The following options are available in this test mode:
Option
Description
Default
value
--mutex-num
Number of mutexes. The actual mutex to lock is
chosen randomly before each lock
4096
--mutex-locks
Number of mutex locks to acquire per each
request
50000
--mutex-loops
Number of iterations for an empty loop to
perform before acquiring the lock
10000
4.4. memory
This test mode can be used to benchmark sequential memory reads or writes.
Depending on command line options each thread can access either a global
or a local block for all memory operations.
The following options are available in this test mode:
Option
Description
Default
value
--memory-block-size
Size of memory block to use
1K
--memory-scope
Possible values: global, local. Specifies
whether each thread will use a globally
allocated memory block, or a local one.
global
--memory-total-size
Total size of data to transfer
100G
--memory-oper
Type of memory operations. Possible
values: read, write.
100G
4.5. fileio
This test mode can be used to produce various kinds of file I/O workloads.
At the prepare stage SysBench creates a specified number of files with a
specified total size, then at the run stage, each thread performs specified I/O
operations on this set of files.
When the global --validate option is used with the fileio test mode,
SysBench performs checksums validation on all data read from the disk. On
each write operation the block is filled with random values, then the
checksum is calculated and stored in the block along with the offset of this
block within a file. On each read operation the block is validated by
comparing the stored offset with the real offset, and the stored checksum
with the real calculated checksum.
The following I/O operations are supported:
seqwr sequential write
seqrewr
sequential rewrite
seqrd sequential read
rndrd random read
rndwr
random write
rndrw
combined random read/write
Also, the following file access modes can be specified, if the underlying
platform supports them:
Asynchronous I/O mode
At the moment only Linux AIO implementation is supported. When
running in asynchronous mode, SysBench queues a specified number
of I/O requests using Linux AIO API, then waits for at least one of
submitted requests to complete. After that a new series of I/O
requests is submitted.
Slow mmap() mode
In this mode SysBench will use mmap'ed I/O. However, a
separate mmap will be used for each I/O request due to the limitation of
32-bit architectures (we cannotmmap() the whole file, as its size migth
possibly exceed the maximum of 2 GB of the process address space).
Fast mmap() mode
On 64-bit architectures it is possible to mmap() the whole file into the
process address space, avoiding the limitation of 2 GB on 32-bit
platforms.
Using fdatasync() instead of fsync()
Additional flags to open(2)
SysBench can use additional flags to open(2), such
as O_SYNC, O_DSYNC and O_DIRECT.
Below is a list of test-specific option for the fileio mode:
Option
Description
--file-num
Number of files to create
--file-block
-size
Block size to use in all I/O operations
--file-total
-size
Total size of files
--file-test-
mode
Type of workload to produce. Possible values: seqwr,
seqrewr, seqrd, rndrd, rndwr, rndwr (see above)
--file-io-mo
de
I/O mode. Possible
values: sync, async, fastmmap, slowmmap (onl
y if supported by the platform, see above).
--file-async
-backlog
Number of asynchronous operations to queue per
thread (only for --file-io-mode=async, see above)
--file-extra
-flags
Additional flags to use with open(2)
--file-fsync
-freq
Do fsync() after this number of requests (0 -
don't use fsync())
--file-fsync
-all
Do fsync() after each write operation
--file-fsync
-end
Do fsync() at the end of the test
--file-fsync
-mode
Which method to use for synchronization. Possible
values: fsync, fdatasync (see above)
--file-merge
Merge at most this number of I/O requests if possible
d-requests
(0 - don't merge)
--file-rw-ra
tio
reads/writes ration for combined random read/write
test
Usage example:
$ sysbench --num-threads=16 --test=fileio --file-total-size=3G
--file-test-mode=rndrw prepare
$ sysbench --num-threads=16 --test=fileio --file-total-size=3G
--file-test-mode=rndrw run
$ sysbench --num-threads=16 --test=fileio --file-total-size=3G
--file-test-mode=rndrw cleanup
In the above example the first command creates 128 files with the total size
of 3 GB in the current directory, the second command runs the actual
benchmark and displays the results upon completion, and the third one
removes the files used for the test.
4.6. oltp
This test mode was written to benchmark a real database performance. At
the prepare stage the following table is created in the specified database
(sbtest by default):
CREATE TABLE `sbtest` (
`id` int(10) unsigned NOT NULL auto_increment,
`k` int(10) unsigned NOT NULL default '0',
`c` char(120) NOT NULL default '',
`pad` char(60) NOT NULL default '',
PRIMARY KEY (`id`),
KEY `k` (`k`));
Then this table is filled with a specified number of rows.
The following execution modes are available at the run stage:
Simple
In this mode each thread runs simple queries of the following form:
SELECT c FROM sbtest WHERE id=
N
