Stratus Vortex Cooler Kits: Installation and and Kit Contents – 1st Edition – 03/28/2018

Stratus Vortex Cooler Kits

Stratus Vortex Enclosure Cooler Kits

AutomationDirect.com

Tech Support: 770-844-4200

3505 Hutchinson Road

Cumming, GA 30040

• Be sure to replace the 40-micron filter element in the

filter/regulator with the 5-micron replacement filter. The

5-micron filter is required to separate harmful foreign

matter from the air supply. This is required to maintain

a clean supply of air to the cooler, allowing virtually

maintenance-free operation.

• When installing components, it is important to locate

the solenoid valve upstream of the filter/regulator. This

assures there are no unnecessary flow restrictions to the

cooler and allows the semi-automatic drain feature of

the filter/regulator to work properly.

• All pneumatic components and the vortex cooler have

1/4” FNPT air inlets/outlets. To be sure there is ample

flow to the vortex cooler, all fittings and piping supplied

to the components must be of the same size or larger.

Smaller fittings, excessive turns (elbows, tees, etc), or use

of plastic tubing fittings will reduce flow and affect the

performance of the vortex cooler.

• Plastic tubing is not recommended as the fittings

associated with tubing and tubing inside diameter can

reduce airflow. Do not use “quick couplings” anywhere

in the system as they create flow restrictions and your

cooler will not perform correctly.

• Size your supply airline to the solenoid valve correctly.

Up to 10’ long runs will require a pipe size of at least

1/4” (3/8” for hoses). 10’ to 50’ long runs will require a

pipe size of 3/8” (1/2” for hoses). 50’ to 100’ long runs

will require a pipe size of 1/2” (5/8” for hoses).

• Maximum supply air pressure on this combination of

components is 145psi.

Important Installation Instructions

Vortex Cooler Kits

Kit Number Voltage Capacity

BTUH [W]

Air

Consumption

SCFM [SLPM]

Vortex Cooler

Number Solenoid Valve Thermostat Filter/Reg-

ulator

5-micron

Filter

TVK08-005-4X-120A 120VAC 500 [147] 8 [227] TV08-005-4X DVD-2BC2A-120A 011169-00 AFR-3233 AFE-31

TVK10-006-4X-120A 120VAC 600 [176] 10 [283] TV10-006-4X DVD-2BC2A-120A 011169-00 AFR-3233 AFE-31

TVK15-010-4X-120A 120VAC 1000 [293] 15 [425] TV15-010-4X DVD-2BC2A-120A 011169-00 AFR-3233 AFE-31

TVK25-018-4X-120A 120VAC 1800 [528] 25 [708] TV25-018-4X DVD-2BC2A-120A 011169-00 AFR-3233 AFE-31

TVK35-025-4X-120A 120VAC 2500 [732] 35 [991] TV35-025-4X DVD-2BC2A-120A 011169-00 AFR-3233 AFE-31

TVK08-005-4X-24D 24VDC 500 [147] 8 [227] TV08-005-4X DVD-2BC2A-24D 011169-00 AFR-3233 AFE-31

TVK10-006-4X-24D 24VDC 600 [176] 10 [283] TV10-006-4X DVD-2BC2A-24D 011169-00 AFR-3233 AFE-31

TVK15-010-4X-24D 24VDC 1000 [293] 15 [425] TV15-010-4X DVD-2BC2A-24D 011169-00 AFR-3233 AFE-31

TVK25-018-4X-24D 24VDC 1800 [528] 25 [708] TV25-018-4X DVD-2BC2A-24D 011169-00 AFR-3233 AFE-31

TVK35-025-4X-24D 24VDC 2500 [732] 35 [991] TV35-025-4X DVD-2BC2A-24D 011169-00 AFR-3233 AFE-31

Component Warranties 5-Year 1-Year 1-Year 2-Year 2-Year
