FMU Export of the Opal-RT Simulator
Release 1.0.0
LBNL - Building Technology and Urban Systems Division
Sep 27, 2017
ii
CHAPTER
ONE
INTRODUCTION
This user manual explains how to export the Python RT-LAB API of OPAL-RT as a Functional Mock-up Unit (FMU)
for model exchange or co-simulation using the Functional Mock-up Interface (FMI) standard version 1.0 or 2.0. The
RT-LAB API FMU allows to interface with the OPAL-RT real-time simulator through the FMI API.
Note: The RT-LAB API exported FMU has been tested on Windows with OPAL-RT/RT-Lab version 11.1.4.59.
1
FMU Export of the Opal-RT Simulator, Release 1.0.0
2 Chapter 1. Introduction
FMU Export of the Opal-RT Simulator, Release 1.0.0
4 Chapter 2. Requirements
CHAPTER
THREE
OPAL-RT FMU
This section explains how to export the RT-LAB API of OPAL-RT as an FMU.
To export the Python RT-LAB API,
1. edit the XML template SimulatorModeldescritpion.xml provided in the utilities of the distri-
bution of SimulatorToFMU
to specify the inputs, and outputs of the FMU.
2. run SimulatorToFMU.py to create the RT-LAB API FMU with
# Windows:
> python parser\\SimulatorToFMU.py -s opalrtfmu\\utilities\\simulator_
˓→wrapper.py
Note: To use the FMU, the path to the configuration file of OPAL-RT will be set in the FMU. This file has the
extension .llp and specifies the location of the OPAL-RT simulink grid model. Examples of such files can be
found in the xamples folders of RT-LAB. The path to the configuration file will be either set by the master algorithm
which imports the RT-LAB API FMU, or provided as -c argument for SimulatorToFMU.py. See the user guide of
SimulatorToFMU for a list of arguments of SimulatorToFMU.
To use the FMU, the content of the .binaries.zip and the .scripts.zip folders need to be added to the
PATH and the PYTHONPATH as described in the SimulatorToFMU user guide.
5
FMU Export of the Opal-RT Simulator, Release 1.0.0
6 Chapter 3. OPAL-RT FMU
CHAPTER
FOUR
HELP
The help section of SimulatorToFMU dicusses issues and solutions encountered when exporting or running the RT-
LAB API FMU.
7
FMU Export of the Opal-RT Simulator, Release 1.0.0
8 Chapter 4. Help
CHAPTER
FIVE
NOTATION
This chapter shows the formatting conventions used throughout the User Guide.
The command-line is an interactive session for issuing commands to the operating system. Examples include a DOS
prompt on Windows, a command shell on Linux, and a Terminal window on MacOS.
The User Guide represents a command window like this:
# This is a comment.
> (This is the command prompt, where you enter a command)
(If shown, this is sample output in response to the command)
Note that your system may use a different symbol than “>” as the command prompt (for example, “$”). Furthermore,
the prompt may include information such as the name of your system, or the name of the current subdirectory.
9
FMU Export of the Opal-RT Simulator, Release 1.0.0
10 Chapter 5. Notation
CHAPTER
SIX
GLOSSARY
Dymola Dymola, Dynamic Modeling Laboratory, is a modeling and simulation environment for the Modelica lan-
guage.
Functional Mock-up Interface The Functional Mock-up Interface (FMI) is the result of the Information Technology
for European Advancement (ITEA2) project MODELISAR. The FMI standard is a tool independent standard to
support both model exchange and co-simulation of dynamic models using a combination of XML-files, C-header
files, C-code or binaries.
Functional Mock-up Unit A simulation model or program which implements the FMI standard is called Functional
Mock-up Unit (FMU). An FMU comes along with a small set of C-functions (FMI functions) whose input
and return arguments are defined by the FMI standard. These C-functions can be provided in source and/or
binary form. The FMI functions are called by a simulator to create one or more instances of the FMU. The
functions are also used to run the FMUs, typically together with other models. An FMU may either require the
importing tool to perform numerical integration (model-exchange) or be self-integrating (co-simulation). An
FMU is distributed in the form of a zip-file that contains shared libraries, which contain the implementation of
the FMI functions and/or source code of the FMI functions, an XML-file, also called the model description file,
which contains the variable definitions as well as meta-information of the model,additional files such as tables,
images or documentation that might be relevant for the model.
Modelica Modelica is a non-proprietary, object-oriented, equation-based language to conveniently model complex
physical systems containing, e.g., mechanical, electrical, electronic, hydraulic, thermal, control, electric power
or process-oriented subcomponents.
MODELISAR MODELISAR is an ITEA 2 (Information Technology for European Advancement) European project
aiming to improve the design of systems and of embedded software in vehicles.
PyFMI PyFMI is a package for loading and interacting with Functional Mock-Up Units (FMUs), which are compiled
dynamic models compliant with the Functional Mock-Up Interface (FMI).
Python Python is a dynamic programming language that is used in a wide variety of application domains.
