that your administrator sent to you in email. If
the URL contains an activation code, you do not need to enter anything in
the Password or Activation Code text box.
5 If you are prompted a second time for RSA SecurID credentials or RADIUS authentication credentials,
enter the next generated number on the token.
Do not enter your PIN and do not enter the same generated number entered previously. If necessary,
wait until a new number is generated.
If this step is required, it is required only when you mistype the rst passcode or when conguration
seings in the RSA server change.
6 In the login dialog box, type your user name and password, select a domain, and tap Connect.
If the Domain drop-down menu is hidden, you must type the user name as username@domain or
domain\username.
7 (Optional) Tap the display protocol seings icon in the upper-right corner of the screen to select the
display protocol to use.
VMware Blast provides beer baery life and is the best protocol for high-end 3D and mobile device
users. The default display protocol is PCoIP.
8 Tap a remote desktop or application icon to connect to it.
After you connect to a remote desktop or application for the rst time, a shortcut for the desktop or
application is saved to the Recent tab. The next time you want to connect to the remote desktop or
application, you can tap this shortcut.
If Horizon Client cannot connect to the remote desktop, perform the following tasks:
nDetermine whether Connection Server is congured not to use SSL. Horizon Client requires SSL
connections. Check whether the global seing in Horizon Administrator for the Use SSL for client
connections check box is deselected. If so, you must either select the check box, so that SSL is used, or
set up your environment so that clients can connect to an HTTPS enabled load balancer or other
intermediate device that is congured to make an HTTP connection to Connection Server.
Chapter 2 Managing Remote Desktop and Application Connections
VMware, Inc. 19
nVerify that the security certicate for Connection Server is working properly. If it is not, in Horizon
Administrator, you might also see that the agent on desktops is unreachable.
nVerify that the tags set on the Connection Server instance allow connections from this user. See the View
Administration document.
nVerify that the user is entitled to access the desktop or application. See the Seing Up Virtual Desktops in
Horizon 7 or Seing Up Published Desktops and Applications in Horizon 7 document.
Use Unauthenticated Access to Connect to Remote Applications
A Horizon administrator can use the Unauthenticated Access feature to create Unauthenticated Access users
and entitle those users to remote applications on a Connection Server instance. Unauthenticated Access
users can log in to the server anonymously to connect to their remote applications.
Before you have end users access a remote application with the Unauthenticated User feature, test that you
can connect to the remote application from a client device. You might need to specify a server and supply
credentials for your user account.
Prerequisites
nPerform the administrative tasks described in “Preparing Connection Server for Horizon Client,” on
page 8.
nSet up Unauthenticated Access users on the Connection Server instance. For information, see
"Providing Unauthenticated Access for Published Applications" in the View Administration document.
nCongure the certicate checking mode for the SSL certicate presented by the server. See “Seing the
Certicate Checking Mode in Horizon Client,” on page 17.
nIf you are accessing remote applications outside of the corporate network, verify that your client device
is set up to use a VPN connection and turn on that connection.
Procedure
1 If a VPN connection is required, turn on the VPN.
2 On the Chrome OS device, tap the Chrome App Launcher icon in the taskbar and tap the Horizon
Client for Chrome OS app.
The Horizon Client window opens.
3 Tap the  (gear) icon in the upper-right corner of the Horizon Client window, tap
Unauthenticated access, and select the Unauthenticated access check box.
4 Connect to the server on which you have unauthenticated access to remote applications.
Option Description
Connect to a new server Enter the name of a server, enter a description (optional), and tap Connect.
Connect to an existing server Tap the server shortcut on the Servers tab.
Connections between Horizon Client and servers always use SSL. The default port for SSL connections
is 443. If the server is not congured to use the default port, use the format shown in this example:
view.company.com:1443.
5 When the login window appears, select a user account from the User account drop-down menu, if
required.
If only one user account is available, the user account is automatically selected.
VMware Horizon Client for Chrome OS Installation and Setup Guide
20 VMware, Inc.
6 (Optional) Select the Always use this account check box to bypass the login window the next time you
connect to the server.
To deselect this seing before you connect to the server the next time, touch and hold the server
shortcut until the context menu appears, tap Edit, tap Forget the saved Unauthenticated Access
account (name), and tap Done.
7 Tap Connect to log in to the server.
The application selection window appears.
8 Tap an application icon to start the application.
After you connect to a remote application for the rst time, a shortcut for the application is saved to the
Recent tab. The next time you want to connect to the application, you can tap the shortcut instead of tapping
the server icon.
Manage Server Shortcuts
After you connect to a server, Horizon Client creates a server shortcut. You can edit and remove server
shortcuts.
Horizon Client saves the server name or IP address in a shortcut, even if you mistype the server name or
type the wrong IP address. You can delete or change this information by editing the server name or IP
address. If you do not type a server description, the server name or IP address becomes the server
description.
Procedure
1 On the Servers tab, tap and hold the server shortcut until the context menu appears.
2 Use the context menu to delete the server or edit the server name, server description, or user name.
3 If you edited the server shortcut, tap Done to save your changes.
Select a Favorite Remote Desktop or Application
You can select remote desktops and applications as favorites. Favorites are identied by a star. The star helps
you quickly nd your favorite desktops and applications. Your favorite selections are saved, even after you
log o from the server.
Prerequisites
Obtain the credentials you need to connect to the server, such as a user name and password or RSA SecurID
and passcode.
Procedure
1 On the Servers tab, tap the server shortcut.
2 If prompted, supply your RSA user name and passcode, your Active Directory user name and
password, or both.
Chapter 2 Managing Remote Desktop and Application Connections
VMware, Inc. 21
3 Perform these steps to select or deselect a desktop or application as a favorite.
Option Description
Select a favorite On the All tab, tap and hold the desktop or application name until the
context menu appears and tap Mark as Favorite. A star appears in the
upper right corner of the name and the name appears on the Favorites tab.
Deselect a favorite On the All or Favorites tab, tap and hold the desktop or application name
until the context menu appears and tap Unmark Favorite. A star no longer
appears in the upper right corner of the name and the name disappears
from the Favorites tab.
4 To display only favorite desktops or applications, tap the Favorites tab.
You can tap the All tab to display all the available desktops and applications.
Disconnecting From a Remote Desktop or Application
You can disconnect from a remote desktop without logging o, so that applications remain open on the
remote desktop. You can also disconnect from a remote application so that the remote application remains
open.
When you are connected to the remote desktop or application, you can disconnect by tapping the
Disconnect icon in the Unity Touch sidebar.
N A Horizon administrator can congure a remote desktop to automatically log o when it is
disconnected. In that case, any open programs in the remote desktop are stopped.
Log Off From a Remote Desktop
You can log o from a remote desktop operating system, even if you do not have a desktop open in
Horizon Client. If you are currently connected to and logged in to a remote desktop, you can use the
Windows Start menu to log o. After Windows logs you o, the desktop is disconnected.
Prerequisites
Obtain the credentials that you use to log in, such as your Active Directory user name and password, RSA
SecurID user name and passcode, or RADIUS authentication user name and passcode.
Procedure
1 On the Servers tab, tap the server shortcut.
2 If prompted, supply your RSA user name and passcode, your Active Directory user name and
password, or both.
3 On the All tab, tap and hold the desktop shortcut until the context menu appears.
If the desktop is a favorite, you can also perform this step on the Favorites tab.
4 Tap Log  in the context menu.
Any unsaved les that are open on the remote desktop are closed during the logo operation.
What to do next
Tap the back arrow in the upper-left corner of the Horizon Client window, or the Disconnect icon in the
upper-right corner of the Horizon Client window, and tap Log Out to disconnect from the server.
VMware Horizon Client for Chrome OS Installation and Setup Guide
22 VMware, Inc.
Manage Desktop and Application Shortcuts
After you connect to a remote desktop or application, Horizon Client saves a shortcut for the recently used
desktop or application. You can rearrange and remove these shortcuts.
Procedure
nPerform these steps to remove a desktop or application shortcut from the Recent tab.
a Tap and hold the shortcut until Remove Shortcut appears at the boom of the window.
b Drag the shortcut to Remove Shortcut.
nTo move a desktop or application shortcut, drag and drop it to the new location.
Chapter 2 Managing Remote Desktop and Application Connections
VMware, Inc. 23
VMware Horizon Client for Chrome OS Installation and Setup Guide
24 VMware, Inc.
Using a Remote Desktop or
Application on a Chrome OS Device 3
Horizon Client for Chrome OS includes additional features to aid in navigation on Chrome OS devices.
Users can use external devices with remote desktops and applications and save documents in remote
applications.
This chapter includes the following topics:
n“Feature Support Matrix,” on page 25
n“Gestures,” on page 27
n“Using the Unity Touch Sidebar with a Remote Desktop,” on page 28
n“Using the Unity Touch Sidebar with a Remote Application,” on page 30
n“Using the Onscreen Keyboard,” on page 31
n“Screen Resolutions and Using External Displays,” on page 31
n“Using the Real-Time Audio-Video Feature,” on page 32
n“Saving Documents in a Remote Application,” on page 32
n“Internationalization,” on page 32
Feature Support Matrix
Some features are supported on one type of Horizon Client but not on another.
Table 3‑1. Features Supported on Windows Desktops for Chrome OS Horizon Clients
Feature
Windows
10 Desktop
Windows
8.x
Desktop
Windows 7
Desktop
Windows XP
Desktop
Windows
Vista
Desktop
Windows
Server
2008/2012 R2
or Windows
Server 2016
Desktop
RSA SecurID or
RADIUS
X X X Limited Limited X
Single sign-on X X X Limited Limited X
RDP display protocol
PCoIP display
protocol
X X X Limited Limited X
VMware Blast display
protocol
X X X X
USB redirection
VMware, Inc. 25
Table 3‑1. Features Supported on Windows Desktops for Chrome OS Horizon Clients (Continued)
Feature
Windows
10 Desktop
Windows
8.x
Desktop
Windows 7
Desktop
Windows XP
Desktop
Windows
Vista
Desktop
Windows
Server
2008/2012 R2
or Windows
Server 2016
Desktop
Client drive
redirection
Real-Time Audio-
Video
X X X X
Wyse MMR
Windows 7 MMR
Virtual printing
Location-based
printing
X X X Limited Limited X
Smart cards
Multiple monitors X X X Limited Limited X
Windows 10 desktops require View Agent 6.2 or later or Horizon Agent 7.0 or later. Windows Server 2012
R2 desktops require View Agent 6.1 or later. Windows Server 2016 desktops require Horizon Agent 7.0.2 or
later.
I View Agent 6.1 and later and Horizon Agent 7.0 and later releases do not support Windows XP
and Windows Vista desktops. View Agent 6.0.2 is the last View release that supports these guest operating
systems. Customers who have an extended support agreement with Microsoft for Windows XP and Vista,
and an extended support agreement with VMware for these guest operating systems, can deploy the View
Agent 6.0.2 version of their Windows XP and Vista desktops with Connection Server 6.1.
For descriptions of these features and their limitations, see the View Architecture Planning document.
Feature Support for Published Desktops on RDS Hosts
RDS hosts are server computers that have Windows Remote Desktop Services and View Agent or
Horizon Agent installed. Multiple users can have desktop sessions on an RDS host simultaneously. An RDS
host can be either a physical machine or a virtual machine.
N The following table contains rows only for the features that are supported. Where the text species a
minimum version of View Agent, the text "and later" is meant to include Horizon Agent 7.0.x and later.
Table 3‑2. Features Supported for RDS Hosts with View Agent 6.0.x or Later, or Horizon Agent 7.0.x or
Later, Installed
Feature
Windows Server 2008 R2
RDS Host
Windows Server 2012
RDS Host
Windows Server 2016 RDS
Host
RSA SecurID or RADIUS X X Horizon Agent 7.0.2 and later
Single sign-on X X Horizon Agent 7.0.2 and later
PCoIP display protocol X X Horizon Agent 7.0.2 and later
VMware Blast display
protocol
Horizon Agent 7.0 and later Horizon Agent 7.0 and
later
Horizon Agent 7.0.2 and later
HTML Access View Agent 6.0.2 and later
(virtual machine only)
View Agent 6.0.2 and
later (virtual machine
only)
Horizon Agent 7.0.2 and later
VMware Horizon Client for Chrome OS Installation and Setup Guide
26 VMware, Inc.
Table 3‑2. Features Supported for RDS Hosts with View Agent 6.0.x or Later, or Horizon Agent 7.0.x or
Later, Installed (Continued)
Feature
Windows Server 2008 R2
RDS Host
Windows Server 2012
RDS Host
Windows Server 2016 RDS
Host
Virtual printing (for desktop
clients)
View Agent 6.0.1 and later
(virtual machine only)
View Agent 6.0.1 and
later (virtual machine
only)
Horizon Agent 7.0.2 and later
(virtual machine only)
Location-based printing View Agent 6.0.1 and later
(virtual machine only)
View Agent 6.0.1 and
later (virtual machine
only)
Horizon Agent 7.0.2 and later
(virtual machine only)
Multiple monitors (for
desktop clients)
X X Horizon Agent 7.0.2 and later
Unity Touch (for mobile and
Chrome OS clients)
X X Horizon Agent 7.0.2 and later
Real-Time Audio-Video
(RTAV)
Horizon Agent 7.0.2 and
later
Horizon Agent 7.0.2 and
later
Horizon Agent 7.0.3 and later
For information about which editions of each guest operating system are supported, see the View Installation
document.
For information about Real-Time Audio Video (RTAV) requirements, see “System Requirements for Real-
Time Audio-Video,” on page 8.
Gestures
VMware has created user interaction aids to help you navigate conventional Windows user interface
elements on a non-Windows device.
Clicking
As in other apps, you can tap your touchpad to click a user interface element. If the Chrome OS device has a
touch screen, you can touch to click a user interface element. You can also use an external mouse.
Right-Clicking
The following options are available for right-clicking:
nTap with two ngers on the touchpad.
nHold down the Alt key on the keyboard and tap the touchpad with a single nger.
nUse an external mouse to right-click.
nIf the Chrome OS device has a touch screen, tap with two ngers at nearly the same time. The right-
click occurs where the rst nger tapped.
Scrolling and Scrollbars
The following options are available for vertical scrolling.
nTap and hold with your thumb and then scroll down with one nger on the touchpad. You can also
scroll with two ngers.
nUse an external mouse to scroll.
nIf the Chrome OS device has a touch screen, tap with one or two ngers and then drag to scroll. The text
under your ngers moves in the same direction as your ngers. Scrolling with one nger does not work
if you have zoomed in or when the onscreen keyboard is displayed.
Chapter 3 Using a Remote Desktop or Application on a Chrome OS Device
VMware, Inc. 27
Zooming In and Out
As in other apps, use the keyboard and press Ctrl and + to zoom in and Ctrl and - to zoom out. If the
Chrome OS device has a touch screen, you can pinch your ngers apart to zoom out and pinch your ngers
together to zoom in.
Window Resizing
To use the touchpad to resize a window, touch and hold one nger at the corner or side of the window and
drag to resize. If the Chrome OS device has an external mouse, place your cursor on the edge of the window
and drag the border of the window to make it wider or narrower. You cannot resize the window if it is
maximized.
Sound, Music, and Video
If sound is turned on for your device, you can play audio in a remote desktop.
Using the Unity Touch Sidebar with a Remote Desktop
You can quickly navigate to a remote desktop application or le from a Unity Touch sidebar. From this
sidebar, you can open les and applications, switch between running applications, and minimize, maximize,
restore, or close windows and applications in a remote desktop.
The Unity Touch feature is available only if a Horizon administrator has enabled it. If users have a oating
desktop, users’ favorite applications and les can be saved only if Windows roaming user proles are
congured for the remote desktop. A Horizon administrator can also create a default Favorite Applications
list that end users see the rst time the sidebar appears. For more information, see "Conguring Unity
Touch" in the Conguring Remote Desktop Features in Horizon 7 document.
If the Unity Touch feature is enabled, the sidebar appears on the left side of the window when you rst
access a remote desktop.
Figure 3‑1. Unity Touch Sidebar for a Remote Desktop
From this sidebar, you can perform many actions on a le or application.
Table 3‑3. Unity Touch Sidebar Actions for a Remote Desktop
Action Procedure
Show or hide the onscreen
keyboard
Tap the Keyboard icon.
Change Horizon Client seings Tap the  icon.
Disconnect from the desktop Tap the Disconnect icon.
Show the sidebar Drag the sidebar to the right or tap the sidebar tab.
VMware Horizon Client for Chrome OS Installation and Setup Guide
28 VMware, Inc.
Table 3‑3. Unity Touch Sidebar Actions for a Remote Desktop (Continued)
Action Procedure
Hide the sidebar Drag the sidebar to the left or tap in the desktop area.
Navigate to an application Tap All Programs and navigate to the application just as you would from the Windows
Start menu.
Navigate to a le Tap My Files to access the User folder, and navigate to the le. My Files includes
folders such as My Pictures, My Documents, and Downloads.
My Files includes the folders in the user prole (%USERPROFILE% directory). If you
relocate the system folder in the %USERPROFILE% directory, the My Files menu can
also display content from the relocated folder, whether it is a local relocated folder or a
network share folder.
Search for an application or le nTap in the Search box and type the name of the application or le.
nTo use voice dictation, tap the microphone on the keyboard.
nTo launch an application or le, tap the name of the application or le in the search
results.
nTo return to the home view of the sidebar, tap the X to close the Search box.
Open an application or le Tap the name of the le or application in the sidebar. The application starts and the
sidebar closes.
Switch between running
applications or open windows
Tap the application name under Running Applications. If more than one le is open
for one application, tap the chevron (>) next to the application to expand the list.
Minimize a running application
or window
Tap and hold the application name under Running Applications until the context
menu appears. Tap Minimize.
Maximize a running
application or window
Tap and hold the application name under Running Applications until the context
menu appears. Tap Maximize.
Close a running application or
window
Tap and hold the application name under Running Applications until the context
menu appears. Tap Close.
Restore a running application
or window to its previous size
and position
Tap and hold the application name under Running Applications until the context
menu appears. Tap Restore.
Create a list of favorite
applications or les
1 Search for the application or le, or tap Manage under the Favorite Applications
or Favorite Documents list.
If the Manage bar is not visible, tap the chevron (>) next to Favorite Applications
or Favorite Files.
2 Tap the check box next to the names of your favorites in the search results or in the
list of available applications or les.
The favorite that you add last appears at the top of your favorites list.
Remove an application or le
from the favorites list
1 Search for the application or le, or tap Manage under the Favorite Applications
or Favorite Dcuments list.
If the Manage bar is not visible, tap the chevron (>) next to Favorite Applications
or Favorite Documents.
2 Tap to remove the check mark next to the name of the application or le in the
favorites list.
Reorder an application or le in
the favorites list
1 Tap Manage under the Favorite Applications or Favorite Documents list.
If the Manage bar is not visible, tap the chevron (>) next to Favorite Applications
or Favorite Documents.
2 In the favorites list, touch and hold the handle on the left side of the application or
le name and drag the favorite up or down the list.
Chapter 3 Using a Remote Desktop or Application on a Chrome OS Device
VMware, Inc. 29
Using the Unity Touch Sidebar with a Remote Application
You can quickly navigate to a remote application from a Unity Touch sidebar. From this sidebar, you can
launch applications, switch between running applications, and minimize, maximize, restore, or close remote
applications. You can also switch to a remote desktop.
The Unity Touch feature is available only if a Horizon administrator has enabled it.
Figure 3‑2. Unity Touch Sidebar for a Remote Application
From the Unity Touch sidebar, you can perform many actions on a remote application.
Table 3‑4. Unity Touch Sidebar Actions for a Remote Application
Action Procedure
Show or hide the onscreen
keyboard
Tap the Keyboard icon.
Modify Horizon Client seings Tap the  icon.
Disconnect from the application Tap the Disconnect icon.
Show the sidebar Drag the sidebar to the right or tap the sidebar tab. When the sidebar is open, you
cannot perform actions on the application window.
Hide the sidebar Drag the sidebar to the left or tap in the application area. When the sidebar is open,
you cannot perform actions on the application window.
Switch between running
applications
Tap the application under Current Connection.
Open an application Tap the name of the application under Applications in the sidebar. The application
starts and the sidebar closes.
Close a running application 1 Tap and hold the application name under Current Connection until the context
menu appears.
2 Tap Close.
Minimize a running application 1 Tap and hold the application name under Current Connection until the context
menu appears.
2 Tap Minimize.
Maximize a running application 1 Tap and hold the application name under Current Connection until the context
menu appears.
2 Tap Maximize.
VMware Horizon Client for Chrome OS Installation and Setup Guide
30 VMware, Inc.
Table 3‑4. Unity Touch Sidebar Actions for a Remote Application (Continued)
Action Procedure
Restore a running application 1 Tap and hold the application name under Current Connection until the context
menu appears.
2 Tap Restore.
Switch to a remote desktop Tap the desktop name under Desktops.
Using the Onscreen Keyboard
You can use an onscreen keyboard in a remote desktop or application. To display the onscreen keyboard, tap
the Keyboard icon in the Unity Touch sidebar. To hide the onscreen keyboard, tap the Keyboard icon again.
The onscreen keyboard includes the PageUp and PageDn navigation keys, function keys, and other keys
that you often use in Windows environments, including Ctrl, Alt, Del, Shift, Win, Caps, Esc, and Del. Use
the Shift key on this keypad when you need to use key combinations that include the Shift key, such as Ctrl
+Shift. To tap a combination of these keys, such as Ctrl+Alt+Shift, rst tap the onscreen Ctrl key. After the
Ctrl key turns blue, tap the onscreen Alt key. After the Alt key turns blue, tap the onscreen Shift key. A
single onscreen key is provided for the key combination Ctrl+Alt+Del.
You can tap the pen icon on the left side of the Ctrl key to display the local input buer. Text that you type
into this text box is not sent to an application until you tap Send. For example, if you open an application
such as Notepad and tap the pen icon, the text that you type does not appear in the Notepad application
until you tap Send. This feature is useful if you have a poor network connection and characters do not
immediately appear when you type them. With this feature, you can quickly type up to 1,000 characters and
then either tap Send or Return to have all 1,000 characters appear at once in the application.
Screen Resolutions and Using External Displays
You can use Horizon Client with external displays and you can change screen resolutions.
When you connect a Chrome OS device to an external display or projector, you can display Horizon Client
in full-screen mode by pressing the full screen key on the device's keyboard.
Enlarging the Screen Resolution for a Remote Desktop
By default, the display resolution is set so that the entire Windows desktop ts inside the client device, and
the desktop icons and task bar icons are a certain size. If you change the default to a higher resolution, the
desktop still ts inside the client device, but the desktop and taskbar icons become smaller.
Changing the Display Resolution Setting
To change the resolution seing, tap the  (gear) icon in the upper-right corner of the Horizon Client
window, tap Display, and tap Resolution.
Using Projectors
You can use the Resolution seing to set a larger resolution for projectors.
Using the Multiple Monitor Feature
With the multiple monitor feature, you can extend a remote desktop to one external monitor. To enable the
multiple monitor feature, see “Enable the Multiple Monitor Feature for Horizon Client,” on page 11.
Chapter 3 Using a Remote Desktop or Application on a Chrome OS Device
VMware, Inc. 31
Using the Real-Time Audio-Video Feature
With the Real-Time Audio-Video feature, you can use the client device's built-in cameras and microphones
in a remote desktop. Real-Time Audio-Video is compatible with standard conferencing applications such as
Skype, WebEx, and Google Hangouts.
Real-Time Audio-Video is enabled by default when you install Horizon Client on the client device.
For information about seing up the Real-Time Audio-Video feature on a remote desktop, see the
Conguring Remote Desktop Features in Horizon 7 document.
If the camera is currently being used by another app, it cannot be used by the remote desktop
simultaneously. Also, if the camera is being used by the remote desktop, it cannot be used by the client
device at the same time.
If the client device has both a front and a back camera, you can select which camera to use in the remote
desktop. In the Unity Touch sidebar, tap the  (gear) icon, tap Camera, tap Select a camera, and tap
the camera to use. The Camera seing is available only when the camera is started.
Saving Documents in a Remote Application
With certain remote applications, such as Microsoft Word or WordPad, you can create and save documents.
Where these documents are saved depends on your company's network environment. For example, your
documents might be saved to a home share mounted on your local computer.
A Horizon administrator can use the RDS Proles group policy seing called Set Remote Desktop Services
User Home Directory to specify where documents are saved. For more information, see the Conguring
Remote Desktop Features in Horizon 7 document.
Internationalization
Both the user interface and the documentation are available in English, Japanese, French, German,
Simplied Chinese, Traditional Chinese, Korean, and Spanish. You can also input characters for these
languages.
VMware Horizon Client for Chrome OS Installation and Setup Guide
32 VMware, Inc.
Troubleshooting Horizon Client 4
You can solve most Horizon Client problems by reseing the desktop or reinstalling the app.
This chapter includes the following topics:
n“Restart a Remote Desktop,” on page 33
n“Reset a Remote Desktop or Remote Applications,” on page 34
n“Uninstall Horizon Client,” on page 34
n“Horizon Client Stops Responding or the Remote Desktop Freezes,” on page 35
n“Problem Establishing a Connection When Using a Proxy,” on page 35
Restart a Remote Desktop
You might need to restart a remote desktop if the desktop operating system stops responding. Restarting a
remote desktop is the equivalent of the Windows operating system restart command. The desktop operating
system usually prompts you to save any unsaved data before it restarts.
You can restart a remote desktop only if a Horizon administrator has enabled the desktop restart feature for
the desktop.
For information about enabling the desktop restart feature, see the Seing Up Virtual Desktops in Horizon 7 or
Seing Up Published Desktops and Applications in Horizon 7 document.
Prerequisites
nObtain login credentials, such as an Active Directory user name and password, RSA SecurID user name
and passcode, or RADIUS authentication user name and passcode.
nIf you have not logged in at least once, become familiar with the procedure “Connect to a Remote
Desktop or Application,” on page 18.
Procedure
1 On the Servers tab, tap the server shortcut to connect to the server.
2 If prompted, supply your RSA user name and passcode, your Active Directory user name and
password, or both.
3 Touch and hold the desktop name until the context menu appears.
You can perform this step from either the All or Favorites tab.
4 Tap Restart in the context menu.
Restart is available only if the status of the desktop is such that the action can be taken.
VMware, Inc. 33
The operating system in the remote desktop reboots and Horizon Client disconnects and logs o from the
desktop.
What to do next
Wait an appropriate amount of time for system startup before you aempt to reconnect to the remote
desktop.
If restarting the remote desktop does not solve the problem, you might need to reset the remote desktop. See
“Reset a Remote Desktop or Remote Applications,” on page 34.
Reset a Remote Desktop or Remote Applications
You might need to reset a remote desktop if the desktop operating system stops responding and restarting
the remote desktop does not solve the problem. Reseing remote applications quits all open applications.
Reseing a remote desktop is the equivalent of pressing the Reset buon on a physical PC to force the PC to
restart. Any les that are open on the remote desktop are closed and are not saved.
Reseing remote applications is the equivalent of quiing the applications without saving any unsaved
data. All open remote applications are closed, even applications that come from dierent RDS server farms.
You can reset a remote desktop only if a Horizon administrator has enabled the desktop reset feature for the
desktop.
For information about enabling the desktop reset feature, see the Seing Up Virtual Desktops in Horizon 7 or
Seing Up Published Desktops and Applications in Horizon 7 document.
Prerequisites
nObtain login credentials, such as an Active Directory user name and password, RSA SecurID user name
and passcode, or RADIUS authentication user name and passcode.
nIf you have not logged in at least once, become familiar with the procedure “Connect to a Remote
Desktop or Application,” on page 18.
Procedure
1 On the Servers tab, tap the server shortcut to connect to the server.
2 If prompted, supply your RSA user name and passcode, your Active Directory user name and
password, or both.
3 Touch and hold the desktop or application name until the context menu appears.
You can perform this step from either the All or Favorites tab.
4 Tap Reset in the context menu.
Reset is available only if the status of the desktop or application is such that the action can be taken.
When you reset a remote desktop, the operating system in the remote desktop reboots and Horizon Client
disconnects and logs o from the desktop. When you reset remote applications, the applications quit.
What to do next
Wait an appropriate amount of time for system startup before aempting to reconnect to the remote desktop
or application.
Uninstall Horizon Client
You can sometimes resolve problems with Horizon Client by uninstalling and reinstalling Horizon Client
for Chrome OS.
You uninstall Horizon Client for Chrome OS just as you would any Chrome OS app.
VMware Horizon Client for Chrome OS Installation and Setup Guide
34 VMware, Inc.
Procedure
uOn your Chrome OS device, tap the App Launcher icon in the taskbar, right-click the Horizon Client
for Chrome OS app icon, and select Uninstall.
What to do next
Reinstall Horizon Client.
See “Install or Upgrade Horizon Client for Chrome OS,” on page 10.
Horizon Client Stops Responding or the Remote Desktop Freezes
When the window freezes, rst, try reseing the remote desktop operating system.
Problem
Horizon Client does not work or repeatedly exits unexpectedly or the remote desktop freezes.
Cause
Assuming that Horizon servers are congured properly and that rewalls surrounding them have the
correct ports open, other issues usually relate to Horizon Client on the device or to the guest operating
system on the remote desktop.
Solution
nIf the operating system in the remote desktop freezes, use Horizon Client on the device to reset the
desktop.
This option is available only if the Horizon administrator has enabled this feature.
nUninstall and reinstall the app on the device.
nIf reseing the remote desktop and reinstalling Horizon Client do not help, you can reset the Chrome
OS device, as described in the device user guide.
nIf you get a connection error when you aempt to connect to the server, you might need to change your
proxy seings.
Problem Establishing a Connection When Using a Proxy
Sometimes if you aempt to connect to Connection Server using a proxy while on the LAN, an error occurs.
Problem
If the Horizon environment is set up to use a secure connection from the remote desktop to Connection
Server, and if the client device is congured to use an HTTP proxy, you might not be able to connect.
Cause
Unlike Windows Internet Explorer, the client device does not have an Internet option to bypass the proxy
for local addresses. When an HTTP proxy is used for browsing external addresses, and you try to connect to
Connection Server using an internal address, you might see the error message Could not establish
connection.
Solution
uRemove the proxy seings so that the device no longer uses a proxy.
Chapter 4 Troubleshooting Horizon Client
VMware, Inc. 35
VMware Horizon Client for Chrome OS Installation and Setup Guide
36 VMware, Inc.
Index
A
Add Server button 18
agent, installation requirements 10
audience 5
C
certificates, ignoring problems 17
Chrome Web Store 10
Connection Server 8
connection problems 35
customer experience program, desktop pool
data 13
D
default server 12
default view 11
deleting server icons 18
disconnecting from a remote desktop 22
display requirements 31
displays, external 31
E
external displays 31
F
favorites 21
favorites list in Unity Touch sidebar 28
feature support matrix 25
H
H.264 decoding 11
hardware requirements 7
Horizon Client
disconnect from a desktop 22
setup for Chrome OS clients 7
starting 18
troubleshooting 35
Horizon Client for Chrome, installing 10
I
internationalization 32
K
keyboard, onscreen 27
L
log off 22
logging in 18
M
manage desktop shortcuts 23
managing desktops 17
multiple monitors 11
O
onscreen keyboard 31
operating systems, supported on the agent 10
P
prerequisites for client devices 8
projectors 31
proxy connections 35
R
Real-Time Audio-Video feature 8
remote desktops 25
reset a desktop 34
resizing windows 27
resolution, screen 31
restart desktop 33
RSA SecurID tokens 9
RTAV 32
S
saving documents in a remote application 32
screen resolution 31
scrolling 27
security servers 8
server connections, managing 17
server icons 18
server names 18
shortcut, desktops 23
sidebar, Unity Touch 28
software tokens 9
SSL options 10
system requirements 7
T
tablet gestures 27
tokens, RSA SecurID 9
VMware, Inc. 37
troubleshooting, connection problems 35
U
Unauthenticated Access 20
uninstalling the client software 34
Unity Touch feature 28
Unity Touch sidebar 30
VMware Horizon Client for Chrome OS Installation and Setup Guide
38 VMware, Inc.

Navigation menu
