arm2hpdl(1) General Commands Manual arm2hpdl(1)
NAME
arm2hpdl − Add HP download header/trailer to an ARM ELF binary.
SYNOPSIS
arm2hpdl [options]arm-binary.img > hpdl.dl
DESCRIPTION
arm2hpdl adds an HP download header/trailer to an ARM ELF binary.Ifthe file already has an HP
header,just copyittostdout.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−D level
Set Debug level[0].
EXAMPLES
Add an HPDL header to a HP LaserJet 1005.
$arm2hpdl sihp1005.img > sihp1005.dl
FILES
/usr/bin/arm2hpdl, /lib/firmware/hp/*
SEE ALSO
foo2zjs(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
arm2hpdl 0.0 Thu Apr 07 11:47:50 2016 1
foo2hbpl2-wrapper(1) General Commands Manual foo2hbpl2-wrapper(1)
NAME
foo2hbpl2-wrapper − Convert Postscript into a ZJS printer stream
SYNOPSIS
foo2hbpl2-wrapper [options][ps-file]
DESCRIPTION
foo2hbpl2-wrapper is a Foomatic compatible printer wrapper for the foo2hbpl2 printer driver. This script
reads a Postscript ps-file or standard input and converts it to Zenographics ZjStream printer format for driv-
ing the Dell 1355, Dell C1765, Epson AcuLaser M1400, Epson AcuLaser CX17NF,Fuji Xerox DocuPrint
CM205, Fuji Xerox DocuPrint CM215, Fuji Xerox DocuPrint P205, Xerox WorkCentre 3045 MFP,and
Xerox WorkCentre 6015 MFP printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Print in color (else monochrome).
−C colormode
Color correction mode [0].
10 ICM color profile (using −G *.icm file)
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [1].
Media HBPL
plain 1
bond 2
lwcard 3
lwgcard 4
labels 5
envelope 6
recycled 7
plain2 8
bond2 9
lwcard2 10
lwgcard2 11
recycled2 12
−p paper
Paper size code to send to printer [1].
Paper HBPL
A4 1
B5jis 2
A5 3
foo2hbpl2-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2hbpl2-wrapper(1) General Commands Manual foo2hbpl2-wrapper(1)
letter 4
executive 5
fanfold german legal6
folio 6
legal7
env#10 9
envMonarch 10
envC5 11
envDL 12
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [7].
1upper 4 manual
2lower 7 auto
−t Draft mode. Every other pixel is white.
−T density
Print density (1-5). The default is 3 (medium).
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2hbpl2 for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the ZjStream. foo2hbpl2-wrapper always runs
Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regardless
whether or not the printer has unprintable regions. This option is used to move the position of the
clipped image back to where it belongs on the page. The default is to send the amount which was
clipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
foo2hbpl2-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2hbpl2-wrapper(1) General Commands Manual foo2hbpl2-wrapper(1)
−P Do not send START_PLANE codes on monochrome output. May be needed by some mono-
chrome-only printers, such as the HP LaserJet 1000.
−X padlen
Add extra zero padding to the end of BID segments. The default is 16 bytes. Padding 16 bytes of
zeroes is needed for older ZjStream printers, such as the Minolta 2200DL and HP LaserJet 1000,
and seems harmless to newer ones, such as the Minolta 2300DL. So the default should be good
for all cases.
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2hbpl2 and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome ZjStream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2hbpl2-wrapper testpage.ps > testpage.prn
hbpl2decode < testpage.prn
lpr −P rawtestpage.prn
Create a color ZjStream stream from a Postscript document:
foo2hbpl2-wrapper −c testpage.ps > testpage.prn
foo2hbpl2-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2hbpl2-wrapper(1) General Commands Manual foo2hbpl2-wrapper(1)
FILES
/usr/bin/foo2hbpl2-wrapper
SEE ALSO
foo2hbpl2(1), hbpldecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2hbpl.rkkda.com/
foo2hbpl2-wrapper 0.0 Thu Apr 07 11:47:50 2016 4
foo2hbpl2(1) General Commands Manual foo2hbpl2(1)
NAME
foo2hbpl2 − Convert Ghostscript pbmraworbitcmyk format into a ZJS printer stream
SYNOPSIS
foo2hbpl2 [options]<pbmraw-file >hbpl2-file
foo2hbpl2 [options]<bitcmyk-file >hbpl2-file
foo2hbpl2 [options]<pksmraw-file >hbpl2-file
DESCRIPTION
foo2hbpl2 converts Ghostscript pbmraw, bitcmyk, or pksmrawoutput formats to monochrome or color
HBPL version 2 streams, for driving the Dell 1355, Dell C1765, Epson AcuLaser M1400, Epson AcuLaser
CX17NF,Fuji Xerox DocuPrint CM205, Fuji Xerox DocuPrint CM215, Fuji Xerox DocuPrint M215, Fuji
Xerox DocuPrint P205, Xerox WorkCentre 3045 MFP,and Xerox WorkCentre 6015 MFP printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [1].
Media HBPL
plain 1
bond 2
lwcard 3
lwgcard 4
labels 5
envelope 6
recycled 7
plain2 8
bond2 9
lwcard2 10
lwgcard2 11
recycled2 12
−p paper
Paper code to send to printer [1].
Paper HBPL
A4 1
B5jis 2
A5 3
letter 4
foo2hbpl2 0.0 Thu Apr 07 11:47:50 2016 1
foo2hbpl2(1) General Commands Manual foo2hbpl2(1)
executive 5
fanfold german legal6
folio 6
legal7
env#10 9
envMonarch 10
envC5 11
envDL 12
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (InputSlot) code to send to printer [7].
1upper 4 manual
2lower 7 auto
−t Draft mode. Every other pixel is white.
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2hbpl2 for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the ZjStream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−P Do not send START_PLANE codes on monochrome output. May be needed by some black and
white only printers, such as the HP LaserJet 1000.
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−X padlen
Add extra zero padding to the end of BID segments. The default is 16 bytes. Padding 16 bytes of
zeroes is needed for older ZjStream printers, such as the Minolta 2200DL and HP LaserJet 1000,
and seems harmless to newer ones, such as the Minolta 2300DL. So the default should be good
for all cases.
Debugging Options
These options are used for debugging foo2hbpl2.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
foo2hbpl2 0.0 Thu Apr 07 11:47:50 2016 2
foo2hbpl2(1) General Commands Manual foo2hbpl2(1)
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white ZJS stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r1200x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2hbpl2 −r1200x600 −g10200x6600 −p1 >testpage.zm
Create a color ZJS stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g10200x6600 −r1200x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2hbpl2 −r1200x600 −g10200x6600 −p1 >testpage.zc
FILES
/usr/bin/foo2hbpl2
SEE ALSO
foo2hbpl2-wrapper(1), hbpldecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
Peter Korf <peter@niendo.de>
http://foo2hbpl.rkkda.com/
foo2hbpl2 0.0 Thu Apr 07 11:47:50 2016 3
foo2hiperc-wrapper(1) General Commands Manual foo2hiperc-wrapper(1)
NAME
foo2hiperc-wrapper − Convert Postscript into a HIPERC printer stream
SYNOPSIS
foo2hiperc-wrapper [options][ps-file]
DESCRIPTION
foo2hiperc-wrapper is a Foomatic compatible printer wrapper for the foo2hiperc printer driver. This
script reads a Postscript ps-file or standard input and converts it to the Oki HIPERC printer format for driv-
ing the Oki C310dn, C3100, C3200, C3300n, C3400n, C5100n, C5500n, C5600n and the C5800n HIPERC
printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Print in color (else monochrome).
−C colormode
Color correction mode [0].
10 ICM color profile (using −G *.icm file)
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [0].
Media HIPERC
plain 0
labels 1
transparency2
−p paper
Paper size code to send to printer [2].
1A42letter
3leg al−−
5A56B5jis
7A68envMonarch
9env DL10env C5
11 env#10 12 executive
13 env#914leg al13.5"
15 A3 16 tabloid/ledger
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [600x600].
foo2hiperc-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2hiperc-wrapper(1) General Commands Manual foo2hiperc-wrapper(1)
−s source
Source (Input Slot) code to send to printer [0].
0auto select
1tray1 2 tray2
3multi 4 manual
−t Draft mode. Every other pixel is white.
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2hiperc for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size].
−L mask
Send the logical clipping values from −u/-l in the HIPERC stream. foo2hiperc-wrapper always
runs Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regard-
less whether or not the printer has unprintable regions. This option is used to move the position of
the clipped image back to where it belongs on the page. The default is to send the amount which
wasclipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−z model
Model is 0 for non-A3 sized printers, and 1 for A3/Tabloid/Ledger sized printers (i.e. C810, etc.).
The default is 0.
−Z compressed
Use uncompressed (0) or compressed (1) JBIG data.
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
foo2hiperc-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2hiperc-wrapper(1) General Commands Manual foo2hiperc-wrapper(1)
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2hiperc and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome HIPERC stream from a Postscript document, examine it, and then print it using nc(1)
or netcat(1):
foo2hiperc-wrapper testpage.ps > testpage.hc
hipercdecode < testpage.hc
nc 192.168.1.NNN 9100 < testpage.hc
Create a color HIPERC stream from a Postscript document:
foo2hiperc-wrapper −c testpage.ps > testpage.hc
FILES
/usr/bin/foo2hiperc-wrapper
SEE ALSO
foo2hiperc(1), hipercdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2hiperc.rkkda.com/
foo2hiperc-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2hiperc(1) General Commands Manual foo2hiperc(1)
NAME
foo2hiperc − Convert Ghostscript pbmraworbitcmyk format into a HIPERC printer stream
SYNOPSIS
foo2hiperc [options]<pbmraw−file >hiperc−file
foo2hiperc [options]<bitcmyk−file >hiperc−file
foo2hiperc [options]<pksmraw−file >hiperc−file
DESCRIPTION
foo2hiperc converts Ghostscript pbmraw, bitcmyk, or pksmrawoutput formats to monochrome or color
HIPERC streams, for driving the Oki C310dn, C3100, C3200, C3300n, C3400n, C5100n, C5500n, C5600n,
and the C5800n HIPERC printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [5100x6600].
−m media
Media code to send to printer [0].
Media HIPERC
plain 0
labels 1
transparency2
−p paper
Paper code to send to printer [2].
1A42letter
3leg al−−
5A56B5jis
7A68envMonarch
9env DL10env C5
11 env#10 12 executive
13 env#914leg al13.5"
15 A3 16 tabloid/ledger
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [600x600].
−s source
Source (InputSlot) code to send to printer [0].
foo2hiperc 0.0 Thu Apr 07 11:47:50 2016 1
foo2hiperc(1) General Commands Manual foo2hiperc(1)
0auto select
1tray1 2 tray2
3multi 4 manual
−t Draft mode. Every other pixel is white.
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2hiperc for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the HIPERC stream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−Z compressed
Use uncompressed (0) or compressed (1) JBIG data.
Debugging Options
These options are used for debugging foo2hiperc.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white HIPERC stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r600x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2hiperc −r600x600 −g5100x6600 −p0 >testpage.zm
Create a color HIPERC stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g5100x6600 −r600x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
foo2hiperc 0.0 Thu Apr 07 11:47:50 2016 2
foo2hiperc(1) General Commands Manual foo2hiperc(1)
|foo2hiperc −r600x600 −g5100x6600 −p0 >testpage.zc
FILES
/usr/bin/foo2hiperc
SEE ALSO
foo2hiperc-wrapper(1), hipercdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.com>
http://foo2hiperc.rkkda.com/
foo2hiperc 0.0 Thu Apr 07 11:47:50 2016 3
foo2hp(1) General Commands Manual foo2hp(1)
NAME
foo2hp − Convert Ghostscript pbmraworbitcmyk format into a ZJS printer stream
SYNOPSIS
foo2hp [options]<pbmraw-file >zjs-file
foo2hp [options]<bitcmyk-file >zjs-file
foo2hp [options]<cups-file >zjs-file
DESCRIPTION
foo2hp converts Ghostscript pbmraw, bitcmyk, or cups output formats to monochrome or color ZJS
streams, for driving the Hewlett-Packard 2600n color laser printer and other Zenographics-based printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−b bits Bits per plane if autodetect doesn’twork (1 or 2) [1].
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [1].
Media HPLJ 2600n
plain 1
preprinted 514
letterhead 513
transparency2
prepunched 515
labels 265
bond 260
recycled 516
color 512
tough 276
envelope 267
light 258
heavy 262
cardstock 261
lightglossy 268
glossy 269
heavyglossy 270
cover277
photo 278
foo2hp 0.0 Thu Apr 07 11:47:50 2016 1
foo2hp(1) General Commands Manual foo2hp(1)
−p paper
Paper code to send to printer [1].
1letter 9 A4
5leg al11A5
7executive 13B5jis
20 env#10 27 envDL
28 envC534env B5
37 envMonarch
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [600x600].
−s source
Source (InputSlot) code to send to printer [7].
1tray 2 7auto
2tray 1
−t Draft mode. Every other pixel is white.
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2hp for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the ZjStream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−O c,m,y,k
Alignment of CMYK in rows. The default is 0,0,0,0.
−P Do not send START_PLANE codes on monochrome output. May be needed by some black and
white only printers, such as the HP LaserJet 1000.
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−X padlen
Add extra zero padding to the end of BID segments. The default is 16 bytes.
Debugging Options
These options are used for debugging foo2hp.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
foo2hp 0.0 Thu Apr 07 11:47:50 2016 2
foo2hp(1) General Commands Manual foo2hp(1)
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white ZJS stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r600x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2hp −r600x600 −g5100x6600 −p1 >testpage.zm
Create a color ZJS stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g5100x6600 −r600x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2hp −r600x600 −g5100x6600 −p1 >testpage.zc
FILES
/usr/bin/foo2hp
SEE ALSO
foo2hp2600-wrapper(1), zjsdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2hp.rkkda.com/
foo2hp 0.0 Thu Apr 07 11:47:50 2016 3
foo2hp2600-wrapper(1) General Commands Manual foo2hp2600-wrapper(1)
NAME
foo2hp2600-wrapper − Convert Postscript into a ZJS printer stream
SYNOPSIS
foo2hp2600-wrapper [options][ps-file]
DESCRIPTION
foo2hp2600-wrapper is a Foomatic compatible printer wrapper for the foo2hp printer driver. This script
reads a Postscript ps-file or standard input and converts it to Zenographics ZjStream printer format for driv-
ing the Hewlett-Packard 2600n color laser printer and other Zenographics-based printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−b bits Number of bits per plane. 1 or 2. [1].
−c Print in color (else monochrome).
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [1].
Media HPLJ 2600n
plain 1
preprinted 514
letterhead 513
transparency2
prepunched 515
labels 265
bond 260
recycled 516
color 512
tough 276
envelope 267
light 258
heavy 262
cardstock 261
lightglossy 268
glossy 269
heavyglossy 270
cover277
photo 278
−p paper
Paper size code to send to printer [1].
foo2hp2600-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2hp2600-wrapper(1) General Commands Manual foo2hp2600-wrapper(1)
1letter 9 A4
5leg al11A5
7executive 13B5jis
20 env#10 27 envDL
28 envC534env B5
37 envMonarch
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [7].
1tray 2 4manual/tray 1
2tray 3 7auto
−t Draft mode. Every other pixel is white.
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2hp for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the ZjStream. foo2hp2600-wrapper always runs
Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regardless
whether or not the printer has unprintable regions. This option is used to move the position of the
clipped image back to where it belongs on the page. The default is to send the amount which was
clipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−O parm=val
Alignment of CMYK. parm is c, m, y,ork.val is in rows. Multiple options are allowed. The
default is "−Oc=0 −Om=0 −Oy=0 −Ok=0".
−P Do not send START_PLANE codes on monochrome output. May be needed by some mono-
chrome-only printers, such as the HP LaserJet 1000.
foo2hp2600-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2hp2600-wrapper(1) General Commands Manual foo2hp2600-wrapper(1)
−X padlen
Add extra zero padding to the end of BID segments. The default is 16 bytes. Padding 16 bytes of
zeroes is needed for older ZjStream printers, such as the Minolta 2200DL and HP LaserJet 1000,
and seems harmless to newer ones, such as the Minolta 2300DL. So the default should be good
for all cases.
−z model
Model: Model: 0=HP CLJ 1600/2600n; 1=HP CLJ CP1215
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.Ifprofile.icm is
none.icm, then prepare for ordering a ICM custom printer profile (i.e. from www.ICCFac-
tory.com).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2hp and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome ZjStream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2hp2600-wrapper testpage.ps > testpage.zm
zjsdecode < testpage.zm
lpr −P rawtestpage.zm
Create a color ZjStream stream from a Postscript document:
foo2hp2600-wrapper −c testpage.ps > testpage.zc
foo2hp2600-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2hp2600-wrapper(1) General Commands Manual foo2hp2600-wrapper(1)
FILES
/usr/bin/foo2hp2600-wrapper
SEE ALSO
foo2hp(1), zjsdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2hp.rkkda.com/
foo2hp2600-wrapper 0.0 Thu Apr 07 11:47:50 2016 4
foo2lava-wrapper(1) General Commands Manual foo2lava-wrapper(1)
NAME
foo2lava-wrapper − Convert Postscript into a LAVA FLOWorOPL printer stream
SYNOPSIS
foo2lava-wrapper [options][ps-file]
DESCRIPTION
foo2lava-wrapper is a Foomatic compatible printer wrapper for the foo2lava printer driver. This script
reads a Postscript ps-file or standard input and converts it to Zenographics LAVA FLOWprinter format for
driving the Konica Minolta magicolor 1600W color laser printer,the Konica Minolta magicolor
1680MF/1690MF AIO printer,the Konica Minolta magicolor 2480/2490 MF AIO printer,the Konica
Minolta magicolor 2530 DL network color laser printer,and other Zenographics-based LAVA FLOWprint-
ers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Print in color (else monochrome).
−C colormode
Color correction mode [0].
1Photos (using m2300w CRDs)
2Photos and text (using m2300w CRDs)
3Graphics and text (using m2300w CRDs)
10 ICM color profile (using −G *.icm file)
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [0].
Media 2530DL
plain 0
transparency4
thick stock 20
envelope 22
letterhead 23
postcard 25
labels 26
recycled 27
−p paper
Paper size code to send to printer [2].
foo2lava-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2lava-wrapper(1) General Commands Manual foo2lava-wrapper(1)
1executive 25A5
2letter 26 A4
3leg al45B5jis
80 envMonarch 65 B5iso
81 env#10 90 envDL
91 envC592env B5
835 4x6" photo 837 10x15cm photo
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [255].
1Tray 1 255 auto
4Tray 2
−t Draft mode. Every other pixel is white.
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2lava for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the LAVA FLOWstream. foo2lava-wrapper always
runs Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regard-
less whether or not the printer has unprintable regions. This option is used to move the position of
the clipped image back to where it belongs on the page. The default is to send the amount which
wasclipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−z model
Model. The default is [0].
model protocol Description
0LAVA FLOWmagicolor 2490 MF
foo2lava-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2lava-wrapper(1) General Commands Manual foo2lava-wrapper(1)
0LAVA FLOWmagicolor 2530 DL
1OPL magicolor 2480 MF
2LAVA FLOWmagicolor 1600W
2LAVA FLOWmagicolor 1680MF
2LAVA FLOWmagicolor 1690MF
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2lava and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome LAVA FLOWstream from a Postscript document, examine it, and then print it using
aRAW print queue:
foo2lava-wrapper testpage.ps > testpage.zm
lavadecode < testpage.zm
lpr −P rawtestpage.zm
Create a color LAVA FLOWstream from a Postscript document:
foo2lava-wrapper −c testpage.ps > testpage.zc
FILES
/usr/bin/foo2lava-wrapper
foo2lava-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2lava-wrapper(1) General Commands Manual foo2lava-wrapper(1)
SEE ALSO
foo2lava(1), lavadecode(1) opldecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
foo2lava-wrapper 0.0 Thu Apr 07 11:47:50 2016 4
foo2lava(1) General Commands Manual foo2lava(1)
NAME
foo2lava − Convert Ghostscript pbmraworbitcmyk format into a LAVA FLOWoraOPL printer stream
SYNOPSIS
foo2lava [options]<pbmraw-file >lava-file
foo2lava [options]<bitcmyk-file >lava-file
foo2lava [options]<pksmraw-file >lava-file
DESCRIPTION
foo2lava converts Ghostscript pbmraw, bitcmyk, or pksmrawoutput formats to monochrome or color
LAVA FLOWorOPL streams, for driving the Konica Minolta magicolor 2530 DL network color laser
printer,the Konica Minolta magicolor 2480/2480 MF AIO printer,and other Zenographics-based
LAVA FLOWprinters.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [0].
Media 2530DL
plain 0
transparency4
thick stock 20
envelope 22
letterhead 23
postcard 25
labels 26
recycled 27
−p paper
Paper code to send to printer [2].
1executive 25A5
2letter 26 A4
3leg al45B5jis
80 envMonarch 65 B5iso
81 env#10 90 envDL
91 envC592env C6
835 4x6" photo 837 10x15cm photo
foo2lava 0.0 Thu Apr 07 11:47:50 2016 1
foo2lava(1) General Commands Manual foo2lava(1)
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (InputSlot) code to send to printer [255].
1Tray 1 255 auto
4Tray 2
−t Draft mode. Every other pixel is white.
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2lava for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the LAVA FLOWstream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−z model
Model. The default is [0].
model protocol Description
0LAVA FLOWmagicolor 2490 MF
0LAVA FLOWmagicolor 2530 DL
1OPL magicolor 2480 MF
2LAVA FLOWmagicolor 1600W
2LAVA FLOWmagicolor 1680MF
2LAVA FLOWmagicolor 1690MF
Debugging Options
These options are used for debugging foo2lava.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
foo2lava 0.0 Thu Apr 07 11:47:50 2016 2
foo2lava(1) General Commands Manual foo2lava(1)
−D level
Set Debug level[0].
EXAMPLES
Create a black and white LAVA FLOWstream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r1200x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2lava −r1200x600 −g10200x6600 −p1 >testpage.zm
Create a color LAVA FLOWstream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g10200x6600 −r1200x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2lava −r1200x600 −g10200x6600 −p1 >testpage.zc
FILES
/usr/bin/foo2lava
SEE ALSO
foo2lava-wrapper(1), lavadecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.com>
http://foo2zjs.rkkda.com/
foo2lava 0.0 Thu Apr 07 11:47:50 2016 3
foo2oak-wrapper(1) General Commands Manual foo2oak-wrapper(1)
NAME
foo2oak-wrapper − Convert Postscript into an OAKT printer stream
SYNOPSIS
foo2oak-wrapper [options][ps-file]
DESCRIPTION
foo2oak-wrapper is a Foomatic compatible printer wrapper for the foo2oak printer driver. This script
reads a Postscript ps-file or standard input and converts it to Oak Technology OAKT printer format for driv-
ing the HP Color LaserJet 1500 laser printer,Kyocera KM-1636/KM-2035 copiers, and other OAKT-based
printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−b bits Number of bits per plane (1 or 2) [1].
−c Print in color (else monochrome).
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [1].
Media HP CLJ 1500 KM-1635
−z0 −z1
autoselect 0 0
plain 1 1
preprinted 2 2
letterhead 3 3
transparency4 4
prepunched 5 5
labels 6 6
bond 7 7
recycled 8 8
color 9 9
cardstock 10 10
envelope 11 11
light 13 na
tough 14 na
vellum na 15
rough na 16
thick na 19
highqual na 20
−p paper
Paper size code to send to printer [1].
foo2oak-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2oak-wrapper(1) General Commands Manual foo2oak-wrapper(1)
1letter 3 ledger
5leg al6statement
7executive 8 A3
9A411A5
12 B4 13 B5jis
14 folio 19 env9
20 env10 27 envDL
28 envC5 30 envC4
37 envMonarch 257 A6
258 B6 259 B5iso
260 env6
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [600x600].
−s source
Source (Input Slot) code to send to printer [7].
1tray1 2 tray2
4manual 7 auto
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2oak for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the OAKT stream. foo2oak-wrapper always runs
Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regardless
whether or not the printer has unprintable regions. This option is used to move the position of the
clipped image back to where it belongs on the page. The default is to send the amount which was
clipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−z model
Model is 0 for the HP Color LaserJet 1500, and 1 for the Kyocera KM-1635/KM-2035 copiers.
The default is 0.
foo2oak-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2oak-wrapper(1) General Commands Manual foo2oak-wrapper(1)
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2oak and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome OAKT stream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2oak-wrapper testpage.ps > testpage.oak
oakdecode < testpage.oak
lpr −P rawtestpage.oak
Create a color OAKT stream from a Postscript document:
foo2oak-wrapper −c testpage.ps > testpage.oak
FILES
/usr/bin/foo2oak-wrapper
SEE ALSO
foo2oak(1), oak(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2oak.rkkda.com/
foo2oak-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2oak(1) General Commands Manual foo2oak(1)
NAME
foo2oak − Convert Ghostscript pbmraw, pgmraworbitcmyk format into an OAKT printer stream
SYNOPSIS
foo2oak [options]<pbmraw-file >OAKT-file
foo2oak [options]<pgmraw-file >OAKT-file
foo2oak [options]<bitcmyk-file >OAKT-file
DESCRIPTION
foo2oak converts Ghostscript pbmraworbitcmyk output formats to monochrome or color OAKT streams,
for driving the HP Color LaserJet 1500 laser printer,Kyocera KM-1636/KM-2035 copiers, and other
OAKT-based printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [1].
Media Code
autoselect 0
plain 1
preprinted 2
letterhead 3
transparency4
prepunched 5
labels 6
bond 7
recycled 8
color 9
cardstock 10
envelope 11
light 13
tough 14
vellum 15
rough 16
thick 19
highqual 20
−p paper
Paper code to send to printer [1].
foo2oak 0.0 Thu Apr 07 11:47:50 2016 1
foo2oak(1) General Commands Manual foo2oak(1)
1letter 3 ledger
5leg al6statement
7executive 8 A3
9A411A5
12 B4 13 B5jis
14 folio 19 env9
20 env10 27 envDL
28 envC5 30 envC4
37 envMonarch 257 A6
258 B6 259 B5iso
260 env6
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [600x600].
−s source
Source (InputSlot) code to send to printer [7].
1tray1 2 tray2
4manual 7 auto
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2oak for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the OAKT stream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−M mirror
Mirror bytes. Mirror is 0 for Kyocera KM-1635/KM-2035 and 1 for the HP Color LaserJet 1500.
The default is 1.
−z model
Model is 0 for the HP Color LaserJet 1500, and 1 for the Kyocera KM-1635/KM-2035 copiers.
The default is 0.
Debugging Options
These options are used for debugging foo2oak.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
foo2oak 0.0 Thu Apr 07 11:47:50 2016 2
foo2oak(1) General Commands Manual foo2oak(1)
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white OAKT stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r600x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2oak −r600x600 −g5100x6600 −p1 >testpage.oak
Create a color OAKT stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g5100x6600 −r600x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2oak −r600x600 −g5100x6600 −p1 >testpage.oak
FILES
/usr/bin/foo2oak
SEE ALSO
foo2oak-wrapper(1), oakdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2oak.rkkda.com/
foo2oak 0.0 Thu Apr 07 11:47:50 2016 3
foo2qpdl-wrapper(1) General Commands Manual foo2qpdl-wrapper(1)
NAME
foo2qpdl-wrapper − Convert Postscript into a QPDL printer stream
SYNOPSIS
foo2qpdl-wrapper [options][ps-file]
DESCRIPTION
foo2qpdl-wrapper is a Foomatic compatible printer wrapper for the foo2qpdl printer driver. This script
reads a Postscript ps-file or standard input and converts it to Samsung/Xerox QPDL printer format for driv-
ing the Samsung CLP-300, CLX-2160, CLX-3160, CLP-315, CLX-3175, CLP-600, CLP-610, CLP-620,
CLP-360, CLP-365, and Xerox Phaser 6110 QPDL printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Print in color (else monochrome).
−C colormode
Color correction mode [0].
1CRD
10 ICM color profile (using −G *.icm file)
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [0].
Media QPDL
plain 0
thick 1
thin 2
bond 3
color 4
card 5
labels 6
envelope 7
preprinted 8
cotton 9
recycled 10
transparency11
archive 12
−p paper
Paper size code to send to printer [0].
foo2qpdl-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2qpdl-wrapper(1) General Commands Manual foo2qpdl-wrapper(1)
0letter 1 legal
2A43executive
6env #10 7 envMonarch
8env C59envDL
11 B5jis 12 B5iso
16 A5 17 A6
23 envC624folio
25 env6.75 26 env#9
28 oficio
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [255].
1auto 2 manual
3multi 4 tray1
−t Draft mode. Every other pixel is white.
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2qpdl for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size].
−L mask
Send the logical clipping values from −u/-l in the QPDL stream. foo2qpdl-wrapper always runs
Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regardless
whether or not the printer has unprintable regions. This option is used to move the position of the
clipped image back to where it belongs on the page. The default is to send the amount which was
clipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−z model
Printer model. Model 0 is the default.
model Description
0CLP-300, CLX-2160, CLX-3160
foo2qpdl-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2qpdl-wrapper(1) General Commands Manual foo2qpdl-wrapper(1)
1CLP-600
2CLP-310, CLP-315, CLP-610, CLX-3175
3CLP-620, CLP-360, CLP-365
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−a parm=val
Color Adjust. parm is b, c, s, cr,mg, yb for brightness, contrast, saturation, cyan-red balance,
magenta-green balance, and yellow-blue balance. val is 0 to 100. Multiple options are allowed.
The default is "−ab=50 −ac=50 −as=50 −acr=50 −amg=50 −ayb=50". This only works when the
−z3 (e.g. CLP−365) model is set!
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2qpdl and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome QPDL stream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2qpdl-wrapper testpage.ps > testpage.zm
qpdldecode < testpage.zm
lpr −P rawtestpage.zm
Create a color QPDL stream from a Postscript document:
foo2qpdl-wrapper −c testpage.ps > testpage.zc
foo2qpdl-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2qpdl-wrapper(1) General Commands Manual foo2qpdl-wrapper(1)
FILES
/usr/bin/foo2qpdl-wrapper
SEE ALSO
foo2qpdl(1), qpdldecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2qpdl.rkkda.com/
foo2qpdl-wrapper 0.0 Thu Apr 07 11:47:50 2016 4
foo2qpdl(1) General Commands Manual foo2qpdl(1)
NAME
foo2qpdl − Convert Ghostscript pbmraworbitcmyk format into a QPDL printer stream
SYNOPSIS
foo2qpdl [options]<pbmraw-file >qpdl-file
foo2qpdl [options]<bitcmyk-file >qpdl-file
foo2qpdl [options]<pksmraw-file >qpdl-file
DESCRIPTION
foo2qpdl converts Ghostscript pbmraw, bitcmyk, or pksmrawoutput formats to monochrome or color
QPDL streams, for driving the Samsung CLP-300, CLX-2160, CLP-600, CLX-3160, CLP-610 CLP-620,
CLP-360, CLP-365, and the Xerox Phaser 6110 QPDL printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [0].
Media QPDL
plain 0
thick 1
thin 2
bond 3
color 4
card 5
labels 6
envelope 7
preprinted 8
cotton 9
recycled 10
transparency11
archive 12
−p paper
Paper code to send to printer [0].
foo2qpdl 0.0 Thu Apr 07 11:47:50 2016 1
foo2qpdl(1) General Commands Manual foo2qpdl(1)
0letter 1 legal
2A43executive
6env #10 7 envMonarch
8env C59envDL
11 B5jis 12 B5iso
16 A5 17 A6
23 envC624folio
25 env6.75 26 env#9
28 oficio 21 custom
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (InputSlot) code to send to printer [255].
1auto 2 manual
3multi 4 tray1
−t Draft mode. Every other pixel is white.
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2qpdl for a particular printer.
−a b,c,s,cr,mg,yb
Color Adjust: brightness, contrast, saturation, cyan-red balance, magenta-green balance, and yel-
low-blue balance from 0 to 100. The default is 50,50,50,50,50,50. This only works when the −z3
(e.g. CLP−365) model is set!
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the QPDL stream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−z model
Printer model. Model 0 is the default.
model Description
0CLP-300, CLX-2160, CLX-3160
1CLP-600
2CLP-310, CLP-315, CLP-610, CLX-3175
3CLP-620, CLP-360, CLP-365
foo2qpdl 0.0 Thu Apr 07 11:47:50 2016 2
foo2qpdl(1) General Commands Manual foo2qpdl(1)
Debugging Options
These options are used for debugging foo2qpdl.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white QPDL stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r1200x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2qpdl −r1200x600 −g10200x6600 −p0 >testpage.zm
Create a color QPDL stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g10200x6600 −r1200x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2qpdl −r1200x600 −g10200x6600 −p0 >testpage.zc
FILES
/usr/bin/foo2qpdl
SEE ALSO
foo2qpdl-wrapper(1), qpdldecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.com>
http://foo2qpdl.rkkda.com/
foo2qpdl 0.0 Thu Apr 07 11:47:50 2016 3
foo2slx-wrapper(1) General Commands Manual foo2slx-wrapper(1)
NAME
foo2slx-wrapper − Convert Postscript into a SLX printer stream
SYNOPSIS
foo2slx-wrapper [options][ps-file]
DESCRIPTION
foo2slx-wrapper is a Foomatic compatible printer wrapper for the foo2slx printer driver. This script reads
aPostscript ps-file or standard input and converts it to Software Imaging K.K. SLX printer format for driv-
ing the Lexmark C500 network color laser printer and other SLX-based printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Print in color (else monochrome).
−m media
Media code to send to printer [0].
Media SLX
plain 0
transparency1
labels 2
thick1 3
envelope1 4
thin 5
thick2 6
envelope2 7
middle 8
special 9
−p paper
Paper size code to send to printer [6].
6letter 2 A4
9leg al4B5
8executive 5 B5iso
10 env#10 11 envDL
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [0].
0auto 1 cassette1
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
foo2slx-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2slx-wrapper(1) General Commands Manual foo2slx-wrapper(1)
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2slx for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the ZjStream. foo2slx-wrapper always runs Ghost-
script with the ideal page dimensions, so that the scale of the image is correct, regardless whether
or not the printer has unprintable regions. This option is used to move the position of the clipped
image back to where it belongs on the page. The default is to send the amount which was clipped
by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2slx and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
foo2slx-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2slx-wrapper(1) General Commands Manual foo2slx-wrapper(1)
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome ZjStream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2slx-wrapper testpage.ps > testpage.zm
slxdecode < testpage.zm
lpr −P rawtestpage.zm
Create a color ZjStream stream from a Postscript document:
foo2slx-wrapper −c testpage.ps > testpage.zc
FILES
/usr/bin/foo2slx-wrapper
SEE ALSO
foo2slx(1), slxdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2slx.rkkda.com/
foo2slx-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2slx(1) General Commands Manual foo2slx(1)
NAME
foo2slx − Convert Ghostscript pbmraworbitcmyk format into a SLX printer stream
SYNOPSIS
foo2slx [options]<pbmraw-file >slx-file
foo2slx [options]<bitcmyk-file >slx-file
foo2slx [options]<pksmraw-file >slx-file
DESCRIPTION
foo2slx converts Ghostscript pbmraw, bitcmyk, or pksmrawoutput formats to monochrome or color SLX
streams, for driving the Lexmark C500 network color laser printer and other SLZ-based printers. The SLX
stream is a variant of ZjStream produced by Software Imaging K.K.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [0].
Media SLX
plain 0
transparency1
labels 2
thick1 3
envelope1 4
thin 5
thick2 6
envelope2 7
middle 8
special 9
−p paper
Paper code to send to printer [6].
6letter 2 A4
9leg al4B5
8executive 5 B5iso
10 env#10 11 envDL
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (InputSlot) code to send to printer [0].
foo2slx 0.0 Thu Apr 07 11:47:50 2016 1
foo2slx(1) General Commands Manual foo2slx(1)
0auto 1 cassette1
Printer Tweaking Options
These are the options used to customize the operation of foo2slx for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the ZjStream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
Debugging Options
These options are used for debugging foo2slx.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white SLX stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r1200x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2slx −r1200x600 −g10200x6600 −p1 >testpage.zm
Create a color SLX stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g10200x6600 −r1200x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2slx −r1200x600 −g10200x6600 −p1 >testpage.zc
FILES
/usr/bin/foo2slx
SEE ALSO
foo2slx-wrapper(1), slxdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2slx.rkkda.com/
foo2slx 0.0 Thu Apr 07 11:47:50 2016 2
foo2xqx-wrapper(1) General Commands Manual foo2xqx-wrapper(1)
NAME
foo2xqx-wrapper − Convert Postscript into a XQX printer stream
SYNOPSIS
foo2xqx-wrapper [options][ps-file]
DESCRIPTION
foo2xqx-wrapper is a Foomatic compatible printer wrapper for the foo2xqx printer driver. This script
reads a Postscript ps-file or standard input and converts it to XQX printer format for driving the HP LaserJet
P1005/P1006/P1007/P1008, the HP LaserJet P1505, the HP LaserJet P2014, the HP LaserJet M1005 MFP,
the HP LaserJet M1120 MFP,the HP LaserJet Pro M1212nf MFP,and other XQX-based printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [1].
Media M1005
standard 1
transparency2
envelope 257
letterhead 259
thick 261
postcard 262
labels 263
−p paper
Paper size code to send to printer [1].
1letter 9 A4
5leg al11A5
7executive 13B5
20 env#10 27 envDL
28 envC534env B5
37 envMonarch 257 16k 197x273
263 16k 184x260 263 16k 195x270
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [7].
foo2xqx-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2xqx-wrapper(1) General Commands Manual foo2xqx-wrapper(1)
1upper 4 manual
2lower 7 auto
−t Draft mode. Every other pixel is white.
−T density
Print density (1-5). The default is 3 (medium).
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
Printer Tweaking Options
These are the options used to customize the operation of foo2xqx for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the ZjStream. foo2xqx-wrapper always runs
Ghostscript with the ideal page dimensions, so that the scale of the image is correct, regardless
whether or not the printer has unprintable regions. This option is used to move the position of the
clipped image back to where it belongs on the page. The default is to send the amount which was
clipped by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
Debugging Options
These options are used for debugging foo2xqx and its wrapper.
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome ZjStream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2xqx-wrapper testpage.ps > testpage.xqx
xqxdecode < testpage.xqx
lpr −P rawtestpage.xqx
FILES
/usr/bin/foo2xqx-wrapper
foo2xqx-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2xqx-wrapper(1) General Commands Manual foo2xqx-wrapper(1)
SEE ALSO
foo2xqx(1), xqxdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2xqx.rkkda.com/
foo2xqx-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2xqx(1) General Commands Manual foo2xqx(1)
NAME
foo2xqx − Convert Ghostscript pbmrawinto a XQX printer stream
SYNOPSIS
foo2xqx [options]<pbmraw-file >xqx-file
DESCRIPTION
foo2xqx converts Ghostscript pbmrawtomonochrome XQX streams, for driving the HP LaserJet
P1005/P1006/P1007/P1008, the HP LaserJet P1505, the HP LaserJet P2014, the HP LaserJet M1005 MFP,
the HP LaserJet M1120 MFP,the HP LaserJet Pro M1212nf MFP,and other XQX-based printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [1].
Media M1005
standard 1
transparency2
envelope 257
letterhead 259
thick 261
postcard 262
labels 263
−p paper
Paper code to send to printer [1].
1letter 9 A4
5leg al11A5
7executive 13B5
20 env#10 27 envDL
28 envC534env B5
37 envMonarch 257 16k 197x273
263 16k 184x260 264 16k 195x270
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (InputSlot) code to send to printer [7].
foo2xqx 0.0 Thu Apr 07 11:47:50 2016 1
foo2xqx(1) General Commands Manual foo2xqx(1)
1upper 4 manual
2lower 7 auto
−t Draft mode. Every other pixel is white.
−T density
Print density (1-5). The default is 3 (medium).
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2xqx for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the ZjStream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
Debugging Options
These options are used for debugging foo2xqx.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white XQX stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r1200x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2xqx −r1200x600 −g10200x6600 −p1 >testpage.zm
FILES
/usr/bin/foo2xqx
foo2xqx 0.0 Thu Apr 07 11:47:50 2016 2
foo2xqx(1) General Commands Manual foo2xqx(1)
SEE ALSO
foo2xqx-wrapper(1), xqxdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2xqx.rkkda.com/
foo2xqx 0.0 Thu Apr 07 11:47:50 2016 3
foo2zjs-pstops(1) General Commands Manual foo2zjs-pstops(1)
NAME
foo2zjs-pstops − Add PS code for foo2*-wrapper
SYNOPSIS
foo2zjs-pstops [options][file]
DESCRIPTION
Add PS code for foo2zjs-wrapper.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−a Accurate screens code.
−c CIE Color.
−n Neuter CUPS cupsPSLevel2
−r Rotate 90 degrees clockwise.
−w Well Tempered Screens code.
−D level
Set Debug level[0].
FILES
/usr/bin/foo2zjs-pstops
SEE ALSO
foo2hp2600-wrapper(1), foo2lava-wrapper(1), foo2oak-wrapper(1), foo2qpdl-wrapper(1), foo2slx-
wrapper(1), foo2xqx-wrapper(1), foo2zjs-wrapper(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
foo2zjs-pstops 0.0 Thu Apr 07 11:47:50 2016 1
foo2zjs-wrapper(1) General Commands Manual foo2zjs-wrapper(1)
NAME
foo2zjs-wrapper − Convert Postscript into a ZJS printer stream
SYNOPSIS
foo2zjs-wrapper [options][ps-file]
DESCRIPTION
foo2zjs-wrapper is a Foomatic compatible printer wrapper for the foo2zjs printer driver. This script reads
aPostscript ps-file or standard input and converts it to Zenographics ZjStream printer format for driving the
Minolta/QMS 2300 DL network color laser printer and other Zenographics-based printers.
This script can be used in a standalone fashion, but is intended to be called from a printer spooler system
which uses the Foomatic printer database.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Print in color (else monochrome).
−C colormode
Color correction mode [0].
1Photos (using m2300w CRDs)
2Photos and text (using m2300w CRDs)
3Graphics and text (using m2300w CRDs)
10 ICM color profile (using −G *.icm file)
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−m media
Media code to send to printer [1].
2300DL 2200DL HP 1018 HP P1102 HP
HP 1005 HP 1020 HP P1606 CP1025
−z0 −z0 −z1 −z2 −z3
Media
standard 1 11 11
transparency222 22
envelope 257 na 267 267 267
letterhead 259 na 513 513 513
bond na na 260 260 260
thick 261 4261 na na
postcard 262 na na na na
rough na na 263 263 263
heavy na na 262 262 262
labels 263 3263 265 265
vellum na na 273 273 273
medium na na na 282 282
extraheavy na na na 283 283
color na na 512 512 512
light na na 258 258 258
preprinted na na 514 514 514
foo2zjs-wrapper 0.0 Thu Apr 07 11:47:50 2016 1
foo2zjs-wrapper(1) General Commands Manual foo2zjs-wrapper(1)
prepunched na na 515 515 515
recycled na na 516 516 516
−p paper
Paper size code to send to printer [1].
MC 2300DL HP 1018 HP P1102 HP
HP 1005 HP 1020 HP P1606 CP1025
−z0 −z1 −z2 −z3
Paper
letter 1 111
legal5555
executive 7 777
A4 9 999
A5 11 11 11 11
B5jis 13 13 13 13
env#10 20 20 20 20
envDL27272727
envCL28282828
envB534343434
envMonarch 37 37 37 37
postcard (japan) na 260 43 43
B5iso na 259 na na
A6 na 262 70 70
double postcard
rotated na 261 82 82
16k 197x273 na 257 257 257
fanfold german
legalna 258 258 258
16k 184x260 na na 263 263
16k 195x270 na na 264 264
photo 4x6 na na na 268
photo 5x8 na na na 269
photo 10x15 na na na 270
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (Input Slot) code to send to printer [7].
1upper 4 manual
2lower 7 auto
−t Draft mode. Every other pixel is white.
−T density
Print density (1-5). The default is 3 (medium).
−2 −3 −4 −5 −6 −8 −9 −10 −12 −14 −15 −16 −18
Print in N-up. Requires the psutils package.
−o orient
Orientation used for N-up.
Portrait −op (normal)
Landscape −ol (rotated 90 degrees anticlockwise)
Seascape −os (rotated 90 degrees clockwise)
foo2zjs-wrapper 0.0 Thu Apr 07 11:47:50 2016 2
foo2zjs-wrapper(1) General Commands Manual foo2zjs-wrapper(1)
Printer Tweaking Options
These are the options used to customize the operation of foo2zjs for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [varies with
paper size]. The defaults should work on the 2200DL and 2300DL, and have not been tested on
anyother printers.
−L mask
Send the logical clipping values from −u/-l in the ZjStream. foo2zjs-wrapper always runs Ghost-
script with the ideal page dimensions, so that the scale of the image is correct, regardless whether
or not the printer has unprintable regions. This option is used to move the position of the clipped
image back to where it belongs on the page. The default is to send the amount which was clipped
by −u and −l, and should be good in most cases.
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−P Do not send START_PLANE codes on monochrome output. May be needed by some mono-
chrome-only printers, such as the HP LaserJet 1000.
−X padlen
Add extra zero padding to the end of BID segments. The default is 16 bytes. Padding 16 bytes of
zeroes is needed for older ZjStream printers, such as the Minolta 2200DL and HP LaserJet 1000,
and seems harmless to newer ones, such as the Minolta 2300DL. So the default should be good
for all cases.
−z model
Model. Default is 0.
0KM2300DL / HP 1000 / HP 1005
1HP1018 / HP 1020 / HP 1022
2HPPro P1102 / P1566 / P1606dn
3HPPro CP1025
Color Tweaking Options
These are the options used to control the quality of color output. Color correction is currently a WORK IN
PROGRESS.
−g gsopts
Additional options to pass to Ghostscript, such as −g“-dDITHERPPI=nnn”, etc. This option may
appear more than once.
−G profile.icm
Convert profile.icm to a Postscript color rendering dictionary (CRD) using foo2zjs-icc2ps and
adjust the printer colors by using the Postscript setcolorrendering operator.(WORK IN
PROGRESS).
−G gamma-file.ps
Prepend gamma-file.ps to the Postscript input to perform color correction using the setcolortrans-
fer Postscript operator.For example, the file might contain:
{0.333 exp} {0.333 exp} {0.333 exp} {0.333 exp} setcolortransfer
foo2zjs-wrapper 0.0 Thu Apr 07 11:47:50 2016 3
foo2zjs-wrapper(1) General Commands Manual foo2zjs-wrapper(1)
−I intent
Select profile intent from the ICM file. 0=Perceptual, 1=Colorimetric, 2=Saturation, 3=Absolute.
Default is 0 (perceptual).
Debugging Options
These options are used for debugging foo2zjs and its wrapper.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a monochrome ZjStream from a Postscript document, examine it, and then print it using a RAW
print queue:
foo2zjs-wrapper testpage.ps > testpage.zm
zjsdecode < testpage.zm
lpr −P rawtestpage.zm
Create a color ZjStream stream from a Postscript document:
foo2zjs-wrapper −c testpage.ps > testpage.zc
FILES
/usr/bin/foo2zjs-wrapper
SEE ALSO
foo2zjs(1), zjsdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
foo2zjs-wrapper 0.0 Thu Apr 07 11:47:50 2016 4
foo2zjs(1) General Commands Manual foo2zjs(1)
NAME
foo2zjs − Convert Ghostscript pbmraworbitcmyk format into a ZJS printer stream
SYNOPSIS
foo2zjs [options]<pbmraw-file >zjs-file
foo2zjs [options]<bitcmyk-file >zjs-file
foo2zjs [options]<pksmraw-file >zjs-file
DESCRIPTION
foo2zjs converts Ghostscript pbmraw, bitcmyk, or pksmrawoutput formats to monochrome or color ZJS
streams, for driving the Minolta/QMS 2300 DL network color laser printer and other Zenographics-based
printers.
COMMAND LINE OPTIONS
Normal Options
These are the options used to select the parameters of a print job that are usually controlled on a per job
basis.
−c Force color mode if autodetect doesn’twork.
−d duplex
Duplexcode to send to printer [1].
1off 2 long edge 3short edge
−g xpixxypix
Set page dimensions in pixels [10200x6600].
−m media
Media code to send to printer [1].
2300DL 2200DL HP 1018 HP P1102 HP
HP 1005 HP 1020 HP P1606 CP1025
−z0 −z0 −z1 −z2 −z3
Media
standard 1 11 11
transparency222 22
envelope 257 na 267 267 267
letterhead 259 na 513 513 513
bond na na 260 260 260
thick 261 4261 na na
postcard 262 na na na na
rough na na 263 263 263
heavy na na 262 262 262
labels 263 3263 265 265
vellum na na 273 273 273
medium na na na 282 282
extraheavy na na na 283 283
color na na 512 512 512
light na na 258 258 258
preprinted na na 514 514 514
prepunched na na 515 515 515
recycled na na 516 516 516
foo2zjs 0.0 Thu Apr 07 11:47:50 2016 1
foo2zjs(1) General Commands Manual foo2zjs(1)
−p paper
Paper code to send to printer [1].
MC 2300DL HP 1018 HP P1102 HP
HP 1005 HP 1020 HP P1606 CP1025
−z0 −z1 −z2 −z3
Paper
letter 1 111
legal5555
executive 7 777
A4 9 999
A5 11 11 11 11
B5jis 13 13 13 13
env#10 20 20 20 20
envDL27272727
envCL28282828
envB534343434
envMonarch 37 37 37 37
postcard (japan) na 260 43 43
B5iso na 259 na na
A6 na 262 70 70
double postcard
rotated na 261 82 82
16k 197x273 na 257 257 257
fanfold german legal
legalna 258 258 258
16k 184x260 na na 263 263
16k 195x270 na na 264 264
photo 4x6 na na na 268
photo 5x8 na na na 269
photo 10x15 na na na 270
−n copies
Number of copies [1].
−r xresxyres
Set device resolution in pixels/inch [1200x600].
−s source
Source (InputSlot) code to send to printer [7].
1upper 4 manual
2lower 7 auto
−t Draft mode. Every other pixel is white.
−T density
Print density (1-5). The default is 3 (medium).
−J filename
Filename string to send to printer.
−U username
Username string to send to printer.
Printer Tweaking Options
These are the options used to customize the operation of foo2zjs for a particular printer.
−u xoff xyoff
Set the offset of the start of the printable region from the upper left corner,inpixels [0x0].
foo2zjs 0.0 Thu Apr 07 11:47:50 2016 2
foo2zjs(1) General Commands Manual foo2zjs(1)
−l xoff xyoff
Set the offset of the end of the printable region from the lower right corner,inpixels [0x0].
−L mask
Send logical clipping amounts implied by −u/-l in the ZjStream [3].
0don’tsend anylogical clipping amounts
1only send Y clipping amount
2only send X clipping amount
3send both X and Y clipping amounts
−P Do not send START_PLANE codes on monochrome output. May be needed by some black and
white only printers, such as the HP LaserJet 1000.
−A AllIsBlack: convert C=1,M=1,Y=1 to just K=1. Works with bitcmyk input only.
−B BlackClears: K=1 forces C,M,Y to 0. Works with bitcmyk input only.
−X padlen
Add extra zero padding to the end of BID segments. The default is 16 bytes. Padding 16 bytes of
zeroes is needed for older ZjStream printers, such as the Minolta 2200DL and HP LaserJet 1000,
and seems harmless to newer ones, such as the Minolta 2300DL. So the default should be good
for all cases.
−z model
Model. Default is 0.
0KM2300DL / HP 1000 / HP 1005
1HP1018 / HP 1020 / HP 1022
2HPPro P1102 / P1566 / P1606dn
3HPPro CP1025
Debugging Options
These options are used for debugging foo2zjs.
−S plane
Output just a single color plane from a color print and print it on the black plane. The default is to
output all color planes.
1Cyan
2Magenta
3Yellow
4Black
−D level
Set Debug level[0].
EXAMPLES
Create a black and white ZJS stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −r1200x600 −sDEVICE=pbmraw
−sOutputFile=- − < testpage.ps
|foo2zjs −r1200x600 −g10200x6600 −p1 >testpage.zm
Create a color ZJS stream:
gs −q −dBATCH −dSAFER −dQUIET −dNOPAUSE
−sPAPERSIZE=letter −g10200x6600 −r1200x600 −sDEVICE=bitcmyk
−sOutputFile=- − < testpage.ps
|foo2zjs −r1200x600 −g10200x6600 −p1 >testpage.zc
foo2zjs 0.0 Thu Apr 07 11:47:50 2016 3
foo2zjs(1) General Commands Manual foo2zjs(1)
FILES
/usr/bin/foo2zjs
SEE ALSO
foo2zjs-wrapper(1), zjsdecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
foo2zjs 0.0 Thu Apr 07 11:47:50 2016 4
gipddecode(1) General Commands Manual gipddecode(1)
NAME
gipddecode − Decode a GIPD stream into human readable form.
SYNOPSIS
gipddecode [options]<gipd-file
DESCRIPTION
gipddecode decodes a Granite Image Printer Driver(GIPD) stream into human readable form. Granite
Systems was acquired by Monotype Imaging.
AGIPD stream is the printer language used by the Lexmark X500 and the Dell 1125 MFP printers.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an GIPD stream file.
$gipddecode −h x500-mono.prn
0: OFST 0len=128
80: OFST 1len=128
100: OFST 2len=128
180: OFST 3len=128
200: OFST 4len=128
[SNIP]
27d80: OFST 1275 len=128
27e00: \033%-12345X@PJL SET DISPINFOWHILEPRINT=OFF
27e2a: @PJL SET DISPATPAPERCHANG=OFF
27e49: @PJL SET JAMRECOVERY=ON
27e62: @PJL SET OUTPUTBLANKPAPER=OFF
27e81: @PJL SET PRINTSLOWLY=OFF
27e9b: @PJL SET REVERSEPRINT=OFF
27eb6: \033%-12345X
27ebf: GDIJ len=108
unk0=0, unk1=0, unk2=0, unk3=0, unk4=0
unk5=16777221(0x1000005), unk6=0, unk7=0, unk8=0, paper=0
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
27f37: GDIP len=52
nplane = 1, w254 = 4896, h254 = 6110
132018de, 0, 0, 0, 0, 1000000, 0, 0, 0, 0, 0, 0, 0,
27f77: GDIB 0len=60 (0x3c)
27fcb: GDIB 1len=252 (0xfc)
280df: GDIB 2len=124 (0x7c)
28173: GDIB 3len=956 (0x3bc)
28547: GDIB 4len=1692 (0x69c)
28bfb: GDIB 5len=572 (0x23c)
gipddecode 0.0 Thu Apr 07 11:47:50 2016 1
gipddecode(1) General Commands Manual gipddecode(1)
28e4f: GDIB 6len=17084 (0x42bc)
2d123: GDIB 7len=18108 (0x46bc)
317f7: GDIB 8len=8508 (0x213c)
3394b: GDIB 9len=1756 (0x6dc)
3403f: GDIB 10 len=1596 (0x63c)
34693: GDIB 11 len=892 (0x37c)
34a27: GDIB 12 len=2332 (0x91c)
3535b: GDIB 13 len=8380 (0x20bc)
3742f: GDIB 14 len=3452 (0xd7c)
381c3: GDIB 15 len=60 (0x3c)
38217: GDIB 16 len=1468 (0x5bc)
387eb: GDIB 17 len=2076 (0x81c)
3901f: GDIB 18 len=284 (0x11c)
39153: GDIB 19 len=1660 (0x67c)
397e7: GDIB 20 len=2908 (0xb5c)
3a35b: GDIB 21 len=156 (0x9c)
3a40f: GDIB 22 len=188 (0xbc)
3a4e3: GDIB 23 len=220 (0xdc)
3a5d7: GDIB 24 len=60 (0x3c)
3a62b: PIDG
3a637: JIDG
Total Size = 75843 (0x12843)
FILES
/usr/bin/gipddecode
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
gipddecode 0.0 Thu Apr 07 11:47:50 2016 2
hbpldecode(1) General Commands Manual hbpldecode(1)
NAME
hbpldecode − Decode a HBPL stream into human readable form.
SYNOPSIS
hbpldecode [options]<hbpl-file
DESCRIPTION
hbpldecode decodes a HBPL stream into human readable form. HBPL is Host Based Printer Language.
There are twoversions of HBPL in existence.
Version one is an HBPL stream with JBIG2 (?) data. This data is used by the Dell 1250c, Dell C1660w,
Epson AcuLaser C1700, Fuji-Xerox cp105b, and similar printers. These printers are unsupported.
Version twoisanHBPL stream with JBIG encoded data. This data is used by the Xerox WorkCentre 6015,
Fuji Xerox DocuPrint CM205, Dell 1355c, and similar printers. These printers are supported by
foo2hbpl2-wrapper et al.
Both versions can be decoded by hbpldecode.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an HBPL stream file, version 1.
$hbpldecode −h 1250c-mono.prn
0: \033%-12345X@PJL JOB MODE=PRINTER
1f: @PJL SET STRINGCODESET=UTF8
3b: @PJL COMMENT DATE=06/01/2011
58: @PJL COMMENT TIME=13:28:30
73: @PJL COMMENT DNAME=empty − Notepad
96: @PJL SET JOBATTR="@LUNA=rick"
b4: @PJL SET COPIES=1
c6: @PJL SET QTY=1
d5: @PJL SET JOBATTR="@TRCH=OFF"
f2: @PJL SET DUPLEX=OFF
106: @PJL SET BINDING=LONGEDGE
120: @PJL SET RENDERMODE=GRAYSCALE
13e: @PJL SET ECONOMODE=OFF
155: @PJL SET RET=ON
165: @PJL SET JOBATTR="@IREC=OFF"
182: @PJL SET JOBATTR="@HOAD=I0A00020F"
1a5: @PJL SET JOBATTR="@JOAU=rick"
1c3: @PJL SET JOBATTR="@CNAM=RICK-VB"
1e4: @PJL SET IWAMANUALDUP=OFF
1fe: @PJL SET IWAJAMRECOVERY=AUTO
21b: @PJL SET JOBATTR="@MSIP=NORMAL"
hbpldecode 0.0 Thu Apr 07 11:47:50 2016 1
hbpldecode(1) General Commands Manual hbpldecode(1)
23b: @PJL SET PAPERDIRECTION=SEF
257: @PJL SET RESOLUTION=600
26f: @PJL SET BITSPERPIXEL=8
287: @PJL SET JOBATTR="@DRDM=RASTER"
2a7: @PJL SET JOBATTR="@TCPR=33"
2c3: @PJL SET JOBATTR="@TUCR=33"
2df: @PJL SET JOBATTR="@TTRC=33"
2fb: @PJL SET JOBATTR="@TSCR=33"
317: @PJL SET JOBATTR="@GCPR=33"
333: @PJL SET JOBATTR="@GUCR=33"
34f: @PJL SET JOBATTR="@GTRC=33"
36b: @PJL SET JOBATTR="@GSCR=33"
387: @PJL SET JOBATTR="@ICPR=34"
3a3: @PJL SET JOBATTR="@IUCR=34"
3bf: @PJL SET JOBATTR="@ITRC=34"
3db: @PJL SET JOBATTR="@ISCR=34"
3f7: @PJL SET JOBATTR="@TDFT=0"
412: @PJL SET JOBATTR="@GDFT=0"
42d: @PJL SET JOBATTR="@IDFT=0"
448: @PJL ENTER LANGUAGE=HBPL
461: RECTYPE ’A’ [0x41]:
462: 81 a1: 0x0
465: 82 a2: 0x7
469: 83 a2: 0x1
46d: RECTYPE ’C’ [0x43]:
46e: 91 a1: 0x0
471: 92 a1: 0x1
474: 93 a1: 0x1
477: 94 a1: 0x0
47a: 95 c2: 0x0
480: 96 a1: 0x0
483: 97 c3: 0x0
489: 98 a1: 0x0
48c: 99 a4: 1 [PAGECNT]
492: 9a c4: 5104x6600 [WxH]
49c: 9b a1: 0x0
49f: 9c a1: 0x1
4a2: 9d a1: 0x9
4a5: 9e a1: 0x2
4a8: 9f a1: 0x5
4ab: a0 a1: 0x8
4ae: a1 a1: 0x0
4b1: a2 c4: 5104x6600 [WxH]
4bb: RECTYPE ’Q’ [0x51]:
4bc: RECTYPE ’R’ [0x52]:
4bd: a3 a1: 0x0
4c0: a4 a2: 6457 (0x1939) bytes of data...
1dfe: RECTYPE ’S’ [0x53]:
1dff: RECTYPE ’D’ [0x44]:
1e00: RECTYPE ’B’ [0x42]:
1dff: \033%-12345X@PJL EOJ
Decode an HBPL stream file, version 2.
hbpldecode 0.0 Thu Apr 07 11:47:50 2016 2
hbpldecode(1) General Commands Manual hbpldecode(1)
$hbpldecode −h 6015c-color.prn
0: 33%-12345X@PJL JOB NAME=PRINTER
20: @PJL SET JOBATTR="HOST:dual.rkkda.org"
48: @PJL SET JOBATTR="USER:rick"
66: @PJL SET JOBATTR="DOCU:(stdin)"
87: @PJL SET JOBATTR="OWNR:rick"
a5: @PJL SET DUPLEX=OFF
ba: @PJL SET MEDIASOURCE=0
d2: @PJL SET RENDERMODE=COLOR
ed: @PJL SET RESOLUTION=600
106: @PJL SET BITSPERPIXEL=2
11f: @PJL SET COPIES=1
132: @PJL ENTER LANGUAGE=HBPL
14c: RECTYPE JP [Job Parameters]
00000000: 1b 4a 50 04 01 00 00 01 00 00 00 00 00 00 00 00 .JP..... ........
00000010: b0 bd ac 43 00 f0 cf 08 f4 9f ac 43 59 ba a0 43 ...C.... ...CY..C
00000020: f4 9f ac 43 00 e0 cd 08 9c ba a0 43 00 f0 cf 08 ...C.... ...C....
00000030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ........ ........
18c: RECTYPE PS [Page Start]
00000000: 1b 50 53 3c 00 14 00 00 06 19 00 00 00 78 f4 01 .PS<.... .....x..
00000010: 90 03 00 00 04 01 01 00 58 02 e0 00 00 00 e0 00 ........ X.......
00000020: 00 00 e0 00 00 00 f0 00 00 00 00 00 00 00 00 00 ........ ........
00000030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ........ ........
w,h=5120x6406 res=600 color=1
mediatype=Plain(1) papersize=Letter(4)
1cc: Cyan BIH:
DL = 0, D = 0, P = 1, − = 0, XY = 10240 x 6406
L0 = 128, MX = 0, MY = 0
Order = 0
Options = 64 LRLTWO
51 stripes, 0 layers, 1 planes
...cyan data skipped...
2ac: Magenta BIH:
DL = 0, D = 0, P = 1, − = 0, XY = 10240 x 6406
L0 = 128, MX = 0, MY = 0
Order = 0
Options = 64 LRLTWO
51 stripes, 0 layers, 1 planes
...magenta data skipped...
38c: Yellow BIH:
DL = 0, D = 0, P = 1, − = 0, XY = 10240 x 6406
L0 = 128, MX = 0, MY = 0
Order = 0
Options = 64 LRLTWO
51 stripes, 0 layers, 1 planes
...yellow data skipped...
46c: Black BIH:
DL = 0, D = 0, P = 1, − = 0, XY = 10240 x 6406
L0 = 128, MX = 0, MY = 0
Order = 0
Options = 64 LRLTWO
51 stripes, 0 layers, 1 planes
...black data skipped...
55c: RECTYPE PE [Page End]
hbpldecode 0.0 Thu Apr 07 11:47:50 2016 3
hbpldecode(1) General Commands Manual hbpldecode(1)
00000000: 1b 50 45 3c 00 00 00 00 77 00 00 00 7c 00 00 00 .PE<.... w...|...
00000010: 08 e0 cd 08 00 00 00 00 9c 55 ac bf f4 9f ac 43 ........ .U.....C
00000020: e0 a3 ac 43 00 00 00 00 19 00 00 00 75 9e 99 43 ...C.... ....u..C
00000030: 00 21 99 43 00 00 00 00 01 00 00 00 9a 0e 99 43 .!.C.... .......C
59c: \033%-12345X@PJL EOJ
FILES
/usr/bin/hbpldecode
SEE ALSO
foo2hbpl2-wrapper(1), foo2hbpl2(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
Peter Korf <peter@niendo.de>
http://foo2hbpl.rkkda.com/
hbpldecode 0.0 Thu Apr 07 11:47:50 2016 4
hipercdecode(1) General Commands Manual hipercdecode(1)
NAME
hipercdecode − Decode a HIPERC stream into human readable form.
SYNOPSIS
hipercdecode [options]<hiperc-file
DESCRIPTION
hipercdecode decodes a HIPERC stream into human readable form. Uncompressed and JBIG formats are
handled.
An HIPERC stream is the printer language used by the Oki Data C310dn, C3100, C3200n, C3250n,
C3300n, C3400n, C5100n, C5250n, C5500n, C5600, and the C5800n printers.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an HIPERC stream file created by foo2hiperc.
$foo2hiperc-wrapper testpage.ps | hipercdecode −h
0: \033%-12345X@PJL
f: @PJL RDYMSG DISPLAY = "Unknown"
30: @PJL SET OKIJOBACCOUNTJOB USERID="Unknown" JOBNAME="Unknown"
6e: @PJL SET OKIAUXJOBINFO DATA="DocumentName=Unknown"
a2: @PJL SET OKIAUXJOBINFO DATA="ComputerName=dual.rkkda.org"
dd: @PJL SET OKIAUXJOBINFO DATA="ReceptionTime=00:00:00 2008/01/30"
11e: @PJL SET OKIAUTOTRAYSWITCH=ON
13d: @PJL SET OKIPAPERSIZECHECK=ENABLE
160: @PJL SET RESOLUTION=600
179: @PJL SET PAPER=LETTER
190: @PJL SET OKITRAYSEQUENCE=PAPERFEEDTRAY
1b8: @PJL SET OKIPAPERFEED=TRAY1
1d5: @PJL SET OKIMEDIATYPE = PLAIN
1f4: @PJL SET LPARM:PCL OKIPRINTMARGIN=INCH1D6
21f: @PJL SET COPIES=1
232: @PJL SET QTY=1
242: @PJL SET HIPERCEFFECTIVEBLOCKSIZE=34799360
26e: @PJL ENTER LANGUAGE=HIPERC
289: RECTYPE 0(len=52,0x34 cnt=1)
291: BLKNUM 0, nbie=1, pn=3 [black] uc=0,0, wid=4864 ud=0,100
2a5: BLKNUM 1(len=20), uncompressed=1, bie:
DL = 48, D = 48, P = 49, − = 48, XY = 4864 x 6816
L0 = 256, MX = 0, MY = 0
Order = 0
Options = 0
1stripes, 0 layers, 49 planes
hipercdecode 0.0 Thu Apr 07 11:47:50 2016 1
hipercdecode(1) General Commands Manual hipercdecode(1)
2bd: RECTYPE 1(len=155668,0x26014 cnt=1)
2c5: BLKNUM 0(len=4), plane=3, uc=0,0,0
2cd: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
262d1: RECTYPE 1(len=155668,0x26014 cnt=2)
262d9: BLKNUM 0(len=4), plane=3, uc=0,0,0
262e1: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
4c2e5: RECTYPE 1(len=155668,0x26014 cnt=3)
4c2ed: BLKNUM 0(len=4), plane=3, uc=0,0,0
4c2f5: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
722f9: RECTYPE 1(len=155668,0x26014 cnt=4)
72301: BLKNUM 0(len=4), plane=3, uc=0,0,0
72309: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
9830d: RECTYPE 1(len=155668,0x26014 cnt=5)
98315: BLKNUM 0(len=4), plane=3, uc=0,0,0
9831d: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
be321: RECTYPE 1(len=155668,0x26014 cnt=6)
be329: BLKNUM 0(len=4), plane=3, uc=0,0,0
be331: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
e4335: RECTYPE 1(len=155668,0x26014 cnt=7)
e433d: BLKNUM 0(len=4), plane=3, uc=0,0,0
e4345: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
10a349: RECTYPE 1(len=155668,0x26014 cnt=8)
10a351: BLKNUM 0(len=4), plane=3, uc=0,0,0
10a359: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
13035d: RECTYPE 1(len=155668,0x26014 cnt=9)
130365: BLKNUM 0(len=4), plane=3, uc=0,0,0
13036d: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
156371: RECTYPE 1(len=155668,0x26014 cnt=10)
156379: BLKNUM 0(len=4), plane=3, uc=0,0,0
156381: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
17c385: RECTYPE 1(len=155668,0x26014 cnt=11)
17c38d: BLKNUM 0(len=4), plane=3, uc=0,0,0
17c395: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
1a2399: RECTYPE 1(len=155668,0x26014 cnt=12)
1a23a1: BLKNUM 0(len=4), plane=3, uc=0,0,0
1a23a9: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
1c83ad: RECTYPE 1(len=155668,0x26014 cnt=13)
1c83b5: BLKNUM 0(len=4), plane=3, uc=0,0,0
1c83bd: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
1ee3c1: RECTYPE 1(len=155668,0x26014 cnt=14)
1ee3c9: BLKNUM 0(len=4), plane=3, uc=0,0,0
1ee3d1: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
2143d5: RECTYPE 1(len=155668,0x26014 cnt=15)
2143dd: BLKNUM 0(len=4), plane=3, uc=0,0,0
2143e5: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
23a3e9: RECTYPE 1(len=155668,0x26014 cnt=16)
23a3f1: BLKNUM 0(len=4), plane=3, uc=0,0,0
23a3f9: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
2603fd: RECTYPE 1(len=155668,0x26014 cnt=17)
260405: BLKNUM 0(len=4), plane=3, uc=0,0,0
26040d: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
286411: RECTYPE 1(len=155668,0x26014 cnt=18)
286419: BLKNUM 0(len=4), plane=3, uc=0,0,0
286421: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
hipercdecode 0.0 Thu Apr 07 11:47:50 2016 2
hipercdecode(1) General Commands Manual hipercdecode(1)
2ac425: RECTYPE 1(len=155668,0x26014 cnt=19)
2ac42d: BLKNUM 0(len=4), plane=3, uc=0,0,0
2ac435: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
2d2439: RECTYPE 1(len=155668,0x26014 cnt=20)
2d2441: BLKNUM 0(len=4), plane=3, uc=0,0,0
2d2449: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
2f844d: RECTYPE 1(len=155668,0x26014 cnt=21)
2f8455: BLKNUM 0(len=4), plane=3, uc=0,0,0
2f845d: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
31e461: RECTYPE 1(len=155668,0x26014 cnt=22)
31e469: BLKNUM 0(len=4), plane=3, uc=0,0,0
31e471: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
344475: RECTYPE 1(len=155668,0x26014 cnt=23)
34447d: BLKNUM 0(len=4), plane=3, uc=0,0,0
344485: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
36a489: RECTYPE 1(len=155668,0x26014 cnt=24)
36a491: BLKNUM 0(len=4), plane=3, uc=0,0,0
36a499: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
39049d: RECTYPE 1(len=155668,0x26014 cnt=25)
3904a5: BLKNUM 0(len=4), plane=3, uc=0,0,0
3904ad: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
3b64b1: RECTYPE 1(len=155668,0x26014 cnt=26)
3b64b9: BLKNUM 0(len=4), plane=3, uc=0,0,0
3b64c1: BLKNUM 1(len=155648), Data=00 00 00 00 00 00 00 00 00 00 00 ...
3dc4c5: RECTYPE 1(len=97300,0x17c14 cnt=27)
3dc4cd: BLKNUM 0(len=4), plane=3, uc=0,0,0
3dc4d5: BLKNUM 1(len=97280), Data=00 00 00 00 00 00 00 00 00 00 00 ...
3f40d9: RECTYPE 255 (len=8,0x8 cnt=28)
3f40e1: \033%-12345X
FILES
/usr/bin/hipercdecode
SEE ALSO
foo2hiperc-wrapper(1), foo2hiperc(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2hiperc.rkkda.com/
hipercdecode 0.0 Thu Apr 07 11:47:50 2016 3
lavadecode(1) General Commands Manual lavadecode(1)
NAME
lavadecode − Decode a LAVA FLOWstream into human readable form.
SYNOPSIS
lavadecode [options]<lavaflow-file
DESCRIPTION
lavadecode decodes a LAVA FLOWstream into human readable form.
ALAVA FLOWstream is the printer language used by some Konica Minolta printers, such as the KM
magicolor 2530 DL.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an LAVA FLOWstream file created by foo2lava.
$lavadecode −h < testpage.prn
0: \033%-12345X@PJL JOB NAME="stdin"
1f: \033%-12345X@PJL JOB USERNAME=""
3d: \033%-12345X@PJL JOB TIMESTAMP="07/20/2007"
66: \033%-12345X@PJL JOB OSINFO="Linux/2.6.20-1.2316.fc5"
99: \033%-12345X@PJL ENTER LANGUAGE=LAVAFLOW
bf: \033E RESET
c1: \033&l0S DUPLEX: [off]
c6: \033&l0G
cb: \033&u1200D XRESOLUTION: [1200]
d3: \033&l1X COPIES: [1]
d8: \033&x1X TRANSMIT ONCE COPIES: [1]
dd: \033&l0O ORIENTATION: [port]
e2: \033*r1U NBIE: [1]
e7: \033*g8W BW/COLOR: [8]
fmt=2 np=1
BLACK: X=1200, Y=600, unk=0, #=4(2)
f4: \033*b1234M COMPRESSION: [1234] (JBIG)
fc: \033&l2A PAGE SIZE: [letter]
101: \033&l255H PAPER SOURCE: [auto]
108: \033&l0M MEDIA TYPE: [plain]
10d: \033&l0E TOP MARGIN: [0]
112: \033*r9792S XRASTER: [9792,0x2640]
11a: \033*r6400T YRASTER: [6400,0x1900]
122: \033&l0U
127: \033&l0Z
12c: \033*p200X XOFFSET: [200]
133: \033*p200Y YOFFSET: [200]
lavadecode 0.0 Thu Apr 07 11:47:50 2016 1
lavadecode(1) General Commands Manual lavadecode(1)
13a: \033*r1A [Page 1]
13f: \033*b20V [black]
DL = 0, D = 0, P = 1, − = 0, XY = 9792 x 6400
L0 = 128, MX = 0, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
50 stripes, 0 layers, 1 planes
159: \033*b65536V JBIG data (first) [65536,0x10000]
ff 02 c2 79 54 3e be e1 a0 de 08 9a b1 d2 c2 59
... ae 88 ef a7 c7 96 d3 96 a6 d7 2c 06 38 75 22 44
10162: \033*b26432W JBIG data (end) [26432,0x6740]
0e 89 66 ce 01 41 41 41 41 41 41 41 41 41 41 41
... 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
168ab: \033*x3887138K BLACK DOTS: [3887138]
168b6: \033*x58781662W BLACK WHITEDOTS: [58781662]
168c2: \033*rC END PAGE
168c6: \033&l0H PAPER SOURCE: [eject]
168cb: \033E RESET
168cd: \033%-12345X
FILES
/usr/bin/lavadecode
SEE ALSO
foo2lava-wrapper(1), foo2lava(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2lava.rkkda.com/
lavadecode 0.0 Thu Apr 07 11:47:50 2016 2
oakdecode(1) General Commands Manual oakdecode(1)
NAME
oakdecode − Decode an OAKT printer stream into human readable form.
SYNOPSIS
oakdecode [options]<OAKT-file
DESCRIPTION
oakdecode decodes an OAKT printer stream into human readable form.
An OAKT printer stream is the printer language used by the HP Color LaserJet 1500 and other printers.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−r basename
Basename of .jbg file for saving rawplanes
−i Suppress display of image records.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an OAKT file created by foo2oak.
$oakdecode < testpage.oak
0d (80) 1 OTHER
0c (64) Wed Nov 05 16:30:50 2003 a07d3 100005 32001e
0a (80) testpage.pdf
14 (16) (no args)
28 (16) Source=Tray1
29 (80) PaperType=0 UNK8=2,0,0,0, blanks(63)
2a (32) Copies=1 UNK=0
2b (32) papercode=25 xwid=4648 ywid=9000 UNK=0
33 (64)
u0 u1 w hresx resy nBits
x0 x0 2128 4300 600 600 x1
15 (16) (no args)
bih0 w h l0 bih5 dlen plen unk yOff P subP
3c (64) 00010000 2176 256 256 58030020 1050 1056 000 64 30
DL = 0, D = 0, P = 1, − = 0, XY = 2176 x 256
L0 = 256, MX = 32, MY = 0
Order = 3ILEAVE SMID
Options = 88 LRLTWO TPDON TPBON
1stripes, 0 layers, 1 planes
3c (64) 00010000 2176 256 256 58030020 3668 3680 000 320 30
3c (64) 00010000 2176 256 256 58030020 1463 1472 000 640 30
3c (64) 00010000 2176 256 256 58030020 1975 1984 000 896 30
3c (64) 00010000 2176 224 224 58030020 2744 2752 000 1152 3 0
3c (64) 00010000 2176 256 256 58030020 988 992 000 1440 3 0
3c (64) 00010000 2176 256 256 58030020 2892 2896 000 1696 3 0
3c (64) 00010000 2176 256 256 58030020 3634 3648 000 1952 3 0
oakdecode 0.0 Thu Apr 07 11:47:50 2016 1
oakdecode(1) General Commands Manual oakdecode(1)
3c (64) 00010000 2176 256 256 58030020 3236 3248 000 2208 3 0
3c (64) 00010000 2176 256 256 58030020 2279 2288 000 2464 3 0
3c (64) 00010000 2176 256 256 58030020 3746 3760 000 2720 3 0
3c (64) 00010000 2176 200 200 58030020 2404 2416 000 2976 3 0
3c (64) 00010000 2176 256 256 58030020 3114 3120 000 3240 3 0
3c (64) 00010000 2176 96 96 58030020 1142 1152 000 3496 3 0
3c (64) 00010000 2176 256 256 58030020 2094 2112 000 3752 3 0
3c (64) 00010000 2176 256 256 58030020 1319 1328 000 4008 3 0
3c (64) 00010000 2176 36 36 58030020 208 224 000 4264 3 0
17 (16) (no args)
18 (16) UNK=0
0b (16) (no args)
FILES
/usr/bin/oakdecode
SEE ALSO
foo2oak-wrapper(1), foo2oak(1), jbg2pbm(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2oak.rkkda.com/
oakdecode 0.0 Thu Apr 07 11:47:50 2016 2
opldecode(1) General Commands Manual opldecode(1)
NAME
opldecode − Decode a Raster Object (opl) stream into human readable form.
SYNOPSIS
opldecode [options]<zjs-file
DESCRIPTION
opldecode decodes a Raster Object (opl) stream into human readable form.
ARaster Object stream is the printer language used by some Konica Minolta printers, such as the KM
magicolor 2480 MF.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an Raster Object stream file created by foo2lava-wrapper −z1.
$foo2lava-wrapper −z1 testpage.ps | opldecode −h
0: Event=StartOfJob;
11: OSVersion=WindowsXP;
25: DrvVersion=2.0.1410.0;
3b: Resolution=1200x600;
4f: RasterObject.Compression=JBIG;
6d: Sides=OneSided;
7c: MediaSize=custom_size_8.5x11in;
9b: MediaType=plain;
ab: MediaInputTrayCheck=top;
c3: RasterObject.BitsPerPixel=1;
df: RasterObject.Planes=00FFFF,0,0,0,0,0,0;
106: RasterObject.Width=9792;
11e: RasterObject.Height=6400;
137: RasterObject.Data#20=
DL = 0, D = 0, P = 1, − = 0, XY = 9792 x 6400
L0 = 128, MX = 0, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
50 stripes, 0 layers, 1 planes
161: RasterObject.Data#32768=
817a: RasterObject.Data#32768=
10193: RasterObject.Data#3168=
10e0b: RasterObject.Planes=FF00FF,0,0,0,0,0,0;
10e32: RasterObject.Width=9792;
10e4a: RasterObject.Height=6400;
10e63: RasterObject.Data#20=
opldecode 0.0 Thu Apr 07 11:47:50 2016 1
opldecode(1) General Commands Manual opldecode(1)
DL = 0, D = 0, P = 1, − = 0, XY = 9792 x 6400
L0 = 128, MX = 0, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
50 stripes, 0 layers, 1 planes
10e8d: RasterObject.Data#32768=
18ea6: RasterObject.Data#32768=
20ebf: RasterObject.Data#19200=
259d8: RasterObject.Planes=FFFF00,0,0,0,0,0,0;
259ff: RasterObject.Width=9792;
25a17: RasterObject.Height=6400;
25a30: RasterObject.Data#20=
DL = 0, D = 0, P = 1, − = 0, XY = 9792 x 6400
L0 = 128, MX = 0, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
50 stripes, 0 layers, 1 planes
25a5a: RasterObject.Data#32768=
2da73: RasterObject.Data#32768=
35a8c: RasterObject.Data#32768=
3daa5: RasterObject.Data#7056=
3f64d: RasterObject.Planes=000000,0,0,0,0,0,0;
3f674: RasterObject.Width=9792;
3f68c: RasterObject.Height=6400;
3f6a5: RasterObject.Data#20=
DL = 0, D = 0, P = 1, − = 0, XY = 9792 x 6400
L0 = 128, MX = 0, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
50 stripes, 0 layers, 1 planes
3f6cf: RasterObject.Data#32768=
476e8: RasterObject.Data#17472=
4bb41: Event=EndOfPage;
4bb51: Event=EndOfJob;
FILES
/usr/bin/opldecode
SEE ALSO
foo2lava-wrapper(1), foo2opl(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2lava.rkkda.com/
opldecode 0.0 Thu Apr 07 11:47:50 2016 2
osx-hplj-hotplug(1) General Commands Manual osx-hplj-hotplug(1)
NAME
osx-hplj-hotplug − Daemon for downloading firmware files for Mac OS X
SYNOPSIS
osx-hplj-hotplug [options]
DESCRIPTION
osx-hplj-hotplug is a daemon for Mac OS X which watches for Hewlett-Packard LaserJet 1000, 1005,
1018, 1020, P1005, P1006, P1007, P1008, and P1505 being plugged in. If so, then the firmware is down-
loaded to it.
NOTE: this is not needed by Linux, which has a proper hotplug mechanism.
Here is a /etc/rc.local start:
#BEGIN osx-hplj-hotplug from foo2zjs
killall osx-hplj-hotplug
osx-hplj-hotplug >/tmp/osx-hplj-hotplug 2>&1 &
#END osx-hplj-hotplug from foo2zjs
COMMAND LINE OPTIONS
−D level
Set Debug level[0].
FILES
/usr/share/foo2*/firmware/*
SEE ALSO
/etc/rc.local,
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
osx-hplj-hotplug 0.0 Sun Jun 20 04:33:46 2010 1
printer-profile(1) General Commands Manual printer-profile(1)
NAME
printer-profile − Profile using X-Rite ColorMunki and Argyll CMS
SYNOPSIS
printer-profile [options]manuf model [rgb|cmyk] [patches] [ink-limit]
DESCRIPTION
printer-profile prints a test chart, uses the ColorMunki instrument to scan it in, then computes an ICM pro-
file using the Argyll Color Management System.
Manuf is "sam". Model is "clp-300", "clp-315", "clp-325" or "clp-365".
Manuf is "hp". Model is "2600" or "cp1215".
Manuf is "km". Model is "2300" or "2530".
Manuf is "dell". Model is "1355".
"rgb" is the usual setting. "patches" is a multiple 196 per page.
Edit the script for additional models.
OPTIONS
−b 1|2 Bits per pixel (1)
−r XRESxYRES Resolution. Default=’’. ()
−P rem-print Remote print (64-bit) machine, or none (amd)
−S rem-scan Remote scan (ColorMunki) machine, or none (mac)
−D lvl Debug level
EXAMPLES
Profile the Samsung clp-315:
$printer-profile sam 315 rgb 196
BUGS
gs 8.64 and before has problems with 32-bit machines and color profile data. Don’tuse!
Youneed Argyll_V1.5.1 or later.
FILES
/usr/bin/printer-profile, /usr/share/foo2*/icm/testing.icm
SEE ALSO
firefox http://www.xritephoto.com/html/colormunkisplash.htm
firefox http://www.argyllcms.com/
firefox http://www.argyllcms.com/Argyll_V1.5.1_src.zip
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
printer-profile 0.0 Thu Apr 07 11:47:50 2016 1
qpdldecode(1) General Commands Manual qpdldecode(1)
NAME
qpdldecode − Decode a QPDL stream into human readable form.
SYNOPSIS
qpdldecode [options]<qpdl-file
DESCRIPTION
qpdldecode decodes a QPDL stream into human readable form. Only the JBIG compression format (0x13)
is handled.
An QPDL stream is the printer language used by the Samsung CLP-300, CLP-600, CLX-3160 and the
Xerox Phaser 6110 printers.
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an QPDL stream file created by foo2qpdl.
0: \033%-12345X@PJL DEFAULT SERVICEDATE=20070212
2c: @PJL SET USERNAME="Unknown"
49: @PJL SET JOBNAME="testpage.pdf"
6a: @PJL SET COLORMODE=COLOR
84: @PJL SET PAPERTYPE = NORMAL
a1: @PJL ENTER LANGUAGE = QPDL
bd: RECTYPE 0x0 len=17
res=600, copies=1, papersize=letter(0), w=2550, h=3300
papersource=auto, unk=0, duplex=0:0, unk=0,2, unk=268(0x10c)
ce: RECTYPE 0xc len=68(0x44)
stripe=0, WB=1248(0x4e0), H=128(0x80), plane=4, comp=0x13,
len=56(0x38)
magic=0x39abcdef, len=20(0x14), unk=0,0,0,0,0,0,
checksum=0x356
DL = 0, D = 0, P = 1, − = 0, XY = 9984 x 6400
L0 = 6400, MX = 0, MY = 0
Order = 0
Options = 72 LRLTWO TPBON
1stripes, 0 layers, 1 planes
112: RECTYPE 0xc len=68(0x44)
stripe=0, WB=1248(0x4e0), H=128(0x80), plane=1, comp=0x13,
len=56(0x38)
magic=0x39abcdef, len=20(0x14), unk=0,0,0,0,0,0,
checksum=0x356
DL = 0, D = 0, P = 1, − = 0, XY = 9984 x 6400
L0 = 6400, MX = 0, MY = 0
Order = 0
qpdldecode 0.0 Thu Apr 07 11:47:50 2016 1
qpdldecode(1) General Commands Manual qpdldecode(1)
Options = 72 LRLTWO TPBON
1stripes, 0 layers, 1 planes
156: RECTYPE 0xc len=68(0x44)
stripe=0, WB=1248(0x4e0), H=128(0x80), plane=2, comp=0x13,
len=56(0x38)
magic=0x39abcdef, len=20(0x14), unk=0,0,0,0,0,0,
checksum=0x356
DL = 0, D = 0, P = 1, − = 0, XY = 9984 x 6400
L0 = 6400, MX = 0, MY = 0
Order = 0
Options = 72 LRLTWO TPBON
1stripes, 0 layers, 1 planes
19a: RECTYPE 0xc len=68(0x44)
stripe=0, WB=1248(0x4e0), H=128(0x80), plane=3, comp=0x13,
len=56(0x38)
magic=0x39abcdef, len=20(0x14), unk=0,0,0,0,0,0,
checksum=0x356
DL = 0, D = 0, P = 1, − = 0, XY = 9984 x 6400
L0 = 6400, MX = 0, MY = 0
Order = 0
Options = 72 LRLTWO TPBON
1stripes, 0 layers, 1 planes
1de: RECTYPE 0xc len=77488(0x12eb0)
stripe=1, WB=1248(0x4e0), H=128(0x80), plane=1, comp=0x13,
len=77476(0x12ea4)
magic=0x39abcdef, len=77440(0x12e80), unk=2000000,0,0,0,0,0,
checksum=0x9326d7
1308e: RECTYPE 0xc len=77680(0x12f70)
stripe=1, WB=1248(0x4e0), H=128(0x80), plane=2, comp=0x13,
len=77668(0x12f64)
magic=0x39abcdef, len=77632(0x12f40), unk=2000000,0,0,0,0,0,
checksum=0x9367e5
25ffe: RECTYPE 0xc len=69232(0x10e70)
stripe=1, WB=1248(0x4e0), H=128(0x80), plane=3, comp=0x13,
len=69220(0x10e64)
magic=0x39abcdef, len=69184(0x10e40), unk=2000000,0,0,0,0,0,
checksum=0x83938a
36e6e: RECTYPE 0xc len=45616(0xb230)
stripe=1, WB=1248(0x4e0), H=128(0x80), plane=4, comp=0x13,
len=45604(0xb224)
magic=0x39abcdef, len=45568(0xb200), unk=2000000,0,0,0,0,0,
checksum=0x58015d
4209e: RECTYPE 0x1 len=3
copies=1
420a1: RECTYPE 0x9 len=0
420a2: \033%-12345X
FILES
/usr/bin/qpdldecode
SEE ALSO
foo2qpdl-wrapper(1), foo2qpdl(1)
qpdldecode 0.0 Thu Apr 07 11:47:50 2016 2
qpdldecode(1) General Commands Manual qpdldecode(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2qpdl.rkkda.com/
qpdldecode 0.0 Thu Apr 07 11:47:50 2016 3
slxdecode(1) General Commands Manual slxdecode(1)
NAME
slxdecode − Decode a SLX stream into human readable form.
SYNOPSIS
slxdecode [options]<slx-file
DESCRIPTION
slxdecode decodes a SLX stream into human readable form.
ASLX stream is the printer language used by some Lexmark printers, such as the C500.
More information on the Software Imaging K.K. SLX stream can be found at:
http://softwareimaging.com/products-services/sorcerer/index.asp
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−r basename
Basename of .jbg file for saving rawplanes
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an SLX file created by foo2slx.
$slxdecode < testpage.zm
SLX_MAGIC, 0x584c53a5 (SLX)
SLT_START_DOC, 12 items
SLI_PAGECOUNT, 4294967295 (0xffffffff)
SLI_DMDUPLEX, 0 (0x0)
SLI_DMCOLLATE, 0 (0x0)
SLI_0x3, 0 (0x0)
SLI_DISPLAY, 0 (0x0)
SLI_0x5, 0 (0x0)
SLI_0x6, 0 (0x0)
SLI_0x7, 1 (0x1)
SLI_0x8, 0 (0x0)
SLI_0x9, 0 (0x0)
SLI_COUNT, 1 (0x1)
SLI_DMCOLLATE, 0 (0x0)
SLT_START_PAGE, 16 items [Page 1]
SLI_DMPAPER, 6 (0x6)
SLI_CUSTOM_X, 0 (0x0)
SLI_CUSTOM_Y, 0 (0x0)
SLI_DMCOPIES, 1 (0x1)
SLI_DMDEFAULTSOURCE, 0 (0x0)
SLI_DMMEDIATYPE, 0 (0x0)
SLI_NBIE, 0 (0x0)
SLI_RESOLUTION_X, 600 (0x258)
slxdecode 0.0 Thu Apr 07 11:47:50 2016 1
slxdecode(1) General Commands Manual slxdecode(1)
SLI_RESOLUTION_Y, 600 (0x258)
SLI_OFFSET_X, 102 (0x66)
SLI_OFFSET_Y, 102 (0x66)
SLI_RASTER_X, 4896 (0x1320)
SLI_RASTER_Y, 6392 (0x18f8)
SLI_0x10d, 4896 (0x1320)
SLI_0x10e, 6392 (0x18f8)
SLI_0x10f, 1 (0x1)
SLT_JBIG_BIH, 0 items
Data: 20 bytes
DL = 0, D = 0, P = 1, − = 0, XY = 4896 x 6392
L0 = 128, MX = 0, MY = 0
Order = 0
Options = 8 TPBON
50 stripes, 0 layers, 1 planes
SLT_JBIG_BID, 0 items
Data: 116 bytes
SLT_END_JBIG, 0 items
SLT_END_PAGE, 0 items
SLT_END_DOC, 0 items
FILES
/usr/bin/slxdecode
SEE ALSO
foo2slx-wrapper(1), foo2slx(1), jbg2pbm(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2slx.rkkda.com/
slxdecode 0.0 Thu Apr 07 11:47:50 2016 2
usb_printerid(1) General Commands Manual usb_printerid(1)
NAME
usb_printerid − prints the ID of the printer on a USB port
SYNOPSIS
usb_printerid [options]/dev/usb/lpNNN
DESCRIPTION
usb_printerid prints the identification of the printer on a USB port using the ioctl control
LPIOC_GET_DEVICE_ID.
EXAMPLES
Print the USB info before and after downloading the firmware.
#usb_printerid /dev/usb/lp0
GET_DEVICE_ID string:
MFG:Hewlett-Packard;MDL:HP LaserJet 1020;CMD:ACL;CLS:PRINTER;\
DES:HP LaserJet 1020;
#cp/lib/firmware/hp/sihp1020.dl /dev/usb/lp0
#usb_printerid /dev/usb/lp0
GET_DEVICE_ID string:
MFG:Hewlett-Packard;MDL:HP LaserJet 1020;CMD:ACL;CLS:PRINTER;\
DES:HP LaserJet 1020;FWVER:20050309;
FILES
/usr/bin/usb_printerid, /lib/firmware/hp/*
SEE ALSO
arm2hpdl(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
usb_printerid 0.0 Thu Apr 07 11:47:50 2016 1
xqxdecode(1) General Commands Manual xqxdecode(1)
NAME
xqxdecode − Decode a XQX stream into human readable form.
SYNOPSIS
xqxdecode [options]<xqx-file
DESCRIPTION
xqxdecode decodes a XQX stream into human readable form.
An XQX stream is the printer language used by some HP LaserJet printers, such as the HP LaserJet M1005
(MFP).
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−h Print hexfile offsets.
−o Print file offsets.
−D level
Set Debug level[0].
EXAMPLES
Decode an XQX stream file created by foo2xqx.
$xqxdecode −h < testpage.xm
0: \033%-12345X@PJL JOB
12: @PJL SET JAMRECOVERY=OFF
2b: @PJL SET DENSITY=3
3e: @PJL SET ECONOMODE=OFF
55: @PJL SET RET=MEDIUM
69: @PJL INFO STATUS
7a: @PJL USTATUS DEVICE = ON
93: @PJL USTATUS JOB = ON
a9: @PJL USTATUS PAGE = ON
c0: @PJL USTATUS TIMED = 30
10c: @PJL SET JOBATTR="JobAttr4=20061118160242"
10c: XQX_MAGIC, 0x5851582c (,XQX)
110: XQX_START_DOC(1), 7 items
118: XQXI_0x80000000, 84 (0x54)
124: XQXI_0x10000005, 1(0x1)
130: XQXI_0x10000001, 0(0x0)
13c: XQXI_DMDUPLEX, 0(0x0)
148: XQXI_0x10000000, 0(0x0)
154: XQXI_0x10000003, 1(0x1)
160: XQXI_END, 3735928559 (0xdeadbeef)
16c: XQX_START_PAGE(3), 15 items [Page 1]
174: XQXI_0x80000000, 180 (0xb4)
180: XQXI_0x20000005, 1(0x1)
18c: XQXI_DMDEFAULTSOURCE, 7(0x7)
198: XQXI_DMMEDIATYPE, 1(0x1)
1a4: XQXI_0x20000007, 1(0x1)
1b0: XQXI_RESOLUTION_X, 600 (0x258)
xqxdecode 0.0 Thu Apr 07 11:47:50 2016 1
xqxdecode(1) General Commands Manual xqxdecode(1)
1bc: XQXI_RESOLUTION_Y, 600 (0x258)
1c8: XQXI_RASTER_X, 9856 (0x2680)
1d4: XQXI_RASTER_Y, 6432 (0x1920)
1e0: XQXI_VIDEO_BPP, 2(0x2)
1ec: XQXI_VIDEO_X, 4923 (0x133b)
1f8: XQXI_VIDEO_Y, 6432 (0x1920)
204: XQXI_ECONOMODE, 0(0x0)
210: XQXI_DMPAPER, 1(0x1)
21c: XQXI_END, 3735928559 (0xdeadbeef)
228: XQX_START_PLANE(5), 4 items
230: XQXI_0x80000000, 64 (0x40)
23c: XQXI_0x40000000, 0(0x0)
248: XQXI_BIH(0x40000002)
DL = 0, D = 0, P = 1, − = 0, XY = 9856 x 6432
L0 = 128, MX = 16, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
51 stripes, 0 layers, 1 planes
264: XQXI_END, 3735928559 (0xdeadbeef)
270: XQX_JBIG(7), 110 items
2e6: XQX_END_PLANE(6), 0 items
2ee: XQX_END_PAGE(4), 0 items
2f6: XQX_END_DOC(2), 0 items
Total size: 110 bytes
0: \033%-12345X@PJL EOJ
12: \033%-12345X
FILES
/usr/bin/xqxdecode
SEE ALSO
foo2xqx-wrapper(1), foo2xqx(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2xqx.rkkda.com/
xqxdecode 0.0 Thu Apr 07 11:47:50 2016 2
zjsdecode(1) General Commands Manual zjsdecode(1)
NAME
zjsdecode − Decode a ZjStream into human readable form.
SYNOPSIS
zjsdecode [options]<zjs-file
DESCRIPTION
zjsdecode decodes a ZjStream into human readable form.
AZjStream is the printer language used by some Minolta/QMS and HP printers, such as the 2300DL and
LJ-1000.
More information on Zenographics ZjStream can be found at:
http://ddk.zeno.com
COMMAND LINE OPTIONS
These are the options that can appear on the command line.
−d basename
Basename of .pbm file for saving decompressed planes.
−r basename
Basename of .jbg file for saving rawplanes
−h Print hexfile offsets.
−o Print file offsets.
−p Don’tdo4byte padding
−D level
Set Debug level[0].
EXAMPLES
Decode an ZjStream file created by foo2zjs.
$zjsdecode < testpage.zm
ZJT_START_DOC, 3 items
ZJI_PAGECOUNT, 0 (0x0)
ZJI_DMDUPLEX, 1 (0x1)
ZJI_QUANTITY, 1 (0x1)
ZJT_START_PAGE, 17 items
ZJI_0x17, 0 (0x0)
ZJI_0x16, 1 (0x1)
ZJI_VIDEO_X, 10200 (0x27d8)
ZJI_VIDEO_Y, 6600 (0x19c8)
ZJI_VIDEO_BPP, 1 (0x1)
ZJI_RASTER_X, 10200 (0x27d8)
ZJI_RASTER_Y, 6600 (0x19c8)
ZJI_OFFSET_X, 0 (0x0)
ZJI_OFFSET_Y, 0 (0x0)
ZJI_NBIE, 1 (0x1)
ZJI_RESOLUTION_X, 1200 (0x4b0)
ZJI_RESOLUTION_Y, 600 (0x258)
ZJI_DMDEFAULTSOURCE, 7 (0x7)
ZJI_DMCOPIES, 1 (0x1)
ZJI_DMPAPER, 1 (0x1)
ZJI_DMMEDIATYPE, 1 (0x1)
zjsdecode 0.0 Thu Apr 07 11:47:50 2016 1
zjsdecode(1) General Commands Manual zjsdecode(1)
ZJI_MINOLTA_PAGE_NUMBER, 1 (0x1)
ZJT_JBIG_BIH, 0 items
Data: 20 bytes
DL = 0, D = 0, P = 1, − = 0, XY = 10200 x 6600
L0 = 128, MX = 16, MY = 0
Order = 3ILEAVE SMID
Options = 92 LRLTWO TPDON TPBON DPON
52 stripes, 0 layers, 1 planes
ZJT_JBIG_BID, 0 items
Data: 65536 bytes
ZJT_JBIG_BID, 0 items
Data: 29120 bytes
ZJT_END_JBIG, 0 items
ZJT_END_PAGE, 0 items
ZJT_END_DOC, 0 items
FILES
/usr/bin/zjsdecode
SEE ALSO
foo2zjs-wrapper(1), foo2zjs(1), jbg2pbm(1)
AUTHOR
Rick Richardson <rick.richardson@comcast.net>
http://foo2zjs.rkkda.com/
zjsdecode 0.0 Thu Apr 07 11:47:50 2016 2
zjsdecode(1) General Commands Manual zjsdecode(1)
zjsdecode 0.0 Thu Apr 07 11:47:50 2016 3

Navigation menu
